User Manual Brother CP2160L

Documents for Brother CP2160L

The following documents are available:
User Manual Other Documents
  • Sewing Guide - (English) Download
  • Quick Reference Guide - (English) Download
  • Stitch Chart - (English) Download
  • Notification about included accessories - (English) Download
  • Accessories catalog - (English) Download
Photos
CP2160L photo
Operation Manual
Product Code: 888-N00/N02/N20/N22/N40/N42
Sewing Machine
English
888-N00/N02/N20/N22/N40/N42
D01F5E-101
To get information about Videos, please go to http://s.brother/cvkag/.
Please visit us at http://s.brother/cpkag/ where you can get the support
information (Sewing Guide, Stitch Chart, Instruction Videos, FAQs, etc.)
for your Brother product.
Trademarks
App Store is a service mark of Apple Inc.
Android and Google Play are trademarks of Google, Inc.
Use of these trademarks are subject to Google Permissions.
Brother SupportCenter is a mobile app that provides the support
information (Instruction Videos, FAQs, etc.) for your Brother product.
Visit the Google Play™ or App Store to download.
App StoreGoogle Play™
Be sure to read this document before using the machine.
We recommend that you keep this document nearby for future reference.
Cover1-4
PANTONE 285CVC
K
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ����������������������2
Names of Machine Parts ��������������������������������������������4
Main parts ����������������������������������������������������������������������� 4
Needle and presser foot section �������������������������������������� 4
Operation buttons ����������������������������������������������������������� 4
Flat bed attachment ��������������������������������������������������������� 4
Accessories ����������������������������������������������������������������5
Included accessories ������������������������������������������������������� 5
Optional accessories ������������������������������������������������������ 5
Using Your Machine ��������������������������������������������������5
Power supply ������������������������������������������������������������������ 6
Foot controller ����������������������������������������������������������������� 6
Operation panel �������������������������������������������������������������� 6
Settings/Functions ����������������������������������������������������������� 6
Threading the Machine ����������������������������������������������7
Winding/Installing the bobbin ����������������������������������������� 7
Upper threading �������������������������������������������������������������� 9
Drawing up the bobbin thread �������������������������������������� 11
Fabric/Thread/Needle Combination ������������������������12
Needle ���������������������������������������������������������������������13
Checking the needle ����������������������������������������������������� 13
Replacing the needle ����������������������������������������������������� 13
Sewing with the twin needle ����������������������������������������� 13
Replacing the Presser Foot ���������������������������������������14
Replacing the presser foot ��������������������������������������������� 14
Removing the presser foot holder ���������������������������������� 15
Sewing Basics�����������������������������������������������������������15
Selecting the stitch �������������������������������������������������������� 15
Setting the stitch length and stitch width ����������������������� 15
Starting to sew ��������������������������������������������������������������� 16
Sewing reverse/reinforcement stitches ��������������������������� 16
Automatic reverse/reinforcement stitching ��������������������� 17
Thread tension �������������������������������������������������������������� 17
Utility Stitches ���������������������������������������������������������17
Overcasting stitches ������������������������������������������������������ 17
Blind hem stitching �������������������������������������������������������� 18
Buttonhole sewing �������������������������������������������������������� 19
Button sewing (for models equipped with
the button fitting foot “M”) �������������������������������������������� 21
Zipper insertion������������������������������������������������������������� 22
Bar tack stitching ����������������������������������������������������������� 23
Making Adjustment��������������������������������������������������23
Brother Support Website Information
(Downloading Manuals) ������������������������������������������24
Care and Maintenance ���������������������������������������������24
Restrictions on oiling ����������������������������������������������������� 24
Precautions on storing the machine ������������������������������� 24
Cleaning the machine surface ��������������������������������������� 24
Cleaning the race ���������������������������������������������������������� 24
Troubleshooting �������������������������������������������������������25
Frequent troubleshooting topics ������������������������������������ 25
Upper thread tightened up �������������������������������������������� 25
Tangled thread on wrong side of fabric ������������������������� 25
Incorrect thread tension ������������������������������������������������ 26
Fabric is caught in the machine and cannot be
removed ������������������������������������������������������������������������ 26
If the thread becomes tangled under the bobbin
winder seat�������������������������������������������������������������������� 28
List of symptoms������������������������������������������������������������ 28
Error Messages ���������������������������������������������������������30
Operation beep ������������������������������������������������������������� 30
Index ������������������������������������������������������������������������31
