13 ConnectingtoaPC

13 - D-SUBconnection

13 - DVI-Dconnection

14 - DisplayPortconnection

15 - Peripheraldeviceconnection

16 CUSTOMIZING SETTINGS

17 CustomizingSettings

20 TROUBLESHOOTING

22 SPECIFICATIONS

22 24MB34PY

23 24MB34D

24 PresetModes(Resolution)

24 D-SUB/DVITiming

24 DPTiming

25 D-SUB/DVITiming

25 Indicator

ASSEMBLING AND PREPARING

ENGLISH

ASSEMBLING AND PREPARING

Unpacking

Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocaldealerwhereyou

purchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproductandaccessories.



Donotuseanyunapprovedaccessoriestoensurethesafetyandproductlifespan.



Anydamagesorinjuriesbyusingunapprovedaccessoriesarenotcoveredbythewarranty.



Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.



Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgradeof

productfunctions.

CAUTION

NOTE

Stand Base Stand BodyStand Base

CD(Owner's Manual) /

Card

D-SUB Cable

(Thiscableisnot

includedinall

countries.)

(Dependingonthecountry) (Dependingonthecountry)

Power Cord

DVI-D Cable

(Thiscableisnot

includedinall

countries.)

DisplayPort Cable

24MB34PY

(Thiscableisnot

includedinall

countries.)

One Screw Cable Holder USB CableAudio Cable

24MB34D 24MB34D24MB34PY

24MB34PY 24MB34PY 24MB34PY 24MB34PY

ASSEMBLING AND PREPARING

ENGLISH

Parts and buttons

(PowerButton)

Power Indicator



LEDOn:Powerison



LEDOff:Powerisoff

FrontSideButtons

ASSEMBLING AND PREPARING

ENGLISH

Stand Base

Setting up the Monitor set

Attaching the Stand Base

24MB34PY

 PlacetheMonitorsetwiththescreensidedownon

aflatandcushionedsurface.

Stand Base

Stand Body

Stand Base

Stand Body



Toprotectthescreenfromscratches,coverthe

surfacewithasoftcloth.

 Usingacoin,turnthescrewclockwisetosecurethe

stand base.

 Checktheposition (at the front and rear) ofthe

standbody, then mountthestand baseonthe

stand body asshowninthefigure.

CAUTION

Stand Base



Illustrationsinthisdocumentrepresenttypical

procedures,sotheymaylookdifferentfromthe

actualproduct.



Donotcarrythemonitorupsidedownbyjust

holdingthestandbase.Thismaycausethemoni-

tortofalloffthestandandcouldresultinper-

sonalinjury.



Whenliftingormovingthemonitor,donottouch

themonitorscreen.Theforceappliedtothemoni-

torscreenmaycausedamagetoit.



Donotapplyforeignsubstances(oils,lubricants,

etc.)tothescrewpartswhenassemblingthe

product.(Doingsomaydamagetheproduct.)



Applyingexcessiveforcewhentighteningscrews

maycausedamagetothemonitor.Damage

causedinthiswaywillnotbecoveredbythe

productwarranty.

Detaching the stand base

 Placethemonitor'sscreenfacedown.

Toprotectthescreenfromscratches,coverthe

surfacewithasoftcloth.

 Usingacoin,turnthescrewinthestandbasecoun-

terclockwise.Detachthestand base fromthestand

body.

CAUTION

ASSEMBLING AND PREPARING

ENGLISH

AttachtheStand Bodytothemonitorset.

AttachtheStand Base.

Tiedownthebaselocktoperpendicularity

direction.

Setting up the Monitor set

Attaching the Stand Base

24MB34D

 PlacetheMonitorsetwiththescreensidedownon

aflatandcushionedsurface.

Layafoammatorsoftprotectiveclothonthe

surfacetoprotectthescreenfromdamage.

CAUTION



Stand Base

Stand Body

Detaching the Stand Base

 PlacetheMonitorsetwiththescreensidedownon

aflatandcushionedsurface.

Stand Base

Stand Body

PushingthePUSHbutton,TaketheStand Body

fromthemonitorset.

Changeyourlockontheproductasitfollows

andturnitinthearrowdirection.

PullouttheStand Base.





Ifyoucan'treleasethestandbaseeventhe

lockingknobisatareleaseposition,Pleasepush

theindicatedknobdownandretryit.

CAUTION



Thisillustrationdepictsthegeneralmodelof

connection.Yourmonitormaydifferfromthe

itemsshowninthepicture.



Donotcarrytheproductupsidedownholding

onlythestandbase.Theproductmayfallandget

damagedorinjureyourfoot.

CAUTION

ASSEMBLING AND PREPARING

ENGLISH

Mounting on a table

 Liftthemonitorandplaceitonthetableinan

uprightposition.

Installatleast100 mm awayfromthewalltoen-

suresufficientventilation.

100 mm

Detaching the stand body

 Placethemonitor'sscreenfacedown.Toprotectthe

screenfromscratches,coverthesurfacewithasoft

cloth.

 Usingascrewdriver,removethefourscrewsand

detachthestandfromthemonitor.

Using the cable holder

FixtheKnob(Cableholder)tothe

Hole(Hingebody).

UseonescrewtofixtheCableHolderand

monitorset.

ClosetheCableholder.

NOTE



Theholesareusedforwallmountbracket.



Variesdependinguponyourcountryormodel.

24MB34PY

24MB34D

ASSEMBLING AND PREPARING

ENGLISH

 Pressthe (Power)buttononthefrontofthe

monitortoturnonthemonitor.



Unplugthepowercordpriortomovingorinstall-

ingthemonitor.Thereisriskofelectricshock.

CAUTION

Adjusting the angle

 Placethemonitormountedonthestandbaseinan

uprightposition.

 Adjusttheangleofthescreen.Theangleofthe

screencanbeadjustedupto5°forwardsand20°

backwardsforacomfortableviewingexperience.

Front SideRear Side

 Adjusttheangleofthescreen.Theangleofthe

screencanbeadjustedupto5°forwardsand20°

backwardsforacomfortableviewingexperience.

 ConnectthePowercordtothemonitor,thenplug

thepowercordintothewalloutlet.

Front SideRear Side

24MB34PY

24MB34D

ASSEMBLING AND PREPARING

ENGLISH



Toavoidinjurytothefingerswhenadjustingthe

screen,donotholdthelowerpartofthemoni-

tor'sframeasillustratedbelow.



Becarefulnottotouchorpressthescreenarea

whenadjustingtheangleofthemonitor.

WARNING

24MB34PY

24MB34D

ASSEMBLING AND PREPARING

ENGLISH

Using the Kensington locking device

TheconnectorfortheKensingtonlockislocatedonthe

rearofthemonitor.

Formoreinformationoninstallationandusage,referto

theKensingtonlockusermanualorvisitthewebsiteat

http://www.kensington.com.

ConnectthemonitortothetablewiththeKensington

lockcable.



UsingtheKensingtonlockisoptional.Theacces-

soriescanbepurchasedatyourlocalelectronics

store.

NOTE



Oncethepinisremoved,itisnotnecessarytore-

insertittoadjusttheheight.

 Theheightcanbeadjustedupto120 mm.



Donotputyourfingerbetween

thescreenandthebase(chas-

sis)whenadjustingthescreen's

height.

CAUTION

WARNING

120 mm

Adjusting the stand height

 Placethemonitormountedonthestandbaseinan

uprightposition.

 Removethetapeattachedatthebottomrearof

thestand body,thenpulloutthelocking pin.

Tape

Locking Pin

Stand Body

24MB34PY

24MB34D

ASSEMBLING AND PREPARING

ENGLISH

Swivel stand



ImageshownmaydifferfromyourMonitorset.

 Swivel355degreesandadjusttheangleofthe

Monitorsettosuityourview.

 Liftthemonitortoitshighestheighttoutilizethe

Pivotfunction.

Using the Pivot function

Thepivotfunctionallowsyoutorotatethescreen90

degreesclockwise.

 Landscape&Portrait:Youcanrotatethepanel90°

clockwise.Pleasebecautiousandavoidcontactbe-

tweenthemonitorheadandtheStandBasewhen

rotatingthescreentoaccessthePivotfunction.If

themonitorheadtouchestheStandBase,thenthe

StandBasecouldcrack.

Head

section

Stand

section

 Becarefulwiththecableswhenrotatingthescreen.

24MB34PY

ASSEMBLING AND PREPARING

ENGLISH

Mounting on a wall

Forproperventilation,allowaclearanceof100mmon

eachsideandfromthewall.Detailed

instructionsareavailablefromyourdealer,seethe

optionalTiltWallMountingBracketInstallationand

SetupGuide.

IfyouintendtomounttheMonitorsettoawall,attach

Wallmountinginterface(optionalparts)tothebackof

theset.

WhenyouinstalltheMonitorsetusingawallmounting

interface(optionalparts),attachitcarefullysoitwillnot

drop.

 Please,Usethescrewandwallmountinterfacein

accordancewithVESAStandards.

 Ifyouusescrewlongerthanstandard,themonitor

mightbedamagedinternally.

 Ifyouuseimproperscrew,theproductmightbe

damagedanddropfrommountedposition.Inthis

case,LGElectronicsisnotresponsibleforit.

 VESAcompatibleonlywithrespecttoscrew

mountinginterfacedimensionsandmountingscrew

specifications.

 PleaseuseVESAstandardasbelow.



784.8mm(30.9inch)andunder

*WallMountPadThickness:2.6mm

*Screw:

4.0mmxPitch0.7mmx

Length10mm



787.4mm(31.0inch)andabove

*PleaseuseVESAstandardwallmountpadand

screws.

100 mm



UsethescrewsthatarelistedontheVESA

standardscrewspecifications.



Thewallmountkitwillincludeaninstallation

manualandnecessaryparts.



Thewallmountbracketisoptional.Youcan

obtainadditionalaccessoriesfromyourlocal

dealer.



Thelengthofscrewsmaydifferdependingon

thewallmount.Besuretousetheproperlength.



Formoreinformation,refertotheinstructions

suppliedwiththewallmount.

NOTE

Model

24MB34PY 24MB34D

VESA (A x B)

100x100

Standard screw

Number of screws

Wall Mount Plate

(Optional)

RW120



Disconnectthepowercordfirst,andthenmove

orinstalltheMonitorset.Otherwiseelectric

shockmayoccur.



IfyouinstalltheMonitorsetonaceilingor

slantedwall,itmayfallandresultinsevere

injury.



UseonlyanauthorizedLGwallmountand

contactthelocaldealerorqualifiedpersonnel.



Donotovertightenthescrewsasthismay

causedamagetotheMonitorsetandvoidyour

warranty.



Useonlyscrewsandwallmountsthatmeet

theVESAstandard.Anydamagesorinjuriesby

misuseorusinganimproperaccessoryarenot

coveredbythewarranty.



Screwlengthfromoutersurfaceofbackcover

shouldbeunder8mm.

CAUTION

BackCover

WallmountPad

BackCover

Standardscrew

Max.8mm

USING THE MONITOR SET

ENGLISH

USING THE MONITOR SET

Connecting to a PC



YourMonitorsetsupportsPlug&Play*.

*Plug&Play:APCrecognizesaconnecteddevice

thatusersconnecttoaPCandturnon,without

deviceconfigurationoruserintervention.

D-SUB connection

TransmitsanalogvideofromyourPCtotheMonitorset.

ConnectthePCandtheMonitorsetwiththesupplied

D-sub15pinsignalcableasshowninthefollowing

illustrations.



Mac adapter

ForAppleMacintoshuse,aseparateplugadapter

isneededtochangethe15pinhighdensity(3

row)D-SUBVGAconnectoronthesuppliedcable

toa15pin2rowconnector.



WhenusingaD-Subsignalinputcableconnector

forMacintosh

NOTE

DVI-D connection

TransmitsadigitalvideosignalfromyourPCtothe

Monitorset.ConnectthePCandtheMonitorsetwitha

DVIcableasshowninthefollowingillustrations.



Connectthesignalinput

cableandtightenitby

turningthescrewsclockwise.



Donotpressthescreenwith

yourfingerforalongtime

asthismayresultintemporarydistortiononthe

screen.



Avoiddisplayingafixedimageonthescreenfor

alongperiodoftimetopreventimageburn.Use

ascreensaverifpossible.

CAUTION

USING THE MONITOR SET

ENGLISH



"Self Image Setting" Function.

Thisfunctionprovidestheuserwithoptimal

displaysettings.Whentheuserconnects

themonitorforthefirsttime,thisfunction

automaticallyadjuststhedisplaytooptimal

settingsforindividualinputsignals.(Only

supportedinAnalogMode)



‘AUTO’ Function.

Whenyouencounterproblemssuchasblurry

screen,blurredletters,screenflickerortilted

screenwhileusingthedeviceorafterchanging

screenresolution,presstheAUTOfunction

buttontoimproveresolution.(Onlysupportedin

AnalogMode)

NOTE

Self Image Setting Function

Pressthepowerbuttononthebottompaneltoturnthe

poweron.Whenmonitorpoweristurnedon,the"Self

Image Setting"Functionisexecutedautomatically.(Only

supportedinAnalogMode)



Theremaybenovideooraudiooutputdepending

ontheDPversionofthePC.



IfyouusegenericcablesnotcertifiedbyLG,the

screenmaynotdisplayortheremaybeimage

noises.

DisplayPort connection

Transmitsthedigitalvideoandaudiosignalsfromyour

PCtothemonitor.ConnectyourPCtothemonitorus-

ingtheDisplayPortcableasillustratedbelow.

Pressthemenubuttonandthenselecttheinputoption

fromtheinputmenu.

NOTE

24MB34PY

USING THE MONITOR SET

ENGLISH



Peripheraldevicesaresoldseparately.



TheUSBportsontheleftandbottomofthe

monitorcanbeusedtoconnectthekeyboard,

mouse,andotherUSBdevices.

Peripheral device connection

Connectperipheraldevicestothemonitor.

NOTE



Headphonesorspeakersmaynotworknormally,

dependingontheserverPCsettings.



Virtualsolutionsmayaffectthefunctionsor

speedofthespecificUSBstoragedevice.

NOTE



Themonitor'sUSBterminalsupportsUSB2.0and

highspeedcables.  





DP=DisplayPort

TwoUSBDownstreamports

Connecttheseportstoamouse,USB

keyboard,memorystickwithcurrent

specunder100mA.

OneUSBUpstreamport

Connectthisporttothedown-

streamportofacomputer,laptopor

USBmonitor(YourcomputerorUSB

monitormustsupportUSBandhave

USBports).

(Not Provided)

24MB34D

24MB34PY

CUSTOMIZING SETTINGS

ENGLISH

CUSTOMIZING SETTINGS

 PressthedesiredbuttononthebottomoftheMonitorset.

 ChangethevalueofthemenuitembypressingthebuttonsonthebottomoftheMonitorset.

Toreturntotheuppermenuorsetothermenuitems,usetheuparrow( )button.

 SelectEXITtoleavetheOSDmenu.

Monitor set Buttons

Button Description

Accessesthemainmenus.(Seep.17)

OSD Locked/OSD

Unlocked

Thisfunctionallowyoutolockthecurrentcontrolsettings,sothat

theycannotbeinadvertentlychanged.

PressandholdtheMENUbuttonforseveralseconds.ThenOSDof

“OSDLock”willappear.Afterthat,usercanselectlockorunlockby

pressingleft/rightbutton.

Ifuserselectsthe“Lock”iconbypressingthe“OK”button,the

message“OSDLocked”willappear.Otherwise,“OSDUnlocked”will

appear.Afterselectingthe“Lock”,IfyouwanttochangetoUnlock,

youcanpushthe“MENU”buttonforseveralseconds.Themessage

“OSDUnlocked”willappear.

UsethisbuttontoenterReaderModemenu.Itsfunctionworkstodisplayscreenaspaper-

likepictureforEyecomfort.Ifyouwanttomoreinformation.(Seep.19)

UsethisbuttontoenterSMARTENERGYSAVINGmenu.

(

Seep.19

)

Whenadjustingyourdisplaysettings,alwayspresstheAUTObuttonontheMONITOR

SETUPOSD.(OnlysupportedinAnalogMode)

The best display mode 24MB34PY:1920x1080

24MB34D:1920x1080

Youcanchoosetheinputsignal.

• Whentwoinputsignalsareconnected,youcanselecttheinputsignalyouwant.

• Whenonlyonesignalisconnected,itisautomaticallydetected.Thedefaultsettingis

D-SUB.

EXIT

ExittheOSD(OnScreenDisplay).

(PowerButton)

Turnsthepoweronoroff.

Power Indicator

Thepowerindicatorstayswhiteifthedisplayisrunningproperly(On

Mode).IfthedisplayisinSleepMode,thepowerindicatorblinkswhite.

CUSTOMIZING SETTINGS

ENGLISH

Customizing Settings

Menu Analog Digital DP Description

Volume

24MB34PY

● ● ●

Toadjustthevolume

Brightness

● ● ●

Toadjustthebrightnessofthescreen

Contrast

24MB34D

● ●

Toadjustthecontrastofthescreen

Wide/Original

● ● ●

Wide

Switchtofullscreenmodeaccordingtoinputimagesignal.

Original

Changetheinputimagesignalratiotooriginal.

*ThisfunctionworksonlyifinputresolutionislowerthanMonitorset

ratio(16:9).

Reset

● ● ●

Restoreallfactorydefaultsettings.Pressthe

◄

,

►

buttonstoreset

immediately.

Menu > Next Menu Analog Digital DP Description

Picture Contrast

24MB34PY

● ● ●

Toadjustthecontrastofthescreen

Sharpness

● ● ●

Toadjusttheclearnessofthescreen

Color Gamma

● ● ●

Tocustomizethecolorofthescreen

Color Temp

Display Horizontal

●

Toadjustthepositionofthescreen

Vertical

Clock

●

Toimprovetheclarityandstabilityofthescreen

Phase

Audio

24MB34PY

Audio Input

●

Toselecttheaudioinput

Others Language

● ● ●

Tocustomizethescreenstatusforauser'soperating

environment

Power Indicator

Off Time Setting



Analog: D-SUB(Analogsignal)input.



Digital: DVI-D(Digitalsignal)input.



DP: DisplayPortinput.

CUSTOMIZING SETTINGS

ENGLISH

Menu > Next Menu > Picture

Description

Contrast

24MB34PY

Toadjustthecontrastofthescreen.

Sharpness Toadjusttheclearnessofthescreen.

Menu > Next Menu > Color

Description

Gamma Setyourowngammavalue.:Gamma0,Gamma1,Gamma2onthemonitor,

highgammavaluesdisplaywhitishimagesandlowgammavaluesdisplay

blackishimages.

Color Temp Custom

• Red:Setyourownredcolorlevels.

• Green: Setyourowngreencolorlevels.

• Blue:Setyourownbluecolorlevels.

Selectthescreencolor.

Warm: Setthescreentowarmcolortemperature(morered).

Medium:Setthescreentomediumcolortemperature.

Cool: Setthescreentocoolcolortemperature(moreblue).

Menu > Next Menu > Display

Description

Horizontal Tomoveimageleftandright.

Vertical Tomoveimageupanddown.

Clock Tominimizeanyverticalbarsorstripesvisibleonthescreenbackground.The

horizontalscreensizewillalsochange.

Phase Toadjustthefocusofthedisplay.Thisitemallowsyoutoremoveany

horizontalnoiseandclearorsharpentheimageofcharacters.

Menu > Next Menu > Audio

Description

Audio Input (OnlyinDPinput)

24MB34PY

ToSelecttheaudiosourcetooutputtospeakerfrombelowitems.

1.Audio-In:Theaudiosourceonexternalanalogaudiojack.

(OnlyinDsub/DVI-Dinput)

2.DP:TheaudiosourceonDPport.

3.Auto:TheaudiosourceisswitchedautomaticallybetweenDPorAudio-In.

DPhashigherpriority.(OnlyinDPinput)

Menu > Next Menu > Others

Description

Language Tochoosethelanguageinwhichthecontrolnamesaredisplayed.

Power Indicator Usethisfunctiontosetthepowerindicatoronthebottomsideofthemonitor

toOnorOff.IfyousetOff,itwillgooff.

IfyousetOnatanytime,thepowerindicatorwillautomaticallybeturnedon.

Off Time Setting Themonitorsetwillswitchtopoweroffmodeafterthetimetobechosenby

user(1~24hours)

CUSTOMIZING SETTINGS

ENGLISH

Reader Mode

Description

Reader 1 Itisamodethatthescreenisadjustedtothebestforthenewspaper.Ifyou

wantscreenmorebright,youcancontrolbrightnessinMenuOSD.

Reader 2 Itisamodethatthescreenisadjustedtothebestforthecartoon.Ifyouwant

screenmorebright,youcancontrolbrightnessinMenuOSD.

Reader Off Itisamodethatreadermodeisoff.

NOTE

IfoptionofReaderModeisReader1orReader2,SMARTENERGYSAVINGwillautomaticallybeOff.

NOTE

SMART ENERGY SAVING

Description

High

EnablesSMARTENERGYSAVINGyoucansaveenergywiththisenergy-highefficient

function.

Low

EnablesSMARTENERGYSAVINGyoucansaveenergywiththisenergy-lowefficient

function.

Off DisablesSMARTENERGYSAVING.

*

SMART ENERGY SAVING:

Conserveenergybyusingluminancecompensationalgorithm.



SavingDatadependsonthePanel.So,thosevaluesshouldbedifferentfromeachpanelandpanelvendor.If

optionofSMARTENERGYSAVINGisHighorLow,monitorluminancebecomehigherorlowerdependonsource.



IfoptionofSMARTENERGYSAVINGisHighorLow,ReaderModewillautomaticallybeReaderOff.

TROUBLESHOOTING

ENGLISH

TROUBLESHOOTING

Check the following before calling for service.

No image appears

Isthepowercordofthedisplay

connected?





Checkandseeifthepowercordisconnectedproperlytothepoweroutlet.

Isthepowerindicatorlighton?





PressthePowerbutton.

Isthepoweronandthepowerindicator

White?





Adjustthebrightnessandthecontrast.

Isthepowerindicatorflickering?





Ifthedisplayisinpowersavingmode,trymovingthemouseorpressingany

keyonthekeyboardtobringupthescreen.





TrytoturnonthePC.

Doyouseean"OUTOFRANGE"

messageonthescreen?





ThismessageappearswhenthesignalfromthePC(videocard)isoutof

horizontalorverticalfrequencyrangeofthedisplay.Seethe'Specifications'

sectionofthismanualandconfigureyourdisplayagain.

Doyouseea"NOSIGNAL"messageon

thescreen?





Whenthemonitorison"No-Signal"in5minutes,themonitorgoestoDPM

mode.

Do you see a "OSD LOCKED" message on the screen?

Doyousee“OSDLOCKED”whenyou

pushMENUbutton?





Youcansecurethecurrentcontrolsettings,sothattheycannotbe

inadvertentlychanged.YoucanunlocktheOSDcontrolsatanytime

bypushingtheMENUbuttonforseveralseconds:themessage“OSD

UNLOCKED”willappear.

Display image is incorrect

DisplayPositionisincorrect.





PresstheAUTObuttontoautomaticallyadjustyourdisplayimagetothe

idealsetting.

Onthescreenbackground,vertical

barsorstripesarevisible.





PresstheAUTObuttontoautomaticallyadjustyourdisplayimagetothe

idealsetting.

Anyhorizontalnoiseappearinginany

imageorcharactersarenotclearly

portrayed.





PresstheAUTObuttontoautomaticallyadjustyourdisplayimagetothe

idealsetting.





CheckControl Panel

►

Display

►

Settingsandadjustthedisplaytothe

recommendedresolutionoradjustthedisplayimagetotheidealsetting.Set

thecolorsettinghigherthan24bits(truecolor).

TROUBLESHOOTING

ENGLISH

Display image is incorrect

Thescreencolorismonoorabnormal.





Checkifthesignalcableisproperlyconnectedanduseascrewdrivertofasten

ifnecessary.





Makesurethevideocardisproperlyinsertedintheslot.





Setthecolorsettinghigherthan24bits(truecolor)atControl Panel

►



Settings.

Thescreenblinks.





Checkifthescreenissettointerlacemodeandifyes,changeittothe

recommendresolution.

Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message?

Haveyouinstalledthedisplaydriver?





BesuretoinstallthedisplaydriverfromthedisplaydriverCD(ordiskette)

thatcomeswithyourdisplay.Or,youcanalsodownloadthedriverfromour

website:http://www.lg.com.





MakesuretocheckifthevideocardsupportsPlug&Playfunction.



CheckControl Panel

►

Display

►

Settingsandseeifthefrequencyortheresolutionwerechanged.Ifyes,

readjustthevideocardtotherecommendresolution.



Iftherecommendedresolution(optimalresolution)isnotselected,lettersmaybeblurredandthescreenmaybe

dimmed,truncatedorbiased.Makesuretoselecttherecommendresolution.



ThesettingmethodcandifferbycomputerandO/S(OperationSystem),andresolutionmentionedabovemay

notbesupportedbythevideocardperformance.Inthiscase,pleaseasktothecomputerorthevideocard

manufacturer.

CAUTION

SPECIFICATIONS

ENGLISH

SPECIFICATIONS

Display Screen Type FlatPanelActivematrix-TFTLCDAnti-Glarecoating

Pixel Pitch 0.2715mmx0.2715mm(PixelPitch)

Sync Input Horizontal Frequency 30kHzto83kHz(Automatic)

Vertical Frequency 56Hzto75Hz(D-SUB,DVI-D)

56Hzto61Hz(DP)

Input Form SeparateSync.Digital

Video Input Signal Input 15pinD-SUBConnector/DVI-DConnector(Digital)/

DPConnector

Input Form RGBAnalog(0.7Vp-p/75ohm),Digital

Resolution Max VESA1920x1080@60Hz

Recommend VESA1920x1080@60Hz

Plug & Play DDC2B(Analog,Digital,DP)

Power Consumption Onmode:16.7WTyp.(ENERGYSTAR®standard)*

24.9WTyp.(Outgoingcondition)**

SleepMode≤0.3W

OffMode≤0.3W

Power Input AC100-240V~50/60Hz1.2A

Speaker Wattage 1W+1W

Dimensions

(Width x Height x

Depth)

With Stand 569.1mmx381.8mmx239mm

Without Stand 569.1mmx341.9mmx63mm

Weight With Stand 4.75kg

Without Stand 3.45kg

Environmental

conditions

Operating Temperature

Operating Humidity

10°Cto35°C

10%to80%

Storage Temperature

Storage Humidity

-20°Cto60°C

5%to90%non-Condensing

Thespecificationsaresubjecttochangewithoutnotice.

*Thepowerconsumptionlevelcanbedifferentbyoperatingconditionandmonitorsetting.

*TheOnmodepowerconsumptionismeasuredwithENERGYSTAR®teststandard.

**TheOnmodepowerconsumptionismeasuredwithLGEteststandard(FullWhitepattern,Maximumresolution).

24MB34PY

SPECIFICATIONS

ENGLISH

SPECIFICATIONS

Display Screen Type FlatPanelActivematrix-TFTLCDAnti-Glarecoating

Pixel Pitch 0.2715mmx0.2715mm(PixelPitch)

Sync Input Horizontal Frequency 30kHzto83kHz(Automatic)

Vertical Frequency 56Hzto75Hz(D-SUB,DVI-D)

Input Form SeparateSync.Digital

Video Input Signal Input 15pinD-SUBConnector/DVI-DConnector(Digital)

Input Form RGBAnalog(0.7Vp-p/75ohm),Digital

Resolution Max VESA1920x1080@60Hz

Recommend VESA1920x1080@60Hz

Plug & Play DDC2B(Analog,Digital)

Power Consumption Onmode:16.7WTyp.(ENERGYSTAR®standard)*

21WTyp.(Outgoingcondition)**

SleepMode≤0.3W

OffMode≤0.3W

Power Input AC100-240V~50/60Hz1.2A

Dimensions

(Width x Height x

Depth)

With Stand 569.1mmx433mmx209.8mm

Without Stand 569.1mmx341.9mmx63mm

Weight With Stand 3.85kg

Without Stand 3.55kg

Environmental

conditions

Operating Temperature

Operating Humidity

10°Cto35°C

10%to80%

Storage Temperature

Storage Humidity

-20°Cto60°C

5%to90%non-Condensing

Thespecificationsaresubjecttochangewithoutnotice.

*Thepowerconsumptionlevelcanbedifferentbyoperatingconditionandmonitorsetting.

*TheOnmodepowerconsumptionismeasuredwithENERGYSTAR®teststandard.

**TheOnmodepowerconsumptionismeasuredwithLGEteststandard(FullWhitepattern,Maximumresolution).

24MB34D

SPECIFICATIONS

ENGLISH

Preset Modes (Resolution)

24MB34PY

D-SUB/DVI Timing

Display Modes (Resolution)

Horizontal

Frequency(kHz)

Vertical

Frequency(Hz)

Polarity(H/

720x400 31.468 70 -/+

640x480 31.469 60 -/-

640x480 37.500 75 -/-

800x600 37.879 60 +/+

800x600 46.875 75 +/+

1024x768 48.363 60 -/-

1024x768 60.023 75 +/+

1152x864 67.500 75 +/+

1280x1024 63.981 60 +/+

1280x1024 79.976 75 +/+

1680x1050 65.290 60 -/+

1920x1080 67.5 60 +/+

RecommendMode

DP Timing

Display Modes (Resolution)

Horizontal

Frequency(kHz)

Vertical

Frequency(Hz)

Polarity(H/

640x480 31.469 60 -/-

800x600 37.879 60 +/+

1024x768 48.363 60 -/-

1280x1024 63.981 60 +/+

1680x1050 65.290 60 -/+

1920x1080 67.5 60 +/+

RecommendMode

SPECIFICATIONS

ENGLISH

24MB34D

D-SUB/DVI Timing

Display Modes (Resolution)

Horizontal

Frequency(kHz)

Vertical

Frequency(Hz)

Polarity(H/

720x400 31.468 70 -/+

640x480 31.469 60 -/-

640x480 37.500 75 -/-

800x600 37.879 60 +/+

800x600 46.875 75 +/+

1024x768 48.363 60 -/-

1024x768 60.023 75 +/+

1152x864 67.500 75 +/+

1280x1024 63.981 60 +/+

1280x1024 79.976 75 +/+

1680x1050 65.290 60 -/+

1920x1080 67.500 60 +/+ RecommendMode

Indicator

Mode LED Color

OnMode White

SleepMode BlinkingWhite

OffMode Off

Make sure to read the Safety Precautions before

using the product.

Keep the Owner’s Manual (CD) in an accessible place

for future reference.

The model and serial number of the SET is located

on the back and one side of the SET. Record it below

should you ever need service.

As an ENERGY STAR Partner LGE U. S.

A.,Inc. has determined that this product

meets the ENERGY STAR guidelines for

energy efficiency.

ENERGY STAR is a set of power-saving

guidelines issued by the U.S.Environmental

Protection Agency(EPA).

MODEL

SERIAL

LG 24MB34D-B 24" class (23.5” diagonal) TN Monitor (TAA Compliant)

Product's Documents

User Manual

Specifications

LG Electronics 24MB34D-B Questions and Answers

Related Products

LG Electronics 24MB34PY-B 24" Class (23.8" Diagonal) TN Monitor (TAA Compliant)

LG Electronics 24MB35D-B 24" Class (23.8” Diagonal) IPS Monitor

LG Electronics 24MB35PU-B - 24" class (23.8" diagonal) IPS Monitor

LG Electronics 24MK400H-B 24" Class Full HD TN Monitor

LG 24BK550Y-B 24” Class (23.8” Diagonal) IPS Multi-tasking Monitor
