Operating Instructions
Household Use
Electronic Rice Cooker
USA/CAN
SR
-
DF101
SR
-
DF181
感謝您購買Panasonic產品。
• 本產品只適合家庭用。
•
使用本產品時，請仔細閱讀本使用說明書並遵循安全注意事項。
•
使用本產品前，請特別留意「安全注意事項」（第28~29頁）。
•
請確認保修證已蓋好購買日期和購買店名戳章，並與本使用說明書放在一起。
型號
Model No. 1.0L
1.8L
保留備用
Thank you for purchasing the Panasonic product.
• This product is intended for household use only.
• Please read these instructions carefully and follow safety precautions when using this product.
• Before using this product please give your special attention to “Safety Precautions” (Page 4~5).
• Please make sure the date and name of store of purchase are stamped and keep it with this Operating Instructions.
Reserve it for later use
Merci d’avoir acheté ce produit Panasonic.
• Ce produit est conçu uniquement pour une utilisation domestique.
• Veuillez lire ces instructions attentivement et suivre les consignes de sécurité lors de l’utilisation de ce produit.
• Avant d’utiliser ce produit,
• Assurez-vous que la date d’achat et le nom du magasin où vous avez acheté le produit sont indiqués et conservez ces
informations avec le mode d’emploi.
Conservez le mode d’emploi pour une utilisation ultérieure
Veuillez porter une attention particulière aux « Consignes de sécurité » (Pages 16~17).
目錄
安全注意事項
零件名稱
•
操作面板
•
本體
準備工作
功能
•
快速/蒸餸
•
白米
•
保溫
•
糙米
•
稀飯/湯
菜譜
清潔保養
故障排除
規格
使用之前 用途 困惑時
Table of Contents
Safety Precautions
Parts identification
•
Control panel
•
Entire unit
Preparations
Functions
•
Quick Cook/Steam
•
Brown Rice
•
White Rice
•
Keep Warm
•
Porridge/Soup
Recipes
Cleaning and
maintenance
Troubleshooting
Specifications
Before use Usage In Trouble
................ 28~29
.................................... 31
.............................................. 32
..................................... 36~37
................................... 38
................................... 39
............................................. 39
.................................... 30
....................................... 30
...................................... 32
.................................... 33
.............................................. 34
.......................................... 35
.............................................. 30
.....
4~5
............................. 7
................................... 8
........................... 12~13
......................... 14
................. 15
...................... 15
備忘
Memo
.................................... 40~41.............................. 40~41
................. 6
................................. 6
........................ 8
.............. 9
.................................. 10
............................. 11
................................... 6
Table des matières
Consignes de sécurité
Identification des pièces
•
Panneau de commande
•
Vue d’ensemble de l’appareil
Préparations
Fonctions
•
Cuisson rapide/Vapeur
•
Riz brun
•
•
Gruau/Soupe
Recettes
Nettoyage et
entretien
Guide de dépannage
Caractéristiques techniques
Avant l’utilisation
Utilisation
Problèmes de fonctionnement
..... 16~17
......................... 3............................. 2
........................... 19
............................... 20
......................... 14~25
................................... 26
............ 27
........ 27
Mémo
............................... 40~41
.......... 18
...................... 18
..................... 20
............ 21
......................................... 22
................................ 23
......... 18
Riz blanc • Maintien au chaud
IMPORTANT
SAFEGUARDS
PRÉCAUTIONS
À PRENDRE
使用說明書
微型電腦飯煲 家庭用
Mode d’emploi
Utilisation domestique
Cuiseur de riz électronique
N° de modèle
español y coreano P46～P75
스페인의 과 한국의 46 페이지～75페이지
IMPORTANT SAFEGUARDS
14. SAVE THESE INSTRUCTIONS.
When using electrical appliances, basic safety precautions should always be followed
including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against electrical shock do not immerse cord, plugs, or Rice Cooker
except the pan in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Remove plug from outlet when the appliance is not in use, before putting on or taking off
parts, and before cleaning. Allow to cool before handling.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions or has been damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair, or adjustment.
7. The use of accessory attachments not recommended by the appliance manufacturer may
cause injuries.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Extreme caution must be used when moving an appliance containing hot oil or other hot
liquids.
12. Always attach plug to appliance before plugging cord into wall outlet.
To disconnect, turn the control to “ off ” , then remove plug from wall outlet.
13. Do not use appliance for other than intended use.
15. This product is intended for household use.
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of
electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does
not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
a) A short power-supply cord (or detachable power-supply cord) is to be provided to reduce
the risk resulting from becoming entangled in or tripping over a longer cord.
b) Longer detachable power-supply cords or extension cords are available and may be
used if care is exercised in their use.
c) If a longer detachable power-supply cord or extension cord is used,
1) The marked electrical rating of the cord set or extension cord should be at least as
great as the electrical rating of the appliance, and
2) The cord should be arranged so that it will not drape over the countertop or tabletop
where it can be pulled on by children or tripped over unintentionally.
NOTE
2
PRÉCAUTIONS À PRENDRE
14. CONSERVER CE MANUEL
Lors de l’utilisation de tout appareil électrique, il est toujours recommandé de prendre
certaines précautions, dont les suivantes :
1. Lire toutes les instructions.
2. Éviter de toucher aux surfaces chaudes. Toujours utiliser les poignées ou les anses.
3. Afin de prévenir tout risque de choc électrique, ne pas immerger les cordons, les fiches
ou l’appareil dans l’eau ou tout autre liquide, à l’exception du panier et du couvercle
intérieur amovible.
4. Ne jamais laisser des enfants utiliser l’appareil sans surveillance.
5. Après usage et avant le nettoyage, toujours débrancher l’appareil. Laisser refroidir avant
de retirer des pièces ou de les remettre en place.
6. Ne jamais utiliser l’appareil si sa fiche ou son cordon est endommagé ou après avoir
constaté une défectuosité ou des dommages. Le cas échéant ce câble doit être remplacé
par le fabricant, son service après-vente ou une personne de qualification similaire afin
d’éviter tout danger!
7. L’utilisation d’accessoires non recommandés par le fabricant peut représenter un risque
de dommages.
8. Ne pas utiliser l’appareil à l’extérieur.
9. Ne pas laisser le cordon pendre d’une table ou d’un comptoir, ni le mettre en contact
avec une surface chaude.
10. Ne pas placer l’appareil sur le dessus ou à proximité d’un appareil de chauffage, ni dans
un four chaud.
11. S’assurer d’être extrêmement prudent lors du déplacement d’un appareil contenant de
l’huile chaude ou tout autre liquide chaud.
12. Toujours brancher le cordon d’alimentation à l’appareil avant d’en brancher la fiche dans
une prise secteur. Avant de débrancher, couper le contact, puis retirer la fiche de la prise
secteur.
13. N’utiliser l’appareil qu’aux fins recommandées.
15. Cet appareil a été conçu pour un usage domestique.
Cet appareil est muni d’une fiche polarisée (fiche avec une lame plus large que l’autre).
Par mesure de sécurité, cette prise ne peut être insérée que dans un sens dans une prise
polarisée. Si la fiche ne peut être insérée dans la prise, en inverser le sens. Si la fiche ne
peut toujours être insérée, communiquer avec un électricien pour remplacer la prise de
courant. Ne pas tenter de contourner cette mesure de sécurité.
a) Le cordon d’alimentation fourni est court (ou détachable) de manière à prévenir les
risques d’emmêlement et d’accidents.
b) Des rallonges ou des cordons plus longs sont disponibles. lls doivent être utilisés avec
prudence.
c) Si une rallonge ou un cordon long est utilisé:
1) La quissance électrique du cordon ou de la rallonge devrait être au moins aussi
élevée que celle de l’appareil.
2) Le cordon ou la rallonge ne devrait pas pendre du comptoir ou de la table afin
d’éviter que des enfants tirent dessus ou trébuchent.
NOTA
3
Safety Precautions
Must be followed!
Indicates serious
injury or death.
The following charts indicate the degree of damage caused by wrong operation.
The symbols are classified and explained as follows.
Warning
■
■
■
■
■
■
■
■
(It may cause a burn.)
Steam vent
■
■
Warning:
Caution:
Indicates risk of
injury or property
damage.
These symbols indicate
prohibition.
This symbol indicates requirement
that must be followed.
In order to prevent accidents or injuries to the users, other people, and damage to
property, please follow the instructions below.
Do not use the appliance
if the power cord or
power plug is damaged
or the power plug is
loosely connected to the
power outlet.
Do not damage the power
cord or power plug.
Do not plug or unplug the
power plug with wet hands.
Do not get your face close
to the steam vent or touch
it with your hand. Keep the
steam vent out of reach of
small children.
Do not modify, disassemble,
or repair this appliance.
Insert the power plug firmly.
Do not immerse the
appliance in water or
splash it with water.
Use only a power outlet rated
at 10 amperes and alternating
electric current at 120 volts.
(It may cause an electric
shock, short circuit or fire.)
Especially metal objects
such as pins or wires.
(It may cause an electric
shock or malfunction.)
(It may cause burn or injury.)
Do not insert any objects
in the vent or gap.
This appliance is not
intended for use by
persons (including
children) with reduced
physical, sensory or
mental capabilities, or lack
of experience and knowl-
edge, unless they have
been given supervision or
instruction concerning use
of the appliance by a
person responsible for
their safety. Children
should be supervised to
ensure that they do not
play with the appliance.
Following actions are strictly
prohibited.
(It may cause an electric
shock.)
(It may cause a fire,
electric shock or injury.)
(Otherwise it may cause an
electric shock and fire caused
by the heat that may generate
around the power
plug.)
(It may cause a short
circuit or electric shock.)
(Plugging other devices
into the same outlet may
cause electric overheating,
which may cause a fire.)
Modifying, placing near heating
elements, bending, twisting, pulling,
putting heavy objects on top, and
bundling the cord (It may cause an
electric shock, short circuit or fire.)
• If the supply cord is damaged, it
must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order
to avoid a hazard.
•
Please enquire with an authorised
dealer if water gets inside the appliance.
• Use only an extended cord rated
at 10 amperes minimum.
• Do not use a broken power plug
or a loose power outlet.
• Please make enquiries at the
store or the repair department
of an authorised dealer.
■
■
Clean the power plug
regularly.
(A soiled power plug may
cause insufficient insulation
due to the moisture, and
may cause a fire.)
(e.g. for abnormal
situations or
breaking down)
• Unplug the power plug, and
wipe with a dry cloth.
Discontinue using the appliance immediately and unplug the power
connector in cases of abnormal situations and breaking
down.
(It may cause smoking, a fire, or electric shock.)
•
The power plug and the power cord become abnormally hot.
•
The power cord is damaged or power failure occurs when is touched.
• The main body is deformed or abnormally hot.
• The unit gives out smoke or scorching smell.
• There are cracks, looseness or wobbles of the appliance.
• The heating plate is warped or the pan is deformed.
Please make enquiries at Panasonic authorized service center for inspection and repair immediately.
4
Precautions for Use
Caution
Cast heater
Temperature sensor
Pan
Safety Precautions
Must be followed!
Please put in correct amount
of rice and water and select
functions correctly according
to the operating instructions.
(So as to avoid overflow of rice water,
half-cooked rice or scorched rice.)
Before using the appliance, remove
the protective bag on the pan and
the anti-tarnish paper between the
pan and the cast heater.
Please always clean the foreign objects such as rice
on the pan, cast heater and temperature sensor.
When there is any overflow
of rice water from the steam
vent, pull out the power plug
immediately to disconnect
the power supply. Do not
resume the use until the rice
water on the power plug and
the instrument plug is
cleaned with a dry cloth.
The appliance is for household use
only. Do not use it for any
commercial or industrial purposes
or any purposes other than cooking.
When power failure occurs during
the operation of the appliance, the
cooking result may be affected.
(So as to avoid poor cooking or fire.)
Do not cover the outer lid
with cloth or other objects
when the appliance is in use.
(So as to avoid deformation, color
change of the outer lid or failure.)
Avoid using the
appliance under
direct sunlight.
(So as to avoid color change.)
Do not serve out rice
with any metal object.
(So as to avoid scratching the
pan coating and causing peeling
of the coating.)
Do not put ingredients to be
cooked directly into the
appliance in which no pan is
placed.
(So as to prevent any impurities from
causing failure.)
Do not use the appliance on
any heat labile object such as
carpet, electric heating carpet
and tablecloth (made of vinyl
plastics), etc.
(So as to avoid poor cooking or fire.)
●
Do not tilt or overturn
the appliance.
●
Before cleaning, turn
off the power switch
and pull out the power
plug.
■
Do not use the appliance on following places.
■
Do not expose the power plug with steam.
■
Be sure to hold the power
plug when unplugging the
power plug.
■
Do not use the cord set (for
instrument plug and power
plug) that is not specified for
use with this appliance. Also
do not transfer them.
■
Do not touch heating
elements while the
appliance is in use
or after cooking.
■
Do not touch the
hook button while
moving the
appliance.
■
Do not open the
outer lid while
cooking.
■
Do not use other pans
than the one specified.
■
Please allow the appliance to
cool down before cleaning it.
■
Unplug the power plug from
the power outlet when the
appliance is not in use.
• The place where it may be splashed with
water or near a heat source.
• The place with an uneven surface or on
non-heat-resistant carpet.
• Near a wall or furniture. (It may cause a
discoloration or deformation.)
• Do not expose the power plug with steam when it
is plugged in. (It may cause a short circuit or fire.)
When using a cabinet with sliding table, use the
appliance where the power plug cannot be
exposed to steam.
(Otherwise it may cause an
electric shock, short circuit,
resulting in fire.)
(It may cause an electric
shock, leak, and fire.)
(Touching hot elements may
cause a burn.)
Especially the
heating plate (It may
cause a burn.)
(It may cause the
outer lid to open,
resulting in a burn.)
(It may cause a
burn.)
(It may cause a
burn and injury due
to overheat or
malfunction.)
(Otherwise it may cause an
electric shock and fire caused
by a short circuit due to the
insulation deterioration.)
5
Before use
Power cord
Rice
scoop (1)
Steaming
basket (1)
Measuring cup
(about 180 mL) (1)
Please clean the accessories before using.
Accessories
160
120
80
40
Parts identification
Control panel
Entire unit
Body
Control panel
Hook button
Outer lid
Heating plate
Pan
Pan seal ring
Moisturizing cap
Handle
(both sides)
Press this button for
quick cooking or steam
cooking.
Press this button for
cooking of rice.
Press this button for
cooking of porridge
or soup.
Press this button for
keep warm function.
This warm jar has no touch
sound or end sound.
Quick Cook/Steam
Brown Rice
Off
Keep
Warm
Porridge/Soup
FUZZY MICROCOMPUTER
White Rice
Press this button for
cooking of brown rice.
Press this button to
cancel the previous
operation or stop keep
warm function.
6
Rice quantity
(measuring cups)
Water quantity (measuring cup provided)
Mixed rice Glutinous rice
1
2
3
4
5
Attentions
The above water quantities can be increased
or decreased according to personal preference.
1.0 L Model
1
2
4
---
---
1.8 L Model
1
2
4
5
6
3
/
4
1.0 L Model
1
2
3
---
---
1.8 L Model
1
2
3
4
5
(Example: 1.8 L Model)
The cooking result
may be affected
Correct
Model No.
Maximum
cooking volume
Maximum cooking volume (measuring cup provided)
3
/
4
1
/
4
Preparations
Measure rice with the measuring cup provided
1
●
The volume of the measuring cup is about 180 mL (150 g).
●
Maximum quantity of rice to be cooked at once P13.
●
When using 1.8 L Model for quick cooking of rice or cooking of long-shaped
rice, please keep the maximum quantity of rice within 8 cups.
Wash the rice till the water turns relatively clear
2
Place the washed rice into the pan
3
Add water until the corresponding waterline and dry the outside of the pan.
●
When adding water, pay attention to the scales at both
sides and keep them at the same height.
● When stewing soup, the total volume of ingredients and
water shall not exceed the maximum waterline for “PORRIDGE”.
●
When cooking mixed rice or glutinous rice, please add
water according to the following table.
4
Attentions
Put the pan into the body and close the outer lid
●
In order that the pan bottom can be closely attached
to the cast heater, please rotate the pan along the
direction indicated by the arrow for 2 or 3 times.
●
Please check whether the moisturizing cap is correctly positioned. ( P12)
●
When closing the outer lid, please confirm that there is a “click” sound.
5
Connect the plugs
● Please connect the instrument plug to the body first
and then connect the power plug. Make sure that both
plugs are firmly connected.
1
/
4
1
/
4
1
/
2
1
/
2
Body
Instrument
plug
Power plug
Outlet
1.0 L Model 1.8 L Model
2 5
* When using the steaming basket while
cooking rice, please refer to the table
on the right for the maximum cooking
volumes.
<Example>
When the rice quantity is 6
measuring cups, wash the rice
and put into the pan, then add
water into the pan till the water
surface reaches scale “6” at
waterline of “WHITE RICE”.
①Wash the rice quickly with plenty of water and stirring the rice lightly to
wash it while changing water.
②
Repeat for several times [wash the rice→pour out water], till the water turns relatively clear.
●
In order to avoid scratching the non-stick coating on the pan surface, do
not wash rice in the pan.
●
Wash the rice thoroughly. Otherwise, rice crust may appear and the residual rice
bran may affect the taste of the rice.
Usage
WHITE RICE CUP
BROWN
RICE
PORRIDGE
10
8
6
4
2
6
4
2
2
1
1
1/2
1/2
7
Functions Quick Cook/Steam
Kind reminder
The indicator
lights up
Press [Off] button
The indicator
turns off
1
2
2
● No sound when the cooking process is over.
● At this time, the steaming basket is very hot.
Please be careful when taking it out.
Operations
(For example: steam with [Quick Cook/Steam] function)
The cooking is over
Quick Cook/Steam
Brown Rice
Off
Keep
Warm
Porridge/Soup
FUZZY MICROCOMPUTER
White Rice
●
When steaming food at same time as cooking
rice, please select [White Rice] function.
●
The time of steam shall be determined
according to the water quantity in the
pan. Please adjust the water quantity
according to the time required.
●
After the water gets boiled and fully
evaporated, the warm jar will turn to the
keep warm function automatically.
●
If you want to stop steam function
during cooking, press [Off] button.
●
[Quick Cook/Steam] button can be used for
quick cooking rice, please refer to P7
[White Rice] for detailed operations. As the
cooking time is shortened, the rice may be
harder or there may be rice crust.
●
After the water in the pan gets boiled and
fully evaporated, the steaming function is
ended and the warm jar will turn to keep
warm function automatically.
1
●
The indicator for [Quick Cook/Steam] lights up
and the steaming starts.
The indicator lights up
Water
Steaming
basket
Press [Quick Cook/Steam]
button
Table of steaming time and water quantity. The entire duration from the start to
the end refers to the time shown in the following table.
*
The maximum time of steaming is about 70 minutes. When the time is up, no matter the water
is completely evaporated or not, the warm jar will turn to keep warm function automatically.
Steaming time (approx.)
1 Measuring cup 2 Measuring cups
3 Measuring cups
15 Minutes
30 Minutes 50 Minutes 65 Minutes
1
/
2
Measuring cup
Water quantity (approx.)
●
Add a proper quantity of water (refer to the
following table).
●
Put the steaming basket into the pan.
●
Put the foods to be steamed into the steaming
basket.
●
Close the outer lid.
Quick Cook/Steam
Keep
Warm
Keep
Warm
8
Functions White Rice • Keep Warm
1
●
The indicator for [White Rice] lights
up and the cooking starts.
The indicator lights up
The indicator lights up
Press [White Rice] button
Loosen the rice
Quick Cook
White Rice
About 30 minutes
About 38 minutes
Cooking time (reference)
●
●
●
●
●
●
Keep Warm
Operations
( For example: cook rice with [White Rice] function)
Kind reminder
1
●
Menu
Brown Rice, Mixed
rice, Glutinous rice
Porridge
Keep
warm
○
×
×
Affect the taste or
cause strange smell
Rice from getting
thicker
The result after
kept warm
The cooking is over
●
When cooking mixed rice or
glutinous rice, please select
[White Rice] function. For water
quantity, please refer to P5.
●
Rice cooked with [White Rice]
function can be softer and has a
better taste.
The reference time required for cooking at the voltage of 120 V, the room temperature
of 20°C, the water temperature of 18°C and the medium rice quantity refers to the
time listed in the left table. (1.0 L Model: 3 cups, 1.8 L model: 5 cups)
The cooking time may vary slightly according to different voltages, room
temperatures, water temperatures, water quantities, rice quantities and rice qualities.
The cooking time of mixed rice or glutinous rice may vary because
of the different ingredients added into the rice.
●
When the cooking process is over, the warm jar will turn to
keep warm function automatically. To prevent the rice from
sticking together, please loosen the rice after cooking.
●
No sound when the cooking process is over.
When the cooking process is over, all functions will turn to keep
warm function automatically. But some functions are not
recommended to use keep warm function, when the cooking
process is over, please press [Off] button after cooking.
You can enjoy the rice within 5 hours in keep warm function,
so as not to affect the taste or cause strange smell.
When in keep warm function, there may be some
droplets at the edge of the pan.
The rice taste may be affected if the rice scoop is left in
the warm jar when the rice is in keep warm function.
Quick Cook/Steam
Brown Rice
Off
Keep
Warm
Keep
Warm
Porridge/Soup
FUZZY MICROCOMPUTER
White Rice
White Rice
Quick Cook,
White Rice, Soup
Usage
9
Functions Brown Rice
1
●
The indicator for [Bronw Rice] lights up and
the cooking starts.
The indicator lights up
Press [Brown Rice] button
Loosen the rice
Brown
Rice
About 1 hour
and 50 minutes
Cooking time
(reference)
●
●
Operations
(For example: cook rice with [Brown Rice] function)
Kind reminder
●
Do not use keep warm function
for brown rice, so as not to
affect the taste.
1
The cooking is over
Brown Rice
The reference time required for cooking at the voltage of 120 V,
the room temperature of 20°C, the water temperature of 18°C
and the medium rice quantity refers to the time listed in the left
table. (1.0 L Model: 2 cups, 1.8 L model: 3 cups)
The cooking time may vary slightly according to different
voltages, room temperatures, water temperatures, water
quantities, rice quantities and rice qualities.
●
When the cooking process is over,
the warm jar will turn to keep warm
function automatically. However, keep
warm function is not recommended to
prevent from affecting the taste,
press [Off] button after cooking.
●
No sound when the cooking process
is over.
Quick Cook/Steam
Brown Rice
Off
Keep
Warm
Porridge/Soup
FUZZY MICROCOMPUTER
White Rice
The indicator
lights up
The indicator
turns off
Keep
Warm
Keep
Warm
10
Functions Porridge/Soup
1
●
The indicator for [Porridge/Soup] lights up and the
cooking starts.
●
Reference cooking time (approx.): 1 hour and 30 minutes.
The indicator lights up
Press [Porridge/Soup] button
Kind reminder
1
Press [Off] button
2
2
When the maximum cooking volume of soup (ingredients and
water) exceeds the maximum waterline for “PORRIDGE”,
overflow or half-cooked soup may occur. (Refer to P13
for specifications)
Operations (For example: when cooking porridge with [Porridge/Soup] function)
The cooking is over
●
Incorrect water quantity or rice quantity
may lead to overflow of rice water from
the steam vent.
●
When the outer lid is opened in cooking,
the amount of moisture condensation
may be increased.
●
When the porridge is kept in keep warm
function for an excessively long time, it
will get thicker.
●
Each time after use, take off and clean
the moisturizing cap so as to prevent
any strange smell.
The indicator
lights up
The indicator
turns off
Keep
Warm
Keep
Warm
●
After the cooking process is over, the
warm jar will turn to keep warm
function automatically.
However, keep warm function is not
recommended to prevent from affecting
the taste, press [Off] button after cooking.
●
No sound when the cooking process is
over.
Quick Cook/Steam
Brown Rice
Off
Keep
Warm
Porridge/Soup
White Rice
FUZZY MICROCOMPUTER
Porridge/Soup
11
Usage
Recipes
Mixed Chicken Rice
Ingredients: Seasoning:
Rice 3 measuring cups Cooking wine, soy sauce 20 mL each
Water 4 measuring cups Salt 3 g
Chicken 80 g, chopped into small pieces
Burdock 35 g, sliced
Mushroom 2 pieces, after soaking in water, remove
the base and shred into strips
Fried bean curd 2 pieces, pour with hot water to remove
grease and then shred into strips
Carrot 40 g, shredded into strips
Cooking method:
1) Boil the chicken and burdock in hot water quickly and drain them immediately.
2) Wash the rice, put into the pan and add 4 measuring cups of water.
3) Pour the seasoning into the pan, stir and put the remaining ingredients in. Close the outer lid.
4) Press [White Rice] button to start cooking. When the cooking process is over, you can enjoy
the meal.
Caution: · Because of the different ingredients added into the rice, there may be
scorched rice at the bottom.
· In this recipe, the cooking volume is for 1.8 L Model. Please refer to the
specifications listed on P13 for cooking volumes for 1.0 L Model.
· 1 cup (measuring cup): about 150 g.
Corn and Rib Soup
Ingredients: Seasoning:
Ribs 500 g, chopped into 5cm pieces Salt 6.5 g
Corn 2, about 450 g, cut into 5cm pieces
Water
Amount of water for scale 5 waterline
of “White Rice”
Cooking method:
1) Put the ribs into boiling water to remove residual blood and drain them for later use.
2) Put all ingredients into the pan, add salt and close the outer lid.
3) Press [Porridge/Soup] button, and the cooking process will end after about 1 hour and 30 minutes.
(Other seasoning such as chicken powder can be added according to personal preference.)
12
Dim Sum (frozen)
Ingredients:
(A) Small pieces
Shrimp dumplings
Sumai
Cooking method:
1) Defrosting is not required. Just put the frozen Dim Sum on the steaming basket and spray some
water on the surface of Dim Sum.
2) Add 1/2 measuring cup of cold water into the pan.
3) Put the steaming basket into the pan and close the outer lid.
4) Press [Quick Cook/Steam] button, wait for about 10 minutes and then press [Off] button.
(B) Big pieces
Steamed BBQ pork buns
Steamed buns
Sticky rice in lotus leaf
Recipes
Mung Bean and Lilium Porridge
Ingredients: Seasoning:
Mung bean 70 g Sugar According to personal preference
Sticky rice 70 g
Lilium 10 g
Cooking method:
1) Put the washed mung beans, sticky rice and lilium into the pan and add water until scale 1 of
waterline for “PORRIDGE”.
2) Close the outer lid and press [Porridge/Soup] button. The cooking process will end after
about 1 hour and 30 minutes.
3) Add some sugar according to personal preference and enjoy the meal.
Usage
13
●
Before cleaning and maintenance, please pull out the power plug first. Do not clean the warm jar until it cools down.
●
When cleaning the warm jar, do not immerse it into water, or clean it with lacquer thinner, alcohol, cleaning powder or hard brush, etc.
●
Do not use dishwasher.
Temperature sensor
•
Cast heater
Pan
●
●
●
●
●
●
Clean with diluted detergent and soft sponge.
Accessories
Rice scoop
Measuring cup
160
120
80
40
Steaming basket
Moisturizing cap
Disassembling
Pull out from the
heating plate.
Cleaning and maintenance
Attentions
●
Clean with diluted detergent and soft sponge. Wipe off any
water on the pan.
●
Color change or stripes may appear on the fluoridized
coating surface, which will not affect human health or
normal functions of the warm jar.
●
Depending on the frequency of use, rubbing traces
may appear on the outside of the pan, which will not
affect the performance of the warm jar.
●
When there is any foreign object adhering to such parts, gently
scrub it away with fine crocus paper (#600) or a dry cloth.
●
Seal ring
Entire unit
●
Outer lid (sealed part)
Assembling
Insert into the hole on the
heating plate in a reverse
direction as disassembly.
Please fully insert it into the
hole to prevent falling off.
Caution
●
The moisturizing cap can be taken off directly.
Clean it after each use.
●
After cleaning, do not dry it with a dishwasher etc.;
otherwise deformation or crack may be caused.
●
When installing it after cleaning, please make
sure that the seal ring has been installed on the
moisturizing cap.
Clean with a well-wrung cloth.
●
If foreign objects are not removed, the foreign objects on the
heating plate may stick to it and become difficult to remove.
Clean the heating plate after each use. As the metal parts
are heated, there may be color change or stripes on their
surfaces, which will not affect their normal functions.
●
Do not pull the pan seal ring.
14
Items for check
In the following events
Rice
Rice kept warm
Harder
Half-
cooked
Softer
Color
change
Dry
Strange
smell
Rice crust
scorched
Button
operations
do not work
The plug is pulled out or gets loose.
When there
are
[pop] sounds in cooking, water
drops at the bottom of the pan (outside) and gets
broken after being heated. This is not a malfunction.
When there are [click] sounds in cooking, the
cast heater is adjusting the temperature, this
is not a malfunction.
The
following
sounds
appear
during the
use
Rice water
overflow
● ● ●
Troubleshooting
Please check the following items
Model No.
Power/rated frequency
Power cord length (approx.) m
1.0
Product weight (approx.) kg
Rated power (rice cooking)
Width
Length
Height
Dimensions
(approx.) cm
Maximum cooking volume (ingredients + water) for soup L
White Rice/Quick Cook
Mixed rice/Glutinous rice
750 W
0.09~0.36
[1/2~2 cups]
24.7
2.3
0.18~1.8 [1~10 cups]
Quick Cook [1~8 cups]
0.18~0.9
[1~5 cups]
SR
-
DF181
24.5
33.9
19.9
1.5
0.18~1.0 [1~5.5 cups]
0.18~0.54
[1~3 cups]
Brown Rice
0.18~1.08
[1~6 cups]
0.18~0.54
[1~3 cups]
0.09~0.18
[1/2~1 cup]
SR
-
DF101
Rice cooking
volume
(rice quantity) L
Porridge cooking volume (rice quantity) L
Specifications
2.5 2.8
Rated volume of pan L
3
4.8
120 V ~ 60 Hz
●
Marked with , it means that the maximum cooking volume for soup is the highest
waterline for “PORRIDGE”.
●
For power cord replacement and product repairing, please contact the authorized
service center of Panasonic.
●
The design and specifications are intended to change without prior notice.
●
Incorrect rice quantity or water quantity
● Rice is not fully washed
● The pan bottom is uneven
●
There are foreign objects on the outside
of the pan or temperature sensor
● The outer lid is not correctly closed
●
The moisturizing cap is not correctly installed
● Grease is added when cooking the rice
●
After cooking is finished, the rice is not loosen
● Keep warm over 5 hours
●
The quantity of rice kept warm is too small
● The rice scoop is left in the warm jar
when the rice is kept warm
● The cold rice is kept warm
● The outer lid is not firmly closed
● The pan is not cleaned
● While in cooking, the plug is pulled out
or the [Off] button is touched
● The wrong button is pressed
15
In Trouble
