cadetheat.com Tel: 360-693-2505 PO Box 1675 Vancouver, WA 98668-1675
Benets You Can Depend On
SAVE THESE INSTRUCTIONS
Perfectoe Heater
Owner’s Manual
.375”
.952
3½”
8.9
14½”
36.83
18”
45.7
8¼”
21
8¼”
21
Grill Front
Wall Can To p
Wall Can Side
Grill Side
17”
43.18
3½”
8.89
Grill Front
17”
43.18
3½”
8.89
Grill Front
• Slim design with space saving comfort for:
Toekick areas in your kitchen and bath cabinets
Recreational vehicles
Stairwells
Fireplace Hearths
• Safe for you and your family
Peace of mind with automatic high
temperature shutoff feature
• Common sense components designed with you
in mind
1. NO sharp edges
2. Corrosion resistant
3. Rugged, reliable element for instant warmth
4. Easy to install
• Your Cadet heater has been thoroughly tested
and is guaranteed with a 2 year extended
warranty
(1)
Standard built-in thermostat is single pole and has no “OFF” position.
(2)
240 volt models can be used at 208 volts. Wattage equals 75% of 240v rated
wattage.
(3)
For installations above 7000 feet, highest wattage recommended is 750 watts.
Note: Optional built-in thermostat kits sold separately
TOOLS REQUIRED:
• Phillips Screwdriver
• Straight Screwdriver
• Wire Strippers
• Utility Knife
• (4) 1 1/2“ Wood Screws
• Insulated Wire Connectors
• (1) Strain Relief Connector
Perfectoe Models
Line
Voltage
Model w/o
Thermostat
Model w/
Thermostat
(1)
Watts Amps
240
(2)
UC072 750 3.13
UC102
(3)
1000 4.17
120
UC051 500 4.17
UC101
(3)
UC101T
(3)
1000 8.33
http://www.cadetheat.com/wall-heaters/perfectoe
Page 1
Perfectoe Models With Thermostat
*Wall Thermostat Not Required
Perfectoe Models Without Thermostat
*Wall Thermostat Required
Rating Label
Reset Button
Built-in Thermostat
