Samsung WF435AT Front Load Washer

User Manual - Transcript

• Page 1 - English - : Washing Machine user manual Imagine the possibilities Thank you for purchasing this Samsung product WF435AGJ This manual is made with 100 recycled paper WF435A03159B06ENindd 1 201433 102412
• Page 2 - English - : 2 key features of your new Smart PowerFoam washer key features of your new Smart PowerFoam washer 1 VRT PLUS Vibration Reduction Technology This Samsung washer minimizies noise and vibration with dual 3D vibration sensors and smart control technology ensuring quiet operation 2 The Largest Capacity Samsungs extralarge capacity laundry machine can wash a full set of your bedding a kingsize comforter or up to 32 bath towels in a single load Since you dont have to do as many loads you save time money water and energy 3 PowerFoam Samsungs effective PowerForm delivers improved cleanliness with advanced fabric care PowerFoam allows detergent to distribute evenly and penetrate fabrics faster and deeper 4 PureCycleTub Cleaning cycle Clean your drum with one button This Pure Cycle is specially designed to remove detergent residue amp dirt bulidup in the tub diaphragm and door glass without the need for special chemical detergents 5 SpeedSpray Samsungs new Speed Spray technology saves you up to 25 more time when doing laundry by shortening wash times while still keeping all segments of the washing process and getting your clothes clean Based on 8 pounds loads Normal cycle under Normal Soil level without any options on previous and existing 43 cuft Samsung front loading washers released until 2011 without Speed Spray Speed Spray performs in Normal Bedding PLUS Deep Steam Stain Away and Eco Cold cycle and the saving time may vary by cycles and various load and option compositions 6 Deep steam The Deep Steam feature boosts cleaning performance and loosens grime and dirt thus providing superior cleaning results 7 Smart Care Samsungs Smart Care an automatic errormonitoring system detects and diagnoses problems at an early stage and provides a quick and easy solution With the innovative Smart Control technology you can also be alerted when the problem occurs via your smart phones 8 Stylish design The stylish design of this washer blends well with your environment 9 Digital Display amp Center jog dial The Jog dial enables you to select cycles in both directions with ease and the display is easy to use and understand WF435A03159B06ENindd 2 201433 102412
• Page 3 - English - : key features of your new Smart PowerFoam washer 3 10 DD Motor The power to handle anything Our directdrive inverter motor delivers power right to the washer tub from a variable speed reversible motor A beltless directdrive motor generates a higher spin speed of 1300rpm for more effective quiter operation The washer also has fewer moving parts meaning fewer repairs 11 Sanitize When selecting this cycle the water heats to an extra high temperature to remove 999 of certain bacteria typically found on clothing bedding or towels This certification is conducted by NSF International an independent thirdparty testing and certification organization Please check the garment care label to avoid garment damage Only sanitizing cycles have been designed to meet the requirements of this protocol for sanitization efficacy 12 Pedestal with Storage Drawers Model No WE357 An optional 15 pedestal is available to raise the washer for easier loading and unloading It also offers a builtin storage drawer that can hold a 100 oz bottle of detergent 13 Stacking Model No SK5AXAA Samsung washers and dryers can be stacked to maximize usable space An optional stacking kit is available for purchase from your Samsung retailer ltPedestal with Storage Drawersgt ltStackinggt NSF Protocol P172 Sanitization Performance of Residential and Commercial FamilySized Clothes Washers WF435A03159B06ENindd 3 201433 102413
• Page 4 - English - : 4 safety information safety information Congratulations on your new Samsung washer This manual contains important information on the installation use and care of your appliance Please take time to read this manual to take full advantage of your washers many benefits and features WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS The Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur It is your responsibility to use common sense caution and care when installing maintaining and operating your washer IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS What the icons and signs in this user manual mean WARNING Hazards or unsafe practices that may result in severe personal injury or death To reduce the risk of fire explosion electric shock or personal injury when using your washer follow these basic safety precautions CAUTION Hazards or unsafe practices that may result in minor personal injury or property damage Do NOT attempt Do NOT disassemble Do NOT touch Follow directions explicitly Unplug the power plug from the wall socket Make sure the machine is grounded to prevent electric shock Call the service center for help Note These warning signs are here to prevent injury to you and others Please follow them explicitly After reading this section keep it in a safe place for future reference SAVE THESE INSTRUCTIONS WF435A03159B06ENindd 4 201433 102413
• Page 5 - English - : safety information 5 SAVE THESE INSTRUCTIONS WARNING To reduce the risk of fire electric shock or injury to persons when using your appliance follow basic precautions including the following 1 Read all instructions before using the appliance 2 Do not wash or dry articles that have been previously cleaned in washed in soaked in or spotted with gasoline drycleaning solvents other flammable or explosive substances as they give o vapors that could ignite or explode 3 Do not allow children to play on or in the appliance Close supervision of children is necessary when the appliance is used near children 4 Before the appliance is removed from service or discarded remove the door to the washing or drying compartment 5 Do not reach into the appliance if the drum is moving 6 Do not install or store this appliance where it will be exposed to the weather 7 Do not tamper with controls 8 Do not repair or replace any part of the appliance or attempt any servicing unless specifically recommended in the usermaintenance instructions or in published userrepair instructions that you understand and have the skills to carry out 9 Do not add gasoline drycleaning solvents or other flammable or explosive substances to the wash water These substances give o vapors that could ignite or explode 10 Under certain conditions hydrogen gas may be produced in a hot water system that has not been used for 2 weeks or more HYDROGEN GAS IS EXPLOSIVE If the hot water system has not been used for such a period before using a washer or combination washerdryer turn on all hot water faucets and let the water flow from each for several minutes This will release any accumulated hydrogen gas As the gas is flammable do not smoke or use an open flame during this time State of California Proposition 65 Warnings WARNINGThis product contains chemicals known to the State of California to cause cancer and reproductive toxicity WARNING WARNING WF435A03159B06ENindd 5 201433 102413
• Page 6 - English - : 6 safety information safety information SAVE THESE INSTRUCTIONS CRITICAL INSTALLATION WARNINGS Plug the power cord into an AC 120 V 60 Hz 15 A wall socket or higher and use the socket for this appliance only In addition do not use an extension cord Sharing a wall socket with other appliances using a power strip or using an extension cord may result in electric shock or fire Do not use an electric transformer It may result in electric shock or fire Ensure that the voltage frequency and amperage provided at the wall socket match the power specifications of the product The installation of this appliance must be performed by a qualified technician or service company Failing to do so may result in electric shock fire an explosion problems with the product or injury Remove all foreign substances such as dust or water from the power plug terminals and contact points using a dry cloth on a regular basis Unplug the power plug and clean it with a dry cloth Failing to do so may result in electric shock or fire Plug the power plug into the wall socket in the right direction so that the cord runs towards the floor If you plug the power plug into the socket in the opposite direction the electric wires within the cable may be damaged and this may result in electric shock or fire This appliance must be properly grounded Do not ground the appliance to a gas pipe plastic water pipe or telephone line Improper grounding may result in electric shock fi re an explosion or problems with the product Never plug the power cord into a socket that is not grounded correctly and make sure that it is in accordance with local and national codes Do not install this appliance near a heater or inflammable material Do not install this appliance in a humid oily or dusty location or in a location exposed to direct sunlight and water rain drops Do not install this appliance in a location where gas may leak This may result in electric shock or fire Plug the power plug into the wall socket firmly Do not use a damaged power plug damaged power cord or loose wall socket This may result in electric shock or fire Do not pull or excessively bend the power cord Do not twist or tie the power cord Do not hook the power cord over a metal object place a heavy object on the power cord insert the power cord between objects or push the power cord into the space behind the appliance This may result in electric shock or fire WARNING WF435A03159B06ENindd 6 201433 102413
• Page 7 - English - : safety information 7 SAVE THESE INSTRUCTIONS Do not pull the power cord when unplugging the power plug Unplug the power plug by holding the plug Failing to do so may result in electric shock or fire If the power plug or power cord is damaged contact your nearest service center INSTALLATION CAUTIONS Position the appliance so that the power plug is easily accessible Failing to do so may result in electric shock or fire due to electric leakage Install your appliance on a level and hard floor that can support its weight Failing to do so may result in abnormal vibrations noise or problems with the product Unplug the power plug when the appliance is not being used for long periods of time or during a thunderlightning storm Failing to do so may result in electric shock or fire CRITICAL USAGE WARNINGS If the appliance is flooded cut the power immediately and contact your nearest service center If the appliance emits a strange noise a burning smell or smoke unplug the power plug immediately and contact your nearest service center Failing to do so may result in electric shock or fire In the event of a gas leak such as propane gas LP gas etc ventilate immediately without touching the power plug Do not touch the appliance or power cord Do not use a ventilating fan A spark may result in an explosion or fire Do not wash items contaminated with gasoline kerosene benzene paint thinner alcohol or other flammable or explosive substances This may result in electric shock fire or an explosion Do not open the washer door by force while the washer is operating hightemperature washingdryingspinning Water flowing out of the washer may result in burns or cause the floor to be slippery This may result in injury Opening the door by force may result in damage to the product or personal injury Make sure to remove the packaging sponge styrofoam attached to the bottom of the washer before using it Do not insert your hand under the washer This may result in injury CAUTION WARNING WF435A03159B06ENindd 7 201433 102413
• Page 8 - English - : 8 safety information safety information SAVE THESE INSTRUCTIONS Do not touch the power plug with wet hands This may result in electric shock Do not turn the appliance o by unplugging the power plug while an operation is in progress Plugging the power plug into the wall socket again may cause a spark and result in electric shock or fire Keep all packaging materials well out of the reach of children as packaging materials can be dangerous to children If a child places a bag over its head it may result in suocation Do not let children or infirm persons use this washer unsupervised Failing to do so may result in electric shock burns or injury Do not insert your hand or a metal object under the washer while it is operating This may result in injury Make sure the detergent drawer is closed before you put laundry into the washer or remove laundry from the washer If the detergent drawer is open you could strike the drawer with your head and injure yourself Do not attempt to repair disassemble or modify the appliance yourself Do not use any fuse such as cooper steel wire etc other than the standard fuse If you need to repair or reinstall the appliance contact your nearest service center Failing to do so may result in electric shock fire problems with the product or injury If water has enters the appliance anywhere but the drum unplug the power plug and contact your nearest service center Failing to do so may result in electric shock or fire When the water supply hose comes loose from the faucet and floods the appliance unplug the power plug Failing to do so may result in electric shock or fire If any foreign substance enters the appliance unplug the power plug and contact you nearest service center Failing to do so my result in electric shock or fire USAGE CAUTIONS If the the washer is contaminated by a foreign substance such as detergent dirt food waste etc unplug the power plug and clean the washer using a damp soft cloth Failing to do so may result in discoloration deformation damage or rust If struck hard the front glass can break Take care when using the washer If the glass is broken it may result in injury CAUTION WF435A03159B06ENindd 8 201433 102413
• Page 9 - English - : safety information 9 SAVE THESE INSTRUCTIONS After a water supply failure or when reconnecting the water supply hose open the faucet slowly Open the faucet slowly after a long period of nonuse The air pressure in the water supply hose or the water pipe may result in damage to a part or in water leakage If a drain error occurs during an operation check if there is a drainage problem If the washer is used when it is flooded because of a drainage problem it may result in electric shock or fire due to electric leakage Insert the laundry into the washer completely so that laundry does not get caught in the door If laundry gets caught in the door it may result in damage to the laundry or the washer or result in water leakage Ensure that the faucet is turned o when the washer is not being used Ensure that the screw on the water supply hose connector is firmly connected to the faucet and properly tightened Failing to do so may result in property damage or injury Take care that the Rubber Seal and the Front Door Glass are not contaminated by a foreign substance eg waste thread hair etc If a foreign substance is caught in the door or the door is not completely closed it may cause water leakage Open the faucet and check if the water supply hose connector is firmly tightened and that there is no water leaking before using the product If the water supply hose connectors are loose it may result in water leakage The product you have purchased is designed for domestic use only The use for business purposes qualifi es as product misuse In this case the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse If the wash is not performed and the laundry is left for a period of time after adding detergent or applying stain remover or pretreatment onto the laundry the laundry may be discolored Select the recommended cycle and temperature on the basis of the laundry items sort the laundry by color on the basis of its colorfastness and select the appropriate cycle Make sure that foreign objects such as pins buttons and coins are removed from clothing items when adding laundry into the washer Wash dirty laundry separately from relatively clean items and wash fragile items separately from tougher textiles If an item is stained wash it as fast as possible Use stain remover or detergent only after testing the colorfastness of the item by applying a small quantity to an inside seam WF435A03159B06ENindd 9 201433 102413
• Page 10 - English - : 10 safety information safety information SAVE THESE INSTRUCTIONS Do not stand on top of the appliance or place objects such as laundry lighted candles lighted cigarettes dishes chemicals metal objects etc on the appliance This may result in electric shock fire problems with the product or injury Do not operate the appliance with wet hands This may result in electric shock Do not spray volatile material such as insecticide onto the surface of the appliance As well as being harmful to humans it may also result in electric shock fire or problems with the product Do not place an object that generates a electromagnetic field near the washer This may result in injury due to a malfunction Since the water drained during a hightemperature wash or drying cycle is hot do not touch the water This may result in burns or injury Do not wash spin or dry waterproof seats mats or clothing Do not wash thick hard mats even if the washer mark is on the care label This may result in injury or damage to the washer walls floor or clothing due to abnormal vibrations Woolen bedding rain covers fishing vests ski pants sleeping bags diaper covers sweat suits and bicycle motor cycle car covers etc Do not operate the washer when the detergent box is removed This may result in electric shock or injury due to water leakage Do not touch the inside of the tub during or just after drying as it is hot This may result in burns Do not insert your hand into the detergent dispenser after opening it This may result in injury as your hand may be caught Do not place any nonlaundry objects such as shoes food waste or animals into the washer This can cause abnormal vibrations that can damage the washer and in the case of pets cause severe injury or death Do not press the buttons using sharp objects such as pins knifes fingernails etc This may result in electric shock or injury Do not wash laundry contaminated by oils creams or lotions usually found in skincare shops or massage clinics This may result in the rubber seal becoming deformed and water leakage Do not leave metal objects safety pins hair pins etc or bleach in the tub for long periods of time This may cause the tub to rust If rust appears on the surface of the tub apply a neutral cleansing agent to the surface and use a sponge to clean it Never use a metal brush WF435A03159B06ENindd 10 201433 102413
• Page 11 - English - : safety information 11 SAVE THESE INSTRUCTIONS Do not use dry cleaning detergent directly and do not wash rinse or spin laundry contaminated by dry cleaning detergent This may result in spontaneous combustion or ignition due to the heat from the oxidation of the oil Do not use hot water from water coolingheating devices This may result in problems with the washer Do not use natural handwashing soap in the washer If it hardens and accumulates inside the washer it may result in problems with the product discoloration rust or bad odors Do not wash large laundry items such as bedding in the washing net Failing to do so may result in injury due to abnormal vibrations Place smaller items such as lace socks and lingerie in the washing net Do not use hardened detergent If it accumulates inside the washer it may cause water leakage Do not wash throw rugs or doormats If you wash throw rugs or doormats sand will accumulate inside the washer It may result in errors such as no draining Take care that childrens fingers are not caught in the door when closing it This may result in injury CRITICAL CLEANING INSTRUCTIONS Do not clean the appliance by spraying water directly onto it Do not use the strong acid cleaning agent Do not use benzene thinner or alcohol to clean the appliance This may result in discoloration deformation damage electric shock or fire Before cleaning or performing maintenance unplug the appliance from the wall socket Failing to do so may result in electric shock or fire WARNING WF435A03159B06ENindd 11 201433 102413
• Page 12 - English - : 12 contents contents INSTALLING YOUR WASHER 14 Unpacking your washer 14 Overview of your washer 15 Electrical 15 Grounding 15 Water 15 Drain facility 16 Flooring 16 Location considerations 16 Alcove or closet installation 16 Undercounter installationwasher only 17 With optional pedestal base or stacking kit 18 Important note to installer 18 Installation flow chart OPERATING INSTRUCTIONS 21 Loading your washer 21 Getting started WASHING A LOAD OF LAUNDRY 22 Overview of the control panel 24 Delay Start 25 Child Lock 26 Spin Only 26 Drum Light 26 Garment 26 My cycle 26 DEEP STEAM 27 Smart Care 28 Washing clothes using the cycle selector 28 ATC Auto Temperature Control 29 Detergent use 29 Features WF435A03159B06ENindd 12 201433 102413
• Page 13 - English - : contents 13 MAINTAINING YOUR WASHER 31 Cleaning the exterior 31 Cleaning the interior 32 Cleaning the dispensers 32 Storing your washer 33 Cleaning the debris filter 34 Cleaning the door sealbellow 34 Preserving the top cover and the front frame 35 Pure Cycle TM TROUBLESHOOTING 36 Check these points if your washer 38 Information codes APPENDIX 40 Fabric care chart 41 Cycle chart 43 Helping the environment 43 Declaration of conformity 43 Specification 01 contents WF435A03159B06ENindd 13 201433 102414
• Page 14 - English - : 14 installing your washer installing your washer UNPACKING YOUR WASHER Unpack your Washer and inspect it for shipping damage Make sure you have received all of the items shown below If your Washer was damaged during shipping or you do not have all of the items contact 1800SAMSUNG7267864 To prevent personal injury or strain wear protective gloves whenever lifting or carrying the unit Packing materials can be dangerous to children keep all packing material plastic bags polystyrene etc well out of the reach of children OVERVIEW OF YOUR WASHER Parts supplied Wrench Bolt hole covers Water supply hoses Hose guide User manual book Plastic zip hose tie Tools needed Pliers Flat screwdriver Adjustable legs Cold water supply hose Hot water supply hose Drain Hose Detergent drawer Control panel Door Tub Debris filter Drain tube Filter cover WARNING WF435A03159B06ENindd 14 201433 102416
• Page 15 - English - : installing your washer 15 BASIC LOCATION REQUIREMENTS Electrical 120 Volt 60 Hz 15 AMP fuse or circuit breaker Individual branch circuit serving only your Washer is recommended Your Washer is equipped with a power cord NEVER USE AN EXTENSION CORD Grounding ELECTRICAL GROUNDING IS REQUIRED ON THIS APPLIANCE This appliance must be grounded In the event of malfunction or breakdown grounding will reduce the risk of electric shock by providing a path of least resistance for electric current This appliance is equipped with a power cord having a threeprong grounding plug for use in a properly installed and grounded outlet The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances Improper connection of the equipmentgrounding conductor can result in a risk of electrical shock Check with a qualified electrician or serviceman if you are in doubt as to whether the appliance is properly grounded Do not modify the plug provided with the appliance if it does not fit the outlet have a proper outlet installed by a qualified electrician IMPORTANT SAFETY PRECAUTIONS To prevent unnecessary risk of fire electrical shock or personal injury all wiring and grounding must be done in accordance with the National Electrical Code ANSIFNPA No 70 Latest Revision and local codes and ordinances It is the personal responsibility of the appliance owner to provide adequate electrical service for this appliance NEVER CONNECT GROUND WIRE TO PLASTIC PLUMBING LINES GAS LINES OR HOT WATER PIPES Water To correctly fill your Washer in the proper amount of time water pressure of 20116 psi 137 800kPa is required Water pressure less than 20 psi may cause water valve failure or may not allow the water valve to shut off completely Or it may extend the fill time beyond what your Washer controls allow resulting in your Washer turning off A time limit is built into the controls in the event of an internal hose becoming loose and flooding your home The water faucets must be within 4 feet122 cm of the back of your Washer for the inlet hoses provided with your Washer Accessory inlet hoses are available in various lengths up to 10 feet305cm for faucets that are further away from the back of your Washer To avoid the possibility of water damage Have water faucets easily accessible Turn off faucets when the washer is not in use Periodically check that there is no leakage from the water inlet hose fittings CHECK ALL CONNECTIONS AT THE WATER VALVE AND FAUCET FOR LEAKS Using hard water or bad quality water may cause the water supply valve to operate abnormally Drain facility The recommended height of the standpipe is 18 in46 cm The drain hose must be routed through the drain hose clip to the standpipe The standpipe must be large enough to accept the outside diameter of the drain hose The drain hose is attached at the factory 01 installing your washer CAUTION WARNING CAUTION CAUTION WARNING WF435A03159B06ENindd 15 201433 102416
• Page 16 - English - : 16 installing your washer installing your washer Flooring For best performance your Washer must be installed on a solidly constructed floor Wood floors may need to be reinforced to minimize vibration andor unbalanced load situations Carpeting and soft tile surfaces are contributing factors in vibration may cause your washer to move slightly during the spin cycle Never install your washer on a platform or weakly supported structure Location considerations Do not install your washer in areas where water may freeze since your washer will always maintain some water in its water valve pump and hose areas This can cause damage to the pump hoses and other components Alcove or closet installation MINIMUM CLEARANCES FOR CLOSET AND ALCOVE INSTALLATIONS Sides 1 in 25 mm Rear 59 in 150 mm Top 17 in 432 mm Closet Front 2 in 51 mm If the washer and dryer are installed together the closet front must have at least a 72 in² 465 cm² unobstructed air opening Your washer alone does not require a specific air opening A Recessed area B Side view closet or confined area Undercounter installationwasher only 1 in 25 cm 1 in 25 cm 1 in 25 cm 27 in 686 cm 27 in 686 cm A 2 in 5 cm 59 in 15 cm 341 in 865 cm 17 in 432 cm B 1 in 25 cm 1 in 25 cm 27 in 686 cm 396 in 1006 cm WF435A03159B06ENindd 16 201433 102417
• Page 17 - English - : installing your washer 17 With optional pedestal base or stacking kit Required Dimensions for Installation With Pedestal Required Dimensions for Installation With Stacking Kit 01 installing your washer 1 in 25 cm 27 in 686 cm 78 in 198 cm 6 in 152 cm Closet or Door 48 in² 310 cm² 24 in² 155 cm² 3 in 76 cm 3 in 76 cm 1 in 25 cm 341 in 865 cm 59 in 15 cm 5 in 127 cm 27 in 686 cm 390 in 99 cm 536 in 1362 cm 59 in 15 cm 341 in 865 cm 512 in 130 cm to clear open door WF435A03159B06ENindd 17 201433 102418
• Page 18 - English - : 18 installing your washer installing your washer IMPORTANT NOTE TO INSTALLER Please read the following instructions carefully before installing your Washer These instructions should be retained for future reference We recommend you hire a professional for installation of this washer Installation flow chart Selecting a location Running a Calibration mode Refer to the following description Finish the installation Removing the shipping bolts Drum only Connecting the water and the drain Adjusting the levelling feet Powering your washing machine Running a test cycle Run a test cycle RinseSpin with small amount of laundary about 45 Towels Yes Please check again before steps No Does your washer have excess vibration or noise STEP 1 Selecting a Location Before you install your washer make sure the location Has a hard level surface without carpeting or flooring that may obstruct ventilation Has no dust oil and detergent etc Is away from direct sunlight Has adequate ventilation Will not freeze below 32 F or 0 C Is away from heat sources such as oil or gas Has enough slack for the power cord Doesnt have any carpeting that will obstruct ventilation openings STEP 2 Removing the Shipping Bolts Before using your Washer you must remove the four shipping bolts from the back of the unit 1 Loosen all the bolts with the supplied wrench 2 Slide the bolt and spacer up and remove the bolt with the spacer through the hole in the rear wall of your washer Repeat for each bolt Fill the holes with the supplied Bolt Hole Covers See page 14 4 Keep the shipping bolts and spacers for future use WF435A03159B06ENindd 18 201433 102419
• Page 19 - English - : installing your washer 19 STEP 3 Installing your Washer 1 Place the drain hose in the drain facility Be sure an airtight connection is NOT made between the drain hose and the standpipe The standpipe must be at least 18 in or 46 cm high Caution must always be exercised to avoid collapsing or damaging the drain hose For best results the drain hose should not be restricted in any way by elbows couplings or excessive lengths For situations where the drain hose cannot be conveniently elevated to at least 18 in or 46 cm the drain hose must be supported If drain hose is installed below 1846cm water can be drained in cycle working cause of siphon phenomenon It causes the washer to nF error Drain Hose can be installed until 96245cm maximum But drain capability can be reduced at this height It causes the washer to have odor because of remained water in the drain system Connection the hose guide within 615cm from the end of the drain hose If the drain hose is extended more than 615cm beyond the end of the hose guide mold or microorganisms could spread to the inside of the washer 2 Check the inlet hose to ensure a washer is inside each fill hose Thread the inlet hoses to the HOT and COLD faucet connections On the other end of the hose check for one rubber washer per hose and install each fill hose to the water valve Make sure the hose with the Hot printed line is attached to the HOT faucet Tighten by hand until snug then twothirds of a turn with pliers 3 Connect the other end of the Hot and Cold water supply hose to the inlet water valve at the rear of the washing machineTighten by hand until snug then twothirds of a turn with pliers For correct water use connect both HOT and COLD water valves If either or both are not connected an nF no fill error can occur 4 Turn on the HOT and COLD water supply and check all connections at the water valve and the faucet for leaks 1RPRUHWKDQ ರFP RVHXLGH 01 installing your washer 96 Max 18 Min 96 Max 18 Min Hose retainer Tie strap Laundry tub Stand pipe Cold Hot Cold printed Hot printed Rubber Washer WF435A03159B06ENindd 19 201433 102421
• Page 20 - English - : 20 installing your washer 5 Slide your washer into position 6 Level your washer by turning the leveling legs in or out as necessary by hand or by using the wrench included with your washer When your washer is level tighten the locking nuts using the wrench or flathead screwdriver 7 Plug the power cord into a 3Prong well grounded 120 volt 60 Hz approved electrical outlet protected by a 15 amp fuse or comparable circuit breaker Your washer is grounded through the third prong of the power cord when plugged into a threeprong grounded receptacle Your Washer must be leveled on all four sides A carpenters level should be used on all four corners of your Washer Its a good idea after the first dozen washes to recheck your washers levelness Avoid damage to the legs Do not move the Washer unless the Lockingnuts are fastened to the bottom of the Washer Test run Make sure that you install your washing machine correctly by running the RinseSpin cycle after the installation is complete STEP 4 Calibration mode Before using Calibration mode be sure to take out all items from the drum Your Samsung washer automatically detects the weight of the laundry For more accurate weight detection please run Calibration Mode after the installation Calibration mode is performed by following the steps below 1 Turn on the washer 2 Press the Temp button and Delay Start button simultaneously at least 3 seconds 3 Remove any contents in the tub and close the door 4 Press the StartPause button to run Calibration Mode 5 The drum rotates clockwise and counterclockwise approximately for for approximately 3 minutes 6 When Calibration Mode is finished the EnEnd appears on the display and the washing machine turns off automatically The washing machine is now ready for use installing your washer Levelling Leg Locking Nut WF435A03159B06ENindd 20 201433 102421
• Page 21 - English - : operating instructions 21 operating instructions LOADING YOUR WASHER You can fill the tub with dry unfolded clothes but DO NOT OVERLOAD the tub Overloading may reduce washing efficiency cause excess wear and possibly cause creasing or wrinkling of the load Wash delicate items such as bras hosiery and other lingerie in the Delicates cycle with similar lightweight items When washing big bulky items or a few smaller items that dont fill the tub completely a rug a pillow stuffed toys or one or two sweaters for example add a few towels to improve tumbling and spin performance During the spin cycle the washer may add additional water to redistribute the excessive imbalance inside the drum When washing heavily soiled loads do not overload your Washer in order to assure good cleaning results To add a forgotten item 1 Press the StartPause Button 2 Wait for the Door Lock light to go out 5 seconds 3 Add the item close the door and press the StartPause Button After a 10second pause the cycle will resume GETTING STARTED 1 Load your Washer 2 Close the door Push the laundry into the drum completely to prevent the laundry from being caught in the door or from falling out of the drum 3 Add detergent and additives to the dispenser see page 29 4 Select the appropriate cycle and options for the load see page 22 5 Press the StartPause Button The drum automatically rotates and measures the weight of the laundry without supplying water in order to adjust the wash time The rotating display on the display panel indicates that the weight of the laundry is being measured 6 The Wash Indicator light will illuminate 7 The estimated cycle time will appear in the display The time may fluctuate to better indicate the time remaining in the cycle The actual time required for a cycle may differ from the estimated time in the display depending on the water pressure water temperature detergent and laundry 8 Before your washer starts to fill it will make a series of clicking noises to check the door lock and do a quick drain When the cycle is complete the Door Lock light will go out and End will appear in the display DO NOT attempt to open the door until the Door Lock light is off To add a forgotten item see Loading your Washer section page 21 When your Washer is restarted after a pause expect a delay of up to 15 seconds before the cycle continues Pressing the Power button cancels the cycle and stops your washer The Pre Wash Wash Rinse and Spin indicator lights will illuminate during those portions of the cycle Do not place anything on top of your washer while it is running 02 operating instructions CAUTION WARNING WF435A03159B06ENindd 21 201433 102422
• Page 22 - English - : 22 washing a load of laundry washing a load of laundry WARNING To reduce the risk of fire electric shock or injury to persons read the IMPORTANT SAFETY INSTRUCTIONS before operating this appliance OVERVIEW OF THE CONTROL PANEL Cycle Selector Select the appropriate cycle for the type of load This will determine the tumble pattern and spin speed for the cycle To minimize wrinkling of laundry select the Perm Press cycle Normal For most fabrics including cottons linens and normally soiled garments Heavy Duty For sturdy colorfast fabrics and heavily soiled garments Bedding PLUS For bulky items such as blankets and sheets When you are washing comforters use liquid detergent Sanitize For heavily soiled colorfast garments This cycle heats the water to 150F to eliminate bacteria If Pause is selected during the heating portion of the Sanitize Cycle your Washer door will remain locked for your safety Stain Away For stained clothes Stain Away cycle provides outstanding stain removal performance with the utmost gentle care avoiding the need for pretreatment of stains For Best stain removal performance it is recommended to use hot temperature option in this cycle in which the wash temperature is increased using the internal heater for overall cleaning of the different stains Deep Steam For heavily soiled colorfast garments this cycle provides high washing temperature and steam and is efficient in cleaning stains Eco Cold It provides useful daily care for normally and lightly soiled laundry by using only cold water saving energy and caring fabric It cleans as effectively as the warm wash setting on conventional Normal cycle under Normal and Light Soil level options Cleaning performance of Eco Cold cycle may not be equal to conventional Normal cycle under heavy soil level option For best result it is recommended to use less than 8 pounds conventional Normal cycle Normal cycle on previous and existing Samsung front loading washers released until 2009 without PowerFoam Perm Press For washandwear synthetic fabrics and lightly to normally soiled garments Active Wear Use this cycle to wash exercise wear such as sports jersey training pants shirtstops and other performance clothing This cycle provides effective soil removal with gentle action for special fabric care 3 4 5 6 1 8 WARNING WF435A03159B06ENindd 22 201433 102422
• Page 23 - English - : washing a load of laundry 23 DelicatesHand Wash For sheer fabrics bras lingerie silk and other handwashonly fabrics For best results use liquid detergent Wool For machinewashable wool Loads should be under 8 pounds For best results we recommend a load of 44 pounds or less The Wool cycle washes laundry by moving the wash drum horizontally to maintain the characteristics of the wool fibers and to prevent damage to the cloth It then stops for a while to allow the laundry to soak in the water This pause in the operation of the Wool cycle is normal We recommend you use a neutral detergent to prevent damage to the cloth and to improve the washing results Quick Wash For lightly soiled garments needed quickly Rinse Spin Use for loads that need rinsing only or to add rinseadded fabric softener to a load Digital Display The large Digital Display is easy to use It provides instructions and diagnostics while keeping you updated on the cycle status and time remaining Temperature selection button Press the button repeatedly to cycle through the different water temperature options Extra Hot Heavily soiled colorfast items Only available with the Sanitize cycle Hot Whites and heavily soiled colorfast items Warm Colorfast items When warm rinse is selected only the final rinse will be warm The other rinses will be cold to conserve energy Eco Warm Moderately soiled colorfast items most wrinklefree items Cold Brightly colored very lightly soiled items Spin selection button Press the button repeatedly to cycle through the different spin speed options Extra High Removes more water from loads during spin To minimize wrinkling of wrinklefree and noiron fabrics DO NOT use the Extra High spin option for these loads nor overload your Washer High Use for underwear tshirts jeans and sturdy cottons Medium Use for jeans wrinklefree or washandwear items and synthetics Low Use for delicate items needing a slow spin speed No Spin Drains your Washer without spinning Use for extremely delicate items that cannot tolerate any spin Soil Level selection button Press the button to select the soil levelwashing time Heavy Normal Light Heavy For heavily soiled loads Normal For moderately soiled loads This setting is best for most loads Light For lightly soiled loads 03 washing a load of laundry WF435A03159B06ENindd 23 201433 102423
• Page 24 - English - : 24 washing a load of laundry Select Cycle Option Press these buttons to select different cycle options Pre Wash To use this feature add detergent to the pre wash section of the detergent compartment When turned on the washer fills with cold water and detergent tumbles then drains and advances to the selected wash cycle Some cycles cannot be selected with with this option You cannot select the prewash option in the Wool Quick Wash DelicatesHandwash and RinseSpin cycles Extra Rinse Add an additional rinse at the end of the cycle to more thoroughly remove laundry additives and perfumes Extra Spin Add additional time to remove more water from loads Signal OnOff When you activate Signal off function the Signal off lamp illuminate My Cycle Choose your favorite cycle including temperature spin soil level option etc Delay Start Any cycle can be delayed for up to 24 hours in onehour increments Displayed hour indicates the time at which the wash will be started Pure Cycle TM Use to clean dirt and bacteria from the drum Regular use after every 40 washes is recommended No detergent or bleach is needed see page 35 Steam Press this button to use the Steam Wash function Steam Wash is available with Normal Heavy Duty Bedding PLUS Sanitize Stain Away cycles For heavily soiled colorfast garments Steam Wash improves stain treatment and uses less water See page 26 StartPause selection button Press to pause and restart programs Power button Press once to turn your washer on press again to turn your washer off If the washer is left on for more than 10 minutes without any buttons being touched the power automatically turns off Delay Start You can set the washing machine to finish your wash automatically at a later time choosing a delay of between 1 to 24 hours in 1 hour increments The hour displayed indicates the time at which the wash will be finished 1 Manually or automatically set your washing machine according to the type of laundry you are washing 2 Press the Delay Start button repeatedly until the delay time is set 3 Press the StartPause button The Delay Start indicator will be lit and the clock will begin counting down until it reaches the set time 4 To cancel a Delay End function press the Power button and then turn the washing machine on again washing a load of laundry WF435A03159B06ENindd 24 201433 102424
• Page 25 - English - : washing a load of laundry 25 Child Lock This function prevents children from playing with your washer Although the Child Lock function is activated you must keep an eye on children so that they do not operate your washer Activating the Child Lock function Press and hold both the Spin and Soil Level buttons simultaneously for approximately 3 seconds When you activate the Child Lock function the door locks and the Child Lock lamp illuminates If you press the StartPause button after you have activated the Child Lock function none of the buttons will work except for the Power button If you press a button when the buttons are locked the Child Lock lamp blinks Pausing the Child Lock function When the door is locked or the buttons are locked by the Child Lock function you can pause the Child Lock operation for 1 minute by pressing and holding both the Spin and Soil Level buttons simultaneously for approximately 3 seconds If you pause the Child Lock mode temporarily the door lock is released for 1 minute for user convenience During this period the Child Lock lamp blinks If you open the door after the minute is over an alarm sounds for up to 2 minutes If you close the door within the 2 minutes the door is locked and the Child Lock function is reactivated If you close the door after the 2 minutes the door is not locked automatically and no alarm sounds Deactivating the Child Lock function Press and hold both the Spin and Soil Level buttons simultaneously for approximately 6 seconds When you deactivate the Child Lock function the door is unlocked and the Child Lock is turned off TheChildLockfunctionpreventschildrenortheinfirmfromaccidentlyoperatingthe washer and injuring themselves Ifachildentersthewashingmachinethechildmaybecometrappedandsuffocate OnceyouhaveactivatedtheChildLockfunctionitcontinuesworkingevenifthepower is turned off Openingthedoorbyforcecanresultininjuryduetodamagetotheproduct To add laundry after you have activated the Child Lock function you must first pause or deactivate the Child Lock function If you want to open the door of the washing machine when the Child Lock function is activated Pause or deactivate the Child Lock function Turn the washing machine off and then on again 03 washing a load of laundry CAUTION CAUTION WARNING WF435A03159B06ENindd 25 201433 102424
• Page 26 - English - : 26 washing a load of laundry Spin Only If you press the Power button and then press and hold the Spin button for 2 seconds the spin time will be displayed on the display panel Then press the Spin button repeatedly until the required spin level is selected and then press the StartPause button Before pressing the Spin Only button you can select a cycle with the Cycle Selector If you have selected a cycle you can only select the corresponding spin level Drum Light 1 If the door is opened when the power is on the Drum Light is automatically turned on 2 If the door is closed when the power is on the Drum Light is automatically turned off 3 Press the Temp and the Spin buttons simultaneously to turn the Drum Light on or off 4 If 4 minutes have passed after the Drum Light is turned on the Drum Light is automatically turned off Garment You can add or take out laundry items even after the wash has started as long as the Garment light is on Pushing the StartPause button unlocks the door unless the water is too hot or if there is too much water in your Washer If you are able to unlock the door and wish to continue the wash cycle close the door and press the StartPause button My cycle Allows you to activate your custom wash temperature spin soil level etc with onebutton convenience By pushing the My Cycle button you activate the settings used during the My Cycle mode The My Cycle light will indicate activation You can select all options as follows in My Cycle mode 1 Select cycle using the Cycle Selector dial 2 After cycle selection set each option See page 41 for available option settings with each cycle 3 Then you can start My Cycle by pushing the StartPause button in My Cycle mode The cycle and options you select will be displayed the next time you choose My Cycle You can change the My Cycle settings by repeating the same process above The last used setting will be displayed the next time you choose My Cycle DEEP STEAM DEEP STEAM Magic Steam The Deep Steam feature boosts cleaning performance and loosens grime and dirt providing superior cleaning results For heavily soiled colorfast garments this cycle provides a high washing temperature and steam and is effective for cleaning stains How DEEP STEAM works If you select steam the steam acts at the most effective times for the detected amount of laundry maximizing the effect of the steam increasing the wash temperature enhancing the Soak effect and improving wash performance Press Steam button to use the Steam Wash function Steam Wash is available with the Normal Heavy Duty Bedding PLUS Sanitize Stain Away and Deep Steam cycles For heavily soiled colorfast garments Steam Wash improves stain treatment and uses less water washing a load of laundry WF435A03159B06ENindd 26 201433 102424
• Page 27 - English - : washing a load of laundry 27 Washer takes small amounts of water in tub and Heater heats water into evaporation To use the Steam function perform the following steps 1 Load the washer 2 Press the Power button 3 Turn the Cycle Selector and select a steam cycle The Deep Steam cycle automatically selects the Steam Wash function 4 Press the Steam button 5 Add detergent into the dispenser tray for a wash and add fabric softener up to the marked line 6 Press the StartPause button The washer automatically selects the optimal wash conditions by sensing the weight of the laundry Steam may not necessarily be visible during the steam cycles Steam may not be present during entire steam wash cycle Too much steam could damage clothing Do not use steam with delicate fabrics such as wool silk or easily discolored fabrics Steam may not be present during entire steam wash cycle Do not touch the door The door surface can become very hot Smart Care This function enables you to check the status of the washing machine using a smartphone 1 To enable the Smart Care function press and hold the Soil Level and Steam button for 3 seconds within 10 seconds after turning the power on by pressing the Power button 2 If the Smart Care function is activated the led on window display rotates for 2 or 3 seconds and then the Smart Care indicator is lit on the display 3 Run the Smart Care app on your smart phone 4 The Smart Care function is optimized with Galaxy S Galaxy S2 iPhone 4 and iPhone 4S 5 Focus your smart phones camera on the display panel of the washing machine 6 If the smart phones camera is focused on the display panel of the washing machine the result is automatically recognized and the error type and countermeasures are displayed on the smart phone 7 If an error occurs more than twice please manually enter the error code displayed on the display panel of the washing machine into the Smart Care app Downloading the Smart Care app DownloadtheSamsungSmartWasherDryerAppintoyourmobilephonefromthe Android market or Apple App store Search word Samsung Smart WasherDryer Precautions when using Smart Care Ifalightingdeviceegfluorescentorlampisreflectedonthedisplaypanelofthe washing machine the result on the display panel may not be recognized easily Ifanerroroccursmorethantwicepleasemanuallyentertheerrorcodedisplayedonthe display panel of the washing machine into the Smart Care app Iftheangleofthesmartphonecameraandthedisplaypanelofthewashingmachineis incorrect the error may not be recognized properly Please try to hold the smart phone at an angle to the display panel as shown by the figure CAUTION 03 washing a load of laundry WF435A03159B06ENindd 27 201433 102425
• Page 28 - English - : 28 washing a load of laundry Washing clothes using the cycle selector Your new washing machine makes washing clothes easy using Samsungs Fuzzy Control automatic control system When you select a wash program the machine will set the correct temperature washing time and washing speed 1 Press the Power button 2 Open the door 3 Load the articles of clothing one at a time loosely into the drum without overfilling it 4 Close the door 5 Add detergent softener and prewash detergent if necessary into the appropriate compartments Prewash is only available when selecting the Normal Perm Press Sanitize Bedding Plus Deep Steam and Heavy Duty cycles It is only necessary if your clothing is heavily soiled 6 Use the Cycle Selector to select the appropriate cycle according to the type of material Normal Heavy Duty Perm Press Sanitize Bedding Plus Deep Steam Eco Cold Stain Away Active Wear DelicatesHand Wash Wool Quick Wash Rinse Spin and Spin Only The relevant indicators will illuminate on the control panel 7 At this time you can control the wash temperature the number of rinse cycles the spinning speed and the delay time by pressing the appropriate option button 8 Press the StartPause button on the Cycle Selector and the wash will begin The process indicator will light up and the remaining time for the cycle will appear in the display Pause Option 1 Within 5 minutes of starting a wash it is possible to addremove laundry items tofrom the wash 2 Press the StartPause button to unlock the door 3 The door cannot be opened when the water is too HOT or the water level is too HIGH 4 After closing the door press the StartPause button to restart the wash When the cycle is finished After the total cycle has finished the power will turn off automatically 1 Open the door 2 Remove laundry ATC AUTO TEMPERATURE CONTROL ATC is the control function that the washer controls water temperature with temperature sensor thermistor Because there are numerous water temperatures depending on the customers environmentscold areas warm areas various water temperature settings of heater temperature etcs ATC function in our washer maintains the certain level of wash temperature to output the best washing performance at each cycle If you select normal amp heavy duty course those courses are the regulation and UL course Since new washer must reduce the amount of energy usage at first priority customer will notice more cold water entering the washer But This is Normal not a problem In those regulation course Hot temperature is similar to acceptable adult bathwater temperature and warm temperature is similar to comfortable swimmingpool water temperature If customer want to wash clothes in specific water temperature customer should choose a different course at each temperatureHotWarmEco Warm washing a load of laundry WF435A03159B06ENindd 28 201433 102425
• Page 29 - English - : washing a load of laundry 29 DETERGENT USE Your Washer is designed to use high efficiency HE detergents For best cleaning results use a high efficiency detergents such as Tide HE Wisk HE Cheer HE or Gain HE High efficiency detergents contain suds suppressors that reduce or eliminate suds When fewer suds are produced the load tumbles more efficiently and cleaning is maximized Regular detergent is not recommended Please use HE detergents only Reducing the amount of detergent may reduce the quality of cleaning It is important to pretreat stains sort carefully by color and soil level and avoid overloading Brand names are trademarks of their respective manufacturers FEATURES Automatic dispenser Your Washer has separate compartments for dispensing detergent and colorsafe bleach chlorine bleach and fabric softener Add all laundry additives to their respective compartments before starting your Washer The automatic dispenser MUST ALWAYS be in place before starting your Washer DO NOT open the automatic dispenser when your washer is running To use Never exceed the manufacturers recommendations when adding detergent This compartment holds liquid detergent for the main wash cycle which is added to the load at the beginning of the cycle When using powdered detergent remove the liquid detergent compartment from the detergent drawer The washer will not dispense powdered detergent from the liquid detergent compartment Detergent compartment 1 Pour the recommended amount of laundry detergent directly into the detergent compartment before starting your Washer 2 If you are using colorsafe bleach add it with the detergent to the detergent compartment When adding colorsafe bleach with detergent it is best if both laundry products are in the same form granular or liquid 03 washing a load of laundry WARNING Liquid detergent compartment WF435A03159B06ENindd 29 201433 102425
• Page 30 - English - : 30 washing a load of laundry Pre wash compartment When using the Pre Wash option detergent should be added to both the Pre Wash compartment and the detergent compartment The detergent will automatically be dispensed during Pre Wash If high efficiency HE detergent is used add 13 of the recommended amount to the Pre Wash compartment and 23 of the recommended amount to the detergent compartment Bleach compartment Liquid chlorine bleach only 1 Add chlorine bleach to the bleach compartment DO NOT exceed the MAX FILL line 2 Avoid splashing or overfilling the compartment 3 Your Washer automatically dispenses bleach into the tub at the appropriate time 4 The dispenser automatically dilutes liquid chlorine bleach before it reaches the wash load Never pour undiluted liquid chlorine bleach directly onto the load or into the tub It is a powerful chemical and can cause fabric damage such as weakening of the fibers or color loss if not used properly If you prefer to use colorsafe nonchlorine bleach add it to the appropriate detergent compartment DO NOT pour colorsafe bleach into the Bleach compartment Oxitype boosters or colorsafe bleach can be added to the drum prior to adding laundry Put the laundry into the drum only after confirming that the oxitype boosters or colorsafe bleach has completely entered the hole of the drum However to use powdered detergent and powder oxitype boosters or powdered color safe bleach at the same time it is more effective putting them in together and removing the liquid detergent holder from the detergent compartment Fabric softener compartment 1 Pour the recommended amount of liquid fabric softener into the softener compartment For smaller loads use less than one capful 2 Dilute the fabric softener with water until it reaches MAX FILL in the compartment 3 The dispenser automatically releases liquid fabric softener at the proper time during the rinse cycle Use the softener compartment ONLY for liquid fabric softeners DO NOT use the Downy Ball in the fabric softener compartment with this Washer It will not add fabric softener at the appropriate time Use the detergent Compartment It is not recommended using liquid fabric softener that is too sticky as it may not mix with the water sufficiently Brand names are trademarks of their respective manufacturers washing a load of laundry Fabric Softener compartment Bleach compartment WF435A03159B06ENindd 30 201433 102426
• Page 31 - English - : maintaining your washer 31 maintaining your washer CLEANING THE EXTERIOR Turn off the water faucets after finishing the days washing This will shut off the water supply to your Washer and prevent the unlikely possibility of damage from escaping water Leave the door open to allow the inside of your Washer to dry out Use a soft cloth to wipe up all detergent bleach or other spills as they occur Clean the following as recommended Control Panel Clean with a soft damp cloth Do not use abrasive powders or cleaning pads Do not spray cleaners directly on the panel Cabinet Clean with soap and water CLEANING THE INTERIOR Clean the interior of your Washer periodically to remove any dirt soil odor mold mildew or bacterial residue that may remain in your Washer as a result of washing clothes Failure to follow these instructions may result in unpleasant conditions including odors andor permanent stains on your Washer or laundry Hard water deposits may be removed if needed Use a cleaner labeled Washer safe 04 maintaining your washer WF435A03159B06ENindd 31 201433 102426
• Page 32 - English - : 32 maintaining your washer CLEANING THE DISPENSERS The automatic dispenser may need to be cleaned periodically due to laundry additive buildup 1 Pull the detergent liquid holder out of the detergent compartment 2 Remove the siphon cap from the fabric softener and bleach compartments 3 Wash all of the parts under running water 4 Clean the dispenser recess with a soft brush 5 Reinsert the siphon cap and push it firmly into place 6 Push the dispenser back into place 7 Run a RinseSpin cycle without any load in your washer STORING YOUR WASHER Washers can be damaged if water is not removed from hoses and internal components before storage Prepare your Washer for storage as follows Select the Quick Wash cycle and add bleach to the automatic dispenser Run your Washer through the cycle without a load Turn the water faucets off and disconnect the inlet hoses Unplug your Washer from the electrical outlet and leave your Washer door open to let air circulate inside the tumbler If your Washer has been stored in belowfreezing temperatures allow time for any leftover water in your Washer to thaw out before use maintaining your washer Siphon cap WF435A03159B06ENindd 32 201433 102427
• Page 33 - English - : maintaining your washer 33 CLEANING THE DEBRIS FILTER We recommend cleaning the debris filter when water does not drain well or the nd error message is displayed 1 Unplug the washing machine from the power supply 2 Open the filter cover using a coin or a key 3 Holding the drain cap pull the drain tube that is hooked on the guide hook to the frontDo not pull the drain tube with excessive force 4 Place a bowl under the washing machine to catch any remaining water Then hold the drain tube with one hand and turn the emergency drain cap counter clockwise with the other hand to separate it from the drain tube 5 Drain the remaining water completely 6 Pull out the debris cap and debris filter assembly 7 Wash any dirt or other material from the debris filter Make sure the drain pump propeller behind the debris filter is not blocked 8 When you have finished cleaning the filter insert the debris cap and filter assembly back into the washer Turn the debris filter cap clockwise until the indicator on the debris filter cap is in the 12 oclock position pointing to the indicator on the washer 9 Reattach the emergency drain cap to the drain tube and then hook the tube to the hook guide 10 Reinstall the filter cover the filter cover 04 maintaining your washer Debris filter cap Step 2 Step 1 Drain cap Debris filter cap Debris filter Filter cover WF435A03159B06ENindd 33 201433 102430
• Page 34 - English - : 34 maintaining your washer CLEANING THE DOOR SEALBELLOW 1 Open the washer door and remove any clothing or items from the washer 2 Inspect the gray colored sealbellow between the door opening and the basket for stained areas Pull back the sealbellow to inspect all areas under the sealbellow and to check for foreign objects 3 If stained areas are found wipe down these areas of the sealbellow using the procedure that follows a Mix a dilute solution using ¾ cup 177 mL of liquid chlorine bleach and 1 gal 38 L of warm tap water b Wipe the sealbellow area with the dilute solution using a damp cloth c Let stand 5 minutes d Wipe down area thoroughly with a dry cloth and let the washer interior air dry with door open IMPORTANT Wear rubber gloves when cleaning for prolonged periods Refer to the bleach manufacturers instructions for proper use PRESERVING THE TOP COVER AND THE FRONT FRAME Do not place any heavy or sharp objects or a detergent box on the washing machine Keep them on the purchased pedestal or in a separate storage box This may scratch or damage the top cover of the washing machine Since the entire washing machine has a highgloss finish the surface can be scratched or damaged Therefore avoid scratching or damaging the surface when using the washing machine maintaining your washer sealbellow WF435A03159B06ENindd 34 201433 102430
• Page 35 - English - : maintaining your washer 35 PURE CYCLE TM Pure Cycle is a selfcleaning cycle that removes mold that may occur inside the washing machine 1 Press the Power button 2 Press the Pure Cycle TM button OncethePureCyclebuttonispressedtheonly function that can be set is Delay Start 3 Press the StartPause button IfyoupresstheStartPausebuttonPureCycle begins Using Pure Cycle you can clean the drum without using a cleansing agent Never use Pure Cycle when laundry is in the washing machine This may cause damage to the laundry or a problem with the washing machine If you want to use drum cleansing agent use only 110 of the amount of the drum cleansing agent recommended by the cleansing agent manufacturer When using a powdertype cleansing agent remove the liquid detergent compartment The Pure Cycle Auto Indicator Function If the Pure Cycle button is lit after a wash it indicates that tub drum cleaning is required In this case remove the laundry from the washing machine turn the power on and clean the drum by running Pure Cycle If you do not run Pure Cycle the Pure Cycle indicator turns off However the Pure Cycle indicator will light again after two washes Not running Pure Cycle at this point will not cause a problem with the washing machine Although the Pure Cycle Auto Indicator appears once a month or so the frequency may differ depending on the number of times the washing machine is used 04 maintaining your washer CAUTION WF435A03159B06ENindd 35 201433 102432
• Page 36 - English - : 36 troubleshooting troubleshooting CHECK THESE POINTS IF YOUR WASHER PROBLEM SOLUTION Will not start Make sure the door is firmly closed Make sure your Washer is plugged in Make sure the water source faucets are open Make sure to press the StartPause Button to start your Washer Make sure Child Lock is not activated see page 25 Before your Washer starts to fill it will make a series of clicking noises to check the door lock and do a quick drain Check the fuse or reset the circuit breaker Has no water or not enough water Turn both faucets on fully Make sure the door is tightly closed Straighten the water inlet hoses Disconnect hoses and clean screens Hose filter screens may be clogged Open and close the door then press the StartPause Button Has detergent remaining in the automatic dispenser after the wash cycle is complete Make sure your Washer is running with sufficient water pressure Make sure the Detergent Selector dial is in the upper position when using granular detergent Vibrates or is too noisy Make sure your Washer is set on a level surface If the surface is not level adjust your Washer feet to level the appliance Make sure that the shipping bolts are removed Make sure your Washer is not touching any other object Make sure the laundry load is balanced Stops Plug the power cord into a live electrical outlet Check the fuse or reset the circuit breaker Close the door and press the StartPause Button to start your Washer For your safety your Washer will not tumble or spin unless the door is closed Before your Washer starts to fill it will make a series of clicking noises to check the door lock and do a quick drain There may be a pause or soak period in the cycle Wait briefly and it may start Check the screens on the inlet hoses at the faucets for obstructions Clean the screens periodically WF435A03159B06ENindd 36 201433 102432
• Page 37 - English - : troubleshooting 37 PROBLEM SOLUTION Fills with the wrong temperature water Turn both faucets on fully Make sure the temperature selection is correct Make sure the hoses are connected to the correct faucets Flush water lines Check the water heater It should be set to deliver a minimum 120 F 49 C hot water at the tap Also check the water heater capacity and recovery rate Disconnect the hoses and clean the screens The hose filter screens may be plugged As your Washer is filling the water temperature may change as the automatic temperature control feature checks incoming water temperature This is normal While your Washer is filling you may notice just hot andor just cold water going through the dispenser when cold or warm wash temperatures are selected This is a normal function of the automatic temperature control feature as your Washer determines the temperature of the water Door locked or will not open Press the StartPause Button to stop your Washer Your Washer door will remain locked during the heating portion of the Sanitize Cycle It may take a few moments for the door lock mechanism to disengage Does not drain andor spin Check the fuse or reset the circuit breaker Straighten the drain hoses Eliminate kinked hoses If there is a drain restriction call for service Close the door and press the StartPause Button For your safety your Washer will not tumble or spin unless the door is closed Make sure the debris filter is not clogged Load is too wet at the end of the cycle Use the High or Extra High spin speed Use high efficiency detergent to reduce oversudsing Load is too small Very small loads one or two items may become unbalanced and not spin out completely Leaks water Make sure the door is firmly closed Make sure all hose connections are tight Make sure the end of the drain hose is correctly inserted and secured to the drainage system Avoid overloading Use high efficiency detergent to prevent oversudsing Has excessive suds Use high efficiency detergent to prevent oversudsing Reduce the detergent amount for soft water small or lightly soiled loads NonHE detergent is NOT recommended Has an odor Excessivesudscollectinnooksandcranniesandcancausefoulodors Run cleansing cycles to sanitize the machine periodically Silver Care or Sanitize Cycle or Pure Cycle Clean the door seal Diaphragm Dry the interior of your washer after the total cycle has finished 05 troubleshooting WF435A03159B06ENindd 37 201433 102432
• Page 38 - English - : 38 troubleshooting INFORMATION CODES Information codes may be displayed to help you better understand what is occurring with your washer ERROR CODE MEANING amp SOLUTION dc An unbalanced load that prevents your washer from spinning Redistribute the load press the StartPause button dS The door is open when the washer is running Close the door tightly and restart the cycle If the code reappears call customer service FL Your washer failed to lock the door Close the door tightly and restart the cycle If the code reappears call customer service Hr A water temperature control problem Heater control problem Call customer service LE Your washer has tried to fill but has not reached the proper water level Call customer service LO The door will not unlock Make sure the door is firmly closed Press the Power button to turn o your washer then turn it on again If the code reappears call customer service nd Your washer is not draining This can also mean that the unit senses a small clog while draining 1 Turn o the unit for 10 seconds and then turn it on again 2 Select the Spin Only cycle 3 Press the StartPause to drain the water If it still does not drain call for service nF Your washer has tried to fill but was unsuccessful Make sure the water faucets are open all the way Check for bent hoses Check the inlet screens on the hoses If you are using a Flood Safety Device please remove the device and connect the water hoses directly to the unit Check if the hot water supply hose is connected You must connect the hot water supply hose because hot water is supplied by the Auto Temperature Control ATC function if the temperature of the cold water is lower than 59F When washer displays nF washer do draining for 3 minutes At this time Power button is invalid nF1 The hotcold water hose connection is not correct Please connect the hotcold water hose connection correctly OE A fault is detected in the water level sensor Call customer service 1E The Water Level sensor is not working properly Call customer service E2 A jammed key Call customer service troubleshooting WF435A03159B06ENindd 38 201433 102433
• Page 39 - English - : troubleshooting 39 ERROR CODE MEANING amp SOLUTION tE A temperature sensor problem Restart the cycle If the code reappears call customer service 3E A motor problem Restart the cycle If the code reappears call customer service 2E HighLow voltage detected Restart the cycle If the code reappears call customer service AE A Communication error between the SUBSensor PBA and the MAIN PBA Call customer service 8E A MEMS sensor problem Call customer service SF1 SF2 SF3 A system error Call customer service SUdS Too many suds are detected during the wash session The unit is put on hold until the amount of suds have been reduced The unit will then go back to operating When it finishes washing the End and SUdS codes will blink in turn For any codes not listed above call 18007267864 1800SAMSUNG 05 troubleshooting WF435A03159B06ENindd 39 201433 102433
• Page 40 - English - : 40 appendix appendix FABRIC CARE CHART The following symbols provide garment care direction The Clothing care labels include symbols for washing bleaching drying and ironing or dry cleaning when necessary The use of symbols ensures consistency among garment manufacturers of domestic and imported items Follow care label directions to maximize garment life and reduce laundering problems Wash Cycle Special Instructions Warning Symbols for Laundering Normal Line Dry Hang to Dry Do Not Wash Permanent Press Wrinkle Resistant Wrinkle Control Drip Dry Do Not Wring GentleDelicates Dry Flat Do Not Bleach Hand Wash Heat Setting Do Not Tumble Dry Water Temperature High No Steam added to iron Hot Medium Do Not Iron Warm Low Dryclean Cold Any Heat Dry Clean Bleach No HeatAir Do Not Dry Clean Any Bleach when needed IronDry or Steam Temperatures Line Dry Hang to Dry Only NonChlorine colorsafe Bleach when needed High Drip Dry Tumble Dry Cycle Medium Dry Flat Normal Low Permanent Press Wrinkle Resistant Wrinkle Control Gentle Delicates The dot symbols represent appropriate wash water temperatures for various items The temperature range for Hot is 105 125 F 41 52C for Warm 85 105 F29 41 C and for Cold 60 85 F16 29 C Wash water temperature must be a minimum of 60 F16C for detergent activation and effective cleaning The clothes Washer may not ensure these temperatures because the actual water temperatures entering your Washer are dependent on water heater settings and regional water supply temperatures For example cold water entering the home in the northern states during winter may be 40 F4 C which is too cold for effective cleaning The water temperature in this situation will need to be adjusted by selecting a warm setting adding some hot water to the MAX FILL line or using your Washers heating option if available WF435A03159B06ENindd 40 201433 102433
• Page 41 - English - : appendix 41 CYCLE CHART Use this chart to set the best cycle and option for your laundry Factory setting Selectable x Not available Course Functions Temp Spin Extra Hot Hot Warm Eco Warm Cold Extra High High Medium Low No Spin Normal X Heavyduty X Perm Press X X X Sanitize X X X X Bedding Plus X X X X Deep Steam X X X X Rinse Spin X X X X Quick Wash X Wool X X X X X DelicatesHand wash X X X X X Stain Away X Active Wear X X X X eco Cold X X X X Pure Cycle X X X X X X X X 06 appendix WF435A03159B06ENindd 41 201433 102434
• Page 42 - English - : 42 appendix CYCLE CHART Use this chart to set the best cycle and option for your laundry Factory setting Selectable x Not available Course Functions Options Soil Level Extra Rinse Extra Spin My Cycle Pre Wash Delay Start Steam Heavy Normal Light Normal Heavyduty Perm Press X Sanitize Bedding Plus Deep Steam X X X X Rinse Spin X X Quick Wash X X X Wool X X X X X X X X DelicatesHand wash X X X Stain Away Active Wear X eco Cold X X X Pure Cycle X X X X appendix WF435A03159B06ENindd 42 201433 102434
• Page 43 - English - : appendix 43 HELPING THE ENVIRONMENT Your Washer is manufactured from recyclable materials If you decide to dispose of it please observe local waste disposal regulations Cut off the power cord so that the appliance cannot be connected to a power source Remove the door so that animals and small children cannot get trapped inside the appliance Do not exceed the detergent quantities recommended in the detergent manufacturers instructions Use stain removal products and bleaches before the wash cycle only when necessary Save water and electricity by only washing full loads the exact amount depends upon the program used DECLARATION OF CONFORMITY This appliance complies with UL2157 SPECIFICATION TYPE FRONT LOADING WASHER DIMENSIONS Div Inches mm A HeightOverall 387 984 B Width 27 686 C Depth with door open 90 512 1300 D Depth 341 865 WATER PRESSURE 20116 psi 137800 kPa WEIGHT 105 kg 2315 lb HEATER RATING 900 W POWER CONSUMPTION WASHING 120 V 200 W WASHING AND HEATING 120 V 1150 W SPIN 120 V 550 W DRAIN 120 V 80 W SPIN REVOLUTION WF435AGJ 1300 rpm 06 appendix A B D C WF435A03159B06ENindd 43 201433 102435
• Page 44 - English - : 44 warranty warranty USA WARRANTY SAMSUNG WASHER LIMITED WARRANTY TO ORIGINAL PURCHASER This SAMSUNG brand product as supplied and distributed by SAMSUNG ELECTRONICS AMERICA INC SAMSUNG and delivered new in the original carton to the original consumer purchaser is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of One 1 year part and labor Two 2 years Control Board Parts Part Only Three 3 years stainless tub part Part Only Five 5 years washing motor part Part Only Ten 10 years washing DD motor part Part Only This limited warranty begins on the original date of purchase and is valid only on products purchased and used in the United States To receive warranty service the purchaser must contact SAMSUNG for problem determination and service procedures Warranty service can only be performed by a SAMSUNG authorized service center The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNGs authorized service center SAMSUNG will provide inhome service during the warranty period at no charge subject to availability within the contiguous United States Inhome service is not available in all areas To receive inhome service product must be unobstructed and accessible to the service agent If service is not available SAMSUNG may elect to provide transportation of the product to and from an authorized service center SAMSUNG will repair replace or refund this product at our option and at no charge as stipulated herein with new or reconditioned parts or products if found to be defective during the limited warranty period specified above All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG Replacement parts and products assume the remaining original warranty or ninety 90 days whichever is longerThis limited warranty covers manufacturing defects in materials and workmanship encountered in normal noncommercial use of this product and shall not apply to the following damage that occurs in shipment delivery and installation applications and uses for which this product was not intended altered product or serial numbers cosmetic damage or exterior finish accidents abuse neglect fire water lightning or other acts of nature or God use of products equipment systems utilities services parts supplies accessories applications installations repairs external wiring or connectors not supplied or authorized by SAMSUNG that damage this product or result in service problems incorrect electrical line voltage fluctuations and surges customer adjustments and failure to follow operating instructions maintenance and environmental instructions that are covered and prescribed in the instruction book product removal and reinstallation problems caused by pest infestations This limited warranty does not cover problems resulting from incorrect electric current voltage or supply light bulbs house fuses house wiring cost of a service call for instructions or fixing installation errors SAMSUNG does not warrant uninterrupted or errorfree operation of the product WF435A03159B06ENindd 44 201433 102435
• Page 45 - English - : warranty 45 EXCEPT AS SET FORTH HEREIN THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS OR IMPLIED AND SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE NO WARRANTY OR GUARANTEE GIVEN BY ANY PERSON FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS OR ANY OTHER SPECIAL INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE MISUSE OR INABILITY TO USE THIS PRODUCT REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE WITHOUT LIMITING THE FOREGOING PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS DAMAGE OR INJURY TO PURCHASER AND PURCHASERS PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE MISUSE OR INABILITY TO USE THIS PRODUCT THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages so the above limitations or exclusions may not apply to you This warranty gives you specific rights and you may also have other rights which vary from state to state To obtain warranty service please contact SAMSUNG at Samsung Electronics America Inc 85 Challenger Road Ridgefield Park NJ 07660 1800SAMSUNG 7267864 wwwsamsungcomussupport Visits by a Service Engineer to explain functions maintenance or installation is not covered by warranty Please contact your Samsung call agent for help with any of these issues WF435A03159B06ENindd 45 201433 102435
• Page 46 - English - : 46 warranty warrantyCANADA SAMSUNG WASHER LIMITED WARRANTY TO ORIGINAL PURCHASER This SAMSUNG brand product as supplied and distributed by SAMSUNG ELECTRONICS CANADA INC SAMSUNG and delivered new in the original carton to the original consumer purchaser is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of One 1 year part and labor Ten 10 years washing DD motor Part only This limited warranty begins on the original date of purchase and is valid only on products purchased and used in the Canada To receive warranty service the purchaser must contact SAMSUNG for problem determination and service procedures Warranty service can only be performed by a SAMSUNG authorized service center The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNGs authorized service center SAMSUNG will provide inhome service during the warranty period at no charge subject to availability within the Canada Inhome service is not available in all areas To receive inhome service product must be unobstructed and accessible to the service agent If service is not available SAMSUNG may elect to provide transportation of the product to and from an authorized service center SAMSUNG will repair replace or refund this product at our option and at no charge as stipulated herein with new or reconditioned parts or products if found to be defective during the limited warranty period specified above All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG Replacement parts and products assume the remaining original warranty or ninety 90 days whichever is longerThis limited warranty covers manufacturing defects in materials and workmanship encountered in normal noncommercial use of this product and shall not apply to the following damage that occurs in shipment delivery and installation applications and uses for which this product was not intended altered product or serial numbers cosmetic damage or exterior finish accidents abuse neglect fire water lightning or other acts of nature or God use of products equipment systems utilities services parts supplies accessories applications installations repairs external wiring or connectors not supplied or authorized by SAMSUNG that damage this product or result in service problems incorrect electrical line voltage fluctuations and surges customer adjustments and failure to follow operating instructions maintenance and environmental instructions that are covered and prescribed in the instruction book product removal and reinstallation problems caused by pest infestations This limited warranty does not cover problems resulting from incorrect electric current voltage or supply light bulbs house fuses house wiring cost of a service call for instructions or fixing installation errors SAMSUNG does not warrant uninterrupted or errorfree operation of the product WF435A03159B06ENindd 46 201433 102435
• Page 47 - English - : warranty 47 EXCEPT AS SET FORTH HEREIN THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS OR IMPLIED AND SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE NO WARRANTY OR GUARANTEE GIVEN BY ANY PERSON FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS OR ANY OTHER SPECIAL INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE MISUSE OR INABILITY TO USE THIS PRODUCT REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE WITHOUT LIMITING THE FOREGOING PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS DAMAGE OR INJURY TO PURCHASER AND PURCHASERS PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE MISUSE OR INABILITY TO USE THIS PRODUCT THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY Some provinces do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages so the above limitations or exclusions may not apply to you This warranty gives you specific rights and you may also have other rights which vary from province to province To obtain warranty service please contact SAMSUNG at Samsung Electronics Canada Inc 2050 Derry Road West Mississauga Ontario L5N 0B9 Canada 1800SAMSUNG 7267864 wwwsamsungcomcasupport English wwwsamsungcomcafrsupport French FAX18664364617 Visits by a Service Engineer to explain functions maintenance or installation is not covered by warranty Please contact your Samsung call agent for help with any of these issues WF435A03159B06ENindd 47 201433 102435
• Page 48 - English - : QUESTIONS OR COMMENTS COUNTRY CALL OR VISIT US ONLINE AT USA 1800SAMSUNG 7267864 wwwsamsungcomussupport MEXICO 01800SAMSUNG 7267864 wwwsamsungcommxsupport CANADA 1800SAMSUNG 7267864 wwwsamsungcomcasupport English wwwsamsungcomcafrsupport French Visits by a Service Engineer to explain functions maintenance or installation is not covered by warranty Please contact your Samsung call agent for help with any of these issues Code No DC6803159B06EN bitlysamsungwashers WF435A03159B06ENindd 48 201433 102436
• Page 49 - French - : Lavelinge manuel dutilisation Un monde de possibilités Nous vous remercions davoir choisi ce produit Samsung WF435AGJ Ce manuel a été imprimé sur du papier 100 recyclé WF435A03159B06CFRindd 1 201433 102430
• Page 50 - French - : 2 caractéristiques principales de votre nouveau lavelinge Smart PowerFoam caractéristiques principales de votre nouveau lavelinge Smart PowerFoam 1 VRT PLUS Vibration Reduction Technology Système de réduction des vibrations Ce lavelinge Samsung permet de réduire le bruit et les vibrations grâce à ses capteurs de vibrations 3D et sa technologie de commande intelligente son fonctionnement est donc plus silencieux 2 Tambour grande capacité Le lavelinge Samsung très grande capacité permet de laver un jeu de draps complet une couette King Size grande taille ou 32 serviettes de bain en un seul chargement Résultat vous économisez du temps de largent de leau et de lélectricité 3 PowerFoam Le système PowerFoam de Samsung permet dobtenir encore plus de propreté tout en protégeant vos tissus les plus fragiles PowerFoam permet de distribuer de façon équitable la lessive et de pénétrer les tissus en profondeur et plus rapidement 4 PureCycle programme de nettoyage du tambour Nettoyez le tambour avec un seul bouton Le programme Pure Cycle a été conçu spécialement pour éliminer les résidus de lessive et la saleté accumulés dans le tambour le diaphragme et le hublot en verre sans ajouter de nettoyant chimique spécial 5 SpeedSpray La nouvelle technologie Speed Spray de Samsung vous économise jusquà 25 du temps lorsque vous effectuez une lessive en raccourcissant les temps de lavage tout en conservant tous les cycles du procédé de lavage et en garantissant la propreté de votre linge Basé sur des charges de 8 livres 4 kg cycle Normal Niveau de salissure Normal sans aucune option sur les lavelinge à chargement frontal Samsung 43 cuft 120 litres précédents et existants livrés jusquen 2011 sans la fonction Speed Spray Speed Spray effectue les cycles Normal Literie Plus VAPEURS PROF Antitache et ÉcoFroid et le temps économisé peut varier selon les cycles les diverses charges et les compositions doptions 6 Vapeurs intensives La fonction Deep Steam Vapeurs intensives renforce les performances de lavage et élimine efficacement les taches les résultats sont spectaculaires 7 Smart Care Entretien intelligent La fonction Samsung Smart Care un système de surveillance des erreurs automatique détecte et diagnostique les problèmes dès quils surviennent et offre une solution simple et rapide Avec la technologie innovante Smart Control vous pouvez également être alerté via votre smartphone lorsquun problème survient 8 Design élégant Le design élégant de ce lavelinge se fond à merveille dans votre environnement 9 Affichage numérique et molette centrale La molette centrale permet de sélectionner facilement des programmes dans les deux sens et laffichage est simple à utiliser et à comprendre WF435A03159B06CFRindd 2 201433 102430
