Table of Contents
Read me first
Getting started
5 Package contents
6 Device layout
8 Charging the battery
10 Using a memory card
12 Turning the device on and off
12 Locking and unlocking the screen
Basics
13 Using the touch screen
16 Home screen layout
20 Notifications and quick setting panels
22 Opening apps
22 Installing or uninstalling apps
24 Entering text
26 Screen capture
27 My Files
28 Power saving feature
Network connectivity
29 Wi-Fi
Motions & usability features
30 Motions and gestures
32 Multi window
Personalizing
35 Managing the Home and Apps screens
36 Setting wallpaper and ringtones
37 Changing the screen lock method
38 Private mode
40 Setting up accounts
Contacts
41 Adding contacts
41 Managing contacts
Camera
44 Basic shooting
45 Shooting modes
46 Camera settings
Gallery
48 Viewing content on the device
Table of Contents
3
76 Performing a data reset
Settings
77 About Settings
77 Connections
79 Device
83 Personal
87 System
Appendix
89 Troubleshooting
94 Removing the battery
Health and Safety
Useful apps and features
49 S Planner
51 Email
53 Video
54 Clock
55 Calculator
55 Memo
56 Smart Manager
57 Microsoft apps
57 Google apps
Connecting with other
devices
59 Bluetooth
61 Wi-Fi Direct
62 SideSync
69 Screen Mirroring
71 Mobile printing
Device & data manager
72 Transferring data from your previous
device
74 Using the device as a removable disk
for data transfer
74 Updating the device
75 Backing up and restoring data
4
Read me first
Please read this manual before using the device to ensure safe and proper use.
•
Descriptions are based on the device’s default settings.
•
Some content may differ from your device depending on the region, service provider, or
device’s software.
•
Content (high quality content) that requires high CPU and RAM usage will affect the
overall performance of the device. Apps related to the content may not work properly
depending on the device’s specifications and the environment that it is used in.
•
Samsung is not liable for performance issues caused by apps supplied by providers other
than Samsung.
•
Samsung is not liable for performance issues or incompatibilities caused by edited
registry settings or modified operating system software. Attempting to customize the
operating system may cause the device or apps to work improperly.
•
Software, sound sources, wallpapers, images, and other media provided with this device
are licensed for limited use. Extracting and using these materials for commercial or other
purposes is an infringement of copyright laws. Users are entirely responsible for illegal
use of media.
•
Default apps that come with the device are subject to updates and may no longer be
supported without prior notice. If you have questions about an app provided with
the device, contact a Samsung Service Centre. For user-installed apps, contact service
providers.
•
Modifying the device’s operating system or installing softwares from unofficial sources
may result in device malfunctions and data corruption or loss. These actions are violations
of your Samsung licence agreement and will void your warranty.
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Note: notes, usage tips, or additional information
5
Getting started
Package contents
Check the product box for the following items:
•
Device
•
Quick start guide
•
USB cable
•
USB power adapter
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
Getting started
6
Device layout
Touch screen
Recent apps button
Home button
Back button
Headset jack
Volume button
Power button
Front camera
Multipurpose jack
Speaker
GPS antenna
Microphone
Memory card slot
Rear camera
Getting started
7
•
Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.
•
Using a Samsung-approved screen protector is recommended. Unapproved screen
protectors may cause the sensors to malfunction.
•
Do not allow water to contact the touch screen. The touch screen may malfunction
in humid conditions or when exposed to water.
Buttons
Button Function
Power
•
Press and hold to turn the device on or off.
•
Press to turn on or lock the screen.
Recent apps
•
Tap to open the list of recent apps.
•
Tap and hold to access additional options for the current
screen.
Home
•
Press to turn on the screen while the screen is locked.
•
Press to return to the Home screen.
•
Press and hold to launch
Google
.
Back
•
Tap to return to the previous screen.
Volume
•
Press to adjust the device volume.
Getting started
8
Charging the battery
Use the charger to charge the battery before using it for the first time. A computer can be also
used to charge the battery by connecting it to the device using the USB cable.
Use only Samsung-approved chargers, batteries, and cables. Unapproved chargers or
cables can cause the battery to explode or damage the device.
•
When the battery power is low, the battery icon appears empty.
•
If the battery is completely discharged, the device cannot be turned on
immediately when the charger is connected. Allow a depleted battery to charge for
a few minutes before turning on the device.
•
If you use multiple apps at once, network apps, or apps that need a connection
to another device, the battery will drain quickly. To avoid disconnecting from the
network or losing power during a data transfer, always use these apps after fully
charging the battery.
1
Connect the USB cable to the USB power adapter and then plug the end of the USB cable
into the multipurpose jack.
Connecting the charger improperly may cause serious damage to the device. Any
damage caused by misuse is not covered by the warranty.
Getting started
9
2
Plug the USB power adapter into an electric socket.
•
The device can be used while it is charging, but it may take longer to fully charge
the battery.
•
If the device receives an unstable power supply while charging, the touch screen
may not function. If this happens, unplug the charger from the device.
•
While charging, the device may heat up. This is normal and should not affect the
device’s lifespan or performance. If the battery gets hotter than usual, the charger
may stop charging.
•
If the device is not charging properly, take the device and the charger to a
Samsung Service Centre.
3
After fully charging, disconnect the device from the charger. First unplug the charger
from the device, and then unplug it from the electric socket.
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
Reducing the battery consumption
Your device provides options that help you save battery power. By customizing these options
and deactivating features in the background, you can use the device longer between charges:
•
When you are not using the device, switch to sleep mode by pressing the Power button.
•
Close unnecessary apps using the task manager.
•
Deactivate the Bluetooth feature.
•
Deactivate the Wi-Fi feature.
•
Deactivate auto-syncing of apps.
•
Decrease the backlight time.
•
Decrease the screen brightness.
Getting started
10
Using a memory card
Installing a memory card
Your device accepts memory cards with maximum capacity of 128 GB. Depending on the
memory card manufacturer and type, some memory cards may not be compatible with your
device.
•
Some memory cards may not be fully compatible with the device. Using an
incompatible card may damage the device or the memory card, or corrupt the data
stored in it.
•
Use caution to insert the memory card right-side up.
•
The device supports the FAT and the exFAT file systems for memory cards. When
inserting a card formatted in a different file system, the device asks to reformat the
memory card.
•
Frequent writing and erasing of data shortens the lifespan of memory cards.
•
When inserting a memory card into the device, the memory card’s file directory
appears in the
My Files
→
SD card
folder.
1
Open the cover of the memory card slot.
2
Insert a memory card with the gold-coloured contacts facing downwards.
3
Push the memory card into the slot until it locks in place.
4
Close the cover of the memory card slot.
Getting started
11
Removing the memory card
Before removing the memory card, first unmount it for safe removal. On the Home screen, tap
Apps
→
Settings
→
Storage
→
Unmount SD card
.
1
Open the cover of the memory card slot.
2
Push the memory card until it disengages from the device, and then pull it out.
3
Close the cover of the memory card slot.
Do not remove the memory card while the device is transferring or accessing
information. Doing so can cause data to be lost or corrupted or can damage the
memory card or device. Samsung is not responsible for losses that result from the
misuse of damaged memory cards, including the loss of data.
Formatting the memory card
A memory card formatted on a computer may not be compatible with the device. Format the
memory card on the device.
On the Home screen, tap Apps
→
Settings
→
Storage
→
Format SD card
→
Format SD card
→
Erase everything
.
Before formatting the memory card, remember to make backup copies of all
important data stored in the device. The manufacturer’s warranty does not cover loss
of data resulting from user actions.
Getting started
12
Turning the device on and off
Press and hold the Power button for a few seconds to turn on the device.
When you turn on your device for the first time or after performing a data reset, follow the on-
screen instructions to set up your device.
To turn off the device, press and hold the Power button, and then tap
Power off
.
Follow all posted warnings and directions from authorized personnel in areas where
the use of wireless devices is restricted, such as airplanes and hospitals.
Locking and unlocking the screen
Pressing the Power button turns off the screen and locks it. Also, the screen turns off and
automatically locks if the device is not used for a specified period.
To unlock the screen, press the Power button or the Home button and flick your finger in any
direction within the unlock screen area.
You can change the unlock code to unlock the screen. Refer to Changing the screen lock
method for more information.
13
Basics
Using the touch screen
•
Do not allow the touch screen to come into contact with other electrical devices.
Electrostatic discharges can cause the touch screen to malfunction.
•
To avoid damaging the touch screen, do not tap it with anything sharp or apply
excessive pressure to it with your fingertips.
•
The device may not recognize touch inputs close to the edges of the screen, which
are outside of the touch input area.
•
Leaving the touch screen idle for extended periods may result in afterimages
(screen burn-in) or ghosting. Turn off the touch screen when you do not use the
device.
•
It is recommended to use fingers when you use the touch screen.
Tapping
To open an app, to select a menu item, to press an on-screen button, or to enter a character
using the keyboard on the screen, tap it with a finger.
Basics
14
Tapping and holding
Tap and hold an item or the screen for more than 2 seconds to access available options.
Dragging
To move an item, tap and hold it and drag it to the target position.
Double-tapping
Double-tap on a webpage or image to zoom in. Double-tap again to return.
Basics
15
Flicking
Flick left or right on the Home screen or the Apps screen to see another panel. Flick up or
down to scroll through a webpage or a list of items, such as contacts.
Spreading and pinching
Spread two fingers apart on a webpage, map, or image to zoom in a part. Pinch to zoom out.
Basics
16
Home screen layout
Home screen
The Home screen is the starting point for accessing all of the device’s features. It displays
widgets, shortcuts to apps, and more. Widgets are small apps that launch specific app
functions to provide information and convenient access on your Home screen.
To view other panels, scroll left or right, or tap one of the screen indicators at the bottom of
the screen. To customize the Home screen, refer to Managing the Home screen.
A widget
An app A folder
Screen indicators
Apps screen icon
Favourite apps
Basics
17
Home screen options
On the Home screen, tap and hold an empty area, or pinch your fingers together to access
the available options.
Basics
18
Apps screen
The Apps screen displays icons for all apps, including newly installed apps.
On the Home screen, tap Apps to open the Apps screen. To view other panels, scroll left or
right, or select a screen indicator at the bottom of the screen. To customize the Apps screen,
refer to Managing the Apps screen.
Edit the apps
screen
An app
A screen indicator
Basics
19
Indicator icons
Indicator icons appear on the status bar at the top of the screen. The icons listed in the table
below are most common.
The status bar may not appear at the top of the screen in some apps. To display the
status bar, drag down from the top of the screen.
Icon Meaning
Wi-Fi connected
Bluetooth feature activated
GPS activated
Synced with the web
Connected to computer
Alarm activated
Mute mode activated
Flight mode activated
Error occurred or caution required
Battery power level
Basics
20
Notifications and quick setting panels
Using the notifications panel
When you receive new notifications, such as messages, indicator icons appear on the status
bar. To see more information about the icons, open the notifications panel and view the
details.
To open the notifications panel, drag the status bar downwards. To close the notifications
panel, drag the bar from the bottom of the screen upwards.
You can use the following functions on the notifications panel.
Launch Settings.
Clear all notifications.
Adjust the brightness.
Change user.
Activate or deactivate options.
Tap and hold a button to view
more detailed settings.
Tap a notification and perform
various actions.
Rearrange quick setting
buttons.
Basics
21
Rearranging quick setting buttons
To rearrange quick setting buttons on the notifications panel, tap
EDIT
, tap and hold an item,
drag the item to another location, and then tap
DONE
.
Using the quick setting panel
You can activate or deactivate some features on the notifications panel.
Tap the following options to activate or deactivate them. You can view more detailed settings
if you tap and hold a button.
•
Wi-Fi
: Refer to Wi-Fi for more information.
•
Location
: Activate or deactivate the GPS feature.
•
Sound
/
Mute
: Select a sound mode.
•
Screen rotation
: Allow or prevent the interface from rotating when you rotate the device.
Some apps do not allow screen rotation.
•
Bluetooth
: Refer to Bluetooth for more information.
•
Power saving
: Refer to Power saving for more information.
•
Flight mode
: Refer to Flight mode for more information.
•
Do not disturb
: Activate or deactivate blocking mode. In blocking mode, the device will
block notifications. To select which notifications will be blocked, tap
Settings
→
Sounds
and notifications
→
Do not disturb
.
•
U. power saving
: Refer to Power saving mode for more information.
•
Smart stay
: When you activate this feature, the screen stays on as long as you look at it.
•
Private mode
: Refer to Private mode for more information.
•
Screen Mirroring
: Refer to Screen Mirroring for more information.
•
Sync
: When you activate this feature, the device automatically syncs apps, such as
calendar or email.
Basics
22
Opening apps
On the Home screen or the Apps screen, select an app icon to open it.
To open the list of recently-used apps, tap
and select an app icon to open.
Closing an app
Tap and drag an app icon to the top or bottom to close it. To close all running apps, tap
CLOSE ALL
.
Installing or uninstalling apps
Galaxy Apps
Use this app to purchase and download apps.
Tap
Galaxy Apps
on the Apps screen.
This app may not be available depending on the region or service provider.
Installing apps
Browse apps by category or tap
SEARCH
to search for a keyword.
Select an app to view information about it. To download free apps, tap
INSTALL
. To purchase
and download apps where charges apply, tap the button that shows the app’s price.
To change the auto update settings, tap
→
Settings
→
Auto update apps
, and
then select an option.
Basics
23
Play Store
Use this app to purchase and download apps.
Tap
Play Store
on the Apps screen.
Installing apps
Browse apps by category or tap to search for a keyword.
Select an app to view information about it. To download free apps, tap
INSTALL
. To purchase
and download apps where charges apply, tap the price and follow the on-screen instructions.
To change the auto update settings, tap
→
Settings
→
Auto-update apps
, and
then select an option.
Managing apps
Uninstalling or disabling apps
To disable default apps, open the Apps screen and tap
EDIT
. appears on the apps that you
can disable. Select an app and tap
DISABLE
→
DONE
.
To uninstall downloaded apps, open the Apps screen and tap
EDIT
→
→
UNINSTALL
→
DONE
. Alternatively, on the Apps screen, tap
Settings
→
Applications
→
Application
manager
, select an app, and then tap
UNINSTALL
.
Enabling apps
On the Apps screen, tap
Settings
→
Applications
→
Application manager
, scroll left to
DISABLED
, select an app, and then tap
ENABLE
.
•
Disabling apps: Disable selected default apps that cannot be uninstalled from the
device. You cannot use disabled apps.
•
Uninstalling apps: Uninstall downloaded apps.
Basics
24
Entering text
Keyboard layout
A keyboard appears automatically when you enter text to send messages, create memos, and
more.
Text entry is not supported in some languages. To enter text, you must change the
input language to one of the supported languages.
Break to the next line.
Move the cursor.
Delete a preceding character.
Enter punctuation marks.
Enter uppercase. For all caps,
tap it twice.
Change the keyboard settings.
Enter a space.
Changing the input language
Tap
→
Add input languages
, and then select the languages to use. If you select two or
more languages, you can switch between the input languages by sliding the space key left or
right.
Using additional keyboard functions
Tap and hold to use various functions. Other icons may appear instead of depending
on the last function that was used.
•
: Enter text by voice.
Open the Settings.
Start or pause entering text by
voice.
Basics
25
•
: Switch to handwriting mode.
Switch to the standard
keyboard.
•
: Add an item from the clipboard.
•
: Enter emoticons.
•
: Switch to the floating or split keyboard.
•
: Change the keyboard settings.
Dictionary
Look up definitions for words while using certain features, such as when browsing webpages.
1
Tap and hold over a word that you want to look up.
If the word you want to look up is not selected, drag
or to select the desired text.
2
Tap
Dictionary
on the options list.
If a dictionary is not preinstalled on the device, tap
next to a dictionary to download it.
3
View the definition in the dictionary pop-up window.
Tap the definition on the screen to view more definitions. In the detailed view, tap
to
add the word to your favourite words list or tap
SEARCH WEB
to use the word as a search
term.
Basics
26
Copying and pasting
1
Tap and hold over text.
2
Drag or to select the desired text, or tap
Select all
to select all text.
3
Tap
Copy
or
Cut
. The selected text is copied to the clipboard.
4
Place the cursor where the text is to be inserted and tap
→
Paste
. To paste text that
you have previously copied, tap
→
Clipboard
and select the text.
Screen capture
Capture a screenshot while using the device.
Press and hold the Home button and the Power button simultaneously. You can view
captured images in
Gallery
. After capturing a screenshot, you can edit the image and share it
with others.
You can also capture screenshots using other methods. Refer to Palm swipe to capture for
more information.
It is not possible to capture a screenshot while using some apps.
Basics
27
My Files
Use this app to access various files stored in the device or in other locations, such as cloud
storage services.
Tap
My Files
on the Apps screen.
Access additional options.
View files saved in cloud
storage services.
View files by categories.
Search for files or folders.
View recent files.
View files stored in the device.
View storage information.
Basics
28
Power saving feature
Power saving mode
Save the battery power by limiting the device’s functions.
On the Apps screen, tap
Settings
→
Battery
→
Power saving mode
, and then tap the switch
to activate it.
To automatically activate power saving mode when the remaining battery power reaches the
preset level, tap
Start power saving
and select an option.
Ultra power saving mode
Use this mode to extend the device’s battery power. In ultra power saving mode, the device
performs the following:
•
Restricts the available apps to essential and selected apps only.
•
Deactivates the Bluetooth feature.
On the Apps screen, tap
Settings
→
Battery
→
Ultra power saving mode
, and then tap the
switch to activate it. Alternatively, open the quick setting panel and tap
U. power saving
to
activate it.
To add an app to the Home screen, tap
and select an app.
To remove an app from the Home screen, tap
MORE
→
Remove
, select an app with , and
then tap
DONE
.
To change the settings for ultra power saving mode, such as network connectivity or sound,
tap
MORE
→
Settings
.
To deactivate ultra power saving mode, tap
MORE
→
Disable ultra power saving mode
.
The usage time left shows the time remaining before the battery power runs
out. Usage time left may vary depending on your device settings and operating
conditions.
29
Network connectivity
Wi-Fi
Connect the device to a Wi-Fi network to use the Internet or share media files with other
devices. Refer to Wi-Fi for additional options.
Turn off Wi-Fi to save the battery when not in use.
1
On the Apps screen, tap
Settings
→
Wi-Fi
, and then tap the
Wi-Fi
switch to activate it.
2
Select a network from the Wi-Fi networks list. Networks that require a password appear
with a lock icon.
3
Tap
CONNECT
.
Once the device connects to a Wi-Fi network, the device will reconnect to that
network each time it is available without requiring a password. To prevent the device
connecting to the network automatically, select it from the list of networks and tap
FORGET
.
30
Motions & usability features
Motions and gestures
Excessive shaking or impact on the device may result in unintended inputs. Control
motions properly.
Mute
On the Apps screen, tap
Settings
→
Motions and gestures
, and then tap the
Mute
switch to
activate it.
Cover the screen with your palm or turn the device over to mute alarms.
Motions & usability features
31
Palm swipe to capture
On the Apps screen, tap
Settings
→
Motions and gestures
, and then tap the
Palm swipe to
capture
switch to activate it.
Place the side of your hand on the screen and sweep it across the screen from the right to
the left or vice versa to capture a screenshot. You can view captured images in
Gallery
. After
capturing a screenshot, you can edit the image and share it with others.
It is not possible to capture a screenshot while using some apps.
Motions & usability features
32
Multi window
About Multi window
Multi window lets you run two apps at the same time in the split screen view. You can also run
multiple apps at the same time in the pop-up view.
Some apps may not support this feature.
Split screen view
1
Tap to open the list of recently used apps.
2
Swipe upwards or downwards and tap on a recent app window.
The selected app will launch in the upper window.
3
Select another app to launch.
You can also launch the split screen view by tapping and holding .
Motions & usability features
33
Using additional options
When using apps in the split screen view, select an app window and tap the circle between
the app windows to access the following options:
•
: Switch locations between app windows.
•
: Drag and drop text or copied images from one window to another. Tap and hold an
item in the selected window and drag it to a location in another window.
Some apps may not support this feature.
•
: Maximize the window.
•
: Close the app.
Motions & usability features
34
Adjusting the window size
Drag the circle between the app windows up or down to adjust the size of the windows.
Pop-up view
1
On the Apps screen, launch an app to use in the pop-up view.
2
Drag down diagonally from either end of the top edge.
The app screen will appear in the pop-up view.
Close the app.
Drag and drop content.
Minimize the window.
Maximize the window.
Moving pop-up windows
To move a pop-up window, tap and hold the circle on a window and drag it to a new location.
35
Personalizing
Managing the Home and Apps screens
Managing the Home screen
Adding items
Tap and hold an app from the Apps screen, and then drag it to the Home screen.
To add widgets, open the Home screen, tap and hold an empty area, tap
Widgets
, tap and
hold a widget, and then drag it to the Home screen.
Moving and removing an item
Tap and hold an item on the Home screen, and then drag it to a new location.
To move the item to another panel, drag it to the side of the screen.
To remove an item, tap and hold the item. Then, drag it to
Remove
that appears at the top of
the screen.
Creating a folder
1
On the Home screen, tap and hold an app, and then drag it over another app.
2
Enter a folder name.
To add more apps to the folder, tap and hold another app, and then drag it to the folder.
Managing panels
On the Home screen, tap and hold an empty area to add, move, or remove a panel.
To add a panel, scroll left to the last panel, and then tap
.
To move a panel, tap and hold a panel preview, and then drag it to a new location.
To remove a panel, tap and hold a panel preview, and then drag it to
Remove
at the top of
the screen.
To set a panel as the main Home screen, tap
.
Personalizing
36
Managing the Apps screen
Changing the sorting method
On the Apps screen, tap
EDIT
. Tap and hold an item and drag it to a new location.
To move the item to another panel, drag it to the side of the screen.
Setting wallpaper and ringtones
Setting wallpaper
Set an image or photo stored in the device as wallpaper for the Home screen or the locked
screen.
1
On the Home screen, tap and hold an empty area, and then tap
Wallpapers
. Alternatively,
on the Apps screen, tap
Settings
→
Wallpaper
.
2
Select a screen to change or apply wallpaper to.
3
Scroll left or right and select from images displayed at the bottom of the screen.
To select photos taken by the device’s camera or other images, tap
From Gallery
.
4
Tap
SET AS WALLPAPER
or
DONE
.
Changing ringtones
Change ringtones for notifications.
On the Apps screen, tap
Settings
→
Sounds and notifications
→
Sounds
→
Default notification sound
, select a ringtone, and then tap
OK
.
Personalizing
37
Changing the screen lock method
You can change the way that you lock the screen to prevent others from accessing your
personal information.
On the Apps screen, tap
Settings
→
Lock screen and security
→
Screen lock type
, and then
select a screen lock method. The device requires an unlock code whenever unlocking it.
If the unlock code is forgotten, take the device to a Samsung Service Centre to reset it.
Pattern
Draw a pattern by connecting four dots or more, and then draw the pattern again to verify it.
Set a backup PIN to unlock the screen when you forget the pattern.
PIN
A PIN consists of numbers only. Enter at least four numbers, and then enter the password
again to verify it.
Password
A password consists of characters and numbers. Enter at least four characters including
numbers and symbols, and then enter the password again to verify it.
Personalizing
38
Private mode
Hide personal content in your device to prevent others from accessing it.
In private mode, you can hide items in
Gallery
,
Video
,
Music
,
My Files
, and
Internet
.
Activating private mode
1
On the Apps screen, tap
Settings
→
Privacy
→
Private mode
, and then tap the switch to
activate it.
If you are activating private mode for the first time, follow the on-screen instructions to
set up a private mode access code.
2
Follow the on-screen instructions to enter the preset private mode access code.
Private mode is activated and
appears on the status bar.
You can view and access the hidden items only when private mode is activated. To
hide items stored in the private folder, deactivate private mode.
Hiding content
1
On the Apps screen, launch an app to hide items.
2
Select an item and tap
MORE
→
Move to Private
.
If private mode is not activated, follow the on-screen instructions to enter the preset
private mode access code.
The selected items will be moved to the private folder.
Personalizing
39
Viewing hidden content
You can view hidden items only when private mode is activated.
1
On the Apps screen, tap
Settings
→
Privacy
→
Private mode
, and then tap the switch to
activate it.
2
Follow the on-screen instructions to enter the preset private mode access code.
3
On the Apps screen, tap
My Files
→
Private
.
Items moved to the private folder will appear on the screen. For bookmarks, you can view
them with the
Internet
app.
Unhiding content
1
In the private folder, tap and hold an item, and then tick items to unhide.
2
Tap
MORE
→
Remove from Private
.
3
Select a folder to move the items to, and then tap
MOVE HERE
.
The items will be moved to the selected folder.
Automatically deactivating private mode
You can set the device to automatically deactivate private mode each time the screen turns
off.
1
On the Apps screen, tap
Settings
→
Privacy
→
Private mode
, and then tap the switch to
activate it.
2
Follow the on-screen instructions to enter the preset private mode access code.
3
Tap the
Auto disable
switch to activate it.
When the
Auto disable
option is enabled, the device will fail to transfer files to the
private folder if the screen turns off during transfer.
Personalizing
40
Setting up accounts
Adding accounts
Some apps used on your device require a registered account. Create accounts to have the
best experience with your device.
On the Apps screen, tap
Settings
→
Accounts
→
Add account
and select an account service.
Then, follow the on-screen instructions to complete the account setup.
To sync content with your accounts, select an account and tick items to sync.
Removing accounts
On the Apps screen, tap
Settings
→
Accounts
, select an account type then an account, and
tap
MORE
→
Remove account
.
41
Contacts
Adding contacts
Moving contacts from other devices
You can move contacts from other devices to your device. Refer to Transferring data from
your previous device for more information.
Creating contacts manually
1
On the Apps screen, tap
Contacts
→
Contacts
.
2
Tap and enter contact information.
•
: Add an image.
•
/ : Add or delete a contact field.
3
Tap
SAVE
.
Managing contacts
Editing a contact
1
On the Apps screen, tap
Contacts
.
2
Select a contact to edit and tap EDIT.
3
Edit the contact information or tap
ADD ANOTHER FIELD
to add more contact
information.
4
Tap
SAVE
.
Contacts
42
Deleting a contact
Select a contact to delete and tap MORE
→
DELETE.
Sharing a contact
Tap MORE
→
Share contact
and then select a sharing method.
Managing groups
On the Apps screen, tap
Contacts
→
GROUPS
.
Creating a new group
Tap ADD, enter a group name, and then tap
SAVE
.
Adding contacts to a group
Select a group, and then tap
ADD
. Select contacts to add, and then tap
DONE
.
Deleting a group
Tap
DELETE
, select user-added groups, and then tap
DELETE
.
Sending a message to group members
Select a group, tap MORE
→
Send message
or
Send email
, select members, tap
DONE
, enter
a message, and then tap the send button.
Move contacts to accounts
Move contacts that are saved in the device to your accounts.
On the Apps screen, tap
Contacts
→
Contacts
.
Tap MORE
→
Settings
→
Move device contacts to
→
Google
account or
Samsung account
.
Contacts
43
Importing and exporting contacts
Import contacts from storage services to your device or export contacts from the device to
storage services.
On the Apps screen, tap
Contacts
.
Tap
MORE
→
Settings
→
Import/Export contacts
, and then select an import or export
option.
Searching for contacts
On the Apps screen, tap
Contacts
.
Use one of the following search methods:
•
Scroll up or down the contacts list.
•
Drag a finger along the index at the left side of the contacts list to scroll through it
quickly.
•
Tap the search field at the top of the contacts list and enter search criteria.
Once a contact is selected, take one of the following actions:
•
: Add to favourite contacts.
•
: Compose an email.
Adding shortcuts for contacts to the Home screen
Add shortcuts to contacts that you frequently communicate with on the Home screen.
1
On the Apps screen, tap
Contacts
.
2
Select a contact.
3
Tap
MORE
→
Add shortcut on home screen
.
44
Camera
Basic shooting
Taking photos or recording videos
1
Tap
Camera
on the Apps screen.
2
Tap the image on the preview screen where the camera should focus.
3
Tap to take a photo or tap to record a video.
•
Spread two fingers apart on the screen to zoom in, and pinch to zoom out.
•
To change the focus while recording a video, tap where you want to focus.
Change the shooting
mode.
Start recording a video.
Take a photo.
View photos and videos
you have captured.
Display current mode.
Switch between the
front and rear cameras.
Change camera
settings.
Use this for
delayed-time shots.
Select a
special effect.
Select the
picture size.
•
The camera automatically shuts off when unused.
•
Make sure that the lens is clean. Otherwise, the device may not work properly in
some modes that require high resolutions.
•
The front camera features a wide-angle lens. Minor distortion may occur in wide-
angle photos and does not indicate device performance problems.
Camera
45
Launching Camera on the locked screen
To quickly take photos of special moments, launch
Camera
on the locked screen.
On the locked screen, drag
outside the large circle.
This feature may not be available depending on the region or service provider.
Camera etiquette
•
Do not take photos or record videos of other people without their permission.
•
Do not take photos or record videos where legally prohibited.
•
Do not take photos or record videos in places where you may violate other people’s
privacy.
Shooting modes
Auto
Use this mode to allow the camera to evaluate the surroundings and determine the ideal
mode for the photo.
On the Apps screen, tap
Camera
→
MODE
→
Auto
.
Panorama
Use this mode to take a panoramic photo. The device identifies the photo with in
Gallery
.
On the Apps screen, tap
Camera
→
MODE
→
Panorama
.
To get the best shot, follow these tips:
•
Move the camera slowly in one direction.
•
Keep the image within the frame on the camera’s viewfinder.
•
Avoid taking photos of indistinct backgrounds, such as an empty sky or a plain
wall.
Camera
46
Continuous shot
Use this mode to take a series of photos of moving subjects.
On the Apps screen, tap
Camera
→
MODE
→
Continuous shot
.
Tap and hold
to take several photos continuously.
Beauty face
Use this mode to take a photo with softened faces for gentler images.
On the Apps screen, tap
Camera
→
MODE
→
Beauty face
.
Sound & shot
Use this mode to take a photo with sound clip. The device identifies the photos with in
Gallery
.
On the Apps screen, tap
Camera
→
MODE
→
Sound & shot
.
Sports
Use this mode to take a photo of fast-moving subjects.
On the Apps screen, tap
Camera
→
MODE
→
Sports
.
Camera settings
On the Apps screen, tap
Camera
→
SETTINGS
. Not all of the following options are available
in both still camera and video camera modes.
•
Video size (rear)
: Select a resolution. Higher resolutions result in higher quality videos,
however they will take up more memory.
•
Gesture control
: Set the device to detect your palm, so you can use it to take self-
portraits.
•
Save as horizontally flipped
: Invert the image to create a mirror-image of the original
scene, when taking photos with the front camera.
•
View mode
: Change the aspect ratio of the preview screen.
•
Grid lines
: Display viewfinder guides to help composition when selecting subjects.
•
Location tags
: Set the device to attach the location tag to the photo.
Camera
47
•
To improve GPS signals, avoid shooting in locations where the signal may be
obstructed, such as between buildings or in low-lying areas, or in poor weather
conditions.
•
When you share a photo with the location tag attached, the location information
may be exposed to others. To avoid this, when viewing the photo, tap
MORE
→
Details
→
EDIT
, and then tap under
Location
to delete your location
information.
•
Review pictures
: Set the device to show photos after capturing them.
•
Storage location
: Select the memory location for storage.
•
Volume keys function
: Set the device to use the Volume button to control the shutter or
zoom function.
•
Reset settings
: Reset the camera settings.
The available options vary depending on the mode used.
48
Gallery
Viewing content on the device
On the Apps screen, tap
Gallery
and select an image or a video.
Video files show the
icon on the preview thumbnail.
To hide or show the menu bar and the preview thumbnails, tap the screen.
Access additional options.
Move to the previous screen.
Delete the image.Add to the favourites list.
Modify the image.
Share the image with others.
Image thumbnails.
49
Useful apps and features
S Planner
Creating events
1
Tap
S Planner
on the Apps screen.
2
Tap . Alternatively, select a date with no events in it and tap the date again.
If the date already has saved events in it, tap the date and tap
.
3
Enter event details.
Enter a title.
Enter the location of the event.
Add more details.
Select a calendar to use or
sync with.
Set a start and end date for the
event.
Set a reminder for the event.
Attach a map showing the
location of the event.
4
Tap
SAVE
to save the event.
Useful apps and features
50
Creating tasks
1
Tap
S Planner
on the Apps screen.
2
Tap
TASKS
, enter details, and then tap
TODAY
or
TOMORROW
to set a due date.
To add more details, tap
.
3
Tap
SAVE
to save the task.
Syncing events and tasks with your accounts
Tap
S Planner
on the Apps screen.
Tap
Calendar
on the Apps screen.
To add accounts to sync with, tap
MORE
→
Manage calendars
→
Add account
. Then, select
an account to sync with and sign in.
To change an account’s syncing option, open the Apps screen, tap
Settings
→
Accounts
, and
then select an account service.
Useful apps and features
51
Email
Setting up email accounts
Tap
Email
on the Apps screen.
Set up an email account when opening
Email
for the first time.
Enter the email address and password. Tap
NEXT
for a private email account or tap
MANUAL
SETUP
for a company email account. After that, follow the on-screen instructions to complete
the setup.
To set up another email account, tap
MORE
→
Settings
→
Add account
.
If you have more than one email account, you can set one as the default account. Tap
MORE
→
Settings
→
MORE
→
Set default account
, select an account, and then tap
DONE
.
Sending emails
Tap
Email
on the Apps screen.
Tap
at the bottom of the screen to compose an email.
Add a CC or BCC.
Add recipients.
Add recipients from the
contacts list.
Enter the email text.
Enter a subject.
Send the email.
Access additional options.
Attach images, videos and
others.
Useful apps and features
52
Reading emails
Tap
Email
on the Apps screen.
Select an email account to use, and new emails are retrieved. To manually retrieve new emails,
flick up on the screen.
Tap an email to read.
Open attachments.
Reply to the email.
Reply to all recipients.
Add this email address to the
contacts list or view other
options.
Mark the email as a reminder.
Go to the previous or next
email.
Delete the email.
Forward the email.
Access additional options.
Useful apps and features
53
Video
Playing videos
Tap
Video
on the Apps screen.
Select a video to play.
Move the control panel
to the left.
Move forwards or
backwards by dragging
the bar.
Change screen ratio.
Skip to the previous
video. Tap and hold to
move backwards
quickly.
Skip to the next video.
Tap and hold to move
forwards quickly.
Access additional
options.
Move the control panel
to the right.
Pause and resume
playback.
Adjust the volume.
Switch to the pop-up
video player.
Open the playlist.
Useful apps and features
54
Clock
Alarm
On the Apps screen, tap
Clock
→
ALARM
.
Setting alarms
Setting alarms
Set an alarm time and tap
OPTIONS
to set other various alarm options, and then tap
SAVE
.
To open the keypad to enter an alarm time, tap
KEYPAD
.
To activate or deactivate alarms, tap
next to the alarm in the alarms list.
Stopping alarms
Tap
DISMISS
to stop an alarm. If you have previously enabled the snooze option, tap
SNOOZE
to repeat the alarm after a specified length of time.
Deleting alarms
Tap on an alarm in the list of alarms.
World clock
On the Apps screen, tap
Clock
→
WORLD CLOCK
.
Creating clocks
Enter a city name or select a city from the globe, and then tap .
Deleting clocks
Tap on a clock.
Stopwatch
On the Apps screen, tap
Clock
→
STOPWATCH
.
Tap
START
to time an event. Tap
LAP
to record lap times.
Tap
STOP
to stop timing. To clear lap times, tap
RESET
.
Useful apps and features
55
Timer
On the Apps screen, tap
Clock
→
TIMER
.
Set the duration, and then tap
START
.
To open the keypad to enter the duration, tap
KEYPAD
.
Tap
DISMISS
when the timer goes off.
Calculator
Use this app for simple or complex calculations.
Tap
Calculator
on the Apps screen.
To clear the history, tap
CLEAR HISTORY
.
Memo
Use this app to create memos and organize them by category.
Tap
Memo
on the Apps screen.
Composing memos
Tap on the memos list and enter a memo. While composing a memo, use the following
options:
•
Category
: Create or set a category.
•
: Insert images.
•
Voice
: Make a voice recording to insert.
•
Tasks
: Add tick boxes at the beginning of each row to create a list of tasks.
To save the memo, tap
SAVE
.
To edit a memo, tap a memo, and then tap the content of the memo.
Searching for memos
Tap
SEARCH
on the memos list and enter a keyword to search for memos that include the
keyword.
Useful apps and features
56
Smart Manager
The Smart manager provides an overview of the status of your device’s battery, storage, RAM,
and system security. You can also automatically optimize the device with one tap.
Using the quick optimization feature
On the Apps screen, tap
Smart Manager
→
CLEAN ALL
.
The quick optimization feature improves device performance through the following actions.
•
Identifying apps that use excessive battery power and clearing some memory.
•
Deleting unnecessary files and closing apps running in the background.
•
Scanning for malware and phishing attacks.
Using the Smart manager
On the Apps screen, tap
Smart Manager
and select a feature.
Battery
Check the remaining battery power and time to use the device. For devices with low battery
levels, conserve battery power by activating power saving features and closing apps that are
consuming an excessive amount of battery power.
The usage time left shows the time remaining before the battery power runs
out. Usage time left may vary depending on your device settings and operating
conditions.
Storage
Check the status of used and available memory capacity. You can delete unused and residual
files or uninstall apps that you do not use any more.
RAM
Check the amount of available RAM. You can close background apps and reduce the amount
of RAM you are using to speed up your device.
Device security
Check the device’s security status. This feature scans your device for malware and blocks
phishing attacks and malicious websites.
Useful apps and features
57
Microsoft apps
Use the Android versions of various Microsoft products: Word, Excel, PowerPoint, OneNote,
Skype and OneDrive.
Tap
Microsoft Apps
on the Apps screen.
These apps may not be available depending on the region or service provider.
Google apps
Google provides entertainment, social network, and business apps. You may require a Google
account to access some apps. Refer to Private mode for more information.
To view more app information, access each app’s help menu.
Some apps may not be available or may be labelled differently depending on the
region or service provider.
Chrome
Search for information and browse webpages.
Gmail
Send or receive emails via the Google Mail service.
Maps
Find your location on the map, search for locations, and view location information for various
places.
Play Music
Discover, listen to, and share music on your device.
Useful apps and features
58
Play Movies
Watch videos stored on your device and download various content to watch from
Play Store
.
Drive
Store your content on the cloud, access it from anywhere, and share it with others.
YouTube
Watch or create videos and share them with others.
Photos
Manage photos, albums, and videos that you have saved on the device and uploaded to
Google+
.
Hangouts
Chat with your friends individually or in groups and use images, emoticons, and video calls
while you are chatting.
Google
Search quickly for items on the Internet or your device.
Voice Search
Search quickly for items by saying a keyword or phrase.
Google Settings
Configure settings for some features provided by Google.
59
Connecting with other devices
Bluetooth
About Bluetooth
Bluetooth creates a direct wireless connection between two devices over short distances. Use
Bluetooth to exchange data or media files with other devices.
•
Samsung is not responsible for the loss, interception, or misuse of data sent or
received via Bluetooth.
•
Always ensure that you share and receive data with devices that are trusted
and properly secured. If there are obstacles between the devices, the operating
distance may be reduced.
•
Some devices, especially those that are not tested or approved by the Bluetooth
SIG, may be incompatible with your device.
•
Do not use the Bluetooth feature for illegal purposes (for example, pirating copies
of files or illegally tapping communications for commercial purposes).
Samsung is not responsible for the repercussion of illegal use of the Bluetooth
feature.
Pairing with other Bluetooth devices
1
On the Apps screen, tap
Settings
→
Bluetooth
, tap the
Bluetooth
switch to activate it,
and then tap
SCAN
.
The detected devices are listed.
To set the device as visible to other devices, tap the device name.
2
Select a device to pair with.
If your device has paired with the device before, tap the device name.
If your device has not paired with the device before, tap the device name and accept the
Bluetooth authorization request on both devices to confirm.
Connecting with other devices
60
Sending and receiving data
Many apps support data transfer via Bluetooth. You can share data, such as contacts or media
files, with other Bluetooth devices. The following actions are an example of sending an image
to another device.
Sending an image
1
On the Apps screen, tap
Gallery
.
2
Select an image.
3
Tap Share
→
Bluetooth
, and then select a device to receive the image.
If the device you want to pair with is not in the list, turn on its visibility option. Or, set your
device as visible to other devices.
4
Accept the Bluetooth authorization request on the other device.
Receiving an image
When another device sends you an image, accept the Bluetooth authorization request. You
can view received images in
Gallery
.
Unpairing Bluetooth devices
1
On the Apps screen, tap
Settings
→
Bluetooth
.
The device displays the paired devices in the list.
2
Tap next to the device’s name to unpair.
3
Tap
Unpair
.
Connecting with other devices
61
Wi-Fi Direct
About Wi-Fi Direct
Wi-Fi Direct connects devices directly via a Wi-Fi network without requiring an access point.
Connecting to other devices
1
On the Apps screen, tap
Settings
→
Wi-Fi
, and then tap the
Wi-Fi
switch to activate it.
2
Tap
Wi-Fi Direct
.
The detected devices are listed.
3
Select a device to connect to.
4
Accept the Wi-Fi Direct authorization request on the other device to confirm.
Sending and receiving data
You can share data, such as contacts or media files, with other devices. The following actions
are an example of sending an image to another device.
Sending an image
1
On the Apps screen, tap
Gallery
.
2
Select an image.
3
Tap Share
→
Wi-Fi Direct
and select a device to receive the image .
4
Accept the Wi-Fi Direct authorization request on the other device.
Connecting with other devices
62
Receiving an image
When another device sends you an image, accept the Wi-Fi Direct authorization request. You
can view received images in
Gallery
.
Ending the device connection
1
On the Apps screen, tap
Settings
→
Wi-Fi
.
2
Tap
Wi-Fi Direct
.
The device displays the connected devices in the list.
3
Tap the device name to disconnect the devices.
SideSync
Introduction
SideSync allows you to easily share your screen and data between Samsung Android
smartphones, tablets, and any computers.
The SideSync app must be installed on both devices that you want to connect. If SideSync is
not installed, use one of the following methods to download and install it:
•
To download and install SideSync on your Samsung Android tablet or smartphone,
search for SideSync in
Galaxy Apps
or
Play Store
. If your device does not support
SideSync, you may not be able to find the app.
•
To download and install SideSync on your computer, visit www.samsung.com/sidesync.
On the webpage, you can also find the information about SideSync system requirements.
To wirelessly connect devices, they must support Wi-Fi Direct and be connected to the same
access point.
The tablet’s operating system includes SideSync 3.0. When the app is first opened, the
message “New version available. Update now?” is displayed. Tap UPDATE
→
UPDATE
to continue (installation of the update is required in order to run SideSync, the app
closes if LATER is selected).
Connecting with other devices
63
Connecting to computers or smartphones
Connecting to a computer
1
Connect your tablet to your computer using a USB cable.
Alternatively, connect both devices to the same access point.
2
Launch
SideSync
on both devices.
3
Tap
START
on both devices.
Both devices will scan each other and connect. Then, the dashboard will appear on your
computer.
Connecting to a smartphone via Wi-Fi Direct
1
Launch
SideSync
on both your tablet and smartphone.
2
Tap
START
on both devices.
Both devices will scan each other and connect.
3
On your smartphone, select your tablet from the detected devices list.
Connecting with other devices
64
4
On the tablet, accept the connection request.
The dashboard will appear on your tablet.
Connecting devices automatically
When two devices have been previously connected, you can set them to reconnect
automatically. Connecting the devices via USB or Wi-Fi Direct automatically launches
SideSync
. If the devices are connected to the same access point, place them near each other
to connect them.
To stop using the auto connection feature, open the smartphone, tap
SideSync
→
MORE
→
Settings
, and then tap the
Auto connect devices
switch to deactivate it. Alternatively, on
the dashboard, tap
MORE
→
Settings
→
Connections
and deactivate the auto connection
feature.
Connecting with other devices
65
Using the dashboard
Launch frequently used apps or view notifications from your smartphone.
When you tap a notification, the related app or program will launch. The following is an image
of a smartphone’s dashboard on the tablet.
Turn on the virtual smartphone
screen.
Access additional options.
Close the dashboard.
Add more apps.
Minimize the dashboard.
Tap a notification and perform
various actions.
You can rearrange or delete apps when you right-click on an app icon.
Connecting with other devices
66
Using the virtual screen
SideSync mirrors a device’s screen on another device. You can use a device’s functions, such
as making calls and launching apps, via the virtual screen. The following is an image of the
virtual tablet screen.
•
Some functions may not work through the virtual screen.
•
The appearance and functions of the virtual screen may vary depending on the
connected device.
End the connection.
Minimize the virtual screen.
Maximize the virtual screen.
Tap to use the following options:
•
: Share the computer’s keyboard and mouse with your tablet.
•
: Set the virtual screen to always stay on top.
•
: Rotate the screen.
•
: Capture a screenshot.
•
: Turn on the tablet’s screen to control it from both your computer and tablet. This
feature may not be available depending on the connected device.
•
: Open the same webpage in the web browser of your computer.
To move the virtual screen, click and drag the top of the virtual screen to a new location.
To adjust the size of the virtual screen, place the mouse pointer over the edge of the virtual
screen, then click and drag it.
Connecting with other devices
67
Switching between screens
To use the actual screen on the connected device, press the Power key or the Home key on
the connected device. The virtual screen turns off and the connected device’s screen turns on.
If your tablet is connected to your computer, click the virtual tablet screen on the computer
to return to it. If your smartphone is connected to your tablet, tap
SWITCH TO TABLET
on the
tablet.
You can view and control the virtual screen and the connected device’s screen
simultaneously. On the virtual screen, tap
→
to turn on the connected
device’s screen. This feature may not be available depending on the connected
device.
Sharing files and clipboard
You can easily share files between connected devices.
Select files on the virtual screen or outside the virtual screen. Then, drag and drop the
selected files into or out of the virtual screen. The selected files will be copied to the intended
device.
You can also conveniently copy and paste text between the connected devices via the
clipboard sharing feature. Copy or cut text from the virtual screen and paste it into a text field
outside of the virtual screen, or vice versa.
Sharing the computer’s keyboard and mouse
Use your tablet’s screen as a dual monitor and control it with the computer’s keyboard and
mouse.
1
On the dashboard, tap
MORE
→
Enable Keyboard and mouse sharing
.
If the virtual screen is open, it will disappear from the computer’s screen.
Connecting with other devices
68
2
Move the mouse pointer to the left or right edge of the computer’s screen to go to your
tablet’s screen.
The mouse pointer will appear on your tablet’s screen.
3
On your tablet, use the computer’s keyboard and mouse to perform actions, such as
entering text, copying and pasting, and selecting items.
To control the computer with the mouse again, return the pointer to the computer’s
screen.
Connecting with other devices
69
Screen Mirroring
About Screen Mirroring
Use this feature to connect your device to a large screen with an AllShare Cast dongle or
HomeSync and then share your contents.
Screen Mirroring
-enabled devices
(AllShare Cast dongle,
HomeSync)
•
This feature may not be available depending on the region or service provider.
•
Some files may be buffered during playback, depending on the network
connection.
•
To save energy, deactivate this feature when not in use.
•
If you specify a Wi-Fi frequency, AllShare Cast dongles or HomeSync may not be
detected or connected.
•
If you play videos or games on a TV, select an appropriate TV mode to get the best
experience.
Connecting with other devices
70
Viewing content on a TV
Before you connect your device to a TV, connect the screen mirroring-enabled device to the
TV. To set up the connection, refer to the device’s user manual. The following actions are an
example of viewing content on a TV connected via an AllShare Cast dongle.
1
Connect the AllShare Cast dongle to the TV using an HDMI cable.
2
On the TV, select a connection mode, such as HDMI mode, to connect an external device.
3
Open the notifications panel and tap
EDIT
→
Screen Mirroring
.
The detected devices are listed.
4
Select a device to connect to.
Your device’s screen appears on the TV screen.
If you connect the device for the first time, tap and hold the dongle’s name in the list and
enter the PIN shown on the TV screen.
5
Open or play a file, and then control the display with the keys on your device.
Connecting with other devices
71
Mobile printing
Connect the device to a printer via Wi-Fi or Wi-Fi Direct, and print images or documents.
Some printers may not be compatible with the device.
Adding printer plug-ins
Add printer plug-ins for printers you want to connect the device to.
On the Apps screen, tap
Settings
→
More connection settings
→
Printing
→
Download
plug-in
, and search for a printer plug-in in
Play Store
. Select a printer plug-in and install it.
Connecting to a printer
On the Apps screen, tap
Settings
→
More connection settings
→
Printing
, select a printer
plug-in, and then tap the switch to activate it. The device searches for printers that are
connected to the same Wi-Fi network as your device.
To add printers manually, select a printer plug-in, tap
MORE
→
Add printer
→
ADD
PRINTER
, enter details, and then tap
OK
.
To change print settings, select a printer plug-in and tap
MORE
→
Printing settings
.
Printing content
While viewing content, such as images or documents, tap
Share
→
Print
→
→
All
printers
, and then select a printer.
72
Device & data manager
Transferring data from your previous device
You can transfer data from a previous device to your new device via Samsung Smart Switch.
The following versions of Samsung Smart Switch are available.
•
Mobile version: Transfer data between mobile devices. You can download the app from
Galaxy Apps
or
Play Store
.
•
Computer version: Transfer data between your device and a computer. You can download
the app from www.samsung.com/smartswitch.
•
Samsung Smart Switch is not supported on some devices or computers.
•
Limitations apply. Visit www.samsung.com/smartswitch for details. Samsung
takes copyright seriously. Only transfer content that you own or have the right to
transfer.
Transferring data from a mobile device
Transfer data from your previous device to your new device.
The following actions are an example of transferring data from your previous Android device.
To import data from a mobile device with a different operating system, refer to the on-screen
instructions.
1
Download and install Smart Switch from
Galaxy Apps
or
Play Store
on your previous and
new devices.
2
Launch
Smart Switch
on both devices.
3
On your new device, tap to select the old device type (iOS device or Android device) then
tap
START and follow the on-screen instructions
.
Device & data manager
73
Transferring data from a computer
Back up data from your previous device to a computer and import the data to your new
device.
1
On the computer, visit www.samsung.com/smartswitch to download Smart Switch.
2
On the computer, launch Smart Switch.
If your previous device is not a Samsung device, back up data to a computer using a
program provided by the device’s manufacturer. Then, skip to the fifth step.
3
Connect your previous device to the computer using the USB cable.
4
On the computer, follow the on-screen instructions to back up data from the device.
Then, disconnect your previous device from the computer.
5
Connect your new device to the computer using the USB cable.
6
On the computer, follow the on-screen instructions to transfer data to your new device.
Device & data manager
74
Using the device as a removable disk for data
transfer
Move audio, video, image, or other types of files from the device to the computer, or vice
versa.
Do not disconnect the USB cable from the device when you are transferring files.
Doing so may cause data loss or device damage.
The devices may not connect properly if they are connected via a USB hub. Directly
connect the device to the computer’s USB port.
1
Connect the device to the computer using the USB cable.
2
Open the notifications panel, and then tap
Connected as a media device
→
Media device (MTP)
.
Tap
Camera (PTP)
if your computer does not support Media Transfer Protocol (MTP) or
not have any appropriate driver installed.
3
Transfer files between your device and the computer.
Updating the device
The device can be updated to the latest software.
Updating over the air
The device can be directly updated to the latest software by the firmware over-the-air (FOTA)
service.
On the Apps screen, tap
Settings
→
About device
→
Software update
→
Update now
.
To automatically check for available updates, tick
Auto update
.
Device & data manager
75
Updating with Smart Switch
Connect the device to a computer and update the device to the latest software.
1
On the computer, visit www.samsung.com/smartswitch to download and install Smart
Switch.
2
On the computer, launch Smart Switch.
3
Connect the device to the computer using a USB cable.
4
On the computer, click the update button in the connection window.
•
Do not turn off the computer or disconnect the USB cable while the device is
updating.
•
While updating the device, do not connect other media devices to the computer.
Doing so may interfere with the update process. Before updating, disconnect all
other media devices from the computer.
Backing up and restoring data
Keep your personal information, app data, and settings safe on your device. You can back up
your sensitive information to a backup account and access it later.
Using a Samsung account
On the Apps screen, tap
Settings
→
Backup and reset
→
Back up my data
, select the items
to back up, and then tap
BACK UP NOW
.
To set the device to automatically back up data, tap the
Auto back up
switch to activate it.
To restore data using a Samsung account, tap
Restore
. Current data will be deleted from the
device to restore the selected items.
Using a Google account
On the Apps screen, tap
Settings
→
Backup and reset
, and then tap the
Back up my data
switch to activate it. Tap
Backup account
and select an account as the backup account.
To restore data using a Google account, tap the
Automatic restore
switch to activate it. When
you reinstall apps, backed up settings and data will be restored.
Device & data manager
76
Performing a data reset
Delete all settings and data on the device. Before performing a factory data reset, ensure you
back up all important data stored on the device. Refer to Backing up and restoring data for
more information.
On the Apps screen, tap
Settings
→
Backup and reset
→
Factory data reset
→
RESET DEVICE
→
ERASE EVERYTHING
. The device automatically restarts.
77
Settings
About Settings
Use this app to configure the device, set app options, and add accounts.
Tap
Settings
on the Apps screen.
To search for settings by entering keywords, tap
SEARCH
.
Connections
Wi-Fi
Activate the Wi-Fi feature to connect to a Wi-Fi network and access the Internet or other
network devices.
On the Settings screen, tap
Wi-Fi
, and then tap the switch to activate it.
To use options, tap
MORE
.
Setting Wi-Fi sleep policy
Tap
MORE
→
Keep Wi-Fi on during sleep
.
Bluetooth
Activate the Bluetooth feature to exchange information over short distances.
On the Settings screen, tap
Bluetooth
, and then tap the switch to activate it.
Flight mode
This disables all wireless functions on your device. You can use only non-network services.
On the Settings screen, tap
Flight mode
, and then tap the switch to activate it.
Settings
78
Data usage
Keep track of your data usage amount.
On the Settings screen, tap
Data usage
.
To use more options, tap
MORE
.
•
Restrict networks
: Set the device to disable sync in the background while using Wi-Fi
network.
More connection settings
Customize settings to control networks.
On the Settings screen, tap
More connection settings
.
Printing
Configure settings for printer plug-ins installed on the device. You can search for available
printers or add one manually to print files.
VPN
Set up and connect to virtual private networks (VPNs).
Ethernet
The Ethernet option is available when an Ethernet adapter is connected to the device. Use
this option to activate the Ethernet feature and configure network settings.
Settings
79
Device
Sounds and notifications
Change settings for various sounds on the device.
On the Settings screen, tap
Sounds and notifications
.
•
Sound mode
: Set the device to use sound mode or silent mode.
•
Volume
: Adjust the volume level for music and videos, system sounds, and notifications.
•
Sounds
: Change the ringtone and system sound settings.
•
Sound quality and effects
: Select a sound effect to apply when you adjust to music.
•
Do not disturb
: Change settings for managing interruptions.
•
Notifications on lock screen
: Set whether or not to show the content of notifications on
the locked screen.
•
App notifications
: Change the notification settings for each app.
Display
Change the display settings.
On the Settings screen, tap
Display
.
•
Brightness
: Set the brightness of the display.
•
Outdoor mode
: Adjust the screen settings for easier viewing while outdoors.
•
Font
: Change the font size and type.
•
Screen timeout
: Set the length of time the device waits before turning off the display’s
backlight.
•
Smart stay
: Set the device to prevent the display backlight from turning off while you are
looking at the display.
•
Daydream
: Set the device to launch a screensaver when the device is charging or
connected to a desktop dock.
Settings
80
Motions and gestures
Activate the motion recognition feature and change the settings that control motion
recognition on your device.
On the Settings screen, tap
Motions and gestures
.
•
Mute
: Set the device to mute alarms by using palm motions or placing the device face
down.
•
Palm swipe to capture
: Set the device to capture a screenshot when you sweep your
hand to the left or right across the screen.
Applications
Application manager
View and manage the apps on your device.
Default applications
Select a default setting for using apps.
Application settings
Customize the settings for each app.
Settings
81
Users
Set up additional user accounts for other users to use the device with personalized settings,
such as email accounts, wallpaper preferences, and more. Following types of user accounts
are available:
•
Owner
: The owner account is created only when setting up the device for the first
time, and cannot be created more than one. This account has full control of the device
including user account management. You can add or delete user accounts only when
using this account.
•
Guest
: This account allows guests to access the device. Information and data used during
a guest session is temporarily stored. Each time you use this account, you are asked
whether to continue the previous guest session or reset it.
•
User
: This account allows users to access their own apps and content, and customize the
device settings that affect all accounts.
•
User (restricted profile)
: A restricted account can only access the apps and content
allowed by the owner account, and cannot use the services that require logging in.
Adding users
1
On the Settings screen, tap
Users
.
2
Tap
Add user or profile
→
User
→
OK
→
SET UP NOW
.
The device will switch to a new user account and the default locked screen will appear on
the screen.
3
Unlock the device and follow the on-screen instructions to complete the account setup.
Adding restricted profiles
1
On the Settings screen, tap
Users
.
2
Tap
Add user or profile
→
User (restricted profile)
.
If you are not using a secure screen lock method with the owner account, follow the on-
screen instructions to set one up.
3
Select the apps and content that restricted users are allowed to access.
Settings
82
Switching users
Tap the user account icon at the top of the locked screen or the notification panel, and then
select an account to switch to.
Locked screen Notification panel
Managing users
When using the owner account, you can delete accounts or change the settings for restricted
accounts.
To delete a user account, tap
next to an account to delete it.
To change the settings for a restricted account, tap
next to an account. You can delete the
account by tapping
.
Settings
83
Personal
Wallpaper
Change the wallpaper settings for the Home screen and the locked screen.
On the Settings screen, tap
Wallpaper
.
•
HOME SCREEN: Select a background image for the Home screen.
•
LOCK SCREEN: Select a background image for the locked screen.
•
HOME AND LOCK SCREENS: Select a background image for the Home screen and the
locked screen.
Lock screen and security
Change the settings for securing the device.
On the Settings screen, tap
Lock screen and security
.
The available options may vary depending on the screen lock method selected.
•
Screen lock type
: Change the screen lock method.
•
Show information
: Change settings for the items displayed on the locked screen.
•
Unlock effect
: Select an effect that you see when you unlock the screen.
•
Find My Mobile
: Access the Find my mobile website (findmymobile.samsung.com). You
can track and control your lost or stolen device from the Find my mobile website.
•
Unknown sources: Set the device to allow the installation of apps from unknown sources.
•
Other security settings
: Configure additional security settings.
Privacy
On the Settings screen, tap
Privacy
.
•
Location
: Change settings for location information permissions.
•
Private mode
: Set the device to prevent others from accessing your personal content by
activating private mode.
•
Report diagnostic info
: Set the device to automatically send the device’s diagnostic and
usage information to Samsung.
Settings
84
Accessibility
Use this feature to improve accessibility to the device.
On the Settings screen, tap
Accessibility
.
•
Vision
: Customize the settings to improve accessibility for visually impaired users.
–
Voice Assistant
: Activate Voice Assistant, which provides voice feedback.
–
Voice Assistant help
: View help information to learn how to use Voice Assistant.
–
Dark screen
: Set the device to turn the screen off at all times to keep the content on
your screen private.
–
Rapid key input
: Set the device to enter a character when you release your finger
from the character on the keyboard. You can use this feature to enter characters
instead of releasing your finger and double-tapping on the screen.
–
Speak passwords
: Set the device to read the password aloud when you enter the
password while Voice Assistant is activated.
–
Font size
: Change the font size.
–
Magnification gestures
: Set the device to magnify the screen and to zoom in on a
specific area.
–
Magnifier window
: Activate a magnifier to zoom in on the screen to view a larger
version of the content.
–
Colour inversion
: Reverse the display colours to improve visibility.
–
Colour correction
: Adjust the colour scheme for the screen when the device
determines that you are colour blind or having difficulty reading content.
–
Accessibility shortcut
: Set the device to activate Voice Assistant when you press and
hold the Power button, and then tap and hold the screen with two fingers.
–
Text-to-speech options
: Change the settings for text-to-speech features used when
Voice Assistant is activated, such as languages, speed, and more.
Settings
85
•
Hearing
: Customize the settings to improve accessibility for users with hearing
impairment.
–
Turn off all sounds
: Set the device to mute all device sounds, such as media sounds.
–
Samsung subtitles (CC)
: Set the device to display closed captions on content
supported by Samsung and to change the closed caption settings.
–
Google subtitles (CC)
: Set the device to display closed captions on content supported
by Google and to change the closed caption settings.
–
Left/right sound balance
: Set the device to adjust the sound balance when using a
headset.
–
Mono audio
: Set the device to switch the sound output from stereo to mono when a
headset is connected.
•
Dexterity and interaction
: Customize the settings to improve accessibility for users who
have reduced dexterity.
–
Universal switch
: Set the device to scan and highlight items on the screen, and then
read them aloud. You can control the touch screen by connecting an external switch,
tapping the screen, or by using head movements and face gestures.
–
Assistant menu
: Set the device to show the assistive shortcut icon that helps you
access functions supported by external buttons or features on the notifications panel.
You can also edit the menu on the shortcut icon.
–
Tap and hold delay
: Set the recognition time for tapping and holding the screen.
–
Interaction control
: Activate interaction control mode to restrict the device’s reaction
to inputs while using apps.
•
Direction lock
: Create a directional combination to unlock the screen.
•
Direct access
: Set the device to open selected accessibility menus when you press the
Home button three times quickly.
•
Notification reminder
: Set the device to alert you to notifications that you have not
checked at the interval.
•
Single tap mode
: Set the device to control notifications by tapping the button instead of
dragging it.
•
Manage accessibility
: Export or import the accessibility settings to share them with
other devices.
•
Services
: View accessibility services installed on the device.
Settings
86
Accounts
Add your Samsung and Google accounts, or other accounts, to sync with.
On the Settings screen, tap
Accounts
.
Backup and reset
Change the settings for managing settings and data.
On the Settings screen, tap
Backup and reset
.
•
Back up my data
: Back up your personal information and app data to the Samsung
server. You can also set the device to automatically back up data.
•
Restore
: Restore previously backed up personal information and app data from your
Samsung account.
•
Backup account
: Set up or edit your Google backup account.
•
Back up my data
: Set the device to back up settings and app data to the Google server.
•
Automatic restore
: Set the device to restore settings and app data when the apps are
reinstalled on the device.
•
Factory data reset
: Reset settings to the factory default values and delete all data.
Settings
87
System
Language and input
Change the settings for text input. Some options may not be available depending on the
selected language.
On the Settings screen, tap
Language and input
.
•
Language
: Select a display language for all menus and apps.
•
Default keyboard
: Select a default keyboard type for text input.
•
Samsung keyboard
: Change the Samsung keyboard settings.
•
Google voice typing
: Change the voice input settings.
•
Voice input
: Change the settings for the voice recognizer.
•
Text-to-speech options
: Change the text-to-speech settings.
•
Pointer speed
: Adjust the pointer speed for the mouse or trackpad connected to your
device.
The available options may vary depending on the region or service provider.
Battery
View battery power information and change power saving options.
On the Settings screen, tap
Battery
.
•
Power saving mode
: Activate power-saving mode and change the settings for power-
saving mode.
•
Ultra power saving mode
: Extend standby time and reduce battery consumption by
displaying a simpler layout and allowing limited access to apps.
•
Display battery percentage
: Set the device to display the remaining battery life as a
percentage on the status bar.
The usage time left shows the time remaining before the battery power runs
out. Usage time left may vary depending on your device settings and operating
conditions.
Settings
88
Storage
View memory information for your device and memory card, or format a memory card.
On the Settings screen, tap
Storage
.
Formatting a memory card permanently deletes all data from it.
The actual available capacity of the internal memory is less than the specified
capacity because the operating system and default apps occupy part of the memory.
The available capacity may change when you upgrade the device.
Date and time
Access and alter the following settings to control how the device displays the time and date.
On the Settings screen, tap
Date and time
.
If the battery remains fully discharged or removed from the device, the time and date
is reset.
•
Automatic date and time
: Automatically update the time and date when moving across
time zones.
•
Set date
: Set the current date manually.
•
Set time
: Set the current time manually.
•
Select time zone
: Set the home time zone.
•
Use 24-hour format
: Display time in 24-hour format.
About device
Access device information, edit the device name, or update device software.
On the Settings screen, tap
About device
.
89
Appendix
Troubleshooting
Before contacting a Samsung Service Centre, please attempt the following solutions. Some
situations may not apply to your device.
When you turn on your device or while you are using the device, it
prompts you to enter a password:
•
When the device lock feature is enabled, you must enter the password you set for the
device.
Your device displays network or service error messages
•
When you are in areas with weak signals or poor reception, you may lose reception. Move
to another area and try again. While moving, error messages may appear repeatedly.
•
You cannot access some options without a subscription. For more information, contact
your service provider.
Your device does not turn on
When the battery is completely discharged, your device will not turn on. Fully charge the
battery before turning on the device.
Appendix
90
The touch screen responds slowly or improperly
•
If you attach a protective cover or optional accessories to the touch screen, the touch
screen may not function properly.
•
If you are wearing gloves, if your hands are not clean while touching the touch screen,
or if you tap the screen with sharp objects or your fingertips, the touch screen may
malfunction.
•
The touch screen may malfunction in humid conditions or when exposed to water.
•
Restart your device to clear any temporary software bugs.
•
Ensure that your device software is upgraded to the latest version.
•
If the touch screen is scratched or damaged, visit a Samsung Service Centre.
Your device freezes or has fatal errors
If your device freezes or hangs, you may need to close apps or turn off the device and turn it
on again. If your device is frozen and unresponsive, press and hold the Power button and the
Volume button down simultaneously for more than 7 seconds to restart it.
If this does not solve the problem, perform a factory data reset. On the Apps screen, tap
Settings
→
Backup and reset
→
Factory data reset
→
RESET DEVICE
→
ERASE EVERYTHING
. Before performing the factory data reset, remember to make backup
copies of all important data stored in the device.
If the problem is still not resolved, contact a Samsung Service Centre.
The Internet is often disconnected
•
Ensure that you are not blocking the device’s internal antenna.
•
When you are in areas with weak signals or poor reception, you may lose reception. You
may have connectivity problems due to issues with the service provider’s base station.
Move to another area and try again.
•
When using the device while moving, wireless network services may be disabled due to
issues with the service provider’s network.
Appendix
91
The battery icon is empty
Your battery is low. Charge the battery.
The battery does not charge properly (For Samsung-approved
chargers)
•
Ensure that the charger is connected properly.
•
Visit a Samsung Service Centre and have the battery replaced.
The battery depletes faster than when first purchased
•
When you expose the device or the battery to very cold or very hot temperatures, the
useful charge may be reduced.
•
Battery consumption increases when you use messaging features or some apps, such as
games or the Internet.
•
The battery is consumable and the useful charge will get shorter over time.
Your device is hot to the touch
When you use apps that require more power or use apps on your device for an extended
period of time, your device may feel hot to the touch. This is normal and should not affect
your device’s lifespan or performance.
Error messages appear when launching the camera
Your device must have sufficient available memory and battery power to operate the camera
app. If you receive error messages when launching the camera, try the following:
•
Charge the battery.
•
Free some memory by transferring files to a computer or deleting files from your device.
•
Restart the device. If you are still having trouble with the camera app after trying these
tips, contact a Samsung Service Centre.
Appendix
92
Photo quality is poorer than the preview
•
The quality of your photos may vary, depending on the surroundings and the
photography techniques you use.
•
If you take photos in dark areas, at night, or indoors, image noise may occur or images
may be out of focus.
Error messages appear when opening multimedia files
If you receive error messages or multimedia files do not play when you open them on your
device, try the following:
•
Free some memory by transferring files to a computer or deleting files from your device.
•
Ensure that the music file is not Digital Rights Management (DRM)-protected. If the file is
DRM-protected, ensure that you have the appropriate licence or key to play the file.
•
Ensure that the file formats are supported by the device. If a file format is not supported,
such as DivX or AC3, install an app that supports it. To confirm the file formats that your
device supports, visit www.samsung.com.
•
Your device supports photos and videos captured with the device. Photos and videos
captured by other devices may not work properly.
•
Your device supports multimedia files that are authorized by your network service
provider or providers of additional services. Some content circulated on the Internet,
such as ringtones, videos, or wallpapers, may not work properly.
Another Bluetooth device is not located
•
Ensure that the Bluetooth wireless feature is activated on your device.
•
Ensure that the Bluetooth wireless feature is activated on the device you wish to connect
to.
•
Ensure that your device and the other Bluetooth device are within the maximum
Bluetooth range (10 m).
If the tips above do not solve the problem, contact a Samsung Service Centre.
Appendix
93
A connection is not established when you connect the device to a
computer
•
Ensure that the USB cable you are using is compatible with your device.
•
Ensure that you have the proper driver installed and updated on your computer.
•
If you are a Windows XP user, ensure that you have Windows XP Service Pack 3 or higher
installed on your computer.
Your device cannot find your current location
GPS signals may be obstructed in some locations, such as indoors. Set the device to use Wi-Fi
or a mobile network to find your current location in these situations.
Data stored in the device has been lost
Always make backup copies of all important data stored in the device. Otherwise, you cannot
restore data if it is corrupted or lost. Samsung is not responsible for the loss of data stored in
the device.
A small gap appears around the outside of the device case
•
This gap is a necessary manufacturing feature and some minor rocking or vibration of
parts may occur.
•
Over time, friction between parts may cause this gap to expand slightly.
Appendix
94
Removing the battery
•
To remove the battery, you must visit an authorized service centre with the provided
instructions.
•
For your safety, you must not attempt to remove the battery. If the battery is not
properly removed, it may lead to damage to the battery and device, cause personal
injury, and/or result in the device being unsafe.
•
Samsung does not accept liability for any damage or loss (whether in contract or tort,
including negligence) which may arise from failure to precisely follow these warnings and
instructions, other than death or personal injury caused by Samsung’s negligence.
1
Remove the memory card from the device.
2
Insert the device opening tool into the gap between the device’s screen and the back
cover.
Then, start separating the screen from the back cover by using the tool to pry them apart.
3
Continue reinserting the tool and prying the screen and the back cover apart at close
intervals around the device.
4
When the screen is disengaged, separate the screen and the back cover.
Then, put the back cover aside and place the screen face down on a flat work surface.
5
Disconnect the battery connectors.
6
Peel the flap from the battery, and then pull it to remove the battery.
95
Health and Safety
This safety information contains content for mobile devices. Some content may be not
applicable to your device. To prevent injury to yourself and others or damage to your device,
read the safety information about your device before using the device.
Warning: Failure to comply with safety warnings and
regulations can cause serious injury or death.
Do not use damaged power cords or plugs, or loose electrical sockets
•
Unsecured connections can cause electric shock or fire.
Do not touch the power cord with wet hands or disconnect the charger by pulling the
cord
•
Doing so may result in electrocution.
Do not bend or damage the power cord
•
Doing so may cause electric shock or fire.
Do not use your device while it is charging or touch your device with wet hands
•
Doing so may cause electric shock.
Do not short-circuit the charger or the device
•
Doing so may cause electric shock or fire, or the battery may malfunction or explode.
Do not use your device outdoor during a thunderstorm
•
Doing so may result in electric shock or device malfunction.
Use manufacturer-approved chargers, accessories, and supplies
•
Using generic chargers may shorten the life of your device or cause the device to
malfunction. They may also cause a fire or cause the battery to explode.
•
Use only Samsung-approved charger specifically designed for your device. Incompatible
battery and charger can cause serious injuries or damage to your device.
•
Samsung cannot be responsible for the user’s safety when using accessories or supplies
that are not approved by Samsung.
•
Do not drop or cause an impact to the charger or the device
Handle and dispose of the device and charger with care
•
Never dispose of the device in a fire. Never place the device on or in heating devices,
such as microwave ovens, stoves, or radiators. The device may explode when overheated.
Follow all local regulations when disposing of used battery or device.
•
Never crush or puncture the device.
Health and Safety
96
•
Avoid exposing the device to high external pressure, which can lead to an internal short
circuit and overheating.
Protect the device and charger from damage
•
Avoid exposing your device to very cold or very hot temperatures.
•
Extreme temperatures can damage the device and reduce the charging capacity and life
of your device and battery.
•
Never use a damaged charger.
Do not store your device near or in heaters, microwaves, hot cooking equipment, or
high pressure containers
•
The battery may leak.
•
Your device may overheat and cause a fire.
Do not use or store your device in areas with high concentrations of dust or airborne
materials
•
Dust or foreign materials can cause your device to malfunction and may result in fire or
electric shock.
Do not bite or suck the device
•
Doing so may damage the device or result in an explosion or fire.
•
Children or animals can choke on small parts.
•
If children use the device, make sure that they use the device properly.
Do not insert the device or supplied accessories into the eyes, ears, or mouth
•
Doing so may cause suffocation or serious injuries.
Caution: Failure to comply with safety cautions and regulations
can cause injury or property damage
Do not use your device near other electronic devices
•
Most electronic devices use radio frequency signals. Your device may interfere with other
electronic devices.
Do not use your device in a hospital, on an aircraft, or in an automotive equipment that
can be interfered with by radio frequency
•
Avoid using your device within a 15 cm range of a pacemaker, if possible, as your device
can interfere with the pacemaker.
•
To minimize possible interference with a pacemaker, use your device only on the side of
your body that is opposite the pacemaker.
•
If you use medical equipment, contact the equipment manufacturer before using your
Health and Safety
97
device to determine whether or not the equipment will be affected by radio frequencies
emitted by the device.
•
On an aircraft, using electronic devices can interfere with the aircraft’s electronic
navigational instruments. Make sure the device is turned off during takeoff and landing.
After takeoff, you can use the device in flight mode if allowed by aircraft personnel.
•
Electronic devices in your car may malfunction, due to radio interference from your
device. Contact the manufacturer for more information.
Do not expose the device to heavy smoke or fumes
•
Doing so may damage the outside of the device or cause it to malfunction.
If you use a hearing aid, contact the manufacturer for information about radio
interference
•
The radio frequency emitted by your device may interfere with some hearing aids. Before
using your device, contact the manufacturer to determine whether or not your hearing
aid will be affected by radio frequencies emitted by the device.
Do not use your device near devices or apparatuses that emit radio frequencies, such as
sound systems or radio towers
•
Radio frequencies may cause your device to malfunction.
•
Turn off the device in potentially explosive environments
•
Turn off your device in potentially explosive environments instead of removing the
battery.
•
Always comply with regulations, instructions and signs in potentially explosive environments.
•
Do not use your device at refuelling points (gas stations), near fuels or chemicals, or in
blasting areas.
•
Do not store or carry flammable liquids, gases, or explosive materials in the same
compartment as the device, its parts, or accessories.
If you notice strange smells or sounds coming from your device or the battery, or if
you see smoke or liquids leaking from the device or battery, stop using the device
immediately and take it to a Samsung Service Centre
•
Failure to do so may result in fire or explosion.
Comply with all safety warnings and regulations regarding mobile device usage while
operating a vehicle
•
While driving, safely operating the vehicle is your first responsibility. Never use your
mobile device while driving, if it is prohibited by law. For your safety and the safety of
others, use your common sense and remember the following tips:
Health and Safety
98
•
Position your device within easy reach. Make sure you can access your wireless device
without taking your eyes off the road.
•
Suspend use in heavy traffic or hazardous weather conditions. Rain, sleet, snow, ice, and
heavy traffic can be hazardous.
•
Do not take notes or look up phone numbers. Jotting down a “to do” list or flipping
through your address book takes attention away from your primary responsibility of
driving safely.
Care for and use your mobile device properly
Keep your device dry
•
Humidity and liquids may damage the parts or electronic circuits in your device.
•
Do not turn on your device if it is wet. If your device is already on, turn it off and remove
the battery immediately (if the device will not turn off or you cannot remove the battery,
leave it as-is). Then, dry the device with a towel and take it to a service centre.
•
Liquids will change the colour of the label that indicates water damage inside the device.
Water damage to your device can void your manufacturer’s warranty.
Store your device only on flat surfaces
•
If your device falls, it may be damaged.
Do not store your device in very hot or very cold areas. It is recommended to use your
device at temperatures from 5 °C to 35 °C
•
Do not store your device in very hot areas such as inside a car in the summertime. Doing
so may cause the screen to malfunction, result in damage to the device, or cause the
battery to explode.
•
Do not expose your device to direct sunlight for extended periods of time (on the
dashboard of a car, for example).
•
Store the battery at temperatures from 0 °C to 45 °C.
Do not store your device with metal objects, such as coins, keys, and necklaces
•
Your device may be scratched or may malfunction.
Do not store your device near magnetic fields
•
Your device may malfunction or the battery may discharge from exposure to magnetic
fields.
•
Magnetic stripe cards, including credit cards, phone cards, passbooks, and boarding
passes, may be damaged by magnetic fields.
Health and Safety
99
Do not use your device or applications for a while if the device is overheated
•
Prolonged exposure of your skin to an overheated device may cause low temperature
burn symptoms, such as red spots and pigmentation.
Use caution when exposed to flashing lights
•
While using your device, leave some lights on in the room and do not hold the screen too
close to your eyes.
•
Seizures or blackouts can occur when you are exposed to flashing lights while watching
videos or playing Flash-based games for extended periods. If you feel any discomfort,
stop using the device immediately.
•
If anyone related to you has experienced seizures or blackouts while using a similar
device, consult a physician before using the device.
•
If you feel discomfort, such as a muscle spasm, or disoriented, stop using the device
immediately and consult a physician.
•
To prevent eye strain, take frequent breaks while using the device.
Reduce the risk of repetitive motion injuries
When you repetitively perform actions, such as pressing keys, drawing characters on a touch
screen with your fingers, or playing games, you may experience occasional discomfort in your
hands, neck, shoulders, or other parts of your body. When using your device for extended
periods, hold the device with a relaxed grip, press the keys lightly, and take frequent breaks. If
you continue to have discomfort during or after such use, stop using the device and consult a
physician.
Protect your hearing and ears when using a headset
•
Excessive exposure to loud sounds can cause hearing damage.
•
Exposure to loud sounds while walking may distract your attention and cause an
accident.
•
Always turn the volume down before plugging the earphones into an audio source and
use only the minimum volume setting necessary to hear your conversation or music.
•
In dry environments, static electricity can build up in the headset. Avoid using headsets
in dry environments or touch a metal object to discharge static electricity before
connecting a headset to the device.
•
Do not use a headset while driving or riding. Doing so may distract your attention and
cause an accident, or may be illegal depending on your region.
Use caution when using the device while walking or moving
•
Always be aware of your surroundings to avoid injury to yourself or others.
Health and Safety
100
•
Make sure the headset cable does not become entangled in your arms or on nearby
objects.
Do not carry your device in your back pockets or around your waist
•
You could be injured or damage the device if you fall.
Do not paint or put stickers on your device
•
Paint and stickers can clog moving parts and prevent proper operation.
•
If you are allergic to paint or metal parts of the device, you may experience itching,
eczema, or swelling of the skin. When this happens, stop using the device and consult
your physician.
Do not use the device if the screen is cracked or broken
•
Broken glass or acrylic could cause injury to your hands and face. Take the device to a
Samsung Service Centre to have it repaired.
Install mobile devices and equipment with caution
•
Ensure that any mobile devices or related equipment installed in your vehicle are securely
mounted.
•
Avoid placing your device and accessories near or in an airbag deployment area.
Improperly installed wireless equipment can cause serious injury when airbags inflate
rapidly.
Do not drop your device or cause impacts to your device
•
Your device may be damaged or may malfunction.
•
If bent or deformed, your device may be damaged or parts may malfunction.
Ensure maximum battery and charger life
•
Avoid charging your device for more than a week, as overcharging may shorten battery
life.
•
Over time, unused device will discharge and must be recharged before use.
•
Disconnect the charger from power sources when not in use.
•
Leaving batteries unused over time may reduce their lifespan and performance. It may
also cause the batteries to malfunction or explode, or cause a fire.
•
Follow all instructions in this manual to ensure the longest lifespan of your device
and battery. Damages or poor performance caused by failure to follow warnings and
instructions can void your manufacturer’s warranty.
•
Your device may wear out over time. Some parts and repairs are covered by the warranty
within the validity period, but damages or deterioration caused by using unapproved
accessories are not.
Health and Safety
101
When using the device, mind the following
•
Do not cover the antenna area with your hands or other objects. This may cause
connectivity problems or drain the battery.
Do not disassemble, modify, or repair your device
•
Any changes or modifications to your device can void your manufacturer’s warranty. If
your device needs servicing, take your device to a Samsung Service Centre.
When cleaning your device, mind the following
•
Wipe your device or charger with a towel or an eraser.
•
Do not use chemicals or detergents. Doing so may discolour or corrode the outside the
device or may result in electric shock or fire.
Do not use the device for anything other than its intended use
•
Your device may malfunction.
Avoid disturbing others when using the device in public
Allow only qualified personnel to service your device
•
Allowing unqualified personnel to service your device may result in damage to your
device and will void your manufacturer’s warranty.
Handle memory cards and cables with care
•
When inserting a card or connecting a cable to your device, make sure that the card is
inserted or the cable is connected to the proper side.
•
Do not remove a card while the device is transferring or accessing information, as this
could result in loss of data and/or damage to the card or device.
•
Protect cards from strong shocks, static electricity, and electrical noise from other devices.
•
Do not touch gold-coloured contacts or terminals with your fingers or metal objects. If
dirty, wipe the card with a soft cloth.
•
Inserting a card or connecting a cable by force or improperly may result in damage to the
multipurpose jack or other parts of the device.
Protect your personal data and prevent leakage or misuse of sensitive information
•
While using your device, be sure to back up important data. Samsung is not responsible
for the loss of any data.
•
When disposing of your device, back up all data and then reset your device to prevent
misuse of your personal information.
•
Carefully read the permissions screen when downloading applications. Be particularly
cautious with applications that have access to many functions or to a significant amount
of your personal information.
Health and Safety
102
•
Check your accounts regularly for unapproved or suspicious use. If you find any sign of
misuse of your personal information, contact your service provider to delete or change
your account information.
•
In the event your device is lost or stolen, change the passwords on your accounts to
protect your personal information.
•
Avoid using applications from unknown sources and lock your device with a pattern,
password, or PIN.
Do not distribute copyright-protected material
•
Do not distribute copyright-protected material without the permission of the content
owners. Doing this may violate copyright laws. The manufacturer is not liable for any legal
issues caused by the user’s illegal use of copyrighted material.
Malware and viruses
To protect your device from malware and viruses, follow these usage tips. Failure to do so may
result in damages or loss of data that may not be covered by the warranty service
•
Do not download unknown applications.
•
Do not visit untrusted websites.
•
Delete suspicious messages or email from unknown senders.
•
Set a password and change it regularly.
•
Deactivate wireless features, such as Bluetooth, when not in use.
•
If the device behaves abnormally, run an antivirus program to check for infection.
•
Run an antivirus program on your device before you launch newly-downloaded
applications and files.
•
Install antivirus programs on your computer and run them regularly to check for
infection.
•
Do not edit registry settings or modify the device’s operating system.
Correct disposal of this product
This product and its electronic accessories (e.g., charger, headset, USB cable) should not be
disposed of with other household waste.
To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them responsibly
to promote the sustainable reuse of material resources.
This device is compliant with RoHS.
Health and Safety
103
Correct disposal of batteries in this product
The battery incorporated in this product is not user replaceable. For information on its
replacement, please contact your service provider. Do not attempt to remove the battery or
dispose it in a fire. Do not disassemble, crush, or puncture the battery. If you intend to discard
the product, the waste collection site will take the appropriate measures for the recycling and
treatment of the product, including the battery.
Disclaimer
Some content and services accessible through this device belong to third parties and are
protected by copyright, patent, trademark and/or other intellectual property laws. Such
content and services are provided solely for your personal non-commercial use. You may
not use any content or services in a manner that has not been authorized by the content
owner or service provider. Without limiting the foregoing, unless expressly authorized by the
applicable content owner or service provider, you may not modify, copy, republish, upload,
post, transmit, translate, sell, create derivative works, exploit, or distribute in any manner or
medium any content or services displayed through this device.
“THIRD PARTY CONTENT AND SERVICES ARE PROVIDED “AS IS.” SAMSUNG DOES NOT
WARRANT CONTENT OR SERVICES SO PROVIDED, EITHER EXPRESSLY OR IMPLIED, FOR ANY
PURPOSE. SAMSUNG EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING BUT NOT
LIMITED TO, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
SAMSUNG DOES NOT GUARANTEE THE ACCURACY, VALIDITY, TIMELINESS, LEGALITY, OR
COMPLETENESS OF ANY CONTENT OR SERVICE MADE AVAILABLE THROUGH THIS DEVICE
AND UNDER NO CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL SAMSUNG BE LIABLE,
WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES, ATTORNEY FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING
OUT OF, OR IN CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS A RESULT OF
THE USE OF ANY CONTENT OR SERVICE BY YOU OR ANY THIRD PARTY, EVEN IF ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES.”
Third party services may be terminated or interrupted at any time, and Samsung makes no
representation or warranty that any content or service will remain available for any period
of time. Content and services are transmitted by third parties by means of networks and
transmission facilities over which Samsung has no control. Without limiting the generality of
this disclaimer, Samsung expressly disclaims any responsibility or liability for any interruption
or suspension of any content or service made available through this device.
Samsung is neither responsible nor liable for customer service related to the content and
services. Any question or request for service relating to the content or services should be
made directly to the respective content and service providers.
Health and Safety
104
Acknowledging Special Precautions and Industry Canada Notice
Cautions
Any changes or modifications to your device not expressly approved in this document could
void your warranty for this equipment, and void your authority to operate this equipment.
Only use approved batteries, antennas, and chargers. The use of any unauthorized accessories
may be dangerous and void the phone warranty if they cause damage or a defect to the
device.
Although your device is quite sturdy, it is a complex piece of equipment and can be broken.
Avoid dropping, hitting, bending, or sitting on it.
Information to User
This equipment has been tested and found to comply with the limits of a Class B digital
device. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation; if this equipment does cause
harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•
Reorient/relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Warning: At very high volumes, prolonged listening to a headset can damage your
hearing.
Specific Absorption Rates (SAR) for Wireless Devices
The SAR is a value that corresponds to the relative amount of RF energy absorbed by the user
of a wireless device.
The SAR value of a device is the result of an extensive testing, measuring and calculation
process. It does not represent how much RF the device emits. All devices are tested at their
highest value in strict laboratory settings. But when in operation, the SAR of a device can be
substantially less than the level reported to Industry Canada. This is because of a variety of
factors including its proximity to a base station antenna, design and other factors. What is
important to remember is that each device meets strict federal guidelines. Variations in SARs
do not represent a variation in safety.
Health and Safety
105
All devices must meet the federal standard, which incorporates a substantial margin of safety.
As stated above, variations in SAR values between different model devices do not mean
variations in safety. SAR values at or below the federal standard of 1.6 W/kg are considered
safe for use by the public.
This device has been tested and meets RF exposure guidelines when used with an accessory
that contains no metal and that positions the mobile device 0mm from the body.
Owner’s Record
The model number, regulatory number, and serial number are located on a nameplate inside
the battery compartment. Record the serial number in the space provided below. This will be
helpful if you need to contact us about your phone in the future.
Model: SM-T560NU
Serial No.:
Copyright
Copyright © 2016 Samsung Electronics
This manual is protected under international copyright laws.
No part of this manual may be reproduced, distributed, translated, or transmitted in any form
or by any means, electronic or mechanical, including photocopying, recording, or storing
in any information storage and retrieval system, without the prior written permission of
Samsung Electronics.
Trademarks
•
SAMSUNG and the SAMSUNG logo are registered trademarks of Samsung Electronics.
•
Bluetooth
®
is a registered trademark of Bluetooth SIG, Inc. worldwide.
•
Wi-Fi
®
, Wi-Fi Protected Setup
™
, Wi-Fi Direct
™
, Wi-Fi CERTIFIED
™
, and the Wi-Fi logo are
registered trademarks of the Wi-Fi Alliance.
•
All other trademarks and copyrights are the property of their respective owners.
IC Notice
This Class B digital apparatus complies with Canadian ICES-003.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
