Frigidaire FFSS2325TP0 refrigerator User Manual

TABLE OF CONTENTS

www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352

All about the

Use & Care

of your Refrigerator

Important Safety Instructions ......................2

Features at a Glance ...................................4

Installation ................................................5

Door Removal Instructions - Style 1 .............7

Door Removal Instructions - Style 2 .............9

Handle Installation ...................................11

Connecting Water Supply .......................... 12

Controls ...................................................14

A07198501 (January 2017)

Storage Features ...................................... 17

Automatic Ice & Water Dispenser ..............18

Changing the Filter ................................... 23

Normal Operating Sounds and Sights ......... 24

Care and Cleaning ....................................25

Before you Call .........................................27

Major Appliance Warranty .........................30

WARNING

WARNING indicates a potentially hazardous

situation which, if not avoided, could result

in death or serious injury.

IMPORTANT

IMPORTANT indicates installation, operation

or maintenance information which is

important but not hazard-related.

DANGER

DANGER indicates an imminently hazardous

situation which, if not avoided, will result in

death or serious injury.

Denitions

This is the safety alert symbol. It is used to

alert you to potential personal injury hazards.

Obey all safety messages that follow this

symbol to avoid possible injury or death.

Doors

 Handles are secure and tight

 Door seals completely to cabinet on all

sides

 Freezer door is level across the top

Leveling

 Refrigerator is level, side-to-side and

tilted ¼” (6mm) front-to-back

 Toe grille is properly attached to

refrigerator

 Cabinet is setting solid on all corners

Electrical Power

 House power turned on

 Refrigerator plugged in

Ice Maker

 House water supply connected to

refrigerator

 No water leaks present at all connections

- recheck in 24 hours

 Ice maker is turned ON

 Ice & water dispenser operates correctly

 Frontltermustbeushwithlter

housing (select models)

Final Checks

 Shipping material removed

 Fresh food and freezer temperatures set

 Crisper humidity controls set

 Registration card sent in

Installation Checklist

CAUTION

CAUTION indicates a potentially hazardous

situation which, if not avoided, may result in

minor or moderate injury.

IMPORTANT SAFETY INSTRUCTIONS

For your Safety

• DO NOT store or use gasoline, or other

ammableliquidsinthevicinityofthisor

any other appliance. Read product labels

forwarningsregardingammabilityand

other hazards.

• DO NOT operate the refrigerator in the

presence of explosive fumes.

• Avoid contact with any moving parts of

automatic ice maker.

• Remove all staples from the carton. Staples

can cause severe cuts, and also destroy

nishesiftheycomeincontactwithother

appliances or furniture.

WARNING

Please read all instructions before using this

refrigerator.

Child Safety

Destroy or recycle the carton, plastic bags, and

any exterior wrapping material immediately

after the refrigerator is unpacked. Children

should NEVER use these items to play.

Cartons covered with rugs, bedspreads, plastic

sheets or stretch wrap may become airtight

chambers,andcanquicklycausesuffocation.

Proper Disposal of your Refrigerator

or Freezer

Risk of child entrapment

Child entrapment and suffocation are not

problems of the past. Junked or abandoned

refrigerators or freezers are still dangerous

– even if they will sit for “just a few days”. If

you are getting rid of your old refrigerator or

IMPORTANT SAFETY INSTRUCTIONS

Grounding type wall receptacle

Do not, under

any circumstances,

cut, remove,

or bypass the

grounding prong.

Power cord with

3-prong gounded plug

Electrical information

• The refrigerator must be plugged into its

own dedicated 115 Volt, 60 Hz., 15 Amp,

AC only electrical outlet. The power cord

oftheapplianceisequippedwithathree-

prong grounding plug for your protection

against electrical shock hazards. It must be

plugged directly into a properly grounded

three prong receptacle. The receptacle must

be installed in accordance with local codes

andordinances.Consultaqualiedelectrician.

WARNING

These guidelines must be followed to ensure

that safety mechanisms in this refrigerator

will operate properly.

IMPORTANT

Pressing and holding the On/Off button for

three seconds, located on the temperature

control panel (Electronic controls), or

turning the Freezer and Fresh Food controls

to “0” (Mechanical controls) will disable your

refrigerator’s cooling system, but does not

disconnect the power to the LED lighting

and other electrical components. To turn off

power to your refrigerator you must unplug

the power cord from the electrical outlet.

CAUTION

To avoid personal injury or property damage,

handle tempered glass shelves carefully. Shelves

may break suddenly if nicked, scratched, or

exposed to sudden temperature change.

Avoid connecting refrigerator to a Ground

Fault Interrupter (GFI) circuit. Do not use an

extension cord or adapter plug.

• If the power cord is damaged, it should

be replaced by an authorized service

technician to prevent any risk.

• Never unplug the refrigerator by pulling on

thepowercord.Alwaysgriptheplugrmly,

and pull straight out from the receptacle to

prevent damaging the power cord.

• Unplug the refrigerator before cleaning

and before replacing a light bulb to avoid

electrical shock.

• Performance may be affected if the voltage

varies by 10% or more. Operating the

refrigeratorwithinsufcientpowercan

damage the compressor. Such damage is

not covered under your warranty.

• Do not plug the unit into an electrical outlet

controlled by a wall switch or pull cord to

prevent the refrigerator from being turned

off accidentally.

freezer, please follow the instructions below to

help prevent accidents.

Proper Disposal of Refrigerators/Freezers

We strongly encourage responsible appliance

recycling/disposal methods. Check with your

utility company or visit

www.energystar.gov/recycle for more

information on recycling your old refrigerator.

Before you throw away your old

refrigerator/freezer:

• Remove doors.

• Leave

shelves in

place so

children may

not easily

climb inside.

• Have

refrigerant

removed by

aqualied

service

technician.

IMPORTANT

CFC/HCFC Disposal

Your old refrigerator may have a cooling system

thatusedCFCsorHCFCs(chlorouorocarbons

orhydrochlorouorocarbons).CFCsandHCFCs

are believed to harm stratospheric ozone if

released to the atmosphere. Other refrigerants

may also cause harm to the environment if

released to the atmosphere.

If you are throwing away your old refrigerator,

make sure the refrigerant is removed for

properdisposalbyaqualiedtechnician.If

you intentionally release refrigerant, you may

besubjecttonesandimprisonmentunder

provisions of environmental legislation.

FEATURES AT A GLANCE

Features may vary according to model

CAUTION:

Do Not Remove

Magnet Behind

Dairy

Compartment

Dairy

Compartment

Glass Shelf

Door Bin

Crisper Pan

and Cover

Fixed

Door Bin

Toe Grille

Fixed

Door Bin

Ice

Container

Shelf

Water Filter

(Location varies by model)

Ice Cream Shelf

Ice Maker

Door Bins

Fixed

Door Bin

Slide Out Basket

Door Bin

Glass Shelf

Glass Shelves

LED Lights

IMPORTANT

Features not included with your refrigerator can be purchased at

www.frigidaire.com or by calling 1-800-944-9044.



NOTE

If your refrigerator is placed with the door

hinge side against a wall, you may have to

allow additional space so the door can be

opened wider.

INSTALLATION

CAUTION

Do Not install the refrigerator where the

temperature will drop below 55°F (13°C) or

rise above 110°F (43°C). The compressor

will not be able to maintain proper

temperatures inside the refrigerator.

Do Not block the toe grille on the lower front

ofyourrefrigerator.Sufcientaircirculation

is essential for the proper operation of your

refrigerator.

This Use & Care Guide provides general

operating instructions for your model. Use

the refrigerator only as instructed in this

Use & Care Guide. Before starting the

refrigerator, follow these important rst

steps.

Location

• Choose a place that is near a grounded

electrical outlet. Do Not use an extension

cord or an adapter plug.

• If possible, place the refrigerator out of

direct sunlight and away from the range,

dishwasher or other heat sources.

• Therefrigeratormustbeinstalledonaoor

that is level and strong enough to support

a fully loaded refrigerator.

• Consider water supply availability for

modelsequippedwithanautomaticice

maker. If you do not hook up water to

the refrigerator, remember to turn the ice

maker off.

Installation

Installation clearances

• Allow the following clearances for ease

of installation, proper air circulation, and

plumbing and electrical connections:

Sides & Top

inch

Back 1 inch

Toe Grille Installation and

Removal

To install toe grille

1 Open both doors. Slide left and right

sides of toe grille over lower hinges of

refrigerator.

2 Whilepushingtoegrillermlyagainst

cabinet, fasten bottom clips of toe grille to

cabinet.

3 Fasten top clips to cabinet.

4 Close the doors. Fasten right and left side

clips into groove of bottom hinge.

To remove toe grille

1 With both doors closed, unfasten right

and left side clips of toe grille from bottom

hinge groove.

2 Openbothdoors.Pressrmlyontopof

toe grille until top of toe grille pops off.

3 Pull toe grille outward toward your body

and off of lower hinges.

Installing Toe Grille

Removing Toe Grille

INSTALLATION



NOTE

The refrigerator doors are designed to shut

by themselves within a 20 degree opening.

Raise

Door Opening

Your refrigerator should be positioned to

allow easy access to a counter or table when

removing food. For best use of drawers and

freezer baskets, the refrigerator should be

in a position where both the refrigerator and

freezer doors can be fully opened.

Guidelines for nal positioning of

your refrigerator:

• All four corners of the cabinet must rest

rmlyontheoor.

• The cabinet should be level at the front

and rear.

• The sides should tilt ¼ inch (6 mm) from

front to back (to ensure that doors close

and seal properly).

• Doors should align with each other and be level.

All of these conditions can be

met by raising or lowering the

adjustable front rollers.

To level the cabinet using the front rollers:

1 Open both doors and remove the toe

grille (see “Toe Grille Installation and

Removal” in the “Installation” section).

2 Closethedoorsanduseaat-blade

screwdriver or

inch socket wrench to

raise or lower the front rollers.

3 Ensure both doors are bind-free with their

seals touching the cabinet on all four sides.

Set Screw

(some models)

Hinge

Flange

Open Door

7/16" Wrench and

3/32" Hex Key (some models)

Door Stop

Flange

6 Replacethetoegrillebyttingitinto

place (see “Toe Grille Installation and

Removal” in the “Installation” section).

Raise

Door

Raise

Door

To level the doors using the adjustable

lower hinge:

4 After leveling, verify door stop contacts

lower hinge and top of door does not

contact upper hinge through full movement

of door (from fully closed to fully open).

5 Reinstall set screw, locking the door height.



NOTE

Some models will not have a set screw. For

those models follow steps 2 through 4.

1 Before leveling either door, remove set

screw that locks door height into position.

(The door cannot be adjusted without set

screw removed).

2 If the refrigerator door is lower than the

freezer door, raise the refrigerator door by

turning the adjustment screw clockwise

using a

inch wrench. (See illustration.)

3 If the freezer door is lower than the

refrigerator door, raise the freezer door by

turning the adjustment screw clockwise

using a

inch wrench. (See illustration.)

DOOR REMOVAL INSTRUCTIONS - STYLE 1

Socket Wrench Set

Adjustable Wrench 3/8" Fixed Wrench

Tools Necessary:

AND

Phillips

Head

Getting through narrow spaces

Ifyourrefrigeratorwillnottthroughanentrancearea,youcanreduceitssizebyremovingthe

doors.Checkrstbymeasuringtheentrance.

1. Disconnect electrical supply.

2. Open both doors, then remove toe grille.

3. Close doors.

To Remove Refrigerator Door:

1. Remove top hinge cover screw on

refrigerator door and remove cover.

2. Trace around hinge with soft lead pencil.

This will make it easier to realign doors

when they are replaced.

3. Remove top hinge and lift refrigerator

door off bottom hinge pin. Set door aside.

4. Remove bottom hinge, if necessary.

5. Reverse this procedure to reinstall

refrigerator door.



NOTE

Before you begin, turn Freezer and Fresh

Food controls to “O” and remove electrical

power cord from wall outlet. Remove any

food from door shelves.

Top Hinge

Cover

Screw

Top

Hinge

Screw

Bottom

Hinge

Screw

Cover Screw

Top

Hinge

Cover

Top

Hinge

Screws

Door

Hinge

Assembly

Screws

CAUTION

Be sure doors are set aside in a secure

position where they cannot fall and cause

personal injury.

DOOR REMOVAL INSTRUCTIONS - STYLE 1

Door

Water

Line

Tubing

Screws

Hinge

Assembly

To Remove Freezer Door:

1. Disconnect water line coming from lower

hinge of freezer door at connection

located under front of freezer: Press outer

ringagainstfaceoftting,thenpullto

remove tube.

2. Remove top hinge cover screw on freezer

door and remove cover.

3. Disconnect wiring harness connector plug

attophinge:placeyourthumbsonat

sides of each connector and bend both

partsbackandforth,thenwithrmgrasp,

pull both pieces apart.

4. Trace around hinge with soft lead pencil.

This will make it easier to realign doors

when they are replaced.

5. Remove top hinge, allowing wiring harness

to pull through hinge and lift freezer door

off of bottom hinge pin. Lay door down

attoavoidkinkingwaterline.

6. Remove bottom hinge, if necessary.

7. Reverse this procedure to reinstall freezer

door.

When both doors have been reinstalled,

connect water line by inserting tube and push

untilmarktouchesfaceoftting,replacetoe

grille and plug in electrical power cord. Turn

both temperature controls to center position.

Adjust settings as necessary.

To Disconnect

1. Press outer ring against face of

fitting

2. Pull to

remove tube

Insert tube and push until mark

touches face of fitting

To Connect

DOOR REMOVAL INSTRUCTIONS - STYLE 2

To prepare for removing the

doors:

1 Make sure the electrical power cord is

unplugged from the wall outlet.

2 Open both doors and remove the toe

Socket

Wrench Set

Adjustable

Wrench

3/8" Fixed

Wrench

Top Hinge

Cover Front

Screw

Top

Hinge

Screw

Bottom

Hinge

Screw

Top Hinge

Cover Rear

Screw

Phillips™

Head

Tools Necessary:

To remove the refrigerator door:

1 Trace lightly around the door’s top hinge

with a pencil. This makes reinstallation

easier.

grille (as explained in the Installation

Instructions that came with your

appliance).

3 Remove any food from the door shelves.

4 Close the doors.

To remove the refrigerator top

hinge cover:

1 Remove the three screws from each cover

over the top door hinges.

2 Lift hinge cover straight up and off.

Rear Cover

Screw

Front Cover

Screws

Top

Hinge

Cover

Hinge

Screws

Top

Hinge

2 Remove the two screws from the top

hinge. Lift the door off of the bottom

hinge and set it aside.

DOOR REMOVAL INSTRUCTIONS - STYLE 2

Door

Hinge

Assembly

Closer

Hinge

Screws

CAUTION

Be sure doors are set aside in a secure position

where they cannot fall and cause personal injury.

Door

Hinge

Assembly

Screws

Water

Line

Tubing

Non-Adjusting Hinge (some models)

Closer

Hinge

Door

Water

Line

Tubing

Screws

Hinge

Assembly

Adjustable Hinge (some models)

Front

Cover Screws

Rear

Cover

Screw

Top Hinge

Cover

Hinge

Screws

Multi-Wire

Cable

Top

Hinge

To Disconnect

1. Press outer ring against face of

fitting

2. Pull to

remove tube

Insert tube and push until mark

touches face of fitting

To Connect

Adjustable Hinge

To reinstall the refrigerator door, reverse the

above steps.

To remove the freezer top hinge

cover:

1 Remove the two screws from each cover

over the top door hinges.

2 Lift hinge cover straight up and off.

To remove the freezer door:

1 Detach the multi-wire cable connector

located above the top hinge. Grasp both

sidesoftheconnectorrmlyandpullapart.

3 Detach the water tube from the connector

located below the freezer door. The

connector releases when you press its

outer sleeve inward.

4 Remove the screws from the top hinge

and pull the multi-wire cable through it.

Lift the door off of the bottom hinge.

5 Remove the two bottom hinge screws and

hinge if necessary.

6 Lay the door on its side to avoid damage

to the water tube extending from the

bottom hinge.

To reinstall the freezer door, reverse the above

steps.

3 Remove the two bottom hinge screws and

hinge if necessary.

2 Trace lightly around the hinge with a

pencil. This makes reinstallation easier.

HANDLE INSTALLATION

IMPORTANT

To ensure proper installation of handles,

please review these instructions and

illustrations thoroughly prior to installing the

handles.

CAUTION

Wear gloves and safety goggles and use

extreme CAUTION when installing these

handles. The rounded end of the handles

may be sharp (some models).

Ensure Handle Set Screws

are Facing Each Other

with Doors Closed

1 Remove handles from carton and any

other protective packaging.

2 Position freezer handle end caps over

upper and lower pre-installed shoulder

bolts (A) that are fastened into door,

ensuring the holes for the set screws are

facing towards the refrigerator door.

3 Whileholdinghandlermlyagainstdoor,

fasten upper and lower Allen set screws

(B) with supplied Allen wrench.

4 Repeat steps 2 and 3 to install refrigerator

handle. Ensure the holes for the set screws

are facing towards the freezer door.



NOTE

All set screws should be tightened and sub-

ush(Allensetscrewshouldbeseatedjust

below the surface of the end cap) of handle

end cap. The end caps should be drawn

tight to freezer and refrigerator doors with

no gaps.

Freezer Upper

End Cap

Refrigerator Upper

End Cap

Refrigerator Lower

End Cap

Freezer Lower

End Cap

WARNING

To avoid electric shock, which can cause

death or severe personal injury, disconnect

the refrigerator from electrical power before

connecting a water supply line to the

refrigerator.



NOTE

Check with your local building authority

for recommendations on water lines and

associated materials prior to installing your

new refrigerator. Depending on your local/

state building codes, Frigidaire recommends

for homes with existing valves its Smart

Choice

water line kit 5304490728 (with

a 6 ft. Stainless Steel Water Line) and for

homes without an existing valve, Frigidaire

recommends its Smart Choice

water line

kit 5304490717 (with a 20 ft. copper water

line with self-tapping saddle valve). Please

refer to www.frigidaire.com/store for more

information.

CAUTION

To Avoid Property Damage:

• Copper or Stainless Steel braided tubing

is recommended for the water supply

line. Water supply tubing made of ¼

inch plastic is not recommended to be

used. Plastic tubing greatly increases

the potential for water leaks, and the

manufacturer will not be responsible for

any damage if plastic tubing is used for

the supply line.

• DO NOT install water supply tubing in

areas where temperatures fall below

freezing.

• Chemicals from a malfunctioning softener

can damage the ice maker. If the ice

maker is connected to soft water, ensure

that the softener is maintained and

working properly.

IMPORTANT

Ensure that your water supply line

connections comply with all local plumbing

codes.

CONNECTING THE WATER SUPPLY

Before Installing The Water Supply Line, You

Will Need:

• BasicTools:adjustablewrench,at-blade

screwdriver, and Phillips

screwdriver

• Access to a household cold water line with

water pressure between 30 and 100 psi.

• A water supply line made of ¼ inch

(6.4mm) OD, copper or stainless steel

tubing. To determine the length of tubing

needed, measure the distance from the

ice maker inlet valve at the back of the

refrigerator to your cold water pipe. Then

add approximately 7 feet (2.1 meters),

so the refrigerator can be moved out for

cleaning (as shown).

To Connect Water Supply Line To Ice Maker

Inlet Valve

1 Disconnect refrigerator from electric power

source.

2 Place end of water supply line into sink or

bucket.TurnONwatersupplyandush

supply line until water is clear. Turn OFF

water supply at shutoff valve.

3 Remove plastic cap from water valve inlet

and discard cap.

4 If you use copper tubing - Slide brass

compression nut, then ferrule (sleeve)

onto water supply line. Push water supply

line into water valve inlet as far as it

will go (¼ inch/6.4 mm). Slide ferrule

(sleeve)intovalveinletandngertighten

compression nut onto valve. Tighten

another half turn with a wrench; DO NOT

over tighten. See Figure 1.

  Ifyouusebraidedexiblestainlesssteel

tubing - The nut is already assembled on

the tubing. Slide nut onto valve inlet and

ngertightennutontovalve.Tighten

another half turn with a wrench; DO NOT

over tighten. See Figure 2.

• A shutoff valve to connect the water supply

line to your household water system. DO

NOT use a self-piercing type shutoff valve.

• Donotre-usecompressionttingoruse

thread seal tape.

• A compression nut and ferrule (sleeve) for

connecting a copper water supply line to

the ice maker inlet valve.

IMPORTANT

After connecting the water supply, refer to

“How to Prime the Water Supply System”

for important information about priming an

empty water supply system.

Your refrigerator’s water supply system

includesseveraltubinglines,awaterlter,

a water valve, and a water tank. To ensure

that your water dispenser works properly,

thissystemmustbecompletelylled

withwaterwhenyourrefrigeratorisrst

connected to the household water supply

line.

Steel

Clamp

Braided

Flexible

Stainless

Steel

Water Line

Water Valve

Bracket

Valve Inlet

Water Valve

6 ft (1.8 Meters) Braided flexible

stainless steel water line from

household water supply.

Plastic Water Tubing

to Ice Maker

Fill Tube

(Include enough tubing in loop to allow

moving refrigerator out for cleaning.)

Figure 2

Figure 1

Plastic Water

Tubing to Ice

Maker Fill

Tube

Steel

Clamp

Brass

Compression

Nut

Ferrule

(Sleeve)

Copper

water line

Water Valve

Bracket

Valve Inlet

Water Valve

Copper water line

from household

water supply

(Include enough tubing in loop to allow

moving refrigerator out for cleaning.)

CONNECTING THE WATER SUPPLY

5 With steel clamp and screw, secure water

supply line (copper tubing only) to rear

panel of refrigerator as shown.

6 Coil excess water supply line (copper

tubing only), about 2½ turns, behind

refrigerator as shown and arrange coils so

they do not vibrate or wear against any

other surface.

7 Turn ON water supply at shutoff valve and

tighten any connections that leak.

8 Reconnect refrigerator to electrical power

source.

9 To turn ice maker on, lower wire signal

arm.



NOTE

When changing control settings, wait 24 hours for the temperature to stabilize before making

additional changes.

Allowing Cooling Time Before Use

To ensure safe food storage, allow your refrigerator to operate with the doors closed for at least

8 to 12 hours before placing food inside. During this cooling period, you do not need to adjust

the controls, which are preset at the factory.

Setting Cooling Temperatures

(Single Digit Display - Features may vary.)

TEMPERATURE ADJUSTMENT

To adjust the temperature to a higher or lower setting, press the Up (Cold) or Down (Colder)

buttonclosesttothedisplay.Thersttimeyoupressthebutton,thedisplayshowscurrent

setting you entered. Each press of the button after that changes the setting by one.

The display shows your new setting momentarily, then changes back to the current temperature.

CONTROLS

Your refrigerator comes with a state-of-the-art electronic digital control system. The system’s

control panel is located at the top of the fresh food compartment.

The two digital displays on the left half of the control panel indicate the current settings or

temperatures of your freezer and fresh food compartments. Should you desire to see what the

current accurate temperature is, place a separate thermometer inside the freezer or fresh food

compartment in the desired location.

Temperature Adjustment

If Fresh Food compartment

is too warm

Adjust Fresh Food control one degree colder by pressing Down

(Colder) button.

If Fresh Food compartment

is too cold

Adjust Fresh Food control one degree warmer by pressing the Up

(Cold) button.

If Freezer compartment is

too warm

Adjust Freezer control one degree colder by pressing Down

(Colder) button.

If Freezer compartment is

too cold

Adjust Freezer control one degree warmer by pressing the Up

(Cold) button.

ALARMS

Power Fail

In the event of a power failure, the ‘power fail’ alarm will sound three times. The ‘power fail’

alarm is an audible alarm only and does not display in the control panel.

High Temperature

Whenawarmrefrigeratorisrstpoweredon,the‘powerfail’alarmwillsoundandthecurrent

set points will be displayed for a few seconds. After 20 minutes the ‘high temp’ alarm will sound

if the freezer temperature is above 26°F or if the fresh food temperature is above 55°F (or both

are above).

If the unit is above the temperatures mentioned in the paragraph above, the affected

compartment temperature display (fresh food, freezer or both) on the control panel will display

‘HI’ and an alarm will sound. To disable the alarm press any key on the control panel. After

which the control panel will then show the display temperature. The unit will continue to

monitor the product temperatures for ‘high temp’ condition every 20 minutes. If the ‘high temp’

condition persists, the alarm will sound again and can be reset again. Contact a customer

service representative if the high temp alarm continues.

The audible portion of the alarm will silence itself once the product temperature is below 26°F

for the freezer temperature and 55°F for the fresh food temperature. The control panel will still

show ‘HI’ until it is acknowledged by the user by pressing any key on the control panel. After

which the control panel will then show the display temperature.

Door Ajar

If the door has been left open for an extended period of time an alarm will sound. (Some

models will have a ‘door ajar’ indicator on the control panel). The alarm will continue to sound

until the door is closed.

CONTROLS

IF TEMPERATURE DISPLAYS FLASH...

Ifeveryousee“OP”or“SH”ashing,itmayindicatethatthecontrolsystemhasdetecteda

performanceproblem.Callyourservicerepresentative,whocaninterprettheashingmessage.

To maintain temperatures, a fan circulates air in the refrigerator and freezer compartments. For

good circulation, do not block cold air vents with food items.

Numeric Display

Freezer Fresh Food

Warmest 1 1

Factory Setting 6 6

Coldest 9 9



NOTE

The advanced electronic control system in your refrigerator includes additional display modes

that service professionals can use to rapidly diagnose performance issues.

CONTROLS

Turning the Cooling system on and off

You can disable the cooling system in your refrigerator by pressing the On/Off button located

on the left side of the temperature control panel. To ensure that you do not accidentally

turn off the cooling system, the button does not work unless you press and hold it for three

seconds. Once you disable the cooling system, all refrigeration to the freezer and fresh food

compartments stops. To turn the cooling system back on, you must again press and hold the

On/Off button for three more seconds. Controls will display OF°

/OF°

when turned off.



NOTE

Pressing the On/Off button on the control panel disables your refrigerator’s cooling system

but does not disconnect power to lights and other electrical components. To turn off power to

your refrigerator you must unplug the power cord from the wall outlet.

Each time you make settings on the control panel, a single audible tone acknowledges your

input.

CAUTION

To avoid personal injury or property damage,

handle tempered glass shelves carefully.

Shelves may break suddenly if nicked,

scratched, or exposed to sudden temperature

change. Allow the glass shelves to stabilize

to room temperature before cleaning. Do not

wash in dishwasher.

STORAGE FEATURES

Glass Shelf

Glass Shelf Adjustment

Refrigerator shelves are easily adjusted to suit

individual needs. Before adjusting the shelves,

remove all food. Shelves are supported at the

back of the refrigerator.

To adjust shelves:

1 Lift front edge up.

2 Pull shelf out.

Replace the shelf by inserting the hooks at rear

of the shelf into the wall bracket. Lower the shelf

into the desired slots and lock into position.

Door storage

Door bins and shelves are provided for convenient

storageofjars,bottles,andcans.Frequentlyused

itemscanbequicklyselected.

Some models have door bins that can

accommodate gallon-sized plastic drink containers

and economy-sized jars and containers. Some

bins are adjustable for maximum storage capacity.

The dairy compartment, which is warmer than the

general food storage section, is intended for short

term storage of cheese, spreads, or butter.

Crisper Drawer

Crisper Humidity Control

Higher Humidity Lower Humidity



NOTE

Leafy vegetables keep best when stored with

the humidity control set on Higher Humidity,

or in a drawer without a Humidity Control.

This keeps incoming air to a minimum and

maintains maximum moisture content.

Crispers

Crispersallowyoutheexibilitytostoreany

manner of items including fruits, vegetables,

nuts, etc. Crispers do not feature humidity

controls.

Fresh Drawers with Humidity

Control (some models)

The fresh drawers, located under the bottom

refrigerator shelf, are designed for storing fruits,

vegetables, and other fresh produce. The fresh

drawers feature humidity control which allows you

to adjust the humidity within the drawer. This can

extend the life of fresh vegetables that keep best

in high humidity. Wash items in clear water and

remove excess water before placing them in the

crispers. Items with strong odors or high moisture

content should be wrapped before storing.

CUBE Press the CUBE Touch Pad to get cubed ice. A green light will appear

above the Touch Pad. Press glass against ICE dispensing paddle as far up

as possible to catch all ice.

CRUSH Press the CRUSH Touch Pad to get crushed ice. A green light will appear

above the Touch Pad. Press glass against ICE dispensing paddle as far up

as possible to catch all ice.

LIGHT Press the LIGHT Touch Pad to turn on dispenser light. Press again to turn

the light off. The light also turns on automatically when ice and/or water is

dispensed. Replace light bulb with an appliance bulb of the same wattage.

FILTER

STATUS

The FILTER STATUS indicator light above the Touch Pad will light up

eachtimethedispenserisused.Thefollowinglterlightindicationsare:

Green Thelterisstilloperatingwithinitsspeciedlifecycle.

Amber Thelterhasreachedapproximately80percentofitsusefullife.

Thisistherecommendedtimetopurchaseareplacementlter.

Red Thelteris100percentusedup.Changethelterassoonas

possible.

Aftertheltercartridgehasbeenchanged,pressandholdtheFILTER

RESET Touch Pad for 10-15 seconds.

NOTE:TheGreen,AmberandRedlightswillashwhenresetis

completed.

LOCK The Ice & Water Dispenser can be locked out to prevent unwanted use.

To Lock Out Press the LOCK Touch Pad for 3-5 seconds. A red light

will appear above the Touch Pad.

To Unlock Press the LOCK Touch Pad for 3-5 seconds until the

red light above the Touch Pad goes out.

WATER To operate the water dispenser, press a glass against the WATER

dispensing paddle. To stop dispensing water, pull the glass away from

the dispensing paddle. Dispensed water is not cold. For colder water, add

crushed ice or cubes before dispensing water. A drip tray located at the

base of the dispenser catches small spills and allows them to evaporate.

This drip tray is removable and dishwasher safe. Do not pour water and

excess ice in this area because there is no drain.

AUTOMATIC ICE & WATER DISPENSER



NOTE

Your refrigerator may have some or all of the features listed below. Become familiar with these

features and their use and care.

AUTOMATIC ICE & WATER DISPENSER

Crush Press the Crush Touch Pad to get crushed ice. A red indicator will appear above the

Touch Pad. Press glass against ICE dispensing paddle as far up as possible to catch

all ice.

Cube Press the Cube Touch Pad to get cubed ice. A red indicator will appear above the

Touch Pad. Press glass against ICE dispensing paddle as far up as possible to catch

all ice.

Light On Press the Light On Touch Pad to turn on dispenser light. A red indicator will appear

above the Touch Pad.

Light

Off

Press the Light Off Touch Pad to turn off dispenser light. A red indicator will appear

above the Touch Pad.

Water To operate the water dispenser, press a glass against the WATER dispensing

paddle. To stop dispensing water, pull the glass away from the dispensing paddle.

Dispensed water is not cold. For colder water, add crushed ice or cubes before

dispensing water. A drip tray located at the base of the dispenser catches small

spills and allows them to evaporate. This drip tray is removable and dishwasher

safe. Do not pour water and excess ice in this area because there is no drain.



NOTE

Your refrigerator may have some or all of the features listed below. Become familiar with these

features and their use and care.

IMPORTANT

Your ice maker is shipped from the factory

with the wire signal arm in the ON position.

To ensure proper function of your ice

maker, hook up water supply immediately

or turn ice maker OFF by lifting the wire

signal arm until it clicks and locks in the UP

position (side mounted). If the ice maker is

not turned off and the water supply is not

connected, the water valve will make a loud

chattering noise.

AUTOMATIC ICE & WATER DISPENSER

Priming the Water Supply System

Your refrigerator’s water supply system includes

severaltubinglines,anadvancedwaterlter,

a distribution valve bank, and a reserve tank

(some models) to ensure ample supply to

the ice and water dispenser at all times. This

systemneedstobecompletelylledwithwater

whenrstconnectedtoanexternalsupplyline.

To prime the water supply system:

1 Begin by pressing and holding a drinking

glass against the water dispenser paddle.

2 Keep the glass in this position until water

comes out of the dispenser. It may take

about 1½ minutes.

3 Continue dispensing water for about four

minutestoushthesystemandplumbing

connections of any impurities (stopping to

empty the glass as necessary).

Ice Maker Operation & Care

The ice maker, ice bin, and dispenser feeding

mechanism are located in the top of the freezer

compartment. After the refrigerator is installed

properly and has cooled for several hours, the

ice maker can produce ice within 24 hours. It

cancompletelyllanicebininabouttwodays.

Using the Ice Maker after

Installation

Beforemakingiceforthersttime,besure

to prime the water supply system. Air in new

plumbing lines can result in two or three empty

ice maker cycles. Furthermore, if the system

isnotushed,thersticecubesmaybe

discoloredorhaveanoddavor.



NOTE

The water dispenser has a built-in device that

shutsoffthewaterowafterthreeminutes

of continuous use. To reset this shutoff

device, simply release the dispenser paddle.

CAUTION

For proper dispenser operation, recommended

water supply pressure should fall between 30

psi and 100 psi. Excessive pressure may cause

waterltertomalfunction.

Ice Production: What to Expect

How Much Ice Will a Side Mounted Ice

Maker Produce in 24 Hours?

A side mounted ice maker will produce 4 to 4.5

pounds of ice every 24 hours, depending on

usage conditions. Ice is produced at a rate of 8

cubes every 75 to 90 minutes.

OFF

Wire

Signal Arm

Turning the SIDE MOUNTED Ice

Maker On and Off

To begin ice production, lower the wire signal

arm to the DOWN or ON position. The ice

maker turns off automatically when the ice

container becomes full. To stop the ice maker,

raise the wire signal arm until it clicks and

locks in the UP or OFF position.

IMPORTANT

Small ice cubes or ice chips jamming in the

icemakermaybeasignthatyourwaterlter

needs changing. If you have a side mounted

ice maker you may also experience hollow

cubes partially frozen cubes with water inside.

When these cubes are harvested, they break

open and spill water over the other ice cubes

in the ice container, forming a solid mass of

ice.Asthewaterlternearstheendofits

useful life and becomes clogged with particles,

less water is delivered to the ice maker during

eachcycle.Theicemakercan’tlleverycube

in the ice maker mold, leading to small cubes

or chips that can get caught between the ice

ejector blades and the stripper. Remember,

if your ice maker is jamming with small ice

cubes or it’s been six months or longer since

youlastchangedyourwaterlterreplace

thewaterlterwithanewone.Poorquality

householdwatermayrequiretheltertobe

changedmorefrequently.

CAUTION

Chemicals from a malfunctioning water

softener can damage the ice maker. If the

water supply to your refrigerator is softened,

be sure the softener is maintained to work

properly.

CAUTION

NEVER use an ice pick or similar sharp

instrument to break up the ice. This could

damage the ice storage bin and dispenser

mechanism.

AUTOMATIC ICE & WATER DISPENSER

Ice Maker/Dispenser Tips

• Ice cubes stored too long may develop

anoddavor.Emptytheicecontaineras

explained below.

• Occasionally shake the ice container to keep

ice separated.

• If your refrigerator is not connected to a

water supply or the water supply is turned

off, turn Off the ice maker.

• Ifyouneedalargequantityoficeatone

time, it is best to get cubes directly from the

ice container.

• The following sounds are normal when the

ice maker is operating:

- Motor running

- Ice dropping into ice container

- Water valve opening or closing

- Ice loosening from tray

- Running water

• When dispensing ice, you will hear a

snapping or clicking sound when the ice

chute opens and closes.

• Turn Off the ice maker when cleaning the

freezer and during vacations.

- If you turn Off the ice maker for a

long period of time, you should also

turn off the water supply valve.

Cleaning the Ice Maker

Clean the ice maker and ice bin at regular

intervals, particularly before you take a

vacation or move.

To clean the ice maker:

1 Turn Off the ice maker.

2 Remove the ice bin by lifting up and out.

3 Empty and carefully clean the ice bin with

mild detergent. Rinse with clear water. Do

not use harsh or abrasive cleaners.

4 Allow the ice bin to dry completely before

replacing in the freezer.

5 Remove ice chips and clean the ice bin

shelf and the freezer door chute.

6 Replace the ice bin. Turn On the ice maker

to resume ice production.

Remove and empty the ice

storage bin if:

• An extended power failure (one hour or

longer) causes ice cubes in the ice storage

bin to melt and freeze together, jamming

the dispenser mechanism.

• Youdonotusetheicedispenserfrequently.

Ice cubes will freeze together in the bin,

jamming the dispenser mechanism.

Remove the ice storage bin and shake to

loosen the cubes or clean as explained above.

IMPORTANT

When removing or replacing the ice bin,

DO NOT rotate the auger in the ice bin.

If the auger is accidentally rotated, you

must realign the auger by turning it in 90

degree turns (see below) until the ice bin

tsintoplacewiththedrivemechanism.If

the auger is not properly aligned when

replacing the ice bin, the refrigerator will

only dispense Crushed Ice. The freezer door

may also not close properly causing warm

air to leak into the freezer.

AUTOMATIC ICE & WATER DISPENSER

Auger

Locating the Filter

Yourrefrigeratorisequippedwithawaterltering

system.Thewaterltersystemltersalldispensed

drinking water, as well as the water used to

produce ice.

Water Filter

Thewaterlterislocatedatthetoprightsideof

the fresh food compartment.

Do not use with water that is microbiologically

unsafeorofunknownqualitywithoutadequate

disinfection before or after the system. Systems

certiedforcystreductionmaybeusedon

disinfectedwatersthatmaycontainlterablecysts.

Test & certication results:

• Rated Capacity - 200 gallons/757 liters for

PureSource Ultra

and PureSource 3

iceandwaterlter

• Ratedserviceow-.50gallonsperminute

• Operating Temp.: Min. 33°F, Max. 100°F

• Maximum Rated Pressure - 100 pounds per

squareinch

• Recommended Minimum Operating Pressure:

30poundspersquareinch

To replace your PureSource 3

water lter:

It is not necessary to turn the water supply off

tochangethelter.Bereadytowipeupany

smallamountsofwaterreleasedduringthelter

replacement.

1 Turn Off the ice maker.

2 Removethelterbypushingontheend/face

ofthelter.

3 Slidetheoldwaterltercartridgestraightout

of the housing and discard it.

4 Unpackagethenewltercartridge.Using

the alignment guide, slide it gently into the

lterhousinguntilitstopsagainstthesnap-in

connector at the back of the housing.

5 Push rmly until the cartridge snaps

into place (you should hear a click

as the cartridge engages the snap-in

connector).

6 Press a drinking glass against the water

dispenser while checking for any leaks at the

lterhousing.Anyspurtsandsputtersthat

occur as the system purges air out of the

dispenser system are normal.

7 Afterllingoneglassofwater,continue

ushingthesystemforaboutfour minutes.

8 Turn On the ice maker.

9 Press and hold the Water Filter button on

the Ice & Water Dispenser control panel for

three seconds. When the display changes from

“Red” to “Green,” the status has been reset.

Ordering Replacement Filters

Toorderyourreplacementlters,pleasevisitour

online store at www.frigidaire.com/store, by calling

toll-free at 877-808-4195, or by visiting the dealer

where you purchased your refrigerator. Frigidaire

recommendsthatyouorderextralterswhenyou

rstinstallyourrefrigerator,andthatyoureplace

yourltersatleastonceeverysixmonths.

Herearetheproductnumberstorequestwhen

ordering:

PureSource Ultra

Water Filter

Part# ULTRAWF

PureSource 3

Water Filter

Part #WF3CB

Replacing the Water Filter

Ingeneral,youshouldchangethewaterltereverysix

monthstoensurethehighestpossiblewaterquality.

Water Filter Status on the user interface prompts

youtoreplacethelterafterastandardamountof

water (200 gallons/757 liters for PureSource Ultra

and PureSource 3

)

hasowedthroughthesystem.

If your refrigerator has not been used for a period of

time(duringmovingforexample),changethelter

before reinstalling the refrigerator.

Filter Cartridge

The PureSource 3

ice and water

ltersystemistestedandcertiedto

NSF/ANSI Standards 42 and 53 for

thereductionofclaimsspeciedon

the performance data sheet.

More about your Advanced Water

Filter



NOTE

IfyourrefrigeratorisequippedwithaPureSource

waterlter,itcanbereplacedwitha

PureSource Ultra

waterlter.Replacingyour

PureSource 3

waterlterwithaPureSource

Ultra

waterlterremovesmorepotential

contaminants as tested by NSF. The contaminants

or other substances removed or reduced by this

waterlterarenotnecessarilyinallusers’water.

CHANGING THE FILTER



NOTE

IfyourrefrigeratorisequippedwithaPureSource

Ultra

waterlter,itmustbereplacedwith

PureSource Ultra

waterlterULTRAWF.

The PureSource Ultra

ice and

waterltersystemistestedand

certiedtoNSF/ANSIStandards42and

53forthereductionofclaimsspecied

on the performance data sheet.



NOTE

Energyefcientfoaminyourrefrigeratoris

not a sound insulator.

Understanding the Sounds you

may Hear

Yournew,high-efciencyrefrigeratormay

introduce unfamiliar sounds. These sounds

normally indicate your refrigerator is operating

correctly.Somesurfacesonoors,walls,and

kitchen cabinets may make these sounds more

noticeable.

Following is a list of major components in your

refrigerator and the sounds they can cause:

A Evaporator Refrigerant through the

evaporator may create a boiling or

gurgling sound.

B Evaporator fan You may hear air being

forced through the refrigerator by the

evaporator fan.

C Defrost heater During defrost cycles,

water dripping onto the defrost heater

may cause a hissing or sizzling sound.

After defrosting, a popping sound may

occur.

D Automatic ice maker When ice has

been produced, you will hear ice cubes

falling into the ice bin.

E Electronic control & automatic

defrost control These parts can produce

a snapping or clicking sound when turning

the cooling system on and off.

F Condenser fan You may hear air being

forced through the condenser.

G CompressorModern,high-efciency

compressors run much faster than in the

past. The compressor may have a high-

pitched hum or pulsating sound.

H Water valve Makes a buzzing sound each

timeitopenstolltheicemaker.

I Drain pan (not removable) You may hear

water dripping into the drain pan during

the defrost cycle.

J Condenser May create minimal sounds

from forced air.

K Motorized damper May produce a light

humming during operation.

L Ice chute When dispensing ice, you will

hear a snapping or clicking sound when

the solenoid opens and closes the ice

chute.



NOTE

During automatic defrost cycle, a red glow

in the back wall vents of your freezer

compartment is normal.

NORMAL OPERATING SOUNDS AND SIGHTS

IMPORTANT

If you store or move your refrigerator in freezing temperatures, be sure to completely drain

the water supply system. Failure to do so could result in water leaks when the refrigerator is

put back into service. Contact a service representative to perform this operation.

CAUTION

• Pull the refrigerator straight out to move it. Shifting it from side to side may damage

ooring.Becarefulnottomovetherefrigeratorbeyondtheplumbingconnections.

• Damp objects stick to cold metal surfaces. Do not touch refrigerated surfaces with wet or

damp hands.

• Sudden temperature changes can cause glass breakage.



NOTE

If you set your temperature controls to turn off cooling, power to lights and other electrical

components will continue until you unplug the power cord from the wall outlet.

Protecting your investment

Keeping your refrigerator clean maintains appearance and prevents odor build-up. Wipe up any

spills immediately and clean the freezer and fresh food compartments at least twice a year.

When cleaning, take the following precautions:

• Never use CHLORIDE or cleaners with bleach to clean stainless steel.

• Do not wash any removable parts in a dishwasher.

• Always unplug the electrical power cord from the wall outlet before cleaning.

• Remove adhesive labels by hand. Do not use razor blades or other sharp instruments which

can scratch the appliance surface.

• Do not remove the serial plate.

Donotuseabrasivecleanerssuchaswindowsprays,scouringcleansers,brushes,ammable

uids,cleaningwaxes,concentrateddetergents,bleachesorcleanserscontainingpetroleum

products on plastic parts, interior doors, gaskets or cabinet liners. Do not use paper towels,

metallic scouring pads, or other abrasive cleaning materials or strong alkaline solutions.

CARE & CLEANING

Care & Cleaning Tips

Part What To Use Tips and Precautions

Interior & Door

Liners

• Soap and water

• Baking soda and water

Use two tablespoons of baking soda in

onequartofwarmwater.Be sure to

wring excess water out of sponge

or cloth before cleaning around

controls, light bulb or any electri-

cal part.

Door Gaskets • Soap and water Wipe gaskets with a clean soft cloth.

Drawers & Bins • Soap and water Use a soft cloth to clean drawer run-

ners and tracks.

Glass Shelves • Soap and water

• Glass cleaner

• Mildliquidsprays

Allow glass to warm to room tempera-

ture before immersing in warm water.

Toe Grille • Soap and water

• Mildliquidsprays

• Vacuum attachment

Vacuum dust from front of toe grille.

Remove toe grille (see Installation

Instructions). Vacuum backside, wipe

with sudsy cloth or sponge. Rinse and

dry.

Exterior &

Handles

• Soap and water

• Non Abrasive Glass Cleaner

Do not use commercial household

cleaners containing ammonia, bleach

or alcohol to clean handles. Use a

soft cloth to clean smooth handles.

DO NOT use a dry cloth to clean

smooth doors.

Exterior &

Handles

(Stainless Steel

Models Only)

• Soap and water

• Stainless Steel Cleaners

Never use CHLORIDE or cleaners

with bleach to clean stainless steel.

Clean stainless steel front and handles

with non-abrasive soapy water and a

dishcloth. Rinse with clean water and a

soft cloth. Use a non-abrasive stainless

steel cleaner. These cleaners can be

purchased at most home improvement

or major department stores. Always

follow manufacturer’s instructions. Do

not use household cleaners containing

ammonia or bleach.

NOTE: Always clean, wipe and dry

with the grain to prevent scratch-

ing. Wash the rest of the cabinet with

warmwaterandmildliquiddetergent.

Rinse well, and wipe dry with a clean

soft cloth.

Replacing LED

Bulbs

• Unplug refrigerator

• Wear gloves

• Remove light cover

• Replace old LED bulb

• Replace light cover

• Plug in the refrigerator

CAUTION: Wear gloves when

replacing LED bulbs to avoid get-

ting cut.

Use same wattage when replacing LED

bulb.

CARE & CLEANING

BEFORE YOU CALL

Visit our web site at

www.frigidaire.com

1-800-944-9044 (United States)

1-800-265-8352 (Canada)

CONCERN CAUSE SOLUTION

AUTOMATIC ICE MAKER

Ice maker is

not making any

ice.

• Ice maker wire signal arm is

in the “up” or OFF position.

• Ice maker has small cube

caught in mechanism.

• Saddle valve on cold

water pipe is clogged

or restricted by foreign

material.

• Move wire signal arm to the “down” or ON

position (side mounted).

• Remove small cube from ice maker. The

iceandwaterltercartridgemaybe

clogged.Replaceltercartridge.

• Turn off household water line valve.

Remove valve. Ensure that valve is not

a self-piercing saddle valve. Clean valve.

Replace valve if necessary.

Ice maker is

not making

enough ice.

• Ice maker is producing

less ice than you expect.

• Check to see if water

dispenser is dispensing

slower than normal.

• Freezer control is set too

warm.

• Side mounted ice maker should produce 4

to4.5pounds(approximately4quarts)of

ice every 24 hours.

• Ifitis,replacetheiceandwaterlter

cartridge.

• Set freezer control to colder setting to im-

prove performance of the ice maker. Allow

24 hours for temperature to stabilize.

Ice maker will

not stop mak-

ing ice.

• Ice maker wire signal arm

is being held down by

some item in the freezer.

• Move item and release wire signal arm.

Remove any ice cubes that are frozen

together over the wire signal arm.

Ice cubes are

freezing to-

gether.

• Ice cubes are not being

usedfrequentlyenough.

• Ice cubes are hollow

(partially frozen cubes

with water inside).

• Freezer control is set too

warm.

• Remove ice container and discard ice from

container. Ice maker will produce fresh supply.

• Theiceandwaterltercartridgemaybe

clogged.Replaceltercartridge.

• Set freezer control to colder setting. Allow

24 hours for temperature to stabilize.

DISPENSER (Ice & Water)

Dispenser will

not dispense

ice.

• Dispenser lock out is

engaged.

• There is no ice in the bin

to be dispensed.

• The refrigerator doors are

not completely closed.

• Dispenser paddle has

been pressed too long

and the dispenser motor

has overheated.

• Press and hold control lock for three

seconds.

• See the “Ice maker is not making any ice”

section above.

• Be sure the refrigerator doors are com-

pletely closed.

• The motor overload protector will reset in

about three minutes and then ice can be

dispensed.

Ice dispenser is

jammed.

• Ice has melted and

frozen around auger

duetoinfrequentuse,

temperatureuctuations,

and/or power outages.

• Ice cubes are jammed

between ice maker and

back of ice container.

• Remove ice container, thaw, and empty

the contents. Clean container, wipe dry,

and replace in proper position. When new

ice is made, dispenser should operate.

• Remove ice cubes that are jamming the

dispenser.

BEFORE YOU CALL

CONCERN CAUSE SOLUTION

DISPENSER (Ice & Water) (Continued)

Dispenser will

not dispense

water.

• Dispenser lock out is

engaged.

• Waterlternotseated

properly.

• Waterlterisclogged.

• Household water line

valve is not open.

• Press and hold control lock for three

seconds.

• Removeandreinstallthewaterlter.Be

suretopushthelterrmlysothatyou

hear it lock solidly into position.

• Replaceltercartridge.Besuretoremove

protectivecapsandpushthelterrmlyso

that you hear it lock solidly into position.

• Open household water line valve. See CON-

CERN column AUTOMATIC ICE MAKER.

Water has an

odd taste and/

or odor.

• Water has not been dis-

pensed for an extended

period of time.

• Unit not properly con-

nected to cold water line.

• Draw and discard 10-12 glasses of water

to freshen the supply.

• Connect unit to cold water line that sup-

plies water to the kitchen faucet.

Water pressure

is extremely

low.

• Cut-off and cut-on pres-

sures are too low (well

systems only).

• Reverse osmosis system

is in regenerative phase.

• Have someone turn up the cut-off and

cut-on pressure on the water pump sys-

tem (well systems only).

• It is normal for a reverse osmosis system to be

below 20 psi during the regenerative phase.

Water not cold

enough.

• As warmer tap water goes

throughthelterand

enters the water tank the

chilled water is pushed

through to the dispenser.

Once the chilled water is

used up it will take several

hours to bring the freshly

replaced water to a cooler

temperature.

• Some models are

designed without a

water tank, these water

dispensing systms are not

designed to chill water.

• Add ice to cup or container before dis-

pensing water.

• Add ice to cup or container before dis-

pensing water

OPENING/CLOSING OF DOORS/DRAWERS

Door(s) will not

close.

• Door was closed too

hard, causing other door

to open slightly.

• Refrigerator is not level.

Itrocksontheoor

when moved slightly.

• Refrigerator is touching a

wall or cabinet.

• Close both doors gently.

• Ensureoorislevelandsolid,andcan

adequatelysupporttherefrigerator.Contacta

carpentertocorrectasaggingorslopingoor.

• Ensureoorislevelandsolid,andcan

adequatelysupporttherefrigerator.Contacta

carpentertocorrectasaggingorslopingoor.

Drawers are

difcult to

move.

• Food is touching shelf on

top of drawer.

• Track that drawers slide

on is dirty.

• Remove top layer of items in drawer.

• Ensure drawer is properly installed on

track.

• Clean drawer, rollers, and track. See Care

& Cleaning.

BEFORE YOU CALL

CONCERN CAUSE SOLUTION

RUNNING OF REFRIGERATOR

Compressor

does not run.

• Freezer control is set to

“OF” or “0”.

• Refrigerator is in defrost

cycle.

• Plug at electrical outlet

is disconnected.

• House fuse blown or

tripped circuit breaker.

• Power outage.

• Set freezer control.

• This is normal for a fully automatic defrost

refrigerator. The defrost cycle occurs peri-

odically, lasting about 30 minutes.

• Ensure plug is tightly pushed into outlet.

• Check/replace fuse with a 15 amp time-

delay fuse. Reset circuit breaker.

• Check house lights. Call local electric company.

Refrigerator

runs too much

or too long.

• Room or outside

weather is hot.

• Doors are opened too

frequentlyortoolong.

• Fresh Food/freezer door

may be slightly open.

• Freezer control is set

too cold.

• Fresh Food/freezer

gasket is dirty, worn,

cracked,orpoorlytted.

• Condenser is dirty.

• It’s normal for the refrigerator to work

longer under these conditions.

• Warm air entering the refrigerator causes

it to run more. Open doors less often.

• Ensure refrigerator is level. Keep food and con-

tains from blocking door. See PROBLEM column

OPENING/CLOSING OF DOORS/DRAWERS.

• Set Fresh Food control to warmer setting

until refrigerator temperature is satisfactory.

Allow 24 hours for temperature to stabilize.

• Clean or change gasket. Leaks in door

seal will cause refrigerator to run longer in

order to maintain desired temperatures.

• Clean condenser. See Care & Cleaning.

Compressor

goes off and on

frequently.

• Thermostat keeps the

refrigerator at a con-

stant temperature.

• This is normal. Refrigerator goes on and

off to keep temperature constant.

DIGITAL TEMPERATURE DISPLAY

Digital temper-

ature displays

are ashing.

• Electronic control system

has detected a perfor-

mance problem.

• Call your Frigidaire service representative,

who can interpret any messages or num-

bercodesashingonthedigitaldisplays.

WATER/MOISTURE/FROST INSIDE REFRIGERATOR

Moisture col-

lects on inside

of refrigerator

walls.

• Weather is hot and

humid.

• Door is slightly open.

• The rate of frost buildup and internal

sweating increases.

• See PROBLEM column OPENING/CLOSING

OF DOORS/DRAWERS.

Water collects

on bottom

side of drawer

cover.

• Vegetables contain and

give off moisture.

• It is not unusual to have moisture on the

bottom side of the cover.

• Move humidity control (some models) to

lower setting.

Water collects

in bottom of

drawer.

• Washed vegetables and

fruit drain while in the

drawer.

• Dry items before putting them in the

drawer. Water collecting in bottom of

drawer is normal.

WATER/MOISTURE/FROST OUTSIDE REFRIGERATOR

Moisture col-

lects on outside

of refrigerator

or between

doors.

• Weather is humid.

• Door is slightly open,

causing cold air from in-

side refrigerator to meet

warm air from outside.

• This is normal in humid weather. When hu-

midity is lower, the moisture should disappear.

• See PROBLEM column OPENING/CLOSING

OF DOORS/DRAWERS.

MAJOR APPLIANCE WARRANTY

Your appliance is covered by a one year limited warranty. For one year from your original date of

purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove

to be defective in materials or workmanship when such appliance is installed, used and maintained

in accordance with the provided instructions.

Exclusions

If You Need Service

This warranty does not cover the following:

1. Products with original serial numbers that have been removed, altered or cannot be readily determined.

2. Product that has been transferred from its original owner to another party or removed outside

the USA or Canada.

3. Rust on the interior or exterior of the unit.

4. Products purchased “as-is” are not covered by this warranty.

5. Food loss due to any refrigerator or freezer failures.

6. Products used in a commercial setting.

7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances

not in ordinary household use or used other than in accordance with the provided instructions.

8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.

9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards,

shelves, etc., which are not a part of the appliance when it is shipped from the factory.

10. Servicecallstorepairorreplaceappliancelightbulbs,airlters,waterlters,other

consumables, or knobs, handles, or other cosmetic parts.

11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry

trip charges, or mileage expense for service calls to remote areas, including the state of Alaska.

12. Damagestothenishofapplianceorhomeincurredduringinstallation,includingbutnot

limitedtooors,cabinets,walls,etc.

13. Damages caused by: services performed by unauthorized service companies; use of parts other than

genuine Electrolux parts or parts obtained from persons other than authorized service companies; or

externalcausessuchasabuse,misuse,inadequatepowersupply,accidents,res,oractsofGod.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES

CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT

REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES,

INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE

LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE

YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH

AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS

WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO

NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,

OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR

EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL

RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.

This warranty only applies in the USA and Canada. In the USA, your appliance is warranted

by Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In

Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person to

change or add to any obligations under this warranty. Obligations for service and parts under this

warranty must be performed by Electrolux or an authorized service company. Product features or

specicationsasdescribedorillustratedaresubjecttochangewithoutnotice.

Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty

periodshouldserviceberequired.Ifserviceisperformed,itisinyourbestinteresttoobtainand

keep all receipts. Service under this warranty must be obtained by contacting Electrolux at the

addresses or phone numbers below.

USA

1.800.944.9044

Frigidaire

10200 David Taylor Drive

Charlotte, NC 28262

Canada

1.800.265.8352

Electrolux Canada Corp.

5855 Terry Fox Way

Mississauga, Ontario, Canada

L5V 3E4

Frigidaire FFSS2325TP0 refrigerator

Product's Documents

User Manual

Specifications

Frigidaire FFSS2325TP0 Questions and Answers
