Washing Machine

User Manual

BFL8510MG

Document Number=

This product was manufactured using the latest technology in environmentally friendly conditions.

3 / EN

Washing Machine / User’s Manual

1 General safety instructions

This section includes security instructions which may help prevent the

injuries and material damage risks. All kinds of warranties shall be invalid if

these instructions are not observed.

1.1 Life and property safety

Never place the product on a carpet-covered floor. Electrical parts will get

overheated since air cannot circulate from under the device. This will cause

problems with your product.

Unplug the product if it is not in use.

Always have the installation and repairing procedures carried out by the

Authorized Service Agent. Manufacturer shall not be held liable for damages

that may arise from procedures carried out by unauthorized persons.

The water supply and draining hoses must be securely fastened and remain

undamaged. Otherwise, water leak may occur.

While there is still water inside the product, never open the loading door or

remove the filter. Otherwise, risk of flooding and injury from hot water will

occur.

Do not force open the locked loading door. Door can be opened a few

minutes after the washing cycle ends. In case of forcing the loading door to

open, the door and the lock mechanism may get damaged.

Use detergents, softeners and supplements suitable for automatic washing

machines only.

Follow the instructions on the label of textiles and the detergent package.

1.2 Children's safety

This product can be used by the children who are at the age of 8 and

over and the people whose physical, sensory or mental skills are not

fully developed or who do not have necessary required experience and

knowledge as long as they are supervised or trained about the safe use of

the product and its risks. Children should not play with the device. Cleaning

and maintenance works should not be performed by children unless they

are supervised by someone. Children of less than 3 years should be kept

away unless continuously supervised.

Packaging materials may be dangerous for the children. Keep packaging

materials in a safe place away from reach of the children.

Electrical products are dangerous for the children. Keep the children away

from the product when it is in use. Do not allow them to play with the product.

Use child lock to prevent children from intervening with the product.

4 / EN

Washing Machine / User’s Manual

Do not forget to close the loading door when leaving the room where the

product is located.

store all detergents and additives in a safe place away from the reach of

the children by closing the cover of the detergent container or sealing the

detergent package.

1.3 Electrical safety

If the product has a failure, it should not be operated unless it is repaired by

the Authorized Service Agent. Risk of electric shock!

This product is designed to resume operating in the event of powering

on after a power interruption. If you wish to cancel the programme, see

"Cancelling the programme" section.

Plug the product into a grounded outlet protected by a 16 A fuse. Do not

neglect to have the grounding installation made by a qualified electrician.

Our company shall not be liable for any damages that will arise when the

product is used without grounding in accordance with the local regulations.

Do not wash the product by spraying or pouring water onto it! Risk of electric

shock!

Never touch the power cable plug with wet hands! Do not grab the power

cord to unplug the machine, always unplug it by holding the socket with one

hand, and pulling the plug with the other hand.

Product should be unplugged during installation, maintenance, cleaning

and repair procedures.

If the power cable is damaged, it must be replaced by the manufacturer,

after sales service or a similarly qualified person (preferably an electrician)

or someone designated by the importer in order to avoid possible risks.

1.4 Hot surface safety

While washing the laundry at high temperatures,

the loading door glass will get hot. Considering

this fact, during washing operation keep the

children away from the loading door of the

product to prevent them touching it.

5 / EN

Washing Machine / User’s Manual

Important instructions for environment

2.1 Compliance with WEEE Directive

This product complies with EU WEEE Directive (2012/19/EU). This product bears a

classification symbol for waste electrical and electronic equipment (WEEE).

This product has been manufactured with high quality parts and materials which can be

reused and are suitable for recycling. Do not dispose of the waste product with normal

domestic and other wastes at the end of its service life. Take it to the collection center for

the recycling of electrical and electronic equipment. Please consult your local authorities to

learn about these collection centers.

Compliance with RoHS Directive:

The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not contain

harmful and prohibited materials specified in the Directive.

2.2 Package information

Packaging materials of the product are manufactured from recyclable materials in accordance with

our National Environment Regulations. Do not dispose of the packaging materials together with the

domestic or other wastes. Take them to the packaging material collection points designated by the local

authorities.

3 Intended use

• Thisproducthasbeendesignedfordomesticuse.Itisnotforcommercialpurposesoritshouldnotbeused

out of its intended use.

• Theproductmustonlybeusedforwashingandrinsingoflaundrythataremarkedaccordingly.

• Themanufacturerwaivesanyresponsibilityarisenfromincorrectusageortransportation.

6 / EN

Washing Machine / User’s Manual

4 Technical specifications

Supplier name or trademark Beko

Model name BFL8510MG

Rated capacity (kg) 8,5

Maximum spin speed (rpm) 1400

Built-in No

Height (cm) 84

Width (cm) 60

Depth (cm) 60

Net weight (±4 kg.) 75

Single Water inlet / Double Water inlet

•/-

•Available

Electrical input (V/Hz) 220-240 V / 50Hz

Total current (A) 10

Total power (W) 2000-2350

Main model code 108

Technical specifications may be changed without prior notice to improve the quality of the product.

7 / EN

Washing Machine / User’s Manual

4.1 Installation

• Applytothenearestauthorizedserviceagentfortheinstallationofyourproduct.

• Preparationofthelocationandelectrical,tapwaterandwastewaterinstallationsattheplaceofinstallation

is under customer's responsibility.

• Makesurethatthewaterinletanddischargehosesaswellasthepowercablearenotfolded,pinchedor

crushed while pushing the product into its place after installation or cleaning procedures.

• Makesurethattheinstallationandelectricalconnectionsoftheproductareperformedbyauthorized

service. Manufacturer shall not be held liable for damages that may arise from procedures carried out by

unauthorized persons.

• Priortoinstallation,visuallycheckiftheproducthasanydefectsonit.Ifso,donothaveitinstalled.

Damaged products cause risks for your safety.

4.1.1 Appropriate installation location

• Placetheproductonahardandlevelfloor.Donotputitontoacarpetwithhighpileorothersimilar

surfaces.

• Whenthewashingmachineanddryerareplacedontopofeachother,theirtotalweight–whenloaded–

amounts to 180 kilograms. Place the product on a solid and flat floor that has sufficient load carrying

capacity!

• Donotplacetheproductonthepowercable.

• Donotinstalltheproductintheenvironmentswherethetemperaturefallsbelow0ºC.

• Leaveaminimumspaceof1cmbetweenthemachineandthefurniture.

• Onagraduatedfloor,donotplacetheproductnexttotheedgeoronaplatform.

4.1.2 Removing packaging reinforcement

Tilt the machine backwards to remove the packaging reinforcement.

Remove the packaging reinforcement by pulling the ribbon. Do not make

this operation alone by yourself.

4.1.3 Removing the transportation locks

1 Loosen all bolts with an appropriate wrench until they turn freely.

2 Remove the transport safety bolts by turning them slightly.

3 Insert the plastic covers in the bag containing the user manual to the openings on the rear panel.

CAUTION: Remove the transportation safety bolts before operating the washing machine! Otherwise, the product will be

damaged.

Keep the transportation safety bolts in a safe place to reuse when the washing machine needs to be moved again in the

future.

Install the transport safety bolts in reverse order of the disassembly procedure.

Never move the product without the transportation safety bolts properly fixed in place!

8 / EN

Washing Machine / User’s Manual

4.1.4 Connecting water supply

Thewatersupplypressurerequiredtoruntheproductisbetween1to10bars(0.1–1MPa).Itisnecessarytohave

10–80litersofwaterflowingfromthefullyopentapinoneminutetohaveyourmachinerunsmoothly.Attachapressure

reducing valve if water pressure is higher.

CAUTION: Models with a single water inlet should not be connected to the hot water tap. In such a case the laundry will

get damaged or the product will switch to protection mode and will not operate.

CAUTION: Do not use old or used water inlet hoses on the new product. It may cause stains on your laundry.

1 Tighten the nuts of the hose by hand. Never use a tool when

tightening the nuts.

2 When hose connection is completed, check whether there is leak

problems at the connection points by opening the taps fully. If any

leaks occur, turn off the tap and remove the nut. Retighten the nut

carefully after checking the seal. In order to prevent the water leaks

and resultant damages, keep the taps closed when you do not use

the product.

4.1.5 Connecting the drain hose to the drain

• Attachtheendofthedrainhosedirectlytowastewaterdrain,lavatoryorbathtub.

CAUTION: Your drain house will be flooded if the hose comes out of its housing during water discharge. Moreover, there

is risk of scalding due to high washing temperatures! In order to prevent such situations and make sure that the machine

performs water intake and discharge processes without any problem, fix the drain hose securely.

40 cm

100 cm

•Connectthedrainhosetoaminimumheightof40cm

and a maximum height of 100 cm.

•Incasethedrainhoseiselevatedafterlayingitonthe

floor level or close to the ground (less than 40 cm above

the ground), water discharge becomes more difficult and

the laundry may come out excessively wet. Therefore,

follow the heights described in the figure.

• Topreventthewastewatertogobackintothemachineagainandtoensureeasydrainage,donotimmerse

the end of the hose into the waste water or do not insert it into the drain for more than 15 cm. If it is too

long, cut it short.

• Theendofthehoseshouldnotbebent,itshouldnotbesteppedonandthehosemustnotbepinched

between the drain and the machine.

• Ifthelengthofthehoseistooshort,useitbyaddinganoriginalextensionhose.Lengthofthehosemay

not be longer than 3.2 m. To avoid water leak failures, the connection between the extension hose and the

drain hose of the product must be fitted well with an appropriate clamp as not to come off and leak.

9 / EN

Washing Machine / User’s Manual

4.1.6 Adjusting the feet

CAUTION: In order to ensure that the product operates more silently and vibration-free, it must stand level and balanced

on its feet. Balance the machine by adjusting the feet. Otherwise, the product may move from its place and cause crushing

and vibration problems.

CAUTION: Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged.

1 Loosen the lock nuts on the feet by hand.

2 Adjust the feet until the product stands in a stable and balanced way.

3. Tighten all lock nuts by hand again.

4.1.7 Electrical connection

Connect the product to a grounded outlet protected by a 16 A fuse. Our company shall not be liable for any

damages that will arise when the product is used without grounding in accordance with the local regulations.

• Connectionmustcomplywithnationalregulations.

• Powercableplugmustbewithineasyreachafterinstallation.

• Ifthecurrentvalueofthefuseorbreakerinthehouseislessthan16Amps,haveaqualifiedelectrician

install a 16 Amp fuse.

• Thevoltagespecifiedinthe"Technicalspecifications"sectionmustbeequaltoyourmainsvoltage.

• Donotmakeconnectionsviaextensioncablesormulti-plugs.

CAUTION: Damaged power cables must be replaced by the Authorized Service Agents.

4.1.8 Initial use

Before starting to use the product make sure that the preparations are

made which are in line with the “Important Safety and Environment

Instructions” and the instructions in the “Installation” section.

To prepare the product for washing laundry, perform first operation

in Drum Cleaning programme. If this program is not available in your

machine, apply the method which is described in the section 4.4.2.

Use an anti-limescale suitable for the washing machines.

Some water might have remained in the product due to the quality control processes in the production. It is not harmful for

the product.

10 / EN

Washing Machine / User’s Manual

4.2 Preparation

4.2.1 Sorting the laundry

* Sort laundry according to type of fabric, color, and degree of soiling and allowable water temperature.

* Always obey the instructions given on the garment tags.

4.2.2 Preparing laundry for washing

• Laundryitemswithmetalattachmentssuchas,underwiredbras,beltbucklesormetalbuttonswilldamage

the machine. Remove the metal pieces or wash the clothes by putting them in a laundry bag or pillow case.

• Takeoutallsubstancesinthepocketssuchascoins,pensandpaperclips,andturnpocketsinsideoutand

brush. Such objects may damage the product or cause noise problem.

• Putsmallsizeclothessuchasinfant'ssocksandnylonstockingsinalaundrybagorpillowcase.

• Placecurtainsinwithoutcompressingthem.Removecurtainattachmentitems.

• Fastenzippers,sewloosebuttonsandmendripsandtears.

• Wash“machinewashable”or“handwashable”labeledproductsonlywithanappropriateprogramme.

• Donotwashcoloursandwhitestogether.New,darkcolouredcottonsreleasealotofdye.Washthem

separately.

• Toughstainsmustbetreatedproperlybeforewashing.Ifunsure,checkwithadrycleaner.

• Onlyusethedyes/colorchangersanddescalingagentswhichareappropriatetomachinewash.Always

follow the instructions on the package.

• Washtrousersanddelicatelaundryturnedinsideout.

• KeeplaundryitemsmadeofAngorawoolinthefreezerforafewhoursbeforewashing.Thiswillreduce

pilling.

• Laundrythataresubjectedtomaterialssuchasflour,limedust,milkpowder,etc.intenselymustbeshaken

off before placing into the machine. Such dusts and powders on the laundry may build up on the inner parts

of the machine in time and can cause damage.

4.2.3 Things to be done for energy saving

Following information will help you use the product in an ecological and energy-efficient manner.

• Operatetheproductinthehighestcapacityallowedbytheprogrammeyouhaveselected,butdonot

overload; see, "Programme and consumption table". See, “Programme and consumption table"

• Alwaysfollowtheinstructionsonthedetergentpackaging.

• Washslightlysoiledlaundryatlowtemperatures.

• Usefasterprogrammesforsmallquantitiesoflightlysoiledlaundry.

• Donotuseprewashandhightemperaturesforlaundrythatisnotheavilysoiledorstained.

• Ifyouplantodryyourlaundryinadryer,selectthehighestspinspeedrecommendedduringwashing

process.

• Donotusemoredetergentthantherecommendedamountspecifiedonitspackage.

4.2.4 Loading the laundry

1. Open the laundry cover.

2. Put the laundry items into the machine in a loose manner.

3. Push and close the loading cover until you hear the locking sound. Ensure that no items are caught in the

door. The loading door is locked while a programme is running. The door can only be opened a while after

the programme comes to an end.

4.2.5 Correct load capacity

The maximum load capacity depends on the type of laundry, the degree of soiling and the washing

programme desired.

Machine automatically adjusts the water amount according to the weight of the laundry put inside it.

WARNING: Follow the information in the “Programme and consumption table”. When overloaded, machine's washing

performance will drop. Moreover, noise and vibration problems may occur.

11 / EN

Washing Machine / User’s Manual

4.2.6 Using detergent and softener

When using detergent, softener, starch, fabric dye, bleacher and decolorant, descaling agents; read the manufacturer's

instructions written on the package and follow the dosages specified. Use measuring cup if available.

The detergent drawer is composed of three compartments:

–(1)forprewash

–(2)formainwash

–(3)forsoftener

–( ) in addition, there is a siphon piece in the softener

compartment.

Detergent, softener and other cleaning agents

• Adddetergentandsoftenerbeforestartingthewashingprogramme.

• Whilethewashingcycleisinprogress,donotleavethedetergentdispenseropen!

• Whenusingaprogrammewithoutprewash,donotputanydetergentintotheprewashcompartment

(compartment nr. "1").

• Inaprogrammewithprewash,donotputliquiddetergentintotheprewashcompartment(compartmentnr.

"1").

• Donotselectaprogrammewithprewashifyouareusingadetergentbagordispensingball.Placethe

detergent bag or the dispensing ball directly among the laundry in the machine.

If you are using liquid detergent, do not forget to place the liquid detergent container into the main wash

compartment (compartment number “2”).

Choosing the detergent type

Detergent type to be used depends on the fabric type and color.

• Usedifferentdetergentsforcolouredandwhitelaundry.

• Washyourdelicateclothesonlywithspecialdetergents(liquiddetergent,woolshampoo,etc.)usedsolely

for delicate clothes.

• Whenwashingdarkcolouredclothesandquilts,itisrecommendedtouseliquiddetergent.

• Washwoolenswithspecialdetergentmadespecificallyforwoolens.

CAUTION: Use only detergents manufactured specifically for washing machines.

CAUTION: Do not use soap powder.

Adjusting detergent amount

The amount of washing detergent to be used depends on the amount of laundry, the degree of soiling and

water hardness.

• Donotuseamountsexceedingthedosagequantitiesrecommendedonthedetergentpackagetoavoid

problems of excessive foam, poor rinsing, financial savings and finally, environmental protection.

• Uselesserdetergentforsmallamountsorlightlysoiledclothes.

Using softeners

Pour the softener into the softener compartment of the detergent drawer.

• Donotexceedthe(>max<)levelsignonthesoftenercompartment.

• Ifthesoftenerhaslostitsfluidity,diluteitwithwaterbeforeputtingitinthedetergentdrawer.

12 / EN

Washing Machine / User’s Manual

Using liquid detergents

If the product contains a liquid detergent cup:

• Puttheliquiddetergentcontainerintothe

compartment no “2”.

• Iftheliquiddetergentlostitsfluidity,diluteit

with water before putting it into the detergent

container.

If the product does not contain a liquid detergent cup:

• Donotuseliquiddetergentfortheprewashinaprogrammewithprewash.

• LiquiddetergentstainsyourclotheswhenusedwithDelayedStartfunction.Ifyouaregoingtousethe

Delayed Start function, do not use liquid detergent.

Using gel and tablet detergent

• Ifthegeldetergentthicknessisfluidalandyourmachinedoesnotcontainaspecialliquiddetergentcup,

put the gel detergent into the main wash detergent compartment during first water intake. If your machine

contains a liquid detergent cup, fill the detergent into this cup before starting the programme.

• Ifthegeldetergentthicknessisnotfluidalorintheshapeofcapsuleliquidtablet,putitdirectlyintothe

drum before washing.

• Puttabletdetergentsintothemainwashcompartment(compartmentnr."2")ordirectlyintothedrum

before washing.

Using starch

• Puttheliquidsoda,powdersodaorthefabricdyeintothesoftenercompartment.

Do not use softener and starch together in a washing cycle.

Wipe the inside of the machine with a damp and clean cloth after using starch.

Using limescale remover

•Whenrequired,uselimescaleremoversmanufacturedspecificallyforwashingmachinesonly.

Using bleaches

Add the bleach at the beginning of the washing cycle by selecting a prewash program. Do not put detergent

in the prewash compartment. As an alternative application, select a programme with extra rinse and add

the bleaching agent while the machine is taking water from the detergent compartment during first rinsing

step.

• Donotusebleachingagentanddetergentbymixingthem.

• Usejustalittleamount(approx.50ml)ofbleachingagentandrinsetheclothesverywellasitcausesskin

irritation. Do not pour the bleach onto the laundry and do not use it with the colored items.

• Whenusingoxygen-baseddecolorant,selectaprogramwhichwashesthelaundryatalowtemperature.

• Oxygen-baseddecolorantcanbeusedwiththedetergent;however,ifitisnotatthesameconsistence,first

put detergent in the compartment number “2” in the detergent dispenser and wait for the machine to flush

the detergent when taking in water. While the machine continues taking in water, add decolorant in the

same compartment.

13 / EN

Washing Machine / User’s Manual

4.2.7 Tips for efficient washing

Clothes

Light Colours and

Whites

Colours

Black/Dark

Colours

Delicates/

Woolens/Silks

(Recommended temperature

range based on soiling level:

40-90

(Recommended temperature range

based on soiling level: cold -40

(Recommended

temperature range based

on soiling level: cold

-40

(Recommended

temperature range

based on soiling

level: cold -30

Soiling Level

Heavily

Soiled

(difficult stains

such as grass,

coffee, fruits and

blood.)

It may be necessary to pre-treat

the stains or perform prewash.

Powder and liquid detergents

recommended for whites can be

used at dosages recommended

for heavily soiled clothes. It is

recommended to use powder

detergents to clean clay and soil

stains and the stains that are

sensitive to bleaches.

Powder and liquid detergents

recommended for colors can be

used at dosages recommended

for heavily soiled clothes. It is

recommended to use powder

detergents to clean clay and

soil stains and the stains that

are sensitive to bleaches. Use

detergents without bleach.

Liquid detergents

suitable for colors

and dark colors can

be used at dosages

recommended for heavily

soiled clothes.

Prefer liquid

detergents produced

for delicate clothes.

Woolen and silk

clothes must be

washed with special

woolen detergents.

Normally

Soiled

(For example,

stains caused by

body on collars

and cuffs)

Powder and liquid detergents

recommended for whites can be

used at dosages recommended

for normally soiled clothes.

Powder and liquid detergents

recommended for colors can be

used at dosages recommended for

normally soiled clothes. Detergents

which do not contain bleach should

be used.

Liquid detergents

suitable for colors

and dark colors can

be used at dosages

recommended for

normally soiled clothes.

Prefer liquid

detergents produced

for delicate clothes.

Woolen and silk

clothes must be

washed with special

woolen detergents.

Lightly

Soiled

(No visible stains

exist.)

Powder and liquid detergents

recommended for whites can be

used at dosages recommended

for lightly soiled clothes.

Powder and liquid detergents

recommended for colors can be

used at dosages recommended for

lightly soiled clothes. Detergents

which do not contain bleach should

be used.

Liquid detergents

suitable for colors

and dark colors can

be used at dosages

recommended for lightly

soiled clothes.

Prefer liquid

detergents produced

for delicate clothes.

Woolen and silk

clothes must be

washed with special

woolen detergents.

14 / EN

Washing Machine / User’s Manual

4.3 Operating the product

4.3.1 Control panel

1 - Programme selection knob

2 - Temperature level lights

3 - Spin level indicator lights

4 - Duration information display

5 - Child lock enabled light

6 - End Time Setting button

7 - Door lock enabled light

8 - Programme Follow-up indicator lights

9 - On / Off button

10 - Start / Pause button

11 - Auxiliary function buttons 3

12 - Auxiliary function buttons 2

13 - Auxiliary function buttons 1

14 - Spin speed adjustment button

15 - Temperature adjustment button

16 - Programme selection indicator lights

3 4 5 6

7 8

11121314

15 / EN

Washing Machine / User’s Manual

4.3.2 Programme and consumption table

Note for test institutions:

Data required for performance tests shall be provided upon request. Requests can be e-mailed to the following address:

info.australialaundry@beko.com

Do not forget to provide the code, stock and serial numbers of the product to be tested in your request e-mail along with your contact

information. Code, stock and serial numbers of the product is located on the type label attached to the inside of the door.

• :Selectable.

* : Automatically selected, no canceling.

** : Energy Label programme ( AS/NZS 2040)

*** : If maximum spin speed of the product is lower then this value, you can only select up to the maximum spin speed.

- : See the programme description for maximum load.

The auxiliary functions in the table may vary according to the model of your product.

Water and power consumption may vary subject to the changes in water pressure, water hardness and temperature, ambient

temperature, type and amount of laundry, selection of auxiliary functions and spin speed, and changes in electric voltage.

You can see the washing time of the programme you have selected on the display of the product. It is normal that small differences

may occur between the time shown on the display and the real washing time.

Auxiliary function selection modes can be changed by the manufacturing company. Existing selection modes can be removed or new

selection modes can be added.

"The manufacturer reserves the right to make modifications in the programmes and auxiliary functions given in the table. While these

modifications will not change the product performance, programme steps and durations can change."

16 / EN

Washing Machine / User’s Manual

4.3.3 Programme selection

1 Determine the programme suitable for the type, quantity and soiling level of the laundry in accordance with

the "Programme and consumption table".

Programmes are limited with the highest spin speed appropriate for that particular type of fabric.

When selecting a programme, always consider the type of fabric, colour, degree of soiling and permissible water temperature.

Always select the relevant lowest required temperature. Higher temperature means higher electricity consumption.

2 Select the desired programme with the Programme Selection knob.

4.3.4 Programmes

• Cottons Eco

Use to wash your normally soiled, durable cotton and linen laundry. Although it washes longer than all other

programmes, it provides high energy and water savings. Actual water temperature may be different from the

stated wash temperature. When you load the machine with less laundry (e.g. ½ capacity or less), periods in

programme stages may automatically get shorter. In this case, energy and water consumption will decrease

more, providing a more economic wash.

Normally soiled laundry may be washed with reduced amount of detergent to save energy and protect the

environment.

• Cottons

You can wash your durable cotton laundry (sheets, bedlinen, towels, bathrobes, underwear etc.) in this

programme. When the fast+ wash function key is pressed, programme duration becomes notably shorter but

effective washing performance is ensured with intense washing movements. If the fast+ wash function is not

selected, superior washing and rinsing performance is ensured for your heavily soiled laundry.

• Synthetics

You can wash your laundry (such as shirts, blouses, synthetic/cotton blended fabrics etc.) in this programme.

The programme duration gets notable shorter and washing with high performance is ensured. If the fast+

wash function is not selected, superior washing and rinsing performance is ensured for your heavily soiled

laundry.

• Wool / Hand Wash

Use to wash your woolen/delicate laundry. Select the appropriate temperature complying with the tag of your

clothes. Your laundry will be washed with a very gentle washing action in order not to damage the clothes.

The Woolmark Company confirms that the woolen washing programme of this

product can be used to wash machine-washable woolen products provided to

follow the information on the label of the cloth and the instruction given by the

manufacturer of this product. M13985

17 / EN

Washing Machine / User’s Manual

• Anti-Allergy +

Use this programme for your laundry for which you require an anti-allergic and hygienic washing at high

temperature with intensive and long washing cycle. The high level of hygiene is ensured thanks to long heating

duration and additional rinsing step.

 •Programmewastestedbythe“VDE”institutewiththe20°Ctemperatureoptionselectedanditwas

certified in terms of its efficacy in eliminating bacteria and mould.

 •Programmewastestedby“TheBritishAllergyFoundation”(AllergyUK)withthe60°Ctemperature

option selected and it was certified in terms of its efficacy in eliminating allergens in addition to bacteria and

mould.

Allergy UK is the operational name of The British Allergy Foundation. The Seal of Approval

endorsement, which indicates that the product bearing it specifically restricts / reduces /

removes allergens from the environment of the allergy sufferer or has significantly reduced

allergen content, was created in order to provide guidance for people seeking advice in this

issue. It is aimed to assure poeple that products had been scientifically tested or reviewed

with measurable results.

• Dark Care / Jeans

Use this programme to protect the colour of your dark-coloured garments or jeans. It performs high

performance washing with special drum movement even if the temperature is low. When the fast+ wash

function is selected, the effective washing performance is maintained even if the washing duration gets

notably shorter. It is recommended to use liquid detergent or woolen shampoo for dark coloured laundry. Do

not wash your delicate clothes containing wool or etc.

• Spin+Drain

You can use this function to remove the water on the garment of drain the water in the machine.

• Rinse

Use when you want to rinse or starch separately.

• Shirts

This programme is used to wash the shirts made from cotton, synthetic and synthetic blended fabrics

altogether. It reduces wrinkles. When the fast+ wash function is selected, the Pre-treatment algorithm is

executed.

 •Applythepre-treatmentchemicalonyourgarmentsdirectlyoraddittogetherwithdetergentwhen

the machine starts to take water from the main washing compartment. Thus, you can obtain the same

performance as you obtain with normal washing in a much shorter period of time. Usage life of your shirts

increases.

• Mix 40

Use to wash your cotton and synthetic clothes together without sorting them.

• Delicates

You can wash your delicate clothes such as cotton/synthetic blended knitwear or hosiery in this programme. It

washes with more delicate washing action. Wash your clothes whose colour you want to preserve either at 20

degrees or by selecting the cold wash option.

• Daily Quick / Quick 14

Use this programme to wash your lightly soiled or unspotted cotton clothes in a short time. The programme

duration can be reduced up to 14 minutes when the fast+ wash function is selected. When the fast+ wash

function is selected, maximum 2 (two) kg of laundry must be washed.

18 / EN

Washing Machine / User’s Manual

• Bedding&Blanket

Use this programme to wash your fiber duvets that bear "machine washable" tag. Check that you have loaded

the duvet correctly in order not to damage the machine and the duvet. Remove the duvet cover before loading

the duvet into the machine. Fold the duvet into two and load it into the machine. Load the duvet into the

machine paying attention to place it in a way that it will not contact the bellow or the glass.

Do not load more than 1 double fiber duvet (200 x 200 cm).

Do not wash your duvets, pillows and etc. that contain cotton in the machine.

CAUTION: Do not wash the items apart from duvets such as carpets, rugs and etc. in the machine. Permanent damage

occurs in the machine.

• Sports&Outdoor

You can use this programme to wash sports and outdoors garments that contain cotton/synthetics mix and

water repellent covers such as gore-tex etc. It makes sure your garments are washed gently thanks to special

rotating movements.

•

CoolClean

Use to wash your moderately soiled and durable cotton/synthetic laundry. An effective washing is provided

thanks to the intense washing action and double jet system.

• StainExpert

The machine has a special stain programme which enables the removal of different types of stains in the

most effective way. Use this programme only for durable colourfast cotton laundry. Do not wash delicate

and pigmenting clothes and laundry in this programme. Before washing, garment tags should be checked

(recommended for cotton shirts, trousers, shorts, t-shirts, baby clothes, pyjamas, aprons, table clothes,

beddings, duvet cover, bed sheet, pillowcase, bath-beach towel, towel, socks, cotton underwear that are

suitable for washing at high temperature and long time). In the automatic stain programme, you can wash

24 types of stains divided into two different groups according to fast+ function selection. You can see stain

groups based on the selection of the fast+ function.

You can find stain groups based on fast+ function below:

When Fast+ function is selected:

Blood Tea Red Wine

Chocolate Coffee Curry

Pudding Fruit juice Jam

Egg Ketchup Coal

19 / EN

Washing Machine / User’s Manual

When Fast+ function is not selected:

Butter Sweat Salad Dressing

Grass Collar Soil Make-up

Mud Food Machine Oil

Coke Mayonnaise Baby Food

•Selectthestainprogramme.

•Selectthestainyouwanttocleanbylocatingitinthegroupsaboveandselectingtherelatedgroupwiththe

fast+ auxiliary function key.

•Readthegarmenttagcarefullyandensurethatcorrecttemperatureandspinspeedareselected.

4.3.5 Temperature selection

Whenever a new programme is selected, the recommended temperature for the selected programme appears

on the temperature indicator.

To decrease the temperature, press the Temperature Adjustment button. Temperature will decrease gradually.

Temperature level lights will not turn on when the cold level is selected.

If the programme has not reached the heating step, you can change the temperature without switching the product to Pause

mode.

4.3.6 Spin speed selection

Whenever a new programme is selected, the recommended spin speed of the selected programme is

displayed on the spin speed indicator.

To decrease the spin speed, press the Spin Speed Adjustment button. Spin speed decreases gradually.

Then, depending on the model of the product, "Rinse Hold" and "No Spin" options appear on the display.

When "No Spin" is selected, the rinse level indicator lights will not turn on.

If the programme has not reached the spinning step, you can change the spinning speed without switching the product to

Pause mode.

20 / EN

Washing Machine / User’s Manual

Rinse hold

If you are not going to unload your clothes immediately after the programme completes, you can use rinse

hold function to keep your laundry in the final rinsing water in order to prevent them from getting wrinkled

when there is no water in the product. Press Start/Pause button after this process if you want to drain the

water without spinning your laundry. Programme will resume and complete after draining the water.

If you want to spin the laundry held in water, adjust the spin speed and press Start / Pause button. The

programme will resume. Water is drained, laundry is spun and the programme is completed.

4.3.7 Auxiliary function selection

Select the desired auxiliary functions before starting the programme.

Chosen auxiliary function indicator lights up.

When you try to change an auxiliary function that is not allowed to be selected with the current programme, indicator light

of the relevant auxiliary function will flash and an audio warning is given.

Furthermore, you may also select or cancel auxiliary functions that are suitable to the running programme

after the washing cycle starts. If the wash cycle has reached a point where no auxiliary function can be

selected, an audio warning will be given and the related auxiliary function's light will flash.

Some functions cannot be selected together. If a second auxiliary function conflicting with the first one is selected before

starting the product, the function selected first will be canceled and the second auxiliary function selection will remain active.

An auxiliary function that is not compatible with the programme cannot be selected. (See, "Programme and consumption

table".)

Some programmes have auxiliary functions that must be operated simultaneously. Those functions cannot be cancelled. The

frame of the auxiliary function will not be illuminated, only inner area will be illuminated.

4.3.7.1 Auxiliary functions

• Prewash

A Prewash is only worthwhile for heavily soiled laundry. Not using the Prewash will save energy, water,

detergent and time.

• Fast+

When this function is selected, the durations of the relevant programmes get shorter by 50%.

Thanks to the optimised washing steps, high mechanic activity and optimum water consumption,

high washing performance is achieved in spite of the reduced duration.

• Pet Hair Removal

This function helps to remove pet hair that remain on your garments more effectively.

When you select this function, Prewash and Extra Rinse steps are added to the normal programme. Thus,

washing is performed with more water and the pet hair is removed more effectively.

21 / EN

Washing Machine / User’s Manual

4.3.7.2 Functions/Programs selected by pressing the key for 3”

• Drum Cleaning

Use regularly (once in every 1-2 months) to clean the drum and provide the required hygiene. Operate the

programme while the machine is completely empty. To obtain better results, put powder lime-scale remover

for washing machines into the detergent compartment no. “2”. When the programme is over, leave the loading

door ajar so that the inside of the machine gets dry.

Press and hold the 1st auxiliary function key for 3 seconds to select the programme.

This is not a washing programme. It is a maintenance programme.

Do not run the programme when there is something in the machine. If you try to do so, the machine detects that there is

load inside and aborts the programme.

• Child Lock

Use Child Lock function to prevent children from tampering with the product. Thus you can avoid any changes

in a running programme.

You can switch on and off the product with On / Off button when the Child Lock is active. When you switch on the product

again, programme will resume from where it has stopped.

To activate the Child Lock:

Press and hold 2nd auxiliary function button for 3 seconds. In the programme selection display on the

panel, „CL 3-2-1 On“ light will turn on. When this light is on you can stop pressing on 2nd when this warning

is displayed.

To deactivate the Child Lock:

Press and hold 2nd Auxiliary Function button for 3 seconds. In the programme selection display on the

panel, „CL 3-2-1 Off“ light will turn on.

• Anti-Creasing+

This function is selected when the 3rd auxiliary function is pressed and held for 3 seconds and the

programme follow-up light for the relevant step turns on. When the function is selected, the drum rotates

for up to 8 hours for preventing the laundry from creasing at the end of the programme. You can cancel the

programme and take your laundry out at any time during the 8-hour duration. Press the function selection

key or the machine on/off key to cancel the function. The programme follow-up light will remain on until the

function is canceled or the step is complete.

4.3.8 End Time

With the End Time function, the startup of the programme may be delayed up to 24 hours. After pressing

End Time button, the programme's estimated ending time is displayed. If the End Time is adjusted, End Time

indicator is illuminated.

1 Open the loading door, place the laundry and put detergent, etc.

2 Select the washing programme, temperature, spin speed and, if required, the auxiliary functions.

3 Set the end time of your choice by pressing the End Time button. End Time indicator illuminates.

4 Press Start / Pause button. Time countdown starts. “:” symbol in the middle of the end time on the display

starts flashing.

22 / EN

Washing Machine / User’s Manual

Adjusting the end time

If you want to cancel End Time function, press On / Off button to turn off and on the product.

Do not use liquid detergents when you activate End Time function! There is the risk of staining of the clothes.

You must press Start/Pause and wait for the door to open to add laundry into the machine during the End Time countdown.

Press Start/Pause once again after adding the laundry to resume the countdown. At the end of the countdown, End Time

indicator turns off, washing cycle starts and the time of the selected programme appears on the display.

When the End Time selection is completed, the time appears on the screen is the total of the end time chosen with the

duration of the selected programme.

4.3.9 Starting the programme

1. Press Start / Pause button to start the programme.

2. Programme follow-up light showing the startup of the programme will turn on.

If no programme is started or no key is pressed within 10 minute during programme selection process, the product will turn

off automatically. Display and all indicators will turn off.

If you press on the On / Off button, the programme information set as default will be displayed.

4.3.10 Loading door lock

There is a locking system on the loading door of the product that prevents opening of the door in cases when

the water level is unsuitable.

"Door Locked" light in the panel turns on when the loading door is locked.

4.3.11 Changing the selections after programme has started

After the programme has started you can make the following changes.

Switching the product to pause mode

Press the Start/Pause button to switch the machine to pause mode while a programme is running. The light

of the step which the machine is in starts flashing in the Programme Follow-up indicator to show that the

machine has been switched to the pause mode. Also loading door light blinks until the door is ready to be

opened. When the loading door is ready to be opened Loading Door light will turn off, programme step light

will continue to flash.

Changing the auxiliary function, speed and temperature

Depending on the step the programme has reached, you can cancel or select the auxiliary functions. See

"Auxiliary function selection".

Also you can change temperature and cycle adjustments. See "Temperature selection" and "Spin speed

selection".

If no change is allowed, the relevant light will flash 3 times.

Adding or taking out laundry

1. Press the Start / Pause button to switch the product to pause mode. The programme follow-up light of the

relevant step during which the machine was switched into the pause mode will flash.

2. Wait until the Loading Door can be opened.

3. Open the Loading Door and add or take out the laundry.

4. Close the Loading Door.

5. Make changes in auxiliary functions, temperature and speed settings if necessary.

6. Press Start / Pause to operate the product.

23 / EN

Washing Machine / User’s Manual

4.3.12 Cancelling the programme

The programme is cancelled when the product is turned off and on again. Press and hold On / Off button for

3 seconds.

If you press On / Off button when the Child Lock is enabled, the programme will not be cancelled. You should cancel the

Child Lock first.

If you want to open the loading door after you have cancelled the programme but it is not possible to open the loading

door since the water level in the product is above the loading door opening, then turn the Programme Selection knob to

Pump+Spin programme and discharge the water in the product.

4.3.13 End of programme

The "Complete" light (LED) will turn on when the programme is over.

If you do not press any button for 10 minutes, the product will turn off automatically. Display and all indicators

are turned off.

Completed programme steps will be displayed if you On / Off.

4.3.14 Energy saving mode

If no action is taken for 2 minutes after turning on the product with On / Off button or after the chosen

programme ends, the product will switch to energy saving mode automatically. The brightness of the indicator

lights will decrease. This display will be closed completely if programme time display is available.

If you turn the programme knob or touch any button, the lights will switch back to previous position.

This is a feature of this product, and not an error.

24 / EN

Washing Machine / User’s Manual

4.4 Maintenance and cleaning

Service life of product extends and frequently experienced problems will be reduced if it is cleaned at regular

intervals.

4.4.1 Cleaning the detergent drawer

Clean the detergent drawer at regular intervals (every 4-5 washing cycles) as

shown below in order to prevent accumulation of powder detergent in time.

Lift the rear part of the siphon to remove it as illustrated.

If more than normal amount of water and softener mixture starts to gather in the

softener compartment, the siphon must be cleaned.

1 Press the dotted point on the siphon in the softener compartment and pull towards you until the

compartment is removed from the machine.

2. Wash the detergent drawer and the siphon with plenty of lukewarm water in a washbasin. In order to

prevent the residues to contact your skin, clean it with an appropriate brush by wearing a pair of gloves.

3 Insert the drawer back into its place after cleaning and make sure that it is seated well.

4.4.2 Cleaning the loading door and the drum

For products with drum cleaning programme, please see Operating the product - Programmes.

Repeat Drum Cleaning process in every 2 months.

Use an detergent / anti-limescale suitable for the washing machines.

After every washing make sure that no foreign substance is left in the drum.

If the holes on the bellow shown in the figure is blocked, open the holes using a

toothpick.

Foreign metal substances will cause rust stains in the drum. Clean the stains on the

drum surface by using cleaning agents for stainless steel.

Never use steel wool or wire wool. These will damage the painted, chromated and

plastic surfaces.

4.4.3 Cleaning the body and control panel

Wipe the body of the machine with soapy water or non-corrosive mild gel detergents as necessary, and dry

with a soft cloth.

Use only a soft and damp cloth to clean the control panel.

4.4.4 Cleaning the water intake filters

There is a filter at the end of each water intake valve at the rear of the machine and also at the end of each

water intake hose where they are connected to the tap. These filters prevent foreign substances and dirt in

the water to enter the washing machine. Filters should be cleaned as they do get dirty.

1. Close the taps.

2. Remove the nuts of the water intake hoses to access

the filters on the water intake valves. Clean them with an

appropriate brush. If the filters are too dirty, remove them

from their places with a pliers and clean in this way.

3. Take out the filters on the flat ends of the water intake

hoses together with the gaskets and clean thoroughly

under running water.

4. Replace the seals and filters carefully and tighten their

nuts by hand.

25 / EN

Washing Machine / User’s Manual

4.4.5 Draining remaining water and cleaning the pump filter

The filter system in your machine prevents solid items such as buttons, coins and fabric fibers clogging the

pump impeller during discharge of washing water. Thus, the water will be discharged without any problem and

the service life of the pump will extend.

If the machine fails to drain water, the pump filter is clogged. Filter must be cleaned whenever it is clogged or

in every 3 months. Water must be drained off first to clean the pump filter.

In addition, prior to transporting the machine (e.g., when moving to another house) and in case of freezing of

the water, water may have to be drained completely.

CAUTION: Foreign substances left in the pump filter may damage your machine or may cause noise problem.

CAUTION: If the product is not being used, shut the tap shut, remove mains pipe and drain the water inside the machine

against any likely freezing.

CAUTION: After each use, turn off the water tap to which the mains hose is connected.

In order to clean the dirty filter and discharge the water:

1 Unplug the machine to cut off the supply power.

CAUTION: Temperatureofthewaterinsidethemachinemayriseupto90ºC.Toavoidtheburningrisk,cleanthefilter

after the water inside the machine is cooled down.

2. Open the filter cover.

3 Follow the below procedures in order to drain water.

The product has an emergency water draining hose, in order to drain the water:

a Pull the emergency draining hose out from its seat

b Place a large container at the end of the hose. Drain

the water into the container by pulling out the plug at

the end of the hose. When the container is full, block

the inlet of the hose by replacing the plug. After the

container is emptied, repeat the above procedure to

drain the water in the machine completely.

c When draining of water is finished, close the end by

the plug again and fix the hose in its place.

d Turn and remove the pump filter.

4. Clean any residues inside the filter as well as fibers, if any, around the pump impeller region.

5. Replace the filter.

6. If the filter cap is composed of two pieces, close the filter cap by pressing on the tab. If it is one piece, seat

the tabs in the lower part into their places first, and then press the upper part to close.

26 / EN

Washing Machine / User’s Manual

5 Troubleshooting

Problem Reason Solution

Program does not start after

closing the door.

Start / Pause / Cancel button was not pressed. •*Press the Start / Pause / Cancel button.

It may be difficult to close the loading door in case of

excessive loading.

•Reduce the amount of laundry and make sure that

the loading door is closed properly.

Programme cannot be started or

selected.

Washing machine has switched to self protection

mode due to a supply problem (line voltage, water

pressure, etc.).

• Press and hold On / Off button for 3 seconds.

(see. "Cancellation of program")

Water in the machine. Some water might have remained in the product due

to the quality control processes in the production.

•This is not a failure; water is not harmful to the

machine.

Machine does not fill with water. Tap is turned off. •Turn on the taps.

Water inlet hose is bent. •Flatten the hose.

Water inlet filter is clogged. •Clean the filter.

Loading door may be open. •Close the door.

Machine does not drain water. Water drain hose might be clogged or twisted. •Clean or flatten the hose.

Pump filter is clogged. • Clean the pump filter.

Machine vibrates or makes noise. Machine might be standing unbalanced. •Adjust the feet to level the machine.

A hard substance might have entered into the pump

filter.

•Clean the pump filter.

Transportation safety bolts are not removed. •Remove the transportation safety bolts.

Laundry quantity in the machine might be too little. •Add more laundry to the machine.

Machine might be overloaded with laundry. • Take out some of the laundry from the machine

or distribute the load by hand to balance it

homogenously in the machine.

Machine might be leaning on a rigid item. •Make sure that the machine is not leaning on

anything.

There is water leaking from the

bottom of the washing machine.

Water drain hose might be clogged or twisted. •Clean or flatten the hose.

Pump filter is clogged. • Clean the pump filter.

Machine stopped shortly after the

programme started.

Machine might have stopped temporarily due to low

voltage.

•It will resume running when the voltage restores to

the normal level.

Machine directly discharges the

water it takes in.

Draining hose might not be at adequate height. •Connect the water draining hose as described in

the operation manual.

No water can be seen in the

machine during washing.

The water level is not visible from outside of the

washing machine.

•This is not a failure.

Loading door cannot be opened. Door lock is activated because of the water level in

the machine.

•Drain the water by running the Pump or Spin

programme.

Machine is heating up the water or it is at the spinning

cycle.

• Wait until the programme completes.

Child lock is engaged. Door lock will be deactivated

a couple of minutes after the programme has come

to an end.

•Wait for a couple of minutes for deactivation of

the door lock.

Loading door may be stuck because of the pressure it

is subjected to.

•Grab the handle and push and pull the loading

door to release and open it.

Washing takes longer time than

specified in the manual.(*)

Water pressure is low. • Machine waits until taking in adequate amount

of water to prevent poor washing quality due to

the decreased amount of water. Therefore, the

washing time extends.

Voltage might be low. •Washing time is prolonged to avoid poor washing

results when the supply voltage is low.

Input temperature of water might be low. •Required time to heat up the water extends in cold

seasons. Also, washing time can be lengthened to

avoid poor washing results.

Number of rinses and/or amount of rinse water might

have increased.

•Machine increases the amount of rinse water

when good rinsing is needed and adds an extra

rinsing step if necessary.

Excessive foam might have occurred and automatic

foam absorption system might have been activated

due to too much detergent usage.

• Use recommended amount of detergent.

27 / EN

Washing Machine / User’s Manual

Problem Reason Solution

Programme time does not

countdown. (On models with

display) (*)

Timer may stop during water intake. •Timer indicator will not countdown until the

machine takes in adequate amount of water. The

machine will wait until there is sufficient amount

of water to avoid poor washing results due to lack

of water. Timer indicator will resume countdown

after this.

Timer may stop during heating step. •Timer indicator will not countdown until the

machine reaches the selected temperature.

Timer may stop during spinning step. •Automatic unbalanced load detection system

might be activated due to the unbalanced

distribution of the laundry in the drum.

Programme time does not

countdown. (*)

There might be unbalanced load in the machine. •Automatic unbalanced load detection system

might be activated due to the unbalanced

distribution of the laundry in the drum.

Machine does not switch to

spinning step. (*)

There might be unbalanced load in the machine. •Automatic unbalanced load detection system

might be activated due to the unbalanced

distribution of the laundry in the drum.

The machine will not spin if water is not drained

completely.

•Check the filter and the draining hose.

Excessive foam might have occurred and automatic

foam absorption system might have been activated

due to too much detergent usage.

• Use recommended amount of detergent.

Washing performance is poor:

Laundry turns gray. (**)

Insufficient amount of detergent has been used over a

long period of time.

•Use the recommended amount of detergent

appropriate for water hardness and the laundry.

Washing was made at low temperatures for a long

time.

•Select the proper temperature for the laundry to

be washed.

Insufficient amount of detergent is used with hard

water.

•Using insufficient amount of detergent with hard

water causes the soil to stick on the cloth and

this turns the cloth into gray in time. It is difficult

to eliminate graying once it happens. Use the

recommended amount of detergent appropriate

for water hardness and the laundry.

Too much detergent is used. •Use the recommended amount of detergent

appropriate for water hardness and the laundry.

Washing performance is poor:

Stains persist or the laundry is not

whitened. (**)

Insufficient amount of detergent is used. •Use the recommended amount of detergent

appropriate for water hardness and the laundry.

Excessive laundry was loaded in. •Do not load the machine in excess. Load with

amounts recommended in the "Programme and

consumption table".

Wrong programme and temperature were selected. • Select the proper programme and temperature for

the laundry to be washed.

Wrong type of detergent is used. •Use original detergent appropriate for the

machine.

Too much detergent is used. •Put the detergent in the correct compartment. Do

not mix the bleaching agent and the detergent

with each other.

Washing performance is poor: Oily

stains appeared on the laundry. (**)

Regular drum cleaning is not applied. •Clean the drum regularly. For this, please see

4.4.2.

Washing performance is poor:

Clothes smell unpleasantly. (**)

Odours and bacteria layers are formed on the drum as

a result of continuous washing at lower temperatures

and/or in short programmes.

•Leave the detergent drawer as well as the loading

door of the machine ajar after each washing.

Thus, a humid environment favorable for bacteria

cannot occur in the machine.

Colour of the clothes faded. (**) Excessive laundry was loaded in. •Do not load the machine in excess.

Detergent in use is damp. • Keep detergents closed in an environment free

of humidity and do not expose them to excessive

temperatures.

A higher temperature is selected. •Select the proper programme and temperature

according to the type and soiling degree of the

laundry.

28 / EN

Washing Machine / User’s Manual

Problem Reason Solution

It does not rinse well. The amount, brand and storage conditions of the

detergent used are inappropriate.

•Use a detergent appropriate for the washing

machine and your laundry. Keep detergents closed

in an environment free of humidity and do not

expose them to excessive temperatures.

Detergent is put in the wrong compartment. •If detergent is put in the prewash compartment

although prewash cycle is not selected, machine

can take this detergent during rinsing or

softener step. Put the detergent in the correct

compartment.

Pump filter is clogged. • Check the filter.

Drain hose is folded. •Check the drain hose.

Laundry became stiff after

washing. (**)

Insufficient amount of detergent is used. •Using insufficient amount of detergent for the

water hardness can cause the laundry to become

stiff in time. Use appropriate amount of detergent

according to the water hardness.

Detergent is put in the wrong compartment. •If detergent is put in the prewash compartment

although prewash cycle is not selected, machine

can take this detergent during rinsing or

softener step. Put the detergent in the correct

compartment.

Detergent might be mixed with the softener. • Do not mix the softener with detergent. Wash and

clean the dispenser with hot water.

Laundry does not smell like the

softener. (**)

Detergent is put in the wrong compartment. •If detergent is put in the prewash compartment

although prewash cycle is not selected,

machine can take this detergent during rinsing

or softener step. Wash and clean the dispenser

with hot water. Put the detergent in the correct

compartment.

Detergent might be mixed with the softener. • Do not mix the softener with detergent. Wash and

clean the dispenser with hot water.

Detergent residue in the detergent

drawer. (**)

Detergent is put in wet drawer. •Dry the detergent drawer before putting in

detergent.

Detergent has gotten damp. •Keep detergents closed in an environment free

of humidity and do not expose them to excessive

temperatures.

Water pressure is low. • Check the water pressure.

The detergent in the main wash compartment got

wet while taking in the prewash water. Holes of the

detergent compartment are blocked.

•Check the holes and clean if they are clogged.

There is a problem with the detergent drawer valves. •Call the Authorized Service Agent.

Detergent might be mixed with the softener. • Do not mix the softener with detergent. Wash and

clean the dispenser with hot water.

Regular drum cleaning is not applied. •Clean the drum regularly. For this, please see

4.4.2.

Too much foam forms in the

machine. (**)

Improper detergents for the washing machine are

being used.

•Use detergents appropriate for the washing

machine.

Excessive amount of detergent is used. •Use only sufficient amount of detergent.

Detergent was stored under improper conditions. •Store detergent in a closed and dry location. Do

not store in excessively hot places.

Some meshed laundry such as tulle may foam too

much because of their texture.

•Use smaller amounts of detergent for this type

of item.

Detergent is put in the wrong compartment. •Put the detergent in the correct compartment.

Softener is being taken early. •There may be problem in the valves or in the

detergent dispenser. Call the Authorized Service

Agent.

Foam is overflowing from the

detergent drawer.

Too much detergent is used. •Mix 1 tablespoonful softener and ½ l water and

pour into the main wash compartment of the

detergent drawer.

•Put detergent into the machine suitable for the

programmes and maximum loads indicated in the

“Programme and consumption table”. When you

use additional chemicals (stain removers, bleachs

and etc), reduce the amount of detergent.

29 / EN

Washing Machine / User’s Manual

Problem Reason Solution

Laundry remains wet at the end of

the programme. (*)

Excessive foam might have occurred and automatic

foam absorption system might have been activated

due to too much detergent usage.

•Use recommended amount of detergent.

(*) Machine does not switch to spinning step when the laundry is not evenly distributed in the drum to prevent any damage to the machine

and to its surrounding environment. Laundry should be rearranged and re-spun.

(**) Regular drum cleaning is not applied. Clean the drum regularly. See 4.4.2

CAUTION: If you cannot eliminate the problem although you follow the instructions in this section, consult your dealer or the

Authorized Service Agent. Never try to repair a nonfunctional product yourself.

Beko BFL8510MG 8.5kg Front Load Washing Machine

Product's Documents

User Manual

Specifications

Beko BFL8510MG Questions and Answers

Related Products

Beko BMM5DFO5741W 7/5KG 1400 Spin Washer Dryer - White

Beko WDA8514AT 8kg/5kg Washer Dryer Combo

BFL8520W Beko 8.5kg Front Load Washing Machine

Beko BFLB1020W 10kg Front Load Washing Machine

Beko BFLB124ADW 12kg Front Load Washing Machine

Beko BFL7520W 7.5kg Front Load Washing Machine
