PQ0853 Page 1 / 2
3
-
TIER DOVE PAIR OUTDOOR
WATER FOUNTAIN
GSI-774
Read the assembly instructions carefully and follow the care instructions.
Save these instructions for future reference.
Select a smooth, level surface to place the fountain.
Note: When rst used, there may be air in the pump. It may take several minutes for trapped air to escape, allowing water to ow.
03/2020
NOTE: The water tubing is built into the fountain decorative
top. Take care when handling the water tube; detaching the
water tube from the decorative top will damage the fountain
and void the product warranty.
A Pedestal 1
B Large Tier 1
C Electric Submersible Pump 1
D Large Column 1
E Medium Tier 1
F Small Column 1
G Small Tier 1
H Decorative Top 1
ASSEMBLY
1. Place Large Tier (B) into Pedestal (A), twist large tier to lock onto pedestal.
2. Place Electric Submersible Pump (C) into Large Tier (B) and run the power cord through Large Tier (B) and Pedestal (A).
3. Run built-in tubing of Decorative Top (H) through Small Tier (G), twist decorative top to lock onto small tier.
4. Connect Small Tier (G) to Small Column (F), twist to lock tier to column and place the assembled top pieces onto
Medium Tier (E).
5. Place Medium Tier (E) onto Large Column (D), twist to lock tier onto column.
6. Carefully holding the assembled tiers, connect tubing from Decorative Top (H) to the Electric Submersible Pump (C),
place assembled pieces onto Large Tier (B).
7. Fill the fountain with enough water to keep the pump fully submerged during operation.
8. Plug the power cord into a properly grounded GFCI outlet.
Inspect packaging to ensure all
parts are accounted for before
disposing of packing materials.
Purchase Date: / / Order/Customer Reference Number:
Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell.
Replacement parts or products will be sent at our discretion within the 1-year warranty period. Proof of purchase, with
the date of purchase as well as photos of the merchandise defect, must be provided. Photos are used to determine
the cause of defects and for future quality control. Register your warranty at https://tiny.cc/SunnydazeWarranty
If you have any questions, comments or concerns, feel free to contact us by phone at 888-881-4668, by email:
customerser vice@nethealthshops.com, or via our contact us page at ht tps://tiny.cc/SunnydazeContact
PQ0853 Page 2 / 203/2020
WARNING!
Manufacturer and seller expressly disclaim any and all liability from personal injury, property damage
or loss, whether direct or indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
TROUBLESHOOTING
• Ensure that the pump is fully submerged and add water to the reservoir if necessary.
• Check the pump and tubing for obstructions.
• If water is not flowing within several moments of the fountain being plugged in, the pump may have trapped air
which can prevent water from circulating properly. Simply unplug the power supply for a few moments and plug it
back in.
• If water is not flowing evenly, it may be due to the porous nature of the slate material. Moisten the entire slate
surface beneath the downspout to even out water flow.
• Some splashing is normal. Check the flow control on the body of the pump; it may need to be adjusted to achieve
the desired flow rate.
• Check to make sure the power outlet is working; if in doubt about electrical connections, consult a certified electrician.
If you are still experiencing issues, please contact our customer service team through one of the methods mentioned
at the top of page 1. To expedite response time, please have the item number and order information available.
USE & CARE
• For outdoor use only.
• Check the water level frequently to ensure the pump remains fully submerged; never allow the pump to run dry as
it will burn out the motor.
• Only use water in this fountain. Distilled water will help prevent mineral buildup but is not required, avoid heavily
chlorinated tap water as it may damage the fountain or pump.
• Periodically change the water to reduce scale and buildup — clean the fountain and pump regularly for optimal
performance and appearance.
DO NOT use harmful additives such as bleach, chlorine, etc.
DO NOT use a pressure washer or abrasive materials to wash the fountain.
• Always shut off the power supply before cleaning and maintaining the fountain and the recirculating pump.
• Take care when handling the pump; only pick it up by the body of the pump, never by the power cord.
• During freezing temperatures, drain the fountain, disconnect the pump and store indoors; allowing ice to form may
crack the fountain and will damage the pump.
IMPORTANT INFORMATION
