Home Theater Seating
ASSEMBLY & GENERAL USE GUIDE
2906-E
Rev. 4-18-2018
IMPERIAL
PAGE 1
What’s Inside the Box
Step 1: Attach the Backrest to the Seat Base
Step 2: Connect the Power Cable
Using the Power Control Panel
Troubleshooting Guide
Seat Part List
Warranty Info & Contact Information
2
3
4
5
6
7
8
Table of Contents
PAGE 2
1. BACKREST
3. RED BAG
2. SEAT
1. BACKREST
2. SEAT
3. RED BAG (Includes: Power Adapter & Power Adapter Cable)
What’s Inside the Box
PAGE 3
Slide the Backrest Female Brackets onto the Backrest Male Brackets.
Push until you hear a click on both sides. This will indicate that the backrest is secured.
STEP 1
Attach the Backrest to the Seat Base
PAGE 4
Power Adapter
Power Adapter
Cable
Plug the Power Adapter Cable into the Power Adapter. Connect the Power Adapter to the Power Recline
Cable. Lock the two cables together.
Connect the Power Cable
STEP 2
PAGE 5
Using the Power Control Panel
POWERED
RECLINE
2.
USB CHARGING
PORT
1.
USB CHARGING PORT
Plug in any USB-powered device to charge it.
1.
POWERED RECLINE
Push to set the powered recline to your preferred position.
2.
PAGE 6
Troubleshooting Guide
Why isn’t my chair reclining?
Q.
A.
The Power Adapter has become loose or disconnected.
21 3
Unplug and re-plug in the
Power Adapter to a wall
outlet.
The green light on the
Power Adapter should be
illuminated.
Unplug and re-plug in
the Power Adapter to the
Powered Recline Cable.
How do I remove the backrest from the seat base?
Q.
A.
Pull up on the locking tab on the
Backrest Female Bracket and firmly
pull the backrest upward.
The Backrest Female Bracket has a locking tab.
PAGE 7
Seatcraft Imperial with Power Recline
Double Arm Home Theater Seat
2906-3E
PRODUCTION DATE:
4/1/2016 - CURRENT
SOUNDSHAKER
81-1608
SOUNDSHAKER CORD
81-3031
Revised 4/19/2018
Recline Mechanism - Power PT-L&P 3368-4
Recliner Motor PT-L&P 3368
Backrest Only 2906-(Material)-BC01
LAF Armrest Only - Power 2906-(Material)-3EA01
RAF Armrest Only - Power 2906-(Material)-3EC01
Backrest
Left
Arm
Right
Arm
Seat
BACKREST BRACKET (FEMALE)
PT-LP-1412630001
POWER CONTROL PANEL
PT-MLSK5-DL
COPPER NAILHEAD
PT-1CM COPPERY NAIL
COPPER CUPHOLDER
PT-COPPERY METAL CUPHOLDER
PLASTIC GLIDES FOR MECHANISM
PT-F3-3
BACKREST BRACKET (FEMALE)
PT-LP-1412630001
POWER ADAPTER
PT-MLTR006
ADAPTER CABLE
PT-PS1300AM
Seatcraft Imperial with Power Recline
2906-E
PAGE 8
Warranty Information
Seatcraft is proud of its high standards of quality and workmanship that go into our products.
The customer is protected by the following Limited Warranty, which applies to seats under
normal indoor residential use. This warranty does not apply to seats used for commercial,
institutional, or other non-residential uses.
ONE YEAR LIMITED WARRANTY: Seatcraft provides (1) one year comprehensive coverage
for all components such as materials, foam and frame parts, and mechanisms including
motorized parts from defective materials or workmanship.
MATERIAL: Normal fabric fading, shrinking, or stretching is not covered by this warranty.
Similarly, the natural markings, stretching, and shrinking of leather is a proud mark of
authenticity and therefore not covered by this warranty. Evidence of improper cleaning, abuse,
or abnormal use of the materials will void this warranty.
FOAM AND FRAME PARTS: Seatcraft warrants these components for (1) one year from the
time of delivery, against manufacturing defects. Foam compression is natural, and therefore
not covered by this warranty.
MECHANISMS: Seatcraft warrants these components for (1) one year from the time of delivery,
against manufacturing defects. After the warranty period, the customer is responsible for
inspection, labor and transportation costs.
No warranties, express or implied, apply after the expiration of this Limited Warranty. The
warranty period covers repair, substitution, and replacement. No returns or refunds are
covered. A proof of purchase is required to service a claim; simply present the bill of sale to the
dealer from whom the item was purchased, to request warranty service. Seatcraft is not liable
for incidental or consequential damages occurring outside the terms of this warranty, even if
advance knowledge of such damages was possible.
Contact Information
We’re here to help. For any missing or damaged parts or installation assistance please call us
at 1-855-244-0170.
HOURS
Mon-Fri 6AM - 7PM PST
Sat 9AM - 5PM PST
Sun 10AM - 5PM PST
