Use and Care Manual for Dishwasher

QUICK START GUIDE

• Please read the corresponding content on the instruction manual for detailed operating method.

Connecting to Power and Drain

• The power supply is 120VAC 60Hz. The specification of the socket is 10A 120VAC.
• The connection of the drain pipe: Put end of the drain into a sink or bucket.
• Please make sure drain hose is positioned in the proper space (I.E sink, bucket, etc) to avoid leakage

Adding Water To Dishwasher Tank

• Before adding water, you need to press power button to turn on the dishwasher.
• There are two ways to add water into the tank

1. Connect inlet hose to the tap (sink house included for hookup)
2. Open the cap and add water into the dishwasher tank

• There are two ways of knowing the tank is filled and ready to use :

1. Before starting - When the tanks is filled the machine will beep for 3 seconds (5L - approximately 3 pitchers)
2. After Starting - If there is not enough water the water icon will appear on the panel. If there is enough water the water icon light will be off and the machine will beep for 3 seconds.

• To Force Drain - In standby mode, you can press and hold “GLASS” button + “AIR REFRESH” button for 3 seconds simultaneously to drain the water tank.

Note: Make sure the hose is fastened tightly. and there is no leakage. Switch off the faucet at the end of program.

Loading the Dishwasher

• Please remove large residue from items before placing in the complete washer.

• Open the dishwasher door. Place dishes in order of size starting with two sides to the middle. All cutlery are suggested to be tilted to improve cleaning performance. The arm will be blocked with the improper placement of the cutlery and cleaning effect may not be ideal.

Try to leave the dirty facing toward the spray arm.

• Add the detergent. Pods, liquid or powder detergent all acceptable.
• When washing fruit, do NOT add detergent.

Close the Door, Select the Program and Start the Dishwasher

• Please make sure drain hose is positioned in the proper space (I.E sink, bucket, etc) to avoid leakage.

GETTING TO KNOW YOUR APPLIANCE

IMPORTANT:

• Before using this dishwasher for the first time and to get the best performance, read these instructions.

DISHWASHER FEATURES

CONTROL PANEL

LOADING THE DISHWASHER BASKETS

Not suitable for use:

• Certain cutlery with wooden or mother of pearl handles
• Plastic items that are not heat resistant
• Non heat resistent bonded cutlery or China
• Pewter or Copper items
• Delicate crystal
• Steel or silver items subject to rusting or discoloration
• Wooden items
• Glazed items may fade

For the best performance of the dishwasher, follow these loading guidelines.

• Scrape off any large food particles.
• Soften remnants of burnt food in pans.
• It is not necessary to rinse all dishes under running water.
• Place objects in the dishwasher in following way:

Load hollow items such as cups, glasses, pans etc. with the opening facing downwards

Curved items, or those with recesses, should be loaded at aslant so that water can run off.

All utensils are placed in the way that the spray arms can rotated freely during washing.

• Very small items should not be washed in the dishwasher as they could fall out.
• Dishes and items of cutlery must not lie inside one another, or cover each other.
• To avoid damage to glasses, they must not be touch.
• Take precautions with large cutlery so that blades do not touch the dishwasher components. It may be necessary to place some large cutlery horizontally.
• Do not overload the dishwasher. Position the dishes and cookware so that they will not get moved by the spray of water.

Recommended loading layout with 1 serving bowl and 2 settings personal tableware

• Folding Down the Rack Shelves
• The spikes are used for holding plates and a platter. They can be lowered to make more room for large items.
• Folding down to load large size tableware or fruit basket or baby bottle rack.

DETERGENT USE

Only use detergent made specifically for dishwashers. Do not use rinse aids. Dishwasher detergent is corrosive! Keep away from children.

Use long programs when using Detergent tablets. Short programs may not allow the tablets to fully dissolve.

• The use of Normal washing program in combination with Low alkaline concentrated detergents with natural enzymes reduces pollution and is good for your dishes.
• The detergent must be refilled before the start of each wash cycle. Your dishwasher uses less detergent than traditional dishwashers. Generally, only one tablespoon of detergent is needed for a normal wash load. Always add the detergent just before starting the dishwasher otherwise it could get damp and will not dissolve properly.

WASH CYCLE

• The table below shows which programs are bet for each cleaning job and how much detergent is needed.

Note: Fruit wash program need to fill with water below 86°F manually, to keep the freshness in shap.

STARTING A WASH CYCLE:

1. Load the basket( according to guidelines in the "Loading the Dishwasher" section.
2. Load the detergent according the "Wash cycle table”and "Adding Detergent" section.
3. Insert the plug into the socket. The power supply is 120VAC 60HZ
4. Press the power button to turn on the appliance,
5. Connect the inlet hose to the tap, make sure that the water supply is turned on to full pressure, or add water the tank manually.
6. Select a suitable program according to the “Wash cycle table”
7. When a program is selected, the appropriate light will illuminate.
8. Press the Start/ Pause button and the machine will start.
9. To pause the dishwasher press the Start/Pause button. An alarm will sound every minute until the button is pressed again to restart the wash cycle.

TO CHANGE A WASH CYCLE:

1. A wash cycle can only be changed if it has been running for a short time prior to detergent being released and water being drained.
2. Press the Start/Cancel button to pause the washing.
3. Then press and hold the Press Start/Cancel for more than 3 seconds, the machine will go into stand by mode.
4. Press a new program button to select the desired program

FORGET TO ADD A DISH?

You can only add a dish if the dishwasher has been running for a short time prior to detergent being released and water being drained.

1. Press the Start/Cancel button Or open the door a little to stop the washing cycle. When the door is opened the machine will pause.
2. After the spray arms stop working, you can open the door completely.
3. Add forgotten dishes.
4. Close the door.
5. Press the Start/Cancel button, the dishwasher will run .
6. NOTE: It is dangerous to open the door when washing, has commenced because the hot water may scald you.

WHEN THE CYCLE IS COMPLETE

When the cycle has finished. the buzzer will sound for 8 seconds. then stop. Turn off the appliance using the ON/OFF button. shut off the water supply and open the door of the dishwasher. Wait a 15 minutes before unloading the dishwasher to avoid burning yourself. as the dishes and utensils are still hot.

Switch OFF the Dishwasher

1. Switch off the dishwasher by pressing the ON/OFF button.
2. Turn off the water tap!
3. NOTE: When unloading the dishwasher it is normal that a small bit of water will remain.

FILTER

• Never use the dishwasher without filters! The performance may be affected and dishes and utensils could become damaged.
• Make sure the filter is properly assembled.
• The entire filter assembly should be cleaned once a week. Remove food remnants and clean the filters under running water.
• The filter efficiently removes food particles from the wash water, allowing it to be recycled during the cycle. For best performance and results, the filter assembly must be cleaned regularly. For this reason, it is a good idea tore move the larger food particles trapping in the filter after each wash cycle by rinsing the filter and cup under running water.

STEP 1: Rotate the filter assembly counter-clockwise, then lift up

STEP 2: Lift the fine filter up from the main filter

CARING FOR THE DISHWASHER

• The control panel and exterior be cleaned by using a lightly dampened cloth. After cleaning, make sure to dry it thoroughly. .Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher. To remove spots or stains from the surface of the interior, use a cloth dampened with water an a little vinegar,
• To clean the edge around the door, you should use only a soft warm, damp cloth. Avoid penetration of water into the door lock and electrical components.
• Never use a spray cleaner to clean the door panel as it may damage the door lock and electrical components. Abrasive agents or some paper towel should not be used because of the risk of scratching or leaving spots on the stainless steel surface. Protect against freezing
• Take the following frost protection measures for he dishwasher operation in winter.
• After each wash cycle perform the following:

1. Cut the power to the unit
2. Turn off the water supply and disconnect the water inlet pipe from the water valve.
3. Drain water from the inlet pipe and water valve (Use a pan to catch the water).
4. Remove the filter at the bottom and use a soft cloth to soak up any residual water.
5. If your dishwasher cannot work because of the ice, please contact authorised service person.

CLEANING THE SPRAY ARMS

• The spray arms can be easily removed for periodic cleaning of the nozzles to prevent possible clogging. Wash them under running water and carefully replace them in their seats, checking that their rotary movement is in no way impeded.
• Grasp the middle of the spray arm, pull it upwards to remove it. Wash the arms under a jet of running water and replace it carefully to its seat. After reassembly, check that the spray arms rotate freely. Otherwise, check that they have been installed correctly

GENERAL TIPS

• Before cleaning or performing maintenance, always remove the plug.
• After every wash, turn off the water supply to the appliance and leave the door slightly ajar.
• When not in use for a longtime - It is recommend that you run a wash cycle with the dishwasher empty and then remove the plug from the socket, turn off the water supply and leave the door of the appliance slightly open. This will help the door seals to last longer and prevent odors.
• Moving the appliance - If the appliance must be moved, try to keep it in the vertical position.
• Installation preparation - The installation position of dishwasher should be near the existing water inlet tap. One side of the cabinet sink should be chosen to facilitate the connection of drain hoses of the dishwasher.
• Water connection - Connect the hot water supply hose to a threaded 3/4 (inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the water is clear and free of impurities. If this precaution is not taken, there is a risk that the water inlet can get blocked and damage the appliance.

Please Note: If the supplied hose does not fit your tap, you may need to contact a plumbing supply company for an adapter.

CONNECTION OF DRAIN HOSES

• The drain hose must be correctly fitted to avoid water leaks. Ensure that the water drain hose is not kinked or in any way impeded.
• How to drain excess water from hoses - If the sink is higher than the surface where you have placed your dishwasher it will be necessary to It will be necessary to drain excess water in to a bucket that is lower than the dishwasher position.
• If you need a drain hose extension, make sure to use a similar drain hose an no longer than 12 feet otherwise the cleaning effect of the dishwasher could be reduced.

TROUBLESHOOTING
