Pioneer VSX-1131 7.2 Channel AV Receiver

User Manual - Transcript

• Page 1 - English - : Basic Manual Hookup Step1 Choose your Speaker Layout 3 Step2 Connect the Speakers 9 Step3 Connect the TV 12 Step4 Connect the AV Components 14 Step5 Connect Other Cables 18 Setup Step6 Power On amp Initial Setup 19 HDMI Setup 20 Playback Basic Playback 21 Network Functions 22 Others 24 Part Names Front Panel 26 Rear Panel 27 Remote Controller 28 Display 28 This manual includes information needed when starting up and also instructions for frequently used operations The quotAdvanced Manualquot is available on the internet with details about the playback features listening modessettings details specifications and troubleshooting The Advanced Manual is created in a format that makes it easy to read on a PC or Smartphone httpwwwpioneeraudiovisualcommanualvsx1131advenhtml Advanced Manual found here VSX1131 gt Before start gt Hookup gt Setup gt Playback gt Part Names AV Receiver SN29402189VSX1131BASEnbook 1 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 2 - English - : gt Before start gt Hookup gt Setup gt Playback gt Part Names Whats in the box 1 Main unit 2 Remote controller RC914R 1 Batteries AAAR03 2 3 Indoor FM antenna 1 4 AM loop antenna 1 5 Speaker setup microphone 1 6 Power cord 1 Main features This unit is connected between your TV and your AV components To play select the source with the input selector You can connect 71ch of speakers to this unit with 7ch at 170 W 6 ohms 1 kHz 09THD North American models 160 W 6 ohms 1 kHz 1THD European Australian Asian and Taiwanese models per channel plus a powered subwoofer pre out jack Supports playback in Dolby Atmos format which provides 360e sound placement The HDMI jack supports 4K video input and output Jacks IN1 to 3 and OUT MAINSUB support HDCP22 HDMI CEC functionality Control features such as linking input switching with the input selector and players conforming to the CEC standard switching audio output and volume using the remote controller of a CEC compliant TV and automatically switching this unit to standby when the TV is turned off HDMI Standby Through Video and audio signals from AV components can be transmitted to the TV even if this unit is in standby ARC Connection with an ARCcompatible TV is complete with one HDMI cable Easy Initial Setup using onscreen guidance and OnScreen Display OSD showing operations on the TV Internet radio and AirPlay via wired LAN or WiFi wireless LAN and network features such as Music Server that enables PC music file playback USB playback plus other playback features such as AMFM radio and BLUETOOTH play Playback formats supported by Music Server and USB include WAV FLAC and DSD highres source Multizone Connection which allows you to play in the main room and listen in a separate room ZONE 2 You can connect a speaker B system We plan to provide support for the DTSX audio format through a firmware update for this unit Refer to our homepage for more information CAUTION Connect speakers with 6 Ω to 16 Ω impedance The power cord must be connected only after all other cable connections are completed 0 We will not accept responsibility for damage arising from the connection of equipment manufactured by other companies For Taiwanese models only SN29402189VSX1131BASEnbook 2 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 3 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names Step1 Choose your Speaker Layout Front Speakers Center Speaker Surround Speakers Powered Subwoofer For 51Channel System This is a 51channel system that is the basic surround system Front speakers output front stereo sound and a center speaker outputs center sound such as dialogs and vocals Surround speakers create back sound field Powered subwoofer reproduces bass sounds and creates rich sound field The front speakers should be positioned at ear height while the surround speakers should be positioned just above ear height Center speaker should be set up facing the listening position Place the powered subwoofer towards the front Placing it between the center speaker and a front speaker gives you a natural sound even when playing music 0 The front speakers center speaker and surround speakers are counted as 5 channels and the powered subwoofer is counted as 01 of a channel giving us the name 51ch system Go To quotHookupquot P9 1 22e to 30e 2 120e Speaker B System In a 51Channel System you can connect one more set of front speakers to use as a Speaker B System In this state the 51 Channel System becomes the Speaker A System and you can switch the same audio to output from A B or AB There is no output from Speakers B if Zone Speaker connection P17 is used Go To quotHookupquot P9 SN29402189VSX1131BASEnbook 3 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 4 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names P3 Surround Back Speakers For 71Channel System with Surround Back Speakers This is a system with surround back speakers added to the basic 51channel system The connection of surround back speakers improves the sense of envelopment and connectivity of sound created by the back sound field and provides a more real sound field You can select the Dolby Atmos listening mode which realizes the most uptodate 3D surround sound when the input format is Dolby Atmos With formats other than Dolby Atmos you can still create a sound field by outputting sound from the surround back speakers when you select the Dolby Surround listening mode The optimal positioning is for surround back speakers to be at ear height Place the surround speakers in a more slightly forward position than you would in a 51channel system 0 If you are including surround back speakers in the setup surround speakers are required Go To quotHookupquot P9 1 22e to 30e 2 90e to 110e 3 135e to 150e Speaker B System In a 71Channel System with Surround Back Speakers you can connect one more set of front speakers to use as a Speaker B System In this state the 71 Channel System becomes the Speaker A System and you can switch the same audio to output from A B or AB Note that sound is not output from the surround back speaker when AB is selected There is no output from Speakers B if Zone Speaker connection P17 is used Go To quotHookupquot P9 SN29402189VSX1131BASEnbook 4 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 5 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names 3 09 m or more P3 9 Height Speakers Choose one of the following Front High Speakers Rear High Speakers For 71Channel System with Height SpeakerA This is a basic 51channel system with the addition of height speakers either as front high speakers or rear high speakers Select which speakers to setup according to the environment of the room You can select the Dolby Atmos listening mode 512 channel playback which realizes the most uptodate 3D surround sound including overhead sounds when the input format is Dolby Atmos With formats other than Dolby Atmos you can still create a sound field by outputting sound from the height speakers when you select the Dolby Surround listening mode Front high speakers or rear high speakers should be situated at least 09 m higher than the front speakers Front high speakers should be situated directly above the front speakers and the distance between the rear high speakers should match the distance between the front speakers Both should be set up facing the listening position Go To quotHookupquot P10 1 22e to 30e 2 120e SN29402189VSX1131BASEnbook 5 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 6 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names P3 9 Height Speakers Choose one of the following Top Front Speakers Top Middle Speakers Top Rear Speakers For 71Channel System with Height SpeakerB This is a basic 51channel system using ceiling speakers for example with the addition of height speakers either as top front speakers top middle speakers or top rear speakers Select which speakers to setup according to the environment of the room You can select the Dolby Atmos listening mode 512 channel playback which realizes the most uptodate 3D surround sound including overhead sounds when the input format is Dolby Atmos With formats other than Dolby Atmos you can still create a sound field by outputting sound from the height speakers when you select the Dolby Surround listening mode Fit top front speakers on the ceiling forward of the seating position top middle speakers on the ceiling directly above the seating position and top rear speakers on the ceiling behind the seating position The distance between each pair should match the distance between the two front speakers 0 Dolby Laboratories recommends placing this type of height speakers to obtain the best Dolby Atmos effect Go To quotHookupquot P10 1 30e to 55e 2 65e to 100e 3 125e to 150e SN29402189VSX1131BASEnbook 6 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 7 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names P3 9 Height Speakers Choose one of the following Dolby Enabled Speakers Front Dolby Enabled Speakers Surround Dolby Enabled Speakers Surround Back For 71Channel System with Height SpeakersC This is a basic 51channel system that using Dolby enabled speakers with the addition of height speakers either as Dolby enabled speakers front or Dolby enabled speakers surround or Dolby enabled speakers surround back Select which speakers to setup according to the environment of the room Dolby enabled speakers are special speakers designed to face the ceiling so that sound is heard after bouncing off the ceiling so that sound appears to be coming from overhead You can select the Dolby Atmos listening mode 512 channel playback which realizes the most uptodate 3D surround sound including overhead sounds when the input format is Dolby Atmos With formats other than Dolby Atmos you can still create a sound field by outputting sound from the height speakers when you select the Dolby Surround listening mode Place them either above the front speakers or above the surround speakers or above the surround back speakers If they are integrated Dolby enabled speakers put in place of the front speakers the surround speakers or the surround back speakers Go To quotHookupquot P10 1 22e to 30e 2 90e to 120e 3 135e to 150e SN29402189VSX1131BASEnbook 7 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 8 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names Front Speakers BiAmping Center Speaker Surround Speakers Powered Subwoofer For BiAmping the Speakers It is possible to connect front speakers supporting BiAmping to improve quality of the bass and treble The maximum number of channels available with this connection is 51 because BiAmping speakers require one amplifier for the tweeter jacks and one amplifier for the woofer jacks The effects and placements for speakers are the same as the 51channel plan that doesnt use BiAmping speakers Go To quotHookupquot P11 1 22e to 30e 2 120e SN29402189VSX1131BASEnbook 8 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 9 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names Step2 Connect the Speakers 12 12 mm Speaker B 1 Speaker cable 2 Subwoofer cable in case of Pages 3 to 4 Connect 123456 for a 51channel system With a 71Channel System with Surround Back Speakers also connect 7 and 8 Up to two powered subwoofers can be connected The same signal is output from each of the SUBWOOFER jacks With this connection you can connect one more set of front speakers to use as a Speaker B System Switch Speakers AB with AV Adjust P25 Note that sound is not output from the surround back speaker when AB is selected Make sure the exposed wires of the speakers do not stick out of the speaker terminals when connecting If the exposed wires of the speakers touch the rear panel or the and wires touch each other the protection circuit will be activated Setup 0 Settings for the speaker configuration you have connected need to be made in quot1 Full Auto MCACCquot P19 in Initial Setup SN29402189VSX1131BASEnbook 9 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 10 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names 12 12 mm 1 Speaker cable 2 Subwoofer cable in case of Pages 5 to 7 Connect 1234569 Up to two powered subwoofers can be connected The same signal is output from each of the SUBWOOFER jacks 0 Apart from these connections you can also connect surround back speakers 7 and 8 However you can only output audio from one set of 78 or 9 at a time When both are connected you can select which speakers to prioritize with AV Adjust P25 Make sure the exposed wires of the speakers do not stick out of the speaker terminals when connecting If the exposed wires of the speakers touch the rear panel or the and wires touch each other the protection circuit will be activated Setup 0 Settings for the speaker configuration you have connected need to be made in quot1 Full Auto MCACCquot P19 in Initial Setup SN29402189VSX1131BASEnbook 10 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 11 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names 12 12 mm For high frequency For low frequency 1 Speaker cable 2 Subwoofer cable in case of Page 8 Connect front speakers compatible with BiAmping connection to the FRONT jacks and the SURROUND BACK jacks Make sure you remove the jumper bar fitted between the woofer jacks and tweeter jacks of the front speakers In case of BiAmping connection refer to the instruction manual of your speakers Up to two powered subwoofers can be connected The same signal is output from each of the SUBWOOFER jacks Make sure the exposed wires of the speakers do not stick out of the speaker terminals when connecting If the exposed wires of the speakers touch the rear panel or the and wires touch each other the protection circuit will be activated Setup 0 BiAmping connection requires you to change some settings Select quotYesquot in quotBiAmpquot in quot1 Full Auto MCACCquot P19 in the Initial Setup SN29402189VSX1131BASEnbook 11 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 12 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names Step3 Connect the TV HDMI IN ARC TV 1 HDMI cable if you have ARC TV This unit is connected between your TV and AV components If you connect two or more AV components you can select the video displayed on the TV and the audio output from this unit by changing the input selector Shown here are the connections for a TV that supports the ARC Audio Return Channel feature By connecting with a single HDMI cable you can not only output the video input to this unit to the TV but you can also play the sound from the TV through this unit Choose an HDMI IN jack on the TV that supports ARC when connecting Another TV or projector can be connected to the HDMI OUT SUB jack This jack does not support ARC For details about how to output the video to a connected device P21 Setup 0 Settings are required to use the ARC function Select quotYesquot in quot5 Audio Return Channelquot P20 in the Initial Setup 0 Please refer to the TVs operation manual for directions on connections and setup for the TV SN29402189VSX1131BASEnbook 12 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 13 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names TV 1 HDMI cable 2 Digital optical cable if you have NonARC TV This unit is connected between your TV and AV components If you connect two or more AV components you can select the video displayed on the TV and the audio output from this unit by changing the input selector This describes the connections for a TV that does not support the ARC Audio Return Channel feature By connecting with both an HDMI cable and a digital optical cable you can not only output the video input to this unit to the TV but you can also play the sound from the TV through this unit 0 Connection with a digital optical cable is not necessary if you will watch TV through a device such as a cable settop box that is not use a tuner built into the TV Another TV or projector can be connected to the HDMI OUT SUB jack This jack does not support ARC For details about how to output the video to a connected device P21 SN29402189VSX1131BASEnbook 13 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 14 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names Step4 Connect the AV Components BDDVD GAME CableSatellite settop box Streaming media player 1 HDMI cable if you have HDMI AV Components This is an example of connection with an AV component that has an HDMI jack With connection to an AV component that conforms with the CEC Consumer Electronics Control standard you can use features such as the HDMI CEC feature that links with the input selector and the HDMI Standby Through feature which allows you to play video and audio from AV components on the TV even when this unit is in standby mode 0 To play 4K or 1080p video use a high speed HDMI cable Further to enjoy HDCP22 compatible video connect to the HDMI IN1 to IN3 jacks You can connect a device such as a video camera to the AUX INPUT HDMI jack on the front panel Setup 0 HDMI setup P20 is required to use the HDMI CEC and HDMI Standby Through features Make settings after all connections are complete 0 To enjoy digital surround sound including Dolby Digital audio output should be set to quotBitstream outputquot on the connected Bluray Disc player or other device SN29402189VSX1131BASEnbook 14 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 15 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names OR BDDVD 1 Component video cable 2 Digital optical cable 3 Analog audio cable if you have NonHDMI AV Components This is an example of connection with an AV component that does not have an HDMI jack Make the connections to the AV component to match the jacks it has When video input connection is to the BDDVD jack the audio input connection should also be to the BDDVD jacks and so on so that you connect the video input jacks to the jacks with the same name as the audio input jacks Note that video signals input to the VIDEO IN jack or the COMPONENT VIDEO IN jacks will be upconverted to HDMI signals and then output from the HDMI OUT jack 0 To enjoy digital surround playback in formats such as Dolby Digital you need to make a connection for audio signals with a digital coaxial cable or digital optical cable Setup 0 The COMPONENT VIDEO IN jacks are compatible only with 480i or 576i resolution When you input video signals to the COMPONENT VIDEO IN jacks set the output resolution of the player to 480i or 576i Select interlace if there is no option for 480i etc If your player does not support 480i or 576i output use the VIDEO IN jack 0 To enjoy digital surround sound including Dolby Digital audio output should be set to quotBitstream outputquot on the connected Bluray Disc Player or other device SN29402189VSX1131BASEnbook 15 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 16 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names OR CD Turntable 1 Digital coaxial cable 2 Analog audio cable if you have Audio Components Example of a connection with an audio component Connect a CD player using a digital coaxial cable or analog audio cable You can also connect a turntable that has an MMtype cartridge to the PHONO jack 0 If the turntable has a builtin audio equalizer connect it to another AUDIO IN jack Further if the turntable uses an MC type cartridge install an audio equalizer compatible with the MC type cartridge between the unit and the turntable then connect to any AUDIO IN jack other than the PHONO jack If the turntable has a ground wire connect it to the SIGNAL GND terminal of this unit SN29402189VSX1131BASEnbook 16 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 17 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names BDDVD ZONE2 LINE OUT ZONE SPEAKER ZONE2 LINE IN MAIN ROOM 1 Analog audio cable 2 Speaker cable Multizone Connection You can enjoy audio in the separate room by for example playing a Bluray Disc player in the main room where this unit is located and listening to internet radio in the separate room ZONE 2 0 DSD and Dolby TrueHD audio signals are not output to ZONE 2 when selected with the quotNETquot input selector Connections with an AV component When outputting the audio of an external AV component to ZONE 2 you need to connect using an analog audio cable ZONE 2 LINE OUT It is possible to play 2 ch source in a separate room while 71 ch source is being played in the main room Connect the ZONE 2 LINE OUT jacks of the unit and the LINE IN jacks of the premain amplifier in a separate room with an analog audio cable ZONE SPEAKER It is possible to connect speakers in a separate room and play 2 ch sources 0 You can play through a maximum of 51 channels in the main room during ZONE 2 playback Listening modes such as the Dolby Atmos modes cannot be selected 0 There is no output from Speakers B if Zone Speaker connection is used Setup 0 Settings are required in Initial Setup quot4 Multi Zone Setupquot P20 to enjoy this feature SN29402189VSX1131BASEnbook 17 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 18 - English - : gt Before start gt Hookup gtSetup gtPlayback gtPart Names Step5 Connect Other Cables Antenna Hookup Move the antenna around while playing the radio to find the position with the best reception Use a thumb tack or similar to attach the indoor FM antenna to a wall North American and Taiwanese models European Australian and Asian models AM loop antenna Indoor FM antenna AM FM Network Hookup Connect this unit to the network using wired LAN or WiFi wireless LAN You can enjoy network features such as internet radio Music Server and AirPlay by connecting the unit to the network If you connect by wired LAN connect with an Ethernet cable to the NETWORK port as shown in the illustration To connect by WiFi then after selecting quotWirelessquot in quot3 Network Connectionquot P20 in Initial Setup select the desired setting method and follow the onscreen instructions to configure the connection Power Cord Hookup Connect the power cord to the power outlet after completing all other connections 0 Taiwanese models include removable power cords Connect the power cord to AC IN of the unit and then connect to the outlet Always disconnect the outlet side first when disconnecting the power cord SN29402189VSX1131BASEnbook 18 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 19 - English - : gt Before start gt Hookup gtSetup gt Playback gt Part Names Step6 Power On amp Initial Setup Initial Setup starts automatically Once all connections are complete change the TVs input to the input for this unit inset batteries in the remote controller and press Í to turn the power on When you turn the unit on for the first time Initial Setup is automatically shown on the TV to enable you to make settings required for startup using simple operations following onscreen guidance These instructions will guide you through some items that you need to check beforehand Read beforehand so the setup goes smoothly Operation Select the item with the cursors of the remote controller and press ENTER a To return to the previous screen press b To redo the Initial Setup If you terminate the procedure on the way or want to change a setting made during Initial Setup press on the remote controller select quotSystem Setupquot quotMiscellaneousquot quotInitial Setupquot from Home and press ENTER 1 Full Auto MCACC Place the supplied speaker setup microphone in the listening position measure the test tones emitted by the speakers then the unit automatically sets the optimum volume level for each speaker the crossover frequencies and the distance from the listening position This also enables correction of distortion caused by the acoustic environment of the room 0 Use a tripod or similar to place the speaker setup microphone at ear height 0 The subwoofer sound may not be detected since it is extremely low frequencies Set the subwoofer volume to more than halfway 0 Calibration takes several minutes to be completed The speakers emit the test tone at high volume during measurement so be careful of your surroundings Keep the room as quiet as possible during measurement If the measurement is interrupted turn off the household appliances a b Initial Setup Language Select English Deutsch Français Español Italiano Nederlands Svenska MCACC SETUP MIC SN29402189VSX1131BASEnbook 19 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 20 - English - : gt Before start gt Hookup gtSetup gt Playback gt Part Names 2 Source Connection Check that each input source is connected correctly Follow the guidance select the input you want to confirm start play of the selected player and confirm that the images appear on the TV and that sound is played 3 Network Connection Set up WiFi connection with an access point such as a wireless LAN router There are the following two methods of connecting by WiFi quotScan Networksquot Search for an access point from this unit Find out the SSID of the access point beforehand quotUse iOS Device iOS7 or laterquot Share the iOS devices WiFi settings with this unit If you select quotScan Networksquot there are a further two choices of connection method Check the following 0 quotEnter Passwordquot Enter the password or key of the access point to connect 0 quotPush Buttonquot If the access point has an automatic connection button you can connect without entering a password 0 If the SSID of the access point is not displayed then in the screen listing the SSIDs select quotOtherquot with the cursor on the remote controller and press ENTER then follow the onscreen instructions Keyboard input To switch between upper and lower case select quotAaquot on the screen and press ENTER To select whether to mask the password with quotquot or display it in plain text press Fav on the remote controller Press CLEAR to delete all the input characters 0 A confirmation screen asking you to agree to the privacy policy is displayed during network setting Select quotYesquot and press ENTER to indicate agreement 4 Multi Zone Setup When you want to enjoy audio in a room other than the main room set the audio output method for the separate room ZONE2 If you have connected speakers in a separate room with speaker cable select quotUsing AV Receiverquot If you have connected a premain amplifier in a separate room with an analog audio cable select quotwith External Premain Amplifierquot 5 Audio Return Channel If you have connected a TV that supports ARC select quotYesquot This units ARC setting turns on and you can listen to the TVs audio through this unit WiFi Setup SSID When finished select the quotOKquot key Ɵơ OKAa a b cdef ghi jklm nopqr s t uvwxy z 1 2 3456789 0 AaAll Erase HDMI Setup HDMI CEC Make this setting to enable the control feature for devices complying with the CEC standard This is set to on automatically if you have selected quotYesquot in quot5 Audio Return Channelquot in the Initial Setup Press the button on the remote controller to set quotSystem Setupquot quotHardwarequot quotHDMIquot quotHDMI CECquot to quotOnquot on the TV screen Also enable the CEC control feature on the CEC device you have connected HDMI Standby Through Even if this unit is in standby the input signals from AV components are transmitted to the TV 0 quotAutoquot quotAuto Ecoquot Select one of these settings when connected AV components comply with the CEC standard Irrespective of the input selector selected immediately before switching the unit to standby you can transmit the input signals from AV components to the TV Select quotAuto Ecoquot if the TV is also CECcompliant You can reduce power consumption in standby mode 0 quotInput selector names for BDDVD etcquot You can transmit the input signals from the set input selector to the TV It can be selected when quotHDMI CECquot is set to quotOffquot 0 quotLastquot You can transfer the input signals of the input selector selected immediately prior to the unit being switched to standby It can be selected when quotHDMI CECquot is set to quotOffquot To exit the settings press HDMI HDMI CEC HDMI Standby Through Audio TV Out Audio Return Channel Auto Delay On AutoEco Auto Auto On SN29402189VSX1131BASEnbook 20 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 21 - English - : gt Before start gt Hookup gt Setup gt Playback gtPart Names Basic Playback AV Component Playback 1 Switch the input on the TV to that assigned to the unit 2 Press the input selector a on the remote controller with the same name as the jack to which you connected the player to switch the input For example press BDDVD to play the player connected to the BDDVD jack Press TV to listen the TVs sound You can also select input with the 21 buttons 0 When the CEC link function works the input switches automatically when you have connected a CEC compliant TV and player to this unit using HDMI connection 3 Start play on the player 4 Use VOL b to adjust the volume When a TV is connected to the HDMI OUT SUB jack Press the button on the remote controller to display the AV Adjust and set quotOtherquot quotHDMI Outquot to either quotSUBquot or quotMAINSUBquot Listening Mode This unit is equipped with a variety of listening modes For details on the listening modes see the Advanced Manual This section introduces some of the popular modes 0 A future firmware update is planned to enable this unit to support playback in DTS NeuralX audio format Neo6 Cinema and Neo6 Music are available until an update AUTODIRECT button c You can select the Auto Surround Direct and Pure Direct modes In either case for 2 channel input signals the Stereo mode is automatically selected that plays only from the front speakers and subwoofer and for multichannel input signals listening modes are automatically selected that match the input signal so Dolby Digital for Dolby Digital sources and DTSHD Master Audio for DTSHD Master Audio The Direct mode shuts down some processing that can affect sound quality such as the tone control features so you can enjoy even better sound quality The Pure Direct mode shuts down even more processes that affects sound quality so you get a more faithful reproduction of the original sound In this case the speaker calibration made with MCACC is disabled 0 Depending on the input signal and speaker configuration the Dolby Surround and DTS NeuralX modes that expand 2 channel and 51 channel input signals to 51 channel and 71 channel may be automatically selected SURR button d You can select a variety of listening modes to suit your taste There are the Dolby Digital DTSHD Master Audio and Stereo modes that you can choose to suit the input signal or the Dolby Surround and DTS NeuralX modes that can expand 2 channel and 51 channel input signals to 51 or 71 channels You can also enjoy original surround modes such as ExtStereo and Drama modes STEREO button e You can select the quotStereoquot mode to playback only from the front speakers and subwoofer The listening mode last selected for the source is remembered for each of the AUTODIRECT SURR and STEREO buttons If content you play is not supported by the listening mode you selected last the listening mode that is standard for that content is selected automatically Press f repeatedly to switch the display of the main unit in order of f a b c d e SN29402189VSX1131BASEnbook 21 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 22 - English - : gt Before start gt Hookup gt Setup gt Playback gtPart Names Network Functions Network Services 1 Switch the input on the TV to that assigned to the unit 2 Press NET to display the network service list screen 3 Select the item with the cursors of the remote controller and press ENTER to confirm your selection a To return to the previous screen press b Internet Radio When this unit is connected to a network you can listen to TuneIn or other preregistered Internet radio services After selecting the desired service follow the onscreen instructions using the cursors to select radio stations and programs then press ENTER to play Play starts when 100 is displayed for buffering Music Server You can play music files stored on homenetwork compliant PCs or NAS devices connected to the same network as this unit Select the server with the cursors select the desired music file and press ENTER to start playback Play starts when 100 is displayed for buffering Notes 0 Network services become selectable after the network starts up even if they cannot be selected first 0 Functionality may be introduced by firmware updates and service providers may cease services meaning that some network services and content may become unavailable in the future Furthermore available services may vary depending on your area of residence a b USB Play music files on a USB storage device 0 Operation cannot be guaranteed for all USB storage devices 1 Switch the input on the TV to that assigned to the unit 2 Plug your USB storage device with the music files into the USB port on the front of the unit 3 Press USB on the remote controller 4 Select the desired folder or music file with the cursors of the remote controller and press ENTER to confirm and start playback a 0 This unit can use USB storage devices that comply with the USB mass storage device class standard The unit is also compatible with USB storage devices using the FAT16 or FAT32 file system formats a SN29402189VSX1131BASEnbook 22 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 23 - English - : gt Before start gt Hookup gt Setup gt Playback gtPart Names AirPlay You can wirelessly enjoy the music files on an iPhone iPod touch or iPad connected to the same access point as this unit 0 Update the OS version on your iOS device to the latest version 1 Connect the iOS device to the access point 2 Press NET 3 Tap the AirPlay icon in the control center of the iOS device and select this unit from the list of devices displayed and tap quotDonequot 4 Play the music files on the iOS device 0 The default status is for the Network Standby feature to be on so when you do steps 3 and 4 above this unit automatically comes on and input switches to quotNETquot To reduce the amount of power consumed in standby mode press the button on the remote controller then in the Home displayed set quotSystem Setupquot quotHardwarequot quotPower Managementquot quotNetwork Standbyquot to quotOffquot 0 Due to the characteristics of AirPlay wireless technology the sound produced on this unit may slightly be behind the sound played on the AirPlayenabled device You can also play back music files on the computer with iTunes Ver 102 or later Before operation make sure this unit and the PC are connected to the same network then press NET on this unit Next click the AirPlay icon in iTunes select this unit from the list of devices displayed and start play of a music file VSXXXXXX iPhone BLUETOOTH Playback Pairing 1 When you press BT AUDIO on the remote controller quotNow Pairingquot is displayed on this units display and the pairing mode is enabled 2 Enable turn on the BLUETOOTH function of the BLUETOOTH enabled device then select this unit from amongst the devices displayed If a password is requested enter quot0000quot 0 To connect another BLUETOOTH enabled device press and hold BT AUDIO until quotNow Pairingquot is displayed then perform step 2 above This unit can store the data of up to 8 paired devices 0 The coverage area is 48 feet 15 meters Note that connection is not always guaranteed with all BLUETOOTH enabled devices Playing Back 1 When the unit is on connect the BLUETOOTH enabled device 2 The input selector of this unit will be automatically switched to quotBT AUDIOquot 3 Play music Increase the volume of the BLUETOOTH enabled device to an appropriate level 0 Due to the characteristics of BLUETOOTH wireless technology the sound produced on this unit may slightly be behind the sound played on the BLUETOOTH enabled device VSXXXXXX SN29402189VSX1131BASEnbook 23 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 24 - English - : gt Before start gt Hookup gt Setup gt Playback gtPart Names Others Listening To the Radio 1 Press TUNER a on the remote controller repeatedly to select either quotAMquot or quotFMquot on the display 2 Press MODE c on the remote controller so that the quotTunMode Autoquot is displayed on the display 3 When you press the cursor b buttons on the remote controller automatic tuning starts and searching stops when a station is found When tuned into a radio station the quotTUNEDquot indicator on the display lights You can preset up to 40 stations 1 Tune into the AMFM radio station you want to register 2 Press Fav d on the remote controller so that the preset number on the display flashes 3 While the preset number is flashing about 8 seconds repeatedly press the cursor b buttons on the remote controller to select a number between 1 and 40 4 Press Fav d again on the remote controller to register the station When registered the preset number stops flashing To select a preset radio station press the cursor b buttons on the remote controller 0 To delete a preset station press the cursor b buttons on the remote controller to select the preset number you want to delete press Fav d on the remote controller and then press CLEAR e while the preset number is flashing When deleted the number on the display goes off Frequency step setting Press the button on the remote controller to select quotSystem Setupquot quotMiscellaneousquot quotTunerquot quotAMFM Frequency Stepquot or quotAM Frequency Stepquot and select the frequency step for your area For Taiwanese models the setting is quot10 kHz 02 MHzquot at the time of purchase Please change it to quot9 kHz 005 MHzquot Note that when this setting is changed all radio presets are deleted c d e a b Multizone Settings are required if you have connected the speakers in the separate room ZONE 2 using speaker cables If you havent made the Multi Zone settings P20 in Initial Setup press the button on the remote controller and make the settings in System Setup accessed from the Home screen that is displayed Select quotZone 2quot in quotSystem Setupquot quotSpeakerquot quotConfigurationquot quotZone Speakerquot Play 1 While holding down MODE a on the remote controller press ZONE 2 b for 3 or more seconds until the remote indicator blinks twice 0 The remote controller switches to the mode for controlling ZONE 2 2 Point the remote controller at the main unit and press Í d quotZ2quot lights on the main unit display 3 Press the input selector button e of the input to be played in the separate room On the main unit after pressing ZONE 2CONTROL within 8 seconds turn the INPUT SELECTOR dial to select the input to be played in the separate room 0 You can only select the same inputs for the main room and separate room with the quotNETquot or quotBLUETOOTHquot or quotUSBquot input selector If you have quotNETquot selected in the main room and then select quotUSBquot in the separate room the main room also switches to quotUSBquot You cannot select different stations for the main room and separate room with To return the remote controller to main room control mode While holding down MODE a on the remote controller press MAIN c for 3 seconds or more until the remote indicator flashes once a b c d e SN29402189VSX1131BASEnbook 24 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 25 - English - : gt Before start gt Hookup gt Setup gt Playback gtPart Names the AMFM radio 4 Volume adjustment is done on the premain amplifier for the separate room when connected via ZONE 2 LINE OUT When outputting from ZONE speakers adjust with VOL on the remote controller To control on the main unit press ZONE 2CONTROL and adjust with the MASTER VOLUME control within 8 seconds 0 If ZONE 2 is on power consumption during standby becomes larger than normal To turn off the function Press Í while in the mode for controlling ZONE 2 on the remote controller Alternatively press ZONE 2ONOFF on the main unit Playing in ZONE 2 only If you turn the unit to standby during multizone playback the Z2 indicator is dimmed and the playback mode is switched to playback in a separate room only Setting ZONE 2 to on while this unit is in standby will also switch the playback mode to the same setting AV Adjust By pressing on the remote controller during play you can adjust frequently used settings such as the switching the speakers and adjusting sound quality using onscreen menus Select the item with the cursors of the remote controller and press ENTER to confirm your selection To return to the previous screen press Note that there is no display on the TV screen when the input selector is quotCDquot quotTVquot quotPHONOquot quotFMquot or quotAMquot so follow the main units display while doing the operations quotTonequot It is possible to enhance or moderate the bass and treble quotOtherquot Enables you to make a variety of settings 0 quotSound Delayquot If the video is behind the audio you can delay the audio to offset the gap 0 quotSound Retrieverquot Improve the quality of compressed audio 0 quotSpeakersquot You can switch the output on the surround back speakers and height speakers and switch the output for speakers AB Home When you press on the remote controller the Home is displayed and you can make settings in the various menus Select the item with the cursors of the remote controller and press ENTER to confirm your selection To return to the previous screen press quotSystem Setupquot Advanced settings to provide you with an even better experience quotMCACCquot Setup the speakers automatically or make desired changes to the equalizer quotNetworkBluetoothquot Make WiFi connection settings or settings related to BLUETOOTH When the unit is operating erratically Resetting this unit Restarting the unit may help it operate more smoothly To restart the unit turn it to standby and then press Í STANDBYON on the main unit for at least 5 seconds The units settings will be maintained If there is no improvement even after the unit is restarted try disconnecting and reconnecting the power cords of the unit and connected equipment When there is still no improvement resetting the unit to the status at the time of shipment may solve the problem If you reset the unit status your preferences will be reset to the defaults Note them down before the operation below How to reset the unit 1 While holding down AUTODIRECT on the main unit press Í STANDBYON on the main unit 2 quotClearquot appears on the display and the unit returns to standby Do not unplug the power cord until quotClearquot disappears from the display To reset the remote controller while holding down MODE press until the remote indicator flash twice about 3 seconds AV Adjust Tone Level MCACC Other Bass Treble BDDVD SN29402189VSX1131BASEnbook 25 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 26 - English - : gt Before start gt Hookup gt Setup gt Playback gtPart Names Front Panel 1 INPUT SELECTOR dial Switch the input to be played 2 MCACC indicator This lights when you have enabled the speaker calibration made with MCACC 3 FL OFF indicator This lights when you have pressed DIMMER repeatedly to turn the display off 4 DIMMER button Switches the brightness of the display 5 ZONE 2ONOFF button Switches the multizone function onoff 6 ZONE 2CONTROL button Controls the multizone function 7 HOME MENU button Displays the Home 8 Display P28 9 Cursor buttons TUNE PRESET button and ENTER button Select the item with the cursors and press ENTER to confirm your selection When using the TUNER select the frequency with TUNE or select preset stations with PRESET NETWORK indicator When the power of the unit is on this lights when quotNETquot is selected with the input selector and the unit is connected to the network If the unit is in standby mode this lights when functions such as HDMI CEC and network standby are enabled It does not light when ZONE 2 is on however WIRELESS indicator Lights when the unit is connected to the wireless network Remote control sensor RETURN button Returns the display to the previous state MASTER VOLUME Allows you to adjust the volume Í STANDBYON button Turns the unit on or into standby mode PHONES jack Stereo headphones with a standard plug 14 inch or ø63 mm are connected MCACC SETUP MIC jack The supplied speaker setup microphone is connected Listening mode button Select the listening mode SOUND RETRIEVER button Turns onoff the Sound Retriever function that provides better sound quality for compressed audio PURE DIRECT button Swithes to the Pure Direct mode USB port A USB storage device is connected so that music files stored in it can be played You can also supply power 5V1A to USB devices with a USB cable AUX INPUT AUDIO jack You can play the audio from an external player by connecting using a stereo mini plug cable AUX INPUT HDMI jack Connect to a video camera etc using a HDMI cable 12 106121314115798 18 2117 19 20 22 SN29402189VSX1131BASEnbook 26 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 27 - English - : gt Before start gt Hookup gt Setup gt Playback gtPart Names Rear Panel 1 DIGITAL IN OPTICALCOAXIAL jacks Input TV or AV component digital audio signals with a digital optical cable or digital coaxial cable 2 ANTENNA AM LOOPFM 75Ω terminal The supplied antennas are connected 3 VIDEO IN jacks Input the AV component video signals with an analog video cable 4 COMPONENT VIDEO IN jacks Input the AV component video signals with a component video cable 5 NETWORK port Connect to the network with an Ethernet cable 6 HDMI OUT jacks Transmit video signals and audio signals with a HDMI cable connected to a monitor such as a TV or projector 7 HDMI IN jacks Transmit video signals and audio signals with a HDMI cable connected to an AV component 8 Wireless antenna Used for WiFi connection or when using a BLUETOOTH enabled device Adjust their angles according to the connection status 9 Power cord North American European Australian and Asian models AC IN Taiwanese models The supplied power cord is connected SIGNAL GND terminal The ground wire of the turntable is connected AUDIO IN jacks Input AV component audio signal with an analog audio cable SPEAKERS terminals Connect speakers with speaker cables North American models are compatible with banana plugs ZONE 2 LINE OUT jack Output audio signals with an analog audio cable to a premain amplifier in a separate room ZONE 2 SUBWOOFER PRE OUT jack Connect a powered subwoofer with a subwoofer cable Up to two powered subwoofers can be connected The same signal is output from each of the SUBWOOFER PRE OUT jacks 1110 1312 23 5 764 180 90 Taiwanese models SN29402189VSX1131BASEnbook 27 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 28 - English - : gt Before start gt Hookup gt Setup gt Playback gtPart Names Remote Controller 1 Í button Turns the unit on or into standby mode 2 Input selector buttons Select the input to be played Use the buttons in 3 to select quotSTRM BOXquot quotAUXquot or quotPHONOquot 3 21 button Input source played switches each time you press one of these buttons 4 AV ADJUST button You can perform common settings on the TV screen 5 Cursor buttons and ENTER button Select the item with the cursors and press ENTER to confirm your selection 6 button Displays the Home 7 Volume buttons Allows you to adjust the volume This button also cancels the muting 8 button Temporarily mutes audio Press again to cancel muting 9 LISTENING MODE buttons Allows you to select the listening mode MAINZONE 2 buttons Controls the multizone function The ZONE 3 button is not used with this unit Play button Used for play operations when playing Music Server or USB button Used for repeat or random play operations when playing Music Server or USB CLEAR button Deletes all characters you have entered when entering text on the TV screen STATUS button Switches the information on the display button Returns the display to the previous state MODE button Switches tuning to a station between automatic tuning and manual tuning Fav button Registers a radio station 30 30 Approx5 m Display 1 This may light when performing operations with the quotNETquot quotUSBquot input selector 2 Lights in the following conditions Z2 When ZONE 2 is on When connected by BLUETOOTH When connected by WiFi NET When quotNETquot is selected with the input selector and the unit is connected to the network It will flash if the connection to the network is not correct USB When quotUSBquot is selected with the input selector and the unit is connected by USB and the USB device is selected Flashes if the USB is not properly connected HDMI When HDMI signals are input and the HDMI input is selected DIGITAL When digital signals are input and the digital input is selected 3 Lights according to the type of input digital audio signals and the listening mode 4 Lights in the following conditions RDS European Australian and Asian models Receiving RDS broadcasting TUNED Receiving AMFM radio STEREO Receiving FM stereo SLEEP When the sleep timer is set AUTO STBY Auto Standby is on 5 The currently selected speaker system lights 6 Lights when headphones are connected 7 Flashes when muting is on 8 Displays various information of the input signals 9 Lights when adjusting the volume SpeakerChannel display Displays the output channel that corresponds to the selected listening mode 2 3 65 7 SN29402189VSX1131BASEnbook 28 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 29 - English - : License and Trademark Information Manufactured under license from Dolby Laboratories Dolby Dolby Atmos Dolby Surround and the doubleD symbol are trademarks of Dolby Laboratories For DTS patents see httppatentsdtscom Manufactured under license from DTS Inc DTS the Symbol DTS in combination with the Symbol the DTSHD logo and DTSHD Master Audio are registered trademarks or trademarks of DTS Inc in the United States andor other countries DTS Inc All Rights Reserved The terms HDMI and HDMI HighDefinition Multimedia Interface and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries The WiFi CERTIFIED Logo is a certification mark of the WiFi Alliance AirPlay iPad iPhone and iPod touch are trademarks of Apple Inc registered in the US and other countries iPad Air and iPad mini are trademarks of Apple Inc Made for iPod Made for iPhone and Made for iPad mean that an electronic accessory has been designed to connect specifically to iPod iPhone or iPad respectively and has been certified by the developer to meet Apple performance standards Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards Please note that the use of this accessory with iPod iPhone or iPad may affect wireless performance AirPlay works with iPhone iPad and iPod touch with iOS 433 or later Mac with OS X Mountain Lion or later and PC with iTunes 1022 or later Apple Apple TV and Safari are trademarks of Apple Inc registered in the US and other countries The BLUETOOTH word mark and logos are registered trademarks owned by Bluetooth SIG Inc and any use of such marks by Onkyo Corporation is under license Other trademarks and trade names are those of their respective owners BLUETOOTH 文字標誌和圖形標誌為 Bluetooth SIG Inc 所有的註冊商標且 Onkyo Corporation 在授權下使用任何該等標記其他商標和商名為各自所有者 的商標和商名 Onkyo Corporation does not guarantee BLUETOOTH compatibility between the AV receiver and all BLUETOOTH enabled devices For compatibility between the AV receiver and another device with BLUETOOTH technology consult the devices documentation and dealer In some countries there may be restrictions on using BLUETOOTH devices Check with your local authorities Onkyo Corporation ne garantit pas la compatibilité BLUETOOTH entre lampli tuner AV et tous les appareils compatibles BLUETOOTH Pour assurer la compatibilité entre lamplituner AV et un autre périphérique à technologie BLUETOOTH consultez la documentation de lappareil et le vendeur Dans certains pays il peut exister des restrictions sur lutilisation dappareils BLUETOOTH Vérifiez auprès des autorités locales Onkyo Corporation no garantiza la compatibilidad BLUETOOTH entre el receptor de AV y todos los dispositivos con tecnología BLUETOOTH Para obtener información sobre la compatibilidad entre el receptor de AV y otro dispositivo con tecnología BLUETOOTH consulte al distribuidor y la documentación del dispositivo En algunos países es posible que el uso de dispositivos BLUETOOTH esté restringido Consulte con las autoridades locales Onkyo Corporation non garantisce la compatibilità BLUETOOTH tra il ricevitore AV e tutti i dispositivi abilitati al BLUETOOTH Per verificare la compatibilità tra il ricevitore AV e un altro dispositivo dotato di tecnologia BLUETOOTH consultare la documentazione del dispositivo in questione o contattare il rivenditore In alcuni Paesi potrebbero esistere delle limitazioni per lutilizzo di dispositivi BLUETOOTH Verificare le condizioni con le autorità locali Onkyo Corporation garantiert nicht die BLUETOOTH Kompatibilität zwischen dem AVReceiver und allen BLUETOOTH fähigen Geräten Zur Kompatibilität zwischen dem AVReceiver und einem anderen Gerät mit BLUETOOTH Technologie schauen Sie in die Dokumentation des Geräts und fragen Sie den Händler Es kann sein dass es in einigen Ländern Beschränkungen zur Nutzung der BLUETOOTH Geräte gibt Prüfen Sie das bei Ihren lokalen Behörden Onkyo Corporation garandeert niet de BLUETOOTH compatibiliteit tussen de AVreceiver en alle BLUETOOTH apparaten Raadpleeg voor compatibiliteit tussen de AVreceiver en een ander apparaat met BLUETOOTH technologie de documentatie van het apparaat of de verkoper In sommige landen geldt mogelijk een beperking op het gebruik van BLUETOOTH apparatuur Controleer de wetgeving in het land van gebruik Корпорация Onkyo не гарантирует совместимость по связи BLUETOOTH между AVресивером и всеми устройствами с функцией BLUETOOTH Сведения о совместимости между AVресивером и другим устройством с функцией BLUETOOTH можно получить в документации на устройство и у его продавца В некоторых странах могут действовать ограничения на использование устройств с функцией BLUETOOTH Для получения информации по этому вопросу обращайтесь к представителям местной власти Onkyo Corporation 不保證 AV 接收器與所有 BLUETOOTH 啟用裝置之間的 BLUETOOTH 兼容性 有關 AV 接收器與其他配備 BLUETOOTH 技術的裝置之間的兼容性請參閱裝 置的相關文檔並諮詢經銷商某些國家可能對使用 BLUETOOTH 裝置有所限 制請與您所在地相關機構進行確認 PANDORA the PANDORA logo and the Pandora trade dress are trademarks or registered trademarks of Pandora Media Inc Used with permission Google Cast and the Google Cast badge are trademarks of Google inc The product with this logo is conformed to HiRes Audio standard defined by Japan Audio Society This logo is used under license from Japan Audio Society This product is protected by certain intellectual property rights of Microsoft Use or distribution of such technology outside of this product is prohibited without a license from Microsoft Windows and the Windows logo are trademarks of the Microsoft group of companies QR Code is a registered trademark of DENSO WAVE INCORPORATED xvColor and xvColor logo are trademarks of Sony Corporation DSD and the Direct Stream Digital logo are trademarks of Sony Corporation MPEG Layer3 audio coding technology licensed from Fraunhofer IIS and Thomson All other trademarks are the property of their respective owners Toutes les autres marques commerciales sont la propriété de leurs détenteurs respectifs El resto de marcas comerciales son propiedad de sus respectivos propietarios Tutti gli altri marchi di fabbrica sono di proprietà dei rispettivi proprietari Alle anderen Warenzeichen sind das Eigentum ihrer jeweiligen Eigentümer Alle andere handelsmerken zijn eigendom van de desbetreffende rechthebbenden Все товарные знаки являются собственностью соответствующих владельцев 所有其他商標為各自所有者所有 ΕϭλϟΕέΎηϝ ΑϘΗγ ϣϥϳΑ87227ΙϭΗϭϠΑϟϲϓϖϓϭΗΩϭΟϭ2QNRϥϣοΗϻ 87227ΙϭΗϭϠΑϟΎΑΓΩϭίϣϟΓίϬΟϷϊϳϣΟϭΓέϭλϟϭ ΙϭΗϭϠΑϟΎΑΩϭίϣέΧίΎϬΟϱϭΓέϭλϟϭΕϭλϟΕέΎηϝ ΑϘΗγ ϣϥϳΑϖϓϭΗϟϯΩϣϰϠϋϑέόΗϠϟ ϥϭϛΗΩϗˬϝϭΩϟνόΑϲϓϝϳϛϭϟϝγϭίΎϬΟϠϟΔϘϓέϣϟϖΎΛϭϟΔόΟέϣΑϡϗˬ87227 ΔϳϠΣϣϟΕΎρϠγϟϊΟέ87227ΙϭΗϭϠΑϟΎΑΓΩϭίϣϟΓίϬΟϷϡΩΧΗγϰϠϋΕΩϳϳϘΗϙΎϧϫ ϥϳϳϧόϣϟΎϬΑΎΣλϷΔϛϭϠϣϣϯέΧϷΔϳέΎΟΗϟΕΎϣϼόϟϊϳϣΟ SN29402189VSX1131BASEnbook 29 ページ ２０１６年１月１８日　月曜日　午後６時２１分
• Page 30 - English - : DISCLAIMER Through this device you are able to link to other services or websites which are not under the control of any company which has designed manufactured or distributedhave distributed this device and its affiliates collectively Company We have no control over the nature content and availability of those services The inclusion of any links does not necessarily imply a recommendation or endorse the views expressed within them All information content and services available through this device belong to third parties and are protected by copyright patent trademark andor other intellectual property laws of applicable countries The information content and services provided through this device are for your personal noncommercial use only Any information content or services may not be used in any manner other than previously approved by the appropriate content owner or service provider You may not modify copy republish translate exploit create derivative works upload post transmit sell or distribute in any manner any information content or services available through this device unless expressly permitted by the appropriate copyright patent trademark andor other intellectual property owner including without limitation content owner or service provider THE CONTENT AND SERVICES AVAILABLE THROUGH THIS DEVICE ARE PROVIDED AS IS COMPANY DOES NOT WARRANT INFORMATION CONTENT OR SERVICES SO PROVIDED EITHER EXPRESSLY OR IMPLIEDLY FOR ANY PURPOSE COMPANY EXPRESSLY DISCLAIMS ANY WARRANTIES EXPRESS OR IMPLIED INCLUDING BUT NOT LIMITED TO WARRANTIES OF TITLE NONINFRINGEMENT MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE Company makes no representation or warranty of any kind express or implied about the completeness accuracy validity legality reliability suitability or availability with respect to the information content or services available through this device Company shall not be liable whether in contract or tort including negligence and strict liability for any direct indirect special incidental or consequential damages or any other damages arising out of or in connection with any information contained in or as a result of the use of any content or service by you or any third party even if Company has been advised of the possibility of such damages nor shall Company be liable for any third party claims against users of this device or any third party In no event shall Company be responsible nor liable for without limiting the generality of the foregoing any interruption or suspension of any information content or service available through this device Company is neither responsible nor liable for customer service related to the information content and services available through this device Any question or request for service relating to the information content or services should be made directly to the appropriate content owners and services providers SN29402189VSX1131BASEnbook 30 ページ ２０１６年１月１８日　月曜日　午後６時２１分
