Washing Machine

User’s Manual

BFL853ADW

Document Number=

This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN

Washing Machine / User’s Manual

1 General safety instructions

This section contains safety instructions that will help protect from risk of

personal injury or property damage. Failure to follow these instructions shall

void any warranty.

1.1 Life and property safety

Never place the product on a carpet-covered floor. Otherwise, lack of airflow

beneath the machine will cause electrical parts to overheat. This will cause

problems with your product.

Unplug the product if it is not in use.

Always have the installation and repairing procedures carried out by the

Authorized Service Agent. The manufacturer shall not be held liable for

damages that may arise from procedures carried out by unauthorised

persons.

The water supply and draining hoses must be securely fastened and remain

undamaged. Otherwise, there is the risk of water leakage.

While there is still water inside the product, never open the loading door or

remove the filter. Otherwise, risk of flooding and injury from hot water will

occur.

Do not force open the locked loading door. The door will open immediately

after the washing cycle has ended. If the door does not open, apply the

solutions provided for "Loading door cannot be opened." error in the

Troubleshooting section. In case of forcing the loading door to open, the

door and the lock mechanism may get damaged.

Use detergents, softeners and supplements suitable for automatic washing

machines only.

Follow the instructions on the label of textile products and the detergent

package.

1.2 Children's safety

This product can be used by children at and above 8 years old and by persons

whose physical, sensory or mental capabilities were not fully developed or

who lack experience and knowledge provided that they are supervised or

trained on the safe usage of the product and the risks it brings out. Children

should not play with the product. Cleaning and maintenance works should

not be performed by children unless they are supervised by someone.

Children under the age of 3 should be kept away unless continuously

supervised.

Packaging materials are dangerous for the children. Keep packaging

materials in a safe place away from reach of the children.

4 / EN

Washing Machine / User’s Manual

Electrical products are dangerous for the children. Keep children away from

the product when it is in use. Do not allow them to play with the product.

Use child lock to prevent children from intervening with the product.

Do not forget to close the loading door when leaving the room where the

product is located.

Store all detergents and additives in a safe place away from the reach of

the children by closing the cover of the detergent container or sealing the

detergent package.

1.3 Electrical safety

If the product has a failure, it should not be operated unless it is repaired by

the Authorized Service Agent! There is the risk of electric shock!

This product is designed to resume operating in the event of powering

on after a power interruption. If you wish to cancel the programme, see

"Cancelling the programme" section.

Plug the product into a grounded outlet protected by a 16 A fuse.

Do not wash the product by spraying or pouring water onto it! There is the

risk of electric shock!

Never touch the power cable plug with wet hands! Never unplug by pulling

on the cable. Always press on the plug with one hand and pull out the plug

by grabbing with the other hand.

Product should be unplugged during installation, maintenance, cleaning

and repair procedures.

If the power cable is damaged, it must be replaced by the manufacturer,

authorized service or a similarly qualified person (preferably an electrician)

or someone designated by the importer in order to avoid possible risks.

1.4 Hot surface safety

The glass of the loading door gets too hot while

washing at higher temperatures. Therefore,

especially do not allow children touch the

loading door glass while washing.

5 / EN

Washing Machine / User’s Manual

Important instructions for environment

2.1 Compliance with WEEE Directive

This product complies with EU WEEE Directive (2012/19/EU). This product bears a

classification symbol for waste electrical and electronic equipment (WEEE).

This product has been manufactured with high quality parts and materials which can be

reused and are suitable for recycling. Do not dispose of the waste product with normal

domestic and other wastes at the end of its service life. Take it to the collection center for

the recycling of electrical and electronic equipment. Please consult your local authorities to

learn about these collection centers.

Compliance with RoHS Directive:

The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain

harmful and prohibited materials specified in the Directive.

2.2 Package information

Packaging materials of the product are manufactured from recyclable materials in accordance with

our National Environment Regulations. Do not dispose of the packaging materials together with the

domestic or other wastes. Take them to the packaging material collection points designated by the local

authorities.

Intended use

•Thisproducthasbeendesignedfordomesticuse.Itisnotforcommercialpurposesorit

should not be used out of its intended use.

•Theproductmustonlybeusedforwashingandrinsingoflaundrythataremarked

accordingly.

•Themanufacturerwaivesanyresponsibilityarisenfromincorrectusageor

transportation.

6 / EN

Washing Machine / User’s Manual

4 Technical specifications

Supplier name or trademark Beko

Model name BFL853ADW

Rated capacity (kg) 8,5

Maximum spin speed (rpm) 1400

Built-in No

Height (cm) 84

Width (cm) 60

Depth (cm) 65

Net weight (±4 kg.) 75

Single Water inlet / Double Water inlet

•/-

•Available

Electrical input (V/Hz) 220-240 V / 50Hz

Total current (A) 10

Total power (W) 2000-2350

Main model code 978

Technical specifications may be changed without prior notice to improve the quality of the product.

7 / EN

Washing Machine / User’s Manual

4.1 Installation

• Preparationofthelocationandelectrical,tapwaterandwastewaterinstallationsattheplaceofinstallation

is under customer's responsibility.

• Makesurethatthewaterinletanddischargehosesaswellasthepowercablearenotfolded,pinchedor

crushed while pushing the product into its place after installation or cleaning procedures.

• Priortoinstallation,visuallycheckiftheproducthasanydefectsonit.Ifso,donothaveitinstalled.

Damaged products cause risks for your safety.

4.1.1 Appropriate installation location

• Placetheproductonahardandlevelfloor.Donotputitontoacarpetwithhighpileorothersimilar

surfaces.

• Whenthewashingmachineanddryerareplacedontopofeachother,theirtotalweight–whenloaded–

amounts to 180 kilograms. Place the product on a solid and flat floor that has sufficient load carrying

capacity!

• Donotplacetheproductonthepowercable.

• Donotinstalltheproductintheenvironmentswherethetemperaturefallsbelow0ºC.

• Leavingagapatthesidesofthemachineissuggestedtoreducevibrationandnoise

• Onagraduatedfloor,donotplacetheproductnexttotheedgeoronaplatform.

• DonotplaceheatsourcessuchasHobs,Irons,Ovens,etc.onthewashingmachineanddonotusethem

on the product.

4.1.2 Removing packaging reinforcement

Tilt the machine backwards to remove the packaging reinforcement.

Remove the packaging reinforcement by pulling the ribbon. Do not make

this operation alone by yourself.

4.1.3 Removing the transportation locks

1 Loosen all bolts with an appropriate wrench until they turn freely.

2 Remove the transport safety bolts by turning them slightly.

3 Insert the plastic covers in the bag containing the user manual to the openings on the rear panel.

CAUTION: Remove the transportation safety bolts before operating the washing machine! Otherwise, the product will be

damaged.

Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the

future.

Install the transport safety bolts in reverse order of the disassembly procedure.

Never move the product without the transportation safety bolts properly fixed in place!

8 / EN

Washing Machine / User’s Manual

4.1.4 Connecting water supply

Thewatersupplypressurerequiredtoruntheproductisbetween1to10bars(0.1–1MPa).Itisnecessarytohave

10–80litersofwaterflowingfromthefullyopentapinoneminutetohaveyourmachinerunsmoothly.Attachapressure

reducing valve if water pressure is higher.

CAUTION: Models with a single water inlet should not be connected to the hot water tap. In such a case the laundry will

get damaged or the product will switch to protection mode and will not operate.

CAUTION: Do not use old or used water inlet hoses on the new product. It may cause stains on your laundry.

1 Tighten the nuts of the hose by hand. Never use a tool when

tightening the nuts.

2 When hose connection is completed, check whether there is leak

problems at the connection points by opening the taps fully. If any

leaks occur, turn off the tap and remove the nut. Retighten the nut

carefully after checking the seal. In order to prevent the water leaks

and resultant damages, keep the taps closed when you do not use

the product.

4.1.5 Connecting the drain hose to the drain

• Attachtheendofthedrainhosedirectlytowastewaterdrain,lavatoryorbathtub.

CAUTION: Your drain house will be flooded if the hose comes out of its housing during water discharge. Moreover, there

is risk of scalding due to high washing temperatures! In order to prevent such situations and make sure that the machine

performs water intake and discharge processes without any problem, fix the drain hose securely.

40 cm

100 cm

•Connectthedrainhosetoaminimumheightof40cm

and a maximum height of 100 cm.

•Incasethedrainhoseiselevatedafterlayingitonthe

floor level or close to the ground (less than 40 cm above

the ground), water discharge becomes more difficult and

the laundry may come out excessively wet. Therefore,

follow the heights described in the figure.

• Topreventthewastewatertogobackintothemachineagainandtoensureeasydrainage,donotimmerse

the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too

long, cut it short.

• Theendofthehoseshouldnotbebent,itshouldnotbesteppedonandthehosemustnotbepinched

between the drain and the machine.

• Ifthelengthofthehoseistooshort,useitbyaddinganoriginalextensionhose.Lengthofthehosemay

not be longer than 3.2 m. To avoid water leak failures, the connection between the extension hose and the

drain hose of the product must be fitted well with an appropriate clamp as not to come off and leak.

9 / EN

Washing Machine / User’s Manual

4.1.6 Adjusting the feet

CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced

on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing

and vibration problems.

CAUTION: Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged.

1 Loosen the lock nuts on the feet by hand.

2 Adjust the feet until the product stands in a stable and balanced way.

3. Tighten all lock nuts by hand again.

4.1.7 Electrical connection

Connect the product to a grounded outlet protected by a 16 A fuse. Our company shall not be liable for any

damages that will arise when the product is used without grounding in accordance with the local regulations.

• Connectionmustcomplywithnationalregulations.

• Thewiringfortheelectricaloutletcircuitmustbesufficienttomeettheappliancerequirements.Useofa

Groud Fault Circuit Interrupter (GFCI) is recommended.

• Powercableplugmustbewithineasyreachafterinstallation.

• Ifthecurrentvalueofthefuseorbreakerinthehouseislessthan16Amps,haveaqualifiedelectrician

install a 16 Amp fuse.

• Thevoltagespecifiedinthe"Technicalspecifications"sectionmustbeequaltoyourmainsvoltage.

• Donotmakeconnectionsviaextensioncablesormulti-plugs.

CAUTION: Damaged power cables must be replaced by the Authorised Service Agents.

4.1.8 Initial use

Before starting to use the product make sure that the preparations are

made which are in line with the “Important Safety and Environment

Instructions” and the instructions in the “Installation” section.

To prepare the product for washing laundry, perform first operation

in Drum Cleaning programme. If this program is not available in your

machine, apply the method which is described in the section 4.4.2.

Use an anti-limescale suitable for the washing machines.

Some water might have remained in the product due to the quality control processes in the production. It is not harmful for

the product.

10 / EN

Washing Machine / User’s Manual

4.2 Preparation

4.2.1 Sorting the laundry

* Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature.

* Always observe the instructions given on the garment care labels.

4.2.2 Preparing laundry for washing

• Laundryitemswithmetalattachmentssuchas,underwiring,beltbucklesormetalbuttonswilldamagethe

product. Remove the metal pieces or wash such clothes by putting them in a laundry bag or pillow case.

•Takeoutallsubstancesinthepocketssuchascoins,pensandpaperclips,andturnpocketsinsideoutand

brush. Such objects may damage the product or cause noise problem.

• Putsmallsizeclothessuchasinfant'ssocksandnylonstockingsinalaundrybagorpillowcase.

• Placecurtainsinwithoutcompressingthem.Removecurtainattachmentitems.

• Fastenzippers,sewloosebuttonsandmendripsandtears.

• Wash“Machinewashable”or“Handwashable”labeledproductsonlywithanappropriateprogramme.

• Donotwashcoloursandwhitestogether.New,darkcolouredcottonsreleasealotofdye.Washthem

separately.

• Toughstainsmustbetreatedproperlybeforewashing.Ifunsure,checkwithadrycleaner.

• Onlyusethedyes/colorchangersanddescalingagentswhichareappropriateformachinewash.Always

follow the instructions on the package.

• Washtrousersanddelicatelaundryturnedinsideout.

• KeeplaundryitemsmadeofAngorawoolinthefreezerforafewhoursbeforewashing.Thiswillreduce

piling.

• Laundrythataresubjectedtomaterialssuchasflour,limedust,milkpowder,etc.intenselymustbeshaken

off before placing into the product. Such dusts and powders on the laundry may build up on the inner parts

of the product in time and can cause damage.

4.2.3 Tips for energy saving

Following information will help you use the product in an ecological and energy-efficient manner.

• Operatetheproductinthehighestloadcapacityallowedfortheprogrammeyouhaveselected,butdonot

overload. See, "4.3.3 Programme and consumption table."

• Observethetemperatureinstructionsonthedetergentpackaging.

• Washslightlysoiledlaundryatlowtemperatures.

• Usefasterprogrammesforsmallquantitiesoflightlysoiledlaundry.

• Donotuseprewashandhightemperaturesforlaundrythatisnotheavilysoiledorstained.

• Ifyouplantodryyourlaundryinadryer,selectthehighestspinspeedrecommendedduringwashing

process.

• Donotusemoredetergentthantherecommendedonthedetergentpackaging.

4.2.4 Loading the laundry

1. Open the loading door.

2. Put the laundry items into the product in a loose manner.

3 Push the loading door to close until you hear a locking sound. Ensure that no items are caught in the door.

The loading door is locked while a programme is running. The door lock will open immediately after the

washing programme has ended. Then you can open the loading door. If the door does not open, apply the

solutions provided for "Loading door cannot be opened." error in the Troubleshooting section.

4.2.5 Correct load capacity

The maximum load capacity depends on the type of laundry, the degree of soiling and the desired washing

programme.

The product automatically adjusts the water amount according to the weight of the laundry put inside it.

WARNING: Comply with the information in the section "4.3.3 Programme and consumption table". When overloaded,

product's washing performance will drop. Moreover, noise and vibration problems may occur.

11 / EN

Washing Machine / User’s Manual

4.2.6 Using detergent and softener

When using detergent, softener, starch, fabric dye, bleach and descaling agents to be added through the detergent container

2, read the manufacturer's instructions written on the package and follow the dosages specified. Use a measuring cup, if any.

For programmes where liquid detergent dosing is selected, do not add any powder detergent.

WARNING: Do not use liquid detergents or other cleaning products other than fabric softeners produced for washing

machines to soften the clothes. Only use liquid softeners for washing machines.

Detergent, softener and other cleaning agents

1 2 3

1- Liquid detergent compartment

2 - Powder detergent compartment

3 - Softener compartment

• Adddetergentandsoftenerbeforestartingthewashingprogramme.

• Placethedetergentbagorthedispensingballdirectlyamongthelaundryintheproduct.

• Thereisnopre-washcompartmentorpre-washoption.

Washing agents such as viscous jelly detergents cannot be used in detergent drawers or dosing compartments.

WARNING: Close the detergent drawer before starting the washing programme and never open the drawer while the

product is running.

4.2.6.1 Auto Dosing

Initial Setup:

Switch on the machine by pressing the on/off button. The dosing symbol ( ) will appear in programmes that

permit detergent dosing. If the liquid detergent and softener compartments are empty or the remaining agents

in these compartments are below the limits, the dosing symbol will flash in programmes that permit dosing.

Adding Liquid Detergent and Softener

• Pullthedetergentdrawertowardsyourselftoopenit.

• Toaddliquiddetergent(left)andsoftener(right),openthelidof

the relevant container upwards as shown in the image.

12 / EN

Washing Machine / User’s Manual

MAX

• Whenaddingliquiddetergentorsoftener,donotexceedthetip

of the «Max» label.

• Closethelid.

• Closethedetergentdrawerbypushingitslowly.

• Afterclosingthedetergentdrawer,theflashingdosingsymbol(

) will start to light up steadily.

• Indicatesthatthecomponentsarefilledandthedraweris

closed.

• Forcolouredandwhitelaundry,itisrecommendedtofillcommonlyusedliquiddetergentinthe

compartment.

• Despitethefactthatthedetergentcompartmentsarefilled,if'detergentsymbol'continuestoflash,

the detergent drawer is not fully closed. Ensure that the drawer is seated in place by pushing it.

WARNING: While the detergent drawer is full with detergent and/or softener:

a- Do not pull the machine,

b- Do not change its place,

c- Do not tilt the machine to its side or back,

WARNING: To make these actions, first you should take out the drawer from the machine.

WARNING: If you wish to start the programme when there is no detergent in the detergent drawer, please remember

that you must cancel the liquid detergent dosing and wash the laundry with powder detergent.

WARNING: The liquid detergent dosing container must be filled only with liquid detergent, and the softener dosing

container only with softener. Filling these compartments with any kind of liquid or powder chemical other than these may

harm your laundry or washing machine.

4.2.6.2 Dose Selection and Cancellation or Powder Detergent Use

• Forsomeprogrammesofthemachine,liquiddetergentcouldnotbeselected.Insuchcases,powder

detergent should be used. Please see the Programme Table for details.

• Afterselectingthetemperature,spinspeedandauxiliaryfunction,starttheprogrammebypressingthe

started/pause button.

• Themachinewillmeasuretheload,anddeterminethedetergentamountdependingontheloadamount

and selected functions. During the washing operation, the detergent intake is not visible, it will be taken

in directly with the water.

• Ifitisrequestedtousepowderdetergentinprogrammeswheredetergentdosingsystemactivates

required amount of powder detergent should be added to the detergent compartment. If you wish to use

the detergent compartment in the middle, you need to cancel your liquid detergent selection.

• ProgrammeisstartedbypressingStart/Pausebutton.Whenthemachinestartstotakeinwater,the

powder detergent will also be taken in.

• Ifyouwanttousealiquiddetergentwhosecharacteristicsaredifferentthanthatofthedetergentin

the liquid detergent compartment for once, you must add the different liquid detergent into the middle

powder detergent compartment and cancel your liquid detergent selection.

• Softenerwillbetakeninthroughthedetergentdosingsystem.

13 / EN

Washing Machine / User’s Manual

Liquid detergent and softener dosing symbols will be active or inactive depending on the

programme selected on the display.

• Iftheliquiddetergentsymbolison,thismeansthatliquiddetergentdosingisactive.

• Ifthesoftenersymbolison,thismeansthatsoftenerdosingisactive.

• Iftheliquiddetergentsymbolisoff,thismeansthatyoucanwashyourlaundrywithpowderdetergent.

• Ifthesoftenersymbolisoff,thismeansnosoftenerwillbeusedintherinsingstep.

The first position on the display: means liquid detergent is active, softener is on.

If liquid detergent and softener symbols are active on the display, the liquid detergent will

become on and the softener will become off after you press the Auto Dosing key for the first

time.

When you press the Auto Dosing key for the second time, powder detergent and softener

will become on.

When you press the Auto Dosing key for the third time, powder detergent will become on

and softener will become off. Finally, when you press it for the fourth time, it will return to

the initial position.

4.2.6.3 When the Detergent and/or Softener Run(s) Out:

• Whenthedetergentorsoftenerinthedetergentcompartmentrunsout,the“dosingsymbol”onthe

display will flash. When this symbol flashes, you need to add detergent or softener to the dosing

compartment. The product can dose for 2 to 3 cycles as of the moment that the symbol flashes.

4.2.6.4 Adding Detergent or Softener to the Wrong Compartment:

• Ifthedetergentorsoftenerisaddedtothewrongcompartments,see4.4.1“Cleaningthedetergent

drawer”.

14 / EN

Washing Machine / User’s Manual

4.2.7 Tips for efficient washing

Clothes

Light Colours and

Whites

Colours

Black/Dark

Colours

Delicates/

Woolens/Silks

(Recommended temperature

range based on soiling level:

40-90°C)

(Recommended temperature

range based on soiling level:

cold -40°C)

(Recommended

temperature range

based on soiling level:

cold -40°C)

(Recommended

temperature range

based on soiling level:

cold -30°C)

Soiling Level

Heavily Soiled

(difficult stains such

as grass, coffee, fruits

and blood.)

It may be necessary to pre-treat

the stains or perform prewash.

Powder and liquid detergents

recommended for whites can be

used at dosages recommended

for heavily soiled clothes. It is

recommended to use powder

detergents to clean clay and soil

stains and the stains that are

sensitive to bleaches.

Powder and liquid

detergents recommended

for colors can be used at

dosages recommended

for heavily soiled clothes.

It is recommended to use

powder detergents to clean

clay and soil stains and the

stains that are sensitive to

bleaches. Detergents which

do not contain bleach should

be used.

Liquid detergents

suitable for colors

and dark colors can

be used at dosages

recommended for

heavily soiled clothes.

Prefer liquid

detergents produced

for delicate clothes.

Woolen and silk

clothes must be

washed with special

woolen detergents.

Normally Soiled

(For example, stains

caused by body on

collars and cuffs)

Powder and liquid detergents

recommended for whites can be

used at dosages recommended

for normally soiled clothes.

Powder and liquid detergents

recommended for colors

can be used at dosages

recommended for normally

soiled clothes. Detergents

which do not contain bleach

should be used.

Liquid detergents

suitable for colors

and dark colors can

be used at dosages

recommended for

normally soiled clothes.

Prefer liquid

detergents produced

for delicate clothes.

Woolen and silk

clothes must be

washed with special

woolen detergents.

Lightly Soiled

(No visible stains

exist.)

Powder and liquid detergents

recommended for whites can be

used at dosages recommended

for lightly soiled clothes.

Powder and liquid detergents

recommended for colors

can be used at dosages

recommended for lightly soiled

clothes. Detergents which

do not contain bleach should

be used.

Liquid detergents

suitable for colors

and dark colors can

be used at dosages

recommended for

lightly soiled clothes.

Prefer liquid

detergents produced

for delicate clothes.

Woolen and silk

clothes must be

washed with special

woolen detergents.

If a special liquid detergent must be used, you can cancel the liquid detergent dosing and add the special detergent to the

powder detergent compartment no 2. In such cases, no time delay function should not be used.

15 / EN

Washing Machine / User’s Manual

4.3 Operating the product

4.3.1 Control panel

1. Programme Selection knob

2 - Spin Speed Adjustment button

3 - Temperature Adjustment button

4 - Display

5 - Programme Follow-up indicator

6 - On/Off button

7 - Start/Pause button

8 - End Time Adjustment button

9 - Auxiliary Function button 4

10 - Auxiliary Function button 3

11 - Auxiliary Function button 2

12 - Auxiliary Function button 1

13 - Programme Selection LEDs

4.3.2 Display symbols

a b c d e f g

ik jm ln

a- Temperature indicator

b- internet Connection indicator

c- Steam indicator

d- Audio Warning indicator

e- No Water indicator

f- Dosing symbols

g- Start/Pause indicator

h- Programme Follow-up indicator

i- Delayed Start Enabled indicator

j- Auxiliary Function indicators

k- Duration Information Line

l- Lock Indicators

m- Load indicator

n- Speed indicator

The visuals used for machine description in this section are schematic and may not match exactly will the features of your

machine.

AntiCrease+

Wash

Auto

Dosing

Night

Mode

End

Fast+

Pet Hair

Removal

Temperature

BFL853ADW

Cottons Eco

Synthetics

Dark Care

Jeans

Wool

Hand Wash

Delicates

Spin+DrainRinse

Bedding&Blanket

StainExpert

Shirts

Auto Program

On /

Start/

Pause

Cottons

Sports&Outdoor

CoolClean

Anti-Allergy+

Daily/Quick

Quick 14’

Ending In

3 4 5

891011

16 / EN

Washing Machine / User’s Manual

4.3.3 Programme and consumption table

Note for test institutions:

Data required for performance tests shall be provided upon request. Requests can be e-mailed to the following address:

[email protected]

Do not forget to provide the code, stock and serial numbers of the product to be tested in your request e-mail along with your contact

information. Code, stock and serial numbers of the product is located on the type label attached to the inside of the door.

• :Selectable.

* : Automatically selected, no canceling.

** : Energy Label programme (AS/NZS 2040)

*** : If maximum spin speed of the machine is lower then this value, you can only select up to the maximum spin speed.

**** : Programme detects the type and quantity of the laundry to automatically adjust water and energy consumption

and programme time.

- : See the programme description for maximum load.

Auxiliary functions

Programme

Max. Load (kg)

Water Consumption (l)

Energy Consumption (kWh)

Max. Speed***

Fast+

Auto Dosing

Pet Hair Removal

Night Mode

AntiCrease+

Selectable

temperature range

°C

Cottons

90 8,5 96 2,35 1400 • • • • • Cold-90

60 8,5 96 1,65 1400 • • • • • Cold-90

40 8,5 92 1,10 1400 • • • • • Cold-90

Cottons Eco 40** 8,5 73 0,953 1400 • Cold-40

Synthetics

60 4,5 70 1,25 1200 • • • • • Cold-60

40 4,5 70 0,80 1200 • • • • • Cold-60

Daily Quick / Quick 14’

90 8,5 66 2,10 1400 • • • • Cold-90

60 8,5 66 1,10 1400 • • • • Cold-90

30 8,5 62 0,20 1400 • • • • Cold-90

Daily Quick / Quick 14’+ Fast+ 90 2 40 0,15 1400 • • • • Cold-90

Dark Care / Jeans 40 4 88 0,90 1200 • • • • Cold-40

Wool / Hand Wash 40 2 54 0,45 1200 • • Cold-40

Delicates 40 4 57 0,60 1200 • • Cold-40

Bedding&Blanket 60 - 90 1,45 1000 • • Cold-60

Anti-Allergy+ 90 8,5 99 2,15 1400 • 20-90

Shirts 60 4 70 1,20 800 • • • • Cold-60

StainExpert 60 4,5 79 1,65 1400 • • • 30-60

Sports&Outdoor 40 4 57 0,50 1200 • Cold-40

CoolClean - 4,5 51 0,20 1400 • • Cold-30

Auto Program 60 8,5 **** **** 1400 • • • • • Cold-60

Drum Cleaning 70 - 85 2,00 700 • 70

17 / EN

Washing Machine / User’s Manual

The auxiliary functions in the table may vary according to the model of your machine.

Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient

temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.

You can see the washing duration on the display of your machine while selecting a programme. Depending on the amount of laundry

you have loaded into your machine, there may be a difference of 1-1.5 hours between the duration shown on the display and the

actual duration of the wash cycle. Duration will be automatically updated soon after the washing starts.

"Selection patterns for auxiliary functions can be changed by the manufacturer company. New selection patterns can be added or

removed."

"The spin speed of your machine may vary according to the programme; this spin speed cannot exceed the max. spin speed of your

machine."

4.3.4 Programme selection

1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with

"Programme and consumption table".

Programmes are limited with the highest spin speed appropriate for that particular type of fabric.

When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water

temperature.

Always select the lowest appropriate temperature. Higher temperature means higher electricity consumption.

2 Select the desired programme with the Programme Selection knob.

4.3.5 Programmes

• Cottons Eco

Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other

programmes, it provides high energy and water savings. Actual water temperature may be different from the

stated wash temperature. When you load the machine with less laundry (e.g. ½ capacity or less), periods in

programme stages may automatically get shorter. In this case, energy and water consumption will decrease

more, providing a more economic wash.

Normally soiled laundry may be washed with reduced amount of detergent to save energy and protect the

environment.

• Cottons

You can wash your durable cotton laundry (sheets, bedlinen, towels, bathrobes, underwear etc.) in this

programme. When the quick wash function button is pressed, programme duration becomes notably shorter

but effective washing performance is ensured with intense washing movements. If the quick wash function is

not selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.

• Synthetics

You can wash your laundry (such as shirts, blouses, synthetic/cotton blended fabrics etc.) in this programme.

The programme duration gets notable shorter and washing with high performance is ensured. If the quick

wash function is not selected, superior washing and rinsing performance is ensured for your heavily soiled

laundry.

18 / EN

Washing Machine / User’s Manual

• Wool / Hand Wash

Use to wash your woolen/delicate laundry. Select the appropriate temperature complying with the tag of your

clothes. Your laundry will be washed with a very gentle washing action in order not to damage the clothes.

"Woolens programme of this machine is approved by “The Woolmark Company” for

washing machine-washable woolen products provided that the products are washed in

accordance with the instructions on the product tag and the instructions published by

the manufacturer of this machine. M13985"

In UK, Ireland, Hong Kong and India, the Woolmark trademark is a Certification

trademark.

• Anti-Allergy+

Use this programme for your laundry (baby clothes, bed sheets, bedlinen, underwear, etc. cotton items) for

which you require an anti-allergic and hygienic washing at high temperature with intensive and long washing

cycle. The high level of hygiene is ensured thanks to long heating duration and additional rinsing step.

 •Programmewastestedbythe“VDE”institutewiththe20°Ctemperatureoptionselectedanditwas

certified in terms of its efficacy in eliminating bacteria and mould.

 •Programmewastestedby“TheBritishAllergyFoundation”(AllergyUK)withthe60°Ctemperature

option selected and it was certified in terms of its efficacy in eliminating allergens in addition to bacteria and

mould.

Allergy UK, is the brand of the British Allergy Association. Seal of Approval is created to

guide people that require recommendation about a product that the related product restricts

/ reduces / eliminates the allergens or reduces the allergen content significantly in the

ambient where allergy patients exist. It aims to provide assurance that the products are

tested scientifically or examined in a way to provide measurable results.

• Bedding&Blanket

Use this programme to wash your fiber duvets that bear "machine washable" tag. Check that you have loaded

the duvet correctly in order not to damage the machine and the duvet. Remove the duvet cover before loading

the duvet into the machine. Fold the duvet into two and load it into the machine. Load the duvet into the

machine paying attention to place it in a way that it will not contact the bellow or the glass.

Besides, use this programme to wash your coats, vest, jackets etc. containing feathers with a "machine-

washable" label on them.

Do not load more than 1 double fiber duvet (200 x 200 cm).

Do not wash your duvets, pillows and etc. that contain cotton in the machine.

CAUTION: Do not wash the items apart from duvets such as carpets, rugs and etc. in the machine. Otherwise,

permanent damage will occur in the machine.

• Spin+Drain

You can use this function to remove the water on the garment of drain the water in the machine.

• Rinse

Use when you want to rinse or starch separately.

• Shirts

This programme is used to wash the shirts made from cotton, synthetic and synthetic blended fabrics

altogether. It reduces wrinkles. When the quick wash function is selected, the Pre-treatment algorithm is

executed.

 •Applythepre-treatmentchemicalonyourgarmentsdirectlyoraddittogetherwiththedetergent

when the machine starts to take water in the powder detergent compartment. Thus, you can obtain the same

performance as you obtain with normal washing in a much shorter period of time. Usage life of your shirts

increases.

19 / EN

Washing Machine / User’s Manual

•

Daily Quick / Quick 14’

Use this programme to wash your lightly soiled or unspotted cotton clothes in a short time. The programme

duration can be reduced down to 14 minutes when the quick wash function is selected. When the quick wash

function is selected, maximum 2 (two) kg of laundry must be washed.

•

Dark Care / Jeans

Use this programme to protect the colour of your dark-coloured garments or jeans. It performs high

performance washing with special drum movement even if the temperature is low. It is recommended to use

liquid detergent or woolen shampoo for dark coloured laundry. Do not wash your delicate clothes containing

wool or etc.

• Auto Program

Use to wash frequently washable cotton, synthetic or blended (cotton+synthetic) clothes. Programme detects

the type and quantity of the laundry to automatically adjust water consumption and programme time.

CAUTION: Do not wash your woolen and delicate clothes in this programme.

Select a suitable temperature if the temperature shown on the temperature display is not compatible with the warnings on

the garment label.

The maximum washing temperature in Automatic programme depending on the soiling level and laundry type

is60ºC.Washingperformancemaynotbeatthedesiredlevelforheavilysoiledwhitesandstubbornstains

(collar, sock soil, perspiration stain, etc.). In this case, it is recommended to select Cottons programme with

prewash and set the temperature to 50-60°C.

Many types of clothing are correctly detected and safely washed in Automatic programme.

• Delicates

You can wash your delicate clothes such as cotton/synthetic blended knitwear or hosiery in this programme. It

washes with more delicate washing action. Wash your clothes whose colour you want to preserve either at 20

degrees or by selecting the cold wash option.

• CoolClean

Use to wash your moderately soiled and durable cotton/synthetic laundry. An effective washing is provided

thanks to the intense washing action and double jet system.

• Sports&Outdoor

You can use this programme to wash sports and outdoors garments that contain cotton/synthetics mix and

water repellent covers such as gore-tex etc. It makes sure your garments are washed gently thanks to special

rotating movements.

•

StainExpert

The machine has a special stain programme which enables the removal of different types of stains in the

most effective way. Use this programme only for durable colourfast cotton laundry. Do not wash delicate

and pigmenting clothes and laundry in this programme. Before washing, garment tags should be checked

(recommended for cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas, aprons, table clothes, bed

sheets, duvet covers, pillowcases, bath-beach towels, towels, socks, cotton underwear that are suitable for

washing at high temperature and long time). In the automatic stain programme, you can wash 24 types of

stains divided into two different groups according to quick function selection. You can see stain groups based

on the selection of the quick function.

You can find stain groups based on quick function below:

When quick function is selected:

Blood Tea Red Wine

Chocolate Coffee Curry

Pudding Fruit juice Jam

Egg Ketchup Coal

20 / EN

Washing Machine / User’s Manual

When quick function is not selected:

Butter Sweat Salad Dressing

Grass Collar Soil Make-up

Mud Food Machine Oil

Coke Mayonnaise Baby Food

•Selectthestainprogramme.

•Selectthestainyouwanttocleanbylocatingitinthegroupsaboveandselectingtherelatedgroupwiththe

quick auxiliary function button.

•Readthegarmenttagcarefullyandensurethatcorrecttemperatureandspinspeedareselected.

4.3.6 Temperature selection

Whenever a new programme is selected, the recommended temperature for the programme appears on the

temperature indicator. It is possible that the recommended temperature value is not the maximum temperature

that can be selected for the current programme.

Press the Temperature Adjustment button to change the temperature. Temperature will decrease by steps

of 10 °C.

Finally, “-” symbol indicating the cold wash option appears on the display.

No change can be made in programmes where temperature adjustment is not allowed.

You can also change the temperature after the washing starts. This change can be made if the washing steps

allow it. Changes cannot be made if the steps do not allow it.

If you scroll to cold wash option and press Temperature Adjustment button again, the recommended maximum temperature

for the selected programme appears on the display. Press the Temperature Adjustment button again to decrease the

temperature.

4.3.7 Spin speed selection

Whenever a new programme is selected, the recommended spin speed of the selected programme is

displayed on the Spin Speed indicator.

It is possible that the recommended spin speed value is not the maximum spin speed that can be selected for the current

programme.

Press the Spin Speed Adjustment button to change the spin speed. Spin speed decreases gradually.

Then, depending on the model of the product, "Rinse Hold" and "No Spin" options appear on the display.

21 / EN

Washing Machine / User’s Manual

Spin Speed Adjustment button only serves for decreasing the spin speed.

Rinse Hold option is indicated with “ı_ı” symbol and No Spin option is indicated with “_” symbol.

If you are not going to unload your laundry immediately after the programme completes, you can use Rinse

Hold function in order to prevent them from getting wrinkled when there is no water in the machine.

This function holds the laundry in the final rinsing water.

If you want to spin your laundry after the Rinse Hold function:

- Adjust the Spin Speed.

- Press Start / Pause / Cancel button. The programme will resume. Machine drains the water and spins the

laundry.

If you want to drain the water at the end of the programme without spinning, use No Spin function.

No change can be made in programmes where spin speed adjustment is not allowed.

You can change the spin speed after the washing starts if the washing steps allow it. Changes cannot be

made if the steps do not allow it.

Rinse hold

If you are not going to unload your clothes immediately after the programme completes, you can use rinse

hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled

when there is no water in the machine. Press Start / Pause button after this process if you want to drain the

water without spinning your laundry. Programme will resume and complete after draining the water.

If you want to spin the laundry held in water, adjust the Spin Speed and press Start / Pause button.

The programme will resume. Water is drained, laundry is spun and the programme is completed.

4.3.8 Auxiliary function selection

Select the desired auxiliary functions before starting the programme. Whenever a programme is selected,

frames of the auxiliary function symbol that can be selected together with it illuminates. And when you select

an auxiliary function, the interior area of the auxiliary function symbol also starts to illuminate.

Frame of the auxiliary function symbol that cannot be selected with the current programme does not illuminate.

Also the frames of the auxiliary function suitable for the current programme after the washing has started

remains illuminated. You can select or cancel the auxiliary functions whose frames are illuminated. If the wash

cycle has reached a point where you cannot select the auxiliary function, the function's frame turns off.

22 / EN

Washing Machine / User’s Manual

Some functions cannot be selected together. If a second auxiliary function conflicting with the first one is selected before

starting the machine, the function selected first will be canceled and the second auxiliary function selection will remain

active. For example, if you want to select Quick Wash after you have selected the Additional Water, Additional Water will be

canceled and Quick Wash will remain active.

An auxiliary function that is not compatible with the programme cannot be selected. (See, "Programme and consumption

table")

Some programmes have auxiliary functions that must be operated simultaneously. Those functions cannot be cancelled. The

frame of the auxiliary function will not be illuminated, only inner area will be illuminated.

4.3.8.1 Auxiliary functions

• Fast+

When this function is selected, the durations of the relevant programmes get shorter by 50%.

Thanks to the optimised washing steps, high mechanic activity and optimum water consumption,

high washing performance is achieved in spite of the reduced duration.

When you select this function, load your machine with half of the maximum laundry specified in the programme table.

• Night Mode

Use to wash the cottons with lesser energy consumption and silently. Spin steps are cancelled for a silent

washing and the cycle ends with the Rinse Hold step. After completion of the programme, run Spin cycle to

spin the laundry.

•

Pet Hair Removal

This function helps to remove pet hair that remain on your garments more effectively.

When you select this function, Prewash and Extra Rinse steps are added to the normal programme. Thus,

washing is performed with more water and the pet hair is removed more effectively.

• Auto Dosing

With this auxiliary function key, you can change your detergent and dose preferences. For detailed information,

see 4.2.6.2 “Detergent and Softener Dose or Powder Detergent Selection“

4.3.8.2 Functions/Programmes Selected by Pressing the Function Keys for 3 Seconds

• Drum Cleaning

Press and hold the auxiliary function button 1 for 3 seconds to select the programme.

Use regularly (once in every 1-2 months) to clean the drum and provide the required hygiene. Operate the

programme while the machine is completely empty. To obtain better results, put powder lime-scale remover

for washing machines when the powder detergent function is selected. When the programme is over, leave the

loading door ajar so that the inside of the machine gets dry.

This is not a washing programme. It is a maintenance programme.

Do not run the programme when there is something in the machine. If you try to do so, the machine detects that there is

load inside and aborts the programme.

• Child lock

Use Child Lock function to prevent children from tampering with the machine. Thus you can avoid any changes

in a running programme.

23 / EN

Washing Machine / User’s Manual

You can switch on and off the machine with On / Off button when the Child Lock is active. When you switch on the machine

again, programme will resume from where it has stopped.

When the Child Lock is enabled, an audio warning will be given if the buttons are pressed. Audio warning will be canceled if

the buttons are pressed five times consecutively.

To activate the Child Lock:

Press and hold Auxiliary Function button 2 for 3 seconds. After the countdown as “CL 3-2-1" on the

display is over, "CL On" symbol appears on the display. Release Auxiliary Function button 2 when this

warning is displayed.

To deactivate the Child Lock:

Press and hold Auxiliary Function button 2 for 3 seconds. After the countdown as “CL 3-2-1" on the

display is over, "CL Off" symbol disappears.

• AntiCrease+

This function is selected when the 4th auxiliary function is pressed and held for 3 seconds and the programme

follow-up light for the relevant step turns on. When the function is selected, the drum rotates for up to 8 hours

for preventing the laundry from creasing at the end of the programme. You can cancel the programme and

take your laundry out at any time during the 8-hour duration. Press the function selection key or the machine

on/off key to cancel the function. The programme follow-up light will remain on until the function is canceled

or the step is complete. If the function is not cancelled, it will be active in the subsequent washing cycles as

well.

• Auto Dosing Setting

You can enable this function by pressing the auxiliary function key 3 for 3 seconds. With this function, the

dosing amounts of the Liquid Detergent and Softener are changed.

Changing the dosing amounts of Liquid Detergent and Softener:

• PressandholdAuxiliaryFunctionbutton3for

3 seconds.

• Youcanpressthe“Temperature”selection

button( ) to change the liquid detergent

dosing levels as below.

1: Low

2: Medium

3: High

• Youcanpressthe“Spin”selectionbutton(

)to change the softener dosing levels as

below.

1: Low

2: Medium

3: High

24 / EN

Washing Machine / User’s Manual

• Aftersettingthedosingamounts,youcanpresstheautodosingkeytoreturntothemainmenu.Forall

programmes, dosing will be performed based on the latest settings you have selected until you select a

new setting.

4.3.9 End Time

Ending In

Remaining time for the completion of the programme while it is running is displayed as “01:30” in hours and

minutes format.

Programme time may differ from the values in section "Programme and consumption table" depending on the water

pressure, water hardness and temperature, ambient temperature, amount and the type of laundry, auxiliary functions selected

and the changes at the mains voltage.

With the End Time function, the startup of the programme may be delayed up to 24 hours. After pressing

End Time button, the programme's estimated ending time is displayed. If the End Time is set, End Time

indicator is illuminated.

In order for the End Time function is activated and the programme is completed at the end of the specified

time, you must press Start/Pause button after adjusting the time.

If you want to cancel End Time function, press On/Off button to turn off and on the machine.

When you have activated the End Time function, do not add liquid detergent in the powder detergent compartment no 2.

There is the risk of staining of the clothes.

1 Open the loading door, place the laundry and put detergent, etc.

2 Select the washing programme, temperature, spin speed and, if required, the auxiliary functions.

3 Set the end time of your choice by pressing the End Time button. End Time indicator illuminates.

4 Press Start/Pause button. Time countdown starts. “:” sign in the middle of the end time on the display

starts flashing.

Additional laundry may be loaded during the End Time countdown period. At the end of the countdown, End Time indicator

turns off, washing cycle starts and the time of the selected programme appears on the display.

When the End Time selection is completed, the time appears on the screen consists of end time plus the duration of the

selected programme.

4.3.10 Starting the programme

1 Press Start/Pause button to start the programme.

2 The Start/Pause button's light which was off before starts to illuminate steadily now, indicating that the

programme has started.

25 / EN

Washing Machine / User’s Manual

3 Loading door is locked. The door lock symbol appears on the display after the loading door is locked.

4 Programme follow-up indicator lights on the display will show the current programme step.

4.3.11 Loading door lock

There is a locking system on the loading door of the machine that prevents opening of the loading door in

cases when the water level is unsuitable.

"Door Locked" symbol appears on the display when the loading door is locked.

Opening the loading door in case of power failure:

In case of power failure, you can use the loading door emergency handle under the pump filter cap to open the loading

door manually.

CAUTION: To avoid any water overflow before opening the loading door, make sure there is no water left inside the

machine.

• Open the pump filter cap.

26 / EN

Washing Machine / User’s Manual

• Release the loading door emergency handle located at the rear side of

the filter cap.

• Pull down the loading door emergency handle once and open the loading

door. After opening the loading door, re-insert the loading door emergency

handle.

• f the loading door does not open, try again by pulling down the handle.

4.3.12 Changing the selections after programme has started

Adding laundry after the programme has started :

If the water level in the machine is suitable when you press Start/Pause button, the door lock will be

deactivated and the door will open, allowing you to add garments. The door lock icon on the display goes off

when the door lock is deactivated. After adding garments, close the door and press Start/Pause button once

again to resume the washing cycle.

If the water level in the machine is not suitable when you press Start/Pause button, the door lock cannot be

deactivated and the door lock icon on the display remains on.

If the temperature of the water inside the machine is above 50°C, you cannot deactivate the door lock for safety reasons,

even if the water level is suitable.

Switching the machine to pause mode:

Press the Start/Pause button to switch the machine to pause mode. Pause symbol will flash on the display.

Changing the programme selection after programme has started:

The programme change is not allowed when the current programme is running.

You can select the new programme after switching the current programme to pause mode.

The selected program starts anew.

27 / EN

Washing Machine / User’s Manual

Changing the auxiliary function, speed and temperature

Depending on the step the programme has reached, you can cancel or activate the auxiliary functions. See,

"Auxiliary function selection".

You can also change the speed and temperature settings. See, "Spin speed selection" and "Temperature

selection".

The loading door will not open if the water temperature in the machine is high or the water level is above the loading door

baseline.

4.3.13 Cancelling the programme

The programme is cancelled when the machine is turned off and on again. Press and hold On/Off button for 3

seconds. After the countdown as "3-2-1" on the display is over, the machine turns off.

If you press On/Off button when the Child Lock is enabled, the programme will not be cancelled. You should cancel the Child

Lock first.

If you want to open the loading door after you have cancelled the programme but it is not possible to open the loading

door since the water level in the machine is above the loading door baseline, then turn the Programme Selection knob to

Pump+Spin programme and drain the water in the machine.

4.3.14 End of programme

End symbol appears on the display when the programme is completed.

If you do not press any button for 10 minutes, the machine will switch to OFF mode. Display and all indicators

are turned off.

Completed programme steps will be displayed if you press On/Off button.

4.3.15 Adjusting the VOLUME level

Low volume and high volume

Press and hold 1st and 2nd auxiliary function buttons for 3 seconds to adjust the volume level. After the

countdown as "3-2-1" on the display is over, the volume level symbol will appear and the new volume level

will be displayed.

4.3.16 Drum Illumination

Drum illumination lamp of your machine will light up during programme selection. The light will turn off

when you start the programme. If no programme is started or no key is pressed within 10 minutes during

programme selection process, the drum illumination lamp will turn off.

Drum illumination lamp of your machine will light up after the programme is completed. It will go off when

you press the On/Off button. The drum illumination lamp will turn off if you do not press any button within 10

minutes after the programme has ended.

28 / EN

Washing Machine / User’s Manual

4.4 Maintenance and cleaning

Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular

intervals.

4.4.1 Cleaning the detergent drawer

When to clean

• Ifyouseehardened,viscousdetergentorsoftenerwhenyouopenthedosingcontainerlid,

• Ifyouarenotsatisfiedwiththewashingresults(thedetergentorsoftenermaynotbetakenintothe

washing medium since it is hardened),

• Iftheliquidsinthecompartmentdonotdecreaseforalongtimeeventhoughyoudonotadddetergent

or softener and dosing is selected,

• Ifyouwanttochangethewashingagentsyouhaveaddedtothecompartment(forexample,ifyouare

not satisfied with the detergent and do not want to use it) or if you have made a mistake when adding

the agents (for example, if you have added detergent to the softener compartment or softener to the

detergent compartment),

• Ifyouaregoingtoaddadetergentorsoftenerfromadifferentbrandthantheoneyounormallyuse,

• Ifyouareaddingawashingagentofadifferentnature(forexample,ifyouareaddingdetergentfor

coloured laundry when there is detergent for white laundry in the compartment),

• Ifyouareaddingawashingagentwithadifferentconcentration(Tonotwastetheolddetergent,you

can add it to the powder detergent compartment in the next wash and select «powder detergent active»

on the display.)

• Ifthenewsoftenertobeaddedhasthesamecharacteristicsbuthasadifferentscent(pleasekeepin

mind that if you add the new softener without cleaning the remnants of the previous one, this mixture

will give a different smell),

• Ifyouarenotgoingtousetheproductforalongtime(forexample,whengoingtothesummerhouse

and when returning - 3 months or more) (the washing agent may increasingly thicken and get hardened

in the end, and thus the system may not perform dosing even if it shows that the compartments are

full.)

Cleaning:

Before cleaning, press the On/Off button to switch of the product and unplug it.

It is recommended for you to wear a glove to avoid contacting the detergent you will take out of the detergent drawer and

other washing agents.

• Pressthebluepartinthemiddleofthedetergent

drawer and then pull the drawer towards yourself

to take it out.

• Takeoutthedischargebarthatislocatedatthebackofthedrawer.

• Theholebehindthedetergentcompartmentthatwillbeemptiedisplacedoveracontainer.

• Slightlypushthedischargebarintotheslotatthebackofthedetergentcompartment.

• Thedetergentstartstoflowtothecontainer.

• Repeatthesameprocessforsoftener.

29 / EN

Washing Machine / User’s Manual

• Useaflatscrewdrivertoremovethetabsholdingtheuppercoverofthedetergentdrawer(thereare

6 tabs in total: two on the right side of the drawer, two on the left and two at the back) and wash the

inside of the drawer.

• Afterwashingit,placethecoverbacktoitslocation.Makesurethatalltabsarefitted.Ifthetabsdonot

seat properly, liquids may leak or the detergent drawer may get stuck or difficultly move on the drawer

slide. For this reason, please ensure that the tabs are fitted in place.

• Fitthedischargebartoitsslotatthebackofthedrawer.

• Payingattentiontoitsslotandslides,fitthedrawerbackinplaceandpushittoclose.Afteradding

detergent and softener, it will be ready to be used in programmes with dosing function.

4.4.2 Cleaning the loading door and the drum

For products with drum cleaning programme, please see Operating the product - Programmes.

Select

Repeat Drum Cleaning process in every 2 months.

Use an anti-limescale suitable for the washing machines.

After every washing make sure that no foreign substance is left in the

product.

If the holes on the bellow shown in the figure is blocked, open the holes

using a toothpick.

Foreign metal substances will cause rust stains in the drum. Clean the

stains on the drum surface by using cleaning agents for stainless steel.

Never use steel wool or wire wool. These will damage the painted,

chromated and plastic surfaces.

4.4.3 Cleaning the body and control panel

Wipe the body of the product with soapy water or non-corrosive mild gel detergents as necessary, and dry

with a soft cloth.

Use only a soft and damp cloth to clean the control panel.

4.4.4 Cleaning the water intake filters

There is a filter at the end of each water intake valve at the rear of the product and also at the end of each

water intake hose where they are connected to the tap. These filters prevent foreign substances and dirt in

the water to enter the product. Filters should be cleaned if they are dirty.

30 / EN

Washing Machine / User’s Manual

1. Close the taps.

2. Remove the nuts of the water intake hoses to access the filters on the water intake valves. Clean them

with an appropriate brush. If the filters are too dirty, remove them from their places with a pliers and

clean in this way.

3. Take out the filters on the flat ends of the water intake hoses together with the gaskets and clean

thoroughly under running water.

4. Replace the gaskets and filters carefully and tighten their nuts by hand.

4.4.5 Draining remaining water and cleaning the pump filter

The filter system in your product prevents solid items such as buttons, coins and fabric fibers clogging the

pump impeller during draining of washing water. Thus, the water will be drained without any problem and the

service life of the pump will extend.

If the product fails to drain water inside it, the pump filter is clogged. Filter must be cleaned whenever it is

clogged or in every 3 months. Water must be drained off first to clean the pump filter.

In addition, prior to transporting the product (e.g., when moving to another house) water should be drained

completely.

WARNING: Foreign substances left in the pump filter may damage your product or may cause noise problem.

WARNING: In regions where freezing is possible, the tap must be closed, system hose must be removed and the water

inside the product must be drained when the product is not in use.

WARNING: After each use, turn off the tap to which the mains hose is connected.

In order to clean the dirty filter and drain the water:

1 Unplug the product to cut off the supply power.

WARNING: Temperatureofthewaterinsidetheproductmayriseupto90ºC.Toavoidtheriskofscalding,cleanthe

filter after the water inside the product is cooled down.

2 Open the filter cover.

3 Follow the below procedures in order to drain water.

If the product has an emergency water draining hose, in order to drain the water:

a Pull the emergency draining hose out from its

seat.

b Place a large container at the end of the hose.

Drain the water into the container by pulling

out the plug at the end of the hose. When the

container is full, block the inlet of the hose

by replacing the plug. After the container is

emptied, repeat the above procedure to drain the

water in the product completely.

c When draining of water is finished, close the end

by the plug again and fix the hose in its place.

d Turn and remove the pump filter.

4 Clean any residues inside the filter as well as fibers, if any, around the pump impeller region.

5. Replace the filter.

6. If the filter cap is composed of two pieces, close the filter cap by pressing on the tab. If it is one piece, seat

the tabs in the lower part into their places first, and then press the upper part to close.

31 / EN

Washing Machine / User’s Manual

5 Troubleshooting

Problem Cause Solution

Programs do not start after the

loading door is closed.

Start / Pause / Cancel button is not pressed. •*Press Start / Pause / Cancel button.

It may be difficult to close the loading door in case of

excessive loading.

•Reduce the amount of laundry and make sure

that the loading door is closed properly.

Programme cannot be started or

selected.

The product has switched to self protection mode

due to a supply problem (line voltage, water pressure,

etc.).

• Press and hold On/Off button for 3 seconds

to reset the product to factory settings. (See

"Cancelling the programme")

Water inside the product. Some water has remained in the product due to the

quality control processes in the production.

•This is not a failure; water is not harmful to the

product.

The product does not take water

in.

Tap is turned off. •Turn on the taps.

Water inlet hose is bent. •Flatten the hose.

Water inlet filter is clogged. •Clean the filter.

Loading door is not closed. •Close the door.

The product does not drain water. Water drain hose is clogged or twisted. •Clean or flatten the hose.

Pump filter is clogged. • Clean the pump filter.

Product vibrates or makes noise. Product is standing unbalanced. •Stable the product by adjusting the feet.

A hard substance has entered into the pump filter. •Clean the pump filter.

Transportation safety bolts are not removed. •Remove the transportation safety bolts.

Laundry quantity in the product is too little. •Add more laundry to the product.

Excessive laundry is loaded in the product. •Take out some of the laundry from the product

or distribute the load by hand to balance it

homogeneously in the product.

Product is leaning on a rigid item. •Make sure that the product is not leaning on

anything.

There is water leaking from the

bottom of the product.

Water drain hose is clogged or twisted. •Clean or flatten the hose.

Pump filter is clogged. • Clean the pump filter.

Product stopped shortly after the

programme started.

Machine has stopped temporarily due to low voltage. • Product will resume running when the voltage

restores to the normal level.

Product directly drains the water

it takes in.

Draining hose is not at adequate height. •Connect the water draining hose as described in

the user manual.

No water can be seen in the

product during washing.

Water is inside the invisible part of the product. •This is not a failure.

Loading door cannot be opened. Loading door lock is activated because of the water

level in the product.

•Drain the water by running the Pump or Spin

programme.

Product is heating up the water or it is at the spinning

cycle.

• Wait until the programme completes.

Loading door may be stuck because of the pressure it

is subjected to.

•Grab the handle and push and pull the loading

door to release and open it.

If there is no power, loading door of the product will

not open.

•To open the loading door, open the pump filter

cap and pull down the emergency handle

positioned at the rear side of the said cap. See

"Loading door lock"

32 / EN

Washing Machine / User’s Manual

Problem Cause Solution

Washing takes longer than

specified in the user manual.(*)

Water pressure is low. • Product waits until taking in adequate amount

of water to prevent poor washing quality due to

the decreased amount of water. Therefore, the

washing time extends.

Voltage is low. •Washing time is prolonged to avoid poor washing

results when the supply voltage is low.

Input temperature of water is low. •Required time to heat up the water extends

in cold seasons. Also, washing time can be

lengthened to avoid poor washing results.

Number of rinses and/or amount of rinse water have

increased.

•Product increases the amount of rinse water

when good rinsing is needed and adds an extra

rinsing step if necessary.

Excessive foam has occurred and automatic foam

absorption system has been activated due to too

much detergent usage.

• Use recommended amount of detergent.

Programme time does not

countdown. (On models with

display) (*)

Timer may stop during water intake. •Timer indicator will not countdown until the

product takes in adequate amount of water. The

product will wait until there is sufficient amount

of water to avoid poor washing results due to lack

of water. Timer indicator will resume countdown

after this.

Timer may stop during heating step. •Timer indicator will not countdown until the

product reaches the selected temperature.

Timer may stop during spinning step. •Automatic unbalanced load detection system is

activated due to the unbalanced distribution of the

laundry in the product.

Programme time does not

countdown. (*)

There is unbalanced load in the product. •Automatic unbalanced load detection system is

activated due to the unbalanced distribution of the

laundry in the product.

Product does not switch to

spinning step. (*)

There is unbalanced load in the product. •Automatic unbalanced load detection system is

activated due to the unbalanced distribution of the

laundry in the product.

The product will not spin if water is not drained

completely.

•Check the filter and the draining hose.

Excessive foam has occurred and automatic foam

absorption system has been activated due to too

much detergent usage.

• Use recommended amount of detergent.

Washing performance is poor:

Laundry turns gray. (**)

Insufficient amount of detergent has been used over a

long period of time.

•Use the recommended amount of detergent

appropriate for water hardness and the laundry.

Washing has been made at low temperatures for a

long time.

•Select the proper temperature for the laundry to

be washed.

Insufficient amount of detergent is used with hard

water.

•Using insufficient amount of detergent with hard

water causes the soil to stick on the cloth and

this turns the cloth into gray in time. It is difficult

to eliminate graying once it happens. Use the

recommended amount of detergent appropriate

for water hardness and the laundry.

Excessive amount of detergent is used. •Use the recommended amount of detergent

appropriate for water hardness and the laundry.

33 / EN

Washing Machine / User’s Manual

Problem Cause Solution

Washing performance is poor:

Stains persist or the laundry is not

whitened. (**)

Insufficient amount of detergent is used. •Use the recommended amount of detergent

appropriate for water hardness and the laundry.

Excessive laundry is loaded in. •Do not load the product in excess. Load with

amounts recommended in the "4.3.3 Programme

and consumption table".

Wrong programme and temperature were selected. • Select the proper programme and temperature for

the laundry to be washed.

Wrong type of detergent is used. •Use original detergent appropriate for the product.

Excessive amount of detergent is used. •Put the detergent in the correct compartment. Do

not mix the bleaching agent and the detergent

with each other.

Washing performance is poor: Oily

stains appeared on the laundry.

(**)

Regular drum cleaning is not applied. •Clean the drum regularly. For this procedure,

please see "4.4.2 Cleaning the loading door and

the drum".

Washing performance is poor:

Clothes smell unpleasantly. (**)

Odours and bacteria layers are formed on the drum as

a result of continuous washing at lower temperatures

and/or in short programmes.

•Leave the detergent drawer as well as the loading

door of the product ajar after each washing.

Thus, a humid environment favorable for bacteria

cannot occur in the machine.

Colour of the clothes faded. (**) Excessive laundry was loaded in. •Do not load the product in excess.

Detergent in use is damp. • Keep detergents closed in an environment free

of humidity and do not expose them to excessive

temperatures.

A higher temperature was selected. •Select the proper programme and temperature

according to the type and soiling degree of the

laundry.

Washing machine does not rinse

well.

The amount, brand and storage conditions of the

detergent used are inappropriate.

•Use a detergent appropriate for the washing

machine and your laundry. Keep detergents

closed in an environment free of humidity and do

not expose them to excessive temperatures.

Detergent was put in the wrong compartment. •Add the detergent and the softener to the right

compartment.

Pump filter is clogged. • Check the filter.

Drain hose is folded. • Check the drain hose.

Laundry became stiff after

washing. (**)

Insufficient amount of detergent is used. •Using insufficient amount of detergent for the

water hardness can cause the laundry to become

stiff in time. Use appropriate amount of detergent

according to the water hardness.

Detergent was put in the wrong compartment. •Add the detergent and the softener to the right

compartment.

Detergent was mixed with the softener. •Do not mix the softener with detergent. Wash and

clean the drawer with hot water.

Laundry does not smell like the

softener. (**)

Detergent was put in the wrong compartment. •Add the detergent and the softener to the right

compartment.

Detergent was mixed with the softener. •Do not mix the softener with detergent. Wash and

clean the drawer with hot water.

Softener dosing setting level is low. •Increase the softener dosing amount by one level.

See “Auto Dosing Setting”

34 / EN

Washing Machine / User’s Manual

Problem Cause Solution

Detergent residue in the detergent

drawer. (**)

Detergent was put in wet drawer. •Dry the detergent drawer before putting in

detergent.

Detergent has gotten damp. •Keep detergents closed in an environment free

of humidity and do not expose them to excessive

temperatures.

Water pressure is low. • Check the water pressure.

The detergent in the main wash compartment got

wet while taking in the prewash water. Holes of the

detergent compartment are blocked.

•Check the holes and clean if they are clogged.

There is a problem with the detergent drawer valves. •Call the Authorised Service Agent.

Detergent was mixed with the softener. •Do not mix the softener with detergent. Wash and

clean the drawer with hot water.

Regular drum cleaning is not applied. •Clean the drum regularly. For this procedure,

please see "4.4.2 Cleaning the loading door and

the drum".

Too much foam forms inside the

product. (**)

Improper detergents for the washing machine is used. •Use detergents appropriate for the washing

machine.

Excessive amount of detergent is used. •Use only sufficient amount of detergent.

Detergent was stored under improper conditions. •Store detergent in a closed and dry location. Do

not store in excessively hot places.

Some meshed laundry such as tulle may foam too

much because of their texture.

•Use smaller amounts of detergent for this type

of item.

Detergent was put in the wrong compartment. •Put the detergent in the correct compartment.

Foam is overflowing from the

detergent drawer.

Too much detergent is used. •Mix 1 tablespoonful softener and ½ l water and

pour into the main wash compartment of the

detergent drawer.

•Put detergent into the product suitable for the

programmes and maximum loads indicated

in the “4.3.3 Programme and consumption

table”. When you use additional chemicals (stain

removers, bleaches and etc), reduce the amount

of detergent.

Laundry remains wet at the end of

the programme. (*)

Excessive foam has occurred and automatic foam

absorption system has been activated due to too

much detergent usage.

•Use recommended amount of detergent.

(*) The product does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the

product and to its surrounding environment. Laundry should be rearranged and re-spun.

(**) Regular drum cleaning is not applied. Clean the drum regularly. See 4.4.2

WARNING: If you cannot eliminate the problem although you follow the instructions in this section, consult your dealer or

the Authorised Service Agent. Never try to repair a nonfunctional product yourself.

Beko BFL853ADW 8.5kg Front Load Washing Machine

Product's Documents

User Manual

Specifications

Beko BFL853ADW Questions and Answers

Related Products

Beko BMM5DFO5741W 7/5KG 1400 Spin Washer Dryer - White

Beko WDA8514AT 8kg/5kg Washer Dryer Combo

BFL8520W Beko 8.5kg Front Load Washing Machine

Beko BFLB1020W 10kg Front Load Washing Machine

Beko BFLB124ADW 12kg Front Load Washing Machine

Beko BFL7520W 7.5kg Front Load Washing Machine
