For more product information visit: bit.ly/laxtech_support
1. Grasp both ends of the Mounting Bracket and detach it from the
Window Thermometer.
2. Use a screwdriver to open the Battery Cover and remove the
plastic tab from under the AAA battery. Thermometer should
turn on.
3. Replace Battery Cover and set the time. This will help ensure
your MIN/MAX values reset correctly.
4. Follow the mounting steps under POSITIONING for best results.
POWER UP SET TIME
OUTDOOR
WINDOW THERMOMETER
MODEL: WS-1025U
DC: 110920
1. Hold the MODE button to enter the Settings Menu.
2. Use the + button to adjust, and MODE to confirm.
Settings Menu order:
• Hour
• Minutes
Mounting Bracket
Adhesive
Strips for
Window
Mountin
g
Battery Cover
1-AAA
(included)
Current
Temperature
(Fahrenheit only)
Minimum
Temperature
Resets at 8PM
Maximum
Temperature
Resets at 8AM
Buttons
Leg
Slot for
Leg
POSITIONING
1. Select a location where the Window Thermometer will be out of
direct sunlight for accurate readings.
2. Clean your window and remove the Adhesive Strip covers from
the Mounting Bracket.
3. Firmly press the bracket onto your window surface, holding the
Adhesive Strips down for a good 30 seconds.
4. Reattach the Window Thermometer onto the Mounting Bracket.
5. For improved visibility, UV, and rain protection, slide the
included plastic plate onto the back of the thermometer.
• The minimum temperature automatically resets at 8:00 P.M.
• The maximum temperature automatically resets at 8:00 A.M.
Note: Time needs to be setcorrectly for accurate minimum and
maximum temperatures over the past 24 hours.
MIN/MAX TEMPERATURE
