User Manual Oster TSSTTVFDDG-DS French Door Countertop Oven

User Manual

French Door Countertop Oven

Manual de Instrucciones

Horno de mostrador con

puerta francesa

P.N. 180803 Rev. B

Visit us at www.oster.com

TSSTTVFDDG

MODEL/MODELO

(NYSE: NWL). Printed in China.

Newell Brands, Inc. (NYSE: NWL). Impresso en China.

CBA-100517

Welcome

Congratulations on your purchase of an

OSTER

Countertop Oven! If you require service

on your

OSTER

Countertop Oven, do not return to place of purchase. Please contact us at www.

oster.com or 1.800.334.0759.

Features of Your Countertop Oven

(See Figure 1)

1. Removable Wire Racks/Broil Rack

2. Interior Light

3. Time Display

4. Control Buttons

5. Two Rack Positions

6. Easy Clean Interior Walls

7. Glass Doors

8. Internal Removable Crumb Tray

9. Baking Pan

Control Buttons

Function Buttons –

(See Figure 2)

Bake – Select to bake.

Turbo – Select to bake with convection.

Broil – Select to Broil.

Toast – Select to toast bread, bagels, etc.

Pizza – Select to bake a large pizza.

Defrost – Select to defrost foods.

Dehydrate – Select to dehydrate foods

Timer

– Adjusts time, temperature or toast shade.

Temp

– Adjusts temperature.

Clock – Sets the Oven Clock.

Stop/Cancel – Stops heating or cancels function.

Start – Starts baking/cooking process.

NOTE – Oven is on when display icons are illuminated

and ﬂashing.

Pressing Stop/Cancel button twice turns off unit.

7 8

English-1 English-2

Figu re 2

igur e 1

To Use the Pizza Function

Place oven rack into the desired position before heating the oven. (See “Positioning Rack” Section)

Arrange pizza on the wire rack.

Push the Pizza button and 20:00 default time will appear. Use arrow keys to adjust

the time as desired. Push the Start button.

Interior light turns on when timer is on. At the end of cooking cycle the light

turns off automatically.

NOTE – The Pizza function temperature is set at 400°F and cannot be adjusted.

If different temperature is desired, cancel Pizza function and use Bake function.

For 2 Pizzas: Place the 2 pizzas on the wire racks. Cook the pizzas for about one-half the recommended

time, and then switch the rack positions to allow the pizzas to uniformly cook top and bottom.

Defrosting Function

When defrosting do not preheat oven.

Temperature Control is already set to 150°F and cannot be adjusted.

Push the defrost button. Use arrow keys to adjust time. Allow 15 to 20 minutes per side for

meats or ﬁsh to defrost. Always cook food promptly after thawing.

Push the Start button.

Interior light turns on when timer is on. At the end of cooking cycle the light turns off automatically.

Dehydrate Function

When dehydrating do not preheat oven. Temperature Control is already set to 150°F and can-

not be adjusted. Push the dehydrate button. Use arrow keys to adjust time. Dehydrate time can

be adjusted up to 6hrs. Push the start button to start dehydrating.

For more information on dehydrating food, please visit www.oster.com

Preparing To Use Your Countertop Oven for the First Time

If you are using your countertop oven for the ﬁrst time, please be sure to:

Remove any stickers from the surface of the oven.

Open oven door and remove all printed documents and paper from inside the countertop oven.

Clean the rack, tray, and pan with hot water, a small amount of dishwashing liquid

and a non-abrasive sponge or cleaning pad.

CAUTION: DO NOT IMMERSE THE BODY OF THE UNIT IN WATER.

Dry the unit thoroughly before using.

Select a location for the countertop oven. The location should be in an open area on a ﬂat

counter where the plug will reach an outlet.

Plug the countertop oven into a 120 Volt AC electrical outlet.

Using Your Countertop Oven

Setting the Clock

Push the Clock button. The clock will ﬂash.

Use the arrow keys to set the hour. Push the Clock button again.

Use the arrow keys to set the minutes.

Push the Clock button once more or the start button and the time will be set.

Preheating the Oven

Place oven rack into the desired position before heating the oven.

(See “Positioning Rack” Section)

This oven has a preheat feature in Turbo Convection Bake and Bake mode. Select the mode, Turbo

Convection or Bake. Use the temp arrow keys to select the desired temperature.

Use the timer arrow keys to select the desired time.

Push the Start button. Display will show PrE until temperature is reached, the oven will beep and

display remaining time. At this time you may adjust the selected time. The temperature may also be

adjusted. If you increase the temperature the unit will go back to preheat mode until it reaches the

new set temperature.

To bypass the preheat function press the start button a second time.

To Use the Bake Function

Place oven rack into the desired position before heating the oven.

(See “Positioning Rack” Section)

Arrange food on the wire rack or in the baking pan.

Push the Bake button. Use the Temperature arrow keys to select desired temperature.

Use the Time arrow keys to select desired time.

Push the Start button.

The oven will go into the preheat mode. To bypass the preheat mode press the start

button a second time.

Interior light turns on when timer is on. At the end of cooking cycle the light turns

off automatically.

NOTE – Upper and lower heating elements will cycle ON and OFF to maintain the desired

temperature, and may not glow.

When baking is completed, open door fully and remove food carefully.

English-3 English-4

elpful

Tips

/ TroublesHooTing

Problem

• Overcooked /

Undercooked

Foods

• Burnt Smell

• Oven does not

turn ON

• Only one heating

element is

heating up

• Heating elements

do not stay ON

• Cannot change

function button

Solution

• You may have to adjust the time and

temperature to desired taste.

• Because your countertop oven is smaller than

your regular oven, it will heat up faster and

generally cook in shorter periods of time.

• Refer to “Positioning Rack” Section,

Page English-4. Rack may need to be

adjusted to accommodate food type.

• Refer to “Cleaning Your Countertop

Oven” Section, Page English-5.

• Plug the countertop oven into a 120-volt

AC electrical outlet.

• Set timer knob and temperature knob to

desired setting. Both must be turned on

to operate the countertop oven.

• Press Start.

• When toasting, make sure the oven is

not

set to broil setting.

• Be certain that function is as desired.

• Heating elements may not glow.

• Press cancel.

Potential CauSe

• Incorrect temperature or

time setting

• Rack placement

• Food build-up inside

oven, on heating elements

or in crumb tray.

• Unit is unplugged

• Did not press Start.

• Function setting

selection determines

which heating element

will operate.

• Heating elements will

cycle ON and OFF to

maintain proper heat.

• Need to cancel function.

1 Year Satisfaction Guarantee

Sunbeam Products, Inc., or if in Canada, Sunbeam Corporation (Canada) Limited, (collectively

“Sunbeam”) warrants that for a period of fone year from the date of purchase, this product will

be free from defects in material and workmanship. Sunbeam, at its option, will repair or replace

this product or any component of the product found to be defective during the guarantee period.

Replacement will be made with a new or remanufactured product or component. If the product

is no longer available, replacement may be made with a similar product of equal or greater value.

This is your exclusive guarantee. Do NOT attempt to repair or adjust any electrical or

mechanical functions on this product. Doing so will void this guarantee. This guarantee is valid

for the original retail purchaser from the date of initial retail purchase and is not transferable.

Keep the original sales receipt. Proof of purchase is required to obtain satisfaction guarantee

performance. Sunbeam dealers, service centers, or retail stores selling Sunbeam products do not

have the right to alter, modify or any way change the terms and conditions of this guarantee.

This guarantee does not cover damage resulting from any of the following: negligent use or

misuse of the product, use on improper voltage or current, use contrary to the operating

instructions, disassembly, repair or alteration by anyone other than Sunbeam or an authorized

Sunbeam service center. Further, the guarantee does not cover: Acts of God, such as ﬁre, ﬂood,

hurricanes and tornadoes.

What are the limits on Sunbeam’s Liability?

Sunbeam shall not be liable for any incidental or consequential damages caused by the breach

of any express, implied or statutory guarantee or condition. Except to the extent prohibited by

applicable law, any implied guarantee or condition of merchantability or ﬁtness for a particular

purpose is limited in duration to the duration of the above guarantee. Sunbeam disclaims all

other guarantees, conditions or representations, express, implied, statutory or otherwise. Sun-

beam shall not be liable for any damages of any kind resulting from the purchase, use or misuse

of, or inability to use the product including incidental, special, consequential or similar damages

or loss of proﬁts, or for any breach of contract, fundamental or otherwise, or for any claim

brought against purchaser by any other party.

Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or

consequential damages or limitations on how long an implied guarantee lasts, so the above

limitations or exclusion may not apply to you. This guarantee gives you speciﬁc legal rights,

and you may also have other rights that vary from province to province, state to state or

jurisdiction to jurisdiction.

How to Obtain Satisfaction Guarantee Service

In the U.S.A.

If you have any question regarding this guarantee or would like to obtain guarantee service,

please call 1-800-334-0759 and a convenient service center address will be provided to you.

In Canada

If you have any question regarding this guarantee or would like to obtain guarantee service,

please call 1-800-667-8623 and a convenient service center address will be provided to you.

In the U.S.A., this guarantee is offered by Sunbeam Products, Inc., located in Boca Raton,

Florida 33431. In Canada, this guarantee is offered by Sunbeam Corporation (Canada) Limited,

located at 20 B Hereford Street, Brampton, Ontario L6Y 0M1. If you have any other problem

or claim in connection with this product, please write to the Consumer Service Department.

PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF

THESE ADDRESSES OR TO THE PLACE OF PURCHASE.

English-5 English-7English-6 English-8

Positioning Rack

To accommodate a wide variety of foods, the oven has 2

racks and two (2) rack positions. (See Figure 3)

Positioning of the rack will depend on the size of the food

and desired browning.

Before removing the rack, allow the unit to cool.

PLEASE NOTE – For best toast and pizza results,

position the rack in the top rack position.

Positioning Pan

• To accommodate a wide variety of foods the oven has two pan positions. The pan can

be placed on top of the rack or inserted into the guide rails below the rack. (See Figure Below)

• Before removing the pan allow the unit to cool.

• Positioning of the oven pan will depend on the desired cooking method. For baking, place

the pan on top of one of the racks. For grilling or broiling, insert the pan into the guide rails

below the rack and place the food on top of the rack.

PLEASE NOTE

–

Do not to use the broil pan under the rack in the lower position.

Cleaning Your Countertop Oven

Before cleaning your OSTER

Countertop Oven, press Stop/Cancel button twice, unplug it and

allow it to cool. To clean, wipe with damp cloth.

CAUTION:

DO NOT IMMERSE IN WATER!

Make sure to use only mild, soapy water.

Abrasive cleaners, scrubbing brushes and chemical cleaners will damage the

coating on this unit.

Empty crumb tray frequently to avoid accumulation

of crumbs.

Countertop oven racks are dishwasher

safe (top of dishwasher only).

This appliance has no user serviceable parts. Any servicing beyond that described in the Cleaning

Section should be performed by an Authorized Service Representative only. See Warranty Section.

Figu re 3

For Baking

For Grilling

or Broiling

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed to

reduce the risk of ﬁre, electric shock, and/or injury to persons including the following:

1. Read all instructions before using this product.

This appliance generates heat during use. Do not touch hot surfaces. Use

handles or knobs. Always protect your hands with non-slip oven mitts or similar.

3. To protect against electric shock, do not place or immerse cord, plugs, or

appliance in water or other liquid.

4. This appliance is not to be used by children or by persons with reduced physical,

sensory or mental capabilities.

5. Close supervision is necessary when any appliance is used near children.

Children should not play with the appliance.

6. Unplug from outlet when not in use, before putting on or taking off parts

and before cleaning. Allow to cool before putting on or taking off parts, and

before cleaning. To disconnect, turn any control to OFF, then unplug power

cord from outlet. Do not disconnect by pulling on cord. Always grasp the

plug and pull to disconnect.

7. Do not operate any appliance with a damaged cord or plug or after the appliance

malfunctions, or has been damaged in any manner. Do not attempt to replace or

splice a damaged cord. Return appliance to the manufacturer (see warranty) for

examination, repair or adjustment.

8. The use of accessory attachments not recommended by the appliance

manufacturer may cause injuries.

9. Do not use outdoors or for commercial purposes.

10. Do not let cord hang over edge of table or counter, or touch hot surfaces.

11. Do not place on or near wet surfaces, or heat sources such as a hot gas or electric

burner, or in a heated oven.

12. Extreme caution must be used when moving an appliance or removing a pan,

containing hot oil or other hot liquids. Always protect your hands with non-slip

oven mitts or similar.

13. Do not use appliance for other than intended use. Misuse can cause injuries.

Intended for household countertop use only. Keep 6 inches (152 mm) clear from

the wall and on all sides. Always use appliance on a dry, stable, level surface.

14. Oversize foods or metal utensils must not be inserted in a countertop oven as

they may create a ﬁre or risk of electric shock.

15. A ﬁre may occur if the countertop oven is covered, touching or near ﬂammable

materials, including curtains, draperies, towels, walls, and the like, when in

operation. Do not store any item on top of the appliance when in operation.

16. Do not clean with metal scouring pads. Pieces can break off the pad and touch

electrical parts, creating a risk of electric shock.

17. Extreme caution should be exercised when using containers constructed of

materials other than metal or glass.

18. Do not store any materials, other than manufacturers recommended accessories,

in this oven when not in use.

19. Do not place any of the following materials in the oven: paper, cardboard,

plastic, or any materials that may catch ﬁre or melt.

20. Do not cover crumb tray or any part of the oven with metal foil. This will cause

overheating of the oven.

21. Empty the crumb tray after each use.

22. The glass door is made of tempered glass. Always inspect the glass door for chips,

cracks or any other damage. Do not use the countertop oven if the glass door is

damaged, as the glass may shatter during use.

23. Do not use with a programmer, timer, wireless plug adapter or outlet that allows

control remotely, or connect to a circuit that is regularly switched on and off by

the utility.

SAVE THESE INSTRUCTIONS

HOUSEHOLD USE ONLY

North American models with polarized plugs:

POWER CORD INSTRUCTIONS:

A short power-supply cord or detachable power-supply cord is provided to reduce risks

resulting from becoming entangled in or tripping over a longer cord. Longer detachable

power-supply cords or extension cords are available and may be used if care is exercised

in their use. If a long detachable power-supply cord or extension cord is used:

a. The marked electrical rating of the cord set or extension cord should be at

least as great as the electrical rating of the appliance;

b. The cord should be arranged so that it will not drape over the countertop

or tabletop where it can be pulled on by children or tripped over

unintentionally; and

c. If the appliance is of the grounded type, the cord set or extension cord

should be a grounding-type 3-wire cord.

Do not pull, twist or otherwise abuse the power cord.

NOTICES

1. Some countertop and table surfaces are not designed to withstand the prolonged

heat generated by certain appliances. Do not set the heated unit on a ﬁnished wood

table. We recommend placing a hot pad or trivet under your countertop oven to

prevent possible damage to the surface.

2. During initial use of this appliance, some slight smoke and/or odor may be

detected. This is normal with many heating appliances and will not recur after

a few uses.

POLARIZED PLUG

This appliance has a polarized plug, (one blade is wider than

the other). As a safety feature to reduce the risk of electrical

shock, this plug is intended to t in a polarized outlet only

one way. If the plug does not t fully in the outlet, reverse

the plug. If it still does not t, contact a qualied electrician.

Do not attempt to defeat this safety feature or modify the plug in any way. If the plug ts

loosely into the AC outlet or if the AC outlet feels warm do not use that outlet.

To Use the Convection Fan Bake Function

When you select the Convection Bake the convection fan will turn on and circulate air

allowing the food to cook evenly and faster.

Place oven rack into the desired position before heating the oven.

(See “Positioning Rack” Section)

Arrange food on the wire rack or in the baking pan.

Push the Convection Bake button until “Convection Bake” lights up on display.

Use the Temp arrow keys to select desired temperature.

Push Timer arrow keys to select desired time.

Push the Start button.

The oven will go into the preheat mode. To bypass the preheat mode press the start

button a second time.

Interior light turns on when timer is on. At the end of cooking cycle the light turns off automatically.

NOTE – Both heating elements will cycle ON and OFF to maintain the desired temperature,

and may not glow.

When baking is completed, open door fully and remove food carefully.

To Use the Broil Function

Place the pan into the guide rails below the rack and place the food on top of the rack.

(See “Positioning Rack” Section)

Place broil rack in oven.

Push Broil button until the word “Broil” lights up on display.

Push Timer arrows to select the desired time.

Push the Start button.

Interior light turns on when timer is on. At the end of cooking cycle the light turns off automati

cally.

NOTE – The top heating element will cycle ON and OFF to maintain desired temperature,

and may not glow.

When broiling is completed, open door fully and remove food carefully.

WARNING: DO NOT LEAVE COUNTERTOP OVEN UNATTENDED.

To Use the Toast Function

Place oven rack into the desired position before heating the oven. (See “Positioning Rack” Sec-

tion)

NOTE – Different types of bread require different settings. Lighter breads and wafﬂes

require a lighter setting. Darker breads, mufﬁns, and English mufﬁns require a darker setting.

Arrange food on the wire rack.

Push the Toast button. Use arrows to select Toast Shade.

Press the Start button.

When toasting is completed, open door fully and remove food carefully.

Storing Your Countertop Oven

Allow the appliance to cool completely before storing. If storing the countertop oven for long

periods of time make certain that the countertop oven is clean and free of food particles. Store

the countertop oven in a dry location such as on a table or countertop or cupboard shelf.

Other than the recommended cleaning, no further user maintenance should be necessary.

Loading ...

User Manual Oster TSSTTVFDDG-DS French Door Countertop Oven

Documents for Oster TSSTTVFDDG-DS

User Manual

Specifications

Photos
