www.cadetheat.com Tel: 360-693-2505 PO Box 1675 Vancouver, WA 98668-1675
Benets You Can Depend On
SAVE THESE INSTRUCTIONS
NLW Heater
Owner’s Guide
21”
53.34cm
16¾”
42.54cm
19
1
/8”
48.58cm
14
1
/8”
35.88cm
15”
38.1cm
4”
10.16cm
13
/16”
2.06
Side Grill Front
Wall Can Top
Wall Can Side
TOOLS REQUIRED:
• Phillips Screwdriver
• Straight Screwdriver
• Wire Strippers
• Utility Knife
• (4) 1 1/2“ Wood Screws
• Insulated Wire Connectors
• (1) Strain Relief Connector
(1)
Standard built-in thermostat is double pole and provides “OFF” position.
(2)
240 volt models can be used at 208 volts. Wattage equals 75% of 240v rated
wattage.
NLW Models
Line
Voltage
Model w/
Thermostat and
Fan Switch
(1)
Watts Amps
208
NLW208T 2000 9.62
NLW308T 3000 14.42
NLW408T 4000 19.23
240
(2)
NLW202T 2000/1500 8.33/7.21
NLW302T 3000/2250 12.5/10.82
NLW402T 4000/3000 16.67/14.42
NLW452T 4500/3375 18.75/16.23
• Quiet, comfortable warmth delivered with a large
fan that gently circulates air
• Safe for you and your family
Peace of mind with automatic high temperature
shutoff feature
• Improve air circulation and add comfort to your
home in off-season with a fan only switch
• Common sense components designed with you in
mind
1. NO sharp edges
2. Corrosion resistant
3. Easy to install
• Your Cadet heater has been thoroughly tested
and is guaranteed with a 2 year extended
warranty
New installation requires wall can (sold separately): Model Numbers NLWC
Recess Mount or NLWCS Surface Mount.
http://www.cadetheat.com/products/wall-heaters/NLW
Page 1
NLW with Thermostat
Wall Thermostat Not Required
Built-in Thermostat
Rating Label
Reset Button
