Safety information
• Before using your new Samsung Refrigerator, please read
this manual thoroughly to ensure that you know how to
operate the features and functions that your new appliance
offers safely and efciently.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory, or
mental capabilities, or those who lack experience and
knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person
responsible for their safety.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Warnings and Important Safety Instructions in this manual
do not cover all possible conditions and situations that
may occur.
It is your responsibility to use common sense, caution,
and care when installing, maintaining, and operating your
appliance.
• Because these following operating instructions cover
various models, the characteristics of your refrigerator
may differ slightly from those described in this manual and
not all warning signs may be applicable. If you have any
questions or concerns, contact your nearest service center
or nd help and information online at www.samsung.com.
Safety information
Untitled-13 3 2017-06-26 3:32:00
Safety information
English4
Safety information
• R-600a or R-134a is used as a refrigerant. Check the
compressor label on the rear of the appliance or the rating
label inside the fridge to see which refrigerant is used for
your refrigerator. When this product contains ammable
gas (Refrigerant R-600a), contact your local authority in
regard to safe disposal of this product.
• In order to avoid the creation of a ammable gas-air
mixture if a leak in the refrigerating circuit occurs, the size
of the room in which the appliance may be sited depends
on the amount of refrigerant used.
• Never start up an appliance showing any signs of damage.
If in doubt, consult your dealer. The room must be 1 m³
in size for every 8 g of R-600a refrigerant inside the
appliance.
The amount of refrigerant in your particular appliance is
shown on the identication plate inside the appliance.
• Refrigerant squirting out of the pipes could ignite or cause
an eye injury. When refrigerant leaks from the pipe, avoid
any naked ames and move anything ammable away
from the product and ventilate the room immediately.
- Failing to do so may result in re or explosion.
• It is hazardous for anyone other than an Authorised
Service Person to service this appliance. In Queensland
– the authorized Service Person MUST hold a Gas Work
Authorisation or Licence for hydrocarbon refrigerants, to
carry out Servicing or repairs which involve the removal of
covers. (For Australia only)
Untitled-13 4 2017-06-26 3:32:00
English 5
Safety information
Important safety symbols and precautions:
WARNING
Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal
injury or property damage.
These warning signs are here to prevent injury to you and
others.
Please follow them carefully.
After reading this section, keep it in a safe place for future
reference.
Severe warning signs for transportation and site
WARNING
• When transporting and installing the appliance,care should
be taken to ensure that no parts of the refrigerating circuit
are damaged.
- Refrigerant leaking from the pipe work could ignite
or cause an eye injury. If a leak is detected, avoid any
naked ames or potential sources of ignition and air
the room in which the appliance is standing for several
minutes.
Untitled-13 5 2017-06-26 3:32:00
Safety information
English6
Safety information
- This appliance contains a small amount of isobutane
refrigerant (R-600a), a natural gas with high
environmental compatibility that is, however, also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no parts
of the refrigerating circuit are damaged.
Critical installation warnings
WARNING
• Do not install the refrigerator in a damp location or place
where it may come in contact with water.
- Deteriorated insulation on electrical parts may cause an
electric shock or re.
• Do not place this refrigerator in direct sunlight or expose it
to the heat from stoves, room heaters, or other appliances.
• Do not plug several appliances into the same multiple
power strip. The refrigerator should always be plugged
into its own individual electrical outlet which has a voltage
rating that matches the voltage listed on the refrigerator’s
rating plate.
- This provides the best performance and also prevents
overloading of house wiring circuits, which could cause
a re hazard from overheated wires.
• If the wall socket is loose, do not insert the power plug.
- There is a risk of electric shock of re.
• Do not use a power cord that has cracks or abrasion
damage along its length or at either end.
Untitled-13 6 2017-06-26 3:32:00
English 7
Safety information
• Do not bend the power cord excessively or place heavy
objects on it.
• Do not pull or excessively bend the power cord.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal object, place a
heavy object on the power cord, insert the power cord
between objects, or push the power cord into the space
behind the appliance.
• When moving the refrigerator, be careful not to roll over or
damage the power cord.
- This may result in an electric shock or re.
• Never unplug your refrigerator by pulling on the power
cord. Always grip the plug rmly and pull straight out from
the outlet.
- Damage to the cord may cause a short-circuit, re, and/
or electric shock.
• Do not store explosive substances such as aerosol cans
with a ammable propellant in this appliance.
• Do not install this appliance near a heater or inammable
material.
• Do not install this appliance in a location where gas may
leak.
- This may result in an electric shock or re.
• This refrigerator must be properly located and installed in
accordance with the instructions in this manual before you
use it.
• Connect the power plug in the proper position with the
cord hanging down.
- If you connect the power plug upside down, the wire
can get cut off and cause a re or electric shock.
Untitled-13 7 2017-06-26 3:32:00
Safety information
English8
Safety information
• Make sure that the power plug is not crushed or damaged
by the back of the refrigerator.
• Keep the packing materials out of reach of children.
- There is a risk of death from suffocation if a child puts
the packing materials on his or her head.
• The appliance must be positioned so that the plug is
accessible after installation.
- Failing to do so may result in an electric shock or re
due to electric leakage.
• Do not install this appliance in a humid, oily or dusty
location, in a location exposed to direct sunlight and water
(rain drops).
- Deteriorated insulation of electrical parts may cause an
electric shock or re.
• If any dust or water is in the refrigerator, pull out power
plug and contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
• Do not stand on top of the appliance or place objects (such
as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance.
- This may result in an electric shock, re, problems with
the product, or injury.
• You need to remove all the protective plastic lm before
you initially plug the product in.
• Children should be supervised to ensure that they do not
play with the snap rings used for door adjustment or the
water tube clips.
- There is risk of death by suffocation if a child swallows
a snap ring or water tube clip. Keep the snap rings and
water tube clips out of children’s reach.
Untitled-13 8 2017-06-26 3:32:00
English 9
Safety information
• The refrigerator must be safely grounded.
- Always make sure that you have grounded the
refrigerator before attempting to investigate or repair
any part of the appliance. Power leakages can cause
severe electric shock.
• Never use gas pipes, telephone lines, or other potential
lightning attractors as an electrical ground.
- You must ground the refrigerator to prevent any power
leakages or electric shocks caused by current leakage
from the refrigerator.
- This may result in an electric shock, re, explosion, or
problems with the product.
• Plug the power plug into the wall socket rmly. Do not use
a damaged power plug, damaged power cord, or loose wall
socket.
- This may result in an electric shock or re.
• If the power cord is damaged, have it replaced
immediately by the manufacturer or one of its service
agents.
• The fuse on the refrigerator must be changed by a
qualied technician or service company.
- Failing to do so may result in an electric shock or
personal injury.
Untitled-13 9 2017-06-26 3:32:00
Safety information
English10
Safety information
Installation cautions
CAUTION
• Allow sufcient space around the refrigerator and install it
on a at surface.
- Keep the ventilation space in the appliance enclosure or
mounting structure clear of obstructions.
• Allow the appliance to stand for 2 hours before loading
foods after installation and turning on.
• We strongly recommend you have a qualied technician or
service company install the refrigerator.
- Failing to do so may result in an electric shock, re,
explosion, problems with the product, or injury.
• Overload on any one door may fell the refrigerator,
causing physical injury.
Critical usage warnings
WARNING
• Do not insert the power plug into a wall socket with wet
hands.
- This may result in an electric shock.
• Do not store articles on the top of the appliance.
- When you open or close the door, the articles may fall
and cause personal injury and/or material damage.
• Do not insert hands, feet or metal objects (such as
chopsticks, etc.) into the bottom or the back of the
refrigerator.
- This may result in an electric shock or injury.
Untitled-13 10 2017-06-26 3:32:00
English 11
Safety information
- Any sharp edges may cause a personal injury.
• Do not touch the inside walls of the freezer or products
stored in the freezer with wet hands.
- This may cause frostbite.
• Do not put a container lled with water on the refrigerator.
- If spilled, there is a risk of re or electric shock.
• Do not keep volatile or ammable objects or substances
(benzene, thinner, propane gas, alcohol, ether, LP gas, and
other such products) in the refrigerator.
- This refrigerator is for storing food only.
- This may result in re or explosion.
• Children should be supervised to ensure that they do not
play with the appliance.
- Keep ngers out of “pinch point” areas. Clearances
between the doors and cabinet are necessarily small. Be
careful when you open the doors if children are in the
area.
• Do not let children hang on the door or door bins. A
serious injury may occur.
• Do not let children go inside the refrigerator. They could
become trapped.
• Do not insert your hands into the bottom area under the
appliance.
- Any sharp edges may cause personal injury.
• Do not store pharmaceutical products, scientic materials,
or temperature sensitive products in the refrigerator.
- Products that require strict temperature controls must
not be stored in the refrigerator.
Untitled-13 11 2017-06-26 3:32:00
Safety information
English12
Safety information
• Do not place or use electrical appliance inside
the refrigerator/freezer, unless they are of a type
recommended by the manufacturer.
• If you smell pharmaceutical or smoke, pull out power plug
immediately and contact your Samsung Electronics service
center.
• If any dust or water is in Refrigerator, pull out power plug
and contact your Samsung Electronics service center.
- Otherwise there is a risk of re.
• Do not let children step on a drawer.
- The drawer may break and cause them to slip.
• Do not leave the doors of the refrigerator open while the
refrigerator is unattended and do not let children enter
inside the refrigerator.
• Do not allow babies or children go inside the drawer.
- It can cause death from suffocation by entrapment or
personal injury.
• Do not overll the refrigerator with food.
- When you open the door, an item may fall out and
cause personal injury or material damage.
• Do not spray volatile material such as insecticide onto the
surface of the appliance.
- As well as being harmful to humans, it may also result
in an electric shock, re, or problems with the product.
• Do not use or place any substances sensitive to
temperature such as ammable sprays, ammable objects,
dry ice, medicine, or chemicals near or inside of the
refrigerator.
Untitled-13 12 2017-06-26 3:32:00
English 13
Safety information
• Do not use a hair dryer to dry the inside of the
refrigerator. Do not place a lighted candle in the
refrigerator for removing bad odours.
- This may result in an electric shock or re.
• Fill the water tank, ice tray and water cubes only with
potable water (mineral water or puried water).
- Do not ll the tank with tea, juice or sports drink, this
may damage the refrigerator.
• Do not stand on top of the appliance or place objects (such
as laundry, lighted candles, lighted cigarettes, dishes,
chemicals, metal objects, etc.) on the appliance. This may
result in an electric shock, re, problems with the product,
or injury. Do not put a container lled with water on the
appliance.
- If spilled, there is a risk of re or electric shock.
• Do not use mechanical devices or any other means
to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Never stare directly at the UV LED lamp for long periods of
time.
- This may result in eye strain due to the ultraviolet rays.
• Do not put fridge shelf in upside down. Shelf stopper could
not work.
- It may cause a personal injury because of glass shelf
drop.
• Keep ngers out of “pinch point” areas. Clearances
between the doors and cabinet are necessarily small. Be
careful when you open the doors if children are in the area.
Untitled-13 13 2017-06-26 3:32:01
Safety information
English14
Safety information
• If a gas leak is detected, avoid any naked ames or
potential sources of ignition, and air the room in which the
appliance is standing for several minutes.
- Do not touch the appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in explosion or re.
• Use only the LED Lamps provided by the manufacturer or
its service agents.
• Bottles should be stored tightly together so that they do
not fall out.
• This product is intended only for the storage of food in a
domestic environment.
• Do not attempt to repair, disassemble, or modify the
refrigerator yourself.
- Unauthorized modications can cause safety problems.
To reverse an unauthorized modication, we will charge
the full cost of parts and labor.
• Do not use any fuse (such as cooper, steel wire, etc.) other
than a standard fuse.
• If your refrigerator needs to be repaired or reinstalled,
contact your nearest service center.
- Failing to do so may result in an electric shock, re,
problems with the product, or injury.
• If the interior or exterior LED lamp has gone out, contact
your nearest service center.
• If the refrigerator emits a burning smell or smoke, unplug
the refrigerator immediately and contact your Samsung
Electronics service center.
- Failing to do so may result in an electric or re hazards.
Untitled-13 14 2017-06-26 3:32:01
English 15
Safety information
• Pull the power plug out of the socket before changing the
interior lamps of the refrigerator.
- Otherwise, there is a risk of electric shock.
• If you experience difculty changing a non-LED light,
contact a Samsung service center.
• If the product is equipped with LED lamps, do not
disassemble the Lamp Covers and LED lamps yourself.
- Contact a Samsung service center.
• Plug the power plug into the wall socket rmly.
• Do not use a damaged power plug, damaged power cord or
loose wall socket.
- This may result in an electric shock or re.
Usage cautions
CAUTION
• Do not re-freeze frozen foods that have thawed
completely. Do not place carbonated or zzy drinks in
the freezer compartment. Do not put bottles or glass
containers in the freezer.
- When the contents freeze, the glass may break and
cause personal injury.
• Use only the ice maker provided with the refrigerator.
• To get the best performance from the product:
- Do not place food too close to the vents at the rear of
the refrigerator as this can obstruct free air circulation
in the refrigerator compartment.
- Wrap food up properly or place it in airtight containers
before putting it into the refrigerator.
Untitled-13 15 2017-06-26 3:32:01
Safety information
English16
Safety information
- Do not place glass bottles or carbonated beverages
into the freezer. They can freeze and break. Broken
beverage containers can cause injury.
- Please observe maximum storage times and expiration
dates of frozen goods.
• Do not place glass or bottles or carbonated beverages into
the freezer.
- The container may freeze and break, and this may
result in injury.
• Do not place carbonated or zzy drinks in the freezer
compartment. Do not put bottles or glass containers in the
freezer.
- When the contents freeze, the glass may break and
cause personal injury and property damage.
• Service Warranty and Modication.
- Any changes or modications performed by a 3rd
party on this nished appliance are not covered
under Samsung warranty service, nor is Samsung
responsible for safety issues that result from 3rd party
modications.
• Do not block the air vents inside the refrigerator.
- If the air vents are blocked, especially with a plastic
bag, the refrigerator can be over cooled. If a cooling
period lasts too long, the water lter may break and
cause water leakage.
• Use only the ice-maker provided with the refrigerator.
• Wipe excess moisture from the inside and leave the doors
open.
- Otherwise, odor and mold may develop.
Untitled-13 16 2017-06-26 3:32:01
English 17
Safety information
• If the refrigerator is disconnected from the power supply,
you should wait for at least ve minutes before plugging it
back in.
• When the refrigerator got wet by water, pull out the power
plug and contact your Samsung Electronics service center.
• Do not strike or apply excessive force to any glass surface.
- Broken glass may result in a personal injury and/or
property damage.
• Fill the water tank and ice cube trays with potable water
only (tap water, mineral water, or puried water).
- Do not ll the tank with tea or a sports drink. This may
damage the refrigerator.
• Be careful that your
ngers are not caught in.
• The lamps in the freezer and refrigerator can be turned off
if the doors of the freezer and refrigerator are left open
for 2 seconds or longer.
- The lamps will turn back on when the doors are closed
and opened again.
• If the refrigerator is ooded, make sure to contact your
nearest service center.
- There is a risk of electric shock or re.
Untitled-13 17 2017-06-26 3:32:01
Safety information
English18
Safety information
• Do not keep vegetable oil in your refrigerator’s door bins.
The oil can solidify, making it foul-tasting and difcult to
use. In addition, the open container can leak and the leaked
oil can cause the door bin to crack. After opening an oil
container, it is best to keep the container in a cool and
shaded place such as a cupboard or pantry.
- Examples of vegetable oil: olive oil, corn oil, grape-seed
oil, etc.
Cleaning cautions
CAUTION
• Do not spray water directly on the inside or outside the
refrigerator.
- There is a risk of re or electric shock.
• Do not use a hair dryer to dry the inside of the
refrigerator.
• Do not place a lighted candle in the refrigerator to remove
bad odors.
- This may result in an electric shock or re.
• Do not spray cleaning products directly on the display.
- Printed letters on the display may come off.
• If any foreign substance such as water has entered the
appliance, unplug the power plug and contact your nearest
service center.
- Failing to do so may result in an electric shock or re.
Untitled-13 18 2017-06-26 3:32:01
English 19
Safety information
• Use a clean, dry cloth to remove any foreign matter or dust
from the power plug blades. Do not use a wet or damp
cloth when cleaning the plug.
- Otherwise, there is a risk of re or electric shock.
• Do not clean the appliance by spraying water directly onto
it.
• Do not use benzene, thinner, or Clorox, Chloride for
cleaning.
- They may damage the surface of the appliance and may
cause a re.
• Never put ngers or other objects into the dispenser hole.
- It may cause a personal injury or material damage.
• Before cleaning or performing maintenance, unplug the
appliance from the wall socket.
- Failing to do so may result in an electric shock or re.
• Use a clean sponge or soft cloth and a mild detergent in
warm water to clean the refrigerator.
• Do not use abrasive or harsh cleansers such as window
sprays, scouring cleansers, ammable uids, muriatic
acid, cleaning waxes, concentrated detergents, bleaches,
or cleansers containing petroleum products on exterior
surfaces (doors and cabinet), plastic parts, door and interior
liners, and gaskets.
- These can scratch or damage the material.
• Do not clean glass shelves or covers with warm water
when they are cold. Glass shelves and covers may break if
exposed to sudden temperature changes or impacts such
as bumping or dropping.
Untitled-13 19 2017-06-26 3:32:01
Safety information
English20
Safety information
Critical disposal warnings
WARNING
• Please dispose of the packaging material from this product
in an environmentally friendly manner.
• Ensure that none of the pipes on the back of the
refrigerator are damaged prior to disposal.
• R-600a or R-134a is used as a refrigerant. Check the
compressor label on the rear of the appliance or the rating
label inside the fridge to see which refrigerant is used for
your refrigerator. If this refrigerator contains ammable
gas (Refrigerant R-600a), contact your local authority in
regard to safe disposal of this product.
• When disposing of this refrigerator, remove the door/
door seals and door latch so that small children or
animals cannot become trapped inside. Children should
be supervised to ensure that they do not play with the
appliance. If trapped inside, a child may get hurt or
suffocate to death.
- If trapped inside, the child may become injury and
suffocate to death.
• Cyclopentane is used in the insulation. The gases in the
insulation material require a special disposal procedure.
Please contact your local authorities in regard to the
environmentally safe disposal of this product.
• Keep all packaging materials well out of the reach of
children, as packaging materials can be dangerous to
children.
- If a child places a bag over his or her head, the child
could suffocate.
Untitled-13 20 2017-06-26 3:32:01
English 21
Safety information
Additional tips for proper usage
• In the event of a power failure, call the local ofce of your
electric company and ask how long the failure is going to
last.
- Most power failures that are corrected in an hour or two
will not affect your refrigerator temperatures. However,
you should minimize the number of door openings
while the power is off.
- Should the power failure last more than 24 hours,
remove and discard all frozen food.
• The refrigerator might not operate consistently (frozen
contents can thaw or temperatures can become too
warm in the frozen food compartment) if sited for an
extended period of time in a location where ambient air
temperatures are constantly below the temperatures for
which the appliance is designed.
• In case of particular foods, keeping it under refrigeration
can have a bad effect on preservation due to its properties.
• Your appliance is frost free, which means there is no need
to manually defrost your appliance. This will be carried out
automatically.
• Temperature rise during defrosting complies with ISO
requirements. If you want to prevent an undue rise in the
temperature of frozen food while the appliance defrosts,
wrap the frozen food in several layers of newspaper.
• Do not re-freeze frozen foods that have thawed
completely.
Untitled-13 21 2017-06-26 3:32:01
Safety information
English22
Safety information
Saving Energy Tips
• Install the appliance in a cool, dry room with adequate
ventilation. Ensure that it is not exposed to direct sunlight
and never put it near a direct source of heat (a radiator, for
example).
• Not to block any vents and grilles is recommended for
energy efciency.
• Allow warm food to cool down before placing it in the
appliance.
• Put frozen food in the refrigerator to thaw. You can then
use the low temperatures of the frozen products to cool
food in the refrigerator.
• Do not keep the door of the refrigerator open for too long
when putting food in or taking food out. The shorter the
time the door is open, the less frost build-up you’ll have in
the freezer.
• It is recommended to install the refrigerator with clearance
to the back and sides. This will help reduce power
consumption and keep your energy bills lower.
• For the most efcient use of energy, please keep the all
inner ttings such as baskets, drawers, shelves on the
position supplied by manufacturer.
Untitled-13 22 2017-06-26 3:32:01
English 23
Safety information
This appliance is intended to be used in household
and similar applications such as
• staff kitchen areas in shops, ofces and other working
environments;
• farm houses and by clients in hotels, motels and other
residential type environments;
• bed and breakfast type environments;
• catering and similar non-retail applications.
Instructions about the WEEE
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the
product and its electronic accessories (e.g. charger, headset, USB cable)
should not be disposed of with other household waste at the end of their
working life. To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate these items
from other types of waste and recycle them responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased
this product, or their local government ofce, for details of where and
how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
Untitled-13 23 2017-06-26 3:32:01
English24
Installation
Follow these instructions carefully to ensure a proper installation of this refrigerator and to
prevent accidents before using it.
WARNING
• Use the refrigerator only for its intended purpose as described in this manual.
• Any servicing must be performed by a qualied technician.
• Dispose of the product packaging material in compliance with the local regulations.
Refrigerator at a glance
NOTE
The actual image and provided component parts of the refrigerator may differ, depending
on the model and the country.
09
10
11
12
01
02
03
05
04
06
07
08
01 Shelf Fre *
02 Ice Maker *
03 Fresh Room *
04 Guard-Egg
05 Slide Shelf
06 Deodorizer *
07 Movable VEG Box *
08 Vegetable Drawer *
09 Freezer Guard
10 Water Tank *
11 Multi Storage Basket *
12 Guard-Bottle
* applicable models only
Installation
Untitled-13 24 2017-06-26 3:32:01
English 25
Installation
Optional accessories *
Spacer: This helps keep the refrigerator cool.
Cool pack: This helps keep the refrigerator cool.
Ice tray: Used to make ice.
Twist Ice Maker: Used to make ice.
* Your refrigerator may not include optional accessories listed above. Provision of optional
accessories depends on the model and the country.
To secure more room for storage in the freezer compartment
Remove one or more optional accessories such as cool pack(s), shelf or shelves, twist
ice maker(s), ice storage bins and their supports, all of which can be removed manually
without a tool.
• These optional accessories do not affect thermal and mechanical performance.
• A declared storage volume of the freezer is based on the nonexistence of those optional
accessories.
• To remove both ice makers, remove the right-handed one rst (applicable to Ice Max
models).
• For best energy efciency, make sure all of shelves, drawers, and baskets are placed in
their original position.
Untitled-13 25 2017-06-26 3:32:02
Installation
English26
Installation
Load limit indicator (applicable models only)
The refrigerator has a load limit indicator
on the top right side of the freezer
compartment.
CAUTION
• Do not put or keep food items over the
load limit indicator. Otherwise, energy
efciency may be affected.
Untitled-13 26 2017-06-26 3:32:02
English 27
Installation
Step-by-step installation
STEP 1 Select a site
Site requirements:
• Solid, level surface without carpeting or ooring that may obstruct ventilation
• Away from direct sunlight
• Adequate room for opening and closing the door
• Away from a heat source
• Room for maintenance and servicing
• Temperature range: between 10 °C and 43 °C
Clearance
See the pictures and table below for space requirements for installation.
01
02
Model A B C
RT38 1275 1001 115°
RT38 (Glass
Door Only)
1290 1001 115°
RT35 1275 1001 115°
RT35 (Glass
Door Only)
1290 1001 115°
RT32 1221 1040 135°
RT29 1221 1040 135°
(unit: mm)
01 100 mm
02 50 mm
03 at least 50 mm
B
C
A
03 03
Untitled-13 27 2017-06-26 3:32:02
Installation
English28
Installation
STEP 2 Spacing (applicable models only)
1. Open the door and locate the provided
spacers (x2).
2. Unpack both spacers and attach them
to the rear of the refrigerator as shown.
They help ventilate air to the rear wall
and save power consumption.
STEP 3 Flooring
• The surface to install the refrigerator
must support a fully loaded refrigerator,
or approximately 90 kg.
• To protect the oor, put a large piece
of cardboard on each leg of the
refrigerator.
• Once the refrigerator is in its nal
position, do not move it unless
necessary to protect the oor. If you
have to, use a thick paper or cloth such
as old carpets along the movement path.
STEP 4 Adjust the levelling feet
Level the refrigerator by manually
adjusting the levelling feet. Turn the
levelling feet clockwise to lower the
position, or turn counter clockwise to raise.
For safety reasons, adjust the front side a
little higher than the rear side.
Untitled-13 28 2017-06-26 3:32:03
English 29
Installation
CAUTION
Before moving the refrigerator, make sure
to turn the levelling feet counter clockwise
so that the bottom of the refrigerator at
least 66 mm from the oor.
STEP 5 Attach the door support (glass door models only)
A
To prevent the refrigerator from falling or
shaking while it is operating or when the
door guard is fully loaded but the fridge is
empty, follow these instructions to attach
the door support (A). This work must be
done by two persons.
1. Tilt the refrigerator backward, and have
one person hold the refrigerator from
the back.
2. The other person inserts the door
support (A) into the bottom hole of the
door.
3. Use a Philips screwdriver to tighten the
screw.
CAUTION
To avoid personal injury or product
damage from a fall or scratch, use caution
throughout the entire process.
Untitled-13 29 2017-06-26 3:32:03
Installation
English30
Installation
STEP 6 Initial settings
By completing the following steps, the refrigerator should be fully functioning.
1. Plug the power cord into the wall socket to turn the refrigerator on.
2. Open the door, and check if the interior light lights up.
3. Set the temperature to the coldest, and wait for about an hour. Then, the freezer will be
slightly chilled, and the motor will run smoothly.
4. Wait until the refrigerator reaches the set temperature. Now the refrigerator is ready
for use.
STEP 7 Final check
When installation is complete, conrm that:
• The refrigerator is plugged into an electrical outlet and grounded properly.
• The refrigerator is installed on a at, level surface with a reasonable clearance from the
wall or the cabinet.
• The refrigerator is level and is sitting rmly on the oor.
• The door opens and closes freely, and the interior light turns on automatically when you
open the door.
Untitled-13 30 2017-06-26 3:32:03
English 31
Operations
Feature panel
Button type
01 02 03 01 02 03
01 Freezer (Power Freeze) 02 Freezer Convert / Ice
On/Off (applicable
models only)
03 Fridge (Power Cool)
Operations
Untitled-13 31 2017-06-26 3:32:03
Operations
English32
Operations
01 Freezer (Power Freeze)
Freezer
The Freezer button can be used to set the freezer temperature
between -15 °C and -23 °C (default: -19 °C).
Each time you press the button, the temperature changes in this
sequence:
-23 °C -15 °C -17 °C -19 °C -21 °C -23 °C
CAUTION
• To prevent system failure or food spoiling, do not set the
temperature to -15 °C in summer (above 35 °C).
• Do not store glass bottles containing liquid in the freezer. Glass
bottles will crack or break into pieces when the liquid freezes.
Power Freeze
Power Freeze speeds up the freezing process at maximum fan speed.
The freezer keeps running at full speed for several hours and then
returns to the previous temperature.
• To activate Power Freeze, press and hold Freezer for 3 seconds.
The corresponding indicator ( ) lights up, and the refrigerator will
speed up the cooling process for you.
• To deactivate, press and hold Freezer again for 3 seconds. The
freezer returns to the previous temperature setting.
• To freeze large amounts of food, activate Power Freeze for at least
20 hours before putting food in the freezer.
• The freezer keeps running at full speed for 50 hours and then
returns to the previous temperature.
NOTE
Using Power Freeze increases power consumption. Make sure you
turn it off and return to the previous temperature if you do not intend
to use it.
Untitled-13 32 2017-06-26 3:32:03
English 33
Operations
02 Freezer Convert / Ice On/Off (applicable models only)
Freezer Convert
You can use the entire refrigerator with Fridge mode, or turn off the
freezer.
To change the default freezer mode, press and hold Freezer Convert
for 3 seconds to enter the selection mode. Then, press Freezer Convert
to select a desired mode.
The mode changes in this sequence: Fridge Off Freezer Off
Fridge setting mode.
• If you select Fridge, the Fridge indicator turns on. Power Freeze
will be deactivated if active, and Ice On will turn off if enabled.
• If you select Off, the Off indicator turns on. The freezer will be
turned off.
• If you select the Freezer setting mode, the freezer temperature
indicators turn on for your selection. The default freezer
temperature is -19 °C.
Your changes will be set and activated after 10 seconds. To cancel or
change the mode again, press and hold Freezer Convert again for 3
seconds. Then, follow the instructions as mentioned above.
NOTE
• If you press and hold Freezer convert for 3 seconds in Freezer
mode, the refrigerator switches to Fridge mode and you can select
a mode (selection mode).
• If you press and hold Freezer convert for 3 seconds in other
modes, the refrigerator switches to selection mode where you can
press Freezer Convert to select a different mode.
• When refrigeration or freezing functions are at 'Off mode', the
temperature of the fridge or freezer remains under 15 °C to
prevent mold and odors, using low electricity
• Fridge or Freezer cannot be powered off independently.
• Do not store food or beverage in refrigerator when refrigeration
or freezing functions are at 'Off mode'. 15 °C is not cool enough to
prevent spoilage.
WARNING
• Do not put glass bottles containing liquid in the freezer. When cancelling Freezer
Convert, the glass bottles may break or burst in the freezer.
• Make sure to remove frozen foods from the freezer before enabling the Freezer
Convert. Frozen foods melt and spoil as the temperature increases (Freezer mode
changes to Fridge mode).
• Make sure to remove chilled foods from the freezer before disabling the Freezer
Convert. Chilled foods may freeze as the temperature decreases (Fridge mode changes
to Freezer mode).
NOTE
If you want to use Freezer Convert, it is strongly recommend to use plastic containers to
store food, especially vegetables.
Untitled-13 33 2017-06-26 3:32:03
Operations
English34
Operations
Ice On/Off
(Applicable models only)
By default, the refrigerator is set to make ice with the corresponding
indicator on. To disable this function, press Ice On/Off to turn it off.
We recommend disabling the function in the following cases:
• The ice bucket is already full of ice.
• You want to save power consumption.
• The water tank is empty.
NOTE
If you press Freezer Convert to select Fridge or Off, the refrigerator
enters Ice Off mode.
03 Fridge (Power Cool)
Fridge
To adjust the fridge temperature, press Fridge to select the
corresponding temperature. You can change the temperature between
1 °C and 7 °C (default: 3 °C).
With the temperature set to 1 °C, press Fridge to turn the vacation
indicator on. The temperature bar turns off. Press again to deactivate
Vacation mode. The temperature bar displays 7 °C.
CAUTION
• In winter, do not set the temperature control to 1 °C. This may
cause problems with the cooling performance.
• In summer, do not set the temperature control to 5-7 °C. This may
also cause problems with the cooling performance.
Power Cool
Power Cool speeds up the cooling process at maximum fan speed. The
fridge keeps running at full speed for several hours and then returns
to the previous temperature.
• To activate Power Cool, press and hold Fridge for 3 seconds. The
corresponding indicator ( ) lights up, and the refrigerator will
speed up the cooling process for you.
• To deactivate Power Cool, press and hold Fridge again for 3
seconds. The fridge returns to the previous temperature setting.
NOTE
Using Power Cool increases power consumption. Make sure you turn it
off and return to the previous temperature if you don’t intend to use
it.
Untitled-13 34 2017-06-26 3:32:03
English 35
Operations
Vacation
If you are going on vacation or a business trip, or if you do not intend
to use the fridge for an extended time, use the Vacation mode.
• To activate Vacation mode, press Fridge with the 1 °C indicator
selected. The vacation indicator ( ) turns on while the display
of the fridge temperatures will turn off. The fridge temperature
will be controlled under 17 °C, but the freezer remains active as
previously set.
• To deactivate Vacation mode, press Fridge again. The fridge
temperature will restore the default 7 °C.
NOTE
It is strongly recommended to empty the fridge compartment and
make sure the door is closed.
Untitled-13 35 2017-06-26 3:32:04
Operations
English36
Operations
Dial type
Fridge
To ensure optimal performance, we recommend setting the temperature to Optimal.
• To decrease the temperature for strong
cooling, set the temperature control to
level 4-5.
• To increase the temperature for weak
cooling, set the temperature control to
level 1-2.
CAUTION
• In winter, do not set the temperature control to level 4-5. This may cause problems with
the cooling performance.
• In summer, do not set the temperature control to level 1-2. This may also cause
problems with the cooling performance.
Vacation
If you are going on vacation or a business trip, or if you do not intend to use the fridge for
an extended time, use the Vacation mode.
To activate Vacation mode, turn the fridge
dial to select Vacation (vacation level). The
fridge temperature will be controlled under
17 °C, but the freezer remains active as
previously set. The Vacation mode will be
deactivated automatically if you adjust the
fridge temperature.
NOTE
It is strongly recommended to empty the fridge compartment and make sure the door is
closed.
Untitled-13 36 2017-06-26 3:32:04
English 37
Operations
Freezer
• To decrease the temperature for strong
cooling, set the temperature control to
level 4-5.
• To increase the temperature for weak
cooling, set the temperature control to
level 1-2.
CAUTION
• In winter, do not set the temperature control to level 4-5. This may cause problems with
the cooling performance.
• In summer, do not set the temperature control to level 1-2. This may also cause
problems with the cooling performance.
Fridge (Convertible)
You use the freezer as Fridge mode.
To enable Fridge mode for the freezer, turn the Freezer Temp. Control dial to a Fridge
(Convertible) level.
Once setup is complete, the temperature of the freezer is controlled to about 3 °C.
NOTE
It is strongly recommended to empty the fridge compartment and make sure the door is
closed.
Untitled-13 37 2017-06-26 3:32:04
Operations
English38
Operations
Special features
The actual image and special functions of your refrigerator may differ, depending on the
model and the country.
Ice making (applicable models only)
Twist ice maker
A
1. Open the freezer door, and slide open
the ice tray.
2. Fill the tray with water up to the
maximum level (A) marked on the inner
rear of the tray.
3. Slide the tray back into position.
NOTE
The ice making time depends on your
temperature settings.
NOTE
• Make sure the ice cube storage bin is in
place under the ice tray.
• To dispense the ice cubes, turn the
handle of the bin to the right to empty
half of the ice cubes into the bin. Then,
turn it to the left to empty the other
half.
• Take out the bin by slightly twisting and
pulling to the front.
Tray type
A
To make ice cubes, ll the tray with water
up to the maximum level (A) marked on the
inner rear of the tray.
Untitled-13 38 2017-06-26 3:32:04
English 39
Operations
To empty the ice tray, hold both ends of
the tray and gently twist to remove the ice
cubes.
Water dispenser (applicable models only)
With the water dispenser, you can dispense chilled water without opening the fridge door.
NOTE
If you keep pushing the dispenser lever for about 1 minute, the dispenser will stop
operating for performance issues. To dispense more water, wait a few seconds and try
again.
To ll the water tank
For rst-time use, clean the inner side of
the water tank and dry well.
1. Hold both handgrips on the front of the
tank, and slide out as shown.
A B
2. Open the front lid (A) of the cover or the
entire cover (B) and ll the tank with a
max of 5 L water.
CAUTION
Do not exceed the max line. Water
overows.
3. Reinsert the water tank and t into the
dispenser mechanism. Make sure the
front side (with the front lid) of the tank
faces to the front.
Untitled-13 39 2017-06-26 3:32:05
Operations
English40
Operations
CAUTION
• Make sure the water tank ts into the shelf. Otherwise, the water tank may not operate
properly.
• Do not use the refrigerator without inserting the water tank. This may decrease the
cooling performance.
• Fill the tank only with potable water such as mineral or puried water. Do not use other
liquid.
• Use caution when moving a lled tank. Physical injury may occur if the tank is dropped.
• Do not try to disassemble the internal pump yourself. If the internal pump is damaged
or disconnected from the water tank, the dispenser does not operate.
For rst-time use
• Push the dispenser lever for 10 seconds to emit air from the hoses of the water supply
system.
• Discard the rst six glasses of water to remove impurities in the water supply system.
To dispense water
Put a glass under the water outlet, and gently push against the dispenser lever with the
glass.
CAUTION
• Make sure the glass is in line with the dispenser to prevent the dispensed water from
spilling out.
• If you do not use the water dispenser for 2-3 days, the dispensed water may have an
abnormal smell or taste. This is not a system failure. Discard the rst 1-2 glasses of
water.
Untitled-13 40 2017-06-26 3:32:05
English 41
Operations
Auto ice maker (applicable models only)
For rst-time use
• Let the ice maker make ice for 1-2 days.
• Discard the rst 1-2 buckets of ice to
remove impurities in the water supply
system.
• When the upper ice tray is full, use the
lower ice tray.
Test button
A
If the auto ice maker does not make ice,
remove the ice bucket and press Test (A)
to check if the auto ice maker operates
properly.
Untitled-13 41 2017-06-26 3:32:05
Operations
English42
Operations
Water dispenser
With the water dispenser, you can dispense water without opening the fridge door. The
water tank must be lled with potable water before use.
To ll the water tank with potable water
Open the door and locate the water tank that is located in the door shelf area.
1. Hold the handgrips on both sides of the
water tank and lift up to remove.
2. Fill the water tank with potable water
up to 2.3 liters. You can remove either
the top cap or the cover and pour water.
NOTE
For rst-time use, clean inside the water
tank.
3. Reinsert the water tank and close the
door. Make sure the water outlet of the
water tank faces forward.
Untitled-13 42 2017-06-26 3:32:06
English 43
Operations
4. Put a water glass under the water outlet
of the dispenser, and gently push the
dispenser lever to dispense water. Make
sure the water dispenser is unlocked.
CAUTION
• The water dispenser is designed to dispense potable water. Fill the water tank only with
potable water. Do not ll with any other liquids.
• Do not ll the water tank excessively, which causes an overow.
• Do not try to ll the water tank without removing it from the door.
• Make sure that water tank is seated properly.
• Do not use the refrigerator without the water tank. This may reduce performance and
efciency.
• To prevent water bouncing, make sure the glass is in line with the dispenser lever.
NOTE
To secure more room, you can use the water tank to store food. In this case, remove the lid
of the tank.
Untitled-13 43 2017-06-26 3:32:06
English44
Maintenance
Handle and care
Ice tray provided models
First remove the ice tray, and then lift up
the freezer shelf to remove.
Freezer and fridge shelves
• To remove a shelf, rst open the door
completely. Pull the shelf forward, lift
up, and then pull out.
• When reinserting the shelf, make sure
the “Front” label of the shelf faces
forward.
• Do not attempt to tilt the shelf into
position.
Door guards
Slightly lift up and pull out the door guard.
CAUTION
To prevent accidents, empty the door
guards before removing.
Maintenance
Untitled-13 44 2017-06-26 3:32:06
English 45
Maintenance
Cleaning
Regularly use a dry cloth to remove all foreign substances such as dust or water from the
power plug terminals and contact points.
1. Unplug the power cord of the refrigerator.
2. Use a moistened soft lint-free cloth or paper towel to clean the refrigerator’s interior
and exterior.
3. When done, use a dry cloth or paper towel to dry well.
4. Plug in the power cord of the refrigerator to turn the refrigerator on.
NOTE
If you have removed any removable parts such as shelves for cleaning, refer to the overall
layout in the What’s included section to make sure you have reinserted correctly.
WARNING
• Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning
purposes. They may damage the surface of the refrigerator and cause a re.
• Do not spray water onto the refrigerator. This may cause electric shock.
• Do not put ngers or other objects into the dispenser hole.
Replacement
Deodorizer lter (applicable models only)
A
While holding the top and bottom sides
of the lter case, unlock the lter case to
reveal the deodorizer lter (A). Replace the
lter, and then reinsert the case.
Lamps
The lamps are not user-serviceable. To replace the lamps of the refrigerator, contact a local
Samsung service centre.
Untitled-13 45 2017-06-26 3:32:06
English46
Troubleshooting
If you encounter an abnormal situation with the refrigerator, rst check the table below
and try the suggestions.
General
Symptom Action
Does not operate or
cool.
• Make sure the power cord is connected properly.
• Make sure the temperature control is set correctly.
• Make sure to keep the refrigerator away from direct sunlight
or a heat source. Failing to do so may affect the cooling
performance.
• Make sure the refrigerator has enough room from the rear
and side walls or the cabinet. Failing to do so may affect the
cooling performance.
• Too much food may block the ventilation of the refrigerator.
To keep the refrigerator in normal operation, do not put too
much food inside.
Food in the fridge
freezes.
• Check if the temperature control is set to the lowest
temperature. If so, change the temperature to higher or
optimal.
• This happens if the ambient temperature is too low. Set the
temperature higher.
• Check if food containing a high portion of water is put in the
coldest area of the fridge or near the cooling vent. If this
happens, move the food to other shelves in the fridge.
Emits noises.
• Make sure the refrigerator is installed on a stable, at
surface.
• Make sure the refrigerator has enough room from the rear
and side walls or the cabinet.
• Make sure to keep the refrigerator from impurities or foreign
objects inside or underneath.
• The refrigerator may produce a ticking sound from inside,
which occurs when the various removable parts contract or
expand. This is not a system failure.
The front corners
and sides become
warm and form
condensation.
• To prevent condensation from forming, the refrigerator
has heat-proof piping in the front corners. If the ambient
temperature rises, this equipment may not work effectively.
This is not a system failure.
• Condensation may form on the exterior surface of the
refrigerator if humid air comes into contact with the cool
surface of the refrigerator.
Troubleshooting
Untitled-13 46 2017-06-26 3:32:06
English 47
Troubleshooting
Symptom Action
The ice maker does
not make ice.
• You must wait for 12 hours until the refrigerator makes ice.
• Make sure the ice maker is not stopped while making ice.
• Make sure the freezer is set below 0 °C (or -5 °C in warm
ambient air).
• Make sure the water tank is lled with water.
The water dispenser
is not functioning.
• Check if the water tank is frozen. If so, select a higher fridge
temperature.
• Make sure the water tank is lled with water.
• Make sure the water tank is installed properly.
• Make sure the water lter is installed properly.
Produces a bubbling
sound.
• The refrigerator makes this sound during the cooling process,
which is normal.
A bad smell comes
from inside the
refrigerator.
• Check for any spoiled food. We recommend cleaning the
refrigerator on a regular basis and remove any spoiled or
suspect food items.
• Make sure strong smelling food is wrapped up airtight.
Frost forms on the
interior walls.
• Make sure no food blocks the vents of the refrigerator. It is
also important to arrange food items evenly for ventilation.
• Make sure the door is closed properly.
Condensation forms
on the interior walls
or around vegetables.
• This happens when food containing a high portion of water is
stored uncovered, or the door has been left open for a while.
• Make sure food is covered or put in sealed containers.
Untitled-13 47 2017-06-26 3:32:06
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the
SAMSUNG customer care center.
Country Contact Center Web Site
AUSTRALIA 1300 362 603 www.samsung.com/au/support
NEW ZEALAND 0800 726 786 www.samsung.com/nz/support
DA68-03377Z-02
Untitled-13 48 2017-06-26 3:32:07
