ExpertResults
7000
1
2
11
4
3
5
6
7
8
9
10
1
English 6
English
IMPORTANT
SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE USE
When using electrical products, especially when children are
present, basic safety precautions should always be followed,
including the following:
DANGERS
To reduce the risk of electrocution:
1 Always place and store the charger at a safe distance from
water.
2 Do not reach for a product that has fallen into water. Unplug
immediately.
3 Never use a charger with a damaged cord or plug.
WARNINGS
To reduce the risk of burns, electrocution, fire or physical injury:
1 Do not clean the brush head, the handle or the charger in the
dishwasher.
2 Do not use attachments other than those recommended by
the manufacturer.
3 Do not plug into an outlet with a voltage other than specified
on the bottom of the product. This product is designed to
operate within a range of 100 to 240 volts. Voltage converters
do not warrant voltage compatibility.
4 Never force the plug into an outlet; if the plug does not easily
fit into the outlet, discontinue use.
6
English
5 Discontinue use if the product appears damaged in any way
(brush head, handle or charger, etc.).
6 The power cord cannot be replaced. If the power cord is
damaged, discard the charger.
7 Keep the cord away from heated surfaces.
8 Do not use the base charger outdoors or near heated
surfaces.
9 This product contains no user-serviceable parts. Refer to
‘Warranty and support’ if the product no longer works
properly or needs repair.
10 Keep the Philips Sonicare out of direct sunlight.
11 Use this product only for its intended use as described in this
document or as recommended by your dental professional.
12 This product is not intended for use by persons (including
children) with reduced physical, sensory, or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
13 Children should be supervised to ensure that they do not
play with the product.
14 Philips Sonicare is a personal care device and is not intended
for use on multiple patients in a dental office or institution.
15 The product is not intended to be repaired by service
personnel in case of failure or component defect (unit can be
thrown away).
16 For connection to a supply not in the U.S.A., use a charger of
the proper configuration for the power outlet.
17 Use a UL listed computer, USB Hub, or USB duplex receptacle
when charging the handle in the travel case.
7
English
18 This appliance has only been designed for cleaning teeth,
gums and tongue. Do not use it for any other purpose. Stop
using the appliance and contact your doctor if you
experience any discomfort or pain.
19 Avoid direct contact with products that contain essential oils
or coconut oil. Contact may result in bristle tufts dislodging.
MEDICAL WARNINGS
1 Consult your dental professional before you use this product
if you have had oral or gum surgery in the previous 2 months.
2 Contact your dental professional if excessive bleeding occurs
after using this product or bleeding continues to occur after 1
week of use.
3 Discontinue use of this product and contact a
physician/dentist if discomfort or pain is experienced.
4 This product complies with the safety standards for
electromagnetic devices. If you have a pacemaker or other
implanted device, contact your physician or the device
manufacturer prior to use.
5 Consult your physician if you have other medical concerns.
SAVE THESE
INSTRUCTIONS
Introduction
Congratulations on your new Philips Sonicare power
toothbrush! Superior plaque removal, whiter teeth, and
healthier gums are at your fingertips. Using Philips Sonicare's
combination of gentle sonic technology and clinically
developed and proven features, you can be confident that you
are getting the very best clean, every time. Further support and
8
English
product registration are available to you at:
www.philips.com/welcome
Welcome to the Philips Sonicare family!
Intended use
ExpertResults series power toothbrushes are intended to
remove adherent plaque and food debris from the teeth to
reduce tooth decay and improve and maintain oral health.
ExpertResults series power toothbrushes are intended for
consumer home use. Use by children should be with adult
supervision.
Your Philips Sonicare (Fig. 1)
1 Hygienic travel cap
2 Smart brush head(s)*
3 Handle
4 Power on/off button
5 Intensity light
6 Mode/intensity button
7 Modes
8 Brush head replacement reminder light
9 Battery indication
10 Charger
11 Travel case
*Note: The content of the box may vary based on the model
purchased.
Using your Philips Sonicare
Brushing instructions
1 Push the brush head firmly onto the handle.
9
English
Note: It is normal to see a slight gap between the brush head
and the handle.
2 Wet the bristles and apply toothpaste.
3 Place the toothbrush bristles against the teeth at a slight
angle (45 degrees), pressing firmly to make the bristles reach
the gumline or slightly beneath the gumline.
45°
Note: Keep the center of the brush in contact with the teeth
at all times.
4 Press the power on/off button to turn on the Philips
Sonicare.
5 Apply light pressure to maximize Philips Sonicare’s
effectiveness and let the Philips Sonicare toothbrush do the
brushing for you. Gently move the brush head slowly across
the teeth in a small back and forth motion so the longer
bristles reach between your teeth. Continue this motion
throughout the brushing cycle.
10
English
Note: To learn how to brush with specific modes, see ‘Modes’.
Note: The bristles should slightly flare. Do not scrub.
Note: A change in sound and vibration from the handle alerts
you when you apply too much pressure while brushing.
Note: Your handle will briefly pause its vibration when its time
to brush the next section, see 'QuadPacer'.
6 To clean the inside surfaces of the front teeth, tilt the brush
handle semi-upright and make several vertical overlapping
brushing strokes on each tooth.
Your Philips Sonicare toothbrush is safe to use on:
-
Braces (brush heads wear out sooner when used on braces)
-
Dental restorations (fillings, crowns, veneers)
Brush heads
Your brush heads
To see what type of brush head you have, check the brush head
label at the bottom.
11
English
W
C
3
Brush head name
DiamondClean Premium Plaque
Control
Brush head label
W C3
Benefit
Stain removal Plaque removal
To explore our full range of brush heads, go to
www.philips.com/toothbrush-heads for more information.
BrushSync Technology (Oslo)
BrushSync technology enables your brush heads to
communicate with your handle using a microchip. The symbol at
the bottom of the brush head indicates that it is equipped with
the BrushSync technology.This enables the following features:
-
Brush head mode pairing
-
Brush head replacement reminder
12
English
Brushing modes
Your power toothbrush is equipped with 3 different modes:
Clean, White, and Gum Care. Based on the smart brush head
you use, the mode will be selected automatically. To manually
change the mode, press the mode/intensity button while the
toothbrush is off.
Clean White Gum Care
Benefit
Plaque
removal
Plaque and
surface stains
removal
Plaque
removal and
gum massage
Re-
commended
brush head
Premium
Plaque
Control (C3)
Diamond
Clean (W)
Optimal Gum
Care (G2)
Re-
commended
intensity level
3 3 3
Total
brushing time
2 minutes 2 minutes and
30 seconds
3 minutes
13
English
Clean White Gum Care
How to brush
Brush each
quadrant for
30 seconds
2
4
3
1
Brush each
quadrant for
30 seconds,
2
4
3
1
then brush
the front top
and bottom
teeth for an
additional 30
seconds.
1
2
Brush each
quadrant for
30 seconds,
2
4
3
1
then brush
along the
gumline for an
additional
minute.
Note: After you have completed the brushing cycle, you can
spend additional time brushing the chewing surfaces of your
teeth and areas where staining occurs. You can also brush your
tongue, with the toothbrush turned on or off, as you prefer.
Note: All brush heads work with each mode.
Note: When the Philips Sonicare is used in clinical studies, it
must be used in the Clean mode (for plaque and gum claims) or
14
English
in White mode (for whitening claims), at high intensity, with the
EasyStart feature turned off.
Intensity settings
Your power toothbrush comes with 3 different intensity levels:
low, medium and high. When attached to the handle, the smart
brush head will automatically select the recommended
intensity. To manually change the intensity, turn on the handle
and press the mode/intensity button.
Features
-
EasyStart
-
Brush head replacement reminder
-
Pressure sensor
-
Brush head mode pairing
-
QuadPacer
EasyStart
The EasyStart feature gently increases the power of the handle
over the first 14 brushings to help you get used to the brushing
power of the Philips Sonicare.
The EasyStart feature works with all modes.
Note: The EasyStart feature comes deactivated with your
product. To activate EasyStart, see 'Activating or deactivating
features'.
Brush head replacement reminder
The handle will track the wear of your brush head. It measures:
-
The pressure you apply when you brush
-
The time you have brushed with the brush head
15
English
Once your brush head is no longer effective, the brush head
replacement reminder will blink amber. This indicates that it is
recommended to change your brush head.
Note: The brush head replacement reminder comes activated
with your product. To deactivate this feature, see 'Activating or
deactivating features'.
Pressure sensor
Your Philips Sonicare measures the pressure you apply while
brushing to protect your gums and teeth from damage.
If you apply too much pressure, the handle will change its
vibration until you reduce the pressure.
Note: The pressure sensor comes activated with your product.
To deactivate this feature, see 'Activating or deactivating
features'.
Brush head mode pairing
Brush heads with BrushSync technology are equipped with an
RFID chip. The chip communicates to the handle and
automatically pairs it with the recommended mode and
intensity.
Note: If you change modes/intensity, the handle will remember
the last used setting. If you wish to brush with the
recommended setting, you can find the recommended
modes/intensity in ‘Brushing Modes’.
16
English
QuadPacer
The QuadPacer feature indicates via a brief change in vibration
when you are supposed to move onto the next brushing
section.
The toothbrush will automatically turn off at the end of the
brushing session.
Charging and battery status
Charging
1 Plug the charger into an electrical outlet.
2 Place the handle on the charger.
3 The charging indicator will flash green until your toothbrush
is fully charged.
Battery status (handle on plugged-in charger)
When placed on the charger, the battery light will flash green
based on the current battery level.
LED color
Battery charging status
Flashing green Charging
Solid green Fully charged
Off Fully charged and in sleep
mode
When placing the handle on the charger:
-
The handle will emit 2 short beeps to confirm the handle is
placed properly and the handle starts charging.
-
The battery light will flash green to indicate it is charging.
-
The handle will show solid green when it is fully charged. In
order to preserve the charge, the green light will switch off 30
seconds after the charging process is complete.
17
English
Battery status (when handle is not placed on charger)
When removing the handle from the charger, the battery light at
the bottom of the handle will indicate the status of the battery.
LED color
Number of beeps Status
Solid green n/a Full
Flashing green n/a Medium
Flashing amber 3 Low
Flashing amber 5 Battery empty
Note: Your toothbrush comes pre-charged for first use. After
first use, charge for at least 24 hours.
Note: It is OK to leave the handle on the plugged in charger in
between brushings. This will not impact the battery life
negatively.
Activating or deactivating features
You can activate or deactivate the following features of your
toothbrush:
-
EasyStart
-
Brush head replacement reminder
-
Pressure sensor
1 Place the handle on the charger.
2 Press and hold the power button for:
Feature
Press the power button for
EasyStart 3 seconds
18
English
Brush head replacement
reminder
Up to 5 seconds
Pressure sensor Up to 7 seconds
3 Let go of the power button when you hear:
Feature
You will hear
EasyStart 1 beep
Brush head replacement
reminder
1 beep then 2 beeps
Pressure sensor 1 beep, 2 beeps then 3
beeps
If you see the brush head replacement reminder and the battery
indicator lights flashing green and hear low to high triple tones,
then the feature had been activated.
OR
If you see the brush head replacement reminder and the battery
indicator lights flashing amber and hear high to low triple
tones, then the feature had been deactivated.
19
English
Cleaning
Caution: Unplug the charger before you clean it.
Caution: Do not use essential oils to clean the brush heads as
this can cause damage.
20
English
Caution: Do not use isopropyl rubbing alcohol, vinegar or
bleach to clean the handle as this may cause discoloration.
Caution: Do not push on the rubber seal at the top of the
handle.
Locating the model number
Look on the bottom of the Philips Sonicare toothbrush handle
for the model number (HX751x).
Disposal
This appliance contains a rechargeable battery which must be
disposed of properly. Contact your local town or city officials for
battery disposal information. You can also call
1-800-8-BATTERY or visit www.rbrc.com for battery drop-off
locations.
For assistance, visit our website www.philips.com/support.
Removing the rechargeable battery at the end of
lifetime
Warning: Only remove the rechargeable battery when you
discard the appliance. Make sure the battery is completely
empty when you remove it. Any attempt to remove the
battery will void the warranty.
To remove the rechargeable battery, you need a towel or cloth,
a hammer and a flat-head (standard) screwdriver. Observe basic
safety precautions when you follow the procedure outlined
21
English
below. Be sure to protect your eyes, hands, fingers, and the
surface on which you work.
1 Remove and discard the brush head.
2 Deplete the battery until the handle no longer turns on.
3 Cover the entire handle with a towel or cloth.
1
2
4 Hold the top of the handle with one hand.
5 With your other hand, use your hammer to strike the handle
0.5 inches above the bottom end on all sides to eject the end
cap.
Note: You may have to strike it several times to break the
internal cap connections.
6 Remove the end cap. If the end cap does not release easily,
repeat step 3 until the end cap is released.
22
English
7 Holding the handle upside down with a cloth or towel, push
the handle down on a hard surface. If the internal
components do not easily release from the housing, repeat
step 3 until the internal components are released.
8 Remove the rubber battery cover with a screwdriver.
9 Wedge the screwdriver between the battery and the internal
black frame towards the bottom to separate them.
23
English
10 Insert the screwdriver between the bottom of the battery and
the black frame to break the metal tab connecting the
battery to the green printed circuit board. This will release the
bottom end of the battery from the frame.
11 Grab the battery and pull it away from the internal
components to break the second metal battery tab.
Caution: Be aware of the sharp edges of the battery tabs so
as to avoid injury to your fingers.
12 Cover the battery contacts with tape to prevent any electrical
shock from residual battery charge. The rechargeable battery
can now be recycled and the rest of the product discarded
appropriately.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable standards
and regulations regarding exposure to electromagnetic fields.
Radio Equipment Directive
-
Radio Equipment in this product operates at 13.56 MHz
-
Maximum RF power transmitted by the Radio Equipment is
30.16dBm
24
English
Frequently asked questions
Question
Answer
Is my Philips Sonicare
toothbrush water resistant?
Yes. However, do not fully
submerge the handle in liquid
for an extended period of
time.
How often should I clean the
connection between the brush
head and the handle?
It is recommended to clean
this after each brushing, or at
least once a week.
Can I leave my Philips
Sonicare toothbrush on the
charger between brushings?
Yes, you can always keep your
Philips Sonicare toothbrush
on a plugged-in charger. This
will not affect the battery
lifetime.
How often can I use my Philips
Sonicare toothbrush per
charge?
Your Philips Sonicare
toothbrush should last 2-3
weeks with standard
brushings (2x/day) with a full
battery. You do not have to
charge your Philips Sonicare
toothbrush on a daily basis.
Warranty and support
Philips warrants its products for two years after the date of
purchase. Defects due to faulty materials and workmanship will
be repaired or replaced at Philips’ expense provided that
convincing proof of purchase in the qualifying period is
provided. Philips recommends use of genuine Sonicare brush
heads for optimal performance. Use of other brush heads may
25
English
damage your Sonicare toothbrush and limit your warranty
protection. Contact our Consumer Care Center at
1-800-682-7664 (North America), outside North America
contact your local Philips Consumer Care Center. Internet
information: www.sonicare.com (North America) or
www.philips.com/support (outside North America).
WARRANTY EXCLUSIONS
What is not covered under warranty:
-
Brush heads.
-
Damage caused by use of unauthorized replacement parts or
unauthorized brush heads.
-
Damage caused by misuse, abuse, neglect, alterations or
unauthorized repair.
-
Normal wear and tear, including chips, scratches, abrasions,
discoloration or fading.
IMPLIED WARRANTIES
ANY IMPLIED WARRANTIES, INCLUDING IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, SHALL BE LIMITED TO THE DURATION OF THE
EXPRESS WARRANTIES SET FORTH ABOVE. IN SOME STATES
LIMITATIONS ON DURATION OF IMPLIED WARRANTIES DO
NOT APPLY.
LIMITATION OF REMEDIES
IN NO EVENT SHALL PHILIPS OR ANY OF ITS AFFILIATED OR
SUBSIDIARY COMPANIES BE LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES BASED UPON
BREACH OF WARRANTY, BREACH OF CONTRACT,
NEGLIGENCE, TORT, OR ANY OTHER LEGAL THEORY. SUCH
DAMAGES INCLUDE, WITHOUT LIMITATION, LOSS OF SAVINGS
OR REVENUE; LOSS OF PROFIT; LOSS OF USE; THE CLAIMS OF
THIRD PARTIES INCLUDING, WITHOUT LIMITATION, DENTISTS
26
English
AND DENTAL HYGIENISTS; AND COST OF ANY SUBSTITUTE
EQUIPMENT OR SERVICES. SOME STATES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
27
English
www.philips.com/Sonicare
©2018 Koninklijke Philips N.V. (KPNV). All rights reserved. Philips
and the Philips shield are trademarks of KPNV. Sonicare and the
Sonicare logo are trademarks of Philips Oral Healthcare, LLC
and/or KPNV.
4235.021.6283.3 (10/25/2018)
Product Support:
www.philips.com/support
(Chat Available 24/7)
Register Your Product:
www.sonicare.com/register
>75 % recycled paper
>75 % papier recyclé
