USE & CARE GUIDE Freezer  for Thermador T18ID900LP

Table of contents

  • Important safety instructions
  • Intended use
  • Environmental protection
  • Packaging
  • Old appliances
  • Installation and connection
  • Contents of package
  • Technical data
  • Installing the appliance
  • Check built-in cut-out
  • Side-by-side installation
  • Saving energy
  • Before using for the first time
  • Water connection
  • Electrical connection
  • Getting to know your appliance
  • Appliance
  • Operating controls
  • Ice and water dispenser
  • Equipment
  • Operating the appliance
  • Switching the appliance on
  • Switching off and disconnecting the appliance
  • Setting the language
  • Setting the temperature unit
  • Setting the temperature
  • Super freezing
  • Clean lock
  • Switching ice cube production on or off
  • Reset water filter counter
  • Eco mode
  • Self-test
  • Alarm
  • Door alarm
  • Temperature alarm
  • W Freezer compartment
  • Fully utilizing the freezer volume
  • Purchasing frozen food
  • When loading products
  • Freezing fresh food
  • Thawing frozen food
  • Ice and water dispenser
  • Before using for the first time
  • Observing drinking water quality
  • Information on operation of the ice maker
  • Dispensing ice and water
  • Defrosting
  • Freezer compartment
  • Cleaning
  • Care instructions for stainless steel
  • surfaces
  • Cleaning the display
  • Cleaning the equipment
  • Noises
  • Normal noises
  • Preventing noises
  • Lighting
  • Faults – what to do?
  • Appliance
  • Dispenser
  • Customer service.

Operating tips

  • When the appliance has been switched on, it may take several hours until the set temperatures have been reached. Do not put in any food until the selected temperature has been reached.
  • The fully automatic NoFrost system ensures that the freezer compartment remains frost-free. Defrosting is not required.
  • The front sides of the housing are partly heated slightly. This prevents condensation in the area of the door seal.
  • If the freezer compartment door cannot be immediately re-opened after it has been closed, wait until the resulting low pressure has equalized.

Cleaning

Proceed as follows:

  1. Press the main On/Off switch.
  2. Take out food and store in a cool location. Place ice pack (if available) on the food.
  3. Clean the appliance with a soft cloth, lukewarm water and a little pH-neutral washing-up liquid.
  4. Wipe door seal with clear water and dry thoroughly with a cloth.
  5. Switch appliance back on and put in food

Care instructions for stainless steel surfaces

  • When taking care of and cleaning stainless steel surfaces, use only cleaning agents suitable for stainless steel and a stainless steel cleaning cloth.
  • You can purchase a suitable stainless steel cleaning cloth from customer service.
  • To prevent visible scratches, clean the stainless steel surface in the direction of the structure.

Cleaning the display

  • The change in temperature and humidity can cause the controls to steam up.
  • Switch the clean lock on before cleaning.
  • Use a clean micro-fiber cloth for cleaning.

Cleaning the equipment

To ensure you always have fresh ice cubes and to prevent old ones from sticking together, remove them and clean the ice cube container regularly.

  1. Lift the ice cube container.
  2. Slowly pull out the ice cube container.
  3. Empty and clean the ice cube container with lukewarm water.
  4. Dry the inside of the ice cube container off well so new ice cubes do not freeze and stick to it.
  5.  Insert the ice cube container until it engages.
