36" Gas Cooktop
WCG55US6H
General Features & Properties
AccuSimmer
®
Burner
Fifth Burner
Sealed Burners
Full-Width Grates
Dishwasher-Safe Knobs
Wall Oven Compatible
Electrical Details
Amps 15
Volts 120
Certications
ADA Compliant Yes
Stainless Steel
WCG55US6HS
Also available in:
White
WCG55US6HW
Black
WCG55US6HB
Black Stainless
Steel
WCG55US6HV
Key Features & Benets
EZ-2-Lift
™
Hinged Cast-Iron Grates
Get quick access to spills on the cooktop
with our industry-rst EZ-2-Lift
™
hinged
cast-iron grates. The hinged design lets you
wipe up underneath without removing them.
For a more thorough clean, the grates are
also dishwasher-safe.
Upswept SpillGuard
™
Cooktop
Clean up faster with a cooktop that has
raised edges to help contain spills.
SpeedHeat
™
Burner
Get dinner to the table fast with this burner
that generates the high heat needed to sear
and boil quickly.
NOTE: Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specications subject to
change without notice.
®/™ © 2020. All rights reserved. Printed in the U.S.A. D200104XXE. WCG55US6HSpecSheetV01.
Technical Details
Fuel Type Gas
Number of Burners/
Elements
5
Burner/Element Power
(1) 15000 BTU
(2) 9100 BTU
(1) 12,000 BTU
(1) 5000 BTU
Burner/Element Type/Size
SpeedHeat
™
,
Burner, Sealed
Burner, Simmer
Dimensions
Product Dimensions
(H x W x D)
4-1/8" x
36" x
21"
Cutout Dimensions
(W x D)
33-7/8" x
19"
Reference Material
Install Guide
Use & Care Guide
Warranty
