cadetheat.com Tel: 360-693-2505 PO Box 1675 Vancouver, WA 98668-1675
Benets You Can Depend On
SAVE THESE INSTRUCTIONS
Register Heater
Owner’s Guide
14”
35.6cm
4”
10.2cm
1”
2.5cm
2½”
6.4cm
7
3
/
8
”
18.7cm
3
3
/
8
”
8.6cm
2”
15.1cm
¾”
1.9cm
45°
1
3
/
8
”
3.5cm
5
7
/
8
”
14.9cm
1”
2.5cm
2”
5.1cm
12
5
/
8
”
32.1cm
Side Grill Front
Wall Can Side
Wall Can Bottom
1”
2.5cm
Register Models
Line
Voltage
Model w/o
Thermostat
Watts Amps
120
RM151 500/1000/1500 4.2/8.3/12.5
208
RM108 1000 4.8
RM158 1500 7.2
RM168 700/900/1600 3.4/4.3/7.7
RM208 2000 9.6
240
(1)
RM102 1000/750 4.2/3.6
RM162 700/900/1600 2.9/3.8/6.7
RM202 2000/1500 8.3/7.2
RM222 2250/1687 9.4/8.1
• Safe for you and your family
Peace of mind with automatic high temperature
shutoff feature
• Better air circulation and comfort with biggest,
most powerful blower
• Quiet, efcient and sophisticated—designed with
you in mind
1. NO sharp edges
2. Corrosion resistant
3. Installs quickly with one screw
4. Easy to install, compact wall can
5. Sleek appearance blends in naturally
• Your Cadet heater has been thoroughly tested
and is guaranteed with a 5 year extended
warranty
(1)
240 volt models can be used at 208 volts. Wattage equals 75% of 240v rated
wattage.
Note: A wall thermostat or built-in thermostat kit is
required for comfortable warmth and control
TOOLS REQUIRED:
• Phillips Screwdriver
• Straight Screwdriver
• Wire Strippers
• Utility Knife
• (4) 1 1/2“ Wood Screws
• Insulated Wire Connectors
• (1) Strain Relief Connector
http://www. cadetheat.com/products/wall-heaters/register-plus
Page 1
14”
35.6cm
4”
10.2cm
1”
2.5cm
2½”
6.4cm
7
3
/
8
”
18.7cm
3
3
/
8
”
8.6cm
2”
15.1cm
¾”
1.9cm
45°
1
3
/
8
”
3.5cm
5
7
/
8
”
14.9cm
1”
2.5cm
2”
5.1cm
12
5
/
8
”
32.1cm
Side Grill Front
Wall Can Side
Wall Can Bottom
1”
2.5cm
