USER
MANUAL
EN User Manual
Oven
KPK742220M
CONTENTS
1. SAFETY INFORMATION.............................................................................................2
2. SAFETY INSTRUCTIONS.............................................................................................4
3. PRODUCT DESCRIPTION...........................................................................................8
4. CONTROL PANEL....................................................................................................... 9
5. BEFORE FIRST USE................................................................................................... 11
6. DAILY USE..................................................................................................................11
7. CLOCK FUNCTIONS.................................................................................................14
8. AUTOMATIC PROGRAMMES.................................................................................. 15
9. USING THE ACCESSORIES...................................................................................... 16
10. ADDITIONAL FUNCTIONS.................................................................................... 18
11. HINTS AND TIPS..................................................................................................... 20
12. CARE AND CLEANING.......................................................................................... 35
13. TROUBLESHOOTING.............................................................................................38
14. ENERGY EFFICIENCY.............................................................................................40
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler - features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1.
SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
www.aeg.com
2
manufacturer is not responsible for any injuries or
damage that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away from the appliance unless continuously
supervised.
• Children of less than 3 years of age should be kept
away from the appliance unless continuously
supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts
may become hot during use.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2
General Safety
• Only a qualified person must install this appliance and
replace the cable.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements.
• Always use oven gloves to remove or put in
accessories or ovenware.
ENGLISH
3
• Before carrying out any maintenance, disconnect the
appliance from the power supply.
• WARNING: Ensure that the appliance is switched off
before replacing the lamp to avoid the possibility of
electric shock.
• Do not use the appliance before installing it in the
built-in structure.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Excessive spillage must be removed before the
pyrolytic cleaning. Remove all parts from the oven.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
• Use only the food sensor (core temperature sensor)
recommended for this appliance.
2.
SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• Keep the minimum distance from
other appliances and units.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
• The appliance is equipped with an
electric cooling system. It must be
operated with the electric power
supply.
• The built-in unit must meet the
stability requirements of DIN 68930.
Cabinet minimum
height (Cabinet un-
der the worktop mini-
mum height)
444 (460) mm
Cabinet width 560 mm
www.aeg.com4
Cabinet depth 550 (550) mm
Height of the front of
the appliance
455 mm
Height of the back of
the appliance
440 mm
Width of the front of
the appliance
595 mm
Width of the back of
the appliance
559 mm
Depth of the appli-
ance
567 mm
Built in depth of the
appliance
546 mm
Depth with open
door
882 mm
Ventilation opening
minimum size. Open-
ing placed on the
bottom rear side
560x20 mm
Mains supply cable
length. Cable is
placed in the right
corner of the back
side
1500 mm
Mounting screws 3.5x25 mm
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door or the
niche below the appliance, especially
when it operates or the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• Fully close the appliance door before
you connect the mains plug to the
mains socket.
• This appliance is supplied with a main
plug and a main cable.
2.3 Use
WARNING!
Risk of injury, burns and
electric shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of
this appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
ENGLISH
5
• Do not operate the appliance with
wet hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration
to the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of cavity of the
appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance is in operation. Heat and
moisture can build up behind a
closed furniture panel and cause
subsequent damage to the appliance,
the housing unit or the floor. Do not
close the furniture panel until the
appliance has cooled down
completely after use.
2.4 Care and cleaning
WARNING!
Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, follow the
safety instruction on it's packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of
detergent.
2.5 Pyrolytic cleaning
WARNING!
Risk of Injury / Fires /
Chemical Emissions (Fumes)
in Pyrolytic Mode.
• Before carrying out a Pyrolitic self-
cleaning function or the First Use
please remove from the oven cavity:
– any excess food residues, oil or
grease spills / deposits.
– any removable objects (including
shelves, side rails etc., provided
with the product) particularly any
non-stick pots, pans, trays,
utensils etc.
• Read carefully all the instructions for
Pyrolytic cleaning.
www.aeg.com
6
• Keep children away from the
appliance while the Pyrolytic cleaning
operates.
The appliance becomes very hot and
hot air is released from the front
cooling vents.
• Pyrolytic cleaning is a high
temperature operation that can
release fumes from cooking residues
and construction materials, as such
consumers are strongly advised to:
– provide good ventilation during
and after each Pyrolytic cleaning.
– provide good ventilation during
and after the first use at maximum
temperature operation.
• Unlike all humans, some birds and
reptiles can be extremely sensitive to
potential fumes emitted during the
cleaning process of all Pyrolytic
Ovens.
– Remove any pets (especially birds)
from the vicinity of the appliance
location during and after the
Pyrolytic cleaning and first use
maximum temperature operation
to a well ventilated area.
• Small pets can also be highly sensitive
to the localized temperature changes
in the vicinity of all Pyrolytic Ovens
when the Pyrolytic self cleaning
program is in operation.
• Non-stick surfaces on pots, pans,
trays, utensils etc., can be damaged
by the high temperature Pyrolytic
cleaning operation of all Pyrolytic
Ovens and can be also a source for
low level harmful fumes.
• Fumes released from all Pyrolytic
Ovens / Cooking Residues as
described are not harmful to humans,
including children, or persons with
medical conditions.
2.6 Internal lighting
WARNING!
Risk of electric shock.
• The type of light bulb or halogen
lamp used for this appliance is for
household appliances only. Do not
use it for house lighting.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
2.7 Service
• To repair the appliance contact the
Authorised Service Centre.
• Use original spare parts only.
2.8 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
ENGLISH
7
3. PRODUCT DESCRIPTION
3.1 General overview
1 2
4
3
5
6
7
8
1
2
3
4
1
Control panel
2
Electronic programmer
3
Socket for the core temperature
sensor
4
Heating element
5
Lamp
6
Fan
7
Shelf support, removable
8
Shelf positions
3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
Food Sensor
To measure the temperature inside food.
www.aeg.com
8
4. CONTROL PANEL
4.1 Electronic programmer
21 3 4 5 8 9 10 1176
Use the sensor fields to operate the oven.
Sensor
field
Function Comment
1
- Display Shows the current settings of the oven.
2
ON / OFF To turn on and off the oven.
3
Heating Functions
or Assisted Cook-
ing
Press the sensor field to choose the menu: Assis-
ted Cooking or Heating Functions. To turn on or
turn off the light, press the field for 3 seconds. You
can turn on the light also when the oven is turned
off.
4
Favourites To save and access your favourite programmes.
5
Temperature se-
lection
To set the temperature or show the current tem-
perature in the oven. Press the field for 3 seconds
to turn on or turn off the function: Fast Heat Up.
6
Down key To move down in the menu.
7
Up key To move up in the menu.
8
OK To confirm the selection or setting.
9
Back key To go back one level in the menu. To show the
main menu, press the field for 3 seconds.
ENGLISH 9
Sensor
field
Function Comment
10
Time and addi-
tional functions
To set different functions. When a heating func-
tion operates, press the sensor field to set the tim-
er or the functions: Function Lock, Favourites,
Heat + Hold, Set + Go. You can also change the
settings of the core temperature sensor.
11
Minute Minder To set the function: Minute Minder.
4.2 Display
A
DE
B C
A. Heating function
B. Time of day
C. Heat-up indicator
D. Temperature
E. Duration time or end time of a
function
Other indicators of the display:
Symbol Function
Minute Minder The function works.
Time of day The display shows the current time.
Duration The display shows the necessary time
for cooking.
End Time The display shows when the cooking
time is complete.
Temperature The display shows the temperature.
Time Indication The display shows how long the heat-
ing function works. Press and
at the same time to reset the time.
Calculation The oven calculates the time for cook-
ing.
Heat-up Indicator The display shows the temperature in
the oven.
Fast Heat Up The function is on. It decreases the
heat up time.
Weight Automatic The display shows that the automatic
weight system is on or that weight can
be changed.
www.aeg.com10
Symbol Function
Heat + Hold The function is on.
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
5.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the oven.
Refer to "Care and cleaning" chapter.
Clean the oven and the accessories
before the first use.
Put the accessories and the removable
shelf supports back to their initial
position.
5.2 First Connection
When you connect the oven to the mains
or after the power cut, you have to set
the language, the display contrast, the
display brightness and the time of the
day.
1. Press or to set the value.
2. Press to confirm.
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 Navigating the menus
1. Turn on the oven.
2. Press or to select the menu
option.
3. Press
to move to the submenu or
accept the setting.
At each point you can go
back to the main menu with
.
6.2 The menus in overview
Main menu
Symbol / Menu
item
Application
Heating Func-
tions
Contains a list of heat-
ing functions.
Assisted Cooking
Contains a list of auto-
matic programmes.
Symbol / Menu
item
Application
Favourites
Contains a list of fa-
vourite cooking pro-
grammes created by
the user.
Cleaning
Contains a list of
cleaning programmes.
Basic Settings
Used to set the appli-
ance configuration.
Specials
Contains a list of addi-
tional heating func-
tions.
Submenu for: Basic Settings
Symbol / Menu
item
Description
Set Time of Day
Sets the current time
on the clock.
ENGLISH 11
Symbol / Menu
item
Description
Time Indication
When ON, the display
shows the current time
when you deactivate
the appliance.
Fast Heat Up
When ON, the func-
tion decreases the
heat-up time.
Set + Go
To set a function and
activate it later with a
press of any symbol on
the control panel.
Heat + Hold
Keeps the prepared
food warm for 30 mi-
nutes after a cooking
cycle finished.
Time Extension
Activates and deacti-
vates the time exten-
sion function.
Display Contrast
Adjusts the display
contrast by degrees.
Display Bright-
ness
Adjusts the display
brightness by degrees.
Set Language
Sets the language for
the display.
Buzzer Volume
Adjusts the volume of
press-tones and sig-
nals by degrees.
Key Tones
Activates and deacti-
vates the tone of the
touch fields. It is not
possible to deactivate
the tone of the ON /
OFF touch field.
Alarm/Error
Tones
Activates and deacti-
vates the alarm tones.
Cleaning Re-
minder
Reminds you when to
clean the appliance.
Symbol / Menu
item
Description
DEMO mode
Activation / deactiva-
tion code: 2468.
Service
Shows the software
version and configura-
tion.
Factory Settings
Resets all settings to
factory settings.
6.3 Heating Functions
Heating func-
tion
Application
True Fan Cook-
ing
To bake on up to two
shelf positions at the
same time and to dry
food. Set the tempera-
ture 20 - 40 °C lower
than for the function:
Conventional Cooking.
Pizza Function
To bake food on one
shelf position for a
more intensive brown-
ing and a crispy bot-
tom. Set the tempera-
ture 20 - 40 °C lower
than for the function:
Conventional Cooking.
Conventional
Cooking
To bake and roast food
on one shelf position.
Frozen Foods
To make convenience
food (e.g. french fries,
potato wedges or
spring rolls) crispy.
Grill
To grill flat food and to
toast bread.
www.aeg.com12
Heating func-
tion
Application
Turbo Grilling
To roast larger meat
joints or poultry with
bones on one shelf po-
sition. To make gratins
and to brown.
Bottom Heat
To bake cakes with
crispy bottom and to
preserve food.
Moist Fan Bak-
ing
This function is de-
signed to save energy
during cooking. For the
cooking instructions re-
fer to "Hints and tips"
chapter, Moist Fan Bak-
ing. The oven door
should be closed dur-
ing cooking so that the
function is not interrup-
ted and to ensure that
the oven operates with
the highest energy effi-
ciency possible. When
you use this function,
the temperature in the
cavity may differ from
the set temperature.
The residual heat is
used. The heating pow-
er may be reduced. For
general energy saving
recommendations refer
to "Energy Efficiency"
chapter, Energy Saving.
This function was used
to comply with the en-
ergy efficiency class ac-
cording to EN 60350-1.
When you use this func-
tion the lamp automati-
cally turns off after 30
seconds.
The lamp may automatically
deactivate at a temperature
below 60 °C during some
oven functions.
6.4 Specials
Heating func-
tion
Application
Keep Warm
To keep food warm.
Plate Warming
To preheat plates for
serving.
Preserving
To make vegetable
preserves (e.g. pickles).
Dehydrating
To dry sliced fruit, veg-
etables and mush-
rooms.
Dough Proving
To speed up the rising
of the yeast dough. It
prevents dough sur-
face from drying and
keeps the dough elas-
tic.
Slow Cooking
To prepare tender,
succulent roasts.
Bread Baking
Use this function to
prepare bread and
bread rolls with a very
good professional-like
result in terms of crisp-
iness, colour and crust
gloss.
Defrost
To defrost food (vege-
tables and fruit). The
defrosting time de-
pends on the amount
and size of the frozen
food.
6.5 Setting a heating function
1. Turn on the oven.
2. Select the menu: Heating Functions.
3. Press to confirm.
4. Select a heating function.
ENGLISH
13
5. Press to confirm.
6. Set the temperature.
7. Press to confirm.
6.6 Heat-up indicator
When you turn on a heating function, the
bar on the display comes on. The bar
shows that the temperature increases.
When temperature is reached the buzzer
sounds 3 times and the bar flashes and
then disappears.
6.7 Fast Heat Up
This function decreases the heat-up time.
Do not put food in the oven
when the Fast heat up
function works.
To turn on the function, hold for 3
seconds. The heat-up indicator
alternates.
This function is not available for some
oven functions.
6.8 Residual heat
When you turn off the oven, the display
shows the residual heat. You can use the
heat to keep the food warm.
7. CLOCK FUNCTIONS
7.1 Clock functions table
Clock function Application
Minute
Minder
To set a countdown
(max. 2 h 30 min). This
function has no effect
on the operation of the
oven. You can also turn
it on when the oven is
turned off.
Use to turn on the
function. Press or
to set the minutes
and to start.
Duration
To set how long the
oven works (max. 23 h
59 min).
End Time
To set the switch-off
time for a heating func-
tion (max. 23 h 59 min).
If you set the time for a clock function,
the time starts to count down after 5
seconds.
If you use the clock
functions: Duration, End
Time, the oven turns off the
heating elements after 90 %
of the set time. The oven
uses the residual heat to
continue the cooking
process until the time ends
(3 - 20 minutes).
7.2 Setting the clock functions
Before you use the
functions: Duration, End
Time, you must set a heating
function and temperature
first. The oven turns off
automatically.
You can use the functions:
Duration and End Time at
the same time if you want to
automatically turn on and
turn off the oven on a given
time later.
The functions: Duration and
End Time do not work when
you use the core
temperature sensor.
1. Set a heating function.
2. Press
again and again until the
display shows the necessary clock
function and the related symbol.
3. Press or to set the necessary
time.
www.aeg.com
14
4. Press to confirm.
When the time ends, a signal sounds.
The oven turns off. The display shows a
message.
5. Press any symbol to stop the signal.
7.3 Heat + Hold
Conditions for the function:
• The set temperature is more than 80
°C.
• The function: Duration is set.
The function: Heat + Hold keeps
prepared food warm at 80 °C for 30
minutes. It turns on after the baking or
roasting procedure ends.
You can turn on or turn off the function in
the menu: Basic Settings.
1. Turn on the oven.
2. Select the heating function.
3. Set the temperature above 80 °C.
4. Press again and again until the
display shows: Heat + Hold.
5. Press to confirm.
When the function ends, a signal sounds.
7.4 Time Extension
The function: Time Extension makes the
heating function continue after the end
of Duration.
Applicable to all heating
functions with Duration or
Weight Automatic.
Not applicable to heating
functions with the core
temperature sensor.
1. When the cooking time ends, a
signal sounds. Press any symbol.
The display shows the message.
2. Press to turn on or to cancel.
3. Set the length of the function.
4. Press
.
8. AUTOMATIC PROGRAMMES
WARNING!
Refer to Safety chapters.
8.1 Recipes online
You can find the recipes for the
automatic programmes on our
website.To find the Recipe Book check
the PNC number on the rating plate on
the front frame of the oven cavity.
8.2 Assisted Cooking with
Recipe Automatic
This oven has a set of recipes you can
use. The recipes are fixed and you
cannot change them.
1. Turn on the oven.
2. Select the menu: Assisted Cooking.
Press
to confirm.
3. Select the category and dish. Press
to confirm.
4. Select a recipe. Press
to confirm.
When you use the function:
Manual, the oven uses the
automatic settings. You can
change them as with other
functions.
8.3 Assisted Cooking with
Weight Automatic
This function automatically calculates the
roasting time. To use it, it is necessary to
input the food weight.
1. Turn on the oven.
2. Select the menu: Assisted Cooking.
Press to confirm.
3. Select the category and dish. Press
to confirm.
4. Select the function: Weight
Automatic. Press to confirm.
5. Press
or to set the food
weight. Press to confirm.
The automatic programme starts.
ENGLISH
15
6. You can change the weight at any
time. Press or to change the
weight.
7. When the time ends, a signal sounds.
Press any symbol to turns off the
signal.
With some programmes turn
over the food after 30
minutes. The display shows a
reminder.
9. USING THE ACCESSORIES
WARNING!
Refer to Safety chapters.
9.1 Food sensor
The food sensor measures temperature
inside the food. When the food is at the
set temperature, the appliance
deactivates.
There are two temperatures to be set:
• the oven temperature (minimum 120
°C),
• the food core temperature.
CAUTION!
Use only the food sensor
supplied and the original
replacement parts.
Directions for the best results:
• Ingredients should be at room
temperature.
• Food sensor cannot be used for liquid
dishes.
• During cooking the food sensor must
remain in the dish and the plug in the
socket.
• Use recommended food core
temperature settings. Refer to "Hints
and tips" chapter.
The appliance calculates an
approximate end of cooking
time. It depends on the
quantity of food, the set
oven function and
temperature.
Food categories: meat, poultry
and fish
1. Activate the appliance.
2. Insert the tip of the food sensor into
the centre of meat or fish, in the
thickest part if possible. Make sure
that at least 3/4 of the food sensor is
inside of the dish.
3. Put the plug of the food sensor into
the socket located in the front frame
of the appliance.
The display shows the food sensor
symbol.
4. Press
or in less than 5
seconds to set the food core
temperature.
5. Set a heating function and, if
necessary, the oven temperature.
6. To change the food core
temperature, press .
When the dish reaches the set
temperature, an acoustic signal sounds.
The appliance deactivates automatically.
7. Touch any symbol to stop the signal.
www.aeg.com
16
8. Remove the food sensor plug from
the socket and remove the dish from
the appliance.
WARNING!
There is a risk of burns as the
food sensor becomes hot.
Be careful when you unplug
it and remove it from the
food.
Food category: casserole
1. Activate the appliance.
2. Place half of the ingredients in a
baking dish.
3. Insert the tip of the food sensor
exactly in the centre of the casserole.
The food sensor should be stabilized
in one place during baking. Use a
solid ingredient to achieve that. Use
the rim of the baking dish to support
the silicone handle of the food
sensor. The tip of the food sensor
should not touch the bottom of a
baking dish.
4. Cover the food sensor with the
remaining ingredients.
5. Put the plug of the food sensor into
the socket located in the front frame
of the appliance.
The display shows the food sensor
symbol.
6. Press
or in less than 5
seconds to set the food core
temperature.
7. Set a heating function and, if
necessary, the oven temperature.
8. To change the food core
temperature, press .
When the dish is at the set temperature,
an acoustic signal sounds. The appliance
deactivates automatically.
9. Touch any symbol to stop the signal.
10. Remove the food sensor plug from
the socket and remove the dish from
the appliance.
WARNING!
There is a risk of burns as the
food sensor becomes hot.
Be careful when you unplug
it and remove it from the
food.
9.2 Inserting the accessories
Wire shelf:
Push the shelf between the guide bars of
the shelf support and make sure that the
feet point down.
ENGLISH
17
Baking tray/ Deep pan:
Push the baking tray / deep pan between
the guide bars of the shelf support.
Wire shelf and baking tray / deep pan
together:
Push the baking tray / deep pan between
the guide bars of the shelf support and
the wire shelf on the guide bars above.
Small indentation at the top
increase safety. The
indentations are also anti-tip
devices. The high rim
around the shelf prevents
cookware from slipping of
the shelf.
10. ADDITIONAL FUNCTIONS
10.1 Favourites
You can save your favourite settings,
such as duration, temperature or heating
function. They are available in the menu:
Favourites. You can save 20
programmes.
Saving a programme
1. Turn on the oven.
2. Set a heating function or an
automatic programme.
3. Press again and again until the
display shows: SAVE.
4. Press
to confirm.
The display shows the first free memory
position.
5. Press to confirm.
6. Enter the name of the programme.
The first letter flashes.
7. Press
or to change the letter.
8. Press .
The next letter flashes.
9. Do step 7 again as necessary.
10. Press and hold
to save.
You can overwrite a memory position.
When the display shows the first free
memory position, press or and
press to overwrite an existing
programme.
You can change the name of a
programme in the menu: Edit
Programme Name.
Activating the programme
1. Turn on the oven.
2. Select the menu: Favourites.
3. Press to confirm.
4. Select your favourite programme
name.
5. Press to confirm.
You can press
to go directly to menu:
Favourites. You can also use it when the
oven is off.
10.2 Using the Child Lock
When the Child Lock is on, the oven
cannot be turned on accidentally.
If the Pyrolysis function
works, the door locks
automatically.
A message comes on in the
display when you press any
symbol.
1. Press to turn on the display.
www.aeg.com
18
2. Press and at the same time
until the display shows a message .
To turn off the Child Lock function repeat
step 2.
10.3 Function Lock
This function prevents an accidental
change of the heating function. You can
turn it on only when the oven works.
1. Turn on the oven.
2. Set a heating function or setting.
3. Press again and again until the
display shows: Function Lock.
4. Press to confirm.
If the Pyrolysis function
works, the door is locked
and the symbol of a key
comes on in the display.
To turn off the function, press
. The
display shows a message. Press
again
and then to confirm.
When you turn off the oven,
the function also turns off.
10.4 Set + Go
The function lets you set a heating
function (or a programme) and use it
later with one press of any symbol.
1. Turn on the oven.
2. Set a heating function.
3. Press again and again until the
display shows: Duration.
4. Set the time.
5. Press again and again until the
display shows: Set + Go.
6. Press
to confirm.
Press any symbol (except for ) to start
the function: Set + Go. The set heating
function starts.
When the heating function ends, a signal
sounds.
• Function Lock is on when
the heating function
works.
• The menu: Basic Settings
lets you turn the function:
Set + Go on and off.
10.5 Automatic Switch-Off
For safety reasons the oven turns off
automatically after some time, if a
heating function works and you do not
change any settings.
(°C) (h)
30 - 115 12.5
120 - 195 8.5
200 - 245 5.5
250 - maximum 3
Pyrolytic Cleaning 4.5
The Automatic Switch-off does not work
with the functions: Light, Food Sensor,
Duration, End Time.
10.6 Brightness of the display
There are two modes of display
brightness:
• Night brightness - when the oven is
turned off, the brightness of the
display is lower between 10 PM and 6
AM.
• Day brightness:
– when the oven is turned on.
– if you touch a symbol during the
night brightness (apart from ON /
OFF), the display goes back to
the day brightness mode for the
next 10 seconds.
– if the oven is turned off and you
set the function: Minute Minder.
When the function ends, the
display goes back to the night
brightness.
ENGLISH
19
10.7 Cooling fan
When the oven operates, the cooling fan
turns on automatically to keep the
surfaces of the oven cool. If you turn off
the oven, the cooling fan can continue to
operate until the oven cools down.
11. HINTS AND TIPS
WARNING!
Refer to Safety chapters.
The temperature and baking
times in the tables are
guidelines only. They
depend on the recipes and
the quality and quantity of
the ingredients used.
11.1 Cooking
recommendations
Your oven may bake or roast differently
to the oven you had before. The tables
below show recommended settings for
temperature, cooking time and shelf
position for specific types of the food.
If you cannot find the settings for a
special recipe, look for the similar one.
11.2 Advice for special heating
functions of the oven
Keep Warm
The function allows you to keep food
warm. The temperature is set
automatically to 80 °C.
Plate Warming
The function allows you to warm plates
and dishes before serving. The
temperature is set automatically to 70 °C.
Place plates and dishes in stacks evenly
on the wire shelf. Use the first shelf
position. After half of the warming time
switch their places.
Dough Proving
The function allows you to rise yeast
dough. Put the dough into a big dish and
cover it with a wet towel or plastic foil.
Set function: Dough Proving and the
cooking time.
Defrost
Remove the food packaging and put the
food on a plate. Do not cover the food,
as it can extend the defrosting time. Use
the first shelf position.
11.3 Baking
Use the lower temperature the first time.
You can extend baking times by 10 – 15
minutes if you bake cakes on more than
one shelf position.
Cakes and pastries at different heights
do not always brown equally. There is no
need to change the temperature setting
if an unequal browning occurs. The
differences equalize during baking.
Trays in the oven can twist during baking.
When the trays become cold again, the
distortions disappear.
11.4 Tips on baking
Baking results Possible cause Remedy
The bottom of the cake
is not baked sufficiently.
The shelf position is incor-
rect.
Put the cake on a lower shelf.
www.aeg.com20
Baking results Possible cause Remedy
The cake sinks and be-
comes soggy or streaky.
The oven temperature is
too high.
Next time set slightly lower oven
temperature.
The baking time is too
short.
Next time set a longer baking
time and lower oven temperature.
The cake is too dry. The oven temperature is
too low.
Next time set higher oven tem-
perature.
The baking time is too long. Next time set shorter baking time.
The cake bakes uneven-
ly.
The oven temperature is
too high and the baking
time is too short.
Set lower oven temperature and
longer baking time.
The cake batter is not even-
ly distributed.
Next time spread the cake batter
evenly on the baking tray.
The cake is not ready in
the baking time speci-
fied in a recipe.
The oven temperature is
too low.
Next time set a slightly higher
oven temperature.
11.5 Baking on one oven level
BAKING IN TINS
(°C) (min)
Ring cake / Brioche True Fan Cooking 150 - 160 50 - 70 1
Madeira cake / Fruit cakes True Fan Cooking 140 - 160 70 - 90 1
Sponge cake True Fan Cooking 140 - 150 35 - 50 1
Sponge cake Conventional
Cooking
160 35 - 50 1
Flan base - short pastry, pre-
heat the empty oven
True Fan Cooking 170 - 180 10 - 25 2
Flan base - sponge cake
mixture
True Fan Cooking 150 - 170 20 - 25 2
Apple pie, 2 tins Ø20 cm True Fan Cooking 160 70 - 90 2
Apple pie, 2 tins Ø20 cm Conventional
Cooking
180 70 - 90 1
Cheesecake, use a deep pan Conventional
Cooking
160 - 170 70 - 90 2
ENGLISH 21
CAKE / PASTRIES / BREADS ON BAKING TRAYS
Preheat the empty oven.
(°C) (min)
Plaited bread / Bread crown Conventional
Cooking
170 - 190 30 - 40 1
Christstollen Conventional
Cooking
160 - 180 50 - 70 1
Rye bread Conventional
Cooking
first: 230 20 1
then: 160 -
180
30 - 60
Cream puffs / Eclairs Conventional
Cooking
190 - 210 20 - 35 2
Swiss roll Conventional
Cooking
180 - 200 10 - 20 2
Cake with crumble topping True Fan Cooking 150 - 160 20 - 40 2
Buttered almond cake /
Sugar cakes
Conventional
Cooking
190 - 210 20 - 30 2
Fruit flans (made of yeast
dough / sponge cake mix-
ture)
True Fan Cooking 150 - 160 35 - 55 2
Fruit flans (made of yeast
dough / sponge cake mix-
ture)
Conventional
Cooking
170 35 - 55 2
Fruit flans made of short
pastry
True Fan Cooking 160 - 170 40 - 80 2
Yeast cakes with delicate
toppings (e.g. quark, cream,
custard)
Conventional
Cooking
160 - 180 40 - 80 2
www.aeg.com22
BISCUITS
Use the second shelf position.
(°C) (min)
Short pastry biscuits True Fan Cooking 150 - 160 10 - 20
Short pastry / Pastry strips True Fan Cooking 140 20 - 35
Short pastry / Pastry strips, pre-
heat the empty oven
Conventional Cook-
ing
160 20 - 30
Biscuits made of sponge cake
mixture
True Fan Cooking 150 - 160 15 - 20
Pastries made of egg white True Fan Cooking 80 - 100 120 - 150
Macaroons True Fan Cooking 100 - 120 30 - 50
Biscuits made of yeast dough True Fan Cooking 150 - 160 20 - 40
Puff pastries, preheat the empty
oven
True Fan Cooking 170 - 180 20 - 30
Rolls, preheat the empty oven True Fan Cooking 160 10 - 25
Conventional Cook-
ing
190 - 210 10 - 25
Small cakes, preheat the empty
oven
True Fan Cooking 160 20 - 35
Conventional Cook-
ing
170 20 - 35
11.6 Bakes and gratins
Use the first shelf position.
(°C) (min)
Pasta bake Conventional Cooking 180 - 200 45 - 60
Lasagne Conventional Cooking 180 - 200 25 - 40
Vegetables au gratin,
preheat the empty
oven
Turbo Grilling 160 - 170 15 - 30
ENGLISH 23
Use the first shelf position.
(°C) (min)
Baguettes with melted
cheese
True Fan Cooking 160 - 170 15 - 30
Milk rice Conventional Cooking 180 - 200 40 - 60
Fish bakes Conventional Cooking 180 - 200 30 - 60
Stuffed vegetables True Fan Cooking 160 - 170 30 - 60
11.7 Multilevel baking
Use the function: True Fan Cooking
For 2 trays use the first and fourth shelf
position.
CAKE / PASTRIES / BREADS
ON BAKING TRAYS
(°C) (min)
Cream puffs /
Eclairs, preheat
the empty oven
160 - 180 25 - 45
Dry streusel
cake
150 - 160 30 - 45
CAKES / SMALL CAKES /
BREADS ON BAKING TRAYS
(°C) (min)
Short pastry biscuits 150 - 160 20 - 40
Short pastry / Pastry
strips
140 25 - 45
Biscuits made of
sponge cake mix-
ture
160 - 170 25 - 40
CAKES / SMALL CAKES /
BREADS ON BAKING TRAYS
(°C) (min)
Pastries made of
egg white / Merin-
gues
80 - 100 130 -
170
Macaroons 100 - 120 40 - 80
Biscuits made of
yeast dough
160 - 170 30 - 60
11.8 Tips on Roasting
Use heat-resistant ovenware.
Roast lean meat covered.
Roast large meat joints directly in the tray
or on the wire shelf placed above the
tray.
Put some water in the tray to prevent
dripping fat from burning.
Turn the roast after 1/2 - 2/3 of the
cooking time.
Roast meat and fish in large pieces (1 kg
or more).
Baste meat joints with their own juice
several times during roasting.
www.aeg.com
24
11.9 Roasting tables
Use the first shelf position.
BEEF
(°C) (min)
Pot roast 1 - 1.5 kg Conventional
Cooking
230 120 - 150
Roast beef or fil-
let, rare, preheat
the empty oven
per cm of thick-
ness
Turbo Grilling 190 - 200 5 - 6
Roast beef or fil-
let, medium
per cm of thick-
ness
Turbo Grilling 180 - 190 6 - 8
Roast beef or fil-
let, well done
per cm of thick-
ness
Turbo Grilling 170 - 180 8 - 10
PORK
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Shoulder / Neck / Ham
joint
1 - 1.5 160 - 180 90 - 120
Chops / Spare rib 1 - 1.5 170 - 180 60 - 90
Meatloaf 0.75 - 1 160 - 170 50 - 60
Pork knuckle, pre-
cooked
0.75 - 1 150 - 170 90 - 120
ENGLISH 25
VEAL
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Roast veal 1 160 - 180 120 - 150
Veal knuckle 1.5 - 2 160 - 180 120 - 150
LAMB
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Lamb leg / Roast lamb 1 - 1.5 150 - 180 100 - 120
Lamb saddle 1 - 1.5 160 - 180 40 - 60
GAME
(kg)
(°C) (min)
Saddle / Hare leg,
preheat the empty
oven
up to 1 Conventional Cook-
ing
230 30 - 40
Venison saddle 1.5 - 2 Conventional Cook-
ing
210 - 220 35 - 40
Haunch of venison 1.5 - 2 Conventional Cook-
ing
180 - 200 60 - 90
www.aeg.com26
POULTRY
Use the function: Turbo Grilling.
(kg)
(°C) (min)
Chicken 0.2 - 0.25 each piece 200 - 220 30 - 50
Chicken, half 0.4 - 0.5 each piece 190 - 210 35 - 50
Poultry, portions 1 - 1.5 190 - 210 50 - 70
Duck 1.5 - 2 180 - 200 80 - 100
FISH
(kg)
(°C) (min)
Whole fish 1 - 1.5 Conventional
Cooking
210 - 220 45 - 60
11.10 Crispy baking with Pizza
Function
PIZZA
Use the first shelf position.
(°C) (min)
Tarts 180 - 200 40 - 55
Spinach flan 160 - 180 45 - 60
Quiche lorraine 170 - 190 45 - 55
Cheesecake 140 - 160 60 - 90
Apple pie, cov-
ered
150 - 170 50 - 60
Vegetable pie 160 - 180 50 - 60
PIZZA
Preheat the empty oven before
cooking.
Use the second shelf position.
(°C) (min)
Pizza, thin
crust
200 - 230 15 - 20
Pizza, thick
crust, use a
deep pan
180 - 200 20 - 30
Swiss flan 170 - 190 45 - 55
ENGLISH 27
PIZZA
Preheat the empty oven before
cooking.
Use the second shelf position.
(°C) (min)
Unleavened
bread
230 - 250 10 - 20
Puff pastry
flan
160 - 180 45 - 55
Flammku-
chen
230 - 250 12 - 20
Pierogi 180 - 200 15 - 25
11.11 Bread Baking
Preheating is not recommended.
BREAD
Use the second shelf position.
(°C) (min)
White bread 180 - 200 40 - 60
BREAD
Use the second shelf position.
(°C) (min)
Baguette 200 - 220 35 - 45
Brioche 160 - 180 40 - 60
Ciabatta 200 - 220 35 - 45
Rye bread 180 - 200 50 - 70
Wholemeal bread 180 - 200 50 - 70
Whole grain bread 170 - 190 60 - 90
11.12 Grill
Grill only thin pieces of meat or fish.
Preheat the empty oven before cooking.
Put a pan on the first shelf position to
collect fat.
www.aeg.com
28
GRILL
Use the first shelf position.
(°C) (min)
1st side 2nd side
Roast beef, medium 210 - 230 30 - 40 30 - 40
Beef fillet, medium 230 20 - 30 20 - 30
Pork loin 210 - 230 30 - 40 30 - 40
Veal loin 210 - 230 30 - 40 30 - 40
Saddle of lamb 210 - 230 25 - 35 20 - 35
Whole fish, 0.5 - 1 kg 210 - 230 15 - 30 15 - 30
11.13 Slow Cooking
This function allows you to prepare lean,
tender meat and fish. It is not applicable
for: poultry, fatty roast pork, pot roast.
Food Sensor temperature should not be
higher than 65 °C .
1. Sear the meat for 1 - 2 minutes on
each side in a pan over high heat.
2. Put the meat in the roasting pan or
directly on the wire shelf. Put a tray
below the wire shelf to collect fat.
Always cook without a lid while using
this function.
3. Use Food Sensor.
4. Select the function: Slow Cooking.
You can set the temperature
between 80 °C and 150 °C for the
first 10 minutes. The default is 90 °C.
Set the temperature for Food Sensor.
5. After 10 minutes, the oven
automatically lowers the temperature
to 80 °C.
Use the first shelf position.
(kg)
(°C) (min)
Roast beef 1 - 1.5 150 120 - 150
Beef fillet 1 - 1.5 150 90 - 110
Roast veal 1 - 1.5 150 120 - 150
Steak 0.2 - 0.3 120 20 - 40
ENGLISH 29
11.14 Frozen Foods
Remove the food packaging. Put the
food on a plate.
Do not cover the food, as this can extend
the defrost time.
DEFROSTING
Use the second shelf position.
(°C) (min)
Pizza, frozen 200 - 220 15 - 25
Pizza American, frozen 190 - 210 20 - 25
Pizza, chilled 210 - 230 13 - 25
Pizza snacks, frozen 180 - 200 15 - 30
French fries, thin 200 - 220 20 - 30
French fries, thick 200 - 220 25 - 35
Wedges / Croquettes 220 - 230 20 - 35
Hash browns 210 - 230 20 - 30
Lasagne / Cannelloni, fresh 170 - 190 35 - 45
Lasagne / Cannelloni, frozen 160 - 180 40 - 60
Baked cheese 170 - 190 20 - 30
Chicken wings 190 - 210 20 - 30
11.15 Defrost
Remove the food packaging and put the
food on a plate.
Use the first shelf position.
Do not cover the food, as this can extend
the defrost time.
(kg)
(min)
Defrosting
time
(min)
Further de-
frosting
time
Chicken 1 100 - 140 20 - 30 Put the chicken on an upturned sau-
cer in a big plate. Turn halfway
through.
www.aeg.com30
(kg)
(min)
Defrosting
time
(min)
Further de-
frosting
time
Meat 1 100 - 140 20 - 30 Turn halfway through.
Meat 0.5 90 - 120 20 - 30 Turn halfway through.
Trout 0.15 25 - 35 10 - 15 -
Strawberries 0.3 30 - 40 10 - 20 -
Butter 0.25 30 - 40 10 - 15 -
Cream 2 x 0.2 80 - 100 10 - 15 Whip the cream when still slightly
frozen in places.
Gateau 1.4 60 60 -
11.16 Preserving
Use only preserve jars of the same
dimensions available on the market.
Do not use jars with twist-off and
bayonet type lids or metal tins.
Use the first shelf position.
Put no more than six one-litre preserve
jars on the baking tray.
Fill the jars equally and close with a
clamp.
The jars cannot touch each other.
Put approximately 1/2 litre of water into
the baking tray to give sufficient moisture
in the oven.
When the liquid in the jars starts to
simmer (after approximately 35 - 60
minutes with one-litre jars), stop the oven
or decrease the temperature to 100 °C
(see the table).
Set the temperature to 160 - 170 °C.
SOFT FRUIT
(min)
Cooking time un-
til simmering
Strawberries / Blue-
berries / Raspber-
ries / Ripe gooseber-
ries
35 - 45
STONE FRUIT
(min)
Cooking
time until
simmering
(min)
Continue
to cook at
100 °C
Peaches /
Quinces /
Plums
35 - 45 10 - 15
ENGLISH 31
VEGETABLES
(min)
Cooking
time until
simmering
(min)
Continue to
cook at 100
°C
Carrots 50 - 60 5 - 10
Cucumbers 50 - 60 -
Mixed pickles 50 - 60 5 - 10
VEGETABLES
(min)
Cooking
time until
simmering
(min)
Continue to
cook at 100
°C
Kohlrabi /
Peas / Aspar-
agus
50 - 60 15 - 20
11.17 Dehydrating
Use the third shelf position.
(°C) (h)
Beans 60 - 70 6 - 8
Peppers 60 - 70 5 - 6
Vegetables for soup 60 - 70 5 - 6
Mushrooms 50 - 60 6 - 8
Herbs 40 - 50 2 - 3
Plums 60 - 70 8 - 10
Apricots 60 - 70 8 - 10
Apple slices 60 - 70 6 - 8
Pears 60 - 70 6 - 9
11.18 Food Sensor
BEEF Food core temperature (°C)
Rare Medium Well done
Roast beef 45 60 70
Sirloin 45 60 70
www.aeg.com32
BEEF Food core temperature (°C)
Less Medium More
Meatloaf 80 83 86
PORK Food core temperature (°C)
Less Medium More
Ham / Roast 80 84 88
Saddle chop / Pork loin, smoked /
Pork loin, poached
75 78 82
VEAL Food core temperature (°C)
Less Medium More
Roast veal 75 80 85
Veal knuckle 85 88 90
MUTTON / LAMB Food core temperature (°C)
Less Medium More
Mutton leg 80 85 88
Mutton saddle 75 80 85
Roast lamb / Lamb leg 65 70 75
GAME Food core temperature (°C)
Less Medium More
Hare saddle / Venison saddle 65 70 75
Hare leg / Hare, whole / Venison
leg
70 75 80
ENGLISH 33
POULTRY Food core temperature (°C)
Less Medium More
Chicken 80 83 86
Duck, whole / half / Turkey, whole /
breast
75 80 85
Duck, breast 60 65 70
FISH (SALMON, TROUT,
ZANDER)
Food core temperature (°C)
Less Medium More
Fish, whole / large / steamed /
Fish, whole / large / roasted
60 64 68
CASSEROLES - PRE-
COOKED VEGETABLES
Food core temperature (°C)
Less Medium More
Zucchini casserole / Broccoli cas-
serole / Fennel casserole
85 88 91
CASSEROLES - SAVOURY Food core temperature (°C)
Less Medium More
Cannelloni / Lasagne / Pasta bake 85 88 91
CASSEROLES - SWEET Food core temperature (°C)
Less Medium More
White bread casserole with / with-
out fruit / Rice porridge casserole
with / without fruit / Sweet noodle
casserole
80 85 90
11.19 Moist Fan Baking -
recommended accessories
Use the dark and non-reflective tins and
containers. They have better heat
absorption than the light colour and
reflective dishes.
www.aeg.com34
Pizza pan
Baking dish
Ramekins
Flan base tin
Dark, non-reflective
28 cm diameter
Dark, non-reflective
26 cm diameter
Ceramic
8 cm diameter,
5 cm height
Dark, non-reflective
28 cm diameter
11.20 Moist Fan Baking
Use the first shelf position.
(°C) (min)
Pasta gratin 200 - 220 45 - 60
Potato gratin 180 - 200 70 - 85
Moussaka 180 - 200 75 - 90
Lasagne 180 - 200 70 - 90
Cannelloni 180 - 200 65 - 80
Bread pud-
ding
190 - 200 55 - 70
Use the first shelf position.
(°C) (min)
Rice pudding 180 - 200 55 - 70
Apple cake,
made of
sponge cake
mixture (round
cake tin)
160 - 170 70 - 80
White bread 200 - 210 55 - 70
12. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
12.1 Notes on cleaning
Cleaning
Agents
Clean the front of the oven with a soft cloth with warm water and a mild
cleaning agent.
To clean metal surfaces, use a dedicated cleaning agent.
Clean stubborn stains with a special oven cleaner.
ENGLISH 35
Everyday Use
Clean the oven cavity after each use. Fat accumulation or other food re-
mains may cause fire. The risk is higher for the grill pan.
Dry the cavity with a soft cloth after each use.
Accessories
Clean all accessories after each use and let them dry. Use a soft cloth with
warm water and a cleaning agent. Do not clean the accessories in a dish-
washer.
Do not clean the non-stick accessories using aggressive agents, sharp-
edged objects or in a dishwasher.
12.2 Removing the shelf
supports
To clean the oven, remove the shelf
supports.
CAUTION!
Be careful when you remove
the shelf supports.
1. Pull the front of the shelf support
away from the side wall.
2. Pull the rear end of the shelf support
away from the side wall and remove
it.
2
1
Install the removed accessories in the
opposite sequence.
12.3 Pyrolysis
CAUTION!
If there are other appliances
installed in the same
cabinet, do not use them at
the same time as the
function: Pyrolysis. It can
cause damage to the
appliance.
The cleaning cannot start:
• if the core temperature sensor is not
removed.
• if the oven door are not closed.
1. Remove all accessories and
removable shelf supports.
2. Clean the oven cavity with warm
water and mild detergent. Clean the
inner door glass with warm water and
soft cloth.
3. Turn on the oven.
4. Enter the Menu and select the
function: Pyrolysis. Press
.
5. Set the duration of the cleaning:
Option Description
Quick For a light
cleaning: 1 h.
Normal For a stand-
ard cleaning:
1 h 30 min.
www.aeg.com36
Intense For a thor-
ough clean-
ing: 2 h 30
min.
6. Press .
When the cleaning starts, the oven door
is locked and the lamp does not work.
To stop the cleaning before it is
completed, turn off the oven.
WARNING!
After the function is
completed, the oven is very
hot. There is a risk of burns.
The door stays locked and some of the
oven functions are not available after the
cleaning is completed until temperature
in the oven decreases.
12.4 Removing and installing
the door
You can remove the door and the
internal glass panels to clean it. The
number of glass panels is different for
different models.
WARNING!
The door is heavy.
1. Open the door fully.
2. Fully lift up the clamping levers (A) on
the two door hinges.
A
A
3. Close the door until it is at an angle
of approximately 45°.
45°
4. Hold the door with one hand on each
side and pull it away from the oven at
an upwards angle.
5. Put the door with the outer side
down on a soft cloth on a stable
surface.
6. Hold the door trim (B) on the top
edge of the door at the two sides
and push inwards to release the clip
seal.
1
2
B
CAUTION!
Rough handling of the glass,
especially around the edges
of the front panel, can cause
the glass to break.
7. Pull the door trim to the front to
remove it.
8. Hold the door glass panels on their
top edge one by one and pull them
up out of the guide.
9. Clean the glass panel with water and
soap. Dry the glass panel carefully.
ENGLISH
37
When the cleaning is completed, do the
above steps in the opposite sequence.
Install the smaller panel first, then the
larger and the door.
WARNING!
Make sure that the glasses
are inserted in the correct
position otherwise the
surface of the door may
overheat.
12.5 Replacing the lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
1. Turn off the oven.
Wait until the oven is cooled down.
2. Disconnect the oven from the mains.
3. Put a cloth on the bottom of the
cavity.
The top lamp
1. Turn the lamp glass cover to remove
it.
2. Clean the glass cover.
3. Replace the lamp with a suitable 300
°C heat-resistant lamp.
4. Install the glass cover.
13. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
13.1 What to do if...
Problem Possible cause Remedy
You cannot activate or oper-
ate the oven.
The oven is not connected
to an electrical supply or it is
connected incorrectly.
Check if the oven is correctly
connected to the electrical
supply (refer to the connec-
tion diagram if available).
The oven does not heat up. The oven is turned off. Turn on the oven.
The oven does not heat up. The clock is not set. Set the clock.
The oven does not heat up. The necessary settings are
not set.
Make sure that the settings
are correct.
The oven does not heat up. The automatic switch-off is
on.
Refer to "Automatic switch-
off".
The oven does not heat up. The Child Lock is on. Refer to "Using the Child
Lock".
The oven does not heat up. The door is not closed cor-
rectly.
Fully close the door.
www.aeg.com38
Problem Possible cause Remedy
The oven does not heat up. The fuse is blown. Make sure that the fuse is
the cause of the malfunction.
If the fuse is blown again
and again, contact a quali-
fied electrician.
The lamp does not operate. The lamp is defective. Replace the lamp.
The core temperature sensor
does not operate.
The plug of the core tem-
perature sensor is not cor-
rectly installed into the sock-
et.
Put the plug of the core tem-
perature sensor as far as
possible into the socket.
The display shows F111. The plug of the core tem-
perature sensor is not cor-
rectly installed into the sock-
et.
Put the plug of the core tem-
perature sensor as far as
possible into the socket.
The display shows an error
code that is not in this table.
There is an electrical fault. • Turn off the oven with the
house fuse or the safety
switch in the fuse box
and turn it on again.
• If the display shows the
error code again, contact
the Customer Care De-
partment.
Steam and condensation
settle on the food and in the
cavity of the oven.
You left the dish in the oven
for too long.
Do not leave the dishes in
the oven for longer than 15 -
20 minutes after the cooking
process ends.
The appliance is activated
and does not heat up. The
fan does not operate. The
display shows "Demo".
The demo mode is activa-
ted.
Refer to "Basic Settings" in
"Daily use" chapter.
13.2 Service data
If you cannot find a solution to the
problem yourself, contact your dealer or
an Authorised Service Centre.
The necessary data for the service centre
is on the rating plate. The rating plate is
on the front frame of the oven cavity. Do
not remove the rating plate from the
oven cavity.
We recommend that you write the data here:
Model (MOD.) .........................................
Product number (PNC) .........................................
Serial number (S.N.) .........................................
ENGLISH 39
14. ENERGY EFFICIENCY
14.1 Product Information
Sheet
Product information according to EU 65-66/2014
Supplier's name AEG
Model identification KPK742220M 944066388
Energy Efficiency Index 80.8
Energy efficiency class A+
Energy consumption with a standard load, conven-
tional mode
0.89 kWh/cycle
Energy consumption with a standard load, fan-forced
mode
0.59 kWh/cycle
Number of cavities 1
Heat source Electricity
Volume 43 l
Type of oven Built-In Oven
Mass 37.4 kg
EN 60350-1 - Household electric cooking
appliances - Part 1: Ranges, ovens, steam
ovens and grills - Methods for measuring
performance.
14.2 Energy saving
The oven contains features
which help you save energy
during everyday cooking.
Make sure that the oven door is closed
properly when the oven operates. Do not
open the door too often during cooking.
Keep the door gasket clean and make
sure it is well fixed in its position.
Use metal cookware to improve energy
saving.
When possible, do not preheat the oven
before cooking.
Keep breaks between baking as short as
possible when you prepare a few dishes
at one time.
Cooking with fan
When possible, use the cooking
functions with fan to save energy.
Residual heat
If a programme with the Duration or End
Time selection is activated and the
cooking time is longer than 30 minutes,
the heating elements automatically turn
off earlier in some oven functions.
The fan and lamp continue to operate.
When you turn off the oven, the display
shows the residual heat. You can use that
heat to keep the food warm.
When the cooking duration is longer
than 30 minutes, reduce the oven
temperature to minimum 3 - 10 minutes
before the end of cooking. The residual
heat inside the oven will continue to
cook.
Use the residual heat to warm up other
dishes.
www.aeg.com
40
Keep food warm
Choose the lowest possible temperature
setting to use residual heat and keep a
meal warm. The residual heat indicator
or temperature appears on the display.
Cooking with the lamp off
Turn off the lamp during cooking. Turn it
on only when you need it.
Moist Fan Baking
Function designed to save energy during
cooking.
When you use this function the lamp
automatically turns off after 30 seconds.
You may turn on the lamp again but this
action will reduce the expected energy
savings.
15. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
ENGLISH
41
www.aeg.com42
ENGLISH 43
www.aeg.com/shop
867300534-C-222019
