EN
Quick Guide
CONTROL PANEL
1. ON/OFF button
2. DRYING button
3. DRYING ONLY button
4. MULTI RINSE button
5. OPTION button
6. DIRECT INJECTION button
7. START/PAUSE button and indicator light
8. KEY LOCK button
9. DELAY TIMER button
10. SPIN button
11. TEMPERATURE button
12. AUTO CLEAN button
13. WASH CYCLE SELECTOR KNOB
WASH CYCLE TABLE
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.
To receive more comprehensive assistance, register the
appliance on www.hotpoint.eu/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.
DETERGENT DISPENSER DRAWER
Compartment *:
Do not insert detergent in this compartment.
Compartment 1: Washing detergent (powder
or liquid)
If liquid detergent is used, the removable plastic
partition A (supplied) should be used for proper
dosage.
If powder detergent is used, place the partition
into slot B.
Compartment 2: Additives (fabric softeners, etc.)
The fabric softener must not exceed the “MAX” level.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
A
B
*
13
7
8
9
10
11
12
1 2
4
DISPLAY
5 6
3
in terms of energy and water consumption for washing and drying normally soiled cotton
laundry. At the end of cycle the garments can be immediately stored to the cupboard.
For all testing institutes:
2) Long cotton cycle: set programme 3 at temperature 40°C.
3) Long synthetics cycle: set cycle 4 at a temperature of 40°C.
* By selecting the cycle and excluding the spin cycle, the washer-dryer will drain only.
** The duration of the wash cycles can be checked on the display.
*** After programme end and spinning with maximum selectable spin speed, in default
programme setting.
**** If a drying cycle is also programmed, the machine will run a “wash+dry” programme
lasting 45’ and a 1kg laundry load.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected.The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60 (Wash) - Test wash cycle in compliance with EU Ecodesign regulation
2019/2014. The most ecient programme in terms of energy and water consumption for
washing normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly diers from the values stated in the table.
4) Eco 40-60 (Wash &Drying)-
Test
wash and
drying cycle in compliance with EU
Ecodesign regulation
2019/2014
. To access “wash and dry” cycle select “Eco 40-60” wash
programme and set “Drying” option level to
“
Cupboard
”.
The most ecient programme
Maximum load 10 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Detergents and
Additives
Recommended
detergent
Residual
dampness %
(****)
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Wash cycle
Temperature
Max.
spin speed
(rpm)
Max.
load for
washing
(kg)
Duration
(h : m)
Drying
Max.
load for
drying
(kg)
Wash
Fabric
softener
Powder
Liquid
Setting Range 2 3
1
Anti-Stain Turbo
(Anti-Stain Turbo 45‘)
40 °C
- 40 °C
1200 5.5 **
5.5
–
– – – –
2
Anti-Stain 20°
(Anti-Stain Power 20°)
20 °C
- 20 °C
1600 10.0 **
7.0
–
– – – –
3 Cotton (2) 40 °C
- 60 °C
1600 10.0 3:55
7.0
49 1.14 107 45
4 Synthetics (3) 40 °C
- 60 °C
1200 5.5 2:55
5.5
35 0.83 80 43
5
Rapid 30’
(Fast 30’)
30 °C
- 30 °C
800 5.5 0:30 **** 5.5
–
71 0.21 50 27
6
Mix Wash & Dry
(Wash & Dry Mix)
40 °C 40 °C 800 3.5 **
3.5
–
– – – –
7 Shirts Wash & Dry 40 °C 40 °C 1000 3.0 **
3.0
–
– – – –
8 Wool 40 °C
- 40 °C
800 2.5 **
2.5
–
– – – –
9
Eco 40-60 (1)
(Wash)
40 °C 40°C
1551 10.0 3:59
7.0
44 1.07 59 35
1551 5.0 3:00
44 0.83 59 35
1551 2.5 2:15
44 0.58 42 33
10 20°C 20 °C
- 20 °C
1600 10.0 1:50
7.0
–
54.5 0.20 95 22
11
White
(Whites)
60 °C
- 90 °C
1600 10.0 2:40
7.0
54 1.90 100 55
12 Anti Allergy 60°C 40 °C - 60 °C 1600 5.5 **
5.5
– – – –
13 Steam Refresh – – – 2.0 ** – – – – – – – – – –
14
Ultradelicates
(Ultra Delicates)
30 °C
- 30 °C
– 1.0 **
1.0
–
– – – –
Rinse&Spin
(Rinse)
– – 1600 10.0 **
7.0 –
– – – – – –
Spin&Drain *
(Spin + Pump out)
– – 1600 10.0 **
7.0 – – – – – – – –
Required dosage Optional dosage
9
Eco 40-60 (4)
(Wash & Drying)
40 °C 40 °C
1551 7.0 9:50
7.0
0 5.10 75 33
1551 3.5 6:00
3.5
0 2.70 53 33
