@8 CK£BECKER 1
INSTRUCTION
MANUAL
DATE CODE
Catalog Number BV2500, BV9000
BEFORE YOU CALL, HAVETHE FOLLOWING INFORMATION AVAILABLE, CATALOGNo.,TYPE
No., AND DATECODE. IN MOST CASES, A BLACK & DECKER REPRESENTATIVE
CAN RESOLVE YOUR PROBLEM OVER THE PHONE. IFYOU HAVEA SUGGESTION OR
COMMENT, GIVE US A CALL. YOUR FEEDBACK ISVITALTO BLACK & DECKER.
KEYINFORMATIONYOU SHOULDKNOW:
i efore operating, make sure that either the blower or vacuum tube assembly is locked
in place.
ThepowerswitchmustbeOFFin order to depressthe releasebuttonfor changing blower
and vacuum tube assemblies.
SAVETHISMANUALFORFUTUREREFERENCE•
VEA ELESPANOLEN LA CONTRAPORTADA.
INSTRUCTIVO DE OPERACION, CENTROS DE SERVICIO Y P©LIZA DE GARANTJA.
ADVERTENCIA: LEASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
Form No. 625233-00 Cat. # BY2500, BY9000 (MAY-04)
Copyright © 2004 Black & Decker Printed in Mexico
TO REDUCERISKOF INJURY:
" Before any use, be sure everyone using this tool reads and understands all safety instructions and other
information contained in this manual.
Save these instructions and review frequently prior to use and in instructing others.
/_ WARNING: When using an electric appliance, basic safety precautions should always be followed
to reduce risk of fire, electric shock, and personal injury, including the following.
z_WARNING: Some dust created by this product contains chemicals known to the State of California to
cause cancer, birth defects or other reproductive harm. Some examples of these
chemicals are:
compounds in fertilizers
compounds in insecticides, herbicides and pesticides
arsenic and chromium from chemically treated lumber
To reduce your exposure to these chemicals, wear approved safety equipment such as dust masks that are
specially designedto filter out microscopic particles.
/k WARNING: This product contains chemicals, including lead, known to the State of California to
causecancer, and birth defects or other reproductive harm. Wash hands after handling.
CAUTION: Wear appropriate personalhearingprotectionduring use. Undersomeconditionsand
duration of use,noisefrom thisproductmay contributeto hearingloss.
READ ALLINSTRUCTIONS BEFOREUSING BLOWER.
READand follow all instructions.
DO NOT place inlet or outlet of vacuum near eyesor ears when operating.
THIS APPLIANCE IS PROVIDED WITH DOUBLE INSULATION. Use only identical replacement parts. See instructions for
servicing of double insulated appliances.
STOREIDLETOOLS. When not in use, the unit should Bestored in a dry, high or locked-up place- out of reach of children.
DON'T OVERREACH. Keep proper footing and balance at all times.
DO NOT pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.
MAINTAIN TOOL WITH CARE. Keep fan area clean for Best and safest performance. Follow instructions for proper
maintenance.
DO NOT attempt to repair the BIower/vac. Toassure product safety and reliability, repairs, maintenance, and adjustments
should be performed By Black & Decker service centers or authorized service stations, always using Black & Decker
replacement parts.
DO NOT operate blower/vac in a gaseous or explosive atmosphere. Motors in these tools normally spark, and the sparks
might ignite fumes.
DO NOT use to pick up flammable or combustible liquids such as gasoline or use in areas where they may Be present.
USEEXTRACARE when cleaning on stairs.
DO NOT leave appliance when plugged in. Unplug from outlet when not in use and before servicing.
DO NOT allow to be used as a toy. Close attention is necessary when used By or near children. Not recommended for use by
children.
DO NOT attempt to clear clogs from tool without first unplugging it.
USEONLY as described in this manual. Use only manufacturer's recommended attachments.
DO NOT usewith damaged cord or plug. If appliance is not working as it should, has been dropped, damaged, leftoutdoors,
or dropped intowater, return it to a service center.
DO NOT pull or carry By cord, use cord as a handle, or pull cord around sharp edges or corners. Keep cord away from
heated surfaces.
DO NOT unplug By pulling on cord. Tounplug, grasp the plug, not the cord.
DO NOT put any objects into openings. Do not usewith any opening blocked; keep free of dust, lint, hair and everything that
may reduce air flow.
KEEPhair, loose clothing, fingers, and all parts of Body away from openings and moving parts.
TURN OFF all controls Before unplugging.
DO NOT vacuum water, other liquids, or wet objects such as leaves. Never immerse any part of the tool in liquid.
DO NOT handle plug or appliance with wet hands.
KEEPCHILDREN, BYSTANDERSAND ANIMALS AWAY from thework area a minimum of 30 feet (10 meters) when starting or
operating the tool.
INSPECTTHEAREA Before using the tool. Remove all debris and hard objects such as rocks, glass, wire, etc. that can ricochet,
be thrown, or otherwise cause in ury or damage during operation. As a vacuum, the tool is designed to pick up dry material
such as eaves, grass, sma twigs,and Bitsof paper. Do not vacuum stones, grave, meta, Broken g ass, etc.
/kWARNING: Toreduce the risk of electrical shock; do not expose to rain, do not useon wet surfaces.
Store indoors.
,"k WARNING: Turn off and unplug unit, then wait until fan stops or at least 10 seconds Before removing the blower or
vacuum tube assemblies.
SAVE THESE INSTRUCTIONS
ReleaseButton
B0ut0ndeD_gagement OFF ON
B0t0nesdeLiberaci6n Arr_t EnMarche
Apagada Encendid0
0
Switch
Interraptor
0
ExtensionTube
TubedeRallange
Tub0de
\
!
VacuumTube
Tube
0
\ \
0
o
0
BlowingMode
Souffleuse
MododeSoplad0r
0
0
VacuumingMode
Aspirateur
MododeAspiradora
......i A i /
J ._,
Your Blower/Vac is double-insulated to give you added safety. In a double insulated appliance, M'o systemsof insulation are
provided instead ofgrounding. No grounding means is provided on a double insulated appliance, nor should a means for
grounding be addedto the appliance. Servicing a double insulated appliance requires extreme care and knowledge of the
system and should Be done only by qualified service personnel. Replacementparts for a double insulated appliance must Be
identical to the parts they replace. A double insulated appliance is markedwith the words double insulated or "double
insulation". The symbol (square within a square) may also Be marked on the appliance.
Double insulated tools have 2-wire cords and can be used with 2-wire or 3-wire extension cords. Only round jacketed
extension cords should be used, and we recommend that they be listed by Underwriters Laboratories (U.L.) (C.S.A. in
Canada). If the extension will be used outside, the cord must Be suitable for outdoor use. Any cord marked as outdoor can also
Be used for indoor work.
An extension cord must have adequate wire size (AWG or American Wire Gauge) for safely, and to prevent lossof power and
overheating. The smaller the gauge number of the wire, the greater the capacity of the cable, that is 16 gauge has more
capacity than 18 gauge. When using more than one extension to make up the total length, be sure each individual extension
contains at leastthe minimum wire size.
To determine the minimum wire size required, refer to the chart Below. Before using an extension cord, inspect it for loose or
exposed wires, damaged insulation, and defective fittings. Make any needed repairs or replace the cord if necessary.
Volts
120V
240V 0-50
Ampere Rating
More Not more American Wire Gage
Than Than
0 - 6 18 16 16 14
6 - 10 18 16 14 12
10- 12 16 16 14 12
12- 16 14 12 Not Recommended
Minimum Gage forCordSets
TotalLengthof Cordin Feet
0-25 26-50 51-100 101-150
51-100 101-200 201-300
