GB
Quick Guide
THANK YOU FOR PURCHASING A HOTPOINT PRODUCT.
To receive more comprehensive assistance, register the
appliance on
www.hotpoint.eu/register
Before using the appliance carefully read the Health and Safety guide.
Before using the machine, it is imperative that the transport bolts are removed. For more
detailed instructions on how to remove them, see the Installation Guide.
CONTROL PANEL
WASH CYCLE TABLE
For all testing institutes:
2) Long cotton cycle: set programme 3 at temperature 40°C.
3) Long synthetics cycle: set cycle 4 at a temperature of 40°C.
* By selecting the 15 cycle and excluding the spin cycle, the washing machine will drain only.
** The duration of the wash cycles can be checked on the display.
*** If “Steam Hygiene” option is set, the duration of the wash cycles will increase.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as
the temperature and pressure of the incoming water, ambient temperature, amount of
detergent, load quantity and type, load balancing and any additional options selected.
1) Test wash cycle in compliance with regulation 1061/2010:
This cycle is designed for normally soiled cotton loads and is the most ecient in terms of
both electricity and water consumption; it should be used for garments washable at 60°C or
at 40°C. The actual washing temperature may dier from the indicated value.
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
1. ON/OFF button
2. CHILD LOCK button
3. EXTRA TOUCH button
4. EXTRA TOUCH indicator lights
5. START/PAUSE button and indicator light
6. OPTION button and indicator light
7. DELAY START button
8. SPIN button
9. TEMPERATURE button
10. WASH CYCLE SELECTOR KNOB
Maximum load 8 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Detergents and
Additives
Recommended
detergent
Residual
dampness %
Energy con-
sumption kWh
Total water l
Wash cycle
Temperature
Max.
spin speed
(rpm)
Max.
load
(kg)
Duration
(minutes)
Wash
Fabric
softener
Powder Liquid
Default Range
1 2
1
Mixed 40°C - 40°C 1600 8 **
–
– – –
2
Eco Cotton
(1)
60°C
60°C 1600 8 225
44 1,08 55
40°C 1600 8 220
44 1,03 92
3 Cotton (2) 40°C
- 60°C 1600 8 220
44 1,03 92
4 Synthetics (3) 40°C
- 60°C 1200 4,5 175
53 0,54 55
5 Delicates 40°C
- 40°C 1000 4,5 **
–
– – –
6 Wool 40°C
- 40°C 800 2 **
–
– – –
7 White 40°C
- 90°C 1600 8 **
– – – –
8 Duvet 30°C
- 30°C 1000 3,5 **
–
– – –
9 Rapid 30 min 30°C
- 30°C 800 4,5 **
–
– – –
10 Full Load 45 min 40°C
- 40°C 1200 8 **
–
– – –
11 Shirts 40°C
- 40°C 600 2 **
–
– – –
12 Baby 40°C
- 40°C 800 4 **
–
– – –
13 Anti Stain 40° 40°C
- 40°C 1600 8 **
–
– – –
14 Anti Allergy 60°C
- 60°C 1600 5 **
– – –
15
Spin & Drain * – – 1600 8 ** – – – – – – –
16
Rinse & Spin – – 1600 8 ** –
– – – – –
Required dosage Optional dosage
DETERGENT DISPENSER DRAWER
Compartment *:
Do not insert detergent in this compartment.
Compartment 1: Washing detergent (powder
or liquid)
If liquid detergent is used, the removable plastic
partition A (supplied) should be used for proper
dosage.
If powder detergent is used, place the partition
into slot B.
Compartment 2: Additives (fabric softeners, etc.)
The fabric softener must not exceed the “MAX” level.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
A
B
*
1
10
2
DISPLAY
4
5
6
7
8
9
3
