Ceramic Heater with Wi-Fi INSTRUCTION MANUAL Dimplex DHCER20WIFI

TABLE OF CONTENTS

  • WARNINGS AND PRECAUTIONS
  • STRUCTURE
  • OPERATION
  • CLEANING AND MAINTENANCE
  • TECHNICAL REFERENCE DATA
  • WARRANTY

OPERATION

ON / OFF

This button is used to switch the unit ON and OFF

TIMER

A timer can be set so the unit turns off automatically after a set period. When Pressing the TIMER button once, the ‘h’ indicator will illuminate. Press the ‘+/-’ button to set the timer between 0-12 hours. Each press of the ‘+/-’ button increases/decreases the set time in 1 hour increments. If a time isn’t set within 5 seconds, the unit will exit the timer function and revert to displaying the room temperature.

LOW / HIGH POWER

By simply pressing this button, you can regulate the mode from LOW Power to HIGH Power depending on your needs. The unit automatically starts in LOW Power mode.

SWING

The unit will begin to oscillate after pressing the SWING button, the indicator light will illuminate. To turn off the SWING function, press the swing button again, and the swing will stop and the indicator light will switch off

ECO MODE

When ECO Mode is selected, the unit will automatically adjust to suitable settings according to the room temperature. When the room temperature is below 18°C, the unit will operate in HIGH Power, and when the room is above 18°C, the machine will operate in LOW Power. When the room reaches 22°C the unit will stop working, until the room temperature decreases, and will resume working again.

WI-FI

You can operate the unit wirelessly when connected to Wi-Fi. You’ll need a Wi-Fi connection, and mobile device with the Dimplex CONNECT IT app installed.

  1. Connect mobile device to Wi-Fi and download the Dimplex CONNECT IT app from the App Store, or Google Play.
  2. Once installed, launch the app.
  3. Press and hold the Wi-Fi button at the back of the unit (8) until the Wi-Fi indicator light flashes rapidly
  4. Click ‘Add the new device’. The SSID should automatically pick up the Wi-Fi connection name.
  5. Enter the Wi-Fi password ‘123456’ and hit connect.
  6. Once connected you can control the unit via your mobile device and with a 3G or 4G network connection.
