Fujifilm FinePix XP120 - Waterproof Digital Camera User Manual

FINEPIX XP120 Series

DIGITAL CAMERA

Owner’s Manual

For information on related products, visit our website at

http://www.fujifilm.com/products/digital_cameras/index.html

Before You Begin

First Steps

Basic Photography and Playback

More on Playback

Movies

Connections

Menus

Technical Notes

Troubleshooting

Appendix

BL00004870-200

Wireless Networks

For Your Safety

Be sure to read these notes before use

Safety Notes

• Makesurethatyou use your cameracorrectly. Read these safety

notesandyourOwner’s Manualcarefullybeforeuse.

• Afterreadingthesesafetynotes,storetheminasafeplace.

About the Icons

Theicons shown below are used in this document to indicate the

severity of the injury or damage that can result if the information

indicatedbytheiconisignoredandtheproductisusedincorrectly

asaresult.

WARNING

Thisiconindicatesthatdeathorseriousinjurycanresultifthe

informationisignored.

CAUTION

Thisiconindicatesthatpersonalinjuryormaterialdamagecan

resultiftheinformationisignored.

The icons shown below are used to indicate the nature of the

instructionswhicharetobeobserved.

Triangular icons tell you that this information requires

attention(“Important”).

Circular icons with a diagonal bar tell you that the action

indicatedisprohibited(“Prohibited”).

Filledcircleswithanexclamationmarkindicateanactionthat

mustbeperformed(“Required”).

Thesymbolsontheproductrepresentthefollowing:

ClassIIequipment(Theconstructionoftheproductisdouble-

insulated.)

Notes for waterproof products

• Whennotinuse,thiscamerashouldbestoredinadrylocation.

• If liquid other than fresh water or sea water is spilled onto the

camera,please wipe off with a lintfreeclose after rinsing it with

freshwater.Pleasecheckwithyourlocalservicecentreifunsure.

• Waterproof/dustproof products are excluded from prohibition

against water/dust exposure.  Keep this in mind when reading

followingnotesandcautions.

WARNING

Unplug from

power socket

If a problem arises, turn the camera off, remove the battery, and

disconnect and unplug the AC power adapter.  Continueduseof

thecamerawhenitisemittingsmoke,isemittinganyunusual

odor, or is in any other abnormal state can cause a fire or

electricshock.ContactyourFUJIFILMdealer.

Do not allow water or foreign objects to enter the camera.Ifwater

orforeignobjectsgetinsidethecamera,turnthecameraoff,

removethebattery,anddisconnectandunplugtheACpower

adapter.  Continued use of the camera can cause a fire or

electricshock.ContactyourFUJIFILMdealer.

Do not use in

the bathroom or

shower

Do not use the camera in the bathroom or shower (excluding

waterproof products).Thiscancauseafireorelectricshock.

Do not

disassemble

Never attempt to change or take apart the camera (never open

the case).Failuretoobservethisprecautioncancausefireor

electricshock.

Do not touch

internal parts

Should the case break open as the result of a fall or other accident,

do not touch the exposed parts.Failuretoobservethisprecaution

could result in electric shock or in injury from touching the

damagedparts.Removethebatteryimmediately,takingcare

toavoidinjuryorelectricshock,andtaketheproducttothe

pointofpurchaseforconsultation.

iii

For Your Safety

WARNING

Do not change, heat or unduly twist or pull the connection cord and

do not place heavy objects on the connection cord.Theseactions

coulddamagethecordandcauseafireorelectricshock.Ifthe

cordisdamaged,contactyourFUJIFILMdealer.

Do not place the camera on an unstable surface.Thiscancausethe

cameratofallortipoverandcauseinjury.

Never attempt to take pictures while in motion. Do notusethe

camerawhileyou arewalkingordrivinga vehicle.Thiscan

resultinyoufallingdownorbeinginvolvedinatrafficaccident.

Do not touch any metal parts of the camera during a thunderstorm.

Thiscancauseanelectricshockduetoinducedcurrentfrom

thelightningdischarge.

Do not use the battery except as specified.  Load the battery as

shownbytheindicator.

Do not heat, change or take apart the battery. Do not drop or subject

the battery to impacts. Do not store the battery with metallic

products.Anyoftheseactionscancausethebatterytoburstor

leakandcausefireorinjuryasaresult.

Use only the battery or AC power adapters specified for use with this

camera.Do not use voltages other than the power supply voltage

shown.Theuseofotherpowersourcescancauseafire.

If the battery leaks and fluid gets in contact with your eyes, skin or

clothing, flush the affected area with clean water and seek medical

attention or call an emergency number right away.

Do not use the charger to charge batteries other than those specified

here.Thesuppliedbatterychargerisforuseonlywiththetype

of battery supplied with the camera.  Using the charger to

chargeconventionalbatteriesorother typesofrechargeable

batteriescancausethebatterytoleakfluid,overheatorburst.

WARNING

Danger of explosion if battery is incorrectly replaced. Replace only

with the same.

Do not use in the presence of flammable objects, explosive gases,

or dust.

When carrying the battery, install it in a digital camera or keep it

in the hard case. When storing the battery, keep it in the hard case.

When discarding, cover the battery terminals with insulation tape.

Contactwithothermetallicobjectsorbatteries could cause

thebatterytoigniteorburst.

Keep small accessories, such as memory cards and the hot shoe

cover, out of reach of children and infants.Thereisa possibility

that children and infants may accidentally swallow small

accessories,suchasmemorycardsandthehotshoecover.Be

suretostorememorycardsoutofthereachofsmallchildren.

Ifachildswallowsamemorycard,seekmedicalattentionor

callanemergencynumber.

Turn the camera off in crowds.Thecameraemitsradio-frequency

radiationthatmayinterferewithpacemakers.

Turn the camera off in the vicinity of automatic doors, public address

systems, and other automatically controlled devices.Thecamera

emitsradio-frequencyradiationthatmaycausethesedevices

tomalfunction.

Keep the camera at least 22cm (0.7 ft.) away from people wearing

pacemakers.Thecameraemitsradio-frequencyradiationthat

mayinterferewithpacemakers.

Keep out of the reach of small children.Chokingorotherinjuries

may occur if the strap or power cord accidentally becomes

wound around the neck, or if an accessory is accidentally

swallowed.

For Your Safety

WARNING

Do not view the sun through the lens or camera viewfinders.

Failuretoobservethisprecautioncancausepermanentvisual

impairment.

Using a flash too close to a person’s eyes may temporarily affect the

eyesight.Thereisariskofvisualimpairment.Whenusingthe

flashtophotographachildorinfant,takespecialcaretokeep

enoughdistance.

Consult with hospital or airline staff before using the camera in

a hospital or on an aircraft.  This camera may interfere with

hospitaloraviationequipment.

CAUTION

Do not use this camera in locations affected by oil fumes or steams.

Thiscancauseafireorelectricshock.

Do not use this camera in locations affected by humidity or dust

(excluding waterproof products).Thiscancauseafireorelectric

shock.

Do not leave this camera in places subject to extremely high

temperatures.Donotleavethecamerainlocationssuchasa

sealedvehicleorindirectsunlight.Thiscancauseafire.

Do not place heavy objects on the camera.  This can cause the

heavyobjecttotipoverorfallandcauseinjury.

Do not move the camera while the AC power adapter is still

connected. Do not pull on the connection cord to disconnect the AC

power adapter.Thiscandamagethepowercordorcablesand

causeafireorelectricshock.

Do not use the AC power adapter when the plug is damaged or the

plug socket connection is loose.Thiscouldcauseafireorelectric

shock.

CAUTION

Do not cover or wrap the camera or the AC power adapter in a cloth or

blanket.Thiscancauseheattobuildupanddistortthecasing

orcauseafire.

When you are cleaning the camera or you do not plan to use the

camera for an extended period, remove the battery and disconnect

and unplug the AC power adapter. Failuretodosocan causea

fireorelectricshock.

Unplug from

power socket

When charging ends, unplug the charger from the power socket.

Leavingthechargerpluggedintothepowersocketcancause

afire.

When a memory card is removed, the card could come out of the slot

too quickly.Use your finger to hold it and gently release the card.

Injurycouldresulttothosestruckbytheejectedcard.

Request regular internal testing and cleaning for your camera.

Build-up of dust in your camera can cause a fire or electric

shock.  Contact your FUJIFILM dealer to request internal

cleaningeverytwoyears.Pleasenotethatthisserviceisnot

freeofcharge.

Keep the sun out of the frame when shooting backlit subjects.

Sunlightfocusedintothecamerawhenthesunisinorcloseto

theframecancausefireorburns.

Do not carry the camera or lens while they are attached to a tripod.

Theproductcanfallorstrikeotherobjects,causinginjury.

For Your Safety

The Battery and Power Supply

Note: Check the type of battery used in

your camera and read the appropriate

sections.

The following describes the proper use

of batteries and how to prolong their life.

Incorrectusecanshortenbatterylifeorcause

leakage,overheating,fire,orexplosion.

Li-ion Batteries

Read this section if your camera uses a

rechargeable Li-ion battery.

The battery is not charged at shipment.

Charge the battery before use.  Keep the

batteryinitscasewhennotinuse.

■ Notes on the Battery

Thebattery gradually loses its charge when

not in use.  Charge the battery one or two

daysbeforeuse.

Battery life can be extended by turning the

cameraoffwhennotinuse.

Battery capacity decreases at low

temperatures; a depleted battery may not

functionatwhencold.Keepafullycharged

sparebatteryinawarmplaceandexchange

as necessary, or keep the battery in your

pocket or other warm place and insert it in

the camera only when shooting.  Do not

placethebatteryindirectcontactwithhand

warmersorotherheatingdevices.

■ Charging the Battery

Charging times will increase at ambient

temperatures below +10°C (+50°F) or

above +35°C (+95°F). Do not attempt to

charge the battery at temperatures above

40°C (+104°F); at temperatures below 0°C

(+32°F),thebatterywillnotcharge.

Do not attempt to rechargeafully charged

battery.Thebatterydoesnothoweverneed

tobefullydischargedbeforecharging.

The battery may be warm to the touch

immediately after charging or use.  This is

normal.

■ Battery Life

Atnormaltemperatures,the battery can be

recharged about 300 times.  A noticeable

decreaseinthelengthoftimethebatterywill

hold a charge indicates that it has reached

the end of its service life and should be

replaced.

■ Storage

Performancemaybeimpairedifthebatteryis

leftunusedforextendedperiodswhen fully

charged.Runthebatteryflatbeforestoringit.

Ifthecamerawillnotbeusedforanextended

period,removethe battery and storeit in a

dry place with an ambient temperature of

from+15°Cto+25°C(+59°Fto+77°F).Do

notstoreinlocationsexposedtoextremesof

temperature.

■ Cautions: Handling the Battery

• Donottransportorstorewithmetalobjects

suchasnecklacesorhairpins.

• Donotexposetoflameorheat.

• Donotdisassembleormodify.

• Usewithdesignatedchargersonly.

• Do not drop or subject to strong physical

shocks.

• Donotexposetowater.

• Keeptheterminalsclean.

• Thebatteryandcamerabodymaybecome

warmtothetouchafterextendeduse.This

isnormal.

AA Alkaline/Rechargeable NiMH Batteries/

AA lithium batteries

Read this section if your camera uses

AA alkaline or rechargeable AA NiMH

batteries.  Information on compatible

batterytypesmaybefoundelsewhereinthe

cameramanual.

■ Cautions: Handling the Batteries

• Donotexposetowater, flame,orheat,or

storeinwarmorhumidconditions.

• Donottransportorstorewithmetalobjects

suchasnecklacesorhairpins.

• Donotdisassembleormodifythebatteries

orbatterycasing.

• Donotsubjecttostrongphysicalshocks.

• Do not use batteries that are leaking,

deformed,ordiscolored.

• Keep out of reach of infants and small

children.

• Insertinthecorrectorientation.

For Your Safety

• Donotmixoldandnewbatteries,batteries

withdifferentchargelevels,or batteriesof

differenttypes.

• If the camera will not be used for an

extended period, remove the batteries.

Notethatthecameraclockwillbereset.

• The batteries may be warm to the touch

immediately after use.  Turn the camera

off and allow the batteries to cool before

handling.

• Battery capacity tends to decrease at low

temperatures.  Keep spare batteries in a

pocketorotherwarmplaceandexchange

as necessary.  Cold batteries may recover

someoftheirchargewhenwarmed.

• Fingerprintsandotherstainsonthebattery

terminals can impair battery performance.

Thoroughly clean the terminals with a

soft,dryclothbeforeinsertingtheminthe

camera.

Ifthebatteriesleak,cleanthebattery

compartment thoroughly before

insertingnewbatteries.

If fluid from the battery comes into

contact with skin or clothing, flush

theaffectedareawithwater.If fluid

enters your eyes, immediately flush

the affected area with water and seek

medical attention.Do not rub your eyes.

Failure to observe this precaution could

result in permanent visual impairment.

■ NiMH Batteries

The capacity of Ni-MH batteries may be

temporarily reduced when new, after long

periods of disuse, or if they are repeatedly

recharged before being fully discharged.

This is normal and does not indicate a

malfunction.  Capacity can be increased by

repeatedly discharging the batteries using

the discharge option in the camera setup

menu and rechargingthem using a battery

charger.

Q CAUTION:Donotusethedischargeoption

withalkalinebatteries.

Thecameradrawsasmallamountofcurrent

even when off.  Ni-MH batteries that have

been left in the camera for an extended

period may be drawn down to the point

that they no longer hold a charge. Battery

performance may also drop if the batteries

arerundowninadevicesuchasaflashlight.

Usethedischargeoptioninthecamerasetup

menutodischargeNi-MHbatteries.Batteries

that no longer hold a charge even after

repeatedlybeing discharged and recharged

havereachedtheendoftheirservicelifeand

mustbereplaced.

Ni-MHbatteriescanberechargedinabattery

charger (sold separately).  Batteries may

become warm to the touch after charging.

Refer to the instructions provided with

the charger for more information.  Use the

chargerwithcompatiblebatteriesonly.

Ni-MH batteries gradually lose their charge

whennotinuse.

■ Disposal

CAUTION:Disposeofusedbatteriesinaccord

withlocalregulations.

AC Power Adapters (Available Separately)

This section applies to all camera models. 

Use only FUJIFILM AC power adapters

designatedforusewiththiscamera.Other

adapterscoulddamagethecamera.

• TheACpoweradapterisforindooruseonly.

• BesuretheDCplugissecurelyconnected

tothecamera.

• Turn the camera off before disconnecting

theadapter.Disconnecttheadapterbythe

plug,notthecable.

• Donotusewithotherdevices.

• Donotdisassemble.

• Donotexposetohighheatandhumidity.

• Donotsubjecttostrongphysicalshocks.

• Theadaptermayhumorbecomehottothe

touchduringuse.Thisisnormal.

• If the adapter causes radio interference,

reorientorrelocatethereceivingantenna.

vii

For Your Safety

Using the Camera

Do not aim the camera at extremely bright

lightsources,suchasthe sun inacloudless

sky.Failuretoobservethisprecautioncould

damagethecameraimagesensor.

Take Test Shots

Before taking photographs on important

occasions (such as at weddings or before

taking the camera on a trip), take a test

shotandviewtheresultintheLCDmonitor

to ensure that the camera is functioning

normally.  FUJIFILM Corporation can not

accept liability for damages or lost profits

incurredasaresultofproductmalfunction.

Notes on Copyright

Unless intended solely for personal use,

images recorded using your digital camera

systemcannotbeusedinwaysthatinfringe

owner.Notethatsomerestrictionsapplyto

the photographing of stage performances,

entertainments, and exhibits, even when

intended purely for personal use.  Users

are also asked to note that the transfer of

memory cards containing images or data

protected under copyright laws is only

permissible within the restrictions imposed

bythosecopyrightlaws.

Handling

Toensurethatimagesarerecordedcorrectly,

do not subject the camera to impact or

physical shocks while images are being

recorded.

Liquid Crystal

In the event that the LCD monitor is

damaged, care should be taken to avoid

contact with liquid crystal. Take the urgent

actionindicatedshouldanyofthefollowing

situationsarise:

• If liquid crystal comes in contact with your skin,

clean the area with a cloth and then wash

thoroughlywithsoapandrunningwater.

• If liquid crystal enters your eyes, flush the

affectedeyewithcleanwaterforatleast15

minutesandthenseekmedicalassistance.

• If liquid crystal is swallowed, rinse your

mouththoroughlywithwater.Drinklarge

quantities of water and induce vomiting,

thenseekmedicalassistance.

Althoughthedisplayis manufacturedusing

extremelyhigh-precisiontechnology,itmay

containpixelsthatarealwayslitorthatdonot

light.This is not a malfunction, and images

recordedwiththeproductareunaffected.

Trademark Information

xD-Picture CardandEaretrademarksof

FUJIFILMCorporation.Thetypefacesincluded

hereinaresolelydevelopedbyDynaComware

Taiwan Inc.Macintosh,Mac OSandmacOS

are trademarks of Apple Inc., registered in

the U.S. and other countries.  Windows is

either a registered trademark or trademark

ofMicrosoftCorporationintheUnitedStates

and/or other countries. Wi-Fi® and Wi-Fi

Protected Setup® are registered trademarks

of the Wi-Fi Alliance. Adobe and Adobe

Reader are either trademarks or registered

trademarks of Adobe Systems Incorporated

in the U.S.A.  and/or other countries.  The

SDHCandSDXClogosaretrademarksofSD-

3C,LLC. The HDMIlogoisatrademark.All

othertradenamesmentionedinthismanual

arethetrademarksorregistered trademarks

oftheirrespectiveowners.

Electrical Interference

This camera may interfere with hospital or

aviation equipment.  Consult with hospital

or airline staff before using the camera in a

hospitaloronanaircraft.

Exif Print (Exif Version 2.3)

Exif Print is a newly revised digital camera

file format in which information stored

with photographs is used for optimal color

reproductionduringprinting.

IMPORTANT NOTICE:

Read Before Using the Software

Directorindirectexport,inwholeorinpart,

oflicensedsoftwarewithout thepermission

of the applicable governing bodies is

prohibited.

viii

For Your Safety

IMPORTANT:Read the following notices before using the camera’s

built-in wireless transmitter.

Q This product, which contains encryption function developed

in the United States, is controlled by the United States Export

Administration Regulations and may not be exported or re-

exported toanycountrytowhichtheUnited Statesembargoes

goods.

• Use only as part of a wireless network.  FUJIFILM does not accept

liabilityfordamagesresultingfromunauthorizeduse.Donotuse

in applications requiring a high degree of reliability, for example

inmedicaldevicesorothersystemsthatmaydirectlyorindirectly

impacthumanlife.Whenusingthedeviceincomputerandother

systems that demand a greaterdegreeofreliabilitythan wireless

networks,besuretotakeallnecessaryprecautionstoensuresafety

andpreventmalfunction.

• Use only in the country in which the device was purchased.Thisdevice

conformstoregulationsgoverningwirelessnetworkdevicesinthe

countryinwhichitwaspurchased.Observealllocationregulations

when using the device.  FUJIFILM does not accept liability for

problemsarisingfromuseinotherjurisdictions.

• Wireless data (images) may be intercepted by third parties.Thesecurity

ofdatatransmittedoverwirelessnetworksisnotguaranteed.

• Do not use the device in locations subject to magnetic fields, static

electricity, or radio interference.  Do not use the transmitter in

the vicinity of microwave ovens or in other locations subject to

magnetic fields, static electricity, or radio interference that may

prevent reception of wireless signals.  Mutual interference may

occurwhenthetransmitterisusedinthevicinityofotherwireless

devicesoperatinginthe2.4GHzband.

• The wireless transmitter operates in the 2.4GHz band using DSSS and

OFDM modulation.

Wireless Network Devices: Cautions

• This device operates on the same frequency as commercial, educational,

and medical devices and wireless transmitters.Italsooperatesonthe

samefrequencyaslicensedtransmittersandspecialunlicensedlow-

voltagetransmittersusedinRFIDtrackingsystemsforassemblylines

andinothersimilarapplications.

• To prevent interference with the above devices, observe the following

precautions. Confirm thattheRFIDtransmitteris not inoperation

before using this device.  If the device causes interference to

premisesradio stationsusedforRFID tracking,immediatelyeither

relocate this device or stop the emission of radio waves.  If you

notice that this device causes interference in low-voltage RFID

tracingsystems,contactaFUJIFILMrepresentative.

2.4DS/OF4

This sticker indicates that this device

operatesinthe2.4GHzbandusingDSSS

and OFDM modulation and may cause

interferenceatdistancesofupto40m.

About This Manual

Before using the camera, read this manual and the warnings in “For Your Safety”

(P ii). For information on specific topics, consult the sources below.

Table of Contents ............................P xv Troubleshooting .......................... P 100

The “Table of Contents” gives an

overview of the entire manual. The

principal camera operations are

listed here.

Having a specific problem with the

camera? Find the answer here.

Warning Messages and Displays ... P 107

Find out what’s behind that flashing

icon or error message in the display.

Memory Cards

Pictures can be stored in the camera’s internal memory or on optional SD, SDHC, and

SDXC memory cards (P 12), referred to in this manual as “memory cards.”

Frequently-Used Buttons

■ Deleting Pictures

y To delete a picture, display it full frame

and press the selector up (b).

■ Taking Pictures During Playback

y To return instantly to shooting mode,

press the shutter button halfway.

View

Shoot

■ Turning the Camera on in

Playback Mode

y When the camera is

off, playback can be

started by pressing the

a button for about a

second.

Product Features and Precautions for Use

■ Water, Dust, and Shock Resistance

Q The camera complies with JIS Class 8 water resistance and JIS Class 6 (IP68) dust resistance

standards, and has passed FUJIFILM drop tests (drop height: 1.75 m/5.7 ft.; impact surface:

plywood, thickness 5 cm/2.0 in.) compliant with MIL-STD 810F Method 516.5: Shock. These

results were obtained through in-house testing and are not a blanket guarantee of water

resistance or invulnerability to damage or destruction. The accessories supplied with the

camera are not water resistant.

■ Before Use

Inspect the water-resistant seal and adjacent surfaces and remove

any dust, sand, or other foreign matter using a soft, dry cloth.

Q Have the water-resistant seal replaced if it is deformed or

otherwise damaged (note that a fee is charged for this service;

contact your retailer or a FUJIFILM-authorized repair technician for

more information). Failure to replace the seal could result in leaks

and damage to the camera.

Holding the battery-chamber cover closed against the

camera body (

), rotate the latch until it clicks into place

(

), indicating that the cover is secure.

Check that the cover is secure by rotating the latch in the opposite direction and confirming

that the cover does not open.

xii

Product Features and Precautions for Use

Q The front surface of the camera lens is protected by a sheet of glass. Foreign matter on the

glass will appear in photographs; keep the glass clean at all times.

Q Be sure that the battery-chamber is fully latched. The presence of water, mud, or sand in the

camera could cause malfunction.

Q Do not open or close the battery-chamber cover with wet hands or in locations that are dusty,

sandy, or near water, for example while on or by a body of water.

Q Be sure the camera is completely dry before inserting or removing batteries or memory cards

or connecting the USB or HDMI cable.

Q The camera does not float. Be sure to attach the strap and keep it around your wrist when

using the camera.

■ During Use

Q Restrict underwater use to depths of 20 m (65 ft.) or less and periods shorter than 120 minutes.

Clean and dry the camera within one hour of using it underwater.

Q The interior of the camera is not waterproof. Do not open or close the battery-chamber cover

while under water. After cleaning the camera, be sure it is completely dry before opening or

closing the battery-chamber cover.

Q Do not use in hot springs or heated pools.

Q The camera may lose water resistance if subjected to excessive force or vibration. Do not dive

into water with the camera or otherwise subject it to excessive force. In the event the camera

is subjected to strong physical shocks, contact your retailer or a FUJIFILM-authorized repair

technician.

Q If the camera is left on the sand, its temperature may exceed operating limits and sand may

get into the speaker or microphone.

Q Sunscreen, suntan lotion, or other oily substances may discolor the camera body and should

be removed with a damp cloth.

Q Note that the color of the supplied strap may fade or transfer to other items if it is exposed to

moisture or friction.

xiii

Product Features and Precautions for Use

■ After Use

Perform the following steps after using the camera underwater or in locations where foreign

matter might adhere to the camera body.

Securely close the battery-chamber cover and rinse the camera

under the tap or leave it in a basin of fresh water for about ten

minutes.

Remove water from the camera with a soft, dry cloth and leave it to dry in a well-ventilated

location in the shade.

After confirming that the camera has dried and is free of water droplets, open the battery-

chamber cover and use a soft, dry cloth to remove any water, dust, or other foreign matter

from the battery chamber.

Q Remove any foreign matter from the water-resistant seal and adjacent surfaces. Foreign

matter could damage the seal, lowering water resistance.

Q Liquid soaps, detergents, alcohol, and other cleansers may affect water resistance and should

never be used.

Q After use, remove water droplets and foreign matter with a dry cloth, firmly latch the battery-

chamber cover, and soak the camera in fresh water for about ten minutes. Dry the camera

thoroughly after removing it from the water.

xiv

Product Features and Precautions for Use

■ Storage and Maintenance

Q Do not store at temperatures below 0 °C (32 °F) or above 40 °C (104 °F).

Q To ensure continued water resistance, it is recommended that you have the water-resistant

seal replaced about once a year (a fee is charged for this service). Contact your retailer or a

FUJIFILM-authorized repair technician for more information.

■ Condensation Inside the Lens

In some environments, condensation (fog) may form inside of lens.

This does not indicate a malfunction. Condensation can be removed

by leaving the battery-chamber cover open in a location with a steady

temperature that is free of heat, humidity, sand, and dust.

Condensation

Condensation is particularly likely to occur if the camera is placed in cold water after being

exposed to high temperatures or taken from a cold to a warm environment or if the battery

chamber is opened in a humid location.

■ Cold Climates

Q Battery performance drops at low temperatures, reducing the number of pictures that can be

taken. Insulate the camera to keep it warm or place it in your clothing.

Q Use an NP-45S battery.

Q Display response may slow at low temperatures. This is not a malfunction.

Table of Contents

For Your Safety ..................................................................ii

Safety Notes .....................................................................ii

About This Manual ...........................................................ix

Frequently-Used Buttons .................................................x

Product Features and Precautions for Use......................xi

Before You Begin

Symbols and Conventions .................................................1

Supplied Accessories .........................................................1

Parts of the Camera ..........................................................2

Camera Displays ...............................................................4

Shooting ........................................................................4

Playback .........................................................................5

First Steps

Inserting the Battery and a Memory Card .......................7

Compatible Memory Cards .............................................12

Charging the Battery ......................................................14

Turning the Camera on and Off ......................................17

Shooting Mode ..............................................................17

Playback Mode ...............................................................17

Basic Setup ......................................................................19

Basic Photography and Playback

Taking Pictures in Q (Scene Recognition) Mode ......20

Viewing Pictures .............................................................24

More on Playback

Playback Options

To view the most recent picture in the LCD monitor, press the a button.

100-0001

Press the selector right to view pictures in the order recorded, left to view

pictures in reverse order. Keep the selector pressed to scroll rapidly to the

desired frame.

R Pictures taken using other cameras are indicated by a m (“gift image”) icon during

playback.

Continuous Shooting

In the case of pictures taken in continuous shooting mode, only the first frame

of each series will be displayed. Press the selector down to view the other

pictures in the series.

R Pictures taken in continuous shooting mode have file names that start with “S”.

(e.g. S0010001.JPG)

I Favorites: Rating Pictures

To rate the picture currently displayed in full-frame playback, press DISP/BACK

and press the selector up and down to select from zero to five stars.

51More on Playback

Playback Options

Playback Zoom

Press T to zoom in on pictures displayed in single-frame playback; press W to

zoom out. When the picture is zoomed in, the selector can be used to view

areas of the image not currently visible in the display.

Navigation window shows

portion of image currently

displayed in LCD monitor

Zoom indicator

Press DISP/BACK to exit zoom.

R The maximum zoom ratio varies with image size. Playback zoom is not available

with cropped or resized copies saved at a size of a or smaller.

52 More on Playback

Playback Options

Multi-Frame Playback

Pressing W when a picture is shown full-frame in the LCD monitor displays the

current image with previous and following images in the background. Press

W to increase the number of images displayed to two, nine, or one hundred,

T to view fewer images.

100-0001

When two or more images are displayed, use the selector to highlight images

and press MENU/OK to view the highlighted image full frame. In the nine- and

hundred-frame displays, use the selector to view more pictures.

53More on Playback

A Deleting Pictures

To delete individual pictures, multiple selected

pictures, or all pictures, press the selector up

(b), and choose from the options below. Note

that deleted pictures can not be recovered. Copy

important pictures to a computer or other storage device before proceeding.

Option Description

FRAME

Press the selector left or right to scroll through pictures and press MENU/OK to

delete the current picture (a confirmation dialog is not displayed).

SELECTED FRAMES

Highlight pictures and press MENU/OK to select or deselect (pictures that

are protected or in a print order are shown by u). When the operation is

complete, press DISP/BACK to display a confirmation dialog, then highlight OK

and press MENU/OK to delete the selected pictures.

ALL FRAMES

A confirmation dialog will be displayed; highlight OK and press MENU/OK to

delete all unprotected pictures (if a memory card is inserted, only the pictures

on the memory card will be affected; the pictures in internal memory are only

deleted if no memory card is inserted). Pressing DISP/BACK cancels deletion;

note that any pictures deleted before the button was pressed can not be

recovered.

R Protected pictures can not be deleted. Remove protection from any pictures you

wish to delete (P 83).

R Pictures can also be deleted by A ERASE from playback menu.

R If a message appears stating that the selected images are part of a DPOF print order,

press MENU/OK to delete the pictures.

ERASE

BACK

SET

FRAME

SELECTED FRAMES

ALL FRAMES

54 More on Playback

b Image Search

Search for pictures.

Select b IMAGE SEARCH in the playback menu (P 80), highlight one of

the following search criteria, and press MENU/OK:

• BY DATE: Search by date.

• BY FACE: Find all pictures containing faces.

• BY I FAVORITES: Search by rating.

• BY SCENE: Find all pictures that match a selected scene.

• BY TYPE OF DATA: Find all still pictures or all movies.

Select a search condition. Only pictures that match the search condition

will be displayed. To delete or protect selected pictures or to view the

search results in a slide show, press MENU/OK and choose A ERASE

(P 53), D PROTECT (P 83), or I SLIDE SHOW (P 82).

55More on Playback

k PhotoBook Assist

Create books from your favorite photos.

Creating a PhotoBook

Select NEW BOOK for k PHOTOBOOK ASSIST in the playback menu

(P 85) and choose from the following options:

• SELECT FROM ALL: Choose from all available pictures.

• SELECT BY IMAGE SEARCH: Choose from pictures matching selected search

conditions (P 54).

R Neither photographs a or smaller nor movies can be selected for photobooks.

Scroll through the images and press the selector up to select or deselect.

To display the current image on the cover, press the selector down. Press

MENU/OK to exit when the book is complete.

R The first picture selected becomes the cover image. Press the selector down to

select a different image for the cover.

Select COMPLETE PHOTOBOOK (to select all photos or all photos

matching the specified search conditions for the book, choose SELECT

ALL). The new book will be added to the list in the photobook assist menu.

Q Books can contain up to 300 pictures.

Q Books that contain no photos are automatically deleted.

56 More on Playback

k PhotoBook Assist

Viewing Photobooks

Highlight a book in the photobook assist menu and press MENU/OK to display

the book, then press the selector left or right to scroll through the pictures.

Editing and Deleting Photobooks

Display the photobook and press MENU/OK. The following options will be

displayed; select the desired option and follow the on-screen instructions.

• EDIT: Edit the book as described in “Creating a PhotoBook” (P 55).

• ERASE: Delete the book.

57More on Playback

Viewing Panoramas

If you press the selector down when a panorama is displayed full frame, the

camera will play back the picture from left to right or from bottom to top. To

pause playback, press the selector down; press the selector down again to

resume. To exit to full-frame playback, press the selector up while panorama

playback is in progress. Once displayed in full-frame playback, panoramas

can be zoomed in or out using the zoom control or deleted by pressing the

selector up (b).

PLAY

STOP PAUSE

Wireless Networks

Wireless Transfer (FUJIFILM Camera Remote/FUJIFILM PC AutoSave)

Access wireless networks and connect to computers, smartphones,

or tablets. For downloads and other information, visit http://fujifilm-

dsc.com/wifi/.

fujilm Wi-Fi app

Connecting with smartphones

Press the Wi-Fi button of the camera during playback to connect to

smartphones via a wireless network.

When connecting to smartphones, you can use the following functions:

• Taking pictures using smartphones

• Uploading pictures to smartphones

• Browsing and downloading the pictures on the camera using smartphones

• Downloading location data from smartphones

Before proceeding, download the free FUJIFILM Camera Remote app and install

it on your smartphone.

This option can also be enabled by r WIRELESS COMMUNICATION from

shooting or playback menu.

59Wireless Networks

Wireless Transfer (FUJIFILM Camera Remote/FUJIFILM PC AutoSave)

Saving Pictures to a Computer

Press and hold the Wi-Fi button during playback to save pictures to a computer

over a wireless network.

R This option can also be enabled by s PC AUTO SAVE from playback menu.

Before proceeding, install the free FUJIFILM PC AutoSave application to the

destination computer and adjust settings as desired.

Movies

Recording Movies

Press t to shoot a movie. During recording, the

following indicators will be displayed and sound will

be recorded via the built-in microphone (be careful

not to cover the microphone during recording).

REC

12m34s

y REC icon

Time remaining

Number of photos that

can be taken during

recording

To end recording, press the t button again. Recording ends automatically

when the movie reaches maximum length or memory is full.

Automatic Scene Selection

In Q mode, the camera selects the scene according to shooting

conditions and the type of subject: d (portraits), d (poorly-

lit landscapes), dd (poorly-lit portraits), c (landscapes),

e (close-ups), or a (other subjects).

REC

12m34s

Scene icon

61Movies

Recording Movies

Taking Photographs During Recording

Press the shutter button to take a photograph during recording.

R The photo is saved separately from the movie and does not appear as part of the movie.

Q Photos can not be taken while a high-speed movie is being recorded.

Q The number of photos that can be taken is limited.

DIGITAL IMAGE STABILIZER

You can correct camera vibrations that occur when shooting movies to shoot images with only

minor vibrations using the bDIGITAL IMAGE STABILIZER in the setup menu (P 92).

R Zoom can be adjusted while recording is in progress. The type of zoom can be

selected using the p MOVIE ZOOM TYPE option in the setup menu (P 94).

R If the subject is poorly lit, the AF-assist lamp may light to assist the focus operation.

To turn the AF-assist lamp off , select OFF for C AF ILLUMINATOR (P 94).

R Focus, exposure and white balance are adjusted automatically throughout

recording (the focus mode can be selected using the F MOVIE AF MODE option

in the shooting menu; P 77). The color and brightness of the image may vary from

that displayed before recording begins.

R Sounds made by the camera may be recorded.

Q Do not open the battery-chamber cover during shooting or saving a movie on a

memory card. Failure to observe this precaution could prevent the movie from

being played back.

Q Vertical or horizontal streaks may appear in movies containing very bright subjects.

This is normal and does not indicate a malfunction.

62 Movies

Recording Movies

Q The temperature of the camera may rise if it is used to record movies for an extended

period or if the ambient temperature is high. This is normal and does not indicate

a malfunction.

Q The mode selected may vary with shooting conditions.

63Movies

Viewing Movies

During playback, movies are displayed in the LCD monitor

as shown at right. The following operations can be

performed while a movie is displayed:

Option Description

Start/pause

playback

Press the selector down to start playback. Press again to

pause.

End playback/

delete

Press the selector up to end playback. If playback is not in

progress, pressing the selector up will delete the movie.

Adjust speed

Press the selector left or right to adjust playback speed

during playback.

Adjust volume

Press MENU/OK to pause playback and display volume

controls. Press the selector up or down to adjust the

volume and press MENU/OK to exit. Volume can also be

adjusted from the setup menu.

PLAY

Playback Speed

Press the selector left or right to adjust playback speed. Speed is

shown by the number of arrows (M or N).

Arrow

STOP PAUSE

5m42s

Q Do not cover the speaker during playback.

Connections

Viewing Pictures on High-Definition TVs

The camera can be connected to High-Definition (HD) devices using an HDMI

cable (available separately from third-party sources).

Turn the camera off and connect the HDMI cable as shown below.

Insert into Micro

HDMI connector

(Type D)

Insert into HDMI

connector

Micro HDMI connector

Q Use an HDMI cable no more than 1.5 m (4.9 ft.) long with a Micro HDMI

connector (Type D) for connection to the camera.

Q When connecting cables, be sure the connectors are fully inserted.

R When an HDMI cable is connected, pictures and sound are played back on the TV.

Tune the television to the HDMI input channel. See the documentation

supplied with the television for details.

Press the a button for about a second to turn the camera on. The camera

monitor turns off and pictures and movies are played back on the TV. Note

that the camera volume controls have no effect on sounds played on the

TV; use the television volume controls to adjust the volume.

R Some televisions may briefly display a black screen when movie playback begins.

65Connections

Creating a DPOF Print Order

The K PRINT ORDER (DPOF) option in the playback menu can be used to

create a digital “print order” for DPOF-compatible printers.

DPOF

DPOF (Digital Print Order Format) is a standard that allows pictures to be

printed from “print orders” stored in internal memory or on a memory card.

The information in the order includes the pictures to be printed and the

number of copies of each picture.

Select playback mode and press MENU/OK to display the playback menu.

Highlight K PRINT ORDER (DPOF) and press MENU/OK.

Highlight one of the following options and press MENU/OK:

• WITH DATE s: Print the date of recording on pictures.

• WITHOUT DATE: Do not print the date of recording on pictures.

R Some printers do not support date printing. See the printer manual for details.

Press the selector left or right to display a picture you wish to add to or

remove from the print order.

66 Connections

Creating a DPOF Print Order

Press the selector up or down to choose the number of copies (up to 99).

To remove a picture from the print order, press the selector down until the

number of copies is zero.

Repeat Steps 4–5 to complete the print order and press MENU/OK when

settings are complete.

A confirmation dialog will be displayed. Press MENU/OK to save the print

order.

R Remove the memory card to create or modify a print order for the pictures in

internal memory.

R Print orders can contain a maximum of 999 pictures.

R If a memory card is inserted containing a print order created by another camera,

a message will be displayed. Create a new print order as described above.

67Connections

instax SHARE Printers

Print pictures from your digital camera to instax SHARE printers.

Establishing a Connection

Select instax PRINTER CONNECTION SETTING in the camera setup menu

and enter the instax SHARE printer name (SSID) and password.

The Printer Name (SSID) and Password

The printer name (SSID) can be found on the

bottom of the printer; the default password is

“1111”. If you have already chosen a different

password to print from a smartphone, enter that

password instead.

68 Connections

instax SHARE Printers

Printing Pictures

Turn the printer on.

Select instax PRINTER PRINT in

the camera playback menu. The

camera will connect to the printer.

FUJIFILM-CAMERA-1234

CONNECTING TO PRINTER

CANCEL

PRINTER PRINT

instax-12345678

R To print a frame from a burst

sequence, display the frame before

selecting instax PRINTER PRINT.

Use the selector to display the

picture you want to print, then

press MENU/OK.

100-0020

instax-12345678

PRINTER PRINT

TRANSMIT CANCEL

R Pictures taken with other cameras

can not be printed.

R The area printed is smaller than

the area visible in the LCD monitor.

The picture will be sent to the

printer and printing will start.

FUJIFILM-CAMERA-1234

CANCEL

SENDING

PRINTER PRINT

instax-12345678

69Connections

Viewing Pictures on a Computer (MyFinePix Studio)

Read this section for information on copying pictures to a computer.

Windows

Use MyFinePix Studio to copy pictures to your computer, where they can

be stored, viewed, organized, and printed. MyFinePix Studio is available for

download from the following website:

http://fujifilm-dsc.com/mfs/

fujilm mfs

Once download is complete, double-click the downloaded file (“MFPS_Setup.

EXE”) and follow the on-screen instructions to complete installation.

Macintosh

Pictures can be copied to your computer using Image Capture (supplied with

your computer) or other software.

70 Connections

Viewing Pictures on a Computer (MyFinePix Studio)

Connecting the Camera

If the pictures you wish to copy are stored on a memory card, insert the

card into the camera.

R Windows users may require the Windows CD when starting the software for

the first time.

Q Loss of power during transfer could result in loss of data or damage to internal

memory or the memory card. Charge the battery before connecting the camera.

Turn the camera off and connect the

supplied USB cable as shown, making

sure the connectors are fully inserted.

Connect the camera directly to the

computer; do not use a USB hub or

keyboard.

Q The camera uses a Micro-B USB 2.0

connector.

Press the a button for about a second to turn the camera on.

Copy pictures to the computer using MyFinePix Studio or applications

provided with your operating system.

For more information on using the software, start the application and select

the appropriate option from the Help menu.

Connect to

camera Micro

USB connector

(Micro-B)

71Connections

Viewing Pictures on a Computer (MyFinePix Studio)

Q If a memory card containing a large number of images is inserted, there may be a

delay before the software starts and you may be unable to import or save images.

Use a memory card reader to transfer pictures.

Q Make sure that the computer does not display a message stating that copying is in

progress before turning the camera off or disconnecting the USB cable. Failure to

observe this precaution could result in loss of data or damage to internal memory

or the memory card.

Q Disconnect the camera before inserting or removing memory cards.

Q The user bears all applicable fees charged by the phone company or Internet

service provider when using services that require an Internet connection.

Disconnecting the Camera

After data is saved, turn the camera off and disconnect the USB cable.

Menus

Using the Menus: Shooting Mode

Using the Shooting Menu

To display the shooting menu, press MENU/OK in

shooting mode. Highlight items and press the

selector right to view options, then highlight an

option and press MENU/OK. Press DISP/BACK to exit

when settings are complete. The options available

vary with the shooting mode selected.

Shooting Menu Options

A SHOOTING MODE (default: Q)

Choose a shooting mode according to the type of subject (P 25).

N ISO

Control the camera’s sensitivity to light. Higher values can reduce blur; note, however, that

mottling may appear in pictures taken at high sensitivities.

100 ISO 6400

Bright Scene Dark

Less noticeable Noise (mottling) More noticeable

Option Description

AUTO (1600) /

AUTO (800) / AUTO (400)

Sensitivity is adjusted automatically in response to shooting conditions,

but will not be raised above the value in parentheses.

6400 / 3200 / 1600 / 800 /

400 / 200 / 100

Sensitivity is set to the specified value, which is shown in the display.

73Menus

Using the Menus: Shooting Mode

O IMAGE SIZE (default: O 4:3)

Choose the image size (large, medium, or small) and aspect ratio (4 : 3,

3 : 2, 16 : 9, or 1 : 1) at which pictures are recorded. Large pictures can be

printed at large sizes with no drop in quality, while small pictures require

less memory, allowing more pictures to be recorded.

O 4 : 3

Size Aspect ratio

Q When pictures are recorded to internal memory, the default value is set to Q 4:3.

Size Versus Aspect Ratio

Size

Option Prints at sizes up to

34 × 25 cm (13.5 × 10 in.)

24 × 18 cm (9.5 × 7 in.)

cm (7

in.)

Aspect ratio

4 : 3:

Pictures have the same proportions as the camera display.

3 : 2:

Pictures have the same proportions as a frame of 35 mm film.

16 : 9: Suited for display on High Definition (HD) devices.

1 : 1: Pictures are square.

74 Menus

Using the Menus: Shooting Mode

T IMAGE QUALITY

(default: N)

Choose how much image files are compressed.

Option Description

FINE Low compression. Select for higher image quality.

NORMAL High compression. Select this option to store more pictures.

P FINEPIX COLOR (default: c)

Enhance contrast and color saturation or take pictures in black and white.

Option Description

c STANDARD

Standard contrast and saturation. Recommended in most situations.

a CHROME

Vivid contrast and color. Choose for vivid shots of flowers or enhanced greens

and blues in landscapes.

b B&W

Take pictures in black and white.

f SEPIA

Take pictures in sepia.

R Settings other than c STANDARD are shown by an icon in the LCD monitor.

R Depending on the subject, the effects of a CHROME may not be visible in the LCD monitor.

75Menus

Using the Menus: Shooting Mode

D WHITE BALANCE

(default: AUTO)

For natural colors, choose a setting that matches the light source.

Option Description

AUTO White balance adjusted automatically.

For subjects in direct sunlight.

For subjects in the shade.

Use under “daylight” fluorescent lights.

Use under “warm white” fluorescent lights.

Use under “cool white” fluorescent lights.

Use under incandescent lighting.

For underwater photography.

R Results vary with shooting conditions. Play pictures back after shooting to check colors in

the LCD monitor.

76 Menus

Using the Menus: Shooting Mode

R CONTINUOUS (default: J)

Capture motion in a series of pictures.

Option Description

P CONTINUOUS

The camera takes pictures while the shutter button is pressed.

J CONTINUOUS

K CONTINUOUS

O CONTINUOUS

M FINAL

The camera shoots while the shutter button is pressed and records the last

several pictures.

N FINAL

Q FINAL

R See page 113 for the frame rate and number of pictures taken in each mode.

R Focus and exposure are determined by the first frame in each series.

R In P mode, O IMAGE SIZE is fixed at Q 16 : 9.

R The flash turns off automatically.

R Frame rate varies with shutter speed.

R The number of pictures that can be recorded depends on the memory available.

b FACE DETECTION

Choose whether the camera automatically detects and sets focus and exposure for human

portrait subjects (P 37).

77Menus

Using the Menus: Shooting Mode

F AF MODE

This option controls how the camera selects the focus area. Regardless of the option selected,

the camera will focus on the subject in the center of the LCD monitor when macro mode is on.

Option Description

r CENTER

The camera focuses on the subject in the center of the frame.

s MULTI

When the shutter button is pressed halfway, the camera detects high-contrast

subjects near the center of the frame and selects the focus area automatically.

x TRACKING

Position the subject in the center focus area and press the selector left. Focus

will track the subject as it moves through the frame.

R Note that in x mode, the camera focuses continuously, increasing the drain on the battery,

and that the sound of the camera focusing may be audible.

FMOVIE AF MODE

This option controls how the camera selects the focus area for movies.

Option Description

r CENTER

The camera focuses on the subject in the center of the frame.

u CONTINUOUS

The camera continuously adjusts focus to reflect changes in the distance to

subjects near the center of the frame.

R Note that in u mode, the camera focuses continuously, increasing the drain on the battery,

and that the sound of the camera focusing may be audible.

78 Menus

Using the Menus: Shooting Mode

V MOVIE MODE (default: i)

Choose a frame size for movies.

Option Description

i 1920 × 1080 (60fps)

Full HD (High Definition).

i 1920 × 1080 (30fps)

h 1280

× 720

(60fps

)

High Definition.

f 640 × 480 (30fps) Standard definition.

k 640 × 480 (120 fps)

High speed movie.

Q Sound is not recorded, and focus, exposure, and white balance

are not adjusted automatically.

Q Zoom can not be adjusted.

k 320 × 240 (240 fps)

k 160 × 120 (320 fps)

Q When pictures are recorded to internal memory, the default value is set to f 640 × 480.

Q No face is detected when shooting in i 1920 × 1080 (60fps).

79Menus

Using the Menus: Shooting Mode

i TIME-LAPSE MOVIE MODE

(default: i)

Choose a frame size and frame rate for time-lapse movies.

Option Description

i 1920 × 1080 (60fps)

Full HD (High Definition).

i 1920 × 1080 (30fps)

i 1920 × 1080 (10fps)

h 1280

× 720

(60fps

)

High Definition. h 1280

× 720

(30fps

)

h 1280

× 720

(10fps

)

f 640 × 480 (60fps)

Standard definition.

f 640 × 480 (30fps)

f 640 × 480 (10fps)

r WIRELESS COMMUNICATION

When connecting to smartphones, you can use the following functions:

• Taking pictures using smartphones

• Uploading pictures to smartphones

• Browsing and downloading the pictures on the camera using smartphones

• Downloading location data from smartphones

For information on using wireless networks, visit http://fujifilm-dsc.com/wifi/.

80 Menus

Using the Menus: Playback Mode

Using the Playback Menu

To display the playback menu, press MENU/OK in

playback mode. Highlight items and press the

selector right to view options, then highlight an

option and press MENU/OK. Press DISP/BACK to exit

when settings are complete.

Playback Menu Options

r WIRELESS COMMUNICATION

When connecting to smartphones, you can use the following functions:

• Taking pictures using smartphones

• Uploading pictures to smartphones

• Browsing and downloading the pictures on the camera using smartphones

• Downloading location data from smartphones

For information on using wireless networks, visit http://fujifilm-dsc.com/wifi/.

s PC AUTO SAVE

Upload pictures to a computer over a wireless network. For information on using wireless

networks, visit http://fujifilm-dsc.com/wifi/.

b IMAGE SEARCH

Search for pictures (P 54).

A ERASE

Delete all or selected pictures (P 53).

81Menus

Using the Menus: Playback Mode

n MOVIE EDIT

Edit movies.

Q Do not turn the camera off while editing movies.

■ MOVIE TRIMMING

Remove opening or ending footage to create an edited copy of the current movie.

Display the desired movie.

Select n MOVIE EDIT > MOVIE TRIMMING in the playback menu. To remove footage from

the start of the copy, proceed to Step 3; otherwise, proceed to Step 4.

Press the selector down to begin playback and press it down again when the new opening

frame is reached.

Press MENU/OK. To remove footage from the end of the copy, proceed to Step 5; otherwise,

proceed to Step 6.

Press the selector down to begin playback and press it down again when the new closing

frame is reached.

Press MENU/OK to save the copy.

■ MOVIE JOIN

Add existing footage to the end of the current movie to create an edited copy.

Display the desired movie.

Select n MOVIE EDIT > MOVIE JOIN in the playback menu.

Press the selector left or right to highlight a movie.

Press MENU/OK to add the highlighted footage to the end of the current movie and save the

resulting copy, or press DISP/BACK to exit without creating a copy.

R Both movies must have been recorded at the same frame size and frame rate.

82 Menus

Using the Menus: Playback Mode

e CREATE CINEMAGRAPH

Create a cinemagraph, which is a still image with a portion that moves (P 30).

I SLIDE SHOW

View pictures in an automated slide show. Choose the type of show and press MENU/OK to start.

Press DISP/BACK at any time during the show to view on-screen help. The show can be ended at

any time by pressing MENU/OK.

Option Description

NORMAL

Press selector left or right to go back or skip ahead one frame. Select FADE-IN

for fade transitions between frames.

FADE-IN

NORMAL g

As above, except that camera automatically zooms in on faces selected with

Intelligent Face detection.

FADE-IN g

R The camera will not turn off automatically while a slide show is in progress.

B RED EYE REMOVAL

If the current picture is marked with a g icon to indicate that it was taken with Intelligent Face

Detection, this option can be used to remove red-eye. The camera will analyze the image; if red-

eye is detected, the image will be processed to create a copy with reduced red-eye.

Display the desired picture.

Select B RED EYE REMOVAL in the playback menu.

Press MENU/OK.

R Red eye may not be removed if the camera is unable to detect a face or the face is in profile.

Results may differ depending on the scene. Red eye can not be removed from pictures that

have already been processed using red-eye removal or pictures created with other devices.

R The amount of time needed to process the image varies with the number of faces detected.

R Copies created with B RED EYE REMOVAL are indicated by a e icon during playback.

83Menus

Using the Menus: Playback Mode

D PROTECT

Protect pictures from accidental deletion.

Select D PROTECT in the playback menu.

Highlight one of the following options and press MENU/OK:

• FRAME: Protect selected pictures. Press the selector left or right to view pictures and press

MENU/OK to select or deselect. Press DISP/BACK when the operation is complete.

• SET ALL: Protect all pictures.

• RESET ALL: Remove protection from all pictures.

Q Protected pictures will be deleted when the memory card or internal memory is formatted

(P 89).

G CROP

Create a cropped copy of the current picture.

Display the desired picture.

Select G CROP in the playback menu.

Use the zoom buttons to zoom in and out and use the selector to scroll the picture until the

desired portion is displayed.

Press MENU/OK to display a confirmation dialog.

Press MENU/OK again to save the cropped copy to a separate file.

R Larger crops produce larger copies. If the size of the final copy will be a, YES will be

displayed in yellow.

84 Menus

Using the Menus: Playback Mode

O RESIZE

Create a small copy of the current picture.

Display the desired picture.

Select O RESIZE in the playback menu.

Highlight a size and press MENU/OK to display a confirmation dialog.

Press MENU/OK to save the resized copy to a separate file.

R The sizes available vary with the size of the original image.

C IMAGE ROTATE

Rotate pictures taken in tall orientation so that they are displayed in tall orientation in the LCD

monitor.

Display the desired picture.

Select C IMAGE ROTATE in the playback menu.

Press the selector down to rotate the picture 90 ° clockwise, up to rotate it 90 ° counterclockwise.

Press MENU/OK. The picture automatically be displayed in the selected orientation whenever

it is played back on the camera.

R Protected pictures can not be rotated. Remove protection before rotating pictures (P 83).

R The camera may not be able to rotate pictures created with other devices.

85Menus

Using the Menus: Playback Mode

E COPY

Copy pictures from internal memory to a memory card.

Select E COPY in the playback menu.

Highlight one of the following options and press the selector right:

• a INTERNAL MEMORY y b CARD: Copy pictures from internal memory to a memory card.

• b CARD y a INTERNAL MEMORY: Copy pictures from a memory card to internal memory.

Highlight one of the following options and press MENU/OK:

• FRAME: Copy selected pictures. Press the selector left or right to view pictures and press

MENU/OK to copy the current picture.

• ALL FRAMES: Copy all pictures.

R Copying ends when the destination is full.

R DPOF print information is not copied (P 65).

k PHOTOBOOK ASSIST

Create books from your favorite photos (P 55).

K PRINT ORDER (DPOF)

Create a digital “print order” for DPOF-compatible printers (P 65).

V instax PRINTER PRINT

Print pictures on optional FUJIFILM instax SHARE printers (P 67).

86 Menus

Using the Menus: Playback Mode

J DISP ASPECT

Choose how High Definition (HD) devices display pictures with an aspect ratio of 4 : 3 (this option

is available only when an HDMI cable is connected). Select 16 : 9 to display the image so that it

fills the screen with its top and bottom cropped out, 4 : 3 to display the entire image with black

bands at either side.

4 : 3

16 : 9

16 : 9 4 : 3

R Photographs with an aspect ratio of 16 : 9 are displayed full screen, those with an aspect ratio

of 3 : 2 in a black frame.

87Menus

The Setup Menu

Using the Setup Menu

Display the setup menu.

1.1 Press MENU/OK to display the menu for the

current mode.

1.2 Press the selector left to highlight the tab for

the current menu.

EXIT

SET

SET-UP

EXIT

SET

SET-UP

Tab

1.3 Press the selector down to highlight X.

1.4 Press the selector right to place the cursor in the setup menu.

Adjust settings.

Highlight items and press the selector right to view options, then highlight

an option and press MENU/OK. Press DISP/BACK to exit when settings are

complete.

88 Menus

The Setup Menu

Setup Menu Options

F DATE/TIME

Set the camera clock (P 19).

N TIME DIFFERENCE (default: h)

Switch the camera clock instantly from your home time zone to the local time at your destination

when traveling. To specify the difference between local time and your home time zone:

Highlight g LOCAL and press the selector right.

Use the selector to choose the time difference between local time and your home time zone

in increments of 15 minutes.

Press MENU/OK.

To switch between local time and your home time zone, highlight g LOCAL or h HOME and

press MENU/OK.

Option Description

h HOME Switch to the time currently selected for F DATE/TIME (see above).

g LOCAL

Switch to local time. If this option is selected, g and the time and date will be

displayed in yellow for three seconds each time the camera is turned on.

L a

Choose a language.

o SILENT MODE

(default: OFF)

Select ON to disable the speaker, flash, and AF-assist illuminator in situations in which camera

sounds or lights may be unwelcome (note that the flash will still fire in C/g mode).

89Menus

The Setup Menu

R RESET

Reset all settings except F DATE/TIME, N TIME DIFFERENCE, and O BACKGROUND COLOR

to default values.

Highlight R RESET and press the selector right to display a confirmation dialog.

Highlight OK and press MENU/OK.

K FORMAT

If a memory card is inserted in the camera, this option will format the memory card. If no

memory card is inserted, this option will format internal memory. Select OK to begin formatting.

Q All data—including protected pictures—will be deleted from the memory card or internal

memory. Be sure important files have been copied to a computer or other storage device.

Q Do not open the battery cover during formatting.

A IMAGE DISP.

(default: 1.5 SEC)

Choose how long pictures are displayed in the LCD monitor after shooting.

Option Description

1.5 SEC

Pictures are displayed for 1.5 seconds (1.5 SEC) or 0.5 seconds (0.5 SEC).

Colors may differ slightly from those in the final image.

0.5 SEC

ZOOM (CONTINUOUS) Pictures are displayed until the MENU/OK button is pressed.

OFF Pictures are not displayed after shooting.

R OFF has no effect in continuous shooting, Y ADVANCED FILTER, j PRO LOW-LIGHT and

k HDR.

90 Menus

The Setup Menu

B FRAME NO.

(default: CONT.)

New pictures are stored in image files named using a four-digit file

number assigned by adding one to the last file number used. The file

number is displayed during playback as shown at right. B FRAME NO.

controls whether file numbering is reset to 0001 when a new memory

card is inserted or the current memory card or internal memory is

formatted.

Directory

number

File

number

Frame number

100-0001

Option Description

CONTINUOUS

Numbering continues from the last file number used or the first available file

number, whichever is higher. Choose this option to reduce the number of

pictures with duplicate file names.

RENEW

Numbering is reset to 0001 after formatting or when a new memory card is

inserted.

R If the frame number reaches 999-9999, the shutter release will be disabled (P 109).

R Selecting R RESET (P 89) sets B FRAME NO. to CONTINUOUS but does not reset the

file number.

R Frame numbers for pictures taken with other cameras may differ.

91Menus

The Setup Menu

G OPERATION VOL. (default: c)

Adjust the volume of the sounds produced when camera controls are operated. Choose f

(mute) to disable control sounds.

H SHUTTER VOLUME (default: c)

Adjust the volume of the sounds produced when the shutter is released. Choose f (mute)

to disable the shutter sound.

e SHUTTER SOUND (default: i)

Choose the sound made by the shutter.

I PLAYBACK VOLUME

(default: 7)

Adjust the volume for movie playback.

J LCD BRIGHTNESS

(default: AUTO)

Control the brightness of the display.

Option Description

AUTO

Display brightness is automatically adjusted during shooting in response to

ambient lighting conditions. Brightness is not adjusted during playback.

MANUAL

Press the selector up or down to adjust brightness and then press MENU/OK.

Choose from values between –5 and +5.

92 Menus

The Setup Menu

h LCD POWER SAVE

(default: U ON)

Choose whether the display automatically dims to save power in shooting mode. This option

does not take effect during playback.

Option Description

U POWER SAVE ON

The display dims to save power if no operations are performed for a few

seconds. Normal brightness can be restored by pressing the shutter button

halfway.

U POWER SAVE OFF

Automatic dimming off.

M AUTO POWER OFF

(default: 2 MIN)

Choose the length of time before the camera turns off automatically when no operations are

performed. Shorter times increase battery life; if OFF is selected, the camera must be turned

off manually. Note that in some situations the camera turns off automatically even when OFF

is selected.

L IS MODE (default: l)

Choose whether image stabilization is performed at all times when the camera is in shooting

mode (l CONTINUOUS), or only when the shutter button is pressed halfway (m SHOOTING

ONLY). Choose OFF to turn image stabilization off when using a tripod.

b DIGITAL IMAGE STABILIZER

(default: ON)

If ON is selected, camera vibrations that occur when shooting movies are corrected, allowing

you to shoot images with only minor vibrations.

R Digital image stabilizer is unavailable when shooting still images.

B RED EYE REMOVAL

(default: ON)

Choose ON to remove red-eye effects caused by the flash when shooting with Intelligent Face

Detection.

R Red-eye reduction is performed only when a face is detected.

93Menus

The Setup Menu

R INTELLIGENT DIGITAL ZOOM

(default: OFF)

If ON is selected, selecting T at the maximum optical zoom position triggers intelligent digital

zoom, further magnifying the image while processing it for sharp, high-resolution results.

The Zoom Indicator

INTELLIGENT DIGITAL

ZOOM on

W T

Optical zoom Intelligent

digital zoom

INTELLIGENT DIGITAL

ZOOM off

W T

Optical zoom

R Selecting another mode may end intelligent digital zoom.

R When combined with optical zoom, intelligent digital zoom offers zoom factors as high as

10×.

R Intelligent digital zoom may sometimes produce lower quality images than optical zoom.

R The time needed to record images increases.

R The effects are not visible in the display during shooting.

R Intelligent digital zoom is not available in continuous mode or during movie recording.

94 Menus

The Setup Menu

p MOVIE ZOOM TYPE (default: D)

Choose the type of zoom available during movie recording: C DIGITAL or D OPTICAL.

R Movies recorded using digital zoom may be slightly “grainy”.

C AF ILLUMINATOR

(default: ON)

If ON is selected, the AF-assist illuminator will light to assist autofocus.

Q The camera may be unable to focus using the AF-assist illuminator in some cases. If the

camera is unable to focus in macro mode, try increasing the distance to the subject.

Q Avoid shining the AF-assist illuminator directly into your subject’s eyes.

m AUTOROTATE PB

(default: ON)

Choose ON to automatically rotate “tall” (portrait-orientation) pictures during playback.

O BACKGROUND COLOR

Choose a color scheme.

h WIND FILTER

Choose ON to reduce the noise of the wind when shooting movies.

r WIRELESS SETTINGS

Adjust settings for connection to a wireless network. For information on using wireless networks,

visit http://fujifilm-dsc.com/wifi/.

95Menus

The Setup Menu

s PC AUTO SAVE SETTING

Choose a destination for images uploaded using s PC AUTO SAVE. For information on using

wireless networks, visit http://fujifilm-dsc.com/wifi/.

U GEOTAGGING SET-UP

Access location data options.

Option Description

GEOTAGGING Choose whether to save location data with pictures.

LOCATION INFO Display locatin data.

V instax PRINTER CONNECTION SETTING

Adjust settings for connection to optional FUJIFILM instax SHARE printers (P 67).

U DATE STAMP

(default: OFF)

Stamp the time and/or date of recording on photographs as they are taken.

Option Description

R+S

Stamp new photographs with the date and time of recording.

Stamp new photographs with the date of recording.

OFF Do not stamp the time and date on new photographs.

Q Time and date stamps can not be deleted. Turn U DATE STAMP off to prevent time and date

stamps appearing on new photographs.

Q If the camera clock is not set, you will be prompted to set the clock to the current date and

time (P 19).

Q We recommend that you turn the DPOF “print date” option off when printing images with a

time and date stamp (P 65).

Q Date and time can not be added to the movies and the panoramas.

Technical Notes

Optional Accessories

The camera supports a wide range of accessories from FUJIFILM and other

manufacturers.

FINEPIX XP120 Series

DIGITAL CAMERA

■ Printing

SP-1

Wireless LAN

instax SHARE printer

SP-2

USB cable (supplied)

SD card slot or card reader

Computer

†

■ Computer Related

■ Audio/Visual

SD/SDHC/SDXC

memory card

†

HDTV

†

HDMI cable

†

* Available separately from FUJIFILM.

† Available separately from third-party suppliers.

97Technical Notes

Optional Accessories

Accessories from FUJIFILM

The following optional accessories are available from FUJIFILM. For the latest

information on the accessories available in your region, check with your local

FUJIFILM representative or visit http://www.fujifilm.com/products/digital_

cameras/index.html.

Rechargeable

Li-ion batteries

NP-45S: Additional large-capacity NP-45S rechargeable

batteries can be purchased as required.

Battery

chargers

BC-45W: Replacement battery chargers can be purchased

as required. The BC-45W charges an NP-45S battery in

about 120 minutes at +20 °C (+68 °F).

BC-45C: Replacement battery chargers can be purchased

as required. The BC-45C charges an NP-45S battery in

about 110 minutes at +20 °C (+68 °F).

instax SHARE

printers

SP-1/SP-2: Connect via wireless LAN to print pictures on instax film.

98 Technical Notes

Caring for the Camera

To ensure continued enjoyment of the product, observe the following

precautions.

Storage and Use

If the camera will not be used for an

extended period, remove the battery

and memory card. Do not store or

use the camera in locations that are:

• exposed to rain, steam, or smoke

• very humid or extremely dusty

• exposed to direct sunlight or very

high temperatures, such as in a

closed vehicle on a sunny day

• extremely cold

• subject to strong vibration

• exposed to strong magnetic

fields, such as near a broadcasting

antenna, power line, radar emitter,

motor, transformer, or magnet

• in contact with volatile chemicals

such as pesticides

• next to rubber or vinyl products

■ Condensation

Sudden increases in temperature,

such as occur when entering a heated

building on a cold day, can cause

condensation inside the camera. If

this occurs, turn the camera off and

wait an hour before turning it on

again. If condensation forms on the

memory card, remove the card and

wait for the condensation to dissipate.

99Technical Notes

Caring for the Camera

Cleaning

Use a blower to remove dust from the protective glass covering the lens and

LCD monitor, then gently wipe with a soft, dry cloth. Any remaining stains can

be removed by wiping gently with a piece of FUJIFILM lens-cleaning paper to

which a small amount of lens-cleaning fluid has been applied. Care should

be taken to avoid scratching the protective glass or LCD monitor. The camera

body can be cleaned with a soft, dry cloth. Do not use alcohol, thinner, or

other volatile chemicals.

Traveling

Keep the camera in your carry-on baggage. Checked baggage may suffer

violent shocks that could damage the camera.

100

Troubleshooting

Problems and Solutions

Water in the Camera

Problem Solution

Water in the camera.

The battery-chamber cover was not fully closed before the camera was immersed, or

was opened under water: Take the camera to a FUJIFILM-authorized service technician for

repairs. Do not turn the camera on.

Power and Battery

Problem Solution

The camera does not

turn on.

• The battery is exhausted: Charge the battery or insert a fully-charged spare battery (P 7, 14).

• The battery is inserted incorrectly: Reinsert in the correct orientation (P 8).

• The battery-chamber cover is not latched: Latch the battery-chamber cover (P 10).

The battery runs down

quickly.

• The battery is cold: Warm the battery by placing it in a pocket or other warm place and reinsert

it in the camera immediately before taking a picture.

• There is dirt on the battery terminals: Clean the terminals with a soft, dry cloth.

• Q is selected for shooting mode: Select B mode to reduce the drain on the battery

(P 25).

• x TRACKING is selected for F AF MODE: Select a different AF mode (P 77).

• The battery has been charged many times: The battery has reached the end of its charging

life. Purchase a new battery.

The camera turns off

suddenly.

Charge the battery or insert a fully-charged spare battery (P 7, 14).

Charging is slow.

Charge the battery at room temperature (P v).

101Troubleshooting

Problems and Solutions

Problem Solution

The battery does not

charge. / The self-timer

lamp flashes.

Reinsert the battery in the correct orientation and make sure that the power connection is made

(P 7, 14).

• There is dirt on the battery terminals: Clean the terminals with a soft, dry cloth.

• The battery has been charged many times: The battery has reached the end of its charging

life. Purchase a new battery. If the battery still fails to charge, contact your FUJIFILM dealer.

• The battery is too hot or too cold: Wait for the battery temperature to stabilize.

Menus and Displays

Problem Solution

Menus and displays are

not in English.

Select ENGLISH for L a (P 19, 88).

Shooting

Problem Solution

No picture is taken when

the shutter button is

pressed.

• Memory is full: Insert a new memory card or delete pictures (P 9, 53).

• Memory is not formatted: Format the memory card or internal memory (P 89).

• There is dirt on the memory card contacts: Clean the contacts with a soft, dry cloth.

• The memory card is damaged: Insert a new memory card (P 9).

• The battery is exhausted: Charge the battery or insert a fully-charged spare battery (P 7, 14).

• The camera has turned off automatically: Turn the camera on (P 17).

The camera does not

focus.

• The subject is close to the camera: Select macro mode (P 41).

• The subject is far away from the camera: Cancel macro mode (P 41).

• The subject is not suited to autofocus: Use focus lock (P 38).

102 Troubleshooting

Problems and Solutions

Problem Solution

Macro mode is not

available.

Choose a different shooting mode (P 25).

Intelligent Face Detection

is not available.

Choose a different shooting mode (P 25).

No face is detected.

• The subject’s face is obscured by sunglasses, a hat, long hair, or other objects: Remove

the obstructions.

• The subject’s face occupies only a small area of the frame: Change the composition so that

the subject’s face occupies a larger area of the frame (P 37).

• The subject’s head is tilted or horizontal: Ask the subject to hold their head straight.

• The camera is tilted: Keep the camera level (P 21).

• The subject’s face is poorly lit: Shoot in bright light.

Wrong subject is

selected.

The selected subject is closer to the center of the frame than the main subject. Recompose the

picture or turn face detection off and frame the picture using focus lock (P 38).

The flash does not fire.

• The flash is not available in the current shooting mode: Choose a different shooting mode

(P 25).

• The battery is exhausted: Charge the battery or insert a fully-charged spare battery (P 7, 14).

• The camera is in continuous mode: Press the burst mode button to select single-frame mode

(P 49).

• The camera is in silent mode: Turn silent mode off (P 88).

• The flash is off (P): Choose a different flash mode (P 42).

Some flash modes are

not available.

• The desired flash mode is not available in the current shooting mode: Choose a different

shooting mode (P 25).

• The camera is in silent mode: Turn silent mode off (P 88).

The flash does not fully

light the subject.

• The subject is not in range of the flash: Position the subject in range of the flash (P 114).

• The flash window is obstructed: Hold the camera correctly (P 21).

103Troubleshooting

Problems and Solutions

Problem Solution

Pictures are blurred.

• The protective glass covering the lens is dirty: Clean the glass (P 99).

• The protective glass covering the lens is blocked: Keep objects away from the lens (P 21).

• s is displayed during shooting and the focus frame is displayed in red: Check focus

before shooting (P 107).

• k is displayed during shooting: Use the flash or a tripod (P 43).

Pictures are mottled.

• A slow shutter speed is selected at high temperatures: This is normal and does not

indicated a malfunction.

• The camera has been used continuously at high temperatures or a temperature

warning is displayed: Turn the camera off and wait for it to cool down.

Vertical lines appear in

pictures.

The camera has been used continuously at high temperatures. Turn the camera off and wait for

it to cool down.

“Smear” in the form of

vertical purple or white

lines appears in the

display.

Vertical purple or white lines may appear after the camera has been used continuously at high

temperatures or when a very bright object is in the frame; this phenomenon is common to all CCD

image sensors and does not indicate a malfunction. These lines are recorded in movies but do not

appear in photographs. Avoid framing bright objects when filming movies.

Location data Location data are incorrect. The camera has been moved since location data were last updated.

Sounds made by the

camera are recorded with

movies.

• u CONTINUOUS is selected for F MOVIE AF MODE: Select a different AF mode

(P 77).

• Zoom was adjusted during shooting: Do not adjust zoom during shooting.

• Intelligent Face Detection is on: Turn Intelligent Face Detection off (P 37).

104 Troubleshooting

Problems and Solutions

Playback

Problem Solution

Pictures are grainy. The pictures were taken with a different make or model of camera.

Playback zoom is

unavailable.

The current picture is a resized copy with a size of a.

No sound in movie

playback.

• Playback volume is too low: Adjust playback volume (P 91).

• The microphone was obstructed: Hold the camera correctly during recording (P 21, 60).

• The speaker is obstructed: Hold the camera correctly during playback (P 63).

Selected pictures are not

deleted.

Some of the pictures selected for deletion are protected. Remove protection using the device with

which it was originally applied (P 83).

File numbering is

unexpectedly reset.

The battery-chamber cover was opened while the camera was on. Turn the camera off before

opening the battery-chamber cover (P 17).

105Troubleshooting

Problems and Solutions

Connections/Miscellaneous

Problem Solution

No picture or sound.

• The camera is not properly connected: Connect the camera properly (P 64).

• Input on the television is set to “TV”: Set input to “HDMI”.

• The volume on the TV is too low: Adjust the volume.

The computer does not

recognize the camera.

Be sure the camera and computer are correctly connected (P 70).

The camera is

unresponsive.

• Temporary camera malfunction: Remove and reinsert the battery (P 7).

• The battery is exhausted: Charge the battery (P 14) or insert a fully-charged spare

battery (P 7).

• The camera is connecting to a wireless network: Disconnect from the wireless network.

The camera does not

function as expected.

Remove and reinsert the battery (P 7). If the problem persists, contact your FUJIFILM dealer.

No sound.

Turn silent mode off (P 88).

Time and date stamps

• Time and date stamps are not correct: Set the camera clock (P 19).

• Time and date stamps appear on photographs: Time and date stamps can not be deleted.

To prevent stamps appearing on new photographs, select OFF for U DATE STAMP

(P 95).

106 Troubleshooting

Problems and Solutions

Wireless Networks

For information on troubleshooting wireless networks,

visit http://digital-cameras.support.fujifilm.com/app?pid=x.

Problem Solution

Problem connecting or

uploading pictures to

smartphone.

Can not shoot photos

using a smartphone.

• The smartphone is too far away: Move the devices closer.

• Nearby devices are causing radio interference: Move the camera and smartphone away

from microwave ovens or cordless phones.

• The smartphone is connected to another device: The smartphone and camera can connect

to only one device at a time. End the connection and try again.

• There are several smartphones in the vicinity: Try connecting again. The presence of

multiple smartphones can make connection difficult.

The current image is a movie or was created on another device and can not be uploaded to a

smartphone.

Smartphone will not

display pictures.

Select ON for r WIRELESS SETTING> RESIZE IMAGE FOR SMARTPHONE

H. Selecting OFF increases upload times for larger images; in addition, some phones may not

display images over a certain size.

107Troubleshooting

Warning Messages and Displays

The following warnings are displayed in the LCD monitor:

Warning Description

B (red) Low battery. Charge the battery (P 14) or insert a fully-charged spare battery (P 7).

A (blinks red) Battery exhausted. Charge the battery (P 14) or insert a fully-charged spare battery (P 7).

Slow shutter speed. Pictures may be blurred; use the flash or a tripod.

(displayed in red with red

focus frame)

The camera can not focus. Try one of the following solutions:

• Use focus lock to focus on another subject at the same distance, then recompose the picture

(P 38).

• Use macro mode to focus when taking close-ups (P 41).

Aperture or shutter speed

displayed in red

The subject is too bright or too dark and the picture will be over- or under-exposed. If the subject

is dark, use the flash (P 42).

FOCUS ERROR

Camera malfunction or moving parts of lens obstructed. Turn the camera off and then on again,

taking care not to touch the lens. If the message persists, contact a FUJIFILM dealer.

TURN OFF THE CAMERA

AND TURN ON AGAIN

LENS CONTROL ERROR

CARD NOT INITIALIZED

• The memory card or internal memory is not formatted or the memory card was

formatted in a computer or other device: Format the memory card or internal memory

using the K FORMAT option in the camera setup menu (P 89).

• The memory card contacts require cleaning: Clean the contacts with a soft, dry cloth. If

the message is repeated, format the card (P 89). If the message persists, replace the card.

• Camera malfunction: Contact a FUJIFILM dealer.

PROTECTED CARD

The memory card is locked. Unlock the card (P 9).

BUSY

The memory card is incorrectly formatted. Use the camera to format the card (P 89).

108 Troubleshooting

Warning Messages and Displays

Warning Description

Turn the camera off and wait for it to cool. If no action is taken, the camera will turn off

automatically.

CARD ERROR

The memory card is not formatted for use in the camera. Format the card (P 89).

The memory card contacts require cleaning or the memory card is damaged. Clean the contacts

with a soft, dry cloth. If the message is repeated, format the card (P 89). If the message

persists, replace the card.

Incompatible memory card. Use a compatible card (P 12).

Camera malfunction. Contact a FUJIFILM dealer.

a MEMORY FULL

The memory card or internal memory is full and pictures can not be recorded or copied. Delete

pictures or insert a memory card with more free space.

b MEMORY FULL

INTERNAL MEMORY IS

FULL

INSERT A NEW CARD

WRITE ERROR

• Memory card error or connection error: Reinsert the card or turn the camera off and then

on again. If the message persists, contact a FUJIFILM dealer.

• Not enough memory remaining to record additional pictures: Delete pictures or insert

a memory card with more free space.

• The memory card or internal memory is not formatted: Format the memory card or

internal memory (P 89).

READ ERROR

• The file is corrupt or was not created with the camera: The file can not be viewed.

• The memory card contacts require cleaning: Clean the contacts with a soft, dry cloth. If

the message is repeated, format the card (P 89). If the message persists, replace the card.

• Camera malfunction: Contact a FUJIFILM dealer.

109Troubleshooting

Warning Messages and Displays

Warning Description

FRAME NO. FULL

The camera has run out of frame numbers (current frame number is 999-9999). Format the

memory card and select RENEW for B FRAME NO. in the setup menu. Take a picture

to reset frame numbering to 100-0001, then select CONTINUOUS for B FRAME NO

(P 90).

DEACTIVATE SILENT MODE

An attempt was made to choose a flash mode or adjust the volume with the camera in silent

mode. Exit silent mode before choosing a flash mode or adjusting the volume (P 88).

TOO MANY FRAMES

A search has returned more than 5,000 results, or more than 999 frames were selected for

deletion. Perform a different search or select fewer pictures.

PROTECTED FRAME

An attempt was made to delete to a protected picture. Remove protection and try again (P 83).

a CAN NOT CROP

a pictures can not be cropped.

CAN NOT CROP The picture is damaged or was not created with the camera.

P CANNOT EXECUTE

An attempt was made to create a resized copy at a size equal to or larger than the original.

Choose a smaller size.

Q CANNOT EXECUTE

a CANNOT EXECUTE

CAN NOT ROTATE An attempt was made to rotate a picture that can not be rotated.

F CAN NOT ROTATE

Movies can not be rotated.

m CANNOT EXECUTE

Resize or red-eye removal can not be applied to the selected picture.

F CANNOT EXECUTE

Red-eye removal can not be applied to movies.

110 Troubleshooting

Warning Messages and Displays

Warning Description

NO CARD

No memory card inserted when E COPY is selected in the playback menu. Insert a memory

card.

b NO IMAGE

The source selected for E COPY contains no images. Select a different source.

a NO IMAGE

DPOF FILE ERROR

The DPOF print order on the current memory card contains more than 999 images. Copy the

pictures to internal memory and create a new print order.

CAN NOT SET DPOF The picture can not be printed using DPOF.

F CAN NOT SET DPOF

Movies can not be printed using DPOF.

COMMUNICATION ERROR

A connection error occurred while pictures were being printed or copied to a computer or other

device. Confirm that the device is turned on and that the USB cable is connected.

Ensure the battery chamber

cover is locked.

Check that the battery-chamber cover is latched. Note that the cover may already be latched;

this message merely encourages you to check that the cover is secure before proceeding.

111

Appendix

Memory Card Capacity

The following table shows the recording time or number of pictures available

at different image sizes. All figures are approximate; file size varies with the scene

recorded, producing wide variations in the number of files that can be stored. The

number of exposures or length remaining may not diminish at an even rate. A limited

number of test pictures can be taken when no memory card is inserted.

■ Photographs

O P Q

4 : 3 3 : 2 16 : 9 1 : 1 4 : 3 3 : 2 16 : 9 1 : 1 4 : 3 3 : 2 16 : 9 1 : 1

4 GB

FINE

460 520 620 620 920 1,040 1,220 1,240 2,300 2,050 3,420 2,420

NORMAL

930 1,040 1,230 1,230 1,820 2,040 2,400 2,440 3,380 3,030 4,990 3,550

8 GB

FINE

940 1,050 1,250 1,250 1,860 2,090 2,460 2,500 4,620 4,120 6,870 4,850

NORMAL

1,860 2,090 2,470 2,470 3,660 4,110 4,830 4,900 6,800 6,080 10,020 7,140

■ Movies

1920 × 1080

(60fps)

1920 × 1080

(30fps)

1280 × 720

(60 ps)

f 640 × 480

(30fps)

k 640 × 480

(120fps)

k 320 × 240

(240fps)

k 160 × 120

(320fps)

4 GB

36 min. 36 min. 40 min. 188 min. 64 min. 127 min. 141 min.

8 GB

73 min. 73 min. 81 min. 378 min. 128 min. 255 min. 284 min.

1 Use a H card or better. Individual movies can not exceed 29 minutes in length.

2 Individual movies can not exceed 120 minutes in length.

3 Use a H card or better. Individual movies can not exceed 30 seconds in length.

112 Appendix

Specifications

System

Model Digital Camera FinePix XP120 Series

Effective pixels 16.4 million

Image sensor 

 -in. square pixel CMOS with primary color filter

Storage media • Internalmemory(approx. 96 MB) • SD/SDHC/SDXCmemorycards

File system Compliant with Design Rule for Camera File System (DCF), Exif 2.3, and Digital Print Order

Format (DPOF)

File format • Still pictures: Exif 2.3 JPEG (compressed)

• Movies: MOV (H.264)/Linear PCM/monaural sound

Image size (pixels)

• O

4 : 3: 4,608 × 3,456

• O

3 : 2: 4,608 × 3,072

• O

16 : 9: 4,608 × 2,592

• O

1 : 1: 3,456 × 3,456

• P

4 : 3: 3,264 × 2,448

• P

3 : 2: 3,264 × 2,176

• P

16 : 9: 3,264 × 1,840

• P

1 : 1: 2,432 × 2,432

• Q

4 : 3: 2,048 × 1,536

• Q

3 : 2: 2,304 × 1,536

• Q

16 : 9: 1,920 × 1,080

• Q

1 : 1: 1,728 × 1,728

Lens Fujinon 5 × optical zoom lens, F3.9 (wide angle) – F4.9 (telephoto)

Focal length f=5.0 mm–25.0 mm (35-mm format equivalent: 28 mm–140 mm)

Digital zoom Up to about 2 × with intelligent digital zoom (up to 10 × when combined with optical zoom)

Aperture F3.9/F6.2 (wide angle), F4.9/F8.0 (telephoto)

Focus range

(distance from front of lens)

Approx. 60 cm (1.9 ft.)–infinity (wide angle); 1.0 m (3.2 ft.)–infinity (telephoto)

•

Macro: approx. 9 cm–2.0 m/3.5 in.–6.5 ft. (wide angle); 1.0 m–3.0 m/3.2 ft.–9.8 ft. (telephoto)

113Appendix

Specifications

System

Sensitivity Standard output sensitivity equivalent to ISO 100, 200, 400, 800, 1600, 3200, 6400 (image size

P or Q); AUTO (400), AUTO (800), AUTO (1600)

Metering 256-segment through-the-lens (TTL); MULTI

Exposure control Programmed AE

Exposure compensation –2 EV – +2 EV in increments of 

 EV

Image stabilization Optical stabilization (image-sensor shift)

Shutter speed

(combined mechanical and

electronic shutter)

• Q, B, P, g, k, C, h, M, Y, N, O, Q, R, s, F, s, U, V,

W: 

 s–

 s

• j: / s–/ s

• r: / s–/ s

• H: 4 s–/ s

Continuous

Approx. frame rate (fps)

Continuous frames (Image size)

3.0

10 (OP), 40 (Q)

5.0

10 (OP), 20 (Q)

70 (Q16:9)

3.0

10 (OP), 20 (Q)

5.0

10 (OP), 20 (Q)

*1 Theframeratevarieswithshootingconditionsandthenumberofimagesrecorded.

*2 UseaHcardorbetter.

Focus • Mode: Single AF, continuous AF

• Focus-area selection: CENTER, MULTI, TRACKING

• Autofocus system: Contrast-detect TTL AF

114 Appendix

Specifications

System

White balance Auto, direct sunlight, shade, daylight fluorescent, warm white fluorescent, cool white fluorescent,

incandescent, underwater

Self-timer

Off, 2 sec., 10 sec., g (GROUP TIMER), INTERVAL SHOOTING, TIME-LAPSE MOVIE

Time-lapse movie

• i 1920×1080: 1080p, 60 fps

• i 1920×1080: 1080p, 10 fps

• h 1280×720: 720p, 30 fps

• f 640×480: VGA, 60 fps

• f 640×480: VGA, 10 fps

• i 1920×1080: 1080p, 30 fps

• h 1280×720: 720p, 60 fps

• h 1280×720: 720p, 10 fps

• f 640×480: VGA, 30 fps

Flash Auto flash; effective range when sensitivity is set to AUTO is approx. 70 cm–4.4 m/2.3 ft.–14.4 ft.

(wide angle), 1.0 m–3.8 m/3.2 ft.–12.4 ft. (telephoto); effective range in macro mode is approx.

30 cm–2.0 m/1.0 ft.–6.5 ft. (wide angle), 1.0 m–3.0 m/3.2 ft.–9.8 ft. (telephoto)

Flash mode Auto, fill flash, off, slow sync (red-eye removal off); auto with red-eye removal, fill flash with red-

eye removal, off, slow sync with red-eye removal (red-eye removal on)

LCD monitor 3.0-in. (7.6 cm), 920 k-dot color LCD monitor; frame coverage approx. 100 %

Movies

• i 1920×1080: 1080p, 60 fps

• h 1280×720: 720p, 60 fps

• k 640×480: 120fps

• k 160×120: 320fps

• i 1920×1080: 1080p, 30 fps

• f 640×480: VGA, 30 fps

• k 320×240: 240fps

115Appendix

Specifications

Input/output terminals

Digital input/output USB 2.0 High-Speed, Micro USB connector (Micro-B); MTP/PTP

HDMI output Micro HDMI connector (Type D)

Power supply/other

Power supply NP-45S rechargeable battery

Battery life (approximate

number of frames that can

be taken with a fully-charged

battery)

Battery type Approximate number of frames

NP-45S (type supplied with camera) 210

CIPA standard, measured in B (auto) mode using battery supplied with camera and SD

memory card.

Note: Number of shots that can be taken with battery varies with battery charge level and will

decline at low temperatures.

Charging time Approx. 120 minutes (+20 °C/+68 °F)

Camera dimensions

(W × H × D)

109.6 mm × 71.0 mm × 27.8 mm/4.3 in. × 2.7 in. × 1.0 in., excluding projections

Shooting weight Approx. 203 g/7.1 oz., including battery and memory card

Camera weight Approx. 186 g/6.5 oz., excluding battery, accessories, and memory card

Operating conditions • Temperature: –10 °C – +40 °C/+14 °F – +104 °F

• Humidity: 10% – 80% (no condensation)

116 Appendix

Specifications

Wireless transmitter

Standards IEEE 802.11b/g/n (standard wireless protocol)

Operating frequency • U. S. A., Canada, Taiwan: 2,412MHz–2,462MHz (11 channels)

• Other countries: 2,412MHz–2,472MHz (13 channels)

Access protocols Infrastructure

NP-45S rechargeable battery

Nominal voltage DC 3.7 V

Nominal capacity 740 mAh

Dimensions (W × H × D) 31.4 mm × 39.5 mm × 5.8 mm/1.2 in. × 1.5 in. × 0.2 in.

Weight Approx. 19.0 g/0.6 oz.

AC power adapter

Rated input 100 V–240 V AC, 50/60 Hz

Input capacity • 100 V: 11.6 VA • 240 V: 15.5 VA

Rated output 5.0 V DC, 1000 mA

Operating temperature 0 °C – +40 °C/+32 °F – +104 °F

Weight Approx. 32 g/1.1 oz.

Weight and dimensions vary with the country or region of sale.

117Appendix

Specifications

■ Notices

• Specifications subject to change without notice. FUJIFILM shall not be held liable for

damages resulting from errors in this manual.

• Although the LCD monitor is manufactured using advanced high-precision

technology, small bright points and anomalous colors may appear, particularly in the

vicinity of text. This is normal for this type of LCD monitor and does not indicate a

malfunction; images recorded with the camera are unaffected.

• Digital cameras may malfunction when exposed to strong radio interference (e.g.,

electric fields, static electricity, or line noise).

• Due to the type of lens used, some distortion may occur at the periphery of images.

This is normal.

7-3, AKASAKA 9-CHOME, MINATO-KU, TOKYO 107-0052, JAPAN

http://www.fujifilm.com/products/digital_cameras/index.html

Restrictions on Camera Settings

The options available in each shooting mode are listed below.

Shooting Mode

Option Q B P G g j k C h M Y r N O H Q R s F s U V W

N BOFF

AUTO

4 4 4 4 4 4 4 4 4 4 4

4 4 4 4

4 4 4 4 4 4 4 4 4

4 4 4 4 4

BON K

4 4 4 4 4 4 4

4 4 4 4

4 4

4 4 4 4 4 4 4 4 4

h S/R

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

4 4 4 4 4 4 4 4 4 4 4 4 4

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

F F

4 4 4 4 4 4 4 4 4

4 4 4 4 4 4 4 4

4 4

AUTO

AUTO (1600)

AUTO (800)

AUTO (400)

6400

3200

1600

800

400

200

100

O O

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

4 4 4 4 4

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

4 4 4 4 4 4 4 4 4

4 4 4 4 4 4 4 4 4 4 4

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

P c

4 4 4 4 4 4 4 4

4 4 4 4 4 4

4 4 4 4 4 4 4 4

4 4

Restrictions on Camera Settings

Shooting Mode

Option Q B P G g j k C h M Y r N O H Q R s F s U V W

R P

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

4 4 4 4 4 4 4 4 4 4 4 4 4

OFF

4 4 4

4 4 4 4 4

4 4

4 4 4 4 4 4

4 4

F r

4 4

i 1920×1080 (60fps)

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

i 1920×1080 (30fps)

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

h 1280×720 (60fps)

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

f 640×480 (30fps)

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

k 640×480 (120fps)

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

k 320×240 (240fps)

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

k 160×120 (320fps)

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

(F)

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

L l

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

OFF

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

4 4 4

4 4 4 4

4 4 4 4 4 4 4 4 4 4 4

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

4 4 4 4 4 4

4 4 4 4 4 4 4 4 4

4 4

4 4 4

4 4 4 4 4

4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4

1 Automatically optimized for selected shooting mode.

2 OFF only.

3 Can be selected only when AUTO or g is set.

Fujifilm FinePix XP120 - Waterproof Digital Camera

Product's Documents

Owner’s Manual

Specifications

Fujifilm FinePix XP120 Questions and Answers

Related Products

Fujifilm XP140 Waterproof Digital Camera w/16GB SD Card

Fujifilm XP140 Waterproof Digital Camera w/16GB SD Card

Hiseeu YHB98-PD 4K 8MP PoE IP Camera Waterproof WDR Night Vision

Hiseeu TZ-HB612 3MP Outdoor Wireless Camera Waterproof

XTU S3 4K30FPS WiFi Action Camera Waterproof Camera, 20MP Sports Camera

Triplett BR260 High Definition Videoscope Waterproof Camera, 3-Inch LCD Display, and 2M Cable
