user manual
Ceramic glass hob
EHET66CS, EHET96CS
Electrolux. Thinking of you.
Share more of our thinking at www.electrolux.com
Contents
Safety instructions .................................. 2
Description of the Appliance ................... 3
Operating the appliance ......................... 6
Tips on cooking and frying .................... 10
Cleaning and Care ................................ 11
What to do if ... ..................................... 12
Technical data ...................................... 13
Disposal ............................................... 13
Installation Instructions ......................... 13
Assembly .............................................. 15
Warranty .............................................. 16
Service ................................................. 18
Subject to change without notice
Safety instructions
Warning! Please comply with these
instructions. If you do not, any
damage resulting is not covered by
the warranty.
Correct use
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or in-
struction concerning use of the appliance
by a person responsible for their safety.
• Do not leave the appliance unattended
during operation.
• This appliance should be used only for
normal domestic cooking and frying of
food.
• The appliance must not be used as a work
surface or as a storage surface.
• Additions or modifications to the appliance
are not permitted.
• Do not place or store flammable liquids,
highly inflammable materials or fusible ob-
jects (e.g. plastic film, plastic, aluminium)
on or near the appliance.
Children's safety
• The cooking zones will become hot when
you cook. Therefore, always keep small
children away from the appliance.
• The appliance is not intended for use by
young children or infirm persons without
supervision.
• Children should be supervised to ensure
that they do not play with the appliance.
Warning! Accessible parts will
become hot during use. To avoid
burns young children should be kept
away
General Safety
• The appliance may only be installed and
connected by trained, registered service
engineers.
• Built-in appliances may only be used after
they have been built into suitable built-in
units and work surfaces that meet stand-
ards.
• In the event of faults with the appliance or
damage to the glass ceramic (cracks,
scratches or splits), the appliance must be
switched off and disconnected from the
electrical supply, to prevent the possibility
of an electric shock.
• Repairs to the appliance must only be car-
ried out by trained registered service engi-
neers.
Safety during use
• Remove stickers and film from the glass
ceramic.
• There is the risk of burns from the appli-
ance if used carelessly.
• Cables from electrical appliances must not
touch the hot surface of the appliance or
hot cookware.
• Overheated fats and oils can ignite very
quickly. Warning! Fire hazard!
• Switch the cooking zones off after each
use.
2 electrolux
Warning! If the surface is cracked,
switch off the appliance to avoid
possibility of electric shock.
Safety when cleaning
• For cleaning, the appliance must be
switched off and cooled down.
• For safety reasons, the cleaning of the ap-
pliance with steam jet or high pressure
cleaning equipment is not permitted.
How to avoid damage to the appliance
• The glass ceramic can be damaged by
objects falling onto it.
• The edge of the glass ceramic can be
damaged by being knocked by the cook-
ware.
• Cookware made of cast iron, cast
aluminium or with damaged bottoms can
scratch the glass ceramic if pushed across
the surface.
• Before spillage can become burnt on to
the cooking surface, remove it with a
damp cloth.
• To avoid damaging cookware and glass
ceramics, do not allow saucepans or frying
pans to boil dry.
• Do not use the cooking zones with empty
cookware or without cookware.
Description of the Appliance
Cooking surface layout
EHET 66CS
1 2
4 35
145 mm
145 mm
180 mm
120/175/210 mm
1 Single cooking zone 1200W
2 Single cooking zone 1800W
3 Single cooking zone 1200W
4 Control panel
5 Triple cooking zone 2300/1600/800W
electrolux 3
EHET 96CS
145 mm
180 mm
170 mm
265 mm
120/175/210 mm
1
2
45 3
1 Single cooking zone 1200W
2 Multi-purpose cooking zone
2200/1400W
3 Single cooking zone 1800W
4 Control panel
5 Triple cooking zone 2300/1600/800W
Control panel layout
EHET 66CS
1 32 4
9
10
5 6 7
8
1 On/Off with power indicator
2 Lock with pilot light
3 A triple ring cooking zone
4 Heat setting selection
5 Display
6 Cooking zone indicators Timer function
7 Timer display
8 Timer
9 Zone selection indicator
10 Stop+Go function
4 electrolux
EHET 96CS
1 32 4
10
11
5 6 7 8
9
1 On/Off with power indicator
2 Lock with pilot light
3 A triple ring cooking zone
4 Heat setting selection
5 Display
6 Cooking zone indicators Timer function
7 Timer display
8 Multipurpose cooking zone
9 Timer
10 Zone selection indicator
11 Stop+Go function
Touch Control sensor fields
The appliance is operated using Touch Control sensor fields. Functions are controlled by
touching sensor fields and confirmed by displays and acoustic signals. Touch the sensor
fields from below, without covering other sensor fields.
Sensor field Function
On / Off To switch the appliance on and off
Increase settings To increase heat settings
Reduce settings To reduce heat settings
Timer To select timer settings
Increase settings To increase Timer time
Reduce settings To reduce Timer time
Lock To lock/unlock the control panel
Stop+Go To switch the Keep Warm setting on/ off
Triple ring switch To switch outer rings on and off
Multi-purpose zone switch To switch the outside ring on and off
Displays
Display Description
Cooking zone is switched off
Keep warm setting Keep warm setting is set
Heat settings Heat setting is set
Automatic warm up function Automatic warm-up function is activated
Error Malfunction has occurred
electrolux 5
Display Description
Residual heat Cooking zone is still hot
Child safety device Lock/child safety device is activated
Automatic switch off Switch off is active
Residual heat indicator
Warning! Risk of burns from residual heat. After being switched off, the cooking
zones need some time to cool down. Look at the residual heat indicator.
Important! Residual heat can be used for melting and keeping food warm.
Operating the appliance
Switching the appliance on and off
Control panel Display Pilot light
Switch on
Touch for 2 seconds /
lights up
Switch off
Touch for 1 second / none
goes out
Important! After switching on, within approx. 10 seconds a heat setting or a function
must be set, otherwise the appliance automatically switches itself off.
Setting the heat setting
Control panel Indicator
To increase
Touch to
To decrease
Touch to
To switch off
Touch and at the same time
The keep warm setting lies between and . It is used to keep food
warm.
Switching the outside ring on and off
By switching the outside rings on or off, the effective heating surface can be matched to the
size of the cookware.
Before an outside ring can be switched
on, the inside ring must be switched on
Triple cooking zone Sensor panel Power indicator
To switch on the middle ring
Touch for 1-2 seconds.
One power indicator is lit.
To switch on the outside ring
Touch for 1-2 seconds.
Two power indicators are lit.
To switch off the outside ring
Touch for 1-2 seconds.
Second power indicator goes
out.
To switch off the middle ring
Touch for 1-2 seconds.
First power indicator goes
out.
Multi-purpose zone Sensor field Pilot light
To switch on outside ring
Touch for 1-2 seconds
is lit
6 electrolux
Multi-purpose zone Sensor field Pilot light
To switch off outside ring
Touch for 1-2 seconds
goes out
Switching the STOP+GO function on and off
The STOP+GO function simultaneously switches all cooking zones that are switched on to
the keep warm setting and then back to the heat setting that was previously set.
Timer functions are not stopped by
STOP+GO.
STOP+GO locks the whole control
panel except the sensor field .
Control panel Display
To switch on
Touch
To switch off
Touch
previously set heat setting
Locking/unlocking the control panel
The control panel, with the exception of the “On/Off” sensor field, can be locked at any time
to prevent the change of settings.
Control panel Display
Switch on
Touch (for 5 seconds)
Switch off
Touch
previously set heat setting
When you switch the appliance off, the
locking function is automatically
switched off.
Using the automatic warm-up function
All cooking zones are equipped with an automatic warm up function
. When setting a
heat setting using
and starting from , the cooking zone switches to full power for a
certain amount of time and then automatically switches back to the heat setting set.
Control panel Possible heat set-
tings
Display
Switch on (only when starting
at
)
Touch to (after 5 seconds)
Switch off
Touch to / to
Not used
Touch to to
If during the automatic warm up
a higher heat setting is selected, e.g.
from
to , the automatic warm
up is adjusted.
If there is still residual heat on the
cooking zone (display
), the
automatic warm up is not per-
formed.
The length of time that the automatic warm up function operates depends on the
heat setting selected.
Heat setting Length of the automatic warm up [min:sec]
0:30
1:00
1:40
4:50
6:30
electrolux 7
Heat setting Length of the automatic warm up [min:sec]
10:10
2:00
3:30
4:30
---
Using the child safety device
The child safety device prevents unintentional use of the appliance.
Switching on the child safety device
Step Control panel Display/Signal
1.
Switch on appliance. (Do not set a
heat setting.)
2.
Touch for 4 seconds
3. The child safety device is switched on.
Switching off the child safety device
Step Control panel Display/Signal
1.
Switch on appliance. (Do not set a
heat setting.)
2
Touch for 4 seconds lights up
3.
Switch appliance off.
4. The child safety device is switched off.
The child safety device can only be switched on and off, if no heat setting is set.
The child safety device can be switched off in this way for a single cooking
session; it remains activated afterwards.
Overriding the child safety device
Step Control panel Display / Signal
1.
Switch appliance on
2.
Touch for 4 seconds lights up
Until the appliance is next switched off, it can be used as normal. After switching off the appliance, the
child safety device is active again.
After overriding the child safety device, a heat setting or a function must be set
within approx. 10 seconds, otherwise the appliance automatically switches it-
self off.
Using the timer
Function Condition Outcome after the time has
elapsed
Automatic cut-out a heat setting is set
acoustic signal and
00
flashes,
the cooking zone switches itself
off
8 electrolux
Function Condition Outcome after the time has
elapsed
Countdown timer cooking zones not in use
acoustic signal and
00
flashes
Selecting a cooking zone
Step Control panel Display
1.
Touch once
Pilot light of the first cooking zone flashes
2.
Touch once
Pilot light of the second cooking zone flashes
3.
Touch once
Pilot light of the third cooking zone flashes
4.
Touch once
Pilot light of the fourth cooking zone flashes
If a heat setting is set on this cooking zone in addition to a countdown timer,
the cooking zone is switched off after the time set has elapsed.
If a cooking zone is switched off, the timer function set is also switched off.
If the pilot light is flashing more slowly, the heat setting can be set or modified.
If other timer functions are set, after a few seconds the shortest remaining time
of all the timer functions is displayed and the corresponding pilot light flashes.
Setting the time
Step Control panel Indicator
1.
Select for the cooking zone
The pilot light for the cooking zone se-
lected flashes
2.
Touch or
00
to
99
minutes
After a few seconds the pilot light flashes more slowly. The time is set. The time counts down.
Switching off the timer function
Step Control panel Indicator
1.
Select for the cooking zone
Pilot light of cooking zone selected
flashes faster. Time remaining is dis-
played
2.
Touch
The time remaining counts backwards
to
00
The pilot light goes out. The Timer function for the selected cooking zone is switched off.
Changing the time
Step Control panel Indicator
1.
Select for the cooking zone
Pilot light of the selected cooking zone
flashes faster. Time remaining is dis-
played
2.
Touch or
0
1
to
99
minutes
After a few seconds, the pilot light flashes more slowly. The time is set. The time counts down.
electrolux 9
Displaying the time remaining for a cooking zone
Step Control panel Indicator
1.
Touch for the cooking zone
Pilot light of the cooking zone selected
flashes faster. The time remaining is
displayed
After a few seconds the pilot light flashes more slowly.
Switching off the acoustic signal
Step Control panel Indicator
1.
Touch
The acoustic signal to acknowledge
The acoustic signal stops
Automatic switch off
• If after switching on the cooking surface, a
heat setting is not set for a cooking zone
within approx. 10 seconds, the cooking
surface automatically switches itself off.
• If one or more sensor fields are covered by
objects (a pan, cloths, etc.) for longer than
approx. 10 seconds, a signal sounds and
the cooking surface switches off
automatically.
• If all cooking zones are switched off, the
cooking surface automatically switches it-
self off after approx. 10 seconds.
• If one of the cooking zones is not switched
off after a certain time, or if the heat setting
is not modified, the relevant cooking zone
switches off automatically.
is dis-
played. Before being used again, the
cooking zone must be set to
.
Heat setting Switches off after
-
6 hours
-
5 hours
4 hours
-
1.5 hours
Tips on cooking and frying
Information on acrylamides
According to the latest scientific knowl-
edge, intensive browning of food,
especially in products containing starch,
can constitute a health risk due to acryla-
mides. Therefore we recommend cook-
ing at the lowest possible temperatures
and not browning foods too much.
Cookware
• You can recognise good cookware from
the bottoms of the pans. The bottom
should be as thick and flat as possible.
• Cookware made of enamelled steel or with
aluminium or copper bottoms can leave
discolorations on the glass ceramic sur-
face which are difficult or impossible to
remove.
Energy saving
Always place cookware on the cooking
zone before it is switched on.
Switch cooking zones off before the end
of the cooking time, to take advantage
of residual heat.
If possible, always place lids on the
pans.
10 electrolux
Bottom of pans and cooking zones
should be the same size.
Cleaning and Care
Warning! Watch out! Risk of burns from residual heat.
Warning! Sharp objects and abrasive cleaning materials will damage the
appliance. Clean with water and washing up liquid.
Warning! Sharp cleaning agents will damage the appliance. Remove residues
with water and washing up liquid.
Cleaning the appliance after each use:
1. Wipe the appliance with a damp cloth
and a little washing up liquid.
2. Rub the appliance dry using a clean cloth.
Removing deposites
Remove
Type of dirt at once
when the appliance has
cooled down
using
sugar, food containing
sugar
yes ---
a scraper
1)
plastics, tin foil yes ---
a scraper
1)
limescale and water
rings
--- yes
cleaner for glass ceramic or
stainless steel
1)
fat splashes --- yes
cleaner for glass ceramic or
stainless steel
1)
shiny metallic
discoloration
--- yes
cleaner for glass ceramic or
stainless steel
1)
1) *Scrapers and cleaners for glass ceramic and stainless steel can be purchased in specialized shops
Removing deposites
1. Place a scraper on the glass ceramic sur-
face at an angle.
2. Remove residues by sliding the blade
over the surface.
3. Wipe the appliance with a damp cloth
and a little washing up liquid.
4. Rub the appliance dry using a clean cloth.
Remove stubborn residues with a
cleaner for glass ceramic or stain-
less steel.
Scratches or dark stains on the
glass ceramic that cannot be re-
moved do not however affect the
functioning of the appliance.
Warning! Residues from cleaning
agents will damage the appliance.
Remove residues with water and
washing up liquid.
electrolux 11
What to do if ...
Problem Possible cause Remedy
The cooking zones will not
switch on or are not func-
tioning.
More than 10 seconds have
passed since the appliance was
switched on
Switch the appliance on again.
The child safety device is switched
on
Deactivate the child safety device
(See the section “Child safety de-
vice”)
Several sensor fields were touched
at the same time
Only touch one sensor field
Automatic switch off has been trig-
gered
Remove any objects (pan, cloths,
etc.) that are lying on the control
panel. Switch the appliance on
again
The lock is switched on
Switch off the lock (See the section
“Locking/unlocking the control
panel”)
Acoustic signal sounds
when appliance is
switched off
The control panel is wholly or partly
covered by objects.
Remove objects.
The residual heat indicator
is not displaying anything
The cooking zone was only on for a
short time and is therefore not hot
If the cooking zone is supposed to
be hot, call the Customer Service
Department.
The automatic warm up
function is not switching it-
self on
There is still residual heat on the
cooking zone
Let the cooking zone cool down
The highest heat setting is set
The highest heat setting has the
same power as the automatic
warm up function
The heat setting was set using the
sensor field
1. Switch off the cooking zone
2. Set the cooking zone using the
sensor field
Acoustic signal sounds
and appliance switches it-
self on and then off again;
after 5 seconds another
acoustic signal sounds
The On/Off sensor field has been
covered up, e.g. by a cloth
Do not place any objects on the
control panel
is lit
Overheating protection for the
cooking zone has been triggered
Switch off the cooking zone.
Switch the cooking zone on again
Automatic switch off has been trig-
gered
Switch off the cooking zone.
Switch the cooking zone on again
and number are dis-
played
Electronics fault Disconnect the appliance from the
electrical supply for a few minutes
(Take the fuse out of the house’s
wiring system) If after switching on
again,
is displayed again, call
the customer service department
If you are unable to remedy the problem
by following the above suggestions,
please contact your dealer or the
Customer Care Department.
Warning! Repairs to the appliance
are only to be carried out by
qualified service engineers.
12 electrolux
Considerable danger to the user
may result from improper repairs.
If the appliance has been wrongly
operated, the visit from the
customer service technician or
dealer may not take place free of
charge, even during the warranty
period.
Technical data
Model EHET 66CS EHET 96CS
PNC 949 163 050 949 163 051
Product dimensions
(w x d) mm
612 x 530 896 x 518
Cut-out dimensions
(w x d) mm
560 x 490 (485) 880 x 490 (485)
Voltage (volts) 230 230
Cycles (Hz) 50 50
Service Cord not fitted not fitted
elements
no.
zones
watts
no.
zones
watts
left front 3 2300/1600/800 3 2300/1600/800
left rear 1 1200 1 1200
right front 1 1200 1 1800
right rear 1 1800 2 2200/1400
total 6500 7500
Disposal
The symbol on the product or on its
packaging indicates that this product may
not be treated as household waste. Instead
it should be taken to the appropriate
collection point for the recycling of electrical
and electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for
the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. For more
detailed information about recycling of this
product, please contact your local council,
your household waste disposal service or the
shop where you purchased the product.
Packaging material.
The packaging materials are
environmentally friendly and can be
recycled. The plastic components
are identified by markings, e. g.,
>PE<, >PS< etc. Please use mark-
ings to dispose of the packaging
materials in the appropriate
container at the community waste
disposal facilities.
Installation Instructions
Warning! Safety instructions Warning! This must be read! The laws,
ordinances, directives and standards in
force in the country of use are to be
followed (safety regulations, proper
recycling in accordance with the
regulations, etc.)
electrolux 13
Important! Installation may only be carried
out by a qualified electrician.
The minimum distances to other appliances
and units are to be observed.
Anti-shock protection must be provided by
the installation, for example drawers may
only be installed with a protective floor
directly underneath the appliance.
The cut surfaces of the worktop are to be
protected against moisture using a suitable
sealant. The sealant seals the appliance to
the work top with no gap. Do not use silicon
sealant between the appliance and the work
top.
Avoid installing the appliance next to doors
and under windows. Otherwise hot cook-
ware may be knocked off the rings when
doors and windows are opened.
Caution! Warning! Risk of injury
from electrical current.
• The electrical mains terminal is live.
• Make electrical mains terminal free of volt-
age.
• Follow connection schematic.
• Observe electrical safety rules.
• Ensure anti-shock protection by installing
correctly.
• The appliance must be connected to the
electrical supply by a qualified electrician.
• Loose and inappropriate plug and socket
connections can make the terminal over-
heat.
• Have the clamping connections correctly
installed by a qualified electrician.
• Use strain relief clamp on cable.
Caution! The surface temperature
exceeds 95°C. To avoid a hazard,
underbench access must be restric-
ted
Electrical Connection
Before connecting, check that the nominal
voltage of the appliance, that is the voltage
stated on the rating plate, corresponds to the
available supply voltage. Also check the
power rating of the appliance and ensure that
the wire is suitably sized in accordance with
local wiring rules to suit the appliance power
rating. The rating plate is located on the lower
casing of the hob. The heating element volt-
age is AC230V~. The appliance also works
perfectly on networks with AC220V~ or
AC240V~. Means for disconnection must be
incorporated in the fixed wiring in accord-
ance with local wiring rules.The hob is to be
connected to the mains using a device that
allows the appliance to be disconnected
from the mains at all poles with a contact
opening width of at least 3 mm, eg.
automatic line protecting cut-out, earth leak-
age tripsorfuse. If this appliance’s mains ca-
ble is damaged, it must be replaced by a
special cable (type H05BB-F Tmax 90°C; or
higher). The latter is available from the
Customer Care Department. The connection
must be carried out as shown in the diagram.
The connecting links should be fitted accord-
ing to the appropriate connection diagram.
The earth lead is connected to terminal
.
The earth lead must be longer than leads
carrying electric current. The cable con-
nections must be made in accordance
with regulations and the terminal screws
tightened securely. Finally, the connecting
cable is to be secured with the mains cable
cleat and the covering closed by pressing
firmly (lock into place). Before switching on
for the first time, any protective foil or stickers
must be removed from the glass ceramic
surface.
Warning! Once connected to the
mains supply check that all cooking
zones are ready for use by briefly
switching each on in turn at the
maximum setting.
• A duplicate rating label is supplied
with this unit. For easy identification of
this unit after installation, stick it to a
readily available surface adjacent to
the cooktop.
Sticking on the seal
• Clean the worktop around the cutout area.
• Stick the single-sided adhesive sealing
tape provided on the underside of the hob
around the outside edge ensuring that it is
not stretched. The two ends of the tape
should join in the middle of one side. After
trimming the tape (allow it to overlap by 2-3
mm), press the two ends together.
14 electrolux
The cut-out section in the worktop
is illustrated in the drawing with the
dimensions 560 x 490 / 880 x 490
mm. The appliance can also be built
into a shorter cut-out section with
the dimensions 560 x 485 / 880 x 485
mm.
Assembly
EHET 66CS EHET 96CS
Warning! Surface temperatures of base exceed 95°C, under bench access must
be restricted by use of non-combustible barrier on installation
electrolux 15
Rating plates
EHET 66CS
PNC:
949163050
Made in China
Model: EHET66CS
APP NO.:55HAD GL A0
AU APP NO.:S/91
S NO: 80200950 50Hz 6.5 KW
220 - 240 V AC
220 - 240 V
EHET 96CS
PNC:
949163051
Made in China
Model: EHET96CS
APP NO.:55HCD GL A0
AU APP NO.:S/91
S NO: 80200949 50Hz 7.5 KW
220 - 240 V AC
220 - 240 V
Warranty
FOR SALES IN AUSTRALIA AND NEW ZEA-
LAND
This document sets out the terms and
conditions of product warranties for
Electrolux branded appliances. It is an
important document. Please keep it with
your proof of purchase documents in a
safe place for future reference should
you require service for your Electrolux
appliance. General Terms and Condi-
tions
1. In this warranty
– Electrolux' means Electrolux Home
Products Pty Ltd ABN 51 004 762 341
in respect of Appliances purchased in
Australia and Electrolux (NZ) Limited in
respect of Appliances purchased in
New Zealand;
– 'Appliance' means any Electrolux
product purchased by you accompa-
nied by this document;
– 'Warranty Period' means
i) where you use the Appliance for
personal, domestic or household pur-
poses in Australia the period of 24
months and in New Zealand the
period of 24 months;
ii) where you use the Appliance for
commercial purposes, in Australia the
period of 3 months and in New Zea-
land the period of 3 months, (if the
period stated is 0 months you are not
covered by this product warranty) fol-
lowing the date of original purchase of
the Appliance;
– 'you' means the purchaser of the Ap-
pliance not having purchased the ap-
pliance for re-sale, and 'your' has a
corresponding meaning.
2. This warranty only applies to Appliances
purchased and used in Australia or New
Zealand and is in addition to (and does
not exclude, restrict, or modify in any
way) any non-excludable statutory war-
ranties in Australia or New Zealand.
3. Electrolux warrants that, when
dispatched from an Electrolux ware-
house, the Appliance is free from defects
in materials and workmanship for the
Warranty Period.
16 electrolux
4. During the Warranty Period Electrolux or
its Authorised Service Centre will, at no
extra charge if your appliance is readily
accessible without special equipment,
and subject to these terms and condi-
tions, repair or replace any parts which it
considers to be defective. You agree that
any replaced Appliances or parts be-
come the property of Electrolux. This
warranty does not apply to light globes,
batteries, filters or similar perishable
parts.
5. Parts and Appliances not supplied by
Electrolux are not covered by this
warranty.
6. Where you are within an Electrolux serv-
ice area, this warranty covers the cost of
transport of the Appliance to and from
Authorised Service Centres of Electrolux
and travelling costs for representatives of
the Authorised Service Centre to and
from your home or business. If you are
outside an Electrolux service area, you
will bear these costs. For information
about whether you are within an Electro-
lux service area, please phone 13 13 49
in Australia, or 0800 10 66 10 in New
Zealand.
7. Proof of purchase is required before you
can make a claim under this warranty.
8. You may not make a claim under this
warranty unless the defect claimed is
due to faulty or defective parts or work-
manship. Electrolux is not liable in the
following situations (which are not ex-
haustive):
– The Appliance is damaged by
i) accident
ii) misuse or abuse, including failure to
properly maintain or service
iii) normal wear and tear
iv) power surges, electrical storm
damage or incorrect power supply
v) incomplete or improper installation
vi) incorrect, improper or inappropriate
operation
vii) insect or vermin infestation.
– The Appliance is modified without
authority from Electrolux in writing.
– The Appliance's serial number or
warranty seal has been removed or
defaced.
– The Appliance was serviced or re-
paired by anyone other than Electrolux
or its Authorised Service Centres.
9. This warranty, the contract to which it
relates and the relationship between you
and Electrolux are governed by the law
applicable in the Australian State where
the Appliance was purchased or the law
applicable in New Zealand if the Appli-
ance was purchased in New Zealand.
Where the Appliance was purchased in
New Zealand for business purposes the
Consumer Guarantee Act does not ap-
ply.
Limitation of Liability
10. To the extent permitted by law:
– Electrolux excludes all warranties
other than as contained in this docu-
ment;
– Electrolux shall not be liable for any
loss or damage whether direct or in-
direct or consequential arising from
your purchase, use or non-use of the
Appliance.
11. Provisions of the Trade Practices Act
and State consumer legislation in
Australia, and the Consumer Guaran-
tees Act, the Sale of Goods Act and the
Fair Trading Act in New Zealand, imply
warranties or conditions, or impose ob-
ligations, upon Electrolux which cannot
be excluded, restricted or modified. To
the extent permitted by law, the liability
of Electrolux (if any) arising out of or in
relation to the Appliance or any services
supplied by Electrolux shall be limited
(where it is fair and reasonable to do so),:
– in the case of Appliances, at its option,
to the replacement or repair of the Ap-
pliances or the supply of equivalent
products or the payment of the cost of
replacing the Appliances or having the
Appliances repaired or of acquiring
equivalent Appliances. Upon being re-
placed, parts and Appliances become
the property of Electrolux; or
– in the case of services, at its option, to
the supply of the services again or the
payment of the cost of having the
services re-supplied;
and in the case of Appliances or services
supplied in New Zealand, loss or dam-
age whether direct or indirect or conse-
quential that is reasonably foreseeable.
electrolux 17
Privacy
You acknowledge that in the event that you
make a warranty claim it will be necessary for
Electrolux and its Authorised Service Centres
to exchange information in relation to you to
enable Electrolux to meet its obligations un-
der this warranty.
Important Notice
Before Calling a Service Technician please
check carefully the operating instructions,
service booklet and the warranty terms and
conditions.
FOR SERVICE
OR TO FIND THE ADDRESS OF
YOUR NEAREST STATE SERV-
ICE CENTRE IN AUSTRALIA
Please call 13 13 4 9
For the cost of a local call (Australia only)
SERVICE AUSTRALIA
ELECTROLUX HOME PROD-
UCTS
FOR SPARE PARTS
OR TO FIND THE ADDRESS OF
YOUR NEAREST STATE
SPARE PARTS CENTRE IN
AUSTRALIA
Please call 13 13 50
For the cost of a local call (Australia only)
FOR SERVICE
OR TO FIND THE ADDRESS OF
YOUR NEAREST AUTHORISED
SERVICE CENTRE IN NEW
ZEALAND
Free call 0800 10 66 10
SERVICE NEW ZEALAND
ELECTROLUX HOME PROD-
UCTS
FOR SPARE PARTS
OR TO FIND THE ADDRESS OF
YOUR NEAREST SPARE
PARTS CENTRE IN NEW ZEA-
LAND
Free call 0800 10 66 20
Service
In the event of technical faults, please first
check whether you can remedy the problem
yourself with the help of the operating in-
structions (section “What to do if…”).
If you were not able to remedy the problem
yourself, please contact the Customer Care
Department or one of our service partners.
In order to be able to assist you quickly, we
require the following information:
– Model description
– Product number (PNC)
– Serial number
(S No. - see rating plate)
–Type of fault
– Any error messages displayed by
the appliance
– three digit letter-number combination
for glass ceramic
18 electrolux
electrolux 19
892930001-B-032008-03
www.electrolux.com
www.electrolux.com.au
