LG Electronics LRBCC1204S 12 Cu. Ft. Bottom Freezer Counter-depth Refrigerator

3 IMPORTANT SAFETY INSTRUCTIONS

7 Interior

9 Installation Overview

9 Unpacking the Refrigerator

10 Choosing the Proper Location

10 Installing the Rear Spacers

11 Dimensions and Clearances

12 Reversing Doors

18 Sabbath Mode

19 Freezer Icemaker

20 Fresh Converter

20 Fresh Vegetable Drawer

20 Storing Food

22 LG ThinQ Application

23 Cleaning

• To reduce the risk of injury to persons, adhere to all industry recommended safety procedures including

• Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has

• Only connect this product to a dedicated grounded electrical outlet rated for use with this product

There is a risk of suffocation.

• Do not install the refrigerator in a damp or dusty place where insulation on electrical parts may

• Do not place the refrigerator in direct sunlight or expose it to the heat from heating appliances such as

• Do not bend or pinch the power cord excessively or place heavy objects on it.

• This product is not to be used for special purposes such as the storage of medicine or test materials or

• DO NOT allow children to climb, stand, or hang on the refrigerator doors or on the shelves in the

• Do not refreeze frozen food that has thawed completely. Doing so may result in a serious health hazard.

• Do not use an adapter plug or plug the power plug into a multi-outlet extension cord.

• Do not use a cord that shows cracks or abrasion damage along its length or at either the plug or

• Do not operate the refrigerator or touch the power cord with wet hands.

• Do not modify or extend the power cord.

• Do not use an uncertified power outlet. Do not plug appliance into a damaged wall outlet.

• Do not put hands, feet or other objects into the air vents or bottom of the refrigerator. Doing so could

• Do not use any fuse (such as copper, steel wire, etc.) other than a standard fuse.

• Do not place or use an electrical appliance inside the refrigerator, unless it is of a type recommended by

• Do not put animals inside the appliance.

• Do not place heavy or fragile objects, liquid filled containers, combustible substances, or flammable

• If connected to a circuit protected by fuses, use time delay fuse.

• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

• Do not use mechanical devices or other means to accelerate the defrosting process, other than those

• Do not use a hair dryer to dry the inside of the refrigerator.

• Do not light a candle to remove odors in the refrigerator.

• In the event of a refrigerant leak, move flammable objects away from the refrigerator. Ensure the area is

• Keep flammable materials and vapors, such as gasoline, away from the refrigerator.

• This appliance can be used by children aged from 8 years and above and persons with reduced

• Do not store glass containers or soda in the freezer compartment. Contents may expand when frozen,

• Do not store, disassemble or repair the appliance yourself or allow unqualified personnel to do so.

• Do not use or place flammable substances (chemicals, medicine, cosmetics, etc) near the refrigerator

• Junked or abandoned refrigerators are dangerous, even if they are sitting for only a few days. When

• If disposing of a refrigerator, make sure the refrigerant is removed for proper disposal by a qualified

• Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight out

the refrigerator. Failure to do so can result in

back injury or other injury.

when moving the refrigerator for cleaning or

service. Always pull the refrigerator straight

out when moving it. Do not wiggle or walk the

• Remove tape and any temporary labels from

your refrigerator before using. Do not remove

any warning labels, the model and serial number

label, or the Tech Sheet that is located under the

front of the refrigerator.

• To remove any remaining tape or glue, rub

the area briskly with your thumb. Tape or glue

residue can also be easily removed by rubbing

a small amount of liquid dish soap over the

• Reinstall or adjust shelves as needed.

Refrigerator shelves are installed in the shipping

position. Reinstall shelves according to your

individual storage needs.

that contains alcohol, a flammable liquid or an abrasive when removing

any tape or adhesive from the refrigerator. Remove adhesive residue by

wiping it off with your thumb or dish detergent.

information on the rear surface of the refrigerator.

to spoil, or a bad odor to remain inside the refrigerator.

Depending on the model, some of the following functions may not be available.

The control panel may differ from model to model.

Indicates the set temperature of the freezer compartment in Fahrenheit (°F).

temperature from -7 °F to 5 °F.

Indicates the set temperature of the refrigerator compartment in Fahrenheit (°F).

new set temperature from 33 °F to 43 °F.

• The displayed temperature is the target temperature, and not the actual temperature of the

To avoid damaging vegetables, do not store them

This drawer helps to keep fruit and vegetables

fresh. You can control the amount of humidity by

sliding the lever at the front of the drawer.

For storing vegetables.

For storing fruit.

• If you are leaving home for a short period, like a

short vacation, the refrigerator should be left on.

Refrigerated foods that are able to be frozen will

stay preserved longer if stored in the freezer.

• If you are leaving the refrigerator turned off for

an extended period, remove all food and unplug

the power cord. Clean the interior, and leave the

doors open to prevent fungi from growing in the

refrigerator.

packaging should be wiped down to prevent

adjacent foods from being contaminated.

• If the refrigerator is kept in a hot and humid

place, frequent opening of the door or storing a

lot of vegetables in the refrigerator may cause

condensation to form. Wipe off the condensation

with a clean cloth or a paper towel.

• If the refrigerator doors are opened or closed too

often, warm air may penetrate the refrigerator

and raise its temperature. This can increase the

Wrap or store food in the refrigerator in airtight

Keep opened butter in covered

dish or closed compartment. When

storing an extra supply, wrap in

freezer packaging and freeze.

Store in original wrapping until

used. Once opened, rewrap tightly

in plastic wrap or aluminum foil.

milk, place containers on an

Do not wash or hull fruit until it

is ready to be used. Sort and

keep fruit in original container in

a crisper, or store in completely

closed paper bag on refrigerator

shelf.

Remove store wrapping, trim or

tear off bruised and discolored

Place in plastic bags or plastic

container and store in crisper.

Freeze fresh fish and shellfish

if they are not being eaten the

same day purchased. Eating fresh

fish and shellfish the same day

purchased is recommended.

or aluminum foil, or store in plastic

communicate with the appliance using a

smartphone.

for product improvement purposes without

notice to users.

Search for the LG ThinQ application from the

Google Play Store or Apple App Store on a smart

phone. Follow instructions to download and install

the application.

This feature is only available on models with the

or logo.

• To avoid injuries, empty the drawer before

Assemble the vegetable drawer in the reverse

order of the removal process.

Should your LG Refrigerator (“Product”) fail due to a defect in materials or workmanship under normal and

proper use, during the warranty period set forth below, LG Electronics (“LG”) will, at its option, repair or

replace the Product. This limited warranty is valid only to the original retail purchaser of the Product and

applies only when purchased and used within the United States including U.S. Territories.

than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by either: (i)

sending an e-mail to [email protected], with the subject line: “Arbitration Opt Out” or (ii) calling 1-800-980-

2973. You must include in the opt out e-mail or provide by telephone: (a) your name and address; (b) the

date on which the product was purchased; (c) the product model name or model number; and (d) the serial

number (the serial number can be found (i) on the product; or (ii) online by accessing https://www.lg.com/

us/support/repair-service/schedule-repair-continued and clicking on “Find My Model & Serial Number”).

You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail

or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure.

Opting out of this dispute resolution procedure will not affect the coverage of the Limited Warranty in any

way, and you will continue to enjoy the full benefits of the Limited Warranty. If you keep this product and do

Should your LG Refrigerator (“Product”) fail due to a defect in materials or workmanship under normal

and proper use, during the warranty period set forth below, LG Electronics Canada, Inc. (“LGECI”) will,

at its option, repair or replace the Product upon receipt of proof of the original retail purchase. This

limited warranty is valid only to the original retail purchaser of the Product and applies only to a Product

distributed, purchased and used within Canada, as determined at the sole discretion of LGECI.

parts only)

Parts and Labor

Part only (Consumer will be

TO OBTAIN WARRANTY SERVICE AND ADDITIONAL INFORMATION, PLEASE CALL OR VISIT OUR

WEBSITE:

Call 1-888-542-2623 (7 A.M. to 12 A.M., 365 days a year) and select the appropriate option from the

EXCEPT WHERE PROHIBITED AT LAW, ALL DISPUTES BETWEEN YOU AND LG ARISING OUT

OF OR RELATING IN ANY WAY TO THIS LIMITED WARRANTY OR THE PRODUCT SHALL BE

RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND NOT IN A COURT OF GENERAL

JURISDICTION. EXCEPT WHERE PROHIBITED AT LAW, YOU AND LG BOTH IRREVOCABLY AGREE

TO WAIVE THE RIGHT TO A JURY TRIAL AND TO BRING OR PARTICIPATE IN A CLASS ACTION.

LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LGECI Legal

Team at 20 Norelco Drive, North York, Ontario, Canada M9L 2X6 (the “Notice of Dispute”). You and LG

agree to engage in good faith discussions in an attempt to amicably resolve your claim. The notice must

provide your name, address, and telephone number; identify the product that is the subject of the claim;

and describe the nature of the claim and the relief being sought. If you and LG are unable to resolve the

dispute within 30 days of LG’s receipt of the Notice of Dispute, the dispute shall be resolved by binding

arbitration in accordance with the procedure set out herein. You and LG both agree that, during the

arbitration proceeding, the terms (including any amount) of any settlement offer made by either you or LG

will not be disclosed to the arbitrator until the arbitrator determines the dispute.

combined or consolidated with a dispute involving any other person’s or entity’s product or claim. More

specifically, without limitation of the foregoing, except to the extent such a prohibition is not permitted at

law, any dispute between you and LG shall not under any circumstances proceed as part of a class or

representative action. Instead of arbitration, either party may bring an individual action in small claims

court, but that small claims court action may not be brought on a class or representative basis except to

the extent this prohibition is not permitted at law in your province or territory of jurisdiction as it relates to

the claims at issue between you and LG.

demand for arbitration. The arbitration will be private and confidential, and conducted on a simplified

and expedited basis before a single arbitrator chosen by the parties under the provincial or territorial

for the court to decide. The arbitrator is bound by the terms of this provision.

and any disputes between you and LG except to the extent that such law is preempted by or inconsistent

with applicable federal or provincial/territorial law. Should arbitration not be permitted for any claim, action,

dispute or controversy between you and LG, you and LG attorn to the exclusive jurisdiction of the courts

of the province or territory of your purchase for the resolution of the claim, action, dispute or controversy

between you and LG.

location or agree to a telephonic arbitration.

is unenforceable, the remaining provisions will continue in full force and effect to the maximum extent

permitted by applicable law. Should LG fail to enforce strict performance of any provision of this Limited

Warranty (including these arbitration procedures), it does not mean that LG intends to waive or has waived

any provision or part of this Limited Warranty.

require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later

than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by either (i)

sending an e-mail to [email protected], with the subject line: “Arbitration Opt Out;” or (ii) calling 1-800-980-

2973. You must include in the opt out e-mail or provide by telephone: (a) your name and address; (b) the

date on which the product was purchased; (c) the product model name or model number; and (d) the serial
