iNSTALLATiON AND SERVICE MUST BE PERFORMED BY A QUALiFiED iNSTALLER.._
iMPORTANT: SAVE FOR LOCAL ELECTRICAL iNSPECTOR'S USE.
READ AND SAVE THESE iNSTRUCTiONS FOR FUTURE REFERENCE. C US
FOR YOUR SAFETY: Do nat stare or use gasallne or other flammable vapars
and liquids in the vicinity of this or any other appliance. LISTED
iMPORTANT iNSTALLATiON
iNFORMATiON
* All electric cooktops run off a
single phase, three-wire or four-wire
cable, 240/208 volt, 60 hertz, AC
only electrical supply with ground.
* Please note minimum distance
between cooktop and adjacent and
overhead unprotected cabinetry is
30" (76.2 cm).
The corners
of this unit are fragile.
Carefully install the cooktop
by its sides. When installing,
never let the weight of the
unit rest on any one corner.
30" (76.2 cm) min. for unprotected cabinet.
24" (6t cm) min. for protected surface.
_....... .,.4
30" Min. _
(76.2 cm)
Cooktop Dimensions
4" X 8"
(10.2 cmx 20.3
cm) opening at the
right rear to route
Cooktop Cutout Dimensions
Figure |
30" Ceramic Model 293ΒΌ(75.6) 30 1/8 (76.5) 20 3/8 (51.8) 2034 (52.7) 6 (15.2)
All dimensions ore in inches (cm).
Allow 2" (5 cm) space below cooktop to clear the electric cable and allow for
installation of the junction box on the wall at the back of the cooktop.
Printed in China
P/N 318205431 (1311) Rev. A
English - pages 1-8
EspaSol - pages 9-16
Fran_:ais - pages 17-24
