Bissell 2790 Pet Hair Eraser Turbo Rewind Vacuum

User Manual - Transcript

• Page 1 - English - : Go online for a comprehensive walkthrough of your new purchase This guide has everything you need to get ready for first use including setting up using and maintaining your machine but online youll find additional resources like tips and troubleshooting videos product registration parts and more Go to supportBISSELLcom PET HAIR ERASER TURBO REWIND 2790 SERIES
• Page 2 - English - : 2 BISSELLcom IMPORTANT SAFETY INSTRUCTIONS WARNING TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK OR INJURY Do not leave vacuum cleaner when it is plugged in Unplug from outlet when not in use and before servicing Do not use outdoors or on wet surfaces Do not allow to be used as a toy Close attention is necessary when used by or near children Do not use for any purpose other than described in this user guide Use only manufacturers recommended attachments Do not use with damaged cord or plug If appliance is not working as it should has been dropped damaged left outdoors or dropped into water have it repaired at an authorized service center Do not pull or carry by cord use cord as a handle close a door on cord or pull cord around sharp edges or corners Do not run appliance over cord Keep cord away from heated surfaces Do not unplug by pulling on cord To unplug grasp the plug not the cord Do not handle plug or vacuum cleaner with wet hands Do not put any object into openings Do not use with any opening blocked keep openings free of dust lint hair and anything that may reduce air flow Keep hair loose clothing fingers and all parts of body away from openings and moving parts Turn all controls OFF before plugging or unplugging vacuum cleaner Use extra care when cleaning on stairs Do not use to pick up flammable or combustible materials lighter fluid gasoline kerosene etc or use in areas where they may be present Do not use vacuum cleaner in an enclosed space filled with vapors given off by oilbased paint paint thinner some mothproofing substances flammable dust or other explosive or toxic vapors Do not use to pick up toxic material chlorine bleach ammonia drain cleaner etc Do not pick up anything that is burning or smoking such as cigarettes matches or hot ashes Do not use without filters in place Do not pick up hard or sharp objects such as glass nails screws coins etc Use only on dry indoor surfaces Keep appliance on a level surface Do not carry the vacuum cleaner while it is running Unplug before connecting or disconnecting the TurboBrush Tool Plastic film can be dangerous To avoid danger of suffocation keep away from children Do not plug in your vacuum cleaner until you are familiar with all instructions and operating procedures Turn Power Switch OFF and disconnect polarized plug from electrical outlet BEFORE performing maintenance or troubleshooting checks SAVE THESE INSTRUCTIONS THIS MODEL IS FOR HOUSEHOLD USE ONLY COMMERCIAL USE OF THIS MACHINE VOIDS THE MANUFACTURERS WARRANTY Warranty 5Year limited warranty may vary by state Visit supportBISSELLcom or call 18002377691 for complete warranty information READ ALL INSTRUCTIONS BEFORE USING YOUR APPLIANCE Always connect to a polarized outlet one slot is wider than the other Unplug from outlet when not in use and before conducting maintenance When using an electrical appliance basic precautions should be observed including the following THIS APPLIANCE HAS A POLARIZED PLUG To reduce the risk of electric shock this appliance has a polarized plug one blade is wider than the other This plug will fit in a polarized outlet only one way If the plug does not fit fully in the outlet reverse the plug If it still does not fit contact a qualified electrician to install a proper outlet Do not change the plug in any way
• Page 3 - English - : BISSELLcom 3 Were so happy you chose the Pet Hair Eraser Turbo Rewind We put this guide together to help you set up use and maintain your vacuum Weve also included some tips we think will come in handy when you first start using your vacuum so lets get started For a comprehensive walkthrough of your product go to supportBISSELLcom Warranty 2 Whats in the Box 4 Product View 4 Assembly 5 Using Your Vacuum 6 Automatic Cord Rewind 7 AboveFloor Cleaning 8 Emptying the Dirt Tank9 Cleaning the Inner Cyclone Separator 9 Cleaning and Replacing the Filters 10 Protecting the Vacuums Motor 11 Troubleshooting 11
• Page 4 - English - : 4 BISSELLcom 1 Suction Control 2 Hose 3 Quick Release Extension Wand 4 Dirt Tank Release Button 5 Power Switch 6 Brush Roll ONOFF Switch 7 PreMotor Filter 8 Dirt Tank 9 PostMotor Filter 10 Automatic Cord Rewind Button Product View For additional support videos and information about your vacuum visit supportBISSELLcom Vacuum Base Upper Handle amp Extension Wand Stretch Hose LED Lighted Crevice Tool Pet TurboEraser Tool 2in1 Pet Brush Optional Febreze Filter Whats in the Box Standard accessories may vary by modelTo identify what should be included with your purchase please refer to the Carton Contents list located on the carton top flap Certain trademarks used under license from The Procter amp Gamble Company or its aliates
• Page 5 - English - : BISSELLcom 5 Assembly Go to supportBISSELLcom for assembly videos 1 Slide end of wand into top of base It will click when inserted correctly 2 Attach Stretch Hose by lining the tabs on the circular cuff with the notches on the back of the handle Twist clockwise to lock hose into place 3 Press the Dirt Tank Release Button and pull tank away from the vacuum to remove 4 Attach end of hose to vacuum by sliding square cuff into the bracket below the Power Switch 5 Install optional Febreze filter by twisting tank cover to unlock position and pulling up on the handle Remove the PreMotor Filter and replace with Febreze filter Reinstall tank cover when done 6 Place the Dirt Tank on the vacuum by securing the bottom in place first then push back until you hear a click Certain trademarks used under license from The Procter amp Gamble Company or its affiliates
• Page 6 - English - : 6 BISSELLcom Using Your Vacuum For additional ways to use your vacuums features check out supportBISSELLcom 1 Turn the Power Switch ON Optional Turn the Brush Roll Switch ON to run the PowerBrush for carpet cleaning Brush Roll is ON when light switch is illuminated Turn the Brush Roll Switch OFF when vacuuming hard or delicate surfaces like hardwood tile small area rugs or frieze carpets with long delicate fibers or threads 2 Step gently on base and pull the handle back to recline Note The Brush Roll automatically shuts OFF when vacuum is locked in upright position Recline to reactivate 3 Use the Suction Control Switch to change settings between plush and low carpet for easy multisurface cleaning WARNING Do not plug in your vacuum until you are familiar with all instructions and operating procedures
• Page 7 - English - : BISSELLcom 7 Automatic Cord Rewind If you have trouble with this feature see our troubleshooting videos on supportBISSELLcom 1 To plug in your vacuum gently pull the cord out being careful not to pass the red mark on the cord Plug the cord into an outlet 2 When youre done cleaning unplug the vacuum Hold the plug and press the Automatic Cord Rewind Button to slowly retract the cord 3 If it doesnt fully retract at first pull some of the cord out and press the button again WARNING Hold plug when rewinding onto cord reel Do not allow plug to whip when rewinding
• Page 8 - English - : 8 BISSELLcom AboveFloor Cleaning Visit supportBISSELLcom to see all the ways you can use your vacuums tools 1 Clean hardtoreach spaces with the Quick Release Extension Wand Push the release button to remove and attach desired tool 2 The Stretch Hose can be removed from the extension wand To do so twist circular hose cuff counterclockwise and remove from handle 3 When finished replace the wand back on the vacuum by sliding into place until you hear a click and reattach hose to handle if needed
• Page 9 - English - : BISSELLcom 9 Cleaning the Inner Cyclone Separator We have additional maintenance videos for your machine on supportBISSELLcom 1 Hold the Dirt Tank over a trash container Press the bottom release button to empty 2 Twist Cyclone counter clockwise and pull down to remove 3 Tap separator against inside of trash container and rinse under warm water if necessary Be sure to let it dry completely before placing back in Dirt Tank Emptying the Dirt Tank For additional maintenance steps visit supportBISSELLcom 1 Press the Dirt Tank Release Button and grab the handle to pull the Dirt Tank away from vacuum 2 Hold the Dirt Tank over a trash bin and press the Empty Button Once emptied snap bottom back into place 3 Return the Dirt Tank to the vacuum by securing the bottom in place first and then pushing back until you hear a click WARNING To reduce the risk of electrical shock Turn Power Switch OFF and disconnect polarized plug from electrical outlet before performing maintenance or troubleshooting checks Before using your vacuum make sure that the Dirt Tank is in locked position and that all filters both pre and postfilters are in place DO NOT operate your vacuum without these filters
• Page 10 - English - : 10 BISSELLcom Cleaning and Replacing the Filters Visit BISSELLcom to find replacement filters 1 Press down on tab to remove PostMotor Filter cover 2 Twist filter counter clockwise to unlock and remove from vacuum Remove debris from filter by tapping on the side of a trash container This pleated filter may NOT be washed 3 When reassembling be sure to lock the filter back into place Reattach the filter cover 1 Press the Dirt Tank Release Button and pull away from vacuum 2 Twist tank cover to the unlock position then pull up on handle 3 Remove PreMotor Filter from top of Dirt Tank lid by pulling out 24h 4 Clean with mild detergent rinse and squeeze all excess water Allow filters to dry completely before reinserting 5 Return PreMotor Filters to the top of the Dirt Tank placing the thick foam filter in last 6 Put tank cover back on and twist to lock PreMotor Filter PostMotor Filter WARNING To reduce the risk of electrical shock Turn Power Switch OFF and disconnect polarized plug from electrical outlet before performing maintenance or troubleshooting checks Do not operate vacuum with damp or wet filters Allow components to dry before reassembling the Dirt Tank
• Page 11 - English - : BISSELLcom 11 Problem Possible Cause Remedies Vacuum is hard to push or pull Suction needs adjustment Adjust using the Suction Control feature on the handle See page 6 Vacuum wont pick up dirt There is a clog in the vacuum Remove main hose run broomstick through to clear Remove bottom brush cover and clear debris from brush belt and foot area Remove lower hose and run broomstick through to clear any clogs Filters are dirty Remove and rinse PreMotor Filters Allow enough time for them to dry properly before reinserting Remove and dust off PostMotor Filter See page 10 Incorrect Suction Control settings Adjust using the Suction Control feature See page 6 Brush Roll doesnt rotate Brush Roll Switch is OFF Make sure Brush Roll Switch is ON Vacuum is locked in upright position Recline vacuum and turn the Brush Roll Switch ON Brush Roll has lodged debris or other entanglements keeping the brush from rotating Remove bottom brush cover and clear debris from brush belt and foot area To reset brush motor machine should be unplugged before turning ON Loud noise Suction relief valve was activated Clear any clogs from the upper and lower hose and brush area Also clean all filters Troubleshooting Below are some of the issues you may run into If you dont see the issue youre experiencing below visit supportBISSELLcom WARNING To reduce the risk of electrical shock turn Power Switch OFF and disconnect polarized plug from electrical outlet before performing maintenance or troubleshooting checks Protecting the Vacuums Motor For more assistance with your vacuums motor protection visit supportBISSELLcom There is an internal thermal protector in your vacuum that protects it from overheating It controls the main vacuum motor only not the brush motor When it activates the main motor will stop The front lights and Brush Roll will stay on but there wont be any suction If this happens follow these steps 1 Turn vacuum OFF and unplug from electrical outlet 2 Check for the source of overheating problem full Dirt Tank dirty filters or a clog and fix by following the steps in the Vacuum wont pick up dirt troubleshooting section 3 When the motor cools for approximately 30 minutes the thermal protector automatically resets and cleaning may continue If the vacuum will not turn ON or the thermal protector continues to activate contact Consumer Care 1 Press the Dirt Tank Release Button and pull away from vacuum 2 Twist tank cover to the unlock position then pull up on handle 3 Remove PreMotor Filter from top of Dirt Tank lid by pulling out 24h 4 Clean with mild detergent rinse and squeeze all excess water Allow filters to dry completely before reinserting 5 Return PreMotor Filters to the top of the Dirt Tank placing the thick foam filter in last 6 Put tank cover back on and twist to lock
• Page 12 - English - : 2019 BISSELL Inc All rights reserved Printed in China Part Number 1619997 1119 RevH Visit our website at wwwBISSELLcom But wait theres more Join us online for a complete guide to your new product including troubleshooting product registration parts and more Go to supportBISSELLcom VIDEOS INFOREGISTER PARTS SUPPORT Were Waggin Our Tails BISSELL proudly supports BISSELL Pet Foundation and its mission to help save homeless pets When you buy a BISSELL product you help save pets too Were proud to design products that help make pet messes odors and pet homelessness disappear Visit BISSELLsavespetscom to learn more
