ENGLISH
USER’S MANUAL
Thank you very much for purchasing the HITACHI LCD Monitor.
Before using your monitor, please carefully read the "SAFETY
INSTRUCTIONS" and this "USER'S MANUAL" so you will
know how to operate the monitor properly. Keep this manual in
a safe place. You will find it useful in the future.
Notes on lnstallation Work:
This product is marketed assuming that it is installed by qualified
personnel with enough skill and competence. Always have an
installation specialist or your dealer install and set up the product.
HITACHI cannot assume liabilities for damage caused by mistake
in installation or mounting, misuse, modification or a natural
disaster.
Note for Dealers:
After installation, be sure to deliver this manual to the customer
and explain to the customer how to handle the product.
1
ENGLISH
Important
Please read this User's Manual thoroughly, especially the Safety
Instructions on Page 3 to 6. Mis-use may cause damage to your
LCD monitor, which could shorten its lifespan, or cause injury to
yourself. Should you encounter any difficulty in the set-up or
operation of your monitor, firstly refer to the Troubleshooting
guide at the rear of this manual.
In the unlikely event of a problem occurring with your LCD
monitor, switch off at the mains sockets, pull out the plugs, and
contact your dealer immediately.
CAUTION
Under no circumstances remove the rear cover of your LCD
monitor.
Never guess or take any chances with electrical equipment of
any kind - it is better to be safe than sorry!
Software Notice
It is prohibited for the end user of this product to copy, reverse
engineer or reverse compile the software included therein, save
to the extent permitted by law.
LCD Monitor
After the LCD monitor has been on for any length of time, you will
notice that the screen becomes warm. Please note that this is
normal.
Sometimes the screen might have some tiny bright or dark spots.
Please note that this is normal.
CAUTION
To prevent scratches or damages to the LCD screen, do not
knock or rub the surface with sharp or hard objects. Clean the
screen with a soft cloth moistened with warm water and dry with
a soft cloth. A mild soap may be used if the screen is extremely
dirty. Do not use harsh or abrasive cleaners!
CAUTION
Use a soft cloth to clean the cabinet and control panel of the
monitor. When excessively soiled dilute a neutral detergent in
water, wet and wring out the soft cloth and afterward wipe with a
dry soft cloth.
Never use acid/alkaline detergent, alcoholic detergent, abrasive
cleaner, powder soap, OA cleaner, car wax, glass cleaner, etc.
especially because they would cause discoloration, scratches or
cracks.
Large-screen, high-definition LCD panel
The 32-inch color LCD panel with a resolution of 1366(H) X
768(V) pixels, creates a high-definition, large-screen (aspect
ratio:16:9) and low-profile flat display. Free from electromagnetic
interferences from geomagnetic sources and ambient power
lines, the panel produces high-quality display images free from
color misconvergence and display distortion.
High Performance Digital Processor
A wide range of input signals can be handed, including
composite, component, and HDMI.
High Definition Digital Processor creates the fine-textured image
with dynamic contrast.
In addition, it corresponds to a broad array of personal computer
signals, from 640 x 400 and 640 x 480 VGA to 1600 x 1200
UXGA. (Analog Input)
Easy-to-use remote control and on screen display
system
The remote control included eases the work of setting display
controls. Further, the on-screen display system, displays the
status of signal reception and display control settings in an easy-
to-view fashion.
Power saving system
The International ENERGY STAR® power saver feature saves
power consumption automatically when input signals are not
available. When connected to a VESA DPMS-compliant PC, the
monitor cuts its power consumption while it is idle.
Connecting to an Audio Visual Device
• Two composite/S terminals
*1
, three composite terminals
*2
, two
component terminals
*2
and a HDMI terminal have been added. A
composite video output terminal is also provided as a monitoring
output.
*1
A composite/S terminal = A side input.
*2
If two composite terminal and two component terminal are
used at the same time, the component terminal would govern.
• A wide range of devices can also be connected besides personal
computers.
• A RGB input is possible to switch to component signals from the
Menu screen.
Power Swivel Feature
It allows to turn the LCD monitor left or right within ± 30 degree
using the remote control.
FEATURES
2
FEATURES .......................................................... 1
SAFETY INSTRUCTIONS .................................... 3
NOTES ................................................................ 7
COMPONENT NAMES ......................................... 8
Main Unit ............................................................................... 8
Remote control ...................................................................... 9
Loading Batteries............................................................... 9
Handling the Remote Control ............................................ 9
INSTALLATION INSTRUCTIONS ...................... 12
Installation ........................................................................... 12
Anti-tumble measures ......................................................... 12
Connection to an Audio Visual Device ................................ 13
Connecting to a PC ............................................................. 15
Connecting the Speaker Cables .......................................... 16
Mounting the Side Input ...................................................... 17
Power Cord Connection ...................................................... 18
OPERATING INSTRUCTIONS ........................... 19
Turning Power On and Off .................................................. 19
Input Switching .................................................................... 20
Size Switching ..................................................................... 20
Volume Adjustment ............................................................. 22
Audio Mute .......................................................................... 22
Power Swivel ....................................................................... 23
Input Signal Screen Display ................................................ 24
Displaying MULTI PICTURE ............................................... 25
Picture Freezing .................................................................. 27
Using the Menu Screen ....................................................... 28
SETUP MENU (TV mode) ................................................... 29
SETUP MENU (Video mode) .............................................. 31
SETUP MENU
(RGB mode: RGB1 (DVI-PC), RGB2 (RGB)) ...................... 32
FUNCTION MENU .............................................................. 34
PICTURE MENU (TV/Video mode) ..................................... 35
PICTURE MENU (RGB mode) ............................................ 38
AUDIO MENU ..................................................................... 39
TIMER MENU ..................................................................... 40
LANGUAGE MENU ............................................................. 40
OTHER FEATURES ........................................... 41
Automatic Store ................................................................... 41
Audio Switching ................................................................... 42
Power Save Mode ................................................................ 43
DVD Player/ STB Selection ................................................. 43
Signal Check (RGB mode) ................................................... 44
TROUBLESHOOTING ....................................... 45
Symptoms That Seemingly Appear to be Failures ............... 45
Actions to Correct Abnormal Displays ................................. 47
PRODUCT SPECIFICATIONS ............................ 48
Signal Input .......................................................................... 49
Recommended Signal List ................................................... 50
CONTENTS
Note about This Manual
• The information in this manual is subject to change without notice.
• While meticulous care has been taken in the preparation of this manual, you are requested to notify your dealer or us should you have
any comments, views or questions about our product.
• Fully understand the prerequisites to using the product, such as hardware and software specifications and constraints, in using the
product. We are not held liable for damages caused by improper handling of the product.
• Reproduction of this manual in whole or in part without our prior written permission is prohibited.
• The product names mentioned in this manual may be trademarks or registered trademarks of their respective owners.
3
ENGLISH
This LCD monitor has been designed and manufactured to meet international safety standards, but like any electrical equipment, care
must be taken if you are to obtain the best results and safety is to be assured.
Before using this product, please read and understand the Safety Instructions thoroughly to ensure correct usage, and follow all the
instructions.
Various symbols are used in this manual, the user’s manual and on the product itself to ensure correct usage, to prevent danger to the
user and others, and to prevent property damage. The meanings of these symbols are described below. It is important that you read
these descriptions thoroughly and fully understand the contents.
This symbol indicates information that, if ignored, could possibly result in personal injury or even death due to
incorrect handling.
This symbol indicates information that, if ignored, could possibly result in personal injury or physical damage due to
incorrect handling.
Typical Symbols
Never use the monitor if a problem should occur.
Abnormal operations such as smoke, strange odor, no image, no sound, excessive sound, damaged casing, elements,
cables, penetration of liquids or foreign matter, etc. can cause a fire or electrical shock.
In such case, immediately turn off the power switch and then disconnect the power plug from the power outlet. After
making sure that the smoke or odor has stopped, contact your dealer. Never attempt to make repairs yourself because this
could be dangerous.
Do not insert liquids or foreign objects.
Penetration of liquids or foreign objects could result in fire or electrical shock. Use special caution in households where
children are present.
If liquids or foreign objects should enter the monitor, immediately turn off the power switch, disconnect the power plug from
the power outlet and contact your dealer.
• Do not place the monitor in a bathroom.
• Do not expose the monitor to rain or moisture.
• Do not place flower vases, pots, cups, cosmetics, liquids such as water, etc on or around the monitor.
• Do not place metals, combustibles, etc on or around the monitor.
Never disassemble or modify the monitor.
The monitor contains high voltage components. Modification could result in fire or electrical shock.
• Never remove any fixed cover.
Do not give the monitor any shock or impact.
If the monitor should be shocked and/or broken, it could result in an injury, and continued use could result in fire or
electrical shock. If the glass panel is broken or damaged, immediately turn off the power switch, disconnect the power plug
from the power outlet and contact your dealer.
Do not place the monitor on an unstable surface.
If the monitor should be dropped and/or broken, it could result in an injury, and continued use could result in fire or electrical
shock.
• Do not place the monitor on an unstable, slant or vibrant surface such as a wobbly or inclined stand.
Do not obstruct the ventilation of the monitor.
If the ventilation is obstructed during the operation of the monitor or just after switching off the power, it could result in
damage and shorten the lifespan of your monitor due to overheating. Make sure there is ample ventilation.
• Keep a space of 100mm (10cm) or more between the sides, rear and top of the monitor and other objects such as walls.
• Do not place anything around ventilation openings of the monitor.
• Never block ventilation openings.
• Do not put the LCD screen side up.
• Do not cover the monitor with a tablecloth, etc.
• Do not place the monitor on a carpet or bedding, or near a curtain.
Use only the correct power outlet.
Incorrect power supply could result in fire or electrical shock. Use only the correct power outlet depending on the indication
on the monitor and the safety standard.
• The enclosed power cord must be used depending on the power outlet to be used.
This symbol indicates an additional warning (including cautions). An illustration is provided to clarify the contents.
This symbol indicates a prohibited action. The contents will be clearly indicated in an illustration or nearby (the symbol to the
left indicates that disassembly is prohibited).
This symbol indicates a compulsory action. The contents will be clearly indicated in an illustration or nearby (the symbol to
the left indicates that the power plug should be disconnected from the power outlet).
SAFETY INSTRUCTIONS
About the Symbols
WARNING
CAUTION
WARNING
Disconnect the
plug from the
power outlet.
Do not
disassemble.
4
Be cautious of the power cord connection.
Incorrect connection of the power cord could result in fire or electrical shock.
• Do not touch the power cord with a wet hand.
• Check that the connecting portion of the power cord is clean (with no dust), before using. Use a soft and dry cloth to clean the
power plug.
• Insert the power plug into a power outlet firmly. Avoid using a loose, unsound outlet or contact failure.
• Do not cut off the fitted power plug, the removal of which could lead to impaired performance. If you wish to extend the lead,
obtain an appropriate extension lead or consult your dealer.
• Should you require replacing the fuse in the molded plug with a new fuse, then please replace with new one of the same value,
type and approval as the original. Ensure the fuse cover is returned to its original position.
Be sure to keep safety ground connection.
Connect the ground terminal of AC inlet of this monitor with the ground terminal provided at the power outlet using the
enclosed power cord. If the provided plug does not fit your outlet, consult an electrician for replacement of the obsolete outlet.
Be careful in handling the power cord and external connection cables.
If you keep using a damaged power cord or cables, it can cause a fire or electrical shock. Do not apply too much heat, pressure or
tension to the power cord and cables.
If the power cord or cables are damaged (exposed or broken core wires, etc.), contact your dealer.
• Do not place the monitor or heavy objects on the power cord and cables. Also, do not place a spread, cover, etc, over them
because this could result in the inadvertent placing of heavy objects on the concealed power cord or cables.
• Do not pull the power cord and cables. When connecting and disconnecting the power cord or cables, do it with your hand
holding the plug or connector.
• Do not place the cord near the heater.
• Do not touch the power plug just after disconnecting it from the power outlet to prevent electric shock.
• Do not touch the power plug when lightening is close to you.
• Avoid coiling the power cord and bending it sharply.
• Protect the power cord from being walked on, pinched particularly at plugs, conveniences receptacles, and the point where they exit from
the apparatus.
• Do not modify the power cord.
Be careful in handling the battery of the remote control.
Incorrect handling of the battery could result in fire or personal injury. The battery may explode if not handled properly.
• Keep the battery away from children and pets. If swallowed consult a physician immediately for emergency treatment.
• Do not allow the battery to be exposed to fire or water.
• Avoid fire or high-temperature environment.
• Do not hold the battery with metallic tweezers.
• Keep the battery in a dark, cool and dry place.
• Do not short circuit the battery.
• Do not recharge, disassemble or solder the battery.
• Do not physically impact the battery.
• Use only the battery specified in the manual of this monitor.
• Make sure the plus and minus terminals are correctly aligned when loading the battery.
• If you observe a leakage of the battery, wipe out the liquid and then replace the battery. If the liquid adheres your body or clothes, rinse well
with water.
• Obey the local laws on disposing the battery.
SAFETY INSTRUCTIONS (continued)
About the Symbols (continued)
WARNING
Surely connect
the ground wire.
5
ENGLISH
Be careful in moving the monitor.
Neglect could result in an injury or damage.
• Do not move the monitor during use. Before moving, disconnect the power plug and all external connections.
• You are advised to move the monitor with two persons.
• Avoid any impact or shock to the monitor; particularly take care of glass screen.
Do not put anything on top of the monitor.
Placing anything on the monitor could result in loss of balance or falling, and cause an injury or damage. Use special caution
in households where children are present.
Avoid a humid or dusty place.
Placing the monitor in a smoke, a highly humid, dusty place, oily soot or corrosive gas could result in fire or electrical shock.
• Do not place near the kitchen, a humidifier or other place where there is oil, smoke or humidity.
Avoid a high temperature environment.
The heat could have adverse influence on the monitor and other parts, and could result in transformation, melting or fire.
• Do not place the monitor, the remote control and other parts in direct sunlight or near a hot object such as heater, etc.
• Do not put the monitor in a place where the temperature is widely changing.
Remove the power cord for complete separation.
• For safety purposes, disconnect the power cord if the monitor is not to be used for prolonged periods of time.
• Before cleaning, turn off and unplug the monitor. Neglect could result in fire or electrical shock.
Be careful in operating power swivel.
Placing hands or faces near the monitor while operating the swivel function could cause a physical injury or damage.
Use special caution in households where children are present.
Installation environment
Do not obstruct a ventilation hole.
Do not put the monitor on carpet or blanket, or near a curtain which has a possibility of obstructing a ventilation hole of the monitor.
Do not put the monitor in the following places.
• Hot places such as near heater, place exposed to the direct rays of the sun.
• A place where the temperature is widely changing.
• Places with soot, dust or high humidity.
• Poor air ventilation place.
• Place near fire.
• A wet place such as bathroom, or shower room.
• Place where you can trip over it.
• Always vibrating or strongly vibrating places.
• Distorted or unstable places.
Please avoid installing the monitor directly on the wooden floor. Depending on the quality and the condition of the floor, the monitor
stand may stick to the floor face, and the surface could come off when the monitor is lifted up.
How to view the monitor
If you use the monitor in too dark a room, your eyes may become tired.
Please use it in a reasonably bright room.
Avoid direct rays of the sun to the screen in order to prevent eye fatigue.
Your eyes will get fatigued after viewing the monitor for long period of time.
Relax your eyes by viewing away from the monitor from time to time.
Please watch the monitor in downward direction.
How to clean the LCD screen panel of the monitor
Before cleaning the monitor, turn off the monitor and disconnect the power plug from the power outlet.
To prevent scratching or damaging the LCD screen face, do not knock or rub the surface with sharp or hard objects. Clean the screen with
a soft cloth moistened with warm water and dry with a soft cloth. If it is not enough, then use a cloth with mild detergent. Do not use harsh
or abrasive cleaners.
How to clean the cabinet of the monitor
Use a soft cloth to clean the cabinet and control panel of the monitor. When excessively soiled dilute a neutral detergent in water, wet and
wring out the soft cloth and afterward wipe with a dry soft cloth.
Never use acid/alkaline detergent, alcoholic detergent, abrasive cleaner, powder soap, OA cleaner, car wax, glass cleaner, etc. especially
because they would cause discoloration, scratches or cracks.
SAFETY INSTRUCTIONS (continued)
About the Symbols (continued)
CAUTION
Disconnect the
plug from the
power outlet.
PRECAUTIONS
6
Prevention of an obstacle to Radio receivers
This monitor has been designed pursuant to the international EMI standards. This is to prevent a problem to Radio receivers.
- Keep the monitor away from Radio.
- Adjust Radio antennas in order for the monitor not to receive interference.
- The antenna cable of Radio should be kept away from the monitor.
- Use a coaxial cable for antenna.
You can check if this monitor influences Radio receivers by turning off all other equipment other than the monitor.
If you find a problem receiving Radio when using the monitor, check the instructions mentioned above.
Precautions for the cable connection
- Do ensure that all connections, (including the power plug, extension leads and interconnections between the pieces of equipment), are
properly made and in accordance with the manufacturers instructions. Switch off and withdraw the power plug before making or
changing connections.
- Confirm the connector is fixed tightly when the signal cable is connected.
Also confirm the screws on the connector are tightened.
- Plug the power cord of the monitor into a different socket from that for other equipment, such as Radio etc..
- Use a plug with ground terminal and make sure that it connects to the ground.
Precaution during transportation
Please pay attention when you transport this monitor because it is heavy.
Furthermore, use the original carton box and its packaging materials when the monitor is transported.
Failure to transport the monitor in any carton except the original carton may result in damage to the monitor.
Save the original carton box and all packing material.
Do not push the monitor over sideways as transporting it. It may cause damage on the panel glass, increase of the screen defects and/or
damage of the internal fluorescent lamps.
Do not physically impact the remote control.
A physical impact could cause damage or malfunction of the remote control.
• Take care not to drop the remote control.
• Do not place heavy objects on the remote control.
Avoid strong rays.
Any strong rays (such as direct sun rays or room lighting) onto the remote control sensors could invalidate the remote control.
Avoid radio interference.
Any interfering radiation could cause distorted images or noises.
• Avoid radio generator such as a mobile telephone, transceiver, etc. around the monitor.
Set the sound volume at a suitable level.
It is better to keep the volume level low and close the windows at night to protect the neighborhood environment.
Precautions for the installation
- Do not use makeshift stands and NEVER fix legs with wood screws - to ensure complete safety, always fit the manufacturers approved
stand or legs with the fixings provided according to the instructions.
- Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from tip-over.
- This product is designed to comply with the recommended safety standards for tilt and stability. Do not apply excessive pulling force to
the front, or top, of the cabinet that could cause the product to overturn resulting in product damage and/or personal injury.
- Follow instructions for wall, shelf or ceiling mounting as recommended by the manufacturer.
- Only use the attachments/accessories specified by the manufacturer.
- Consult your dealer if you are in any doubt about installation, operation or safety of your equipment.
Other precautions
- Do not leave equipment switched on when it is unattended unless it is specifically stated that it is designed for unattended operation or
has a stand-by mode. Switch off using the switch on the equipment and show your family how to do this. Make special arrangements for
infirm or handicapped people.
- Disposal of this product may require specific instructions pertaining to your resident region.
- Never guess or take any chances with electrical equipment of any kind - it is better to be safe than sorry!
SAFETY INSTRUCTIONS (continued)
About the Symbols (continued)
7
ENGLISH
About screen defects
• High precision technology is used in the making of LCD panels but there may be dark spots (points that do not illuminate) and bright spots
(points that are too bright) in some cases. These do not indicate a malfunction.
About residual images
• In some cases, residual images may remain after the short-term display of still images is displayed. These will disappear in a few minutes
and the display will return to normal. However, if used in high temperatures, it sometimes spends some tens of minutes to return to normal.
Please note this is not a malfunction.
About the panel screen
• LCD screens display images by illuminating fluorescent lamps inside the panel. Because of this, the temperature of the panel surface may
rise in some cases.Also, LCD panels are made of finely processed glass, so please avoid pushing by fingers or hands and giving strong
impact on the panel. It may cause damage to the LC cells, and/or there is danger of glass breakage.
About the power swivel
• Do not put hands or faces close to the monitor while operating the swivel function. It could cause a physical injury. Use special caution in
households where children are present. (Refer to Power Swivel shown on )
Using in low temperatures
• The response speed of LCD panel becomes slow as the ambient temperature goes down. This feature may cause residual images in some
cases, but this is not a malfunction. It will return to normal in a while after the temperature becomes normal.
NOTES
23
8
COMPONENT NAMES
Cabinet
(front frame)
Panel
Front
Control panel
• ( ) indicates the function while the MENU is displayed on the screen.
SUB-POWER button
19
VOLUME UP/DOWN buttons
( WXADJUST buttons)
22
CHANNEL UP/DOWN button
(STSELECT button)
20
MENU button
28
INPUT SELECT button
(OK button)
20
Remote-control receiver
9
Indicating lamp
19
• The main power switch is located on the top.
Main power switch
19
Caution when moving the main unit
• As this product is heavy, whenever it is moved, two
people are required to transport it safely.
• Whenever the unit is moved it should be gripped by
holding the top of the monitor, and the unit should
then be held at the base on both sides for stability
as shown.
• Do not hold the speaker units while moving the set.
The speaker holders may be separated off and the
monitor may fall, and it may result in a physical
injury.
Rear
External device connection terminals
RGB input terminals
15
Speaker
terminals
16
Speaker
terminals
16
T
S
• Adjustment buttons are located
on the top.
Front
Rear
Main Unit
9
ENGLISH
1. Open the battery cover.
• Slide back and remove the battery cover
in the direction of the arrow.
2. Load batteries.
• Load two Size AA batteries included
observing the correct polarities.
3. Close the battery cover.
• Replace the battery cover in the direction
of the arrow and snap it back into place.
Use the remote control within about 5 m from front of the unit’s
remote-control sensor and within 30 degrees on both sides.
COMPONENT NAMES (continued)
Remote control
POWER button
INPUT SELECT buttons
MENU button
OK button
SOUND MODE button
PROGRAM SELECT buttons
(TV)
TV/TEXT button
(TV)
SWIVEL button
FUNCTION SELECT button
RECALL button
DVD CONTROL buttons
FREEZE/RETURN button
SELECT/ADJUST button
PICTURE MODE button
CH I/CH II button (TV)
CHANNEL UP/DOWN button (TV)
VOLUME UP/DOWN button
MULTI MODE button
MULTI PICTURE button
MUTE button
• Do not use new and old batteries together. The batteries could
explode or leak, resulting in fires, physical injury, or stains.
• When loading batteries, observe their correct polarities as
marked on the product. If loaded in the wrong direction, the
batteries could explode or leak, resulting in fires, physical
injury, or stains.
Loading Batteries
CAUTION
ATTENTION
• Do not drop or impact the remote control.
• Do not splash the remote control with water or put it on a wet
object to avoid possible failures.
• Before leaving the remote control out of use for an extended
period of time, remove the batteries from it.
• If the remote control begins to lack responsiveness, replace the
batteries.
• Strong light such as direct sunlight impinging on the
photoreceptor of the remote control can cause operational
failure. Position this unit to avoid direct contact with such light.
Handling the Remote Control
With in 30 degreesWith in 30 degrees
About 5m
About 3m About 3m
10
COMPONENT NAMES (continued)
Remote control (continued)
INPUT SELECT
Press this button to change input mode.
SOUND MODE
You may recall the sound mode by
pressing this button. Each time pressed,
sound mode is changed in following
sequence.
MusicMovie
SpeechFavorite
PROGRAM SELECT
Press these buttons to select a TV
program directly.
TIME (TV)
Pressing this button can indicate the
time by On-Screen display when
receiving a TV program on the screen
including TELETEXT service with the
time information.
CH I/II
This button is for A2 / NICAM models
only.
MULTI MODE
In multi-picture mode, pressing this
button will change the multi-picture
mode.
DVD and SAT *2
FUNCTION SELECT
Press this button to indicate function
mode with a lamp. *1
*1 FUNCTION SELECT button
This remote control has functions to control other makers of DVD player, DVD Recorder, and Set Top Box as well as this set.
Press the button to switch between TV, DVD and SAT modes.
Each time the button is pressed, the indicator will light below the function selected.
For details, refer to
.
*2 LED
The LED indicator lamps for DVD and SAT have 2 modes (Lit or blinking).
Lit: Indicates the mode that has been selected. Press the button to change modes when the LED is lit.
Blinking: Indicates that the maker of DVD or STB can be set. You can set up the maker of DVD or STB while the LED is still
blinking (30 sec). For details, refer to
.
43
43 44
ZOOM
Press this button can change Picture
size.
SWIVEL
Press this button to rotate TV. Use
cursor key () to select the degree of
rotation.
RECALL (TV)
With this button, the display change
between “--”, “---”, “-” and AV00 on the
top right hand corner of the screen.
“--” is for 2 digit channel selection, “---”
is for 3 digit channel selection and “-” is
for 1 digit channel selection.
RECALL (Video/RGB)
Press this button to display input signal.
MUTE
Press this button to turn off the set
sound. When press again or the
volume up button, the audio will be
restored.
DVD CONTROL
You can use these buttons to operate the
selected brand of DVD player.
FREEZE/RETURN
Press this button to change the picture
to freeze mode. Press it again to return
to normal picture.
PICTURE MODE
You may recall the picture mode by
pressing this button. Each time pressed,
picture mode is changed in following
sequence.
NaturalDynamic Cinema
MULTI PICTURE
Press this button to change the screen
to multi-pictures. Press it again to return
to normal picture.
PHOTO INPUT
These buttons are not available in this
model.
11
ENGLISH
[Buttons for TELETEXT Mode]
TELETEXT FUNCTION
COMPONENT NAMES (continued)
Remote control (continued)
COLOR buttons
(RED, GREEN, YELLOW, BLUE)
PAGE UP / DOWN button
REVEAL button
SUB TITLE button
TEXT / TV+TEXT button
INDEX button
TV / TEXT button
CANCEL button
Buttons on Remote Control Function
TV / TEXT
This switches the receiver between the TV mode and the TELETEXT mode.
TEXT / TV + TEXT
In TELETEXT mode, this button switches between TV+TEXT screen (split) and TELETEXT only.
INDEX
This selects the P100 (100 page).
SUB TITLE
Use this to access a subtitle service directly rather than through a TELETEXT service (subject to subtitle service
broadcasting).
CANCEL
This allows the screen to return to the TV mode temporarily while searching for a required text page. When the
required text page has been received, the page number will be displayed at the top left of the screen. Press the
CANCEL button again to display the TELETEXT screen.
RED
GREEN
YELLOW
BLUE
Each of these buttons selects a link page displayed at the lower part of the screen.
REVEAL
This allows hidden information (found on some teletext pages) to be displayed on the screen.
PAGE UP / DOWN
This button increases / decreases the TELETEXT page number.
NOTE
• Certain pages do not show linked pages at the bottom of the screen. To display linked pages, press the INDEX button.
• Refer to Teletext Language shown on
30
12
Securing to a wall or pillar
Using a commercially available cord, chain and clamp, secure the set to a firm wall
or pillar.
Securing desktop
(1) Using wood screws (two), fasten the set to the clamping screw holes on the rear of the stand
as shown.
(2) Using commercially available wood screws, secure the set firmly in position.
Read SAFETY INSTRUCTIONS ( to ) carefully to ensure maximum safety before proceeding to
these steps:
• Choose an appropriate site and install the product on a level table where the stand is secure.
• Install the monitor to have ready access to a power socket available.
• Make sure that the power switch of this device is turned off.
Use one of the special mount units to install this product. A mount of insufficient strength or inadequate design can cause
overturning or dropping and result in fire, electrical shock or injury. Please note that our company assumes absolutely no
responsibility for personal injuries or property damage caused by use of other mount units or improper installation.
• In order to prevent an internal temperature increase, maintain a space of 10cm (4 inches : For a
desktop setup) or more between the sides and other objects such as walls, etc., so that the
ventilation holes are not blocked.(*)
INSTALLATION INSTRUCTIONS
Installation
WARNING
CAUTION
10cm or more*
Clamp
Cord or chain
Wall or Pillar
Have this unit mounted in a stable place. Take measures to prevent it from tumbling down to avoid possible physical injury.
Loosen a cord or chain enough while operating power swivel to avoid possible troubles.
Anti-tumble measures
CAUTION
Hook
Wall or Pillar
Clamp
Cord or chain
Cord or chain
Wood screw
Two places
3 6
CAUTION
13
ENGLISH
(1) Make sure that the power switch of the monitor is turned off.
(2) Make sure that the power switch of the audio visual device is turned off.
(3) Use a commercially available cable and connector to connect the signal input terminal on the rear panel of this device
and the signal output terminal of the audio visual device.
• If a component input terminal and a composite input terminal of AV1 and AV2 connect to the monitor at the same time, the component input
would govern.
• If a video equipment with an S video output terminal is used, cabling by the S video cable is recommended to provide finer video quality.
(If an S video input terminal and a video input terminal of AV3 or AV5 (side input) connect to the monitor at the same time, S video input
would govern.)
• If the OUTPUT (Monitor) terminal is connected to an external monitor with a 75 Ohm terminal, it is possible to view the same image as on
the main unit. But it is possible to monitor only the composite video signal from AV1 ~ AV5 input or the S video signal from AV3 and AV5
that is displayed on the screen at the time.
• Secure connecting cables to the stand with the provided clamps.
HDIM*
• HDMI (High-Definition Multimedia Interface) is a digital interface based on DVI (Digital Visual Interface), which is an added function for
audio visual equipment.
- It does not have degradation by transmission since it is digital.
- With only one cable, it is possible to transmit both picture signals and audio signals.
• In case of using analog audio when connecting with DVI-HDMI transformation connector, use analog audio terminal for AV1 input.
INSTALLATION INSTRUCTIONS (continued)
Connection to an Audio Visual Device
[An example of connecting audio visual devices]
To audio output
terminals
To component
output terminals
To audio output
terminals
To composite
output terminals
To S-video
output terminal
Power
Cord
Speaker (R) Speaker (L)
To composite
output terminal
To component
input terminals
Antenna
Set-Top Box
DVD Player
VTR
VTR
To component
input terminals
To component
output terminals
To audio output
terminals
To audio input
terminals
To composite
input terminals
Headphone
To S, composite
audio output terminal
To audio output
terminals
Side Input
DVD Player
VTR
HDMI*
Monitor (rear panel)
14
If there are noise appearance in the picture of VHF-Low band channel, please use the double-shielded cable
(not provided) for RF LEADS to reduce the noise.
Precautions when connecting the antenna
• Please use a coaxial cable which is free from interference to connect the antenna. Avoid using a parallel flat
feeder wire as interference may occur, causing reception to be unstable and stripe noise to appear on the
screen.
• Avoid using indoor antenna as this may be affected by interference. Please use CATV net or outdoor
antenna.
• Keep the power cord as far away from the antenna wire as possible.
• For safety, install an external antenna conforming to AS1417.1 (applicable for Australia only)
INSTALLATION INSTRUCTIONS (continued)
Connection to an Audio Visual Device (continued)
15
ENGLISH
(1) Make sure that the display signal of the personal computer to be used is compatible with the specifications of this
device.
• See "PRODUCT SPECIFICATIONS" concerning the specifications of this device. ~
(2) Make sure that the power switch of the personal computer is turned off.
(3) Connect the signal input terminal (RGB 1 or RGB 2) on the rear panel of this device to the display signal output terminal
of the personal computer.
• Use a cable that fits the input terminal of this device and the output terminal of the personal computer.
• Depending on the type of personal computer being connected, the use of an optional conversion adapter or the adapter provided with
the personal computer may be necessary in some cases. For details, refer to the instruction manual of the personal computer or ask
the personal computer manufacturer or your local retail dealer.
INSTALLATION INSTRUCTIONS (continued)
Connecting to a PC
48 52
AUDIO IN
ANALOG INPUT
RGB 2
DIGTAL INPUT
RGB 1
Power cable
connector
Monitor (rear panel)
Speaker (R) Speaker (L)
Power cord
(DVI) (D-SUB)
To signal
output
terminal
(D-sub)
To audio
output
terminal
To audio
output
terminal
3.5 mm
Stereo
mini jack
PC
(Example)
DVD Player
Connecting to a PC Device Connecting to an Audio Visual Device
To signal
output
terminal
(DVI)
To signal
output
terminal
(DVI)
•Setting
RGB1: DVI-PC
RGB2: RGB
For details, refer to
51 52
• Setting
RGB1: DVI-STB
RGB2: Component
For details, refer to
50 51
16
1. Attach the speaker connecting cables to the monitor. (Make sure the ferrite core is toward the monitor side)
2. Attach the speaker cables to speaker systems.
Make sure that the main power switch of the monitor is turned off (standby or indicating lamp: off/red) when removing or
connecting the speaker cables.
INSTALLATION INSTRUCTIONS (continued)
Connecting the Speaker Cables
CAUTION
How to connect
the speaker
cables
Press down
the lever
Insert the
wire
Release
the lever
Treating the wire ends
Please prepare the supplied
speaker cables
Pull off while twisting
Red Black
Connect the
red/black
colored wire
Connect the
red colored
wire
Red Black
Connect the
red/black
colored wire
Connect the
red colored
wire
Ferrite core
Ferrite core
Twist the heads
How to connect
the speaker
cables
Hold down
the lever
Insert the
wire
Release
the lever
Connect the red/black - colored
wire to the Black side.
Connect the red - colored wire to
the Red side.
speaker
terminal
17
ENGLISH
1. Mount the side input into the speaker holder.
Hook the clamps (4 pieces) of the speaker holder into the holes as shown in the figure and pull them down until it sounds click.
Fasten the side input with the speaker holder by the accessory screw.
Refer to about the connection of side input.
See the below figure how to treat the cable.
Make sure to secure the power cable and the connecting cables for other audio visual devices, except the speaker connecting
cables, to the clamps and the cable strap of the monitor stand and the rear of it. When the monitor is swiveled, the connectors may
drop out and generate heat. It could cause fire and/or connector failures.Moreover, when wiring up and securing these cables, give
suitable slack not to rub the stand during swiveling or not to block the action of swivel.
INSTALLATION INSTRUCTIONS (continued)
Mounting the Side Input
13
Side input
Screw X 1
(Included with side input)
2. Mount the side input into the holder on rear of the monitor.
Fasten the side input with the holder by the accessory screw.
See the below figure how to treat the cable.
Speaker Holder
Side Input cable
Side Input cable
Cable strap
Bundle the cables
to be secured
Power cord
Connecting
cable
[An example of treating the cables]
CAUTION
18
Connect the power cord, after completing all other connections.
(1) Connect the power cord to this device.
(2) Connect the power cord plug to the power outlet.
(The type of plug is different from this drawing for some countries.)
• Use only the power cord provided.
• Do not use a power supply voltage other than that indicated (AC100-240V, 50/60Hz) as this may cause fire or electric shock.
INSTALLATION INSTRUCTIONS (continued)
Power Cord Connection
2
1
CAUTION
19
ENGLISH
• To turn the monitor power ON, press the main power
switch on the monitor main unit to ON, and then press the
SUB POWER button of control panel or the POWER button
on the remote control.
• To turn the monitor power OFF, press the SUB POWER
button of control panel or the POWER button on the
remote control, and then press the main power switch on
the monitor main unit to OFF.
• During normal use, the main power switch is set in the ON
position, and the monitor can then be turned ON/OFF using the
SUB POWER button or the POWER button on the remote
control.
Indicating lamp
When the indicating lamp lights in orange or the message “No
Sync. Signal”, “Power Save” or “Invalid Scan Freq.” appears on
the screen, there is something unusual about the status of
reception. See “Power Save Mode” or “Symptoms That
Seemingly Appear to be Failures.”
OPERATING INSTRUCTIONS
Indicating
lamp
Power
status
Operating
Off Off
When the main power switch is set to
OFF.
Lights red
Off
(standby)
When the main power switch is ON, and
the POWER button on the remote control
or the SUB POWER button on the upside
of the monitor is OFF.
Lights green On
When the main power switch is ON, and
the POWER button on the remote control
or the SUB POWER button on the upside
of the monitor is ON.
Lights orange
Off
(Power Save)
When the main power switch is ON, and
the POWER button on the remote control
or the SUB POWER button on the upside
of the monitor is ON.
However, the state is in POWER SAVE
mode.(RGB 1 and RGB 2 only.)
ATTENTION
• Avoid repeatedly turning the monitor on and off at short time
intervals. Failures might result from such operation.
• Turn off the main power switch before leaving the monitor out
of use for an extended period of time.
• If a power failure occurs while the main unit is running, it would
be powered on upon recovery from the failure. Turn off the unit
main power switch before leaving the main unit.
Turning Power On and Off
Main power switch
SUB-POWER button
POWER button
Indicating lamp
43 44 45
20
• Input can be switched by pressing the AV1~6, RGB1 or
RGB2 buttons of the remote control.
• Input can be switched to TV by pressing CHANNEL
UP/DOWN button or PROGRAM SELECT buttons.
• Input can be switched in the sequence of TV AV1
AV2 AV3 AV4 AV5 AV6 RGB1 RGB2 by
pressing the INPUT SELECT button of the control panel.
Each time the ZOOM button of the remote control is
pressed, the screen display size will change in sequence
and the status will be displayed at the bottom of the screen.
• During TV/VIDEO signal input (AV1, AV2, AV3, AV4, AV5,
AV6, RGB1(set to [DVI-STB])and RGB2(set to [Compo-
nent]))
• The size will fix as Full mode and not change when receiving the
component signal of 1080i/50, 1080i/60 or 720p/60.
Display size selection diagram
OPERATING INSTRUCTIONS (continued)
CHANNEL UP/DOWN buttons
INPUT SELECT button
Input Switching
TV AV1 AV2 AV3 AV4
RGB2 RGB1 AV6 AV5
RGB2 RGB1 AV6 AV5
Size Switching
Panoramic
Cinema
Full
Zoom
4:3
Full
INPUT SELECT
buttons
ZOOM button
RECALL button
CHANNEL
UP/DOWN
button
PROGRAM
SELECT
buttons
When you want to Set the display size to Input signal Display screen Remarks
Play a 4:3 image in a 16:9 screen faithfully.
4:3
(4:3 signal)
Blanking occurs on both sides.
Play a 4:3 image in a 16:9 screen with the
height and width of the middle of the screen
enlarged on equal scales and with both sides
appearing somewhat enlarged.
Panoramic
Play a 16:9 VISTA size image in the 4:3 image
faithfully reproduced on the 16:9 screen.
Zoom
(Vista)
• The 4:3 image is called a letterbox
image.
• In some cases, some slight blanking may
remain at the top and bottom.
Play a 21:9 Cinema size image in the 4:3
image expanded vertically on the 16:9 screen.
Cinema
(Cinema)
In some cases, some slight blanking may
remain at the top and bottom.
Play a 4:3 image faithfully in a 16:9 screen in
the standard vertical size and horizontally
squeezed.*
Full
(Squeeze)
* An image with an aspect ratio of 16:9
shrunk horizontally to 4:3 to display in a
4:3 screen
21
ENGLISH
Vertical picture position can be adjusted for [Panoramic], [Zoom] and [Cinema] mode as follows.
1. Press ZOOM button and SELECT buttons during picture size display.
2. Position display will appear.
3. Adjustment range of each picture size are as shown below.
[Panoramic] - 12 to + 12
[Zoom] and [Cinema] - 31 to + 31
4. When 1080i/60 component signal is received, vertical position can be adjusted only one step up. (The range: 0 to +1)
• During RGB Input (RGB1 (set to [DVI-PC]) and RGB2 (set to [RGB]))
* Real mode gives the image of the same shape as it is displayed on a computer monitor.
This mode is only available for VGA (640 X 480), WVGA (864 X 480),SVGA (800 X 600),XGA (1024 X768) and WXGA (1280 X768).
Display area selection diagram (RGB input)
Processes such as compression (thinning) and expansion are performed for the above signal display. Because of this, there is a
possibility that flicker may become noticeable on Zoom (1 ~ 3) depending on the display contents. If this occurs, turning the Vertical
Filter On can reduce the flicker.
ATTENTION
Using a wide-screen monitor
• This monitor has a screen mode selection feature. If an incompatible screen mode is selected to play certain software, such as a TV
program, the image would appear different from the original. Take this into consideration when making screen mode choices.
• Use of this monitor in its enlarged display mode with the wide feature enabled in coffee shops, hotels and other establishments for
commercial or public viewing purposes could infringe on the copyright holder’s right protected by Copyright Law.
• When a normal 4:3 image is displayed over the entire screen in the Panoramic mode, parts of the periphery of the image may disappear
and/or appear distorted in some cases. Use the 4:3 mode to view images, which were created in 4:3 mode.
This mode allows 4:3 content to be viewed without picture distortion.
Resolution Full display Circular display
Display Full Normal Real Zoom1 Zoom2 Zoom3
640 X 480
(VGA)
800 X 600
(SVGA)
1024 X 768
(XGA)
1280 X 1024
(SXGA)
1600 X 1200
(UXGA)
1366 X768
(WXGA)
Selected
character
WXGA Type
can’t select
OPERATING INSTRUCTIONS (continued)
Size Switching (continued)
Position + 31 Position - 31
Press Press
Normal Full Zoom1
Real Zoom3 Zoom2
32
33
22
The volume can be adjusted by pressing the and
buttons of the remote control (or the and volume
buttons of the monitor unit).
• When a button is pressed, the volume adjustment status
guide will be displayed.
• The volume will increase when the button is pressed while
the guide is being displayed.
• The volume will decrease when the button is pressed while
the guide is being displayed
The audio volume can be temporarily muted by pressing the
MUTE button of the remote control.
• When a button is pressed, the volume adjustment status
guide (magenta) will be displayed.
• The volume setting can be lowered by pressing the button
while the audio is mute.
• The muting can be cancelled by pressing the button or
MUTE button while the audio is mute.
• The audio from the headphone terminal is not mute.
• The audio from the speaker is automatically mute while
connecting the headphone to the headphone terminal of the
side input (AV5).
When the MUTE button of the remote control is pressed
again, the audio will be restored and the volume display
(green) will appear.
OPERATING INSTRUCTIONS (continued)
Volume Adjustment
Volume setting value
Adjustment status guide display
Audio Mute
Volume setting value
Adjustment status guide display
(The display color will change to magenta : volume → Mute)
23
ENGLISH
• This feature controls the motorized stand. It allows turning the LCD monitor left or right using the remote control.
1. Press Swivel button.
The controlling icon appears on the screen.
• If the connecting cable is not connected, the indication "Not Available" appears.
• The swivel display disappears in about 6 seconds without any operation.
2. Adjust for preferred angle.
Opposite directions are displayed on the screen while the monitor is swiveled.
Adjust by using key while the swivel display is on the screen.
Swiveling angle of the monitor is available within ±30 degrees from the front face.
Make sure that the main power switch of the monitor is turned off when removing or connecting the power cord, the connector
cables, and the speaker cables.
ATTENTION
• Do not push the panel manually while using the swivel function. It could cause damage to the stand or the panel.
• Do not get on and hang from the monitor. Do not swing the monitor back and forth and around either. It could cause a failure of the
stand.
• Do not put hands or faces close to the monitor while operating the swivel function. It could cause a physical injury. Use special caution
in households where children are present.
• Do not put any object, like a vase, near the monitor in swiveling area. It would cause a breakage of the object and /or a failure of the
stand.
• Place the monitor on the stable location, or the swivel function would not operate correctly. It would cause a malfunction.
• In the case of using the monitor wall mounted, be sure to detach the connecting cable between the monitor and the stand.
Caution when connecting the monitor with the stand
• When detaching the stand from
the monitor, make sure to
detach the connector cable from
the stand connection terminal on
the rear of the monitor.
• When attaching the stand to the monitor
once again, insert the connector cable
into the stand connection terminal on the
rear of the monitor.
• Make sure that the direction of the connector for stand connecting cable is correct.
OPERATING INSTRUCTIONS (continued)
Power Swivel
WARNING
Swivel
Pinch right and
left locks of the
connector and pull
out downward.
Insert until it clicks.
24
The input signal status can be displayed on the
screen by pressing the RECALL button of the
remote control.
• The display will go out in approximately 6 seconds.
OPERATING INSTRUCTIONS (continued)
Input Signal Screen Display
RGB
Input mode
Signal mode
Input horizontal frequency
Input vertical frequency
Off-timer
On-timer
RECALL button
AV1
Composite
-- -- Min.
-- -- : -- --
OFF
ON
VIDEO
Input mode
Signal mode
Off-timer
On-timer
1
ABCDE
-- -- Min.
-- -- : -- --
OFF
ON
TV
TV position
Name
Off-timer
On-timer
Sound mode
25
ENGLISH
When the MULTI PICTURE button on the remote control is
pressed, the screen will display the multi pictures. And then
three types of the screen can be selected by pressing the
MULTI MODE button on the remote control.
The multi-picture mode will change in the following
sequence each time the MULTI MODE button is pressed.
Pressing the MULTI PICTURE button one time will display 2 pictures.
• The speaker icon can be shifted left and right by pressing the and SELECT buttons; the audio will
be output from the side on which the speaker icon is located.
• The same signal input cannot be selected for both screens at the same time.
• The TV channel can be changed by pressing the CHANNEL UP/DOWN button on the remote control.
• The signal input mode of picture-A or picture-B (the one that the speaker icon is located on) can be
selected by pressing INPUT SELECT buttons on the remote control.
• Pressing the MULTI PICTURE button once again will cancel the multi-picture mode.
• Refer to the table for 2 pictures (Split) mode.
Pressing the MULTI MODE button one time at the 2 pictures mode will display 4 pictures.
• Press and SELECT buttons to select picture A or picture B indicated by a red triangle. For pictures
on right, press and SELECT buttons to select picture. The selected input display number would
change green.
• The TV channel can be changed by pressing the CHANNEL UP/DOWN button on the remote control.
• The audio can only be output from picture A in 4 pictures mode.
• The component signal input mode cannot be selected in pictures B. Refer to the table for 4 pictures
mode.
• Pressing the MULTI PICTURE button at the 4 pictures mode will cancel the multi-picture mode. And then,
pressing the MULTI PICTURE button again will display the 4 pictures.
Pressing the MULTI MODE button one time at the 4 pictures mode will display 12 pictures.
• Starting from channel 1, preset channels will automatically display in sequence on the 12 windows.
• This function activates only in TV mode.
• After several seconds, it refreshes the picture one by one.
• Pressing the MULTI PICTURE button at the 12 pictures mode will cancel the multi-picture mode. And
then, pressing the MULTI PICTURE button again will display the 12 pictures again.
• Pressing the MULTI MODE button at the 12 pictures mode will display the 2 pictures (Split) mode.
OPERATING INSTRUCTIONS (continued)
Displaying MULTI PICTURE
INPUT SELECT
buttons
MULTI MODE
button
CHANNEL
UP/DOWN button
RECALL button
MULTI PICTURE
button
SELECT/ADJUST
button
(, , , )
Activating the Split mode from the TV screen
Activating the 4 pictures mode from the TV screen
Activating the 12 pictures mode from the TV screen
AB
5AV1
26
8
6
11
B1
B2
B3
A
5
26
26
Pressing the MULTI PICTURE button one time will display 2 pictures.
• The speaker icon can be shifted left and right by pressing the and SELECT buttons. The audio of the
video will be output from the side on which the speaker icon is located.
• The same video input mode cannot be selected for both screens at the same time.
• Pressing the MULTI PICTURE button again will cancel the 2 pictures display.
• Refer to the table for 2 pictures (Split) mode.
Pressing the MULTI PICTURE button one time will display 2 pictures.
• This mode can be available from RGB1 (DVI-PC) and RGB2 (RGB) input.
• The speaker icon can be shifted up and down by pressing the and SELECT buttons. The audio will
be output from the side on which the speaker icon is located.
• The sub-screen position can be selected up and down by pressing
and SELECT buttons.
• The sub-screen can be selected with the AV1~AV6, TV channel buttons from the status that the speaker
icon appears on the left side of AV¾ etc. as shown in the diagram to the right.
• Pressing the MULTI PICTURE button again will cancel the 2 pictures display.
• "Frequency Mode" in the Setup Menu should be set to Movie when sub-screen is the component signal of
1080i/50 or 1080i/60.
AV1: Displays the VIDEO input signal of the sub-screen.
2 Pictures (Split)
4 Pictures
Activating the Split mode from the video input screen
Activating the MULTI PICTURE mode from the RGB input screen
NOTE
• Even if the input of the horizontal / vertical synchronizing signal (or video signal) stops in the multi picture display, the mode will not
change to power save mode.
Input terminal AV1 ~ AV5 AV1, AV2,AV6 RGB1 RGB2
TELE
TEXT
Sub
TV
PAL
SECAM
NTSC3.58
NTSC4.43
576i
576p
480i
480p
1080i/50 1080i/60 720p/60 STB Component
Main
T V
{{ { {{{ { { {
AV1 ~ AV5
PAL, SECAM {{ { {{{ { {
NTSC3.58/4.43 {{ { {{{ { {
AV1
AV2
AV6
576i, 576p {{ { {{{ { {
480i, 480p {{ { {{{ { {
1080i/50 {{ { {{{ { {
1080i/60 {{ { {{{ { {
720p/60 {{ { {{{ { {
RGB1 STB
RGB2 Component {{ { {{{ { {
({ : Available)
Teletext is available only for TV
Input terminal AV1 ~ AV5 AV1, AV2,AV6 RGB1 RGB2
TELE
TEXT
Sub
TV
PAL
SECAM
NTSC3.58
NTSC4.43
576i
576p
480i
480p
1080i/50 1080i/60 720p/60 STB Component
Main
TV {
{{
AV1 ~ AV5
PAL, SECAM {{ {
NTSC3.58/4.43 {{ {
AV1
AV2
AV6
576i, 576p {{ {
480i, 480p {{ {
1080i/50 {{ {
1080i/60 {{ {
720p/60 {{ {
RGB1 STB
RGB2 Component {{ {
({ : Available)
OPERATING INSTRUCTIONS (continued)
Displaying MULTI PICTURE (continued)
AV1 AV2
Main Sub
Sub 1
Sub 2
Sub 3
Main
27
ENGLISH
When the FREEZE button on the remote control is pressed, the screen transfers into the
freeze mode.
• There are two types of freezing screen mode, Split and Strobe. These are possible to select at the
“Freeze Mode” setting of the Function Menu.
• The Split mode will display 2 pictures from the same source on the screen with one active picture and
the other still.
• The Strobe mode will display 12 pictures with the last picture active, while other 11 windows are still.
• Pressing the FREEZE button again changes the screen back to the normal picture.
• This function is also available from video input mode besides TV mode. Refer to the table for Freeze
function as below:
Split Strobe
TV O O
PAL. SECAM O O
NTSC3.58/4.43 O O
576i O O
480i O O
576p O
480p O
1080i/50 O
1080i/60 O
720p/60 O
RGB. DVI-PC
( O : Available )
OPERATING INSTRUCTIONS (continued)
FREEZE button
Picture Freezing
AB
5
[Split]
[Strobe]
28
When the MENU button is pressed, the adjustment menu screen
will be displayed; from there, several adjustments and settings
are possible by using the SELECT button, ADJUST button and
OK button.
• Refer to - concerning the adjustment items and the
settings.
1. Press the MENU button to display the Main Menu screen.
2. Press the OK button to display the Picture Menu screen.
(Use the and SELECT buttons to select other items.)
3. Use the and SELECT buttons to select the item to be
adjusted and then use the and ADJUST buttons to
adjust (example: Contrast).
• Press the RETURN button to return to the previous screen.
• If there is no operation for a period of one minute, the Adjustment
Menu screen will be closed automatically.
OPERATING INSTRUCTIONS (continued)
Example: Selecting the Picture screen from TV/Video mode
Using the Menu Screen
(On-screen display system)
MENU button
RECALL button
SELECT/ADJUST
button
(, , , )
OK button
RETURN button
29 41
Audio
Timer
Function
Setup
Language
Select
OK Set
Select Return Exit
Brightness : – 31
Color : 0
Contrast : + 31
Sharpness : 0
Color Temperature : Normal
Back Light
Contrast Mode
Reset
Reset
Tint : + 31
:
Normal
:
+ 20
Mode
:
Dynamic
OK
Contrast + 31
Next / Prev Adjust Return
29
ENGLISH
OPERATING INSTRUCTIONS (continued)
SETUP MENU (TV mode)
Audio
Timer
Function
Setup
Language
Select
OK Set
Setup
Auto Tuning
Manual Tuning
Fine Tuning
Sort
Teletext Language
Auto Off Off
Select Set Return
OK
Setup
Auto Tuning
Manual Tuning
Fine Tuning
Sort
Teletext Language
Auto Off Off
Select Set Return
OK
Setup
Manual Tuning
Position 99
Frequency 250MHz
Name ABCDE
Sound System BG
Color System Auto
Skip Off
NR Off
Antenna Att. Off
Select Return Exit
Setup
Auto Tuning
Manual Tuning
Fine Tuning
Sort
Teletext Language
Auto Off Off
Select Set Return
OK
Setup
Auto Tuning
Manual Tuning
Fine Tuning
Sort
Teletext Language
Auto Off Off
Select Set Return
OK
Setup
Auto Tuning
Manual Tuning
Fine Tuning
Sort
Teletext Language
Auto Off Off
Select Set Return
OK
Setup
Teletext Language
West Europe
East Europe
Cyrillic
Greek/Turkish
Select Return Exit
Setup
Auto Tuning
Mode Position
Search
Select Set Return
OK
Setup
Auto Tuning
Mode Position
Search
Select Set Return
Setup Prog.No.199
Fine Tuning +56
Select Adjust Return
Setup
Sort
Position Name MHz
100 ABCDE 62MHz
101 BBC1 83MHz
102 ----- 97MHz
103 BBC 106MHz
104 FGHIJ 175MHz
105 XYZAB 189MHz
106 ----- 199MHz
107 ----- 225MHz
Select Return Exit
Setup
Auto Tuning
Scanning Channel Number: 33
Cancel
OK
Cancel
MENU
30
Selected characters WX Setup hint
Auto Tuning
Mode
Select the channel entry method between position setting or direct setting.
And press the OK button to fix it.
• If [Position] is selected, the screen display will be numbers (1~199 and
AV00).
• If [Direct] is selected, the screen display will be C** at the channel 0~99
and S** at the channel 100~199.
Search
Press the OK button and it starts the auto tuning.
Manual Tuning
Position
Set the position number (1~199 and AV00) or channel number (C**, S**) by
( + ) ( - ) CHANNEL UP/DOWN button.
Frequency
• If [Position] has been selected, search the frequency here by pressing
W and X buttons.
• If [Direct] has been selected, this function will be not available (grayed out).
Name
This is used to input the name of the TV station within 5 letters. After fixing
the cursor on the first digit, select a letter by T and S SELECT buttons and
move to next digit by X ADJUST button. Press the OK button again after
finished.
• Selectable letters are “0”~`”9”, ”A”~`”Z”, “+”, “–”, ” ”(blank), ”,”(comma) and
”.”(period).
Sound System
Select the sound system through the 5 different settings.
Color System
Select the color system through the 5 different settings.
Skip
If this is set to On, that position will be skipped while selecting positions by
CHANNEL UP/DOWN button.
This is automatically set to On for those non-broadcasting channels.
NR
If this is set to On, it helps to reduce the noise interference visible on the
screen, especially in the weaker signal reception areas.
Antenna Att
If this is set to On, it helps to reduce the noise inter ference visible on the
screen in case of strong airwave.
Fine Tuning
Decreasing the frequency data
for the main tuner
Increasing the frequency data for
the main tuner.
After completing the fine-tuning, press the RETURN button to exit this mode.
• The variable range is -56 ~ +56.
Sort
(When the Mode in Auto Tuning menu is set to [Direct], this function will be not available (grayed out).)
(A Line of position List)
Press OK button at a line that is required to change order, then the
characters will change to green. And move it up or down in the list by
pressing S and T SELECT buttons. And press OK button to complete it.
Press the RETURN button to exit.
Teletext Language
Select the teletext language, depending on the area utilized, through the 4
settings; West Europe, East Europe, Cyrillic and Greek/Turkish.
• Select West Europe when watch in Singapore, Australia, Malaysia, and so
on.
Auto Off
If this is set to On, the power will be turned off when there is no transmission
signal and no operation for about 10 minutes in the TV mode.
OPERATING INSTRUCTIONS (continued)
SETUP MENU (TV mode) (continued)
31
ENGLISH
OPERATING INSTRUCTIONS (continued)
SETUP MENU (Video mode)
Selected characters Setup hint
System
Do not change the original setting.
(System1: Europe/Asia, System2: North America)
Color System
AV1~AV5
This should correspond to the color system of the signal from the
equipment that is connected to AV1~AV5 video input terminal.
• Normally, set this to Auto. The system of the input signal will be
automatically recognized.
• If the input signal contains much noise or has a low level at Auto and
the operation is found erratic, set this to match the input signal.
• When the component signal is received, this would be not available
(grayed out).
Video Input
AV1, AV2
This should correspond to the signal mode of the signal from the
equipment that is connected to AV1, AV2 video input terminal.
• Normally, set this to Auto. The signal mode of the input signal will be
automatically recognized.
• If the input signal contains much noise or has a low level at Auto and
the operation is found erratic, set this to match the input signal.
RGB1
This should correspond to the signal mode of the signal from the
equipment that is connected to RGB1 DVI terminal.
RGB2 (1st step)
This should correspond to the signal mode of the signal from the
equipment that is connected to RGB2 D-sub terminal.
RGB2 (2nd step)
This step should be set only when [Component] is selected on the 1st
step.
This should correspond to the signal mode of the signal from the
equipment that is connected to RGB2 D-sub terminal.
• Normally, set this to Auto. The signal mode of the input signal will be
automatically recognized.
• If the input signal contains much noise or has a low level at Auto and
the operation is found erratic, set this to match the input signal.
System1
System2
32
OPERATING INSTRUCTIONS (continued)
SETUP MENU (RGB mode: RGB1 (DVI-PC), RGB2 (RGB))
Selected characters Setup hint
Auto Adjust*
Adjust
Pressing the OK button here,
Automatic regulation is started.
Horizontal Position. Vertical Position. Horizontal Clock and Clock
Phase are adjusted automatically.
Horizontal Position
Moves the horizontal position to left. Moves the horizontal position to right.
Adjust the left-side display position.
Screen display changes to Magenta color if beyond the available
range. (This function is only for RGB2. It’s not available (grayed
out) for RGB1 (DVI-PC).)
Vertical Position
Moves down the vertical position Moves up the vertical position.
Adjust the vertical display position.
Screen display changes to Magenta color if beyond the available
range. (This function is only for RGB2. It’s not available (grayed
out) for RGB1 (DVI-PC).)
Horizontal Clock
Reduces the dot clock frequency
(shrinks the right side).
Increases the dot clock frequency
(expands the right side).
Adjust for maximum character clarity.
(This function is only for RGB2. It’s not available (grayed out) for
RGB1 (DVI-PC).)
Clock Phase
Slows the dot clock phase (shifts
slightly to left).
Advances the dot clock phase (shifts
slightly to right).
Adjust for clear character visibility.
(This function is only for RGB2. It’s not available (grayed out) for
RGB1 (DVI-PC).)
Reset
(off the function) (waiting to reset)
The original factory settings for the items of this Menu page can
be restored by pressing the OK button.
Input Level
Normally set to 0.7 V. If white is found to spread across the
screen, set to 1.0 V. (This is effective only for RGB2.)
Frequency Display
Set this to Off if the frequency information of the Input Signal
Screen Display is not required.
WVGA Type
This is only available for W-VGA signal.
When it is set to On, the display area mode can be selected Full
or Real. (With RGB1 INPUT, the screen remains the same. RGB2
(ANALOG) INPUT only)
WXGA Mode
This is only available for W-XGA signal.
(RGB2 (ANALOG) INPUT only)
Off
33
ENGLISH
* Depending on the type of signal displayed, displays may not be optimized through automatic adjustment. Adjust manually to optimize them.
Selected characters Setup hint
Vertical Filter
Turn On when concerned about screen flicker.
Frequency Mode
Grayed out This function is not available.
RGB1
This should correspond to the signal mode of the signal from the
equipment that is connected to RGB1 DVI terminal.
RGB2 (1st step)
This should correspond to the signal mode of the signal from the
equipment that is connected to RGB2 D-sub terminal.
RGB2 (2nd step)
This step should be set only when [Component] is selected on the
1st step.
This should correspond to the signal mode of the signal from the
equipment that is connected to RGB2 D-sub terminal.
• Normally, set this to Auto. The signal mode of the input signal
will be automatically recognized.
• If the input signal contains much noise or has a low level at
Auto and the operation is found erratic, set this to match the
input signal.
OPERATING INSTRUCTIONS (continued)
SETUP MENU (RGB mode: RGB1 (DVI-PC), RGB2 (RGB)) (continued)
34
Selected characters Setup hint
Screen Saver
This moves the picture around the screen in small amounts, at set
intervals, to reduce the residual image. This is where stationary objects,
such as screen logos, leave a slight image visible after they should have
disappeared.
Screen Wipe
On 60Min.
This is used to reduce the residual image that can occur with stationary
pictures by the white field signal. Select On (continuous operation) or 60
Min. (time limit operation) and press the OK button. Press the MENU or
RETURN button on the remote control to return to normal viewing.
Black Side Panel
This turns the gray sidebars to the black sidebars when watching normal
mode screen size area. It is always set to Off when the monitor powered
On. It is recommended to set to Off to reduce the residual image.
Video Power Save
This is used to reduce power consumption for video input when there is
no video signal. Setting it On will lead the monitor to the standby mode
when the AV input with no signal is selected.
Freeze Mode
This selects the display condition of the FREEZE mode between Split (2
pictures) and Strobe (12 pictures).
Default Zoom
This selects the screen display size of TV input that appears first when
the main power turned on.
Reset
(off the function) (waiting to reset)
This original factory settings for the items of this Menu page can be
restored by pressing the OK button.
OPERATING INSTRUCTIONS (continued)
FUNCTION MENU
35
ENGLISH
OPERATING INSTRUCTIONS (continued)
PICTURE MENU (TV/Video mode)
36
Selected characters Setup hint
Picture Mode
Dynamic: This setting is best for very bright ambient lighting.
Natural: This setting is for normal lighting conditions.
Cinema: This setting is best for watching movie.
Contrast
Narrows the gap between
brightness and darkness.
Broadens the gap between
brightness and darkness.
Adjust for maximum visibility to suit the ambient brightness.
This can adjust further till [+40] by pressing and holding SELECT
button at [+31]. The color for [+32] to [+40] numbers will change from
green to magenta. This special mode is better for dark scenes.
For normal viewing we recommend that the Contrast is set to [+31].
Brightness
Black is subdued for increased
overall darkness.
Black is set off for increased overall
brightness.
Adjust to preference.
Color
Decrease color intensity. Increase color intensity. Adjust to preference.
Sharpness
Soft Sharp
Shift to the minus (-) side for a softer effect and plus (+) for sharper
picture.
Tint
Enhances red and weakens green. Enhances green and weakens red.
This is not available to adjust when receiving PAL/SECAM signal.
Then the character will be grayed out.
Adjust for the most realistic skin color.
Color Temperature
Normally set to Cool.
Contrast Mode
Dynamic: Emphasizes the differences between video shadings to
improve the feeling of contrast.
Normal: The gradation of an image is reproduced as faithfully as
possible.
Auto: Detects image brightness and automatically adjusts for natural
brightness.
Back Light
Darkens the screen. Brightens the screen. Adjust to preference (for the maximum visibility).
Reset
(off the function) (waiting to reset)
The original factory settings for the items of this Menu page can be
restored by pressing the OK button.
YNR
Performs picture signal noise reduction. Turn up to reduce noise.
CNR
Performs color signal noise reduction. Turn up to reduce noise. And it
will be fixed as Off only when selecting DVI-STB mode.
Film Mode
On: Automatically detects the movie film material and faithfully
reproduces the original film image.
Off: Set to OFF when switching between images does not appear
natural.
PAL Comb Filter
This is available only when receiving a PAL composite signal. Turn On
to reduce the discolorations in fine picture detail and provides purer
color.
LTI
Adjusts the sharpness of the picture signal.
CTI
Adjusts the sharpness of the color signal.
Black Enhancement
Adjusts the black level compensation.
Auto Color
This is available only when receiving an NTSC composite/S.Video
signal. This monitors and adjusts the color to maintain constant color
levels. It also maintains natural flesh tones while preserving fidelity of
background colors.
Color Temp. Adjustment
Turn On when you wish to change color temperature depending on the
user’s preference.
Amplitude
Red
Brighter scene is decreased in
reddish color.
Brighter scene is increased in
reddish color.
Adjust color temperature depending on the user’s preference. These
settings are independently stored in each of the 4 Color Temperature
modes.
Green
Brighter scene is decreased in
greenish color.
Brighter scene is increased in
greenish color.
Blue
Brighter scene is decreased in
bluish color.
Brighter scene is increased in
bluish color.
Cut Off
Red
Dark scene is decreased in reddish
color.
Dark scene is increased in reddish
color.
Green
Dark scene is decreased in
greenish color.
Dark scene is increased in
greenish color.
Blue
Dark scene is decreased in bluish
color.
Dark scene is increased in bluish
color.
OPERATING INSTRUCTIONS (continued)
PICTURE MENU (TV/Video mode) (continued)
37
ENGLISH
Selected characters Setup hint
Color Management
Turn On when the original balance of each color is required to adjust
depending on the user’s preference.
Magenta
Magenta is weakened. Magenta is strengthened.
This adjusts listed colors individually to make them either deeper or
purer. These settings are independently stored in each of the 4 Color
Temperature modes.
Red
Red is weakened. Red is strengthened.
Yellow
Yellow is weakened. Yellow is strengthened.
Green
Green is weakened. Green is strengthened.
Cyan
Cyan is weakened. Cyan is strengthened.
Blue
Blue is weakened. Blue is strengthened.
Color Decoding
Select the single color screen when that is required to adjust R/G/B level
individually depending on the user’s preference. And set it back to RGB
mode that indicates all color after adjusting.
Press the OK button every time the setting is changed.
Red
Darkens red only. Lightens red only.
This adjusts R/G/B level or tint to make the color appear natural for the
user’s preference. These settings are independently stored in each of the
4 Color Temperature modes.
When select "Tint", the display will be gray to indicate that it is not
available when receiving PAL/SECAM signal.
Green
Darkens green only. Lightens green only.
Color
Decreases color Intensity .
Increases color Intensity.
Tint
Enhances red and weakens
green.
Enhances green and weakens
red.
OPERATING INSTRUCTIONS (continued)
PICTURE MENU (TV/Video mode) (continued)
38
Selected characters Setup hint
Contrast
Narrows the gap between
brightness and darkness.
Broadens the gap between
brightness and darkness.
Adjust for maximum visibility to suit the ambient brightness.
This can adjust further till [+40] by pressing and holding SELECT
button at [+31]. The color for [+32] to [+40] numbers will change from
green to magenta. This special mode is better for dark scenes.
For brighter scene some parts of the picture might not be clear.
We recommend to set at [+31].
Brightness
Black is subdued for increased
overall darkness.
Black is set off for increased
overall brightness.
Adjust to preference.
Color
Decreases color intensity. Increase color intensity. Adjust to preference.
Tint
Enhances red and weakens
green.
Enhances green and weakens
red.
This is not available to adjust when receiving PAL/SECAM signal.
In this case the character will be grayed out.
Adjust for most realistic skin color.
Picture Enhancement
Sets the clarity of small details to the desired level.
Color Temperature
Normally set to Normal.
Color Temp. Adjust
Turn On when you wish to change color temperature is required to
adjust depending on the user’s preference.
Amplitude
Red
Brighter scene is decreased in
reddish color.
Brighter scene is increased in
reddish color.
Adjust color temperature depending on the user’s preterence. These
settings are independently stored in each of the 4 Color Temperature
modes.
Green
Brighter scene is decreased in
greenish color.
Brighter scene is increased in
greenish color.
Blue
Brighter scene is decreased in
bluish color.
Brighter scene is increased in
bluish color.
Cut Off
Red
Dark scene is decreased in
reddish color.
Dark scene is increased in
reddish color.
Green
Dark scene is decreased in
greenish color.
Dark scene is increased in
greenish color.
Blue
Dark scene is decreased in
bluish color.
Dark scene is increased in
bluish color.
Back Light
Darkens the screen. Brightens the screen. Adjust to preference (for the maximum visibility).
Reset
(off the function) (waiting to reset)
The original factory settings for the items of this Menu page can be
restored by pressing the OK button.
OPERATING INSTRUCTIONS (continued)
PICTURE MENU (RGB mode)
39
ENGLISH
OPERATING INSTRUCTIONS (continued)
Selected characters Setup hint
Audio Mode
Movie: This selects the audio suitable for Movie.
Music: This selects the audio suitable for Music.
Speech: This selects the audio suitable for News, Talk show etc.
Favorite: This mode should be adjusted depending on user’s
preference.
Treble
Suppresses treble. Enhances treble. Adjust to preference.
Bass
Suppresses bass. Enhances bass. Adjust to preference.
Balance
Suppresses right-side sound. Suppresses left-side sound. Adjust to preference.
Dynamic Bass
Dynamic Bass takes advantage of the ability of the human ear to be
able to distinguish between two different tones. By using this ability,
Dynamic Bass gives enhanced bass sound that otherwise would not
be heard. Adjust it depending on the user’s preference.
Matrix Surround
This features the spacious sound effects of a stadium.
Perfect Volume
This will automatically adjust volume so each channel and input has
the same average volume level.
Reset
(off the function) (waiting to reset)
The original factory settings for the items of this Menu page can be
restored by pressing the OK button.
Headphone Volume
Turns down the volume. Turns up the volume.
This is to set the volume for headphone. The audio from the speaker is
mute when connected to headphone terminal.
Headphone Select
A/B: During the 2 pictures mode, the audio will be output from
headphone on the screen which is selected between A (left
picture) or B (right picture). The speaker icon is located on the
selected picture.
B: The audio of B (right picture) is output from headphone.
NOTE
About the Headphone
• During PC input (RGB1/RGB2), the audio is not output from the headphone.
• Only with AV1 and AV6 inputs during the 2-pictures mode, even though select “B” from “Headphone Select”, the audio of A (left picture)
is always output from the headphone.
AUDIO MENU
40
Select a language by and SELECT buttons and press the OK button.
Selected characters Setup hint
Off Timer
This function automatically sets the power to standby status when the
indicated time period has elapsed.
On Timer
hours minutes
This automatically sets the power from standby to ON when the indicated
time period has elapsed. The settable time is 00:00~11:59. Input the
required time by and SELECT buttons on the remote control.
OPERATING INSTRUCTIONS (continued)
TIMER MENU
LANGUAGE MENU
41
ENGLISH
Approximately 1 sec. after adjustment is completed, the adjustments will be recorded as shown in the table below.
• The previously recorded items will be lost.
• The signal mode can be identified by the horizontal/vertical sync
frequency and the sync signal polarity. Different signals with which
all the elements are the same or similar will be handled as the
same signal.
OTHER FEATURES
Automatic Store
Menu Display Registration condition
Picture Mode
1 setting is registered.
Contrast
For every input function and every
Picture Mode, 1 setting is registered.
Brightness
Color
Shapness
Tint
Color temperature
Contrast Mode
Back Light
YNR
CNR
Film Mode
PAL Comb Filter
LTI
CTI
Black Enhancement
Auto Color
Color Temp. Adjust
For every Color Temperature, 1
setting is registered.
R Amplitude
G Amplitude
B Amplitude
R Cut Off
G Cut Off
B Cut Off
Color Management
For every input function and every
Picture Mode, 1 setting is registered.
Megenta
1 setting is registered.
Red
Yellow
Green
Cyan
Blue
Color Decoding
—
Red
For every Color Temperature, 1
setting is registered.
Green
Color
For every input function and every
Picture Mode, 1 setting is registered.
Tint
Audio Mode
1 setting is registered.
Treble
For every Audio Mode, 1 setting is
registered.
Bass
Balance
1 setting is registered.
Dynamic Bass
For every Audio Mode, 1 setting is
registered.
Matrix Surround
Perfect Volume
Headphone Volume
Headphone Select
Menu Display Registration condition
Screen Saver
1 setting is registered.
Screen Wipe
(not registered)
Black Side Panel
1 setting is registered.
Video Power Save
Freeze Mode
Default Zoom
System
1 setting is registered.
Color System
—
AV1
For every input function, 1 setting is
registered.
AV2
AV3
AV4
AV5
Video Input
—
AV1
1 setting is registered.
AV2
RGB1
RGB2
Auto Adjust
(not registered)
Horizontal Position
For every signal Mode, 1 setting is
registered. (Only for RGB2)
Vertical Position
Horizontal Clock
Clock Phase
Input Level
1 setting is registered.
Frequency Display
WVGA Type
WXGA Mode
Vertical Filter
Frequency Mode
Language
1 setting is registered.
Audio
Function
Setup
1 setting is registered.
42
A2 / NICAM / Sound Multiplex (TV mode)
• The CH I / II button is only useful for NICAM and sound multiplex signals.
Otherwise pressing this button will have no effect.
BILINGUAL / DUAL sound broadcast
When bilingual program is received, sound mode display appears in yellow as shown on right.
Press the CH I / II button to select the sound to be heard.
Each time the button is pressed, I, II or (force mono) appear cyclically on the screen.
When receiving NICAM signals, NICAM display will appear as below.
STEREO sound broadcast
When a stereo program is received, sound mode display will appear in red, and you can
press the CH I / II button to select between stereo and mono sound.
Each time the button is pressed, or
(force mono) appear cyclically on the screen.
When receiving NICAM signals, NICAM display will appear as below.
Monaural sound broadcast
When a monaural program is received, sound mode display will appear in green.
You can press the CH I / II button to select the sound mode between monaural and forced
mono (sound is same).
Each time the button is pressed, or (force mono) appear cyclically on the screen.
OTHER FEATURES (continued)
NOTE
• If sound signal is not strong enough for quality reception, press the CH I / II button until appears on the screen to receive a clear
mono sound.
• If sound has hiss noise or keep switching between stereo and mono mode due to signal condition, press the CH I / II button until
appears on the screen to receive a clear mono sound.
Audio Switching
8
NICAM [II]
[I]
[II]
NICAM [I]
NICAM [II]
Sound multiplex signal received
NICAM signal received
Yellow
Yellow Green
Yellow
Green
Yellow
Select I, II or (force mono) to hear the CH I, CH II or MONO broadcast respectively.
8
NICAM
Sound multiplex signal received
NICAM signal received
Green
Green
Red
Red
Select or (force mono) to hear the STEREO or MONO broadcast respectively.
8
43
ENGLISH
When the RGB1, RGB2 input is selected
• When this unit is connected to a VESA DPMS computer, the Power Save (Off) mode can be set to be activated automatically when the
computer is not being used to reduce power consumption by this unit.
Returning to operating status
• Operate the personnal computer, or press either the INPUT SELECT button of the main unit or the RGB1/RGB2 buttons of the remote
control.
• You can use this remote control to operate the selected maker of DVD Player and STB by pressing the following buttons on the remote
control simultaneously.
<“DVD” Selection>
<“SAT” Selection>
OTHER FEATURES (continued)
Power Save Mode
RGB sync signal
Horizontal Yes No Yes No
Vertical Yes Yes No No
PC signal Active (normal display) Blank (no display)
Operation mode On Off
Indicating lamp Lights green Lights orange
Power consumption 158W 3W or less
DVD Player/ STB Selection
Makers of DVD Player Set Maker Set Type Makers of DVD Player Set Maker Set Type
HITACHI
RCA
FUNAI
Mitsubishi
Pioneer
ONKYO RED
Panasonic
ZENITH GREEN
TOSHIBA
THOMSON YELLOW
Philips
SHINCO BLUE
JVC
SKYWORTH
SAMSUNG
BUBUKO
Sony
DENON
Sharp
2-4-12
Makers of STB Player Set Maker Set Type
HITACHI
TOSHIBA
DGTEC
Panasonic
44
Set up hint
Example) HITACHI DVD
To operate HITACHI DVD player, press and hold the button,
followed by the button.
1. Set up the maker
Press
button to indicate the DVD LED on the remote control.
While the DVD LED is flashing, press and .
2. Set up the maker type
Release the button while keeping button depressed.
Then, press the button.
3. Confirm the setting
After setting the maker and type, press the POWER button on the remote control.
If the DVD does not switch on, repeat step 1 and 2 using other maker types as listed in the chart on .
Changes in the signal status are displayed on the screen as they arise.
NOTE
• Not all models of the listed makers can be operated using this remote control.
Status Display Action
When Frequency Display is set to ON,
the input signal is switched or when
the RECALL button is pressed.
A guide is displayed for the input
terminal and the horizontal and
vertical sync frequency.
When the sync signal is no longer
detected.
• A guide displays No Sync. Signal,
and Power Save (for approx. 5 sec.)
• When the condition continues where
the sync signal cannot be detected,
indicator lamp of power source
changes in orange and the mode
switches to power save mode.
Recheck the personal computer
power switch status and the
connection status.
When the input signal does not match
the monitor specifications or is in an
unstable status.
A guide displays Invalid Scan Freq. Recheck the input signal
specifications. ~
OTHER FEATURES (continued)
DVD Player/STB Selection (continued)
43
Signal Check (RGB mode)
RGB
! No Sync. Signal
! Invalid Scan. Freq.
50 52
45
ENGLISH
Make the checks suggested below depending on the symptoms observed. If the symptoms remain uncorrected, contact your dealer.
Customer servicing can be hazardous.
Symptom Point to check See page
• No picture with the power-indicating lamp off. • Check the way the power cable is connected.
• Press the power switch.
• The message “No Sync. Signal” or “Power
Save” is displayed.
• No picture with the power indicating lamp
lights in orange.
No sync signal is detected.
• Check the way the signal cable is connected.
• Make sure that the switch of the computer, imaging
equipment, etc., is turned on.
• Make sure the computer is not in the power-save mode.
• Check to see if the input selection matches the connection
terminal.
• The message “Invalid Scan Freq.” is
displayed.
An input signal is not received normally.
• Check to see if the input signal matches the monitor
specifications.
• Check the way the signal cable is connected.
• The power indicating lamp is normally lit but
no picture.
• Check the contrast and brightness settings (adjust them for
higher contrast and brightness).
• Check the way the signal cable is connected.
• The display image appears flowing slantwise.
• Text displayed across the screen appears
vertically streaked, with the characters in
vertical columns blurred.
• Adjust the dot clock frequency and phase. (Adjust the dot
clock frequency first, the dot clock phase next.)
(RGB input)
• Text displayed across the screen appears
blurred.
• A fine pattern flickers when displayed on the
screen.
• Adjust the dot clock phase for the clearest viewing.
(RGB input)
• The remote control does not work. • Check to see if the batteries are loaded in the remote control
in opposite direction.
• Check to see if the batteries in the remote control are OK.
• The display image does not appear in the
normal position.
• Check to see if the displayed input signal match the monitor
specification by pressing button.
• Turn off the screen saver.
• The display has lack of picture around the
screen.
(PC input mode only)
• Turn off the screen saver.
• The temperature of the display panel surface is high. • The LCD monitor is lighting the fluorescent lamps inside of
the panel.
In some cases, this may cause the temperature of the panel
surface to increase. Please note that this is not a malfunction.
—
TROUBLESHOOTING
Symptoms That Seemingly Appear to be Failures
WARNING
18
19
! No Sync. Signal
15
! Invalid Scan Freq.
15
50
51
52
15
36
38
32
47
32
47
9
15
34
50
51
52
34
46
Symptom Point to check See page
• There are locations on the screen that are different from the
periphery (*).
* Points that do not light, points with brightness different
from that of the periphery, points with color different from
that of the periphery, etc.
• High-precision technology is used to manufacture the LCD
panel. However in some cases, there are minor defects in
some parts of the screen. Please note that this is not a
malfunction.
—
• Coarse horizontal stripes appear in FULL display. • Adjusting the Clock Phase will reduce the horizontal stripes.
(RGB input)
• Flickering in the form of horizontal lines oscillating up and down.
(PC INPUT MODE only)
• If the direct frequency from the computer is below 85Hz, try
a higher frequency (upper limit 85Hz). There may be a slight
attenuation of the current image.
• Try turning the Vertical Filter On. For this case however, the
vertical resolution will drop.
• The top of the monitor heats up. • When used for long periods of time, the top of the monitor
may heat up. This is not a malfunction.
—
• Text characters are displayed with varying thicknesses. • The thicknesses of characters and lines may vary if images
with a vertical resolution greater than 768 lines are
displayed; however, this is not a malfunction.
—
• The screen becomes dark and the images cannnot be seen
during VTR special playback (fast forward, rewind)
• This sometimes occurs when a component output VTR such
as the 480i is connected.
This is not a malfunction; therefore, please take note that
this may occur. When it does occur, change to composite
output,or S.video output.
—
• During multi picture mode, sub pictures are not displayed. • Sub pictures image might not be able to be displayed,
depending on the combination.
(Reter to the table of “2 pictures mode” and “4 pictures
mode”)
• The screen display sizes are not switched. • The screen display size is fixed at “Full” as receiving
1080i/60Hz, 1080i/50Hz, and 720p/60Hz.
—
• Images from AV6 (HDMI) are not displayed. • Check the cable and output format of connecting device.
(Reter to “Connecting to an Audio Visual Device”, and
"Recommended Signal List".)
TROUBLESHOOTING (continued)
Symptoms That Seemingly Appear to be Failures (continued)
32
33
26
13
50
47
ENGLISH
Depending on the kind of system equipment used, images may not be displayed normally. In this case, make the adjustments
suggested below. (only for RGB2)
• The display image may be momentarily disturbed during clock adjustment but this is not a failure.
Symptom 1
Text displayed across the screen appears vertically streaked, with some characters blurred (Figure 1).
Example
Figure 1
Adjustment
procedure
1) Press the MENU button. The Main Menu will be displayed.
2) Press the SELECT button and select Setup.
3) Press the OK button. The Setup Menu will be displayed.
4) Press the SELECT button and select Auto Adjust.
When adjustment is not possible with Auto Adjust
5) Press the MENU button. The Main Menu will be displayed.
6) Press the SELECT button and select Setup.
7) Press the OK button. The Setup Menu will be displayed.
8) Press the SELECT button and select Horizontal Clock.
(Display fine patterns as characters or a vertical striped pattern over the entire screen during Horizontal Clock adjustment.)
9) Press the or ADJUST buttons and search for clear characters over the entire screen.
10) Perform adjustment for symptom 2 below, when the characters are blurred on the entire screen.
Symptom 2
Text displayed across the screen appears blurred in its entirety (Figure 2).
A fine pattern flickers when displayed on the screen (Figure 3).
Example
Figure 2 Figure 3
Adjustment
procedure
1) Press the MENU button. The Main Menu will be displayed.
2) Press the SELECT button and select Setup.
3) Press the OK button. The Setup Menu will be displayed.
4) Press the SELECT button and select Auto Adjust.
When adjustment is not possible with Auto Adjust
5) Press the MENU button. The Main Menu will be displayed.
6) Press the SELECT button and select Setup.
7) Press the OK button. The Setup Menu will be displayed.
8) Press the SELECT button and select Clock Phase.
(Display fine patterns as characters or a vertical striped pattern over the entire screen during Clock Phase adjustment.)
9) Press or ADJUST buttons to make the text appear
clean across the screen.
9) Press or ADJUST buttons to make the text appear
without flickering.
TROUBLESHOOTING (continued)
Actions to Correct Abnormal Displays
Vertical Streaks
Before adjustment.
Some characters are blurred.
After adjustment.
All characters are
blurred.
After adjustment.
All characters appear
crisp now.
Before adjustment
After adjustment
Before adjustment
After adjustment
48
Product specifications and designs are subject to change without notice.
• The monitor takes at least 30 minutes to attain the status of optimal picture quality.
PRODUCT SPECIFICATIONS
Panel
Display
dimensions
Approx.32 inches (698 (H) x 392 (V) mm, diagonal 800 mm)
Resolution
1366 (H) x 768 (V) pixels
Net dimensions
1015(W) x 618 (H) x 340 (D) mm
Net weight
25.0 kg
Ambient
conditions
Temperature
Operating: 5°C to 35°C, Storage: -15°C to 60°C
Relative humidity
Operating: 20% to 80%, Storage: 20% to 90%(non-condensing)
Power supply
AC100-240V, 50/60Hz
Power consumption/at standby
158W/<1W
/<2W ( only when DVI used )
Audio output
speaker 12W+12W (6Ω)
(RGB input)
Input terminals
RGB1 DVI input terminal (DVI-D)
RGB1 audio input terminal (3.5mm Stereo Mini Jack)
RGB2 analog RGB input terminal (D-sub 15-pin)
RGB2 audio input terminal (3.5mm Stereo Mini Jack)
Input signals
0.7 V/1.0 Vp-p, analog RGB (Recommended Signal)
480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
Sync signals
H/V separate, TTL level [2KΩ]
H/V composite, TTL level [2KΩ]
Sync on green, 0.3 Vp-p [75Ω]
Recommended signal
44 modes
(Video input)
Input terminals
AV1: composite video input terminal (RCA)
AV1: Y/P
B/PR video input terminal (RCA)
AV1: L/R audio input terminal (RCA)
AV2: composite video input terminal (RCA)
AV2: Y/P
B/PR video input terminal (RCA)
AV2: L/R audio input terminal (RCA)
AV3: composite video input terminal (RCA)
AV3: S video input terminal
AV3: L/R audio input terminal (RCA)
AV4: composite video / L/R audio input terminal (RCA)
AV5 = AV3
AV6: HDMI input terminal
Input signals
AV1: PAL, SECAM, NTSC3.58, NTSC4.43
AV1: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
AV2: PAL, SECAM, NTSC3.58, NTSC4.43
AV2: 480i, 576i, 480p, 576p, 1080i/50, 1080i/60, 720p/60
AV3: PAL, SECAM, NTSC4.43, NTSC3.58
AV4: PAL, SECAM, NTSC4.43, NTSC3.58
AV5 = AV3
AV6: HDMI input signal .
Output signal
OUTPUT (MONITOR): composite video monitor-output terminal (RCA)
OUTPUT (MONITOR): L/R audio monitor-output terminal (RCA)
OUTPUT (HEADPHONE): L/R audio monitor-output terminal (Mini-pin)
Recommended signal
23 modes
(RF input)
Input terminals
ANT: 75Ω Unbalanced
RF Video System
PAL B, G, H / I / D, K
SECAM B, G / D, K / K1
NTSC-M
51 52
50
50 51
49
ENGLISH
RGB terminal (D-sub 15-pin connector)
S-input connector pin specifications
HDMI connector pin specifications
DVI terminal (DVI-D)
PRODUCT SPECIFICATIONS (continued)
Signal Input
Pin Input signal
1
R(PR/CR)
2
G or sync on green (Y)
3
B (PB/CB)
4
No connection
5
No connection
6
R.GND (PR/CR. GND)
7
G.GND (Y. GND)
8
B.GND (PB/CB. GND)
9
No connection
10
GND
11
No connection
12
[SDA]
13
H. sync or H/V composite sync
14
V.sync. [V.CLK]
15
[SCL]
( ) : With component input
Pin Input signal
1
Y
2
Y-GND
3
C
4
C-GND
Frame
GND
Pin Input signal Pin Input signal
1
TMDS Data2+
11
TMDS Clock Shield
2
TMDS Data2 Shield
12
TMDS Clock-
3
TMDS Data2-
13
CEC
4
TMDS Data 1+
14
Reserved(N.C. on device)
5
TMDS Data1 Shield
15
SCL
6
TMDS Data1-
16
SDA
7
TMDS Data0+
17
DDC/CED Ground
8
TMDS Data0 Shield
18
+5V Power
9
TMDS Data0-
19
Hot Plug Detect
10
TMDS Clock+
Pin Input signal Pin Input signal
1
T.M.D.S. Data2-
14
+5V Power
2
T.M.D.S. Data2+
15
Ground (for+5V)
3
T.M.D.S. Data2/4 Shield
16
Hot Plug Detect
4
T.M.D.S. Data4-
17
T.M.D.S. Data0-
5
T.M.D.S. Data4+
18
T.M.D.S. Data0+
6
DDC Clock
19
T.M.D.S. Data0/5 Shield
7
DDC Data
20
T.M.D.S. Data5-
8
No Connect
21
T.M.D.S. Data5+
9
T.M.D.S. Data1-
22
T.M.D.S. Clock Shield
10
T.M.D.S. Data1+
23
T.M.D.S. Clock+
11
T.M.D.S. Data1/3 Shield
24
T.M.D.S. Clock-
12
T.M.D.S. Data3-
Frame
GND
13
T.M.D.S. Data3-
• When different kinds of input signals are simultaneously input
to the monitor via a graphics board or the like, the monitor will
automatically select the signals in the following priority order:
* Even in the case of the recommended signals shown on the
following page, there may be instances when correct display
is not possible. In this case, use H/V separate sync, H/V
composite sync.
Sync signal type Priority
H/V separate sync. 1
H/V composite sync. 2
sync.on Green * 3
50
Applicable video signals for input terminal (TV mode)
(O:Available)
With composite input(AV1~AV5 input) and S-video input (AV3, AV5 input).
With component input (AV1, AV2 and RGB2-component input).
With HDMI input (AV6 input).
PRODUCT SPECIFICATIONS (continued)
Terminal
RCA/S-video
HDMI
DVI D-sub
Remarks
Signal Name CVBS S-video Component PC STB RGB Component
AV1
OO
Refer to Setup Menu
AV2
OO
Refer to Setup Menu
AV3
OO
Refer to Setup Menu
AV4
O
Refer to Setup Menu
AV5
OO
Refer to Setup Menu
AV6
O
RGB1
OO
Refer to Setup Menu
RGB2
OO
Refer to Setup Menu
Recommended Signal List
31
31
31
31
31
33
33
No.
Signal mode
Horizontal
frequency (kHz)
Dot clock
frequency (MHz)
Remarks
Signal Name Resolution
Vertical frequency
(Hz)
1
NTSC4.43
NTSC3.58
525 59.94 15.73
2
PAL
SECAM
625 50.00 15.63
No.
Signal mode
Horizontal
frequency (kHz)
Dot clock
frequency (MHz)
Remarks
Signal Name Resolution Vertical frequency (Hz)
1
576i 576 50.00 15.63
2
480i 480 59.94 15.73
3
576p 576 50.00 31.26
4
480p 480 59.94 31.47
5
1080i/50 1080 50.00 28.13
6
1080i/60 1080 60.00 33.75
7
720p/60 720 60.00 45.00
No.
Signal mode
Horizontal
frequency (kHz)
Dot clock
frequency (MHz)
Remarks
Signal Name Resolution Vertical frequency (Hz)
1
VGA 640 x 480 59.94 31.47 25.18 EIA-861B
2
576i 720(1440) x 576 50.00 15.63 27.00 EIA-861B
3
480i 720(1440) x 480 59.94 15.73 27.00 EIA-861B
4
576p 720 x 576 50.00 31.25 27.00 EIA-861B
5
480p 720 x 480 59.94 31.47 27.00 EIA-861B
6
1080i/50 1920 x 1080 50.00 28.13 74.25 EIA-861B
7
1080i/60 1920 x 1080 60.00 33.75 74.25 EIA-861B
8
720p/60 1280 x 720 60.00 45.00 74.25 EIA-861B
51
ENGLISH
With Digital signal input.
(O:Acceptable)
PRODUCT SPECIFICATIONS (continued)
Recommended Signal List (continued)
No.
Signal mode
Horizontal
frequency
(kHz)
Dot clock
frequency
(MHz)
Setup Menu Condition
Remarks
Signal Name Resolution
Vertical frequency
(Hz)
DVI-PC DVI-STB
1
VGA
640 X 400 70.08 31.47 25.18 O
2 640 X 480 59.94 31.47 25.18 O O
3
W-VGA 864 X 480 59.94 31.47 34.24 O WVGA type: On
4
VESA
640 X 480 72.81 37.86 31.50 O
5
640 X 480 75.00 37.50 31.50 O
6
640 X 480 85.01 43.27 36.00 O
7
800 X 600 56.25 35.16 36.00 O
8
800 X 600 60.32 37.88 40.00 O
9
800 X 600 72.19 48.08 50.00 O
10
800 X 600 75.00 46.88 49.50 O
11
800 X 600 85.06 53.67 56.25 O
12
1024 X 768 60.00 48.36 65.00 O
13
1024 X 768 70.07 56.48 75.00 O
14
1024 X 768 75.03 60.02 78.75 O
15
480p 720 X 480 59.94 31.47 27.00 O EIA-861B
16
576p 720 X 576 50.00 31.25 27.00 O EIA-861B
17
720p/60 1280 X 720 60.00 45.00 74.25 O EIA-861B
18
1080i/60 1920 X 1080 60.00 33.75 74.25 O EIA-861B
19
1080i/50 1920 X 1080 50.00 28.13 74.25 O EIA-861B
52
With Analog signal input (RGB2 input)
PRODUCT SPECIFICATIONS (continued)
Recommended Signal List (continued)
No.
Signal mode
Horizontal
frequency (kHz)
Dot clock
frequency (MHz)
Remarks
Signal Name Resolution
Vertical frequency
(Hz)
1
VGA
640 X 400 70.08 31.47 25.18
2 640 X 480 59.94 31.47 25.18
3
W-VGA 864 X 480 59.94 31.47 34.24 WVGA type: On
4
VESA
640 X 480 72.81 37.86 31.50
5
640 X 480 75.00 37.50 31.50
6
640 X 480 85.01 43.27 36.00
7
800 X 600 56.25 35.16 36.00
8
800 X 600 60.32 37.88 40.00
9
800 X 600 72.19 48.08 50.00
10
800 X 600 75.00 46.88 49.50
11
800 X 600 85.06 53.67 56.25
12
1024 X 768 60.00 48.36 65.00
13
1024 X 768 70.07 56.48 75.00
14
1024 X 768 75.03 60.02 78.75
15
1024 X 768 85.00 68.68 94.50
16
1152 X 864 75.00 67.50 108.00
17
1280 X 1024 60.02 63.98 108.00
18
1280 X 1024 75.03 79.98 135.00
19
1280 X 1024 85.02 91.15 157.50
20
1600 X 1200 60.00 75.00 162.00
21
1600 X 1200 75.00 93.75 202.50
22
1600 X 1200 85.00 106.25 229.50
23
Macintosh
640 X 480 66.67 35.00 30.24
24
832 X 624 74.55 49.72 57.28
25
1024 X 768 74.93 60.24 80.00
26
1152 X 870 75.06 68.68 100.00
27
W-XGA
1280 X 768 59.833 47.986 81.00
28
1280 X 768 69.997 56.137 94.760
29
W-XGA
1280 X 768 59.876 47.776 79.50 WXGA Mode:1280X768
30
1366 X 768 60.015 47.712 85.50 WXGA Mode:1366X768
• The type of video board or connecting cable used may not allow for correct displays adjustment of Horizontal Position, Vertical Position.
Horizontal Clock and Clock Phase.
• The monitor may fail to display an animation image correctly when a signal having a vertical frequency of 85Hz or higher is input to it.
• The monitor differentiates the signal modes according to the horizontal and vertical frequencies and the horizontal and vertical sync signal
polarities. Note that different signals having all these elements alike may be handled as the same signal.
• Displaying images with more than
768 lines of vertical resolution at Full display (compressed display) can result in the interpolation of
stripes.
