Base Lot Number: _ _ _ _ _ _ _ _ _ _ _ _ _
Purchased Date: ___ / ___ / ______
Dealer’s Name:__________________________
Please register your products at:
https://www.bodycraft.com/product-registration/
Owner’s Manual
1
F735 Oly Plate Holder Option
for the BodyCraft F430 / F730 PRO (Power Rack) or F438 / F738 (RFT PRO)
Open your Camera
App and point it at
the QR Code
Assembled Parts List
F735 v1.3
To see in
FULL COLOR
& additional information,
scan this QR code.
Part # Assembly Parts List QTY
F735-501-ASM Frame, Top, Rt & Lt - Assembly 2
F735-502 Frame, Upright, for Oly Plate Storage 2
F735-503-ASM Frame, Bottom, Rt & Lt - Assembly 2
F735-504-ASM Oly Plate Horn - Assembly 8
F735-514-ASM
Adjustable Foot, for Lower Base Frame -
Assembly 2
Part # Assembly Hardware QTY
F735-505 Nut, Nylon Lock 1/2" - BLACK 8
F735-506 Washer, Spring 3/8" - BLACK 8
F735-507 Bolt, Hex Head 1/2" x 4-1/2" - BLACK 4
F735-508 Bolt, Hex Head 1/2" x 3-1/4" - BLACK 4
F735-509 Bolt, Hex Head 1/2" x 2-1/2" - BLACK 8
F735-510 Bolt, Hex Head 3/8" x 1-1/4" - BLACK 8
F735-511 Washer, Flat 1/2" - BLACK 16
F735-512 Washer, Flat 3/8" - BLACK 8
