Your HOOVER Deep
Cleaner is fully assembled
and
ready to begin cleaning!
®
2
Important Safeguards!
When using an electrical appliance, always follow basic precautions,
including the following:
WARNING:
To reduce the risk of fire, electric
shock, or injury:
• Use indoors only.
• Use only on surfaces moistened
by the cleaning process. Do not
immerse product.
• Connect to a properly grounded
outlet only. See “Grounding
Instructions”.
• Do not clean over floor electrical
outlets.
• Do not use without tanks in place.
• Use extra care when cleaning on
stairs. Do not place deep cleaner on
stairs.
• Use deep cleaner only for its
intended use as described in the
instructions.
• Use only attachments recom-
mended by The Hoover Company;
others may cause hazards.
• The use of an extension cord is
not recommended. If an extension
cord is absolutely necessary, use at
least a 16 gauge 3-wire cord which
has a 3-prong grounding type plug
and a 3-pole receptacle that accepts
the machine plug.
• Unplug deep cleaner when not in
use. Turn off all controls before
unplugging.
• Unplug deep cleaner before con-
necting the powered hand tool.
• Always disconnect cord from electri-
cal outlet before servicing the deep
cleaner.
• Do not unplug by pulling on
cord. To unplug, grasp the plug, not
the cord.
• Never handle plug or appliance
with wet hands.
• Do not pull or carry by cord, use
cord as a handle, close door on cord
or pull cord around sharp edges or
corners. Do not run appliance over
cord. Keep cord away from heated
surfaces.
• Do not use with damaged cord or
plug. If appliance is not working as
it should, has been dropped, dam-
aged, left outdoors, or dropped into
water, take it to a Hoover Factory
Service Center or Authorized
Hoover Warranty Service Dealer.
• Close supervision is necessary
when any appliance is used by or
near children. Do not allow deep
cleaner to be used as a toy or to run
unattended at any time.
• Do not point tools toward people
or pets.
• Use only commercially available
Hoover SteamVac™ cleaners
intended for machine application.
Do not use any type of wax with
deep cleaner.
• Keep detergents and other clean-
ers out of children's reach.
• Do not use to pick up flammable
or combustible liquids such as
gasoline or use in areas where they
may be present.
• Do not pick up chlorine bleach,
drain cleaner, gasoline or any other
toxic material with this appliance.
• Do not pick up anything that is
burning or smoking, such as ciga-
rettes, matches, or hot ashes.
• Avoid picking up hard, sharp
objects with the deep cleaner. They
may damage the machine.
• Keep hair, loose clothing, fingers,
feet and all parts of body away
from openings and moving parts.
• Do not put any object into open-
ings. Do not use with any opening
blocked; keep free of dust, lint,
hair, and anything that may reduce
air flow.
• To help prevent matting and
resoiling, avoid contact with carpets
until they are dry. Keep children
and pets away from carpets until
they are completely dry.
• Store in a dry place. Do not ex-
pose machine to freezing tempera-
tures.
This appliance must be grounded. If it
should malfunction or breakdown,
grounding provides a path of least resis-
tance for electrical current to reduce the
risk of electric shock. This appliance is
equipped with a cord having an equip-
ment-grounding conductor (C) and
grounding plug (A). The plug must be
plugged into an appropriate outlet (B)
that is properly installed and grounded
in accordance with all local codes and
ordinances.
DANGER-
Improper connection of the equipment-
grounding conductor can result in the
risk of electric shock. Check with a quali-
fied electrician or service person if you
are in doubt as to whether the outlet is
properly grounded. Do not modify the
plug provided with the appliance - if it
will not fit the outlet, have a proper out-
let installed by a qualified electrician.
This appliance is for use on a nominal
120 volt circuit and has a grounding
plug that looks like the plug illustrated
in sketch (A).
A temporary adapter (D) may be used to
connect this plug to a 2-pole receptacle
(E) if a properly grounded outlet is not
available. The temporary adapter should
be used only until a properly grounded
outlet (B) can be installed by a qualified
electrician. The green colored rigid ear,
lug, or the like (F) extending from the
adapter must be connected to a perma-
nent ground (G) such as a properly
grounded outlet box cover. Whenever
the adapter is used, it must be held in
place by a metal screw. NOTE: In
Canada, the use of a temporary adapter
is not permitted by the Canadian
Electrical Code.
A
B
C
D
F
G
E
READ ALL INSTRUCTIONS BEFORE USING APPLIANCE.
Save these instructions!
Grounding
Instructions
3
Fill in and Save
For your records, enter the model number and
serial numbers in the spaces provided. These
numbers are located on the data label on the back
of the cleaner.
Model No. ____________________________
Serial No. _____________________________
Save your sales receipt and attach it to this
manual. Proof of date of purchase may be
required for warranty service of your cleaner.
Important safeguards . . . . . . . . 2
Carton contents . . . . . . . . . . . . . 3
Cleaner description . . . . . . . . . . 4
Deep cleaner basics . . . . . . . . . . 5
Filling the tank . . . . . . . . . . . . 5
Emptying the recovery tank . 6
Attaching the hose . . . . . . . . . 7
Selecting & attaching tool . . . 7
Draining & storing hose . . . . 8
Cleaning carpet . . . . . . . . . . 10-11
Cleaning upholstery . . . . . 11-12
Basic steps for cleaning. . . . . . 13
Warranty . . . . . . . . . . . . . . . . . . 14
A.Deep cleaner
B. Hoover Detergent
©2004 The Hoover Company
www.hoover.com
Continued
➜
To contact us:
• www.hoover.com
• 1-800-944-9200 - automated service
dealer locator
• 1-330-499-9499 - our Consumer
Response Center (8 AM to 5 PM
Monday - Friday)
Contents
Carton Contents
A
B
4
Cleaner Description
Features
Press upper handle release
button (B) to fold handle.
1. Hand grip
2. Solution trigger: press to release
cleaning solution
3. Clean Surge™ button
4. Upper handle
5. Upper handle release button
6. Solution tank cap/measuring cup
7. Solution tank release button
8. Solution tank
9. Brush setting selector
10. Nozzle
11. Recovery tank
12. Recovery tank release button
13. Powered hand tool
14. Recovery tank cap
15. Stair/upholstery nozzle
16. Cord hooks (tool caddy removed)
17. Hose door
18. Handle release pedal
19. ON/OFF pedal
20. Hose
21. Cord hooks (tool caddy stored on
cleaner)
22. Hose connector
23. Tool caddy
This deep cleaner is intended for
household use.
Operate deep cleaner only at voltage
specified on data plate on back of
cleaner. Plug deep cleaner into a proper-
ly grounded outlet.
How to fold handleUnfold handle
16
22
17
20
23
13
13
15
18
12
11
10
9
19
7
8
6
14
21
21
16
5
4
3
2
1
B
A
Your HOOVER
Deep Cleaner is
fully assembled and
ready to begin
cleaning!
1
2
Raise upper handle (A) to
upright position until it
locks in place.
5
Fill the solution tank
Unplug deep cleaner from
electrical outlet.
✓ Press button (A) and remove solution
tank (Fig. 3)
✓ Release latches (B) on tank cap and
remove (Fig. 4)
✓ Use cap (Fig. 5) to measure the proper
amount of HOOVER detergent according
to the chart below:
✓ Pour detergent into tank
✓ Fill tank to fill line (C) (approx. 1 gallon) with hot tap water
(Fig. 6)
✓ Replace cap. Secure both latches (B) (Fig. 4)
✓ Place bottom of tank onto cleaner. Pivot top of tank and
snap in place (Fig. 7)
Amount of
Surface detergent Type of detergent
Carpet two HOOVER Carpet/
caps Upholstery Detergent
Upholstery one HOOVER Carpet/
cap Upholstery Detergent
For heavy traffic areas: Pre-treat with HOOVER Spot
and Stain Spray (available at additional cost if not
included with your model)
OR
Use 4 caps of Carpet/Upholstery detergent.
Caution: Detergents contain Anionic and Nonionic
Surfactants. Avoid contact with the eyes and skin. In case
of contact with eyes, flush with cold water for 15 minutes.
In case of contact with skin, wash with water. If irritation
persists, call a physician. For Medical Information (U.S.),
call 1-800-752-7869.
Continued
➜
A
B
B
C
Deep Cleaner Basics
3
4
5
6
7
NOTE: For best results, use only Hoover detergents.
They are specifically formulated for use with your
SteamVac™ Deep Cleaner.
6
Empty the recovery tank
Unplug deep cleaner from electrical outlet.
✓ An automatic shut-off device prevents the cleaner
from picking up more dirty water than it can hold in
the recovery tank.
You will know the tank needs to be emptied --
• The amount of dirty water has reached the full line
(A).
• When the motor sound rises in pitch.
• You do not see dirty solution coming up through
the nozzle.
• The float (B) inside the recovery tank has risen to
the top of the tank (Fig. 8).
✓ Press button (C) and remove tank (Fig. 9).
✓ Release latches (D) on tank cap and remove cap (Fig.
10).
✓ Empty tank.
✓ Replace cap (Fig. 11). Secure both latches (D) (Fig. 10).
✓ Remove any debris that has collected on lint filter (E)
on cleaner body (Fig. 12 and inset).
✓ Place bottom of tank onto cleaner. Pivot top of tank
and snap in place (Fig. 12).
B
A
C
D
D
E
E
8
9
10
11
12
For full suction, it is important that the recovery
tank cap is properly secured before cleaning.
7
Continued
➜
Attach the hose
Select tool
Attach tool
Unplug deep cleaner from electrical outlet.
✓ Place handle in upright position.
✓ The hose and tool caddy can be removed from the
cleaner if you desire.
✓ Remove hose from tool caddy.
✓ Open hose door (A) on back of deep cleaner (Fig. 13).
✓ Align hose connector with hose and solution ports (C)
(Fig. 14).
✓ Push hose into port and lock in place.
✓ To remove hose: Squeeze latches (D) on top and bottom
of hose. Remove hose from port (Fig. 15).
✓ Close hose door (A) tightly (inset).
SpinScrub™ hand tool
• Rotating brushes
• Use on carpet to clean
spots, small areas or
stairs
Stair/Upholstery nozzle
• Built-in brush
• Use on upholstery
Unplug deep cleaner from electrical outlet.
✓ Slide tool onto hose. Snap tool over tab (E) on hose (Fig 18).
✓ To remove tool: Push forward and up on latch (F) (Fig. 19).
Slide tool off hose.
F
E
C
B
D
A
A
A
13
14
15
17
18
19
16
8
When finished using the hose and tool, remove water
from the hose.
✓ Turn deep cleaner on and hold end of hose up for
several seconds (A). Do not press trigger. (Fig. 20)
✓ Turn deep cleaner off and unplug it.
✓ Hold hose connector in sink and press trigger to
remove solution from hose (B) (Fig. 20).
Unplug deep cleaner from electrical outlet.
➤ Hook hose connector (C) into caddy (Fig. 21).
➤ Wrap hose around caddy in a counterclockwise
direction (Fig. 22).
➤ Hook tool connector (D) and ‘SpinScrub’ tool (E) onto
caddy (Fig. 23).
➤ Snap upholstery tool (F) into caddy (Fig. 24).
The handle must be in the upright position in order to
get cleaning solution through the hose.
Drain the hose
Store hose
B
A
F
E
D
C
20
22
21
24
23
9
Continued
➜
You can either store the hose caddy on the cleaner or remove it
to store separately.
To store caddy on the cleaner:
➤ Slide tabs (G) on caddy into slots on back of cleaner (Fig.
25).
➤ Hook top of caddy to cleaner (H).
➤ Wrap cord around cord hooks (I) on caddy (Fig. 26). Rotate
top hook to release cord.
To remove caddy from the cleaner:
➤ Lift caddy off cleaner (Fig. 27).
➤ Wrap cord around cord hooks (J) on back of cleaner (Fig.
28). Rotate bottom hook to release cord.
Hose caddy
Brush speed selector
Clean Surge™ button
Choose ON for normal cleaning of carpet.
Choose OFF when brushing is not desired.
Push ‘Clean Surge’ button (K) to release extra cleaning solution.
Use the ‘Clean Surge’ button when cleaning heavily soiled areas
of carpet (traffic areas, spots, etc.)
No cleaning solution removes all stains from all carpets.
Stain removal varies with the type of spill, time passed before
removal, carpet material, and carpet type.
J
K
K
G
I
H
25
26
27
28
29
30
10
Remove lightweight furniture (tables, lamps, etc.) from area to be cleaned.
Protect any remaining furniture by pinning up furniture skirts and placing
aluminum foil or plastic under legs.
Vacuum carpet thoroughly to remove loose dirt, hair, lint and other debris
(Fig. 31).
Test detergent for colorfastness on a hidden area of carpet.
Wet a white cloth or paper towel with some detergent. Gently rub onto a
hidden area of carpet. Wait ten minutes. Blot with white cloth or paper towel
and check for color transfer.
Pretreat spots, stains and high traffic areas with HOOVER Spot and Stain
Spray (Fig. 32).
Spray spot or area with Spot and Stain Spray. Then proceed with the next
cleaning steps.
For stubborn spots or stains, refer to the stain guide included with your
cleaner.
Fill solution tank with hot tap water and proper amount of HOOVER
detergent (see page 5) (Fig. 33).
Use only HOOVER brand detergents in your deep cleaner. Other brands
may damage the deep cleaner.
Plan your cleaning to avoid walking on wet carpet. Start at the end of the
room farthest from the exit and work in small sections (Fig. 34).
Step on handle release pedal and lower handle. Turn cleaner ON.
Squeeze and hold trigger (A) to release cleaning solution (Fig. 35). Push
cleaner forward SLOWLY then pull it back SLOWLY.
Use ‘Clean Surge’ button (B) in heavily soiled areas (Fig. 35).
Let go of trigger and push cleaner over same area to pick up dirty solution
without putting down more solution. Continue using dry strokes until you
see only a little solution coming up through the nozzle (front of cleaner).
Do not make the carpet too wet! Use no more than two sets of forward and
backward strokes while releasing solution. Always follow with dry strokes -
the more the better.
Listen carefully! When the motor sound changes (rises in pitch), the recovery
tank needs to be emptied.
When water has reached the full line in the recovery tank, the cleaner will
NOT pick up dirty solution.
Allow carpet to dry. Avoid walking on the carpet until it is dry.
Increased air circulation (open doors, turn on fans, etc.) will help carpet dry
thoroughly to prevent the growth of
mold or mildew.
Vacuum thoroughly after carpet has dried. This will reduce any shading left
by the deep cleaner’s brushes.
Cleaning carpet
1
2
3
4
5
6
7
8
9
10
11
12
13
Exit
Start
35
34
33
32
31
A
B
Check fabric cleaning code (Fig. 36). Look on the furniture manufacturer’s
tag for a ‘W’ or ‘WS’ code. These codes indicate that it is alright to use your
deep cleaner to clean the upholstery.
Do not use the deep cleaner on upholstery marked ‘S’, ‘X’ or ‘Dry Clean
Only’.
Vacuum upholstery thoroughly with your vacuum cleaner’s attachments.
Test detergent for colorfastness on a hidden area of upholstery.
Wet a white cloth or paper towel with some detergent. Gently rub onto a
hidden area of upholstery. Wait ten minutes. Blot with white cloth or paper
towel and check for color transfer.
Pretreat spots and stains with HOOVER Spot and Stain Spray (Fig. 37).
Spray spot or area with Spot and Stain Spray. Then proceed with the next
cleaning steps.
For stubborn spots or stains, refer to the stain guide included with your
cleaner.
Fill solution tank with hot tap water and proper amount of HOOVER deter-
gent (see page 5)(Fig. 38).
Use only HOOVER brand detergents in your deep cleaner. Other brands
may damage the deep cleaner.
Attach hose and tool as described in Figs. 13-19 (Fig. 39).
Place handle in full upright position. Turn cleaner ON.
Squeeze and hold trigger (A) to release cleaning solution. Gently press tool
into fabric and slowly pull the tool over the fabric (Fig. 40).
Let go of trigger and pull tool over same area to pick up dirty solution with-
out putting down more solution. Continue using dry strokes until you see
only a little solution coming up through the tool.
Do not make the upholstery too wet! Use no more than two strokes while
releasing solution. Always follow with dry strokes - the more the better.
Listen carefully! When the motor sound changes (rises in pitch), the recovery
tank need to be emptied.
When water has reached the full line in the recovery tank, the cleaner will
NOT pick up dirty solution.
Allow upholstery to dry. Avoid using upholstery until it is dry.
Increased air circulation (open doors, turn on fans, etc.) will help upholstery
dry thoroughly to prevent the growth of mold or mildew.
11
Continued
➜
Cleaning upholstery
1
2
3
4
5
6
7
8
9
10
11
12
THE UPHOLSTERY COMPANY
LICENSE NUMBER:
STAMP HERE
ALL NEW MATERIAL
UNDER PENALTY OF LAW
W
40
39
38
37
36
A
12
Clean the nozzle
Clean the brushes
G
D
E
C
F
A
B
Unplug deep cleaner from electrical outlet.
➤ Remove solution and recovery tanks to prevent possible leaks.
➤ Lift up on top of nozzle (A) and slide off cleaner (Fig. 41).
➤ Wipe debris off nozzle and front of cleaner with a damp cloth.
➤ Tilt cleaner back, raising front of cleaner off floor. Slide nozzle
(B) up from bottom of cleaner (Fig. 42).
➤ Press on upper portion of nozzle to snap in place.
Unplug deep cleaner from electrical outlet.
➤ Remove solution and recovery tanks to prevent possible leaks.
➤ Tilt cleaner back so handle rests on the floor.
➤ Pull brush assembly firmly to remove (Fig. 43).
➤ Rinse brushes under running water.
➤ Align posts (C) on brush assembly with slots (D) in cleaner
(Fig. 44).
➤ Turn brushes slightly to align square post (E) with square hole
(F) in cleaner (Fig. 44).
➤ Press brush assembly firmly and snap in place.
Unplug deep cleaner from electrical outlet.
➤ Remove solution and recovery tanks to prevent possible
leaks.
➤ Tilt cleaner back so handle rests on the floor.
➤ Squeeze filter frame (G) and pull it out until it stops (Fig. 45).
➤ Wipe debris off filter.
➤ Slide filter back into place.
Clean the brush filter
41
42
43
44
45
Routine care for your Deep Cleaner
To obtain approved HOOVER service and genuine HOOVER parts, locate the nearest Hoover
Factory Service Center or Authorized Hoover Warranty Service Dealer (Depot) by:
✓ Checking the Service Section of The Hoover Company on-line at www.hoover.com OR
✓ Checking the list of Factory Service Centers provided with this cleaner OR
✓ Checking the Yellow Pages under “Vacuum Cleaners - Household” OR
✓ Calling 1-800-944-9200 for an automated referral of authorized service outlet locations
(U.S. only)
Do not send your cleaner to The Hoover Company in North Canton for service; this will only result
in delay.
If further assistance is needed, contact The Hoover Company Consumer Response Center, North
Canton, Ohio 44720, Phone: 330-499-9499.
In Canada, contact Hoover Canada, Burlington, Ontario L7R 4A8, Phone: 1-800-263-6376.
Always identify your cleaner by the complete model number when requesting information or order-
ing parts. (The model number appears on the back of the cleaner.)
Storing your Deep Cleaner
Lubrication
Service
✓ Empty solution tank and rinse thoroughly.
✓ Place empty solution tank on deep cleaner. Turn deep cleaner ON. Squeeze trigger and push
deep cleaner forward and back several times. This will clear any solution remaining inside the
cleaner.
✓ Empty recovery tank, rinse thoroughly and let air dry.
✓ Allow brushes and underside of deep cleaner to air dry thoroughly before storing deep
cleaner on a carpeted or wood surface.
The motor is equipped with bearings which contain sufficient lubrication for the life of the motor.
The addition of lubricant could cause damage. Do not add lubricant to motor bearings.
13
Continued
➜
Troubleshooting
Use the list below to help solve minor problems.
What’s the What to do
problem?
Deep cleaner won’t run ✓ Make sure the cleaner is
plugged in firmly.
✓ Check the fuse or breaker.
Low suction ✓ Empty the recovery tank; it
may be full and the auto-
matic shut-off engaged.
✓ Make sure recovery tank cap
is securely latched.
Cleaning solution won’t ✓ Make sure solution tank is
dispense securely in place
✓ Refill the solution tank if it is
empty
Brushes won’t rotate ✓ Clean brush filter as
described in Fig. 45.
✓ Set Brush Speed Selector to
ON.
Low suction in hose during ✓ Make sure recovery tank cap
tool use is securely latched.
✓ Disconnect hose from cleaner
and check for blockage in
hose.
14
Full One Year
Warranty
(Domestic Use)
Your HOOVER® appliance is war-
ranted in normal household use, in
accordance with the Owner’s
Manual against original defects in
material and workmanship for a
period of one full year from date of
purchase. This warranty provides, at
no cost to you, all labor and parts to
place this appliance in correct operat-
ing condition during the warranted
period. This warranty applies when
the appliance is purchased in the
United States including its territories
and possessions, or in Canada or
from a U. S. Military Exchange.
Appliances purchased elsewhere are
covered by a limited one year war-
ranty which covers the cost of parts
only. This warranty does not apply if
the appliance is used in a commercial
or rental application.
This warranty only applies when the
product is in use in the country or
territory in which it is purchased.
Warranty service can only be
obtained by presenting the appliance
to one of the following authorized
warranty service outlets. Proof of
purchase will be required before ser-
vice is rendered.
1. Hoover Factory Service
Centers.
2. Hoover Authorized Warranty
Service Dealers (Depots).
For an automated referral of autho-
rized service outlets in the U.S.A.,
phone 1-800-944-9200 OR
visit The Hoover Company on-line
at www.hoover.com
This warranty does not cover pick
up delivery, or house calls; however,
if you mail your appliance to a
Hoover Factory Service Center for
warranty service, transportation will
be paid one way.
While this warranty gives you spe-
cific legal rights, you may also have
other rights which vary from state to
state.
If further assistance is needed, or if
there are questions concerning this
warranty or the availability of war-
ranty service outlets, write or phone
the Consumer Response Center, The
Hoover Company, 101 East Maple
St., North Canton, Ohio 44720,
Phone 1-330-499-9499.
In Canada, contact Hoover Canada,
Burlington, Ontario L7R 4A8,
1-800-263-6376.
15
