525i
530i
545i
Owner's Manual for Vehicle
Congratulations, and thank you for choosing a BMW.
Thorough familiarity with your vehicle will provide you with
enhanced control and security when you drive it. We therefore
have this request:
Please take the time to read this Owner's Manual and familiarize
yourself with the information that we have compiled for you
before starting off in your new vehicle. It contains important data
and instructions intended to assist you in gaining maximum use
and satisfaction from your BMW's unique range of technical fea-
tures. The manual also contains information on maintenance
designed to enhance operating safety and contribute to main-
taining the value of your BMW throughout an extended service
life.
This Owner's Manual should be considered a permanent part of
this vehicle. It should stay with the vehicle when sold to provide
the next owner with important operating, safety and maintenance
information.
This manual is supplemented by a Service and Warranty Infor-
mation Booklet for US models or a Warranty and Service Guide
Booklet for Canadian models.
We wish you an enjoyable driving experience.
BMW AG
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
© 2004 Bayerische Motoren Werke
Aktiengesellschaft
Munich, Germany
Reprinting, including excerpts,
only with the written consent of
BMW AG, Munich.
Order No. 01 41 0 158 518
US-English VIII/04, 09 04 500
Printed in Germany
Printed on environmentally friendly paper,
bleached without chlorine, suitable for recycling.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference At a glanceControlsDriving tips
Communication NavigationEntertainmentMobility
Contents
The fastest way to find specific topics is to use
the index on page 202.
Using this Owner's Manual
4 Notes
Reporting safety defects 7
At a glance
10 Cockpit
16 Control Center
22 Voice command system
Controls
28 Opening and closing
38 Adjustments
47 Transporting children safely
51 Driving
65 Everything under control
76 Technology for comfort, convenience
and safety
87 Lamps
90 A congenial climate
96 Practical interior accessories
Driving tips
106 Things to remember when driving
Navigation
114 Starting navigation system
115 Destination entry
124 Destination guidance
128 What to do if …
Entertainment
132 On/off and tone
138 Radio
145 CD player and CD changer
Communications
152 Telephoning
161 TeleService, BMW Assist
Mobility
168 Refueling
170 Wheels and tires
176 Under the hood
180 Maintenance
182 Replacing components
189 Giving and receiving assistance
Reference
196 Technical data
199 Short commands of voice command
system
202 Everything from A to Z
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Notes
4
Notes
Using this Owner's Manual
We have made every effort to ensure that you
are able to find what you need in this Owner's
Manual as quickly as possible. The fastest way
to find specific topics is to refer to the detailed
index at the back of the manual. If you wish to
gain an initial overview of your vehicle, you will
find this in the first chapter.
Should you sell your BMW some day, please
remember to hand over the Owner's Manual as
well; it is an important component of your vehi-
cle.
Additional sources of information
Should you have any other questions, your
BMW center will be glad to advise you at any
time.
You can find information on BMW, e.g. technol-
ogy, on the Internet at www.bmwusa.com.
Symbols used
Indicates precautions that must be fol-
lowed precisely in order to avoid the pos-
sibility of personal injury and serious damage to
the vehicle.
Indicates information that will assist you
in gaining the optimum benefit from your
vehicle and enable you to care more effectively
for your vehicle.
Refers to measures that can be taken to
help protect the environment.
<Marks the end of a specific item of informa-
tion.
*
Indicates special equipment, country-spe-
cific equipment and optional extras, as well as
equipment and functions not yet available at the
time of printing.
"..." Identifies Control Display texts used to
select individual functions.
Symbols on vehicle components
Indicates that you should consult the rel-
evant section of this Owner's Manual for
information on a particular part or assembly.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
5
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainmentMobility
The individual vehicle
On purchasing your BMW, you have decided in
favor of a model with individualized equipment
and features. This Owner's Manual describes
the entire array of options and equipment avail-
able with a specific BMW model.
Please bear in mind that the manual may con-
tain information on accessories and equipment
that you have not specified for your own vehicle.
Sections describing options and special equip-
ment are marked by asterisks
*
to assist you in
identifying possible differences between the
descriptions in this manual and your own vehi-
cle's equipment.
If equipment in your BMW is not described in
this Owner's Manual, please refer to the accom-
panying Supplementary Owner's Manuals.
Editorial notice
BMW pursues a policy of continuous, ongoing
development that is conceived to ensure that
our vehicles continue to embody the highest
quality and safety standards combined with
advanced, state-of-the-art technology. For this
reason, it is possible that the features described
in this Owner's Manual could differ from those
on your vehicle.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Notes
6
For your own safety
Maintenance and repair
Advanced technology, e.g. the use of
modern materials and high-performance
electronics, requires specially adapted mainte-
nance and repair methods. Therefore, have cor-
responding work on your BMW carried out only
by a BMW center or a workshop that works
according to BMW repair procedures with cor-
respondingly trained personnel. If work is car-
ried out improperly there is a danger of conse-
quential damage and the related safety risks.<
California Proposition 65 Warning
California law requires us to issue the following
warning:
Engine exhaust and a wide variety of
automobile components and parts,
including components found in the interior fur-
nishings in a vehicle, contain or emit chemicals
known to the State of California to cause cancer
and birth defects and reproductive harm. In
addition, certain fluids contained in vehicles and
certain products of component wear contain or
emit chemicals known to the State of California
to cause cancer and birth defects or other
reproductive harm.
Battery posts, terminals and related accesso-
ries contain lead and lead compounds. Batter-
ies also contain other chemicals known to the
State of California to cause cancer. Wash your
hands after handling. Used engine oil contains
chemicals that have caused cancer in labora-
tory animals. Always protect your skin by wash-
ing thoroughly with soap and water.<
Parts and accessories
For your own safety, use genuine parts
and accessories approved by BMW.
When you purchase accessories tested and
approved by BMW and Genuine BMW Parts,
you simultaneously acquire the assurance that
they have been thoroughly tested by BMW to
ensure optimum performance when installed
on your vehicle.
BMW warrants these parts to be free from
defects in material and workmanship.
BMW will not accept any liability for damage
resulting from installation of parts and accesso-
ries not approved by BMW.
BMW cannot test every product made by other
manufacturers to verify if it can be used on a
BMW safely and without risk to either the vehi-
cle, its operation, or its occupants.
Genuine BMW Parts, BMW Accessories and
other products approved by BMW, together
with professional advice on using these items,
are available from all BMW centers.
Installation and operation of non-BMW
approved accessories such as alarms, radios,
amplifiers, radar detectors, wheels, suspension
components, brake dust shields, telephones,
including operation of any portable phone from
within the vehicle without using an externally
mounted antenna, or transceiver equipment, for
instance, CBs, walkie-talkies, ham radios or
similar accessories, may cause extensive dam-
age to the vehicle, compromise its safety, inter-
fere with the vehicle's electrical system or affect
the validity of the BMW Limited Warranty. Refer
to your BMW center for additional informa-
tion.<
Maintenance, replacement, or repair of
the emission control devices and sys-
tems may be performed by any automotive
repair establishment or individual using any cer-
tified automotive part.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
7
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainmentMobility
Service and warranty
We recommend that you read this publication
thoroughly.
Your BMW is covered by the following warran-
ties:
> New Vehicle Limited Warranty
> Rust Perforation Limited Warranty
> Federal Emissions System Defect Warranty
> Federal Emissions Performance Warranty
> California Emission Control System Limited
Warranty
Detailed information about these warranties is
listed in the Service and Warranty Information
Booklet for US models or in the Warranty and
Service Guide Booklet for Canadian models.
Reporting safety defects
The following applies only to vehicles owned
and operated in the US.
If you believe that your vehicle has a defect
which could cause a crash or could cause injury
or death, you should immediately inform the
National Highway Traffic Safety Administration
(NHTSA) in addition to notifying BMW of North
America, LLC, P.O. Box 1227, Westwood, New
Jersey 07675-1227, Telephone (800) 831-
1117.
If NHTSA receives similar complaints, it may
open an investigation, and if it finds that a safety
defect exists in a group of vehicles, it may order
a recall and remedy campaign. However,
NHTSA cannot become involved in individual
problems between you, your dealer, or BMW of
North America, LLC.
To contact NHTSA, you may either call the Auto
Safety Hotline toll-free at 1-800-424-9393 (or
366-0123 in Washington, D.C. area) or write to:
NHTSA, U.S. Department of Transportation,
Washington, D.C. 20590. You can also obtain
other information about motor vehicle safety
from the Hotline.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
At a glance
This overview of buttons, switches and displays
is intended to familiarize you with
your vehicle's operating environment.
The section will also assist you in becoming
acquainted with the control concepts
and options available for operating
the various systems.
At a glance
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Cockpit
10
Cockpit
Around the steering wheel: controls and displays
1 Rear window blind
*
97
2 Rear window safety switch 35
3 Opening and closing windows 34
4 Adjusting exterior mirrors 45
5
Turn signals 56
High beams, headlamp flasher 88
Roadside parking lamps 88
Check Control 67
Computer 69
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
At a glance
11
Reference ControlsDriving tipsCommunication NavigationEntertainmentMobility
6 Buttons on steering wheel
7 Instrument cluster 12
9 Ignition lock 51
10 Horn: the entire surface
13 Releasing hood 176
14 Opening luggage compartment lid 32
Telephone
*
153:
> Press: accept call or terminate
call
as well as dialing if an entry has
been selected from "A - Z",
"Top 8", "Redial", "Received
calls" or "Missed calls"
> press longer: redialing
Volume
Activating/deactivating voice com-
mand system
*
22
Fast forward/reverse 132
> Radio
Press: change radio station
Press longer: manual search
or automatic search scan
> CD
Press: select track
Press longer: fast forward/
reverse
> Telephone
*
Press: select entry in "A - Z",
"Top 8", "Redial", "Received
calls" or "Missed calls"
Individually programmable
*
46
Individually programmable 46
8
Windshield wipers 57
Rain sensor 57
11
Steering wheel heater
*
46
Steering wheel adjustment 45
12
Cruise control
*
: 58
Active cruise control
*
59
15
Head-Up Display
*
84
16
Parking lamps 87
Low beams 87
Automatic headlamp control
*
87
Adaptive Head Light 88
*
17
Instrument lighting 89
Fog lamps
*
88
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Cockpit
12
Instrument cluster
1 Indicator lamps for turn signals 13
2 Speedometer
3 Indicator and warning lamps 13
4 Display for active cruise control
*
60
5 Tachometer 65
and Energy Control 66
6 Display for
> Clock/date 65
> Outside temperature 65
> Indicator and warning lamps 68
> Speed of cruise control
*
58
> Desired speed for active cruise
control
*
59
7 Display for
> Odometer and trip odometer 65
> Computer 69
> Date and remaining travel distance for
service requirements 66
> Automatic transmission with
Steptronic 55
> SMG Sequential manual
transmission
*
53
> Check Control message present 67
8 Fuel gage 66
9 Resetting trip odometer 65
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
At a glance
13
Reference ControlsDriving tipsCommunication NavigationEntertainmentMobility
Indicator and warning lamps
The concept
Indicator and warning lamps and their combina-
tions are displayed in the display region 1 and in
the display 2. To better differentiate between
malfunctions, different symbols can be shown
on the display 2.
Some lights in the display region 1 are tested
for proper function by briefly lighting up during
starting of the engine or when the ignition is
switched on.
Acknowledging active functions
The following indicator lamps in the display
region 1 indicate that the associated functions
are activated:
What to do in case of a malfunction
All warning lamps and indicator lamps not yet
listed are also accompanied by text messages
on the Control Display. These may contain
more information as to the cause of a malfunc-
tion and instructions on what to do.
Sometimes, warning lamps are also accompa-
nied by supplemental text messages on the
Control Display that are shown immediately.
Text messages that do not appear immediately
are stored and can be displayed subsequently.
For further information on displaying these
messages later, refer to Check Control on
page 67.
Turn signals 56
Handbrake engaged 52
Handbrake engaged for Canadian
models
Front fog lamps 88
DTC Dynamic Traction Control 78
High beams/headlamp flasher 88
DSC Dynamic Stability Control 78
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Cockpit
14
Around the center console: controls and displays
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
At a glance
15
Reference ControlsDriving tipsCommunication NavigationEntertainmentMobility
1 Microphone for telephone
*
153
2 Reading lamps 89
3 Initiating an emergency call
*
189
4 Interior lamps 89
5 Glass sunroof, electric
*
35
6 Passenger airbag status lamp 84
7 Microphone for voice command
system
*
22
8 Control Display 16
Displays for menu navigation
9 Hazard warning flashers
10 Central locking system 31
11 Automatic climate control 90
12 Starting search function
> for radio stations 132
> for tracks 146
13 Ejecting
> navigation DVD
*
114
> audio CD 132
14 Drive for navigation DVD
s*
114
15 Drive for audio CDs 132
16 Switching audio sources on/off and
adjusting volume 132
18 Controller 16
19 Activating voice command system
*
22
20 Opening start menu on Control Display 17
21 Dynamic Driving Control
*
54
Temperature setting, left/right 91
Automatic air distribution and
volume 91
Cooling function 91
AUC Automatic recirculated-air
control 91
Maximum cooling 91
Residual heat mode 92
Switching off automatic climate
control 92
Air volume 91
Defrosting windows 91
Rear window defroster 90
17
Heated seats
*
43
Active seat ventilation
*
44
Active backrest width
adjustment
*
40
Active seat
*
44
PDC Park Distance Control
*
76
DTC Dynamic Traction Control 78
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Control Center
16
Control Center
The Control Center groups the functions of a
large number of switches. This allows these
functions to be operated from a central position.
The following section provides an introduction
to basic menu navigation. The control of the
individual functions is described in connection
with the relevant equipment.
Controls
1 Controller
2 button: open the start menu from
any menu
3 Control Display
By moving the controller 1 horizontally in four
directions 4, rotating 5 and pressing 6, you can
navigate through the menus of the Control Cen-
ters and adjust settings.
To avoid posing an unnecessary hazard
due to inattention, both to your own vehi-
cle's occupants and to other road users: never
attempt to use the controls or make entries
unless traffic and road conditions allow.<
Menu overview
You can call up all the functions in the Control
Center using five menu items.
Communication
> Portable phone
*
> BMW Assist
*
or TeleService
*
Navigation or onboard information
> Navigation system
*
> Onboard information, e.g. for displaying the
average fuel consumption.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
At a glance
17
Reference ControlsDriving tipsCommunication NavigationEntertainmentMobility
Entertainment
> Radio
> CD player and CD changer
*
Climate
> Air distribution
> Seat air conditioning
> Independent ventilation
*
menu
> Switching off Control Display
> Tone and display settings
> Settings for traffic information
> Settings for your vehicle, e.g. for central
locking, or settings for your portable phone
> Display of service requirements and dates
for statutory emission and vehicle inspec-
tions.
Menu navigation
As of ignition key position 1, the following mes-
sage appears on the Control Display:
Confirm the message by pressing the control-
ler; this opens the start menu.
Start menu
From the start menu, you can open four menus
by moving the controller left, right, forward, or
back. Pressing the controller opens the menu.
Opening start menu
Press button.
To open the start menu from the menu:
Press the button twice.
Displays in menu
1 In menus, you can change fields to select
the menu items they contain or to make
adjustments. The current field is high-
lighted.
2 Menu items are usually grouped in horizon-
tal or vertical lists.
3 In these lists, arrows indicate the possibility
of accessing other menu items that are not
currently visible.
4 Settings are displayed graphically, numeri-
cally, or as text.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Control Center
18
5 A symbol indicates the last selected menu
item of the start menu:
Communication
Navigation or onboard information
Entertainment
Climate
menu
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
At a glance
19
Reference ControlsDriving tipsCommunication NavigationEntertainmentMobility
Selecting menu items and making adjustments
1 Selecting individual menu items: turn the
controller. The highlight moves. Menu
items shown in white can be selected.
2 Activating highlighted menu items: press
the controller. New menu items are dis-
played or a function is executed.
3 Changing the current field: move controller
left, right, forward, or back and release.
4 Selecting menu items: such as 1.
5 Adjusting settings: turn the controller. This
causes the graphical display, numerical val-
ues or text displays to change. When you
change into another field or another menu,
the new setting is applied.
Changing directly to the last menu
Move the controller in the corresponding direc-
tion and hold it for longer than approx. 2 sec-
onds. The menu in the selected direction is
opened and the last menu item selected is dis-
played.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Control Center
20
Status information
1 Display
*
for manual or automatic air distri-
bution for the driver's side and passenger
side
2 Display for:
> Entertainment:
Radio, CD or
entertainment sound output
> Telephone
*
:
"Car Phone", "Portable" or no network
3 Display for:
> New entries present in "Missed calls"
*
> Text message/SMS
*
received
> Roaming active
4 Telephone call
s*
or BMW Assist calls
*
enabled
Reception strength for telephone,
depending on the portable phone
5 Time
Other displays:
The status information is temporarily hidden
when there are Check Control instructions or
inputs via the voice command system.
Assistance window*
Additional information can be displayed in the
assistance window:
> The computer or the trip computer
*
> The route map or the arrow view in vehicles
with navigation system
*
> The current position
Switching on assistance window:
Move the controller to the right to change to the
assistance window, and press the controller.
To select the display in the assistance window:
1. Move the controller to the right to change to
the assistance window, and press the con-
troller.
2. Select menu item.
3. Press the controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
At a glance
21
Reference ControlsDriving tipsCommunication NavigationEntertainmentMobility
Closing assistance window:
1. Move the controller to the right to change to
the assistance window, and press the con-
troller.
2. Select "Assist. window off" and press the
controller.
Switching Control Display on/off
To switch off the Control Display:
1. Press button.
This opens the start menu.
2. Press controller to open menu.
3. Select "Display off" and press the control-
ler.
To switch off the Control Display:
Press the controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Voice command system
22
Voice command system
The concept
The voice command system allows you to con-
trol operation of various vehicle systems with-
out ever removing your hands from the steering
wheel.
Individual menu items on the Control Display
can be spoken as commands. This frees you of
having to use the controller.
The voice command system transforms your
oral commands into control signals for the
selected systems and provides support in the
form of instructions or questions.
The voice command system uses a special
microphone located in the area of the interior
rearview mirror, refer to page 14.
Precondition
In the Control Center, set the language that
applies for the voice command system in order
to enable identification of the spoken com-
mands. Setting the language of the Control
Center, refer to page 74.
Symbol in the Owner's Manual
Voice commands
Activating voice command system
1. Press the button in the center console
or on the steering wheel.
This symbol on the Control Display and
an acoustic signal tell you that the voice
command system can respond to com-
mands.
2. Say the command.
The text or numbers that the voice com-
mand system has registered will appear on
the Control Display.
*
{...} Say the specified commands word for
word.
{{...}} Indicates responses of the voice
command system.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
At a glance
23
Reference ControlsDriving tipsCommunication NavigationEntertainmentMobility
This symbol appears on the Control Display
when you can input additional voice com-
mands.
If no other voice commands are possible, then
operate the equipment using the Control Cen-
ter.
Terminating or canceling voice
command system
Press the button on the steering wheel or
on the center console
or
Voice commands
Having the possible voice commands
read aloud
You can have the system read aloud the possi-
ble voice commands related to the selected
menu item on the Control Display.
For example, if you have selected "CD", the
system will read aloud the possible voice com-
mands for operating the CD player and the CD
changer
*
:
Opening help
Using alternative voice commands
There are often a number of commands to run a
function, e.g.:
Calling up functions directly
With short commands you can carry out certain
functions directly, regardless of which menu
item is selected, refer to page 199.
Opening the start menu
Example: selecting a track
1. Press the button on the steering wheel
or in the center console.
{Cancel}
{Options}
{Help}
{Information menu} or {i menu}
{Main menu}
2. {Entertainment}
The system outputs:
{{Entertainment}}
3. {CD}
The system outputs:
{{CD}}
4. Select track, e.g.:
{Track 1}
The system outputs:
{{Track 1}}
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Voice command system
24
Notes
The portable phone can also be operated
by voice commands, refer to page 158.<
For voice commands, bear the following in
mind:
> Issue the commands smoothly and at nor-
mal volume, avoiding excessive emphasis
and pauses.
> Say the names of radio stations in the lan-
guage of the voice command system or the
customary pronunciation for the station.
> For entries in the voice-activated phone
book, only use names in the language of the
voice command system and no abbrevia-
tions
> Keep the doors, windows and glass sunroof
closed to prevent interference from ambi-
ent noise.
> Avoid making other noise in the vehicle
while speaking.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
This chapter is intended to provide you with
information for complete control of your vehicle.
Its extensive array of features and accessories,
both for driving and for your own safety,
comfort and convenience, are described here.
Controls
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Opening and closing
28
Opening and closing
The key set
1 Every master key with remote control con-
tains an extended-life battery as a power
supply, which is charged automatically in
the ignition lock as you drive. You should
use each master key at least twice a year in
order to maintain the charge condition.
Depending on which master key is detected
by the vehicle during unlocking, different
settings in the vehicle are requested and
executed, refer to Key Memory below.
2 Spare key for storage in a safe place, such
as in your wallet.
This key does not fit in the locks of the lug-
gage compartment lid and the glove com-
partment. This is an advantage when valet
parking, for example. The key is not
intended for regular use.
New key
Additional or replacement keys are available at
your BMW center.
Key Memory
How the system functions
Doubtless you have often reflected on how
great it would be if you could configure your
vehicle's various adjustment settings to meet
your own personal requirements. BMW has
designed several freely selectable options into
the vehicle during its development. You can set
these as desired via the Control Center.
You can have up to four different basic settings
adjusted for four different persons for the spe-
cific keys. The only requirement is that each
person uses his or her own master key with
remote control.
When your vehicle is unlocked with the remote
control, the vehicle recognizes the individual
key by means of a data exchange and makes
adjustments accordingly.
Size of Key Memory
> When unlocking with the remote control,
either unlock only the driver's door or the
entire vehicle, refer to page 29
> Locking the vehicle after a short time or
after starting off, refer to page 31
> Assigning the programmable function but-
tons on the steering wheel, refer to page 46
> Settings for the display on the Control Dis-
play:
> Brightness of the Control Display, refer
to page 73
> Measuring units for consumption, travel/
distances, temperature, and pressure,
refer to page 73
> Voice commands in Control Display,
refer to page 74
> 12h/24h mode of the clock, refer to
page 74
> Date format, refer to page 75
> Showing optical warning for PDC Park
Distance Control
*
, refer to page 76
> Selection and brightness of display in
Head-Up Display
*
, refer to page 85
> Air distribution, temperature and intensity
of the automatic air conditioning system,
refer to page 92
> Setting voice instructions for destination
guidance in the navigation system
*
, refer to
page 125
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
29
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
In addition, the following, most recently
selected settings are recalled during unlocking:
> Positions of driver's seat, outside mirrors,
and steering wheel, refer to page 40
> Audio sources, setting volume and tone,
refer to page 133
> Telephone, setting volume, refer to
pages 153, 159
> Radio, displaying memorized stations, refer
to page 140
Central locking system
The concept
The central locking system is ready for opera-
tion whenever the driver's door is closed. The
system simultaneously engages and releases
the locks on the following:
> Doors
> Luggage compartment lid
> Fuel filler door
The central locking system can be operated
from the outside
> via the remote control
> via the door lock
and from inside via the button for the central
locking system.
When actuated from the inside, the fuel filler
door is not locked, refer to page 31.
The anti-theft system is automatically activated
whenever you operate the central locking sys-
tem from outside the vehicle. It prevents the
doors from being unlocked using the lock but-
tons or door handles. The alarm system is
armed/disarmed at the same time. The remote
control is also used to switch the interior lamps
on and off.
You can find more detailed information on the
alarm system on page 33.
In an accident of sufficient severity, the central
locking system automatically unlocks the vehi-
cle. In addition, the hazard warning flashers and
interior lamps come on.
Opening and closing: from
outside
Using the remote control
Protect the remote control against unau-
thorized use by handing over only the
spare key, for example when using valet park-
ing.<
Because any persons or animals left unat-
tended in a parked vehicle could lock the
doors from the inside, you should always keep
the remote control with you; this precaution
ensures that you will remain able to unlock the
vehicle from the outside at all times.<
Unlocking
Use the button to unlock the vehicle accord-
ing to current settings.
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Vehicle settings" and press the
controller.
3. Select "Door locks" and press the control-
ler.
4. Select "Central locking" and press the con-
troller.
5. Select "Unlock button" and press the con-
troller.
6. Select a menu item:
> "All doors"
Press the button once to unlock the
entire vehicle.
> "Driver's door only"
Press the button once to unlock only
the driver's door and the fuel filler door.
Press the button twice to unlock the
entire vehicle.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Opening and closing
30
7. Press the controller.
The setting is stored for the remote control cur-
rently in use.
Convenience opening
Hold button down. The windows and the
glass sunroof open.
Locking
Press button.
Switching on interior lamps
If the vehicle is locked, press the but-
ton.
You can also use this function to locate your
vehicle in parking garages etc.
Panic mode*
By pressing and holding the button for more
than approx. two seconds, you can trigger the
alarm system in response to any impending
danger.
To switch off the alarm: press any of the but-
tons.
Opening luggage compartment lid
Press button.
The luggage compartment lid opens, regard-
less of whether it was previously locked or
unlocked.
During opening, the luggage compart-
ment lid pivots back and up. Ensure that
adequate clearance is available before opening.
A previously locked luggage compartment lid is
also locked again after closing.<
Setting confirmation signals
You can vary or also deactivate the acknowl-
edgment signals for locking or unlocking.
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Vehicle settings" and press the
controller.
3. Select "Door locks" and press the control-
ler.
4. Select "Confirmation" and press the con-
troller.
5. Select desired signal.
6. Press the controller.
The signals are switched on.
Malfunctions
The remote control may malfunction due to
local radio waves.
Should the remote control fail to operate owing
to interference of this kind, unlock and lock the
vehicle via the door lock using the master key.
If it is no longer possible to lock the vehicle
using the remote control, then its battery is dis-
charged. Use this remote control during an
extended drive; this will recharge the battery,
refer to page 28.
For US owners only
The transmitter and receiver units comply with
part 15 of the FCC/Federal Communication
Commission regulations. Operation is gov-
erned by the following:
FCC ID:
LX8766S
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
31
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
LX8766E
LX8CAS
Compliance statement:
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
> this device must not cause harmful interfer-
ence, and
> this device must accept any interference
received, including interference that may
cause undesired operation.
Any unauthorized modifications or
changes to these devices could void the
user's authority to operate this equipment.<
Using door lock
One turn of the key in the driver's door lock
unlocks the driver's door only.
Turning the key a second time unlocks all of the
remaining doors, the luggage compartment lid
and the fuel filler door.
Convenience operation
You also have the option of operating the win-
dows and the glass sunroof from the driver's
door lock.
> Opening:
With the door closed, turn the key to the
unlock position and hold it there.
> Closing:
With the door closed, turn the key to the
lock position and hold it there.
Watch during the closing process to be
sure that no one is injured. Releasing the
key stops the operation.<
Manual operation
If an electrical malfunction occurs, you can
unlock or lock the driver's door with the key in
the end positions of the door lock.
Opening and closing: from
inside
This button serves to unlock or lock doors and
the luggage compartment lid, but does not acti-
vate the anti-theft system. The fuel filler door
remains unlocked.
You can also make the following settings:
> The central locking system automatically
locks the vehicle after a short time when no
door has been opened.
> The central locking system automatically
locks the vehicle as soon as you start to
drive.
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Vehicle settings" and press the
controller.
3. Select "Door locks" and press the control-
ler.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Opening and closing
32
4. Select "Central locking" and press the con-
troller.
5. Select "Relock door if not opened"
or
"Lock after driving".
6. Press the controller.
The setting is selected.
The setting is stored for the remote control cur-
rently in use.
Unlocking and opening doors
> Either unlock the doors together with the
button for the central locking system and
then pull the door handle above the armrest
or
> pull on the door handle of each door twice:
The first time unlocks the door, the second
time opens it.
Locking
> Use the central locking button to lock all of
the doors simultaneously, or
> press down the lock button of the desired
door. To prevent you from being locked out,
the open driver's door cannot be locked
using the lock button.
Because any persons or animals left unat-
tended in a parked vehicle could lock the
doors from the inside, you should always take
the master key with remote control with you to
ensure that you will remain able to unlock the
vehicle from the outside whenever the need
arises.<
Luggage compartment lid
During opening, the luggage compart-
ment lid pivots back and up. Ensure that
adequate clearance is available before open-
ing.<
Opening from inside
Press the button: the luggage compartment lid
opens unless it has been locked.
Opening from outside
Press the button: the luggage compartment lid
opens.
Only the master keys with remote control, refer
to page 28, match the luggage compartment
lock.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
33
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Locking separately
Turn the master key with remote control in the
lock of the luggage compartment lid beyond a
resistance point to the right and withdraw it in
the horizontal position.
This locks the luggage compartment lid and
disconnects it from the central locking system.
If you then only hand over the spare key, refer to
page 28, no access is possible via the luggage
compartment lid. This is an advantage when
valet parking, for example.
Unlocking again and opening manually
Turn master key toward the left until the resis-
tance point: the luggage compartment lid
opens.
If you use the key to unlock the luggage
compartment lid while the alarm system
is armed, the alarm will be triggered. You should
therefore unlock the vehicle ahead of time.
If the alarm is inadvertently triggered: switch off
the alarm, refer to page 34.<
Emergency release
This lever releases the luggage compartment
lid from inside the luggage compartment.
Closing
The handle recesses on the interior trim of the
luggage compartment lid make it easier to pull
down.
Make sure that the closing path of the
luggage compartment lid is clear, as oth-
erwise injuries may result.<
Alarm system
The concept
The vehicle alarm system responds:
> When a door, the hood, or the luggage com-
partment lid is opened
> To movements inside the vehicle: Inner
motion sensor, see below
> To changes in the vehicle's tilt if someone
attempts to steal the wheels or tow the
vehicle
> To interruptions in battery voltage
The system responds to unauthorized vehicle
entry and attempted theft by simultaneously
activating:
> An acoustic alarm, which lasts for a period
of approx. 30 seconds
> The hazard warning flashers for approx. 5
minutes
> The high beams, which flash on and off in
the same rhythm
Arming and disarming alarm system
When you lock or unlock the vehicle, either with
the remote control or at the door lock, the alarm
system is armed or disarmed at the same time.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Opening and closing
34
The system indicates that it has been correctly
armed by switching on the hazard warning
flashers for a single cycle and by emitting an
acoustic signal.
You can also open the luggage compartment lid
with the system armed using the button on
the remote control, refer to page 30. When the
luggage compartment lid is closed, it is locked
again and monitored.
Switching off alarm
> Unlock the vehicle using the remote control,
refer to page 29
> or turn the ignition key to position 1, refer to
page 51.
Indicator lamp displays
> The indicator lamp under the inside rear-
view mirror flashes continuously: the sys-
tem is armed.
> The indicator lamp flashes after locking: the
doors or luggage compartment lid are not
properly closed. Even if you do not close the
alerted area, the system begins to monitor
the remaining areas, and the indicator lamp
flashes continuously after approx. 10 sec-
onds. However, the interior motion sensor
is not activated.
> The indicator lamp goes out after unlocking:
your vehicle has not been disturbed while
you were away.
> The indicator lamp flashes after unlocking
until the key is inserted into the lock, but can
blink for up to approx. 5 minutes: your vehi-
cle has been disturbed while you were
away.
Tilt alarm sensor and interior motion
sensor
Tilt alarm sensor
The tilt of the vehicle is monitored. The alarm
system reacts, e.g. in case of an attempted
wheel theft or towing.
Interior motion sensor
In order for the interior motion sensor to func-
tion properly, the windows and glass sunroof
must be completely closed.
Avoiding unintentional alarms
The tilt alarm sensor and interior motion sensor
may be switched off at the same time. This pre-
vents unintentional alarms, e.g. in the following
situations:
> In stacking garages
> When transporting on car-carrying trains
> When animals are to remain in the vehicle
Switching off tilt alarm sensor and
interior motion sensor
Press the button on the remote control
once again directly after locking.
The indicator lamp lights up briefly and then
flashes continuously. The tilt alarm sensor and
the interior motion sensor are switched off until
the next time the vehicle is unlocked and subse-
quently locked again.
Windows
To prevent injuries, exercise care when
closing the windows and keep them in
your field of vision until they are shut.
When leaving the vehicle, always remove the
ignition key and close the doors to prevent chil-
dren from operating the windows and injuring
themselves etc.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
35
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Opening and closing windows
Ignition key in position 1, refer to page 51:
> Press switch to resistance point:
The window continues to open as long as
you keep the switch pressed.
> Press switch beyond resistance point:
The window opens automatically. Pressing
the switch again stops the opening move-
ment.
You can close the windows in the same manner
by pulling the switch.
After switching off ignition
You can still operate the windows:
> With the Ignition key in position 1 for
approx. 15 minutes
> With the ignition key in position 0 or with the
ignition key removed, for approx. 1 minute,
as long as a front door has not been opened.
For information on using the convenience oper-
ation at the door lock or with the remote control,
refer to page 30 or 31.
Anti-trapping mechanism
If the closing force rises beyond a predefined
threshold during closing, the system will imme-
diately stop moving the window prior to lower-
ing it slightly.
Despite the anti-trapping mechanism
inspect the window's travel path prior to
closing it, as the safety system might fail to
detect certain kinds of obstructions, such as
thin objects, and the window would continue
closing.
Pulling the switch beyond the resistance point
and holding it limits the response of the anti-
trapping mechanism. In this case, if the closing
force exceeds a defined threshold, the window
will only open a few inches/millimeters.
If the switch is pulled past the resistance point
again within approx. 4 seconds, the anti-trap-
ping mechanism will be deactivated.<
Safety switch
With the safety switch, you can prevent the rear
windows from being opened or closed via the
switches in the rear passenger area, by chil-
dren, for example. The LED lights up when this
safety feature is activated.
Always press the safety switch when chil-
dren ride in the rear, as otherwise
unchecked closing of the windows could lead to
injuries.<
Accessories in window area
After installing any accessory – such as a
clamp-on antenna for a portable phone – within
the window's travel range, you will need to have
the system reinitialized for use under the new
conditions. BMW recommends having this
work done by your BMW center.
Glass sunroof, electric*
To prevent injuries, exercise care when
closing the glass sunroof and keep it in
your field of vision until it is shut.
When leaving the vehicle, always remove the
ignition key and close the doors to prevent chil-
dren from operating the sunroof and injuring
themselves.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Opening and closing
36
Ignition key in position 1, refer to page 51.
Raising
Press switch.
> When the glass sunroof is closed, it is raised
slightly and the sliding visor opens slightly.
> When the glass sunroof is open, it automat-
ically travels into the raised position. The
sliding visor remains completely open.
Do not use force to close the headliner
insert with the glass sunroof in its raised
position, as damage to the mechanism could
result.<
Opening, Closing
> Press switch back to the resistance point.
The glass sunroof and the sliding visor open
together for as long as you hold the switch
in position.
> Press switch back past the resistance point.
The glass sunroof and the sliding visor open
automatically. Briefly press the switch again
to stop the opening movement.
In a similar manner, the glass sunroof and the
sliding visor close when you slide the switch
forward. The sliding visor remains open and
must be closed by hand.
For information on using the convenience oper-
ation at the door lock or with the remote control,
refer to page 30 or 31.
After switching off ignition
You can still operate the sunroof:
> With the Ignition key in position 1 for
approx. 15 minutes
> With the ignition key in position 0 or with the
ignition key removed, for approx. 1 minute,
as long as a front door has not been opened.
Automatic opening and closing
Press the switch past the resistance point.
The following movements are also automatic:
> When the sunroof is open, press the switch
in the lifting direction: the sunroof is raised
all the way.
> When the sunroof is raised, press the
switch in the opening direction: the sunroof
is opened all the way.
Pressing the switch again stops the motion.
Anti-trapping mechanism
If the glass sunroof encounters resistance when
closing from roughly the center of the sunroof
opening or when closing from the raised posi-
tion, the closing action is interrupted and the
glass sunroof reopens a short way.
Despite the anti-trapping mechanism
inspect the sunroof's travel path prior to
closing it, as the safety system might fail to
detect certain kinds of obstructions, such as
very thin objects, and the sunroof would con-
tinue closing.
Pressing the switch beyond the resistance
point and holding it there deactivates the anti-
trapping mechanism.<
Following interruptions in electrical
power supply
After a power loss, the sunroof may only
respond to the lift command. The system must
be initialized. BMW recommends having this
work done by your BMW center.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
37
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Manually opening and closing
In the event of an electrical malfunction, you can
move the glass sunroof manually:
1. Fold the cover panel down, if necessary
using screwdriver from onboard tool kit,
refer to page 182.
2. Insert the Allen wrench supplied with the
onboard tool kit, refer to page 182, into the
opening provided. Move the glass sunroof
in the desired direction. The arrow below
indicates the rotation direction for closing.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Adjustments
38
Adjustments
Sitting safely
The ideal sitting position can make a vital con-
tribution to relaxed, fatigue-free driving. The sit-
ting position of the occupants also plays an
important role for passive safety together with
the safety belts and airbags in an accident. To
ensure that the safety systems operate with
optimal efficiency, we strongly urge you to
observe the instructions contained in the fol-
lowing section.
For additional information on transporting chil-
dren safely, refer to page 47.
Airbags
Always maintain an adequate distance
between yourself and the airbags. Always
hold the steering wheel by its rim with hands at
the 9 o'clock and 3 o'clock positions, to mini-
mize the risk of injuries to your hands and arms
in the event of airbag deployment. No one and
nothing is to come between the airbags and the
seat occupant. Do not use the cover of the front
airbag on the front passenger side as a storage
area. Make sure that the front passenger is sit-
ting correctly and does not rest feet or legs on
the instrument panel, otherwise leg injuries can
occur if the front airbag is triggered. Never let an
occupant's head rest near or on a side airbag
because the inflating airbag could cause a seri-
ous or fatal injury.<
Even if you adhere to all the instructions, inju-
ries resulting from contact with airbags cannot
be fully excluded, depending on the circum-
stances. The ignition and inflation noise may
provoke a mild hearing loss in extremely sensi-
tive individuals. This effect is usually only tem-
porary.
For airbag locations and additional information
on airbags, refer to page 83.
Safety belt
Before every drive, make sure that safety belts
are being worn at all of the occupied seats.
Airbags complement the safety belt as an addi-
tional safety device, but they do not represent a
substitute.
At all times, occupants should sit upright
and be properly restrained: infants and
small children in appropriate child-restraint sys-
tems; larger children and adults using the safety
belts. Never allow more than one person to
wear a single safety belt. Never allow infants or
small children to ride in a passenger's lap.
Expectant mothers should always wear their
safety belts, taking care to position the lap belt
against the lower hips, where it will not exert
pressure against the abdominal area. Do not
route the belt across your neck, or run it across
sharp edges. Be sure that the belt does not
become caught or jammed. Avoid twisting the
belt while routing it snugly across the hips and
shoulder. Do not allow the belt to rest against
hard or fragile objects. Otherwise, in the event
of a frontal impact, a loose lap belt could slide
over your hips, leading to abdominal injury.
Avoid wearing clothing that prevents the belt
from fitting properly and pull the shoulder belt
periodically to readjust the tension across your
lap in order to avoid a reduction in the retention
effect of the safety belt.<
For instructions on operating safety belts, refer
to page 42.
Seats
Note before adjusting
Never attempt to adjust your seat while
the vehicle is moving. The seat could
respond with unexpected movement, and the
ensuing loss of vehicle control could lead to an
accident. Also on the passenger side, do not
incline the backrest too far to the rear while the
vehicle is being driven, as otherwise there is a
danger in the event of an accident of 'sliding
under' the safety belt, eliminating the protec-
tion normally provided by the belt.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
39
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Please observe the information on damage to
safety belts provided on page 43 and the infor-
mation on the active front head restraints
on
page 42.
Seat adjustment
To ensure that the safety systems con-
tinue to provide optimized protection,
please observe the adjustment instructions on
page 38.<
1 Longitudinal direction
2 Height
3 Angle
4 Backrest
Adjusting comfort seat*
In this seat, you can also adjust:
1 Backrest width
2 Shoulder support
3 Thigh support
4 Lumbar support, see below.
Shoulder support: the adjustable upper back-
rest also supports the back in the shoulder
region. This provides a relaxed driving position
and helps relieve stress on the shoulder mus-
cles.
After making corrections in the forward/
backward adjustment of the seat, make
sure that the safety belt still fits snugly against
your body. Failure to do so may reduce the pro-
tection provided by the safety belt.<
Adjusting sport seat*
In this seat, you can also adjust the thigh sup-
port 3, see above.
Adjusting lumbar support*
You can also adjust the contour of the backrest
to obtain additional support in the lumbar
region.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Adjustments
40
The upper hips and spinal column receive sup-
plementary support to help you maintain a
relaxed, upright sitting position.
> Increase or decrease curvature: push
switch forward or back.
> Shift curvature up or down: push switch up
or down.
Adjusting active backrest width*
First set a comfortable backrest width, see
above. Based on the backrest width set, the lat-
eral support is automatically adapted to the cur-
rent driving situation.
The adaptation of the backrest width and the
speed of the adjustment vary depending on the
program. You can select from among three pro-
grams from comfort to sport.
Press program button once:
> "Comfort" program: one LED
> "Normal" program: two LEDs
> "Sport" program: three LEDs
To switch off: press button longer.
Easy entry/exit*
To facilitate entry and exit, the backrest tempo-
rarily opens all the way.
Seat, mirror and steering
wheel memory*
You can store and request two different posi-
tions for the driver's seat and passenger seat
*
,
external rearview mirrors, and steering wheel.
The adjustment of the lumbar support is not
stored in the memory.
Storing
1. Turn ignition key to position 1 or 2, refer to
page 51.
2. Set the desired seat, exterior mirror and
steering wheel positions.
3. Press button:
The LED in the button lights up.
4. Press the desired memory button 1 or 2.
The LED goes out.
Requesting
Do not request a position from the mem-
ory while the vehicle is moving. There is a
risk of accident from unexpected movement of
the seat or steering wheel.<
Convenience mode
1. Open the driver's door after unlocking or
turn the ignition key to position 1.
2. Briefly press the desired memory button 1
or 2.
The system immediately cancels the
adjustment procedure when you briefly
press one of the seat adjustment buttons or
one of the memory buttons.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
41
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Safety feature
1. Close the driver's door and turn the ignition
key to position 0 or 2.
2. Press the desired memory button 1 or 2
and maintain pressure until the adjustment
process has been completed.
If the button was pressed inadvertently:
press the button again; the LED goes out.
Position stored in key
The positions of the driver's seat, the external
rearview mirrors, and steering wheel are stored
for the remote key currently in use.
You can choose when the position is requested:
> Request when unlocking vehicle
> Request when opening driver's door
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Vehicle settings" and press the
controller.
3. Select "Door locks" and press the control-
ler.
4. Select "Central locking" and press the con-
troller.
5. Select "Last seat pos." and press the con-
troller.
6. Select "After unlocking" or "After opening
door" and press the controller.
To cancel the request:
Select "Deactivated" and press the controller.
When using this feature, always make
sure that the footwell behind the driver's
seat is empty and unobstructed. Failure to do
so could cause injury or damage to persons or
objects behind the seat as a result of a rearward
movement of the seat.<
Passenger-side exterior mirror tilt
function*
Automatic curb monitor
Activating
1. Slide mirror selector switch into the driver's
side mirror position 1.
2. When you shift into reverse or move the
selector lever into position R, the exterior
mirror on the front passenger side tilts
downward slightly. This allows the driver to
see the area immediately adjacent to the
vehicle – such as a curb – when parking, etc.
Deactivating
Slide mirror selector switch into the passen-
ger's side mirror position 2.
Head restraints
Head restraints reduce the risk of spinal
injury in the event of an accident. Adjust
the head restraints so that they are centered
roughly at the level of your ears.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Adjustments
42
Front seat: height adjustment
You can adjust the height of the head restraints
electrically.
Front seat: angle adjustment
Swivel the head restraint.
With the comfort seat, use the shoulder support
to set the distance to the back of the head.
Adjusting side extensions in the
comfort seat
You can fold the side extensions on the head
restraint forward for increased lateral support in
the resting position.
Front head restraints, active*
The comfort seats are equipped with an active
head restraint.
In the event of a rear-end collision of sufficient
severity, the active head restraint reduces the
distance to the head.
To ensure that the active head restraints
afford maximum protection, and to avoid
unnecessary risks to personal safety, we
request that you read and comply with the fol-
lowing:
> Do not install seat or head-restraint covers
> Never use the head restraints as supports
for suspending objects of any kind, such as
clothes hangers. Refrain from mounting
accessories on either the seat or the head
restraint.<
Rear seats: height adjustment
Up: pull up.
Down: press button 1 and slide the head
restraint downward.
Safety belts
To ensure that the safety systems con-
tinue to provide optimized protection,
please observe the adjustment instructions on
page 38.<
Before every drive, make sure that safety belts
are being worn at all of the occupied seats. Air-
bags complement the safety belt as an addi-
tional safety device, but they do not represent a
substitute.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
43
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Fastening
Make sure you hear the latch plate engage in
the belt buckle.
Safety belt memory for driver's seat
and passenger seat*
The indicator lamp lights up, a signal
sounds, and a message appears on the
display. Please check whether safety
belts are correctly placed.
The safety belt memory is operative at speeds
above approx. 5 mph/8 km/h. It can also be acti-
vated if objects are placed onto the passenger
seat.
Releasing
1. Grasp the belt firmly.
2. Press the red button in the buckle.
3. Guide the belt into its reel.
The shoulder strap's anchorage point will be in
the correct position for adult seat occupants of
every build if the seat is correctly adjusted, refer
to page 38.
The two rear safety belt buckles integrated into
the rear seat are for passengers sitting on the
left and right. The belt buckle embossed with
the word CENTER is intended exclusively for
use by passengers riding in the center position.
Damage to safety belts
If the safety belts are damaged or
stretched in an accident: Have the entire
belt system, including the tensioning mecha-
nisms, replaced at your BMW center or at a
workshop that works according to BMW repair
procedures with correspondingly trained per-
sonnel. Have the belt anchorage points
inspected for damage at the same time. Failure
to observe this precaution may prevent the
safety belts from effectively providing optimal
protection when needed.<
Heated seats*
Front
The temperature setting progresses one step
through its control sequence each time you
press the button. When the maximum tempera-
ture is selected, three LEDs light up.
To switch off: press the button longer.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Adjustments
44
Rear
The operating concept is the same as for the
front heated seats.
Temperature distribution in front
The heat output can be distributed variously in
the seat cushion and the backrest.
Control Center, for principle details, refer to
page 16.
Ignition key in position 2:
1. Select "Climate".
2. Select "Seat heater distribution" and press
the controller.
3. Move the controller to the left or right to
select "Driver" or "Passenger".
4. Turn the controller. The adjustment is
applied; the field can be changed.
Active seat ventilation*
The system progresses one step through the
control sequence each time you press the but-
ton.
To switch off: press the button longer.
The highest position with three LEDs is
used for rapid cooling, e.g. when the vehi-
cle has gotten heated up. After a short time, the
system is automatically switched down one
position in order to prevent excessive cooling.<
Active seat*
The seat cushion is actively varied by alter-
nately raising and lowering the right and left half
of the seat cushion. This reduces muscular ten-
sion and fatigue to help prevent lower back
pain.
Press the button to switch on; the LED lights
up.
If you switch off the active seat, it can take up
to 1 minute before the two halves of the seat
cushion have returned to their initial position.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
45
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Mirrors
Exterior mirrors
The mirror on the passenger side fea-
tures a lens with a more convex surface
than the mirror installed on the driver's side.
When estimating the distance between yourself
and other traffic, bear in mind that the objects
reflected in the mirror are closer than they
appear. This means that estimations of the dis-
tance to following traffic should not be regarded
as precise.<
1 Adjustments
2 Switching to the other mirror or to the auto-
matic parking function, refer to Tilting the
passenger-side mirror, page 41
Storing the mirror positions, refer to Seat, mir-
ror and steering wheel memory on page 40.
Manual adjustment
You can also adjust the mirrors manually if nec-
essary by pressing against the outer edges of
their mirror glass.
Folding mirrors in and out
To prevent the exterior mirrors on this
vehicle from being damaged, always fold
them in by hand before entering an automatic
car wash.<
Automatic heating
Both exterior mirrors are automatically heated
in ignition key position 2.
Interior rearview mirror
To reduce the dazzle effect of following vehi-
cles at night, turn the knob.
Automatically dimming mirrors, refer to
page 107.
Steering wheel
Adjustments
Do not adjust steering wheel while driv-
ing. There is a risk of accident from unex-
pected movement of the steering wheel.<
The steering wheel can be adjusted in four
directions.
Storing steering wheel positions, refer to Seat,
mirror and steering wheel memory on page 40.
Easy entry/exit*
To facilitate entry and exit, the steering wheel
temporarily moves into the uppermost position.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Adjustments
46
Steering wheel heater*
Press the button with the ignition key in
position 2.
When the steering wheel heater is operating,
the LED in the button lights up.
Programmable buttons* on the
steering wheel
You can assign the function buttons individu-
ally.
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Vehicle settings" and press the
controller.
3. Select "Steering wheel buttons" and press
the controller.
The various functions are displayed:
> "Nav. voice instructions"
Voice instructions for the navigation
system
> "Air recirculation on / off"
Permanently shutting off outside air,
refer to AUC Automatic recirculated air
control on page 91
> "Mute on / off"
Mutes the audio sources
> "Monitor on / off"
Switches the Control Display on/off
> "Telephone list"
Switching between Entertainment and
Telephone
> "Next entertainment source"
Changes audio source
4. Select the desired function.
5. Press the controller.
6. Select button if necessary.
7. Press the controller.
The setting is stored for the remote control cur-
rently in use.
You can operate the selected function using the
corresponding button.
Operating function
Press the corresponding button on the steering
wheel.
Voice instructions of navigation system:
> To switch voice instructions on/off: hold the
button down.
> To repeat the last voice instruction: press
button.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
47
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Transporting children safely
The right place for children
Children always in the rear
Accident research shows that the safest place
for children in a vehicle is in the rear seat.
Older children should be tightly secured with a
safety belt, after they have outgrown a booster
seat that is appropriate for their age, height and
weight.
A child sitting in the rear seat and not
properly restrained may place his or her
head on or near the airbag, if so equipped. For
example, a child, even though belted, may fall
asleep with his or her head against the side air-
bag. It may be difficult for a driver to ensure that
children in the rear seat will remain properly
positioned at all times and do not place their
heads on or near the side airbag. Therefore, we
recommend that the rear seat side airbags, if
provided, be deactivated if you plan to transport
children in the rear seat.<
Deactivating rear seat side airbags
The rear seat side airbags may already have
been deactivated by a BMW center. Labels in
the rear door opening should indicate the status
of your rear seat side airbags. If you are uncer-
tain of their status, or wish to have the airbags
activated or deactivated, please contact your
BMW center.
Child-restraint system in the rear
Children under 13 years of age and chil-
dren less than 5 ft/150 cm tall should
always ride in the rear and the restraint systems
should be secured with the vehicle's safety
belts.<
Younger children should be secured in an
appropriate forward-facing child-restraint sys-
tem that has first been properly restrained. We
strongly urge you to carefully read and comply
with the instructions for installation and use
provided by the child-restraint's manufacturer
whenever you use such a device.
All rear sitting positions in your vehicle meet the
recommendations of SAE J1819, an industry-
recommended practice for securing child-
restraint systems in motor vehicles.
Exception for front passenger seat
Should it be necessary to use a child-
restraint system on the front passenger
seat, the airbags on the front passenger side
must be deactivated. Otherwise, there is a con-
siderable risk of injury for the child when the air-
bags are triggered, even with a child-restraint
system. Your BMW center will be glad to advise
you.<
Never install a rearward-facing child-
restraint system in the front passenger
seat of this vehicle if the passenger's airbag is
not deactivated. If you do so, the child could be
severely injured when the airbag is trig-
gered.Your vehicle is equipped with an airbag
supplemental restraint system for the front pas-
senger. Because the backrest on any rearward-
facing child-restraint system – of the kind
designed for infants under 1 year and 20 Ibs./
9 kg – would be within the airbag's deployment
range, you should never mount such a system
in the front passenger seat, since the impact of
the airbag against the child restraint's backrest
could lead to serious or fatal injuries.<
More information on automatic deactivation of
the front passenger airbags, refer to page 83.
Backrest width adjustment
The backrest width adjustment of the
passenger seat must be opened com-
pletely. After the child's seat is installed, mem-
ory positions must not be requested and the
active backrest width adjustment must be
deactivated, otherwise there is the risk of
injury.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Transporting children safely
48
1. After the vehicle is unlocked, sit in the pas-
senger seat and close the door.
2. Open the backrest width adjustment com-
pletely, refer to page 39.
3. Deactivate active backrest width adjust-
ment, refer to page 40.
4. Install child's seat.
Installing child-restraint
systems
Before installing any child-restraint system or
child seat, read the following:
Observe the child-restraint system man-
ufacturer's instructions for installation
and use. Otherwise the degree of protection
may be reduced. After an accident, have all
parts of the child-restraint system and of the
relevant vehicle safety belt system checked and
replaced if necessary. Have this work done only
at your BMW center or at a workshop that works
according to BMW repair procedures with cor-
respondingly trained personnel. <
Commercially-available child-restraint systems
are designed to be secured with a lap belt or
with the lap belt portion of a combination lap/
shoulder belt. Improperly or inadequately
installed restraint systems can increase the risk
of injury to children. Always read and follow the
instructions that come with the system.
Child seat security
All of the rear belt retractors and the front pas-
senger safety belt can be locked for mounting
and securing child-restraint systems.
Information regarding this is located near the
buckle latch of each safety belt.
To lock safety belt
Pull the entire length of the belt from the belt
retractor. Allow the reel to retract the belt
somewhat and engage the buckle, then tighten
the belt against the child-restraint system. The
retraction mechanism is now locked.
To unlock the safety belt
Release the buckle, remove the child-restraint
system and allow the belt retractor to reel the
belt completely in.
Child-restraint system with tether
strap
If you use a child-restraint system with a tether
strap, three additional tether anchorage points
have been provided, refer to the arrows in the
illustration. Depending on the location selected
for sitting in the rear passenger area, attach the
tether strap to the corresponding anchorage
point to secure the child-restraint system, as
shown in the illustration below.
Placement of the tether strap
Outer sitting positions:
Lift the head restraint and pass the tether strap
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
49
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
between the head restraint and the seat back. It
is recommended to readjust the head restraint
into the lowest possible position.
Center sitting position:
Pull the center armrest forward somewhat to
guide the tether strap through the opening.
Then reengage the center armrest.
Adjust the tether strap according to the
child-restraint manufacturer's instruc-
tions.<
LATCH child-restraint fixing system
LATCH: Lower Anchor and Tethers for CHil-
dren.
The rear outer sitting positions are provided
with anchors for a LATCH child-restraint fixing
system.
To attach the LATCH child-restraint fix-
ing system, follow the operating and
safety instructions of the manufacturer.<
Access to anchorage points on rear
seat with through-loading system
The illustration shows the left rear seat as an
example.
The anchorage points for the LATCH child-
restraint fixing system are located underneath
the identifying symbols.
Before attaching the LATCH child-restraint fix-
ing system, pull the belt out of the region of the
child-restraint fixing system.
Access to anchorage points on rear
seat with through-loading system
The illustration shows the right rear seat as an
example.
The anchorage points for the LATCH child-
restraint fixing system are located behind the
indicated protective caps.
Before attaching the child-restraint fixing sys-
tem, remove the LATCH protective caps and
pull the belt away from the region of the child-
restraint fixing system.
On journeys
If the rear is equipped with side airbags,
make sure that children do not lean out of
the child's seat towards the door panels. Other-
wise severe injuries can be caused if the side
airbags are triggered.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Transporting children safely
50
Child-safety locks for rear doors
Slide down the safety lever on the rear doors:
The door can now be opened from the outside
only.
Safety switch for power windows
Always press the safety switch for the power
windows, refer to page 35, when children are
riding in the rear of the vehicle.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
51
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Driving
Ignition lock
0 Steering locked
The key can only be inserted or removed in this
position.
After removing the key, turn the steering wheel
slightly until it locks.
Interlock on automatic transmission
> Only move the selector lever from posi-
tion P when the engine is running.
> To turn the key back to position 0 or to
remove it, first place the selector lever in
position P.
1 Steering unlocked
A slight steering wheel movement often makes
it easier to turn the key from 0 to 1.
Some vehicle systems are ready for operation.
2 Ignition switched on
All vehicle systems are ready for operation.
3 Start engine
Starting engine
Do not run the engine in closed rooms, as
otherwise the inhaling of toxic exhaust
gases can cause unconsciousness and death.
The exhaust gases contain carbon monoxide,
an odorless and colorless, but highly toxic gas.
Never leave an unattended vehicle with the
engine running, as such a vehicle represents a
potential safety hazard.
To prevent the vehicle from rolling, always
select neutral position or position N and apply
the handbrake before leaving the vehicle with
the engine running.<
When starting the engine, do not press the
accelerator pedal.
Do not allow the engine to warm up by leaving it
running while the vehicle remains stationary.
Instead, begin to drive immediately at a moder-
ate engine speed.
Special starting conditions
Press the accelerator pedal halfway down when
starting if
> the engine fails to start on the first attempt,
for instance, if it is very hot or cold
> the engine is started at very low tempera-
tures, below approx. 57/–156, at high
altitudes, over approx. 3,300 ft/1,000 m.
Avoid frequent starting in quick succes-
sion or repeated start attempts in which
the engine does not start. Otherwise, the fuel is
not burned or inadequately burned and there is
a danger of overheating and damaging the cat-
alytic converter.<
Manual transmission
1. Apply the handbrake.
2. Gearshift lever in neutral position.
3. Press the clutch pedal.
If the clutch pedal is not depressed,
the engine will not start.<
4. Start the engine.
Do not end the starting procedure too early,
however after approx. 20 seconds at the lat-
est. Release the ignition key immediately as
soon as the engine starts.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Driving
52
SMG Sequential manual transmission
and automatic transmission
Your BMW is equipped with the convenience
starting feature. It is sufficient to turn the igni-
tion key into position 3 for only a short time and
then release it again. The system responds by
automatically engaging the starter for a certain
period and allowing it to run until the engine
starts, after which it then disengages automati-
cally.
SMG Sequential manual transmission
1. Press the brake pedal.
2. Place selector lever in position N.
3. Start the engine.
If the engine does not start, shift back to
the last gear selected, refer to Instrument
cluster display, and then shift into position N.<
Automatic transmission
1. Press the brake pedal.
2. Place selector lever in position P or N.
3. Start the engine.
Switching off engine
Do not remove the ignition key while the
vehicle is rolling, as otherwise the steer-
ing wheel lock will immobilize the steering.
When leaving the vehicle, remove the ignition
key and lock the steering. When parking on a
downhill incline, apply the handbrake, as other-
wise the vehicle could roll away.<
Manual transmission
1. Turn the ignition key to position 1 or 0.
2. Shift into first gear or reverse.
SMG Sequential manual transmission
1. Engage a driving position.
2. Turn the ignition key to position 1 or 0.
A signal sounds if the transmission is in
Neutral when the engine is switched off.
Automatic transmission
1. Engage selector lever position P.
2. Turn the ignition key to position 1 or 0.
Handbrake
The handbrake is primarily intended to prevent
the vehicle from rolling while parked; it brakes
the rear wheels.
Indicator lamp
The indicator lamp lights up, and an
acoustic signal also sounds when start-
ing off. The handbrake is applied.
Indicator lamp for Canadian models.
Applying
The lever locks in position automatically.
Releasing
Pull slightly upwards, press the button and
lower the lever.
If it becomes necessary under special cir-
cumstances to use the handbrake while
driving, it must not be pulled too sharply. In
doing so, continuously press the button of the
handbrake lever. Strong application of the
handbrake can lead to overbraking of the rear
axle and associated 'fishtailing' of the vehicle
rear end.
The brake lamps do not light up when the hand-
brake is applied.<
To prevent corrosion and one-sided brak-
ing action, occasionally apply the hand-
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
53
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
brake lightly when the vehicle is slowly coming
to a stop if the traffic conditions are suitable.<
Manual transmission
When shifting into 5th/6th gear, press the
selector lever toward the right, otherwise
an inadvertent shift into 3rd or 4th gear could
damage the engine.<
Reverse gear
Select only when the vehicle is stationary.
When pressing the gearshift lever to the left,
overcome some resistance.
The backup lamps switch on automatically
when the ignition key is in position 2.
SMG Sequential manual
transmission*
The concept
The SMG Sequential manual transmission is an
automated manual transmission in which an
electrohydraulic system handles the clutching
and gear changes.
You operate the SMG using the selector lever in
the center console and two shift paddles on the
steering wheel.
It offers you the following functions:
> Optional manual or automatic operation:
Sequential mode or Drive mode
> You have a choice of two driving programs:
Normal or Sport, refer to Dynamic Driving
Control page 54
> Automatic downshifting and prevention of
incorrect shifting even in sequential opera-
tion
> Acceleration assistant, refer to page 55.
The SMG is operational when the ignition key is
in position 2.
Selector lever positions
The current selector lever position is displayed
on the center console.
> R: Reverse
> N: Neutral
> One-touch functions for Sequential mode:
+: manual upshifting
–: manual downshifting
> D: Drive mode
The transmission automatically shifts into
N if the driver's door is opened with the
engine running and neither the pedals, the shift
paddles nor the selector lever are operated.
This is indicated by an acoustic signal and the
flashing display N in the instrument cluster.<
Gear display
R N 1 to 6
The currently engaged gear is displayed, pre-
ceded by a D in Drive mode.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Driving
54
Shiftlock
Press the brake pedal before shifting out of N;
the shift command will not be executed unless
the brake is applied.
R Reverse
Select only when the vehicle is stationary.
Sequential mode
After every engine start, as soon as the selector
lever is pushed to the right and the brake pedal
is pressed, the Sequential mode is activated.
You can shift up and down using the shifting
paddles or the selector lever. You do not need
to remove your foot from the accelerator to do
so.
It is also possible to start off in second gear, e.g.
in slippery conditions.
D Drive mode
In the Drive mode, all forward gears are shifted
automatically.
Shifting from Sequential mode to Drive mode:
press selector lever to the right toward D.
Kick-down:
For rapid acceleration, e.g. when passing, press
the accelerator pedal as far down as it will go.
You achieve maximum acceleration.
To switch back into the Sequential mode: press
selector lever to the right again toward D or shift
using the shifting paddles or the selector lever.
Start off quickly on slopes. Do not hold
the vehicle on a hill by pressing the accel-
erator, but apply the handbrake instead. Other-
wise overheating can occur in the transmission
region.<
Gear changes
Using selector lever
> To upshift, pull the selector lever back.
> To downshift, push the selector lever for-
ward.
Using shift paddles on steering wheel
> To upshift, pull one of the shift paddles.
> To downshift, press.
In the following situations, the SMG in Sequen-
tial mode assists you:
> Upshifts and downshifts are executed only
when they will result in a plausible combina-
tion of engine and vehicle speed; thus, for
example, a downshift that would cause the
engine to overrev will not be executed by
the system.
> When the vehicle is stationary, the trans-
mission automatically downshifts into first
gear.
> Shortly before dropping below a gear-
dependent minimum speed, the transmis-
sion downshifts automatically even without
your intervention.
Dynamic Driving Control
The Dynamic Driving Control makes it possible
for your BMW to react in an even more perfor-
mance-oriented manner at the push of a button:
> The engine responds more spontaneously
to accelerator pedal movements.
> Gearshifts are faster.
> The engine speed range is used optimally in
the Drive mode.
> Cruise control
*
:
The stored speed is reached more quickly
when it is requested.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
55
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Activating system
Press the SPORT button with the ignition key in
position 2.
The LED in the button lights up and SPORT is
displayed in the instrument cluster.
Deactivating system
Press the SPORT button again.
The LED in the button and SPORT in the instru-
ment cluster go out.
Acceleration assistant
The acceleration assistant enables optimized
vehicle acceleration at racing car level on road
surfaces with good adhesion when starting off.
Do not use the acceleration assistant too
often, as otherwise components will wear
prematurely.<
1. Activate the Dynamic Traction Control.
2. Press the DTC button, refer to page 78, for
longer than 3 seconds.
3. Quickly press accelerator pedal all the way
down: kick-down. The ideal starting-off
engine speed is set.
To maintain driving stability, do not deac-
tivate DSC if at all possible.<
Automatic transmission with
Steptronic
In addition to fully automatic operation, you can
also manually shift with the Steptronic, refer to
page 56.
Selector lever positions
P R N D M/S + –
Displays in instrument cluster
P R N D DS M1 to M6
The selector lever position is indicated, and in
the manual mode the gear currently engaged.
Changing selector lever positions
An interlock prevents inadvertent gearshifts
into selector lever positions R and P. To cancel
the interlock, press the button on the front of
the selector lever knob, refer to arrow.
Shiftlock
Press the brake pedal before shifting out of P
or N; the shift command will not be executed
unless the brake is applied.
To prevent the vehicle from creeping after you
select a driving position, maintain pressure on
the brake pedal until you are ready to start.
P Park
Select only when the vehicle is stationary.
The rear wheels are locked.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Driving
56
R Reverse
Select only when the vehicle is stationary.
N Neutral
For example, engage in automatic car washes.
The vehicle can roll.
D Drive, automatic position
Position for normal vehicle operation. All for-
ward gears are available.
Under normal operating conditions, fuel con-
sumption is lowest when driving in position D.
Kick-down
The kick-down mode provides maximum accel-
eration: press the accelerator pedal beyond the
full-throttle resistance point.
Manual operation and Sport program
M/S
Move selector lever from position D toward the
left into the M/S shifting slot:
The sport program is activated and DS appears
in the instrument cluster. This position is
recommended for a performance-oriented
driving style.
When the selector lever is pressed forward or
back, the manual mode is activated and the
Steptronic shifts the gear. The instrument clus-
ter shows M1 through M6.
Upshifts and downshifts are executed only
when they will result in a plausible combination
of engine and vehicle speed; thus, for example,
a downshift that would cause the engine to
overrev will not be executed by the system. The
selected gear appears briefly in the instrument
cluster, followed by the current gear.
To use the automatic function again, move the
selector lever to the right into position D.
Turn signals/
headlamp flasher
1 High beams
2 Headlamp flasher
3 Turn signals
Using turn signals
Press the lever beyond the resistance point.
To turn off manually, press the lever to the
resistance point.
Atypically rapid flashing of the indicator
lamp indicates that a turn signal bulb
needs to be replaced.
After switching off the ignition, make sure that
the roadside parking lamps are not switched
on.<
Signaling for a short time
Press lever to resistance point and hold for as
long as you wish to signal.
Triple turn signal activation
Press the lever to the resistance point; the turn
signal flashes three times.
You can activate or deactivate this function.
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Vehicle settings" and press the
controller.
3. Select "Light" and press the controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
57
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
4. Select "Triple turn signal activation" and
press the controller.
Triple turn signaling is activated.
Wiper system
1 Switching on wipers
2 Switching off wipers or brief wipe
3 Activating/deactivating rain sensor
4 Cleaning windshield and headlamps
5 Adjusting rain sensor sensitivity level
Switching on wipers
The lever automatically returns to its initial posi-
tion when released.
Normal wiper speed
Press once.
The system reverts to operation in the intermit-
tent mode when the vehicle is stationary.
Fast wiper speed
Press twice or press beyond the resistance
point.
The system reverts to normal speed when the
vehicle is stationary.
Rain sensor
The wiper operation is controlled automatically
as a function of the rain intensity. The rain sen-
sor is located on the windshield, directly in front
of the interior rearview mirror.
Activating the rain sensor
Press button. The LED in the button lights up.
Adjusting rain sensor sensitivity level
Turn the serrated dial 5.
Deactivating the rain sensor
Press the button again. The LED goes out.
Deactivate the rain sensor when passing
through an automatic car wash. Failure to
do so could result in damage caused by undes-
ired wiper activation.<
Cleaning windshield and headlamps*
The system sprays washer fluid against the
windshield and activates the wipers for a brief
period.
When the vehicle lighting system is switched
on, the headlamps are cleaned at regular and
appropriate intervals.
Do not use the washers if there is any
danger that the fluid will freeze on the
windshield. If you do so, your vision could be
obscured. To avoid freezing, use a washer fluid
antifreeze, refer to Washer fluid. Do not use
washing mechanisms when the washer fluid
reservoir is empty, otherwise you will damage
the washer pump.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Driving
58
Windshield washer nozzles
The windshield washer nozzles are automati-
cally heated in ignition key position 2.
Washer fluid
Washer fluid antifreeze is flammable.
Always keep it well away from sparks and
open flames, and store it in tightly closed con-
tainers well out of the reach of children. Always
observe the instructions for use provided on the
containers.<
Washer fluid reservoir
Fill with water and – if required – with a washer
antifreeze, according to manufacturer's recom-
mendations.
In order to maintain the mixture ratio, mix
the washer fluid before filling.<
Capacity
3.2USquarts/3liters, in conjunction with head-
lamp washer system
*
approx. 5.3 US quarts/
5liters.
Cruise control*
The concept
The cruise control is available for use at speeds
of approx. 20 mph/30 km/h and higher. The
vehicle maintains and stores the speed that you
set using the lever mounted on the steering col-
umn.
Do not use the cruise control under driv-
ing conditions that do not permit a con-
stant speed, e.g.when driving on winding roads,
in heavy traffic or in poor road conditions such
as snow, rain, ice, and loose road surface.<
One lever for all functions
1 Maintaining speed, storing speed, and
accelerating
2 Maintaining speed, storing speed, and
decelerating
3 Interrupting cruise control
4 Resuming stored speed
Maintaining speed, storing speed, and
accelerating
Press lever to resistance point 1:
The speed currently being driven is maintained
and stored. The display 1 in the speedometer,
refer to page 59, indicates this regulated speed.
Every time you press the lever, the vehicle's
speed increases by roughly 1 mph/1 km/h.
Press lever to resistance point for a longer time:
The vehicle accelerates without pressure on
the accelerator pedal. The system maintains
and stores your current speed as soon as you
release the lever.
Press the lever beyond the resistance point:
increase speed by 5 mph/10 km/h.
The vehicle may accelerate beyond the regu-
lated speed on steep downhill stretches where
the engine's braking effect alone may not be
sufficient to slow the vehicle. Speed can drop
on uphill grades if the engine output is insuffi-
cient.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
59
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Maintaining speed, storing speed, and
decelerating
Pull the lever 2:
Functions are the same as 1, only the vehicle
speed is reduced.
Interrupting cruise control
With the cruise control active, briefly press the
lever up or down 3.
In addition, cruise control is automatically deac-
tivated:
> When the brakes are applied
> When the clutch pedal is depressed or the
automatic transmission/SMG is shifted into
the N position
> When the DSC comes on
Resuming stored speed
Press button 4:
The stored speed is resumed and maintained.
Deactivating system
When the ignition is switched off, the system is
deactivated and the stored speed is deleted.
Displays in instrument cluster
1 Stored desired speed display
2 Digital speed display.
Appears briefly when you select your
desired speed
Active cruise control*
The concept
With active cruise control, you can select a
desired speed which is not only automatically
maintained when driving on open roadways, but
also varied to maintain a selected distance set-
ting as slower traffic is encountered.
Active cruise control is a technological advance
over the familiar cruise control and is a welcome
relief from the constant adjustment of speed
that can accompany driving in traffic on free-
ways or other high-speed thoroughfares. Espe-
cially on longer trips, the system can reduce
fatigue and tension, while increasing your
enjoyment of driving. Please use it safely and
responsibly.
In addition to holding a steady cruising speed,
if you encounter slower vehicles ahead, active
cruise control will, within the scope of given
possibilities, adjust your vehicle's speed auto-
matically so that you can flow with the traffic
without having to make constant adjustments.
If, for example, while cruising at the selected
speed, you begin to approach a slower vehicle
ahead of you in the same lane, the system will
reduce your vehicle's speed to the same as that
of the vehicle ahead to maintain your selected
distance setting between your vehicle and the
vehicle ahead. There are four settings for dis-
tance, which are additionally speed-dependent.
Based on your selected distance setting, the
system automatically decreases the throttle
setting and lightly applies the brakes if neces-
sary. The vehicle brake lamps will automatically
illuminate to signal a following driver to take
action. In addition, it may be necessary for the
vehicle or the driver to downshift, depending on
the kind of transmission your vehicle is
equipped with, to maintain the distance setting
selected. If the vehicle ahead speeds up or
when the lane ahead becomes clear, your vehi-
cle will accelerate to the speed you have
selected by increasing the throttle setting and
shifting gears automatically or by the driver as
needed.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Driving
60
Active cruise control is not and must not
be used as a collision avoidance/warning
system.<
Since this active cruise control system is
a new technology and operates differ-
ently from conventional cruise control systems
which you may be accustomed to, you are
strongly urged to read all of the pages relating
to this system before use. Pay special attention
to the information contained in the Things to
know about active cruise control section in this
manual beginning on page 62.<
Vehicles with manual transmission
You can use the system in the 2nd to 6th gear
within a normal engine speed range and also
change gears. Continuous operation at very
high or very low engine speeds is not possible.
In this case the driver is asked to shift or the
system deactivates itself.
Vehicles with SMG
Continuous operation at very high engine
speeds is not possible in the Sequential mode.
In this case the driver is asked to shift or the
system deactivates itself.
In the Drive mode, the SMG acts similarly to the
automatic transmission in the D position.
Operating active cruise control
1 Activate system, store and increase desired
speed
2 Activate system, store and decrease
desired speed
3 Deactivate system
4 Recall the stored speed and distance or
increase desired speed by 1 mph/1 km/h
with each press of the button
5 Select distance to vehicle driving ahead.
You can choose from four available distance
settings. You will find more detailed infor-
mation on page 62.
Adjust your desired speed to the traffic
conditions and remain ready to brake at
all times. Great differences in speed to the vehi-
cles driving ahead, e.g. when quickly approach-
ing a truck or when another vehicle swerves into
your lane, cannot be compensated for by the
system.<
Displays in instrument cluster
1 Stored desired speed display
2 Detected vehicle display. Lights up when
vehicle driving ahead is detected
3 Selected distance to vehicle driving ahead
4 Digital speed display.
Appears briefly when you select your
desired speed
The system is activated.
The display 3 appears as soon as
you activate the system and no
vehicle is detected driving ahead.
Vehicle detected.
The display 2 lights up yellow
when a vehicle is detected driving
ahead.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
61
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
The system requests that you
intervene by braking or with an
evasive maneuver. The display 2
flashes red and a signal sounds.
The active cruise control cannot
automatically restore the distance to the vehicle
driving ahead. You will find more detailed infor-
mation on page. You will find more detailed
information on page 64.
Automatic intervention by ABS or
DSC, or you actuate the handbrake
while driving. The display 2 flashes
yellow. The active cruise control
now only intervenes by braking.
Desired speed, store and increase
Press the lever forward 1 at a driving speed of
more than approx. 20 mph/30 km/h:
The system applies and stores your current
speed as a desired speed. This speed is indi-
cated on the speedometer and displayed briefly
in the instrument cluster.
Subsequently pressing forward increases the
desired speed to the next multiple of 5 mph/
10 km/h. Each time the lever is pressed forward
again, the desired speed is increased by
another 5 mph/10 km/h until a maximum of
110 mph/180 km/h is reached. The speed then
displayed is stored and achieved, provided that
the road is clear.
If the display ACC --- mph/km/h briefly
appears in the instrument cluster, it might
be that conditions necessary for operation are
not currently being met.
To call up Check Control messages, refer to
page 67.<
Desired speed, store and decrease
Pull back the lever 2:
The current driving speed is rounded off to the
next multiple of 5 mph/10 km/h, displayed and
stored.
Each time the lever is pulled back again, the
desired speed is decreased by another 5 mph/
10 km/h until the minimum speed of 20 mph/
30 km/h is reached. The speed then displayed
is stored and achieved, provided that the road is
clear.
Deactivate system
Press the lever up or down while the system is
active 3. The displays in the instrument cluster
disappear. You can use the system again as
required.
In addition, the system is deactivated automati-
cally:
> When you apply pressure to the brake pedal
> When you select the automatic transmis-
sion's/SMG's neutral position N
> When the manual transmission is shifted
into neutral
> When you deactivate the DSC Dynamic
Stability Control
> When you actuate the handbrake during
driving
> When the system reduces the speed to
below 20 mph/30 km/h due to a traffic situ-
ation
The system deactivates automatically
when the speed is set to below 20 mph/
30 km/h. An acoustic signal sounds and a mes-
sage appears on the Control Display. The active
intervention of the driver is required.<
When you switch off the ignition, the stored
desired speed is deleted.
Resume stored desired speed and
distance setting
Press button 4 when the system is deactivated.
The displays appear in the instrument cluster.
The system is reactivated and uses the last
stored desired speed and distance setting.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Driving
62
Fine adjustment of desired speed
In the activated state, the desired speed
increases by 1 mph/1 km/h each time button 4
is pressed briefly.
Select distance
You can choose from four distance steps.
> Rotary switch downward:
Increase distance
> Rotary switch upward:
Decrease distance
The selected distance is displayed in the instru-
ment cluster.
Distance 1
Distance 2
Distance 3
This distance is always set when
the system is used for the first time
after starting the engine.
Distance 4
Use good judgment to select the appro-
priate following distance given road con-
ditions, traffic, applicable laws and driving rec-
ommendations for safe following distance.<
Things to know about active cruise control
As with conventional cruise control sys-
tems, active cruise control in no way
diminishes or substitutes for the driver's own
personal responsibility, alertness and aware-
ness in adjusting speed, braking or otherwise
controlling the vehicle. The driver should
decide when to use the system on the basis of
road, traffic, visibility, and weather conditions.
Active cruise control is intended for use on
highway-type roadways where traffic is moving
relatively smoothly. Do not use this system in
city driving; heavy traffic such as during rush
hour; on curvy, winding roads, slippery roads or
roads with sharp curves such as highway off-
ramps; during inclement weather such as snow,
strong rain or fog; or when entering inter-
changes, service/parking areas or toll booths.
It is also important to regulate your vehicle's
speed and distance setting within applicable
legal limits. Always be ready to take action or
apply the brakes if necessary, especially when
the system is actively following a vehicle in front
of you.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
63
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Always remember that the range and abil-
ity of the system does have physical limi-
tations. It will not apply the brakes or decelerate
your vehicle when there is a slow-moving vehi-
cle, stopped vehicle or stationary object ahead
of you, as for example, at a traffic light or a
parked vehicle. Also, the system does not react
to oncoming traffic, pedestrians or other types
of potential traffic such as a rider on horseback.
It is also possible that the system may not
detect smaller moving objects such as motor-
cycles or bicycles. Be especially alert when
encountering any of these situations as the sys-
tem will neither automatically brake, nor provide
a warning to you. Also, be aware that every
decrease in the distance setting allows your
vehicle to come closer to a vehicle in front of
you and requires a heightened amount of alert-
ness.<
If while your vehicle is actively following a vehi-
cle in front of you and the vehicle ahead speeds
up or the lane ahead becomes clear, then your
vehicle will accelerate to the speed you have
selected. Be aware that changing to a clear,
unobstructed lane will also result in your vehicle
accelerating.
Be certain to deactivate the system when
you pull into an exit lane for a highway off-
ramp.<
Also, vehicles traveling in a staggered manner
on a highway may cause a delay in the system's
reaction to a vehicle in front of you or may cause
the system to react to a vehicle actually in the
lane next to you. Always be ready to take action
or apply the brakes if necessary.
Active cruise control can only decelerate the
vehicle to approx. 20 mph/30 km/h. If the sys-
tem reduces vehicle speed below 20 mph/
30 km/h or if DSC/ABS is engaged while driving,
the system will automatically deactivate.
Remember, the system cannot stop your
vehicle. In addition, the system is deacti-
vated whenever the driver applies the vehicle
brakes, shifts the transmission to neutral/N, or
deactivates DSC. After any deactivation, the
system will no longer automatically activate the
vehicle brakes, which means the driver must
intervene and resume manual braking. You
should then reactivate the system only when
you are fully aware of the prior speed and dis-
tance settings.<
Active cruise control may brake when you
reduce the stored desired speed; however, the
driver must constantly monitor traffic and inter-
vene if necessary.
When you switch off the engine or ignition,
active cruise control is fully switched off, too,
and any settings you have selected are can-
celed.
Behavior in curves
Because of the limited range of the system, it is
possible that in curves or on the peaks and val-
leys of hilly roads, a vehicle ahead may be rec-
ognized late, or not at all. Therefore, it is up to
the driver to select a speed that is prudent in
view of the curves and terrain of the roadway.
In approaching a curve, it is possible that active
cruise control would react briefly to a vehicle in
the adjacent lane. In addition, the system can
sense if your vehicle is in a curve and may not
accelerate. If your vehicle decelerates in either
case, you can choose to overcome the deceler-
ation by briefly pressing the accelerator pedal.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Driving
64
Driver interventions
Anytime the driver presses down on the
accelerator pedal, any automatic braking
action by the system is interrupted until the
pedal is fully released. After doing this, release
the accelerator and the system again controls
your cruising speed and distance setting. While
driving with activated system, resting your foot
on the accelerator pedal will cause the system
not to brake even if necessary. Be certain that
floormats or other objects on the vehicle floor
do not interfere with movement of the accelera-
tor pedal.<
While active cruise control is capable of
braking your vehicle automatically when
you approach a slower vehicle ahead, it is
important to be aware that the ability of the sys-
tem to apply the brakes is also limited, particu-
larly if you are driving down a steep grade or
when you reduce your desired speed sharply.
The system cannot stop your vehicle. It uses
only a portion of braking system capacity and
does not utilize the full capacity of the vehicle
braking system. Therefore, the system cannot
decrease your speed for large differences in
speed between your vehicle and the vehicle
ahead. Examples: during emergency braking,
when you approach a vehicle traveling at a
much lower speed than your own speed such as
approaching a toll booth or when a much slower
vehicle cuts in front of you at close range.<
Whenever active cruise control
recognizes a situation that requires
driver braking because the system
capacity has been reached or has
been exceeded, the system alerts
the driver by flashing this symbol in the instru-
ment cluster and sounding a signal.
Swerving vehicles
When a vehicle moves from an adjacent lane
into your lane, active cruise control will not rec-
ognize this vehicle until it is fully in your lane
ahead of your vehicle.
Malfunction
The indicator lamp lights up and a mes-
sage appears on the Control Display.
The build-up of foreign matter, e.g.,
snow, ice, dirt, road debris etc., can lead to
reduced detection performance of active cruise
control. You should check the sensor under the
front bumper and clean it as necessary prior to
driving your vehicle. If the sensor becomes cov-
ered by foreign matter or has a malfunction, it is
possible that the sensor will no longer be able to
detect vehicles in front of you. After the system
recognizes that the sensor is no longer func-
tional, a message is displayed on the Control
Display and an acoustic signal is emitted.
When the system does not recognize any
objects, e.g. on infrequently traveled roads
without a shoulder or guard rails, the system
can automatically deactivate temporarily.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
65
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Everything under control
Odometer, outside
temperature display, clock
When the ignition is off you can briefly activate
the time, outside temperature and odometer
displays by pressing the knob 3 in the instru-
ment cluster.
1 Outside temperature display, time,
date
The outside temperature and the time are dis-
played as of ignition key position 1.
Date retrieval:
Press CHECK button on turn signal lever, refer
to page 69.
Time and date setting, refer to page 74.
You can set the measurement unit 7 or 6 on
the Control Display, refer to Measurement units
on page 73.
Ice warning
A signal sounds when the outside temperature
falls to approx. +37.57/+36; this is accompa-
nied by a message.
Please bear in mind that the ice warning
does nothing to alter the fact that black
ice may be present on roads at temperatures
higher than +37.57/+36, e.g. on bridges and
shaded roads.<
2 Odometer and trip odometer
Resetting trip odometer: press the knob 3 in the
instrument cluster.
Tachometer
The white-striped advance warning field,
arrow 1, changes depending on the engine
temperature. The segments disappear in
sequence as the engine warms to its normal
operating temperature. Avoid allowing the
engine speed to rise as far as the orange warn-
ing sector whenever possible.
Engine speeds in the red warning field, arrow 2,
must absolutely be avoided. In this range, the
fuel supply is interrupted to protect the engine.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything under control
66
Energy Control
Displays the current fuel consumption. This
allows you to see whether your current driving
style is conducive to fuel economy with mini-
mum exhaust emissions.
Fuel gage
Fuel tank capacity: approx. 18.5 gallons/
70 liters, including the reserve capacity of
approx. 2.1 gallons/8 liters. You can find infor-
mation on refueling on page 168.
If the tilt of the vehicle varies for a longer period,
when you are driving in mountainous areas, for
example, the indicator may fluctuate slightly.
After the reserve quantity has been reached, a
message appears for a short time on the Con-
trol Display; the remaining range is shown in the
computer. With a range below approx. 30 miles/
50 km, the message remains on the Control
Display.
Refuel as soon as possible once your
cruising range falls below 30 miles/
50 km, as otherwise engine functions are not
ensured and damage can occur.<
Service requirements
The remaining travel distance and the date for
the next maintenance are displayed briefly
when the ignition key is in position 2.
Your BMW Service Advisor can deter-
mine your vehicle's current service
requirements by reading out the data stored in
the master key.<
Additional information
You can view additional information on service
and maintenance procedures on the Control
Display.
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Service" and press the controller.
3. Select "Service requirements" and press
the controller.
4. Select "Status" and press the controller
The display shows a list of selected service and
maintenance procedures, as well as legally
mandated inspections.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
67
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Symbols
No service is currently required.
The deadline for service or a legally man-
dated inspection is approaching. Please
arrange a service appointment soon.
The service deadline has already passed.
You can request more detailed information on
every entry.
Select the entry and press the controller.
To exit from the menu:
Select the arrow and press the controller.
Entering dates for state emission and
vehicle inspections
Make sure the date on the Control Display is
always set correctly, refer to page 74, as other-
wise the effectiveness of CBS Condition Based
Service is not ensured.
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Service" and press the controller
3. Select "Service requirements" and press
the controller.
4. Select "Status" and press the controller
5. Select "Emission inspect." or "State
inspection" and press the controller.
6. Select "Set service date" and press the
controller. The month is highlighted.
7. Turn the controller to make the adjustment.
8. Press the controller to apply the setting.
The year is highlighted.
9. Turn the controller to make the adjustment.
10. Press the controller to apply the setting.
The date entry is stored.
To exit from the menu:
Select the arrow and press the controller.
Check Control
The concept
The Check Control monitors functions in the
vehicle and issues a message if there is a mal-
function in the monitored systems.
Supplementary messages on the Control Dis-
play are intended to assist you in assessing the
severity of malfunctions; they provide you with
the information you need to decide on the best
way to respond.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything under control
68
An example of a message is given below.
In the instrument cluster
This symbol means that a Check Control
message has been generated. The symbol
remains even if the message has been automat-
ically masked after a short time, but is still in
memory.
On the Control Display
An acoustic signal sounds at the same time.
Supplementary instructions
Example:
Exit supplementary instructions:
Select the arrow and press the controller.
Importance of messages
Important messages remain until the malfunc-
tions have been corrected. They cannot be
deleted. If a number of malfunctions occur
simultaneously, they are displayed in succes-
sion.
Less important messages are displayed for
approx. 20 seconds, but remain in memory.
To blank out these messages during the display
period:
Press the CHECK button on turn signal lever.
Check Control symbol and information
on the Control Display
No malfunctions are present in the moni-
tored systems.
Malfunctions are present in the moni-
tored systems.
Depending on the malfunction, supple-
mentary information is shown on the
Control Display.
The symbols also indicate the status of the ser-
vice requirements display, refer to page 66.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
69
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Recalling stored messages
Using CHECK button
1. Hold the button down:
The first stored message is displayed.
2. Press the button:
When the button is pressed again, a differ-
ent message is displayed.
Using Control Center
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Press the controller to open the menu.
3. Select "Service" and press the controller.
4. Select "Check Control messages" and
press the controller. The stored messages
appear on the display
5. Select a message and press the controller.
The display disappears automatically after a
short time.
In order to exit from the display immediately:
Select the arrow and press the controller.
Displays after completion of trip
Malfunction reports generated during the trip
are shown consecutively when you switch off
the ignition.
Before the display disappears, you can display
the messages once again. Press the CHECK
button for approx. 2 seconds. If several mes-
sages are present, you can continue to press
the CHECK button to view them in succession.
The display goes out
> automatically after a brief period
> when you press the CHECK button again
for approximately 2 seconds.
Computer
Requesting functions
As of ignition key position 1, you can use the BC
button in the turn signal lever to call up com-
puter information in the instrument cluster.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything under control
70
Further information appears each time you
press the BC button.
In the instrument cluster
The display sequence:
> Cruising range
> Average speed
> Average fuel consumption
Cruising range
Displays the estimated cruising range available
with the remaining fuel. It is projected based on
the driving style over the last 20 miles/30 km.
Refuel as soon as possible once your
cruising range falls below 30 miles/
50 km, as otherwise engine functions are not
ensured and damage can occur.<
Average speed
Periods with the vehicle parked and the engine
switched off are not included in the calculations
of average speed.
To reset average speed: press BC button on
turn signal lever for approx. 2 seconds.
Average fuel consumption
The average fuel consumption is calculated for
the time during which the engine is running.
You can use the Control Display to view your
fuel consumption rate over two different dis-
tances, refer to Computer or Trip computer*.
To reset average fuel consumption: press BC
button on turn signal lever for approx. 2 sec-
onds.
On the Control Display
You can also call up the computer via the Con-
trol Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Move the controller to the right to open
"Navigation".
In vehicles without navigation system:
Open "Car Data".
3. Select "Car Data" and press the controller
You now have a choice between:
> Computer
> Trip computer,
suitable e.g. for a vacation trip.
Computer
Select "Onboard info" and press the controller.
> Estimated time of arrival at destination:
> Entering a distance manually in the com-
puter, see below.
> Entering a destination in the navigation
system
*
, refer to page 115.
> Cruising range
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
71
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
> Distance to destination:
> Entering a distance manually in the com-
puter, see below.
> Entering a destination in the navigation
system
*
, refer to page 115.
> Average speed
> Average fuel consumption
Trip computer*
Select "Trip computer" and press the control-
ler.
> Departure time
> Driving time
> Distance traveled
> Average speed
> Average fuel consumption
Trip computer, starting, stopping, or resetting
all values:
1. Select "Set" and press the controller.
2. Select the desired menu item.
3. Press the controller.
Entering a distance manually
Control Center, for principle details, refer to
page 16.
1. Open "Navigation".
In vehicles without a navigation system:
Open "Car Data".
2. Select "Car Data" and press the controller.
3. Select "Onboard info" and press the con-
troller.
4. Select "Distance to dest." and press the
controller.
5. Turn the controller to select the distance to
your destination. If needed, hold it against a
slight resistance to enter a larger difference.
6. Press the controller to apply the setting.
The distance is automatically preset during the
destination guidance of the navigation sys-
tem
*
.
Display options
You can display the computer or the trip com-
puter in the assistance window.
Control Center, for principle details, refer to
page 16.
1. Move the controller to the right to change to
the assistance window and press the con-
troller.
2. Select a menu item:
> "Onboard info"
> "Trip computer"
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything under control
72
3. Press the controller.
Speed limit
You can enter a speed and a Check Control
message indicates when you have reached this
speed. This enables you, for example, to
receive warnings if you exceed a speed limit in
an urban area.
You are only warned of reaching this speed a
second time if your vehicle speed falls below it
again by at least 3 mph/5 km/h.
Entering, changing
Control Center, for principle details, refer to
page 16.
1. Open "Navigation".
In vehicles without a navigation system:
Open "Car Data".
2. Select "Car Data" and press the controller.
3. Select "Limit" and press the controller.
4. Select the speed and press the controller.
5. Turn the controller to set the limit. If
needed, hold it against a slight resistance to
enter a larger difference.
6. Press the controller to apply the setting.
Applying your current speed as limit
Control Center, for principle details, refer to
page 16.
1. Open "Navigation".
In vehicles without a navigation system:
Open "Car Data".
2. Select "Car Data" and press the controller.
3. Select "Limit" and press the controller.
4. Select "Select current speed" and press
the controller. The system adopts your cur-
rent speed as the limit.
Activating limit
Control Center, for principle details, refer to
page 16.
1. Open "Navigation".
In vehicles without a navigation system:
Open "Car Data".
2. Select "Car Data" and press the controller.
3. Select "Limit" and press the controller.
4. Select "On" and press the controller.
Limit is activated.
Stopwatch
Control Center, for principle details, refer to
page 16.
1. Open "Navigation".
In vehicles without a navigation system:
Open "Car Data".
2. Select "Car Data" and press the controller.
3. Select "Stopwatch" and press the control-
ler.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
73
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Starting and stopping
> Select "Start" and press the controller.
The stopwatch starts at the displayed time.
> Select "Reset" and press the controller.
The stopwatch is reset and it restarts if it
was running beforehand.
> Select "Stop" and press the controller.
This stops the timer.
Taking an intermediate time reading
Select "Interim time" and press the controller.
The interim time appears below the ongoing
primary stopwatch count.
All of the remaining functions remain
available at all times while the stopwatch
is running. The stopwatch continues operation
in the background.<
Settings on Control Display
Brightness of Control Display
The brightness is automatically adapted to the
ambient lighting conditions. However, you can
change the base setting.
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Press the controller to open the menu.
3. Select "Display settings" and press the
controller.
4. Select "Brightness" and press the control-
ler.
5. If necessary, move the controller to the right
to select "Display Offset".
6. Turn the controller until the desired setting
is selected.
The setting is stored for the remote control cur-
rently in use.
Measurement units
You can change the measurement units for
consumption, distances, temperature and
pressure.
1. Open the menu.
2. Select "Display settings" and press the
controller.
3. Select "Units" and press the controller.
4. Select the menu item to be set.
5. Press the controller.
6. Select the desired measurement unit and
press the controller.
The settings are stored for the remote control
currently in use.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything under control
74
Language on Control Display
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Display settings" and press the
controller.
3. Select "Languages" and press the control-
ler.
4. Select "Text language" and press the con-
troller. You can change the language of the
text displays.
5. Select and activate the desired language by
pressing the controller.
The setting is stored for the remote control cur-
rently in use.
Setting time
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Display settings" and press the
controller.
3. Select "Time" and press the controller.
4. Select "Set time" and press the controller.
The hours are highlighted.
5. Turn the controller to set the hours.
6. Press the controller to apply the setting.
The next setting is highlighted.
7. Make the remaining adjustments. After the
last adjustment, the time is stored.
12h/24h mode
1. Select "Time format" and press the control-
ler.
2. Select the desired mode and press the con-
troller.
The setting is stored for the remote control cur-
rently in use.
Switching on hour signal*
You will hear three tones just before each full
hour.
Select "Hour memo" and press the controller.
The hour signal is activated.
Date setting
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Display settings" and press the
controller.
3. Select "Date" and press the controller.
4. Select "Set date" and press the controller.
The first section of the date display is high-
lighted, in this case the month.
5. Turn the controller to make the adjustment.
6. Press the controller to apply the setting.
The next setting is highlighted.
7. Make the remaining adjustments. After the
last adjustment, the date is stored.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
75
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Changing date format
1. Select "Date format" and press the control-
ler.
2. Select the desired format and press the
controller.
The setting is stored for the remote control cur-
rently in use.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Technology for comfort, convenience and safety
76
Technology for comfort, convenience and
safety
PDC Park Distance Control*
The concept
The PDC assists you when you are parking.
Acoustic signals and an optical display
*
alert
you to the approach of an object from behind
your vehicle. To measure the distance, there
are four ultrasonic sensors in each bumper. The
sensors at the front and at the two rear corners
have a range of approx. 24 in/60 cm; the rear
middle sensors have approx. 5 ft/1.50 m.
PDC is a parking aid that can indicate
objects when they are approached
slowly, as is usually the case when parking.
Avoid approaching an object at high speed, as
otherwise the physical circumstances would
mean that the system warning was too late.<
Automatic mode
When the ignition key is in position 2, the sys-
tem automatically assumes operational status
after a few seconds each time you shift into
reverse or move the selector lever into the R
position.
Wait this short period before driving. The sys-
tem switches itself off when you shift out of
reverse.
Manual mode
Press button, the LED lights up.
Deactivating manual mode
Press the button again; the indicator lamp goes
out.
The system is automatically deactivated once
the vehicle travels approx. 165 ft/50 m or
exceeds a speed of roughly 20 mph/30 km/h;
the indicator lamp goes out. You can reactivate
the system manually as needed.
Signal tones
When nearing an object, the position is corre-
spondingly indicated by an interval tone. Thus,
an object detected to the left rear of the vehicle
will be indicated by a signal tone from the left
rear speaker, etc. As the distance between
vehicle and object decreases, the intervals
between the tones become shorter. If the dis-
tance to the nearest object falls to below
roughly 1 ft/30 cm, then a continuous tone
sounds.
The warning signal is canceled after approx.
3 seconds, if you are moving parallel to a wall.
Malfunction
The LED in the button flashes and a message
appears on the Control Display. PDC is mal-
functioning. Have the system checked.
To prevent this problem, keep the sensors
clean and free of ice or snow in order to ensure
that they will continue to operate effectively.
PDC with visual warning*
You can also have the system show distances
to objects on the Control Display. The Control
Display also indicates objects that are farther
away before a signal tone sounds.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
77
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Press the controller to open the menu.
3. Select "Vehicle settings" and press the
controller.
4. Select "PDC" and press the controller.
5. Select "Monitor display on" and press the
controller.
The PDC screen is activated.
The display appears on the Control Display as
soon as PDC is activated.
The setting for the remote control currently in
use is stored.
System limits
Even with PDC, final responsibility for
estimating the distance between the
vehicle and any obstructions always remains
with the driver. Even when sensors are pro-
vided, there is a blind spot in which objects can
no longer be detected.The system is also sub-
ject to the physical limits that apply to all forms
of ultrasonic measurement, such as those
encountered with thin and wedge-shaped
objects, etc. Low objects already displayed,
e.g. a curb, can also disappear from the detec-
tion area of the sensors again before a continu-
ous tone sounds. Loud noises from outside and
inside your vehicle may prevent you from hear-
ing the PDC signal tone.<
Do not apply high pressure spray to the
sensors for a prolonged period of time.
Keep the spray at least 4 in/10 cm away from
the sensors.<
Driving stability control
systems
Your BMW is equipped with an extended array
of systems designed to enhance and maintain
vehicle stability under extreme conditions.
ABS Antilock Brake System
ABS prevents locking of the wheels during
braking. Safe steering response is maintained
even during full braking. Active safety is thus
increased.
The ABS is operational every time you start the
engine. Safe braking, refer to page 107.
CBC Cornering Brake Control
When braking during curves or when braking
during a gear change, driving stability and
steering response are improved further.
Electronic brake-force distribution
The system controls the brake pressure in the
rear wheels to ensure stable braking behavior.
DBC Dynamic Brake Control
When you apply the brakes rapidly, this system
automatically produces the maximum braking
force boost and thus helps to achieve the short-
est possible braking distance during full brak-
ing. This system exploits all of the benefits pro-
vided by ABS.
Do not reduce the pressure on the brake pedal
for the duration of the brake application. When
the brake pedal is released, DBC is deactivated.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Technology for comfort, convenience and safety
78
DSC Dynamic Stability Control
The system prevents traction loss in the driving
wheels when starting off and accelerating. DSC
also detects unstable driving conditions such
as a fishtailing rear end or sliding of the front
wheels. In these cases, DSC helps the vehicle
maintain a safe course within physical limits by
reducing engine output and through braking
actions in the individual wheels.
The DSC is operational every time you start the
engine.
The laws of physics cannot be repealed,
even with DSC. An appropriate driving
style always remains the responsibility of the
driver. Therefore, do not reduce the additional
safety margin again by taking risks.<
DTC Dynamic Traction Control
DTC is a version of DSC in which the drive out-
put is optimized for particular road conditions,
e.g. unplowed snow-covered roads. The sys-
tem assures the maximal drive output, but with
reduced driving stability. It is therefore neces-
sary to drive with appropriate caution.
You may find it useful to briefly activate DTC
under the following special circumstances:
> When driving on snowy inclines, in slush, or
on unplowed, snow-covered road surfaces
> When rocking a stuck vehicle free or start-
ing off in deep snow or on loose ground
> When driving with snow chains
Activating DTC
Press the button briefly; the DTC indicator lamp
in the instrument cluster lights up.
Deactivating DTC again
Press the button again; the DTC indicator lamp
in the instrument cluster goes out.
Deactivating DTC and DSC together
Press the button until the DSC indicator lamp in
the instrument cluster lights up, but not longer
than approx. 10 seconds. Stabilizing and drive
output promoting actions are no longer exe-
cuted. In addition, the stability promoting inter-
vention of the active steering is deactivated,
refer to page 81.
A message appears on the Control Display.
Please note any supplementary information
that appears there.
To increase vehicle stability, activate DSC again
as soon as possible.
Reactivating DSC
Press the button; the DTC indicator lamp in the
instrument cluster goes out.
To control
The indicator lamp flashes:
DSC or DTC controls the drive forces
and brake forces.
The indicator lamp lights up:
DSC and DTC are deactivated together via the
button DTC.
The indicator lamp lights up:
DTC is activated via the DTC button.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
79
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Malfunction in vehicle stability-control
systems
The brake system warning lamp lights
up in red, appearing together with the
indicator lamps for ABS and DSC. A
message appears on the Control Dis-
play. The driving stability control sys-
tems are deactivated. Conventional
braking efficiency remains available
without limitations. While you may con-
tinue, you should remember to proceed cau-
tiously and drive defensively while avoiding full
brake applications. Have the system checked
as soon as possible.
Display of the previously described
malfunction on Canadian models.
The indicator lamp for DSC lights up; a
message appears on the Control Dis-
play. DSC and DTC are deactivated.
The stability maintenance functions are no
longer available. The vehicle remains in running
order. Have the system checked as soon as
possible.
The warning lamp for the brake system
lights up in yellow; a message appears
on the Control Display. DBC has failed.
Have the system checked as soon as possible.
Display of the previously described
malfunction on Canadian models.
Active roll stabilization*
The concept
Active roll stabilization minimizes body roll and
optimizes vehicle stability during cornering and
evasive maneuvers.
Dynamic stabilizers at the front and rear axles
form the basis for active roll stabilization. Sus-
pension compliance adapts to suit driving con-
ditions, varying from performance-oriented
during cornering to smooth and comfort-ori-
ented when the vehicle is proceeding in a
straight line. During vehicle operation, the sys-
tem continuously runs through closed-loop
control cycles lasting only fractions of a second.
The system assumes operational status each
time you start the engine.
Malfunction
The warning lamp lights up and a mes-
sage appears on the Control Display.
There is a malfunction in the system.
Have the system checked as soon as possible.
If there is a malfunction in the system,
please remember to adapt your speed
accordingly, especially in curves. The suspen-
sion will be noticeably softer and the vehicle will
display a greater tendency to tilt during corner-
ing and in crosswinds. If a message stating that
you should stop appears on the Control Display,
stop and switch off the engine as soon as pos-
sible. In this case the oil level in the reservoir
may have dropped below the minimum, possi-
bly owing to a leak in the hydraulic system. Do
not continue driving. Contact your BMW cen-
ter.<
Flat Tire Monitor
The concept
The Flat Tire Monitor keeps track of the infla-
tion pressures in the four mounted tires as you
drive. The system provides an alert whenever
the inflation pressure drops significantly in rela-
tion to the pressure in another tire.
In the event of a pressure loss, the rolling radius
and therefore the rotation speed of the wheels
change. This change is detected and is
reported as a flat tire.
Functional requirement
In order to assure the reliable reporting of a flat
tire, the system must be initialized for the cor-
rect tire inflation pressure.
Perform the initialization immediately
after correcting the inflation pressure,
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Technology for comfort, convenience and safety
80
after changing a tire or after changing a wheel or
all of the wheels.<
System limits
The Flat Tire Monitor cannot indicate
sudden severe tire damage caused by
outside factors and does not detect a natural,
even pressure drop in all four tires.<
In the following situations, the system could be
delayed or malfunction:
> System has not been initialized
> Driving on snowy or slippery road surface
> Sporty driving style: slip in the drive wheels,
high lateral acceleration
> Driving with snow chains
*
When you are driving with the compact wheel,
the Flat Tire Monitor is unable to function.
Initializing system
The initialization finishes during driving,
which can be interrupted at any time.
When driving resumes, the initialization is con-
tinued automatically. When driving with snow
chains or with the compact wheel, do not initial-
ize the system.<
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Vehicle settings" and press the
controller.
3. Select "FTM" and press the controller.
4. Start engine, but do not start driving.
5. Select "Set tire pressure" and press the
controller.
6. Select "Yes" and press the controller.
7. Start to drive.
The message "Initializing" is displayed.
The initialization finishes during driving. Then
the message "Status: Active" appears on the
Control Display again.
Indication of a flat tire
The warning lamp lights up in red and a
message appears on the Control Dis-
play. In addition, an acoustic signal
sounds. There is a flat tire or extensive inflation
pressure loss.
1. Reduce speed and stop the vehicle care-
fully. Avoid sudden braking and steering
maneuvers.
2. Identify damaged tire.
If identification is not possible, con-
tact a BMW center.<
3. Replace the damaged wheel, refer to
Changing a wheel on page 185.
Vehicles with run-flat tires
1. Cautiously reduce speed to below 50 mph/
80 km/h. Avoid sudden braking and steering
maneuvers. Do not exceed a speed of
50 mph/80 km/h.
If the vehicle is not equipped with run-
flat tires, refer to page 174, do not
continue driving. Continuing to drive with a
flat tire could cause severe accidents.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
81
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
2. At the next opportunity, check the air pres-
sure in all four tires.
If the tire inflation pressure in all four
tires is correct, the Flat Tire Monitor
has not been initialized. The system must
then be initialized.<
3. In the event of complete tire pressure loss,
0 psi/0 kPa, or obvious tire damage, you can
estimate the possible distance for contin-
ued driving on the basis of the following
guide values:
> With a light load:
1 to 2 persons without luggage:
approx. 155 miles/250 km
> With a medium load:
2 persons, luggage compartment full, or
4 persons without luggage:
approx. 94 miles/150 km
> With a full load:
4 or more persons, luggage compart-
ment full:
approx. 30 miles/50 km
Drive reservedly and do not exceed a
speed of 50 mph/80 km/h. In the event of
pressure loss, vehicle handling changes. This
includes reduced tracking stability in braking,
extended braking distance and altered natural
steering characteristics.
If unusual vibrations occur while the vehicle is
being driven, this can indicate final failure of the
damaged tire. Reduce speed and stop as soon
as possible. Do not continue driving. Contact
your BMW center.<
Malfunction
The warning lamp lights up yellow and
a message appears on the Control Dis-
play. The Flat Tire Monitor has a mal-
function or has failed. Have the system checked
as soon as possible.
Active steering*
The concept
The active steering is a system that actively var-
ies the steering angle of the front wheels in rela-
tion to the steering wheel movements.
When you are driving in the low road speed
range, e.g. in a town or when parking, the steer-
ing angle increases, i.e. the steering becomes
very direct. In the higher speed range, on the
other hand, the steering angle is reduced more
and more. This improves the handling capability
of your BMW over the entire speed range.
In critical situations, the system can make tar-
geted corrections to the steering angle pro-
vided by the driver and thus stabilize the vehicle
before the driver intervenes. This stabilizing
intervention is simultaneously deactivated
when DSC is switched off, refer to page 78.
Malfunction
The warning lamp lights up. The active
steering is no longer operational. At low
speeds, greater steering wheel move-
ments are required, whereas at higher speeds,
the vehicle reacts more sensitively to steering
wheel movements. Have the system checked.
If the warning lamp lights up during the first
engine starting following a power supply inter-
ruption, the system must be activated by being
initialized.
Initializing system
1. Start the engine.
2. With the vehicle stationary, turn the steer-
ing wheel from the straight-ahead position
to the left as far as it will go and then back to
the straight-ahead position.
3. Switch off the engine.
When you start the engine again, all the func-
tions of the active steering are available once
again.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Technology for comfort, convenience and safety
82
Brake Force Display
The Brake Force Display lights up in two stages
depending on how strongly you brake.
> Normal braking: the brake lamps and the
center brake lamps light up.
> Forceful braking or braking with ABS: the
illuminated area of the rear brake lamps also
increases.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
83
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Airbags
The following airbags are located under the
marked covers:
1 Front airbags for driver and front passenger
2 Head airbags in front and rear
3 Side airbags in front and rear
Protective action
To ensure that the safety systems con-
tinue to provide optimized protection,
please observe the adjustment instructions on
page 38.<
The front airbags help protect the driver and
front passenger by responding to frontal
impacts in which safety belts alone cannot pro-
vide adequate restraint. When needed, the
head and side airbags help provide protection in
the event of side impact. The relevant side air-
bag supports the side upper body area. The
head air bag supports the head.
The airbags are deliberately not triggered in
every impact situation, e.g. less severe acci-
dents, certain roll-over conditions, or rear-end
collisions.
The rear seat side airbags may already
have been deactivated by a BMW center.
Labels in the rear door opening should indicate
the status of your rear seat side airbags. If you
are uncertain of their status, or wish to have the
airbags activated or deactivated, please contact
your BMW center.<
For information on the correct sitting position,
refer to page 38.
Do not apply adhesive materials to the
cover panels of the airbags, cover them or
modify them in any other way. Do not attempt to
remove the airbag retention system from the
vehicle. Never modify or tamper with either the
wiring or the individual components in the air-
bag system. This category includes the uphol-
stery in the center of the steering wheel, on the
instrument panel, the side trim panels on the
doors and the roof pillars along with the sides of
the headliner. Do not attempt to remove or dis-
mantle the steering wheel. Do not touch the
individual components immediately after the
system has been triggered, because there is a
danger of burns. In the event of malfunctions,
deactivation, or triggering of the airbag restraint
system, have the testing, repair, removal, and
disposal of airbag generators executed only
by a BMW center or a workshop that works
according to BMW repair procedures with cor-
respondingly trained personnel and has the
required explosives licenses. Unprofessional
attempts to service the system could lead to
failure in an emergency or undesired airbag
activation, either of which could result in per-
sonal injury.<
Airbag warning information is also provided on
the sun visors.
Automatic deactivation of front
passenger airbags
Your BMW has a seat occupation detection
system. By evaluating the weight on the front
passenger seat, the system detects whether or
not the seat is occupied by a child in the child-
restraint system or an adult.
> When a child is seated in the child-restraint
system or with an empty seat, the front and
side airbags are automatically deactivated
on the passenger side.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Technology for comfort, convenience and safety
84
> When an adult is traveling in the front seat,
the front and side airbags remain active on
the passenger side.
Although not desired, it can occur in the
case of heavier children that the front
passenger airbags remain active or in the case
of very light adults or young persons that the
front passenger airbags are deactivated. In
these cases, have the person ride in the rear
seat, refer to Passenger airbag status lamp
below. Do not load the passenger seat with any
items in addition to the person to be trans-
ported. Do not fit seat covers, seat cushion pad-
ding, ball mats or other items onto the front pas-
senger seat unless they are specifically
recommended by BMW. Do not place any items
under the seat. Otherwise, the function of the
seat occupation detection could be impaired.<
Operational readiness of airbag system
As of ignition key position of 1, the warning
lamp lights up briefly, thus indicating the opera-
tional readiness of the entire airbag system and
the safety belt tensioners.
Airbag system malfunction
> The warning lamp does not light up as of
ignition key position 1.
> Warning lamp lights up continuously.
A malfunction could prevent the airbag
system from responding in the expected
manner to an impact occurring within its normal
response range.<
Passenger airbag status lamp
The indicator lamp located above the rear view
mirror indicates whether the front passenger
airbag system is active or not active/OFF.
The indicator lamp is used only for the
front passenger airbag system. The indi-
cator lamp illuminates to show that the front
passenger airbag system is OFF/not active.<
> The lamp illuminates briefly during startup,
but then goes out if the seat is empty, or an
adult or child of sufficient size is detected.
> The lamp remains illuminated when a child
in a rear facing child-restraint system is
detected and indicates that the passenger
airbag system is off.
If the lamp is illuminated when the seat is
occupied by a very light adult or teenager,
it is recommended that the person sit in the
rear.<
Find more information about passenger airbag
system and seat occupancy detection in the
section Automatic deactivation of front passen-
ger airbags above.
Head-Up Display*
The concept
With the Head-Up Display important informa-
tion is projected into the driver's field of view,
e.g. navigation instructions. This enables you to
take in this information without looking away
from the road.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
85
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Switching on/off
With the ignition key in position 2:
Press the button to activate or deactivate Head-
Up Display.
1 Navigation instructions
2 Display
> Cruise control
> Active cruise control
3 Speed
Selecting displays
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Press the controller to open the menu.
3. Select "Display settings" and press the
controller.
4. Select "Head-Up Display selection" and
press the controller.
5. Select desired information of Head-Up
Display.
6. Press the controller.
The information is shown on the Head-
Up Display.
The settings are stored for the remote control
currently in use.
Setting brightness
The brightness of the display is automatically
adapted to the ambient lighting conditions.
However, you can change the base setting.
With the low beams switched on, the brightness
can also be adjusted with the serrated dial of the
instrument lighting.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Technology for comfort, convenience and safety
86
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Display settings" and press the
controller.
3. Select "Brightness" and press the control-
ler.
4. Move the controller to the left to select
"Head-Up Display Offset".
5. Turn the controller until the desired setting
is selected.
The setting for the remote control currently in
use is stored.
Notes
The visibility of the displays in the Head-Up Dis-
play is influenced by:
> Sunglasses with certain polarization filters
> Certain seating positions
> Objects on the cover of the Head-Up
Display
> Wet road surface and unfavorable lighting
conditions
If the image is distorted, please have the basic
setting checked at a BMW center.
Special windshield
The windshield is part of the system. The shape
of the windshield complies with the require-
ments of the Head-Up Display to enable a pre-
cise display. A film in the windshield prevents
the double images from being displayed.
Windshield replacement should be carried out
by a BMW center or a workshop that works
according to BMW repair procedures with cor-
respondingly trained personnel.
Care instructions
You can find everything you need to know on
this topic by consulting the separate Caring for
your vehicle brochure.
Only clean the cover of the Head-Up Dis-
play with a soft, lint-free cloth or with a
display cleaning cloth, as otherwise damage
may result.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
87
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Lamps
Parking lamps/low beams
0 Lights off
1 Parking lamps
2 Low beams/daytime driving lamps
*
3 Automatic headlamp control
*
/
Adaptive Head Light
*
Parking lamps
In switch position 1, the front, rear and side
vehicle lighting is switched on. You can use the
parking lamps for parking. For lighting on one
side for parking as an additional feature, refer to
page 88.
Low beams
The low beams are activated in switch
position 2 only when the engine is running, oth-
erwise only the parking lamps are switched on.
Pathway lighting
If the vehicle is parked and the headlamps are
switched off, operating the headlamp flasher
activates the low beams. You can set the dura-
tion on the Control Display or deactivate the
function.
Control Center, for principle details, refer to
page 16.
1. Open the menu.
2. Select "Vehicle settings" and press the
controller.
3. Select "Light" and press the controller.
4. Select "Pathway lighting" and press the
controller.
5. Turn the controller to select the corre-
sponding duration.
6. Press the controller to apply the setting.
Lights on warning
If you turn the ignition key to position 0, an
acoustic signal sounds when you open the
driver's door for a few seconds to remind you
that the light has not yet been switched off.
At the same time a message appears on the
Control Display.
Daytime driving lamps*
If so desired, you can leave the light switch in
the low beam position 2.
Always observe all applicable laws governing
the use of daytime driving lamps.
You can switch on the parking lamps when
needed using the standard procedure
described under Parking lamps.
Automatic headlamp control*
In the switch position 3, the system activates
and switches on and off the low beams in
response to changes in ambient light condi-
tions, for instance, in a tunnel, at dawn and
dusk, and in rain or snow. Adaptive Head Light
*
is active. The LED next to the symbol is illumi-
nated when the low beams are on.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Lamps
88
The low beams remain switched on inde-
pendent of the ambient lighting condi-
tions when you switch on the fog lamps.
With the daytime driving lamps
*
activated, the
low beams are always switched on when the
ignition key is in position 2.<
The automatic headlamp control cannot
serve as a substitute for your personal
judgment in determining when the lamps
should be switched on in response to ambient
lighting conditions. For example, the system
cannot detect fog. To avoid safety risks, you
should always switch on the lamps manually
under these conditions.<
Adaptive Head Light*
The concept
Adaptive Head Light is a variable headlamp
control system that enables better illumination
of the road surface. Depending on the steering
angle and other assumptions, the light from the
headlamp follows the course of the road.
Activating Adaptive Head Light
In the switch position 3, the Adaptive Head
Light is active and the automatic headlamp con-
trol
*
is switched on.
To avoid blinding oncoming traffic, the Adaptive
Head Light
> is not active when driving in reverse
> is only active toward passenger side when
stationary
Malfunction
The LED next to the symbol for automatic head-
lamp control flashes. Adaptive Head Light is
faulty or has failed. Have the system checked as
soon as possible.
High beams/roadside parking
lamps
1 High beams
2 Headlamp flasher
3 Roadside parking lamps
Roadside parking lamps, left or right*
You also enjoy the option of lighting up just one
side of your vehicle when parking. When using
this function, comply with national regulations:
With the ignition off, press the lever in the
desired direction 3, past the resistance point.
The roadside parking lamps drain the bat-
tery. Do not switch them on for long peri-
ods of time, otherwise it may no longer be pos-
sible to start the engine.<
Front fog lamps
The parking lamps or low beams must
be switched on for the fog lamps to
operate. The green indicator lamp in
the instrument cluster lights up whenever the
fog lamps are on.
The fog lamps are switched off whenever the
high beams are switched on.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
89
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
If the automatic headlamp control is acti-
vated, the low beams will come on auto-
matically when you switch on the fog lamps.<
Instrument lighting
You can control the lighting intensity by using
the serrated dial.
Interior lamps
The interior lamps, footwell lamps, door entry
lighting and courtesy lamps
*
are controlled
automatically.
Switching interior lamps on and off
manually
Press the button.
If you want the interior lamps to remain off con-
tinuously, maintain pressure on the button for
approx. 3 seconds.
Reading lamps
Reading lamps are provided in the front and rear
adjacent to the interior lamps. Press the button
to activate or deactivate this system.
To avoid draining the battery, all of the
vehicle's interior lamps are automatically
switched off approx. 15 minutes after the igni-
tion is switched off.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
A congenial climate
90
A congenial climate
1 Airflow directed toward the windshield and
side windows
2 Air for the upper body region, refer to Front
ventilation on page 93
3 Air to footwell
4 Temperature, left side of passenger com-
partment
5 Maximum cooling
6 Defrosting windows and removing conden-
sation
7 Air volume, manual
8 Switching off automatic climate control
9 Switching cooling on and off manually
10 Temperature, right side of passenger com-
partment
11 Residual heat mode
12 AUTO program
13 AUC Automatic recirculated-air control/
Recirculated-air mode
14 LED for independent ventilation
15 Rear window defroster
16 Air grill for interior temperature sensor –
please keep clear and unobstructed
The current setting for air distribution is dis-
played on the Control Display.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
91
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
A congenial climate
For almost all conditions, the AUTO program
offers the optimal air distribution and air vol-
ume. Select an interior temperature you find
pleasant.
The following section contains more detailed
information on the available setting options.
AUTO program
The AUTO program handles the
adjustment of air distribution to the
windshield and side windows, in
the direction of the upper body, and in the foot-
well, as well as the adjustment of the air volume.
It also adapts your instructions for the tempera-
ture to outside influences throughout the year.
The cooling is switched on automatically with
the AUTO program. At the same time, a con-
densation sensor controls the program in such
a way that window condensation is prevented
as much as possible.
Adjusting temperature
You can also set the desired tem-
perature on the driver's side and
the passenger side by turning the
knob.
When you start driving, the system ensures that
the selected temperature is achieved as quickly
as possible. It then maintains this temperature,
regardless of the season.
Defrosting windows and removing
condensation
This program quickly removes ice
and condensation from the wind-
shield and front side windows.
Air volume, manual
You can adjust the air volume by
turning. You can reactivate the
automatic mode for the air volume
with the AUTO button.
Switching cooling function on and off
manually
The cooling function cools and
dehumidifies the incoming air
before also reheating it as
required, according to the temperature setting.
Depending on the weather, the windshield may
fog over briefly when the engine is started.
The cooling function is only available when the
engine is running and is switched on automati-
cally with the AUTO program.
Maximum cooling
This program quickly provides
maximum cooling.
The system switches to the recir-
culated-air mode and the air flows
at maximum air volume only from the air vent
outlets for the upper body area. For this reason
you should ensure that these vent outlets are
open before selecting this program.
AUC Automatic recirculated-air
control/Recirculated-air mode
You can respond to pollutants or
unpleasant odors in the immediate
environment by suspending the
supply of outside air. The system then recircu-
lates the air currently within the vehicle. During
AUC operation, a sensor detects pollutants in
the outside air and controls the shut-off auto-
matically.
By pressing the button repeatedly, you can
request three operating modes:
> LED off: outside air flows in continuously.
> Right LED on, AUC mode: the system
detects pollutants in the outside air and
shuts off the supply as needed.
> Left LED on, recirculated-air mode: the
supply of outside air is permanently shut off.
If condensation starts to form on the
inside window surfaces during operation
in the recirculated-air mode, you should switch
it off while also increasing the air volume as
required.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
A congenial climate
92
The recirculated-air mode should not be used
over an extended period of time, as the air qual-
ity inside the vehicle deteriorates continu-
ously.<
Residual heat mode
Press this button when the engine
is switched off, but warm.
The heat stored in the engine is
used to heat the passenger com-
partment, e.g. while stopped at a school to pick
up a child.
You can adjust the automatic climate control
settings in ignition key position 1.
Provided that the engine has warmed to its nor-
mal operating temperature and the battery is
charged, you can use this function for up to
15 minutes after switching off the ignition. The
LED in the button lights up to confirm compli-
ance with both of these conditions.
Switching off automatic climate control
The air volume, the heater and the
cooling function are all switched
off.
You can restart the automatic cli-
mate control by pressing any of its buttons
except the REST button.
Settings using Control Center
Ignition key:
> On vehicles with separate drives for audio
CDs and navigation DVDs, ignition key in
position 2
> In vehicles with one drive for audio CDs,
ignition key in position 1
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Move the controller to the left to open "Cli-
mate".
You can set the following:
> Manual air distribution, separate for driver's
side and passenger side
> Adjusting temperature in upper body region
> Intensity of the AUTO program
The settings are stored for the remote control
currently in use.
Manual air distribution
You can preset your air distribution yourself and
also individually adjust the air temperature in
the upper body area.
1. Select "Vent settings" and press the con-
troller.
2. Move the controller to select the desired
field and turn the controller to adjust the air
distribution.
1 Airflow directed toward the windshield and
side windows, driver's side only
2 Airflow for the upper body
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
93
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
3 Air to footwell
In order to select the passenger region:
Move controller toward the right.
Pressing the AUTO button cancels the air
distribution settings on the Control Dis-
play and vice versa.<
Adjusting temperature in upper body
region
1. Select "Vent settings" and press the con-
troller.
2. Select the field by moving the controller and
turning the controller to adjust the temper-
ature.
Setting intensity of AUTO program
To meet your individual needs, you can weaken
or strengthen the intensity of the automatic cli-
mate control.
1. Select "Automatic programs" and press the
controller.
2. Select the desired intensity and press the
controller.
Front ventilation
1 Use the serrated dials to smoothly open and
close air vents
2 Use the lever to change the air vent direc-
tion
Do not drop any foreign bodies into the
vent outlets, as otherwise these could be
catapulted outwards and lead to injuries.<
Ventilation for cooling
Adjust the vent outlets to direct the flow of cool
air in your direction, for instance, if the interior
has become too warm, etc.
Draft-free ventilation
Set the vent outlets so that the air flows past
you and is not directed straight at you.
Rear ventilation
1 Use the serrated dial to smoothly open and
close air vents
2 Use the serrated dial to adjust the tempera-
ture:
> Turn toward blue: colder
> Turn toward red: warmer
3 Use the lever to change the air vent direc-
tion
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
A congenial climate
94
Microfilter/activated-charcoal filter
The microfilter removes dust and pollen from
the incoming air. The activated-charcoal filter
provides additional protection by filtering gas-
eous pollutants from the outside air. Your BMW
center replaces this combined filter as a stan-
dard part of your scheduled maintenance.
You can select a display of more detailed infor-
mation on the Control Display, refer to page 66.
Independent ventilation*
The independent ventilation blows air into the
passenger compartment to lower interior tem-
peratures.
The independent ventilation is controlled using
the Control Center. You can set two different
times for the system to start.
The independent ventilation remains on for
30 minutes. It can also be switched on and off
directly. Since the system uses a substantial
amount of electrical current, you should refrain
from activating it twice in succession without
allowing the battery to be recharged in normal
operation between use.
The independent ventilation is ready for use at
any outside temperature, up to ignition key
position 1.
The air emerges through the upper body region
vent outlets in the instrument panel. These vent
outlets must be open for the system to operate.
Switching on and off directly
Control Center, for principle details, refer to
page 16.
1. Open "Climate".
2. Select "Parked car operation" and press the
controller.
3. Select "Automatic ventilation" and press
the controller.
4. Select "Parked car ventilation" and press
the controller.
Independent ventilation is switched on and the
LED flashes.
Preselecting activation times
Control Center, for principle details, refer to
page 16.
1. Open "Climate".
2. Select "Parked car operation" and press the
controller.
3. Select "Activation time" and press the con-
troller.
If you select two activation times that are
in sequence, they must differ by at least
31 minutes.<
4. Move the controller to the left or right to
select "Time 1" or "Time 2".
5. Select the time and press the controller.
The first time setting is highlighted.
6. Turn the controller to make the adjustment.
7. Press the controller to apply the setting.
The next setting is highlighted.
8. Make the remaining adjustments. After the
last adjustment, the time is stored.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
95
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Activating timer
Move the controller to the left or right to select
"Time 1" or "Time 2" and press the controller.
The activation time is activated and the
LED lights up.
The independent ventilation is only
available for activation within the next
24 hours. After that, the time must be reacti-
vated.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Practical interior accessories
96
Practical interior accessories
Integrated universal remote
control*
The concept
The integrated universal remote control can
replace as many as three hand-held transmit-
ters for various remote-controlled accessories,
such as door openers and house alarm sys-
tems. The integrated universal remote control
registers and stores signals from the original
hand-held transmitters.
The signal of an original hand-held transmitter
can be programmed on one of the three mem-
ory buttons 1. Then with the ignition key in
position 2, this programmed memory button 1
can be used to operate the relevant accessory.
The LED 2 flashes to confirm transmission of
the signal.
Should you sell your vehicle one day, be sure to
delete the stored programs beforehand for your
safety, refer to page 97.
To prevent possible damage or injury,
before programming or using the inte-
grated universal remote control, always inspect
the immediate area to make certain that no peo-
ple, animals or objects are within the travel
range of the device. Also, comply with the
safety precautions of the original hand-held
transmitter.<
Checking compatibility
If you see this symbol on the packaging
or in the manual supplied with the orig-
inal hand-held transmitter, it is safe to
assume that it is compatible with the integrated
universal remote control.
If you have additional questions, please
consult your BMW center or call 1-800-
355-3515.
You can also visit these websites:
www.bmwusa.com or
www.homelink.com.
HomeLink is a registered trademark owned by
Johnson Controls, Inc.<
Programming
1 Memory buttons
2 LED
Fixed-code hand-held transmitters
1. Ignition key in position 2.
2. When starting operation for the first time:
Press both outer buttons 1 for approx.
20 seconds until the LED 2 flashes. The
three memory buttons 1 are cleared.
3. Hold the original hand-held transmitter at a
distance of approx. 2 in/5 cm to 8 in/20 cm
from the memory buttons 1.
The required distance between the
hand-held transmitter and the mem-
ory buttons 1 depends on the relevant sys-
tem of the original hand-held transmitter
used.<
4. Simultaneously press the transmit key on
the original hand-held transmitter and the
desired memory button 1 on the integrated
universal remote control. The LED 2 flashes
slowly at first. As soon as the LED 2 flashes
rapidly, release both buttons. If the LED 2
does not flash rapidly after approx. 15 sec-
onds, alter the distance.
5. To program other original hand-held trans-
mitters, repeat steps 3 and 4.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
97
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
The corresponding memory button 1 is now
programmed with the signal of the original
hand-held transmitter.
You can operate the system with the ignition
key in position 2.
If the device can not be operated after
repeated programming, check whether
the original hand-held transmitter uses an alter-
nating-code system. To do so, either read the
instructions for the original hand-held transmit-
ter or hold down the programmed memory
button 1 of the integrated universal remote
control. If the LED 2 on the integrated universal
remote control flashes rapidly for a short time
and then remains lit for approx. 2 seconds, this
indicates that the original hand-held transmitter
uses an alternating-code system. In the case of
an alternating-code system, program the mem-
ory buttons 1 as described at Alternating-code
transmitters.<
Alternating-code transmitters
To program the integrated universal remote
control, consult the operating instructions for
the equipment to be set. You will find informa-
tion there on the possibilities for synchroniza-
tion.
When programming hand-held transmitters
that employ an alternating code, please observe
the following supplementary instructions:
Programming will be easier with the aid of
a second person.<
1. Park your vehicle within the range of the
remote-controlled device.
2. Program the integrated universal remote
control as described above in the section
Fixed-code hand-held transmitters.
3. Locate the button on the receiver of the
device to be set, e.g. on the drive unit.
4. Press the button on the receiver of the
device to be set. After step 4, you have
approx. 30 seconds for step 5.
5. Press the programmed memory button 1 of
the integrated universal remote control
three times.
The corresponding memory button 1 is now
programmed with the signal of the original
hand-held transmitter.
Clearing memory buttons
Press both outer buttons 1 for approx. 20 sec-
onds until the LED 2 flashes: all memory but-
tons are cleared.
The memory of individual memory buttons 1
cannot be cleared.
Roller sun blinds*
Rear window blind
Press the button on the driver's door.
Roller sun blinds for rear side windows
Pull the loop of the roller sun blind and hook
onto bracket.
Glove compartment
Opening
Pull the handle. The light in the glove compart-
ment switches on.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Practical interior accessories
98
Closing
Fold the cover up.
To prevent injury in the event of an acci-
dent while the vehicle is being driven,
close the glove compartment immediately after
use.<
Locking
Lock with a master key. Unlocking is also only
possible with a master key.
If you only hand over the spare key, e.g.
for valet parking, refer to page 28, the
glove compartment cannot be unlocked.<
Rechargeable flashlight
The flashlight is located on the left side of the
glove compartment.
The flashlight can remain plugged in continu-
ously.
Be sure that the flashlight is switched off
when it is inserted into its holder. Failure
to comply with this precaution could lead to
overcharging and damage.<
Center armrest
A storage compartment is located in the arm-
rest between the front seats.
Open cover:
Press button. The cover opens and can be
folded upwards.
The mat in the compartment can be removed
for cleaning.
Depending on the model, the storage compart-
ment contains a folding tray or a telephone cra-
dle
*
.
Open compartment:
Press button and fold cover upward.
The folding tray and telephone cradle
*
can be
folded upward to enable use of the lower area of
the storage compartment.
Ventilating storage compartment in
front armrest
1. Fold the folding tray or telephone cradle
*
upward.
2. Open or close the slider in the storage com-
partment.
Depending on the automatic climate con-
trol setting, the temperature inside the
storage compartment may be higher than in the
rest of the interior. Close the vent as needed.<
Adjusting
Slide the center armrest into the desired posi-
tion.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
99
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Storage compartments
Storage compartment on center
console between front seats
Open by pressing the cover back.
Other compartments
There are other compartments in the doors as
well as in the front and rear center console.
Storage nets are located on the backrests of the
front seats.
Clothes hooks
When suspending clothing from the
hooks ensure that it will not obstruct the
driver's vision. Do not hang heavy objects on
the hooks. If you do so, they could cause per-
sonal injury to occupants during braking or eva-
sive maneuvers.<
Cup holders
Opening:
Briefly press the button.
Do not place containers made of glass in
the cup holders. This would lead to an
increased risk of injury in the event of an acci-
dent.<
Closing:
Press the cover in the center and push in the
cup holder.
Ashtray, front
Opening
Slide back the cover.
Emptying
Push the ashtray toward the front: the ashtray
lifts and can be removed.
Cigarette lighter, front
In ignition key position 2, press in the cigarette
lighter.
The lighter can be removed as soon as it pops
back out.
Hold or touch the hot cigarette lighter by
the knob only. Holding or touching it in
other areas could result in burns.
Always remove the ignition key when you leave
the vehicle so that, e.g., children are unable to
use the lighter and burn themselves.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Practical interior accessories
100
Sockets
With the ignition key in position 2, the cigarette
lighter socket can be used as a power outlet for
hand flashlights, car vacuum cleaners, etc., with
power ratings of up to approx. 200 W at 12 V.
Avoid damaging the socket due to inserting
plugs of different shapes or sizes. The same is
true for all power outlets in the vehicle.
Ashtray, rear
Emptying
Press the entire cover down. The ashtray rises
and can be removed.
Cigarette lighter, rear
Refer to Cigarette lighter, front.
Sockets
In front passenger footwell
In luggage compartment
Center armrest, rear
1 Storage tray:
Pull upward
2 Open cup holder:
Press and open cover
Folding down the center armrest improves
vision toward the rear.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Controls
101
Reference At a glanceDriving tipsCommunication NavigationEntertainmentMobility
Folding down rear seat*
1. Open the buckle of the center safety belt in
the rear and insert the belt tab at the end of
the belt into the fixture on the rear window
shelf.
2. Push the corresponding head restraint
down as far as it will go, refer to page 42.
3. To unlock, pull the corresponding lever in
the luggage compartment.
4. The unlocked rear seat back moves forward
slightly. Fold the seat back forward by the
head restraint.
When you return the seat back to its
upright position, make sure that the
retainer engages properly. If it is not properly
engaged, transported cargo could enter the
vehicle during braking or evasive maneuvers
and endanger the vehicle occupants.<
The lashing eyes in the luggage compartment
provide you with a way to attach luggage com-
partment nets
*
or flexible straps for securing
suitcases and luggage, refer to page 109.
Ski bag*
Designed for safe, clean transport of up to 4
pairs of standard skis or up to 2 snowboards.
With the ski bag you can stow skis with a length
of up to 6.9 ft/2.10 m. When skis of 6.9 ft/2.10 m
in length are loaded, the ski bag will tend to con-
tract, reducing its overall capacity.
Loading
1. Fold down the center armrest, press the
button and open the cover.
2. Press the button again; the cover in the lug-
gage compartment opens. If you press the
button firmly the first time, this also opens
the cover in the luggage compartment
3. Extend the ski bag between the front seats
and fill it. The zipper facilitates access to the
stowed items and drying of the ski bag.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Practical interior accessories
102
4. Insert the belt tab of the ski bag retaining
strap into the center safety belt buckle that
is marked CENTER.
Make sure to load only cleans skis into the ski
bag. Wrap sharp edges to prevent damage.
Securing cargo
After loading, secure the ski bag and its con-
tents. Tighten the retaining strap on the ten-
sioning buckle for this purpose.
Secure the ski bag in this way. If you fail to
do so, it could move around and endanger
occupants during braking or evasive maneu-
vers.<
To store the ski bag, perform the above steps in
reverse order.
Removing ski bag
The ski bag can be completely removed, e.g. for
faster drying or to allow you to put it to other
uses.
Your BMW center will be glad to provide
you with more detailed information on the
various items of equipment.<
1. Pull the handle forward and pull the ski bag
up and out.
2. Close the cover in the luggage compart-
ment.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Driving tips
This section is designed to provide you
with extra support by supplying information
useful in dealing with specific driving and
operating conditions.
Driving tips
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Things to remember when driving
106
Things to remember when driving
Break-in period
Moving parts need breaking-in time to adjust to
each other. To ensure that your vehicle contin-
ues to provide optimized economy of operation
throughout an extended service life, we request
that you devote careful attention to the follow-
ing section.
Engine and differential
Up to 1,200 miles/2,000 km:
You should attempt to vary both engine and
vehicle speeds. Until the break-in period has
been completed, you should also refrain from
exceeding an engine speed of 4,500 rpm or a
driving speed of 100 mph/160 km/h.
Always obey all official speed limits.
Avoid full-throttle operation and use of the
transmission's kick-down mode during these
initial miles.
Once you have driven 1,200 miles/2000 km, the
engine and vehicle speeds can be gradually
increased.
SMG Sequential manual transmission
Do not use the acceleration assistant during the
break-in period, refer to page 55.
Tires
Due to technical factors associated with their
manufacture, tires do not achieve their full trac-
tion potential until after an initial break-in
period. Therefore, drive reservedly during the
first 200 miles/300 km.
Brake system
Brakes require an initial break-in period of
approx. 300 miles/500 km to achieve optimized
contact and wear patterns between brake pads
and rotors.
Clutch
The function of the clutch is only at its opti-
mized level after a distance driven of approx.
300 miles/500 km. During this break-in period,
engage the clutch gently.
Following part replacement
Observe the break-in instructions again if com-
ponents mentioned above must be replaced
after subsequent driving operation.
General driving notes
Closing luggage compartment lid
Operate the vehicle only when the lug-
gage compartment lid is completely
closed. Otherwise, exhaust fumes could pene-
trate to the interior of the vehicle.<
If special circumstances should make it abso-
lutely necessary to operate the vehicle with the
luggage compartment lid open:
1. Close all windows and the glass sunroof.
2. Increase the air volume of the automatic
climate control to a high level, refer to
page 91.
Hot exhaust system
As in all vehicles equipped with a catalytic
converter, extremely high temperatures
are generated in this vehicle. Do not remove the
heat shields installed adjacent to various sec-
tions of the exhaust system, and never apply
undercoating to them. When driving, standing
at idle and while parking take care to avoid pos-
sible contact between the hot exhaust system
and any highly flammable materials such as hay,
leaves, grass, etc. Such contact could lead to a
fire, and with it the risk of serious property dam-
age as well as personal injury.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Driving tips
107
Reference At a glanceControlsCommunication NavigationEntertainmentMobility
Portable phone in the vehicle
BMW discourages the use of mobile
communications devices, e.g. portable
phones, inside the vehicle without a direct con-
nection to an outside antenna. Otherwise, the
vehicle electronics and mobile communication
device can influence one another. In addition,
there is no assurance that the radiation which
results from transmission will be dissipated
from the vehicle interior.<
Interior and exterior mirrors, automatic
dimming feature*
This feature is controlled by two photocells in
the inside rearview mirror. One is integrated into
the glass of the mirror, while the other is located
at an offset position on the rear of the mirror
housing.
For trouble-free operation, keep the photocells
clean and do not cover the area between the
interior rearview mirror and the windshield. Do
not attach stickers of any kind to the windshield
in front of the mirror, either.
Hydroplaning
When driving on wet or slushy roads,
reduce road speed. If you do not, a wedge
of water can form between tires and road sur-
face. This phenomenon is referred to as hydro-
planing, and is characterized by a partial or
complete loss of contact between the tires and
the road surface, ultimately undermining your
ability to steer and brake the vehicle.<
The risk of hydroplaning increases as the tread
depth of the tires decreases, refer also to Mini-
mum tire tread on page 173.
Driving through water
Do not drive through water on the road if it
is deeper than 1 ft/30 cm, and then only at
walking speed at the most. Otherwise, the vehi-
cle's engine, the electrical systems and the
transmission may be damaged.<
Using handbrake on inclines
On inclines, do not hold the vehicle with
the clutch; use the handbrake. Otherwise
greater clutch wear will result.<
SMG Sequential manual transmission
Start off quickly on slopes. Do not hold
the vehicle on a hill by pressing the accel-
erator, but apply the handbrake instead. Other-
wise overheating can occur in the transmission
region.<
Braking safely
Your BMW is equipped with ABS as a standard
feature. In situations that require it, it is best to
brake with full force. Since the vehicle maintains
steering responsiveness, you can still avoid
possible obstacles with a minimum of steering
effort.
Pulsation of the brake pedal, combined with
sounds from the hydraulic circuits, indicate that
ABS is in its active mode.
Do not drive with your foot resting on the
brake pedal. Even light but consistent
pedal pressure can lead to high temperatures,
brake wear and possibly even brake failure.<
Driving in wet conditions
When roads are wet or there is heavy rain,
briefly exert gentle pressure on the brake pedal
every few miles. Monitor traffic conditions to
ensure that this maneuver does not endanger
other road users. The heat generated in this
process helps dry the pads and rotors to ensure
that full braking efficiency will then be available
when you need it.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Things to remember when driving
108
Hills
To prevent overheating and the resulting
reduced efficiency of the brake system,
drive long or steep downhill gradients in the
gear in which the least braking is required. Even
light but consistent pedal pressure can lead to
high temperatures, brake wear and possibly
even brake failure.<
You can further enhance the engine's braking
action by selecting a lower gear in the automatic
transmission's manual mode, downshifting as
far as first gear on extremely steep stretches,
refer to page 56. This strategy helps you avoid
placing excessive loads on the brake system.
Never drive with the clutch pressed or
allow the vehicle to coast with the trans-
mission in Neutral – or with the engine switched
off – there is no engine braking when the trans-
mission is in Neutral, and no power-assist for
brakes and steering when the engine is not run-
ning.
Never allow floor mats, carpets or any other
objects to protrude into the area around the
accelerator and brake pedals and obstruct their
movement.<
Corrosion on brake rotors
When the vehicle is driven only occasionally,
during extended periods when the vehicle is not
used at all, and in operating conditions where
brake applications are less frequent, there is an
increased tendency for corrosion to form on
rotors, while contaminants accumulate on the
brake pads. This occurs because the minimum
pressure which must be exerted by the pads
during brake applications to clean the rotors is
not reached.
Should corrosion form on the brake rotors, the
brakes will tend to respond with a pulsating
effect that even extended application will fail to
cure.
When the vehicle is parked
Condensation forms in the air conditioner sys-
tem during operation, and then exits under the
vehicle.
Traces of condensed water under the
vehicle are therefore normal
.
Before driving into a car wash
To prevent the exterior mirrors on this vehicle
from being damaged, always fold them in by
hand before entering an automatic car wash.
Cargo loading
To avoid loading the tires beyond their
approved carrying capacity, never over-
load the vehicle. Overloading can lead to over-
heating and increases the rate at which damage
develops inside the tires. The ultimate result
can assume the form of a sudden blow-out.<
Determining loading limit
1. Locate the following statement on your
vehicle's placard
*
:
The combined weight of occupants
and cargo should never exceed
XXX lbs. or YYY kg. Otherwise, this could
damage the vehicle and produce unstable
vehicle operating conditions.<
2. Determine the combined weight of the
driver and passengers that will be riding in
your vehicle.
3. Subtract the combined weight of the driver
and passengers from XXX lbs. or YYY kg.
4. The resulting figure equals the available
amount of cargo and luggage load capacity.
For example, if the XXX amount equals
1,400 lbs. and there will be five 150 lb. pas-
sengers in your vehicle, the amount of avail-
able cargo and luggage load capacity is
650 lbs.:
1,400 lbs. minus 750 lbs. = 650 lbs.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Driving tips
109
Reference At a glanceControlsCommunication NavigationEntertainmentMobility
5. Determine the combined weight of luggage
and cargo being loaded on the vehicle. That
weight may not safely exceed the available
cargo and luggage load capacity calculated
in step 4.
6. If your vehicle will be towing a trailer, part of
the load from your trailer will be transferred
to your vehicle. Consult the manual for
transporting a trailer to determine how this
may reduce the available cargo and luggage
load capacity of your vehicle.
Load
The permitted load is the total of the weight of
occupants and cargo/luggage. The greater the
weight of occupants, the less cargo/luggage
can be transported.
Stowing cargo
> Load heavy cargo as far forward and as low
as possible, placing it directly behind the
bulkhead behind the rear seats.
> Cover sharp edges and corners.
> For very heavy cargo when the rear seat is
not occupied, secure each safety belt in the
opposite buckle.
Securing cargo
> Use the luggage net
*
, luggage straps, or
securing straps to hold down small and
lightweight luggage and cargo.
> Heavy-duty cargo straps
*
for securing
larger and heavier objects are available at
your BMW center. Four lashing eyes
mounted in the luggage compartment are
used to secure this lashing equipment, refer
to illustration.
> Please observe the special instructions
supplied with the heavy-duty cargo straps.
Always position and secure the load as
described above. If you do not, it can
endanger the passengers during braking or
evasive maneuvers.
Never exceed either the approved gross vehicle
weight or either of the approved axle loads, refer
to page 198, as excessive loads can pose a
safety hazard, and may also place you in viola-
tion of traffic safety laws.
You should never transport heavy or hard
objects unsecured in the passenger compart-
ment, as they could fly around and pose a safety
hazard to the vehicle's occupants during abrupt
braking or evasive maneuvers.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Things to remember when driving
110
Roof-mounted luggage rack*
A special rack system is available as an option
for your BMW. Please comply with the precau-
tions included with the installation instructions.
Mounting points
The mounting points are located in the door
openings.
Loading roof-mounted luggage rack
Because roof racks raise the vehicle's center of
gravity when loaded, they have a major effect on
its handling and steering response.
You should therefore always remember not to
exceed the approved roof weight, the approved
gross vehicle weight or the axle loads when
loading the rack.
You can find the specified weights on page 198.
The load on the roof must be evenly distributed
and must not extend outward to beyond the lim-
its of the loading surface. Always load the heavi-
est pieces first – at the bottom. Be sure that
adequate clearance is maintained for raising the
glass sunroof, and that objects do not project
into the opening path of the luggage compart-
ment lid.
Secure roof-mounted cargo correctly and
securely to prevent it from shifting or falling off
during the trip.
Drive smoothly. Avoid sudden acceleration and
braking maneuvers. Take corners gently.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Navigation
This chapter describes how you can
enter destinations and specify your route
so that your navigation system guides you
reliably to your destination.
Navigation
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Starting navigation system
114
Starting navigation system
Your navigation system can use satellites to
ascertain the precise position of your vehicle
and guide you reliably to any destination you
enter.
Navigation DVD
Special navigation DVDs are required for each
navigation system. You can obtain the latest
version at your BMW center.
Inserting navigation DVD
1. Insert the navigation DVD with the labeled
side up.
2. Allow approx. 8 seconds for the system to
scan the data from the DVD.
Removing navigation DVD
1. Press button 1.
The DVD emerges slightly from the drive.
2. Remove the DVD.
Display in assistance window
You can display the route or the current position
in the assistance window. This display remains
visible even if you change to another applica-
tion.
1. Move the controller to the right to enter the
assistance window.
2. Press the controller.
Other menu items are displayed.
3. Select the desired view of the route or "Cur-
rent position".
4. Press the controller.
The contents of the assistance window are con-
tinually updated as you drive.
*
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Navigation Driving tips
115
Reference At a glanceControlsCommunication EntertainmentMobility
Destination entry
In entering your destination you can select from
among the following options:
> Entering a destination manually, see below
> Selecting destination via information, refer
to page 118
> Selecting from among recent destinations,
refer to Destination list, page 119
> Selecting destination from address book,
refer to page 120.
> Selecting home address, refer to page 122
After selecting your destination you can pro-
ceed to start the destination guidance, refer to
page 124.
Operating navigation system
Enter data only when the vehicle is sta-
tionary, and always give priority to the
applicable traffic regulations in the event of any
contradiction between traffic and road condi-
tions and the instructions issued by the naviga-
tion system. If you do not observe this precau-
tion, you may be in violation of the law, and can
endanger vehicle occupants and other road
users.<
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Move the controller to the right to open
"Navigation".
3. Select "Navigation" and press the control-
ler.
Entering a destination
manually
The system supports the word matching princi-
ple to make it easier for you to enter the names
of streets or towns. This enables input of differ-
ent spellings and supplements your input auto-
matically so that stored names can be adopted
as destinations as quickly as possible.
Control Center, for principle details, refer to
page 16.
1. Select "Navigation" and press the control-
ler.
2. Select "New destination" and press the
controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Destination entry
116
3. Select "Enter address" and press the con-
troller.
The system also supports you with the follow-
ing features:
> If you do not enter a street, the system will
guide you to the downtown area of a town or
city.
> You can skip the entry of country and local-
ity if the current entries should be retained
for your new destination.
The commands of the voice command system
for destination entry differ from those of the
individual menu items on the Control Display.
You can have the system read aloud the possi-
ble voice commands, refer to page 22.
Selecting country
1. Select "State / Province" or the displayed
country and press the controller.
The list of available countries appears on
the display.
2. Select the country of destination and press
the controller.
In order to be able to start the destination guid-
ance, at least the town/city of the destination or
its zip code must be entered.
Entering destination
1. Select "Town / City" or the displayed town/
city and press the controller.
2. Select the starting letter and press control-
ler.
A list of all towns/cities starting with this let-
ter appears on the Control Display.
3. If necessary, input more letters.
The list gradually grows smaller each time
you enter a new letter.
To input a blank:
Select the symbol and press the control-
ler.
To delete the letter entered:
Move controller toward the right to select
, and press controller.
To delete all letters entered:
Move controller toward the right to select
, and hold the controller down.
4. Select the town/city name from the list and
press the controller.
Inputting destination by postal code
1. Select "Town / City" and press the control-
ler.
2. Input the postal code:
Select the desired digits and press the con-
troller.
To delete the number or letter entered:
Move controller toward the right to select
, and press controller.
To delete all numbers or letters entered:
Move controller toward the right to select
, and hold the controller down.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Navigation Driving tips
117
Reference At a glanceControlsCommunication EntertainmentMobility
3. Select the postal code and press the con-
troller.
The corresponding destination is displayed.
4. Select the destination and press the con-
troller.
Entering street, house number and
intersection
1. Select "Street" or the displayed street and
press the controller.
2. For instructions on entry, refer to Entering
destination.
After the street you can also enter the intersec-
tion or the house number.
The intersection is entered in the same way as
the street.
To enter the house number:
1. Select "House number" and press the con-
troller.
2. To enter the house number:
Select the desired digits and press the con-
troller.
To delete the number or letter entered:
Move controller toward the right to select
, and press controller.
To delete all numbers or letters entered:
Move controller toward the right to select
, and hold the controller down.
3. Select the house number and press the
controller.
Only house numbers stored for the street
on the navigation DVD can be entered.
Starting destination guidance with
manual destination entry
Select "Start guidance" and press the control-
ler.
Destination guidance starts immediately.
If the destination guidance does not need to be
started immediately:
Select "Add to destination list" and press the
controller.
The destination is saved in the destination list,
refer to page 119.
Map-guided destination
selection
If you only know the name of the town or street
of the destination, then you can input the desti-
nation by using a map. You can use the cursor
to localize the destination on the map and then
adopt it into the destination guidance.
Control Center, for principle details, refer to
page 16.
1. Select "Navigation" and press the control-
ler.
2. Select "New destination" and press the
controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Destination entry
118
3. Select "Input map" and press the controller.
A section of a map is displayed on the Con-
trol Display:
> During destination guidance, around the
current destination
> With the destination guidance deacti-
vated, around the last destination
entered
4. Turn the controller to adjust the scale. To
move the map, move the controller in the
desired direction.
The controller can be moved to the left,
right, forward, backwards and also diago-
nally.
5. In order to accept or store the destination at
scales smaller than 1 mile/2 km, press the
controller.
The selected destination and other menu
items are displayed.
6. Select the desired menu item:
> "Start route guidance" switches on the
destination guidance.
> "Show current position" places the cur-
rent position in the center of the map.
> "Show destination position" places the
current destination in the center of the
map.
> "Return to map" switches back to "Input
map".
> Exit the menu.
7. Press the controller.
Selecting destination using
information
You can obtain a display of selected destina-
tions, e.g. hotels, sights or hospitals, and adopt
them into the destination guidance.
Control Center, for principle details, refer to
page 16.
1. Select "Navigation" and press the control-
ler.
2. Select "New destination" and press the
controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Navigation Driving tips
119
Reference At a glanceControlsCommunication EntertainmentMobility
3. Select "Information" and press the control-
ler.
4. Selecting location:
> "On destination"
> "On location"
> "On a new destination"
5. Press the controller.
6. Select the desired type of destination, such
as "Hotels and restaurants".
7. Press the controller.
Destinations appear on the Control Display,
which are sorted alphabetically or accord-
ing to distance.
8. Select a destination and press the control-
ler.
9. Select a menu item:
> To accept the address into the destina-
tion list and start the destination guid-
ance:
Select "Select as destination" and press
the controller.
> To establish a telephone connection:
Select "Call" and press the controller.
To exit from the menu:
Select the arrow and press the controller.
Destination list
The destination list shows the last 20 entered
destinations as well as the current destination
of the destination guidance.
This symbol indicates the current destina-
tion.
Control Center, for principle details, refer to
page 16.
1. Select "Navigation" and press the control-
ler.
2. Select desired destination and press the
controller.
3. The selected destination can be edited:
> To start the destination guidance:
Select "Start guidance".
The destination guidance is started.
> To save the entry:
Select "Add to address book".
> To display information about the desti-
nation: Select "Information on destina-
tion".
> To delete the entry:
Select "Delete entry".
> To delete all entries:
Select "Delete list". The destination
guidance is switched off.
> To change the entry:
Select "Edit". For operation, refer to
Entering destination, page 116.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Destination entry
120
4. Press the controller.
Address book
Opening address book
Control Center, for principle details, refer to
page 16.
Select "Address book" and press the controller.
Storing destinations in address book
You can save approx. 100 destinations in the
address book.
Control Center, for principle details, refer to
page 16.
1. Select "Address book" and press the con-
troller.
2. Select "New address" and press the con-
troller
3. Select "Enter address" and press the con-
troller.
4. Input name and address.
5. Select "Store in address book" and press
the controller.
The entry is stored in the address book.
You can also save a destination from the desti-
nation list into the address book, refer to
page 119.
Storing current position
The current position can be adopted into the
address book.
Control Center, for principle details, refer to
page 16.
1. Select "Address book" and press the con-
troller.
2. Select "New address" and press the con-
troller.
3. Select "Use current location as address"
and press the controller.
The name given can be changed. For oper-
ation, refer to Entering a destination manu-
ally, page 115.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Navigation Driving tips
121
Reference At a glanceControlsCommunication EntertainmentMobility
4. Select "Store in address book" and press
the controller.
You can also enter your current position into the
address book if you have left the sector covered
by the navigation DVD. In this case, you must
enter a name.
Selecting destinations from address
book
Control Center, for principle details, refer to
page 16.
1. Select "Address book" and press the con-
troller.
The stored entries appear on the Control
Display.
2. Select the entry and press the controller.
To start the destination guidance:
Select "Start guidance" and press the control-
ler
Changing destinations from address
book
Control Center, for principle details, refer to
page 16.
1. Select "Address book" and press the con-
troller.
2. Select the entry and press the controller.
3. Select "Edit address" and press the con-
troller.
4. Change entry.
For operation, refer to Entering a destina-
tion manually, page 115.
Deleting individual destinations from
address book
Control Center, for principle details, refer to
page 16.
1. Select "Address book" and press the con-
troller.
2. Select the entry and press the controller.
3. Select "Delete entry" and press the control-
ler.
Deleting all destinations from address
book
Control Center, for principle details, refer to
page 16.
1. Open the start menu.
2. Press the controller to open the menu.
3. Select "Vehicle settings" and press the
controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Destination entry
122
4. Select "Delete data" and press the control-
ler.
5. Select "Delete address book" and press the
controller.
6. Select "Yes" and press the controller.
Storing home address
You can save your current position or the cur-
rent destination as the home address in the
address book. This entry occupies the second
position in the address book.
Control Center, for principle details, refer to
page 16.
1. Select "Address book" and press the con-
troller.
2. Select "Home address" and press the con-
troller.
Select "Use current location as address" or,
during destination guidance, "Save current
destination".
3. Press the controller.
In order to accept the home address as the des-
tination:
Select "Start guidance" and press the control-
ler.
To change the entry:
Select "Edit address" and press the controller.
For operation, refer to Entering a destination
manually, page 115
Route selection
You can influence the calculated route by
choosing certain route criteria.
Changing route criteria
Control Center, for principle details, refer to
page 16.
1. Select "Navigation" and press the control-
ler.
2. Select "Route preference" and press the
controller.
The various criteria are listed on the Control
Display.
3. Select a route criterion for the route:
> "With highways"
Freeways and major traffic arteries are
given priority
> "Avoid highways"
Freeways are avoided where possible
> "Fast route"
Shortest time using combination of
smallest possible distance and sections
where fast driving is possible
> "Short route"
Shortest distance without consideration
of the time
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Navigation Driving tips
123
Reference At a glanceControlsCommunication EntertainmentMobility
4. Press the controller.
The route criterion is highlighted.
5. If necessary, select an additional route cri-
terion and then press the controller:
> "Dynamic route"
Automatic changing of the route in
response to traffic obstruction. Depend-
ing on the type of road and the nature
and length of the traffic obstruction, the
route can also be calculated so that you
travel through the traffic obstruction.
> "Avoid tollroads"
Tollroads are avoided where possible
> "Avoid ferries"
Ferries are avoided where possible
To exit from the menu:
Select the arrow and press the controller.
The route is planned according to fixed rules.
The type of road is taken into account, e.g.
whether it is a highway or a winding road. The
road types are stored on the navigation DVD.
As a result, the routes recommended by the
navigation system may not always be the same
ones that you would choose based on personal
experience.
You can change the choice of route as often as
you like while entering the destination and
whenever the destination guidance is active.
Word matching principle
The system supports the word matching princi-
ple to make it easier for you to enter the names
of streets or towns. The system runs ongoing
checks, comparing your destination entries
with the data stored on the navigation DVD as
the basis for instant response. The user bene-
fits include:
> Names of specific locations can also vary
from the official versions if you are using a
spelling that is customary in another coun-
try.
Example:
Instead of "München", you can also enter
the English spelling "Munich" or the Italian
spelling "Monaco".
> When you are entering the names of towns
and streets the system will complete them
automatically as soon as enough letters are
available to ensure unambiguous identifica-
tion.
> The system only accepts name entries
beginning with letters that are stored on the
navigation DVD. The system will not accept
nonexistent names and addresses.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Destination guidance
124
Destination guidance
Starting destination
guidance
Control Center, for principle details, refer to
page 16.
1. Select "Navigation" and press the control-
ler.
2. Select the destination from the destination
list and press the controller or enter a new
destination, refer to page 115.
3. Select "Start guidance" and press the con-
troller.
The destination guidance is started.
This symbol indicates the current destina-
tion.
After the route has been calculated, destination
guidance is indicated by arrows or a route map
on the Control Display.
1 Predicted time of arrival
2 Distance to the destination on the calcu-
lated route
3 Route criterion
4 Voice instructions switched on/off
During destination guidance, you can operate
other equipment using the Control Center at
any time. You will be punctually notified of a
change of direction by spoken instructions and
the display of the direction arrow.
To exit from the menu:
Select the arrow and press the controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Navigation Driving tips
125
Reference At a glanceControlsCommunication EntertainmentMobility
Terminating/continuing
destination guidance
Control Center, for principle details, refer to
page 16.
This symbol indicates the current destina-
tion.
1. Select the current destination and press the
controller.
2. Select "Start guidance" and press the con-
troller.
The destination guidance is switched off.
When you park the vehicle before reaching the
entered destination, upon restarting you will
see the question "Continue guidance to desti-
nation?".
The destination guidance starts automatically
after a short time.
To start the destination guidance:
Select "Yes" and press the controller.
Displaying current position
You can have your current position displayed
even when the destination guidance is
switched off.
Control Center, for principle details, refer to
page 16.
1. Select "Navigation" and press the control-
ler.
2. Select "Current position" and press the
controller.
The current position of your BMW is displayed.
If the navigation system is unable to identify a
town or city, your current map coordinates will
appear.
To exit from the menu:
Select the arrow and press the controller.
You can also have the current position dis-
played on a map, refer to page 126.
Destination guidance
through voice instructions
Switching voice instructions on/off
Control Center, for principle details, refer to
page 16.
1. Open the start menu.
2. Press the controller to open the menu.
3. Select "Display settings" and press the
controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Destination guidance
126
4. Select "Languages" and press the control-
ler.
5. Select "Navigation voice instructions on"
and press the controller.
The voice instructions are switched on.
The setting is stored for the remote control cur-
rently in use.
Repeat voice instructions and cancel
With the programmable buttons on the steering
wheel, you can also execute the following func-
tions, refer to page 46:
> Repeat the voice instruction:
Press button.
> Switch voice instructions on/off:
Hold the button down.
Adjusting volume
1. Repeat the last voice instruction, if neces-
sary.
2. Turn the button during the voice instruction
to select the desired volume.
This volume is independent of the volume of the
audio and video sources.
The setting is stored for the remote control cur-
rently in use.
Route display
You have the option of displaying various views
of the route during destination guidance.
Displaying arrow view
1. Select "Navigation" and press the control-
ler.
2. Select "Arrow display" and press the con-
troller.
Displaying route map
You can have your current position displayed on
a map. After starting the destination guidance,
the planned route is shown on the map.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Navigation Driving tips
127
Reference At a glanceControlsCommunication EntertainmentMobility
1. Select "Navigation" and press the control-
ler.
2. Select "Map, facing north" or "Map, direc-
tion of travel".
3. Press the controller.
At scales of less than 300 miles/500 km, you
have the option of deciding whether to orient
the map to north or toward your current direc-
tion of travel. At scales of 300 miles/500 km or
greater, the map always points toward north.
Changing scale
Turn the controller to adjust the scale.
Displaying towns/cities and streets of
route
You can have the names of streets and towns/
cities on your route displayed whenever the
destination guidance is active.
The distances remaining to be traveled on each
individual road and directional arrows are also
displayed.
Control Center, for principle details, refer to
page 16.
1. Select "Navigation" and press the control-
ler.
2. Select "Route list" and press the controller.
To exit from the menu:
Select the arrow and press the controller.
Bypassing route sections
During destination guidance, you can revise the
navigation system's route recommendations to
avoid particular stretches of road. Enter the
number of miles/kilometers that you want to
travel before returning to the original route.
Control Center, for principle details, refer to
page 16.
1. Select "New route" and press the control-
ler.
2. Turn the controller to enter the desired
number of miles/kilometers and press the
controller.
The route is recalculated.
To exit from the menu without changing the
route:
Select the arrow and press the controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
What to do if …
128
What to do if …
What to do if …
> a navigation DVD is inserted, but an instruc-
tion to insert the DVD appears on the Con-
trol Display?
The navigation DVD may not be the correct
DVD for the navigation system. This infor-
mation is indicated on the DVD label.
> you request the current position of your
vehicle, but do not receive a precise dis-
play?
The system is unable to receive enough
GPS signals at your current position owing
to obstructions, your current position is not
yet available on your navigation DVD, or the
system is in the process of calculating your
current position. As a rule, reception is
guaranteed when you are in the open.
> the destination guidance does not accept a
destination?
The data of the destination is not stored on
the navigation DVD that is loaded. Select a
destination that is as close as possible to
the original.
> the destination guidance does not accept
an address without the street name?
On the navigation DVD, no downtown area
can be determined for the city or town
entered. Enter any street, or a destination
such as the railway station in the selected
town, and then start the destination guid-
ance.
> you want to enter a destination for the des-
tination guidance, but it is not possible to
select the letters for your desired entry?
The data of the destination is not stored on
the navigation DVD that is loaded. In this
case, the system will not offer you any let-
ters to choose from. Select a destination
that is as close as possible to the original.
> the system stops furnishing directions on
which way to turn as you approach intersec-
tions?
You are driving in an area that has not yet
been completely recorded on the naviga-
tion DVD. Instead of an arrow indicating a
turn, you will see an arrow which indicates
the general direction of your planned route.
Or you have left the recommended route
and the system requires a few seconds to
calculate a new recommended route.
> the navigation system does not react to
entries?
If the battery was disconnected, it takes
about 10 minutes before the system is once
again operational.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Entertainment
Operation of the radio and CD as well as their
tone settings are described in this chapter.
Entertainment
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
On/off and tone
132
On/off and tone
The following audio sources have shared
controls and setting options:
> Radio Business
> CD player
> CD changer
*
Controls
The audio sources can be operated using:
> Buttons in the region of the CD player
> Control Center
> Remote control
*
> Buttons on the steering wheel, refer to
page 10
Buttons in the region of the CD player
The layout of the buttons can vary depending
on your vehicle's equipment.
Equipment with single drive:
Equipment with two drives:
1 Sound output for entertainment on/off,
volume
> Press: switch on/off.
When you switch on, the last set radio
station or CD track is played.
> Turn: adjust volume.
2 Drive for audio CDs
3 Eject CD
4 Station scan/track search
> Change radio station.
> Select track for CD player and
CD changer.
5 Drive for navigation DVDs
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
NavigationEntertainment Driving tips
133
Reference At a glanceControlsCommunicationMobility
Operation using Control Center
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Move the controller back to open "Enter-
tainment".
You have the following choices:
> "FM" and "AM": select radio reception.
> "WB": request weather station.
> "SAT": select satellite radio.
> "CD": select CD player or CD changer.
> "Set": depending on the audio source,
other adjustments can be made, e.g. with
the radio: update station with strongest
reception, save station, tone control, sam-
ple stations.
Switching on/off
In order to switch the Entertainment sound out-
put on and off:
Press knob 1 next to the CD player.
This symbol on the Control Display indi-
cates that sound output is switched off.
Adjusting volume
Turn knob 1 next to the CD player until the
desired volume is set.
You can also adjust the volume on the steering
wheel.
The setting for the remote control currently in
use is stored.
Tone control
You can alter various tone settings, e.g. treble
and bass, or the speed-dependent volume
increase.
The settings are stored for the remote control
currently in use.
Changing tone settings
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Press the controller to open the menu.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
On/off and tone
134
3. Select "Entertainment settings" and press
the controller.
4. Select "Audio" and press the controller.
The tone settings can also be selected when
you have opened "Entertainment" in the start
menu:
Select "Set" and then "Tone" and press the
controller.
Treble and bass
1. Select "Treble / Bass" and press the con-
troller.
2. Move the controller to the left or right to
select "Treble" or "Bass".
3. Turn the controller until the desired setting
is selected.
Balance and fader
You can set the right/left and front/rear volume
balance in the same manner as "Treble / Bass".
Speed-dependent volume increase
The speed-dependent volume control auto-
matically increases the volume with increasing
speed. You can set various stages for the
increase in volume.
1. Select "Speed volume" and press the con-
troller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
NavigationEntertainment Driving tips
135
Reference At a glanceControlsCommunicationMobility
2. Turn the controller.
The adjustment is applied; the field can be
changed.
Professional LOGIC7 HiFi System*
You can select a spatial sound effect that
improves the spatial acoustics in all frequency
ranges.
1. Select "LOGIC7" and press the controller.
2. Select "Concert hall" or "Theater".
3. Press the controller.
LOGIC7 spatial sound is switched on.
To cancel the stereo effect:
Select "Off" and press the controller.
LOGIC7 and the LOGIC7 logo are registered
trade marks of Lexicon, Inc., a company of the
Harman International Group.
Equalizer*
You can set individual sound frequency ranges.
1. Select "Equalizer" and press the controller.
2. Move the controller to the left or right to
select the desired frequency range.
3. Turn the controller until the desired setting
is selected.
Resetting tone settings
You can reset all tone settings except "Speed
volume" to the standard default settings.
1. Open the start menu.
2. Press the controller to open the menu.
3. Select "Entertainment settings" and press
the controller.
4. Select "Audio" and press the controller.
5. Select "Reset" and press the controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
On/off and tone
136
Controls in the back seat*
You can also use a remote control to select
Business radio as the audio source and listen to
it through the headphones or speakers.
Remote control
1 Buttons for menu navigation
2 Volume
3 Station scan/track search
> Change radio station.
> Select track for CD player and
CD changer.
4 Headphones right/left
5 Exit menu for rear seat entertainment
Use the buttons 1 to navigate through the
menu. Pressing and move the controller left,
right, forward, and back is replaced by pressing
the corresponding button, refer to page 16.
Attaching headphones
Connections for the headphones:
Jacks 3.5 mm.
Selecting speakers/headphones
1. Press one of the buttons 1.
2. Select "Rear entertainment using speak-
ers" or "Rear entertainment via head-
phones".
3. Press button.
The last audio source selected is displayed:
> Headphones selected.
> Speakers selected.
To exit from the menu:
Select arrow and press button.
Settings for the remote control
You can limit control and set it so that the audio
source of the speakers is also heard through the
headphones.
Limiting control:
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Press the controller to open the menu.
3. Select "Vehicle settings" and press the
controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
NavigationEntertainment Driving tips
137
Reference At a glanceControlsCommunicationMobility
4. Select "Unlock rear menu" and press the
controller.
5. Select Rear seat and press the controller.
> In order to deactivate the remote control:
"Rear not enabled".
> In order to deactivate the control for the
speakers:
"Headphone operation only".
In order to set the headphones to the same
audio source as for the speakers:
1. Press the button to open the start
menu.
2. Move the controller back to open "Enter-
tainment".
3. Press the controller.
Other menu items are displayed.
4. Select "Headphones" and press the con-
troller.
The same audio source will be heard
over the speakers and headphones.
Tone control
You can adjust the tone right and left for the
speakers or for the headphones.
1. Press one of the buttons 1.
2. Select "Rear entertainment using speak-
ers" or "Rear entertainment via head-
phones" and press the controller.
3. Adjust the tone, refer to page 133.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Radio
138
Radio
Your radio provides reception the FM and AM
wavebands.
Listening to the radio
Press the button if the sound output is switched
off.
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Move the controller back to open "Enter-
tainment".
3. Select "FM" or "AM".
4. Press the controller.
Stations are shown on the Control Display on
the basis of various selection criteria, e.g. "Pre-
sets".
If "Autostore" does not display any stations or
if the stations displayed can no longer be
received, to update the station with the stron-
gest signal, refer to page 139.
Changing station
Turn the controller.
In addition to the stations currently displayed,
you can have stations with another selection
criterion displayed.
You can choose from the following selection
criteria:
> "Autostore":
For the Station with the strongest signal,
refer to page 139.
> "Presets":
Stations you have previously stored, refer to
page 140.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
NavigationEntertainment Driving tips
139
Reference At a glanceControlsCommunicationMobility
To change between these different selection
criteria of stations:
1. Move the controller forward to change the
field.
2. Select a selection criterion.
3. Press the controller.
You can also change the station on the steering
wheel.
Buttons next to CD player:
Press the button for the corresponding
direction.
The system switches to the next displayed sta-
tion.
Sampling stations, scan
The system automatically plays a brief sample
from each of the stations on the current wave-
band.
In "Manual", you can set stations that are
received in addition to those displayed.
Buttons next to CD player:
To start scan, hold down the correspond-
ing direction button.
To stop scanning, press button.
Control Center, for principle details, refer to
page 16.
1. Select "FM" or "AM".
2. Press the controller.
3. Press the controller again.
Other menu items are displayed.
4. Select "Scan" and press the controller.
Scan starts.
To stop the scan:
1. Press the controller.
2. Select "Scan" and press the controller.
This cancels the scan search, and the radio
remains on the current station.
Selecting frequency manually
Control Center, for principle details, refer to
page 16.
1. Select "FM" or "AM".
2. Press the controller.
3. Move the controller forward to change the
field.
4. Select "Manual" and press the controller.
5. Turn the controller to set a certain fre-
quency.
Updating stations with best reception
If you are on a longer journey and leave the
transmission range of the stations originally set,
you can update the list of stations with the best
reception.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Radio
140
Control Center, for principle details, refer to
page 16.
1. Select "FM" or "AM".
2. Press the controller.
3. Move the controller forward to change the
field.
4. Select "Autostore" and press the controller.
5. Press the controller again.
Other menu items are displayed.
6. Select "Autostore" and press the controller.
The display of the stations with the strongest
reception is updated. The stations are dis-
played based on their frequencies.
Storing stations
Control Center, for principle details, refer to
page 16.
1. Select "FM" or "AM".
2. Select the desired station.
"Set" has been selected.
3. Press the controller.
Other menu items are displayed.
4. Select "Store" and press the controller.
"Presets" is displayed.
5. Turn the controller until the desired mem-
ory position is selected.
The number of the memory position
appears beside the name or frequency of
the station.
6. Press the controller.
The station is stored.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
NavigationEntertainment Driving tips
141
Reference At a glanceControlsCommunicationMobility
The channels of the last selection criterion are
displayed once again after a short time.
The stations are stored for the remote control
currently in use.
Changing a memory location
Control Center, for principle details, refer to
page 16.
1. Select "Presets" and press the controller.
2. Select the desired station.
3. Press the controller.
Other menu items are displayed.
4. Select "Store" and press the controller.
5. Turn the controller until the desired mem-
ory position is selected.
The number of the memory position
appears beside the name or frequency of
the station.
6. Press the controller.
The station is stored.
RDS Radio Data System
RDS transmits additional information in the FM
frequency range. RDS stations have the follow-
ing properties:
> In the case of broadcasting networks that
transmit over a number of frequencies,
there is an automatic switch to the fre-
quency with the best reception quality.
> If the reception conditions are good, the
station names are shown on the Control
Display. If the reception is weak or dis-
rupted, it can take some time before the
station names appear.
Weather Band*
Weather Radio is a service of the National Oce-
anic and Atmospheric Administration – NOAA –
of the U.S. Department of Commerce. Weather
messages are repeated every four to six min-
utes and are routinely revised every one to three
hours, or more frequently if needed. Most of the
stations operate 24 hours daily. During severe
weather, National Weather Service forecasters
can interrupt the routine weather broadcasts
and substitute special warning messages. If you
have a question concerning NOAA Weather
Radio, please contact your nearest National
Weather Service Office, or write to National
Weather Service – Attn: W/OM11–, National
Oceanic and Atmospheric Administration,
1325 East-West Highway Silver Spring, MD.
20910.
Selecting Weather Band
Control Center, for principle details, refer to
page 16.
1. Select "WB" and press the controller.
2. Select the Weather Band station and press
the controller.
The Weather Band station may be unavailable
in some regions.
Satellite radio*
You can receive over 100 different channels
with high sound quality.
The channels are offered to you in predefined
packages. To receive the channels of your
choice, you must have this package enabled.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Radio
142
You may experience signal drops and
muting events related to this new tech-
nology.<
Enabling or disabling channels
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Move the controller back to open "Enter-
tainment".
3. Select "SAT".
4. Press the controller.
The channels are displayed.
These channels are enabled.
Enabling
1. Select a channel that has not yet been
enabled and press the controller.
A telephone number and the electronic
serial number, ESN, are displayed.
The electronic serial number is
required to enable or disable.<
2. To enable the channels:
Dial the phone number.
Disabling
1. Select an enabled channel and press the
controller.
2. Select "ESN" and press the controller.
The electronic serial number, ESN, is dis-
played
The electronic serial number is
required to disable.<
3. To disable the channels:
Dial the phone number.
Selecting and storing channel
1. Select "SAT" and press the controller.
Channels are shown on the Control Display
sorted on the basis of selection criteria.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
NavigationEntertainment Driving tips
143
Reference At a glanceControlsCommunicationMobility
2. Select a menu item:
> "Presets":
Up to twelve channels you have stored
previously.
> "All channels":
All channels are displayed.
> "Categories":
All channels, sorted by categories, e.g.
news, jazz.
3. Press the controller.
4. If "Categories" has been selected:
Select the desired category and press the
controller.
The channels of this category are displayed.
5. Select a channel marked with this sym-
bol.
6. Press the controller.
Other menu items are displayed.
7. Select "Play" and press the controller.
Additional information
The name of the channel and additional infor-
mation on the current track are displayed, e.g.
the name of the artist.
1 Artist
2 Track
Storing channel
1. Select desired channel.
2. Press the controller.
Other menu items are displayed.
3. Select "Store" and press the controller.
"Presets" is displayed.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Radio
144
4. Turn the controller to select a memory loca-
tion and press the controller.
The channel is stored. The channels of the last
selection criterion are displayed once again
after a short time.
Changing channel with buttons next to
CD player
Press the button for the corresponding
direction.
The system switches to the next enabled chan-
nel.
Notes
When there is a signal blockage or the transmis-
sion is suspended momentarily for more than
4 seconds, a message appears on the Control
Display.
Service may be interrupted or unavailable
for specific reasons such as environmen-
tal or topographic conditions and others that
satellite radio cannot directly control.
Signal may not be available under tunnels, in
parking garages, next to tall buildings, nearby
trees with dense foliage, nearby mountains or
other possible strong sources of radio interfer-
ence.
Service should resume normally after the
source of signal unavailability has been
cleared.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
NavigationEntertainment Driving tips
145
Reference At a glanceControlsCommunicationMobility
CD player and CD changer
Listening to CDs
CD player: starting CD
When equipped with two drives:
The upper drive is for audio CDs.
Insert the CD into the drive with the labeled side
up.
Playback starts automatically if the sound out-
put is on.
To start playback when there is already a CD in
the drive:
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Move the controller back to open "Enter-
tainment".
3. Select "CD" and press the controller.
4. On vehicles with a CD changer, select "CD"
and press the controller to start the CD
player.
Playback starts automatically if the sound out-
put is switched on.
To eject the CD, press the button on the
CD player.
The CD emerges slightly from the drive.
*
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
CD player and CD changer
146
CD changer: starting CD
1. Fill the CD magazine and insert, refer to
page 147.
Control Center, for principle details, refer to
page 16.
2. Press button.
This opens the start menu.
3. Move the controller back to open "Enter-
tainment".
4. Select "CD" and press the controller.
5. Select the desired CD and press the con-
troller.
At the end of the last track, the next CD will be
selected.
If new CDs have been placed in the CD maga-
zine, playback starts with the lowest CD, e.g.
CD 1, track 1.
The CD magazine's load status is indicated on
the Control Display.
Selecting a track
Buttons next to CD player:
Press the button for the corresponding
direction repeatedly, continuing until you reach
the desired track on the current CD.
The CD will start play at the start of the track.
The track is displayed on the Control Display.
You can also select the track on the steering
wheel.
Control Center, for principle details, refer to
page 16.
Select a track by turning the controller.
Repeating a track
Control Center, for principle details, refer to
page 16.
1. Select "Set" and press the controller.
Other menu items are displayed.
2. Select "Repeat" and press the controller.
The current music track on the CD is repeated.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
NavigationEntertainment Driving tips
147
Reference At a glanceControlsCommunicationMobility
Stop repeating:
Press controller, select "Repeat" and press
controller again.
Sampling tracks, scan
The system automatically plays a brief sample
from each of the tracks on the current CD.
Control Center, for principle details, refer to
page 16.
1. Select "Set" and press the controller.
Other menu items are displayed.
2. Select "Scan" and press the controller.
To stop the scan:
1. Press the controller.
2. Select "Scan" and press the controller.
This cancels the scan, and the selected track
remains.
Random play sequence
In this mode, the music tracks on the current CD
are played once in a random sequence.
Control Center, for principle details, refer to
page 16.
1. Select "Set" and press the controller.
Other menu items are displayed.
2. Select "Random" and press the controller.
Stop random function:
Press controller, select "Random" and press
controller again.
Fast forward/reverse
Buttons next to CD player:
Press and hold the button for the corre-
sponding direction.
CD magazine
The BMW CD changer for six CDs is installed in
the glove compartment.
Remove CD magazine
To insert or remove CDs from the CD maga-
zine 1, you must first remove it from the CD
changer:
1. Press button 2.
The CD magazine 1 is ejected.
2. Remove CD magazine.
Inserting/removing CDs from
CD magazine
When inserting or removing CDs, remember to
hold them only by their edges, taking care to
avoid touching the data side with its reflective
CD memory surface.
Inserting CDs:
Insert the CD in its slot with the label side on
top.
Removing CDs:
Pull out the desired drawer, refer to arrow, and
remove the corresponding CD.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
CD player and CD changer
148
Inserting CD magazine
Push in the CD magazine as far as possible in
the direction of the arrow.
The CD changer automatically reads in the
loaded CDs and is then ready for operation.
Notes
Data from CDs, CD-Rs and CD-RWs can be
played.
Safety notes
The BMW CD drives are Class 1 laser
products. Do not operate if the cover is
damaged, otherwise severe eye damage can
result.
Do not use self-recorded CDs with labels
applied as these can become detached during
playback due to heat build-up and can cause
irreparable damage to the device.
Only use round CDs with a standard diameter
of 4.7 in/12 cm and do not play CDs with an
adapter, e.g. Single-CDs, otherwise the CDs
or the adapter can jam and may no longer be
ejected.
Do not use a combined CD/DVD, e.g. DVD
Plus
,
as otherwise the CD/DVD can jam and will no
longer eject.<
Malfunctions
To prevent illegal CD copying, manufacturers
often use copy protection. This can mean than
some CDs cannot be played or can only be
played to a limited extent. In this case, please
contact the CD dealer or manufacturer.
You may experience playback problems, such
as skips, when using CD-Rs/CD-RWs that you
have copied at home.
If the CD that you have loaded in the drive does
not play, check to ensure that the CD has been
inserted correctly and inspect it for signs of
defects.
High levels of humidity can lead to condensa-
tion on the laser's scan lens and temporarily
prevent it from reading the CD.
Always hold CDs by the edges; do not touch the
reflecting CD memory surface.
Care instructions
You can find everything you need to know on
this topic by consulting the separate Caring for
your vehicle brochure.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Communications
This chapter summarizes how to
operate your portable phone using the
Control Center or voice control and how
to use BMW Assist or TeleService.
Communications
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Telephoning
152
Telephoning
Safety notes
For your own safety
A car phone makes life more convenient in
many ways, and can even save lives in an emer-
gency. While you should consult your portable
phone's separate Owner's Manual for a detailed
description of safety precautions and informa-
tion, we request that you direct your particular
attention to the following:
Adjustments
To avoid posing a danger to yourself and
other road users, never adjust the system
settings unless your vehicle is stationary.<
Using the phone in your vehicle
Using a portable phone to make and
receive calls while driving is already illegal
in many countries in the world. Always use your
hands-free system, or stop your vehicle in an
area where you will not pose a safety hazard to
other road users.<
Vehicles and portable phones
Do not use your portable phone from
within a garage, or near an open hood.
The air in these areas could contain fuel vapors,
and the portable phone might generate sparks
that could cause fires.
This same precaution applies to open luggage
compartment lids on vehicles equipped for
operation using natural gas or hydrogen, and to
all vehicles with luggage compartment-
mounted batteries.<
Antenna
When using the portable phone, ensure
that all persons in the area are at least
20 in/50 cm from the antenna. Do not use the
portable phone when the antenna is damaged.
Contact between your skin and a damaged
antenna can result in minor burns.
If the antenna is damaged, have it replaced
immediately.<
Special environmental conditions
Always switch off your portable phone in
areas where blasting work is being con-
ducted with explosives. The phone signals
could potentially act as a high-frequency trans-
mitter and set off explosions.
Always switch off your portable phone in areas
where an increased explosion danger is
present. This category includes service stations
along with fuel and chemical storage depots,
etc., and all areas in which the air can contain
fuel, chemicals or metal particles. Under these
conditions, your portable phone could conceiv-
ably generate sparks that could lead to a fire or
explosion. Always observe all legal regulations
governing the use of portable phones in the
vicinity of service stations, chemical factories
and other areas where an explosion potential
exists. Never use your portable phone in air-
craft; do not use this portable phone in hospi-
tals, care centers or at other locations where
medical equipment may be in operation, such
as accident sites.
Your service provider can furnish you with more
detailed information on legal regulations gov-
erning the use of your phone.<
Medical equipment
Portable phones can generate interfer-
ence capable of preventing hearing aids
and cardiac pacemakers from operating cor-
rectly. If you or any occupant of the vehicle will
be using such equipment, consult a physician
or the manufacturer of the equipment to deter-
mine whether it is adequately shielded against
high-frequency energy.<
Batteries
Never attempt to dismantle your portable
phone or its battery. Use only approved
battery types – the wrong battery can destroy
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
153
EntertainmentReference At a glanceControlsDriving tipsCommunication NavigationMobility
your portable phone.
To avoid possible short circuits, after removing
a battery you should never allow it to come into
contact with metallic surfaces of any kind.<
Disposing of used batteries
Return used batteries to a recycling col-
lection point or to your BMW center.<
Care instructions
You can find what you need to know about car-
ing for your portable phone in the separate Car-
ing for your vehicle brochure and in the portable
phone Owner's Manual.
Operating options
You can operate the portable phone
*
with:
> The steering wheel, refer to page 10
> The Control Center, refer to page 153
> Voice commands, refer to page 158
You can get information about activating the
portable phone in the separate Owner's Manual
for the Full Preparation Package Cellphone.
Making calls with the car phone:
BMW Assist calls
You can use the car phone via the hands-free
system for BMW Assist calls.
When the status information "Communication"
is displayed in "Car Phone", only BMW Assist
calls are possible.
Hands-free system
The hands-free microphone is located on the
headliner.
The hands-free system is activated whenever
you establish or receive a call using:
> The buttons on the steering wheel
> The Control Center
> Voice commands
Adjusting volume
Turn the knob during a call to select the desired
volume.
This volume for the hands-free system is main-
tained, even if the other audio sources are set to
minimum volume.
The setting for the remote control currently in
use is stored.
Operation using Control
Center
You can use the following functions through
the Control Center as soon as the portable
phone is inserted into the cradle or connected
to the vehicle via Bluetooth:
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Telephoning
154
> Dial phone number
> Phone book
> Top 8
> Redial
> Display accepted calls
> Display missed calls
> Text messages/SMS
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Move the controller forward to open "Com-
munication".
Receiving calls
If you have the phone number of the caller
stored in the phone book and the phone num-
ber is transmitted, the name of the entry is dis-
played.
Accepting a call
Select "Accept" and press the controller.
Rejecting a call
Select "Reject" and press the controller.
The caller is diverted to your mailbox if it has
been activated.
Calling
Dialing phone numbers
1. Select "Phone" and press the controller.
2. Select "Dial" and press the controller.
3. To enter the phone number: select digits
individually and press the controller.
Always enter the complete phone number
consisting of national dialing code, area
code, and phone number.
To delete a wrong number:
Move controller toward the right to select
, and press controller.
4. Select "Dial number" and press the control-
ler.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
155
EntertainmentReference At a glanceControlsDriving tipsCommunication NavigationMobility
Ending call
1. If necessary, select the telephone number.
2. Press the controller.
Other menu items are displayed.
3. Select "End call" and press the controller.
Phone book
After the portable phone is inserted into the cra-
dle or is connected to the vehicle via Bluetooth,
the phone book is transmitted from the portable
phone to the vehicle. Loading the phone book
can take several minutes.
Dialing from phone book
1. Select "Phone" and press the controller.
2. Select "A - Z" and press the controller:
The entries in the phone book of the porta-
ble phone are displayed on the Control Dis-
play; they are sorted alphabetically.
To run a targeted search for an entry, select
the first letter of the entry and press the
controller.
The first entry that starts with this letter is
displayed.
3. Select the desired entry.
4. Press the controller.
Other menu items are displayed.
5. Select "Call" and press the controller.
The system dials the number.
If different phone numbers are stored in the
portable phone under one name, e.g. office and
home, the name is shown once for each phone
number.
Adding digits to phone numbers
You can add other digits to a phone number
stored in the phone book, e.g. to call a specific
extension:
1. Select "Phone" and press the controller.
2. Select "A - Z" and press the controller.
3. Select the desired entry.
4. Press the controller.
Other menu items are displayed.
5. Select "Add digits" and press the controller.
6. To add to the phone number: select digits
individually and press the controller.
7. Select "Dial number" and press the control-
ler.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Telephoning
156
Lists
Your phone can store phone numbers you have
dialed and missed calls in lists. If the caller is
entered in the phone book, the name of the
entry is displayed instead of the phone number.
You can select the desired subscriber from the
list and establish the connection.
Four lists are available:
> "Top 8"
The eight numbers called most frequently
via the list "A - Z" are automatically stored in
the Top 8 list. The number called most
often appears at the top of the list.
> "Redial"
The last eight phone numbers you have
dialed are automatically stored. The last
number dialed is at the top of the list.
> "Received calls"
The phone numbers of the last eight
accepted calls while the portable phone
was in the cradle or connected to the vehi-
cle via Bluetooth are stored. This requires
the telephone number of the caller to have
been sent.
> "Missed calls"
The phone numbers of the last eight calls
that were not accepted while the portable
phone was in the cradle or connected to the
vehicle via Bluetooth are stored. This
requires the telephone number of the caller
to have been sent.
Dialing from a list
To select an entry and establish a connection:
1. Select "Phone" and press the controller.
2. Select the list:
> "Top 8"
> "Redial"
> "Received calls"
> "Missed calls"
3. Press the controller.
4. Select desired entry.
5. Press the controller.
Other menu items are displayed.
6. Select "Call" and press the controller.
The system dials the number.
Deleting individual entries
1. Select the desired entry from the list.
2. Press the controller.
Other menu items are displayed.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
157
EntertainmentReference At a glanceControlsDriving tipsCommunication NavigationMobility
3. Select "Delete" and press the controller.
The entry is deleted.
Deleting the entire list
1. Select an entry from the list.
2. Press the controller.
Other menu items are displayed.
3. Select "Delete all numbers" and press the
controller.
The list is deleted.
Touch tone dialing
Touch tone numbers are required for access
network services or to control devices, e.g.
remote querying on an answering machine.
This function can only be used during an exist-
ing connection.
1. Establish connection.
2. Press the controller.
Other menu items are displayed.
3. Select "Keypad" and press the controller.
4. Select the desired digits and press the con-
troller. Each digit is sent immediately.
Text messages/SMS*
The symbol on the Control Display shows
that you have received a new text message. It
goes out as soon as there are no longer any
unread text messages.
The number of text messages that can be
stored depends on the memory capacity of your
portable phone.
Displaying text messages/SMS
1. Select "SMS" and press the controller.
The list of received text messages is dis-
played on the Control Display.
The symbol indicates unread text mes-
sages.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Telephoning
158
2. Select the desired text message and press
the controller.
The text message is displayed.
To close the text message:
Move controller toward the front to select ,
and press controller.
Calling sender
1. Select the desired text message and press
controller.
The text message is displayed.
2. Select "Options" and press the controller.
3. Select "Call sender" and press the control-
ler.
The selected sender is called.
Deleting text messages/SMS
1. Select the desired text message and press
the controller.
The text message is displayed.
2. Select "Options" and press the controller.
3. Select "Delete" and press the controller.
The text message of the portable phone is
deleted.
Operation by voice*
The concept
You can operate your portable phone without
having to remove your hands from the steering
wheel. The system operates on the basis of
voice commands that you will learn easily after
using them a few times. In addition, you are also
supported by instructions or questions.
Symbols used
Voice commands
In ignition key position 2:
1. Press button on steering wheel.
A sound signal indicates operating readi-
ness.
2. Say voice commands.
To have the system list the voice com-
mands possible in each case:
Canceling operation via voice
Press button on steering wheel
or
In dialogs where text is spoken, not a command,
e.g. a name, canceling is only possible using the
button. The dialog is automatically inter-
rupted when an incoming call is received.
Voice commands
In addition to the commands described in this
Owner's Manual, alternative commands are
often possible for the same functions, e.g.:
The system recognizes digits from zero to nine.
You can say each digit individually or group
them into a sequence of three to five digits to
accelerate the input.
{...} Indicates voice commands.
{{...}} Indicates system announcements.
{Options}.
{Cancel}.
{Dial name} or {Name}.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
159
EntertainmentReference At a glanceControlsDriving tipsCommunication NavigationMobility
Example: dialing phone number
Start the dialog:
Press button on steering wheel.
Adjusting volume
You can adjust the volume for the instructions
from the system:
Turn the button during an instruction to select
the desired volume.
This volume for the instructions is maintained,
even if the other audio sources are set to mini-
mum volume.
The setting for the remote control currently in
use is stored.
Calling
Dialing phone numbers
Correcting phone number
After the last spoken sequence of digits has
been repeated by the system, you can delete
this sequence of digits.
The command {Correct number} can be
repeated as often as you like.
Deleting input
{Delete} is used to delete all the digits entered
so far.
Voice phone book
Operating by voice command requires a per-
sonal voice phone book. Depending on the
equipment, the entries are either transferred
from the memory of your portable phone or they
must be entered independently. In this case, it
is not possible to use voice command either to
call phone numbers stored in the portable
phone or to store new numbers.
Voice command Response
{Dial number}{{Please say the number}}
e.g. {123 456 7890}{{123 456 7890. Continue?}}
{Dial}{{Dialing number}}
1. {Dial number}.
The dialog for establishing a telephone
connection is opened.
2. Say the phone number.
For telephone calls abroad, say {Plus}
and then the country code.
3. {Dial}.
The connection to the desired sub-
scriber is established.
{Correct number}.
The digits are deleted.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Telephoning
160
Storing entry*
An entry always consists of a name and phone
number.
Selecting an entry
The connection to the phone number of the
selected entry is established.
Having entries read aloud* and
selecting
You can have all the entries of your voice phone
book read aloud in the order of input and select
a certain entry to establish a connection:
Redialing
The {Redial} command calls "Redial".
Deleting entry*
You can delete any entry from the voice phone
book.
Deleting all entries*
{Delete phone book} deletes all entries in the
phone book.
Notes
The voice commands in English were
available as of this printing. Other lan-
guages are currently not available. To operate
the portable phone via the voice command sys-
tem, refer to page 22.<
Important for voice commands
For voice commands, bear in mind the follow-
ing:
> Issue the commands smoothly and at nor-
mal volume, avoiding excessive emphasis
and pauses.
> Keep the doors, windows and glass sunroof
closed to prevent interference from ambi-
ent noise.
> Avoid other sources of noise in the vehicle
while speaking, and ask other vehicle occu-
pants to refrain from talking while you are
using the system.
1. {Save name}.
The dialog for storing a name is
opened.
2. Speak name and repeat entry upon
request.
The spoken length of the names in the
phone book must not exceed approx. 2
seconds.
3. Say the phone number when prompted.
4. To store the phone number:
{Save}.
1. {Dial name}.
The dialog for selecting an entry is
opened.
2. Say the name when prompted.
3. Confirm the prompt with {Yes}.
1. {Read phone book}.
The dialog for reading phone book is
opened.
2. {Dial number} when the desired entry is
read aloud.
1. {Delete name}.
The dialog for deleting an entry is
opened.
2. Say the name when prompted.
3. Confirm the prompt with {Yes}.
1. {Delete phone book}.
The dialog for deleting phone book is
opened.
2. Confirm the prompt with {Yes}.
3. Confirm the repeated prompt with
{Yes}.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
161
EntertainmentReference At a glanceControlsDriving tipsCommunication NavigationMobility
TeleService , BMW Assist
TeleService
TeleService supports you when communicat-
ing with a BMW center. The built-in car phone
can be used to transmit data regarding the ser-
vice status of your vehicle or regarding legally
mandated inspections directly to your BMW
center. This is the same data that is also stored
for CBS Condition Based Service in the master
key. Your BMW center can then contact you,
and you can make an appointment that suits
you while you are still on the road. Your advan-
tage here is that your BMW center can prepare
in advance for the required maintenance work.
The functions of TeleService are country-spe-
cific and depend on your contract: the data
regarding the service status of your vehicle or
regarding legally mandated inspections is
transmitted on a country-specific basis either
automatically before they fall due or during your
calls to the BMW center. Your BMW center will
be glad to provide more detailed information.
BMW Assist
BMW Assist provides you with other services in
addition to TeleService. For example, the posi-
tion data of your vehicle can be transferred to
the BMW Assist response center if an emer-
gency call
*
has been initiated.
Many functions of BMW Assist depend on the
individually agreed contract. Data transmission,
e.g. of the CBS Condition Based Service, dif-
fers from country to country.
The subscriber agreement must be completed
successfully before using the BMW Assist ser-
vices.
Requirements
The installed car phone is logged on to a porta-
ble telephone network. This network must be
capable of transmitting the services.
To transmit position data, the vehicle must be
able to determine the current position. This is
displayed on the Control Display. In order to
enable and update TeleService or BMW Assist,
a GPS signal must be present.
Enabling TeleService or BMW Assist
For you to be able to use the services of
TeleService or BMW Assist, these must be
enabled.
To do this, leave the ignition key in position 1
during the entire process.
Control Center, for principle details, refer to
page 16.
1. Press button.
This opens the start menu.
2. Press the controller to open the menu.
3. Select "Communication settings" and
press the controller.
**
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
TeleService, BMW Assist
162
4. Select "BMW Service settings" and press
the controller.
5. Select "Service Status" and press the con-
troller.
6. Select "Enable services" and press the con-
troller.
TeleService and, if applicable, BMW Assist
are enabled; data exchange with the service
center starts.
Enabling takes a few minutes. The status is dis-
played on the Control Display. If you open
another menu, the enable process continue to
run in the background.
Services offered
The following special features apply for the ser-
vices of TeleService and BMW Assist:
> The services offered are country-specific.
> Voice contact is established or data are
transferred, depending on the equipment
and the country. In some countries, it is also
possible to do both.
> The data transferred can be the vehicle
data, your current position or the data of the
CBS Condition Based Service.
Automatic service notification*
The data on the service status of your vehicle or
on legally mandated inspections is transmitted
automatically directly to your BMW center prior
to the due date. You can check when the BMW
center was notified.
Control Center, for principle details, refer to
page 16.
1. Open the start menu.
2. Press the controller to open the menu.
3. Select "Service" and press the controller.
4. Select "Service requirements" and press
the controller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
163
EntertainmentReference At a glanceControlsDriving tipsCommunication NavigationMobility
5. Select "Service notification" and press the
controller.
Breakdown assistance
You can call Roadside Assistance
*
of the BMW
Group should you require help in the event of a
breakdown.
Control Center, for principle details, refer to
page 16.
1. Open the start menu.
2. Press the controller to open the menu.
3. Select "Service" and press the controller.
4. Select "BMW Service" and press the con-
troller.
5. Select "Roadside Assistance" and press
the controller.
If the current position can be determined,
the current vehicle location is displayed.
6. Select "Start service" and press the con-
troller.
Contact to Roadside Assistance will be estab-
lished.
Setting up contact to your BMW center
or BMW Customer Relations
You can contact your BMW center, e.g. to
arrange a service appointment.
For information related to your vehicle, call the
BMW Customer Relations.
Control Center, for principle details, refer to
page 16.
1. Open the start menu.
2. Press the controller to open the menu.
3. Select "Service" and press the controller.
4. Select "BMW Service" and press the con-
troller.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
TeleService, BMW Assist
164
5. Select desired BMW center:
> "Service Request"
> "Customer Relations"
6. Press the controller.
7. Select "Start service" and press the con-
troller.
Contact to the desired BMW center will be
established.
Adapting TeleService or
BMW Assist
Displaying and updating services
If the offering from TeleService or BMW Assist
changes, you will be notified. In this case you
should update the services.
Control Center, for principle details, refer to
page 16.
1. Open the start menu.
2. Press the controller to open the menu.
3. Select "Communication settings" and
press the controller.
4. Select "BMW Service settings" and press
the controller.
5. Select "Service Status" and press the con-
troller.
The current services available from
TeleService or BMW Assist are displayed.
6. Select "Options" and press the controller.
7. Select "Update services" and press the
controller.
Terminating services
If you terminate the services, your vehicle will
not be equipped to contact the BMW Assist call
center.
Control Center, for principle details, refer to
page 16.
1. Open the start menu.
2. Press the controller to open the menu.
3. Select "Communication settings" and
press the controller.
4. Select "BMW Service settings" and press
the controller.
5. Select "Service Status" and press the con-
troller.
6. Select "Terminate services" and press the
controller.
The use of TeleService or BMW Assist is
blocked. To deactivate the blocking function,
enabling must be carried out again, refer to
page 161. This does not affect the contractual
agreements.
The automatic service notification can be dis-
abled separately. Please contact your BMW
center for this purpose.
Enable TeleService and, if applicable, BMW
Assist to log on again.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
165
EntertainmentReference At a glanceControlsDriving tipsCommunication NavigationMobility
Displaying vehicle data
When TeleService or BMW Assist is activated,
the color designation, the license plate and the
vehicle identification number of your vehicle
can be displayed.
Control Center, for principle details, refer to
page 16.
1. Open the start menu.
2. Press the controller to open the menu.
3. Select "Communication settings" and
press the controller.
4. Select "BMW Service settings" and press
the controller.
5. Select "Profile" and press the controller.
To adjust the license plate, please go to your
BMW center.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
This section helps you maintain your
mobility by supplying important information
on vital topics including fuels and lubricants,
wheels and tires, service, maintenance and
breakdown assistance.
Mobility
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Refueling
168
Refueling
Always switch off the engine before refu-
eling. If you do not, fuel cannot be dis-
pensed into the tank and a message on the
Control Display will appear.<
Always observe all applicable precautions
and regulations when handling fuels.
Never carry spare fuel containers in your vehi-
cle. Whether empty or full, these containers can
leak, cause an explosion, and lead to fire in the
event of a collision.<
Fuel filler door
To open and close: press the rear edge of the
fuel filler door.
Manual release
If an electrical malfunction should occur, you
can unlock the fuel filler door manually.
1. In the luggage compartment, raise the floor
mat and the cover located beneath it.
2. Open the snap fasteners of the right side
panel and take off the side panel.
3. Pull the knob with the gas pump symbol.
Observe the following when refueling
When handling fuels always observe any
safety guidelines posted at the service
station.<
Place the fuel filler cap in the bracket attached
to the fuel filler door.
When refueling, insert the filler nozzle com-
pletely into the filler pipe. Lifting the filler nozzle
during refueling leads to
> premature pump shutoff
> a reduced efficiency of the fuel-vapor
recovery system.
The fuel tank is full when the filler nozzle clicks
off the first time.
Fuel tank capacity
Approx. 18.5 gallons/70 liters, including the
reserve capacity of approx. 2.1 gallons/8 liters.
Refuel as soon as possible once your
cruising range falls below 30 miles/
50 km, as otherwise engine functions are not
ensured and damage can occur.<
Closing fuel filler cap
Fit the cap and turn it clockwise until you clearly
hear a click.
Close the filler cap carefully after refuel-
ling until a click is heard. While closing, be
sure not to squeeze the strap which is fastened
to the cap. A loose or missing cap will activate
an indicator lamp and the message Check Gas
Cap
*
on the Control Display.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
169
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
Fuel specifications
The engine uses lead-free gasoline only.
Required fuel
Premium Unleaded Gasoline
The minimum octane rating is 91.
If you use gasoline with this minimum octane
rating, the engine may produce knocking
sounds when starting at high outside tempera-
tures. This has no affect on the engine life.
Minimum octane rating corresponds to the Anti
Knock Index AKI and is determined according
to the so-called (R+M)/2 method.
Do not use leaded gasoline, as otherwise
the lambda probe and catalytic converter
will be permanently damaged.<
Use high-quality brands
Field experience has indicated significant dif-
ferences in fuel quality: volatility, composition,
additives, etc., among gasolines offered for sale
in the United States and Canada. Fuels contain-
ing up to and including 10% ethanol or other
oxygenates with up to 2.8% oxygen by weight,
that is, 15% MTBE or 3% methanol plus an
equivalent amount of co-solvent, will not void
the applicable warranties with respect to
defects in materials or workmanship.
The use of poor-quality fuels may result in
drivability, starting and stalling problems,
especially under certain environmental condi-
tions such as high ambient temperature and
high altitude.
Should you encounter drivability problems
which you suspect could be related to the fuel
you are using, we recommend that you respond
by switching to a recognized high-quality
brand.
Failure to comply with these recommendations
may also result in unscheduled maintenance.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Wheels and tires
170
Wheels and tires
Tire inflation pressure
Information for your safety
It is not merely the tire's service life, but also
driving comfort and – to a great extent – driving
safety that depend on the condition of the tires
and the maintenance of the specified tire pres-
sure.
Checking pressure
Only check tire inflation pressure when the
tires are cold. This means after a maximum of
1.25 miles/2 km driving or when the vehicle has
been parked for at least 2 hours. When tires are
warm, the tire inflation pressure increases.
Check the tire inflation pressure regularly
and correct it as needed, even on the
compact tire: at least twice a month and before
starting long trips. If you fail to observe this pre-
caution you may be driving on tires with incor-
rect tire pressures, a condition that can not only
compromise your vehicle's driving stability, but
also lead to tire damage and the risk of an acci-
dent. Do not drive with deflated, i.e. flat tires,
except run-flat tires. A flat tire will seriously
impair your vehicle's handling and braking
response. Attempts to drive on a flat tire can
lead to loss of control over the vehicle.<
After correcting the inflation pressure(s),
always reinitialize the Flat Tire Monitor,
refer to page 80.<
Pressure specifications for factory-
installed tires
The inflation pressures for your standard tires at
ambient temperature can be found on the door
post when you open the driver's door.
Pressure specifications for other tire
sizes
The tables below provide all the correct inflation
pressures for the specified tire sizes at ambient
temperature.
For correct identification of the right tire
inflation pressure for your tires, observe
the specifications for the corresponding tire
size.<
Tire size
The inflation pressures apply to the tire sizes
approved and tire brands recommended by
BMW; a list of these is available from your BMW
center.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
171
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
525i/530i
Tire size Pressure specifications in psi/kPa
All pressure specifications in
the table are indicated in psi/
kilopascal with cold tires.
Cold = ambient temperature
225/50 R 17 94 V M+S
225/50 R 17 94 W
245/40 R 18 93 W
225/55 R 16 95 Q,T,H M+S
225/50 R 17 94 Q,T,H M+S
525i only:
225/55 R 16 95 V M+S
225/55 R 16 95 V
29/200 35/240 36/250 44/300
245/45 R 17 95 W
245/45 R 17 95 Q,T,H,V M+S
29/200 32/220 33/230 41/280
Front: 245/40 R 18 93 W 29/200 - 36/250 -
Rear: 275/35 R 18 95 W - 32/220 - 41/280
Front: 245/35 R 19 89 Y 29/200 - 33/230 -
Rear: 275/30 R 19 92 Y - 32/220 - 41/280
Compact wheel:
T 135/80 R 17 102 M
61/420
More details on the permissible load and weights can be found on page 198.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Wheels and tires
172
545i
Tire identification marks
Knowledge of the labeling on the side of the tire
makes it easier to identify and choose the right
tires.
Tire size
Speed letter
Q= up to 100 mph/160 km/h
T = up to 118 mph/190 km/h
H = up to 131 mph/210 km/h
V = up to 150 mph/240 km/h
W = up to 167 mph/270 km/h
Y = up to 186 mph/300 km/h
Tire Identification Number
Tires with DOT codes meet the guidelines of
the U.S. Department of Transport.
DOT code:
Tire age
The manufacturing date of tires is contained in
the tire coding: DOT … 3604 means that the
tire was produced in the 36th week of 2004.
BMW recommends that you replace all tires
after 6 years at most, even if some tires may last
for 10 years.
Tire size Pressure specifications in psi/kPa
All pressure specifications in
the table are indicated in psi/
kilopascal with cold tires.
Cold = ambient temperature
225/50 R 17 94 V M+S
225/50 R 17 94 W
245/40 R 18 93 Y
225/50 R 17 94 Q,T,H M+S
32/220 38/260 38/260 45/310
245/45 R 17 95 W
245/45 R 17 95 Q,T,H,V M+S
29/200 35/240 35/240 42/290
Front: 245/40 R 18 93 Y 32/220 - 38/260 -
Rear: 275/35 R 18 95 Y - 35/240 - 42/290
Front: 245/35 R 19 89 Y 32/220 - 38/260 -
Rear: 275/30 R 19 92 Y - 35/240 - 42/290
Compact wheel:
T 135/80 R 17 102 M
61/420
More details on the permitted load and weights can be found on page 198.
e.g.
Nominal width in mm
Aspect ratio in Ξ
Belted construction – radial
Rim diameter in inches
Carrying capacity ID-code
(not in ZR tires)
Speed code letter
(in ZR tires before the R)
205/60 R
1
591W
e.g.
Manufacturer code
for tire make
Tire size and tire design
Tire age
DOT xxxx xxx 3604
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
173
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
Uniform Tire Quality Grading
Quality grades can be found where applicable
on the tire sidewall between tread shoulder and
maximum section width. For example:
Tread wear 200 Traction AA
Temperature A
DOT Quality Grades
Tread wear
Traction AA A B C
Temperature A B C
All passenger car tires must conform to
Federal Safety Requirements in addition
to these grades.<
Tread wear
The tread wear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified gov-
ernment test course. For example, a tire graded
150 would wear one and one-half, 1γ, times as
well on the government course as a tire graded
100. The relative performance of tires depends
upon the actual conditions of their use, how-
ever, and may depart significantly from the
norm due to variations in driving habits, service
practices and differences in road characteris-
tics and climate.
Traction
The traction grades, from highest to lowest, are
AA, A, B, and C.
Those grades represent the tire's ability to stop
on wet pavement as measured under controlled
conditions on specified government test sur-
faces of asphalt and concrete. A tire marked C
may have poor traction performance.
The traction grade assigned to this tire is
based on straight-ahead braking traction
tests, and does not include acceleration, cor-
nering, hydroplaning, or peak traction charac-
teristics.<
Temperature
The temperature grades are A, the highest, B,
and C, representing the tire's resistance to the
generation of heat and its ability to dissipate
heat when tested under controlled conditions
on a specified indoor laboratory test wheel.
Sustained high temperature can cause the
material of the tire to degenerate and reduce
tire life, and excessive temperature can lead to
sudden tire failure. The grade C corresponds to
a level of performance which all passenger car
tires must meet under the Federal Motor Vehi-
cle Safety Standard No. 109. Grades B and A
represent higher levels of performance on the
laboratory test wheel than the minimum
required by law.
The temperature grade for this tire is
established for a tire that is properly
inflated and not overloaded. Excessive speed,
underinflation, or excessive loading, either sep-
arately or in combination, can cause heat
buildup and possible tire failure.<
RSC – run-flat tires
You will recognize run-flat tires by a circular
symbol containing the letters RSC on the side
of the tire, refer to page 174.
M+S
Winter and all-season tires.
These have better winter properties than sum-
mer tires.
Tire condition
Inspect your tires frequently for tread wear,
signs of damage and for foreign objects lodged
in the tread. Check the tread depth.
Minimum tread depth
The tread depth should not drop below 0.12 in/
3 mm, although, for example, European legisla-
tion only specifies a minimum tread depth of
0.063 in/1.6 mm. At tread depths below 0.12 in/
3 mm there is an increased risk of high-speed
hydroplaning, even when only small amounts of
water are present on the road surface.
When winter tires wear down past a tread depth
of 0.16 in/4 mm, they become perceptibly less
suitable for winter conditions. For the sake of
safety, new tires should be installed.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Wheels and tires
174
Wear indicators at the tread-groove base, refer
to arrow, are distributed over the tire's circum-
ference and are marked on the side of the tire
with TWI – Tread Wear Indicator. If the indica-
tors are at the level of the tread, the legally per-
missible tread depth of 0.063 in/1,6 mm has
been reached.
Wheel/tire damage
Please note that low-profile tires cause wheels,
tires and suspension parts to be more suscep-
tible to road hazard and consequential dam-
ages. Unusual vibrations encountered during
normal vehicle operation can indicate tire failure
or some other vehicle defect. This can, for
example, be caused by driving over curbs.
These kinds of problems may also be signaled
by other changes in vehicle response, such as a
strong tendency to pull to the left or right.
In these cases, reduce speed immedi-
ately and have wheels and tires thor-
oughly checked. To do so, drive carefully to the
nearest BMW center or tire shop that works
according to BMW repair procedures with cor-
respondingly trained personnel. If necessary,
have the vehicle towed there. Tire damage can
be extremely dangerous for vehicle occupants
and other road users.<
Servicing tires
Unprofessional attempts by laymen to
service tires can lead to damage and acci-
dents. Have this work performed by skilled pro-
fessionals only. The technicians at your BMW
center will be glad to assist you with the
required professional knowledge and special-
ized equipment.<
Run-flat tires*
You will recognize run-flat tires by a circular
symbol containing the letters RSC on the side
of the tire.
Run-flat tires consist of self-contained tires and
special rims. The tire reinforcement ensures
that the tire retains some residual safety in the
event of pressure drop and driving remains pos-
sible to a restricted degree.
New wheels and tires
Have new wheels and tires installed only
by your BMW center or tire shop that
works according to BMW repair procedures
with correspondingly trained personnel. If this
work is not carried out properly, there is a dan-
ger of subsequent damage and related safety
hazards.<
Retreaded tires
BMW does not recommend that you use
retreaded tires, since driving safety may
be impaired. The causes for this include the
possibly different tire casing structures and the
often wide variations in their age, which can
result in a limited service life.<
The right wheels and tires
BMW recommends that you use only
wheel and tire combinations that BMW
has tested and approved for your particular
vehicle. Variations in factors such as manufac-
turing tolerances mean that even wheels and
tires with identical official size ratings could
actually have different dimensions than the
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
175
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
approved units – these differences could lead to
body contact, and with it the risk of severe acci-
dents. If non-approved wheels and tires are
used, BMW cannot evaluate their suitability,
and therefore cannot be held liable for driving
safety.<
You can inquire about the right wheel/tire com-
bination at your BMW center.
The correct combination of wheels and tires is
another vital factor in ensuring reliable opera-
tion of various vehicle systems such as ABS
and DSC.
To maintain good handling and vehicle
response, use only tires of a single tread config-
uration from a single manufacturer. After a flat
tire, have the original wheel and tire combina-
tion remounted on the vehicle as soon as possi-
ble.
Recommended tire brands
BMW tests certain tire brands for each tire size,
classifies them as road-safe and approves
them. Consult your BMW center for more infor-
mation.
Observe any country-specific regulations, e.g.
on making a corresponding entry in the vehicle
documents.
The factory-mounted tires have been specially
selected to provide optimized performance
when installed on your vehicle; if properly cared
for, they will provide a combination of safety and
excellent ride comfort.
Run-flat tires
When mounting new tires or changing from
summer tires to winter tires or vice versa, use
run-flat tires because there is no spare tire in
case of a flat. Your BMW center will be glad to
advise you.
For safety reasons, BMW recommends
that you do not have damaged run-flat
tires repaired; they should be replaced.<
Special characteristics of winter tires
BMW recommends winter tires for use in cold
winter driving conditions. Although all-season
M+S tires provide better winter traction than
summer tires, they generally fail to provide the
same levels of cold-weather performance as
winter tires.
Pay attention to speed
Do not exceed the maximum permissible
speed for the winter tires, otherwise tire
damage may occur, which can result in acci-
dents.<
Storage
Always store wheels and tires in a cool, dry
place with as little exposure to light as possible.
Always protect tires against all contact with oil,
grease and fuels. Do not exceed the maximum
tire inflation pressure indicated on the side wall
of the tire.
Snow chains*
BMW only tests certain fine-link snow chains,
classifies them as road-safe and approves
them. Consult your BMW center for more infor-
mation. BMW recommends using these
approved, fine-link snow chains.
Use is only permitted in pairs, with winter tires
on the rear wheels.
Observe the manufacturer's instructions when
mounting snow chains. Do not exceed a speed
of 30 mph/50 km/h with the chains mounted.
After snow chains are mounted, do not
initialize the Flat Tire Monitor.
When driving with snow chains, it can be useful
to activate the DTC temporarily, refer to
page 78.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Under the hood
176
Under the hood
Never attempt to perform any service or
repair operations on your vehicle without
the required, professional technical training. If
you do not know what repair procedures to fol-
low, have work on your vehicle done only by
your BMW center or a workshop that works
according to BMW repair procedures with cor-
respondingly trained personnel. If this work is
not carried out properly, there is a danger of
subsequent damage and related safety haz-
ards.<
Hood
Releasing
Pull the lever located under the left side of the
instrument cluster.
Opening
Press the release handle and open the hood.
Closing
Close the hood from a height of approx. 16 in/
40 cm with momentum. It must be clearly heard
to engage.
Make sure that the closing path of the
hood is clear, as otherwise injuries may
result.
If you see any signs that the hood is not com-
pletely closed while driving your vehicle, you
should stop at once and close it securely.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
177
Reference At a glanceControlsDriving tipsCommunica- NavigationEntertainment
Engine compartment
1 Filler neck for engine oil, refer to Adding
engine oil
2 Brake fluid reservoir, located beneath the
microfilter cover
3 Starting-aid terminal, refer to page 190
4 Dipstick for engine oil, refer to Checking oil
level. The dipstick is further toward the rear
on the 545i
5 Washer fluid reservoir of the headlamp and
windshield cleaning systems, refer to
page 58
6 Expansion tank for coolant, refer to
page 178
Engine oil
The engine oil consumption is dependent on
driving style and driving conditions.
Checking oil level
1. With the engine at operating temperature,
i.e. after at least 6 miles/10 km of uninter-
rupted driving, park the vehicle in a horizon-
tal position.
2. Switch off the engine.
3. After approx. 5 minutes, pull out the dip-
stick 4 and wipe it off with a clean lint-free
cloth, paper towel, or similar material.
4. Carefully push the dipstick all the way into
the guide tube and pull it out again.
The oil should extend to between the two
marks on the dipstick.
The oil quantity between the middle of the two
marks on the dipstick is approx. 1.6 US quarts/
1.5 liters.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Under the hood
178
Do not exceed the upper marking on the
dipstick, otherwise an overfilling of oil can
damage the engine.<
Adding engine oil
Do not top off the oil until the oil level has
dropped to just above the lower marking on the
dipstick. In this area a message also appears on
the Control Display.
Refill the oil within the next 125 miles/
200 km, otherwise engine damage could
result.<
Continuous exposure to used oil has
caused cancer in laboratory testing.
For this reason, any skin areas that come into
contact with oil should be thoroughly washed
with soap and water.
Store oil, grease, etc., well out of the reach of
children; always observe all warning labels on
the containers.<
Oil change
Have oil changed only at your BMW center or
at a workshop that works according to BMW
repair procedures with correspondingly trained
personnel.
Specified engine oils
The quality of the engine oil selected has critical
significance for the operation and service life of
an engine. BMW continuously approves spe-
cific oils after confirming their suitability for use
in its vehicles with extensive testing.
Use only approved BMW High Performance
Synthetic Oil.
If you are unable to obtain BMW High Perfor-
mance Synthetic Oil, you can add small
amounts of another synthetic oil between oil
changes. Use only oils with the API SH specifi-
cation or higher.
Ask your BMW center for details concern-
ing the specific BMW High Performance
Synthetic Oil or synthetic oils which have been
approved.<
You can also call BMW of North America at
1-800-831-1117 or visit this website:
www.bmwusa.com to obtain this information.
Viscosity ratings
Viscosity is the oil flow rating as defined in
SAE classes.
The selection of the correct SAE class depends
on the climatic conditions in the area where you
typically drive your BMW.
Approved oils are in SAE classes 5W-40
and 5W-30.<
These oils may be used for driving in all ambient
temperatures.
Coolant
Do not add coolant to the cooling system
when the engine is hot. Escaping coolant
can cause burns.<
Coolant consists of water and the addition of
antifreeze and anticorrosion agent. Not all com-
mercially available additives are suitable for
your BMW. Ask your BMW center for suitable
additives.
Only use suitable additives, as otherwise
engine damage may result. The additives
present a health hazard; observe the instruc-
tions on the containers.<
Comply with the appropriate environ-
mental protection regulations when dis-
posing of coolant additives.<
Checking coolant level
1. The engine must be at ambient tempera-
ture.
2. Turn the cap of the expansion tank counter-
clockwise to allow any accumulated pres-
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
179
Reference At a glanceControlsDriving tipsCommunica- NavigationEntertainment
sure to escape, then continue turning to
open.
3. The coolant level is correct when the cool-
ant level is between the MIN and MAX
marks, refer to the diagram adjacent to the
filler neck.
4. If the coolant is low, slowly add coolant up to
the specified level – do not overfill.
5. Turn the cap until there is an audible click.
6. Have the reason for the coolant loss elimi-
nated as soon as possible.
Brake system
Malfunctions
Brake fluid
The warning lamp lights up in spite of
the handbrake being released; a mes-
sage appears on the Control Display:
Stop immediately.
The brake fluid in the reservoir has fallen to
below the minimum level. At the same time, a
considerably longer brake pedal travel may be
noticeable. Have the system thoroughly
checked.
Display of the previously described
malfunction on Canadian models.
When you continue driving, an increased
brake pedal path can be necessary, and
significantly longer braking distances might be
required. Please adapt your driving style
accordingly.<
Brake pads
The warning lamp lights up in spite of
the handbrake being released; a mes-
sage appears on the Control Display:
The brake pads have reached their minimum
pad thickness. Have brake pads replaced
immediately.
Display of the previously described
malfunction on Canadian models.
For your own safety: use only brake pads
that BMW has approved for the corre-
sponding vehicle model. As BMW cannot
assess the suitability of other brake pads for
use on your vehicle, we are unable to assume
continued responsibility for the vehicle's oper-
ating safety if non-approved pads are
installed.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Maintenance
180
Maintenance
The BMW maintenance
system
The BMW maintenance system supports the
preservation of the traffic and operating safety
of your BMW. The service schedule also
includes operations related to the vehicle's
comfort and convenience features, such as
replacement of the filters for the inside air. The
ultimate objective is to ensure economical
maintenance by providing the ideal service for
your vehicle.
Should the day come when you decide to sell
your BMW, you will find that a complete dealer
service history is an asset of inestimable value.
CBS Condition Based Service
Sensors and special algorithms take the differ-
ent driving conditions of your BMW into
account. Condition Based Service uses this to
determine the current and future service
requirements. By letting you define a service
and maintenance regimen that reflects your
own individual requirements, the system builds
the basis for trouble-free driving.
You can set the Control Display to show
remaining times or distances of selected main-
tenance intervals and legally mandated dead-
lines, refer to page 66:
> Engine oil
> Brakes, front and rear separately
> Microfilter/activated-charcoal filter
> Brake fluid
> Spark plugs
> Vehicle check
> Legally mandated inspections depending
on local regulations
Your vehicle stores this information continu-
ously in the master key while the vehicle is
being driven. After accessing the data stored in
the master key, your BMW Service Advisor can
suggest precisely the right array of service pro-
cedures for your own individual vehicle. You
should therefore hand over to the BMW Service
Advisor the key you last used to drive when you
take your vehicle in for service.
Make sure the date in the Control Center
is always set correctly, refer to page 74,
as otherwise the effectiveness of CBS Condi-
tion Based Service is not ensured.<
Service and Warranty Information
Booklet for US models and Warranty
and Service Guide Booklet for
Canadian models
Please consult your Service and Warranty Infor-
mation Booklet for US models and Warranty
and Service Guide Booklet for Canadian models
for additional information on service require-
ments.
BMW recommends that you have service
and repair operations performed at your
BMW center.
Take the time to ensure that these service pro-
cedures are confirmed by entries in your vehi-
cle's Service and Warranty Information Booklet
for US models and Warranty and Service Guide
Booklet for Canadian models. These entries
verify that your vehicle has received the speci-
fied regular maintenance.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
181
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
OBD Socket
The Onboard Diagnostics OBD interface
socket is located on the left of the driver's side
under the instrument panel and under a cover.
The cover has the letters OBD on it.
The purpose of the OBD system is to ensure
proper operation of the emission control sys-
tem for the vehicle's lifetime. The system mon-
itors emission-related components and sys-
tems for deterioration and malfunction.
An illuminated lamp informs you of the
need for service, not of the need to stop
the vehicle. However, the systems
should be checked by your BMW center at the
earliest possible opportunity.
Display of the previously described
malfunction on Canadian models.
Under certain conditions, the indicator will blink
or flash. This indicates a rather severe level of
engine misfire. When this occurs, you should
reduce speed and consult the nearest BMW
center as soon as possible. Severe engine mis-
fire over only a short period of time can seri-
ously damage emissions control components,
especially the catalytic converter.
When the fuel filler cap is not properly
tightened, the OBD system can detect
the vapor leak and the indicator will light up. If
the filler cap is subsequently tightened, the
indicator should go out within a few days.<
Event Data Recorders
Your vehicle may be equipped with one or more
sensing and diagnostic modules or a recording
device capable of recording or transmitting cer-
tain vehicle data or information. In addition, if
you have a Subscription Service Agreement for
the BMW Assist system, certain vehicle infor-
mation may be transmitted or recorded in order
to provide such services.
Care
Important information on the care and mainte-
nance of your BMW is contained in the Caring
for your vehicle brochure.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Replacing components
182
Replacing components
Onboard tool kit
The on-board tool kit is located in the luggage
compartment lid.
Loosen the wingnut to open.
Wiper blade replacement
1. Fold the wiper arm out and grasp firmly.
2. Press the safety tabs together while sliding
the wiper blade toward the front to disen-
gage it.
Lamps and bulbs
Lamps and bulbs make an essential contribu-
tion to vehicle safety. You must be duly diligent
in replacing them. BMW recommends having
your BMW center perform any work that you do
not feel competent to perform yourself or that is
not described here.
Never touch the glass of new bulbs with
your bare fingers, as even minute
amounts of contamination will burn into the
bulb's surface and reduce its service life. Use a
clean cloth, napkin, etc., or hold the bulb by its
metal socket.<
You can obtain a selection of replacement bulbs
at your BMW center.
Whenever you perform any work on the
lighting system, turn off the lights
involved so as to prevent short circuits from
occurring. To avoid possible injury or equip-
ment damage when replacing bulbs, observe
any instructions provided by the bulb manufac-
turer.<
For care and maintenance of the headlamps,
please follow the instructions in the separate
Caring for your vehicle brochure.
Halogen headlamps
The illustration shows the left-hand side of the
engine compartment.
1 Cover cap for low beams
2 Cover cap for high beams
Turn the cover cap to the left and remove.
Always wear gloves and eye protection –
the atmosphere within the H7 bulb is
pressurized. Failure to observe this precaution
can lead to personal injury should the bulb be
damaged.<
For checking and adjusting headlamp
aim, please contact your BMW center.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
183
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
Low beams
H7 bulb, 55 watts
1. Turn the bulb holder to the left and remove.
2. Remove and replace the bulb.
High beams
H7 bulb, 55 watts
1. Turn the bulb holder to the left and remove.
2. Remove and replace the bulb.
Parking and roadside parking lamps
Bulb 5 watts, W 5 W
1. Turn the cover cap for low beams or high
beams to the left and remove.
2. Pull out the bulb holder.
3. Remove and replace the bulb.
Xenon lamps*
The service life of these bulbs is very long and
the probability of a failure is very low, provided
that they are not switched on and off an unusual
number of times. In the unlikely event that one
of these lamps should fail, you can respond by
switching on your fog lamps and proceeding
carefully in accordance with the reduced visibil-
ity, where allowed by law.
Have work on the Xenon lighting system
performed only by your BMW center or a
workshop that works according to BMW repair
procedures with correspondingly trained per-
sonnel. Due to the high voltage present in the
system, there is a danger of fatal injuries when
work is carried out improperly.<
Parking and roadside parking lamps
In the event of a malfunction, please go to your
BMW center or a workshop that works accord-
ing to BMW repair procedures with correspond-
ingly trained personnel.
Turn signals, front
Bulb 21 watts, PY 21 W
1. Turn the bulb holder to the left and remove.
2. Apply gentle pressure to the bulb while
turning it to the left for removal and replace-
ment.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Replacing components
184
Side-mounted turn signals
Bulb 5 watts, W 5 W
1. Press back against the front edge of the
light with the tip of your finger, then pivot it
out.
2. Turn the bulb holder to the left and remove.
3. Extract the bulb for replacement.
Side marker lamps, front and rear
To replace, please go to your BMW center or a
workshop that works according to BMW repair
procedures with correspondingly trained per-
sonnel.
Tail lamps
> Turn signals: bulb 21 watts, PY 21 W
> Backup lamps: bulb 16 watts, W 16 W
> Other lamps: bulb 21 watts, P 21 W
1 Turn signals
2 Tail lamp and brake lamp
3 Tail lamp and brake lamp
4 Backup lamps
5 Reflector
6 Roadside parking lamp, tail lamp and
brake lamp
Center brake lamp
This lamp uses LED technology for operation.
In the event of a malfunction, please go to your
BMW center or a workshop that works accord-
ing to BMW repair procedures with correspond-
ingly trained personnel.
Fender-mounted lamps
The illustration shows the recess on the left
side of the luggage compartment.
All the bulbs are integrated into a central bulb
fitting.
1. Lift up floor mat.
2. Undo the quick-release fasteners of the
side panel and pull out the panel.
3. Press together at the top and bottom of the
bulb holder and remove.
4. Backup lamps:
Remove and replace the bulb.
Other lamps:
Apply gentle pressure to the bulb while
turning it to the left for removal and replace-
ment.
Lamps in luggage compartment lid
License plate lamp
Bulb 5 watts, C 5 W
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
185
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
1. Insert screwdriver into the slot and press to
the right, refer to arrows. This releases the
lamp.
2. Remove the lamp and replace the bulb.
Backup lamps
In the event of a malfunction, please go to your
BMW center or a workshop that works accord-
ing to BMW repair procedures with correspond-
ingly trained personnel.
LEDs light-emitting diodes
Light-emitting diodes installed behind translu-
cent lenses serve as the light source for many of
the controls and displays in your vehicle. These
light-emitting diodes, which operate using a
concept similar to that applied in conventional
lasers, are officially designated as Class 1 light-
emitting diodes.
Do not remove the covers, and never
stare directly into the unfiltered light for
several hours, as this could result in irritation of
the retina.<
Changing wheels
Safety precautions in the event of a flat
tire or wheel change: Park the vehicle as
far as possible from passing traffic and on solid
ground. Switch on the hazard warning flashers.
Lock the steering wheel in straight-ahead set-
ting of the wheels. Apply the handbrake and
engage first gear, reverse gear or selector lever
position P.
Have all vehicle occupants get out of the vehicle
and ensure that they remain outside the imme-
diate area in a safe place, such as behind a
guardrail.
If a warning triangle or portable hazard warning
lamp is required, set it up on the roadside at an
appropriate distance from the rear of the vehi-
cle. Comply with all safety guidelines and regu-
lations.
Change the wheel only on a level, firm surface
which is not slippery. The vehicle or the jack
could slip to the side if you attempt to raise the
vehicle on a soft or slippery surface such as
snow, ice, tiles, etc.
Position the jack on a firm support surface.
Do not use a wooden block or similar object as a
support base for the jack, as this would prevent
it from extending to its full support height and
reduce its load-carrying capacity.
To avoid serious or fatal injury: never lie under
the vehicle, and never start the engine while it is
supported by the jack.<
What you will need
To avoid rattling noises later on, note the posi-
tions of the tools before removing them, then
return them to their initial positions after com-
pleting work.
1 Chock
*
2 Vehicle jack
*
3 Lug wrench
*
The tools are located in the hollow of the com-
pact wheel.
1. Lift up floor mat or floor panel flap and cover
located beneath it.
2. Take out the required tools.
3. After using the tools, return then to the stor-
age space.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Replacing components
186
With run-flat tires, no tools are provided
for wheel changes. They can be pur-
chased as accessories at your BMW center.<
Compact wheel*
1. Unscrew the wing nut 1.
2. Remove the washer 2 laterally.
3. Take out the tool mounts 3.
4. Remove the compact wheel.
Preparing wheel change
1. Observe the safety precautions above.
2. Prevent the vehicle from rolling:
Place the chock behind the front wheel on
the other side of the vehicle, or on inclines,
in front of this wheel. On a steep grade, take
other steps to prevent the vehicle from roll-
ing.
3. Loosen the lug bolts a half turn.
Jacking up vehicle
1. Position the vehicle jack at the jacking point
closest to the wheel so that the entire sur-
face of the jack base rests on the ground
perpendicularly beneath the jacking point.
The vehicle jack is designed for
changing wheels only. Do not attempt
to raise another vehicle model with it or to
raise any load of any kind. To do so could
cause accidents and personal injury.<
2. Guide the jack head into the rectangular
recess of the jacking point when cranking
up, refer to illustration detail.
3. Jack the vehicle up until the wheel you are
changing is raised from the ground.
Mounting a wheel
1. Unscrew the lug bolts and remove the
wheel.
2. Remove accumulations of mud or dirt from
the mounting surfaces of the wheel and
hub. Also clean the lug bolts.
3. Position the new wheel or compact wheel.
Secure the wheel by turning at least two lug
bolts into opposite bolt holes.
When you mount wheels other than Genu-
ine BMW light-alloy wheels, different lug
bolts may also be required.
4. Screw in the remaining lug bolts. Tighten all
the bolts securely in a diagonal pattern.
5. Lower the vehicle and remove the jack from
beneath the vehicle.
After mounting
1. Tighten the lug bolts in a diagonal pattern.
To ensure safety, always have the
lug bolts checked with a calibrated
torque wrench as soon as possible to
ensure that they are tightened to the speci-
fied torque. The tightening torque is
88.5 lb ft/120 Nm.<
2. When stowing the wheel and tools in the
vehicle, execute these steps in the reverse
order.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
187
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
3. Check and correct the tire inflation pressure
at the earliest opportunity.
Protect valve stems and valve stem
seal caps against dirt and contamina-
tion. Dirt in valve stems is a frequent source
of gradual air loss.<
4. Reinitialize the Flat Tire Monitor, refer to
page 80.
5. Replace the damaged tire with a new one as
soon as possible and have the new wheel
balanced.
Driving with compact wheel
Drive reservedly and do not exceed a speed of
50 mph/80 km/h.
The driving characteristics change, for example
reduced track stability on braking, extended
braking distance, and altered self-steering
characteristics in the limit range. In conjunction
with winter tires, these characteristics are more
pronounced.
Only one compact wheel may be
mounted. You should re-equip with
wheels and tires of the original size as quickly as
possible.<
Vehicle battery
Battery care
The battery is 100% maintenance-free, i.e., the
electrolyte will last for the life of the battery
when the vehicle is operated in a temperate cli-
mate. Your BMW center will be glad to advise in
all matters concerning the battery.
Charging battery
Only charge the battery in the vehicle via the
terminals in the engine compartment with the
engine off. Connections, refer to Jump starting
on page 190.
Disposal
Have old batteries disposed of by your
BMW center or hand them in to a recy-
cling center. Maintain the battery in an upright
position for transport and storage. Always
restrain the battery to prevent it from tipping
over during transport.<
Power failure
After a temporary power loss, the functioning of
some equipment may be limited and require
reinitialization. Individual settings are also lost
and must be updated again:
> Active steering
The system is deactivated and must be ini-
tialized, refer to page 81. Until then, the
steering will react differently than usual.
> Seat, mirror and steering wheel memory
The positions must be stored again, refer to
page 40.
> Time and Date
The settings must be updated, refer to
page 74.
> Radio
Stations must be stored again, refer to
page 140.
> Navigation system
You must wait until it becomes operational
again, refer to page 128.
Fuses
Never attempt to repair a blown fuse and
do not replace a defective fuse with a sub-
stitute of another color or amperage rating, as
this could lead to a circuit overload, ultimately
resulting in a fire in the vehicle.<
Spare fuses, plastic tweezers and fuse alloca-
tion diagram are located in the compartment for
the onboard tool kit, refer to page 182.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Replacing components
188
In glove compartment
1. Release both quick-release fasteners.
2. Fold the cover forward or remove.
In luggage compartment
1. Lift up floor mat.
2. Release the quick-release fastener of the
right side panel and pull out the panel.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
189
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
Giving and receiving assistance
Emergency calling*
Conditions for an emergency call:
> Once ignition key is in position 1.
> The car phone is logged on to a cellular
telephone network.
> The emergency call system is operable.
Initiating an emergency call
1. To open the protective cover of the keypad:
touch the protective cover.
2. Press the button for at least 2 seconds.
The indicator lamp in the button lights up.
As soon as the voice connection to the
BMW Assist response center has been
established, the indicator lamp flashes.
If conditions allow, remain in the vehicle until
the connection has been established. You will
then be able to provide a detailed description of
the situation.
If the current location of your vehicle can be
determined with vehicles with an activated
BMW Assist, it will be transmitted to the BMW
Assist response center.
Activating BMW Assist, refer to page 161.
If the indicator lamp flashes, but you are unable
to hear the BMW Assist response center
through the hands-free system, this could indi-
cate, for instance, that the hands-free system
is no longer operational. However, the BMW
Assist response center may then still be able to
hear you.
Under certain conditions, an emergency call
is automatically initiated immediately after a
severe accident. The automatic emergency call
is not affected by the button being pressed.
For technical reasons, the emergency call
cannot be guaranteed under unfavorable
conditions.<
Warning triangle*
Always observe all legal regulations
requiring a warning triangle to be carried
in the vehicle.<
The warning triangle is located in the luggage
compartment lid.
Loosen the wingnut to open.
First-aid kit*
Some of the articles contained in the first-
aid kit have a limited service life. There-
fore, check the expiration dates of the contents
regularly and replace the contents concerned in
good time if necessary. You can find replace-
ments in any pharmacy. Comply with legal
requirements requiring you to carry a first-aid
kit in the vehicle.<
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Giving and receiving assistance
190
The first-aid kit is located in the luggage com-
partment lid.
Loosen the wingnut to open.
Roadside Assistance*
The Roadside Assistance of the BMW Group
offers you assistance in the event of a break-
down around the clock, also on weekends and
public holidays.
The phone numbers of the Roadside Assis-
tance in your home country can be found in the
Contact brochure.
In the case of vehicles with BMW Assist or
TeleService, you can contact the Roadside
Assistance of the BMW Group for assistance in
the event of a breakdown directly via the Con-
trol Center, refer to page 163.
Jump starting
When your battery is discharged, you can use
two jumper cables to start your BMW with
power from the battery in a second vehicle. You
can also use the same method to help start
another vehicle. Use only jumper cables with
fully-insulated clamp handles.
To avoid the risk of potentially fatal injury,
always avoid all contact with electrical
components while the engine is running. Care-
fully adhere to the following sequence, both to
prevent damage to one or both vehicles, and to
guard against possible personal injuries.<
Preparation
1. Check whether the battery of the other
vehicle has a voltage of 12 Volts and
approximately the same capacitance in Ah.
This information can be found on the bat-
tery.
2. Switch off the engine of the assisting vehi-
cle.
3. Switch off any electrical accessories in both
vehicles.
There must not be any contact between
the bodies of the two vehicles, as other-
wise there is a danger of shorting.<
Connecting jumper cables
To avoid personal injury from sparks,
always observe this sequence when con-
necting jumper cables.<
On your BMW, the so-called starting-aid termi-
nal in the engine compartment serves as the
battery positive terminal, also refer to Engine
compartment essentials on page 177. The
symbol + is embossed on the cover.
1. Fold open the cover of the BMW starting-
aid terminal. To do so, pull the tab.
2. Attach one end of the jumper cable plus/+
to the positive terminal of the battery or a
starting-aid terminal of the vehicle provid-
ing assistance.
3. Attach the second end of the cable to the
positive terminal of the battery or to a start-
ing-aid terminal of the vehicle to be started.
Your BMW has a special nut as body ground or
negative pole.
4. Attach one end of the jumper cable minus/–
to the negative terminal of the battery or to
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
191
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
an engine or body ground of the assisting
vehicle.
5. Attach the second end of the cable to the
negative terminal of the battery or to the
engine or body ground of the vehicle to be
started.
Starting engine
1. Start the engine on the assisting vehicle
and allow it to run for several minutes at
increased speed.
2. Start the engine on the other vehicle in the
usual way. If the first start attempt is not
successful, wait a few minutes before
another attempt in order to allow the dis-
charged battery to recharge.
3. Let the engines run for a few minutes.
4. Disconnect the jumper cables by reversing
the connection sequence.
Check the battery and recharge if necessary.
Never use spray fluids to start the
engine.<
Towing and tow-starting
Always observe all applicable towing laws
and regulations.<
Never allow passengers to ride in a towed
vehicle for any reason.<
Using tow fitting
The threaded tow fitting is stored in the
onboard tool kit and must always remain in the
vehicle. It can be screwed in at the front or rear
of the BMW.
In order to avoid damaging the tow fitting
and the vehicle, please follow these
instructions: use only the tow fitting provided
with the vehicle and screw it all the way in. Use
the tow fitting for towing only on roads. Avoid
lateral loading of the tow fitting, e.g. do not lift
the vehicle by the tow fitting.<
Access to screw thread
Rectangular cover panel in bumper: press on
the arrow symbol on the cover panel.
Front
Rear
Being towed
Make sure that the ignition key is in posi-
tion 1, as otherwise the steering lock will
engage, making it impossible to steer the vehi-
cle. There is no power assist with the engine
stopped. This then requires increased effort for
braking and steering. Active steering is deacti-
vated and larger steering wheel movements are
required.<
Switch on the hazard warning flashers depend-
ing on the local regulations. If the electrical sys-
tem fails, mark the vehicle to be towed, e.g. with
a sign or warning triangle in the rear window.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Giving and receiving assistance
192
Vehicles with manual transmission
Gearshift lever in neutral position.
Vehicles with automatic transmission
Selector lever in position N.
Do not exceed a towing speed of 45 mph/
70 km/h and a towing distance of
90 miles/150 km, as otherwise the automatic
transmission may be damaged.<
Vehicles with SMG Sequential manual
transmission
With the ignition switched on, engage the
selector lever position N, then switch off the
ignition again.
Towing methods
In some countries, towing with tow bars or
ropes in public traffic is not permitted. Familiar-
ize yourself with the regulations on towing in the
respective country.
With tow bar
The towing vehicle may not be lighter
than the vehicle to be towed, as otherwise
it will not be possible to control vehicle
response.<
The tow fittings used should be on the same
side on both vehicles. Should it prove impossi-
ble to avoid mounting the tow bar at an offset
angle, please observe the following:
> Clearance and maneuvering capability will
be sharply limited during cornering.
> When mounted at an angle, the tow bar will
exert lateral forces, tending to push the
vehicle sideways.
Secure the tow bar to the tow fitting only.
Otherwise damage to other vehicle parts
could result.<
With tow rope
When starting off in the towing vehicle, make
sure that the tow rope is taut.
To avoid jerking and the associated
stresses on vehicle components when
towing, always use nylon ropes or nylon straps.
Secure the tow rope to the tow fitting only.
Otherwise damage to other vehicle parts could
result.<
With tow truck
Have the BMW transported with a tow truck
with a so-called lift bar or on a load bed.
Do not lift vehicle by tow fitting or body
and chassis parts, as otherwise damage
may result.<
Tow-starting
Do not tow-start vehicles with an auto-
matic transmission.
Jump starting, refer to page 190.<
Only tow-start vehicles with a catalytic con-
verter with the engine cold. It is better to jump
start the engine, refer to page 190.
1. Switch on the hazard warning flashers,
comply with country-specific regulations.
2. Turn the ignition key to position 2.
3. Shift into 3rd gear. Vehicles with SMG, see
below.
4. Have the vehicle tow-started with the clutch
pedal completely depressed and slowly
release the clutch. After the engine starts,
immediately depress the clutch pedal com-
pletely again.
5. Stop at a suitable location, remove the tow
bar or rope and switch off the hazard warn-
ing flashers.
6. Have the vehicle checked.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Mobility
193
Reference At a glanceControlsDriving tipsCommunication NavigationEntertainment
Vehicles with SMG Sequential manual trans-
mission:
1. Tow-start in selector lever position N.
2. Select Sequential mode. The correct gear
will be selected and engaged automatically.
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
This chapter contains the technical data,
the short commands of the voice command
system, and the index that will direct you as
quickly as possible to the information sought.
Reference
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Technical data
196
Technical data
Engine data
525i 530i
Displacement
Number of cylinders
cu in/cmµ 152.2/2,494
6
181.8/2,979
6
Maximum output
at engine speed
hp
rpm
184
6,000
225
5,900
Maximum torque
at engine speed
lb ft/Nm
rpm
175/237
3,500
214/290
3,500
545i
Displacement
Number of cylinders
cu in/cmµ 268.4/4,398
8
Maximum output
at engine speed
hp
rpm
325
5,900
Maximum torque
at engine speed
lb ft/Nm
rpm
330/450
3,600
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Technical data
198
Weights
Never exceed either the approved axle loads or the gross vehicle weight.
Capacities
525i 530i
Curb weight
with manual transmission
with automatic transmission/SMG
lbs./kg
3,428/1,555
3,450/1,565
3,472/1,575
3,494/1,585
Approved gross weight
with manual transmission
with automatic transmission/SMG
lbs./kg
4,530/2,055
4,552/2,065
4,575/2,075
4,597/2,085
Load lbs./kg 1,102/500 1,102/500
Approved front axle load lbs./kg 2,161/980 2,227/1,010
Approved rear axle load lbs./kg 2,601/1,180 2,601/1,180
Approved roof load capacity lbs./kg 220/100 220/100
Luggage compartment volume cu ft/l 18.4/520 18.4/520
545i
Curb weight
with manual transmission
with automatic transmission/SMG
lbs./kg
3,803/1,725
3,814/1,730
Approved gross weight
with manual transmission
with automatic transmission/SMG
lbs./kg
4,905/2,225
4,916/2,230
Load lbs./kg 1,103/500
Approved front axle load lbs./kg 2,403/1,090
Approved rear axle load lbs./kg 2,679/1,215
Approved roof load capacity lbs./kg 220/100
Luggage compartment volume cu ft/l 18.4/520
Notes
Fuel tank
Reserve
gal/liters
gal/liters
approx. 18.5/70
approx. 2.1/8
Fuel grade: page 169
Window and headlamp
washer system quarts/liters approx. 3.2/3
For more details: page 58
Engine with oil filter renewal
525i, 530i
545i
quarts/liters
6.9/6.5
8.5/8.0
BMW High Performance
Synthetic Oil.
Oil grades: page 178
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
199
At a glanceControlsDriving tipsCommunication NavigationEntertainmentMobility
Short commands of voice command
system
With short commands you can carry out certain
functions directly, regardless of which menu
item is selected. Here are the important short
commands for the voice command system.
Communication
Navigation
*
Function Command
To open phone 154 {Phone}
To dial phone number 154 {Dial number}
To display phone book 155 {A to Z}
To select from the phone book 155 {Call ...} or
{Dial name}
To display "Top 8" 156 {Top 8}
To redial 156 {Redial}
To display "Received calls" 156 {Received calls}
To display "Missed calls" 156 {Missed calls}
To display "SMS" 157 {SMS}
To display "Bluetooth" {Bluetooth}
To open BMW Assist 161 {BMW Assist}
Function Command
To display current position 125 {Current position}
To open destination entry 115 {Enter address} or
{New destination}
To display "Input map" 117 {Input map}
To open "Information" 118 {Information menu}
To display address book 120 {Address book} or
{From address book}
To display route criteria 122 {Route preference}
To display arrow display 126 {Arrow display}
To display route map 126 {Map}, {Map facing north} or
{Map direction of travel}
To change scale 127 {Scale ... kilometers} or
{Scale ... meters}
To display roads or towns/cities along route 127 {Route list}
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Short commands of voice command system
200
Onboard info
Entertainment
Climate
Function Command
To display computer 70 {Onboard info}
To display trip computer 71 {Trip computer}
To open speed limit 72 {Limit}
To open stopwatch 72 {Stopwatch}
Function Command
To switch on radio 138 {Radio on}
To open "FM" 138 {FM menu}
To open "AM" 138 {AM menu}
To open "All stations" 138 {FM All stations}
To select radio station 138 {Station} Name
To open "Presets" 138 {FM presets} or
{AM presets}
To select stored station 138 {Station ...}
To open "Manual" 139 {FM manual} or
{AM manual}
To open strongest radio station 139 {AM Autostore}
To open "CD" 145 {CD menu}
To select CD 145 {CD 1...6}
To select music track 146 {Track ...}
Function Command
Move temperature distribution for seat heating
forward 44
{Seat heater distribution}
To open "Vent settings" 92 {Vent settings}
To open "Automatic programs" 93 {Automatic programs}
To open "Parked car ventilation" 94 {Parked car operation}
To open "Automatic ventilation" 94 {Automatic ventilation}
To display activation times 94 {Activation time}
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
201
At a glanceControlsDriving tipsCommunication NavigationEntertainmentMobility
menu
Function Command
To open "Door locks" 29, 31 {Door locks}
To open "Steering wheel buttons" 46 {Steering wheel buttons}
To open "Light" 56 {Light}
To open "Communication settings" 161 {Communication settings}
To open "BMW Service settings" 161 {BMW Service settings}
To open "BMW Service" 163 {BMW service}
To open "Service requirements" 66, 162 {Service requirements}
To open "Service" 66, 162 {Service}
To display "Check Control messages" 69 {Check Control messages}
To open "Display settings" 73 {Display settings}
To open "Head-Up Display selection" 85 {HUD configurations}
To set brightness of Control Display 73 {Brightness}
To open "Units" 73 {Units}
To open "Languages" 74, 125 {Language}
To open "Time" 74 {Time}
To open "Date" 74 {Date}
To open "PDC" 76 {PDC}
To open "FTM" 80 {FTM}
To open "Entertainment settings" 133 {Entertainment settings}
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything from A to Z
202
Everything from A to Z
Index
"..." Identifies Control Display
texts used to select
individual functions,
pointing out where these are
located.
A
ABS Antilock Brake
System 77
– indicator lamp 79
– malfunction 79
ACC, refer to Active cruise
control 59
Acceleration assistant for
SMG Sequential manual
transmission 55
Accessories 6
Acoustic Signal, refer to
Check Control 67
Activated-charcoal filter 94
"Activation time" for
independent ventilation 94
Active cruise control 59
– indicator lamp 60
– malfunction 64
– selecting distance 62
– sensor, refer to
Malfunction 64
Active head restraints,
front 42
Active roll stabilization 79
Active seat 44
Active seat ventilation 44
Active steering 81
– initializing system 81
– warning lamp 81
Adaptive Head Light 88
"Add digits" for portable
phone 155
"Address book" for
navigation 120
Address for navigation
– deleting 121
– entering 115
– selecting 121
– storing current position 120
"Add to destination list" 117
Adhesive bandages, refer to
First-aid kit 189
Adjusting active backrest
width 40
Adjusting temperature in
upper body region 93
Adjusting the temperature
with automatic climate
control 91
Adjusting the thigh support 39
Adjusting the tone during
audio operation, refer to
Tone control 133
Adjustment in audio mode
– front-to-rear 134
– right/left balance 134
"After opening door" 41
"After unlocking" 41
Airbags 83
– sitting safely 38
– warning lamp 84
Air circulation, refer to Air
recirculation 91
Air distribution
– automatic 91
– manual 92
Airing, refer to Ventilation 93
Air recirculation
– AUC Automatic recircu-
lated-air control 91
– recirculated-air mode 91
"Air recirculation on / off" 46
Air vent outlets of automatic
climate control 90
Air vents 90
– refer to Ventilation 93
Air volume 91
AKI, refer to Fuel
specifications 169
Alarm system 33
– avoiding unintentional
alarms 34
– interior motion sensor 34
– switching off the alarm 34
– switching off the tilt alarm
sensor and interior motion
sensor 34
– tilt alarm sensor 34
All around the center
console 14
All around the steering
wheel 10
"All channels" 143
"All doors" 29
All-season tires, refer to
Winter tires 175
Altering stretch of road 127
"AM", reception
range 133, 138
Antenna for portable
phone 152
Antifreeze
– coolant 178
– washer fluid 58
Antilock Brake System
ABS 77
– indicator lamp 79
Anti-theft alarm system, refer
to Alarm system 33
Anti-theft system 29
Anti-trapping mechanism
– glass sunroof, electric 36
– power windows 35
Approved axle loads, refer to
Weights 198
Approved gross vehicle
weight, refer to Weights 198
Armrest, refer to Center
armrest
– rear 100
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
203
At a glanceControlsDriving tipsCommunica- NavigationEntertainmentMobility
Arrival time
– refer to Computer 70
– refer to Starting destination
guidance 124
"Arrow display" during
navigation 126
Ashtray
– front 99
– rear 100
Assist, refer to BMW
Assist 161
Assistance systems, refer to
Driving stability control
systems 77
Assistance window 20
AUC Automatic recirculated-
air control 91
"Audio" 134
Audio 132
– controls 132
– switching on/off 132
– tone control 133
– volume 133
Automatic
– air distribution 91
– air volume 91
– garage door opener 96
– headlamp control 87
– service notification 162
– steering wheel adjustment,
refer to Easy entry/exit 45
– storing stations 139
Automatic car washes 108
– also refer to Caring for your
vehicle brochure
Automatic climate control 90
– automatic air distribution 91
– settings using the Control
Center 92
– switching off 92
Automatic curb monitor 41
"Automatic programs" 93
Automatic recirculated-air
control AUC 91
Automatic station search 139
Automatic transmission with
Steptronic 55
– convenience start 52
– interlock 51
– kick-down 56
– selector lever interlock 55
– shiftlock 55
– sport program 56
– starting the engine 52
– tow starting 192
– tow-starting 192
"Automatic ventilation" 94
AUTO program for automatic
climate control 91
"Autostore" on the radio 140
Average fuel consumption 70
– setting the units 73
Average speed, refer to
Computer 70
"Avoid ferries" for
navigation 123
Avoid freeways for
navigation 122
"Avoid highways" for
navigation 122
Avoiding unintentional
alarms 34
"Avoid tollroads" for
navigation 123
Axle loads, refer to
Weights 198
"A - Z" 155
B
Backrests, refer to Seats 38
Backrest width adjustment 39
Backup lamps, refer to
Reverse gear 53
– replacing bulbs 184
Backup lamps, refer to Tail
lamps 184
Balance, tone control 134
Bandages, refer to First-aid
kit 189
Bass, tone control 134
Battery, refer to Vehicle
battery 187
– jump starting 190
Being towed 191
Belts, refer to Safety belts 42
Beverage holder, refer to Cup
holders 99
Black ice, refer to Ice
warning 65
Blower, refer to Air volume 91
BMW Assist 161
– enabling 161
– services offered 162
BMW maintenance
system 180
"BMW Service" 163
"BMW Service settings" 162
Bottle holder, refer to Cup
holders 99
Brake Assistant, refer to DBC
Dynamic Brake Control 77
Brake fluid 179
– warning lamp 179
Brake Force Display 82
Brake lamps
– Brake Force Display 82
– replacing bulbs 184
Brake pads 179
– breaking-in 106
Brake rotors 108
Brakes
– ABS Antilock Brake
System 77
– brake fluid 179
– Brake Force Display 82
– brake pads 179
– breaking-in 106
– handbrake 52
– warning lamps 13
Brake system 106, 179
– brake fluid level 179
– brake pads 106, 179
– breaking-in 106
– disc brakes 108
– warning lamp 79, 179
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything from A to Z
204
Braking
– CBC Cornering Brake
Control 77
– DBC Dynamic Brake
Control 77
– electronic brake-force
distribution 77
– refer to Braking safely 107
Breakdown assistance 163
Breakdown services, refer to
Roadside Assistance 190
Breaking-in the clutch 106
Breaking-in the
differential 106
Break-in period 106
"Brightness" 73
Brightness of Control
Display 73
Buttons on steering wheel 11
C
California Proposition 65
Warning 6
"Call" 155
Call
– accepting 154
– displaying accepted 156
– ending 155
– in absence 156
– starting 154
Calling
– from phone book 155
– from Top 8 list 156
– redialing 156
– refer to telephone Owner's
Manual
"Calling sender" 158
Can holder, refer to Cup
holders 99
Capacities 198
Car battery, refer to Vehicle
battery 187
Car care, refer to Caring for
your vehicle brochure
Car-care products, refer to
Caring for your vehicle
brochure
"Car data" 70
Care 181
– refer to Caring for your
vehicle brochure
Cargo, securing 102, 109
Cargo loading 108
Caring for artificial leather,
refer to Caring for your
vehicle brochure
Caring for leather, refer to
Caring for your vehicle
brochure
Caring for light-alloy wheels,
refer to Caring for your
vehicle brochure
Caring for plastic, refer to
Caring for your vehicle
brochure
Caring for the carpet, refer to
Caring for your vehicle
brochure
Caring for the vehicle finish,
refer to Caring for your
vehicle brochure
Car jack
– jacking points 186
Car keys, refer to Key set 28
Car phone 153
– installation location, refer to
Center armrest 98
– refer to Portable phone 152
– refer to separate Owner's
Manual
Car radio, refer to Radio 138
Car vacuum cleaner
connection, refer to
Sockets 100
Car wash 108
– also refer to Caring for your
vehicle brochure
Catalytic converter, refer to
Hot exhaust system 106
"Categories" 143
CBC Cornering Brake
Control 77
CBS Condition Based
Service 180
"CD" 133, 145
CD changer 145
– controls 132
– fast forward/reverse 147
– installation location 147
– playing a track 147
– random order 147
– repeating a track 146
– selecting a CD 146
– selecting a track 146
– switching on/off 132
– tone control 133
– volume 133
CD player 145
– controls 132
– fast forward/reverse 147
– playing a track 147
– random order 147
– repeating a track 146
– selecting a track 146
– switching on/off 132
– tone control 133
– volume 133
Center armrest
– front 98
– rear 100
Center brake lamp 184
Center console 14
"Central locking" 29
Central locking system 29
– from inside vehicle 31
Changes, technical
– refer to For your own
safety 6
– refer to Parts and
accessories 6
Changing gear
– automatic transmission with
Steptronic 55
Changing settings
– on Control Display 73
Changing the language on the
Control Display 74
Changing the measurement
units on the Control
Display 73
Changing wheels 174, 185
CHECK button 69
Check Control 67
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
205
At a glanceControlsDriving tipsCommunica- NavigationEntertainmentMobility
"Check Control
messages" 69
Check Gas Cap 168
Checking the air pressure,
refer to Tire inflation
pressure 170
Child-restraint fixing system
LATCH 49
Child restraints 47
Child restraint systems 47
Child-safety lock 50
Child seats 47
Chime, refer to Check
Control 67
Chock 185
Chrome parts, care, refer to
Caring for your vehicle
brochure
Cigarette lighter 99
Cleaning, refer to Caring for
your vehicle brochure
Cleaning the windshield, refer
to Wiper system 57
"Climate" 44
Clock 65
– 12h/24h mode 74
– time setting 74
Closing
– from inside 31
– from outside 29
Clothes hooks 99
Cockpit 10
Cold start, refer to Starting
engine 51
"Comfort", active backrest
width adjustment 40
Comfort area, refer to All
about the center console 14
Comfort seat 39
"Communication" 154
"Communication
settings" 161
Compact Disc
– refer to CD changer 145
– refer to CD player 145
Compact wheel
– changing wheels 186
– inflation pressure 171
Computer 69
– clock, 12h/24h mode 74
– displays on Control
Display 70
– hour signal 74
"Concert hall" 135
Condition Based Service
CBS 180
"Confirmation" 30
Confirmation signals for
locking and unlocking 30
Consumption, refer to
Average consumption 70
Consumption indicator
– Energy Control 66
"Continue guidance to
destination?" 125
Control Center 16
– adjusting brightness 73
– assistance window 20
– automatic climate control 92
– changing settings 19, 73
– changing the menu page 19
– confirming selection or
entry 19
– controller 16
– displays, menus 16
– language selection 74
– lists 19
– menu item selection 19
– menu navigation 17
– operating elements 16
– selecting units of
measurement and display
format 73
– setting time and date 74
– start menu 17
– status information 20
– symbols 17
Control Display, refer to
Control Center 16
Controller, refer to Control
Center 16
Controls, refer to Cockpit 10
Convenience operation
– glass sunroof 30
– windows 30
Convenience start, refer to
Starting engine 51
Coolant 178
– level 178
Cooling, maximum 91
Cornering Brake Control
CBC 77
Country of destination for
navigation 116
Courtesy lamps 89
Cradle for telephone or
portable phone 98
Cruise control 58, 59
– active cruise control 59
Cruising range 70
Cup holders 99
Curb weight, refer to
Weights 198
Current fuel consumption 66
"Current position" 125
Current position
– displaying 125
– entering 120
– storing 120
"Customer Relations" 164
Cylinders, refer to Engine
data 196
D
Dashboard, refer to
Cockpit 10
Data 196
– capacities 198
– dimensions 197
– engine 196
– technical data 196
– weights 198
"Date" 74
Date 65
– display format 75
– retrieval 65
– setting 74
"Date format" 75
Daytime driving lamps 87
DBC Dynamic Brake
Control 77
– warning lamp 79
"Deactivated" 41
Deactivating front passenger
airbags 47, 83
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything from A to Z
206
Decommissioning the vehicle
– refer to Caring for your
vehicle brochure
Defrosting windows 91
Defrosting windows and
removing condensation 91
Defrosting windshield, refer to
Defrosting windows 91
Defrost position, refer to
Defrosting windows 91
"Delete address book" for
navigation 122
"Delete all numbers" on the
portable phone 157
"Delete data" for
navigation 122
"Delete" for portable
phone 157, 158
Destination address
– deleting 121
– entering 115
Destination for navigation
– destination list 119
– entry 115
– selecting from address
book 121
– selecting using
information 118
– storing 120
Destination guidance 124
– bypassing route
sections 127
– canceling voice
instructions 46
– changing specified
route 122
– displaying routes 126
– distance and arrival 124
– interrupting 125
– starting 124
– terminating/continuing 125
– voice instructions 125
– volume of voice
instructions 126
Destination list 119
Destinations recently driven
to 119
"Dial" for portable phone 154
"Dial number" 154
"Diamond button" 46
Diamond button 46
Digital clock 65
Dimensions 197
Dipstick for engine oil 177
Directional indicators, refer to
Turn signals 56
Direction announcements,
refer to Voice
instructions 125
Direction instructions, refer to
Voice instructions 125
Directory, refer to Phone
book 155
Directory for navigation, refer
to Address book 120
Disc brakes 108
Displacement, refer to Engine
data 196
Display, refer to Control
Center 16
"Display off" 21
Displays, refer to Instrument
cluster 12
"Display settings" 73
Displays on the windshield,
refer to Head-Up Display 84
Disposal, vehicle battery 187
Distance, refer to
Computer 70
Distance cruise control, refer
to Active cruise control 59
"Distance to dest." 71
Distance to destination, refer
to Computer 70
Distance warning, refer to
PDC Park Distance
Control 76
Divided rear seat back, refer to
Folding down rear seat 101
Door entry lighting 89
Door keys 28
Door lock 31
Door locking, acknowl-
edgment signals 30
"Door locks" 29
Doors
– manual operation 31
– remote control 29
DOT Quality Grades 173
Draft-free ventilation 93
Drinks holder, refer to Cup
holders 99
Drive mode 54
"Driver's door only" 29
Driving lamps, refer to Parking
lamps/low beams 87
Driving notes 106
Driving route, refer to
Displaying route 126
Driving stability control
system 77
Driving through water 107
Driving tips, refer to Driving
notes 106
Dry air, refer to Cooling
function 91
Drying the air, refer to Cooling
function 91
DSC Dynamic Stability
Control 78
– indicator lamp 13, 78
– malfunction 79
DTC Dynamic Traction
Control 78
– activating 78
– indicator lamp 13, 78
DVD for navigation 114
Dynamic Brake Control
DBC 77
Dynamic Driving Control 54
"Dynamic route" for
navigation 123
Dynamic Stability Control
DSC 78
– indicator lamp 13, 78, 79
Dynamic Traction Control
DTC 78
– indicator lamp 13, 78
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
207
At a glanceControlsDriving tipsCommunica- NavigationEntertainmentMobility
E
Easy entry/exit 45
– backrest width 40
Eject button, refer to Buttons
on CD player 132
Electrical malfunction
– door lock 31
– driver's door 31
– fuel filler door 168
– glass sunroof 37
– glass sunroof, electric 37
– luggage compartment lid 33
Electric steering wheel
adjustment 45
Electronic brake-force
distribution 77
Emergency call 189
Emergency operation, refer to
Manual operation
– door lock 31
– driver's door 31
– fuel filler door 168
– glass sunroof 37
– luggage compartment lid 33
Emergency release of luggage
compartment lid from
luggage compartment's
interior 33
Emergency services, refer to
Roadside Assistance 190
"Emission inspect." 67
"Enable services" 162
"End call" 155
Energy-conscious driving,
refer to Energy Control 66
Energy Control 66
Engine
– breaking-in 106
– data 196
– speed 196
– starting 51
– starting difficulties 51
– switching off 52
Engine compartment 177
Engine coolant 178
Engine oil
– adding 178
– checking the oil level 177
– specified engine oils 178
Engine output, refer to Engine
data 196
Engine speed 196
Engine starting, refer to
Starting engine 51
"Enter address" 116
Entering destination 116
Entering the address 115
Entering the intersection 117
"Entertainment" 133
"Entertainment settings" 134
Entry map for destination 117
"Equalizer", refer to Tone
control 135
"ESN" 142
ESP Electronic Stability
Program, refer to DSC
Dynamic Stability
Control 78
Event Data Recorders 181
Exhaust system, refer to Hot
exhaust system 106
Exterior mirrors 45
– automatic dimming
feature 107
– automatic heating 45
Exterior rearview mirror
– passenger-side mirror tilt
function 41
F
Fader, tone control 134
Failure messages, refer to
Check Control 67
False alarm, refer to Avoiding
unintentional alarms 34
Fastening safety belts, refer to
Safety belts 42
– warning lamp 43
Fastest route for
navigation 122
"Fast route" for
navigation 122
First aid, refer to First-aid
kit 189
First-aid kit 189
Flashlight 98
– refer to Rechargeable
flashlight 98
Flash when locking/
unlocking 30
Flat tire
– changing wheels 185
– compact wheel 186
– Flat Tire Monitor 80
– run-flat tires 80, 174
Flat Tire Monitor 79
– false alarms 80
– initializing system 80
– malfunctions 81
– snow chains 175
– system limits 80
– warning lamp 80
Flat tires, refer to Tire
condition 173
"FM", reception
range 133, 138
FM, waveband 138
Fog lamps 88
– indicator lamp 13, 88
Folding down rear seat 101
Folding rear seat back 101
Footbrake, refer to Braking
safely 107
Footwell lamps 89
Forward, fast
– CD changer 147
– CD player 147
For your own safety 6
Front airbags 83
Front armrest, refer to Center
armrest
– front 98
Front seat adjustment 38
"FTM" 80
Fuel 169
– capacity 198
– display 66
– high-quality brands 169
– quality 169
– specifications 169
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything from A to Z
208
Fuel consumption display
– computer, average fuel
consumption 70
Fuel display, refer to Fuel
gage 66
Fuel filler door 168
– releasing in the event of
electrical malfunction 168
Fuel gage 66
Fuses 187
G
Garage door opener, refer to
Integrated universal remote
control 96
Gasoline, refer to Required
fuel 169
Gasoline display, refer to Fuel
gage 66
Gear changes
– SMG Sequential manual
transmission 54
Gear display
– automatic transmission with
Steptronic 55
– SMG Sequential manual
transmission 53
Gearshift lever
– automatic transmission with
Steptronic 55
– manual transmission 53
– SMG Sequential manual
transmission 53
General driving notes 106
Glass sunroof, electric 35
– auto-remote operation from
outside 31
– opening and closing
manually 37
– remote control 30
Glove compartment 97
– lighting 97
– rechargeable flashlight 98
GPS navigation, refer to
Navigation system 114
Grills, refer to Ventilation 93
Grills of the automatic climate
control 90
Gross vehicle weight, refer to
Weights 198
H
Halogen lamps 183
Handbrake 52
– indicator lamp 13, 52
Hands-free system 153
– refer to Microphone 14
Hazard warning flashers 15
Head airbags 83
Headlamp control,
automatic 87
Headlamp flasher 56
Headlamps 87
– care, refer to Caring for your
vehicle brochure
– cleaning, refer to Wiper
system 57
– replacing bulbs 183
Head Light, refer to Adaptive
Head Light 88
"Headphone operation
only" 137
"Headphones" 137
Head restraints 41
– front head restraints,
active 42
Head-Up Display 84
Heated mirrors 45
Heated rear window 90
Heated seats 43
Heated steering wheel 46
Heating 90
– exterior mirrors 45
– interior 90
– rear window 90
– residual heat utilization 92
– seats 43
– steering wheel 46
Heating while stationary 92
Heating with engine switched
off, refer to Residual heat
utilization 92
Heavy cargo, refer to Securing
cargo 109
Height, refer to
Dimensions 197
Height adjustment
– seats 39
– steering wheel 45
High beams 88
– headlamp flasher 88
– indicator lamp 13
– replacing bulbs 183
High water, refer to Driving
through water 107
Hills 108
Holder for cups 99
"Home address" 122
Hood 176
Horn 10
Hot exhaust system 106
"Hour memo" 74
"House number" for desti-
nation entry 117
Hydraulic brake assistant,
refer to DBC Dynamic Brake
Control 77
Hydroplaning 107
I
Ice warning 65
iDrive, refer to Control
Center 16
Ignition key 28
Ignition key positions, refer to
Ignition lock 51
Ignition lock 51
Independent ventilation 94
– activating the activation
time 95
– preselecting activation
times 94
– switching on and off
directly 94
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
209
At a glanceControlsDriving tipsCommunica- NavigationEntertainmentMobility
Indicator/warning lamps 13
– ABS Antilock Brake
System 79
– active steering 81
– airbags 84
– brake fluid 179
– brake pads 179
– brake system 13, 79
– DSC Dynamic Stability
Control 13, 78
– DTC Dynamic Traction
Control 13, 78
– Flat Tire Monitor 80
– front fog lamps 13
– overview 13
– safety belt warning 42
Individual air distribution 92
Individually assignable
buttons on the steering
wheel 46
Individual settings, refer to
Key Memory 28
Inflation pressure, refer to Tire
inflation pressure 170
Inflation pressure monitoring,
refer to Flat Tire Monitor 79
Information
– on another location 118
– on current position 118
– on destination location 118
"Information" for
navigation 119
"Information on
destination" 119
Initializing, refer to Power
loss 187
"Input map" 118
Installation location
– CD changer 147
– portable phone 98
Instructions for navigation
system, refer to Voice
instructions 125
Instrument cluster 12
Instrument illumination, refer
to Instrument lighting 89
Instrument lighting 89
Instrument panel
– refer to Cockpit 10
– refer to Instrument
cluster 12
Integrated universal remote
control 96
"Interim time" 73
Interior lamps 89
– remote control 30
Interior motion sensor 34
– switching off 34
Interior rearview mirror 45
– automatic dimming
feature 107
Interlock on automatic
transmission 51
Intermittent mode of the
wipers 57
J
Jacking points 186
Joystick, refer to Control
Center 16
Jumpering, refer to Jump
starting 190
Jump starting 190
K
Key Memory 28
"Keypad" 157
Keys 28
Kick-down
– automatic transmission with
Steptronic 56
– SMG Sequential manual
transmission 54
Knock control 169
L
Lamps, refer to Parking lamps/
low beams 87
Lamps and bulbs 182
"Languages" 74
– for navigation 126
Lashing down cargo, refer to
Securing cargo 109
Lashing eyes, refer to
Securing cargo 109
Last destinations, refer to
Destination list 119
"Last seat pos." 41
LATCH child-restraint fixing
system 49
LEDs light-emitting
diodes 185
Length, refer to
Dimensions 197
Letter symbol with portable
phone 157
License plate lamp, replacing
bulbs 184
"Light" 56, 87
Light-emitting diodes
LEDs 185
Lighter 99
Lighter socket 100
Lighting
– instruments 89
– of the vehicle, refer to
Lamps 87
Lights on warning 87
Light switch 87
"Limit" 72
Loading
– securing cargo 109
– stowing cargo 109
– vehicle 108
Location, navigation drive 114
"Lock after driving off" 32
Lock buttons in the doors,
refer to Locking 32
Locking
– from inside 32
– from outside 30
– setting confirmation
signals 30
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything from A to Z
210
Locking and unlocking doors
– from inside 31
– from outside 29
– setting confirmation
signals 30
"LOGIC7", refer to Tone
control 135
Low beams 87
– automatic 87
– replacing bulbs 183
Lower back support, refer to
Lumbar support 39
Lug bolts 186
– tightening torque, refer to
After mounting 186
– wrench 185
Luggage compartment
– capacity 198
– opening/closing, refer to
Luggage compartment
lid 32
– opening from inside 32
– opening from outside 32
– opening separately 33
– opening with remote
control 30
– socket 100
Luggage compartment lid 32
– emergency operation 33
– locking and unlocking from
inside 31
– locking separately 33
– opening from inside 32
– opening from outside 32
– securing separately 33
– unlocking manually 33
Luggage rack, refer to Roof-
mounted luggage rack 110
Lumbar support 39
LW, waveband 138
M
M+S tires, refer to Winter
tires 175
Maintenance, refer to Service
and Warranty Information
Booklet for US models or
Warranty and Service Guide
Booklet for Canadian
models 180
Maintenance system 180
Malfunction warnings, refer to
Check Control 67
Manual air distribution 92
Manually controlled recircu-
lated air 91
Manual mode
– automatic transmission with
Steptronic 56
– SMG Sequential manual
transmission 54
"Manual" on the radio 139
Manual operation
– door lock 31
– driver's door 31
– glass sunroof 37
Manual release
– fuel filler door 168
– luggage compartment lid 33
Manual transmission 53
Map
– changing scale 127
– destination entry 117
"Map, direction of travel" 127
"Map, facing north" 127
Map facing north 126
Master key with remote
control 28
Maximum cooling 91
Maximum roof weight 198
Maximum speed
– for winter tires 175
– with compact wheel 187
Memory
– refer to Key Memory 28
– refer to Seat, mirror and
steering wheel memory 40
Menus, refer to Control
Center 16
Menu selection 19
Microfilter 94
Microphone
– for hands-free system 153
– for portable phone 14
– for voice command
system 14
Mirrors 45
– automatic curb monitor 41
– dimming feature 107
– folding in and out 45
– heating 45
– memory, refer to Seat, mirror
and steering wheel
memory 40
"Missed calls" 156
Missed calls 156
Monitor, refer to Control
Center 16
"Monitor display on" 77
"Monitor on / off" 46
Most recent portable phone
numbers 156
Multi-function steering wheel,
refer to Buttons on steering
wheel 11
Multifunction switch
– refer to Turn signals/
headlamp flasher 56
– refer to Wiper/washer
system 57
Music track, finding 147
"Mute on / off" 46
MW, waveband 138
N
Navigation destination
– home address 122
– manual entry 115
– selecting via map 117
Navigation drive, location 114
Navigation DVD 114
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
211
At a glanceControlsDriving tipsCommunica- NavigationEntertainmentMobility
Navigation system 114
– address book 120
– bypassing route
sections 127
– destination entry 115
– destination guidance in
assistance window 114
– destination list 119
– displaying current
position 125
– entering a destination
manually 115
– opening 115
– route display 126
– route list 127
– selecting destination using
information 118
– selecting destination via
map 117
– selecting route criteria 122
– starting destination
guidance 124
– switching off, refer to Termi-
nating/continuing desti-
nation guidance 125
– terminating/continuing
destination guidance 125
– voice instructions 125
– volume adjustment 126
"Navigation voice instructions
on" 126
Neck support, refer to Head
restraints 41
"New address" for
navigation 120
"New destination" 115, 117
New key 28
"New route" 127
New wheels and tires 174
"Next entertainment
source" 46
"Normal", active backrest
width adjustment 40
Nozzles, refer to Windshield
washer nozzles 58
Nylon rope, refer to Towing
and Tow-starting 191
O
OBD Socket 181
Octane ratings, refer to Fuel
specifications 169
Odometer 65
Oil
– capacity 198
– consumption, refer to
Engine oil, checking 177
– dipstick 177
– level 177
– refilling, refer to Engine oil,
adding 178
– specified engine oils 178
Oil change intervals, refer to
Service requirements 66
Old batteries, refer to
Disposal 187
"On a new destination" for
navigation 119
Onboard computer, refer to
Control Center 16
"Onboard information" 70, 71
Onboard tool kit 182
"On destination" 119
"On location" 119
Opening and closing
– from inside 31
– from outside 29
– using remote control 29
– using the door lock 31
Operation by voice for
portable phone 158
– adjusting volume 159
– canceling 158
– correcting phone
number 159
– dialing phone number 159
– placing a call 159
– redialing 160
– voice commands 158
– voice phone book 159
"Options" for portable
phone 158
Orientation menu, refer to
Control Center, start
menu 17
Output, refer to Engine
data 196
Outside air, refer to AUC
Automatic recirculated-air
control 91
Outside temperature
display 65
– changing unit of
measurement 73
– in computer 73
P
Panic mode 30
Park Distance Control PDC 76
"Parked car operation" 94
Parking aid, refer to PDC Park
Distance Control 76
Parking brake, refer to
Handbrake 52
Parking lamps 87
– replacing bulbs 183
Parking lamps/low beams 87
– replacing bulbs 183
Parking vehicle 52
Parts and accessories 6
Passenger-side mirror tilt
function 41
"Pathway lighting" 87
Pathway lighting 87
"PDC" 77
PDC Park Distance Control 76
Phone book 153
Phone numbers
– deleting from phone
book 156
– dialing 154
– most recent numbers 156
– selecting in phone book 156
– Top 8 156
"Play" on the radio 143
Pollen, refer to Microfilter/
activated charcoal filter 94
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything from A to Z
212
Portable phone
– accepted calls 156
– adjusting volume 153
– calling 154
– ending call 155
– hands-free system 153
– installation location, refer to
Center armrest 98
– missed calls 156
– operation using Control
Center 153
– phone book 155
– redialing 156
– refer to separate Owner's
Manual
– SMS 157
– Top 8 156
– touch tone dialing 157
Portable phone battery 152
Portable phone in the
vehicle 107
Portable phones, use in the
interior, refer to Mobile
communications
systems 107
Position
– displaying 125
– storing 120
Power failure 187
Power windows, refer to
Windows 34
Preselecting activation times
of the Independent
ventilation 94
"Presets" on the
radio 138, 143
Pressure, tires 170
Pressure monitoring of tires,
refer to Flat Tire Monitor 79
Programmable buttons on the
steering wheel 46
Protective function, refer to
Anti-trapping mechanism
– glass sunroof, electric 36
– windows 35
R
Radio
– autostore 139
– controls 132
– sampling stations 139
– satellite radio 141
– selecting the frequency
manually 139
– selecting the
waveband 133, 138
– station search 139
– station selection 138
– station with the best
reception 139
– storing stations 140
– switching on/off 132
– tone control 133
– volume 133
– Weather Band 141
Radio-control key, refer to
Master key with remote
control 28
Rain sensor 57
"Random", random play
sequence 147
Reading lamps 89
Rear armrest, refer to Rear
center armrest 100
Rear lamp, refer to Tail
lamps 184
– replacing bulbs 184
"Rear not enabled" 137
Rear seat back, folding 101
"Rear seat entertainment via
headphones" 136
"Rear seat entertainment via
speakers" 136
Rear seats
– folding backrests 101
– head restraint adjustment 42
– heating 44
Rear ventilation 93
Rearview mirror 45
Rear window blind, refer to
Roller sun blinds 97
Rear window defroster 90
Rear window safety switch 35
"Received calls" 156
Receiving level of portable
phone, refer to Status
information 20
Reception
– quality 141
– radio stations 141
– regional station 139
Recirculated-air mode
– air recirculation 91
– AUC Automatic recircu-
lated-air control 91
Reclining seat, refer to
Backrest 39
Recording times, refer to
Stopwatch 72
"Redial" for portable
phone 156
Refueling 168
Releasing hood 176
"Relock door if not
opened" 32
Remaining distance
– refer to Computer 70
– refer to Cruising range 70
Remote control 28
– entertainment 136
– garage door opener 96
– luggage compartment lid 30
– malfunction 30
Removing condensation on
the windows 91
"Repeat" in audio mode 146
Replacement fuses 187
Replacement key, refer to
New key 28
Replacement of tires, refer to
Changing wheels 185
Replacing bulbs, refer to
Lamps and bulbs 182
Replacing tires 174
Reporting an accident, refer
Initiating an emergency
call 189
Reporting safety defects 7
Reserve warning, refer to Fuel
gage 66
Reservoir for washer
systems 58
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
213
At a glanceControlsDriving tipsCommunica- NavigationEntertainmentMobility
"Reset" stopwatch 73
Residual heat mode 92
Restraint system for
children 47
Restraint systems, refer to
Safety belts 42
Retreaded tires 174
Reverse, fast
– CD changer 147
– CD player 147
Reverse gear
– automatic transmission with
Steptronic 56
– manual transmission 53
– SMG Sequential manual
transmission 54
Road map 126
"Roadside Assistance" 163
Roadside Assistance 190
Roadside parking lamps 88
– replacing bulbs 183
Roller sun blind, refer to Sun
blinds 97
Roof-mounted luggage
rack 110
Rope, refer to Towing and
tow-starting 191
Rotary pushbutton, refer to
Control Center 16
Route 122
– bypassing sections 127
– changing 122
– displaying 126
– displaying arrow view 126
– displaying map 126
– displaying town 127
– list 127
– selecting 122
– selecting criteria 122
"Route list" for navigation 127
Route map 126
"Route preference" 122
Route selection 122
RSC, refer to Run-flat
tires 174
Run-flat System Components
RSC, refer to Run-flat
tires 174
Run-flat tires 174
– continuing driving with a
damaged tire 80
– flat tire 80
– new wheels and tires 174
– tire inflation
pressure 80, 170
– tire replacement 174, 175
S
Safety 6
Safety belts 42
– damage 43
– sitting safely 38
– warning lamp 43
Safety belt tensioners
– refer to Airbags 83
– refer to Safety belts 42
Safety systems
– ABS Antilock Brake
System 77
– airbags 83
– DSC Dynamic Stability
Control 78
– safety belts 42
Satellite radio 141
– enabling 142
– selecting channel 142
– storing channel 142
"SAT" for radio 133, 142
"Save current
destination" 122
Scan
– CD changer 147
– CD player 147
– radio 139
"Scan", playing stations 139
"Scan", playing tracks 147
Screen, refer to Control
Center 16
Screw thread for tow
fitting 191
"Seat heater distribution" 44
Seats 38
– active backrest width
adjustment 40
– adjusting the seats 38
– comfort seat 39
– easy entry/exit 40
– heating 43
– lumbar support 39
– memory, refer to Seat, mirror
and steering wheel
memory 40
– sitting safely 38
– Sports seat 39
– storing the setting 40
– thigh support 39
– ventilation, refer to Active
seat ventilation 44
"Select as destination" 119
"Select current speed" 72
Selecting audio sources, refer
to Operation using Control
Center 133
Selecting distance for active
cruise control 62
Selecting new scale for
navigation 127
Selecting route 122
Selecting the frequency
manually 139
Selection options with
navigation system 122
Selector lever
– automatic transmission with
Steptronic 55
– SMG Sequential manual
transmission 53
Selector lever interlock, refer
to Shiftlock
– automatic transmission with
Steptronic 55
– SMG Sequential manual
transmission 54
Selector lever positions
– automatic transmission with
Steptronic 55
– manual transmission 53
– SMG Sequential manual
transmission 53
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything from A to Z
214
Sequential manual trans-
mission SMG 53
"Service" 66, 162
Service, refer to Roadside
Assistance 190
Service and Warranty Infor-
mation Booklet for US
models and Warranty and
Service Guide Booklet for
Canadian models 180
Service car, refer to Roadside
Assistance 190
Service interval indicator, refer
to Service requirements 66
"Service notification" 163
"Service Request" 164
"Service
requirements" 66, 162
Service requirements 66
– also refer to CBS Condition
Based Service 180
"Service Status" 162
"Set date" 74
"Set" in audio mode 133
"Set service date" 67
"Set time" 74
Settings, configuring, refer to
Key Memory 28
Setting speed limit 72
Setting the time, refer to
Preselecting switch-on
times 94
"Set tire pressure" 80
Shifting gears
– automatic transmission with
Steptronic 56
– SMG Sequential manual
transmission 54
Shiftlock
– automatic transmission with
Steptronic 55
– SMG Sequential manual
transmission 54
Shift paddles 54
Short commands of voice
command system 199
Shortest route for
navigation 122
"Short route" for
navigation 122
Shoulder support 39
"Show current position" 118
"Show destination
position" 118
Shuffled, refer to Random
– CD changer 147
– CD player 147
Side airbags 83
Side marker lamps, replacing
bulbs 184
Side turn signals, replacing
bulbs 184
Side window blind, refer to
Sun blinds 97
Sitting safely 38
– with airbags 38
– with safety belts 38
Ski bag 101
Ski sack, refer to Ski bag 101
Sliding/tilt sunroof, refer to
Glass sunroof, electric 35
SMG Sequential manual
transmission 53
– acceleration assistant 55
– breaking-in 106
– convenience start 52
– Dynamic Driving Control 54
– gear display 53
– kick-down 54
– shiftlock 54
– towing 192
– tow-starting 192
"SMS" 157
Snow chains 175
Socket for Onboard
Diagnostics interface 181
Socket outlet
– cigarette lighter socket 100
Sockets 100
SOS, refer to Initiating an
emergency call 189
Sound output for Enter-
tainment on/off 133
Spare fuses 187
Spare key 28
Spare wheel
– refer to Changing
wheels 185
– refer to Compact wheel 186
Special oils, refer to Specified
engine oils 178
Specified engine oils 178
Speed
– with compact wheel 187
– with winter tires 175
Speed-dependent
volume 134
Speed limit warning, refer to
Speed limit 72
Speedometer 12
"Speed volume", refer to
Tone control 134
"Sport", active backrest width
adjustment 40
Sport program, refer to
Dynamic Driving Control 54
Sports seat 39
Stability control, refer to
Driving stability control
systems 77
"Star button" 46
Star button 46
"Start destination
guidance" 118
"Start" for stopwatch 73
"Start guid-
ance" 117, 119, 121, 124
Starting, refer to Starting
engine 51
Starting assistance, refer to
Jump-starting 190
Starting difficulties
– jump starting 190
– refer to Special starting
conditions 51
Start menu in Control
Display 17
"Start service" 163
"State / Province" for desti-
nation entry 116
"State inspection" 67
Station, refer to Radio 138
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
215
At a glanceControlsDriving tipsCommunica- NavigationEntertainmentMobility
"Status" 66
Status of this Owner's Manual
at time of printing 5
Steering wheel
– adjustment 45
– buttons on steering
wheel 11
– easy entry/exit 45
– heating 46
– memory 40
– programmable buttons 46
"Steering wheel buttons" 46
Steering with variable ratio,
refer to Active steering 81
Steptronic, refer to Automatic
transmission with
Steptronic 55
"Stop" for stopwatch 73
"Stopwatch" 72
Stopwatch 72
Storage compartments 99
"Store current
destination" 122
"Store current position" 122
"Store in address book" for
navigation 120
"Store" on the radio 140, 143
Storing current position 120
Storing sitting position, refer
to Seat, mirror and steering
wheel memory 40
Storing tires 175
Straps, refer to Loading 109
"Street" for destination
entry 117
Summer tires, refer to Wheels
and tires 170
Sun blinds 97
SW, waveband 138
Switches, refer to Cockpit 10
Switching navigation voice
instructions on/off 125
Switching off engine 52
Switching off the tilt alarm
sensor 34
Switching on
– audio 132
– CD changer 132
– CD player 132
– radio 132
Switching on hour signal 74
Switching the cooling function
on and off 91
Swiveling headlamps, refer to
Adaptive Head Light 88
Symbols 4
– Control Display 20
T
Tachometer 65
Tail lamps 184
– replacing bulbs 184
Tank contents, refer to
Capacities 198
Target cursor for
navigation 118
Technical data 196
Telematik, refer to
TeleService, BMW
Assist 161
Telephone, refer to Portable
phone 152
"Telephone list" 46
TeleService 161
– enabling 161
– services offered 162
Temperature display
– ice warning 65
– outside temperature 65
– setting the units 73
Tempomat, refer to Cruise
control 58
"Terminate services" 164
"Text language" 74
"Theater" 135
The individual vehicle 5
Third brake lamp, refer to
Center brake lamp 184
Tightening torque of the lug
bolts, refer to After
mounting 186
Tilt function, passenger-side
mirror 41
"Time" 74
"Time 1" for independent
ventilation 94
"Time 2" for independent
ventilation 94
"Time format" 74
Timer, refer to Preselecting
activation time 94
Tire inflation pressures 170
Tire pressure, loss 80
Tire pressure monitoring,
refer to Flat Tire Monitor 79
Tire Quality Grading 173
Tire replacement
– new wheels and tires 174
Tires
– age 172
– air loss 80
– breaking-in 106
– changing 174
– condition 173
– damage 174
– flat tire, refer to Changing
wheels 185
– inflation pressure 170
– new wheels and tires 174
– pressure monitoring 79
– replacing 185
– retreaded tires 174
– run-flat tires 174
– size 172
– tread 173
– wear indicators 173
– wheel/tire combination 174
– winter tires 175
"Tone" 134
Tone in audio mode
– adjusting 133
– middle setting 135
Tone on locking/unlocking 30
Tools, refer to Onboard tool
kit 182
"Top 8" for portable
phone 156
Torque
– engine 196
– lug bolts, refer to After
mounting 186
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Everything from A to Z
216
Touch tone dialing 157
Tow fitting 191
Towing 191
– tow fitting 191
"Town / City" for destination
entry 116
Tow-starting 192
Tracks
– random play sequence 147
– sample scan 147
Track width, refer to
Dimensions 197
Traction-assist feature, refer
to DSC Dynamic Stability
Control 78
Traction control, refer to DSC
Dynamic Stability
Control 78
Traffic congestion, refer to
Bypassing route
sections 127
Transmission
– automatic transmission with
Steptronic 55
– manual transmission 53
– SMG Sequential manual
transmission 53
Transporting children
safely 47
Transport securing device,
refer to Securing cargo 109
Tread depth, refer to Minimum
tire tread 173
"Trip computer" 71
Trip computer 71
Trip-distance counter, refer to
Trip odometer 65
"Triple turn signal
activation" 57
Trip odometer 65
Trunk lid, refer to Luggage
compartment lid 32
– emergency operation, refer
to Manual operation 33
Turning circle, refer to
Dimensions 197
Turn signals 56
– indicator lamp 10, 13
– replacing bulbs 183
U
Underbody protection, refer to
Caring for your vehicle
brochure
Uniform Tire Quality Grading/
UTQR 173
"Units" 73
Units
– average fuel
consumption 73
– temperature 73
Universal garage-door
opener, refer to Integrated
universal remote control 96
Universal Remote Control 96
"Unlock button" 29
Unlocking
– from inside 32
– from outside 29
"Unlock rear menu" 137
"Update services" 164
"Use current location as
address" 122
Using tow fitting for towing
and tow-starting 191
V
Valve screw caps, refer to
After mounting 186
Vehicle
– battery 187
– break-in period 106
– care 181
– care, refer to Caring for your
vehicle brochure
– dimensions 197
– loading 108
– parking 52
– washing, refer to Caring for
your vehicle brochure
– weights 198
Vehicle jack 185
Vehicle position, refer to
Displaying current
position 125
"Vehicle settings" 29
Ventilation 93
– draft-free 93
– in the rear 93
Ventilation while stationary 94
Vent outlets of the automatic
climate control 90
Vents, refer to Ventilation 93
Voice command system 22
– short commands 199
Voice instructions for
navigation system 125
– muting 46
– repeating 46, 126
– switching on/off 46, 125
– volume 126
Voice phone book 159
Volume 132
– audio sources 132
– of the luggage
compartment 198
– portable phone 153
– setting speed-
dependent 134
– voice instructions 126
W
Warning lamps, refer to
Indicator/warning lamps 13
Warning messages, refer to
Check Control 67
Warning triangle 189
Warranty and Service Guide
Booklet for Canadian
models 180
Washer fluid 58
– capacity of the reservoir 58
– content of the reservoir 58
Washer fluid reservoir 58
Water on roads, refer to
Driving through water 107
Waveband 138
"WB" 133, 141
Wear indicators in tires, refer
to Minimum tread depth 173
Weights 198
Wheel/tire combination, refer
to New wheels and tires 174
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Reference
217
At a glanceControlsDriving tipsCommunica- NavigationEntertainmentMobility
Wheelbase, refer to
Dimensions 197
Wheel replacement 174
Wheels and tires 170
Width, refer to
Dimensions 197
Windows 34
– auto-remote operation from
outside 31
– convenience operation 30
– safety switch 35
Windshield displays, refer to
Head-Up Display 84
Windshield washer nozzles 58
Windshield washer system
– refer to Wiper system 57
– windshield washer
nozzles 58
Windshield wipers, refer to
Wiper system 57
Winter tires 175
– speed limit selection 72
– storage 175
Wiper blade replacement 182
Wiper system 57
– rain sensor 57
– washer fluid 58
– windshield washer
nozzles 58
– wiper blade
replacement 182
"With highways" for
navigation 122
Word matching principle for
navigation 123
Working in the engine
compartment 176
Wrenches/screwdrivers, refer
to Onboard tool kit 182
X
Xenon lamps 183
– replacing bulbs 183
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
Refueling
To ensure that you always have all the essential
data on hand when refueling, we recommend
that you fill in the following tables with the spec-
ifications and information that apply to your
vehicle. Consult the index for individual specifi-
cations.
Fuel
Engine oil
The oil quantity between the middle of
the two marks on the dipstick is approx.
1.6USquarts/1.5liters.
Tire inflation pressure
Designation
Please enter your preferred fuel here.
Quality
Summer tires
Front Rear
Winter tires
Front Rear
Up to 4 persons
5 persons or 4 plus luggage
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
01 41 0 158 518 ue
*BL015851800A*
The Ultimate
Driving Machine
More about BMW
bmwusa.com
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
5 US-En
Online Edition for Part-No. 01 41 0 158 518 - © 09/04 BMW AG
