Philips CTS660BLK/00 Mobile Phone User Manual

Discover Your Phone

Philips continuously strives to improve its products.

Therefore, Philips reserves the rights to revise this user

guide or withdraw it at any time without prior notice.

Philips provides this user guide “as is” and does not

accept, except as required by applicable law, liability for

any error, omission or discrepancy between this user

guide and the product described. The device is meant to

be connected to GSM/GPRS networks.

How to...

Back of the phone:

camera lens

Navigation keys

Left softkey

Pick up key

Microphone

Headset jack

65,000 colour

main screen

OK key

Camera key

Hang up and

on/off key

Alphanumeric

keypad

Charger connector

Side volume keys

Right softkey

Switch the phone

On/Off

Long press .

Store Numbers

in Phonebook

Enter the phone number and

press to save.

Make a call

Enter the phone number on the

keypad and press to dial.

Access the

Call logs

Press in idle mode. The

Call

logs

displays the

Missed Calls

Dialed Calls

and

Received Calls

Make a IP call

Enter the phone number on the

keypad and long press to dial

with IP prefix.

Answer a call

Press when your phone rings.

End a call

Press .

Reject a call

Press when your phone rings.

Adjust the

earpiece volume

Press the up or down volume

keys during the call.

Adjust ringtone

volume

Press the up or down volume

keys in idle mode.

Softkeys

The left and right soft keys and located at the

top of the keypad allow you to select the

corresponding options that appear on the screen

immediately above them, including during calls. The

functions associated with these keys will vary

according to the current content.

Main Menu

The

Main Menu

gives you access to all the different

features of your mobile phone presented in the form

of a grid. The table above summarises the arrangement

of the

Main Menu

Press to access the

Main Menu

when in idle mode,

then use the navigation key - which directions are

represented in the present guide with the

signs-to browse the icons and lists. Within lists, press

to access the options related to the selected item,

press

Back

to go back one level.

Access the

Phone Book

list

Press in idle mode.

Access the

Main Menu

Press

in idle mode.

Switch to silent mode

Long press key in idle

mode.

Turn on the camera

Press in idle mode.

Take photos

Press or with the

camera active.

Access WAP

Long press in idle mode.

Access

Shortcuts

Press

in idle mode.

Open

Audio Player

Press

in idle mode.

Access

Write Message

Press

in idle mode.

Access

Tone Setup

Press

in idle mode.

Access

Multimedia

Long press in idle mode.

Go to previous menu

Press .

Quickly return to idle

Press .

Phone Book Messages Call History

Settings Multimedia File Manager

Fun & Games User Profiles Organizer

Services Extra Shortcuts

Table of contents

1. Getting Started ........................................... 4

Insert the SIM card and Battery .................... 4

Switch on the phone ....................................... 5

Charge the battery .......................................... 5

Shortcuts function ........................................... 5

2. Calling ............................................................... 6

Make a call ......................................................... 6

Answer and end a call ..................................... 6

Call handsfree ................................................... 6

Options during a call ....................................... 6

Adjust the earpiece volume ........................... 7

Quickcall ............................................................ 7

Make an emergency call .................................. 7

Handle multiple calls ....................................... 7

3. Text or number Entry ........................... 9

Function keys ................................................... 9

Multitap ABC/abc input .................................. 9

Smart ABC/abc input .................................... 10

Numeric input ................................................. 10

4. Phone Book ................................................ 11

Search for a contact in phonebook ........... 11

Manage contacts ............................................. 11

Store a phone number with a name ......... 11

Copy the phone book ................................. 11

Copy or move a phonebook entry .......... 12

Delete contacts .............................................. 12

Caller Group ................................................... 12

Extra Number ................................................. 13

Settings ............................................................. 13

5. Messages ....................................................... 14

SMS .................................................................... 14

MMS .................................................................. 17

Chat .................................................................. 20

Broadcast Message ........................................ 20

6. Call History ................................................ 21

Missed Calls ..................................................... 21

Dialed Calls ..................................................... 21

Received Calls ................................................ 21

Delete Call Log .............................................. 21

Call Time ......................................................... 21

Call Cost .......................................................... 22

SMS Counter .................................................. 22

GPRS Counter ................................................ 22

7. Settings .......................................................... 23

Phone Setup .................................................... 23

Call Setup ......................................................... 25

Network Setup ............................................... 26

Security Setup ................................................. 27

Restore Factory Settings .............................. 29

8. Multimedia ................................................... 30

Camera ............................................................. 30

ImageViewer .................................................... 31

Video Recorder .............................................. 31

Video Player .................................................... 32

Audio Player .................................................... 32

Sound Recorder ............................................. 33

Melody Composer ......................................... 34

9. File Manager ............................................... 35

10. Fun & Games .......................................... 36

Games ............................................................... 36

Themes ............................................................. 36

Game Setting ................................................... 36

11. User Profiles ........................................... 37

12. Organizer .................................................. 38

Calendar ........................................................... 38

To Do List ....................................................... 38

Alarm ................................................................ 39

World Clock ................................................... 39

13. Services ...................................................... 40

STK ................................................................... 40

WAP ................................................................. 40

Data Account ................................................. 41

14. Extra ............................................................. 42

Calculator ........................................................ 42

Units Converter ............................................. 42

Currency Converter ..................................... 42

Health ............................................................... 42

15. Shortcuts ................................................... 43

Change items in Shortcuts .......................... 43

Icons & symbols ............................................ 44

Precautions ....................................................... 45

Troubleshooting ........................................... 49

Philips Authentic Accessories .............. 51

Specific Absorption Rate

Information

....................................................... 52

Limited warranty .......................................... 53

4 Getting Started

1. Getting Started

Please read the safety instructions in the “Precautions”

section before use.

To use your phone, you must insert a valid SIM card

supplied by a GSM operator or retailer. The SIM card

contains your subscription information, your mobile

telephone number, and a memory in which you can

store phone numbers and messages (for more

information, see “Phone Book”).

Insert the SIM card and Battery

Follow the steps below to insert your new SIM card.

Remember to switch off your mobile phone before

removing the back cover.

Remove the battery

To insert the SIM card, you must first remove the

battery. Press the button on the back and slide the

back cover downwards to remove it.

Hold the latch to lift up the battery.

Insert the SIM card

Place the SIM card in the space provided, making sure

that the clipped corner of the card is in correct corner

and that the gold contacts are facing downwards.

Place the battery back to its slot, with the gold

contacts facing downwards until it snaps into place.

Getting Started 5

Replace the back cover by sliding down into its slots

until it stops.

Switch on the phone

To switch on the phone, long-press key. Enter the

PIN code if required. A PIN code is a 4- to 8-digit

secret code for your SIM card. It is preconfigured and

communicated to you by your operator or retailer. For

more information on PIN codes, see “Security Setup”

on page 27.

If you enter an incorrect PIN code three times, your

SIM card will be locked. To unlock it, you must

request the PUK code from your operator.

Charge the battery

Your phone is powered by a rechargeable battery. A

new battery is partially charged and a sound alert will

warn you when the battery reaches low.

Once the battery is back in place you can charge the

phone. Plug in the connector as shown below. Then

plug the other end into a main AC power socket.

The battery symbol indicates the state of charge.

During charging, the charge indicators will scroll.

When all the scroll bars are steady, the battery is fully

charged. You can then disconnect the charger.

Keeping the charger plugged to the mobile when the

battery is fully charged will not damage the battery.

The only way to turn off the charger is to unplug it,

so use an easily accessible AC power socket.

Shortcuts function

Your phone provides ten fast ingoing function items.

You can modify them according to demands. For

more info see “Shortcuts” on page 43.

6 Calling

2. Calling

Make a call

From the idle screen

1. In idle mode, enter the phone number using the

keypad. To correct an error, press .

2. Press to dial.

3. Press to hang up.

For an international call, shortly press twice to

enter the “+” sign for the international prefix.

Using the phonebook

1. Press in idle mode.

2. Select a contact in the list and press , the

selected number is dialled. To select a different

number, press

(see “Phone Book” for more

information).

3. Press to hang up.

Answer and end a call

When receiving a call, the number of the caller may be

displayed, depending on whether or not the person

calling has chosed to display his or her ID. If the number

is stored in the selected phonebook, then the

corresponding name is displayed instead of the number.

•

Answer the call

: press .

•

Reject the call

: press (or long press the down

volume key). If you have activated

Call Divert

, the

call is diverted to a number or voice mail.

•

Hang up

: press .

The phone will not ring if in silent mode.

If you have selected

Any Key

, you can accept a call by

pressing any key except and .

Call handsfree

For your own comfort and safety, ensure you move the

phone away from your ear when calling handsfree,

especially when increasing the volume.

Press

H-Free

during a call to activate handsfree. To

cancel handsfree you can press

H-Held

again to

deactivate it.

Options during a call

During a call, press

Option

to access the following

options.

Calling 7

Mute (On/Off)

This option allows you to mute or unmute the

microphone so that your caller cannot hear you.

Sound Recorder

In most countries, recording telephone conversation is

subject to legislation. We advise you to notify the caller

if you intend to record your conversation and only do

so if they agree.

To record a conversation during a call, select

Sound

Recorder

and press . While recording you can press

Pause

Cont

. To stop recording, press , enter the

name and press to save.

Other options during a call

Press

Option

to be able to perform the following

tasks while a call is ongoing:

Access

Phone Book

to search entry, select

End

to hang

up, send or read messages.

Adjust the earpiece volume

During a call, press the up or down volume key to

increase or decrease the volume.

Quickcall

Quickcall of SIM phonebook

If you have the serial number (for example: 5) of the

contact you want to dial in SIM, you can enter 5# in

idle mode. The phone will show the corresponding

name stored in SIM, press to call the number.

Quickcall of call logs

In idle mode, press to access

Call Logs

list. Select a

number and press to dial the number.

Make an emergency call

Without SIM card

Switch on your phone, the screen shows the

information to remind you to insert SIM, press

SOS

to dial emergency call.

With SIM card

In idle mode, enter 112, then press to dial.

Handle multiple calls

The ability to handle two or more calls at one time

and to make conference calls is dependent on your

operator and/or subscription.

8 Calling

Make a second call

You can make a second call during an active call or

with a call on hold. While on the phone, dial a

number (or select a contact in the phonebook) and

press . The first call is put on hold and the second

number is dialled. You can then press to access the

following options.

•

Swap

to toggle between calls.

•

Conference

to introduce the caller into a conference

call.

Answer a second call

When you receive a second call while being already in

communication, the phone emits a beep alert and the

screen displays the info of the call. You can then:

To receive a second call, you must have deactivated the

Call Divert

and activated

Call Waiting

Press To answer the call (the first one

is put on hold).

Press or To reject the call.

Press

Option

To open the options list. You can

select

End

to end the current call,

then answer the incoming call.

Text or number Entry 9

3. Text or number Entry

You can select the input methods to enter English

letters, words, symbols and numbers. Icons appearing

on the screen indicated the active text mode.

Function keys

Multitap ABC/abc input

To select multitap input method, press until

“ABC” or “abc” appear on the screen. This method

requires multiple key presses to reach the desired

character: the letter “h” is the second letter on the key

4, so you must press it twice to enter “h”. If the

letter you enter and the one you just enter are on the

same key, just wait for a few seconds for the cursor to

appear.

You can press key

to insert a space in multitap

ABC/abc input.

Example: how to enter the word “home”:

Press key 4, 4 (

) 6, 6, 6 (

O), 6

), 3, 3 (

Letters, numbers and symbols are located on each key

as shown in the table below:

To delete the characters or end the editing

mode.

To move the cursor, select letter, monogram,

word or symbol from the list, scroll down the

list.

To return to idle mode.

To select the outstanding word from the list

or enter option menu.

To enter symbols.

To select input method.

Key Characters in the order displayed

. , - ? ! ， @ : # $ / _ 1

a b c 2

d e f 3

g h i 4

j k l 5

m n o 6

p q r s 7

t u v 8

w x y z 9

10 Text or number Entry

Smart ABC/abc input

This is an intelligent editing mode for messages

including a comprehensive dictionary. It allows you to

enter text more quickly. To select Smart input

method, press until “eZi ABC” or “eZi abc”

appear on the screen. Press only once on the key

corresponding to each letter needed to spell a word:

keystrokes input are analyzed and the word suggested

is displayed. If several words are available according to

the keys used, you can press

to choose from

those proposed by the Smart ABC/abc built-in

dictionary (see example below).

Example: how to enter the word “home”:

1. Press key 4, 6, 6, 3 in turn.

The screen displays word:

good

2. Press

to scroll to and select

home

3. Press to confirm the word

home

Numeric input

With this method you can press the corresponding

keys to enter numbers.

Phone Book 11

4. Phone Book

Contacts are stored in one of the two available

phonebooks: in your SIM card (number of entries

depending on capacity) or in your phone (up to 200

names). When entering new names, they will only be

added to the phonebook you have selected.

Search for a contact in phonebook

Search Entry option

1. Access

Phone Book

in idle mode, select

Entry

2. Enter a name, then press

Option

, press .

Phone Book List

Press in idle mode to access phone book list, press

the key for the letter that you want to go to in the list

(e.g. press

9 key three times to access the letter Y).

The first record starting with this letter is selected in

the list.

Manage contacts

Select a name in phone book list and press

Option

to access the following options.

IP Dial Send SMS

View Edit

Delete Copy

Move Duplicate

Store a phone number with a name

1. Access

Phone Book

in idle mode, then select

Add

New Entry

. Select the storage and press .

2. If you select

To SIM

, you need to enter

Name

and

Number

. After you finish entering, press and

enter the number, then press .

3. If you select

To Phone

, the operating steps is the

same as above. You can enter

Name

Number

Home

Number

Company Name

Email Address

Office

Number

Fax Number

and select

Associate Picture

Associate Sound

and

Caller Group

. Press to

confirm. Your phone will inform you that the

name has been saved.

Copy the phone book

You can copy all contacts in phone to SIM card and

vice versa.

1. Access

Phone Book

in idle mode, select

Copy All

then press .

2. Select

From SIM

From

Phone

, press .

12 Phone Book

3. The suggestive message displays on the screen.

Select

Yes

to confirm/cancel the operation.

Copy or move a phonebook entry

1. Select a contact in

Phone Book List

, press

Option

2. Select

Copy

Move

Duplicate

, then press .

Delete contacts

Delete contacts one by one

Method A:

1. Access

Phone Book

in idle mode, select

Delete All

2. Select

One By One

, then select the contacts you

want to delete in phone book list and press .

Method B:

1. Access

Phone Book List

in idle mode.

2. Select the entry you want to delete and press ,

then select

Delete

and press .

Delete all

1. Access

Phone Book

in idle mode.

2. Select

Delete All

. You need to select

From SIM

From Phone

Caller Group

This option allows you to group the contacts in

phonebook in order to be convenient for users.

1. Access

Phone Book

in idle mode, select

Caller Group

2. Select a group and press .

3. Select the corresponding option to modify.

You can set the following options:

Copy

To copy the contact to another memory.

Move

To move the contact to another memory.

Duplicate

To copy the contact to the same memory.

Ring type

To set ring tone for the call from the

contacts in the group.

Alert type

To set alert type for the call from the

contacts in the group.


To set the picture displaying on the

screen when a call is coming from

the contacts in the group.

Group name

To set the name of the group.

Member List

To add or delete members of the

group.

Phone Book 13

Extra Number

Owner Number

The

Owner Number

item allows you to store your own

phone number. We advise that you enter your mobile

number as well as any other relevant information.

Although all its fields can be empty, the

Owner Number

item can not be deleted.

Service Dial Number

This is a kind of service supplied by network provider.

For corresponding function, please ask network

provider.

SOS Number

The SOS number will call the emergency services

number in your country. In most cases, you can call

this number even if you have not yet inserted a SIM

card or entered your PIN.

In Europe the standard emergency number is 112, in

the UK it is 999.

Settings

Memory Status

Select this menu to display the total number of

contacts you have saved in each phonebook, out of the

total number available.

Preferred Storage

Select this menu to set default storage to save contacts.

Fields

Select this menu to set the items displayed in phone

memory.

14 Messages

5. Messages

SMS

This menu allows you to send text messages using the

Short Messaging Service (SMS) and to manage the

messages you send and receive.

Write Message

To compose and send an SMS, follow the steps

detailed below:

1. Select

Write Message

, enter your text and press

to access the next options:

2. Select

Done

, then press to access the next

options:

3. Enter Number: press , enter a number or select

a contact and press .

When you send message via SMS network, your phone

possibly shows “Sent”. It shows that the message has

been sent to SMS center, which you have set in SIM

card, but it does not show that the message has been

sent to destination.

Inbox

This menu allows you to read SMS messages you have

received. The messages are displayed in a list. When a

message is displayed, press to read it, then press

Option

to access the menu options listed below.

Done

To finish the message.

Use Template

To select a pre-configured message.

Insert Object

To add picture, animation, melody

and sound to your message.

Format Text

To set

Text Style

Alignment

and the

alignment of

New Paragraph

Input Method

To select input method.

Send Only

To send the message.

Save and Send

To save the message to outbox and

then send the message.

Save

To save the message to outbox.

Send To Many

To send the message to many

persons.

Send By Group

To send the message to all contacts

in a caller group.

To reply to the sender.

Forward

To forward the selected message.

Chat

To chat with the sender.

Edit

To edit, modify and resend the SMS

to someone.

Messages 15

Outbox

Only when you send the message by selecting

Save and

Send

Save

can the message be stored in outbox.

When a message is displayed, press to read it, then

press

Option

to access the menu options listed below.

Delete

To delete the selected message.

Delete All

To delete all messages in inbox.

Use Number

To extract the number of the sender

or displayed in the message, save the

number in SIM card or phone, dial

the number.

Save Objects

To store multimedia items such as

images in the message into your

phone.

SMS Copy to

Phone/ SIM

To copy the selected message stored

in SIM/phone to phone/SIM.

SMS Move to

Phone/ SIM

To move the selected message stored

in SIM/phone to phone/SIM.

SMS Copy All

To copy all messages stored in SIM/

phone to phone/SIM.

SMS Move All

To move all messages stored in

SIM/phone to phone/SIM.

Send

To send the selected message.

Edit

To send directly or re-edit then send

to other.

Delete

To delete the selected message.

Delete All

Delete all messages in outbox.

Use Number

To extract the number of the

recipient or displayed in the message,

save the number in SIM card or

phone, dial the number.

SMS Copy to

Phone/SIM

To copy the selected message stored

in SIM/phone to phone/SIM.

SMS Move to

Phone/SIM

To move the selected message stored

in SIM/phone to phone/SIM.

SMS Copy All

To copy all messages stored in SIM/

phone to phone/SIM.

SMS Move All

To move all messages stored in SIM/

phone to phone/SIM.

16 Messages

Template

This menu allows you to predefine up to ten messages

that you use most frequently. Select a message and

press to access the next optons.

Message Settings

This menu allows you to configure the SMS settings.

The options are:

Profile Setting

Common Setting

Memory Status

This option is used to display the storage status of the

messages saved in SIM card and phone.

Preferred Storage

This option allows you to select preferred storage to

save the received messages.

Edit

To write a new message or edit the

selected predefined message.

Erase

To delete the selected predefined

message.

SC Address

To select your default SMS centre.

If not available on your SIM card, you

must enter your SMS centre number.

Valid Period

To select the length of time your

messages are to be stored in the SMS

centre. This is useful when the

recipient is not connected to the

network (and thus cannot receive

your message immediately).

This

feature is subscription dependent.

Message Type

To select the type of the message.

This option is network dependent.

Profile Name

To edit the name of the profile.

Delivery

Report

When

, this option will inform

you via SMS whether your own

SMS was received or not.

This

feature is subscription dependent.

Reply Path

When

, this option allows you to

transmit the number of your SMS

message centre together with the

message. The recipient can then

reply using your own SMS centre

and not theirs. This speeds up the

rate of transmission.

This feature is

subscription dependent.

Messages 17

Pref. Bearer

This option allows you to set the preferred

transmission mode. For further detail, please contact

with network provider.

MMS

Your mobile phone can also send and receive MMS

(Multimedia Messaging Service) messages. With

MMS you can send messages that contain pictures,

sounds and text.

When sending MMS messages, your recipient must

also have an MMS-enabled phone in order to be able

to view your message.

Write Message

To compose and send an MMS, follow the steps

detailed below:

1. Select

Write Message

, enter the following message.

2. Press to finish editing and access the next

options.

To set number or E-mail of the

recipient.

To set number or E-mail of the

recipient to be sent the message at

the same time.

Bcc

To set number or E-mail of the

recipient to be sent the message in

secret.

Subject

To set the subject of the message.

Edit content

To edit the content of the message.

You can add text, image, sound and

attachment.

Send Only

To send the message.

Save and Send

To save the message to outbox and

then send the message.

Save to Drafts

To save the message to drafts for

sending later.

Send Options

To set the sending option.

Exit

To exit from editing mode. A

suggestive message will be displayed to

ask you whether to save the message.

18 Messages

Inbox

This menu allows you to read MMS messages you

have received. Select a message, then press to

access the following options.

Outbox

This menu is used to save all message by selecting

Save

and Send

. You can do the following operation:

Drafts

Lists all messages by selecting

Save to Drafts

. You can

do the following operation:

View

To view the message, you can press

to access option menu and can

select

Play

Save image As

Save audio As

to play or save the multimedia

items.

Properties

To view the sender, subject, date

and size.

To reply to the sender.

Reply to all

To reply to sender and all in To and

Cc columns.

Forward

To send the message to others.

Delete

To delete the message.

Delete All

To delete all messages in inbox.

Use Number

To extract the number in the

message.

View

To view the message.

Properties

To view the recipient, subject, date

and size.

Send to

Others/ Resend

To send the message to others. If the

message has not been sent successly,

it will show Resend.

Delete

To delete the message.

Delete All

To delete all messages in outbox.

Use Number

To extract the number in the

message.

View

To view the message.

Properties

To view the recipient, subject, date

and size.

Send

To send the message.

Edit message

To edit the message.

Messages 19

If you have not set the recipient for the message in

drafts, the

Send

option will not display in option

menu.

Templates

Lists five frequently used messages. You can use these

messages when writing a new message. Select a

message and press to access the following options.

Message Settings

This menu allows you to set MMS configuration for

sending or receiving messages.

Delete

To delete the message.

Delete All

To delete all messages in drafts.

Use Number

To extract the number in the

message.

View

To view the content of the

message.

Properties

To view sender, Cc, subject and

size.

Write Message

To take the template as a new

message. You can edit it.

Sending

To set

Validity period

Delivery report

Read report

Priority

Slide Timing

and

Delivery time

options for sending an

MMS.

Receiving

To set

Home network

Roaming

Read

Report

and

Delivery Report

options

for receiving an MMS.

Filters

To set

Anonymous

Max Size

and

options.

Edit Profile

To set the network configuration.

You can contact with network

provider.

Auto Signature

This option can be set

Off

and

allows you to automatically sign

your name or other content in your

message.

Memory Status

To view the storage status of MMS.

20 Messages

Chat

This menu allows you to chat with your contact by

SMS.

1. Select a chat room, then press .

2. Select

Chat Room Info

, enter

My Nickname

and

Destination Number

, then press .

3. Select

Start New

, enter the message and send it to

start chatting.

Voice Mail Server

This menu is used to set mail server number and listen

to voice mail. When you receive voice mail, your

provider will send a message to your phone.

You can set two groups of voice mail server number.

Network service provider supplies the number.

Select an item, then to access the following

options.

You can quickly access voice mail server by long

pressing

key in idle mode.

Broadcast Message

This is a kind of public messages broadcasted to a

group of mobile users. The message are broadcasted

on numbered channels. Generally speaking each

broadcast channel can transmit one kind message.

Please contact with the network provider, they will

supply usable channel and info list.

Receive Mode

This menu is used to set the function of broadcast

message. When

, you can receive the broadcast

message. When

Off

, you can not receive messages.

Read Message

To read broadcast message after activating receive

mode.

Languages

To set the language of the message that can be

received.

Channel Setting

Press to set channel, you can select

Select

Add

Edit

Delete

Edit

To edit voice mail server number.

Connect to Voice

To listen to voice mail.

Call History 21

6. Call History

This menu provides you with the list of outgoing and

incoming calls, attempts at auto redialling and call

details. The different types of calls (

Dialed Calls

Missed

Calls

and

Received Calls

) are represented by different

icons. They are displayed in chronological order with

the most recent on top. If the correspondent is listed

stored in your contacts, the corresponding name is

displayed.

Missed Calls

This menu allows you to view the lately unanswered

calls. You can view the date, time and times of each

missed calls.

Select an item and press to view date, time, times

and number. Press

Option

to access the following

options.

Dialed Calls

This menu allows you to view the lately dialed calls

including attempt or successful talk.

Received Calls

This menu allows you to view the calls received lately.

Delete Call Log

This menu allows you to delete

Missed Calls

Dialed

Calls

Received Calls

Delete All

Call Time

This menu allows you to view

Total Sent

Total Received

and

Last Call Time

(format: hour, minute, second). You

can use

Reset All Time

to reset all call time.

The actual time invoiced for calls and service by your

service provider may vary, depending on network

features, rounding-off for billing purpose, tax and so

forth.

Save to Phone book

Save the number.

Delete

Delete the number.

Dial

Dial the number.

Edit

Edit the number and can save it

to phonebook.

22 Call History

Call Cost

Last Call Cost

This menu is used to display the cost of last call.

Total Cost

To display the total cost of all calls since the cost

counter was last reset. If the total cost exceeds the

maximum cost set in

Max Cost

option, you will no

longer be able to make any calls until you reset the

counter.

Reset Cost

To reset the cost counter, you must enter your PIN2

code first.

Max Cost

To set maximum cost for your calls (need to enter

PIN2).

Price Per Unit

Allows you to set one unit for the cost, this price per

unit is used for calculating the cost of your calls (need

to enter PIN2).

SMS Counter

This menu is used to display the amount of messages

that have been sent and received.

GPRS Counter

This menu is used to count the amount of date sent

and received via GPRS. You can also reset the counter.

The unit is Byte.

Settings 23

7. Settings

This menu allows you to change the settings related to

each available option (time and date, security, call

divert, etc.) and to customise your phone.

Phone Setup

Time and Date

Allows you to set the time and date using the keypad

or with the navigation keys. You can set:

Schedule Power On/Off

This menu allows you to set the time to power on or

off your phone automatically. Select an item and press

to access the following options.

Language

This menu allows you to select a language for all menu

texts. Use

to browse the list and select a language

by pressing .

Preferred Input Methods

This menu allows you to set the default input method.

Display Characteristic

This menu allows you to set the options displayed in

idle mode.

Wallpaper

Set the background image of main screen displayed in

idle mode.

Screen Saver

Set the image displayed after being in idle mode for a

stated time.

Set Home City

Select the city you are in.

Set Time/Date

Enter the figure using keypad or

navigation keys.

Set Format

Include

Time Format

and

Date

Format

Status

You can select

Enable

(the setting is

valid) or

Disable

(the setting is

invalid).

Power On/Off

Select whether to power on or off.

Time

Enter the figure to set the time.

System

Select the predefined image.

User Define

Select the downloaded image.

Setting

Set

Status

(

Off

) and

Waiting

(set

the time for the appearance of the

screen saver image).

Select

Select the image for screen saver.

24 Settings

Power On Display

Allows you to set the image displayed when power on.

Power Off Display

Allows you to set the image displayed when power off.

Show Date and Time

Allows you to set whether to display date and time in

idle mode.

Show Owner Number

Allows you to set whether to display owner number in

idle mode.

Contrast

This menu allows you to adjust the contrast of main

screen.

You can press

to adjust contrast.

Sound Effect

Equalizer

This menu is used to set audio frequency in playing

music.

Greeting Text

This menu allows you to set individuation greeting

text and it is displayed when you switch your phone

on. You need to set the following option, then press

Done

Speed Dial

This menu allows you to rapidly dial the number

stored in phonebook. You can set up to eight speed

dial numbers and need to set

Enable Speed Dial

and

Set

Number

Dedicated key

In idle mode, you can quickly access preset functions

by pressing the navigation keys. This menu allows you

to modify the preset functions according to demands.

Auto update of date and time

This menu is used to update the time in your phone

automatically.

System

Select the predefined image.

User Define

Select the downloaded image.

System

Select the predefined image.

User Define

Select the downloaded image.

Status

Activate/Deactivate the display of

greeting text.

Greeting Text

Set the content of greeting text.

Settings 25

Call Setup

Call ID

With the support of the network you can select

Set By

Network

Hide ID

Send ID

to show or hide your

identity to your correspondent.

Call Waiting

This option is used to

Activate

Deactivate

call

waiting. When this option is active, you hear a beep if

someone tries to call you while already on a call. If this

option is inactive, your phone will not inform you and

the one tries to call you will hear the busy tone or the

call will be diverted to another phone (needs to set

Divert If Busy

). Select

Query Status

to find out the status

of this option.

Call Divert

To divert incoming calls to your mailbox or to a

number (whether in your contacts or not).

Select

Activate

and enter the number. Select

Query

Status

to find out the status of corresponding diverting

options.

Before activating this option, you must enter your

voice mailbox number. This feature is subscription

dependent.

Call Barring

Allows you to limit the use of your phone to specific

calls. This can be applied to

Outgoing Calls

(

All Calls

International Calls

International Except Home

) and/or to

Incoming Calls

(

All Calls

When Roaming

). In both cases,

the

Cancel All

option applies to all calls at once.

Change

Barring PW

is used to change the call barring password.

Query Status

allows you to know whether a type of call

is barred or not.

This feature is network dependent and requires a

specific call barring passowrd supplied by your service

provider.

Divert All

Voice Calls

Will divert all the incoming calls. If you

select this option, you will not receive

any calls until you deactivate it.

Divert If Busy

Divert when you are on a call.

Divert If No

Answer

Divert when you do not answer the

call.

Divert If

Unreachable

Divert when your phone is switched

off or out of service area.

Divert All

Data Calls

Divert all data call.

Cancel All

Divert

Cancel all divert options.

26 Settings

Line Switching

Some SIM card allow you use two subscriber numbers

(network service). This function is available only

when the SIM card supports it.

To switch line you can press to select a line.

Call Time Reminder

This menu allows you to set whether to beep

according to the call time. You can select

Off

(not

beep),

Single

(select from 1 to 3000 seconds as the

beeping time) or

Periodic

(select from 30 to 60 seconds

as periodic beeping time, your phone will beep in this

periodic time every minute).

Call Time Display

This menu is used to set whether to display the call

time during a call.

Auto Redial

If the call you make is not answered, your phone will

automatically redial this number at intervals. To end

redialing you can press or to cancel.

Closed User Group

This function is network dependent. Only after your

phone is set by network provider can you use this

option. It is mainly used to restrict your

correspondent. If this option is active, you can only

talk to users in the group.

IP Number

To set IP number in order to make IP calls. This

function is subscription and network dependent.

Contact your operator for configuration parameters.

Black List

This menu allows you to reject the incoming calls in

your black list.

Network Setup

Network Selection

This menu allows you to select the service network

(suggest you to select

Automatic

Mode

Allows you to set this option

Off

If you select

, your phone will refuse

all calls from the persons in black list.

Black List

Number

Set the numbers to be refused.

Automatic

You phone will automatically select

and register an usable network.

Manual

Provides you with a list of the network

available in the area. Select the network

you want to register with and press

to confirm.

Settings 27

You can select a network other than your home

network only if it has a valid roaming agreement with

your home network. If you change the network, some

problems may arise during the operation of your

phone.

Preferred Networks

Allows you to build a network list in order of

preference. Once defined, the phone will try to register

on the network, according to your preferences.

Band Selection

This menu is used to select the band of network for

call.

GPRS Connection

This menu is used to set the connection mode. You

can select

Always

When Needed

Security Setup

SIM Lock

When the SIM Lock is active, you must enter the PIN

code (PIN code is supplied by the provider with the

SIM card). If the code you enter is incorrect for three

times, you need to enter PUK code (PIN unlocking

code). The PUK code is used to unlock or change the

locked PIN code. If the PUK code is not offered or

lost, you can contact with the network provider.

Enter PIN code, then press . If the status of

SIM

Lock

Off

, then its status will be

, otherwise the

status will be

Off

Phone Lock

This menu is used to set password for your phone and

the default status is

Off

. Once you set

Phone Lock

, you

must enter password each time you switch on your

phone.

Enter the password, then press . If the status of

Phone Lock

Off

, then its status will be

, otherwise

the status will be

Off

Auto Keypad Lock

This menu is used to lock your keypad automatically.

Select the interval of locking the keypad, then press

to confirm.

To unlock the keypad you can press

Unlock

in idle

mode. Press when the screen shows “

Press to

Unlock Keypad

”.

Fixed Dial

This menu is used to restrict the outgoing calls. You

need to enter PIN2 code. The network provider

supplies PIN2 code.

28 Settings

Not all SIM cards have a PIN2. If your SIM card has

not, this option is not usable.

Barred Dial

This menu allows you to restrict different outgoing

calls.

With the support of your SIM card, you can activate

or deactivate this function.

Change Password

This menu is used to change

code,

PIN2

code and

Phone Lock Password

It is supplied with the SIM card. The service provider

supplies the default value.

If you enter an incorrect PIN code three times in

succession, the PIN code of SIM will lock

automatically and you will be asked to enter PUK code

to unlock. You can get the code from the service

provider. If you enter an incorrect PUK code ten times

in succession, the SIM card will be locked forever.

PIN2

It is used to access some special network functions

such as charging or fixed dial etc. If you enter an

incorrect PIN2 code three times in succession, the

PIN2 code of SIM will be locked. To unlock PIN2

code you need to ask the service provider for PUK2

code. If you enter an incorrect PUK2 code ten times

in succession, the functions related to PIN2 code can

not be used anymore.

Phone Lock Password

It protects your phone against unauthorized use by

other people. The password is necessary when you

restore factory settings. The initial phone lock

password is 1122.

Mode

It has two modes:

(you can dial any

number) and

Off

(you can only dial the

numbers stored in

Fixed Dial List

To access the fixed dial list. You can

press

Add

, then enter the name and

phone number, press and enter

PIN2 code, then press .

Fixed Dial

List

To access the fixed dial list. You can

press

Add

, then enter the name and

phone number, press and enter

PIN2 code, then press .

Settings 29

Restore Factory Settings

This menu is used to reset your phone to its factory

configuration.

Enter the password, then press to confirm.

Once you enter the right password (the passowrd is the

same as Phone Lock Password, its default value is

1122), your phone will return to its factory

configuration.

30 Multimedia

8. Multimedia

Camera

Your phone features a built-in digital camera. You can

take pictures, store them in your phone or transfer

them to your PC via cable line, use them as wallpaper

or send them to your friends via MMS.

Activate the camera

Select

Camera

and press or press left side softkey in

idle mode to activate the camera.

When the camera is active, the preview screen is

displayed.

The table below details the operations of the various

keys in camera mode.

Take a picture

1. Frame your picture and press or to take the

picture.

2. Once the picture is taken, a view screen is

displayed. Press to save the picture, or press

to ignore the picture.

Option menu in Camera

This section describes in detail the

Option

menu in

Camera

Zoom in / out

Increase / decrease exposure

compensation

or Take a picture

Exit

Camera

mode and return to

home screen

Access the

Option

Return to previous screen

Set

White Balance

Effect Setting

Set

Delay Timer

Activate / deactivate

Cont Shot

Set

Image Quality

Set

Image Size

To ImageViewer

Access

ImageViewer

Set

White Balance

Shutter Sound

Camera Setting Exposure

and

Banding

Image Setting

Set

Image Size

and

Image Quality

Effect Setting

Set special effect for the picture.

Multimedia 31

ImageViewer

When you take a picture and save it, the file is stored

ImageViewer

folder. When you open the menu, your

photos are displayed as thumbnails. Use the

and

navigation keys to move through the list. Press

Option

to access the following options.

Video Recorder

This menu is used to record a video, and the format of

the video is AVI.

Activate the Video Recorder

Select

Video Recorder

and press to activate video

recorder.

The table below details the operations of the various

keys in video recording mode.

Add Frame

Add a frame to the picture. Some

frames are usable only to some

special size.

Cont Shot

Take many pictures continuously.

Delay Timer

Set delay time. When you press the

function key to take a picture, the

picture will be taken in the time

you set.

Restore Default

Reset the camera settings to their

default values.

View

Display the picture.

View Mode

Set browse style as

List Mode

Matrix Mode

Forward

Apply the picture to other options.

Rename

Rename the picture.

Delete

Delete the picture.

Delete All Files

Delete all pictures.

Sort

Allows you to sort all pictures

separately by name, type, time or

size.

Zoom in / out

Increase / decrease exposure

compensation

or Start / Stop recording

Exit video recording mode and

return to home screen

Access the

Option

32 Multimedia

Recording a video

Frame your picture and press or to start

recording. While recording you can press

Pause

Resume

. Press , or to stop recording and save

the video.

The option menu in Video Recorder

This section describes in detail the

Option

menu in

Video Recorder

Video Player

You can use this option to view the videos you record

or prestored in your phone.

Select a video, then press

Option

to access the

following options.

Audio Player

This menu allows you to play music. The music

stored in player folder can be automatically detected

and added to the play list. You can dial or answer a call

during the music and the player will pause.

Activate Audio Player

Press

in idle mode or select

Audio Player

The table below lists the operations of the various keys

in playing music.

Return to previous screen

Effect Setting

Set

White Balance

To Player

Access Video Player.

CamCoder

Setting

Set

White Balance

Frequency

and

Video Quality

Effect Setting

Set special effect for the video.

Restore

Default

Reset the recorder settings to their

default values.

Play

Play the video.

Rename

Rename the video.

Delete

Delete the video.

Delete All Files

Delete all videos.

Sort

Allows you to sort all videos

separately by name, type, time or

size.

Multimedia 33

Option menu in Audio Player

Add/Delete music

1. Switch off your phone.

2. Connect your phone with computer by USB

cable line. After the computer identify your

phone, you can copy the music to your phone or

delete music in your phone.

All music to play must be stored in root directory. This

is an appointed location and you are not allowed to

change.

Sound Recorder

This menu allows you to record sound. You can also

play, rename and delete the memo you record.

Select a memo then press or press directly to

access

Option

menu.

Play/Pause

Stop

Skip to the previous music

Skip to the next music

Volume keys Adjust the volume of the music

Exit

Audio Player

and return to home

screen

Access

Play

List

, press to access

Option

menu.

Return to previous screen

Play

Play the music.

Details

Display the info of the music.

Add To Rings

Set the music as ring tone.

Refresh List

Refresh the play list in Audio Player.

Settings

Include

List Auto Gen

Repeat

(Music

repeat mode in playing),

Shuffle

(Playing order),

Background Play

(Whether to continue playing when

you exit from audio player) and

Equalizer

Record

Press to start recording, press

Pause

Cont

. recording. To

finish recording, press

Stop

Enter the name then press .

Settings

Set the format of the memo.

Play

Play the memo.

Append

Append sound to the memo.

Rename

Rename the memo.

34 Multimedia

Melody Composer

This menu allows you to edit melody you like and set

it as ring tone.

If there is no melody, you can press

Add

to create a

melody and press to access

Option

menu during

composing. If you select a melody, you can press

to access

Option

menu.

The operations of keys in composing

Press the navigation keys to select the symbol of vibra

or back light then press

keys to turn the effect on

or off.

Option menu in composing

Option menu of a melody

Delete

Delete the memo.

Delete All

Delete all memos.

Forward

Apply the memo to other options.

Insert a rest.

1-7 Enter Do-Si.

8 Insert vibra effect.

9 Insert back light effect.

+ -

Change pitch of the note to high,

middle or low.

# Switch the status of the note to high,

normal or low.

* Change the tempo.

Play

Play the melody.

Play Speed

Select playing speed of the melody.

Select

Instrument

Select a musical instrument.

Save

Save the melody.

Help

Display help information.

Play

Play the melody.

Edit

Edit the melody.

Add

Create a new melody.

Rename

Rename the melody.

Delete

Delete the melody.

Delete All Files

Delete all melodies.

Forward

Apply the melody to other options.

Help

Display help information.

File Manager 35

9. File Manager

This menu allows you to manage the image, sound

recorder, ring tone and music in your phone.

Select

D disk

, Press

Option

to access the following

options.

The top right corner of the screen in file manager

shows the occupation info of the storage. If you select a

folder or file in file manager, the screen will show you

date and size info about it at the same corner.

Open

Allows you to open the folder. You

can select a file or folder to do the

following operation.

• Operations to file

Play

(for music file),

View

(for image

file),

Forward

Detail

Rename

Copy

Move

Delete

Delete All Files

and

Sort

• Operations to folder

Open

Create Folder

Rename

Delete

and

Sort

Create Folder

Create a new folder in the file folder.

Format

Format the folder. (Valid for root

directory only).

36 Fun & Games

10. Fun & Games

Games

Select a game, press . For detail about each game

you can refer to the direction on the screen.

Themes

This menu allows you to set the theme of screen color.

There are three kinds of themes for you to select.

Select a scheme, press

Option

to access the

following options.

No matter which options you set in

Update Period

Set Order

, you must select

Activate

after setting.

Game Setting

This menu allows you to turn audio and vibration

effect of the games on or off.

Select

Game Audio

Game Vibration

, press the

navigation keys to select

Off

, then press to

confirm.

Activate

Activate the selected theme.

Update Period

Set frequency of color updating.

Set Order

Set order of color updating.

User Profiles 37

11. User Profiles

This menu allows you to set the ring of the incoming

call, new message and so on. It also allows you to set

alert type, volume of the ring and answer mode and

backlight etc so that your phone can fit all kinds of

environments.

Select

General

Meeting

Outdoor

Indoor

Headset

, press

Option

to access the following options.

The

Auto

option in Answer Mode shows only in

Headset Mode.

The Headset mode needs not to be activated. As long

as you plug in the earphone, your phone will switch to

Headset mode automatically.

Activate

The mode you select is in operation.

C u s t o m i z e

Allow you to set the selected mode

including

Tone Setup

(Incoming Call,

Alarm, Power On, Power Off, Message

Tone and Keypad Tone),

Volume

(Ring

Tone and Key Tone),

Alert Type

(Ring,

Vibration Only, Vibra and Ring or

Vibra Then Ring),

Ring Type

(Single,

Repeat or Ascending),

Extra Tone

(Warning, Error, Camp on and

Connect),

Answer Mode

(Any Key) and

LCD Backlight

(5, 15, 30 or 45 Sec).

38 Organizer

12. Organizer

This menu contains features and options designed to

help you organised and informed while on the move.

Calendar

This menu allows you to view calendar, access or edit

To Do List

You can press navigation keys to view the calendar.

Select the date to view and press

Option

to access

the following options.

A date with a task is displayed with red color.

To Do List

This menu helps you to manage all kinds of things in

your work or life. You can set the content, detailed

time and alarm of

To Do List

If there is no task in your phone, it shows empty. You

can press

Add

to create a new task. After you edit

the task you can press

Done

If you select a task, you can press

Option

to access

the option menu.

Create a task

View Tasks

Allows you to set date, time, note

and alarm of the schedule. Press

to add new tasks, edit or view the

selected task. (For detail please refer

to “To Do List”).

Jump To Date

Allows you to view appointed date

quickly. Enter a date then press .

Date

Allows you to enter the date of the task.

Time

Allows you to enter the time of the task.

The time format you enter must be 24-

hour system.

Note

Allows you to enter the content of the

task. Press

Edit

, enter the content,

then press to save.

Alarm

Press the navigation keys to set the

status of alarm.

Repeat

Allows you to set frequency:

Once

Every

Day

Weekly

Monthly

Organizer 39

The option menu of a task

Alarm

Your mobile phone has a built-in alarm clock. You

can set up to three separate alarms.

To set an alarm, follow the steps below:

1. Select an alarm and press

Edit

2. Set the status

3. Enter the time.

4. Select

Repeat

Once

Everyday

Days

After you finish the setting, press

Done

To use

Days

mode you can select the week line then set

the status of each day in the week one by one. You can

switch between

and

Off

by pressing the left softkey.

World Clock

This menu allows you to check the time in main cities

around the world.

Press the navigation keys to select cities, the local date

and time will show on the bottom of the screen.

View

View the settings of the selected task.

Add

Add a new task.

Edit Task

Edit the selected task.

Delete Task

Delete the selected task.

Delete All

Delete all tasks in To Do List.

40 Services

13. Services

This menu contains STK and WAP services.

STK

Function items of this menu are subscription

dependent and specific to operators. If the SIM card

you insert has STK function, the STK menu will

display on the screen.

WAP

This option allows you to access the network. Your

phone supplies you with some existent modes to

access network. You can browse the network after you

activate corresponding mode.

Homepage

You can store a homepage for each mode. When you

access WAP, the homepage of the mode will be visited

firstly.

Bookmarks

You can save the address in your phone as a

bookmark.

Select a bookmark, press

Option

to access the

following options.

Recent Pages

You can view the websites you visit recently.

Enter Address

You can enter an address to connect your phone to

network.

Service Inbox

The WAP messages you received are saved in

Service

Inbox

, the service operator will send the WAP messages

to your phone actively.

Settings

Edit Profile

This option is used to set properties of all WAP access

mode. Please contact with the network operator to get

the right setting.

Goto

Access the website of the selected

bookmark.

Edit

Edit the selected bookmark.

Delete

Delete the selected bookmark.

Delete all

Delete all bookmarks.

Add Bookmark

Enter

Title

and

Address

to create a

new bookmark.

Services 41

Select a mode in profile list, then press to access

the following options.

Browser Options

Service Message

This menu is used to set whether to receive service

message. The service message is saved in

Service Inbox

Clear Cache

The information and data you access is stored in cache

of your phone. This option is used to clear the

information in the cache.

Clear Cookies

This menu is used to clear cookies.

When you access the website, some info is saved.

Suggest you clear these sensitive info termly for fear

that personal data will be revealed once your phone is

lost.

Trusted Certificates

Some service needs trusted certificates such as bank

service. When you download the right certificate, you

can save or delete it. If you select save option, the

certificate will be added to trusted certificates.

Data Account

This menu is used to set the info of account, the

existent account is supplied by the manufacturer.

GSM Data

You can set:

Account Name

Number

User Name

Password

Line Type

Speed

and

DNS

GPRS

You can set:

Account Name

APN

User Name

Password

Auth. Type

Activate Profile

Activate the selected WAP access

mode.

Edit Profile

Edit the properties of WAP access

mode.

Timeout

Set waiting time of the browser. If

there is no response in the waiting

time, the browser will terminate the

connection with the website.

Show Images

Set whether to show images when

visiting the website.

42 Extra

14. Extra

This menu contains features and options designed for

your personal use.

Calculator

Your phone has a built-in calculator that you can use

to perform basic calculations. Numbers are entered

with the keypad and operators with the navigation

keys as indicated in the table below:

Units Converter

This menu allows you to use conversion function of

length and weight units.

Press # key to enter decimal point.

Currency Converter

This menu allows you to convert a sum from one

currency into another using the exchange rate of your

choice. You can convert from

Local

Foreign

or vice

versa. Enter a rate in the Rate field, press , select

Rate Representation

(The first line on the screen), enter

an amount in either the

Local

Foreign

fields and press

to get the conversion value.

Rate Representation

option allows you to select the

Rate

you enter is the ratio of

Local to Foreign

Foreign to

Local

You can enter decimal point by pressing # key.

Health

This menu supplies you with the reference of Body

Mass Index and females’ Menstrual.

BMI

Select

Sex

and then enter

Height

and

Weight

, press

to get the result.

Menstrual

The using method is the same as “BMI”. Enter the

corresponding data, then press to get the result.

Add or M+

Subtract or M-

Multiply or MC

Divide or MR

Clear number

Decimal point

or Operation result

Shortcuts 43

15. Shortcuts

This menu allows you to quickly enter ten items by

pressing

in idle mode. You can also modify the

default items according to the actual demand.

Change items in Shortcuts

Select an item you want to modify then press to

enter edit mode. Select the replacing item, then press

to confirm.

44 Icons & symbols

Icons & symbols

In idle mode, several symbols can be displayed

simultaneously on the main screen.

If the network symbol isn’t displayed, the network is

not currently available. You may be in a bad reception

area, moving to a different location may help.

Battery

- The bars indicate the battery

level(3 bars=full, 0 bar=low).

GSM Network

- your phone is connected to

a GSM network.

Reception quality-the more bars are shown

the better the reception is.

Keypad lock activated.

Alarm activated.

Ring

- The alert type is ring.

Vibration only

- The alert type is vibration

only.

Vibra and ring

- The alert type is vibra and

ring.

Vibra then ring

- The alert type is vibra then

ring.

Chat Room1 is in chatting state.

GPRS attach

- Your phone is connected to

the GPRS network.

Voice mail

- You have received a new voice

mail.

Call forward

- Your phone is in calls-forward

state.

Missed call

- You have a missed call.

SMS message

- You have received a new

message.

Line

- The current line.

MMS message

- You have received a new

MMS message.

Precautions

Radio Waves

Your cellular mobile phone is a low power

radio transmitter and receiver. When it is

operating, it sends and receives radio waves.

The radio waves carry your voice or data

signal to a base station that is connected to the

telephone network. The network controls the power

at which the phone transmits.

• Your phone transmits/receives radio waves in the

GSM frequency (900 / 1800 MHz).

• The GSM network controls transmission power

(0.01 to 2 watts).

• Your phone complies with all relevant safety

standards.

•The CE mark on your phone shows compliancy

with European electromagnetic compatibility (Ref.

89/336/EEC) and low voltage directives (Ref. 73/

23/EEC).

Your cellular mobile phone is your responsibility. To

avoid damage to yourself, to others or to the phone

itself, read and follow all the safety instructions and

make them known to anyone borrowing your phone.

Furthermore to prevent unauthorised use of your

phone:

Keep your phone in a safe place and keep it

out of small children's reach.

Avoid writing down your PIN code. Try to

remember it instead.

Switch off the phone and remove the battery if you are

going to leave it unused for a long time.

Change your PIN code after purchasing the phone

and to activate call restriction options.

The design of your phone complies with all

applicable laws and regulations. However

your phone may cause interference with

other electronic devices. Consequently you

should follow all local recommendations and

regulations when using your cellular phone both at

home and when away. Regulations on the use of

cellular phones in vehicles and aircraft are

particularly stringent.

Public concern has been focused for some time on the

possible health risks for users of cellular phones. The

current research on radio wave technology, including

the GSM technology, has been reviewed and safety

standards have been drawn up to ensure protection

from exposure to radio wave energy. Your cellular

telephone complies with all applicable safety standards

and the Radio Equipment and Telecommunications

Terminal Equipment Directive 1999/5/EC.

Always switch off your phone...

Inadequately protected or sensitive electronic

equipment may be affected by radio energy. This

interference can lead to accidents.

Before boarding an aircraft and/or when

packing the phone in your luggage: the use

of mobile phones in an aircraft may be

dangerous for the operation of the aircraft, disrupt the

mobile phones network and may be illegal.

In hospitals, clinics, other health care

centres and anywhere else where you may be

in the close vicinity of medic

al equ

ipment.

In areas with a potentially explosive

atmosphere (e.g. petrol stations and also

areas where the air contains dust particles,

such as metal powders).

In a vehicle transporting flammable products (even if

the vehicle is parked) or a vehicle powered by liquefied

petroleum gas (LPG), check first that the vehicle

complies with the applicable safety rules.

In areas where you are requested to turn off radio

transmitting devices, such as quarries or other areas

where blasting operations are in progress.

Check with the vehicle manufacturer that

electronic equipment used in your vehicle

will not be affected by radio energy.

Pacemakers

If you have a pacemaker:

• Always keep the phone more than 15 cm from your

pacemaker when the phone is switched on, in order

to avoid potential interference.

• Do not carry the phone in a breastpocket.

• Use the ear opposite to the pacemaker to minimise

the potential interference.

• Switch off your phone if you suspect that

interference is taking place.

Hearing aids

If you are a user of a hearing aid, consult your

physician and hearing aid manufacturer to learn

whether your particular device is susceptible to

cellular phone interference.

Improved performance

In order to improve the performance of your phone,

reduce radio energy emission, reduce battery

consumption and ensure safe operation adhere to the

following guidelines:

For the optimal and satisfactory operation of

the phone you are recommended to use the

phone in the normal operating position

(when not using in hands-free mode or with

a hands-free accessory).

• Do not expose your phone to extreme

temperatures.

• Treat the phone with care. Any misuse will void the

International Guarantee.

• Do not immerse the phone in any liquid; if your

phone is damp, switch it off, remove the battery

and let them dry for 24hrs before using them again.

• To clean the phone, wipe it with a soft cloth.

• Placing and receiving calls consumes the same

amount of battery energy. However, the mobile

consumes less energy in idle screen when kept in

the same place. When in idle screen and while you

are moving, your phone consumes energy to

transmit updated location information to the

network. Setting the backlight for a shorter period

of time as well as avoiding unnecessary navigating

in the menus will also help to save the battery’s

energy for longer phoning and stand-by

performances.

Battery information

• Your phone is powered by a rechargeable battery.

• Use specified charger only.

• Do not incinerate.

• Do not deform or open the battery.

• Do not allow metal objects (such as keys in your

pocket) to short circuit the battery contacts.

•Avoid exposure to excessive heat (>60°C or

140° F), moisture or caustic environments.

You should only use Philips authentic

battery and accessories, as the use of any

other accessories may damage your phone

and may be dangerous, and will make all

guarantees for your Philips phone null and

void. The use of an incorrect type of battery may also

cause an explosion.

Your mobile phone and your car

Studies have shown that speaking on the

telephone while driving lowers your

concentration, which can be dangerous.

Adhere to the following guidelines:

• Give your full attention to driving. Pull off the road

and park before using the phone.

• Respect the local regulations in countries where you

drive and use your GSM phone.

• If you want to use your phone in a vehicle, install

the hands-free car kit which is designed for that

purpose.

• Ensure that your phone and car kit do not block any

air bags or other security devices fitted in your car.

The use of an alarm system to operate a vehicle's light

or horn to indicate incoming phone calls is prohibited

on public roads in some countries. Check local

regulations.

EN 60950 Norm

In hot weather or after prolonged exposure to the sun

(e.g., behind a window or a windscreen), the temperature

of your phone's casing might increase, especially when

featuring a metallic finish. Be very careful in this case

when picking up your phone and also avoid using it with

an ambient temperature over 40° C.

Environmental care

Remember to observe the local regulations

regarding the disposal of the packaging

materials, exhausted batteries and old phone

and please promote their recycling.

Philips has marked the battery and packaging with

standard symbols designed to promote the recycling

and appropriate disposal of your eventual waste.

The battery should not be disposed of

with general household waste.

The labelled packaging material is

recyclable.

A financial contribution has been made

to the associated national packaging

recovery and recycling system.

The plastic material is recyclable (also

identifies the type of plastic).

Troubleshooting

The phone does not switch on

Remove/reinstall the battery. Then charge the phone

until the battery icon stops scrolling. Unplug from

charger and try to switch the mobile on.

Your phone doesn’t return to the idle

screen

Long press or switch off the phone, check that the

SIM card and the battery are installed correctly and

switch it on again.

The network symbol is not displayed

The network connection is lost. Either you are in a

radio shadow (in a tunnel or between tall buildings) or

you are outside the network coverage area. Try from

another place, try to reconnect to the network

(especially when abroad), check that the antenna is in

place if your mobile has an external antenna, or

contact your network operator for assistance/

information.

The display doesn’t respond (or the

display responds slowly) to key presses

The display responds more slowly at very low

temperatures. This is normal and does not affect the

operation of the phone. Take the phone to a warmer

place and try again. In other cases please contact your

phone supplier.

Your battery seems to over heat

You might be using a charger that was not intended

for your phone. Make sure you always use the Philips

authentic accessory shipped with your phone.

Your phone doesn’t display the phone

numbers of incoming calls

This feature is network and subscription dependent.

If the network doesn’t send the caller’s number, the

phone will display

Call 1

Withheld

instead. Contact

your operator for detailed information on this subject.

You can’t send text messages

Some networks don’t allow message exchanges with

other networks. First check that you entered the

number of your SMS centre, or contact your operator

for detailed information on this subject.

You have the feeling that you miss some

calls

Check your call divert options.

The display shows SIM failure

Check that the SIM card has been inserted in the right

position. If the problem remains, your SIM card may

be damaged. Contact your operator.

When attempting to use a feature in the

menu, the mobile displays NOT

ALLOWED

Some features are network dependent. They are only

available, therefore, if the network or your

subscription supports them. Contact your operator

for detailed information on this subject.

The display shows INSERT YOUR SIM

CARD

Check that the SIM card has been inserted in the right

position. If the problem remains, your SIM card

might be damaged. Contact your operator.

Your phone is not charging

If your battery is completely flat, it might take several

minutes of pre-charge (up to 5 minutes in some cases)

before the charging icon is displayed on the screen.

Philips Authentic

Accessories

Some accessories, such as a battery and a charger, are

included as standard in the package of your mobile

phone. Additional accessories may also be provided or

sold separately. Package contents may therefore vary.

To maximise the performance of your Philips mobile

phone and not to void the warranty, always purchase

Philips Authentic Accessories that are specially

designed for use with your phone. Philips Consumer

Electronics cannot be held liable for any damage due

to use with non authorised accessories.

Charger

Charges your battery in any AC outlet. Small enough

to carry in a briefcase/handbag.

USB cable

The USB cable enables high speed communication

between your phone and yout computer. You can

manage the information stored in your phone such as

image, animation, photo, video and music. You can

also use the cable to charge battery (This charging

mode is fit for most PC).

Headset

Your phone will activate headset mode automatically

when you plug in the earphone. And you can select

Auto option in answer mode. If this option’s status On,

your phone will automatically answer the incoming

call in 2 seconds.

USB driver CD

If the operating system of your computer is Windows

98, you can use this CD to drive your computer in

order to connect your phone with PC to copy, move

or delete images or music etc.

52 Specific Absorption Rate Information

Specific Absorption Rate Information

International standards

THIS MOBILE PHONE MEETS THE INTERNATIONAL RECOMMENDATIONS FOR EXPOSURE TO

RADIO WAVES

Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the limits for

exposure to radio frequency (RF) energy defined by the international standards. These recommendations have been

established by the International Commission on Non-Ionizing Radiation Protection (ICNIRP) and, the Institute

of Electrical and Electronics Engineers - Standards Associations (IEEE-SA) that forcast a substantial safety margin

for assuring the protection of all persons, regardless of age and health.

The exposure recommendations for mobile phones use a measurement unit known as the Specific Absorption Rate

(SAR). The SAR limit recommended by the ICNIRP for the mobile phones used by the general public is 2,0 W/

kg in 10g of tissue and, is 1,6W/kg in 1g of tissue by IEEE-SA (IEEE Std 1528) for the head.

Tests for SAR have been conducted using recommended operating positions with the mobile phone transmitting

at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest

certified power level, the actual SAR levels of the mobile phone while operating are generally below the maximum

SAR value. This is because the phone is designed to operate at multiple power levels so as to use only the power

required to reach the network. In general, the closer you are to a base station antenna, the lower the power output.

While there may be differences between the SAR levels of various phones and at various positions, they all meet

the international protection standards for exposure to radio waves.

The highest SAR value for this Philips S660 model phone when tested for compliance against the standard was

0,693W/kg for ICNIRP recommendation and 1,047W/kg for IEEE Standard.

For limiting the radio waves exposure, it is recommended to reduce the mobile phone call duration or to use a

headset. The purpose of those precautions is to take the mobile phone away from the head and the body.

Limited warranty

1. What Does This Limited Warranty Cover?

Philips warrants to the original retail purchaser

(“Consumer” or “You”) that this Philips cellular

product and all accessories originally provided by

Philips in the sales package (“Product”) are free

from defects in materials, design and

workmanship under normal use in accordance

with the operating instructions and pursuant to

the following terms and conditions. This limited

warranty extends only to the Consumer for

Products purchased and used in the original

country of purchase. The limited warranty is

valid only in Philips’ intended country of sales of

the product.

2. How Long is The Limited Warranty Period?

The limited warranty period for the Product

extends for ONE (1) YEAR from the date of

purchase of the Product, documented by valid

proof of purchase. The limited warranty for

original Philips rechargeable battery extends for

six (6) months from the date of purchase.

3. What Will Philips Do if The Product is Not Free

From Material Defects in Materials and

Workmanship During The Limited Warranty

Period?

During the limited warranty period, Philips or its

authorized service representative will, at its

option either repair or replace, without charge for

parts or labour, a materially defective Product

with new or refurbished parts or Product and

return such repaired or replaced Product to the

Consumer in working condition. Philips will

retain defective parts, modules or equipment.

Repaired or replaced Product will be covered by

this limited warranty for the balance of the

original limited warranty period or ninety (90)

days from the date of repair or replacement

whichever is longer. Repair or replacement of

Product, at Philips’ option is your exclusive

remedy.

4. What is Not Covered By This Limited Warranty?

This limited warranty does not cover:

a) Product that has been subjected to misuse,

accident, shipping or other physical damage,

improper installation, abnormal operation

handling, neglect, inundation, fire, water or

other liquid intrusion; or

b) Product that has been damaged due to

repair, alteration, or modification by anyone

not authorized by Philips; or

c) Product that has reception or operation

problems caused by signal conditions,

network reliability or cable or antenna

systems; or

d) Product defects or problems caused by uses

with non-Philips products or accessories; or

e) Product which warranty/quality stickers,

product serial number or electronic serial

number has been removed, altered or

rendered illegible; or

f) Product purchased, used, serviced, or

shipped for repair from outside the original

country of purchase, or used for commercial

or institutional purposes (including but not

limited to Products used for rental

purposes); or

g) Product returned without valid proof of

purchase or which proof of purchase has

been altered or is illegible.

h) Normal wear and tear or Force Majeure.

5. How Do You Get Warranty Service?

a) Return the Product to an authorized service

center of Philips. You may contact the local

Philips office for the location of the nearest

authorized service center.

b) The SIM card must be removed from the

Product before it is given to Philips. Philips

assumes no liability for damaged or loss of

the SIM card or the data contained therein.

c) If the Product failure is not covered by this

limited warranty, or this limited warranty is

inapplicable, void or invalid due to any

terms and conditions stated herein, the

Consumer will be charged for the cost of

repair or replacement of the Product and all

other related cost incurred in repairing or

replacing the Product.

d) IMPORTANT - you are required to return

the Product together with a valid proof of

purchase which must identify the point of

purchase, date of purchase, Product model

and Product serial number clearly.

6. Other Limitation: This Warranty is The Entire

Agreement.

EXCEPT FOR THE EXPRESS

WARRANTIES SET FORTH ABOVE AND

THOSE IMPLIED BY LAW AND WHICH

CANNOT BE EXCLUDED OR MODIFIED

BY AGREEMENT, PHILIPS PROVIDES NO

OTHER WARRANTY WHETHER EXPRESS

OR IMPLIED (WHETHER BY STATUTE,

UNDER THE OPERATION OF LAW OR

OTHERWISE) AND SPECIALLY DISCLAIMS

ANY WARRANTY OF SATISFACTORY

QUALITY MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE.

PHILIPS’ TOTAL LIABILITY FOR

DAMAGES RELATING TO OR ARISING

OUT OF THE PURCHASE OR USE OF THE

PRODUCT, REGARDLESS OF THE TYPE

OR CAUSE OF SUCH DAMAGE OR THE

FORM OR CHARACTERISATION OF THE

CLAIM ASSERTED (E.G. CONTRACT OR

TOPIT), SHALL NOT EXCEED THE

ORIGINAL PURCHASE PRICE PAID FOR

THE PRODUCT.

HOWEVER IN NO EVENT SHALL PHILIPS

BE LIABLE FOR ANY PUNITIVE, SPECIAL,

INCIDENTAL, INDIRECT OR

CONSEQUENTIAL DAMAGES (INCLUDING

BUT NOT LIMITED TO THE LOSS OF

USE, LOSS OF TIME, INCONVENIENCE,

COMMERIAL LOSS, LOST PROFITS, LOST

BUSINESS OPPORTUNITIES, COST OF

SUBSTITUTION OF GOODS OR

SERVICES, INVESTMENTS, DAMAGE TO

GOODWILL OR REPUTATION, OR LOSS

OF DATA AND CLAIMS BY THIRD

PARTIES) RESULTING FROM PURCHASE

OR USE OF THE PRODUCT, TO THE

FULLEST EXTENT ALLOWED BY LAW,

WHETHER OR NOT PHILIPS HAS BEEN

ADVISED OF THE POSSIBILTY OF SUCH

DAMAGES. THESE LIMITATIONS SHALL

APPLY NOTWITHSTANDING THE

FAILURE OF THE ESSENTIAL PURPOSE

OF ANY LIMITED REMEDY.

This limited warranty represents the complete

and exclusive agreement between the Consumer

and Philips with respect to this cellular Product

and it supercedes all prior agreements between

the parties, oral or written, and all other

communications between the parties relating to

the subject matter of this limited warranty. No

carrier, retailer, agent, dealer, employee, thereof,

or employee of Philips is authorized to make

modifications to this limited warranty and you

should not rely on any such representation.

This limited warranty does not affect the

Consumer’s statutory rights under applicable

national laws in force.

Declaration of

conformity

We,

Philips (China) Investment Co., Ltd.

BU Wireless China

21F, Tower 1 Kerry Euerbright City

218 Tian Mu Xi Road

Shanghai, P.R.C200010

declare under our sole responsibility that the product

Philips S660

GSM/GPRS Dualband Digital Mobile Phone

TAC: 352422 01

to which this declaration relates, is in conformity with

the following Standards:

Safety: EN 60950/2001

SAR: EN 50360:2001/EN 50361:2001

R&TTE: EN301-511 V9.0.2

EMC: EN301489-1 V1.5.1 and

EN301489-7 V1.2.1

We hereby declare that all essential radio test suites

have been carried out and that the above named

product is in conformity to all the essential

requirements of Directive 1999/5/EC.

The conformity assessment procedure referred to in

Article 10 and detailed in Annex III or IV of Directive

1999/5/EC has been followed with the involvement

of the following Notified Body:

BABT, Belfour House, Churchfield Road, Walton-

On-Thames, Surrey, KT12 2TD, UK

Identification mark: 0168

Aug 08th, 2006

Quality Manager

Philips CTS660BLK/00 Mobile Phone

Product's Documents

User Manual

Specifications

Philips CTS660BLK/00 Questions and Answers

Related Products

Philips M20B/00 Corded Phones Mobile

Philips M20B/00 Corded Phones Mobile

Panasonic KX-TU400EXR Clamshell Mobile Phone - Red

Panasonic KX-TU400EXG Clamshell Mobile Phone - Grey

Panasonic KX-TU400EXC Clamshell Mobile Phone - Green

Panasonic KX-TU110EXC Essential Easy Use Mobile Phone - Blue
