• OWNER’S MANUAL
Please read before using this equipment.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
• MODE D’EMPLOI
Veuillez lire avant d’utiliser cet appareil.
Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by registering your
product now at the following address: www.alpine-usa.com/registration.
You will be informed of product and software updates (if applicable), special promotions, news about Alpine.
Merci d’avoir acheté ce produit Alpine. Nous vous invitons à consacrer un moment à la protection de votre achat en
enregistrant votre produit dès maintenant à l’adresse suivante : www.alpine-usa.com/registration.
Vous serez tenu informé des mises à jour des produits et des logiciels (le cas échéant), des promotions spéciales et de
l’actualité d’Alpine.
Gracias por adquirir este producto Alpine. Con solo unos pocos pasos podrá proteger su producto, registrándolo a través
de la siguiente dirección: www.alpine-usa.com/registration.
Recibirá información sobre nuevos productos y software, promociones especiales y novedades sobre Alpine.
1500 Atlantic Blvd,
Auburn Hills, Michigan 48326, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
161-165 Princes Highway,
Hallam Victoria 3803, Australia
Phone 03-8787-1200
Ohmstrasse 4, 85716 Unterschleissheim, Germany
Phone: +49 (0) 89-32 42 640
For contact information on your respective country,
please visit www.alpine-europe.com.
The 9th Towers, Tower B, 24th Floor, Unit TNB01-03,
33/4 Rama 9 road, Huay Kwang, Bangkok, 10310, Thailand
Phone +66 (2) 090 9596
7-INCH AUDIO/VIDEO RECEIVER
iLX-407
Designed by ALPS ALPINE Japan
3-EN
English
CONTENTS
Operating Instructions
PRECAUTIONS
IMPORTANT INFORMATION ..........................................6
WARNING
Points to Observe for Safe Usage ...............................6
WARNING ...........................................................6
CAUTION.............................................................7
NOTICE ................................................................8
Getting Started
Location of Controls ..................................................... 10
Turning Power On or Off .............................................10
Adjusting the Volume .................................................. 10
Lowering Volume Quickly .......................................... 10
Touch Screen Operation ............................................. 11
Switching Sources .........................................................11
Selecting an Item in a List ..........................................11
About the HOME Screen .............................................12
Editing HOME screen .............................................. 12
About the Indicator Display ......................................13
Setup
Setup Operation ............................................................ 13
General Setup
Radio Setup ..................................................................... 14
Setting the TUNER (FM) Tone Quality
(Tuner Condition) .................................................15
Setting the TUNER (FM) Frequency Step .........15
Setting the Ballgame Mode..................................15
SiriusXM Setup ............................................................... 15
Setting the Parental Lock ......................................15
Signal Strength Information ................................16
AUX Setup ........................................................................ 16
Setting the AUX Select ........................................... 16
Setting the Input Signal .........................................16
Setting the Display Mode......................................16
Language Setup ............................................................16
Wallpaper Setup ............................................................ 17
Setting a Wallpaper using a default image .....17
Setting a Wallpaper using your image .............17
Screen/LED Customize Setup ...................................17
Setting the Brightness of the Backlighting
(Dimmer) ..................................................................17
Adjusting the Minimum Level of Backlight ....17
Adjusting the Dimmer of Button Lighting at
Night..........................................................................18
Date/Clock Setup ..........................................................18
Display Off Setting ........................................................18
About iLX-407 ................................................................. 18
Displaying the Product Information..................18
Displaying Warranty/Copyright Information
... 18
Initializing the System ............................................ 18
Installation Setup .......................................................... 19
Steering Wheel Position Setting .............................. 19
Mute Setting ...................................................................19
iDatalink Setting ............................................................ 19
Setting the Default Vehicle Screen ....................19
Setting the Parking Assist Enable .......................19
Setting the Maestro Module ................................ 19
Connection (Bluetooth) Setup
Displaying Bluetooth Information ..........................20
Pairing the Bluetooth Device .................................... 20
Setting the Bluetooth Device ..............................20
Deleting a Bluetooth Device from the list .......20
Apple CarPlay Setup .....................................................21
Camera Setup
Rear Camera Setup ....................................................... 21
Camera Input Setting .............................................21
Camera Signal Input Setting ................................ 21
Rear Camera Guide Settings ................................22
Camera Picture Quality Setup .............................22
Camera Interrupt Setting
(DISPLAY OFF Mode)............................................22
Front Camera Setup .....................................................23
Camera Input Setting .............................................23
Camera Signal Input Setting ................................ 23
Camera Picture Quality Setup .............................23
Sound Setup
Setting the Media Xpander (MX) ............................. 24
Equalizer Settings ..........................................................24
4-EN
Fader/Balance/Bass/Treble/Subwoofer
Settings..........................................................................24
Setting the Fader/Balance ....................................25
Adjusting the Bass/Treble ..................................... 25
Setting the Subwoofer ...........................................25
Graphic Equalizer Curve Settings (Graphic EQ)
...25
Time Correction Settings ............................................26
Crossover Settings (X-Over).......................................26
Volume Setup ................................................................. 27
Adjusting the Key Sound .......................................27
Adjusting the Source Volume .............................. 27
Setting the Volume for Android Auto™ ............ 27
Setting the Volume for Apple CarPlay ..............27
Adjusting the Volume for Phone ........................27
Turning Subwoofer ON/OFF ......................................27
Rear Speaker Setting ....................................................28
Defeat Setting.................................................................28
About the Crossover ....................................................28
About Time Correction ................................................29
Apple CarPlay (Optional)
Access to Apple CarPlay .............................................. 31
Android Auto (Optional)
What is Android Auto ..................................................31
Activate Android Auto .................................................31
Radio/HD Radio™/RBDS
Radio Basic Operation
Listening to the Radio
.................................................32
Presetting Stations Manually .................................... 33
Presetting Stations Automatically ...........................33
Tuning to Preset Station .............................................33
Receiving a Multicast (HD Radio™ Mode only) ...33
Forced Analog Mode....................................................33
Selecting the Receivable Program Type
(RBDS FM Radio Mode only) ..................................33
Using Ballgame Mode (HD Radio™ Mode only)
... 34
Displaying Radio Text (HD Radio™/
RBDS FM Radio mode only) ...................................34
About the Feature Logos ............................................ 34
USB Flash drive (Optional)
USB Audio
Playback
............................................................................35
Repeat Play ...................................................................... 35
Shuffle Play ...................................................................... 36
Searching for a Desired Song....................................36
USB Video
Fast-forwarding/Fast-reversing ................................ 37
Stopping Playback ........................................................ 37
Repeat Play ...................................................................... 37
Searching for a Desired file ........................................ 37
Setting the Brightness and Contrast ...................... 37
Displaying the Subtitle ................................................37
USB Photo
Playback ............................................................................38
Slide Show .......................................................................38
Setting a Wallpaper with a Photo ............................38
iPod mode on iPhone (Optional)
Playback ............................................................................39
Searching for a Music File ...........................................40
Repeat Play ...................................................................... 40
Shuffle Play ...................................................................... 40
SiriusXM Satellite Radio Operation
(Optional)
Receiving Channels with the SiriusXM Tuner ......41
Tuning Channels by Category .................................. 41
Changing the Display ..................................................42
Checking the SiriusXM Radio ID Number .............42
Storing Channel Presets ..............................................42
Tuning Channels using Presets ................................42
Search Function ............................................................. 42
Selecting the Channel Directly .................................42
Parental Lock Function ................................................43
HDMI Device (Optional)
HDMI Operation .............................................................44
Setting the Brightness and Contrast ...................... 44
Bluetooth Operation
Setup Before Using ....................................................... 45
About Bluetooth .......................................................45
About the Hands-free Phone ............................... 45
Before Using Bluetooth ..........................................45
Hands-free Phone Control
Answering a Call ............................................................46
Hanging up the Telephone ........................................46
Calling................................................................................ 46
Making a phone call using the Phone Menu
... 46
Using Voice Recognition function ...........................47
5-EN
Using Siri......................................................................47
Voice Dial Function ..................................................47
Phone Operation Screen ............................................48
Adjusting the Speech Volume ............................. 48
Changing the Voice Output..................................48
Muting the Microphone ........................................48
DTMF (Touch-Tone) Function ..............................48
Phone Book Function ..................................................48
Searching in the Phone Book ..............................48
Synchronizing the Phone Book ...........................48
Deleting the Phone Book Entries .......................49
Setting contacts as Favorites
(Shortcut Dialing) ......................................................49
Bluetooth Audio
Playback ............................................................................50
Repeat Play ...................................................................... 50
Shuffle Play ...................................................................... 50
Connecting a Bluetooth Device ...............................50
Disconnecting the Bluetooth Connection ......50
Switching the connecting Bluetooth Device
...50
Auxiliary Device (Optional)
Operating Auxiliary Devices (Optional) ................51
Setting the Brightness and Contrast ...................... 51
Camera Operation (Optional)
Rear Camera Operation ...............................................52
Displaying the Camera Image from
the HOME screen ..................................................52
Displaying the rear view video while
the car is in reverse ...............................................52
About the Rear Camera Guide ..................................52
Front Camera Operation ............................................. 54
Displaying the Camera Image from
the HOME screen ..................................................54
iDataLink Operation
Access to iDataLink Mode .......................................... 55
About Parking Sensor screen ...............................56
Factory Media Operation............................................56
Factory SiriusXM Operation .......................................57
Information
Product Software Update ...........................................57
About the Supported Formats ................................57
About MP3/WMA/AAC/FLAC/WAV .................... 57
In Case of Difficulty .......................................................59
If this Message Appears .............................................. 60
Specifications ..................................................................61
Installation and
Connections
WARNING ........................................................ 63
CAUTION.......................................................... 63
Precautions ..................................................... 63
Accessory List ................................................................64
Installation ....................................................................... 64
Caution concerning the installation
location.....................................................................64
Mounting the Microphone ................................... 64
Installation example using the Original
Mounting Bracket ................................................. 64
Connections .................................................................... 65
If an ACC power supply is not available ........... 68
System Example .............................................................69
LIMITED WARRANTY
6-EN
Operating Instructions
PRECAUTIONS
IMPORTANT INFORMATION
FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide more
reasonable protection against harmful interference in a
residential installation, and are more stringent than
“outdoor” requirements.
Operation is subjected to the following two conditions: (1)
This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, you are
encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult an experienced radio/TV technician.
WARNING
Points to Observe for Safe Usage
• Read this manual carefully before using this system
components. They contain instructions on how to use this
product in a safe and effective manner. Alpine cannot be
responsible for problems resulting from failure to observe
the instructions in this manual.
• This manual uses various pictorial displays to show you
how to use this product safely and to alert you to
potential dangers resulting from improper connections
and operation. Following are the meanings of these
pictorial displays. It is important to fully understand the
meanings of these pictorial displays in order to use this
manual and the system properly.
• This product may be used with software applications.
Please follow all usage instructions and warnings when
using this product at all times. Do not use this product or
any software application in a manner which will hinder
safe operation of your vehicle.
WARNING
• Operation of the system while driving is dangerous.
Users should stop vehicle before operating the
software.
• Road conditions and regulations take precedence
over information contained on the map display:
observe actual traffic restrictions and circumstances
while driving.
• This software is designed for use exclusively in the
unit. It cannot and may not be used in conjunction
with other hardware.
WARNING
This symbol means important instructions.
Failure to heed them can result in serious injury
or death.
INSTALL THE PRODUCT CORRECTLY SO THAT THE
DRIVER CANNOT WATCH TV/VIDEO UNLESS THE
VEHICLE IS STOPPED AND THE EMERGENCY BRAKE IS
APPLIED.
It is dangerous for the driver to watch TV/Video while
driving a vehicle. Installing this product incorrectly enables
the driver to watch TV/Video while driving. This may cause a
distraction, preventing the driver from looking ahead, thus
causing an accident. The driver or other people could be
severely injured.
DO NOT WATCH VIDEO WHILE DRIVING.
Watching the video may distract the driver from looking
ahead of the vehicle and cause an accident.
DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR
ATTENTION AWAY FROM SAFELY DRIVING YOUR
VEHICLE.
Any function that requires your prolonged attention should
only be performed after coming to a complete stop. Always
stop the vehicle in a safe location before performing these
functions. Failure to do so may result in an accident.
7-EN
KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL
HEAR OUTSIDE NOISES WHILE DRIVING.
Excessive volume levels that obscure sounds such as
emergency vehicle sirens or road warning signals (train
crossings, etc.) can be dangerous and may result in an
accident. LISTENING AT LOUD VOLUME LEVELS IN A CAR
MAY ALSO CAUSE HEARING DAMAGE.
MINIMIZE DISPLAY VIEWING WHILE DRIVING.
Viewing the display may distract the driver from looking
ahead of the vehicle and cause an accident.
DO NOT DISASSEMBLE OR ALTER.
Doing so may result in an accident, fire or electric shock.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so
may result in fire, etc.
KEEP SMALL OBJECTS SUCH AS SCREWS OUT OF THE
REACH OF CHILDREN.
Swallowing them may result in serious injury. If swallowed,
consult a physician immediately.
USE THE CORRECT AMPERE RATING WHEN REPLACING
FUSES.
Failure to do so may result in fire or electric shock.
DO NOT BLOCK VENTS OR RADIATOR PANELS.
Doing so may cause heat to build up inside and may result
in fire.
USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.
Use for other than its designed application may result in
fire, electric shock or other injury.
MAKE THE CORRECT CONNECTIONS.
Failure to make the proper connections may result in fire or
product damage.
BEFORE WIRING, DISCONNECT THE CABLE FROM THE
NEGATIVE BATTERY TERMINAL.
Failure to do so may result in electric shock or injury due to
electrical shorts.
DO NOT ALLOW CABLES TO BECOME ENTANGLED IN
SURROUNDING OBJECTS.
Arrange wiring and cables in compliance with the manual
to prevent obstructions when driving. Cables or wiring that
obstruct or hang up on places such as the steering wheel,
gear lever, brake pedals, etc. can be extremely hazardous.
DO NOT SPLICE INTO ELECTRICAL CABLES.
Never cut away cable insulation to supply power to other
equipment. Doing so will exceed the current carrying
capacity of the wire and result in fire or electric shock.
DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING
HOLES.
When drilling holes in the chassis for installation, take
precautions so as not to contact, damage or obstruct pipes,
fuel lines, tanks or electrical wiring. Failure to take such
precautions may result in fire.
DO NOT USE BOLTS OR NUTS IN THE BRAKE OR
STEERING SYSTEMS TO MAKE GROUND CONNECTIONS.
Bolts or nuts used for the brake or steering systems (or any
other safety-related system), or tanks should NEVER be used
for installations or ground connections. Using such parts
could disable control of the vehicle and cause fire etc.
DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER
VEHICLE OPERATION, SUCH AS THE STEERING WHEEL
OR GEARSHIFT.
Doing so may obstruct forward vision or hamper movement
etc. and results in serious accident.
CAUTION
This symbol means important instructions.
Failure to heed them can result in injury or
material property damage.
HALT USE IMMEDIATELY IF A PROBLEM APPEARS.
Failure to do so may cause personal injury or damage to the
product. Return it to your authorized Alpine dealer or the
nearest Alpine Service Center for repairing.
HAVE THE WIRING AND INSTALLATION DONE BY
EXPERTS.
The wiring and installation of this unit requires special
technical skill and experience. To ensure safety, always
contact the dealer where you purchased this product to
have the work done.
USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM
SECURELY.
Be sure to use only the specified accessory parts. Use of
other than designated parts may damage this unit
internally or may not securely install the unit in place. This
may cause parts to become loose resulting in hazards or
product failure.
ARRANGE THE WIRING SO IT IS NOT CRIMPED OR
PINCHED BY A SHARP METAL EDGE.
Route the cables and wiring away from moving parts (like
the seat rails) or sharp or pointed edges. This will prevent
crimping and damage to the wiring. If wiring passes
through a hole in metal, use a rubber grommet to prevent
the wire’s insulation from being cut by the metal edge of
the hole.
8-EN
DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE
OR DUST.
Avoid installing the unit in locations with high incidence of
moisture or dust. Moisture or dust that penetrates into this
unit may result in product failure.
NOTICE
Product Cleaning
Use a soft dry cloth for periodic cleaning of the product. For
more severe stains, please dampen the cloth with water
only. Anything else has the chance of dissolving the paint or
damaging the plastic.
Temperature
Be sure the temperature inside the vehicle is between
+45°C (+113°F) and 0°C (+32°F) before turning your unit on.
Maintenance
If you have problems, do not attempt to repair the unit
yourself. Return it to your Alpine dealer or the nearest
Alpine Service Station for servicing.
Protecting the USB connector
• Only an iPhone or USB flash drive can be connected to
the USB connector on this unit. Correct performance
using other USB products cannot be guaranteed.
• If the USB connector is used, be sure to use only the
supplied connector cable with the unit. A USB hub is not
supported.
• Depending on the connected USB flash drive, the unit
may not function or some functions may not be
performed.
• The audio file format that can be played back on the unit
is MP3/WMA/AAC/FLAC/WAV.
• Artist/song name, etc., can be displayed. Certain, special
characters may not be correctly displayed.
CAUTION
Alpine accepts no responsibility for lost data,
etc., even if data, etc., is lost while using this
product.
On Handling USB Flash drive
• This unit can control a memory storage device that
supports the USB Mass Storage Class (MSC) protocol.
Playable audio file formats are MP3, WMA, AAC, FLAC and
WAV.
• USB Flash drive function is not guaranteed. Use USB flash
drive according to the terms of agreement. Read the USB
flash drive Owner’s Manual thoroughly.
• Avoid usage or storage in the following locations:
Anywhere in the car exposed to direct sunlight or high
temperatures.
Anywhere the possibility of high humidity or corrosive
substances are present.
• Fix the USB flash drive in a location where driver
operation will not be hindered.
• USB Flash drive may not function correctly at high or low
temperature.
• Use only certified USB flash drive. Note that even certified
USB flash drive, may not function correctly depending on
its type or state.
• Depending on the settings of the USB flash drive type,
memory state or encoding software, the unit may not
play back or display properly.
• USB Flash drive may take time to start playback. If there is
a particular file other than audio in the USB flash drive, it
may take considerable time before the file is played back
or searched.
• The unit can play back “mp3,” “wma” or “m4a” file
extensions.
• Do not add the above extensions to a file other than
audio data. This non-audio data will not be recognized.
The resulting playback may contain noise that can
damage speakers and/or amplifiers.
• It is recommended to back up important data on a
personal computer.
• Do not remove the USB device while playback is in
progress. Change SOURCE to something other than USB,
then remove the USB device to prevent possible damage
to its memory.
9-EN
• Windows Media are trademarks, or registered trademarks
of Microsoft Corporation in the United States and/or
other countries.
• Apple, iPhone and Siri are trademarks of Apple Inc.,
registered in the U.S. and other countries. Apple CarPlay is
a trademark of Apple Inc.
• Use of the Made for Apple and Works with Apple badges
means that an accessory has been designed to connect
specifically to the Apple product(s) identified in the Made
for Apple badge and to work specifically with the
technology identified in the Works with Apple badge, and
has been certified by the developer to meet Apple
performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and
regulatory standards.
• Please note that the use of this accessory with an Apple
product may affect wireless performance.
• Use of the Apple CarPlay logo means that a vehicle user
interface meets Apple performance standards. Apple is
not responsible for the operation of this vehicle or its
compliance with safety and regulatory standards. Please
note that the use of this product with iPhone may affect
wireless performance.
• Sirius, XM and all related marks and logos are trademarks
of Sirius XM Radio Inc. All rights reserved.
• HD Radio Technology manufactured under license from
iBiquity Digital Corporation. U.S. and Foreign Patents. For
patents see http://dts.com/patents. HD Radio and the HD,
HD Radio, and “ARC” logos are registered trademarks or
trademarks of iBiquity Digital Corporation in the United
States and/or other countries.
• Google, Android, Google Play and Android Auto are
trademarks of Google LLC.
To use Android Auto on your car display, you’ll need an
Android Auto compatible vehicle or aftermarket stereo,
an Android phone running Android 6.0 or higher, and the
Android Auto app.
• The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing LLC in the
United States and other countries.
• The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth SIG, Inc. and any use
of such marks by ALPS ALPINE Co., LTD. is under license.
Other trademarks and trade names are those of their
respective owners.
• MPEG Layer-3 audio coding technology licensed from
Fraunhofer IIS and Thomson. Supply of this product only
conveys a license for private, non-commercial use and
does not convey a license nor imply any right to use this
product in any commercial (i.e. revenue-generation) real
time broadcasting (terrestrial, satellite, cable and/or any
other media), broadcasting/streaming via internet,
intranets and/or other networks or in other electronic
content distribution systems, such as pay-audio or
audio-on-demand applications. An independent license
for such use is required. For details, please visit
http://www.mp3licensing.com
Made for iPhone X, iPhone 8, iPhone 8 Plus, iPhone 7,
iPhone 7 Plus, iPhone SE, iPhone 6s, iPhone 6s Plus,
iPhone 6, iPhone 6 Plus, iPhone 5s
10-EN
Getting Started
Location of Controls
Dimmer Sensor
Senses the brightness of the car interior.
Remote Sensor
Point the remote control transmitter towards the remote
sensor within a range of 2 meters.
/ (DOWN/UP) button
Adjusts the volume.
(MUTE) button
Activates/deactivates MUTE mode.
button
Activate Siri function or voice recognition mode.
(HOME) button
Displays the HOME screen.
(Phone) button
Displays the Phone Menu screen.
Touch to start a conversation when a call is incoming.
About the button descriptions used in this Owner’s
Manual
The buttons found on the face of the unit are expressed
in bold (e.g.
(HOME)). The buttons found on the
touch-screen display are shown in bold within brackets,
[ ] (e.g. [OK]).
Turning Power On or Off
When the ignition key is turned to ACC or ON, the opening
screen will be automatically displayed.
1 Turn the ignition key to the ACC or ON
position.
The unit turns on.
• When the unit is used for the first time, the Radio
main screen is displayed.
• When turned on, the unit displays the last screen that
was displayed before the ignition key was turned off.
For example, if the unit is in radio mode when ignition
is turned off, it will remain in radio mode when
ignition is turned back on.
2 To turn the unit to off, turn the ignition key to
the OFF position.
• The unit is a precision device. Careful handling of the unit
should provide you with years of trouble-free operation.
• Some of this unit’s functions cannot be performed while the
vehicle is in motion. Be sure to stop your vehicle in a safe
location and apply the parking brake before attempting these
operations.
Adjusting the Volume
Adjust the volume by touching
/ .
Volume decreases/increases continuously by touching and
holding
/ .
Volume: 0 to 35
Lowering Volume Quickly
Audio Mute function instantly lowers the volume level to 0.
1 Touch the
(MUTE) button to activate MUTE
mode.
The audio level will be 0.
2 Touch the
(MUTE) button again to bring
the audio back to previous volume level.
11-EN
Touch Screen Operation
You can operate the unit by using the touch panel display.
• Be sure to touch the onscreen button lightly with the pad of
your finger to avoid scratching the display.
Touch operation
Touch a button or list item on the screen lightly.
• If you touch a button and there is no reaction, remove your
finger.
• Onscreen buttons that cannot be operated are dimmed.
Swipe operation
Move your finger lightly with a swipe.
Drag & Drop operation
Touch and hold the desired item, then drag it to its new
location by moving your finger, then release your finger to
place the item.
• Except for USB Photo mode, it is not possible to narrow the
screen with two fingers (pinch in) or spread the screen (pinch
out).
Switching Sources
1 Touch the
(HOME) button.
The HOME screen is displayed.
2 Touch a widget of your desired source.
• In the HOME screen, you can change the widget location on
the screen. For details, see “About the HOME Screen”
(
page 12).
Selecting an Item in a List
To scroll through a list, perform the following operations.
Touch the screen and slide your finger up and
down.
The screen will scroll along with your finger movement.
Returns to the previous screen. Depending on
the function, this button may cancel the
operations performed on the screen.
• After touching the screen, move your finger away from the
screen before dragging and that item will be selected.
12-EN
About the HOME Screen
In the HOME screen, select a widget to perform various
settings and operations of the function.
Touch the
(HOME) button.
The HOME screen is displayed.
• You can also display the HOME screen by touching
[
] at the top of the screen.
■
HOME screen example
HOME screen navigation
Swipe the HOME screen horizontally
with your finger to change the page.
Up to 3 pages exist.
Widget
Touch to activate the function.
• After selecting [Audio] widget, it is possible to switch the
mode to USB Audio mode, iPod mode for iPhone or Bluetooth
Audio mode.
Editing HOME screen
You cannot operate the Widgets editing screen while
driving.
Your vehicle must be parked with the ignition key in the
ACC or ON position. For details, see “To display the
Setup Menu screen” in “Setup Operation” (
page 13).
In the Widgets editing screen, you can change the audio
source order or set the display/hide settings.
1 Touch and hold the HOME screen for at least a
second.
The widgets editing screen is displayed.
HOME screen image
Additional candidate widgets
• The source icon displayed in the Widgets editing
screen is displayed only when usable setup and
conditions of each Audio source are fulfilled. For
details on setup and conditions of each audio source,
see “Switching Sources” (
page 11).
■
Adding a widget
Drag and drop a widget from the additional candidate
widgets area to the desired position of the HOME screen
image area.
• To show more candidate widgets, swipe horizontally.
• There are 3 sizes of widgets.
■
Changing the order of widget
Drag and drop the widget to the desired location.
■
Deleting a widget from the HOME screen
Drag and drop a widget from the HOME screen image
area to
.
• is displayed while touching a widget.
2 Touch the
(HOME) button.
The HOME screen is displayed.
13-EN
About the Indicator Display
The Indicator Bar at the top of the screen displays various
types of information, like the current time.
Recalls the HOME screen.
Displays the currently playing audio source.
Touch to return to the Audio source screen.
Indicates the current time.
You can switch between the 12 hour display and 24 hour
display options (
page 18).
Displays the SiriusXM signal strength when
connecting to SiriusXM Tuner. (If SiriusXM Tuner
is not connected, it is not displayed.)
Lights up when connected to a Bluetooth
compatible device. (Does not display when
connection is set to OFF.)
Setup
Setup Operation
To display the Setup Menu screen:
Your vehicle must be parked with the ignition key in the
ACC or ON position. To do this, follow the procedures
below.
1 Bring your vehicle to a complete stop at a safe
location. Engage the parking brake.
2 Release the parking brake. (For safety, release the
parking brake while depressing the foot brake
pedal).
3 Engage the parking brake again.
• For automatic transmission vehicles, place the
transmission lever in the Park position.
Now, the locking system for the Setup operation has
been released. Engaging the parking brake can
reactivate the Setup Menu, as long as the car’s ignition
has not been turned off. It is not necessary to repeat the
above procedure (1 through 3).
Each time the ignition is turned OFF, perform the above
procedure.
1 Touch the
(HOME) button.
The HOME screen is displayed.
[Settings] button
2 Touch [Settings].
The Settings menu screen is displayed.
14-EN
3 Touch the required setting genre on the
upper part of the Settings menu screen, and
then touch the setting item.
Setting genres:
General: See “General Setup” (
page 14).
Connection: See “Connection (Bluetooth) Setup”
(
page 20).
Camera: See “Camera Setup” (
page 21).
Sound: See “Sound Setup” (
page 24).
General Setup
[General] is selected on the Settings menu screen.
■
General Setup Menu screen
Setting items:
Radio (
page 14)
SiriusXM (
page 15)
AUX (
page 16)
Language (
page 16)
Wallpaper And Theme (
page 17)
Screen/LED Customize (
page 17)
Date/Clock (
page 18)
Display Off (
page 18)
About (
page 18)
Installation (
page 19)
Steering Wheel Position (
page 19)
Mute While Backing Up (page 17)
iDatalink (
page 19)
Radio Setup
[Radio] is selected on the General Setup Menu screen.
15-EN
Setting the TUNER (FM) Tone Quality
(Tuner Condition)
This unit can set your preferred tone quality for FM radio
source.
Setting item:
FM Tuner Setting
Setting contents:
Normal (Initial setting) / HiFi / Stable
Normal: Standard setting
HiFi: High-quality setting
Stable: Control noise
• Noise may be more noticeable when [HiFi] is set, depending
on the reception status. In this case, the [Normal] setting is
recommended.
Setting the TUNER (FM) Frequency
Step
During manual tuning, you can select the frequency step
for FM analog radio station searching.
Setting item:
FM Frequency Step
Setting contents:
100 kHz / 200 kHz (Initial setting)
Setting the Ballgame Mode
To receive live broadcast with HD Radio, set [Ballgame
Mode] to [On].
Setting item:
Ballgame Mode
Touch [
] (Off) or [ ] (On) of “Ballgame
Mode”.
SiriusXM Setup
[Sirius XM] is selected on the General Setup Menu screen.
Setting the Parental Lock
You can lock out channels with passcode protection.
Channels that are locked cannot be accessed without
entering the passcode. You can unlock a channel or change
the passcode using this menu option.
Setting item:
Parental Lock
1 Touch [Parental Lock].
A passcode input screen is displayed.
2 Touch the numeric keypad to input a 4-digit
passcode.
The initial default 4-digit passcode is set to 0000.
After entering the digit, it is displayed as “
”.
• Touch [
] to delete an entered number.
3 Touch [OK].
Setting the Lock status of individual channels
4 Touch [Locked Channels].
The channels list screen is displayed.
5 Touch [
] (Off) or [ ] (On) of the
channels list to set the Parent Lock.
Clearing the Lock of ALL the locked Channels
4 Touch [Clear All Locked Channels].
5 Touch [Yes] to clear the lock of all the locked
channels.
Touch [No] to cancel.
Changing the Lock Passcode
4 Touch [Edit Code].
The numeric keypad screen is displayed.
5 Use the keypad to enter the current (old)
4-digit passcode, and then touch [OK].
The initial passcode is set to “0000.”
• Touch [
] to delete an entered number.
6 Touch [OK] to confirm the entry.
7 Now use the keypad to enter the new 4-digit
passcode.
8 Touch [OK].
9 Use the keypad to enter the new 4-digit
passcode a second time to verify it, and then
touch [OK].
• Remember to keep a note of the passcode in a safe place in
case you forget the code.
16-EN
Signal Strength Information
While listening to a SiriusXM Channel, the Signal strength of
the current channel will be displayed.
Setting item:
Signal Indicator
This menu item displays the SiriusXM signal strength as
Excellent, Good, Weak or No Signal.
• If the Signal indicator reports Weak or No Signal and your
vehicle is parked outside with no obstructions to the southern
sky, then your SiriusXM antenna may not be properly
installed or may have become damaged.
AUX Setup
[AUX] is selected on the General Setup Menu screen.
■
Usable 3-pole mini AV plug
The unit accepts the following 3-pole mini AV plug pin-out:
Audio L (White)
Audio R (Red)
Ground
• Please check pin-out carefully before use of this product.
Depending on the cable, there may be no sound.
Setting the AUX Select
You can set up the connected AUX device.
Setting item:
AUX Select
Setting contents:
AUX (Initial setting) / Factory Media + Drive Recorder
• When “AUX” is set, audio will not be output from Factory
Media or Factory SiriusXM mode.
• When “Factory Media + Drive Recorder” is set, AUX In Audio
will be used by the Factory Media and Factory SiriusXM
mode. Only AUX In Video will be output in the AUX mode.
Audio will not be output.
Setting the Input Signal
The video input signal type can be chosen.
Setting item:
Input Signal
Setting contents:
NTSC (Initial setting) / PAL
Setting the Display Mode
You can switch the Display Mode of the video file to be
played.
Setting item:
Display Mode
Setting contents:
Full (Initial setting) / 4.3
Language Setup
[Language] is selected on the General Setup Menu screen.
The Setup menu, feedback information, etc. for this unit can
be changed to appear in the selected language.
Setting item:
Language
Setting contents:
English (Initial setting) / Deutsch / Français / Español /
Italiano / Português / Polski / Nederlands / Dansk /
Suomi / Norsk / Svenska / Slovenčina / Čeština / Magyar
/ Ελληνικά / Türkçe / русский /
/ / / Bahasa
Indonesia / Bahasa Melayu / Tiếng Việt / /
• The currently selected language is displayed.
17-EN
Wallpaper Setup
[Wallpaper And Theme] is selected on the General Setup
Menu screen.
You can change the wallpaper of the display screen from 4
different colored default images or your image.
Setting a Wallpaper using a default
Setting contents:
Amber / Blue / Green / Red
Touch the desired image, and then touch [Set
Wallpaper].
Setting a Wallpaper using your image
1 Touch [User Image].
The image selecting screen is displayed.
2 Select an image stored on the connected USB
Flash drive.
The selected image thumbnail is displayed.
If not using an image as a wallpaper, touch [Default
Image] to return to the previous screen without
selecting.
3 Touch [Crop].
4 Touch the area to be trimmed for a wallpaper.
If the image is 800 × 480 pixel, this step is not necessary.
5 Touch [Set Theme] to change the theme color.
6 Touch the desired color.
7 Touch [Set Wallpaper].
Screen/LED Customize Setup
[Screen/LED Customize] is selected on the General Setup
Menu screen.
Setting item:
Dimmer / Screen Dimmer Level / Key Illumination Level
Setting the Brightness of the
Backlighting (Dimmer)
Backlighting is provided by LEDs light built into the liquid
crystal panel. The illumination control adjusts the
brightness of the backlighting based on the car ambient
lighting for easier viewing.
Setting item:
Dimmer
Setting contents:
Off / On / Auto (Initial setting)
Off: Deactivate Auto Dimmer mode to keep
the background illumination of the
monitor bright.
On: Keep the background illumination of
the monitor dark.
Auto: Adjust the brightness of the background
illumination of the monitor
automatically to the brightness of the
car interior.
• When [On] is set, the setting is also applied for the button
lighting in “Adjusting the Dimmer of Button Lighting at Night”
(
page 17) and “Adjusting the Minimum Level of Backlight”
(
page 18).
Adjusting the Minimum Level of
Backlight
You can adjust the brightness of the backlight. This function
could be used, for instance, to change the screen brightness
while traveling at night.
Setting item:
Screen Dimmer Level
Setting contents:
-15 to 15 (Initial setting: 0)
• This setting is only available when “Dimmer” is set to [On] or
[Auto].
18-EN
Adjusting the Dimmer of Button
Lighting at Night
You can adjust the brightness of the button lighting at
night with the dimmer.
Setting item:
Key Illumination Level
Setting level:
-2 to 2 (Initial setting: 0)
• This setting is only available when “Dimmer” is set to [On] or
[Auto].
Date/Clock Setup
[Date/Clock] is selected on the General Setup Menu screen.
You can set the display type of the Date/Clock adjustment
and the clock display to 12-hours or 24-hours, depending
on your preference.
Setting item:
Date/Clock
Touch [
] or [ ] to adjust the day, month, year,
hour, minute and AM/PM.
• To change to 24-hour, set “24H” to [On] (
).
• To set the daylight saving time (Summer Time mode), set
“DST” to [On] (
).
Display Off Setting
When [Display Off] is selected on the General Setup Menu
screen, the display is turned Off.
Setting item:
Display Off
• To cancel Display Off mode, touch the screen or any button.
• Display Off mode is canceled when the power or ACC is
turned off.
• When the gear lever is shifted to the reverse (R) position and
the rear camera is connected, the rear camera image is
displayed.
• When a call is received on a Bluetooth-connected phone, the
incoming call screen is displayed.
• You can also activate Display Off mode directly by touching
the [Display Off] widget on the HOME screen.
About iLX-407
[About] is selected on the General Setup Menu screen.
[About] enables you to check the Serial No., Firmware
Version, Model Name, and to initialize various settings.
Displaying the Product Information
You can view the version information of this product. Make
note of this information and refer to it whenever you
contact Alpine Tech Support or an Alpine-authorized dealer.
Setting item:
Version Information
Setting contents:
Serial No. / SYSTEM version / Firmware Version
Displaying Warranty/Copyright
Information
Setting item:
Warranty/Copyright Information
Setting contents:
Open source licenses / Notice
Initializing the System
You can initialize all data, to restore the factory settings.
Remove the USB flash drive, etc. from the system before
operation.
1 Touch [Restore Factory Setting].
2 After the confirmation message appears,
touch [Yes].
The confirmation screen appears.
3 Touch [Confirm].
The system starts initialization.
• Do not turn on/off the power, change the ignition key position
or remove the screen panel until system restart is completed.
19-EN
Installation Setup
[Installation] is selected on the General Setup Menu
screen.
Vehicle Setup enables you to check the connection status of
Reverse Lead/Parking Brake Lead.
When selecting the item, the Installation check screen is
displayed.
Setting item:
Installation
Setting contents:
Reverse / Parking Brake
Steering Wheel Position Setting
[Steering Wheel Position] is selected on the General Setup
Menu screen.
Set this item when Apple CarPlay is used/Android
smartphone which installed Android Auto App is
connected.
This setting influences Apple CarPlay/Android Auto mode.
Setting item:
Steering Wheel Position
Setting contents:
Left (Initial setting) / Right
Mute Setting
[Mute While Backing Up] is selected on the General Setup
Menu screen.
You can set the sound will be muted automatically when
the gear lever is moved to the reverse (R) position.
Setting item:
Mute While Backing Up
Touch [
] (Off) or [ ] (On) of “Mute
While Backing Up”.
iDatalink Setting
[iDatalink] is selected on the General Setup Menu screen.
Setting the Default Vehicle Screen
You can set the Default Vehicle Screen displayed in
iDataLink mode.
Setting item:
Default Vehicle Screen
Setting contents:
Gauges / Climate / Parking Assist / Vehicle Info. / Last
Mode (Initial setting)
• Depending on the car, some setting contents or this setting
item may not be displayed.
Setting the Parking Assist Enable
You can set up the camera for Parking Assist.
Setting item:
Parking Assist Enable
Setting contents:
Off (Initial setting) / Primary Camera / Secondary Camera
Setting the Maestro Module
You can change the setting of the connected iDataLink
module.
Setting item:
Maestro Module
• This setting is only available when the iDataLink Maestro®
module (sold separately) is connected.
• Depending on the iDataLink module, the setting contents may
differ.
20-EN
Connection (Bluetooth)
Setup
[Connection] is selected on the Setup menu screen.
■
Connection Setup Menu screen
Setting items:
Bluetooth Information (page 20)
Set Bluetooth Device (
page 20)
Apple CarPlay (
page 21)
Displaying Bluetooth Information
[Bluetooth Information] is selected on the Connection
Setup Menu screen.
You can display the Bluetooth device name and device
address of this unit.
Setting item:
Bluetooth Information
Pairing the Bluetooth Device
[Set Bluetooth Device] is selected on the Connection
Setup Menu screen.
Search for Bluetooth compatible devices.
Setting item:
Set Bluetooth Device
1 Touch [Set Bluetooth Device].
The Bluetooth Setup screen is displayed.
• You can also display the Bluetooth Setup screen
directly by touching the [Bluetooth Settings] widget
on the HOME screen.
2 Select this unit on the Bluetooth device.
A message about the device to be registered is
displayed.
3 Touch [Yes].
The Bluetooth device is connected.
If you connecting to a smartphone, a message to
download the phonebook is displayed.
4 Touch [ ] (Audio) or/and [ ] (Hands-free)
of the device you want to connect from the
list.
Audio: Device is used as an Audio device.
Hands-free: Device is used as a Hands Free Device.
• You can register up to 5 Bluetooth compatible mobile
phones.
• You can connect 1 Blutooth Device to each of
Bluetooth Audio mode and Hands-free mode.
• The Bluetooth registration process differs depending on the
device version and SSP (Simple Secure Pairing). If a 4 or 6
character Passcode appears on this system, enter the Passcode
on the Bluetooth device.
• If a 6 character Passkey appears on this device, make sure the
same passkey is displayed on the Bluetooth compatible device
and touch [OK].
• If all 5 devices have been registered, you cannot register a 6th
device. To register another device, you need to delete one of
the other 5 devices first.
Setting the Bluetooth Device
Select one of 5 paired Bluetooth compatible devices that
you previously registered.
Touch [
] (Audio) or [ ] (Hands-free) of the
device you want to connect from the Paired
Device list.
• You can also change the connected device by touching the
device name.
Deleting a Bluetooth Device from the
list
You can delete the information of a previously connected
Bluetooth compatible device.
1 Touch [
] of the Bluetooth compatible
device to delete from the Paired Device list.
2 Touch [Yes].
• Touching [No] will cancel the setting.
Setting the Auto Connection
You can connect the last connected device automatically.
Set “Auto Connect” to [On] (
).
21-EN
Apple CarPlay Setup
[Apple CarPlay] is selected on the Connection Setup Menu
screen.
To use the Apple CarPlay (
page 31), set “Apple CarPlay” to
[On].
Setting item:
Apple CarPlay
Touch [
] (Off) or [ ] (On) of “Apple
CarPlay”.
Camera Setup
[Camera] is selected on the Setup Menu screen.
You can set up items related to the Camera.
■
Camera Setup Menu screen
Setting items:
Rear Camera (page 21)
Front Camera (
page 23)
Rear Camera Setup
[Rear Camera] is selected on the Camera Setup Menu
screen.
Camera Input Setting
[Camera Select] is selected on the Camera Setup Menu
screen.
Setting item:
Camera Select
Setting contents:
Off (Initial setting) / Rear
Off: No camera is connected.
Rear: Rear camera is connected.
Camera Signal Input Setting
[Camera Signal] is selected on the Camera Setup Menu
screen.
When the camera is connected, the video input signal type
can be chosen.
Further setting item:
Camera Signal
Setting contents:
NTSC (Initial setting)/PAL
22-EN
Rear Camera Guide Settings
[Parking Guide Adjust] is selected on the Camera Setup
Menu screen.
You can adjust the camera guide position.
Setting item:
Parking Guide Adjust
1 Touch [Parking Guide Adjust] on the Camera
Setup menu screen.
The camera guide adjustment screen is displayed.
2 Slide [ ] to adjust.
3 After the adjustment is completed, touch
[Save].
• Touching [Init.] clears adjustments and returns to the
setting before guide line alteration.
4 Touch [
] to complete the adjustment and
return to the previous screen.
Turning the Rear Camera Guide On/Off
When displaying the rear camera view on the screen, you
can set to hide or show the camera guide.
Setting item:
Guide On/Off
Setting contents:
Off / On
Adjusting the Caution Position
You can move the position of the displaying message on
the screen.
Setting item:
Caution
Camera Picture Quality Setup
[Visual Adjust] is selected on the Camera Setup Menu
screen.
You can adjust the picture quality for the primary and
secondary cameras.
Setting item:
Visual Adjust
Adjusting Brightness
Setting item:
Brightness
Setting contents:
-15 to 15 (Initial setting: 0)
• You can adjust the brightness between MIN (-15) and MAX
(+15).
Adjusting Color of Display
Setting item:
Color
Setting contents:
-15 to 15 (Initial setting: 0)
• You can adjust the color between MIN (-15) and MAX (+15).
Adjusting Display Contrast
Setting item:
Contrast
Setting contents:
-15 to 15 (Initial setting: 0)
• You can adjust the contrast between MIN (-15) and MAX
(+15).
Camera Interrupt Setting (DISPLAY
OFF Mode)
You can set whether to display the rear camera image when
the gear lever is moved to the reverse (R) position while the
unit is turned off.
Setting item:
Camera Interrupt (DISPLAYOFF Mode)
Touch [
] (Off) or [ ] (On) of “Camera
Interrupt (DISPLAYOFF Mode)”.
23-EN
Front Camera Setup
[FrontCamera] is selected on the Camera Setup Menu
screen.
Camera Input Setting
[Camera Select] is selected on the Camera Setup Menu
screen.
Setting item:
Camera Select
Setting contents:
Off (Initial setting) / Front
Off:
No camera is connected.
Front:
Front camera is connected.
Camera Signal Input Setting
[Camera Signal] is selected on the Camera Setup Menu
screen.
When the camera is connected, the video input signal type
can be chosen.
Further setting item:
Camera Signal
Setting contents:
NTSC (Initial setting)/PAL
Camera Picture Quality Setup
[Visual Adjust] is selected on the Camera Setup Menu
screen.
You can adjust the picture quality for the primary and
secondary cameras.
Setting item:
Visual Adjust
Adjusting Brightness
Setting item:
Brightness
Setting contents:
-15 to 15 (Initial setting: 0)
• You can adjust the brightness between MIN (-15) and MAX
(+15).
Adjusting Color of Display
Setting item:
Color
Setting contents:
-15 to 15 (Initial setting: 0)
• You can adjust the color between MIN (-15) and MAX (+15).
Adjusting Display Contrast
Setting item:
Contrast
Setting contents:
-15 to 15 (Initial setting: 0)
• You can adjust the contrast between MIN (-15) and MAX
(+15).
24-EN
Sound Setup
[Sound] is selected on the Settings menu screen.
You can set up items related to the sound quality.
■
Sound Setup Menu screen
Setting items:
Media Xpander (page 24)
EQ Presets (
page 24)
Fader/Balance/Base/Treble/SubW. (
page 24)
Graphic EQ (
page 25)
Time Correction (
page 26)
X-Over (
page 26)
Volume (
page 27)
Subwoofer (
page 27)
Rear Speaker (
page 28)
Defeat (
page 28)
Setting the Media Xpander (MX)
[Media Xpander] is selected on the Sound Setup Menu
screen.
Media Xpander (MX) makes vocals or instruments sound
distinct regardless of the music source. The SiriusXM, USB
Flash drive and iPod, will be able to reproduce the music
clearly even in cars with a lot of road noise.
Setting item:
Media Xpander
1 Touch the check box of [ALL MX].
2 Touch any of [Off] [Level 1] [Level 2] [Level 3].
• To cancel MX mode, set [Off] in step 1.
• MP3/WMA/AAC can have its own MX setting.
• When the Defeat setting is [On], you cannot perform the set
up.
• The MX setting can be performed only when a source is
currently selected.
Equalizer Settings
[EQ Presets] is selected on the Sound Setup Menu screen.
10 typical equalizer settings are preset at the factory for a
variety of musical source material.
Setting item:
EQ Presets
Setting contents:
FLAT (Initial setting) / POP / ROCK / CLASSICAL / JAZZ /
ELECTRONIC / HIP HOP / EASY LISTENING / COUNTRY /
NEWS
• Only one type can be set to On.
• When Equalizer Presets is set, the linked Graphic EQ settings
are also changed. We recommend storing Graphic EQ settings
in a Preset in advance.
• The Equalizer Presets setting can be configured when Defeat
is Off.
Fader/Balance/Bass/Treble/
Subwoofer Settings
[Fader/Balance/Bass/Treble/SubW.] is selected on the
Sound Setup Menu screen.
Setting item:
Fader/Balance/Bass/Treble/SubW.
Cancel
Sound setup finishes.
Fader/Balance Image area
25-EN
Setting the Fader/Balance
Touch the desired point within the image area, or touch
[F] (Front), [R] (Rear), [L] (Left) or [R] (Right).
Fader:
15 (F) to 15 (R)
Balance:
15 (L) to 15 (R)
• To reset to the initial setting (F/R: 0, L/R: 0), touch
[
].
Adjusting the Bass/Treble
Touch [
] or [ ] for each item to be adjusted.
Setting item:
Bass, Treble
Setting contents:
-10 to 10 (Initial setting: 0)
Setting the Subwoofer
Adjusting the Subwoofer Level
Setting item:
Sub W.Level
Setting contents:
0 (Initial setting) to 15
• This setting is only available when “Subwoofer” is set to [On]
(
page 27).
Setting the Subwoofer Phase
The subwoofer output phase is toggled Subwoofer Normal
(0°) or Subwoofer Reverse (180°).
Setting item:
Sub W.Phase
Setting contents:
0° (Initial setting), 180°
• This setting is only available when “Subwoofer” is set to [On]
(
page 27).
Graphic Equalizer Curve Settings
(Graphic EQ)
[Graphic EQ] is selected on the Sound Setup Menu screen.
You can modify the Equalizer settings to create a response
curve more appealing to your personal taste.
Setting item:
Graphic EQ
Setting contents:
-7 to 7
• This setting is only available when “Defeat” is set to [On]
(
page 28).
1 Touch [Graphic EQ] on the Sound Setup menu
screen.
2 Touch the band to be adjusted.
3 Touch [
] or [ ] to adjust the level of the
band.
• You can also adjust the level of the band by moving
the slider.
4 To adjust another band, repeat step 2 to 3,
and adjust all bands.
5 To store the adjusted setting value, touch and
hold [Preset 1], [Preset 2], or [Preset 3] for at
least 2 seconds.
• Settings exceeding the frequency of adjacent bands are not
available.
• While adjusting the Graphic EQ, you should consider the
frequency response of the connected speakers.
• When the Graphic EQ is adjusted, the Equalizer Presets are
overridden.
• When Equalizer Presets is set, the linked Graphic EQ settings
are also changed. We recommend storing Graphic EQ settings
in a Preset in advance.
• Touch [ Flat] to initialize all values.
Calling the Graphic EQ adjusted value
Touch [Preset 1], [Preset 2], or [Preset 3].
The setting stored in the Preset will be recalled.
26-EN
Time Correction Settings
[Time Correction] is selected on the Sound Setup Menu
screen.
Before performing the following procedures, see “About
Time Correction” (
page 29).
Correction mode
Setting item:
Time Correction
1 Touch [Time Correction] on the Sound Setup
menu screen.
2 Touch the Correction mode button, and then
select [ms], [cm] or [inch].
3 Touch [
] or [ ] for each speaker to adjust
the time or distance.
0.0 msec to 9.9 msec (0.1 msec/step)
0.0 cm (0.0 inch) to 336.6 cm (132.56 inch) (3.4 cm/step)
All speaker setting values are adjustable in the range of
20 ms or 680 cm.
4 To store the adjusted setting value, touch and
hold [Preset 1], [Preset 2], or [Preset 3] for at
least 2 seconds.
• Touch [ Flat] to set all values to 0.0.
• If the Rear Speaker setting is Off, the Rear Speaker setting
cannot be edited (
page 28).
• If the Subwoofer setting is Off, the Subwoofer setting cannot be
edited (
page 27).
Calling the Time Correction Value
Calling the pre-set time correction value.
Touch [Preset 1], [Preset 2], or [Preset 3] on the time
correction screen.
The setting stored in the Preset will be recalled.
Crossover Settings (X-Over)
[X-Over] is selected on the Sound Setup Menu screen.
Before performing the following procedures, see “About the
Crossover” (
page 28).
Channel
Setting item:
X-Over
1 Touch [X-Over] on the Sound Setup menu
screen.
2 Touch [Channel], and then select [Front HPF],
[Rear HPF] or [SubW.LPF].
3 Adjust the crossover to your preference.
Selecting the Cut-Off Frequency
Touch [
] or [ ] of “Freq.” (Frequency), and then select the
cut-off frequency.
Setting contents:
20.0 / 25.0 / 31.5 / 40.0 / 50.0 / 63.0 / 80.0 (Initial setting)
/ 100.0 / 125.0 / 160.0 / 200.0 Hz
Adjusting the Slope
Touch [
] or [ ] of “Slope”, and then adjust the HPF or LPF
slope.
Setting contents:
0 (Initial setting) / 6 / 12 / 18 / 24 dB/oct.
Adjusting the Level
Touch [
] or [ ] of “Level”, and then adjust the HPF or LPF
level.
Setting contents:
-12 to 0 dB (Initial setting: 0)
4 Repeat steps 2 to 3 to make adjustment to the
other channels.
5 To store the adjusted setting value, touch and
hold [Preset 1], [Preset 2], or [Preset 3] for at
least 2 seconds.
• Touch [ Flat] to initialize all values.
• If the Rear Speaker setting is Off, the Rear Speaker setting
cannot be edited (
page 28).
27-EN
• If the Subwoofer setting is Off, the Subwoofer setting cannot be
edited (
page 27).
• While adjusting the X-Over you should consider the frequency
response of the connected speakers.
Calling the X-Over adjusted value
Touch [Preset 1], [Preset 2], or [Preset 3].
The setting stored in the Preset will be recalled.
Volume Setup
[Volume] is selected on the Sound Setup menu screen.
Setting items:
Feedback Volume (page 27)
Source Volume (
page 27)
Android Auto™ Volume (
page 27)
Apple CarPlay Volume (
page 27)
Phone Volume (
page 27)
• Settable source differs depending on the connected device and
settings.
Adjusting the Key Sound
You can change the volume of the sound heard when a
button is touched.
Setting item:
Feedback Volume
Setting contents:
0 to 7 (Initial setting: 4)
Adjusting the Source Volume
Touch [Source Volume] on the Volume Setup menu screen.
Setting item:
Radio / Compress* / iPod / Bluetooth Audio / Sirius XM /
HDMI / AUX / Factory Audio
Setting contents:
-5 to +5 (Initial setting: 0)
∗ Compressed Media is the music data in a USB flash drive
(MP3/WMA/AAC/FLAC/WAV).
Setting the Volume for Android Auto™
When an Android Smartphone is connected, touch
[Android Auto Volume] to set the volume for Android Auto
mode.
Setting item:
Entertainment / Notification
Setting contents:
Entertainment: -5 to +5 (Initial setting: 0)
Notification: 0 to 35 (Initial setting: 10)
Setting the Volume for Apple CarPlay
When an iPhone 5s or later is connected, touch [Apple
CarPlay Volume] to set the volume for Apple CarPlay
mode.
Setting item:
Entertainment / Notification / Ringtone / Phone Calls
Setting contents:
Entertainment: -5 to +5 (Initial setting: 0)
Notification: 0 to 35 (Initial setting: 10)
Ringtone: 0 to 11 (Initial setting: 5)
Phone Calls: 0 to 11 (Initial setting: 5)
Adjusting the Volume for Phone
You can adjust the speaker volume and receive volume,
during the call.
Setting item:
Speaker Volume / Mic Level / Ringtone Volume
Setting contents:
Speaker Volume: 0 to 11 (Initial setting: 5)
Mic Level: 1 to 11 (Initial setting: 7)
Ringtone Volume: 0 to 11 (Initial setting: 5)
Turning Subwoofer ON/OFF
If an optional subwoofer is connected to the unit, make the
following setting.
Setting item:
Subwoofer
Touch [
] (Off) or [ ] (On) of
“Subwoofer”.
28-EN
Rear Speaker Setting
You can set the rear speaker output to Off.
Setting item:
Rear Speaker
Touch [
] (Off) or [ ] (On) of “Rear
Speaker”.
Defeat Setting
If Defeat is On, the Equalizer setting are turned Off. This
disables any settings made for these functions.
Setting item:
Defeat
Touch [
] (Off) or [ ] (On) of “Defeat”.
About the Crossover
Crossover (X-Over):
This unit is equipped with an active crossover. The crossover
limits the frequencies delivered to the outputs. Each
channel is controlled independently. Thus, each speaker
pair can be driven by the frequencies for which they have
been optimally designed.
The crossover adjusts the HPF (high pass filter) or LPF (low
pass filter) of each band, and also the slope (how fast the
filter rolls off the highs or lows).
Adjustments should be made according to the
reproduction characteristics of the speakers. Depending on
the speakers, a passive network may not be necessary. If
you are unsure about this point, please consult your
authorized Alpine dealer.
Cut-off
frequency (1/3
octave steps)
Slope Level
HPF LPF HPF LPF
Subwoofer
(LPF)
----
20 Hz -
200 Hz
----
0, 6, 12,
18, 24
dB/oct.
0 to
–12 dB
Rear speaker
(HPF)
20 Hz -
200 Hz
----
0, 6, 12,
18, 24
dB/oct.
----
0 to
–12 dB
Front
speaker
(HPF)
20 Hz -
200 Hz
----
0, 6, 12,
18, 24
dB/oct.
----
0 to
–12 dB
Slope adjusting
Output frequency
range
Front speaker
Rear speaker
Low range High range
Subwoofer
200 Hz
Output frequency
range
LPF cut-off
frequency
HPF cut-off
frequency
20 Hz
(Different from actual
display)
Level adjusting
(0 to –
12 dB)
Slope
F LAT
• HPF (high pass filter): Cuts the lower frequencies and allows
the higher frequencies to pass.
• LPF (low pass filter): Cuts the higher frequencies and allows
the lower frequencies to pass.
• Slope: The level change (in dB) for a frequency change of one
octave.
• The higher the slope value, the steeper the slope becomes.
• Adjust the slope to FLAT to bypass the HP or LP filters.
• Do not use a tweeter without the HPF on or set to a low
frequency, as it may cause damage to the speaker due to the
low frequency content.
29-EN
• Adjustment should be made according to the recommended
crossover frequency of the connected speakers. Determine the
recommended crossover frequency of the speakers. Adjusting
to a frequency range outside that recommended may cause
damage to the speakers.
For the recommended crossover frequencies of Alpine
speakers, refer to the respective Owner’s Manual.
We are not responsible for damage or malfunction of speakers
caused by using the crossover outside the recommended value.
About Time Correction
The distance between the listener and the speakers in a car
vary widely due to the complex speaker placement. This
difference in the distances from the speakers to the listener
creates a shift in the sounds image and frequency
characteristics. This is caused by the time delay between the
sound reaching the listener’s right versus the left ear.
To correct this, this unit is able to delay the audio signal to
the speakers closest to the listener. This effectively creates a
perception of increased distance for those speakers. The
listener can be placed at an equal distance between the left
and right speakers for optimum staging.
The adjustment will be made for each speaker in 3.4 cm
steps.
Example 1. Listening Position: Front
Left Seat
Adjust the time correction level of the front left speaker to a
high value and the rear right to zero or a low value.
The sound is not balanced because the distance between
the listening position and the various speakers is different.
The difference in distance between the front left speaker
and the rear right speaker is 1.75 m (68-7/8”).
Here we calculate the time correction value for the front left
speaker in the diagram on the above.
Conditions:
Farthest Speaker – listening position : 2.25 m (88-9/16”)
Front left speaker – listening position : 0.5 m (19-11/16”)
Calculation: L = 2.25 m – 0.5 m = 1.75 m (68-7/8”)
Time correction = 1.75 ÷ 343* × 1,000 = 5.1 (ms)
∗ Speed of sound: 343 m/s (765 mph) at 20°C
In other words, giving the front left speaker a time
correction value of 5.1 ms makes it seem as if its distance
from the listener is the same as the distance to the farthest
speaker.
Time correction eliminates the differences in the time
required for the sound to reach the listening position.
The time of the front left speaker is corrected by 5.1 ms so
that its sound reaches the listening position at the same
time as the sound of other speakers.
Example 2. Listening Position: All
Seats
Adjust the time correction level of each speaker to almost
the same level.
1 Sit in the listening position (driver’s seat, etc.)
and measure the distance (in meters)
between your head and the various speakers.
2 Calculate the difference between the distance
correction value to the farthest speaker and
the other speakers.
L = (distance to farthest speaker) – (distance to other
speakers)
These values are the time correction values for the
different speakers. Setting these values to make each
sound reach the listening position at the same time as
the sound of other speakers.
30-EN
Time Correction Value List
Time
Difference
(msec)
Distance
(cm)
Distance
(inch)
Time
Difference
(msec)
Distance
(cm)
Distance
(inch)
0.0 0.0 0.0 5.1 173.4 68.3
0.1 3.4 1.3 5.2 176.8 69.7
0.2 6.8 2.7 5.3 180.2 71.0
0.3 10.2 4.0 5.4 183.6 72.4
0.4 13.6 5.4 5.5 187.0 73.7
0.5 17.0 6.7 5.6 190.4 75.0
0.6 20.4 8.0 5.7 193.8 76.4
0.7 23.8 9.4 5.8 197.2 77.7
0.8 27.2 10.7 5.9 200.6 79.1
0.9 30.6 12.1 6.0 204.0 80.4
1.0 34.0 13.4 6.1 207.4 81.7
1.1 37.4 14.7 6.2 210.8 83.1
1.2 40.8 16.1 6.3 214.2 84.4
1.3 44.2 17.4 6.4 217.6 85.8
1.4 47.6 18.8 6.5 221.0 87.1
1.5 51.0 20.1 6.6 224.4 88.4
1.6 54.4 21.4 6.7 227.8 89.8
1.7 57.8 22.8 6.8 231.2 91.1
1.8 61.2 24.1 6.9 234.6 92.5
1.9 64.6 25.5 7.0 238.0 93.8
2.0 68.0 26.8 7.1 241.4 95.1
2.1 71.4 28.1 7.2 244.8 96.5
2.2 74.8 29.5 7.3 248.2 97.8
2.3 78.2 30.8 7.4 251.6 99.2
2.4 81.6 32.2 7.5 255.0 100.5
2.5 85.0 33.5 7.6 258.4 101.8
2.6 88.4 34.8 7.7 261.8 103.2
2.7 91.8 36.2 7.8 265.2 104.5
2.8 95.2 37.5 7.9 268.6 105.9
2.9 98.6 38.9 8.0 272.0 107.2
3.0 102.0 40.2 8.1 275.4 108.5
3.1 105.4 41.5 8.2 278.8 109.9
3.2 108.8 42.9 8.3 282.2 111.2
3.3 112.2 44.2 8.4 285.6 112.6
3.4 115.6 45.6 8.5 289.0 113.9
3.5 119.0 46.9 8.6 292.4 115.2
3.6 122.4 48.2 8.7 295.8 116.6
3.7 125.8 49.6 8.8 299.2 117.9
3.8 129.2 50.9 8.9 302.6 119.3
3.9 132.6 52.3 9.0 306.0 120.6
4.0 136.0 53.6 9.1 309.4 121.9
4.1 139.4 54.9 9.2 312.8 123.3
4.2 142.8 56.3
9.3 316.2 124.6
4.3 146.2 57.6 9.4 319.6 126.0
4.4 149.6 59.0 9.5 323.0 127.3
4.5 153.0 60.3 9.6 326.4 128.6
4.6 156.4 61.6 9.7 329.8 130.0
4.7 159.8 63.0 9.8 333.2 131.3
4.8 163.2 64.3 9.9 336.6 132.7
4.9 166.6 65.7
5.0 170.0 67.0
31-EN
Apple CarPlay (Optional)
Apple CarPlay is a smarter, safer way to use your iPhone in
the car. Apple CarPlay takes the things you want to do with
your iPhone while driving and puts them right on the unit.
You can get directions, make calls, send and receive
messages, and listen to music, all in a way that allows you to
stay focused on the road. Just plug in your iPhone to the
unit and go.
• Before using this function, plug in your iPhone using
Lightning to USB Cable (Supplied with iPhone) to the unit.
• Some functions may not be available while driving.
• About iPhone models usable with this unit, see “iPod mode on
iPhone (Optional)” (
page 39). Only an iPhone 5s or later
compatible with Apple CarPlay function.
• Before operating Apple CarPlay, set “Apple CarPlay” to [On]
(
page 21).
Access to Apple CarPlay
1 Touch the
(HOME) button.
The HOME screen is displayed.
2 Touch [Apple CarPlay].
[Apple CarPlay] button
The Apple CarPlay screen is displayed.
Touch the desired App icon on the unit, or use Siri
function by touching the
button.
• When a used iPhone 5s or later is reconnected, touch the
pop-up message-“Apple CarPlay connected.” within 5 seconds
to access to Apple CarPlay screen, or you can ignore prompt
by touching [
] on the top right.
• The App must be Apple CarPlay compatible in order to
appear in the Home screen.
Android Auto (Optional)
What is Android Auto
Android Auto brings your favorite smartphone apps into
one place, making it easier for drivers to access their
favorite navigation, media, and communication apps on the
road while minimizing the distractions. Talk to Google on
Android Auto™ and get things done with your voice so you
can keep your eyes on the road and hands on the wheel.
Easily send messages, get directions, control media and
more. Just say, “Hey Google” or long-press the voice control
button on your steering wheel.
Activate Android Auto
Download the Android Auto App from the Google Play
store before continuing.
Just plug in your smartphone to the unit’s USB connector,
then follow the prompt to pair your smartphone with the
unit.
• The connected smartphone with Android Auto will disconnect
other phone’s Bluetooth connection and pair to the unit.
1 Touch the
(HOME) button.
The HOME screen is displayed.
2 Touch [Android Auto].
[Android Auto] button
The Android Auto screen is displayed.
• When a used smartphone is reconnected, touch the
pop-up message-“Android Auto connected” within 5
seconds to access to Android Auto screen, or you can
ignore prompt by touching [
] on the top right.
• You can make a call, use voice recognition function
and Android Auto’s compatible navigation app, etc.
• Only Google approved apps with necessary
driver-safety measures in place can be used.
32-EN
Radio/HD Radio™/RBDS
There are 3 types of [Radio] widgets for the HOME screen.
The unit can receive HD Radio broadcasting signals based
on digital radio broadcast standards, in addition to analog
radio broadcasts using RBDS.
HD Radio broadcasting signals are broadcast in the service
areas of the current AM/ FM broadcasters where they
provide digital audio distribution and data services. This
unit receives the above digital broadcasts for your
high-quality sound enjoyment.
Depending on the signal strength in TUNER mode, the unit
will automatically switch between digital signals if they can
be received, and analog radio using RBDS if digital signals
cannot be received. For details, please see “Forced Analog
Mode.”
• RBDS mode is only available during FM broadcast reception.
This unit is able to receive signals based on the terrestrial
digital radio broadcasting standard.
When current AM/FM broadcasters are transmitting digital
audio and data services, HD Radio broadcasting signals are
on-the-air in their service area. You can receive their digital
broadcast and enjoy high quality sound.
If there is no HD Radio broadcasting signal in the current
area, after 10 seconds, this unit will switch to receive the
RBDS Radio signal automatically. However, the display is still
HD Radio Technology mode screen.
■
HD Radio main screen example
HD Radio indicator
Multicast station channels indicator
1: MPS (Main Program Service)
2 -8: SIS (Station Information Service)
Information display
• For details on switching the display of the Radio text,
see “Displaying Radio Text (HD Radio™, RBDS FM Radio
mode only)” (
page 34).
Increases frequency
Touch and hold to change the frequency continuously.
IPreset button
Displays the preset stations with a short touch.
Touch for at least 1 second to memorize the current
station as a preset station.
Displays the Sound Setup Menu screen
(page 24).
PTY Search (RBDS FM Radio Mode only)
Switch to analog mode.
Switches a band.
Memorizes stations automatically
Switches a Seek mode.
Decreases frequency
Touch and hold to change the frequency continuously.
Radio Basic Operation
Listening to the Radio
1 Touch the
(HOME) button and select radio
mode.
The display shows the radio mode screen.
2 Touch [Band] repeatedly to select the desired
band from [FM1] / [FM2] / [AM].
3 Touch [Seek], [Digital Seek], [Manual] or [PTY
Seek] repeatedly to select the tuning mode.
The radio frequency up or down button changes
depending on the tuning mode.
Seek mode* Both strong and weak stations
will be tuned in.
Digital Seek mode Automatically receives a
receivable digital broadcast.
Manual mode The frequency is manually
tuned in steps.
PTY Seek mode
(RBDS FM Radio Mode
only)
The currently selected
program type station will be
tuned.
• During Forced Analog mode, digital broadcasts
cannot be received.
* Depending on the signal, a digital or analog
broadcast is received.
4 Touch [
], [ ], [ ], [ ] to change the radio
frequency up or down respectively.
In Manual mode, touch and hold to change the
frequency continuously.
33-EN
Presetting Stations Manually
1 Tune in a desired radio station you wish to
store in the preset memory by manual or
automatic seek tuning.
2 Touch and hold the Preset number you want
to store for at least 1 second.
The selected station is stored.
3 Repeat the procedure to store up to 5 other
stations onto the same band.
To use this procedure for other bands, simply select the
desired band and repeat the procedure.
A total of 18 stations can be stored in the preset
memory
(6 stations for each band; FM1, FM2 or AM).
• If a preset memory has already been set in the same preset
number, it will be cleared and the new station will be
memorized.
Presetting Stations Automatically
The tuner can automatically seek and store 6 strong stations
in the selected band in ascending order of frequency.
Select the desired band then touch and hold
[A.Memo].
The tuner automatically seeks and stores 6 strong stations
into the preset buttons in ascending order of frequency.
When automatic storing has completed, the station stored
in the preset 1 is selected.
• If no stations are stored, the tuner will return to the original
station you were listening to before the automatic storing
procedure began.
• You can cancel this process by touching [A.Memo] while the
tuner is automatically seeking stations. Canceling will return
the tuner preset to the previous setting.
Tuning to Preset Station
After selecting the desired band, touch the
desired preset button.
The preset station is received.
Receiving a Multicast (HD Radio™
Mode only)
Multicasting is the ability to broadcast multiple program
streams over a single FM frequency. This increases the
amount and diversity of content choices. A maximum of 8
multicast station channels can be selected on this unit.
• Multicast station channels indicator appears when signal
reception is possible.
Touch [ ], [ ] or [ ], [ ].
The sub channel of the received radio station is changed.
Forced Analog Mode
Activate the Compulsory Analog Radio mode to receive
only analog radio signals.
Touch [Analog mode].
The [Analog mode] button is highlighted. To cancel
Compulsory Analog Radio mode, touch [Analog mode]
again.
• During Forced Analog mode, only analog broadcasts will be
received even when digital broadcasts become available.
Selecting the Receivable Program
Type (RBDS FM Radio Mode only)
You can select and receive the currently receivable stations
in the Program Type list screen.
1 Touch [PTY Search]
The display shows the Program Type list screen.
2 Select the desired program type in the
Program Type list screen.
Program Type Seek starts and the receivable program
type is received.
If no Program Type station is found, “No program type
available.” will be displayed.
34-EN
Using Ballgame Mode (HD Radio™
Mode only)
When [Ballgame Mode] is set to [On] (page 15), the LIVE
indicator will lights up when receiving live broadcast such
as sportscast.
■
Ballgame mode screen example
LIVE indicator
• In live broadcast, such as sportscasts, etc., a time lag occurs
between digital sound and analog sound. Therefore, when live
broadcasts are received, a time lag between the real broadcast
may occur and the unit can change to analog broadcasting
automatically.
Displaying Radio Text (HD Radio™/
RBDS FM Radio mode only)
Text messages from a radio station can be displayed.
1 Tune in a radio station that transmits text
messages.
2 Touch the information display area in the FM
radio mode repeatedly to switch to the
desired display.
RBDS:
Station Info Mode
Song Info Mode Radio Text
Mode Station Info Mode
Station Info Mode:
PS / PTY / Frequency / Song Name
Song Info Mode:
PS/Song Name / Artist Name / Album Name
Radio Text Mode:
Radio Text
HD Radio:
Station Info Mode
Song Info Mode Station Info
Mode
Station Info Mode:
Station Name / Frequency / Song Name
Song Info Mode:
Station Name / Song Name / Artist Name / Album Name
About the Feature Logos
• Digital, CD-quality sound. HD Radio Technology enables
local radio stations to broadcast a clean digital signal. AM
sounds like today’s FM and FM sounds like a CD.
• Program Service Data: Contributes to the superior user
experience of HD Radio Technology. Presents song name,
artist, station IDs, HD2/HD3 Channel Guide, and other
relevant data streams.
• Adjacent to traditional main stations are extra local FM
channels.
These HD2/HD3 Channels provide new, original music as
well as deep cuts into traditional genre.
• Visual information related to content being played on your
HD Radio receiver, such as Album Art, historical photographs,
still art from live broadcasts, among other related content.
35-EN
USB Flash drive (Optional)
You can play back music files (MP3/WMA/AAC/FLAC/WAV),
video files (MP4/AVI/WMV/MOV) and photo files (JPG/PNG/
BMP) stored in a USB flash drive on the internal player of
this system.
WARNING
It is dangerous for the driver to watch video while
driving the vehicle. The driver may be distracted
from looking ahead and an accident could occur.
Install the unit correctly so that the driver cannot
watch a video unless the car is stopped and the
parking brake is applied.
If the unit is not installed correctly, the driver will be
able to watch a video while driving and may be
distracted from looking ahead and cause an
accident. The driver or other people could be
severely injured.
USB Audio
■
USB Audio mode screen
Artwork display
Information display
Finds the beginning of next chapter/Fast-
forwards when touched for at least 1 second
Shuffle mode
Repeat mode
Displays the Sound Setup Menu screen (page 24)
Switches to iPod mode of iPhone or Bluetooth
Audio.
Displays the search screen
Pause and Play
Elapsed time/Total time for playing
Current track number/Total track number
Finds the beginning of the current file/Finds a
previous file within one second after playback
starts/Fast-reverses when touched for at least 1
second
Playback
1 Touch the
(HOME) button and select USB
Audio mode.
The display shows the USB Audio mode screen.
2 Touch [
] or [ ] to select the desired track
(file).
Returning to the beginning of the current (or previous)
track (file):
Touch [
].
Fast reverse :
Touch and hold [
].
Advancing to the beginning of the next track (file) :
Touch [
].
Fast forward :
Touch and hold [
].
3 To pause playback, touch [
].
Touching [
] again will resume playback.
• The playback time may not be correctly displayed when a
VBR (Variable Bit Rate) recorded file is played back.
• If there is tag information, artist name/album name/track
name is displayed.
• ID3 tag/WMA tag
If an MP3/WMA/AAC/FLAC/WAV file contains ID3 tag/
WMA tag information, the ID3 tag/WMA tag information is
displayed. (e.g., song name, artist name, and album name)
• When selecting a [Audio] widget on the HOME screen, touch
[Audio Select] to select [USB]. If [USB] is already selected,
you can start playback by selecting a [Audio] widget on the
HOME screen.
Repeat Play
Touch [
], [ ] or [ ] to select Repeat
Play mode.
ALL
:
All files are repeatedly played back.
File
:
Only the file currently playing is repeatedly
played back.
Folder
:
Only files in a folder are repeatedly played
back.
36-EN
Shuffle Play
Touch [
] to select Shuffle Play mode.
Folder
:
A Folder is selected randomly and songs in
the Folder are played back in order. After all
songs are played in a Folder, the next Folder
is selected randomly.
Song
:
All songs in the Folder (Folder/File) including
the song currently being played are played
back in random sequence.
OFF
:
Shuffle mode is Off.
• If you select a track by using the search mode, the Shuffle
mode will be canceled.
Searching for a Desired Song
1 Touch [
] (Search).
2 Touch your desired Folder name or File name.
• When you select a Folder name, repeat the same procedure to
select another Folder name or File name.
• Touch [ Shuffle Songs] to randomly play back all songs in the
USB flash drive.
USB Video
The video formats (USB Flash drive) supported by the unit
are as follows.
– Supported Container: AVI/MP4/WMV/MOV/MPG
– Supported Video Coding: H.264/MPEG-4 AVC
– Supported Audio Coding: MP3, AAC, MPEG2 audio
– MAX File Size: 4GB
■
USB Video mode screen
File Name
Finds the beginning of next file/Fast-forwards
when touched for at least 1 second
Shuffle mode
Displays the Sound Setup Menu screen (page 24)
Switches to USB Photo mode
Displays the search screen
Sets the Brightness and Contrast
Displays the Subtitle
Stop
Pause and Play
Elapsed time/Total time for playing
Current file number/Total file number
Finds the beginning of the current file/Finds a
previous file within one second after playback
starts/Fast-reverses when touched for at least 1
second
Touch the
(HOME) button and select USB
Video mode.
The display shows the USB Video mode screen.
• To select USB Video mode, touch the [USB Video] or [Video]
widget on the HOME screen.
During the USB Video playback, touch the screen to display
the operation screen.
• For the basic operations on USB Video mode, refer to
“Playback” (
page 35).
• The operation screen changes to the visual screen in the USB
Video mode for 5 seconds after an operation has been
performed.
• For your safety, video is not displayed and only audio can be
heard while driving.
37-EN
Fast-forwarding/Fast-reversing
1 During playback, touch and hold [
]
(Fast-reverse) or touch and hold [
]
(Fast-forward).
Touch and hold for more than 1 second to forward/
reverse by a 10 seconds interval.
2 Release [
] or [ ] to return to normal
playback.
• No sound is played back during fast-forwarding/
fast-reversing.
Stopping Playback
Touch [
] during playback.
“STOP” indicator is displayed, and playback stops.
• Playback starts from the beginning when [
] is touched
while playback is stopped.
Repeat Play
Touch [
], [ ] or [ ] to select Repeat
Play mode.
ALL
:
All files are repeatedly played back.
File
:
Only the file currently playing is repeatedly
played back.
Folder
:
Only files in a folder are repeatedly played
back.
Searching for a Desired file
1 Touch [
] (Search).
2 Touch your desired Folder name or File name.
• When you select a Folder name, repeat the same procedure to
select another Folder name or File name.
• Touch [Repeat videos] to repeatedly play back all videos in the
USB flash drive.
Setting the Brightness and Contrast
1 Touch [Visual].
2 Touch [
] or [ ] to adjust the Brightness and
Contrast.
: Adjusting the Brightness
: Adjusting the Contrast
Displaying the Subtitle
Depending on the video file such as “.smi” or “.srt”, you can
display the subtitle contained on the file.
Touch [Subtitle].
To cancel displaying the subtitle, touch [Subtitle] again.
• If the file is not supported or the subtitle is not contained on
the file, [Subtitle] is not available.
38-EN
USB Photo
■
USB Photo mode Preview screen
■
USB Photo mode screen
Photo Preview
Photo files List
Switches to USB Video mode
Sets the photo as a wallpaper (page 17)
Sets the Time Interval for the Slide Show
Applies an Effect to the photo
Plays the Slide Show
File Name
During the USB Photo playback, touch the screen to display
the operation screen.
• The operation screen changes to the visual screen in the USB
Photo mode for 5 seconds after an operation has been
performed.
Playback
1 Touch the
(HOME) button and select USB
Photo mode.
The display shows the USB Photo mode screen.
• To select USB Photo mode, touch the [Photo] or
[Photo Frame] widget on the HOME screen.
2 Select the desired photo from the photo files
list.
• To select the other photo (file), touch [
] to return to the
previous screen.
Slide Show
The Slide Show shows photos that change every 3 seconds.
Touch [Play].
• To stop the Slide Show, touch the screen.
Setting the Effect for Playback
You can set the playback effect how switches to the photo
for Slide Show.
Touch [Effect], and then select the desired effect.
Setting the Time Interval for Slide Show
You can set the time interval to switch to the next photo.
Touch [Time Interval], and then select the
desired time interval.
Setting a Wallpaper with a Photo
To set a wallpaper with your favorite photo, refer to “Setting
a Wallpaper using your image” (
page 17).
39-EN
iPod mode on iPhone
(Optional)
A separately sold Lightning to USB cable (KCU-471i), etc., is
required.
• This unit does not support video playback from iPhone which
connected to this unit via USB Connector.
• Internet or telephone function, etc., of the iPhone is not
controllable from the unit, but these functions can be
controlled using the iPhone itself.
• Before operating iPod mode on iPhone, set “Apple CarPlay” to
[Off] (
page 21).
■
iPod main screen example
Artwork display
Information display*
Finds the beginning of the current file/Finds a
previous file within one second after playback
starts/Fast-reverses when touched for at least 1
second
Shuffle mode
Repeat mode
Displays the Sound Setup Menu screen
(page 24).
Switches to the USB Flash drive or Bluetooth
Audio.
Displays the search screen
Pause and Play
Elapsed time/Total time for playing
Current song no./Total song no.
Finds the beginning of the current file/Finds a
previous file within one second after playback
starts/Fast-reverses when touched for at least 1
second
∗ Podcast mode.
Playback
1 Touch the
(HOME) button and select iPod
mode.
The display shows the iPod mode screen.
2 Touch [
] or [ ] or to select the desired
track (file).
Returning to the beginning of the current (or previous)
track (file):
Touch [
].
Fast reverse the current track :
Touch and hold [
].
Advancing to the beginning of the next track (file) :
Touch [
].
Fast forward the current track :
Touch and hold [
].
3 To pause playback, touch [
].
• If a song is playing on the iPhone before it is connected to the
unit, it will continue playing when it is connected.
• An episode may have several chapters. The chapter can be
changed by touching [
] or [ ].
• If the artist, album or song name, created in iTunes, has too
many characters, songs may not be played back when
connected to the unit. Therefore, a maximum of 64 characters
is recommended. The maximum number of characters for the
unit is 64.
• Some characters may not be correctly displayed.
• When selecting a [Audio] widget on the HOME screen, touch
[Audio Select] to select [iPod]. If [iPod] is already selected,
you can start playback by selecting a [Audio] widget on the
HOME screen.
40-EN
Searching for a Music File
An iPhone can contain thousands of songs. For this reason,
this unit can make various searches using the search
function as shown below.
Using the Playlist/Artist/Album/Podcast/Audiobook/Genre/
Composer/Song/Radio search mode’s individual hierarchy,
you can narrow down your search as shown in the table
below.
<Music Search Menu>
Hierarchy 1 Hierarchy 2 Hierarchy 3 Hierarchy 4
Playlists Songs — —
Artists Albums Songs —
Albums Songs — —
Songs — — —
Genres Artists Albums Songs
Composers Albums Songs —
Podcasts Episodes — —
Audiobooks — — —
Radio — — —
For example: Searching by Artist name
The following example explains how an Artists search is
performed.
1 Touch [ ] (Search) during playback.
2 Touch [Artists].
The Artists search screen is displayed.
3 Touch the desired artist’s name.
4 Touch the desired album’s name.
All songs of the selected album are displayed.
5 Touch the desired song’s name.
The selected song is played back.
Repeat Play
Touch [
] to select Repeat Play mode.
ALL
:
All files are repeatedly played back.
File
:
Only the file currently playing is repeatedly
played back.
OFF
:
Repeat mode is Off.
Shuffle Play
Touch [
] to select Shuffle Play mode.
Songs
:
Song shuffle randomly plays back
songs within a selected category
(playlist, album, etc.). The songs within
the category are played just once until
all songs have been played.
OFF
:
Shuffle mode is Off.
41-EN
SiriusXM Satellite Radio
Operation (Optional)
SiriusXM Tuner operation:
When an optional SiriusXM Tuner is connected to this
unit, the following operations may be performed.
■
SiriusXM main screen example (Song Info.
Mode)
Signal Indicator
Indicates the signal strength of SiriusXM.
Information display
Channel Info. Mode:
Channel No/Long Channel Name/Category Name
Song Info.Mode:
Artist Name/Song Name/Content Info
Changes to the next channel
Preset buttons
Displays the preset channels with a short touch.
Touch for at least 1 second to memorize the current
channel as a preset channel.
Displays the Sound Setup Menu screen
(page 24).
Select the channel number
Changes text information
Displays the search screen
Changes to category browsing mode
Changes to the previous channel
Receiving Channels with the SiriusXM
Tuner
About SiriusXM Satellite Radio
Only SiriusXM® brings you more of what you love to listen
to, all in one place. Get over 140 channels, including
commercial-free music plus the best sports, news, talk,
comedy and entertainment. Welcome to the world of
satellite radio. A SiriusXM Vehicle Tuner and Subscription
are required. For more information, visit www.siriusxm.com.
After you have found the SiriusXM Radio ID, you can
activate your radio. See “Checking the SiriusXM Radio ID
Number” (
page 42).
In the USA, you can activate online or by calling SiriusXM
Listener Care:
• Visit www.siriusxm.com/activatenow
• Call SiriusXM Listener Care at 1-866-635‐2349
For Canadian Subscriptions, please contact:
• Visit www.siriusxm.ca/activatexm
• Call XM Customer Care at 1‐877‐438‐9677
• The SiriusXM Satellite Radio controls on this unit are
available only when a SiriusXM Tuner is connected.
1 Touch the
(HOME) button and select
SiriusXM mode.
The display shows the SiriusXM mode screen.
2 Touch [
] or [ ] to select the desired
channel. Touching and holding either button
will rapidly browse through the channels.
• Refer to the SiriusXM Tuner User Guide for details on how to
install the SiriusXM Tuner.
Tuning Channels by Category
Channels are grouped into categories based on the type of
content heard on the channels.
1 Touch [Category] on the SiriusXM main screen
to activate the category browsing mode.
The channels within the category of the current channel
are listed.
■
Category browsing mode screen example
• Touching [Info] changes the display of information for
the channels in the category with the following three
options.
Channel No./Channel Name
Channel No./Artist
Name Channel No./Song Title Channel No./
Content Info Channel No./ Channel Name
2 Touch [
Category] or [ Category] on the
category browsing mode screen to select a
desired category.
The Category Name is shown at the top of the display.
3 Select the desired channel.
42-EN
Changing the Display
Text information, such as the channel name, artist name/
feature, and song/program title, is available with SiriusXM.
The unit can display this text information as explained
below.
Touch [Info].
Each time you touch this button, the Channel Info. mode
and the Song Info. mode switch alternately. For displayed
contents, see “SiriusXM main screen example (Song Info.
Mode)” (
page 41).
Checking the SiriusXM Radio ID
Number
To subscribe to the SiriusXM Satellite Radio service, it is
necessary to locate and identify the Radio ID of your
SiriusXM Tuner. You can check the Radio ID on the bottom
surface of the SiriusXM Tuner box. You can also check it
from this unit by performing the following procedure.
1 While receiving SiriusXM Radio, touch [
] or
[
] to select channel “0”.
The unit displays the Radio ID number.
2 To cancel the Radio ID number display,
change the channel to a channel other than
“0”.
• The SiriusXM Radio ID does not contain the letters I, O, S, or
F.
Storing Channel Presets
You can store 6 of your favorite SiriusXM channels for easy
recall with Preset buttons.
1 Touch and hold the Preset number you want
to store for at least 1 second to store the
channel.
2 Repeat the procedure to store up to 5 other
channels.
A total of 6 channels can be stored in the preset
memory.
• If you store a new channel into a preset which already has a
channel assigned, the current channel will be cleared and
replaced with the new one.
Tuning Channels using Presets
Touch any one of the Preset numbers you have
already stored in the Preset mode screen.
The preset channel is received.
Search Function
1 Touch [
].
The Search list screen appears.
Search item:
All Channels / Category Name*
∗ The Category name for the channel currently being
received is displayed.
• You can switch the category by touching [
] or [ ] on the
List screen after selecting a Search item.
• You can switch the display format by touching [Info] in the
List screen after selecting a Search item.
Channel No./Channel Name
Channel No./Artist Name
Channel No./Song Title Channel No./Content Info
Channel No./Channel Name
Searching by Channel
2 Touch [All Channels].
All Channels will be displayed in a list.
3 Touch the selected channel.
The channel you selected is received.
Searching by Category
2 Touch Category Name.
The channels within the category of the current channel
are listed.
3 Touch the selected channel.
The channel you selected is received.
Selecting the Channel Directly
You can directly select the channel number by using the
numeric keypad.
1 Touch [Direct Tune].
The numeric keypad input screen is displayed.
2 Touch to input the channel number.
3 Touch [OK].
The selected channel is received.
43-EN
Parental Lock Function
The Parental Control feature allows you to limit access to
any SiriusXM channels, including those with mature
content. When enabled, the Parental Control feature
requires you to enter a passcode to tune to the locked
channels. For information on setting the Parental Control
passcode, see “Setting the Parental Lock” (
page 15).
When a locked channel is selected, “Channel <xxx> Locked”
is displayed and then the numeric keypad appears for you
to enter the passcode.
Input the 4-digit passcode you set in “Setting the
Parental Lock” (
page 15).
The initial number is 0000.
• If you input a wrong passcode, “Incorrect Pass Code entered”
is displayed.
• After entering the correct passcode, you can access all locked
channels without entering the passcode again until the unit is
powered off and then back on.
44-EN
HDMI Device (Optional)
Devices supporting HDMI can connect and play back
through this unit (for example, an optional DVD Player,
iPhone or other Smartphones).
• The HDMI/MHL connecting cable differs depending on the
connected device corresponding to HDMI. Prepare optional
HDMI/MHL connecting cable sets suitable for your device.
HDMI Operation
■
iPhone, Smartphone, etc.
The output of your electronic device will be mirrored on this
unit through the HDMI connector. Control from this unit is
not possible.
• The electronic device must possess an HDMI output interface.
• Not all devices with an HDMI output interface can be
recognised by this unit.
• Use only the Alpine Special HDMI connection cable.
1 Touch the
(HOME) button to select HDMI.
The display shows the HDMI mode screen.
• You can select and change the source in the HOME screen
(
page 12).
• For your safety, video is not displayed and only audio can be
heard while driving.
2 In HDMI player mode, the screen of the device
displays the content of electronic equipment
by mirror image.
Sets the Brightness and Contrast
Displays the Sound Setup Menu screen
(page 24).
Setting the Brightness and Contrast
1 Touch [Visual].
2 Touch [
] or [ ] to adjust the Brightness and
Contrast.
: Adjusting the Brightness
: Adjusting the Contrast
45-EN
Bluetooth Operation
Setup Before Using
About Bluetooth
Bluetooth is a wireless technology allowing communication
between a mobile device or personal computer over short
distances. This enables a hands-free call or data
transmission between Bluetooth compatible devices.
Bluetooth transmission is available in the unlicensed 2.4
GHz spectrum if the distance between devices is within 10
meters. For details, refer to the Bluetooth website (http://
www.bluetooth.com/).
• Depending on the Bluetooth version, a Bluetooth compatible
device may not be able to communicate with this unit.
• Proper function of this unit with all Bluetooth compatible
devices is not guaranteed. For handling of the Bluetooth
compatible device, consult your Alpine dealer or Alpine
website.
• Depending on the surroundings, Bluetooth wireless connection
may be unstable.
• When you place a call, or perform setup operations, be sure to
stop your car in a safe place.
• Depending on the connected Bluetooth compatible device(s),
the function may differ. Also refer to the Owner’s Manual of
the connected device(s).
About the Hands-free Phone
Hands-free calls are possible when using a HFP (Hands-Free
Profile) compatible mobile phone with this unit.
• Avoid performing a hands-free call in heavy traffic or on
narrow or winding streets.
• Close the windows while calling to reduce background noise.
• If both calling parties are using hands-free devices, or the call
is made in a noisy location, difficulty hearing the other
person’s voice is normal.
• Depending on telephone line conditions or certain mobile
devices used, voices may sound unnatural.
• When using a microphone, speak as directly as you can into
the microphone to obtain the best sound quality.
• Certain mobile phone features are dependent on the
capabilities and settings of your service provider’s network.
Additionally, certain features may not be activated by your
service provider, and/or the provider’s network settings may
limit the feature’s functionality.
Always contact your service provider about feature
availability and functionality.
All features, functionality, and other product specifications, as
well as the information contained in the Owner’s Manual are
based upon the latest available information and are believed
to be accurate at the time of printing.
Alpine reserves the right to change or modify any information
or specifications without notice or obligation.
• Notice that when you connect an iPhone 5s or later/Android
smartphone which installed Android Auto App, the operation
screen may differ from this section.
Before Using Bluetooth
Before using the hands-free phone/audio function, the
following settings need to be made.
Register a Bluetooth device in this unit.
• See “Connection (Bluetooth) Setup” (page 20).
• You can search for this unit using a Bluetooth compatible
device, and then connect that Bluetooth compatible device to
this unit. The device name of this unit is “iLX-407” and the
initial number of the passcode is “0000.” Also refer to the
Owner’s Manual of the connected device(s).
Hands-free Phone Control
Touch the Phone button to display the Phone menu screen.
Phone button
• You can also display the Phone menu screen by selecting the
[Phone] widget on the HOME screen.
■
Phone menu screen example
Favorite
Displays a list of numbers set as your favorite.
Dialed
Displays a list of dialed calls.
Received
Displays a list of the received calls.
Missed
Displays a list of the missed calls.
46-EN
Disconnect
Disconnects the Bluetooth device. After disconnecting,
the display changes to [Reconnect] to connect the
disconnected device again.
Change Device
Displays the Bluetooth Setup screen.
Keypad
Use to type a phone number.
Phone Book*
You can make a phone call from the Phone Book, or edit
the Phone Book.
Redial
Dials to the last called number.
∗ If the Hands-Free Phone is not connected, the Bluetooth
Setup screen will be displayed. See “Connection
(Bluetooth) Setup” (
page 20).
Answering a Call
1 An incoming call triggers the ringtone and an
incoming call display.
• You can adjust the ringtone volume by touching [ ]
or [
] of “Ringtone Volume ( ) ”.
2 Touch [
].
The call starts.
• During a call, the audio for the current mode on the unit is
muted. After calling, playback will resume.
• When the caller’s number is transmitted to the system, if the
caller’s name is stored in the phone book, the name is
displayed. If the name is not stored, the number is displayed.
• Touch [
] (Decline) to reject an incoming call.
• By touching [ ], you can mute the microphone. To cancel
MUTE mode, touch [ ]. For details, see “Phone Operation
Screen” (page 48).
• If another call comes during a call, operate on the Bluetooth
Device.
Hanging up the Telephone
1 Touch [
] (End Call).
The call finishes.
Calling
Making a phone call using the Phone
Menu
Making a phone call from the Recent Events list
1 Select a category from [Favorite], [Dialed],
[Received] or [Missed] on the Phone menu.
2 Touch [ ] of the name or number of the
contact which you want to call.
3 Touch [Call].
The phone call is started.
• To use [Favorite], see “Setting contacts as Favorites (Shortcut
Dialing)” (
page 49).
Calling from the Phone Book
1 Touch [Phone Book] on the Phone menu.
The Phone Book screen appears.
2 Touch [ ] of the name or number of the
contact which you want to call.
The phone call is started.
47-EN
Entering a Phone Number to Make a Call
1 Touch [Keypad] on the Phone menu.
The number input screen (Keypad) appears.
Touch [ ] to delete an entered number.
2 Enter the phone number you wish to call.
• You can enter up to 21 digits.
3 Touch [
] (Call).
A confirmation message of the phone number appears.
4 Touch [Call].
The phone call is started.
Calling in Private
When using the Private Call setting, the conversation is not
output through the speaker.
Touch [
] during the call.
• To change the Bluetooth device, touch [Change Device] to
display the Bluetooth Setup screen. See “Connection
(Bluetooth) Setup” (
page 20).
Using Voice Recognition function
You can use Siri function of your iPhone or make a
telephone call by using voice operation of your
smartphone.
• When using Apple CarPlay or Android Auto, the operation
screen may differ from the screen design in the Owner’s
Manual.
Using Siri
You can use the Siri function of your iPhone. To use this
function, set the Siri setting of your iPhone to ON.
• Connect your iPhone to the unit via Bluetooth, then set to
“Hands-free” (
page 20).
• The available functions differ depending on the connected
iPhone.
• Ask Siri to play a track from the music library applies only to
USB source.
• Siri and other streaming services are enabled by connecting to
compatible smartphones that are able to receive data. Please
ensure that cellular data and/or Wi-Fi is turned on in the
smartphone to enjoy these features.
• Extensive use of Siri or other streaming services may increase
your phone’s data usage. Please check with your phone
company to ensure you have an appropriate Data plan.
1 Touch [
] button.
The Voice Recognition mode screen is displayed.
2 Speak into the microphone supplied with this
unit.
3 To finish the Voice Control mode, touch
[Cancel].
• Depending on the iPhone, the Siri function may finish
automatically.
• For adjusting the volume, see “Adjusting the Speech Volume”
(
page 48).
Voice Dial Function
You can make a telephone call by using voice operation.
• Connect your smartphone to the unit via Bluetooth, then set
to “Hands-free” (
page 20).
1 Touch [
] button.
The Voice Dial mode screen is activated.
2 Say the telephone number* or name* you
want to call, into the microphone.
* The number and name depend on the voice dial
information stored in the smartphone.
3 To finish the Voice Dial mode, touch [Cancel].
• You can perform this operation only when a voice dial
compatible smartphone is connected.
• The Voice Dial function performance depends on the
recognition range of the smartphone and mounting location of
the microphone.
Note when the microphone is mounted.
48-EN
• Voice dial operation depends on the function being available
on the smartphone. For details, refer to the owner’s manual of
the smartphone.
• Depending on the smartphone, the Voice Dial operation may
finish automatically.
• For adjusting the volume, see “Adjusting the Speech Volume”
(
page 48).
Phone Operation Screen
Name and phone number
• If it is registered with a Group, the Group Name is also
displayed. Although, depending on the connected
mobile phone, it may not be displayed.
Conversation time
Adjusting the Speech Volume
You can adjust Caller Level and Microphone Level.
Touch [
] or [ ] of “Speaker Volume ( )” or
“Mic Level ( ) ”.
You can adjust the volume in 11 levels.
Changing the Voice Output
The voice output for calls is switchable between car
speakers and the mobile phone speaker.
Touch [
] or [ ].
• Depending on the mobile phone, this operation may not be
possible.
Muting the Microphone
Touch [
].
• To cancel MUTE mode, touch [
].
DTMF (Touch-Tone) Function
Transmits a DTMF (Touch-Tone) during a call.
1 Touch [Keypad].
The number input screen (Keypad) appears.
2 Input number.
• You can transmit a Touch-Tone signal during a call.
Phone Book Function
Phone Book screen example
Searching in the Phone Book
You can make a call using the phone book search function.
1 Touch [Search] on the Phone Book screen.
The Input User Name screen (Keypad) is displayed.
2 Input the string of letters of the name that
you want to search, then touch [OK].
A list of names beginning with the string of letters you
entered is displayed.
3 Touch [
] of the name or number of the
contact which you want to call.
The phone call is started.
• If there are fewer than five registered items in the phone book,
you cannot use the phone book search function.
Synchronizing the Phone Book
You can synchronize the system’s phone book with the
mobile phone’s phone book.
1 Touch [SYNC] on the Phone Book screen.
The confirmation screen is displayed.
2 Touch [Yes].
Synchronization of the phone books starts.
• You can store up to 1,000 registered name in the phone book.
• You can store up to 5 phone numbers by one person’s name.
49-EN
Deleting the Phone Book Entries
Deleting One Entry from the Phone Book
Touch [
] of the contact name (or phone
number) you want to delete.
The selected number is deleted.
Deleting All Entries from the Phone Book
1 Touch [Delete All] on the Phone Book screen.
The confirmation screen is displayed.
2 Touch [Yes].
All entries of the phone book are deleted.
Setting contacts as Favorites
(Shortcut Dialing)
You can set contacts from the Phone Book, Dialed,
Received, and Missed list as favorites.
1 Touch the name or phone number on the list.
2 Touch [
] of “Favorites.”
The phone number is set as a Favorite.
• Up to 5 contacts can be set as Favorites.
• If [
] has already been set with a number, touching it
overwrites the number.
• To delete a contact from the Favorites list, touch [ ].
Bluetooth Audio
If a Bluetooth compatible mobile phone, portable player,
etc. is connected by wireless, you can play back a song
(operation is controllable from the unit).
• Operation may vary, depending on the Bluetooth compatible
device.
■
Bluetooth Audio main screen example
Information display
Finds the beginning of next chapter/Fast-
forwards when touched for at least 1 second
Shuffle mode
Repeat mode
Displays the Sound Setup Menu screen
(page 24).
Switches to the USB Flash drive or iPod mode of
iPhone.
Disconnects the Bluetooth device
Changes the Bluetooth device.
Pause and Play
Elapsed time/Total time for playing
Current track number/Total track number
Finds the beginning of the current file/Finds a
previous file within one second after playback
starts/Fast-reverses when touched for at least 1
second
• The displayed onscreen buttons may differ depending on the
AVRCP version.
• Song title/Artist title/Album title/Elapsed time do not display
for AVRCP Ver. 1.0.
• To play back audio, a mobile phone or a portable player
conforming to A2DP (Advanced Audio Distribution Profile)
or AVRCP (Audio/Video Remote Control Profile) is required.
Not all functions work with all devices.
• During a call, sound on the Bluetooth audio source is paused.
Compatible AVRCP versions: 1.0, 1.3, 1.4, 1.5
• Available functions may differ depending on the AVRCP
version.
50-EN
Playback
1 Touch the
(HOME) button and select
Bluetooth Audio mode.
The display shows the Bluetooth Audio mode screen.
2 Touch [
] or [ ] to select the desired track
(file).
Returning to the beginning of the current file:
Touch [
].
Fast backward the current file:
Touch and hold [
].
Advance to the beginning of the next file:
Touch [
].
Fast forward the current file:
Touch and hold [
].
3 To pause playback, touch [
].
• When selecting a [Audio] widget on the HOME screen, touch
[Audio Select] to select [BT]. If [BT] is already selected, you
can start playback by selecting a [Audio] widget on the
HOME screen.
Repeat Play
Available for AVRCP Ver. 1.4 and 1.5 only.
Touch [
] repeatedly to select Repeat Play
mode.
File :
Only the track currently playing is repeatedly
played back.
ALL
:
Once all of the songs have finished playing,
play back is repeated, starting with the first
song.
Off
:
Repeat mode is Off.
• Operations may differ depending on the connected Bluetooth
compatible device.
Shuffle Play
Available for AVRCP Ver. 1.4 and 1.5 only.
Touch [
] to select Shuffle Play mode.
ALL
:
All songs in the Bluetooth compatible
devices are played back in random sequence.
Any one song does not play back again until
all songs have been played back.
Off
:
Shuffle mode is Off.
• Operations may differ depending on the connected Bluetooth
compatible device.
Connecting a Bluetooth Device
Registering a Bluetooth device in the unit enables
automatic connection.
If it does not connect automatically, run through the
connection procedure again.
Touch [Reconnect] on the Bluetooth Audio
screen.
The Bluetooth connection will start.
Disconnecting the Bluetooth
Connection
Touch [Disconnect] on the Bluetooth Audio
screen.
The Bluetooth connection is disconnected.
Switching the connecting Bluetooth
Device
If multiple Bluetooth devices are registered in this device,
you can change the connection among the registered
devices.
1 Touch [Change Device] on the Bluetooth
Audio screen.
2 Touch the device name.
The connection will transfer to the selected device.
51-EN
Auxiliary Device
(Optional)
Operating Auxiliary Devices
(Optional)
To operate devices connected to the AUX terminals of the
unit, follow the procedure described below.
• Set up the “AUX Setup” (page 16).
• Depending on the connected unit, the onscreen buttons may
not work, or their operation may differ.
WARNING
It is dangerous (and illegal in many states) for the
driver to watch video while driving the vehicle. The
driver may be distracted from looking ahead and an
accident could occur.
Install the unit correctly so that the driver cannot
watch video unless the car is stopped and the
parking brake is applied.
If the unit is not installed correctly, the driver will be
able to watch video while driving and may be
distracted from looking ahead and cause an
accident. The driver or other people could be
severely injured.
1 Touch the
(HOME) button to select
Auxiliary (AUX) mode.
The display shows the Auxiliary (AUX) mode screen.
• When AUX Select is set to “Factory Media + Drive Recorder”,
only the video will be displayed. Audio will not be played. For
details, see “Setting the AUX Select” (
page 16).
• For your safety, video is not displayed and only audio can be
heard while driving.
• For details on the connected auxiliary device, refer to its
owner’s manual.
Setting the Brightness and Contrast
1 Touch [Visual].
2 Touch [
] or [ ] to adjust the Brightness and
Contrast.
: Adjusting the Brightness
: Adjusting the Contrast
52-EN
Camera Operation
(Optional)
When an optional camera is connected, the view video of
camera can be output to the monitor.
Rear camera:
If a rear camera is connected, when the vehicle is reversed,
the rear camera view (guide marks for vehicle width and
available distance) is displayed automatically on the screen
of this unit.
Front camera:
If a front camera is connected, it can assist to check the
condition in front of the car, such as when the road visibility
is bad.
You can adjust the quality of the camera image.
Setting items: Brightness / Color / Contrast
See “Camera Picture Quality Setup” (
page 22).
Rear Camera Operation
Displaying the Camera Image from the
HOME screen
1 Touch the
(HOME) button.
The HOME screen is displayed.
[Camera[Rear]] button
• If [Camera Select] in the Rear Camera setting is set to
[Off] (
page 21), the [Camera[Rear]] button cannot
be selected.
2 Touch [Camera[Rear]].
The Rear Camera view image is displayed.
• Touch [
] to return to the main source screen or previous
screen.
• You can perform a Guide Adjustment for the rear view image.
For details, see “About the Rear Camera Guide” (
page 52).
Displaying the rear view video while
the car is in reverse
1 Shift the gear lever to the reverse (R) position.
The rear view image is displayed while the car remains
in reverse.
2 If you shift the gear lever to a position other
than reverse (R), the monitor returns to the
previous screen.
• Never depend solely on the camera when backing up. Always
turn and look and only use the camera for additional
assistance.
• This function is effective when the reverse wire is properly
connected.
• Touch [
] to return to the main source screen or previous
screen.
• You can perform a Guide Adjustment for the rear view image.
For details, see “About the Rear Camera Guide” (
page 52).
About the Rear Camera Guide
To display the guide, set “Turning the Rear Camera Guide
On/Off” (
page 22) to On. Also, to adjust the guide, see
“Rear Camera Guide Settings” (
page 22).
■
Indication mark meaning
When the car is put into reverse gear, the monitor switches
to the rear view camera image. Guides appear to help
visualize the car’s width and distance from the rear bumper.
Car width extension lines (red, yellow and
green in order of distance)
If properly calibrated, the marks indicate the car’s width.
This helps guide the car’s path when backing up in a
straight line.
The marks represent the distance from the rear of the
car (from the rear end of the bumper).
• The marks do not move in synchronization with the
steering wheel.
• Set the marks to suit the car’s width.
53-EN
Distance guidance lines
The marks represent the distance from the rear of the
car (from the rear end of the bumper).
• The marks do not move in synchronization with the
steering wheel.
• We recommend that you measure the actual distance
to the marks when parked on a level surface.
• Depending on the condition of the car or road surface, the
range of vision may vary.
• The camera has a limited range of vision. Objects at extreme
angles to the camera (e.g. under the bumper or at opposite
ends of the bumper) may not be in the its field-of-vision.
• The rear camera image may have a tint which is different
from the actual surroundings.
• Depending on the car, the guidance may deviate to the right
or left. This is not a malfunction.
■
Distance guidance mark
The distance guides represent the ground level distance
from the rear bumper. It is difficult to accurately estimate
the distance to objects above ground level.
In the following example, the distance to A is 0.5 m and the
distance to B is 1 m.
<Screen>
C
B
A
(about
0.5 m)
<Positions of A, B and C>
about 1 m
In the screen, according to the distance guidance marks,
the truck seems to be parked about 1 m away (at the
position B). In actual fact, however, if you reversed to
position A, you would collide with the truck.
In the screen, positions A, B and C seem to be located in
order of proximity. However, in actual fact, the position
A and C are the same distance, and B is farther away
than positions A and C.
• The car width extension mark represents the distance to the
road surface. The distance to an object on the road is not
accurately represented by the guides.
Error between the screen and the actual road
surface
In the following conditions, errors are produced between
the screen guidance and the actual road surface. (The
illustrations represent a case when the camera is installed in
the standard position.)
■
When there is a steep upward slope behind
the car (example)
<Screen>
Distance guidance marks
<Situation of the car>
Actual distances
Error Error
The distance guidance mark represents the distance to a
flat road surface. Therefore in the case of an upward
slope behind the car, the distance guides are displayed
closer to the rear bumper than the actual distance. For
example, if there is an obstacle on the upward slope, it
may appear farther away than its actual position.
Also, an error may occur between the guidance and the
actual path of the car on the road surface.
54-EN
■
When there is a steep downward slope behind
the car (example)
<Screen>
<Situation of the car>
Error Error
In the case of a downward slope behind the car, the
distance guides are displayed farther from the rear
bumper than the actual distance.
If there is an obstacle on the downward slope, it seems
closer than its actual position.
Also, an error may occur between the guidance and the
actual path of the car on the road surface.
Front Camera Operation
Displaying the Camera Image from the
HOME screen
1 Touch the
(HOME) button.
The HOME screen is displayed.
[Camera[Front]] button
• If [Camera Select] in the Front Camera setting is set
to [Off] (
page 23), the [Camera[Front]] button
cannot be selected.
2 Touch [Camera[Front]].
The Front Camera view image is displayed.
• Touch [
] to return to the main source screen or previous
screen.
55-EN
iDataLink Operation
When the unit is connected to the car’s iDataLink module,
you can transfer and receive data between the car and the
unit to check the car’s status, or to make various operations
from the unit.
• An iDataLink module (sold separately) is required.
• Available functions differ depending on your vehicle. For
details, refer to your vehicle’s instruction manual.
About Audio Interrupt
Audio Interrupt is the function that outputs sound from the
unit when Voice Information (audio reading from the phone
book, etc.)* from the vehicle occurs.
• The Audio Interrupt function of the vehicle differs depending
on the type and grade of the vehicle.
∗ For your safety, when interrupted with Voice Information,
you cannot operate the buttons on the front panel or the
touch buttons on the display, except for some operations.
– The operating restrictions may differ depending on
which mode the unit is in during Voice Information.
– You can use the [
] / [ ] (UP/DOWN) button to
control the volume of Voice Information.
Access to iDataLink Mode
You can check the car’s status, set the air conditioning, etc.
1 Touch the
(HOME) button to select Vehicle
info mode.
• The iDataLink mode screen selected in “Setting the
Default Vehicle Screen” (
page 19) is displayed.
2 Touch the desired tag on the top of the
screen.
Select item:
Climate / Gauges / Park Sensor / Vehicle Info. / Car
Setting
• The displayed tag options differ depending on the type of
vehicle.
3 Adjust or confirm the item/information
accordingly.
• Operable functions and displays may differ depending on the
vehicle.
iDataLink Function Screen example
■
Climate screen example
You can control the temperature inside the vehicle, etc.
■
Gauges screen example
You can check the vehicle’s speed, the engine’s rotation
speed, etc.
■
Parking sensor screen example
You can check the distance from the front and rear of the
vehicle to an obstacle.
• If the car sensor detects an obstacle, the screen automatically
changes to the Parking sensor screen. For details, see “About
Parking Sensor screen” (
page 56).
56-EN
■
Vehicle Information screen example
You can check for open doors, check the tire pressure, the
battery life, etc. for the vehicle.
■
Car Setting screen example (Generic List
screen)
The Generic List/Popup Window/Current source control
screen is displayed.
About Parking Sensor screen
The Parking sensor screen turns on when the front or rear
sensor on your vehicle detects an obstacle within a certain
distance.
Parking Sensor Full screen example
When the front or rear sensor detects an obstacle within a
certain distance, the Parking Sensor screen is displayed, and
the indicator (
- ) that corresponds with that area lights
up.
Indicator colors when an obstacle is detected.
Red: close distance
Orange: medium distance
Yellow: long distance
• Depending on the speed of the vehicle, when moving faster
than a certain speed, the Parking Sensor screen may not be
displayed.
• Vehicles that do not have the obstacle detection sensor cannot
use this function.
Parking Sensor Camera interlock screen example
(Rear camera)
You can check for obstacles through an interlocked camera
image by connecting a Rear Camera or Front Camera.
• Touch the Camera image area to switch to the Camera full
screen.
(While displaying the Camera full screen, touch the Camera
screen, then touch [
] to return to the Parking Sensor
Camera interlock screen.)
• Touch the car icon to switch to the Parking sensor full screen.
(Touch [
] on the Parking Sensor full screen to return to
the Parking Sensor Camera interlock display.)
• To use this function, set the Camera Select setting of the Rear
Camera and Front Camera, to “Rear” or “Front”. For details,
see “Camera Input Setting” (
page 21 or page 23).
Factory Media Operation
You can operate the Factory Audio (USB/iPod/Bluetooth
Audio) from this unit.
Touch the
(HOME) button to select Factory
Media mode.
The display shows the Factory Media mode screen.
• For the basic operations on Factory Media mode, refer to
“USB Audio” (
page 35), “iPod mode on iPhone (Optional)”
(
page 39) and “Bluetooth Audio” (page 49).
Swipe to the right or left to change to the Function mode.
• Available functions differ depending on your vehicle.
57-EN
Factory SiriusXM Operation
You can operate the Factory SiriusXM from this unit.
Touch the (HOME) button to select Factory
SiriusXM mode.
The display shows the Factory SiriusXM mode screen.
• For the basic operations on Factory SiriusXM mode, refer to
“SiriusXM Satellite Radio Operation (Optional)” (
page 41).
Swipe to the right or left to change to the Function mode.
• Available functions differ depending on your vehicle.
Information
Product Software Update
This product use software that can be updated through a
USB flash drive. Download the software from the Alpine
website and update the product using the USB flash drive.
Updating this product
Check the Alpine website for details on updating.
http://www.alpine-usa.com
Important information on the software
About the software license of the product
The software installed in the product contains open-source
software.
For details, refer to the “Open source licenses” screen on this
unit. See “Displaying Warranty/Copyright Information”
(
page 18).
About the Supported Formats
About MP3/WMA/AAC/FLAC/WAV
CAUTION
Except for private use, duplicating audio data
(including MP3/WMA/AAC/FLAC/WAV data) or
distributing, transferring, or copying it, whether for
free or for a fee, without permission of the copyright
holder is strictly prohibited by the Copyright Act
and by international treaty.
What is MP3?
MP3, whose official name is “MPEG Audio Layer 3,” is a
compression standard prescribed by the ISO, the
International Standardization Organization and MPEG
which is a joint activity institution of the IEC.
MP3 files contain compressed audio data. MP3 encoding
is capable of compressing audio data at extremely high
ratios, reducing the size of music files to as much as
one-tenth their original size. This is achieved while still
maintaining near CD quality. The MP3 format realizes
such high compression ratios by eliminating the sounds
that are either inaudible to the human ear or masked by
other sounds.
What is WMA?
WMA, or “Windows Media™ Audio,” is compressed audio
data.
WMA is similar to MP3 audio data.
What is AAC?
AAC is the abbreviation for “Advanced Audio Coding,”
and is a basic format of audio compression used by
MPEG2 or MPEG4.
58-EN
What is FLAC?
FLAC (Free Lossless Audio Codec) is an audio file codec
for lossless compression, developed and offered as open
source software.
Codecs with lossy compression forms, such as MP3 and
AAC, reduce part of the data to improve compression
efficiency.
However, FLAC can reconstruct compressed data to be
an identical copy of the original data by performing
lossless compression. The compression ratio of FLAC is
about 50%.
Method for creating MP3/WMA/AAC/FLAC/WAV (USB
Flash drive) files
Audio data is compressed using software with MP3/
WMA/AAC/FLAC/WAV (USB Flash drive) codecs. For
details on creating MP3/WMA/AAC/FLAC/WAV (USB
Flash drive) files, refer to the user’s manual for that
software.
MP3/WMA/AAC/FLAC/WAV (USB Flash drive) files that
are playable on this device have the file extensions.
MP3: “mp3”
WMA: “wma”
AAC: “m4a”
FLAC: “flac”/”fla”
WAV: “wav”
WMA is not supported for the following files, Windows
Media Audio Professional, Windows Media Audio 10 std
or Windows Media Audio 10 Pro Lossless.
There are many different versions of the AAC format.
Confirm that the software being used conforms to the
acceptable formats listed above. It’s possible that the
format may be unplayable even though the extension is
valid.
Playback of AAC files encoded by iTunes is supported.
Supported playback sampling rates and bit rates
MP3 (USB Flash drive)
Sampling rates: 8 kHz, 11.025 kHz, 12 kHz,
16 kHz, 22.05 kHz, 24 kHz,
32 kHz, 44.1 kHz, 48 kHz
Bit rates: 8 - 320 kbps
WMA (USB Flash drive)
Sampling rates: 8 - 48 kHz
Bit rates: 8 - 384 kbps
AAC (USB Flash drive)
Sampling rates: 8 - 48 kHz
Bit rates: 8 - 384 kbps
FLAC (USB Flash drive)
Sampling rates: 8 - 48 kHz
Bit rates: 8 - 384 kbps
WAV (USB Flash drive)
Sampling rates: 8 - 48 kHz
Bit rates: 64 - 1,536 kbps
This device may not play back correctly depending on
sampling rates.
ID3 tags/WMA tags
This device supports ID3 tag v1.0, v1.1, v2.2, v2.3, v2.4,
and WMA tag Ver.1.x. If tag data is in an MP3/WMA/AAC
file, this device can display the title (track title), artist
name, and album name ID3 tag/WMA tag data.
For non-supported characters, “?” is displayed.
The number of characters may be limited, or not
correctly displayed, depending on the tag information.
Playing back MP3/WMA/AAC/FLAC/WAV
MP3/WMA/AAC files are prepared, then written to a USB
flash drive.
• Maximum numbers of playable files/folders
USB Flash drive: 10,000 files/folders (including Root
Folder)
• Largest playable file size: 512 MB
Playback may not be performed if a USB flash drive
exceeds the limitations described above.
If a file/folder name is long, the maximum possible
number of files may decrease.
• Both Audio and Video files are counted if their formats
are playable on this unit.
Media supported
The media that this device can play back a USB flash
drive.
Corresponding File Systems
This device supports FAT 16/32.
The maximum nested folder depth is 8 (including the
root directory). File names are limited to 256 characters
(including the extension).
Valid characters for folder/file names are letters A-Z (all
caps), numbers 0-9, and ‘_’ (underscore).
Order of files
Files are played back in the order that the writing
software writes them to the USB flash drive. Therefore,
the playback order may not be what’s expected. Verity
the writing order in the software’s documentation. The
playback order of the folders and files is as follows. (The
following numbers may differ from actually displayed
numbers.)
59-EN
Root
Folder
Folder
MP3/WMA/AAC/
FLAC/WAV File
Terminology
Bit rate
This is the “sound” compression rate specified for
encoding. The higher the bit rate, the higher the sound
quality, but also the larger the files.
Sampling rate
This value shows how many times per second the data is
sampled (recorded). For example, music CDs use a
sampling rate of 44.1 kHz, so the sound is sampled
(recorded) 44,100 times per second. The higher the
sampling rate, the higher the sound quality, but also the
larger the volume of data.
Encoding
Converting music CDs, WAVE (AIFF) files, and other
sound files into the specified audio compression format.
Tag
Song information such as track titles, artist names,
album names, etc., written into MP3/WMA/AAC/FLAC/
WAV (USB flash drive) files.
Root folder
The root folder (or root directory) is found at the top of
the file system. The root folder contains all folders and
files. It is created automatically for all USB flash drive.
In Case of Difficulty
If you encounter a problem, please turn the power
off, then on again. If the unit is still not functioning
normally, please review the items in the following
checklist. This guide will help you isolate the
problem if the unit is at fault. Otherwise, make sure
the rest of your system is properly connected, or
then consult your authorized Alpine dealer.
Basic
No function or display.
• Vehicle’s ignition is off.
– If connected according to the instructions, the unit will
not operate with the vehicle’s ignition off.
• Improper power lead connections.
– Check power lead connections.
• Blown fuse.
– Check the fuse on the battery lead of the unit; replace
with the proper value if necessary.
No sound or unnatural sound.
• Incorrect setting of volume/balance/fader controls.
– Readjust the controls.
• Connections are not properly or securely made.
– Check the connections and firmly connect.
Screen not displayed.
• Brightness/Contrast control is set at the minimum
position.
– Adjust the Brightness/Contrast control.
• Temperature in the vehicle is too low.
– Increase the vehicle’s interior temperature to operation
temperature range.
• Connections to the Auxiliary Device are not securely
made.
– Check the connections and firmly connect.
• The Parking Brake Lead is not connected.
• The Parking Brake is not engaged.
– Connect the Parking Brake Lead, then engage the
Parking Brake.
Movement of displayed picture is abnormal.
• Temperature in the vehicle is too high.
– Allow the vehicle’s interior temperature to cool.
Radio
Unable to receive stations.
• No antenna, or open connection in the antenna cable.
– Make sure the antenna is properly connected; replace
the antenna or cable if necessary.
60-EN
Unable to tune stations in the seek mode.
• You are in a weak signal area.
– Make sure the tuner is in DX mode.
• If the area you are in is a primary signal area, the antenna
may not be grounded and connected properly.
– Check your antenna connections; make sure the
antenna is properly grounded at its mounting location.
• The antenna may not be the proper length.
– Make sure the antenna is fully extended; if broken,
replace the antenna with a new one.
Broadcast is noisy.
• The antenna is not the proper length.
– Extend the antenna fully; replace it if it is broken.
• The antenna is poorly grounded.
– Make sure the antenna is grounded properly at its
mounting location.
• The station signal is weak and noisy.
– If above solution does not work, tune in another station.
USB Audio
Unit does not operate.
• Condensation.
– Wait a while (about 1 hour) for the condensation to dry.
Picture is unclear or noisy.
• Vehicle’s battery power is weak.
– Check the battery power and wiring.
(The unit may malfunction if the battery power is under
11 volts with a load applied.)
Handsfree Phone
Ringtone is small
• Depending on your phone, the ringtone volume may be
small, it is not a failure.
If this Message Appears
Various messages are displayed on the screen during
operation. In addition to the messages telling you the
current status or providing guidance for the next operation,
there are also the following error messages. If one of these
error messages is displayed, carefully follow the instructions
in the solution column.
System
This operation is prohibited for your safety.
• A setup operation, etc., was carried out while the vehicle
was running.
– Move the vehicle to a safe location, stop, and engage
the parking brake, then carry out this operation.
Unsupported USB device connected.
• A USB flash drive with a hub is connected.
– You cannot play back from a USB flash drive with a hub.
USB hub connections are also not supported.
Audio/Visual
Unsupported USB device connected.
• An iPhone that is not supported by the unit is connected.
– Connect an iPhone that is supported by the unit.
• A USB device that is not supported by the unit is
connected.
– Attempt to connect another USB flash drive.
• Communication error.
– Turn the ignition key off, and then set to ON again.
– Check the display by reconnecting between the iPhone
and the unit, using the iPhone cable.
– Check the display by reconnecting between the USB
flash drive and the unit.
• Caused by the iPod/iPhone Software Version not being
compatible with this unit.
– Update the iPhone Software Version to be compatible
with this unit.
• The iPhone is not verified.
– Change to another iPhone.
No Song
• There are no data in the iPhone.
– Download data to the iPhone and connect to the unit.
No File
• There are no data in the USB flash drive.
– Download data to the USB flash drive and connect to
this unit.
File format not supported.
• A copy-protected WMA file has been detected.
– You can only play back non-copy-protected files.
• A sampling rate/bit rate not supported by the unit is used.
– Use a sampling rate/bit rate supported by the unit.
Bluetooth
No Bluetooth
• The Bluetooth audio device was not connected correctly.
– Check the settings for the unit and the Bluetooth audio
device and reconnect.
SiriusXM
Check Tuner
• The SiriusXM Tuner is disconnected or the unit is having
trouble communicating with the Tuner.
– Connect the Tuner or check the Tuner connection to the
back of the unit.
61-EN
Check Antenna
• The SiriusXM Satellite Radio antenna or cable is either
damaged or not connected correctly to the SiriusXM
Tuner.
– Check that the SiriusXM antenna cable is connected to
the SiriusXM Tuner and check that the antenna cable is
not kinked or otherwise damaged. Replace the antenna
if necessary.
– SiriusXM products are available at your local car audio
retailer or online at www.shop.siriusxm.com.
No Signal
• The SiriusXM satellite signal is too weak at the current
location.
– Move the vehicle to a location with a clear view of the
southern sky.
– Make sure the Satellite Radio antenna is properly
mounted and not obstructed by metal objects.
Channel Not Subscribed
Call SiriusXM to Subscribe
• The active channel has become unsubscribed or the
requested channel is not available in your subscription
package.
– In the U.S.A., visit www.siriusxm.com or call 1-866-635-
2349 if you have questions about your subscription
package or would like to subscribe to this channel. In
Canada, visit www.siriusxm.ca or call 1-877-438-9677.
– The unit will revert to the previously selected channel
or to channel 1 automatically.
Channel <xxx> Not Available
• The active channel is no longer in the SiriusXM channel
lineup or the user has entered an invalid channel number.
– Visit www.siriusxm.com for information on the current
channel lineup.
• The unit will revert to the previous channel or to channel
1 automatically.
Subscription Updated
Press Any Key to Continue
• Your subscription has been updated.
– Touch [OK] to clear this message.
Channel <xxx> Locked
• A locked channel is selected.
– Input the passcode on the number keypad screen, see
“Parental Lock Function” (
page 43). If wrong passcode
is entered, “Incorrect Pass Code entered” will be
displayed and the unit will revert to the previous
channel.
Specifications
MONITOR SECTION
Screen Size 6.95”
LCD Type Transparent type TN LCD
Operation System TFT active matrix
Number of Picture Elements
1,152,000 pcs.
(800 × 480 × 3 (RGB))
Effective Number of Picture Elements
99% or more
Illumination System LED
FM TUNER SECTION
Tuning Range 87.7 – 107.9 MHz
Mono Usable Sensitivity
9.3 dBf (0.8 µV/75 ohms)
50 dB Quieting Sensitivity
13.5 dBf (1.3 µV/75 ohms)
Alternate Channel Selectivity
80 dB
Signal-to-Noise Ratio
65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
AM TUNER SECTION
Tuning Range 530 – 1,710 kHz
Usable Sensitivity 25.1 μV/28 dBf
HD RADIO SECTION
HD Sensitivity FM: 83 dBm
AM: 90 dBm
Distortion 0.3 %
Separation 65 dB
HD RADIO SECTION
HD Sensitivity FM: 83 dBm
AM: 90 dBm
Distortion 0.3 %
Separation 65 dB
62-EN
USB SECTION
USB requirements USB 2.0
Max. Power Consumption
1,500 mA (CDP Support)
USB Class USB (Play From Device)/
USB (Mass Storage Class)
File System FAT16/32
Number of Channels
2-Channels (Stereo)
Frequency Response*
1
5 – 20,000 Hz (±1 dB)
Total Harmonic Distortion
0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio
100 dB
Channel Separation 85 dB (at 1 kHz)
*1 Frequency response may differ depending on the
encoder software/bit rate.
HDMI SECTION
Input Format 720p/480p/VGA
Bluetooth SECTION
Bluetooth Specification
Bluetooth V4.1
Output Power +4 dBm Ave. (Power class 2)
Profile HFP (Hands-Free Profile)
PBAP (Phone Book Access Profile)
A2DP (Advanced Audio
Distribution Profile)
AVRCP (Audio/Video Remote
Control Profile)
GENERAL
Power Requirement 14.4 V DC
(11–16 V allowable)
Operating temperature
-4°F to +140°F
(-20°C to + 60°C)
Power Output 16 W RMS × 4*
2
*2 Primary amplifier ratings per CEA-2006 Standard
• Power output: measured at 4 Ohms and ≤ 1% THD+N
• S/N: 70 dBA (reference: 1 W into 4 Ohms)
Weight 1.0 kg (2 lbs. 3.3 oz)
Audio output level Preout (Front, Rear): 4V/10k
ohms (max.)
Preout (Subwoofer): 4V/10k
ohms (max.)
CHASSIS SIZE
Width 178 mm (7”)
Height 100 mm (4”)
Depth 60 mm (2-6/16”)
• Due to continuous product improvement, specifications and
design are subject to change without notice.
• The LCD panel is manufactured using an extremely high
precision manufacturing technology. Its effective pixel ratio is
over 99.99%. This means that there is a possibility that 0.01%
of the pixels could be either always ON or OFF.
63-EN
Installation and Connections
Before installing or connecting the unit, please read the
following and pages 6 to 8 of this manual
thoroughly for proper use.
WARNING
KEEP SMALL OBJECTS SUCH AS SCREWS OUT OF THE
REACH OF CHILDREN.
Swallowing them may result in serious injury. If swallowed,
consult a physician immediately.
MAKE THE CORRECT CONNECTIONS.
Failure to make the proper connections may result in fire or
product damage.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.
(Check with your dealer if you are not sure.) Failure to do so
may result in fire, etc.
BEFORE WIRING, DISCONNECT THE CABLE FROM THE
NEGATIVE BATTERY TERMINAL.
Failure to do so may result in electric shock or injury due to
electrical shorts.
DO NOT ALLOW CABLES TO BECOME ENTANGLED IN
SURROUNDING OBJECTS.
Arrange wiring and cables in compliance with the manual
to prevent obstructions when driving. Cables or wiring that
obstruct or hang up on places such as the steering wheel,
gear lever, brake pedals, etc. can be extremely hazardous.
DO NOT SPLICE INTO ELECTRICAL CABLES.
Never cut away cable insulation to supply power to other
equipment. Doing so will exceed the current carrying
capacity of the wire and result in fire or electric shock.
DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING
HOLES.
When drilling holes in the chassis for installation, take
precautions so as not to contact, damage or obstruct pipes,
fuel lines, tanks or electrical wiring. Failure to take such
precautions may result in fire.
DO NOT USE BOLTS OR NUTS IN THE BRAKE OR
STEERING SYSTEMS TO MAKE GROUND CONNECTIONS.
Bolts or nuts used for the brake or steering systems (or any
other safety-related system), or tanks should NEVER be used
for installations or ground connections. Using such parts
could disable control of the vehicle and cause fire etc.
DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER
VEHICLE OPERATION, SUCH AS THE STEERING WHEEL
OR GEARSHIFT.
Doing so may obstruct forward vision or hamper movement
etc. and results in serious accident.
CAUTION
HAVE THE WIRING AND INSTALLATION DONE BY
EXPERTS.
The wiring and installation of this unit requires special
technical skill and experience. To ensure safety, always
contact the dealer where you purchased this product to
have the work done.
USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM
SECURELY.
Be sure to use only the specified accessory parts. Use of
other than designated parts may damage this unit
internally or may not securely install the unit in place. This
may cause parts to become loose resulting in hazards or
product failure.
ARRANGE THE WIRING SO IT IS NOT CRIMPED OR
PINCHED BY A SHARP METAL EDGE.
Route the cables and wiring away from moving parts (like
the seat rails) or sharp or pointed edges. This will prevent
crimping and damage to the wiring. If wiring passes
through a hole in metal, use a rubber grommet to prevent
the wire’s insulation from being cut by the metal edge of
the hole.
DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE
OR DUST.
Avoid installing the unit in locations with high incidence of
moisture or dust. Moisture or dust that penetrates into this
unit may result in product failure.
Precautions
• Be sure to disconnect the cable from the (–) battery post
before installing your unit. This will reduce any chance of
damage to the unit in case of a short-circuit.
• Be sure to connect the color coded leads according to the
diagram. Incorrect connections may cause the unit to
malfunction or damage to the vehicle’s electrical system.
• When making connections to the vehicle’s electrical
system, be aware of the factory installed components (e.g.
on-board computer). Do not tap into these leads to
provide power for this unit. When connecting the unit to
the fuse box, make sure the fuse for the intended circuit
of the unit has the appropriate amperage. When in doubt,
consult your Alpine dealer.
• The unit uses female RCA-type jacks for connection to
other units (e.g. amplifier) having RCA connectors. You
may need an adaptor to connect other units. If so, please
contact your authorized Alpine dealer for assistance.
• Be sure to connect the speaker (–) leads to the speaker (–)
terminal. Never connect left and right channel speaker
cables to each other or to the vehicle body.
64-EN
Accessory List
Main unit ................................................................................................. 1
Quick Reference Guide
................................................................. 1set
<Cables>
Power cable
............................................................................................ 1
USB extension cable
............................................................................1
PRE OUT cable
....................................................................................... 1
Microphone
............................................................................................1
CAN Interface Connector
..................................................................1
<Main unit mounting parts>
Screw (M5×8)
.........................................................................................4
Installation
Caution
• Do not block the unit’s fan, thus preventing air
circulation. If blocked, heat will accumulate inside the
unit and may cause a fire.
Heat sink
Rear of the Unit
Caution concerning the installation
location
Angle of installation
Install at an angle between horizontal and 30°. Note that
installing at an angle outside of this range will result in a
loss of performance and possibly damage.
0 - 30°
Mounting the Microphone
For safe use, make sure of the following:
• Location is stable and firm.
• Does not interfere with safety equipment.
• Driver’s view and operations are not obstructed.
• Microphone is located where the driver’s voice can be
easily picked up (for example, on the sun visor).
When you speak into the microphone, you should not have
to change your driving posture. This may cause a
distraction, taking your attention away from safely driving
your vehicle. Carefully consider direction and distance while
mounting the microphone. Confirm that the driver’s voice
can be easily picked up at the selected location.
Microphone
Cable clamp
(sold separately)
Installation example using the
Original Mounting Bracket
1 Mount the original mounting bracket to the
unit using the supplied screws.
Original Mounting Bracket
Ground Lead*
Chassis
Screws (M5×8)
(included)
2 Connect all other leads of the unit according
to details described in the “Connections”
(
page 65).
3 Mount the unit in a car.
* To securely connect the ground lead, use an already
installed screw on a metal part of the vehicle (marked
(
)) or a clean, bare metal spot on the vehicle’s
chassis.
• Fix the cables carefully. Do not damage them by
mounting them into movable parts, such as the seat
rail, or by locating them against sharp or pointed
edges.
4 Reattach the removed vehicle parts (panels,
etc.) or other aftermarket dash kit back onto
the vehicle.
65-EN
Connections
(12 Violet)
USB extension cable (included)
REMO
(10 Blue/White)
REVERSE
(2 Orange/White)
P. ANT
(9 Blue)
PARKING BRAKE
(11 Yellow/Blue)
ACC
(1 Red)
BATT
(16 Yellow)
GND
(8 Black)
(14 Green)
(15 Green/Black)
(6 White)
(7 White/Black)
(5 Gray/Black)
(4 Gray)
(13 Violet/Black)
PRE OUT cable
Power cable
REAR VIEW CAMERA
FRONT VIEW CAMERA
SUBW
FRONT OUT
REAR OUT
Vehicle Antenna
Microphone (included)
To USB flash drive, iPhone or
Android smartphone
To amplifier or equalizer
To plus side of the back lamp
signal lead of the car
To power antenna
To the parking brake signal lead
Ignition key
To input terminal of amplifier
when adding an external
amplifier
Battery
Rear Left
Front Left
Front Right
Rear Right
Speakers
To RCA Rear camera
To RCA Front camera
CAN Interface Connector (included)
To Interface Box
VIDEO IN
VIDEO OUT
VIDEO IN/OUT cable
To drive recorder, DVD player, etc.
To Rear monitor
To AUX output device or iDataLink
module (Audio only, no Video)
AUX INPUT
66-EN
Radio Antenna Receptacle
Video Input Lead
Video Output Lead
Remote Turn-On Lead (Blue/White)
Connect this lead to the remote turn-on lead of your
amplifier or signal processor.
Reverse Lead (Orange/White)
Power Antenna Lead (Blue)
Connect this lead to the +B terminal of your power
antenna, if applicable.
* This lead should be used only for controlling the
vehicle’s power antenna. Do not use this lead to turn
on an amplifier or a signal processor, etc.
Parking Brake Lead (Yellow/Blue)
Connect this lead to the power supply side of parking
brake switch to transmit the parking brake status signals
to the unit.
Switched Power Lead (Ignition) (Red)
Connect this lead to an open terminal on the vehicle’s
fuse box or another unused power source that provides
(+) 12V only when the ignition is turned on or in the
accessory position.
Fuse Holder (15A)
Battery Lead (Yellow)
Connect this lead to the positive (+) post of the vehicle’s
battery.
Ground Lead (Black)
Connect this lead to a good chassis ground on the
vehicle.
Make sure the connection is made to bare metal and is
securely fastened using the sheet metal screw provided.
Left Rear (+) Speaker Output Lead (Green)
Left Rear (–) Speaker Output Lead (Green/Black)
Left Front (+) Speaker Output Lead (White)
Left Front (–) Speaker Output Lead (White/Black)
Right Front (–) Speaker Output Lead (Gray/Black)
Right Front (+) Speaker Output Lead (Gray)
Right Rear (–) Speaker Output Lead (Violet/Black)
Right Rear (+) Speaker Output Lead (Violet)
AUX Input Connector
Input lead for AUX audio signal or iDataLink audio
signal.
• A separately sold AV/RCA interface cable (3-pole mini
AV plug to 2-RCA) is required. For details on using an
AV/RCA interface cable (3-pole mini AV plug to 2-RCA),
see “Usable AV/RCA Interface Cable (3-pole mini AV
plug to 2-RCA)” (
page 67).
REAR CAMERA Input RCA Connector
Use when connecting a rear camera with RCA Output
Connector.
FRONT CAMER Input RCA Connector
Use when connecting a front camera with RCA Output
Connector.
Subwoofer RCA Connectors
Front Output RCA Connectors
Can be used as Front Output RCA Connectors. RED is
right and WHITE is left.
Rear Output RCA Connectors
Can be used as Rear Output RCA Connectors. RED is
right and WHITE is left.
USB Connector
To USB flash drive, iPhone or Android smartphone.
HDMI Input Connector
• To connect to the HDMI Input Connector, use an
optional HDMI cable with an L-Type (270 degree)
connector.
• Please take note of the size of the HDMI cable’s L-Type
connector. An HDMI cable with a connector exceeding
this size will not be able to connect, as it will interfere
with the peripheral cables, stacking amplifiers, etc.
28.9 mm or less
21 mm
or less
2.5 mm or less
28 mm
or less
VIDEO Input/Output Connector
MAESTRO Connector
To Interface Box.
67-EN
MIC Input Connector
To microphone (included)
Steering Remote Control Interface Connector
To steering remote control interface.
For details about connections, consult your nearest
Alpine dealer.
SiriusXM Tuner Input Connector
To SiriusXM Tuner (sold separately).
• For more information on how to install the SiriusXM
Connect Vehicle tuner, consult the installation guide
included with the tuner.
AUX/PRE OUT/CAMERA Connector
Power Supply Connector
Usable AV/RCA Interface Cable (3-pole mini AV
plug to 2-RCA)
Wiring convention of this system is as follows;
Audio L (White)
Audio R (Red)
Ground
(Red)
(White)
Audio input
terminal (R, L)
• Configuration commercially available 3-pole mini AV plugs is
not standardized.
68-EN
If an ACC power supply is not available
Connection Diagram of SPST Switch (sold separately)
BATTERY
iLX-407
(Red)
ACC
Battery
(Yellow)
SPST SW (Optional)
FUSE (20A)
(Optional)
FUSE (5A)
(Optional)
• If your vehicle has no ACC power supply, add an SPST (single-pole, single-throw) switch (sold separately) and fuse (sold separately).
• The diagram and the fuse amperage shown above are in the case when the unit is used individually.
• If the switched power (ignition) lead of the unit is connected directly to the positive (+) post of the vehicle’s battery, the unit draws
some current (several hundred milliamperes) even when its switch is placed in the OFF position, and the battery may be discharged.
IMPORTANT
Please record the serial number of your unit in the space
provided below and keep it as a permanent record. The
serial number plate is located on the bottom of the unit.
SERIAL NUMBER:
INSTALLATION DATE:
INSTALLATION TECHNICIAN:
PLACE OF PURCHASE:
To prevent external noise from entering the audio system.
• Locate the unit and route the leads at least 10 cm away from the car harness.
• Keep the battery power leads as far away from other leads as possible.
• Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis.
• If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries
various noise suppressors, contact them for further information.
• Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.
69-EN
System Example
Connection of an iPhone
■
When connecting to an iPhone with a Lightning connector
USB connector
USB extension cable (included)
iPhone with a Lightning
connector
(sold separately)
Lightning to USB Cable
KCU-471i (sold separately)
• Do not leave an iPhone in a vehicle for a long time. Heat and humidity may damage the iPhone, and you may not be able to play it
again.
Connection of a USB Flash Drive
USB Flash Drive
(sold separately)
USB connector
USB extension cable (included)
• Do not leave a flash drive in a vehicle for a long time. Heat and humidity may damage the flash drive.
70-EN
Connection of an HDMI Device (iPhone with a Lightning connector)
28.9 mm
2.5 mm
21 mm
28 mm
USB connector
HDMI input connector
USB extension cable (Included) Lightning to USB Cable
KCU-471i (sold separately)
HDMI extension cable
(sold separately)
iPhone with a Lightning
connector (sold separately)
Lightning Digital AV Adapter
(Apple Inc., products) (sold
separately)
Connect using an L-Type HDMI cable
that is within the size as illustrated
below.
71-EN
Connection of an HDMI Device (Android device)
28.9 mm
2.5 mm
21 mm
28 mm
USB connector HDMI input connector
USB extension
cable (Included)
Connect using an L-Type HDMI cable
that is within the size as illustrated
below.
Android device with
HDMI connector
(sold separately)
Android device with
MHL connector
(sold separately)
■
MHL connection kit KCU-610HD
(sold separately)
HDMI connection cable
HDMI Type-D
conversion adapter
Micro USB conversion cable
■
MHL connection kit KCU-610MH
(sold separately)
HDMI connection cable
MHL conversion
adapter
Micro USB conversion cable
• A connection kit or adapter kit suitable for the type of terminal on the connecting device is required.
72-EN
Connection of an External Device)
AUX/PRE OUT/
CAMERA
Connector
PRE OUT cable
AUX INPUT
VIDEO Input/Output Connector
VIDEO IN/OUT cable
VIDEO IN
(Red)
(White)
To Video Output terminal
To Audio Output terminal
External Device (sold separately)
Video Input Lead
AUX Input Connector
RCA Extension Cable (sold separately)
AV/RCA Interface Cable (3-pole mini AV plug to
2-RCA) (sold separately)
• You can change the name of an external device. For details, refer to “Setting the Auxiliary (AUX) Name” in the OWNER’S
MANUAL.
• For details on using an AV/RCA interface cable (3-pole mini AV plug to 2-RCA), see “Usable AV/RCA Interface Cable (3-pole mini
AV plug to 2-RCA)” (
page 67).
73-EN
Connection of an External Amplifier
AUX/PRE
OUT/
CAMERA
Connector
Power Supply Connector
Power cable
PRE OUT
cable
REMO
(Blue/White)
REMOTE ON
(Blue/White)
REMOTE ON
(Blue/White)
SUBW
Amplifier for subwoofer
(sold separately)
To subwoofer input terminal
FRONT OUT
REAR OUT
To front input terminal
Amplifier 4 ch
(sold separately)
To rear input terminal
(Red)
(Red)
(White)
(White)
Subwoofer
Front speaker
Rear speaker
Remote Turn-On Lead (Blue/White)
Subwoofer RCA Connectors
Front Output RCA Connectors
Rear Output RCA Connectors
RCA Extension Cable (sold separately)
74-EN
Connection of a Camera
AUX/PRE
OUT/
CAMERA
Connector
Power Supply Connector
Power cable
PRE OUT
cable
To Video Output terminal
Reverse
(Orange/White)
Connect to the plus side of the car’s reverse lamp.
Camera with RCA video output
(sold separately)
Camera with RCA video output
(sold separately)
REAR VIEW CAMERA
FRONT VIEW CAMERA
To Video Output terminal
Reverse Lead (Orange/White)
REAR CAMERA Input RCA Connector
FRONT CAMERA Input RCA Connector
RCA Extension Cable (sold separately)
LIMITED WARRANTY
ALPINE ELECTRONICS OF AMERICA, INC. (“Alpine”), is dedicated to quality craftsmanship and is pleased to offer this Warranty. We
suggest that you read it thoroughly. Should you have any questions, please contact your Dealer or contact Alpine at one of the
telephone numbers listed below.
•
PRODUCTS COVERED:
This Warranty covers Car Audio Products and Related
Accessories (“the product”). Products purchased in the Canada
are covered only in the Canada. Products purchased in the U.S.A.
are covered only in the U.S.A.
•
LENGTH OF WARRANTY:
This Warranty is in effect for one year from the date of the first
consumer purchase.
•
WHO IS COVERED:
This Warranty only covers the original purchaser of the product,
who must reside in the United States, Puerto Rico or Canada.
•
WHAT IS COVERED:
This Warranty covers defects in materials or workmanship (parts
and labor) in the product.
•
WHAT IS NOT COVERED:
This Warranty does not cover the following:
Damage occurring during shipment of the product to
Alpine for repair (claims must be presented to the carrier).
Damage caused by accident or abuse, including burned
voice coils caused by over-driving the speaker (amplifier
level is turned up and driven into distortion or clipping).
Speaker mechanical failure (e.g. punctures, tears or rips).
Cracked or damaged LCD panels. Dropped or damaged hard
drives.
Damage caused by negligence, misuse, improper operation
or failure to follow instructions contained in the Owner’s
manual.
Damage caused by act of God, including without limitation,
earthquake, fire, flood, storms or other acts of nature.
Any cost or expense related to the removal or reinstallation
of the product.
Service performed by an unauthorized person, company or
association.
Any product which has the serial number defaced, altered or
removed.
Any product which has been adjusted, altered or modified
without Alpine’s consent.
Any product not distributed by Alpine within the United
States, Puerto Rico or Canada.
Any product not purchased from an Authorized Alpine
Dealer.
•
HOW TO OBTAIN WARRANTY SERVICE:
You are responsible for delivery of the product to an
Authorized Alpine Service Center or Alpine for repair and for
payment of any initial shipping charges. Alpine will, at its
option, repair or replace the product with a new or
reconditioned product without charge. If the repairs are
covered by the warranty, and if the product was shipped to
an Authorized Alpine Service Center or Alpine, Alpine will
pay the return shipping charges.
You should provide a detailed description of the problem(s)
for which service is required.
You must supply proof of your purchase of the product.
You must package the product securely to avoid damage
during shipment. To prevent lost packages it is
recommended to use a carrier that provides a tracking
service.
•
HOW WE LIMIT IMPLIED WARRANTIES:
ANY IMPLIED WARRANTIES INCLUDING FITNESS FOR USE AND
MERCHANTABILITY ARE LIMITED IN DURATION TO THE PERIOD
OF THE EXPRESS WARRANTY SET FORTH ABOVE AND NO
PERSON IS AUTHORIZED TO ASSUME FOR ALPINE ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE OF THE PRODUCT.
•
HOW WE EXCLUDE CERTAIN DAMAGES:
ALPINE EXPRESSLY DISCLAIMS LIABILITY FOR INCIDENTAL AND
CONSEQUENTIAL DAMAGES CAUSED BY THE PRODUCT. THE
TERM “INCIDENTAL DAMAGES” REFERS TO EXPENSES OF
TRANSPORTING THE PRODUCT TO THE ALPINE SERVICE CENTER,
LOSS OF THE ORIGINAL PURCHASER’S TIME, LOSS OF THE USE OF
THE PRODUCT, BUS FARES, CAR RENTALS OR OTHERS COSTS
RELATING TO THE CARE AND CUSTODY OF THE PRODUCT. THE
TERM “CONSEQUENTIAL DAMAGES” REFERS TO THE COST OF
REPAIRING OR REPLACING OTHER PROPERTY WHICH IS
DAMAGED WHEN THIS PRODUCT DOES NOT WORK PROPERLY.
THE REMEDIES PROVIDED UNDER THIS WARRANTY ARE
EXCLUSIVE AND IN LIEU OF ALL OTHERS.
•
HOW STATE/PROVINCIAL LAW RELATES TO THE
WARRANTY:
This Warranty gives you specific legal rights, and you may also
have other rights which vary from state to state and province to
province. In addition, some states/provinces do not allow
limitations on how long an implied warranty lasts, and some do
not allow the exclusion or limitation of incidental or
consequential damages. Accordingly, limitations as to these
matters contained herein may not apply to you.
•
IN CANADA ONLY:
This Warranty is not valid unless your Alpine car audio product
has been installed in your vehicle by an Authorized Installation
Center, and this warranty stamped upon installation by the
installation center.
•
HOW TO CONTACT CUSTOMER SERVICE:
Should the product require service, please call the following
number for your nearest Authorized Alpine Service Center.
CAR AUDIO 1-800-ALPINE-1 (1-800-257-4631)
NAVIGATION 1-888-NAV-HELP (1-888-628-4357)
Or visit our website at; http://www.alpine-usa.com
ALPINE ELECTRONICS OF AMERICA, INC., 1500 Atlantic Blvd, Auburn Hills, Michigan 48326, U.S.A.
Do not send products to this address.
Call the toll free telephone number or visit the website to locate a service center.
About the Rules of Bluetooth Electromagnetic Radiation Regulation
USA/Canada
FCC/IC CAUTION
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC
radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed
to comply without maximum permissive exposure evaluation (MPE). But it is desirable that it should
be installed and operated keeping the radiator at least 20 cm or more away from person’s body.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage;
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un
environnement non contrôlé et respecte les règles les radioélectriques (RF) de la FCC lignes
directrices d’exposition et d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet
équipement émet une énergie RF très faible qui est considérée conforme sans évaluation de
l’exposition maximale autorisée (MPE). Cependant, il est souhaitable qu’il devrait être installé et
utilisé en gardant une distance de 20 cm ou plus entre le radiateur et le corps humain.
Don’t forget to take a moment to protect your purchase by registering your product now at the following address: www.alpine-usa.
com/registration.
N’oubliez pas de consacrer un moment à la protection de votre achat en enregistrant votre produit dès maintenant à l’adresse
suivante : www.alpine-usa.com/registration.
Recuerde que con solo unos pocos pasos podrá proteger su producto, registrándolo a través de la siguiente dirección: www.
alpine-usa.com/registration.
