EN Stick blender
Translation of the original manual
SHB 4460WH / SHB 4461GR
SHB 4462BL / SHB 4463OR
SHB 4464RD / SHB 4465VT
SHB 4466YL / SHB 4467TQ
SHB 4468RS
- 2 -
10/2019
Copyright © 2019, Fast ČR, a.s.
EN
Stick blender
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
General warnings
■ This appliance may not be used by children. Keep the appliance and its power cord away
from children.
■ These appliances may be used by persons with reduced physical, sensory or mental
capabilities or with alack of experience and knowledge, if they are supervised or have
been instructed to use the appliance in a safe manner and understand the potential
dangers.
■ Cleaning and maintenance performed by the user must not be performed by unsupervised
children.
■ In the event that the power cord is damaged, have it repaired at aprofessional service
centre to prevent causing adangerous situation. It is forbidden to use the appliance if it
has adamaged power cord.
Warning:
Incorrect use may lead to injuries.
■ Be especially careful not to injure yourself on the sharp cutting edges when handling
the chopping blades, especially when removing the blades from the blending jar, when
emptying the container and when cleaning it.
■ The surfaces of the appliance that come into contact with food must always be cleaned
according to the instructions in this user’smanual.
■ Always turn off the appliance and disconnect it from the power socket if you will not be
using it and if you will be leaving it without supervision, before assembly, disassembly,
cleaning or moving it.
■ Before replacing the accessories or accessible parts that move during use, turn the
appliance off and disconnect it from the power supply.
■ Children must not play with the appliance.
Electrical safety
■ Before connecting this appliance to apower socket, make sure that the voltage stated on
its rating label corresponds to the voltage in your power socket
■ Connect the appliance only to aproperly grounded socket. Do not use an extension cord.
- 3 -
10/2019
Copyright © 2019, Fast ČR, a.s.
■ Never connect the appliance to apower socket until it is properly assembled.
■ Fully unwind the power cord before using it.
■ Do not connect and disconnect the power cord to and from the power socket with wet
hands.
■ Ensure that the power plug contacts do not come into contact with water or any other
liquid. If precisely this happens, carefully dry the power plug before using it again.
■ Do not disconnect the appliance from the power socket by pulling on the power cord.
This could damage the power cord or the power socket. Disconnect the power cord from
the power socket by pulling on the plug.
■ Do not place heavy items on the power cord. Make sure the power cord does not hang
over the edge of atable or that it is not touching ahot surface or sharp objects.
■ Do not wind the power cord around the appliance.
■ To avoid the danger of injury by electrical shock, do not repair the appliance yourself or
make any adjustments to it. Have all repairs or adjustments of the appliance performed
at an authorised service centre. Tampering with the appliance during the warranty period
may void the warranty.
■ To prevent the risk of injury by electrical shock, never submerge the motor unit and its
power cord in water or any other liquid, or wash these parts under running water.
■ Always turn off the appliance and disconnect it from the power socket when you have
finished using it.
■ In the event that the appliance falls into water, under no condition reach for it, rather,
immediately disconnect the power cord from the power socket. Never use an appliance
that was submerged in water. Hand it over to an authorised service centre for inspection.
Safety during use
■ This appliance is designed for household and is intended for blending, chopping and
whipping food. It is also suitable for processing hard ingredients such as coffee beans,
cocoa beans, ice cubes, nutmeg, etc.
■ Do not use the appliance in an industrial environment or outdoors. Do not use it for any
other purposes than those for which it is intended.
■ The appliance is intended for domestic use and similar locations such as:
– kitchens in stores; offices and other workplaces;
– in agriculture;
– for guests of hotels, motels and other similar locations;
– in bed and breakfast establishments.
■ This appliance is not intended to be operated using an external timer switch or aremote
control system.
- 4 -
10/2019
Copyright © 2019, Fast ČR, a.s.
■ Use the appliance and its accessories in accordance with the instructions contained in this
user’smanual.
■ Only use the appliance with the original accessories that came with it.
■ Before every use, check the selected accessory for damage. Never use the appliance with
adamaged accessory.
■ Do not place the appliance or its accessories on an electric or gas stove or in its vicinity,
on the edge of atable or on an unstable surface. Only place the appliance on an even, dry
and stable surface.
■ Do not expose the appliance and its accessories to the outdoor environment, extreme
temperatures, direct sunlight, excessive humidity or excessively dusty environments.
■ Do not place the appliance and its accessories near heaters, open fires or other sources
of heat.
■ Make sure that the appliance is correctly assembled before putting it into operation.
■ Do not touch moving rotating parts during operation. Otherwise, this could result in
injury.
■ Be especially careful when handling hot liquids and foods. Hot steam or splashing hot
foods and liquids may cause scalding. For reasons of increased safety, allow hot foods and
liquids to cool down to at least 45 °C before blending.
■ The operating time of the appliance is 1 minute. Before turning it on again, allow it to
cool down for at least 3 to 5 minutes. When using the appliance to blend sticky or harder
foodstuffs, interrupt operation already after 30 seconds.
■ Do not turn on the appliance when it is empty. Incorrect use of the appliance may
negatively affect its lifetime.
■ Check that the motor unit is turned off, disconnected from the power socket and that the
rotating parts have come to acomplete stop before disassembling the appliance into its
individual parts.
■ Do not perform any maintenance on the appliance other than cleaning the individual
components as described in chapter Cleaning and maintenance.
■ Never use an appliance that is damaged in any way.
■ Do not use the appliance if it has fallen on the floor, if it was submerged in water, if it is not
functioning correctly or if it is damaged in any other way.
■ When handling the blade assembly of the blender or chopper unit, especially when taking
the blade assembly out of the bowl, when emptying the bowl and cleaning it, take special
care to avoid injury by the blades.
■ Do not use the appliance when it is not functioning properly or showing signs of damage.
- 5 -
10/2019
Copyright © 2019, Fast ČR, a.s.
■ In order to prevent ahazardous situation arising, do not repair the appliance yourself
or modify it in any way. Have all repairs performed at an authorised service centre. By
tampering with the appliance, you risk voiding your legal rights arising from unsatisfactory
performance or quality warranty.
■ Store the appliance in adry environment.
- 6 -
10/2019
Copyright © 2019, Fast ČR, a.s.
SHB 4460WH / SHB 4461GR
SHB 4462BL / SHB 4463OR
SHB 4464RD / SHB 4465VT
SHB 4466YL / SHB 4467TQ
SHB 4468RS
T
- MAX -
7
8
16
1
2
3
4
5
6
9
10
12
13
14
15
11
A
- 7 -
10/2019
Copyright © 2019, Fast ČR, a.s.
1
2
3
B
1
C
- 8 -
10/2019
Copyright © 2019, Fast ČR, a.s.
EN
Stick blender
User'smanual
■ Prior to using this appliance, please read the user’smanual thoroughly, even in cases, when one has already familiarised themselves with previous use of similar types of
appliances. Only use the appliance in the manner described in this user’smanual. Keep this user’smanual in asafe place where it can be easily retrieved for future use. In the event
that you hand this appliance over to somebody else, make sure to also include this user’smanual.
■ Carefully unpack the appliance and take care not to throw away any part of the packaging before you find all its parts. We recommend saving the original cardboard box,
packaging material, purchase receipt and responsibility statement of the vendor or warranty card for at least the duration of the legal liability for unsatisfactory performance or
quality. In the event of transportation, we recommend that you pack the appliance in the original box from the manufacturer.
DESCRIPTION OF THE APPLIANCE AND ITS ACCESSORIES
A1 Speed control dial
A2 Normal speed switch
A3 High speed switch (turbo)
A4 Motor unit
A5 Removable blender stick attachment
A6 Blade assembly
It contains titanium-coated stainless steel blades
A7 Beaker, volume 700 ml
A8 Anti-slip base pad / lid
A9 Whisk attachment with gear system
A10 Whisk
A11 Chopper bowl lid with gear system
A12 Chopper with blade assembly
A13 Protective cover
A14 Chopper bowl, volume 500 ml
A15 Shaft
A16 Anti-slip base pad
B1 Help arrow
B2 “Unlocked” symbol
B3 “Locked” symbol
C1 Locking tabs
PURPOSE OF USE
STICK BLENDER ATTACHMENT
■ It is suitable for blending soft ingredients and liquids. It is used namely for preparing baby food, various types of milkshakes, sauces, spreads, etc.
WHISK
■ The whisk is suitable for preparing light batters or for whipping cream, egg whites, dessert creams, liquid sponge cake doughs, mayonnaise, etc. Do not use it to whip thick
doughs.
CHOPPER
■ It is suitable for chopping tougher foods such as meat, semi-hard or hard cheese, fruit and vegetables in their raw state, nuts, herbs, etc. Thanks to its special tabs, it is also suitable
for chopping harder foods such as ice cubes, coffee beans, nutmeg, cocoa beans.
BEFORE FIRST USE
■ Thoroughly wash all removable accessories that are intended to come into contact with food using warm water and aneutral kitchen detergent. Then rinse them with clean water
and allow them to dry naturally or wipe them thoroughly dry using afine wiping cloth.
■ Clean parts A9 and A11, which are equipped with agear system, only using adampened cloth. Take care that water does not enter into these parts.
Attention:
When cleaning blade assemblies A6 and A12, be very careful not to injure yourself on their sharp edges.
■ When cleaning the stick blender attachment A5, do not submerge the top end that connects to the motor unit A4 .
ATTACHING AND REMOVING BLENDING AND WHIPPING ATTACHMENTS
Attention:
Before attaching or removing attachments A5 or A9, make sure that the motor unit A4 is turned off and disconnected from the power socket and that the
rotating parts have come to acomplete stop. The parts of the attachments that are connected to the motor unit, must be thoroughly dry.
■ Depending on the activity, select attachment A5 or A9. Slide the selected attachment on to the motor unit A4 from underneath so that the arrow B1 on the rear side of the motor
unit points at the unlocked padlock symbol B2 on the attachment.
■ Turn the motor unit so that the arrow moves to the locked padlock symbol B3. The connection of both parts is accompanied by aclick.
■ To release the attachment from the motor unit, firmly grasp both parts and turn the motor unit so that the arrow points at the open padlock symbol. Pull both parts away from
each other.
ASSEMBLING AND DISASSEMBLING THE CHOPPER
■ Place the bowl A14 on an even and stable surface. Remove the protective cover A13 from the chopper A12, and seat the chopper on the central shaft A15 on the bottom of
the bowl.
■ Put the lid A11 on to the bowl so that the shaft of the chopper A12 slides into the central part of the lid so that the locking tabs C1 along the sides of the lid fit into the grooves
in the bowl. Turn the lid so that the tabs on the lid slide into the grooves. Correctly securing the lid is accompanied by aclick.
■ Attach the motor unit A4 to the lid A11 following the same procedure as described in chapter Attaching and removing attachments.
■ To remove them proceed in the reverse sequence to their assembly.
OPERATING THE APPLIANCE
■ Select the type of accessories that you wish to use, and assemble the appliance according to the instructions in the preceding chapters.
■ For blending, use the beaker A7 or another suitable container intended for coming into contact with food. The anti-slip base pad A8 also serves as alid for the beaker, when you
wish to use it for short term storage of food.
■ Do not overfill the beaker A7 and bowl A14 past the maximum level marks. This will prevent splattering the ingredients while they are processed.
■ When assembling the chopper, place the food into the bowl A14 only after placing the chopper A12, be on to the central shaft A15 at the bottom of the bowl. Do not fill the
bowl past the maximum level mark (MAX).
- 9 -
10/2019
Copyright © 2019, Fast ČR, a.s.
■ Connect the motor unit A4 to a power socket. Set the required speed using the speed control dial A1. Turn the speed control dial clockwise to increase the speed, and
anticlockwise to reduce the speed. The speed can also be adjusted while the appliance is running. However, speed can only be adjusted when using normal speed. It cannot be
adjusted at high speed.
■ After setting the speed, hold down switch A2 or A3. The appliance will run as long as the switch is held down. Releasing the switch will turn off the appliance.
Attention:
The maximum continuous operating time of the appliance is 1 minute. Then allow it to cool down for 3 to 5 minutes. When using the appliance to blend sticky
or harder foodstuffs, interrupt operation already after 30 seconds.
■ After you finish using it, disconnect the power cord from the power socket. Make sure that the rotating parts have stopped rotating, and disassemble the appliance into its
individual parts. Then clean all used parts according to the instructions in chapter Cleaning and maintenance.
ADVICE AND TIPS
■ When using the blender attachment, it is recommended to always blend at alower speed. While blending, move the blender up and down to blend the ingredients to the
required consistency.
■ To prevent ingredients from splattering, put the blender attachment A5 or the whisk A9 into the beaker containing the ingredients before starting it, and conversely turn it off
before pulling the attachment out of the beaker.
■ To prevent ingredients from splattering, keep the blade assembly A6 of the blending attachment and whisk A10 submerged while the appliance is running. It is recommended
to divide alarger amount of processed ingredients into several batches and to regularly inspect the contents inside the beaker.
■ When using the blender or chopper attachment, it is recommended to process ingredients using short pulses. This will prevent the ingredients from being excessively pulverised
and optimal results will be achieved.
■ To make blending and chopping easier, cut hard ingredients into small pieces.
■ To achieve better blending results, hold the stick blender slightly tilted, while carefully moving it up and down in the beaker. Do not use force to push ingredients down with
the stick blender.
■ Before blending or chopping, remove hard parts such as fruit stones or bones from the blended ingredients. This will prevent damaging the blade assembly.
QUICK GUIDE TO PROCESSING INGREDIENTS
■ The food processing times provided below are only areference. The actual processing time depends on the size of the ingredients, their amount and the required final consistency.
If the required consistency is not achieved during the maximum operating time of the appliance, you may continue processing the food after the appliance has cooled down.
STICK BLENDER
INGREDIENTS AMOUNT SPEED SETTING PROCESSING TIME
Baby food 300 g Medium to maximum 45 s
Spreads 200 g Medium to maximum 30 s
Fruit and vegetables (cooked)
200 g Medium to maximum 45 s
Sauces 500 ml Medium to maximum 45 s
Shakes 500 ml Medium to maximum 30 s
CHOPPER
INGREDIENTS AMOUNT SPEED SETTING PROCESSING TIME
Meat 300 g Medium to maximum 30 s
Fruit and vegetables 200 g Medium to maximum 15 s
Hard and semi-hard cheeses
150 g Maximum 10 s
Hard baked goods 100 g Medium to maximum 20 s
Nuts with shells removed
100 g Maximum 15 s
Herbs 50 g Medium 10 s
■ First, cut up the food into cubes of approximately 2 × 2 cm and only then process with the chopper. With vegetables like onion, it is sufficient to cut them into quarters.
WHIPPING
INGREDIENTS AMOUNT SPEED SETTING PROCESSING TIME
Egg whites 4 pcs Maximum 60 s
Whipping cream 200 ml Maximum 60 s
Light doughs 500 g Medium to maximum 60 s
■ Always whip cream and egg whites in atall narrow beaker. When whipping egg whites, the whisks A8 and the beaker must always be perfectly clean and dry, otherwise whipping
up the egg whites may not succeed.
CLEANING AND MAINTENANCE
■ Before cleaning it, make sure that the appliance is turned off, disconnected from the power socket and that the rotating parts have stopped.
■ Disassemble the appliance into its individual parts. Thoroughly wash the attachments and containers, using warm water and neutral kitchen detergent. Then rinse them with
clean water and allow them to dry naturally or dry them out thoroughly using awiping cloth.
■ Clean parts A9 and A11, which are equipped with agear system, only using adampened cloth. Take care that water does not enter into these parts.
■ When cleaning the blender attachment A5, do not submerge the top end that connects to the motor unit A4.
■ The beaker A7 and bowl A14, the anti-slip base pad A8 and the blade assembly A12 can be washed in adishwasher. Other parts are not intended for washing in adishwasher.
Attention:
When cleaning blade assemblies A6 and A12, be very careful not to injure yourself on their sharp edges.
- 10 -
10/2019
Copyright © 2019, Fast ČR, a.s.
■ After finishing using the stick blender, it is possible to clean the blade assembly A6 by submerging it in warm water with kitchen detergent, and running it for ashort time. Then
disconnect the appliance from the power socket, disassemble it, and rinse the blade assembly with clean drinking water and dry it thoroughly.
■ To clean the outer surface of the motor unit A4, use acloth lightly dipped in aweak detergent solution. After applying the detergent solution, wipe the surface with acloth
lightly dampened in clean water and then wipe dry. Do not use solvents, abrasive cleaning products, etc. for cleaning the appliance. Otherwise the surface coat of the appliance
may be damaged.
Attention:
Never submerge the motor unit A4 or the power cord in water or in any other liquid.
STORAGE
■ When you have finished using the appliance, place it and its accessories in aclean, dry place out of children’sreach. Keep the stored appliance and its accessories away from
extreme temperatures, direct sunlight and excessive humidity and do not store it in an overly dusty environment.
TECHNICAL SPECIFICATIONS
Rated voltage range ....................................................................................................................................................................................................................................................................................................220–240 V
Rated frequency ..............................................................................................................................................................................................................................................................................................................50/60 Hz
Rated power input ............................................................................................................................................................................................................................................................................................................ 1000 W
Electrical shock protection class ............................................................................................................................................................................................................................................................................................... II
Noise level .......................................................................................................................................................................................................................................................................................................................... 85 dB(A)
The declared noise emission level of the appliance is 85 dB(A), which represents alevel Aof acoustic power with respect to areference acoustic power of 1 pW.
EXPLANATION OF TECHNICAL TERMINOLOGY
Safety class for electrical shock protection:
Class II – Electrical shock protection is provided by double or heavy-duty insulation.
Amendments to text and technical parameters are reserved.
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS
Take the packaging material to adesignated municipal waste facility.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used electric or electronic products must not be thrown out with ordinary municipal waste. For proper
disposal and recycling, take these products to designated collection points. Alternatively, in some European Union states or other European countries you may
return your appliances to the local retailer when buying an equivalent new appliance. Correct disposal of this product helps save valuable natural resources and
prevents damage to the environment caused by improper waste disposal. Ask your local authorities or collection facility for more details. In accordance with
national regulations penalties may be imposed for the incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your vendor or supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product, request the necessary information about the correct disposal method from the local council or
from your vendor.
This product meets all the basic requirements of EU directives related to it.
