Samsung UN55NU8000FXZA 55" Class NU8000 Premium Smart 4K UHD TV

User Manual

For UN55NU8000FXZA. Series: Serie 8

PDF File Manual, 24 pages, Read Online | Download pdf file

UN55NU8000FXZA photo
background
8 SERIES
Thank you for purchasing this Samsung product.
To receive more complete service, please register your product at www.samsung.com
Model Serial No.
If you have any questions, please call us at 1-800-SAMSUNG (1-800-726-7864) for assistance.
USER MANUAL
Loading page 2...
Loading page 3...
Loading page 4...
Loading page 5...
Loading page 6...
Loading page 7...
Loading page 8...
Loading page 9...
Loading page 10...
Loading page 11...
Loading page 12...
Loading page 13...
Loading page 14...
Loading page 15...
Loading page 16...
Loading page 17...
Loading page 18...
Loading page 19...
Loading page 20...
Loading page 21...
Loading page 22...
Loading page 23...
Loading page 24...

Other documents for Samsung UN55NU8000FXZA

The following documents are available:
User Manual Installation Instruction
  • Quick Setup Guide - (English) Download
Photos

Specifications

Samsung UN55NU8000FXZA Questions and Answers

Find answers or Ask a question.


  • Total questions: 2
  • Questions unAnswered : 2

Q: Why did my. Screen go away.
I can still hear it just can't see it Reply

Q: What size are the four screws that attach the stand to the back of the tv? Reply

User Manual - Transcript

  • Page 1 - English - : 8 SERIES Thank you for purchasing this Samsung product To receive more complete service please register your product at wwwsamsungcom Model Serial No If you have any questions please call us at 1800SAMSUNG 18007267864 for assistance USER MANUAL
  • Page 2 - English - : Before Reading This User Manual This TV comes with this user manual and an embedded eManual Before reading this user manual review the following User Manual Read this provided user manual to see information about product safety installation accessories initial configuration and product specifications eManual For more information about this TV read the eManual embedded in the product To open the eManual gt Settings gt Support gt Open eManual Scan this QR code with your smart device to visit Samsungs online Customer Service Center You can also visit the site httpwwwsamsungcomussupport on your PC On the website you can download the user manual and see its contents on your PC or mobile device Learning the eManuals assistance functions Search Select an item from the search results to load the corresponding page Index Select a keyword to navigate to the relevant page Recently Viewed Topics Select a topic from the list of recently viewed topics Some menu screens cannot be accessed from the eManual Learning the functions of the buttons that appear on eManual topic pages Try Now Access the associated menu item and try out the feature directly Link Access an underlined topic referred to on an eManual page immediately English 2 English
  • Page 3 - English - : Warning Important Safety Instructions Please read the Safety Instructions before using your TV CAUTION Class II product This symbol indicates that a safety connection to electrical earth ground is not required RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER OR BACK THERE ARE NO USER SERVICEABLE PARTS INSIDE REFER ALL SERVICING TO QUALIFIED PERSONNEL AC voltage Rated voltage marked with this symbol is AC voltage This symbol indicates that high voltage is present inside It is dangerous to make any kind of contact with any internal part of this product DC voltage Rated voltage marked with this symbol is DC voltage This symbol indicates that this product has included important literature concerning operation and maintenance Caution Consult instructions for use This symbol instructs the user to consult the user manual for further safety related information The slots and openings in the cabinet and in the back or bottom are provided for necessary ventilation To ensure reliable operation of this apparatus and to protect it from overheating these slots and openings must never be blocked or covered Do not place this apparatus in a confined space such as a bookcase or builtin cabinet unless proper ventilation is provided Do not place this apparatus near or over a radiator or heat register or where it is exposed to direct sunlight Do not place vessels vases etc containing water on this apparatus as this can result in a fire or electric shock Do not expose this apparatus to rain or place it near water near a bathtub washbowl kitchen sink or laundry tub in a wet basement or near a swimming pool etc If this apparatus accidentally gets wet unplug it and contact an authorized dealer immediately This apparatus uses batteries In your community there might be environmental regulations that require you to dispose of these batteries properly Please contact your local authorities for disposal or recycling information Do not overload wall outlets extension cords or adaptors beyond their capacity since this can result in fire or electric shock Powersupply cords should be placed so that they are not likely to be walked on or pinched by items placed upon or against them Pay particular attention to cords at the plug end at wall outlets and at the point where they exit from the appliance To protect this apparatus from a lightning storm or when left unattended and unused for long periods of time unplug it from the wall outlet and disconnect the antenna or cable system This will prevent damage to the set due to lightning and power line surges English 3
  • Page 4 - English - : Before connecting the AC power cord to the DC adaptor outlet make sure that the voltage designation of the DC adaptor corresponds to the local electrical supply Never insert anything metallic into the open parts of this apparatus This may cause a danger of electric shock To avoid electric shock never touch the inside of this apparatus Only a qualified technician should open this apparatus Be sure to plug in the power cord until it is firmly seated When unplugging the power cord from a wall outlet always pull on the power cords plug Never unplug it by pulling on the power cord Do not touch the power cord with wet hands If this apparatus does not operate normally in particular if there are any unusual sounds or smells coming from it unplug it immediately and contact an authorized dealer or service center Be sure to pull the power plug out of the outlet if the TV is to remain unused or if you are to leave the house for an extended period of time especially when children elderly or disabled people will be left alone in the house Accumulated dust can cause an electric shock an electric leakage or a fire by causing the power cord to generate sparks and heat or by causing the insulation to deteriorate Be sure to contact an authorized Samsung service center for information if you intend to install your TV in a location with heavy dust high or low temperatures high humidity chemical substances or where it will operate 24 hours a day such as in an airport a train station etc Failure to do so may lead to serious damage to your TV Use only a properly grounded plug and wall outlet An improper ground may cause electric shock or equipment damage Class l Equipment only To turn off this apparatus completely disconnect it from the wall outlet To ensure you can unplug this apparatus quickly if necessary make sure that the wall outlet and power plug are readily accessible Store the accessories batteries etc in a location safely out of the reach of children Do not drop or strike the product If the product is damaged disconnect the power cord and contact a Samsung service center To clean this apparatus unplug the power cord from the wall outlet and wipe the product with a soft dry cloth Do not use any chemicals such as wax benzene alcohol thinners insecticide air fresheners lubricants or detergents These chemicals can damage the appearance of the TV or erase the printing on the product Do not expose this apparatus to dripping or splashing Do not dispose of batteries in a fire Do not shortcircuit disassemble or overheat the batteries There is danger of an explosion if you replace the batteries used in the remote with the wrong type of battery Replace only with the same or equivalent type WARNING TO PREVENT THE SPREAD OF FIRE KEEP CANDLES AND OTHER ITEMS WITH OPEN FLAMES AWAY FROM THIS PRODUCT AT ALL TIMES Use care when touching the TV after it has been on for some time Some parts can be warm to the touch State of California Proposition 65 Warning WARNING This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm English 4
  • Page 5 - English - : Internet security Samsung takes a number of steps to protect its Internetcompatible Smart TVs against unauthorized incursions and hacking For example certain sensitive communications between the TV and the Internet servers are encrypted In addition the TVs operating system has adopted controls to prevent the installation of unauthorized applications Although we take steps to protect your Smart TV and personal information no Internetconnected device or transmission is completely secure We therefore encourage you to take additional steps to safeguard your TV secure your Internet connection and minimize the risk of unauthorized access These steps are listed below When Samsung releases software updates to improve the security of your TV you should promptly install these updates To automatically receive these updates turn on Auto Update in the TVs menu gt Settings gt Support gt Software Update gt Auto Update When an update is available a popup message appears on the TV screen Accept the software download and update by selecting YES when prompted Take steps to secure your wireless router and network Your routers manual should provide additional details about how to implement the following measures Secure your wireless routers management settings with a unique password to prevent unauthorized changes to security related settings Implement standard encryption eg WPA2 encryption on your wireless router to secure your wireless network signal Secure access to your wireless network with a hardtoguess password Confirm your routers firewall setting is enabled if so equipped Make sure that all your Internetconnected devices are behind your networks firewall If your router or modem has a standby mode button use it to disconnect your home network from the Internet when it is not in use Use strong passwords for all your Internet accounts Netflix Facebook etc If your TV has a camera recess the camera into the TVs bezel when it is not in use Recessing the camera makes it inoperative If any unexpected messages appear on your TV screen requesting permission to link a device or enable a remote session do NOT accept Do not visit suspicious web sites and do not install any suspicious programs We recommend that users install only those authorized apps provided by Samsung through Samsung Smart Hub Figures and illustrations in this User Manual are provided for reference only and may differ from the actual product appearance Product design and specifications may change without notice English 5
  • Page 6 - English - : Contents English 6 Before Reading This User Manual 2 Warning Important Safety Instructions 3 01 TV Installation Mounting the TV on a wall 7 Providing proper ventilation for your TV 8 Safety Precaution Securing the TV to the wall to prevent falling 9 02 The Samsung Smart Remote About the Buttons on the Samsung Smart Remote 10 Pairing the TV to the Samsung Smart Remote 11 Installing batteries into the Samsung Smart Remote 11 03 Initial Setup Using the TV Controller 12 04 Troubleshooting and Maintenance Troubleshooting 13 What is Remote Support 14 Eco Sensor and screen brightness 15 Caring for the TV 15 05 Specifications and Other Information Specifications 16 Environmental Considerations 17 Decreasing power consumption 17 Dimensions 18 Licenses 18 FCC and Warranty Information Federal Communication Commission Interference Statement 19 LIMITED WARRANTY TO ORIGINAL PURCHASER 20
  • Page 7 - English - : 01 TV Installation Mounting the TV on a wall If you mount this TV on a wall follow the instructions exactly as set out by the manufacturer Unless it is correctly mounted the TV may slide or fall and cause serious injury to a child or adult and serious damage to the TV For models providing wall mount adapters install them as shown in the figure below before installing the wall mount kit Refer to the installation manual included with the Samsung wall mount kit TV TV Wall mount bracket Wall mount bracket C C Wall mount Adapter Wall mount Adapter Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you choose to install the wall mount on your own To order the wall mount kit contact Samsung Customer Care at 1800SAMSUNG 18007267864 You can install your wall mount on a solid wall perpendicular to the floor Before attaching the wall mount to surfaces other than plaster board contact your nearest dealer for additional information If you install the TV on a ceiling or slanted wall it may fall and result in severe personal injury When installing a wall mount kit we recommend you fasten all four VESA screws If you want to install a wall mount kit that attaches to the wall using two top screws only be sure to use a Samsung wall mount kit that supports this type of installation You may not be able to purchase this type of wall mount kit depending on the geographical region Standard dimensions for wall mount kits are shown in the table below If you are installing a thirdparty wall mount note that the length of the screws you can use to attach the TV to the wall mount is shown in column C in the table below TV size in inches VESA screw hole specs A B in millimeters C mm Standard Screw Pitch mm Quantity 4955 200 x 200 4345 M8 125 46575 400 x 400 82 600 x 400 English 7
  • Page 8 - English - : Do not install your wall mount kit while your TV is turned on This may result in personal injury from electric shock Do not use screws that are longer than the standard dimension or do not comply with the VESA standard screw specifications Screws that are too long may cause damage to the inside of the TV set For wall mounts that do not comply with the VESA standard screw specifications the length of the screws may differ depending on the wall mount specifications Do not fasten the screws too firmly This may damage the product or cause the product to fall leading to personal injury Samsung is not liable for these kinds of accidents Samsung is not liable for product damage or personal injury when a nonVESA or nonspecified wall mount is used or when the consumer fails to follow the product installation instructions Do not mount the TV at more than a 15 degree tilt Always have two people mount the TV onto a wall Providing proper ventilation for your TV When you install your TV maintain a distance of at least 4 inches between the TV and other objects walls cabinet sides etc to ensure proper ventilation Failing to maintain proper ventilation may result in a fire or a problem with the product caused by an increase in its internal temperature When you install your TV with a stand or a wall mount we strongly recommend you use parts provided by Samsung Electronics only Using parts provided by another manufacturer may cause difficulties with the product or result in injury caused by the product falling English 8
  • Page 9 - English - : Safety Precaution Securing the TV to the wall to prevent falling Caution Pulling pushing or climbing on the TV may cause the TV to fall In particular ensure your children do not hang on or destabilize the TV This action may cause the TV to tip over causing serious injuries or death Follow all safety precautions provided in the Safety Flyer included with your TV For added stability and safety you can purchase and install the antifall device as described below WARNING Never place a television set in an unstable location The television set may fall causing serious personal injury or death Many injuries particularly to children can be avoided by taking simple precautions such as Using cabinets or stands recommended by the manufacturer of the television set Only using furniture that can safely support the television set Ensuring the television set is not overhanging the edge of the supporting furniture Not placing the television set on tall furniture for example cupboards or bookcases without anchoring both the furniture and the television set to a suitable support Not placing the television set on cloth or other materials that may be located between the television set and supporting furniture Educating children about the dangers of climbing on furniture to reach the television set or its controls If you are retaining and relocating the television set that you are replacing with this new set you should apply the same precautions to the old set When you have to relocate or lift the TV for replacement or cleaning be sure not to pull out the stand Preventing the TV from falling 1 Using the appropriate screws firmly fasten a set of brackets to the wall Confirm that the screws are firmly attached to the wall You may need additional material such as wall anchors depending on the type of wall 2 Using the appropriately sized screws firmly fasten a set of brackets to the TV For the screw specifications refer to quotStandard Screwquot in the table on page 7 3 Connect the brackets fixed to the TV and the brackets fixed to the wall with a durable heavyduty string and then tie the string tightly Install the TV near the wall so that it does not fall backwards Connect the string so that the brackets fixed to the wall are at the same height as or lower than the brackets fixed to the TV lt4975 inchesgt lt82 inchesgt English 9
  • Page 10 - English - : 02 The Samsung Smart Remote About the Buttons on the Samsung Smart Remote The images buttons and functions of the Samsung Smart Remote may differ depending on the model Power Press to turn the TV on or off Number button When pressed a number strip appears on the bottom of the screen Select numbers and then select Done to enter a numeric value Use to change the channel enter a PIN enter a ZIP code etc Return Returns to the previous menu When pressed for 1 second or more the running function is terminated When pressed while you are watching a program the previous channel appears Playpause When pressed the playback controls appear Using these controls you can control the media content that is playing Smart Hub Returns to the Home Screen VOL Volume Move the button up or down to adjust the volume To mute the sound press the button When pressed for 1 second or more the Accessibility Shortcuts menu appears CH Channel Move the button up or down to change the channel To see the Guide screen press the button Directional pad updownleftright Moves the focus and changes the values seen on the TVs menu Select Selects or runs a focused item When pressed while you are watching content detailed program information appears Bixby Runs Bixby Press and hold the button say a command and then release the button to run Bixby When you press the button the Enter My Bixby menu appears at the bottom of the screen Keep the remote more than 06 inches from your face when using and speaking to Bixby through the mic on the remote For more information about the Bixby refer to Smart Features gt Using Bixby in the eManual Color button Use these colored buttons to access additional options specific to the feature you are using English 10
  • Page 11 - English - : Pairing the TV to the Samsung Smart Remote When you turn on the TV for the first time the Samsung Smart Remote pairs to the TV automatically If the Samsung Smart Remote does not pair to the TV automatically point it at the remote control sensor of the TV and then press and hold the buttons labeled and as shown in the figure on the left simultaneously for 3 seconds or more Installing batteries into the Samsung Smart Remote To install the batteries push the rear cover open in the direction of the arrow in the illustration on the left and then insert the batteries as shown in the figure Make sure that the positive and negative ends are facing in the correct direction Alkaline batteries are recommended for longer battery life English 11
  • Page 12 - English - : 03 Initial Setup When you turn on your TV for the first time it immediately starts the Initial Setup Follow the instructions displayed on the screen and configure the TVs basic settings to suit your viewing environment Noise may occur temporarily when the TV communicates with mobile devices The SmartThings app is available on mobile devices for Android 60 or higher and iOS 10 or higher To perform initialization by using the SmartThings app the mobile device must have been connected via WiFi When the popup for setup does not appear automatically on the SmartThings app of your mobile device proceed with the process after manually adding the TV using Add Device on the dashboard of the SmartThings app Using the TV Controller You can turn on the TV with the TV Controller button at the bottom of the TV and then use the Control menu The Control menu appears when the TV Controller is pressed while the TV is On For more information about its usage refer to the figure below TV Controller Remote control sensor Press Move Press amp Hold Select The TV Controller is located on the bottom of the TV Control menu Power Off Volume Up Channel Up Volume Down Channel Down Source English 12
  • Page 13 - English - : 04 Troubleshooting and Maintenance Troubleshooting If the TV seems to have a problem first review this list of possible problems and solutions Alternatively review the Troubleshooting Section in the eManual If none of the troubleshooting tips apply visit wwwsamsungcomsupport or call Samsung Customer Service at 1800SAMSUNG 18007267864 For detailed information on troubleshooting watch the troubleshooting videos at wwwsamsungcomspsn This TFT LED panel is made up of sub pixels which require sophisticated technology to produce There may be however a few bright or dark pixels on the screen These pixels will have no impact on the performance of the product To keep your TV in optimum condition upgrade to the latest software Use the Update Now or Auto Update functions on the TVs menu gt Settings gt Support gt Software Update gt Update Now or Auto Update The TV wont turn on Make sure that the AC power cord is securely plugged in to the TV and the wall outlet Make sure that the wall outlet is working and the power indicator at the bottom of the TV is lit and glowing a solid red Try pressing the Power button on the TV to make sure that the problem is not with the remote control If the TV turns on refer to Remote control does not work below There is no picturevideosound or a distorted picturevideosound from an external device or Weak or No Signal is displayed on the TV or you cannot find a channel Make sure the connection to the device is correct and that all cables are fully inserted Remove and reconnect all cables connected to the TV and the external devices Try new cables if possible Confirm that the correct input source has been selected gt Source Perform a TV self diagnosis to determine if the problem is caused by the TV or the device gt Settings gt Support gt Self Diagnosis gt Start Picture Test or Start Sound Test If the test results are normal reboot the connected devices by unplugging each devices power cord and then plugging it in again If the issue persists refer to the connection guide in the user manual of the connected device If you are not using a cable box or satellite box and your TV is receiving TV signals from an antenna or a cable wall connector run Auto Program to search for channels gt Settings gt Broadcasting gt Auto Program The remote control does not work Check if the power indicator at the bottom of the TV blinks when you press the remotes Power button If it does not replace the remote controls batteries Make sure that the batteries are installed with their poles in the correct direction Try pointing the remote directly at the TV from 5 ft to 6 ft 1518 m away If your TV came with a Samsung Smart Remote Bluetooth Remote make sure to pair the remote to the TV The cable box or satellite box remote control doesnt turn the TV on or off or adjust the volume Program the cable box or satellite box remote control to operate the TV Refer to the cable box or satellite box user manual for the SAMSUNG TV code English 13
  • Page 14 - English - : The TV settings are lost after 5 minutes The TV is in the Retail Mode Change the Usage Mode in the System Manager Menu to Home Mode gt Settings gt General gt System Manager gt Usage Mode gt Home Mode Intermittent WiFi Make sure the TV has a network connection gt Settings gt General gt Network gt Network Status Make sure the WiFi password is entered correctly Check the distance between the TV and the ModemRouter The distance should not exceed 50 ft 152 m Reduce interference by not using or turning off wireless devices Also verify that there are no obstacles between the TV and the ModemRouter The WiFi strength can be decreased by appliances cordless phones stone walls fireplaces etc Single story Multi story Wireless router Wireless repeater Contact your Internet Service Provider ISP and ask them to reset your network circuit to reregister the Mac addresses of your new ModemRouter and the TV Video App problems Youtube etc Change the DNS to 8888 Select gt Settings gt General gt Network gt Network Status gt IP Settings gt DNS Setting gt Enter manually gt DNS Server gt enter 8888 gt OK Reset by selecting gt Settings gt Support gt Self Diagnosis gt Reset Smart Hub What is Remote Support Samsung Remote Support service offers you oneonone support with a Samsung Technician who can remotely Diagnose your TV Adjust the TV settings for you Perform a factory reset on your TV Install recommended firmware updates How does Remote Support work You can easily get Samsung Remote Support service for your TV 1 Call the Samsung Contact Center and ask for remote support 2 Open the menu on your TV and then go to the Support section gt Settings gt Support 3 Select Remote Management then read and agree to the service agreements When the PIN screen appears provide the PIN number to the technician 4 The technician will then access your TV English 14
  • Page 15 - English - : Eco Sensor and screen brightness Eco Sensor adjusts the brightness of the TV automatically This feature measures the light in your room and optimizes the brightness of the TV automatically to reduce power consumption If you want to turn this off go to gt Settings gt General gt Eco Solution gt Ambient Light Detection If the screen is too dark while you are watching TV in a dark environment it may be due to the Ambient Light Detection function The eco sensor is located at the bottom of the TV Do not block the sensor with any object This can decrease picture brightness Caring for the TV If a sticker was attached to the TV screen some debris can remain after you remove the sticker Please clean the debris off before watching TV The exterior and screen of the TV can get scratched during cleaning Be sure to wipe the exterior and screen carefully using a soft cloth to prevent scratches Do not spray water or any liquid directly onto the TV Any liquid that goes into the product may cause a failure fire or electric shock To clean the screen turn off the TV then gently wipe away smudges and fingerprints on the panel with a microfiber cloth Clean the body or panel of the TV with a microfiber cloth dampened with a small amount of water After that remove the moisture with a dry cloth While cleaning do not apply strong force to the surface of the panel because it can damage the panel Never use flammable liquids benzene thinner etc or a cleaning agent For stubborn smudges spray a small amount of screen cleaner on a microfiber cloth and then use the cloth to wipe away the smudges English 15
  • Page 16 - English - : 05 Specifications and Other Information Specifications Model Name UN49NU8000 UN49NU800D UN55NU8000 UN55NU800D Display Resolution 3840 x 2160 3840 x 2160 Screen Size Diagonal Measured Diagonally 49 Class 485 inches 55 Class 546 inches Sound Output 40 W 40 W Dimensions W x H x D Body With stand 430 x 250 x 22 inches 10916 x 6346 x 549 mm 430 x 280 x 118 inches 10916 x 7110 x 2997 mm 483 x 280 x 22 inches 12271 x 7107 x 549 mm 483 x 310 x 127 inches 12271 x 7871 x 3220 mm Weight Without Stand With Stand 289 lbs 131 kg 331 lbs 150 kg 377 lbs 171 kg 417 lbs 189 kg Model Name UN65NU8000 UN65NU800D UN75NU8000 UN75NU800D Display Resolution 3840 x 2160 3840 x 2160 Screen Size Diagonal Measured Diagonally 65 Class 645 inches 75 Class 745 inches Sound Output 40 W 40 W Dimensions W x H x D Body With stand 569 x 328 x 22 inches 14463 x 8338 x 549 mm 569 x 358 x 138 inches 14463 x 9101 x 3498 mm 659 x 380 x 23 inches 16738 x 9641 x 576 mm 659 x 410 x 145 inches 16738 x 10408 x 3692 mm Weight Without Stand With Stand 534 lbs 242 kg 582 lbs 264 kg 794 lbs 360 kg 873 lbs 396 kg English 16
  • Page 17 - English - : Model Name UN82NU8000 UN82NU800D Display Resolution 3840 x 2160 Screen Size Diagonal Measured Diagonally 82 Class 815 inches Sound Output 40 W Dimensions W x H x D Body With stand 720 x 415 x 24 inches 18300 x 10540 x 609 mm 720 x 451 x 152 inches 18300 x 11446 x 3872 mm Weight Without Stand With Stand 981 lbs 445 kg 1008 lbs 457 kg Environmental Considerations Operating Temperature Operating Humidity Storage Temperature Storage Humidity 50F to 104F 10C to 40C 10 to 80 noncondensing 4F to 113F 20C to 45C 5 to 95 noncondensing Notes Design and specifications are subject to change without prior notice This device is a Class B digital apparatus For information about the power supply and more information about power consumption refer to the information on the label attached to the product On most models the label is attached to the back of the TV On some models the label is inside the cover terminal Typical power consumption is measured according to Energy Star Program requirements for televisions Your TV and its accessories may look different than the product images presented in this manual depending on the model All drawings are not necessarily to scale Some dimensions are subject to change without prior notice Refer to the dimensions before installing your TV Not responsible for typographical or printed errors To connect a LAN cable use a CAT 7 STP type cable for the connection Shielded Twist Pair 2018 Samsung Electronics America Inc Dispose unwanted electronics through an approved recycler To find the nearest recycling location go to our website wwwsamsungcomrecyclingdirect or call 877 278 0799 Decreasing power consumption When you shut the TV off it enters Standby mode In Standby mode it continues to draw a small amount of power To decrease power consumption unplug the power cord when you dont intend to use the TV for a long time English 17
  • Page 18 - English - : Dimensions Port panel detail Rear view The displayed image may differ from your TV depending on the model Unit inches Model name 1 2 3 UN49NU8000 UN49NU800D 48 17 5 119 UN55NU8000 UN55NU800D 7 8 201 119 UN65NU8000 UN65NU800D 48 205 119 UN75NU8000 UN75NU800D 99 250 119 The displayed image may differ from your TV depending on the model Unit inches Model name 1 2 3 UN82NU8000 UN82NU800D 151 241 103 Licenses The terms HDMI and HDMI HighDefinition Multimedia Interface and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries English 18
  • Page 19 - English - : FCC and Warranty Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions may cause harmful interference to radio communications However there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception which can be determined by turning the equipment off and on the user is encouraged to try to correct the interference by one of the following measures Reorienting or relocating the receiving antenna Increasing the separation between the equipment and receiver Connecting the radio or TV to an outlet that is on a different circuit than the equipment Consulting the dealer or an experienced radioTV technician for help FCC Caution Any changes or modifications not expressly approved by the party responsible for compliance could void the users authority to operate this equipment This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions 1 This device may not cause harmful interference and 2 this device must accept any interference received including interference that may cause undesired operation For products available in the US and Canadian markets only channels 111 are available You cannot select other channels This device and its antennas must not be colocated or operated in conjunction with any other antenna or transmitter FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment This equipment should be installed and operated so there is at least 8 inches 20 cm between the radiator and your body English 19
  • Page 20 - English - : LIMITED WARRANTY TO ORIGINAL PURCHASER This SAMSUNG brand product as supplied and distributed by SAMSUNG and delivered new in the original carton to the original consumer purchaser is warranted by SAMSUNG against manufacturing defects in materials and workmanship for period of Categories Parts Labor Size Service LCDLED TV 1 Year 1 Year 42quot and Larger CarryIn or In Home 40quot and Smaller CarryIn For commercial use the warranty is 90 Days Parts and Labor This limited warranty begins on the original date of purchase and is valid only on products purchased and used in the United States To receive warranty service the purchaser must contact SAMSUNG for problem determination and service procedures Warranty service can only be performed by a SAMSUNG authorized service center The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNGs authorized service center SAMSUNG will repair or replace this product at our option and at no charge as stipulated herein with new or reconditioned parts or products if found to be defective during the limited warranty period specified above All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG Replacement parts and products assume the remaining original warranty or ninety 90 days whichever is longer Certain products are eligible for Inhome service at Samsungs discretion To receive inhome service the product must be unobstructed and accessible to service personnel If during inhome service repair cannot be completed it may be necessary to remove repair and return the product If inhome service is unavailable SAMSUNG may elect at our option to provide for transportation of our choice to and from a SAMSUNG authorized service center Otherwise transportation to and from the SAMSUNG authorized service center is the responsibility of the purchaser This limited warranty covers manufacturing defects in materials and workmanship encountered in normal and except to the extent otherwise expressly provided for in this statement noncommercial use of this product and shall not apply to the following including but not limited to damage which occurs in shipment delivery and installation applications and uses for which this product was not intended altered product or serial numbers cosmetic damage or exterior finishes accidents abuse neglect fire water lightning or other acts of nature use of products equipment systems utilities services parts supplies accessories applications installations repairs external wiring or connectors not supplied or authorized by SAMSUNG which damage this product or result in service problems incorrect electrical line voltage fluctuations and surges customer adjustments and failure to follow operating instructions cleaning maintenance and environmental instructions that are covered and prescribed in the instruction book reception problems and distortion related to noise echo interference or other signal transmission and delivery problems or brightness related to normal aging or any other issues if the TV is used for commercial or nonnormal consumer use SAMSUNG does not warrant uninterrupted or errorfree operation of the product English 20
  • Page 21 - English - : THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE AND NO WARRANTIES WHETHER EXPRESS OR IMPLIED INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE AND NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY PERSON FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS OR ANY OTHER SPECIAL INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE MISUSE OR INABILITY TO USE THIS PRODUCT REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE WITHOUT LIMITING THE FOREGOING PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS DAMAGE OR INJURY TO PURCHASER AND PURCHASERS PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages so the above limitations or exclusions may not apply to you This warranty gives you specific legal rights and you may also have other rights which vary from state to state To obtain warranty service please contact SAMSUNG at Samsung Electronics America Inc 85 Challenger Road Ridgefield Park NJ 076602112 1800SAMSUNG 7267864 wwwsamsungcom The benefits of this Limited Warranty extend only to the original purchaser of Samsung products from an authorized Samsung reseller THIS LIMITED WARRANTY SHALL NOT APPLY TO ANY SAMSUNG PRODUCTS PURCHASED FROM UNAUTHORIZED RESELLERS OR RETAILERS EXCEPT IN STATES WHERE SUCH RESTRICTION MAY BE PROHIBITED For a list of Samsung authorized retailers please go to httpwwwsamsungcomuspeaceofmindauthorizedresellers html English 21
  • Page 22: This page is intentionally left blank
  • Page 23: This page is intentionally left blank
  • Page 24 - English - : Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products please contact the SAMSUNG customer care center Country Customer Care Center Web Site Address CANADA 1800SAMSUNG 7267864 wwwsamsungcomca support English wwwsamsungcomcafr support French Samsung Electronics Canada Inc 2050 Derry Road West Mississauga Ontario L5N 0B9 Canada USA 1800SAMSUNG 7267864 wwwsamsungcomus support Samsung Electronics America Inc 85 Challenger Road Ridgefield Park NJ 07660 accessibility contact information in USA accessibilityseasamsungcom Scan the QR code to view our helpful howto videos Scan this QR code with your smart phone to see helpful videos If you experience issues please do not take the TV back to the store In the United States of America call us at 1800SAMSUNG 18007267864 or visit us at wwwsamsung com or wwwsamsungcomspsn for support and warranty service For more information see quotTroubleshootingquot in this manual 2018 Samsung Electronics Co Ltd All rights reserved
