WINGMATE
BREATHALYSER
Specifications
Bright LCD
display
Intake Sensor
Wingmate Components
Sensor
Indication of B.A.C
Accuracy
Operation Temperature
Storage Temperature
Response time
Display
Power supply
Use mouthpiece
Dimensions (mm)
Weight
Calibration
Semiconductor type Alcohol sensor
0.00 to 0.40 %BAC
±0.01 %BAC at 0.05 %BAC
0˚C to 40˚C
0˚C to 50˚C
within 5 seconds
2-Digit LCD
Two 1.5V “AA” size alkaline batteries
No mouthpieces required.
103(height) X 40(width) X 18(thickness)
Approx
·
87g (Including Batteries)
The Wingmate can be used up to
200 tests or 6 months whichever
comes first.
Auto Power Off Battery CoverAA Batteries
Congratulations on buying your new Wingmate breathalyser.
Now you can be more aware of your alcohol level and make a
more informed decision after drinking.
We hope you enjoy owning your Wingmate breathalyser. If you
have any questions regarding the unit or want to speak with us
further, please visit andatech.com.au or call 1300 800 200
(between 9am and 5pm Monday to Friday).
The battery power is low. Please replace the
batteries.
The sensor has a problem and needs technical
support. Please contact us.
Please Note: Use Alkaline Batteries only.
Warnings Display
Press and hold the
On/Off button for 2
seconds until you hear
a“beep” and the LCD
display turns on.
1
7
Blow into the intake
sensor of the device. It
will produce a long beep
and then beep twice to
signal that it has enough
sample to provide a
reading. The LCD screen
will scroll with 000 while
it analyses the sample.
Your BAC reading
will be shown on the
screen.
4
0.0 0
WAIT %BAC
5
The BAC result will
be shown for 10
seconds and then
the unit will shut it
self off.
To take another test,
repeat from step 1.
0.0 7
WAIT %BAC
6
0.0 0
WAIT %BAC
3
0.0
WAIT
2
The LCD screen
will display "Wait"
while the device
is warming up.
It will beep twice
once it reaches 0
to indicate that it
is ready for a test.
Drink Driving Story
The Wingmate uses a fuel cell sensor to measure breath alcohol
levels. Depending upon the amount of alcohol registered by the
sensor after a period of time, it will require recalibition. Andatech
recommends the Wingmate is calibrated every 6 months or after
200 uses, whichever comes first.
®
unit
Wingmate
WINGMATE
Product Registration
