ASSEMBLY
1. Place the bottom tier onto the pedestal, twist to lock them together.
2. Place the electric submersible pump in the bottom tier and run the
pump power cord through the built-in pipe and out the bottom of
the pedestal. Ensure the power cord is beneath the groove in the
bottom of the pedestal.
3. Place the column on the bottom tier, twist to lock in place
4. Place the middle tier on the column, twist to lock in place.
5. Run the built-in water tube from the topper through the top tier, twist
to lock the topper onto the top tier.
6. Run the water tube from Step 5 through the middle tier, twist to lock
the top assembly to the middle tier.
7. Connect the water tube to the electric submersible pump and install
the pump access cover.
8. Fill the tiers with enough water to fully submerge the pump.
NOTE:
Additional water will need to be added once the pump
circulates water into the upper tiers.
9. Plug the power cord into a properly grounded GFCI outlet.
Note: When rst used, there may be air in the pump. It may take several minutes for the air to escape and water begins to ow.
More water may need to be added to the bottom tier as the pump begins to circulate water through the fountain.
73688
Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell.
Replacement parts or products will be sent at our discretion within the 1-year warranty period. Proof of purchase, with
the date of purchase as well as photos of the merchandise defect, must be provided. Photos are used to determine
the cause of defects and for future quality control. Register your warranty at https://tiny.cc/SunnydazeWarranty
If you have any questions, comments or concerns, feel free to contact us by phone at 833-982-1977, by email:
customerservice@sunnydazedecor.com, or via our contact us page at https://tiny.cc/SunnydazeContact
Purchase Date: / / Order/Customer Reference Number:
Page 1 / 2 10/2020
3
-
TIER OUTDOOR
WATER FOUNTAIN
FC-73688
Read the assembly instructions carefully and follow the care instructions.
Keep these instructions for future reference.
Select a smooth, level surface to place the fountain. Assemble components on a soft,
Inspect packaging to ensure all
parts are accounted for before
disposing of packing materials.
Fountain Topper 1
Top Tier 1
Middle Tier 1
Column 1
Bottom Tier 1
Pedestal 1
Submersible Electric Pump 1
Pump Access Cover 1
NOTE:
The water tube is built into the
fountain topper. Gently and carefully
uncoil the water tube from inside the
topper. Take care when handling the
water tube; detaching the water tube
from the fountain will damage the
fountain and void the product warranty.
