Flat Window
Cable
(951177)
Connect 4G
SKU: 470103 MAP: $549.99
FEATURES
• Boosts 4G LTE & 3G signals for entire home, office,
cottage, or office
• Coverage area up to 5,000 sq. ft.
• For multiple devices and users
• Works on ALL phones with ALL carriers simultaneously
• Enhances talk, text, and high-speed 4G LTE internet
About
Coverage Area
Kit Includes
Specifications
The Connect 4G allows users to get better voice and data
signal with fewer dropped calls, improved voice quality, fast-
er uploads and downloads. Our 4G signal booster increases
cell signals up to 32x and enhances 4G LTE and 3G signals
for buildings up to 5,000 sq ft. Compatible with all US and
Canadian networks, it works on Verizon, AT&T, Sprint, T-Mo-
bile, US Cellular, Straight Talk and more.
Installation guide available for download and all parts are
included in the kit with trained support staff on call to assist.
All boosters come with a 2-year warranty.
MODEL NUMBER
FREQUENCIES
MAX GAIN
IMPEDANCE
POWER
CONNECTORS
DIMENSIONS
WEIGHT
470103
Band 12/17 700 MHz
Band 13 700 MHz
Band 5 850 MHz
Band 4 1700/2100 MHz
Band 2 1900 MHz
65 dB
75 Ohm
110-240 V AC, 50-60 Hz, 8 W
F-Female
1.25 x 4.25 x 6.5 in
0.465 lbs
Connect 4G Outside Directional
Antenna
(314475)
Inside Panel Antenna
(311155)
Power Supply
(859948)
30’ White Low Loss RG6
(75 Ohm) Coax Cable x2
(950630)
IF YOU HAVE
Stronger 5-Bar Outside Signal
Stronger 3 to 4-Bar Outside Signal
Stronger 3 to 4-Bar Outside Signal
No existing Outside Signal
boosted indoor signal
boosted indoor signal
boosted indoor signal
will not work
-89 AND LOWER
-90 dB
-100 dB
UP TO 5,000 sq. ft.
UP TO 3,500 sq. ft.
UP TO 1,000 sq. ft.
A signal booster likely
YOU MAY RECEIVE
FASTEST
NETWORK
SPEEDS
MULTI-USER
WIRELESS
BOOSTER
UP TO
+65 dB GAIN
UP TO 5,000 sq. ft.
COVERAGE
