en Operating instructions
2
Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Notes on the energy label . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Your vacuum cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Special accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Replacement parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Putting the handle and the flexible hose together . . . . . . . . .15
Inserting the flexible hose . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Putting the handle and the telescopic tube together . . . . . . .15
Ins
erting the telescopic tube into the floor tool . . . . . . . . . . .16
Adjusting the telescopic tube . . . . . . . . . . . . . . . . . . . . . . . . .16
Connecting the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Switching on /off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Controlling the suction level . . . . . . . . . . . . . . . . . . . . . . . . . .18
Vacuuming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Adjusting the floor tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Vacuuming with accessories . . . . . . . . . . . . . . . . . . . . . . . . . .20
Parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Vacuuming stair
s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Carrying the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
When the work is done . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Disconnecting the appliance . . . . . . . . . . . . . . . . . . . . . . . . . .22
Storing and transporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Table of content
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 2
3
Dismantling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Removing the flexible hose . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Disconnecting handle and telescopic tube . . . . . . . . . . . . . . .23
Disconnecting floor nozzle and telescopic tube . . . . . . . . . . .23
Changing the filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Replacing the dust bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Opening the lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Changing the dust bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Changing the motor protection filter . . . . . . . . . . . . . . . . . . .26
Replacin
g the HEPA filter . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Malfunctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Costumer service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Conditions of guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Table of content
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 3
4
Safety information
Congratulations on your purchase of the Bosch GL35
vacuum cleaner. You should only use original Bosch
accessories, which have been specially developed for
your vacuum cleaner, in order to achieve the best possi-
ble vacuuming results.
Pleas
e keep this instruction manual. When passing the
vacuum cleaner on to a third party, please also pass on
this instruction manual.
Intended use
This appliance is intended for domestic use only. This appli-
ance is intended for use up to a maximum height of 2000
metres above s
ea level. Only use this vacuum cleaner in
accordance with the instructions in this instruction manual.
In order to prevent injuries and damage, the vacuum
cleaner must not be used for:
Vacuum-cleaning persons or animals
Vacuuming up:
- hazardous, sharp-edged, hot or glowing substanc
es.
-damp or liquid substances.
- highly flammable or explosive substances and gases.
-ash, soot from tiled stoves and cen tral heating systems.
-toner dust from printers and copiers.
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 4
5
Spare parts, accessories, dust bags
Our original spare parts, original (special) accessories and
original dust bags are designed to work with the features
and requirements of our vacuum cleaners. We therefore
recommend that you only use our original spare parts, ori-
ginal (sp
ecial) accessories and original dust bags. This will
ensure that your vacuum cleaner has a long service life and
that the quality of its cleaning performance will remain con-
sistently high throughout.
! Please note
Using unsuitable or inferior-quality spare parts, (special)
accessories and dust bags can da
mage your vacuum cle-
aner. Damage caused by the use of such products is not
covere d by our guarantee.
Safety information
This vacuum cleaner complies with the recognised
rules of technology and the relevant safety regulations.
The appliance may be used by children over th
e age of
8 years and by persons with reduced physical,
sensory or mental capacity or by persons with a lack
of experience or knowledge if they are supervised or
have been instructed on the safe use of the appliance
and the have understood the potential dangers of
using the appliance.
Children must never play with the appliance.
Safety information
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 5
Cleaning and user maintenance must never be carried
out by children without supervision.
Plastic bags and films must be kept out of the reach
of children before disposal. => Risk of suffocation.
Proper use
Only connect and use the vacuum cleaner in accordan-
ce with the specification
s on the rating plate.
Never vacuum without the dust bag or dust container,
motor protection or exhaust filter.
=> This may damage the vacuum cleaner.
Always keep the vacuum cleaner away from your head
when using nozzles and tubes.
=> This could cause injury!
When vacuumin
g stairs, the appliance must always be
positioned below the user.
Do not use the power cord or the hose to carry or
transport the vacuum cleaner.
For safety reasons, if this appliance's mains power
cable becomes damaged, it must be replaced by the
m
anufacturer, their after-sales service department or a
similarly qualified person.
If using the appliance for longer than 30 minutes, pull
out the power cord completely.
When disconnecting the appliance from the mains, pull
on the plug itself to remove it; do not pull on the power
cord.
Do not pull the power cord over sharp edges or allow
it to become trapped.
6
Safety information
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 6
7
When the cable is being automatically rewound, ensu-
re that the mains plug is not thrown towards persons,
body parts, animals or objects.
=> Use the mains plug to guide the power cord.
Pull out the mains plug before carrying out any work on
the vacuum cleaner.
Do not operate the vacuum cleaner if it is damaged.
Unplug the appliance from the mains if a fault is detec-
ted.
For safety reasons, only authorised after-sales service
personnel are permitted to carry out repairs and fit
replacement parts to the vacuum cleaner
.
Protect the vacuum cleaner from the weather, moistu-
re and sources of heat.
Do not pour flammable substances or substances con-
taining alcohol onto the filters (dust bag, motor pro-
tection filter, exhaust filter, etc.).
The vacuum cleaner is not suitable
for use on con-
struction sites.
=> Vacuuming up building rubble could damage the
appliance.
When not in use, switch off the appliance and pull out
the mains plug.
At the end of its life, the appliance should immediately
be rendered unusable, then disposed of in an appro-
pr
iate manner.
Safety information
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 7
8
Safety information
!Please note
The mains socket must be protected by at least a 16 amp cir-
cuit breaker.
If a circuit breaker is tripped when you switch on the vacuum
cleaner, this may be because other electrical appliances which
have a high curr e nt draw are connected to the same power cir-
cuit.
To pre
vent the circuit breaker from tripping, select the lowest
power setting before switching the appliance on, and increase
the power only once it is running.
Accessories
Your accessories (nozzle, suction pipe, etc.) may look different
from but work in the same way as those depicted in the illust-
rations in this instruction manual.
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 8
9
This vacuum cleaner is a general purpose vacuum cleaner with a
primary hose.
To achieve the declared energy efficiency and cleaning
performance class on carpet and hard floor, please use the
interchangeable universal nozzle.
The
se calculations are based on the Commission Delegated
Regulation (EU) No. 665/2013 of 3rd May 2013 supplementing
Directive 2010/30/EU. Unless otherwise stated, all the proce-
dures referred to in these instructions were carried out in
accordance with the EN 60312-1:2017* standard.
*As the motor service test is carried out with the dust collector
empty, the stated motor service life must be increased by 10% fo
r
tests with the dust collector half filled.
Notes on the energy label
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 9
10
Your vacuum cleaner
10
16
17
1
7
6
5
98 10
1311 14 15
2
4
3
12
18
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 10
11
Adjustable floor tool with
locking collar
Telescopic tube
Flexible hose
Hose hand grip
Power cord
Parking aid
Exhaust grille
Dust bag
Exhaust filter
Motor protection filter
1
2
3
4
5
8
9
6
7
10
Your vacuum cleaner
Carrying handle
Storage aid (on
underside of appliance)
Dust bag compartment
lid
Dust bag change
indicator
On/off button and power
controller
Upholstery nozzle
Crevice nozzle (only
BGL35MOV21)
Hard floor tool
13
14
15
16
17
12
11
18
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 11
12
A
A Hard floor tool BBZ123HD
For vacuuming hard floors (parquet, tiles,
terracotta, etc.)
Special accessories
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 12
13
Replacement parts
B Replacement filter package
Type G ALL PowerProtect Dustbag
Sparepart No.: 00577549
Contents:
- 4 dust bags with fasteners
- 1 micro-hygiene filter
!
PLEASE NOTE
We therefore recommend that you only
use our original dust bags.
Your appliance is a highly efficient
vacuum cleaner that achieves excellent
cleaning results when used with high-
quality dust bags. Only by using high-
quality dust bags (such as Bosch original
dust bags) can you ensure that your
vacuum cleaner is working at the energy
effici
ency class, dust pick-up rate and
dust retention capacity listed on its EU
energy label.
The use of inferior-quality dust bags (e.g.
paper bags) can have a negative effect
on the service life and performance of
your appliance. Using unsuitable or
inferior-quality dust bags can also
damage
your vacuum cleaner. Such
damage is not covered by our guarantee.
You can find more information about this
at www.bosch-home.com/dust-bag
.
You can order our original vacuum
cleaner bags here.
B
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 13
14
Replacement parts
D
DHEPA-filter
Replacement part no.: 00576833
Additional filter for cleaner exhaust air.
Recommended for allergy suffer ers.
Replace once a year.
C
C Motor protecting filter
Replacement part no.: 00577117
Protects the motor in your vacuum clea-
ner and thus increases its service life.
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 14
15
Putting the handle and the
flexible hose together
Figure
● Push the hand grip onto the
flexible hose and lock it in place.
1
Initial use
Inserting the flexible hose
Figure
● Push the flexible hose adapter into
the air intake opening in the
vacuum cleaner lid until it locks in
place.
2
1
Click!
2
Putting the handle and the
telescopic tube together
Figure
● Push the hand grip into the teles-
copic tube until it engages.
3
3
Click!
Click!
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 15
Adjusting the telescopic tube
Figure
● Move the adjusting sleeve in the
direction of the arrow to unlock
the telescopic tube and adjust it
to the length required.
5
16
Initial use
4
Inserting the telescopic tube into
the floor tool
Figure
● Push the telescopic tube into the
connecting piece of the floor tool
until it locks in place.
4
Click!
5
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 16
17
Connecting the appliance
Figure
● Holding the power cord by the
plug, pull out to the required
length and insert the plug into
the mains socket.
6
6
Initial use
GA_8001 061 296_GL35 17.03.2017 13:49 Seite 17
18
8
Controlling the suction level
Figure
Turn the rotary control to infinite-
ly adjust the suction level to the
level required.
min -For vacuuming curtains and
delicate textiles
-For vacuuming upholster ed
furniture and cushions
-For vacuuming delicate rugs
und fo
r daily vacuuming of
lightly soiled floors
-For vacuuming durable floor
coverings
max - For vacuuming hard floors
and heavily soiled rugs and
carpets
8
7
Switching on and off
Figure
● Press the ON/OFF button in the
direction of the arrow to switch
your vacuum cleaner on.
7
Initial use
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 18
19
Vacuuming
Adjusting the floor tool
Figure
Rugs and carpets =>
hard floors=>
If you are vacuuming up relatively
large particles, make sure that you
vacuum them up successively and
carefully to ensure that the vacuum
channel of the floor tool does not
become blocked. If necessary, you
should raise the nozzl
e in order to
better vacuum up the dirt particles.
9
! Please note:
Floor tools are subject to a certain
amount of wear, depending on the
type of hard floor you have (e.g.
rough, rustic tiles). Therefore, you
must check the underside of the floor
tool at regular intervals. Worn under-
sides of floor tools may have sharp
edges that can damage sensitive hard
floors, such as parquet or linoleum.
The manufacturer does not accept
any responsibility for damage caused
by worn floor tools.
9
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 19
10
Vacuuming with accessories
Figure
● Attach the nozzles to the suction
pipe or handle as required:
Crevice nozzle
(only for BGL35MOV21)
a) Crevice nozzle for vacuuming
crevices and corners, etc.
10
a)
b)
20
Vacuuming
Upholstery nozzle
b)Upholstery nozzle for vacuuming
upholstered furniture, curtains,
etc.
Hard floor nozzle
c) For vacuuming hard floor coverings
(tiles, parquet flooring, etc.)
● Push the telescopic tube into the
connecting piece of the hard floor
nozzle until it locks in place.
● To release the connection, press
the locking collar and pull out the
telescopic tube.
c)
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 20
21
Parking aid
Figure
● You can use the parking aid on the
back of the vacuum cleaner if you
wish to stop vacuuming for a short
time.
● Once you have switched off the
appliance, slide the hook on the
floor tool into the recess on the rear
of the appliance.
11
Carrying the appliance
Figure
● To overcome obstacles, e.g. steps,
the appliance can also be carried by
the handle on the appliance body.
13
Vacuuming
13
11
12
Vacuuming stairs
Figure
When vacuuming on stairs, the
appliance must be positioned at
the beginning of the stairs.
Depending on the staircase, 12 to
16 steps can be vacuumed with
the telescopic tube, handle and
floor nozzle installed.
12
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 21
22
When the work is done
Storing and transporting
Figure
To store/transport the appliance,
you can use the storage aid on the
underside of the appliance.
● Stand the appliance upright on its
end.
● Slide the hook on the floor tool
into the recess on the underside of
the appliance.
15
15
14
Disconnecting the appliance
Figure
● Pull out the mains plug.
14
1
2
●
Briefly pull the power cord and
release (The power cord rewinds
automatically).
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 22
23
Dismantling
Removing the flexible hose
Figure
• To remove the flexible hose,
press the two catches together
and pull out the hose.
16
16
1
1
Disconnecting handle and
telescopic tube
Figure
• To release the connection, press
the locking collar and pull out
the telescopic tube.
17
Disconnecting floor nozzle and
telescopic tube
Figure
• To release the connection, press
the locking collar and pull out
the telescopic tube.
18
18
1
2
2
17
1
1
2
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 23
24
Changing the filter
Please note: Always switch off the
appliance before changing the filter.
Replacing the bag
Figure
● If the dust bag change indicator in
the lid is filled completely when
the floor tool is lifted from the floor
with the highest suction level
selected, the dust bag must be
changed, even though it may not
yet be full. Even if the dust bag is
not full, it may still need changing,
du
e to the type of dust which has
been vacuumed.
First check that the nozzle, suction
pipe and flexible hose are not
blocked, as this would also lead to
the dust bag change indicator
being triggered.
19
Opening the lid
Figure
● Unlock the lid by pulling on the
locking lever in the direction of the
arrow.
● Open the lid in the direction of the
arrow.
20
19
20
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 24
25
Changing the filter
Changing the dust bag
You can order a ne w dust bag from
our after-sales service using the fol-
lowing replacement part number:
00577549.
Figure
● Seal the dust bag by pulling the
sealing plate, and remove the
bag.
● Dispose the old dust bag over
household waste.
● Insert the new dust bag into the
holder as far as the stop. As you
do this, leave it folded up, as it is
when removed from its packag-
ing. Unfold the dust bag in the
dust bag compartment as far as
possible. When closing the dust-
bag compartment lid, make sure
that the dust bag is not trapped.
21
Caution: the dust bag compart-
ment lid will only close when the
dust bag or textile dust bag is
inserted.
If the dust bag change indicator
is still lit after the dust bag has
been changed, please check
whether the nozzle, tube or fle-
xible hose are blocked.
21
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 25
2
1
2
2
1
Click!
26
Changing the filter
Changing the motor protection
filter
Figure
● Open the dust bag compartment
lid. Figure
● Release the motor protection fil-
ter from the catch by pulling it
sideways, and pull it out in the
direction of the arrow
● Dispose the old motor protection
filter over household waste.
● Refit the motor protection filter
into the appliance, lock it in
place and close the dust bag
compartment lid.
22
20
22
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 26
27
Your HEPA filter is generally
washable, but we recommend
changing the filter for more
hygienic handling.
Replacing the HEPA filter
If your vacuum cleaner is equipped
with a HEPA filter, this should be
replaced once a year.
Figure
● Open the dust bag compartment
lid.
Figure
●
Unlock the HEPA filter by moving
the locking lever in the direction
of the arrow and remove the
filter from the appliance.
!
N
Note:
If you tap the filter and
then wash it out, the filter have
to dry for at least 24 hours
before resetting the filter.
● Insert the new HEPA filter and
lock it in place.
If you have vacuumed up fine dust
particles, replace if necessary the
motor protection filter and the
HEPA filter.
23
20
Changing the filter
23
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 27
28
Always switch off the vacuum cleaner and disconnect it from
the mains before cleaning the vacuum cleaner. The vacuum
cleaner and plastic accessories can be cleaned with a
commercially available plastic cleaner.
The dust compartment can, if necessary, be cleaned with a
se
cond vacuum cleaner or simply wiped with a dry cloth or
dusting brush.
Subject to technical modifications.
Care
Caution: Do not use a scourer, glass-cleaning agent or
all-purpose cleaning product. Never immerse the
vacuum cleaner in water.
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 28
29
This appliance is labelled in accordance
with European Directive 2012/19/EU
concerning used electrical and electro-
nic appliances (waste electrical and
electronic equipment - WEEE). The gui-
deline determines the framewo
rk for the
return and recycling of used appliances
as applicable throughout the EU.
Disposal
Disposal information
Packaging
The packaging is designed to protect the vacuum cleaner from
being damaged during transportation. It is made of
environmentally friendly materials and can therefore be
recycled.
Dispose of packaging that is no longer required at an
appropriate re
cycling collection point.
Old appliances
Old appliances still contain many valuable materials.
Therefore, please take your old appliances to your retailer or
recycling centre for recycling.
For current disposal methods, please enquire at a retailer or
your local council.
Disposal of filters
and dust bags
Filters and dust bags are manufactured from environmentally fri-
endly materials. Provided that they do not contain substances
that are not permitted in household waste, you can dispose of
them with your normal household waste.
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 29
30
Malfunctions
In the following cases, you must stop the appliance immediately
and contact the after-sales service:
If the power cord is damaged.
If you have accidentally vacuumed up some liquid or liquid has
entered the inside of the appliance;
If the appliance has been dropped and damaged.
In these
cases, the electrical safety of the appliance could no
longer be guaranteed, even if no external damage is visible.
Occuring
malfunction
Possible
cause
Corrective action
The circuit breaker
is tripped when
you switch on the
vacuum cleaner.
Other electrical appli-
ances which have a
high current draw are
connected to the
same power circuit.
Please select the lowest power
setting before switching the aplli-
ance on and increase the power
only once it is running.
Suction power is
reducing.
Nozzle, suction pipe
and / or suction
hoses are blocked.
Please separate the telescopic
tube from the hose and nozzle and
the suction device and handle.
Slide along the telescopic tube.
Loosen and remove the obstruc-
tion.
Dust bag is full. Please replace the dust bag.
Hepa filter is dirty. Please replace the HEPA filter. You
can order a new filter from our
aftersales service using the follo-
wing order no.: 00576833
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 30
31
GB Great Britain
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton
Milton Keynes MK12 5PT
To arrange an engineer visit, to order spare parts and accessories
or for product advice please visit:
www.bosch-home.co.uk
or call
Tel.: 0344 892
8979*
*Calls are charged at the basic rate, please check with your telephone service
provider for exact charges.
Customer Service
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 31
32
For this appliance the guarantee conditions as set out by our
representatives in the country of sale apply. Details regarding
same may be obtained from the dealer from whom the applian-
ce was purchased. For claims under guarantee the sale
s receipt
must be produced.
Conditions of guarantee
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 32
33
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 33
34
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 34
35
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 35
Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München
Germany
www.bosch-home.com
9000 897 085 – 06/13
8001061296 970316
GA_8001 061 296_GL35 17.03.2017 13:50 Seite 36
