G703
LIGHTSPEED Wireless Gaming Mouse
Souris gaming sans l LIGHTSPEED
SETUP GUIDE
|
GUIDE D’INSTALLATION
3 ENGLISH
SETUP INSTRUCTIONS
1 A wireless receiver, USB adapter, and optional 10g weight can
be found in the packaging. Plug one end of the cable into
yourPC, andtheother end into the USB adapter and receiver.
– The receiver can also be used plugged directly into
yourPC. However, using the cable and adapter when
in wireless mode is recommended and allows for better
connectivity and easy access to the cable for recharging.
2 Turn mouse on via the switch on the bottom of the mouse.
10g
1
2
4 ENGLISH
3 To charge, disconnect the cable from the adapter and
plug into the front of the mouse. Your mouse will operate
in data-over-cable mode whenever it is plugged in directly
toaPC. Full charge from empty requires approximately
twohours plugged in to a PC USB port.
Tips:
– Keep the mouse and receiver 2 m+ away from wireless
routersor other 2.4GHz wireless devices to minimize
environmental noise.
– G703 has a wireless range of up to 10 meters. Toensure optimal
performance in noisy wireless environments, andtokeep
thecharging cable easily accessible, itisrecommended
tokeep the receiver within 20 cm ofthemouse.
2 m+
20 cm-
3
5 ENGLISH
MOUSE FEATURES
1 Left (Button 1)
2 Right (Button 2)
3 Wheel click (Button 3)
4 Back (Button 4)
5 Forward (Button 5)
6 DPI Cycle
7 On/O switch (bottom of mouse, not programmable)
8 Weight door
1
6
4
5
2
7
8
3
6 ENGLISH
WIRELESS BATTERY LIFE
G703 has a rechargeable 720mAh LiPol battery which provides
it with up to 32 hours non-stop gaming at 1ms report rate
withlights o, or 24 hours non-stop gaming at 1ms report rate
with RGB color cycling on.*
– Charge level can be checked when the mouse is poweredon
orusing Logitech Gaming Software to assign a button
tocheck charge level.
– Charge level is displayed for seven seconds at mouse
power-onusing the color of the scroll wheel.
– Green = 50–100%
– Orange = 30–50%
– Red = 15–30%
– Flashing red = <15%
Tip: You can program a button to show charge level
usingLGS.
– The scroll wheel will ash red when battery is at 15% or less.
When this happens, plug in your mouse to charge.
– Charge level, power draw, and estimated remaining
batterylife can be checked in Logitech Gaming Software
*Battery life and capacity may vary with age and use. Rechargeable batteries have a limited
number of charge cycles.
7 ENGLISH
CHARGING/DATA OVER CABLE
Plug your mouse in via the provided USB charging cable when
the battery is low. The mouse will seamlessly swap to data-over-
cable mode whenever it is plugged in. G703 is also compatible
with the Logitech G POWERPLAY wireless charging system,
soldseparately.
RGB PROGRAMMABLE LIGHTING
G703 wheel and logo is illuminated with RGB LEDs.
These colors can be customized using Logitech Gaming Software
to a variety of breathing, color cycling, or solid color modes.
Lighting patterns can also be synchronized with other supported
Logitech G devices using this software.
8 ENGLISH
LOGITECH GAMING SOFTWARE
You can customize the 3 onboard proles of the G703 using
the Logitech Gaming Software. These settings include surface
tuning, button programming, lighting color, lighting eects,
report rate, and tracking behavior. G703 allows up to 5 DPI
settings per prole.
By default, G703 has 1 active onboard prole with
thefollowingsettings:
– DPI: 400, 800, 1600, 3200
– RGB lighting: color cycle
– Report rate: 1ms
QUESTIONS
http://support.logitech.com/product/g703
