Thank you for purchasing the VALKIA HU-H01 Ultrasonic Cool Mist Humidifier.
Please read this user manual carefully and keep it in a safe place for future
reference. If you need any assistance, please contact our support team with
your product model number and Amazon order number.
Features
Package Content
• 1 x VALKIA Ultrasonic Cool Mist Humidifier
• 1 x User Manual
Customizedappearance,fashionableandgraceful
RotarySwitch:Mistadjustmentatwill,theoperationissimpleandconvenient
3L large capacity water tank with depth gauge, up to 12 hours of usage
Built-in water filtration device
AUTOShut-off:Itstopsautomaticallywhenwaterranout,whichisenergy-saving
andsafe
1.
2.
3.
4.
5.
- 01 -
Product Diagram
Nozzle
Water Tank
Radiator Cap
Positioning plug
LED indicator
Rotary Switch
Fragrance Box
Floating Ball
- 02 -
Place the humidifier horizontally in a suitable place
Turn the water tank upside down and open the cap
Fill the water tank with clean water and screw the cap tight
Put the water tank back
Connect the power supply
Twist the Rotary Switch to adjust the vapour flow. The LED indicator will turn
GREEN when it works
The LED indicator turns RED and safety device automatically stops working when
the water is used up. Please cut off power, repeat the first step and add water
Before moving the humidifier, please turn off the power and move the entire
machine to prevent the humidifier from malfunctioning
1.
2.
3.
4.
5.
6.
7.
8.
Do NOT use water warmer than 40 °C / 104 °F
Use only clean water
Do not add water from nozzles
Do not put the nozzle towards other appliances
Preference temperature: 5 °C-40 °C, relative humidity: less than 80% RH
●
●
●
●
●
How to Use
Important
- 03 -
User Manual
Ultrasonic Cool Mist Humidifier
Model: HU-H01
Do not disassemble baseboard for repair without authorization.
Do not use it when water depletes. Always turn off and unplug the device
when not in use.
Do not scratch sprayer plate with something hard.
Please keep it away from children and sunlight.
Do not add water from mist vent and you must unplug the device when
adding water and cleaning.
When moving the humidifier, please hold the bottom to prevent it from falling.
This device can not be used by children and mental patients without supervi-
sion.
1.
2.
3.
4.
5.
6.
7.
Please use purified water. Clean sprayer plate and tank per week and
replace water frequently to keep the humidifier clean.
When device was not used for long time, please restore it with the original
package after cleaning and wiping.
Drip 10ml acetum (according to scale) on the surface of sprayer plate,
immerse for 2-5 minutes and then flush it.
Add descaling agent or acetum and 1/4 water into tank , shake and then
flush it.
1.
2.
3.
4.
- 04 - - 05 - - 06 -
Specifications Safety Cautions
Care & Maintenance
Trouble Shooting
Rated Voltage
Dimension
Water tank Capacity
Applying Space
Power cord length
120V～ 60Hz
160*160*318mm
3L
20-30㎡
1.2m
Rated Power
Gross Weight
Working time
Misting Output
Noise Level
25W
1.35kg
8-12 hours
280-380mL/h
Less than 38 dB
Problems
No Power
Power is connected,
but no mist coming
out
The sprayed mist
has odor
No water or too little water in
the water tank
Check water level and
pour enough water into
the water tank
Radiator cap is not tightened
There is dirt in the base or the
water in the water tank is not
clean
Tighten the radiator cap
Cleaning the base and
the inner wall of the water
tank or change a box of
clean water
Possible Reasons
Poor connection
The mist button is not rotated
Solutions
Plug in correctly
Rotate the button again
Water tank leaking
