Safety Precautions
Parts and Accessories
How to Disassemble Chamber
How to Prepare Ingredients
How to Assemble (Smart Hopper/Dual Hopper)
Cautions during Operation
How to Use (Smart Hopper/Dual Hopper)
How to Use Control Lever (by mode/by ingredients)
Screw Stops during Operation
How to Clean
Before Requesting for Repair
Product Specifications / Warranty
H-AI Series ( For Household Use Only / Warranty Included )
CONTENTS
Instruction Manual
TM
1. Read ‘Safety Precautions’ (p. 2) and use the appliance properly.
2. After reading the manual, keep it in a convenient location for future reference.
3. Do not use it abroad which has different power supply and voltage.
4. Any quality improvements is subject to change without notice.
Safety Precautions
Parts and Accessories
How to Disassemble Chamber
How to Prepare Ingredients
How to Assemble
Cautions during Operation
How to Use
How to Use Control Lever
When Screw Stops during Operation
How to Clean
Before Requesting for Repair
Product Specifications / Warranty
02
Safety Precautions
01 You should read <Safety Precautions>
02 You should follow <Safety Precautions>
03 Precautions are classified as follows.
Warning Violating the labeling requirement,
may cause serious injury or death.
DO NOT PLUG IN NOR UNPLUG WITH WET HANDS. It may cause electric shock or
injury.
DO NOT USE OTHER THAN 230 V - 240 V AC. It may cause electric shock, re or abnor-
mal performance. If the voltage is different, it may shorten the life of the motor or cause
a failure.
PLUG THE POWER CORD CORRECTLY AND FIT IT TIGHTLY INTO A WALL SOCKET. It
may cause an electric shock or a re.
IF THE POWER CORD IS DAMAGED, IT MUST BE REPLACED BY THE MANUFACTUR-
ER’S ITS SERVICE OR SIMILARLY QUALIFIED PERSONS IN ORDER TO AVOID A HAZ-
ARD. If the power cord is damaged, it may cause electric shock or re.
NEVER DISASSEMBLE CHAMBER SET PARTS OR INSERT ALIEN SUBSTANCES INTO
THE JUICE OUTLET AND PULP OUTLET WHILE THE JUICER IS RUNNING.It can cause
injury, accident, or trouble
WHEN THE POWER CORD, WIRE IS BROKEN OR DAMAGED OR THE PLUG-IN PART
BECOMES LOOSE, DO NOT OPERATE THE MACHINE. It may cause electric shock, re
or injury.
DO NOT WET OR SPLASH WATER ON THE MAIN BODY.
Be careful not to let any liquids or other substances get into the switch on the appliance.
DO NOT OPERATE THE POWER DIAL WITH WET HANDS.
It may cause an electric shock or re.
FOR SAFETY, GROUND THE APPLIANCE. (MAKE SURE TO USE THE OUTLET WITH
GROUND CONNECTION.) DO NOT GROUND TO GAS PIPE, PLASTIC WATER PIPE,
TELEPHONE LINE, AND SO FORTH.
It could cause electric shock, re, malfunction or explosion.
NEVER DISASSEMBLE THE CHAMBER SET DURING OPERATION NOR INSERT FIN-
GERS, FOREIGN OBJECTS SUCH AS FORKS, SPOONS, ETC. INTO HOPPER CHUTE OR
JUICE OUTLET. It may cause injury, accident or failure.
APPLIANCES CAN BE USED BY PERSONS WITH REDUCED PHYSICAL, SENSORY OR
MENTAL CAPABILITIES OR LACK OF EXPERIENCE AND KNOWLEDGE IF THEY HAVE
BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLIANCE
IN A SAFE WAY AND IF THEY UNDERSTAND THE HAZARDS INVOLVED. CHILDREN
SHALL NOT PLAY WITH THE APPLIANCE. CLEANING AND USER MAINTENANCE
SHALL NOT BE MADE BY CHILDREN. THIS APPLIANCE SHALL NOT BE USED BY
CHILDREN. KEEP THE APPLIANCE OUT OF REACH OF CHILDREN.
DO NOT OPERATE WITHOUT LOCKING THE HOPPER PROPERLY.
It may cause an injury or a failure.
WHEN DETECTING A GAS LEAK, DO NOT INSERT THE POWER CORD INTO THE OUTLET.
OPEN THE WINDOW TO VENTILATE FULLY AND IMMEDIATELY.
It may cause injury or failure.
When placing ingredients into the hopper chute, only use the pusher provided.
It may cause injury or failure.
03
DO NOT RUN THE JUICER WHILE THE CHAMBER SET IS NOT ASSEMBLED
PROPERLY. It can cause injury, accident, or trouble.
WHEN USING THE SMART HOPPER, ENSURE THAT THE MIXING BAR IS ASSEMBLED
PROPERLY BEFORE USE.
If not, it can cause injury, accident, or trouble.
WHEN DETECTING A GAS LEAK, DO NOT INSERT THE POWER CORD INTO
THE OUTLET. OPEN THE WINDOW TO VENTILATE FULLY AND IMMEDIATELY.
It may cause injury or failure.
IF THE SCREW STOPS WHILE IN USE,TURN THE DIAL TO [ REV ] FOR 3~5 SECONDS
TO TURN THE SCREW IN REVERSE DIRECTION, WAIT UNTIL THE REVERSE MOTION
STOPS COMPLETELY, AND THEN TURN THE DIAL TO [ ON ].
If the juicer does not run continuously, it can cause damage to parts due to motor
overheat or performance degradation. If the trouble persists, stop the product and
contact our customer center.
DURING THE OPERATION, DO NOT ATTEMPT TO MOVE THE MAIN BODY, DISASSEM-
BLE THE CHAMBER SET OR PARTS, OR TRY TO LOCK THEM. It may cause an injury or a
failure. If any action is needed, switch off and unplug the power cord rst.
MAKE SURE NO ALIEN SUBSTANCES GET INTO THE HOPPER OTHER THAN
INGREDIENTS WHEN USING THE JUICER.
It can cause damage or breakage.
PLACE THE APPLIANCE ON A FLAT AND STABLE SURFACE.
It may cause injury or failure.
DO NOT OPERATE THE APPLIANCE FOR MORE THAN 30 MINUTES AT A TIME.
It may cause a motor failure due to overheating. Cool it down sufciently about 5 minutes
and operate it again.
DO NOT ALLOW A SEVERE SHOCK TO THE APPLIANCE NOR DROP IT.
It may cause electric shock, re or damage.
IF THE APPLIANCE GIVES OFF AN UNPLEASANT SMELL, EXCESSIVE HEATING, OR
SMOKE, STOP USING THE APPLIANCE IMMEDIATELY AND CONTACT THE LOCAL CUS-
TOMER CARE CENTER. When using a new appliance, it gives off a smell, which
disappears naturally over time.
ALWAYS UNPLUG THE APPLIANCE AFTER USE. ALWAYS DISCONNECT THE APPLI-
ANCE FROM THE POWER SOURCE IF IT IS LEFT UNATTENDED AND BEFORE ASSEM-
BLING, DISASSEMBLING OR CLEANING. WHEN UNPLUGGING THE POWER CORD,
MAKE SURE TO HOLD THE POWER CORD BY ITS HEAD.
Pulling the cord to unplug may cause electric shock or re.
DO NOT WASH THE APPLIANCE AT A HIGH TEMPERATURE, 80
0
C(176
0
F) OR HIGHER.
DO NOT PUT THE APPLIANCE IN A DISHWASHER, A DRYER OR A MICROWAVE ETC.
It may cause a trouble or a deformation of part.
THE APPLIANCE WEIGHS APPROXIMATELY 6.4KG (14.1LB). WHEN MOVING THE
APPLIANCE, MAKE SURE TO HOLD THE MAIN BODY SECURELY WITH BOTH HANDS.
When you carry the appliance by the chamber or by the side of the main body, the main
body might fall and cause an injury or a trouble.
DO NOT USE HOUSEHOLD PRODUCTS FOR COMMERCIAL PURPOSE.
Forcing a large amount of ingredients for extraction may damage the parts.
Please contact the Customer Service Center for the advice on using the product for
commercial purposes.
Caution Violating the labeling requirement,
may cause serious injury or damage to the
appliance.
04
02 Dual Hopper
Hopper
Cover
Safety
Sensor
Hopper
Chu t e
C- Wing
T- Wing
Mixing Bar Axis
Mixing Bar
Screw Axis
Mid Gear
Pulp Outlet
Control Lever
Juice Cap
03 Screw
05 Strainer
04 Chamber
01 Smart Hopper (Hopper Cover / Mixing Bar)
06 Spinning Brush
Juuce Outlet
Juice Cap Packing
Safety
Sensor
Parts and Accessories
Fine Strainer Coarse Strainer
Strainer
Bump
Silicon Brush
Brush Holder
05
Parts and Accessories
11 Cleaning Brush
08 Pulp Container Cover 09 Pulp Container 10 Juice Container
07 Base
Body
Bump
Motor
Spin
Safety Sensor
12 Small Cleaning Brush 13 Pusher
06
Please clean all parts before the first use.
Turn the hopper lid counterclockwise
to open and remove mixing bar, and
separate the chamber and hopper by
turning the hopper counterclockwise.
Pull up the strainer including the
screw and spinning brush from the
chamber to remove.
Hold the wing of the screw and pull
up to remove.
How to Disassemble Chamber
Disassemble the spinning brush and
strainer.
07
► If you are allergic to some ingredients, you need to choose ingredients carefully according to your condition.
► Please refer to the recipe book about how to use the juicer for each ingredient and cautions you need to take.
► Please check how to prepare each ingredient before extraction.
► If not prepared properly, it might be difficult to extract juice from ingredients.
Apple·Pear
Oriental melon
Kiwi
Watermelon
melon·Orange
Grapefruit·Lemon
Mango·Peach
Persimmon
Plum·Cherry
Wheat·Chives
Water parsleys
Angelica·Celery
Kale
Pomegranate ·
Grapes
Mango·Banana
(Smart Hopper Only)
How to Prepare Ingredients
Ginger · Garlic
(Dual Hopper Only)
For fruits such as pear, kiwi, and oriental melon, cut the flesh with the seeds
and peels to 3 cm in size before extraction. For apples, however, apple seeds are
poisonous and it is recommended that you remove them before extraction. The stalk
of oriental melon is bitter. It is recommended that you remove it before extraction.
Separate grapes from the vine.
For pomegranates, remove the husk and only take the flesh.
For fruits such as watermelon, orange, grapefruit, melon, and lemon, remove the
husk and cut the flesh to 3 cm in size.
Mango, persimmon, peach, plum, cherry, cactus, etc., have seeds
that are too solid to chew and swallow. Solid seeds can stop the motor or break
parts. You must remove seeds before extraction and cut the flesh to 3cm in size.
For ingredients with long and tough fiber such as water parsley, angelica, wheat
sprout, and chives, cut them to 3cm in size before use.If not prepared, stalk
vegetables can coil around the mixing bar and strain the motor.
Soft ingredients such as banana and mango might pile up inside or would not
produce much juice if they are extracted by themselves. Extract with solid
ingredients or watery ingredients.
Ex) Mango + Apple , Banana + Apple
The [ MAX ] icon on the hopper indicates the maximum volume
of ingredients inside the hopper. Make sure the ingredients in the
hopper do not exceed that line.
Smart Hopper Icon
The [ ] icon on the hopper indicates the limit for
the volume of ingredients in the hopper for ingredients with
large water content. Orange, grapes, tomato, watermelon, etc.
contain a large amount of water and might run over the chamber.
Please keep the indicated line when filling up the hopper with the
ingredients.
For ingredients containing a lot of fibers such as ginger, remove the peel, cut
them into thin slices, and insert little by little. For root vegetables (carrot, potato,
sweet potato, deodeok, dandelion, etc.), wash them in running water to remove
alien substances such as soil before use. When extracting a large amount of juice,
repeat the process of "disassembling and cleaning after extracting juice from 1kg
of ingredients”.
How to Prepare Ingredients
08
2
STEP
1
STEP
3 4
STEP STEP
Smart Hopper
After [ Step 3 ], match [ ] of the hopper
to [ ] on top of the chamber in a
straight line and turn it clockwise until it
comes to [ ].
Assemble fine strainer and spinning
brush. Push in until they are completely
assembled.
Assemble the screw into [STEP1].
Place the assembly form [ Step 2 ] into the
chamber and turn left and right until the
bump on the bottom of the net falls into the
groove inside the chamber.
▲
How to Assemble
09
7 8
STEP STEP
6
STEP
5
STEP
Smart Hopper
After [ Step 4 ], fit the mixing bar on
the shaft of the screw.
Set the adjusting lever of the chamber set
to [ CLOSE]
Match the bump on the main body so that
the hopper’s handle faces towards the
main body.
Finally, close the pulp cup lid
and push in until it clicks.
After [ Step 5 ], align [ ] on the lid with
[ ] on the upper side of the hopper in
a straight line and turn it clockwise until
the icon on the lid points [ ].
▲
How to Assemble
10
4
STEP
2
STEP
1
STEP
3
STEP
Assemble fine strainer and spinning
brush. Push in until they are completely
assembled.
Assemble the screw into [STEP1].
Place the assembly form [ Step 2 ] into the
chamber and turn left and right until the
bump on the bottom of the net falls into the
groove inside the chamber.
After [ Step 3 ], match [ ] of the hopper
to [ ] on top of the chamber in a
straight line and turn it clockwise until it
comes to [ ].
▲
How to Assemble Dual Hopper
11
5 6
STEP STEP
Set the adjusting lever of the chamber set
to [ CLOSE]
Assemble the bottom of the chamber to
bump of the body.
Finally, close the pulp cup lid
and push in until it clicks.
How to Assemble Dual Hopper
12
Ingredients which needs caution.
It may cause damage or failure.
- For fruits with hard seeds such as mango, persimmon, peach, plum, cherry etc. that are too hard to
chew, the seeds should be removed before extraction.
- Cut stalk vegetables with tough fibers such as water parsley and celery to approximately 3cm in size
before extraction. If you do not prepare the ingredients properly, the juicer might stop or the ingredients
might coil around the mixing bar.
- Do not put in sesame seeds, coffee beans, tree barks, Chinese pepper, and so on that cannot be extracted.
- Do not put in fruits preserved in alcohol, sugar, honey, etc. (grapes, apricot, berries, etc.)
and enzymes (glasswort, houseleek, etc.). It may cause damage or failure.
- Do not insert ingredients that cannot be extracted due to their characteristics, such as figs, aloe, cactus
and ginger. It may cause damage or failure.
[Smart Hopper Only] Soft ingredients such as banana and mango might pile up inside or would
not produce much juice if they are extracted by themselves. Extract with solid ingredients or
watery ingredients.
[Dual Hopper Only] Extracting materials containing a lot of fibers such as ginger in a large
amount can cause breakage or malfunction. Ginger can be extracted only when using the dual
hopper.
We recommend you to drink green vegetable juice and fruit juice immediately after extraction
rather than keeping them for long time.
If you are extracting continuously, empty the pulp cup before continuing.
The pulp can run over.
- If the parts are not assembled properly, the juicer may not operate or it can cause breakage.
When the chamber stops due to overload, turning the power dial to [ REV ] can open the hopper.
- This is a safety mechanism designed to protect the product from damage and is normal.
You may use the appliance for crushing spices (garlic, red pepper), but not for grinding grains.
(It may cause damage or failure. )
Do not re-squeeze pulp discharged through the pulp outlet. Soft fruits can be re-squeezed.
Do not operate the appliance without ingredients inside.
It may cause a failure due to the overheating of the motor.
- When using the appliance continuously, stop for 5 minutes after every 30 minutes of use.
Never insert chopsticks or spoon into pulp outlet during the operation.
- Inserting such as chopsticks etc. into Pulp outlet during operation may cause them to stuck into the
spinning brush and cause damage to the parts.
It is possible that the hopper would not open easily due to the pressure inside the chamber after
extraction.
- Refer to Finishing Mode in p. 16 to discharge remaining pulp. The hopper will open easily
afterwards.
Do not operate the power dial with a wet hand
- It can cause electric shock, short circuit, or fire. Do not stain the power dial and its proximity with
alien substances.
Cautions during Operation
13
Please check how to prepare ingredients according to their characteristics and prepare them
before extraction.
- If you do not prepare ingredients properly, it might be difficult to extract juice from them or break
the juicer.
Check the [MAX] and [ ] icons on the hopper and make sure the ingredients in the
hopper do not exceed that line.
- [ MAX ] and [ ] icons on the side of the hopper indicate the limit for the volume of
ingredients in the hopper depending on the water content of the ingredients.
- Putting an excessive amount of ingredients can strain the motor and break the product or may
lead to the leakage of juice through the gap between chamber of hopper.
Take cautions not to hurt the hand when assembling or disassembling the mixing bar.
- The mixing bar helps the ingredients to move into the chamber smoothly.
When you extract over 400ml at once,
please open the control lever every 400ml to emit the pulp.
- The hopper can’t be opened or it may cause damage when the pressure in the chamber increases.
Do not operate the switch with wet hands.
- It may cause electric shock or fire. Do not put foreign objects near the switch.
If you are extracting continuously, empty the pulp cup before continuing. The pulp can run over.
Strainer
Dual Hopper
Smart Hopper
Fine strainer has tiny and fine holes good to make clean juice.
Coarse strainer has larger holes so is good to make thick juice with flesh in it.
It is to make juice with soft fruits and thick juice like banana, strawberry,
and also useful for smoothie, latte, or soup.
Fine
Strainer
Coarse
Strainer
Note
Ingredients that have been shriveled after refrigerated for a long time may produce small
amount of juice or may not produce any juice. If the unit is not cleaned immediately after use, the
pulp may dry andstick to the unit. This will make assembling and cleaning difficult and may also
lead to performance degradation.
Cautions during Operation
14
1
3
5
2
4
How to Use
Assemble the mixing bar, prepare ingredients
according to their characteristics, and insert them
into the hopper.
Check the [MAX] and [ ] icons on the side
of the hopper and make sure the ingredients in the
hopper do not exceed that line.
Putting an excessive amount of ingredients can
strain the juicer.
Insert the prepared ingredients and close
the lid.
Turn the power dial to [ON] (clockwise).
After extraction, turn the power dial to [ ]
(counterclockwise) to stop the juicer.
Set the lever to [ CLOSE ] before
extraction.
Set the lever to Half Open [ ] when all
ingredients go down through the chamber
set.
Set the lever to [ ] (Half Open) when all
ingredients go down through the chamber set
and operate until no more pulp comes out of the
juicer.
For safety, the main body does not operate by
itself. It will only operate when it is properly
assembled with the chamber set.
Note
When turning the dial to [ON] or [REV], turn it only after
the screw stops completely.
The chamber may not be assembled onto the
main body if the control lever is not in CLOSE
[CLOSE] position.
For performance and safety, the juicer will not
stop instantly but slow down to a stop when the
dial is turned.
◑
◑
Smart Hopper
15
How to Use
Put ingredients gradually in the hopper
chute and press with the pusher.
Press [ON] button to start.
After extraction is completed, place the
switch in the [REV] position.
Place the lever [CLOSE]position before
operating.
Juice : Put the lever in half-closed
[◑] position before putting the last
ingredients.
Ice Cream : Close[CLOSE] the control
lever to use.
The hopper will be opened easily as long as the
residues in the strainer are released.
Stop the machine slowly after press the button for
safety and product performance.
Do not press the ingredients with anything except
the pusher provided.
Cut stalk vegetables with tough fibers such as
water parsley and celery to approximately 3cm in
size before extraction.
Insert diced apple, cherry tomato, and the like
through the side chute for convenience.
When you extract over 400ml at once, please open
the control lever every 400ml to emit the pulp.
The chamber will not be assembled with body if
the control lever is not into CLOSE [CLOSE]
position.
For your safety, this appliance only works when
it's correctly assembled with chamber set.
1
2
5
3
4
Note
When using [ON] or [REV] button,
make sure that the auger stops completely.
Pusher
Upper
hopper
chute
Side
hopper
chute
Dual Hopper
16
The lever is located next to the juice outlet on the chamber.
How to Use Control Lever
Note
If the hopper does not open easily after use, set the lever to ◑ (Half Open) and turn the dial to [REV] for
3~5 seconds and stop. Repeat this twice or three times. You will be able to open it easily afterwards.
For better extracting efficiency,
set the lever to [ CLOSE ].
[ CLOSE ] Juice Extraction Mode
After all ingredients go down the chamber set, turn the
lever to [ ] (Half Open) and run the juicer until no more
pulp comes out of the juicer.
You need to discharge pulp to open the hopper easily.
[◑] Finishing Mode
When detaching and cleaning the chamber, turn the lever
to [OPEN ◯] completely. You can easily and conveniently
clean the chamber.
You cannot move the control lever to [OPEN ◯] position
when the chamber is placed on the main body.
[ OPEN ◯ ] Cleaning Mode
◑
17
How to use control lever by ingredients (Juicing)
Apple, Pear, Melon, Watermelon, Strawberry, Blueberry, Orange, Grapefruits, Lemon, Mango,
Plum, Peach, Cherry, Persimmon, Pineapple, Wheat-Grass, Parsley, Celery, Dandelion, Carrot,
Ginger, Potato, Beet, Tomato, Paprika, Broccoli, Cauliflower, Cabbage, Kale, Spinach (Cooked)
Sweet Potato, Pumpkin, Corn
Grapes, Pomegranate, Kiwi, Tomato, Blackberry, Raspberry, Mulberry, Etc.
Start from control lever in [ CLOSE ] position.
Start from control lever in [ CLOSE ] position.
When extraction is almost finished, place the
control lever into [◑] half-opened position.
When juice starts to come out, place the control
[◑] half-opened position.
1. Start from control lever in
[ CLOSE ]position.
Banana, Strawberry, Blueberry, Etc.
Use the control lever by the properties of each ingredients, you can make a more
delicious juice. When you extract over 400ml at once, please open the control lever
every 400ml to emit the pulp. The hopper can’t be opened or it may cause damage
when the pressure in the chamber increases.
Note
Ingredients
Ingredients with seed
Mix with milk
18
When Screw Stops during Operation
Caution in Using Power Dial
1
2
Note
If the screw still does not turn after following said directions, unplug the power cord, disassemble
chamber set, clean the parts, and try again.
To run in the reverse direction during extraction, turn the dial to [ ] to stop the
juicer completely and then turn to [REV] to run in the reverse direction. Due to the
design of the motor, it will not stop instantly,
but will slow down to a complete stop in the direction it was rotating.
The reverse action is active only when the power dial is held in [REV] position.
Note
Turn the power dial to [REV] for
3~5 seconds (counterclockwise)
and stop and repeat this twice or
three times.
The reverse rotation releases
ingredients tangled inside the
chamber. The reverse option is
active only when you hold the dial
in the reverse position and the
screw will stop when you release
the dial.
After the reverse motion
stops completely, turn the
power dial to [ON]
(clockwise) to run the juicer.
When you turn the dial to [ON]
or [REV], make sure the screw
comes to a complete stop and
then turn the dial to the direction
you want.
19
Cleaning Parts
How to Clean
After the extraction, remove the pulp remaining inside
the chamber by referring to p. 13 (Finishing Mode)
before washing.
After the juicer comes to a complete stop, pull out the
power cord with a dry hand.
Move the chamber set by holding the chamber and the
hopper’s handle with both hands.
Disassemble the chamber set and wash the parts in
running water using the cleaning brush.
Set the lever to [OPEN ] and open the juice cap to
wash the chamber.
The intermediate gear inside the chamber can be
removed for washing.
Silicon packings can be also separated for washing.
(Juice Cap Packing, Silicon Brush)
Soak in the mixture of water, baking soda, citric acid, or
vinegar for 30 minutes for sterilization.
Clean the main body with dried towel or soft cloth.
01
02
03
04
05
06
07
08
09
Note
If the unit is not cleaned immediately after use, the pulp may dry and stick to the unit.
This will make disassembling and cleaning difficult and may also lead to performance
degradation. Do not wash with hot or boiling water, an iron scrubber, abrasive material, sink
solvents, or sharp cleaning tools. Do not put it in a dishwasher or dish dryer. After washing,
thoroughly and naturally dry, and store in a clean area.
◯
20
If the chamber is not easily separated from the
hopper, separate the hopper, while the chamber is
connected to the main body, and wash the hopper
in running water.
If the hopper does not open easily after use
Set the lever to[ ] (Half Open) position and remove
pulp inside the chamber or turn the dial to [REV]
for 3~5 seconds and stop and repeat this twice or
three times. You will be able to open the chamber
lid easily afterwards.
The chamber packing can't be disassembled.
Do not disassemble the chamber packing.
If you try to disassemble the chamber packing,
it might be damaged.
When you clean the chamber set, wash the residue
inside and bottom of the chamber under running
water.
Chamber
How to Clean : Chamber Set
Hopper
Chamber
packing
◑
21
How to Clean : Silicones
Open the juice cap, hold the chamber and juice cap with
one hand, and remove the juice cap packing with your
other hand to disassemble.
Please be careful not to drop or damage the juice
cap and chamber when disassembling the unit.
Push the intermediate gear from the bottom side
of the chamber to remove the gear.
Place the intermediate gear after cleaning.
Intermediate gear
Remove silicone brush from the spinning brush
holder.
Use a cleaning brush and wash the inside and
outside of the spinning brush holder in running
water.
Hold the outer side of the silicon brush and pull it in the
direction of the arrow. Otherwise, the silicon brush can be
torn or the brush holder can be broken. Please follow the
recommended method to separate the silicone brush
Wash the silicone brush in running water in the same
manner.
Silicone brush
1
2
3
After cleaning, attach the silicone brush by
pressing it back to the brush holder in the
direction opposite to the removing direction,
and pull the inner wing inward with your other
hand as shown in the picture so that the brush
would fit into the grooves properly.
If the silicone brush is not inserted properly, the packing may
become worn or fall out during juice extraction.
Juice Cap Packing
22
Before Requesting for Repair
If you need additional information, please contact your local Customer Service Center or visit
www.hurom.com. When applying for after-sales service, please have the manufacturer’s serial
number or bar code ready.
01 The main body will not work on its own.
For safety, the juicer will work properly only when
the chamber set is assembled properly.
02 Please align safety sensors.
For your safety, the appliance only works when the
safety sensor icons are aligned correctly.
04 When inserting ingredients, check with
the [ MAX ] and [ ] icons indicated
on the hopper.
The volume of extracted juice may vary depending
on the ingredients. In some cases the juice might
exceed the chamber capacity and leak between
chamber and hopper.
03 Please prepare ingredients before
inserting them.
Unprepared ingredients might coil around the
mixing bar or damage the product to disrupt the
extraction process.
06 Do not use in ways other than pressing
on the pusher in the inlet.
It may cause damage, injury, etc.
05 Do not insert too many ingredients at
once.
If you insert an excessive amount of ingredients
or thick ingredients, the unit may stop.
23
07 The juicer is not operating at all.
Check if the power cord is connected properly.
Check if the hopper is assembled properly. Check if the hopper’s lid is assembled properly.
Check if the product is assembled in proper order. Refer to p. 08~11 (How to Assemble).
The juicer would not operate properly when the hopper is not assembled properly.
If the trouble still persists after taking said measures, please contact our customer center for further
instruction.
08 The appliance stops during normal operation.
Have you in heavy loads or large pieces of ingredients into the appliance?
Refer to p. 18 of the manual and follow the guideline for using [REV] button.
If the issue is not resolved after following the above process, please contact your local Customer
Service Center.
09 There are fine lines or scratch marks around the screw.
These are molding marks resulting from the normal manufacturing process.
This is normal and there is no problem for use.
10 The chamber set icannot be assembled to the main body.
The chamber set cannot be to the main body when the lever is set to OPEN ◯.
Please set the lever to CLOSE position before assembling the chamber set to the main body.
11 The juice is leaking between chamber and hopper.
Did you put too many ingredients?
The capacity of the chamber is 500ml and the volume of juice varies depending on the water content
of the ingredient Check the [MAX], [ ] icon on the side of the hopper and make sure the
ingredients in the hopper do not exceed that line.
12 Cannot open the hopper.
It is possible that there is pulp remaining inside. Set the lever to (Half Open), turn the power dial to
[ON], and run the juicer to remove the pulp inside or turn the dial to [REV] for 3~5 seconds and stop
and repeat this twice or three times. You will be able to open the chamber lid easily afterwards.
Did you put foreign object or solid object (such as the hard seed such as the seed of persimmons)?
Turn the power dial to [REV] to push up the alien substance toward the inlet to remove.
Do not use excessive force to open the lid. Try to open it in the recommended manner and if you still
cannot open the lid then please contact our Customer Service Center for further instructions.
13 The chamber is shaking or making noise (when extracting juice).
The chamber can shake slightly due to the rotation of the motor.
Extracting juice from various ingredients can cause various degrees of movements depending on
the characteristics of the ingredients (hardness and toughness). This is a normal as the movement is
caused by the rotating screw and is not considered as a trouble. It may seem that it is shaking more
severely when extracting juice from hard ingredients (i.e. carrot/potato/radish/beet, etc.)
compared to when extracting from soft and watery ingredients. Some noise can be generated from
the friction between ingredients depending on the characteristics of the ingredients (i.e. carrot/
cabbage, etc.) when extracting juiceThe noise heard when you move the hopper up or down is normal
for operation.
Before Requesting for Repair
ProductName
Model Name
Rated Voltage
Rated Frequency
Rated Power Consumption
Hurom Slow Juicer
H-AI Series
230 - 240 V
50 Hz
200 W
60 rpm
4DC010581_V.01
Product Specifications / Warranty
Rated Operating Hour
Cord Length
Motor
Fuse
Weight
Less than 30 minutes
1.4 m
250 V 5 A
6.4 kg (14.1Ib)
Product name
Important: For better protection of your purchase, ll out and mail this form to a local distributor where you
purchased the appliance and keep the original receipt.
This certies that the Hurom Slow juicer is covered under warranty by HUROM to be free from defects in
material construction and workmanship.
Hurom provides warranty for two (2) years from the date of purchase by the original purchaser.
Coverage is valid only with proof of purchase from an Authorized Local Distributor.
(No international warranty available)
This warranty does not apply to damages caused by accident, misuse, abuse, commercial use, alteration, failure to
follow operating instructions, or damage caused by parts or service unauthorized by HUROM . Damages caused by
transportation must be claimed with carrier. HUROM disclaims all responsibilities for consequential damages from
incidental losses caused by use of this appliance.
Please check the bottom of your Hurom product for a sticker with a barcode.
This barcode sticker helps verify a genuine Hurom product and identify the product manufacturing date.
Hurom’s manufacturer’s warranty does not cover products with missing or damaged barcode stickers.
Products are to be inspected upon receipt.
For service and assistance with technical difculty, please contact our local Customer Service Center.
Supplier Date of purchase
Address
Model name
Manufacture’s serial number
Customer name
Warranty
W 296mm / L 160 mm / H 435 mm
W 296mm / L 160 mm / H 437 mm
Single-phase induction motor
Product Specifications
Energy efciency
is low at high
rated power
consumption(W).
Outward
Dimension
Manufacture :
Hurom webpage : www.hurom.com
RPM
Smart Hopper
Dual Hopper
