Product Bulletin for
Wi-Fi Technology Switches and Dimmers
Decora Smart
™
with Wi-Fi Technology
Wi-Fi Product Family
The Decora Smart with Wi-Fi Technology
family features in-wall dimmers, a switch,
and plug-in modules for appliances and
lamps. Control using the free My Leviton
app for iOS and Android, no hub required.
Simplify control of the residence –
schedule lights and connected loads to
turn on/o at specific times or based
on sunrise/sunset, easily group smart
devices into rooms, and create scenes
to activate multiple lights at once.
Integrate with IFTTT and Nest, utilize
auto-shuto feature as a countdown
timer in closets, hallways and bathrooms;
plus engage home vs. away to enact
randomization of lighting control,
providing a lived-in appearance.
APP CONTROL:
Remote Access from Anywhere, No Hub
Required! Use the free “My Leviton” app
devices to easily add new devices to
your home. Create schedules like “Good
Morning” to activate appropriate lighting
at preset times. For instance, at 6:30AM
every Monday through Friday, turn the
bedroom lights to 25% and master bath
lights to 50%. As well, Activities can be
created so that you can manually set the
lighting for “Movie Time” from the app as
you begin your movie.
WORKS WITH NEST
®
:
Add lighting control to your Nest eco-
system. Turn Leviton lights on if a Nest
Cam™ detects motion in an area. Adjust
Leviton lights based on when Nest says
you are home or away. Set illumination
time durations and even “blink” all lights
during an emergency situation.
AMAZON ALEXA VOICE CONTROL:
Compatible with all products that
support Amazon Alexa providing voice
control of the load: “Alexa, dim living
room lights to 25%”.
GOOGLE ASSISTANT VOICE CONTROL:
”Ok Google, turn [My Leviton device
name] On”. Works with the Google
Assistant. Google Home is a voice
enabled speaker powered by the Google
Assistant. Easily control smart devices
around the home.
LOW-WATTAGE LED LOADS:
Engineered to function with extremely
sensitive, low-wattage light sources,
such as a single LED bulb in a hallway
or a strand of holiday lights, ensuring
LEDs do not glow when o.
AESTHETICS:
In-wall dimmers and switches boast the new Leviton design
with true rocker action, pressing the top to turn on and the
bottom to turn o. For the 600W and 1000W dimmers, the
dim/brighten bar is conveniently located along the right side
of the paddle, ensuring ease of use. Vanishing LEDs to the
left of the dimmer paddle show current and target light level
with real-time feedback. To meet any decor, color change
kits are available in white, ivory, light almond, gray, black, and
brown. For the most professional installation, pair the device
with an optional Leviton screwless wallplate.
Features and Benefits
No hub required
Voice control using Amazon Alexa or Google Assistant
Works with Nest
Integrate with IFTTT to expand control
Scheduling, remote access, and control via the My Leviton
app for iOS and Android
Control up to 99 devices, 50 schedules, 50 activities,
50 rooms, 50 scenes, and 20 residences within the My
Leviton app
Six color change kits available
Remotes available for 3-way/multi-location control
Limited 5-year warranty
SINGLE POLE WIRING DIAGRAM THREE-WAY WIRING DIAGRAM
DW1KD 1000W Dimmer with Wi-Fi Technology
Agency Standing and Compliance
Complies with UL 1472
CSA Certified (File #003413)
NOM-ANCE Certified
Wi-Fi CERTIFIED™
Complies with FCC Part 15, Class B
SINGLE POLE WIRING DIAGRAM THREE-WAY WIRING DIAGRAM
DW6HD 600W Dimmer with Wi-Fi Technology
Agency Standing and Compliance
Complies with UL 1472
CSA Certified (File #003413)
NOM-ANCE Certified
Wi-Fi CERTIFIED™
Complies with FCC Part 15, Class B
SINGLE POLE WIRING DIAGRAM THREE-WAY WIRING DIAGRAM
DW15S Switch with Wi-Fi Technology
Agency Standing and Compliance
Complies with UL 917
CSA Certified (File #003413)
NOM-ANCE Certified
Wi-Fi CERTIFIED™
Complies with FCC Part 15, Class B
Dimensional Drawings
SAO-10029
REV MAY 2018
Leviton Manufacturing Co., Inc.
Global Headquarters
201 North Service Road, Melville, NY 11747-3138
Tel: 1-800-323-8920 Fax: 1-800-832-9538
Tech Line: (8:30AM-7:00PM ET Monday-Friday): 1-800-824-3005
Leviton Manufacturing Co., Inc.
Energy Management, Controls and Automation
865 Fulton St., Suite 500, New Orleans, Louisiana, 70130
Tel: 1-504-608-9001.
Visit our website at: leviton.com/decorasmart
©2018 Leviton Manufacturing Co., Inc. All rights reserved.
Ordering Information
Description Cat. No.
1000W Dimmer with Wi-Fi Technology DW1KD-1BZ
600W Dimmer with Wi-Fi Technology DW6HD-1BZ
15A Switch with Wi-Fi Technology DW15S-1BZ
Plug-in Outlet with Wi-Fi Technology DW15A-1BW
Plug-in Dimmer with Wi-Fi Technology DW3 HL-1BW
Matching Dimmer Remote DD00R-DLZ
Coordinating Switch Remote DD0SR-1
Matching Switch Remote DD0SR-DLZ
DW15A Plug-in Outlet with Wi-Fi Technology
DW3HL Plug-in Outlet with Wi-Fi Technology
1.95 (44.5)
0.66 (16.8)
1.15 (29.2)
2.97 (75.3)
0.47 (12.0)
2.39 (60.6)
0.69 (17.5)
0.43 (10.8)
2.97 (75.3)
0.84(21.3)
1.56 (39.5)
1.95 (44.5)
0.66 (16.8)
1.15 (29.2)
2.97 (75.3)
0.47 (12.0)
2.39 (60.6)
0.69 (17.5)
0.43 (10.8)
2.97 (75.3)
0.84(21.3)
1.56 (39.5)
Agency Standing and Compliance
Complies with UL 917
CSA Certified (File #003413)
NOM-ANCE Certified
Wi-Fi CERTIFIED™
Complies with FCC Part 15, Class B
Agency Standing and Compliance
Complies with UL 1472
CSA Certified (File #003413)
NOM-ANCE Certified
Wi-Fi CERTIFIED™
Complies with FCC Part 15, Class B
