Using Your Countertop Oven
To Open the Countertop Oven Door:
Step 1: Grab the center of the handle underhanded with fingertips (See Figure 3).
Figure 3
Step 2: Pull down the countertop oven door carefully (See Figure 4).
Figure 4
CAUTION: This appliance generates heat during use. Do not touch hot surfaces.
Always use handles or knobs per above instructions.
Preheating the Oven
Place oven rack into the desired position before heating the oven. (See “Positioning Rack” Section)
Turn the temperature control knob to the desired temperature.
Turn the knob to the desired function.
Set the timer knob to desired time and allow 7–9 minutes for the oven to preheat.
To Use the Variable Broil Function
Select desired oven rack position. (See “Positioning Rack” Section)
Place the baking pan underneath the baking rack to make broiler pan.
Arrange food on broiler pan.
Close the door to the first notch, leaving approximately a 3-inch gap at the top.
This will insure adequate airflow during broiling.
Turn the function dial to BROIL. Only the top heater element will operate.
Turn the temperature control knob to the desired temperature.
Turn the timer knob to the desired time. The timer can be set to for up to 60 minutes.
At the end of the cookin g time, a bell signal sounds, and the oven turns off automatically.
To set the timer for less than 20 minutes, turn the timer past the 20-minute mark to engage
timer switch and then turn it back to desired time; it can then be set for cooking that will only
require a few minutes.
Turn food over about halfway through the broiling time.
When broiling is completed, open door fully and remove food carefully with oven mitt.
WARNING: Cooked food can be very hot. Handle with care. Do not leave
countertop oven unattended.
To Use the Bake Function
Select desired oven rack position. (See “Positioning Rack” Section)
Arrange food on the wire rack or in the baking pan.
Turn the function dial to BAKE. Both the top and bottom heater elements will operate.
Turn the temperature control knob to the desired temperature.
Turn the timer knob to the desired time. The timer can be set for up to 60 minutes.
At the end of the cooking time, a bell signal sounds and the oven turns off automatically.
To set the timer for less than 20 minutes,
turn the timer past the 20-minute mark to engage
timer switch
and then turn it back to desired time
; it can then be set for cooking that will
only require a few minutes.
NOTE – The top and bottom heating elements will cycle ON and OFF to maintain the
desired temperature.
WARNING: Cooked food can be very hot. Handle with care. Do not leave
countertop oven unattended.
To Use the Turbo Convection Bake Function
Select desired oven rack position. (See “Positioning Rack” Section)
Arrange food on the wire rack or in the baking pan.
Turn the function dial to TURBO CONVECTION BAKE. Both the top and bottom heater
elements will operate.
Turn the temperature control knob to the desired temperature.
Turn the timer knob to the desired time. The timer can be set for up to 60 minutes.
At the end of the cooking time, a bell signal sounds and the oven turns off automatically.
To set the timer for less than 20 minutes,
turn the timer past the 20-minute mark to engage
timer switch
and then turn it back to desired time
; it can then be set for cooking that will
only require a few minutes.
NOTE – The top and bottom heating elements will cycle ON and OFF to maintain the
desired temperature.
When baking is completed, open door fully and remove food carefully with oven mitt.
WARNING: Cooked food can be very hot. Handle with care.
Do not leave countertop oven unattended.
Defrosting Tip – When defrosting, do not preheat oven. Turn Temperature Control to 250°F. Allow
15 to 20 minutes per side for meats or fish to defrost. Always cook food promptly after thawing.
FAQs About Turbo Convection Baking
What is Turbo Convection Bake?
Answer: In your Countertop Oven there is a built in fan that circulates the hot air in the oven
chamber to better heat the food.
How do I adjust the time for Turbo Convection Bake?
Answer: On average, convection will shorten the cooking time by 30% but it varies by food.
It is suggested to go with a shorter cooking time to start with and then add time if it is needed.
What are the best foods to use with Turbo Convection Baked?
Answer: While a shorter cook time is often desirable, bake goods in particular benefit from
convection cooking as the circulating air keeps oven temperature consistent throughout.
English-7 English-8
1 Year Limited Warranty
Sunbeam Products, Inc., or if in Canada, Sunbeam Corporation (Canada) Limited, (collectively “Sunbeam”)
warrants that for a period of one year from the date of purchase, this product will be free from defects in material
and workmanship. Sunbeam, at its option, will repair or replace this product or any component of the product
found to be defective during the warranty period. Replacement will be made with a new or remanufactured
product or component. If the product is no longer available, replacement may be made with a similar product
of equal or greater value. This is your exclusive warranty. Do NOT attempt to repair or adjust any electrical or
mechanical functions on this product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. Sunbeam dealers,
service centers, or retail stores selling Sunbeam products do not have the right to alter, modify or any way change
the terms and conditions of this warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or
misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly,
repair or alteration by anyone other than Sunbeam or an authorized Sunbeam service center. Further, the warranty
does not cover: Acts of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on Sunbeam’s Liability?
Sunbeam shall not be liable for any incidental or consequential damages caused by the breach of any
express, implied or statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability
or fitness for a particular purpose is limited in duration to the duration of the above warranty.
Sunbeam disclaims all other warranties, conditions or representations, express, implied,
statutory or otherwise.
Sunbeam shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or
inability to use the product including incidental, special, consequential or similar damages or loss of
profits, or for any breach of contract, fundamental or otherwise, or for any claim brought against
purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or
consequential damages or limitations on how long an implied warranty lasts, so the above limitations or
exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province
to province, state to state or jurisdiction to jurisdiction.
How To Obtain Warranty Service
In the U.S.A.
If you have any question regarding this warranty or would like to obtain warranty service, please call
1.800.334.0759 and a convenient service center address will be provided to you.
In Canada
If you have any question regarding this warranty or would like to obtain warranty service, please call
1.800.667.8623 and a convenient service center address will be provided to you.
In the U.S.A., this warranty is offered by Sunbeam Products, Inc., located in Boca Raton, Florida 33431.
In Canada, this warranty is offered by Sunbeam Corporation (Canada) Limited, located at 20 B Hereford
Street, Brampton, Ontario L6Y 0M1. If you have any other problem or claim in connection with this
product, please write our Consumer Service Department.
PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF
THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
English-6
Welcome
Congratulations on your purchase of an
OSTER
®
Countertop Oven! If you require
service on your
OSTER
®
Countertop Oven, do not return to place of purchase. Please
contact us at www.oster.com or 1.800.334.0759.
Features of Your Countertop Oven
1. One Removable Wire Rack/Broil Rack
2. Temperature Selector Knob
3. Function Selector Knob
4. Timer Selector Knob
5. Power Light
6. Crumb Tray
7. Glass Door
8. Easy Clean Interior Walls
9. Baking Pan
10. Two Rack Positions
Learning About Your Countertop Oven
Removable Wire Rack/Broil Rack –
To accommodate
a wide variety of foods, use for all your broiling and
grilling needs. See “Positioning Rack” section.
Temperature Selector Knob –
Adjust the dial
thermostat to the desired temperature
.
Function Selector Knob –
Select cooking function by
turning the knob to the desired setting.
Timer Selector Knob –
Adjust the dial to the
desired time.
Power Light –
Indicates that oven is on.
Crumb Tray –
For crumbs or fallen food particles
collection. Pulls out for easy cleaning.
Glass Door –
Allows you to see food cooking.
Easy Clean Interior Walls –
Allows for easy cleaning.
Baking Pan –
Use for all your baking needs.
Two Rack Positions
Preparing To Use Your Countertop Oven for the First Time
If you are using your countertop oven for the first time, please be sure to:
Remove any stickers from the surface of the oven.
Open oven door and remove all printed documents and paper from inside the countertop oven.
Clean the rack, tray, and pan with hot water, a small amount of dishwashing liquid and a
non-abrasive sponge or cleaning pad.
CAUTION: DO NOT IMMERSE THE BODY OF THE UNIT IN WATER.
Dry the rack, tray, and pan thoroughly before using.
Select a location for the countertop oven. The location should be in an open area on a flat
counter where the plug will reach an outlet.
Plug the countertop oven into a 120 Volt AC electrical outlet.
The heating elements are designed to work efficiently and maintain a precise temperature.
You may not see the elements glowing, however they are working properly.
PLEASE NOTE – It is recommended that the countertop oven heat at 450° for approxi mately
15 minutes to eliminate any manufacturing residue that may remain after shipping.
English-2
Figure 2
1
2
6
3
4
5
8
10
9
7
Figure 1
To Use the Toast Function
Select desired oven rack position. (See “Positioning Rack” Section)
NOTE – Different types of bread require different settings. Lighter breads and waffles require
a lighter setting. Darker breads, muffins, and English muffins require a darker setting.
Arrange food on the wire rack.
1. Turn the function dial to TOAST. Both the top and bottom heater elements will operate.
WARNING: Cooked food can be very hot. Handle with care. Do not leave countertop
oven unattended.
2. Turn the temperature control knob to the 450°F/TOAST setting.
3. To set the timer, turn the timer past the 20 minute mark to engage timer switch
and set back to desired toast time.
When toasting is completed, open door fully and remove food carefully with oven mitt.
NOTE – The top and bottom heating elements will cycle ON and OFF to maintain
the desired temperature.
To Use The Timer And Stay On Feature (See Fig. 5)
After rotating the Temperature Dial to your desired
temperature, then you must select from the following
options on the Timer Dial.
• For items requiring shorter cooking times, rotate the
Timer Dial clockwise to the desired time. At the sound
of the bell, the oven will automatically turn “Off.”
• For longer cooking times, rotate the Timer Dial
counterclockwise to the “Stay On” setting. Cooking
will continue until the Timer Dial is manually turned
to the “Off” position and the bell will sound.
Positioning Rack
To accommodate a wide variety of foods the oven has two
rack positions. (See Figure 6)
Positioning of the rack will depend on the size of the food
and desired browning.
Before removing the rack allow the unit to cool.
For best toast and pizza results, position the rack in
the upper rack position.
PLEASE NOTE – The oven rack may tilt downward causing
food to shift when the rack is pulled out, proceed with caution.
Positioning Pan
• To accommodate a wide variety of foods the oven has two pan positions. The pan can
be placed on top of the rack or inserted into the guide rails below the rack. (See Figure Below)
• Before removing the pan allow the unit to cool.
• Positioning of the oven pan will depend on the desired cooking method. For baking, place the
pan on top of one of the racks. For grilling or broiling, insert the pan into the guide rails below
the rack and place the food on top of the rack.
For Baking
For Grilling
or Broiling
HelpFUl TipS / TrOUbleSHOOTing
P
roblem
• Overcooked /
Undercooked
Foods
• Burnt Smell
• Oven does not
turn ON
• Only one heating
element is
heating up
• Heating elements
do not stay ON
Solution
• You may have to adjust the time and
temperature to desired taste.
• Because your countertop oven is smaller
than your regular oven, it will heat up
faster and generally cook in shorter
periods of time.
• Refer to “Positioning Rack” Section, Page
English-4. Rack may need to be
adjusted to accommodate food type.
• Refer to “Cleaning Your countertop
oven” Section, Page English-5.
• Plug the countertop oven into a 120-volt
AC electrical outlet.
• Set timer knob and temperature knob to
desired setting. Both must be turned on
to operate the countertop oven.
• When toasting, make sure the oven is
not
set to broil setting.
• Be certain that function is as desired.
P
otential
C
auSe
• Incorrect temperature or
time setting
• Rack placement
• Food build-up inside
oven, on heating elements
or in crumb tray.
• Unit is unplugged
• Timer was not turned
past 10 minute mark.
• Function setting
selection determines
which heating element
will operate.
• Heating elements will
cycle ON and OFF to
maintain proper heat.
Figure 6
F
igure 5
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to
reduce the risk of fire, electric shock, and/or injury to persons including the following:
1. Read all instructions before using this product.
2.
This appliance generates heat during use. Do not touch hot surfaces. Use
handles or knobs. Always protect your hands with non-slip oven mitts or similar.
3. To protect against electric shock, do not place or immerse cord, plugs, or
appliance in water or other liquid.
4. This appliance is not to be used by children or by persons with reduced physical,
sensory or mental capabilities.
5. Close supervision is necessary when any appliance is used near children.
Children should not play with the appliance.
6. Unplug from outlet when not in use, before putting on or taking off parts
and before cleaning. Allow to cool before putting on or taking off parts, and
before cleaning. To disconnect, turn any control to OFF, then unplug power
cord from outlet. Do not disconnect by pulling on cord. Always grasp the
plug and pull to disconnect.
7. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, or has been damaged in any manner. Do not attempt to replace or
splice a damaged cord. Return appliance to the manufacturer (see warranty) for
examination, repair or adjustment.
8. The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
9. Do not use outdoors or for commercial purposes.
10. Do not let cord hang over edge of table or counter, or touch hot surfaces.
11. Do not place on or near wet surfaces, or heat sources such as a hot gas or electric
burner, or in a heated oven.
12. Extreme caution must be used when moving an appliance or removing a pan,
containing hot oil or other hot liquids. Always protect your hands with non-slip
oven mitts or similar.
13. Do not use appliance for other than intended use. Misuse can cause injuries.
Intended for household countertop use only. Keep 6 inches (152 mm) clear from
the wall and on all sides. Always use appliance on a dry, stable, level surface.
14. Oversize foods or metal utensils must not be inserted in a countertop oven as
they may create a fire or risk of electric shock.
15. A fire may occur if the countertop oven is covered, touching or near flammable
materials, including curtains, draperies, towels, walls, and the like, when in
operation. Do not store any item on top of the appliance when in operation.
16. Do not clean with metal scouring pads. Pieces can break off the pad and touch
electrical parts, creating a risk of electric shock.
17. Extreme caution should be exercised when using containers constructed of
materials other than metal or glass.
18. Do not store any materials, other than manufacturers recommended accessories,
in this oven when not in use.
19. Do not place any of the following materials in the oven: paper, cardboard,
plastic, or any materials that may catch fire or melt.
20. Do not cover crumb tray or any part of the oven with metal foil. This will cause
overheating of the oven.
21. Empty the crumb tray after each use.
22. The glass door is made of tempered glass. Always inspect the glass door for chips,
cracks or any other damage. Do not use the countertop oven if the glass door is
damaged, as the glass may shatter during use.
23. Do not use with a programmer, timer, wireless plug adapter or outlet that allows
control remotely, or connect to a circuit that is regularly switched on and off by
the utility.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
North American models with polarized plugs:
POWER CORD INSTRUCTIONS:
A short power-supply cord or detachable power-supply cord is provided to reduce risks
resulting from becoming entangled in or tripping over a longer cord. Longer detachable
power-supply cords or extension cords are available and may be used if care is exercised
in their use. If a long detachable power-supply cord or extension cord is used:
a. The marked electrical rating of the cord set or extension cord should be at
least as great as the electrical rating of the appliance;
b. The cord should be arranged so that it will not drape over the countertop
or tabletop where it can be pulled on by children or tripped over
unintentionally; and
c. If the appliance is of the grounded type, the cord set or extension cord
should be a grounding-type 3-wire cord.
Do not pull, twist or otherwise abuse the power cord.
NOTICES
1. Some countertop and table surfaces are not designed to withstand the prolonged
heat generated by certain appliances. Do not set the heated unit on a finished wood
table. We recommend placing a hot pad or trivet under your countertop oven to
prevent possible damage to the surface.
2. During initial use of this appliance, some slight smoke and/or odor may be
detected. This is normal with many heating appliances and will not recur after
a few uses.
POLARIZED PLUG
This appliance has a polarized plug, (one blade is wider than
the other). As a safety feature to reduce the risk of electrical
shock, this plug is intended to t in a polarized outlet only
one way. If the plug does not t fully in the outlet, reverse
the plug. If it still does not t, contact a qualied electrician.
Do not attempt to defeat this safety feature or modify the plug in any way. If the plug ts
loosely into the AC outlet or if the AC outlet feels warm do not use that outlet.
Cleaning Your Countertop Oven
Before cleaning your OSTER
™
countertop oven, turn controls to OFF, unplug cord,
and allow it to cool. To clean, wipe with damp cloth.
CAUTION: DO NOT IMMERSE IN WATER!
Make sure to use only mild, soapy water. Abrasive cleaners, scrubbing brushes and
chemical cleaners will damage the
coating on this unit. Empty crumb tray frequently to
avoid accumulation
of crumbs.
Countertop oven racks are dishwasher safe
(top of dishwasher only).
This appliance has no user serviceable parts. Any servicing beyond that described in the
Cleaning Section should be performed by an Authorized Service Representative only.
See Warranty Section.
Storing Your Countertop Oven
Allow the appliance to cool completely before storing. If storing the countertop oven
for long periods of time, make certain that the countertop oven is clean and free of food particles.
Store the countertop oven in a dry location such as on a table or countertop or cupboard shelf.
Other than the recommended cleaning, no further user maintenance should be necessary.
Loading ...
Loading ...
Loading ...
