240-0033
10" Jobsite Table Saw
with Folding Stand
OPERATOR’S MANUAL
CAUTION: To Reduce The Risk Of Injury, User Must Read
And Understand Operator’s Manual. Save These Instructions
For Future Reference.
For questions / comments, technical assistance or repair
parts - Please call toll free at: 1-877-684-8912 (Monday -
Friday 8am - 6pm EST.)
TABLE OF CONTENTS
Safety Symbols ............................................................................................................................................................
Safety Instructions .......................................................................................................................................................
Overview ....................................................................................................................................................................
Specications ............................................................................................................................................................
Contents ....................................................................................................................................................................
Assembly ...................................................................................................................................................................
Operation ...................................................................................................................................................................
Adjustments ...............................................................................................................................................................
Maintenance ..............................................................................................................................................................
Troubleshooting .........................................................................................................................................................
Replacement Parts List...............................................................................................................................................
Warranty ....................................................................................................................................................................
Page 2
Page 3
Page 14
Page 15
Page 16
Page 17
Page 31
Page 44
Page 47
Page 48
Page 49
Page 50
Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation
of these symbols will allow you to operate the tool better and safer.
SAFETY SYMBOLS
Page 2
WARNING: The operation of any power tool can result in
foreign objects being thrown into your eyes, which can result in severe
eye damage. Before beginning power tool operation, always wear
safety goggles or safety glasses with side shields and a full-face shield
when needed. We recommend a Wide Vision Safety Mask for use over
eyeglasses or standard safety glasses with side shields. Always use
eye protection which is marked to comply with ANSI Z87.1.
Symbol Name Designation / Explanation
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watts Power
Alternating current Type of current
Direct current Type of characteristic of current
no No-load speed Rotational speed at no load
.../min
Per minute Revolutions, strokes, surface speed orbits, etc., per minute
Class II construction Double insulated construction
Be careful of your hand Danger keep hands away from blade
Wear safety goggles
Read the operator’s manual Read and understand power tool manual
Unlock / to loosen
Lock / to tighten or secure
WARNING: To ensure safety and reliability, all repairs should be performed by a qualied service technician.
The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations
with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any
danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.
SAFETY INSTRUCTIONS
Page 3
WARNING: Be sure to read and understand all safety instructions in this manual, including all safety alert symbols
such as “DANGER,” “WARNING,” and “CAUTION” before using this tool. Failure to follow all instructions listed below may
result in electric shock, re, and/or serious personal injury.
WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result in death
or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, could result in minor or moderate
injury.
DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION. May be used in conjunction with
other symbols or pictographs.
NOTICE: (Without Safety Alert Symbol) Indicates a situation that may result in property damage.
SAVE THESE INSTRUCTIONS!
Safety is a combination of using common sense, staying
alert, and knowing how your miter saw works. Read
this manual to understand this miter saw and how to use it
safely.
GENERAL SAFETY IMFORMATION
1) Work area safety
• Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
• Do not operate power tools in explosive atmospheres,
such as in the presence of ammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
• Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2) Electrical safety
• Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adaptor plugs with
earthed (grounded) power tools. Unmodied plugs and
matching outlets will reduce the risk of electric shock.
• Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is earthed
or grounded.
• Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
• Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
• When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock.
• If operating a power tool in a damp location is
unavoidable, use a ground fault circuit interrupter
(GFCI) protected supply. Use of an GFCI reduces the
risk of electric shock.
3) Personal safety
• Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the inuence of drugs,
alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
• Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal
injuries.
• Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch
or energising power tools that have the switch on invites
accidents.
• Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
SAFETY INSTRUCTIONS
Page 4
WARNING: Read and understand all instructions.
Failure to follow all instructions listed below, may result in
electric shock, re and/or serious personal injury. Save all
warnings and instructions for future reference.
WARNING: To avoid the risk of personal injury,
do not modify this power tool or use accessories not
recommended to t your tool.
WARNING: Read warnings and conditions about
your carbide tipped saw blade.
• Do not operate the saw without the proper saw blade
guard in place.
• Carbide is a very hard but brittle material. Care should be
taken while mounting, using and storing carbide tipped
blades to prevent accidental damage.
• Slight shocks, such as striking the tip, can seriously
damage the blade. Foreign objects on the work piece,
such as wire or nails, can also cause tips to crack or break
off.
• Before using, always visually examine the blade and tips
for cracks, breakage, missing or loose tips, or other
damage.
• Do not use if damage is suspected. Failure to heed safety
instructions and warnings can result in serious bodily
injury or loss of eyesight.
CAUTION: Always follow proper operating
procedures as dened in this manual — even if you
are familiar with use of this or similar tools. Remember that
being careless for even a fraction of a second can result in
severe personal injury.
GENERAL SAFETY RULES
Save all warnings and instructions for future reference.
WARNING: Read all safety warnings, instructions,
illustrations and specications provided with this power
tool. Failure to follow all instructions listed below may result
in electric shock, re and/or serious injury.
The term “power tool” in the warnings refers to your mains-
operated (corded) power tool or battery-operated (cordless)
power tool.
rotating part of the power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
• Dress properly. Do not wear loose clothing or jewelry.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
• If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
devices can reduce dust-related hazards.
• Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury
within a fraction of a second.
4) Power tool use and care
• Do not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it was designed.
• Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
• Disconnect the plug from the power source and/or
remove the battery pack, if detachable, from the power
tool before making any adjustments, changing
accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool
accidentally.
• Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained power tools.
• Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
• Use the power tool, accessories, tool bits, etc., in
accordance with these instructions, taking into account
the working conditions and the work to be performed.
Use of the power tool for operations different from those
intended could result in a hazardous situation.
• Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpected situations.
5) Service
• Have your power tool serviced by a qualied repair person
using only identical replacement parts. This will ensure
that the safety of the power tool is maintained.
SAFETY INSTRUCTIONS
Page 5
WARNING: The use of this tool can generate and/or
disperse dust, which may cause serious and permanent
respiratory or other injury. Always use protection appropriate
for the dust exposure. Direct particles away from the face
and body.
WARNING: To avoid the risk of personal injury,
do not modify this power tool or use accessories not
recommended to your tool.
WARNING: Read warnings and conditions about
your carbide-tipped saw blade.
WARNING: Do not operate the saw without the
proper blade guard in place for all through cut operations.
Make sure the blade guard is reinstalled immediately after
nishing any non-through cut operations which require
removal of the blade guard.
• Carbide is a very hard but brittle material. Care should be
taken while mounting, using and storing carbide tipped
blades to prevent accidental damage.
• Slight shocks, such as striking the tip, can seriously
damage the blade. Foreign objects on the workpiece,
such as wire or nails, can also cause tips to crack or break
off.
• Before using, always visually examine the blade and tips
for cracks, breakage, missing or loose tips, or other
damage.
• Do not use if damage is suspected. Failure to heed safety
instructions and warnings can result in serious bodily
injury or loss of eyesight.
• Read instruction manual and know your tool. Read and
familiarize yourself with entire instruction manual. Learning
the tool’s proper applications, limitations, and specic
potential hazards will greatly minimize the possiblity of
CAUTION: Always follow proper operating
procedures as dened in this manual — even if you
are familiar with use of this or similar tools. Remember that
being careless for even a fraction of a second can result in
severe personal injury.
Handling the power cord on this product may expose you
to chemicals known to cause cancer and birth defects or
other reproductive harm. Wash hands after handling.
power and overheating. A wire gauge size (A.W.G.) of at
least 14 is recommended for an extension cord 25' (7.6 m)
or less in length. If in doubt, use the next heavier gauge.
The smaller the gauge number, the heavier the cord.
• Dress properly. Do not wear loose clothing, gloves,
neckties, or jewelry. They can get caught and draw you
into moving parts. Rubber gloves and nonskid footwear
are recommended when working outdoors. Also wear
protective hair covering to contain long hair.
• ALWAYS wear safety goggles that comply with United
States ANSI Z87.1 and a face shield or dust mask if
operation is dusty. Everyday eyeglasses have only impact-
resistant lenses; they are NOT safety glasses.
• Secure work. Use clamps or a vice to hold workpiece
when practical. It’s safer than using your hand and frees
both hands to operate tool.
• Don’t overreach. Keep proper footing and balance at all
times.
• Maintain tools with care. Keep tools sharp and clean for
better and safer performance. Follow instructions for
lubricating and changing accessories.
• Disconnect tools. All tools should be disconnected when
not in use, before servicing, or when changing attachments,
blades, bits, cutters, etc. Turn the machine “OFF” before
disconnecting tools to avoid an accidental start when
plugging the tools in again. The accidental start may cause
serious injury. Do not touch the terminal or plug’s metal
part when inserting or removing the plug from an outlet.
• Do not plug in or pull out from power supply with wet
hands to prevent electric shock.
• Use recommended accessories. Consult the operator’s
manual for recommended accessories. The use of improper
accessories may risk injury.
• Never stand on tool. Serious injury could occur if the tool
is tipped or if the cutting tool is unintentionally contacted.
Do not use it as a stepping stool.
• Check damaged parts. Before further use of the tool, a
guard or other part that is damaged should be carefully
checked to determine that it will operate properly and
perform its intended function. Check for alignment of
moving parts, binding of moving parts, breakage of parts,
mounting and any other conditions that may affect its
operation. A guard or other part that is damaged must be
properly repaired or replaced by an authorized service
centre to avoid risk of personal injury.
• Use the right direction of feed. Feed workpiece into a
blade or cutter against the direction of rotation of blade
or cutter only. Feeding the workpiece in the same direction
that the saw blade is rotating above the table may result
in the workpiece, and your hand, being pulled into the saw
blade.
SAFETY INSTRUCTIONS
Page 6
accidents and injury. Make sure all users are familiar with
its warnings and instructions before using tool.
• Guard against electric shock by preventing body contact
with grounded surfaces. For example: pipes, radiators,
ranges, refrigerator enclosures.
• Keep guards in place and in good working order. Blade
guard must be in place for all through cut operations.
Reinstall the blade guard immediately after nishing any
non-through cut operations which require removal of the
blade guard. Never operate the saw without the blade
guard in place for any cut which does not require it to be
removed. Make sure the blade guard is operating properly
before each use. A guard that is loose, damaged, or is
not functioning correctly must be repaired or replaced.
• Make sure the saw blade is not contacting the guard,
riving knife or the workpiece before the switch is turned
on. Inadvertent contact of these items with the saw blade
could cause a hazardous condition.
• Remove adjusting keys and wrenches. Form habit of
checking to see that keys and adjusting wrenches are
removed from tool before turning it on.
• Keep work area clean. Cluttered areas and benches
invite accidents. DO NOT leave tools or pieces of wood
on the saw while it is in operation. Distraction or a potential
jam can be dangerous.
• Do not use in dangerous environments. Do not use
power tools in damp or wet locations or expose to rain.
Keep the work area well lit. Locate the tool in a level area.
It should be installed in an area that provides enough room
to easily handle the size of your workpiece. Cramped, dark
areas, and uneven slippery oors invite accidents.
• Keep children and visitors away. All visitors should wear
safety glasses and be kept a safe distance from work area.
Do not let visitors contact tool or extension cord while
operating.
• Make workshop childproof with padlocks and master
switches, or by removing starter keys.
• Don’t force tool. It will do the job better and safer at the
feed rate for which it was designed.
• Feed workpiece at an even pace. Do not bend or twist
the workpiece. If jamming occurs, turn the tool off
immediately, unplug the tool then clear the jam. Jamming
the saw blade by the workpiece can cause kickback or
stall the motor.
• Use the right tool. Don’t force the tool or attachment to
do a job it was not designed for. Don’t use it for a purpose
not intended.
• Use the proper extension cord. Make sure your extension
cord is in good condition. Use only a cord heavy enough
to carry the current your product will draw. An undersized
cord will cause a drop in line voltage resulting in loss of
surface that is green with or without yellow stripes is the
equipment-grounding conductor. If repair or replacement
of the electric cord or plug is necessary, do not connect
the equipment-grounding conductor to a live terminal.
Repair or replace a damaged or worn cord immediately.
Stay constantly aware of cord location and keep it well
away from the rotating blade.
• Inspect extension cords periodically and replace if
damaged.
• Ground all tools. If tool is equipped with three-prong plug,
it should be plugged into a three-hole electrical receptacle.
• Check with a qualied electrician or service personnel
if the grounding instructions are not completely understood,
or if in doubt as to whether the tool is properly grounded.
• Use only correct electrical devices: 3-wire extension
cords that have 3-prong grounding plugs and 3-hole
receptacles that accept the tool's plug.
• Do not modify the plug provided. If it will not t the outlet,
have the proper outlet installed by a qualied electrician.
• Keep tool dry, clean, and free from oil and grease.
Always use a clean cloth when cleaning. Never use brake
uids, gasoline, petroleum-based products, or any solvents
to clean tool.
• Stay alert and exercise control. Watch what you are
doing and use common sense. Do not operate tool when
you are tired. Do not rush.
• Do not use tool if switch does not turn it on and off.
Have defective switches replaced by an authorized service
center.
• Use only correct blades. Do not use blades with incorrect
size holes. Never use blade washers or blade bolts that
are defective or incorrect. The maximum blade capacity
of your saw is 10" (25.4 cm). Blades that do not match
the mounting hardware of the saw will run off-center
causing loss of control.
• Before making a cut, be sure all adjustments are
secure.
• Be sure blade path is free of nails. Inspect for and
remove all nails from lumber before cutting.
• Never touch blade or other moving parts during use.
• Firmly mount the tool on a secure surface to ensure
its stability before operating the tool.
• Never start a tool when any rotating component is in
contact with the workpiece.
• Do not operate a tool while under the inuence
of drugs, alcohol, or any medication.
• When servicing use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
• Use only recommended accessories listed in this manual
or addendums. Use of accessories that are not listed may
• Never leave tool running unattended. Turn the power
off. Don’t leave tool until it comes to a complete stop. An
unattended running saw is an uncontrolled hazard.
• Protect your lungs. Wear a face or dust mask if the cutting
operation is dusty.
• Protect your hearing. Wear ear plugs or muffs during
extended periods of operation.
• Do not abuse cord. Never yank cord to disconnect from
receptacle. Keep cord away from heat, oil, and sharp
edges.
• When operating a power tool outside, use an outdoor
extension cord marked “w-a” or “w”. These cords are
rated for outdoor use and reduce the risk of electric shock.
• Always keep the blade guard and spreader (riving
knife) in place and in working order for all through cut
operations. Reinstall the blade guard immediately after
nishing any non-through cut operations which require
removal of the blade guard.
• Adjust the riving knife as described in this instruction
manual. Incorrect spacing, positioning and alignment can
make the riving knife ineffective in reducing the likelihood
of kickback.
• For the riving knife and anti-kickback pawls to work,
they must be engaged in the workpiece. The riving knife
and anti-kickback pawls are ineffective when cutting
workpieces that are too short to be engaged with the riving
knife and anti-kickback pawls. Under these conditions a
kickback cannot be prevented by the riving knife and
anti-kickback pawls.
• Use the appropriate saw blade for the riving knife. For
the riving knife to function properly, the saw blade diameter
must match the appropriate riving knife and the body of
the saw blade must be thinner than the thickness of the
riving knife and the cutting width of the saw blade must
be wider than the thickness of the riving knife.
• Keep blades clean, sharp, and with sufcient set. Sharp
blades minimize stalling and kickback.
• Keep hands away from cutting area. Keep hands away
from blades. Do not reach underneath work or around or
over the blade while blade is rotating. Do not attempt to
remove cut material when blade is moving. The material
may become trapped between the fence or inside the saw
blade guard, and the saw blade pulling your ngers into
the saw blade. Turn the saw off and wait until the
saw blade stops before removing material.
• Blade coasts after being turned off.
• Never use in an explosive atmosphere. Normal sparking
of the motor could ignite fumes.
• Inspect tool cords periodically. If damaged, have repaired
by a qualied service technician at an authorized service
facility. The conductor with insulation having an outer
SAFETY INSTRUCTIONS
Page 7
1) Guarding related warnings
• Keep guards in place. Guards must be in working
order and be properly mounted. A guard that is loose,
damaged, or is not functioning correctly must be repaired
or replaced.
• Always use saw blade guard, riving knife and anti-
kickback device for every through-cutting operation.
For through-cutting operations where the saw blade cuts
completely through the thickness of the workpiece, the
guard and other safety devices help reduce the risk of
injury.
• Immediately reattach the guarding system after
completing an operation (such as rabbeting, dadoing
or resawing cuts) which requires removal of the guard,
riving knife and/or anti-kickback device. The guard,
riving knife, and anti-kickback device help to reduce the
risk of injury.
• Make sure the saw blade is not contacting the guard,
riving knife or the workpiece before the switch is turned
on. Inadvertent contact of these items with the saw blade
could cause a hazardous condition.
• Adjust the riving knife as described in this instruction
manual. Incorrect spacing, positioning and alignment can
make the riving knife ineffective in reducing the likelihood
of kickback.
• For the riving knife and anti-kickback device to work,
they must be engaged in the workpiece. The riving knife
and anti-kickback device are ineffective when cutting
workpieces that are too short to be engaged with the riving
knife and anti-kickback device. Under these conditions a
kickback cannot be prevented by the riving knife and anti-
kickback device.
• Use the appropriate saw blade for the riving knife. For
the riving knife to function properly, the saw blade diameter
must match the appropriate riving knife and the body of
the saw blade must be thinner than the thickness of the
riving knife and the cutting width of the saw blade must
be wider than the thickness of the riving knife.
2) Cutting procedures warnings
• DANGER: Never place your ngers or hands in the
vicinity or in line with the saw blade. A moment of
inattention or a slip could direct your hand towards the
saw blade and result in serious personal injury.
• Feed the workpiece into the saw blade or cutter only
against the direction of rotation. Feeding the workpiece
in the same direction that the saw blade is rotating above
the table may result in the workpiece, and your hand, being
pulled into the saw blade.
• Never use the miter gauge to feed the workpiece when
ripping and do not use the rip fence as a length stop
when cross cutting with the miter gauge. Guiding the
workpiece with rip fence and the miter guage at the same
time increases the likelihood of saw blade binding and
kickback.
• When ripping, always apply the workpiece feeding
force between the fence and the saw blade. Use a push
stick when the distance between the fence and the
saw blade is less than 6" (15 cm), and use a push block
when this distance is less than 2" (5 cm). “Work helping”
devices will keep your hand at a safe distance from the
saw blade.
• Use only the push stick provided by the manufacturer
or constructed in accordance with the instructions.
This push stick provides sufcient distance between the
hand and the saw blade.
• Never use a damaged or cut push stick. A damaged
push stick may break causing your hand to slip into the
saw blade.
• Do not perform any operation “freehand”. Always use
either the rip fence or the miter gauge to position
and guide the workpiece. “Freehand” means using your
hands to support or guide the workpiece, in lieu of a rip
fence or miter gauge. Freehand sawing leads to
misalignment, binding and kickback.
• Never reach around or over a rotating saw blade.
Reaching for a workpiece may lead to accidental contact
with the moving saw blade.
• Provide auxiliary workpiece support to the rear and/or
sides of the saw table for long and/or wide workpieces
to keep them level. A long and/or wide workpiece has a
tendency to pivot on the table’s edge causing loss
of control, saw blade binding and kickback.
• Feed workpiece at an even pace. Do not bend or twist
the workpiece. If jamming occurs, turn the tool off
immediately, unplug the tool then clear the jam. Jamming
SAFETY INSTRUCTIONS FOR TABLE
SAWS
Page 8
cause the risk of personal injury. Instructions for safe use
of accessories are included with the accessory.
• Double check all setups. Make sure blade is tight and
not making contact with saw or workpiece before connecting
to power supply.
• Do not allow familiarity (gained from frequent use of your
saw) to cause a careless mistake. Always remember that
a careless fraction of a second is sufcient to inict serious
injury. Use extra caution and keep your attention on your
operation when making repetitive cuts. Reduce the
monotony of operations by frequently taking breaks,
cleaning up saw dust, or checking the tool's condition.
SAFETY INSTRUCTIONS
3) Kickback causes and related warnings
Kickback is a sudden reaction of the workpiece due to a
pinched, jammed saw blade or misaligned line of cut in the
workpiece with respect to the saw blade or when a part of
the workpiece binds between the saw blade and the
rip fence or other xed object.
Most frequently during kickback, the workpiece is lifted from
the table by the rear portion of the saw blade and is propelled
towards the operator.
Kickback is the result of saw misuse and/or incorrect
operating procedures or conditions and can be avoided
by taking proper precautions as given below.
• Never stand directly in line with the saw blade. Always
position your body on the same side of the saw blade
as the fence. Kickback may propel the workpiece at high
velocity towards anyone standing in front and in line with
the saw blade.
• Never reach over or in back of the saw blade to pull
or support the workpiece. Accidental contact with the
saw blade may occur or kickback may drag your ngers
into the saw blade.
• Never hold and press the workpiece that is being cut
off against the rotating saw blade. Pressing the workpiece
being cut off against the saw blade will create a binding
condition and kickback.
• Align the fence to be parallel with the saw blade. A
misaligned fence will pinch the workpiece against the saw
blade and create kickback.
• Use a featherboard to guide the workpiece against the
table and fence when making non-through cuts such
as rabbeting, dadoing or resawing cuts. A featherboard
helps to control the workpiece in the event of a kickback.
• Use extra caution when making a cut into blind areas
of assembled workpieces. The protruding saw blade
may cut objects that can cause kickback.
• Support large panels to minimize the risk of saw blade
pinching and kickback. Large panels tend to sag under
their own weight. Support(s) must be placed under
all portions of the panel overhanging the table top.
4) Table saw operating procedure warnings
• Turn off the table saw and disconnect the battery pack
when removing the table insert, changing the saw
blade or making adjustments to the riving knife, anti-
kickback device or blade guard, and when the machine
is left unattended. Precautionary measures will avoid
accidents.
• Never leave the table saw running unattended. Turn it
off and don’t leave the tool until it comes to a complete
stop. An unattended running saw is an uncontrolled
hazard.
• Locate the table saw in a well-lit and level area where
you can maintain good footing and balance. It should
be installed in an area that provides enough room to
easily handle the size of your workpiece. Cramped,
dark areas, and uneven slippery oors invite accidents.
• Frequently clean and remove sawdust from under the
saw table and/or the dust collection device. Accumulated
sawdust is combustible and may self-ignite.
• The table saw must be secured. A table saw that is not
properly secured may move or tip over.
• Remove tools, wood scraps, etc., from the table before
the table saw is turned on. Distraction or a potential jam
can be dangerous.
• Always use saw blades with correct size and shape
(diamond versus round) of arbor holes. Saw blades
that do not match the mounting hardware of the saw will
run off-center causing loss of control.
• Never use damaged or incorrect saw blade mounting
means such as anges, saw blade washers, bolts or
nuts. These mounting means were specially designed for
your saw, for safe operation and optimum performance.
• Never stand on the table saw; do not use it as
a stepping stool. Serious injury could occur if the tool is
tipped or if the cutting tool is accidentally contacted.
• Make sure that the saw blade is installed to rotate in
the proper direction. Do not use grinding wheels, wire
Page 9
• Use extra caution when cutting a workpiece that is
twisted, knotted, warped or does not have a straight
edge to guide it with a miter gauge or along the fence.
A warped, knotted, or twisted workpiece is unstable and
causes misalignment of the kerf with the saw blade, binding
and kickback.
• Never cut more than one workpiece, stacked vertically
or horizontally. The saw blade could pick up one or more
pieces and cause kickback.
• Keep saw blades clean, sharp, and with sufcient set.
Never use warped saw blades or saw blades with
cracked or broken teeth. Sharp and properly set saw
blades minimize binding, stalling and kickback.
SAFETY INSTRUCTIONS
the saw blade by the workpiece can cause kickback or
stall the motor.
• Do not remove pieces of cut-off material while the saw
is running. The material may become trapped between
the fence or inside the saw blade guard and the saw blade
pulling your ngers into the saw blade. Turn the saw off
and wait until the saw blade stops before removing material.
• Use an auxiliary fence in contact with the table top
when ripping workpieces less than 1/16" (2 mm) thick.
A thin workpiece may wedge under the rip fence and
create a kickback.
Page 10
push blocks for non-through cuts.
• NEVER perform any operation “freehand” which means
using only your hands to support or guide the workpiece.
Always use either the rip fence or miter fence to position
and guide the work.
• Provide auxiliary workpiece support to the rear and/or
sides of the saw table for long and/or wide workpieces
to keep them level. A long and/or wide workpiece has a
tendency to pivot on the table’s edge causing loss
of control, saw blade binding and kickback.
• NEVER stand or have any part of your body in line with
the path of the saw blade.
• NEVER reach behind, over, or within 3" (7.6 cm) of the
blade or cutter with either hand for any reason.
• Move the rip fence out of the way when cross cutting.
• Do not use the miter gauge and rip fence during the
same operation.
• Never use the miter gauge to feed the workpiece when
ripping and do not use the rip fence as a length stop
when cross cutting with the miter gauge. Guiding the
workpiece with the rip fence and the miter gauge at the
same time increases the likelihood of saw blade binding
and kickback.
• NEVER attempt to free a stalled saw blade without rst
turning the saw OFF and disconnecting the saw from the
power source.
• Provide adequate support to the rear and sides of the
saw table for wide or long workpieces. A wide or long
workpiece has a tendency to pivot on the table’s edge
causing loss of control, saw blade binding and kickback.
• Avoid kickbacks (work thrown back toward you) by:
1. Keeping blade sharp.
2. Keeping rip fence parallel to the saw blade.
3. Keeping spreader, anti-kickback pawls, and blade guard
in place and operating.
4. Not releasing the work before it is pushed all the way
past the saw blade using a push stick.
5. Not ripping work that is twisted or warped or does not
have a straight edge to guide along the fence.
• Never cut metals, cement board, or masonry. These
materials need to be cut by other special tools. Cutting
them with this tool can result in damage to the saw and
personal injury.
• If the power supply cord is damaged, it must be replaced
only by the manufacturer or by an authorized service center
to avoid risk.
• Avoid awkward operations and hand positions where
a sudden slip could cause your hand to move into
the cutting tool.
• Make sure the work area has ample lighting to see the
work and that no obstructions will interfere with safe
SAFETY INSTRUCTIONS
brushes, or abrasive wheels on a table saw. Improper
saw blade installation or use of accessories not
recommended may cause serious injury.
• Firmly bolt the saw to a work bench or leg stand
at approximately hip height.
• Never operate the saw on the oor.
• Keep guards in place and in good working order. Blade
guard must be in place for all through cut operations.
Reinstall the blade guard immediately after nishing any
non-through cut operations which require removal of the
blade guard.
• Guard against kickback. Kickback occurs when the
blade stalls rapidly and workpiece is driven back towards
the operator. It can pull your hand into the blade resulting
in serious personal injury. Stay out of blade path and turn
switch off immediately if blade binds or stalls.
• Use rip fence. Always use a fence or straight edge guide
when ripping.
• Use an auxiliary fence in contact with the table top
when ripping workpieces less than 1/16" (2 mm) thick.
A thin workpiece may wedge under the rip fence and
create a kickback. Support large panels. To minimize risk
of blade pinching and kickback, always support large
panels.
• Remove all fences and auxiliary tables before transporting
saw. Failure to do so can result in an accident causing
possible serious personal injury.
• Don’t overreach. Keep proper footing and balance at all
times.
• Never place arms or hands in line with the path of the
cutting blade.
• Always use blade guard, riving knife, and anti-kickback
pawls on all through cut operations. Through cut
operations are those in which the blade cuts completely
through the workpiece as in ripping or cross cutting. Keep
the blade guard down, the anti-kickback pawls down, and
the riving knife in place. Make sure the blade guard, riving
knife, and anti-kickback pawls are reinstalled immediately
after nishing any non-through cut operations which
require their removal.
• ALWAYS lock the rip fence and secure bevel adjustment
rmly before cutting.
• ALWAYS secure work rmly against the rip fence or miter
gauge.
• ALWAYS use a push stick. A push stick is a device used
to push a workpiece through the blade instead of using
your hands. Size and shape can vary but the push stick
must always be narrower than the workpiece to prevent
the push stick from contacting the saw blade. When ripping
narrow stock, always use a push stick so your hand does
not come close to the saw blade. Use a featherboard and
Double insulation is a concept in safety in electric power
tools, which eliminates the need for the usual three-wire
grounded power cord. All exposed metal parts are isolated
from the internal metal motor components with protecting
insulation. Double insulated tools do not need to be grounded.
To reduce the risk of electrical shock, double-insulated
tools are equipped with a polarized plug (one blade is
wider than the other). This plug will t into a polarized
outlet only one way. If the plug does not t, contact a
qualied electrician to install a polarized outlet. Do not
change the plug in any way.
DOUBLE INSULATION
This tool has a precision-built electric motor. It should be
connected to a power supply that is 120 volts, 60 Hz.
A substantial voltage drop will cause a loss of power and
the motor will overheat. If the tool does not operate when
plugged into an outlet, double check the power supply.
Use a proper extension cord. Make sure extension cords
are in good condition. When using an extension cord, be
sure to use a cord that is heavy enough to carry the drawn
current needed by the saw. An undersized cord will cause
a drop in line voltage, resulting in loss of power and
overheating.
The table below shows the correct size to use, depending
on the cord length and nameplate amperage rating. If
in doubt, use the next heavier gauge. The smaller the gauge
number, the heavier the cord.
Be sure extension cords are properly wired and in good
condition. Always replace a damaged extension cord
or have it repaired by a qualied technician before using it.
Protect extension cords from sharp objects, excessive heat,
and damp or wet areas.
ELECTRICAL CONNECTION
GUIDELINES FOR EXTENSION CORDS
WARNING: Do not permit ngers to touch the
terminal or the plug when installing or removing the plug
from an outlet.
WARNING: The double insulated system is intended
to protect the user from shock resulting from a break in the
tool’s internal wiring. Observe all normal safety precautions
to avoid electrical shock.
WARNING: To ensure safety and reliability, all
repairs should be performed by a qualied service technician.
WARNING: Double insulation does not take the
place of normal safety precautions when operating this tool.
CAUTION: Servicing of a product with double
insulation requires extreme care and knowledge of the
system and should be performed only by a qualied service
technician. For service, we suggest you return the tool to
your nearest authorized service center for repair. Always
use original factory replacement parts when servicing. Do
not use power tools in wet or damp locations or expose
them to rain or snow.
FIG. 1
MINIMUM GAUGE (AWG)
EXTENSION CORDS (120V use only)
Amperage rating Total length
Not Recommended
Not more
than
25'
(7.5 m)
6 18
50'
(15 m)
16
100'
(30 m)
16
150'
(45 m)
14
More
than
0
10 18 16 14 126
12 16 16 14 1210
16 14 1212
SAFETY INSTRUCTIONS
operation before performing any work using the table saw.
• Always turn off saw before disconnecting it to avoid
accidental starting when reconnecting to power supply.
• Save these instructions. Refer to them frequently and
use to instruct other users. If you loan someone this tool,
loan them these instructions also.
Page 11
READ OPERATOR’S MANUAL
To reduce the risk of injury, user must read and
understand operator’s manual before using this product.
• USE SAFETY GOGGLES AND EAR PROTECTION
• ALWAYS WEAR EYE PROTECTION THAT CONFORMS
WITH UL REQUIREMENTS. FLYING DEBRIS can cause
permanent eye damage.
Page 12
WARNING: To avoid electrical hazards, re hazards,
or damage to the tool, use proper circuit protection.
WARNING: Do not use blades rated less than the
speed of this tool. Failure to heed this warning could result
in personal injury.
WARNING: Keep the extension cord clear of the
working area. Positon the cord so that it will not get caught
on lumber, tools, or other obstructions while you are working
with a power tool. Failure to do so can result in serious
personal injury.
WARNING: Check extension cords before each
use. If damaged replace immediately. Never use tool with
a damaged cord since touching the damaged area could
cause electrical shock resulting in serious injury.
Use a separate electrical circuit for power tools. This circuit
must not be less than #14 wire with a 15 Amp time delayed
fuse, and should be protected with a time delayed fuse.
Before connecting the tool to the power line, make sure the
switch is in the OFF position and the electric current is rated
the same as the current stamped on the motor’s nameplate.
Running at a lower voltage will damage the motor.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all
operating features and safety rules.
GLOSSARY OF TERMS
• Anti-kickback Pawls: Kickback is a hazard in which the
workpiece is thrown back toward the operator. The teeth
on the anti-kickback pawls point away from the workpiece.
If the workpiece should be pulled back toward the operator,
the teeth dig into the wood to help prevent or reduce the
possibility of kickback.
• Bevel Scale: The easy-to-read scale on the front of the
cabinet shows the exact blade angle.
• Blade: For maximum performance, it is recommended
that you use 10 in. blade provided with your saw. The
blade is raised and lowered with the height/bevel adjusting
handwheel. Bevel angles are locked with the bevel locking
lever.
of the blade.
• Height/Bevel Adjusting Handwheel: Located on the
front of the cabinet, this handwheel is used to lower and
raise the blade for adjustments or blade replacement. The
handwheel also makes the adjustment for bevel angles
easy.
• Fence Rails Locking Lever: The lever under worktable
surface on the right of the saw releases the fence rails or
locks it in place.
• Adjusting Knob: This knob is under the worktable surface
on the front of the saw. Turn it clockwise will slide the
fence rails to right. Turn it counter-clockwise will slide
fence rails to left.
• Outfeed Support: The outfeed support at the back of the
tool gives the operator additional support when cutting
long workpieces.
• Miter Gauge: The miter gauge aligns the wood for a cross
cut. The easy-to-read indicator shows the exact angle for
a miter cut.
• Miter Gauge Grooves: The miter gauge rides in these
grooves on either side of the blade.
• Front Rail: Provides support for the front fence rail and
rip fence.
• Rip Fence with a Narrow Fence: A sturdy metal fence
guides the workpiece and It can be xed on three positions
of the fence rail with rip fence locking knobs secure in
place. The narrow fence can support a workpiece that
extends beyond the working table.
• Scale: Located on the front rail, the easy-to-read scale
provides precise measurements for rip cuts.
• Riving Knife: A metal piece, slightly thinner than the saw
blade, which helps keep the kerf open and prevent
kickback.
• Overload Reset Switch: The saw is equipped with an
overload reset switch to prevent the saw from overload
damage. The saw will automatically shut off if the machine
experiences overloaded cutting or low voltage. Wait for
the motor to cool down for at least ve minutes. Press
the overload reset switch button to reset the overload
switch. After the motor has cooled down, press the green
“I”-button on the switch assembly to restart the saw.
• Arbor: The shaft on which a blade or cutting tool is
mounted.
• Working Table: Surface where the workpiece rests while
performing a cutting operation.
• Kerf: The material removed by the blade in a through-cut,
or the slot produced by the blade in a non-through or partial
cut.
• Push Stick: A push stick should be used for narrow ripping
operations when work piece 6 in. (152 mm) wide or less.
This aids in helping to keep the operator’s hands well away
• Blade Guard: Always keep the guard down over the blade
for through-sawing cuts.
• Bevel Locking Lever: This lever under the worktable
surface on the front of the cabinet, locks the angle setting
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
at any angle other than 90° to the blade.
• Non-Through Cut: Any cutting operation where the blade
does not extend completely through the thickness of the
workpiece.
• Through-sawing: Any cutting operation where the blade
extends completely through the thickness of the workpiece.
• Dado Cut: A non-through cut which produces a square-
sided notch or trough in the workpiece (requires a special
blade).
• Freehand: Performing a cut without the workpiece being
guided by a fence, miter gauge, or other aid. Never perform
any cut freehand with this saw.
from the blade.
• Kickback: A hazard that can occur when the blade binds
or stalls, throwing the workpiece back toward the operator.
• Ripping or Rip Cut: A cutting operation along the length
of the workpiece.
• Bevel Cut: A cutting operation made with the blade at any
angle other than 90° to the table surface.
• Compound Cut: A crosscut made with both a miter angle
and a bevel angle.
• Crosscut: A cutting or shaping operation made across
the grain or width of the workpiece.
• Miter Cut: A cutting operation made with the workpiece
Page 13
Page 14
OVERVIEW
Blade guard
Anti-kickback pawls
Rear fence rail
Riving knife
Table insert
Sub fence
Narrow fence
Blade wrench
Saw blade
Miter gauge
groove
Front fence rail
Rip fence
locking lever
Wheel
Handle
Bevel scale
Height adjusting
knob
Adjusting knob
Rip fence
locking knob
Release lever
Miter gauge
Scale
Switch assembly
Power cord
storage
Height/bevel
adjusting handwheel
Dust extraction
port
Power cord
Working table
Carrying handle
Overload reset
switch
Front rail
Push stick
Adjusting foot
Bevel locking
lever
Outfeed support
Rear rail
Fence rails
locking lever
Rip fence
Bevel scale
Motor
No Load Speed
Double Insulated
Blade
4500 RPM
120 V~ 60 Hz 15A
Yes
10"
Arbor size 5/8"
Bevel range 0°~45°
Working table size 26-1/2" x 22"
Cutting depth at 0° 3-1/2"
Cutting depth at 45° 2-1/4"
Max. cut left of blade with rip fence 20"
Max. cut right of blade with rip fence 32-1/2"
Max width of dado 13/16"
Weight 85 lbs (38.7 kg)
Page 15
SPECIFICATIONS
WARNING: The use of attachments or accessories not listed in this manual might be hazardous and could cause
serious personal injury.
1 1Table Saw Assembly
2 1Miter Gauge
3 1Blade Guard
4 1Anti-kickback Pawls
5 1Outfeed Support
6 1Rip Fence
7 1Sub Fence
8 1Push Stick
9 2Wheels
10 2Opened-ended lade Wrenches
11 2Handles
12 1Rear Leg Stand Assembly A
13 1Rear Leg Stand Assembly B
14 1Lower Leg Stand Assembly
15 1Limited Plate
The following items are included with your table saw:
CONTENTS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
PART DESCRIPTION QUANTITY
17
16
16
1
Spacers
Upper Leg Stand Assembly
18 2Leveling Feet
19 2Adjusting Feet
20 8
21 1
22 1
Hex Bolts M8 x 80
23 4
Hex Socket Flat Head Screws M8 x 50
24 1
Hex Socket Flat Head Screws M6 x 16
25 2
Hex Socket Flat Head Screws M8 x 12
26 1
Flat Washer 8
27 11
Flat Washer 10
28 2
Lock Hex Nut M6
29 1
Lock Hex Nut M8
30 1
4mm Hex Key
Lock Hex Nut M10
5mm Hex Key
PART DESCRIPTION QUANTITY
Page 16
15
16
17
18
19
20
21
22
23
24 25
26
27
28
29
30
Page 17
WARNING: Remove the protective polyfoam from between the saw’s housing and the motor.
CAUTION: This tool is heavy. To avoid back injury, lift with your legs, not your back, and get help when needed.
CAUTION: Many of the illustrations in this manual show only portions of the table saw. This is intentional so that
we can clearly show points being made in the illustrations. Never operate the saw without all guards securely in place and
in good operating condition.
(ITEMS NOT SUPPLIED)
#2 Phillips screwdriver
10mm, 13mm, 16mm wrench
Framing square
Triangle square
2.5mm Hex key
(ITEMS SUPPLIED)
Blade wrench (2 pc)
4mm Hex key (1 pc)
5mm Hex key (1 pc)
UNPACKING YOUR TABLE SAW
YOU WILL NEED
ASSEMBLY
This product requires assembly.
• Carefully lift saw from the carton by the carrying handles located at the each side of the working table of the saw, and
place it on a level work surface.
• Inspect the tool carefully to make sure that no breakage or damage occurred during shipping.
• Do not discard the packing material until you have carefully inspected and satisfactorily operated the tool.
• The saw is factory set for accurate cutting. After assembling it, check for accuracy. If shipping has inuenced the settings,
refer to specic procedures explained in this Operator’s Manual.
• If any parts are damaged or missing, please call 1-877-684-8912 for assistance.
WARNING: The use of attachments or accessories not listed in this manual might be hazardous and could cause
serious personal injury.
WARNING: Do not attempt to modify this tool or create accessories not recommended for use with this tool. Any
such alteration or modication is misuse, and could result in a hazardous condition leading to possible serious personal
injury.
WARNING: Do not connect to the power supply until assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
WARNING: To avoid injury, do not connect this table saw to a power source until it is completely assembled and
adjusted and you have read and understood the operator’s manual.
WARNING: Always make sure the table saw is securely mounted to the stand. Failure to heed this warning can
result in serious personal injury.
ASSEMBLY
Assemble the stand (Fig. 2a-2k)
• Place cardboard or an old blanket on oor in order
to protect the surface of the working table.
• Place the table saw assembly (1) upside down on the
protective material.
• Attach upper leg stand assembly (16) with table saw
assembly (1) with hex bolts M8 x 80 (20), spacers (17)
and lock hex nut M8 (27).
• Attach the limited plate (15) to lower leg stand assembly
(14) with a hex socket at head screw M8 x 50 (21), a at
washer 8 (24), a lock hex nut M8 (27), a hex socket at
head screw M6 x 16 (22) and a hex nut M6 (26).
• Attach the lower leg stand assembly (14) to upper leg
stand assembly (16) with with hex bolts M8 x 80 (20),
spacers (17) and lock hex nut M8 (27).
FIG. 2a
Page 18
FIG. 2b
FIG. 2c
17
24
26
20
17
17
14
17
20
15
27
1
16
27
21
22
27
16
14
Page 19
ASSEMBLY
• Attach the rear leg stand assembly A (12) to the rear leg
stand assembly B (13) with hex socket at head screws
M8 x 12 (23).
• Insert the leveling feet (18) into the holes on the rear leg
stand assembly B (13), and tighten with hex nuts M8 (27).
• Thread the adjusting feet (19) into the holes on the rear
leg stand assembly A (12).
• Attach rear leg stand assembly A & B (12, 13) to table saw
assembly (1) and lower leg stand assembly (14) with hex
bolts M8 x 80 (20), spacers (17) and lock hex nut M8 (27).
FIG. 2d
FIG. 2e
FIG. 2f
12
13
14
20
20
17
27
27
17
17
17
27
27
1
12
18
19
13
13
19
12
23
23
18
Page 20
9
28
ASSEMBLY
• Slide the wheel (9) and at washer 10 (25) onto axle of
lower leg stand assembly (14). Secure with lock hex nut
M10 (28). Repeat for remaining wheel.
• Attach handles (11) to table saw assembly (1). Secure with
hex socket at head screws M8 x 12 (23).
• Push the fence rails lock lever (32) toward the front of the
saw to lock it.
• Grasp the handles (11) and tilt saw back onto wheels (9)
until the stand is balanced on the wheels (9) and rear leg
stand assembly A & B (12,13).
FIG. 2g
FIG. 2h
FIG. 2i
25
23
32
9
13
13
23
14
11
11
9
12
9
11
11
1
WARNING: The table insert must be level with the
saw table. If the table insert is too high or too low, the work-
piece can catch on the uneven edges, resulting in binding
or kickback, which could result in serious personal injury.
WARNING: Be cautious of your hands to avoid being
cut by the saw blade which could result in serious personal
injury when removing or reinstalling the table insert.
Page 21
NOTE: With the stand open, resting on a level surface,
the stand should not move or rock from side to side. If
the stand rocks from side to side, the adjusting feet (19)
need adjusting until the stand is balanced.
33
33
35
34
37
37
ASSEMBLY
• Step on the release lever (33) and pull the handles (11)
toward you at the same time. Once the stand is released
from the release lever, ease the stand toward the oor by
pushing the handles toward the oor.
• With your hands on the handles (11), push the stand toward
the ground until the stand is in an open position.
To remove/replace/align the table insert
(Fig. 3a-3b)
• Lock the blade by turning bevel-locking lever (36) clockwise.
• Lower the blade all the way to down position by turning
the height adjusting knob (34) on the height/bevel adjusting
handwheel (35) counter-clockwise.
FIG. 2j
FIG. 2k
FIG. 3a
19
36
38
11
11
CAUTION: This saw is shipped with riving knife in
“MIDDLE” position. Riving knife must be placed in uppermost
position to attach anti-kickback pawls and blade guard for
all through cut operations.
Page 22
37
37
WARNING: Riving knife has three holes for three
positions. The uppermost position is for all through cuts.
The middle position is for non-through cuts (with blade
guard and anti-kickback pawls removed). The down position
is for dado cuts.
34
ASSEMBLY
• To remove the table insert: Turn the lock knob (37) counter-
clockwise to unlock the table insert (38). Place your index
nger in the hole, pulling the table insert (38) out toward
the front of the saw.
• To reinstall the table insert: Push the table insert (38) down,
turn the lock knob (37) clockwis e to lock the table insert
in place.
• When the table insert is not level with the saw table, using
a 2.5mm hex key (not supplied), adjust the four set screws
(39) pre-assembled to the table located on the four holes
of the table insert until the table insert is level with
the working table.
Riving knife installation and position
(Fig. 4a-4c)
FIG. 3b
FIG. 4a
FIG. 4b
40 40
40
36
39
41
41
41
40
To place riving knife in uppermost position (for through
cuts)
• Unplug the saw.
In uppermost position
for through cuts
• Remove the table insert.
• Set the saw blade angle to 0°.
• Raise the saw blade to the uppermost positon by turning
the height adjusting knob (34) clockwise.
• Lock the blade by turning bevel locking lever (36) clockwise.
• Unlock riving knife lock knob (40) by turning it counter-
clockwise.
• Grasp the riving knife (41) and pull toward right side of saw
to release it from spring-loaded locking pin.
NOTICE: The different positions corresponds to different
holes. (E.g. the uppermost position corresponds to bottom
hole.)
In middle position
for non-through cuts
In down position
for dado cuts
Page 23
Removing and installing the blade
(Fig. 5a-5b)
43
ASSEMBLY
• Position the riving knife in the uppermost position until
spring-loaded locking pin is re-engaged into the hole on
the riving kinfe.
• Lock the riving knife lock knob (40) by turning it clockwise.
• Reinstall the table insert.
FIG. 4c
FIG. 5a
41
40
10
42
45
44
10
46
To place riving knife in middle or down position, refer
to the above procedure.
CAUTION: To work properly, the saw blade teeth
must point down toward the front of the saw. Failure to heed
this instruction could cause damage to the saw blade, the
saw or the workpiece.
• Unplug the saw.
• Turn height adjusting knob clockwise to raise blade to
maximum height.
• Remove the table insert.
• Remove the blade wrenches from storage area.
WARNING: Only use a 10 in. diameter blade. To
avoid injury from an accidental start, make sure the switch
is in the OFF position and the plug is not connected to the
power source outlet.
WARNING: Be extremely careful when adjusting the
riving knife position. Do not contact blade.
WARNING: Be extremely careful when loosening
arbor nut. Keep rm grasp on both wrenches. Do not allow
hands to slip and contact blade.
Remove the blade (Fig. 5a):
• Using one opened-ended blade wrench (10), place the
at open end on the ats on the inner blade ange (42).
• Using the other opened-ended blade wrench (10), place
the at open end on the ats on the arbor nut (43). Holding
both wrenches rmly, pull the opened-ended blade wrench
on the arbor nut (43) forward to the front of the machine.
• Remove arbor nut (43), outer blade ange (44), saw blade
(45) from the arbor (46).
FIG. 6b
Page 24
44
43
46
47
51
49
50
ASSEMBLY
FIG. 5b
42
48
47
45
4
47
4
41
52
CAUTION: The large, at surface of the outer ange
faces the the saw blade and the saw blade (45) is rmly
seated against the inner ange (42).
WARNING: If the inner ange has been removed,
replace it before placing the saw blade on arbor. Failure to
do so could cause an accident.
Anti-kickback pawls installation
(Fig. 6a-6b)
FIG. 6a
Install the blade (Fig.5b):
• Place one new blade on arbor (46). Make sure saw blade
teeth point down at the front side of saw table. Place outer
ange (44) and arbor nut (43) on arbor and use blade
wrenches to tighten nut securely. DO NOT over tighten.
• Lower the saw blade to lowest position and replace table
insert.
CAUTION: Pull up on anti-kickback pawl assembly
to make sure it is secured to riving knife.
• Unplug the saw.
• Set the blade angle to 0°.
• Raise the saw blade to maximum height by turning height
adjusting knob clockwise.
• Lock the blade by turning bevel locking lever clockwise.
• Place the riving knife in the highest position.
• Pull out and hold knob (47) and push anti-kickback pawls
up, remove it from the anti-kickback pawls storage (48) at
the bottom left rear side of the saw. (Fig. 6a)
• Pull out and hold knob (47). Align slot in anti-kickback
pawls (4) over the slot (49) indicated of riving kinfe (41).
Place the spring pin (50) on the anti-kickback pawls (4)
into the slot (49) indicated on the riving knife (41).
• Press anti-kickback pawls (4) down until it snaps into
place and release knob (47) to insert the pin (51) into hole
(52) indicated on the riving knife (41).
WARNING: Replace dull or damaged anti-kickback
pawls. Dull or damaged anti-kickback pawls may not stop
a kickback, increasing the risk of serious personal injury.
Anti-kickback pawls should only be installed for through
cuts.
1
2
• Unplug the saw.
• Pull out the knob (53) on the blade guard and push the
blade guard forward to the front of the saw and up until
the pin comes out from the slot in the mounting bracket
(blade guard storage) (54) at bottom rear right side of the
saw, then remove the blade guard from the U-bracket
(blade guard storage) (54) at bottom middle right side of
the saw (Fig. 7a).
• Pull out the knob (53) on the blade guard and place the
pin (55) on the blade guard (3) into the slot (56) marked
on the riving knife (41) and meanwhile align the pin (57) on
the blade guard hole (58) marked on the riving knife (41).
• Pull blade guard fully back onto riving knife and release
the knob (53) to lock guard into position.
• If blade guard is not parallel to table when riving knife is
in uppermost position (through cuts), adjust the set screw
(59) as necessary. (Fig. 7c)
Blade guard installation (Fig. 7a-7c)
FIG. 7a
FIG. 7b
FIG. 7c
Page 25
ASSEMBLY
54
3
57
53
53
53 55
3
58
41
54
56
3
59
1
2
Page 26
Rip fence installation (Fig. 8a-8c)
FIG. 8a
FIG. 8b
FIG. 8c
ASSEMBLY
6
60
65
62
60
60
63
63
64
65
64
66
60
66
60
64
61
62
61
32
60
6
2
CAUTION: There are three position screws (63, 64,
65) on the each front and rear fence rails (61, 62) to attach
rip fence (6). Position screws (63, 64) use for rip fence on
the right of saw blade. Position screws (65) use for rip fence
on the left of saw blade. (Fig. 8b)
• Loosen the rip fence locking knobs (60) on the rip fence.
• Holding the rip fence (6) at an angle, align the position
screws (front and back) on fence rails with the fence slots
(66).
• Slide the slots (66) onto the position screws and rotate the
fence down until it rests on the rails.
• Secure the rip fence in place by turning the rip fence
locking knobs (60).
• Push down the fence rails locking lever (32) toward the
rear of the saw to unlock it.
• Loosen the rip fence locking knobs (60) on the rip fence.
• Sliding the rip fence (6) to right and swing it up at an
angle, then remove the fence from the front and rear fence
rails (61, 62).
CAUTION: Three position screws apply to three
different scales:
Position screws 63 (AA): Begin with 0 to 24 1/2 in. end.
(Rip fence located on the right of the blade)
Position screws 64 (BB): Begin with 8 in. to 32 1/2 in. end.
(Rip fence located on the right of the blade)
Position screws 65 (CC): Begin with 22 in. to 0 end.
(Rip fence located on the left of the blade)
CAUTION: The rip fence should be parallel to the
saw blade. If not, refer to the section “Aligning rip fence to
blade”.
AA
0
8
1
9
2
10
22
30
23
31
24
32
21
29
CC
BB
1
3
4
2
1
1
2
Page 27
• Loosen two stop screws (67) on the extension poles (68)
of the outfeed support (5).
• Loosen the locking knobs (69) under the working table
counter-clockwise.
• Insert the rear extension table poles (68) into the two holes
in the rear of the work table and into the extension tube
brackets that are located under the work table. Position
the outfeed support.
• Thread the locking knobs (69) into the the holes under the
work table and tighten them.
• Thread the two stop screws (67) into the holes located on
ends of the extension poles (68) and tighten them.
Outfeed support assembly installation
(Fig. 9a-9b)
The miter gauge (2) can be installed on each miter gauge
groove (70) on either side of blade.
Miter gauge installation (Fig. 10)
FIG. 9a
FIG. 9b
FIG. 10
ASSEMBLY
68
5
67
2
72
69
67
68
68
5
69
67
70
2
70
71
1
2
2
1
4
3
• Remove the miter gauge (2) from storage area (71) located
on inside of the right saw).
• Slide the guide rail (72) of the miter gauge (2) into one of
the guide grooves (70) of the saw table intended for this
purpose.
3
1
Page 28
• The table saw has two convenient storage areas (one on
either side of the saw) specically designed for the saw’s
accessories: rip fence (6), sub fence (7), miter gauge (2),
power cord (73), blade guard (3), push stick (8), blade
wrenches (10) and anti-kickback pawls (4).
• When not in use, store accessories securely.
To store the table saw accessories
(Fig. 11)
• To close the stand for moving, return fence rails and
outfeed support to inner position. Lock the front and rear
fence rails by pushing the fence rails locking lever up to
front of saw. Store the accessories securely.
• At the same time, step on release lever (33), grasp handles
(11) and lift them up and away from the body.
Closing, moving or opening stand
(Fig. 12a-12e)
Closing stand (Fig. 12a-12b)
FIG. 11
FIG. 12a
ASSEMBLY
7
8
6
73
10
2
3
4
11
33
2
2
1
4
3
Page 29
• Push the table saw until the release lever (33) clicks and
locks into place.
• Holding the handles (11) rmly, pull the handles toward
you until the stand and table saw are balanced on the
wheels (9).
• Push the table saw to the desired location, then either open
the stand for table saw operation or store the table saw in
a dry environment.
Moving stand (Fig. 12c)
• Step on the release lever (33) and pull the handles (11)
toward you at the same time.
• Once the stand is released from the release lever, ease
the stand toward the oor by pushing the handles toward
the oor.
Opening stand (Fig. 12d-12e)
FIG. 12b
FIG. 12c
FIG. 12d
ASSEMBLY
33
33
11
11
9
11
2
1
3
• With your hands on the handles (11), push the stand toward
the ground until the tile saw is in an open position with
the release lever (33) locking into place.
FIG. 12e
FIG. 13
Page 30
ASSEMBLY
The dust extraction port (74) is 2-1/2" (6.35 cm) in size
and is located on the back of the table saw. This port
can be connected directly to a dust collection system
by connecting the pick up end of the dust collection hose
to the dust port.
Connect to a dust collection system
(Fig. 13)
11
33
74
WARNING: ALWAYS connect to a dust collection
system. The table saw must be regularly checked for dust
build up and cleaned frequently, otherwise there is a risk of
heat build up and potential re.
CAUTION: This table saw is designed to cut wood and wood composition products only. Never cut metals, cement
board, or masonry.
Page 31
Applications
You can use this tool for the purposes listed below:
• Straight-line cutting operations, such as crosscutting, ripping, mitering, and compound cutting.
• Cabinet making and woodworking.
Operating components
• The upper portion of the blade projects up through the table and is surrounded by an insert called the table insert. The
height of the blade is set with a height adjusting handle on the height/bevel adjusting handwheel. Detailed instructions
are provided in this manual for the basic cut: cross cuts, miter cuts, bevel cuts, and compound cuts.
WARNING: To reduce the risk of serious personal injury, turn switch off and unplug the tool before making any
adjustments or removing/installing attachments or accessories. An accidental start-up can cause injury.
WARNING: To reduce the risk of serious personal injury, have push stick ready to use before starting cut.
WARNING: In the event of a power failure or when the tool is not in use, turn the switch OFF. This action will
prevent the tool from accidentally starting when power returns.
WARNING: ALWAYS make sure your workpiece is not in contact with the blade before operating the switch to
start the saw. Blade contact could result in kickback or thrown workpiece.
WARNING: To reduce the risk of accidental starting, ALWAYS make sure the switch is in the OFF position before
plugging saw into the power source.
WARNING: DO NOT use blades rated less than the speed of this tool. Failure to heed this warning could result in
serious personal injury.
WARNING: The operation of any power tool can result in foreign objects being thrown into the eyes, which can
result in severe eye damage. Always wear safety goggles or standard safety glasses with side shields complying with United
States ANSI Z87.1 before commencing power tool operation.
WARNING: Never operate the saw with the blade guard removed except for dado and other non-through cuts.
Reinstall the blade guard immediately after nishing any non-through cut operations which require removal of the blade
guard. Failure to heed this instruction could result in serious personal injury.
WARNING: Feed the workpiece into the saw blade or cutter only against the direction of rotation. Feeding the
workpiece in the same direction that the saw blade is rotating above the table may result in the workpiece, and your hand,
being pulled into the saw blade.
WARNING: Before using the saw, verify the following each and every time: 1) ALWAYS wear proper eye, hearing
and respiratory equipment. 2) Blade is securely tightened. 3) Bevel angle and fence rails locking lever is locked. 4) If ripping,
ensure that rip fence locking lever is locked and that the fence is parallel to the blade. 5) If crosscutting, miter gauge lock
knob is securely tightened. 6) The blade guard assembly is properly attached and the anti-kickback assembly is functioning.
WARNING: Although many of the illustration in this Operator's Manual are shown with the blade guard removed
for clarity, do not operate the saw without the blade guard unless specically instructed to do so.
OPERATION
Page 32
• The rip fence is used to position workpiece for lengthwise cuts and narrow fence is used for extension table for large
workpiece cuts.
• It’s very important to use the blade guard assembly for all through-cut sawing operations. The blade guard assembly
includes: riving knife, anti-kickback pawls, and blade guard.
Causes of kickback
Kickback can occur when the blade stalls or binds, causing the workpiece to be kicked back toward the operator with
great force and speed. If your hands are near the saw blade, they may be jerked loose from the workpiece and come into
contact with the blade. Obviously, kickback can cause serious injury, and it is well worth using precautions to avoid the
risks. Kickback can be caused by any action that pinches the blade in the wood, such as the following:
• Making a cut with incorrect blade depth.
• Sawing into knots or nails in the work piece.
• Twisting the wood while making a cut.
• Failing to support the workpiece.
• Forcing a cut.
• Cutting warped or wet lumber.
• Using the wrong blade for the type of cut.
• Not following correct operating procedures.
• Misusing the saw.
• Failing to use the anti-kickback pawls.
• Cutting with a dull, gummed-up, or improperly set blade.
Precautions of kickback
NOTE: Kickback can be avoided by taking following proper precautions:
• Never stand directly in line with the saw blade. Always position your body on the same side of the saw blade as the fence.
Kickback may propel the workpiece at high velocity towards anyone standing in front and in line with the saw blade.
• Never reach over or in back of the saw blade to pull or to support the workpiece. Accidental contact with the saw blade
may occur or kickback may drag your ngers into the saw blade.
• Never hold and press the workpiece that is being cut off against the rotating saw blade. Pressing the workpiece being
cut off against the saw blade will create a binding condition and kickback.
• Align the fence to be parallel with the saw blade. A misaligned fence will pinch the workpiece against the saw blade and
create kickback.
• Use a featherboard to guide the workpiece against the table and fence when making non-through cuts such as rabbets,
dado cuts. A featherboard helps to control the workpiece in the event of a kickback.
• Use extra caution when making a cut into blind areas of assembled workpieces. The protruding saw blade may cut
objects that can cause kickback.
• Support large panels to minimize the risk of saw blade pinching and kickback. Large panels tend to sag under their own
weight. Support(s) must be placed under all portions of the panel overhanging the table top.
• Use extra caution when cutting a workpiece that is twisted, knotted, warped or does not have a straight edge to guide
it with a miter gauge or along the fence. A warped, knotted, or twisted workpiece is unstable and causes misalignment
of the kerf with the saw blade, binding and kickback.
• Never cut more than one workpiece, stacked vertically or horizontally. The saw blade could pick up one or more pieces
and cause kickback.
• When restarting the saw with the saw blade in the workpiece, center the saw blade in the kerf so that the saw teeth are
not engaged in the material. If the saw blade binds, it may lift up the workpiece and cause kickback when the saw is
restarted.
• Keep saw blades clean, sharp, and with sufcient set. Never use warped saw blades or saw blades with cracked or broken
teeth. Sharp and properly set saw blades minimize binding, stalling and kickback.
OPERATION
Page 33
77
34
75
76
76
75
45
a
36
FIG. 14
FIG. 15
ASSEMBLY
WARNING: To reduce the risk of injury, be sure
switch is in the OFF position before plugging machine in.
Switch assembly and overload reset
switch (Fig. 14)
Changing blade depth (Fig. 15)
Changing blade angle (bevel) (Fig. 16)
• Press the green “I”-Button (75) to turn on the saw.
• Press the switch paddle (76) to turn off the saw.
• The saw will automatically shut down when in a power
failure, restart the machine by pressing the green "I" button
on the switch assembly .
• The saw is equipped with the overload reset switch (77)
to prevent the saw from overload damage. The saw will
automatically shut off if the machine is overloaded while
cutting or has low voltage. Wait for the motor to cool down
for at least ve minutes. And press the overload reset
switch button to resume the overload switch. After the
motor has cooled down, press the green “I”-button on the
switch assembly to restart saw.
Blade depth should be set so that outer points of blade (45)
are higher than workpiece by approximately 1/8 in. to 1/4 in.
and bottom of gullets (a) are below top surface of workpiece.
1
2
CAUTION: A 90° cut has a 0° bevel and a 45° cut
has a 45° bevel.
CAUTION: If bevel indicator is not at zero when
saw blade is at 0°, see the section “Adjusting bevel
indicator”.
• Loosen the bevel locking lever (36) counter-clockwise.
• Adjust bevel angle by rst pushing height/bevel adjusting
handwheel (35) all the way to the left.
• Holding height/bevel adjusting handwheel, slide bevel
indicator to the right to increase angle of blade (45)
(bringing it closer to 45° from the tabletop). Holding
height/bevel adjusting handwheel, slide bevel indicator to
the left to decrease the angle (bringing blade closer to
90° from the tabletop).
• Make sure blade (45) is at desired angle. Tighten bevel
adjusting lever (36) clockwise.
• Turn the bevel locking lever (36) clockwise to tighten
it securely.
• Raise blade (45) by turning height adjusting knob (34) on
the height/bevel adjusting handwheel clockwise. Lower
blade by turning height adjusting knob (34) counter-clockwise.
• Make sure blade (45) is at proper height.
3
1
2
35
45
36
FIG. 16
1
4
3
2
Page 34
FIG. 17a
FIG. 17b
OPERATION
32
79
32
78
78
79
32
CAUTION: When ripping, always lock the fence
rails locking lever.
WARNING: To reduce the risk of injury, always
make sure the rip fence is parallel to the blade before
beginning any operation.
Rip fence (FIG. 17a-17d)
Fence rails locking lever (Fig. 17a)
The fence rails locking lever locks the rip fence in
place preventing movement during cutting.
• To lock the fence rails locking lever (32), push it up toward
the front of the saw.
• To unlock the fence rails locking lever (32), push it down
toward the rear of the saw.
CAUTION: Retract the narrow fence whenever
working over the working table.
Narrow fence (Fig. 17b)
Your table saw is equipped with a narrow fence (78) to
support workpiece that extends beyond the working table.
• To use the narrow fence (78), loosen the locking lever (79)
counter-clockwise and rotate the narrow fence (78) to
position B as shown in Fig. 17b, then tighten the locking
lever.
• When not in use, loosen the locking lever (79) counter-
clockwise and retract the narrow fence (78) to position
A shown in Fig. 17b.
B
A
2
2
1
3
Page 35
When ripping a narrow workpiece, it is necessary to attach
the sub fence assembly to the rip fence to prevent hands
from getting too close to the blade.
• Install rip fence (6) on position screws (63) or position
scews (65). (Refer to Fig. 8b on Page 26)
• Rotate the narrow fence (78) to vertical position.
• Pull up the locking lever (80) on the sub fence and remove
the sub fence (7) from the storage position (81) located on
the middle of left saw.
• Align the slot of sub fence (7) with the narrow fence (78),
and push the sub fence (7) down.
• Lock it in place by pushing down locking lever (80).
• Sub fence (7) can be mounted on left or right side of the
rip fence (6).
• When not in use, store the sub fence in storage position.
Use sub fence (for rip cutting narrow
workpiece) (Fig. 17c)
FIG. 17c
FIG. 17d
The miter gauge (2) provides accuracy in angled cuts. For
very close tolerances, test cut is recommended.
Miter gauge (Fig. 18)
FIG. 18
OPERATION
80
83
84
80
80
82
2
7
78
32
82
85
6
6
85
7
81
2
3
4
1
There are two miter gauge grooves, one on either side of
blade. When making a 90° cross cut, use either miter gauge
groove. When making a beveled cross cut (blade tilted in
relation to working table), miter gauge should be located in
groove on right so that blade is tilted away from miter gauge
and hands.
Using miter gauge
• Loosen lock knob (85).
• With miter gauge in miter gauge groove, rotate gauge until
desired angle on scale is reached.
• Retighten lock knob (85).
The adjustment knob allows smaller adjustments when
setting the rip fence.
• Unlock the fence rails locking lever (32).
• Slide the rip fence (6) close to the desired position.
• Slowly turn the adjustment knob (82) to set the rip fence
to desired position. Turn the adjustment knob clockwise
to extend the front and rear fence rails (83, 84) to right.
Turn the adjustment knob counter-clockwise to extend
the front and rear fence rails (83, 84) to left.
• Lock the fence rails locking lever (32).
Adjustment knob (Fig. 17d)
2
2
1
3
2
2
3
4
1
3
The outfeed support (6) slides to give operator additional
support for cutting long workpieces.
• Unplug the saw.
• Loosen the locking knobs (69) under the working table
counter-clockwise.
• Stand behind saw. Grasp outfeed support (6) with both
hands and pull until it is fully extended.
• Tighten the locking knobs (69).
Outfeed support (Fig. 19)
FIG. 19
Page 36
OPERATION
6
69
69
2
1
3
WARNING: When using featherboard, it must be mounted in front of the blade and used only against the uncut
portion of the workpiece to avoid a kickback that could result in serious injury.
Cutting aids such as push stick, push blocks, featherboards and jigs should be used where appropriate to maximize
your ability to control your workpiece for a safe and precise cut. When making non-through cuts or ripping narrow
stock, always use a push stick, push block, featherboard and/or jig set-up so hands do not come within 6 inches of blade.
Cutting aids
A push stick is included with your saw. Additional push sticks and other cutting aids can be purchased separately at any
authorized dealer. Instructions for making cutting aids can be found on page 37-38.
Push stick can be purchased or made to securely hold down the workpiece against the table when making non-through
cuts or ripping narrow stock. The stick must be narrower than the workpiece, with a 90° notch in one end and shaped for
a grip on the other end.
Push sticks
Push blocks are blocks used to securely hold down the workpiece against the table. They include some gripping surface
or handle to hold the block. Any screws running through the underside of the block to fasten the handle should be recessed
in order to avoid contact with the workpiece.
Push blocks
A featherboard is a device used to help control the workpiece by guiding it securely against the table or rip
fence. Featherboards are especially useful when ripping small workpieces and for completing non-through cuts. The end
is angled with a series of narrow slots to give a friction hold on the workpiece. It is locked in place on the
table with a C-clamp.
Featherboards
Push Stick Construction
Included Standard Push Stick
20°-30°
90°
15.7 in. (400 mm)
Notch to
prevent hand
from slipping
Cut here to push 1/2 in. wood
Cut here to push 3/4 in. wood
Drill hole for
hanging
Page 37
OPERATION
WARNING: Do not attempt to create a jig unless you are thoroughly familiar with table saw safety. Do not use any
jig that could result in pinching of a kerf or jamming of the workpiece between the jig and the blade. Incorrect setups may
cause kickback which could result in serious injury.
Jigs
Jigs may be created with a variety of special set-ups to control particular workpiece shapes for particular cuts. Guidance
on how to make specialized jigs can be found in woodworking magazines and other reference sources.
How to make a push stick (Fig. 20a-20b)
• In order to operate your table saw safely, you must use a
push stick whenever the size or shape of the workpiece
would otherwise cause your hands to be within 6 in.
(152 mm) of the saw blade or other cutter. A push stick is
included with this saw.
• No special wood is needed to make additional push-sticks
as long as it’s sturdy and long enough. A length of 15.7 in.
(400 mm) is recommended with a notch that ts against
the edge of the workpiece to prevent slipping. It’s a good
idea to have several push sticks of the same length 15.7
in. (400 mm) with different size notches for different
workpiece thicknesses.
• The shape can vary to suit your own needs as long as it
performs its intended function of keeping your hands
away from the blade.
FIG. 20a
FIG. 20b
Sandpaper or
old mouse pad
material
Wooden
dowel
70°
3/4 in.
12 in.
2 1/2 in.
1/4 in.
1/8 in.
4 in.
6 in.
2 in.
Page 38
OPERATION
How to make a featherboard (Fig. 21)
• Select a solid piece of lumber approximate 3/4 in. thick,
2 1/2 in. wide and 12 in. long.
• Mark the center width on one end of stock. Miter width to
70° (See miter cut section for information on miter cuts).
• Set rip fence to allow approximately a 1/4 in. “nger” to
be cut in the stock.
• Feed stock only to mark previously a 1/4 in. “nger” to be
cut in the stock.
• Turn saw off and allow blade to completely stop rotating
before removing stock.
• Reset rip fence and cut spaced rips into workpiece
to allow approximately 1/4 in. ngers and 1/8 in. spaces
between ngers.
How to make a push block (Fig. 22)
• Select a piece of wood about 4 in. wide, 6 in. long and 1
to 2 in. thick (a cutoff from a 2 by 4 makes a good blank
for a push block).
• Drill a hole in the block and glue in a dowel to use
as a handle (you can angle the hole to provide a
more comfortable grip on the handle).
• To nish off the block, glue a piece of sandpaper or some
kind of rubber material (old mouse pads work well) to the
bottom of the block.
FIG. 21
FIG. 22
Through cuts
WARNING:
- Always make sure the blade guard and anti-kickback pawls are in place and working properly when making these cuts
to avoid possible injury.
- DO NOT use blades rated less than the speed of this tool. Failure to heed this warning could result in personal injury.
- To avoid kickback, make sure one side of the workpiece is securely against the rip fence during any rip cut, and hold
the workpiece rmly against the miter gauge during any miter cut.
- DO NOT attempt compound miter cuts, with blade beveled and miter fence angled, until you are thoroughly familiar with
the basic cuts and understand how to avoid kickback.
- DO NOT attempt to make any cuts not covered here unless you are thoroughly familiar with the proper procedures and
necessary accessories.
- Using rip fence as a cutoff gauge when cross cutting will result in kickback which can cause serious personal injury.
- Never make freehand cuts without miter gauge or rip fence. Unguided workpieces can result in serious injury.
OPERATION
Page 39
FIG. 24
Cutting tips
• The kerf (the cut made by the blade in the wood) will be wider than the blade to avoid overheating or binding. Make
allowance for the kerf when measuring wood.
• Make sure the kerf is made on the waste side of the measuring line.
• Cut the wood with the nish side up.
• Knock out loose knots before making cut.
• Always provide proper support for wood as it comes out of saw.
Making cuts
• Stand slightly to the side of blade path to reduce the chance of injury should kickback occur.
• Use miter gauge when making cross, miter, bevel and compound miter cuts. To secure angle, lock miter gauge in place
by twisting lock knob clockwise. ALWAYS tighten lock knob securely in place before use.
Types of cuts (Fig. 23)
There are six basic cuts: 1) the cross cut, 2) the rip cut, 3) the miter cut, 4) the bevel cross cut, 5) the bevel rip cut, and
6) the compound (bevel) miter cut.
WARNING: Never use the rip fence and miter gauge together. This may cause a kickback condition and injury the
operator.
Cross cut
Rip cut
Miter cut
Bevel cross cut Bevel rip cut Compound (bevel) miter cut
CAUTION: All other cuts are combinations of these basic six. Operating procedures for making each kind of cut
are given later in this section.
Making a cross cut
• Remove rip fence.
• Set blade to correct depth for workpiece.
• Set miter gauge to 0° and tighten lock knob.
• Make sure wood is clear of blade before turning on saw.
• To turn saw on, press the green “I”-button.
• Let blade build up to full speed before moving workpiece into blade.
• Hand closest to blade should be placed on miter gauge lock knob and hand farthest from blade should be placed on
workpiece. Feed workpiece into blade.
• When cut is complete, turn saw off. Wait for blade to come to a complete stop before removing workpiece.
OPERATION
Page 40
Making a miter cut
• Remove rip fence.
• Set blade to correct depth for workpiece.
• Set miter gauge to 0° and tighten lock knob.
• Make sure the wood is clear of the blade before turning on the saw.
• Turn the saw on.
• Let the blade build up to full speed before moving the workpiece into the blade.
• Hand closest to blade should be placed on miter gauge lock knob and hand farthest from blade should be placed on
workpiece. Feed workpiece into blade.
• When cut is complete, turn saw off. Wait for blade to come to a complete stop before removing workpiece.
Making a bevel cross cut
• Remove rip fence.
• Unlock bevel locking lever.
• Adjust bevel angle to desired setting.
• Lock bevel locking lever.
• Set blade to correct depth for workpiece.
• Set miter gauge to 0° and tighten lock knob.
• Make sure wood is clear of blade before turning on saw.
• Turn saw on.
• Let blade build up to full speed before moving workpiece into blade.
• Hand closest to blade should be placed on miter gauge lock knob and hand farthest from blade should be placed on
workpiece. Feed workpiece into blade.
• When cut is complete, turn saw off. Wait for blade to come to a complete stop before removing workpiece.
Making a rip cut
• Set blade to correct depth for workpiece.
• Unlock the fence rails locking lever and slide rip fence to desired distance from blade for cut.
• Lock the fence rails locking lever.
• Make sure wood is clear of blade before turning on saw.
• When ripping a long workpiece, slide the outfeed support to fully extend.
• To turn saw on, press the green “I”-button.
• Position workpiece at on table with edge ush against rip fence. Let blade build up to full speed before
feeding workpiece into blade.
• Once blade has made contact with workpiece, use hand closest to rip fence for guidance. Make sure edge of workpiece
remains in solid contact with both rip fence and surface of table. If ripping a narrow piece, use push stick and/or push
blocks to move piece through cut and past blade.
• When cut is complete, turn saw off. Wait for blade to come to a complete stop before removing workpiece.
Making a bevel rip cut
• Remove miter gauge.
• Unlock bevel locking lever.
• Adjust bevel angle to desired setting.
• Lock bevel locking lever.
• Set blade to correct depth for workpiece.
• Unlock the fence rails locking lever and slide rip fence to desired distance from blade for cut.
• Lock the fence rails locking lever.
OPERATION
Page 41
Making a compound (bevel) miter cut
• Remove rip fence.
• Unlock bevel locking lever.
• Adjust bevel angle to desired setting.
• Lock bevel locking lever.
• Set blade to correct depth for workpiece.
• Set miter gauge to desired angle and tighten lock knob.
• Make sure wood is clear of blade before turning on saw.
• Turn the saw on.
• Let the blade build up to full speed before moving the workpiece into the blade.
• Hand closest to blade should be placed on miter gauge lock knob and hand farthest from blade should be placed on
workpiece. Feed workpiece into blade.
• When cut is complete, turn saw off. Wait for blade to come to a complete stop before removing workpiece.
Making a large panel cut
• Slide the outfeed support to fully extend, and place a support the same height as top of working table behind saw for
cut and add supports to sides as needed.
• Depending on shape of panel, use rip fence or miter gauge. If panel is too large to use either rip fence or miter gauge, it
is too large for this saw.
• Make sure wood does not touch blade before saw is turned on.
• Turn the saw on.
• Position workpiece at on table with edge ush against rip fence. Let blade build up to full speed before
feeding workpiece into blade.
• Use push stick to move piece through cut and past blade.
• When cut is complete, turn saw off. Wait for blade to come to a complete stop before removing workpiece.
• Make sure wood is clear of blade before turning on saw.
• When ripping a long workpiece, slide the outfeed support to fully extend.
• Turn saw on.
• Position workpiece at on table with edge ush against rip fence.
• Let blade build up to full speed before moving workpiece into blade.
• Once blade has made contact with workpiece, use hand closest to rip fence for guidance. Make sure edge of workpiece
remains in solid contact with both rip fence and surface of table. If ripping a narrow piece, use push stick to move piece
through cut and past blade.
• When cut is complete, turn saw off. Wait for blade to come to a complete stop before removing workpiece.
Dados and other non-through cuts
The use of a non-through cut is essential to cutting grooves, rabbets and dados. Non-through cuts can be made using a
standard blade having a diameter of 10 inches, or a dado blade up to 13/16 inches wide with a diameter of 8 inches. Non-
through cuts are the only type of cuts that should be made without the blade guard assembly installed. Make sure the
blade guard assembly is reinstalled upon completion of this type of cut.
OPERATION
Page 42
• Unplug saw.
• Unlock bevel locking lever.
• Adjust bevel angle to 0°.
• Lock bevel locking lever.
• Remove blade guard and anti-kickback pawls.
• Place riving knife in “middle” position.
• Set blade to correct depth for workpiece.
• Depending on shape and size of wood, use either rip fence or miter gauge.
• Plug saw into power source and turn saw on.
• Let blade build up to full speed before moving workpiece into blade.
• Always use push blocks, push sticks, and/or featherboard when making non-through cuts to reduce the risk of serious
injury.
• When cut is made, turn saw off. Wait for blade to come to a complete stop before removing workpiece.
• Unplug saw.
• Unlock bevel locking lever (36) counter-clockwise.
• Adjust bevel angle to 0° by pushing height/bevel adjusting
handwheel (35) all the way to the left.
• Lock bevel locking lever (36) clockwise.
• Remove blade guard (3), anti-kickback pawls (4) and table
Making a non-through cut
WARNING:
- To reduce the risk of serious injury when making non-through cuts, follow all applicable warnings and instructions listed
below in addition to those listed above for the relevant through cut.
- When making a non-through cut, blade is covered by workpiece during most of cut. Be alert to exposed blade at start
and nish of every cut to avoid the risk of personal injury.
- Never feed wood with hands when making any non-through cuts such as rabbets. To avoid personal injury, always use
push blocks, push sticks, and/or featherboards.
- Read the appropriate section which describes the type of cut in addition to this section on non-through cuts. For example,
if your non-through cut is a straight cross cut, read and understand the section on straight cross cuts before proceeding.
- Once non-through cuts are completed, unplug saw and reinstall riving knife in uppermost position. Install anti-kickback
pawls and blade guard.
WARNING:
- Once all dado cuts are completed, unplug saw and reinstall
riving knife in uppermost position. Install anti-kickback
pawls and blade guard.
- Always use push blocks, push sticks, and/or featherboards
when making dado cuts to avoid the risk of serious injury.
- This saw cannot be used to make a bevel dado cut.
- Always place riving knife in “DOWN” position.
FIG. 24a
Make a dado cut (Fig. 24a-24c)
The dado table insert is required for this procedure. The
dado table insert (242-4533 ) and dado blades are sold
separately. This saw is designed for use with a diameter of
8 inches stack dado up to 13/16 inch wide. Make sure the
blade guard is reinstalled upon completion of this type of cut.
3
33
35
2
4
1
36
4
3
38
FIG. 24b
FIG. 24c
OPERATION
Page 43
insert (38). (Fig. 24a)
• Remove the arbor nut (43), outer ange (44) and saw blade
(45) from arbor (46). (Fig. 24b)
• Mount the dado blade, using the appropriate blade (86)
and chippers (87) for the desired width of cut.
• Reinstall the outer ange and the arbor nut.
NOTE: Make sure the arbor nut is fully engaged and the
arbor extends past a securely tightened arbor nut.
• Place riving knife (41) in “DOWN” position. (Fig. 24c)
• Install the dado table insert (88) (Fig. 24c), rotate the blade
by hand to make sure it turns freely, and then lower the
blade.
• Position the workpiece at on the table, with the edge ush
against the rip fence or miter gauge.
• Plug saw into power source and turn saw on.
• Let blade build up to full speed before moving workpiece
into blade.
• Always use push blocks, push sticks, and/or featherboard
when making dado cuts to reduce the risk of serious injury.
• When cut is made, turn saw off. Wait for blade to come to
a complete stop before removing workpiece.
WARNING:
Always put all spacers in proper location when changing
back to saw blade. Failure to do so may result in possible
injury and damage to the tool.
NOTE: When cutting with a dado blade, use a dust collection
system to prevent heavy dust loads from piling up under the
saw and on the fan intake on the motor. Clean these areas
often.
44
86
86 41
43
46
45
88
87
41
86
FIG. 25
Page 44
63
89
32
45
6
WARNING: Before performing any adjustment, make sure tool is unplugged from power supply and switch is in
off position. Failure to do so could result in serious personal injury.
The table saw has been adjusted at the factory for making very accurate cuts. However, some components might have
been jarred out of alignment during shipping. Also, over a period of time, readjustment will probably become necessary
due to wear.
Carefully check alignment with a framing square before beginning adjustments to conrm whether they are necessary. Use
test cuts after completing adjustments to avoid damaging workpiece.
CAUTION: Unplug saw. Remove blade guard and
anti-kickback pawls. Raise the blade by turning height
adjusting knob.
CAUTION: The adjustment must be correct. If it is
not, kickback could result in a serious injury and inability to
make accurate cuts.
WARNING: Rip fence must be aligned to blade so
that wood does not bind, resulting in kickback. Failure to
do so could result in serious personal injury.
Rip fence and blade alignment is set at factory and in most cases will not need to be adjusted. However, the
alignment should always be checked after installing blade or before making cuts, and can be adjusted if necessary.
If rip fence is out of alignment with blade, adjustment is needed.
Aligning rip fence to blade (Fig. 25)
DO NOT loosen any position screws for this adjustment
until alignment has been checked with a square to be sure
adjustment is necessary. Once screws are loosened, items
must be reset.
To check/adjust:
• Place the framing square (89) beside the blade (45), and
Unlock the fence rails locking lever (32) to move the rip
fence (6) up to the square.
• Lock the fence rails locking lever (32) and note the
measurement on the rip scale.
• Move the fence back and rotate the framing square (89)
180° to check the other side.
• If the two measurements are not the same, loosen the
position screws (63) on the extension poles and then align
it.
• Retighten the position screws with 4 mm hex key
(supplied). Recheck alignment after position screws are
retightened.
• Replace the blade guard and anti-kickback pawls.
• Make two or three test cuts using scrap wood. If the cuts
are not true, repeat the process.
ADJUSTMENTS
Page 45
FIG. 26a
FIG. 26b
FIG. 26c
89
90
45
45
92
91
CAUTION: For easy of use, bevel adjust should
stop at 45° and 90°.
This saw has positive stops that will quickly position the
saw blade at 90° (0°) or 45° to the table.
Angle settings of saw have been set at the factory
and, unless damaged in shipping, should not require setting
during assembly. After extensive use, they may need to be
checked.
To check 90° (0°) bevel:
• Turn power off and unplug the saw.
• Raise the blade to the maximum height by turning the
height adjusting knob clockwise.
• Remove the anti-kickback pawls and blade guard.
• Using a framing square (89), set the blade (45) to exactly
90°.
• If the blade stops bevelling before it gets to 90°, loosen
the 90° stop set screw (90) (located at the left of the bevel
track on the front), and then adjust it to 90°.
• With the blade set at 90°, slowly turn the 90° stop
set screw (90) until you feel resistance. Bevel the blade
away from 90° a little, and then back to the stop.
• Re-measure the angle and repeat the stop adjustment as
necessary until the blade stops at 90°.
Bevel adjustment (Fig. 26a-26c)
ADJUSTMENTS
To check 45° bevel:
• Turn power off and unplug the saw.
• Raise the blade to the maximum height by turning the
height adjusting knob clockwise.
• Remove the anti-kickback pawls and blade guard.
• Using a triangle square (91), set the blade (45) to exactly
45°.
• If the blade stops bevelling before it gets to 45°, loosen
the 45° stop set screw (92) (located at the right of the
bevel track on the front), and then adjust it to 45°.
• With the blade set at 45°, slowly turn the 45° stop
set screw (92) until you feel resistance. Bevel the blade
away from 45° a little, and then back to the stop.
• Re-measure the angle and repeat the stop adjustment as
necessary until the blade stops at 45°.
Page 46
63
95
97
FIG. 27
FIG. 28
6
64
99
94
93
98
96
32
ADJUSTMENTS
• Unlock the fence rails lock lever (32).
• Set the blade at 0° bevel and move the rip fence (6) in until
it touches the blade.
• Lock the fence rails lock lever (32).
• Loosen the rip fence scale indicator screws (93, 94) and
set the red line (95) on the rip fence scale indicator (96) to
read zero.
• Retighten the rip fence indicator screws (93, 94). The top
rip scale reads correctly only when the fence is mounted
on the right side of the blade and is in position screw (63)
(for 0 to 24.5 in. ripping) [not the 32.5 in. position]. The
bottom scale reads correctly only when the fence is mounted
on the right side of the blade and in position screw (64)
(for 8 in. to 32.5 in. ripping).
Adjusting rip fence scale indicator
(Fig. 27)
Adjust the red line on the bevel indicator if it is not aligned
with zero when the blade is perpendicular to the table.
• With blade perpendicular to table, loosen screw (97).
• Set the bevel indicator (98) to align with 0° on bevel scale
(99).
• Retighten screw (97).
Adjusting bevel indicator (Fig. 28)
Page 47
WARNING: When servicing, use only identical replacement parts. Use of any other part may create a hazard or
cause product damage.
WARNING: Always wear safety goggles or safety glasses with side shields during power tool operation or when
blowing dust. If operation is dusty, also wear a dust mask.
WARNING: Before performing any maintenance, make sure the tool is unplugged from the power supply and
switch is in the off position.
WARNING: DO NOT at any time let brake uids, gasoline, petroleum-based products, penetrating oils, etc., come
in contact with plastics parts. Chemicals can damage, weaken, or destroy plastic.
MAINTENANCE
GENERAL MAINTENANCE
LUBRICATION
• Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types
of commercial solvents and may be damaged by their use. Use clean cloths to remove dirt, dust, oil, grease, etc.
• Periodically check all clamps, nuts, bolts, and screws for tightness and condition. Make sure the table insert is in good
condition and level with the working table.
• Check the blade guard assembly after performing maintenance to make sure it is installed correctly and functioning
properly.
• Clean plastic part only with a soft damp cloth. DO NOT use any aerosol or petroleum solvents.
• All of the bearings in this tool are lubricated with a sufcient amount of high grade lubricant for the life of the unit under
normal operating conditions. Therefore, no further lubrication is required.
Page 48
Saw will not start. • Allow motor to cool and reset by pushing
reset switch.
• Plug in saw.
• Replace fuse or reset circuit breaker.
• Have the cord replaced by a qualied
electrician.
• Overload tripped.
• Saw is not plugged in.
• Fuse blown or circuit breaker tripped.
• Cord is damaged.
Does not make 45° and 90°
rip cuts.
• See section “Bevel adjusment”.
• See section “Adjusting bevel indicator”.
• See section “Aligning rip fence to blade”.
• Positive stop not adjusted correctly.
• Bevel angle pointer not set accurately.
• Rip fence not properly aligned.
PROBLEM PROBLEM CAUSE CORRECTIVE ACTION
TROUBLESHOOTING
Material pinches blade when
ripping.
• See section “Aligning rip fence to blade”.
• Select another piece of wood.
• Rip fence not aligned with blade.
• Warped wood, edge against fence is not
straight.
Material binds on riving knife. • Align the riving knife with saw blade.• Riving knife not aligned correctly with
blade.
Saw makes unsatisfactory
cuts.
• Replace blade.
• Turn the blade around.
• Remove the blade and clean with
turpentine and coarse steel wool.
• Change the blade.
• Clean table with turpentine and steel
wool.
• Dull blade.
• Blade mounted backwards.
• Gum or pitch on blade.
• Incorrect blade for work being done.
• Gum or pitch on blade causing erratic
feed.
Material kicked back from
blade.
• Align the riving knife with saw blade.
• Install and use rip fence.
• Install and use riving knife (with guard).
• Replace blade.
• Push material all the way past saw blade
before releasing work.
• Tighten lock knob.
• Riving knife not aligned correctly with
blade.
• Feeding stock without rip fence.
• Riving knife not in place.
• Dull blade.
• The operator letting go of material before
it is past saw blade.
• Miter angle lock knob is not tightened.
Blade does not raise or bevel
freely.
• Brush or blow out loose dust and dirt.• Sawdust and dirt in elevation/beveling
mechanisms.
Machine vibrates excessively. • Tighten all mounting hardware.
• Reposition on at, level surface.
• Secure the workbench to oor.
• Replace blade.
• The saw is not mounted securely to the
stand.
• Stand is on uneven oor.
• Workbench is moving.
• Damaged saw blade.
Blade does not come up to
speed or reset trips too easily.
• Replace with adequate size cord.
• Contact your electric company.
• Extension cord too light or too long.
• Low house voltage.
For questions / comments, technical assistance or repair parts - Please call toll free at: 1-877-684-8912 (Monday - Friday
8am - 6pm EST.)
REPLACEMENT PARTS LIST
Page 49
A
B
C
D
E
F
G
H
I
J
K
L
A 24000330001
24000330002
24000330003
24000330007
24000330009
Miter Gauge
Blade Guard
Table Insert
PART DESCRIPTION PART#
G
B
IC
24000330004Push StickD
24000330005Blade WrenchE
24000330006Bevel Locking LeverF
24000330008H
Rip Fence Locking Knob
Rip Fence Locking Lever
Leveling Foot
24000330010
J Adjusting Foot
24000330011
K Blade Locking Assembly
242-4533L Dado Table Insert
PART DESCRIPTION PART#
FIG. 30
Distributed by: Menard, Inc., Eau Claire, WI 54703
SAVE YOUR RECEIPTS
THIS WARRANTY IS VOID WITHOUT THEM
10" JOBSITE TABLE SAW
WARRANTY
90-DAY MONEY BACK GUARANTEE:
This MASTERFORCE
®
brand power tool carries our 90-DAY Money Back Guarantee.
If you are not completely satisfied with your MASTERFORCE
®
brand power tool
for any reason within ninety (90) days from the date of purchase, return the tool with
your original receipt to any MENARDS
®
retail store, and we will provide you a refund –
no questions asked.
3-YEAR LIMITED WARRANTY:
This MASTERFORCE
®
brand power tool carries our famous No Hassle 3-Year Limited
Warranty to the original purchaser. If, during normal use, this MASTERFORCE
®
power
tool breaks or fails due to a defect in material or workmanship within three (3) years
from the date of original purchase, simply bring this tool with the original sales receipt
back to your nearest MENARDS
®
retail store. At its discretion, MASTERFORCE
®
agrees to have the tool or any defective part(s) repaired or replaced with the same or
similar MASTERFORCE
®
product or part free of charge, within the stated warranty
period, when returned by the original purchaser with original sales receipt. Not
withstanding the foregoing, this limited warranty does not cover any damage that
has resulted from abuse or misuse of the Merchandise. This warranty: (1) excludes
expendable parts including but not limited to blades, brushes, belts, bits, light bulbs,
and/or batteries; (2) shall be void if
this tool is used for commercial and/or rental
purposes; and (3) does not cover any losses, injuries to persons/property or costs. This
warranty does give you specific legal rights and you may have other rights, which vary
from state to state. Be careful, tools are dangerous if improperly used or maintained.
Seller’s employees are not qualified to advise you on the use of this Merchandise.
Any oral representation(s) made will not be binding on seller or its employees. The
rights under this limited warranty are to the original purchaser of the Merchandise
and may not
be transferred to any subsequent owner. This limited warranty is in lieu
of all warranties, expressed or implied including warranties or merchantability and
fitness for a particular purpose. Seller shall not be liable for any special, incidental, or
consequential damages. The sole exclusive remedy against the seller will be for the
replacement of any defects as provided herein, as long as the seller is willing or able
to replace this product or is willing to refund the purchase price as provided above.
For insurance purposes, seller is not allowed to demonstrate an
y of these power tools
for you.
For questions / comments, technical assistance or repair parts – Please Call Toll
Free at: 1-877-684-8912. (M-F 8am – 6pm)
