Product SERIAL NO.
KX1Axxxxxxxxxx (from page 1 to 28)
KX2Axxxxxxxxxx (from page 29 to 66)
User manual
HTS3541
For product support, visit
www.philips.com/welcome
EN: For further assistance, call the customer support service in your country.
• To obtain assistance in the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands, contact
Philips Customer Care Center at 1-866-310-0744
• To obtain assistance in Mexico, contact Philips Customer Care Center at 01 800 839 1989;
Mexico city: 5887-9736
For Product recycling information, please visit - www.recycle.philips.com
P&F USA, Inc.
1
English
EN
Contents
1 Important 2
Important safety instructions 2
Care for your product
3
Care of the environment
3
3D health warning
3
Help and support
4
2 Your home theater 4
Main unit 4
Connectors
4
Remote control
5
3 Connect and set up 7
Connect speakers 7
Connect to TV
7
Connect audio from TV and other devices
9
Set up speakers
9
Set up EasyLink (HDMI-CEC control)
10
Connect and set up a home network
10
4 Use your home theater 12
Access the home menu 12
Discs
12
Data fi les
13
USB storage devices
14
Audio, video, and picture options
14
Radio
15
MP3 player
16
Netfl ix
16
VUDU
16
Choose sound
17
5 Change settings 18
Language settings 18
Picture and video settings
18
Audio settings
18
Parental control settings
19
Display settings
19
Energy saving settings
19
Speaker settings
19
Restore default settings
19
6 Update software 20
Check software version 20
Update software through USB
20
Update software through the Internet
20
7 Product specifi cations 21
8 Troubleshooting 23
Troubleshooting 23
9 Notice 24
Copyright 24
Compliance
24
Open source software
25
Trademarks
26
10 Index 27
2 EN
1 Important
Read and understand all instructions before you
use your product. If damage is caused by failure to
follow instructions, the warranty does not apply.
Important safety instructions
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifi ers) that produce
heat.
• Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than
the other. A grounding type plug has two
blades and a third grounding prong. The wide
blade or the third prong are provided for
your safety. If the provided plug does not fi t
into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point where
they exit from the apparatus.
• Only use attachments/accessories specifi ed
by the manufacturer.
• Use only with the cart, stand, tripod, bracket
or table specifi ed by the manufacturer or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storm
or when unused for long periods of time.
• Refer all servicing to qualifi ed service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
• Battery usage CAUTION - To prevent battery
leakage which may result in bodily injury,
property damage, or damage to the unit:
• Install all batteries correctly, + and - as
marked on the unit.
• Do not mix batteries ( old a nd new or
carbon and alkaline , etc.).
• Remove batteries when the unit is not
used for a long time.
• The product/remote control may contain a coin/
button type battery, which can be swallowed.
Keep the battery out of reach of children at all
times! If swallowed, the battery can cause serious
injury or death. Severe internal burns can occur
within two hours of ingestion.
• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.
• When you change the batteries, always keep all
new and used batteries out of reach of children.
Ensure that the battery compartment is
completely secure after you replace the battery.
• If the battery compartment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.
• Apparatus shall not be exposed to dripping
or splashing.
• Do not place any sources of danger on the
apparatus (for example. liquid fi lled objects,
lighted candles).
• This apparatus may contain lead and mercury.
Dispose according to local, State or Federal
laws. For disposal or recycling information,
please contact your local authorities. For
additional assistance on recycling options,
please contact www.mygreenelectronics.com
or www.eiae.org or www.recycle.philips.com.
• Use of controls or adjustments or
performance of procedures other than herein
may result in hazardous radiation exposure
or other unsafe operation.
• Disconnect the mains plug to shut off when
fi nd trouble or not in use. The mains plug
shall be readily operable.
3
English
EN
• Do not place this apparatus on the furniture that
is capable of being tilted by a child and an adult
leaning, pulling, standing or climbing on it. A falling
apparatus can cause serious injury or even death.
• This apparatus should not be placed in a
built-in installation such as a bookcase or rack
unless proper ventilation is provided. Make
sure to leave a space of 7.8 inches (20cm) or
more around this apparatus.
Class II equipment symbol
This symbol indicates that the unit has a double
insulation system.
Know these safety symbols
This 'bolt of lightning' indicates uninsulated material
within your unit may cause an electrical shock. For
the safety of everyone in your household, please do
not remove product covering.
The 'exclamation point' calls attention to features for
which you should read the enclosed literature closely
to prevent operating and maintenance problems.
WARNING: To reduce the risk of fi re or electric
shock, this apparatus should not be exposed to
rain or moisture and objects fi lled with liquids, such
as vases, should not be placed on this apparatus.
CAUTION: To prevent electric shock, match wide
blade of plug to wide slot, fully insert.
Care for your product
• Do not insert any objects other than discs
into the disc compartment.
• Do not insert warped or cracked discs into
the disc compartment.
• Remove discs from the disc compartment
if you are not using the product for an
extended period of time.
• Use only microfi ber cloth to clean the product.
Care of the environment
Your product is designed and manufactured with
high quality materials and components, which
can be recycled and reused. Please visit www.
recycle.philips.com for additional information on a
recycling center in your area.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
prevent potentially negative consequences on the
environment and human health.
The batteries supplied do not contain the heavy
metals mercury and cadmium. Nevertheless, in
many areas batteries may not be disposed of with
your household waste. Please ensure you dispose
of batteries according to local regulations.
For perchlorate material, special handling may
apply. Visit www.dtsc.ca.gov/hazardouswaste/
perchlorate.
3D health warning
If you or your family has a history of epilepsy
or photosensitive seizures, consult a medical
professional before exposing yourself to fl ashing
light sources, rapid image sequences or 3D
viewing.
To avoid discomfort such as dizziness, headache or
disorientation, we recommend not watching 3D
for extended periods of time. If you experience
any discomfort, stop watching 3D and do not
immediately engage in any potentially hazardous
activity (for example driving a car) until your
symptoms have disappeared. If symptoms persist,
do not resume watching 3D without consulting a
medical professional fi rst.
Parents should monitor their children during 3D
viewing and ensure they do not experience any
discomfort as mentioned above. Watching 3D is
not recommended for children under six years of
age as their visual system is not fully developed yet.
4 EN
Help and support
Philips provides extensive online support. Visit our
website at www.philips.com/support to:
• download the complete user manual
• print the quick start guide
• watch video tutorials (available only for
selected models)
• fi nd answers to frequently answered
questions (FAQs)
• email us a question
• chat with our support representative.
Follow the instructions on the website to select your
language, and then enter your product model number.
Alternatively, you can contact Philips Consumer
Care in your country. Before you contact Philips,
note down the model number and serial number
of your product. You can fi nd this information on
the back or bottom of your product.
2 Your home theater
Congratulations on your purchase, and welcome
to Philips! To fully benefi t from the support that
Philips offers, register your product at www.philips.
com/welcome.
Main unit
This section includes an overview of the main unit.
a Disc compartment
b Display panel
c ( Open/Close )
Open or close the disc compartment, or
eject the disc.
d ( Play/Pause )
Start, pause or resume play.
e SOURCE
Select an audio or video source for the home
theater.
f ( Standby-On )
Switch the home theater on or to standby.
Connectors
This section includes an overview of the
connectors available on your home theater.
Front connectors
5
English
EN
a ( USB )
Audio, video or picture input from a USB
storage device.
b MUSIC iLINK
Audio input from an MP3 player.
Rear connectors
a AC MAINS
Connect to the power supply.
b SPEAKERS
Connect to the supplied speakers and
subwoofer.
c ANTENNA FM
Fixed FM antenna.
d AUDIO IN - AUX
Connect to an analog audio output on the TV
or an analog device.
e VIDEO OUT
Connect to the composite video input on
the TV.
f HDMI OUT (ARC)
Connect to the HDMI input on the TV.
g LAN
Connect to the LAN input on a broadband
modem or router.
h DIGITAL IN - OPTICAL
Connect to an optical audio output on the
TV or a digital device.
i DIGITAL IN - COAXIAL
Connect to a coaxial audio output on the TV
or a digital device.
Remote control
This section includes an overview of the remote
control.
a ( Standby-On )
• Switch the home theater on or to standby.
• When EasyLink is enabled, press and hold
for at least three seconds to switch all
connected HDMI CEC compliant devices
to standby.
1
2
7
3
4
5
9
11
12
19
17
20
13
6
18
8
10
14
15
16
21
22
6 EN
b ( Home )
Access the home menu.
c Source buttons
• DISC / POP-UP MENU : Switch to disc
source. Access or exit the disc menu
when you play a disc.
• RADIO : Switch to FM radio.
• AUDIO SOURCE : Select an audio input
source.
d BACK
• Return to a previous menu screen.
• In radio mode, press and hold to erase
the current preset radio stations.
e Navigation buttons
• Navigate menus.
• In radio mode, press left or right to start
auto search.
• In radio mode, press up or down to tune
the radio frequency.
f OK
Confi rm an entry or selection.
g / ( Previous/Next )
• Skip to the previous or next track,
chapter or fi le.
• In radio mode, select a preset radio
station.
h ( Stop ) / ( Eject / Open/Close )
• Stop play.
• Press and hold for three seconds to open
or close the disc compartment, or eject
the disc.
i / ( Fast Backward / Fast Forward )
Search backwards or forward. Press
repeatedly to change the search speed.
j +/- ( Volume )
Increase or decrease volume.
k SOUND SETTINGS
Access or exit sound options.
l Alphanumeric buttons
Enter values or letters (using SMS style entry).
m REPEAT
Select or turn off repeat mode.
n Color buttons
• Select tasks or options for Blu-ray discs.
• Netfl ix : Access online videos and TV
episodes from Netfl ix.
• VUDU : Access online videos from VUDU.
o SUBTITLE
Select subtitle language for video.
p AUDIO
Select an audio language or channel.
q ( Mute )
Mute or restore volume.
r ( Pause )
Pause play.
s ( Play )
Start or resume play.
t OPTIONS
• Access more play options while playing a
disc or a USB storage device.
• In radio mode, set a radio station.
u TOP MENU
Access the main menu of a disc.
7
English
EN
3 Connect and set up
This section helps you connect your home theater
to a TV and other devices, and then set it up.
For information about the basic connections of
your home theater and accessories, see the quick
start guide. For a comprehensive interactive guide,
visit www.connectivityguide.philips.com.
Note
• For identifi cation and supply ratings, see the type
plate at the back or bottom of the product.
• Before you make or change any connections,
make sure that all devices are disconnected from
the power outlet.
Connect speakers
The speaker cables are color-coded for easy
connection. To connect a speaker to your home
theater, match the color on the speaker cable to
the color on the connector.
Speaker position plays a critical role in setting up
a surround sound effect. For best effect, position
all the speakers towards the seating position and
place them close to your ear level (seated).
Note
• Surround sound depends on factors such as
room shape and size, type of wall and ceiling,
windows and refl ective surfaces, and speaker
acoustics. Experiment with the speaker positions
to fi nd the optimum setting for you.
Follow these general guidelines for speakers
placement.
1 Seating position:
This is the center of your listening area.
2 FRONT CENTER (front center) speaker:
Place the center speaker directly in front of
the seating position, either above or below
your TV.
3 FRONT LEFT (front left) and FRONT
RIGHT (front right) speakers:
Place the left and right speakers in the front,
and at equal distance from the center speaker.
Make sure that the left, right, and the center
speakers are at equal distance from your
seating position.
4 REAR LEFT (rear left) and REAR RIGHT
(rear right) speakers:
Place the rear surround speakers to the left
and right side of your seating position, either
in line with it or slightly behind it.
5 SUBWOOFER (subwoofer):
Place the subwoofer at least one meter
to the left or right of the TV. Leave about
10-centimeter clearance from the wall.
Connect to TV
Connect your home theater to a TV to watch
videos. You can listen to the TV audio through your
home theater speakers.
Use the best quality connection available on your
home theater and TV.
Option 1: Connect to TV through HDMI
(ARC)
Best quality video
Your home theater supports HDMI version 1.4 -
Audio Return Channel (ARC). If your TV is HDMI
ARC compliant, you can hear the TV audio through
your home theater by using a single HDMI cable.
8 EN
1 Using a High Speed HDMI cable, connect the
HDMI OUT (ARC) connector on your home
theater to the HDMI ARC connector on the TV.
• The HDMI ARC connector on the TV
might be labeled differently. For details,
see the TV user manual.
2 On your TV, turn on HDMI-CEC operations.
For details, see the TV user manual.
• If you cannot hear the TV audio through
your home theater, set up the audio
manually (see 'Set up the audio' on page 10 ) .
Option 2: Connect to TV through
standard HDMI
Best quality video
If your TV is not HDMI ARC compliant, connect
your home theater to the TV through a standard
HDMI connection.
1 Using a High Speed HDMI cable, connect the
HDMI OUT (ARC) connector on your home
theater to the HDMI connector on the TV.
2 Connect an audio cable to hear the TV audio
through your home theater (see 'Connect
audio from TV and other devices' on page 9 ) .
3 On your TV, turn on HDMI-CEC operations.
For details, see the TV user manual.
• If you cannot hear the TV audio through
your home theater, set up the audio
manually (see 'Set up the audio' on page 10 ) .
Note
• If your TV has a DVI connector, you can use an
HDMI/DVI adapter to connect to TV. However,
some of the features may not be available.
TV
Option 3: Connect to the TV through
composite video
Basic quality video
If your TV does not have HDMI connectors, use
a composite video connection. A composite
connection does not support high-defi nition video.
1 Using a composite video cable, connect the
VIDEO connector on your home theater to
the VIDEO IN connector on the TV.
• The composite video connector might
be labeled AV IN , COMPOSITE , or
BASEBAND .
2 Connect an audio cable to hear the TV audio
through your home theater (see 'Connect
audio from TV and other devices' on page 9 ) .
3 When you watch TV programs, press
SOURCE on your home theater repeatedly
to select the correct audio input.
4 When you watch videos, switch your TV to
the correct video input. For details, see the
TV user manual.
TV
TV
9
English
EN
Connect audio from TV and
other devices
Play audio from TV or other devices through your
home theater speakers.
Use the best quality connection available on your
TV, home theater, and other devices.
Note
• When your home theater and TV are connected
through HDMI ARC, an audio connection is not
required (see 'Option 1: Connect to TV through
HDMI (ARC)' on page 7 ) .
Option 1: Connect audio through a digital
optical cable
Best quality audio
1 Using an optical cable, connect the OPTICAL
connector on your home theater to the
OPTICAL OUT connector on the TV or
other device.
• The digital optical connector might be
labeled SPDIF or SPDIF OUT .
Option 2: Connect audio through a digital
coaxial cable
Good quality audio
1 Using a coaxial cable, connect the COAXIAL
connector on your home theater to the
COAXIAL/DIGITAL OUT connector on the
TV or other device.
• The digital coaxial connector might be
labeled DIGITAL AUDIO OUT .
TV
Option 3: Connect audio through analog
audio cables
Basic quality audio
1 Using an analog cable, connect the AUX
connectors on your home theater to the
AUDIO OUT connectors on the TV or other
device.
Set up speakers
Set up the speakers manually to experience
customized surround sound.
Before you start
Make the necessary connections described in the
quick start guide, and then switch the TV to the
correct source for your home theater.
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Audio] > [Speaker Setup] .
4 Enter the distance for each speaker, and
then listen to the test tones and change
the volume. Experiment with the speaker
positions to fi nd the ideal setting.
VCR
10 EN
Set up EasyLink (HDMI-CEC
control)
This home theater supports Philips EasyLink,
which uses the HDMI-CEC (Consumer Electronics
Control) protocol. EasyLink-compliant devices that
are connected through HDMI can be controlled
by a single remote control.
Note
• Depending on the manufacturer, HDMI-CEC is
known by many names. For information on your
device, see the user manual of the device.
• Philips does not guarantee 100% interoperability
with all HDMI-CEC devices.
Before you start
• Connect your home theater to the HDMI-CEC
compliant device through HDMI connection.
• Make the necessary connections described in
the quick start guide, and then switch the TV
to the correct source for your home theater.
Enable EasyLink
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [EasyLink] > [EasyLink] > [On] .
4 On your TV and other connected devices,
turn on HDMI-CEC control. For details, see
the user manual of the TV or other devices.
• On your TV, set the audio output to
'Amplifi er' (instead of TV speakers). For
details, see the TV user manual.
EasyLink controls
With EasyLink, you can control your home theater,
TV, and other connected HDMI-CEC compliant
devices with a single remote control.
• [One Touch Play] (One-touch play): When a
video disc is in the disc compartment, press
( Play ) to wake up the TV from standby, and
then play a disc.
• [One Touch Standby] (One-touch standby):
If one-touch standby is enabled, your home
theater can switch to standby with the remote
control of the TV or other HDMI-CEC devices.
• [System Audio Control] (System audio
control): If system audio control is enabled,
the audio of the connected device is output
through your home theater speakers
automatically when you play the device.
• [Audio Input Mapping] (Audio input
mapping): If system audio control does not
work, map the connected device to the
correct audio input connector on your home
theater (see 'Set up the audio' on page 10 ) .
Note
• To change the EasyLink control settings, press
( Home ), select [Setup] > [EasyLink] .
Set up the audio
If you cannot hear the audio output of a
connected device through your home theater
speakers, check that you have enabled Easylink on
all the devices (see 'Enable EasyLink' on page 10 ) .
Then, set up the EasyLink audio control.
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [EasyLink] > [System Audio Control]
> [On] .
• To play the audio from the TV speakers,
select [Off] , and skip the following steps.
4 Select [EasyLink] > [Audio Input Mapping] .
5 Follow the onscreen instructions to map the
connected device to the audio inputs on your
home theater.
• If you connect your home theater to the
TV through an HDMI ARC connection,
make sure that the TV audio is mapped
to the ARC input on your home theater.
Connect and set up a home
network
Connect your home theater to a home network
with internet access and enjoy:
• Netfl ix online videos
• VUDU online videos
• BD-Live applications
• Software update
11
English
EN
Caution
• Familiarize yourself with the network router
and networking principles. If necessary, read
documentation that accompanies the network
components. Philips is not responsible for lost,
damaged, or corrupt data.
Before you start
• For Netfl ix, VUDU and software update, make
sure that the network router has access to the
Internet with high-speed connection, and is not
restricted by fi rewalls or other security systems.
• Make the necessary connections described in
the quick start guide, and then switch the TV
to the correct source for your home theater.
Set up the wired network
What you need
• A network cable (RJ45 straight cable).
• A network router (with DHCP enabled).
1 Using a network cable, connect the LAN
connector on your home theater to the
network router.
2 Press ( Home ).
3 Select [Setup] , and then press OK .
4 Select [Network] > [Network Installation]
> [Wired (Ethernet)] .
5 Follow the onscreen instructions to complete
the setup.
• If connection fails, select [Retry] , and
then press OK .
6 Select [Finish] , and then press OK to exit.
• To view the network settings, select [Setup]
> [Network] > [View Network Settings] .
LAN
www
Set up the wireless network
Your home theater has built-in Wi-Fi for easy
access to the wireless network.
What you need
• A network router (with DHCP enabled). For
best wireless performance, coverage, and
compatibility, use 802.11n router.
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Network] > [Network Installation]
> [Wireless (Wi-Fi)] , and then press OK .
4 Follow the onscreen instructions to select
and set up the wireless network.
• If connection fails, select [Retry] , and
then press OK .
5 Select [Finish] , and then press OK to exit.
• To view the network settings, select
[Setup] > [Network] > [View Wireless
Settings] .
www
12 EN
4 Use your home
theater
This section helps you use the home theater to
play media from a wide range of sources.
Before you start
• Make the necessary connections described in
the Quick start guide and the user manual.
• Switch the TV to the correct source for the
home theater.
Access the home menu
The home menu provides easy access to
connected devices, setup and other useful features
in your home theater.
1 Press ( Home ).
» The home menu is displayed.
2 Press the Navigation buttons and OK to
select the following:
• [play Disc] : Start disc play.
• [browse USB] : Access the USB content
browser
• [Netfl ix] : Access online videos and TV
episodes from Netfl ix.
• [VUDU] : Access online videos from VUDU.
• [Setup] : Access menus to change video,
audio and other settings.
3 Press ( Home ) to exit.
Discs
Your home theater can play DVDs, VCDs, CDs, and
Blu-ray discs. It can also play discs that you’ve made
at home, such as CD-R discs of photos and music.
1 Insert a disc into the home theater.
2 If the disc does not play automatically, press DISC
or select [play Disc] from the home menu.
3 Use the remote control to control play (see
'Remote control' on page 5 ) .
Note
• To avoid fl ickering, change the brightness of the
display .
Play buttons
Button Action
Navigation
buttons
Navigate menus.
OK Confi rm an entry or selection.
( Play )
Start or resume play.
Pause play.
Stop play.
/
Skip to the previous or next track,
chapter or fi le.
/
Fast backward or fast forward. Press
repeatedly to change the search
speed.
AUDIO Select an audio language or channel.
SUBTITLE Select subtitle language for video.
DISC /
POP-UP
MENU
Access or exit the disc menu.
OPTIONS
Access the advanced options when
you play your audio, video, or media
fi les (see 'Audio, video, and picture
options' on page 14 ) .
REPEAT Select or turn off repeat mode.
Synchronize picture and sound
If the audio and video are not synchronized, delay
the audio to match the video.
1 Press SOUND SETTINGS .
2 Select AUD SYNC , and then press OK .
3 Press the Navigation buttons (up/down) to
synchronize the audio with the video.
4 Press OK to confi rm.
Play Blu-ray 3D disc
Your home theater can play Blu-ray 3D video.
Read the 3D health warning before playing a 3D
disc.
What you need
• A 3D TV.
• A pair of 3D glasses that are compatible with
your 3D TV.
• A 3D Blu-ray video
• A high speed HDMI cable (preferably version
1.4)
13
English
EN
1 Using the high speed HDMI cable, connect
your home theater to a 3D compatible TV.
2 Make sure that the 3D video setting is
enabled. Press
( Home ), select [Setup] >
[Video] > [Watch 3D video] > [Auto] .
• To play 3D discs in 2D mode, select [Off] .
3 Play a Blu-ray 3D disc and put on the 3D glasses.
• During video search and in certain play
modes, the video is displayed in 2D. The
video display returns to 3D when you
resume play.
Bonus View on Blu-ray
On Blu-ray discs that support the Bonus View,
enjoy extra content such as commentaries in a
small screen window. Bonus View is also known as
picture-in-picture.
1 Enable Bonus View in the Blu-ray disc menu.
2 While you play the movie, press OPTIONS .
» The options menu is displayed.
3 Select [PIP Selection] > [PIP] .
• Depending on the video, PIP menu [1] or
[2] is displayed.
• To disable Bonus View, select [Off] .
4 Select [2nd Audio Language] or [2nd Subtitle
Language] .
5 Select the language, and then press OK .
BD-Live on Blu-ray
Access additional features on the Blu-ray discs with
BD-Live content, such as internet chats with the
director, the latest movie trailers, games, wallpaper,
and ringtones.
BD-Live services and content vary from disc to disc.
What you need
• Blu-ray disc with BD-Live content
• a USB storage device, with at least 1 GB of
memory
1 Connect your home theater to a home
network with Internet access (see 'Connect
and set up a home network' on page 10 ) .
2 Connect a USB storage device to your home
theater.
3 Press ( Home ) and select [Setup] .
4 Select [Advanced] > [BD-Live Security] >
[Off] to enable BD-Live.
• To disable BD-Live, select [On] .
5 Select the BD-Live icon in the disc menu, and
then press OK .
» BD-Live starts to load. The loading time
depends on the disc and your internet
connection.
6 Press the Navigation buttons to navigate BD-
Live, and then press OK to select an option.
Note
• To clear the memory on the storage device,
press ( Home ), select [Setup] > [Advanced]
> [Clear memory] .
Data fi les
Your home theater can play pictures, audio and
video fi les contained in a disc or a USB storage
device. Before you play a fi le, check that the fi le
format is supported by your home theater (see
'File formats' on page 21 ) .
1 Play the fi les from a disc or USB storage device.
2 To stop play, press .
• To resume the video from where you
stopped, press
( Play ).
• To play the video from the start, press OK .
Note
• To play DivX DRM protected fi les, connect your
home theater to a TV through an HDMI cable.
Subtitles
If your video has subtitles in multiple languages,
select a subtitle language.
Note
• Make sure that the subtitle fi le has the exact
same name as the video fi le. For example, if the
video fi le is named 'movie.avi', name the subtitle
fi le as 'movie.srt' or 'movie.sub'.
• Your home theater supports the following fi le
formats: .srt, .sub, .txt, .ssa, .ass, smi, and .sami. If
the subtitles do not appear correctly, change the
character set.
14 EN
1 While playing video, press SUBTITLE to
select a language.
2 For DivX videos, if the subtitles do not
appear correctly, continue the following steps
to change the character set.
3 Press OPTIONS .
» The options menu is displayed.
4 Select [Character Set] , and then select a
character set that supports the subtitle.
Europe, India, and Russia
Character
Set
Language
[Standard] English, Albanian, Danish, Dutch,
Finnish, French, Gaelic, German,
Italian, Kurdish (Latin), Norwegian,
Portuguese, Spanish, Swedish and
Turkish
[Central
Europe]
Albanian, Croat, Czech, Dutch,
English, German, Hungarian, Irish,
Polish, Romanian, Slovak, Slovene
and Sorbian
[Cyrillic] Bulgarian, Belorussian, English,
Macedonian, Moldavian, Russian,
Serbian and Ukrainian
[Greek] Greek
VOD code for DivX
Before you purchase DivX videos and play them
on your home theater, register the home theater
on www.divx.com using the DivX VOD code.
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Advanced] > [DivX® VOD Code] .
» The DivX VOD registration code for
your home theater is displayed.
USB storage devices
Enjoy pictures, audio, and video stored on a USB
storage device such as an MP4 player or digital camera.
What you need
• A USB storage device that is formatted for
FAT or NTFS fi le systems, and complies with
the Mass Storage Class.
• A media fi le in one of the supported fi le
formats (see 'File formats' on page 21 ) .
Note
• If you use a USB extension cable, USB HUB, or
USB multi-reader, the USB storage device may
not be recognized.
1 Connect a USB storage device to the
( USB ) connector on your home theater.
2 Press ( Home ).
3 Select [browse USB] , and then press OK .
» A content browser is displayed.
4 Select a fi le, and then press OK .
5 Press the play buttons to control play (see
'Play buttons' on page 12 ) .
Audio, video, and picture options
Use advanced features when you play pictures, audio
and video fi les from a disc or a USB storage device.
Audio options
While playing audio, repeat an audio track, a disc,
or a folder.
1 Press OPTIONS repeatedly to cycle through
the following functions:
• RPT TRACK / RPT FILE : Repeat the
current track or fi le.
• RPT DISC / RPT FOLDER : Repeat all
the tracks on the disc or the folder.
• RPT RANDOM : Play audio tracks in
random order.
• RPT OFF : Turn off the repeat mode.
Video options
While watching video, select options such as
subtitles, audio language, time search, and picture
settings. Depending on the video source, some
options are not available.
1 Press OPTIONS .
» The video options menu is displayed.
2 Press the Navigation buttons and OK to
select and change:
• [Audio Language] : Select audio language
for video.
• [Subtitle Language] : Select subtitle
language for video.
15
English
EN
• [Subtitle Shift] : Change the subtitle
position on the screen.
• [Info] : Display information about what is
playing.
• [Character Set] : Select a character set
that supports the DivX subtitle.
• [Time Search] : Skip to a specifi c part of the
video by entering the time of the scene.
• [2nd Audio Language] : Select the second
audio language for Blu-ray video.
• [2nd Subtitle Language] : Select the second
subtitle language for Blu-ray video.
• [Titles] : Select a specifi c title.
• [Chapters] : Select a specifi c chapter.
• [Angle List] : Select a different camera angle.
• [Menus] : Display the disc menu.
• [PIP Selection] : Display Picture-in-Picture
window when playing a Blu-ray disc that
supports the Bonus View.
• [Zoom] : Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Repeat] : Repeat a chapter or title.
• [Repeat A-B] : Mark two points within a
chapter or track to repeat play, or turn
off the repeat mode.
• [Picture Settings] : Select a predefi ned
color setting.
Picture options
While viewing a picture, zoom into the picture,
rotate it, add animation to a slideshow, and change
the picture settings.
1 Press OPTIONS .
» The picture options menu appears.
2 Press the Navigation buttons and OK to
select and change the following settings:
• [Rotate +90] : Rotate the picture 90
degree clockwise.
• [Rotate -90] : Rotate the picture 90
degree counter-clockwise.
• [Zoom] : Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Info] : Display picture information.
• [Duration per slide] : Select the display
speed for each picture in a slide show.
• [Slide Animation] : Select animation for
the slide show.
• [Picture Settings] : Select a predefi ned
color setting.
• [Repeat] : Repeat a selected folder.
Musical slideshow
If the picture and audio fi les are from the same
disc or USB storage device, you can create a
musical slideshow.
1 Select an audio track, and then press OK .
2 Press BACK , and go to the picture folder.
3 Select a picture, and then press ( Play ) to
start the slideshow.
4 Press to stop slideshow.
5 Press again to stop music.
Note
• Make sure that the picture and audio formats
are supported by your home theater (see 'File
formats' on page 21 ) .
Radio
Listen to FM radio on your home theater, and
store up to 40 radio stations.
Note
• AM and digital radio are not supported.
• If no stereo signal is detected, or if fewer than
fi ve stations are found, you are prompted to
install the radio stations again.
1 Extend the FM antenna at the back of your
home theater and place it away from the TV
or other sources of radiation.
2 Press RADIO .
» If you have already installed the radio
stations, the last channel that you listened
to is played.
» If you have not installed any radio
stations, the message AUTO
INSTALL...PRESS PLAY appears on
the display panel. press
( Play ).
3 Use the remote control to listen or to
change radio stations.
16 EN
Button Action
/
or
Alphanumeric
buttons
Select a preset radio station.
Navigation
buttons
Left/Right: Search for a radio
station.
Up/Down: Fine tune a radio
frequency.
Press to stop the installation of
radio stations.
BACK
Press and hold to erase the
preset radio station.
OPTIONS Manual:
1) Press
OPTIONS . 2)
Press
/ to select your
preset. 3) Press
OPTIONS
again to store the radio station.
Automatic: Press and hold for
three seconds to reinstall the
radio stations.
MP3 player
Connect a MP3 player to play audio fi les.
What you need
• An MP3 player.
• A 3.5mm stereo audio cable.
1 Using the 3.5mm stereo audio cable, connect
the MP3 player to the MUSIC iLINK
connector on your home theater.
2 Press AUDIO SOURCE repeatedly until
MUSIC I-LINK appears on the display panel.
3 Press the buttons on the MP3 player to select
and play audio fi les.
Netfl ix
Use Netfl ix to stream movies and TV episodes
through your home theater. You can also rent
videos from online stores.
For more information on Netfl ix services, visit
www.netfl ix.com.
1 Connect your home theater to a home network
with high-speed Internet access (see 'Connect
and set up a home network' on page 10 ) .
2 Press ( Home ).
3 Select [Netfl ix] , and then press OK .
» The Netfl ix home page is displayed.
4 Use the remote control to navigate and start
a video play.
» If you have not activated your home
theater to play videos from Netfl ix, an
activation code is displayed.
» If you have activated your home
theater, skip step 5.
5 On your computer, visit www.netfl ix.com/
activate to activate your home theater with
the activation code.
• You need to sign in as Netfl ix member..
6 To exit Netfl ix, press ( Home ).
Note
• To deactivate Netfl ix from your home
theater, press , and then select [Setup] > >
[Deactivation] > [Netfl ix] .
• When you contact Netfl ix customer service,
you may ask to provide the ESN (electronic
serial number) of your home theater. To display
the ESN, press , and then select [Setup] >
[Advanced] > [Netfl ix ESN] .
VUDU
Use VUDU to stream movies through your home
theater. VUDU provides on-demand videos and
rich internet applications.
For more information on VUDU services, visit
www.vudu.com.
1 Connect your home theater to a home
network with high-speed Internet access (see
'Connect and set up a home network' on
page 10 ) .
2 Press ( Home ).
3 Select [VUDU] , and then press OK .
» The VUDU home page is displayed.
4 If you have activated your home theater, skip
steps 5 and 6.
5 Select 'Free HD' to acquire an activation code.
6 On your computer, when you receive the
VUDU confi rmation email in your inbox, click
the activation link provided and follow the
prompts through the activation process.
17
English
EN
7 Use the remote control to navigate and start
a video play.
8 To exit VUDU, press ( Home ).
Note
•
To deactivate VUDU from your home theater,
press
, and then select [Setup] > [Advanced]
> [Deactivation] > [VUDU] .
Choose sound
This section helps you choose the ideal sound for
your video or music.
1 Press SOUND SETTINGS .
2 Press the Navigation buttons (left/ right) to
access the sound options on the display.
Sound settings Description
SOUND Select a sound mode.
SURROUND Select surround sound or stereo
sound.
TREBLE Change the high frequency output.
MID Change the middle frequency
output.
BASS Change the low frequency output.
AUD SYNC Delay the audio to match the video.
3 Select an option, and then press OK .
4 Press BACK to exit.
If you do not press a button within a minute,
the menu exits automatically.
Sound mode
Select predefi ned sound modes to suit your video
or music.
1 Press SOUND SETTINGS .
2 Select SOUND , and then press OK .
3 Press the Navigation buttons (up/down) to
select a setting on the display:
• MOVIE : Enjoy a cinematic audio
experience, specially enhanced for movies.
• MUSIC : Recreate the original recording
environment of your music, in the studio
or at a concert.
• ORIGINAL : Experience the original
sound of your movies and music, without
added sound effects.
• NEWS : Hear every word with optimized
speech and clear vocals.
• GAMING : Enjoy thrilling arcade sounds,
ideal for action-packed video games or
loud parties.
4 Press OK to confi rm.
Surround sound mode
Experience an immersive audio experience with
surround sound modes.
1 Press SOUND SETTINGS .
2 Select SURROUND , and then press OK .
3 Press the Navigation buttons (up/down) to
select a setting from your display:
• AUTO : Surround sound based on the
audio stream.
• MULTI-CH : Immersive multi-channel
sound for an enhanced movie experience.
• STEREO : Two-channel stereo sound. Ideal
for listening to music.
4 Press OK to confi rm.
Equalizer
Change the high frequency (treble), mid frequency
(mid), and low frequency (bass) settings of the
home theater.
1 Press SOUND SETTINGS .
2 Select TREBLE , MID or BASS , and then press
OK .
3 Press the Navigation buttons (up/down) to
change the frequency.
4 Press OK to confi rm.
18 EN
5 Change settings
The home theater settings are already confi gured
for optimal performance. Unless you have a reason
to change a setting, we recommend that you keep
the default setting.
Note
• You cannot change a setting that is grayed out.
• To return to the previous menu, press
BACK . To exit the menu, press
( Home ).
Language settings
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Preference] , and then press OK .
4 Press the Navigation buttons and OK to
select and change:
• [Menu language] : Select a display
language for menu.
• [Audio] : Select an audio language for discs.
• [Subtitle] : Select a subtitle language for discs.
• [Disc Menu] : Select a menu language for
discs.
Note
• If your preferred disc language is not available,
select [Others] from the list, and enter the
4-digit language code found at the end of this
user manual .
• If you select a language that is not available on a
disc, the home theater uses the default language
of the disc.
Picture and video settings
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Video] , and then press OK .
4 Press the Navigation buttons and OK to
select and change:
• [TV Display] : Select a picture format to
fi t the TV screen.
• [HDMI Video] : Select the resolution of
video signal that is output from HDMI OUT
(ARC) on your home theater. To enjoy the
selected resolution, make sure that your TV
supports the selected resolution.
• [HDMI Deep Color] : Recreate the natural
world on your TV screen by displaying
vivid images using billion colors. Your home
theater must be connected to a Deep
Color enabled TV through an HDMI cable.
• [Picture Settings] : Select pre defi ned
color settings for the video display.
• [Watch 3D video] : Set HDMI video to
support 3D or 2D video.
Note
• If you change a setting, make sure that the TV
supports the new setting.
Audio settings
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Audio] , and then press OK .
4 Press the Navigation buttons and OK to
select and change:
• [Night Mode] : For quiet listening,
decrease the volume of loud sounds on
your home theater. Night mode is only
available for Dolby-encoded DVD and
Blu-ray discs.
• [HDMI Audio] : Set the HDMI audio
output from your TV, or disable HDMI
audio output from the TV.
• [Default sound settings] : Restore the
equalizer settings of all the sound modes
to the default values.
19
English
EN
Parental control settings
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Preference] , and then press OK .
4 Press the Navigation buttons and OK to
select and change:
• [Change Password] : Set or change your
password for parental control access.
If you do not have a password or have
forgotten your password, enter 0000 .
• [Parental Control] : Restrict access to
discs that are recorded with age ratings.
To play all discs, irrespective of the ratings,
select 8 or [Off] .
Display settings
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Preference] , and then press OK .
4 Press the Navigation buttons and OK to
select and change:
• [Auto Subtitle Shift] : Enable or disable
automatic repositioning of subtitles on
TVs that support this feature.
• [Display Panel] : Set the brightness of the
home theater front panel display.
• [VCD PBC] : Enable or disable the content
menu navigation of VCD and SVCD discs
with Play Back Control feature.
Energy saving settings
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Preference] , and then press OK .
4 Press the Navigation buttons and OK to
select and change:
• [Screen Saver] : Switch the home theater
to screen saver mode after 10 minutes
of inactivity.
• [Auto Standby] : Switch the home theater
to standby after 30 minutes of inactivity.
This timer works only when a disc or
USB play is paused or stopped.
• [Sleep Timer] : Set the duration of the sleep
timer so that the home theater is switched
to standby after the specifi ed period.
Speaker settings
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Advanced] , and then press OK .
4 Press the Navigation buttons and OK to
select and change:
• [Enhanced Audio] : Select [On] to enable
audio post processing at the speaker and
enable karaoke settings (if your product
supports Karaoke). To play the original
audio of the disc, select [Off] .
Tip
• Enable audio post processing before you select a
predefi ned sound mode (see 'Sound mode' on page 17 ) .
Restore default settings
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Advanced] > [Restore default
settings] , and then press OK .
4 Select [OK] , and then press OK to confi rm.
» Your home theater is reset to its default
settings except for some settings such
as parental control and DivX VOD
registration code.
20 EN
6 Update software
Philips continually tries to improve its products.
To get the best features and support, update your
home theater with the latest software.
Compare the version of your current software with
the latest version on www.philips.com/support. If
the current version is lower than the latest version
available on the Philips support website, upgrade
your home theater with the latest software.
Caution
• Do not install a lower version of software than
the current version installed on your product.
Philips is not liable for problems caused due to
software downgrade.
Check software version
Check the version of the current software installed
on your home theater.
1 Press ( Home ).
2 Select [Setup] , and then press OK .
3 Select [Advanced] > [Version Info.] , and then
press OK .
» The software version is displayed.
Update software through USB
What you need
• A USB fl ash drive that is FAT or NTFS-
formatted, with at least 75MB of memory. Do
not use a USB hard drive.
• A computer with Internet access.
• An archive utility that supports the ZIP fi le format.
Step 1: Download the latest software
1 Connect a USB fl ash drive to your computer.
2 In your web browser, go to www.philips.com/
support.
3 At the Philips Support website, fi nd your
product and locate the Software and drivers .
» The software update is available as a zip fi le.
4 Save the zip fi le in the root directory of your
USB fl ash drive.
5 Use the archive utility to extract the software
update fi le in the root directory.
» The fi les are extracted under the UPG_
ALL folder of your USB fl ash drive.
6 Disconnect the USB fl ash drive from your
computer.
Step 2: Update the software
Caution
• Do not switch off the home theater or remove
the USB fl ash drive during the update.
1 Connect the USB fl ash drive containing the
downloaded fi le to your home theater.
• Make sure that the disc compartment is
closed and no disc inside.
2 Press ( Home ).
3 Select [Setup] , and then press OK .
4 Select [Advanced] > [Software Update] > [USB] .
5 Follow the onscreen instructions to confi rm
the update.
» Once complete, the home theater
automatically switches off and restarts. If
it does not, disconnect the power cord
for a few seconds and then reconnect it.
Update software through the
Internet
1 Connect your home theater to a home network
with a high-speed Internet access (see 'Connect
and set up a home network' on page 10 ) .
2 Press ( Home ).
3 Select [Setup] , and then press OK .
4 Select [Advanced] > [Software Update] >
[Network] .
» If an upgrade media is detected, you are
prompted to start or cancel the update.
5 Follow the onscreen instructions to confi rm
the update.
» Once complete, the home theater
automatically switches off and restarts. If
it does not, disconnect the power cord
for a few seconds and then reconnect it.
21
English
EN
7 Product
specifications
Note
• Specifi cations and design are subject to change
without notice.
Region codes
The type plate on the back or bottom of the
home theater shows which regions it supports.
Media formats
• AVCHD, BD, BD-R/ BD-RE, BD-Video, DVD-
Video, DVD+R/+RW, DVD-R/-RW, DVD+R/-R
DL, CD-R/CD-RW, Audio CD, Video CD/SVCD,
Picture fi les, MP3 media, WMA media, DivX
Plus HD media, USB storage device
File formats
• Audio: .aac, .mka, .mp3, .wma, .wav
• Video: .avi, .divx, .mp4, .mkv, .asf, .mpg, .mpeg
• Picture: .jpg, .jpeg, .gif, .png
Audio formats
Your home theater supports the following audio
fi les.
Extension Container Audio
codec
Bit rate
.mp3 MP3 MP3 32 kbps ~
320 kbps
.wma ASF WMA 64 kbps ~
160 kbps
.aac AAC AAC, HE-
AAC
192 kbps
Country
DVD
USA, Canada
1
.wav WAV PCM 1.4 Mbps
.m4a MKV AAC 192 kbps
.mka MKA PCM 27.648 Mbps
.mka MKA Dolby
Digital
640 kbps
.mka MKA DTS core 1.54 Mbps
.mka MKA MPEG 912 kbps
.mka MKA MP3 32 kbps ~
320 kbps
.mka MKA WMA 64 kbps ~
160 kbps
.mka MKA AAC,
HE-
AAC
192 kbps
Video formats
If you have a high defi nition TV, your home theater
allows you to play your video fi les with:
• Resolution: 1920 x 1080 pixels at
• Frame rate: 6 ~ 30 frames per second.
.avi fi les in AVI container
Audio codec Video codec Bit rate
PCM, Dolby
Digital, DTS
core, MP3,
WMA
DivX 3.11,
DivX 4.x,
DivX 5.x,
DivX 6.x
10 Mbps max
MPEG 1, MPEG
2
20 Mbps
(peak 40
Mbps)
MPEG 4 ASP 10 Mbps max
H.264/AVC
[email protected]/4.0;
[email protected]/3.1/3.0
20 Mbps
(peak 40
Mbps)
.divx fi les in AVI container
Audio
codec
Video codec Bit rate
PCM,
Dolby
Digital,
MP3,
WMA
DivX 3.11,
DivX 4.x, DivX 5.x,
DivX 6.x
10 Mbps max
MPEG 1, MPEG 2 20 Mbps
(peak 40
Mbps)
MPEG 4 ASP 10 Mbps max
22 EN
.mp4 or .m4v fi les in MP4 container
Audio codec Video codec Bit rate
Dolby Digital,
MPEG, MP3,
AAC, HE-AAC
MPEG 1,
MPEG 2
20 Mbps
(peak 40
Mbps)
MPEG 4 ASP 10 Mbps max
H.264/AVC
[email protected]/4.0;
[email protected]/3.1/3.0
20 Mbps
(peak 40
Mbps)
.mkv fi les in MKV container
Audio codec Video codec Bit rate
PCM, Dolby Digital,
DTS core, MPEG,
MP3, WMA, AAC,
HE-AAC
MPEG 1,
MPEG 2
20 Mbps
(peak 40
Mbps)
MPEG 4 ASP 10 Mbps
max
H.264/AVC
[email protected]/4.0;
[email protected]/3.1/3.0
20 Mbps
(peak 40
Mbps)
Amplifi er
• Total output power: 300W RMS (30% THD)
• FTC: 60W RMS (1% THD)
• Frequency response: 20 Hz-20 kHz / ±3 dB
• Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)
• Input sensitivity:
• AUX: 2 V
• Music iLink: 1 V
Video
• Signal system: PAL / NTSC
• HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p24
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
• Sampling frequency:
• MP3: 32 kHz, 44.1 kHz, 48 kHz
• WMA: 44.1 kHz, 48 kHz
• Constant bit rate:
• MP3: 32 kbps - 320 kbps
• WMA: 48 kbps - 192 kbps
Radio
• Tuning range: FM 87.5-108 MHz (100 kHz)
• Signal-to-noise ratio: FM 50 dB
• Frequency response: FM 200 Hz-12.5 kHz /
±6 dB
USB
• Compatibility: Hi-Speed USB (2.0)
• Class support: USB Mass Storage Class (MSC)
• File system: FAT16, FAT32, NTFS
• Maximum memory support: < 160 GB
Main unit
• Power supply: 120V~; 60Hz
• Power consumption: 60 W
• Standby power consumption: ≤ 0.9 W
• Dimensions (WxHxD): 360 x 58 x 325 mm
• Weight: 2.4 kg
Subwoofer
• Output power: 50 W RMS (30% THD)
• Impedance: 4 ohm
• Speaker drivers: 133 mm (5.25") woofer
• Dimensions (WxHxD): 160 x 265 x 265 mm
• Weight: 2.50 kg
Speakers
• Output power: 50 W RMS (30% THD)
• Speaker impedance: 4 ohm
• Speaker drivers: 1 x 70 mm (2.75") woofer
• Dimensions (WxHxD): 84.5 x 89 x 89 mm
• Weight: 0.25-0.29 kg/each
Remote control batteries
• 2 x AAA-R03-1.5 V
Laser
• Laser Type (Diode): InGaN/AIGaN (BD),
AIGaInP (DVD/CD)
• Wave length: 405 +7 nm/-7 nm (BD), 655
+10 nm/-10 nm (DVD), 790 +10 nm/-20 nm
(CD)
• Output power (Max. ratings): 20 mW (BD), 6
mW (DVD), 7 mW (CD)
23
English
EN
8 Troubleshooting
Troubleshooting
Warning
• Risk of electric shock. Never remove the casing
of the product.
To keep the warranty valid, never try to repair the
product yourself.
If you have problems using this product, check the
following points before you request service. If you
still have a problem, visit www.philips.com/support.
Main unit
The buttons on the home theater do not work.
• Disconnect the home theater from the
power supply for a few minutes, then
reconnect.
No picture.
• Make sure that the TV is switched to the
correct source for the home theater.
No picture on a TV connected through HDMI.
• Make sure that you use a High Speed HDMI
cable to connect the home theater and TV.
Some Standard HDMI cables do not display
properly for some images, 3D video, or Deep
Color.
• Make sure that the HDMI cable is not faulty. If
it is faulty, replace it with a new cable.
• Press ( Home ) and then 731 on the
remote control to restore the default picture
resolution.
• Change the HDMI video setting, or wait for
10 seconds for auto recovery (see 'Picture
and video settings' on page 18 ) .
Disc does not play high-defi nition video.
• Make sure that the disc contains high-
defi nition video.
• Make sure that the TV supports high-
defi nition video.
• Use an HDMI cable to connect to the TV.
Sound
No sound from home theater speakers.
• Connect the audio cable from your home
theater to your TV or other devices. You do
not need a separate audio connection when
the home theater and TV are connected
through an HDMI ARC connection.
• Set up the audio for the connected device
(see 'Set up the audio' on page 10 ) .
• Reset your home theater to its factory settings
(see 'Restore default settings' on page 19 ) ,
then switch it off and switch on again.
• On your home theater, press SOURCE
repeatedly to select the correct audio input.
Distorted sound or echo.
• If you play audio from the TV through the
home theater, make sure that the TV is muted.
Audio and video are not synchronized.
• 1) Press SOUND SETTINGS . 2) Press
the Navigation buttons (left/right) to select
AUD SYNC , and then press OK . 3) Press
the Navigation buttons (up/down) to
synchronize the audio with the video.
Play
Cannot play a disc.
• Clean the disc.
• Make sure that the home theater supports the
type of disc (see 'Media formats' on page 21 ) .
• Make sure that the home theater supports
the region code of the disc .
• If the disc is a DVD±RW or DVD±R disc,
make sure that it is fi nalized.
Cannot play a DivX fi le.
• Make sure that the DivX fi le is encoded
according to the 'Home Theater Profi le' with
the DivX encoder.
• Make sure that the DivX fi le is complete.
DivX subtitles do not display correctly.
• Make sure that the subtitle fi le name is the
same as the movie fi le name (see 'Subtitles'
on page 13 ) .
• Select the correct character set: 1) Press
OPTIONS . 2) Select [Character Set] . 3) Select
the supported character set. 4) Press OK .
Cannot read the contents of a USB storage device.
• Make sure that the format of the USB storage
device is compatible with the home theater.
• Make sure that the fi le system on the USB
storage device is supported by the home
theater.
24 EN
'No entry' or 'x' sign appears on the TV.
• The operation is not possible.
EasyLink does not work.
• Make sure that the home theater is
connected to a Philips brand EasyLink TV, and
the EasyLink option is turned on (see 'Set up
EasyLink (HDMI-CEC control)' on page 10 ) .
When you switch on the TV, the home theater
automatically switches on.
• This behavior is normal when you are using
Philips EasyLink (HDMI-CEC). To make the home
theater work independently, switch off EasyLink.
Cannot access BD-Live features.
• Make sure that the home theater is
connected a home network with internet
access (see 'Connect and set up a home
network' on page 10 ) .
• Make sure that the network is set up (see
'Set up the wired network' on page 11 ) .
• Make sure that the Blu-ray disc supports BD-
Live features.
• Clear memory storage (see 'BD-Live on Blu-
ray' on page 13 ) .
TV screen is black when you play a Blu-ray 3D
video or a DivX copy protected video.
• Make sure that the home theater is
connected to the TV through an HDMI cable.
• Switch to the correct HDMI source on the TV.
Network
Wireless network distorted or not found.
• Make sure that the wireless network is not
disturbed by microwave ovens, DECT phones,
or other neighboring Wi-Fi devices.
• Place the wireless router and the home
theater within fi ve meters of each other.
• Use a USB extension cable to connect the
Wi-Fi dongle to the home theater.
• If the wireless network does not work
properly, try a wired network installation (see
'Set up the wireless network' on page 11 ) .
Slow video streaming from Netfl ix and VUDU.
• Look in your wireless router’s user manual
for information on indoor range, transfer rate,
and other factors of signal quality.
• You need a high speed Internet connection
for your router.
Netfl ix and VUDU does not work.
• Make sure that the network is correctly
connected and set up (see 'Connect and set
up a home network' on page 10 ) .
• Check the router connection (refer to the
user manual for the router).
9 Notice
This section contains the legal and trademark notices.
Copyright
This item incorporates copy protection technology
that is protected by U.S. patents and other
intellectual property rights of Rovi Corporation.
Reverse engineering and disassembly are prohibited.
Compliance
This equipment has been tested and found to
comply with the limits for a Class B and C digital
device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on, the
user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/
TV technician for help.
To assure continued compliance, any changes or
modifi cations not expressly approved by the party
responsible for compliance could void the user’s
authority to operate this equipment. (Example-
use only shielded interface cables when connecting
to computer or peripheral devices).
25
English
EN
This equipment complies with Part 15 of FCC RF
Rules. Operation is subject to the following two
conditions:
1 This device may not cause interference, and
2 This device must accept any interference,
including interference that may cause
undesired operation of the device.
Caution
• The manufacturer is not responsible for any
radio or TV interference caused by unauthorized
modifi cations to this equipment. Such
modifi cation could void the user authority to
operate the equipment.
Canada
This Device complies with RSS-
210 of the IC Rules; Operation is sub-
ject to the following two conditions:
1 This device may not cause interference, and
2 This device must accept any interference
received, including interference that may
cause undesired operation.
Le présent appareil est conforme aux CNR
d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur
de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
FCC Radiation Exposure Statement: This
equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
This equipment should be installed and operated
with a minimum distance of 20cm between the
radiator and your body. This transmitter must not
be co-located or operated in conjunction with any
other antenna or transmitter.
WARNING: Changes or modifi cations made to
this equipment not expressly approved by Philips
may void the FCC authorization to operate this
equipment.
Model number: PHILIPS HTS3541
Trade Name: Philips
Responsible Party: P&F USA, Inc. PO Box 2248
Alpharetta, GA 30023-2248; 1-866-309-0846
This product incorporates proprietary technology
under license from Verance Corporation and is
protected by U.S. Patent 7,369,677 and other U.S.
and worldwide patents issued and pending as well
as copyright and trade secret protection for certain
aspects of such technology. Cinavia is a trademark
of Verance Corporation. Copyright 2004-2010
Verance Corporation. All rights reserved by Verance.
Reverse engineering or disassembly is prohibited.
Cinavia notice
This product uses Cinavia technology to limit the
use of unauthorized copies of some commercially-
produced fi lm and videos and their soundtracks.
When a prohibited use of an unauthorized copy is
detected, a message will be displayed and playback
or copying will be interrupted.
More information about Cinavia technology
is provided at the Cinavia Online Consumer
Information Center at http://www.cinavia.com. To
request additional information about Cinavia by
mail, send a postcard with your mailing address to:
Cinavia Consumer Information Center, P.O. Box
86851, San Diego, CA, 92138, USA.
Notice for Canada
Class B Clause
This digital apparatus does not exceed the Class B
limits for radio noise emissions from digital apparatus
as set out in the Radio Interference Regulations of
the Canadian Department of Communications.
This Class B digital apparatus complies with
Canadian ICES-003.
Open source software
Philips Electronics Singapore Pte Ltd hereby offers
to deliver, upon request, a copy of the complete
corresponding source code for the copyrighted
open source software packages used in this product
for which such offer is requested by the respective
licenses. This offer is valid up to three years after
product purchase to anyone in receipt of this
information. To obtain source code, please contact
[email protected]. If you prefer not to use
email or if you do not receive confi rmation receipt
within a week after mailing to this email address,
please write to "Open Source Team, Philips Intellectual
Property & Standards, P.O. Box 220, 5600 AE
Eindhoven, The Netherlands". If you do not receive
timely confi rmation of your letter, please email to the
email address above. The texts of the licenses and
acknowledgements for open source software used in
this product are included on a separate leafl et.
26 EN
Trademarks
"Blu-ray 3D" and "Blu-ray 3D" logo are trademarks
of Blu-ray Disc Association.
BONUSVIEW™
'BD LIVE' and 'BONUSVIEW' are trademarks of
Blu-ray Disc Association.
Java and all other Java trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and/or
other countries.
Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535;
7,392,195; 7,272,567; 7,333,929; 7,212,872 & other
U.S. and worldwide patents issued & pending.
DTS-HD, the Symbol, & DTS-HD and the Symbol
together are registered trademarks & DTS-HD
Master Audio | Essential is a trademark of DTS, Inc.
Product includes software.
DTS, Inc. All Rights
Reserved.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
Covered by one or more of the following U.S.
patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274.
DivX®, DivX Certifi ed®, DivX Plus® HD
and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used under
license.
ABOUT DIVX PLUS® HD: DivX® is a digital
video format created by DivX, Inc. This is an offi cial
DivX Certifi ed® device that plays DivX video,
including DivX® Plus HD video (H.264/.MKV) up
to 1080p and premium content. Visit www.divx.
com for more information and software tools to
convert your fi les into DivX video.
ABOUT DIVX VIDEO: DivX® is a digital video
format created by DivX, LLC, a subsidiary of Rovi
Corporation. This is an offi cial DivX Certifi ed®
device that plays DivX video. Visit divx.com for
more information and software tools to convert
your fi les into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certifi ed® device must be registered in order to
play purchased DivX Video-on-Demand (VOD)
movies. To obtain your registration code, locate the
DivX VOD section in your device setup menu. Go
to vod.divx.com for more information on how to
complete your registration.
HDMI, the HDMI logo, and High-Defi nition
Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC in the United
States and other countries.
VuduTM is a trademark of VUDU, Inc.
Netfl ix and the Netfl ix logo are trademarks or
registered trademarks of Netfl ix, Inc.
CLASS 1
LASER PRODUCT
27
English
EN
10 Index
2
2nd audio language 13
2nd subtitle language 13
3
3D disc in 2D mode 12
3D safety 3
3D video 12
5
5.1 speakers 7
A
advanced settings 19
amplifi er 22
audio connection (analog cable) 9
audio connection (coaxial cable) 9
audio connection (HDMI ARC) 7
audio connection (optical cable) 9
audio formats 21
audio from other devices 9
audio input mapping 10
audio language 18
audio options 14
audio post processing 19
audio settings 18
audio setup 10
auto standby 19
auto subtitle shift 19
B
batteries 22
BD-Live 13
Blu-ray 12
Bonus View 13
brightness 19
C
change password 19
character set 13
clear BD-Live memory 13
connect to TV 7
connectors 4
control buttons (disc) 12
control buttons (USB) 12
copyright protection 24
customer support 4
D
data fi les 13
deep color 18
default settings 19
disc language 18
disc menu 18
display panel 19
DivX 13
DivX subtitles 13
E
Easylink (HDMI-CEC) 10
eject disc 4
enhanced audio 19
F
factory settings 19
FAQs 4
fi le formats 21
H
HDMI audio 18
HDMI-CEC 10
home menu 12
home network 10
M
main unit 4
manual setup 9
media formats 21
menu language 18
MP3 16
musical slideshows 15
N
Netfl ix 16
network 10
night mode 18
28 EN
O
one-touch play 10
one-touch standby 10
options 14
P
parental control 19
PBC (play back control) 19
picture options 15
picture resolution 18
picture settings 18
picture-in-picture 13
play disc 12
play music 16
play radio 15
play USB storage device 14
power settings 19
predefi ned sound mode 17
preference 18
program radio stations 15
R
radio 15
region codes 21
remote control 5
S
sleep timer 19
slide animation 15
software update 20
software version 20
sound 17
speaker position 7
speaker setup 9
speaker specifi cations 21
subtitle language 18
subtitle position 19
surround sound 17
synchronize picture and sound 12
system audio control 10
T
troubleshooting (network) 24
troubleshooting (picture) 23
troubleshooting (play) 23
troubleshooting (sound) 23
tune radio stations 15
U
update software (through Internet) 20
update software (through USB) 20
USB storage device 14
user manual 4
V
VCD 19
video connection (composite video) 8
video connection (HDMI ARC) 7
video connection (standard HDMI) 8
video formats 22
video options 14
video settings 18
VOD code (DivX) 14
VUDU 16
W
watch 3D 12
wired network 11
wireless network 11
29EN
Contents
1 Important 29
Important safety instructions 29
Care for your product 30
Care of the environment 31
3D health warning 31
Help and support 31
2 Your home theater 32
Main unit 32
Connectors 32
Remote control 33
3 Connect and set up 35
Connect speakers 35
Connect to TV 36
Connect audio from TV and other
devices 37
Set up speakers 38
Set up EasyLink (HDMI-CEC control) 38
Connect and set up a home network 39
4 Use your home theater 41
Access the home menu 41
Discs 41
Data les 43
USB storage devices 44
Audio, video, and picture options 44
Radio 45
MP3 player 46
Netix 46
VUDU 47
Choose sound 47
5 Change settings 49
Language settings 49
Picture and video settings 49
Audio settings 49
Parental control settings 50
Display settings 50
Energy saving settings 50
Speaker settings 50
Restore default settings 51
6 Update software 52
Check software version 52
Update software through USB 52
Update software through the Internet 53
7 Productspecications 54
8 Troubleshooting 57
Troubleshooting 57
9 Notice 60
Copyright 60
Notice of compliance 60
Open source software 61
Trademarks 61
10 Index 63
30 EN
1 Important
Read and understand all instructions before you
use your product. If damage is caused by failure
to follow instructions, the warranty does not
apply.
Important safety instructions
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources
such as radiators, heat registers, stoves, or
other apparatus (including ampliers) that
produce heat.
• Do not defeat the safety purpose of
the polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding
prong. The wide blade or the third prong
are provided for your safety. If the provided
plug does not t into your outlet, consult
an electrician for replacement of the
obsolete outlet.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories
specied by the manufacturer.
• Use only with the cart, stand, tripod,
bracket or table specied by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
• Unplug this apparatus during lightning
storm or when unused for long periods of
time.
• Refer all servicing to qualied service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
• Battery usage CAUTION - To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
unit:
• Install all batteries correctly, + and - as
marked on the unit.
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries when the unit is not
used for a long time.
• The batteries shall not be exposed to
excessive heat such as sunshine, re or
the like.
• Perchlorate Material - special handling
may apply. See www.dtsc.ca.gov/
hazardouswaste/perchlorate.
• The product/remote control may contain
a coin/button type battery, which can be
swallowed. Keep the battery out of reach
of children at all times! If swallowed, the
battery can cause serious injury or death.
Severe internal burns can occur within two
hours of ingestion.
31EN
• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.
• When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the battery
compartment is completely secure after
you replace the battery.
• If the battery compartment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.
• Apparatus shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on
the apparatus (for example. liquid lled
objects, lighted candles).
• This apparatus may contain lead and
mercury. Dispose according to local, State
or Federal laws. For disposal or recycling
information, please contact your local
authorities. For additional assistance on
recycling options, please contact www.
mygreenelectronics.com or www.eiae.org
or www.recycle.philips.com.
• Where the MAINS plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Do not place this apparatus on the
furniture that is capable of being tilted by a
child and an adult leaning, pulling, standing
or climbing on it. A falling apparatus can
cause serious injury or even death.
• This apparatus should not be placed in a
built-in installation such as a bookcase or
rack unless proper ventilation is provided.
Make sure to leave a space of 7.8 inches
(20cm) or more around this apparatus.
Class II equipment symbol
This symbol indicates that the unit has a double
insulation system.
This 'bolt of lightning' indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The 'exclamation point' calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING: To reduce the risk of re or
electric shock, this apparatus should not be
exposed to rain or moisture and objects lled
with liquids, such as vases, should not be placed
on this apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.
Care for your product
• Do not insert any objects other than discs
into the disc compartment.
• Do not insert warped or cracked discs into
the disc compartment.
• Remove discs from the disc compartment
if you are not using the product for an
extended period of time.
• Use only microber cloth to clean the
product.
32 EN
Care of the environment
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused. Please
visit www.recycle.philips.com for additional
information on a recycling center in your area.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
prevent potentially negative consequences on
the environment and human health.
The batteries supplied do not contain the heavy
metals mercury and cadmium. Nevertheless,
in many areas batteries may not be disposed
of with your household waste. Please ensure
you dispose of batteries according to local
regulations.
For perchlorate material, special handling may
apply. Visit www.dtsc.ca.gov/hazardouswaste/
perchlorate.
3D health warning
If you or your family has a history of epilepsy
or photosensitive seizures, consult a medical
professional before exposing yourself to ashing
light sources, rapid image sequences or 3D
viewing.
To avoid discomfort such as dizziness, headache
or disorientation, we recommend not watching
3D for extended periods of time. If you
experience any discomfort, stop watching
3D and do not immediately engage in any
potentially hazardous activity (for example
driving a car) until your symptoms have
disappeared. If symptoms persist, do not resume
watching 3D without consulting a medical
professional rst.
Parents should monitor their children during
3D viewing and ensure they do not experience
any discomfort as mentioned above. Watching
3D is not recommended for children under six
years of age as their visual system is not fully
developed yet.
Help and support
Philips provides extensive online support. Visit
our website at www.philips.com/support to:
• download the complete user manual
• print the quick start guide
• watch video tutorials (available only for
selected models)
• nd answers to frequently answered
questions (FAQs)
• email us a question
• chat with our support representative.
Follow the instructions on the website to select
your language, and then enter your product
model number.
Alternatively, you can contact Philips Consumer
Care in your country. Before you contact
Philips, note down the model number and
serial number of your product. You can nd this
information on the back or bottom of your
product.
33EN
2 Your home
theater
Congratulations on your purchase, and
welcome to Philips! To fully benet from the
support that Philips offers(e.g. notication
of product software upgrade), register your
product at www.philips.com/welcome.
Main unit
This section includes an overview of the main
unit.
a Disc compartment
b Display panel
c (Open/Close)
Open or close the disc compartment, or
eject the disc.
d (Play/Pause)
Start, pause or resume play.
e SOURCE
Select an audio or video source for the
home theater.
f (Standby-On)
Switch the home theater on or to standby.
Connectors
This section includes an overview of the
connectors available on your home theater.
Front connectors
a (USB)
• Audio, video or picture input from a
USB storage device.
b MUSIC iLINK
Audio input from an MP3 player.
Rear connectors
a AC MAINS
Connect to the power supply.
b SPEAKERS
Connect to the supplied speakers and
subwoofer.
c ANTENNA FM
Fixed FM antenna.
d AUDIO IN-AUX
Connect to an analog audio output on the
TV or an analog device.
e VIDEO OUT
Connect to the composite video input on
the TV.
34 EN
f HDMI OUT (ARC)
Connect to the HDMI input on the TV.
g LAN
Connect to the LAN input on a
broadband modem or router.
h DIGITAL IN-OPTICAL
Connect to an optical audio output on the
TV or a digital device.
i DIGITAL IN-COAXIAL
Connect to a coaxial audio output on the
TV or a digital device.
Remote control
This section includes an overview of the
remote control.
a (Standby-On)
• Switch the home theater on or to
standby.
• When EasyLink is enabled, press
and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.
1
2
7
3
4
5
9
11
12
19
17
20
13
6
18
8
10
14
15
21
16
35EN
b (Home)
Access the home menu.
c Source buttons
• DISC/POP-UP MENU : Switch to disc
source.Access or exit the disc menu
when you play a disc.
• RADIO : Switch to FM radio.
• AUDIO SOURCE : Select an audio
input source.
d BACK
• Return to a previous menu screen.
• In radio mode, press and hold to erase
the current preset radio stations.
e Navigation buttons
• Navigate menus.
• In radio mode, press left or right to
start auto search.
• In radio mode, press up or down to
tune the radio frequency.
f OK
Conrm an entry or selection.
g / (Previous/Next)
• Skip to the previous or next track,
chapter or le.
• In radio mode, select a preset radio
station.
h (Stop) / (Eject/Open/Close)
• Stop play.
• Press and hold for three seconds to
open or close the disc compartment,
or eject the disc.
i / (Fast Backward / Fast Forward)
Search backwards or forward. Press
repeatedly to change the search speed.
j +/- (Volume)
Increase or decrease volume.
k SOUND SETTINGS
Access or exit sound options.
l Alphanumeric buttons
Enter values or letters (using SMS style
entry).
m REPEAT
Select or turn off repeat mode.
n Color buttons
• Select tasks or options for Blu-ray discs.
• Netix: Access online videos and TV
episodes from Netix.
• VUDU: Access online videos from
VUDU.
o SUBTITLE
Select subtitle language for video.
p AUDIO
Select an audio language or channel.
q (Mute)
Mute or restore volume.
r (Pause)
Pause play.
s (Play)
Start or resume play.
t OPTIONS
• Access more play options while playing
a disc or a USB storage device.
• In radio mode, set a radio station.
u TOP MENU
Access the main menu of a disc.
36 EN
3 Connect and set
up
This section helps you connect your home
theater to a TV and other devices, and then set
it up.
For information about the basic connections
of your home theater and accessories, see the
quick start guide.
Note
• For identication and supply ratings, see the type plate
at the back or bottom of the product.
• Before you make or change any connections, make sure
that all devices are disconnected from the power outlet.
Connect speakers
The speaker cables are color-coded for easy
connection. To connect a speaker to your home
theater, match the color on the speaker cable to
the color on the connector.
Speaker position plays a critical role in setting
up a surround sound effect. For best effect,
position all the speakers towards the seating
position and place them close to your ear level
(seated).
Note
• Surround sound depends on factors such as room
shape and size, type of wall and ceiling, windows and
reective surfaces, and speaker acoustics. Experiment
with the speaker positions to nd the optimum setting
for you.
Follow these general guidelines for speakers
placement.
1 Seating position:
This is the center of your listening area.
2 FRONT CENTER (front center) speaker:
Place the center speaker directly in front of
the seating position, either above or below
your TV.
3 FRONT LEFT (front left) and FRONT
RIGHT (front right) speakers:
Place the left and right speakers in the
front, and at equal distance from the center
speaker. Make sure that the left, right, and
the center speakers are at equal distance
from your seating position.
4 REAR LEFT (rear left) and REAR RIGHT
(rear right) speakers:
SUB
WOOFER
FRONT
LEFT
FRONT
CENTER
FRONT
RIGHT
REAR
RIGHT
REAR
LEFT
37EN
Place the rear surround speakers to the
left and right side of your seating position,
either in line with it or slightly behind it.
5 SUBWOOFER (subwoofer):
Place the subwoofer at least one meter
to the left or right of the TV. Leave about
10-centimeter clearance from the wall.
Connect to TV
Connect your home theater to a TV to watch
videos. You can listen to the TV audio through
your home theater speakers.
Use the best quality connection available on
your home theater and TV.
Option 1: Connect to TV through
HDMI (ARC)
Best quality video
Your home theater supports HDMI version
with Audio Return Channel (ARC). If your TV
is HDMI ARC compliant, you can hear the TV
audio through your home theater by using a
single HDMI cable.
1 Using a High Speed HDMI cable, connect
the HDMI OUT (ARC) connector on
your home theater to the HDMI ARC
connector on the TV.
• The HDMI ARC connector on the TV
might be labeled differently. For details,
see the TV user manual.
2 On your TV, turn on HDMI-CEC
operations. For details, see the TV user
manual.
• If you cannot hear the TV audio
through your home theater, set up the
audio manually (see 'Set up the audio'
on page 40).
Option 2: Connect to TV through
standard HDMI
Best quality video
If your TV is not HDMI ARC compliant, connect
your home theater to the TV through a
standard HDMI connection.
1 Using a High Speed HDMI cable, connect
the HDMI OUT (ARC) connector on your
home theater to the HDMI connector on
the TV.
2 Connect an audio cable to hear the TV
audio through your home theater (see
'Connect audio from TV and other devices'
on page 38).
3 On your TV, turn on HDMI-CEC
operations. For details, see the TV user
manual.
• HDMI-CEC is a feature that enables
CEC compliant devices that are
connected through HDMI to be
controlled by a single remote control,
such as volume control for both the
TV and the home theater. (see 'Set
up EasyLink (HDMI-CEC control)' on
page 39)
4 If you cannot hear the TV audio through
your home theater, set up the audio
manually.
Note
• If your TV has a DVI connector, you can use an HDMI/
DVI adapter to connect to TV. However, some of the
features may not be available.
TV
38 EN
Option 3: Connect to the TV through
composite video
Basic quality video
If your TV does not have HDMI connectors, use
a composite video connection. A composite
connection does not support high-denition
video.
1 Using a composite video cable, connect the
VIDEO connector on your home theater
to the VIDEO IN connector on the TV.
• The composite video connector might
be labeled AV IN, COMPOSITE, or
BASEBAND.
2 Connect an audio cable to hear the TV
audio through your home theater (see
'Connect audio from TV and other devices'
on page 38).
3 When you watch TV programs, press
SOURCE on your home theater
repeatedly to select the correct audio
input.
4 When you watch videos, switch your TV to
the correct video input. For details, see the
TV user manual.
TV
TV
Connect audio from TV and
other devices
Play audio from TV or other devices through
your home theater speakers.
Use the best quality connection available on
your TV, home theater, and other devices.
Note
• When your home theater and TV are connected
through HDMI ARC, an audio connection is not
required (see 'Option 1: Connect to TV through HDMI
(ARC)' on page 37).
Option 1: Connect audio through a
digital optical cable
Best quality audio
1 Using an optical cable, connect the
OPTICAL connector on your home
theater to the OPTICAL OUT connector
on the TV or other device.
• The digital optical connector might be
labeled SPDIF or SPDIF OUT.
Option 2: Connect audio through a
digital coaxial cable
Good quality audio
1 Using a coaxial cable, connect the
COAXIAL connector on your home
theater to the COAXIAL/DIGITAL OUT
connector on the TV or other device.
• The digital coaxial connector might be
labeled DIGITAL AUDIO OUT.
TV
39EN
Option 3: Connect audio through
analog audio cables
Basic quality audio
1 Using an analog cable, connect the AUX
connectors on your home theater to the
AUDIO OUT connectors on the TV or
other device.
Set up speakers
Set up the speakers manually to experience
customized surround sound.
Before you start
Make the necessary connections described in
the quick start guide, and then switch the TV to
the correct source for your home theater.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Audio] > [Speaker setup]
4 Enter the distance for each speaker, and
then listen to the test tones and change
the volume. Experiment with the speaker
positions to nd the ideal setting.
VCR
Set up EasyLink (HDMI-CEC
control)
This home theater supports Philips EasyLink,
which uses the HDMI-CEC (Consumer
Electronics Control) protocol. EasyLink-
compliant devices that are connected through
HDMI can be controlled by a single remote
control.
Note
• Depending on the manufacturer, HDMI-CEC is known
by many names. For information on your device, see
the user manual of the device.
• Philips does not guarantee 100% interoperability with
all HDMI-CEC devices.
Before you start
• Connect your home theater to the HDMI-
CEC compliant device through HDMI
connection.
• Make the necessary connections described
in the quick start guide, and then switch
the TV to the correct source for your
home theater.
Enable EasyLink
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [EasyLink] > [EasyLink] > [On] .
4 On your TV and other connected devices,
turn on HDMI-CEC control. For details, see
the user manual of the TV or other devices.
• On your TV, set the audio output to
'Amplier' (instead of TV speakers).
For details, see the TV user manual.
40 EN
EasyLink controls
With EasyLink, you can control your home
theater, TV, and other connected HDMI-CEC
compliant devices with a single remote control.
• [One Touch Play] (One-touch play): When
a video disc is in the disc compartment,
press (Play) to wake up the TV from
standby, and then play a disc.
• [One Touch Standby] (One-touch
standby): If one-touch standby is enabled,
your home theater can switch to standby
with the remote control of the TV or other
HDMI-CEC devices.
• [System Audio Control] (System audio
control): If system audio control is enabled,
the audio of the connected device is
output through your home theater
speakers automatically when you play the
device.
• [Audio Input Mapping] (Audio input
mapping):If system audio control does not
work, map the connected device to the
correct audio input connector on your
home theater.
Note
• To change the EasyLink control settings, press
(Home), select [Setup] > [EasyLink].
Set up the audio
If you cannot hear the audio output of a
connected device through your home theater
speakers, check that you have enabled Easylink
on all the devices (see 'Enable EasyLink' on
page 39). Then, set up the EasyLink audio
control.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [EasyLink] > [System Audio
Control] > [On].
• To play the audio from the TV
speakers, select [Off], and skip the
following steps.
4 Select [EasyLink] > [Audio Input
Mapping].
5 Follow the onscreen instructions to map
the connected device to the audio inputs
on your home theater.
• If you connect your home theater
to the TV through an HDMI ARC
connection, make sure that the TV
audio is mapped to the ARC input on
your home theater.
Connect and set up a home
network
Connect your home theater to a home
network with internet access and enjoy:
• Netix online videos
• VUDU online videos
• BD-Live applications
• Software update
Caution
• Familiarize yourself with the network router and
networking principles. If necessary, read documentation
that accompanies the network components. Philips is
not responsible for lost, damaged, or corrupt data.
Before you start
• For Netix, VUDU and software update,
make sure that the network router has
access to the Internet with high-speed
connection, and is not restricted by
rewalls or other security systems.
• Make the necessary connections described
in the quick start guide, and then switch
the TV to the correct source for your
home theater.
41EN
Set up the wired network
What you need
• A network cable (RJ45 straight cable).
• A network router (with DHCP enabled).
1 Using a network cable, connect the LAN
connector on your home theater to the
network router.
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Network] > [Network
installation] > [Wired (Ethernet)].
5 Follow the onscreen instructions to
complete the setup.
• If connection fails, select [Retry], and
then press OK.
6 Select [Finish], and then press OK to exit.
• To view the network settings, select
[Setup] > [Network] > [View
network settings].
Set up the wireless network
Your home theater has built-in Wi-Fi for easy
access to the wireless network.
What you need
• A network router (with DHCP enabled).
For best wireless performance, coverage,
and compatibility, use 802.11n router.
LAN
www
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Network] > [Network
installation] > [Wireless (Wi-Fi)], and
then press OK.
4 Follow the onscreen instructions to select
and set up the wireless network.
• If connection fails, select [Retry], and
then press OK.
5 Select [Finish], and then press OK to exit.
• To view the network settings, select
[Setup] > [Network] > [View
wireless settings].
42 EN
4 Use your home
theater
This section helps you use the home theater to
play media from a wide range of sources.
Before you start
• Make the necessary connections described
in the quick start guide and the user
manual.
• Complete the rst-time setup. First-time
setup appears when you turn on your
home theater for the rst time or if you do
not complete the setup.
• Switch the TV to the correct source for
your home theater (for example, HDMI,
AV IN).
Access the home menu
The home menu provides easy access to
connected devices, setup and other useful
features in your home theater.
Connect your home theater to a network
router through wired or wireless network
connection, and enjoy:
• Netix online videos
• VUDU online videos
• BD-Live applications
• Software update
Caution
• Familiarize yourself with the network router, media
server software and networking principles. If necessary,
read documentation that accompanies the network
components. Philips is not responsible for lost, damaged,
or corrupt data.
Before you start
• For Netix, VUDU and software updates,
make sure that the network router has
access to the Internet with high-speed
connection and is not restricted by
rewalls or other security systems.
• Make the necessary connections described
in the quick start guide, and then switch
the TV to the correct source for your
home theater.
Discs
Your home theater can play DVDs, VCDs, CDs,
and Blu-ray discs. It can also play discs that
you’ve made at home, such as CD-R discs of
photos, videos, and music.
1 Insert a disc into the home theater.
2 If the disc does not play automatically, press
DISC or select [play Disc] from the home
menu.
3 Use the remote control to control play
(see 'Remote control' on page 34).
• It is normal to hear a little noise when
you play a Blu-ray disc. This does not
mean that your home theater is faulty.
Note
• To avoid ickering, change the brightness of the display.
Play buttons
Button Action
Navigation
buttons
Navigate menus.
Up/Down: Rotate the picture
clockwise or counter-clockwise.
Left/Right: Skip to the previous or
next picture.
OK Conrm an entry or selection.
(Play) Start or resume play.
Pause play.
Stop play.
/ Skip to the previous or next track,
chapter or le.
/ Search fast backwards or forward.
Search slow forward.
43EN
Button Action
AUDIO Select an audio language or
channel.
SUBTITLE Select subtitle language for video.
DISC/
POP-UP
MENU
Access or exit the disc menu.
OPTIONS Access the advanced options
when you play your audio, video,
or media les (see 'Audio, video,
and picture options' on page 45).
REPEAT Select or turn off repeat mode.
Synchronize picture and sound
If the audio and video are not synchronized,
delay the audio to match the video.
1 Press SOUND SETTINGS.
2 Select AUD SYNC, and then press OK.
3 Press the Navigation buttons (up/down)
to synchronize the audio with the video.
4 Press OK to conrm.
Play Blu-ray 3D disc
Your home theater can play Blu-ray 3D video.
Read the 3D health warning before playing a
3D disc.
What you need
• A 3D TV
• A pair of 3D glasses that are compatible
with your 3D TV
• A 3D Blu-ray video
• A high speed HDMI cable
1 Using the high speed HDMI cable, connect
your home theater to a 3D compatible TV.
2 Make sure that the 3D video setting is
enabled. Press (Home), select [Setup] >
[Video] > [Watch 3D video] > [Auto].
• To play 3D discs in 2D mode, select
[Off].
3 Play a Blu-ray 3D disc and put on the 3D
glasses.
• During video search and in certain play
modes, the video is displayed in 2D.
The video display returns to 3D when
you resume play.
Bonus View on Blu-ray
On Blu-ray discs that support the Bonus View,
enjoy extra content such as commentaries in a
small screen window. Bonus View is also known
as picture-in-picture.
1 Enable Bonus View in the Blu-ray disc
menu.
2 While you play the movie, press
OPTIONS.
» The options menu is displayed.
3 Select [PIP selection] > [PIP].
• Depending on the video, PIP menu [1]
or [2] is displayed.
• To disable Bonus View, select [Off].
4 Select [2nd audio language] or [2nd
Subtitle Language].
5 Select the language, and then press OK.
BD-Live on Blu-ray
Access additional features on the Blu-ray discs
with BD-Live content, such as internet chats
with the director, the latest movie trailers,
games, wallpaper, and ringtones.
BD-Live services and content vary from disc to
disc.
What you need
• Blu-ray disc with BD-Live content
• a USB storage device, with at least 1 GB of
memory
1 Connect your home theater to a home
network with Internet access (see
'Connect and set up a home network' on
page 40).
44 EN
2 Connect a USB storage device to your
home theater.
3 Press (Home) and select [Setup].
4 Select [Advanced] > [BD-Live security] >
[Off] to enable BD-Live.
• To disable BD-Live, select [On].
5 Select the BD-Live icon in the disc menu,
and then press OK.
» BD-Live starts to load. The loading
time depends on the disc and your
internet connection.
6 Press the Navigation buttons to navigate
BD-Live, and then press OK to select an
option.
Note
• To clear the memory on the storage device, press
(Home), select [Setup] > [Advanced] > [Clear
memory].
Datales
Your home theater can play pictures, audio and
video les contained in a disc or a USB storage
device. Before you play a le, check that the le
format is supported by your home theater (see
'File formats' on page 55).
1 Play the les from a disc or USB storage
device.
2 To stop play, press .
• To resume the video from where you
stopped, press (Play).
• To play the video from the start, press
OK.
Note
• To play DivX DRM protected les, connect your home
theater to a TV through an HDMI cable.
Subtitles
If your video has subtitles in multiple languages,
select a subtitle language.
Note
• Make sure that the subtitle le has the exact same
name as the video le. For example, if the video le is
named 'movie.avi', name the subtitle le as 'movie.srt'
or 'movie.sub'.
• Your home theater supports the following le formats:
.srt, .sub, .txt, .ssa, .ass, smi, and .sami. If the subtitles do
not appear correctly, change the character set.
1 While playing video, press SUBTITLE to
select a language.
2 For DivX videos, if the subtitles do not
appear correctly, continue the following
steps to change the character set.
3 Press OPTIONS.
» The options menu is displayed.
4 Select [Character set], and then select a
character set that supports the subtitle.
Europe, India, LATAM, and Russia
Character
Set
Language
[Standard] English, Albanian, Danish,
Dutch, Finnish, French, Gaelic,
German, Italian, Kurdish (Latin),
Norwegian, Portuguese, Spanish,
Swedish and Turkish
[Central
Europe]
Albanian, Croat, Czech, Dutch,
English, German, Hungarian, Irish,
Polish, Romanian, Slovak, Slovene
and Sorbian
[Cyrillic] Bulgarian, Belorussian, English,
Macedonian, Moldavian, Russian,
Serbian and Ukrainian
[Greek] Greek
[Baltic] Estonian, Latvian and Lithuanian
45EN
VOD code for DivX
Before you purchase DivX videos and play
them on your home theater, register the home
theater on www.divx.com using the DivX VOD
code.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [DivX
®
VOD Code].
» The DivX VOD registration code for
your home theater is displayed.
USB storage devices
Enjoy pictures, audio, and video stored on a
USB storage device such as an MP4 player or
digital camera.
What you need
• A USB storage device that is formatted for
FAT or NTFS le systems, and complies
with the Mass Storage Class.
• A media le in one of the supported le
formats (see 'File formats' on page 55).
Note
• If you use a USB extension cable, USB HUB, or USB
multi-reader, the USB storage device may not be
recognized.
1 Connect a USB storage device to the
(USB) connector on your home theater.
2 Press (Home).
3 Select [browse USB], and then press OK.
» A content browser is displayed.
4 Select a le, and then press OK.
5 Press the play buttons to control play (see
'Play buttons' on page 42).
Audio, video, and picture
options
Use advanced features when you play pictures,
audio and video les from a disc or a USB
storage device.
Audio options
While playing audio, repeat an audio track, a
disc, or a folder.
1 Press OPTIONS repeatedly to cycle
through the following functions:
• RPT TRK / RPT FILE: Repeat the
current track or le.
• RPT DISC / RPT FOLD: Repeat all the
tracks on the disc or the folder.
• RPT RDOM: Play audio tracks in
random order.
• RPT OFF: Turn off the repeat mode.
Video options
While watching video, select options such
as subtitles, audio language, time search, and
picture settings. Depending on the video source,
some options are not available.
1 Press OPTIONS.
» The video options menu is displayed.
2 Press the Navigation buttons and OK to
select and change:
• [Audio language]: Select audio
language for video.
• [Subtitle Language]: Select subtitle
language for video.
• [Subtitle shift]: Change the subtitle
position on the screen.
• [Info]: Display information about what
is playing.
• [Character set]: Select a character set
that supports the DivX subtitle.
• [Time search]: Skip to a specic part
of the video by entering the time of
the scene.
46 EN
• [2nd audio language]: Select the second
audio language for Blu-ray video.
• [2nd Subtitle Language]: Select the
second subtitle language for Blu-ray video.
• [Titles]: Select a specic title.
• [Chapters]: Select a specic chapter.
• [Angle list]: Select a different camera
angle.
• [Menus]: Display the disc menu.
• [PIP selection]: Display Picture-in-
Picture window when playing a Blu-ray
disc that supports the Bonus View.
• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Repeat]: Repeat a chapter or title.
• [Repeat A-B]: Mark two points within a
chapter or track to repeat play, or turn
off the repeat mode.
• [Picture settings]: Select a predened
color setting.
Picture options
While viewing a picture, zoom into the picture,
rotate it, add animation to a slideshow, and
change the picture settings.
1 Press OPTIONS.
» The picture options menu appears.
2 Press the Navigation buttons and OK to
select and change the following settings:
• [Rotate +90]: Rotate the picture
90 degree clockwise.
• [Rotate -90]: Rotate the picture
90 degree counter-clockwise.
• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.
• [Info]: Display picture information.
• [Duration per slide]: Select the display
speed for each picture in a slide show.
• [Slide animation]: Select animation for
the slide show.
• [Picture settings]: Select a predened
color setting.
• [Repeat]: Repeat a selected folder.
Musical slideshow
If the picture and audio les are from the same
disc or USB storage device, you can create a
musical slideshow.
1 Select an audio track, and then press OK.
2 Press BACK, and go to the picture
folder.
3 Select a picture, and then press (Play) to
start the slideshow.
4 Press to stop slideshow.
5 Press again to stop music.
Note
• Make sure that the picture and audio formats are
supported by your home theater (see 'File formats' on
page 55).
Radio
Listen to FM radio on your home theater, and
store up to 40 radio stations.
Note
• AM and digital radio are not supported.
• If no stereo signal is detected, or if fewer than ve
stations are found, you are prompted to install the
radio stations again.
1 Extend the FM antenna at the back of your
home theater and place it away from the
TV or other sources of radiation.
2 Press RADIO.
» If you have already installed the radio
stations, the last channel that you
listened to is played.
» If you have not installed any radio
stations, the message AUTO
INSTALL...PRESS PLAY appears on
the display panel. press (Play).
3 Use the remote control to listen or to
change radio stations.
47EN
Button Action
/
or
Alphanumeric
buttons
Select a preset radio station.
Navigation
buttons
Left/Right: Search for a radio
station.
Up/Down: Fine tune a radio
frequency.
Press to stop the installation
of radio stations.
BACK Press and hold to erase the
preset radio station.
OPTIONS Manual:
1) Press OPTIONS.
2) Press / to select your
preset.
3) Press OPTIONS again
to store the radio station.
Automatic: Press and hold for
three seconds to reinstall the
radio stations.
SUBTITLE Toggle between the stereo
and mono sounds.
Tuning grid
In some countries, you can toggle the FM tuning
grid between 50 kHz and 100 kHz. Switching
the tuning grid erases all preset radio stations.
1 Press RADIO.
2 Press .
3 Press and hold (Play) to toggle between
50 kHz or 100 kHz.
MP3 player
Connect a MP3 player to play audio les.
What you need
• An MP3 player.
• A 3.5mm stereo audio cable.
1 Using the 3.5mm stereo audio cable,
connect the MP3 player to the MUSIC
iLINK connector on your home theater.
2 Press AUDIO SOURCE repeatedly until
MUSIC I-LINK appears on the display
panel.
3 Press the buttons on the MP3 player to
select and play audio les.
Netix
Use Netix to stream movies and TV episodes
through your home theater. You can also rent
videos from online stores.
For more information on Netix services, visit
www.netix.com.
1 Connect your home theater to a home
network with high-speed Internet access
(see 'Connect and set up a home network'
on page 40).
2 Press (Home).
3 Select [Netix], and then press OK.
» The Netix home page is displayed.
4 Use the remote control to navigate and
start a video play.
» If you have not activated your home
theater to play videos from Netix, an
activation code is displayed.
» If you have activated your home
theater, skip step 5.
5 On your computer, visit
www.netix.com/activate to activate your
home theater with the activation code.
• You need to sign in as Netix member..
6 To exit Netix, press (Home).
48 EN
Note
• To deactivate Netix from your home theater, press ,
and then select [Setup] > > [Deactivation] > [Netix].
• When you contact Netix customer service, you may
ask to provide the ESN (electronic serial number) of
your home theater. To display the ESN, press , and
then select [Setup] > [Advanced] > [NetixESN].
VUDU
Use VUDU to stream movies through your
home theater. VUDU provides on-demand
videos and rich internet applications.
For more information on VUDU services, visit
www.vudu.com.
1 Connect your home theater to a home
network with high-speed Internet access
(see 'Connect and set up a home network'
on page 40).
2 Press (Home).
3 Select [VUDU], and then press OK.
» The VUDU home page is displayed.
4 If you have activated your home theater,
skip steps 5 and 6.
5 Select 'Free HD' to acquire an activation
code.
6 On your computer, when you receive the
VUDU conrmation email in your inbox,
click the activation link provided and
follow the prompts through the activation
process.
7 Use the remote control to navigate and
start a video play.
8 To exit VUDU, press (Home).
Note
• To deactivate VUDU from your home theater,
press , and then select [Setup] > [Advanced] >
[Deactivation] > [VUDU].
Choose sound
This section helps you choose the ideal sound
for your video or music.
1 Press SOUND SETTINGS.
2 Press the Navigation buttons (left/ right)
to access the sound options on the display.
Sound settings Description
SOUND Select a sound mode.
SURROUND Select surround sound or
stereo sound.
TREBLE Change the high frequency
output.
MID Change the middle frequency
output.
BASS Change the low frequency
output.
AUD SYNC Delay the audio to match the
video.
3 Select an option, and then press OK.
4 Press BACK to exit.
If you do not press a button within a
minute, the menu exits automatically.
Sound mode
Select predened sound modes to suit your
video or music.
1 Press SOUND SETTINGS.
2 Select SOUND, and then press OK.
3 Press the Navigation buttons (up/down)
to select a setting on the display:
• MOVIE: Enjoy a cinematic audio
experience, specially enhanced for
movies.
• MUSIC: Recreate the original recording
environment of your music, in the
studio or at a concert.
• ORIGINAL: Experience the original
sound of your movies and music,
without added sound effects.
49EN
• NEWS: Hear every word with
optimized speech and clear vocals.
• GAMING: Enjoy thrilling arcade
sounds, ideal for action-packed video
games or loud parties.
4 Press OK to conrm.
Surround sound mode
Experience an immersive audio experience with
surround sound modes.
1 Press SOUND SETTINGS.
2 Select SURROUND, and then press OK.
3 Press the Navigation buttons (up/down)
to select a setting on the display:
• AUTO: Surround sound based on the
audio stream.
• MULTI-CH: Immersive multi-channel
sound for an enhanced movie
experience.
• STEREO: Two-channel stereo sound.
Ideal for listening to music.
4 Press OK to conrm.
Equalizer
Change the high frequency (treble), mid
frequency (mid), and low frequency (bass)
settings of the home theater.
1 Press SOUND SETTINGS.
2 Select TREBLE, MID or BASS, and then
press OK.
3 Press the Navigation buttons (up/down)
to change the frequency.
4 Press OK to conrm.
50 EN
5 Change settings
The home theater settings are already
congured for optimal performance. Unless
you have a reason to change a setting, we
recommend that you keep the default setting.
Note
• You cannot change a setting that is grayed out.
• To return to the previous menu, press BACK. To
exit the menu, press (Home).
Language settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Menu language]: Select a display
language for menu.
• [Audio]: Select an audio language for
discs.
• [Subtitle]: Select a subtitle language
for discs.
• [Disc menu]: Select a menu language
for discs.
Note
• If your preferred disc language is not available, select
[Others] from the list, and enter the 4-digit language
code found at the end of this user manual.
• If you select a language that is not available on a disc,
the home theater uses the default language of the disc.
Picture and video settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Video], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Tv type]: If the video does not appear
correctly, select a TV type (color
system).
• [TV Display]: Select a picture format
to t the TV screen.
• [HDMI Video]: Select the resolution of
video signal that is output from HDMI
OUT (ARC) on your home theater.
To enjoy the selected resolution,
make sure that your TV supports the
selected resolution.
• [HDMI Deep Color]: Recreate the
natural world on your TV screen by
displaying vivid images using billion
colors. Your home theater must be
connected to a Deep Color enabled
TV through an HDMI cable.
• [Picture Settings]: Select pre dened
color settings for the video display.
• [Watch 3D video]: Set HDMI video to
support 3D or 2D video.
Note
• If you change a setting, make sure that the TV supports
the new setting.
Audio settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Audio], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
51EN
• [Night mode]: For quiet listening,
decrease the volume of loud sounds
on your home theater. Night mode
is only available in DVDs and Blu-ray
discs with Dolby Digital, Dolby Digital
Plus, and Dolby True HD soundtracks.
• [HDMI Audio]: Set the HDMI audio
output from your TV, or disable HDMI
audio output from the TV.
• [Speaker setup]: Set the volume level
and distance of each speaker to obtain
the best possible surround sound.
• [Default sound settings]: Restore the
sound settings to their default values.
Parental control settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Change Password]: Set or change
your password for parental control
access. If you do not have a password
or have forgotten your password, enter
0000.
• [Parental control]: Restrict access
to discs that are recorded with age
ratings. To play all discs, irrespective of
the ratings, select 8 or [Off].
Display settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Auto subtitle shift]: Enable or disable
automatic repositioning of subtitles on
TVs that support this feature.
• [Display panel]: Set the brightness of
the home theater front panel display.
• [VCD PBC]: Enable or disable the
content menu navigation of VCD and
SVCD discs with Play Back Control
feature.
Energy saving settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Screen saver]: Switch the home
theater to screen saver mode after
10 minutes of inactivity.
• [Auto standby]: Switch the home
theater to standby after 30 minutes of
inactivity. This timer works only when a
disc or USB play is paused or stopped.
• [Sleep timer]: Set the duration of the
sleep timer so that the home theater is
switched to standby after the specied
period.
Speaker settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced], and then press OK.
4 Press the Navigation buttons and OK to
select and change:
• [Enhanced audio]: Select [On] to
enable audio post processing at the
speaker and enable karaoke settings
(if your product supports Karaoke).
To play the original audio of the disc,
select [Off].
52 EN
Tip
• Enable audio post processing before you select a
predened sound mode (see 'Sound mode' on page
48).
Restore default settings
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Restore default
settings], and then press OK.
4 Select [OK], and then press OK to
conrm.
» Your home theater is reset to its
default settings except for some
settings such as parental control and
DivX VOD registration code.
53EN
6 Update software
Philips continually tries to improve its products.
To get the best features and support, update
your home theater with the latest software.
Compare the version of your current
software with the latest version on
www.philips.com/support. If the current version
is lower than the latest version available on the
Philips support website, upgrade your home
theater with the latest software.
Caution
• Do not install a lower version of software than the
current version installed on your product. Philips is not
liable for problems caused due to software downgrade.
Check software version
Check the version of the current software
installed on your home theater.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Version
information].
» The software version is displayed.
Update software through
USB
What you need
• A USB ash drive that is FAT or NTFS-
formatted, with at least 75MB of memory.
Do not use a USB hard drive.
• A computer with Internet access.
• An archive utility that supports the ZIP le
format.
Step 1: Download the latest software
1 Connect a USB ash drive to your
computer.
2 In your web browser, go to
www.philips.com/support.
3 At the Philips Support website, nd your
product and locate the Software and
drivers.
» The software update is available as a
zip le.
4 Save the zip le in the root directory of
your USB ash drive.
5 Use the archive utility to extract the
software update le in the root directory.
» The les are extracted under the UPG
folder of your USB ash drive.
6 Disconnect the USB ash drive from your
computer.
Step 2: Update the software
Caution
• Do not switch off the home theater or remove the
USB ash drive during the update.
1 Connect the USB ash drive containing the
downloaded le to your home theater.
• Make sure that the disc compartment
is closed and no disc inside.
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Advanced] > [Software update]
> [USB].
5 Follow the onscreen instructions to
conrm the update.
» Update process takes about 5 minutes
to complete.
» Once complete, the home theater
automatically switches off and restarts.
If it does not, disconnect the power
cord for a few seconds and then
reconnect it.
54 EN
Update software through the
Internet
1 Connect your home theater to a home
network with a high-speed Internet access
(see 'Connect and set up a home network'
on page 40).
2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Advanced] > [Software update] >
[Network].
» If an upgrade media is detected, you
are prompted to start or cancel the
update.
» Downloading of the upgrading le may
take long, depending on your home
network condition.
5 Follow the onscreen instructions to
conrm the update.
» Update process takes about 5 minutes
to complete.
» Once complete, the home theater
automatically switches off and restarts.
If it does not, disconnect the power
cord for a few seconds and then
reconnect it.
55EN
7 Product
specifications
Note
• Specications and design are subject to change without
notice.
Region codes
The type plate on the back or bottom of the
home theater shows which regions it supports.
Media formats
• AVCHD, BD, BD-R/ BD-RE, BD-Video,
DVD-Video, DVD+R/+RW, DVD-R/-RW,
DVD+R/-R DL, CD-R/CD-RW, Audio CD,
Video CD/SVCD, Picture les, MP3 media,
WMA media, DivX Plus HD media, USB
storage device
File formats
• Audio: .aac, .mka, .mp3, .wma, .wav
• Video: .avi, .divx, .mp4, .mkv, .mpg, .mpeg
• Picture: .jpg, .jpeg, .gif, .png
Audio formats
Your home theater supports the following
audio les.
Extension Container Audio
codec
Bit rate
.mp3 MP3 MP3 32 kbps ~
320 kbps
Country
DVD BD
USA, Canada
AA
1
Extension Container Audio
codec
Bit rate
.wma ASF WMA 64 kbps ~
160 kbps
.aac AAC AAC, HE-
AAC
192 kbps
.wav WAV PCM 1.4 Mbps
.m4a MKV AAC 192 kbps
.mka MKA PCM 27.648 Mbps
.mka MKA Dolby
Digital
640 kbps
.mka MKA DTS core 1.54 Mbps
.mka MKA MPEG 912 kbps
.mka MKA MP3 32 kbps ~
320 kbps
.mka MKA WMA 64 kbps ~
160 kbps
.mka MKA AAC, HE-
AAC
192 kbps
Video formats
If you have a high denition TV, your home
theater allows you to play your video les with:
• Resolution: 1920 x 1080 pixels at
• Frame rate: 6 ~ 30 frames per second.
.avilesinAVIcontainer
Audio codec Video codec Bit rate
PCM, Dolby
Digital, DTS
core, MP3,
WMA
DivX 3.11,
DivX 4.x,
DivX 5.x,
DivX 6.x
10 Mbps max
MPEG 1,
MPEG 2
20 Mbps (peak
40 Mbps)
MPEG 4 ASP 10 Mbps max
H.264/AVC
[email protected]/4.0;
[email protected]/3.1/3.0
20 Mbps (peak
40 Mbps)
56 EN
.divxlesinAVIcontainer
Audio codec Video codec Bit rate
PCM, Dolby
Digital, MP3,
WMA
DivX 3.11,
DivX 4.x,
DivX 5.x,
DivX 6.x
10 Mbps max
MPEG 1,
MPEG 2
20 Mbps (peak
40 Mbps)
MPEG 4 ASP 10 Mbps max
.mp4or.m4vlesinMP4container
Audio codec Video codec Bit rate
Dolby Digital,
MPEG, MP3,
AAC, HE-
AAC
MPEG 1,
MPEG 2
20 Mbps (peak
40 Mbps)
MPEG 4 ASP 10 Mbps max
H.264/AVC
[email protected]/4.0;
[email protected]/3.1/3.0
20 Mbps (peak
40 Mbps)
.mkvlesinMKVcontainer
Audio codec Video codec Bit rate
PCM, Dolby
Digital, DTS
core, MPEG,
MP3, WMA,
AAC, HE-
AAC
MPEG 1,
MPEG 2
20 Mbps (peak
40 Mbps)
MPEG 4 ASP 10 Mbps max
H.264/AVC
[email protected]/4.0;
[email protected]/3.1/3.0
20 Mbps (peak
40 Mbps)
.mpgand.mpeglesinPScontainer
Audio codec Video codec Bit rate
PCM, DTS
core, MPEG,
MP3
MPEG 1,
MPEG 2
20 Mbps (peak
40 Mbps)
MPEG 1,
MPEG 2
20 Mbps (peak
40 Mbps)
Amplier
• FTC total output power: 70 W
• Front/rear speakers :
10 W (1%THD, 4ohm, 200Hz-20kHz)
• Center speaker : 5 W (1%THD, 4ohm,
200Hz-20kHz)
• Subwoofer: 25 W (1%THD, 4ohm,
40Hz-100Hz)
• RMS total output power:
300W RMS (30% THD)
• Frequency response: 20 Hz-20 kHz /
±3 dB
• Signal-to-noise ratio:
> 65 dB (CCIR) / (A-weighted)
• Input sensitivity:
• AUX: 2 V
• Music iLink: 1 V
Video
• Signal system: PAL / NTSC
• HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p24
Audio
• S/PDIF Digital audio input:
• Coaxial: IEC 60958-3
• Optical: TOSLINK
• Sampling frequency:
• MP3: 32 kHz, 44.1 kHz, 48 kHz
• WMA: 44.1 kHz, 48 kHz
• Constant bit rate:
• MP3: 32 kbps - 320 kbps
• WMA: 48 kbps - 192 kbps
57EN
Radio
• Tuning range: FM 87.5-108 MHz (100 kHz)
• Signal-to-noise ratio: FM 50 dB
• Frequency response:
FM 200 Hz-12.5 kHz / ±6 dB
USB
• Compatibility: Hi-Speed USB (2.0)
• Class support: USB Mass Storage Class
(MSC)
• File system: FAT16, FAT32, NTFS
• Maximum memory support: < 160 GB
Main unit
• Power supply: 120V~; 60Hz
• Power consumption: 60 W
• Standby power consumption: ≤ 0.9 W
• Dimensions (WxHxD):
360 x 58 x 325 mm
• Weight: 2.4 kg
Subwoofer
• Output power: 50 W RMS (30% THD)
• Impedance: 4 ohm
• Speaker drivers: 133 mm (5.25") woofer
• Dimensions (WxHxD):
160 x 265 x 265 mm
• Weight: 2.50 kg
Speakers
• Output power: 50 W RMS (30% THD)
• Speaker impedance: 4 ohm
• Speaker drivers: 1 x 70 mm (2.75") woofer
• Dimensions (WxHxD): 84.5 x 89 x 89 mm
• Weight: 0.25-0.29 kg/each
Remote control batteries
• 2 x AAA-R03-1.5 V
Laser
• Laser Type (Diode): InGaN/AIGaN (BD),
AIGaInP (DVD/CD)
• Wave length: 405 +7 nm/-7 nm (BD),
655 +10 nm/-10 nm (DVD),
790 +10 nm/-20 nm (CD)
• Output power (Max. ratings): 20 mW
(BD), 6 mW (DVD), 7 mW (CD)
58 EN
8 Troubleshooting
Troubleshooting
Warning
• Risk of electric shock. Never remove the casing of the
product.
To keep the warranty valid, never try to repair
the product yourself.
If you have problems using this product, check
the following points before you request
service. If you still have a problem, visit
www.philips.com/support.
Main unit
The buttons on the home theater do not
work.
• Disconnect the home theater from the
power supply for a few minutes, then
reconnect.
No picture.
• Make sure that the TV is switched to the
correct source for the home theater.
No picture on a TV connected through HDMI.
• Make sure that you use a High Speed
HDMI cable to connect the home theater
and TV. Some Standard HDMI cables do
not display properly for some images, 3D
video, or Deep Color.
• Make sure that the HDMI cable is not
faulty. If it is faulty, replace it with a new
cable.
• Press (Home) and then 731 on the
remote control to restore the default
picture resolution.
• Change the HDMI video setting, or wait
for 10 seconds for auto recovery (see
'Picture and video settings' on page 50).
Discdoesnotplayhigh-denitionvideo.
• Make sure that the disc contains high-
denition video.
• Make sure that the TV supports high-
denition video.
• Use an HDMI cable to connect to the TV.
Sound
No sound from home theater speakers.
• Connect the audio cable from your home
theater to your TV or other devices.
You do not need a separate audio
connection when the home theater and
TV are connected through an HDMI ARC
connection.
• Set up the audio for the connected device
(see 'Set up the audio' on page 40).
• Reset your home theater to its factory
settings (see 'Restore default settings' on
page 52), then switch it off and switch on
again.
• On your home theater, press SOURCE
repeatedly to select the correct audio
input.
Distorted sound or echo.
• If you play audio from the TV through the
home theater, make sure that the TV is
muted.
Audio and video are not synchronized.
• 1) Press SOUND SETTINGS.
2) Press the Navigation buttons (left/right)
to select AUD SYNC, and then press
OK.
3) Press the Navigation buttons (up/
down) to synchronize the audio with
the video.
Play
Cannot play a disc.
• Clean the disc.
• Make sure that the home theater supports
the type of disc (see 'Media formats' on
page 55).
59EN
• Make sure that the home theater supports
the region code of the disc.
• If the disc is a DVD±RW or DVD±R disc,
make sure that it is nalized.
CannotplayaDivXle.
• Make sure that the DivX le is encoded
according to the 'Home Theater Prole'
with the DivX encoder.
• Make sure that the DivX le is complete.
DivX subtitles do not display correctly.
• Make sure that the subtitle le name is
the same as the movie le name (see
'Subtitles' on page 44).
• Select the correct character set:
1) Press OPTIONS.
2) Select [Character set].
3) Select the supported character set.
4) Press OK.
Cannot read the contents of a USB storage
device.
• Make sure that the format of the USB
storage device is compatible with the
home theater.
• Make sure that the le system on the USB
storage device is supported by the home
theater.
'No entry' or 'x' sign appears on the TV.
• The operation is not possible.
EasyLink does not work.
• Make sure that the home theater is
connected to a Philips brand EasyLink TV,
and the EasyLink option is turned on (see
'Set up EasyLink (HDMI-CEC control)' on
page 39).
• For TVs from different manufacturers, the
HDMI CEC could be called differently.
Check theTV user manual on how to
enable it.
When you switch on the TV, the home theater
automatically switches on.
• This behavior is normal when you are using
Philips EasyLink (HDMI-CEC). To make the
home theater work independently, switch
off EasyLink.
Cannot access BD-Live features.
• Make sure that the home theater is
connected a home network with internet
access (see 'Connect and set up a home
network' on page 40).
• Make sure that the network is set up.
Use a wired network installation (see 'Set
up the wired network' on page 41) or
wireless network installation (see 'Set up
the wireless network' on page 41).
• Make sure that the Blu-ray disc supports
BD-Live features.
• Clear memory storage (see 'BD-Live on
Blu-ray' on page 43).
My 3D video played in 2D mode.
• Make sure that your home theater is
connected to a 3D TV through an HDMI
cable.
• Make sure that the disc is a Blu-ray 3D disc,
and the Blu-ray 3D video option is on (see
'Play Blu-ray 3D disc' on page 43).
TV screen is black when you play a Blu-ray 3D
video or a DivX copy protected video.
• Make sure that the home theater is
connected to the TV through an HDMI
cable.
• Switch to the correct HDMI source on
the TV.
Network
Wireless network distorted or not found.
• Make sure that the wireless network is
not disturbed by microwave ovens, DECT
phones, or other neighboring Wi-Fi devices.
• Place the wireless router and the home
theater within ve meters of each other.
• If the wireless network does not work
properly, try a wired network installation
(see 'Set up the wireless network' on page
41).
SlowvideostreamingfromNetixandVUDU.
• Look in your wireless router’s user manual
for information on indoor range, transfer
rate, and other factors of signal quality.
61EN
9 Notice
This section contains the legal and trademark
notices.
Copyright
This item incorporates copy protection
technology that is protected by U.S. patents
and other intellectual property rights of
Rovi Corporation. Reverse engineering and
disassembly are prohibited.
This product incorporates proprietary
technology under license from Verance
Corporation and is protected by U.S. Patent
7,369,677 and other U.S. and worldwide
patents issued and pending as well as copyright
and trade secret protection for certain aspects
of such technology. Cinavia is a trademark
of Verance Corporation. Copyright 2004-
2010 Verance Corporation. All rights reserved
by Verance. Reverse engineering or disassembly
is prohibited.
Cinavia notice
This product uses Cinavia technology to
limit the use of unauthorized copies of some
commercially-produced lm and videos and
their soundtracks. When a prohibited use of an
unauthorized copy is detected, a message will
be displayed and playback or copying will be
interrupted.
More information about Cinavia technology
is provided at the Cinavia Online Consumer
Information Center at http://www.cinavia.com.
To request additional information about Cinavia
by mail, send a postcard with your mailing
address to: Cinavia Consumer Information
Center, P.O. Box 86851, San Diego, CA, 92138,
USA.
Notice of compliance
The device complies with the FCC rules, Part
15 and with 21 CFR 1040.10.Operation is
subject to the following two conditions:
a This device may not cause harmful
interference, and
b This device must accept any interference
received, including interference that may
cause undesired operation.
FCC rules
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy
and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Relocate the receiving antenna.
• Increase the separation between
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
FCC Radiation Exposure Statement:This
equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated with a minimum distance of
20cm between the radiator and your body.
62 EN
This transmitter must not be co-located or
operated in conjunction with any other antenna
or transmitter.
Warning: Changes or modications made to
this equipment not expressly approved by
Philips may void the FCC authorization to
operate this equipment.
Model number: PHILIPS HTS3541/F7
Trade Name: Philips
Responsible Party:P&F USA, Inc. PO Box
2248 Alpharetta, GA 30023-2248; 1-866-310-
0744
Canada:
This device complies with Industry Canada
licence-exempt RSS standard(s). Operation is
subject to the following Two conditions: (1) this
device may not cause harmful interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
This Class B digital apparatus complies with
Canadian ICES-003.
Open source software
Philips Electronics Singapore Pte Ltd hereby
offers to deliver, upon request, a copy of the
complete corresponding source code for the
copyrighted open source software packages
used in this product for which such offer is
requested by the respective licenses. This offer
is valid up to three years after product purchase
to anyone in receipt of this information. To
obtain source code, please contact open.
[email protected]. If you prefer not to use
email or if you do not receive conrmation
receipt within a week after mailing to this email
address, please write to "Open Source Team,
Philips Intellectual Property & Standards, P.O.
Box 220, 5600 AE Eindhoven, The Netherlands".
If you do not receive timely conrmation
of your letter, please email to the email
address above. The texts of the licenses and
acknowledgements for open source software
used in this product are included on a separate
leaet.
Trademarks
"Blu-ray 3D
TM
" and "Blu-ray 3D
TM
" logo are
trademarks of Blu-ray Disc Association.
BONUSVIEW™
'BD LIVE' and 'BONUSVIEW' are trademarks
of Blu-ray Disc Association.
Java and all other Java trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and/or
other countries.
Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535;
7,392,195; 7,272,567; 7,333,929; 7,212,872
& other U.S. and worldwide patents issued
& pending. DTS-HD, the Symbol, & DTS-
HD and the Symbol together are registered
trademarks & DTS-HD Master Audio | Essential
is a trademark of DTS, Inc. Product includes
software. DTS, Inc. All Rights Reserved.
63EN
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
ABOUT DIVX VIDEO: DivX
®
is a digital video
format created by DivX, LLC, a subsidiary
of Rovi Corporation. This is an ofcial DivX
Certied
®
device that plays DivX video. Visit
divx.com for more information and software
tools to convert your les into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This
DivX Certied
®
device must be registered
in order to play purchased DivX Video-on-
Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section
in your device setup menu. Go to vod.divx.com
for more information on how to complete your
registration.
DivX Certied
®
to play DivX
®
and DivX Plus
®
HD (H.264/MKV) video up to 1080p HD
including premium content.
DivX
®
, DivX Certied
®
, DivX Plus
®
HD
and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used
under license.
HDMI, the HDMI logo, and High-Denition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing LLC in
the United States and other countries.
Netix and the Netix logo are trademarks or
registered trademarks of Netix, Inc.
VuduTM is a trademark of VUDU, Inc.
CLASS 1
LASER PRODUCT
64 EN
10 Index
2
2nd audio language 43
2nd subtitle language 43
3
3D disc in 2D mode 43
3D safety 32
3D video 43
5
5.1 speakers 36
A
advanced settings 51
amplier 56
audio connection (analog cable) 39
audio connection (coaxial cable) 38
audio connection (HDMI ARC) 37
audio connection (optical cable) 38
audio formats 55
audio from other devices 38
audio input mapping 40
audio language 50
audio options 45
audio post processing 51
audio settings 50
audio setup 40
auto standby 51
auto subtitle shift 51
B
batteries 57
BD-Live 43
Blu-ray 42
Bonus View 43
brightness 51
C
change password 51
character set 44
clear BD-Live memory 43
connect to TV 37
connectors 33
control buttons (disc) 42
control buttons (USB) 42
copyright protection 61
customer support 32
D
datales 44
deep color 50
default settings 52
disc language 50
disc menu 50
display panel 51
DivX 44
E
Easylink (HDMI-CEC) 39
eject disc 33
enhanced audio 51
F
factory settings 52
FAQs 32
leformats 55
H
HDMI ARC 37
HDMI audio 50
HDMI-CEC 39
home menu 42
home network 40
I
internet 40
65EN
M
main unit 33
manual setup 39
media formats 55
menu language 50
MP3 47
musical slideshows 46
N
Netix 47
network 40
night mode 50
O
one-touch play 40
one-touch standby 40
options 45
P
parental control 51
PBC (play back control) 51
picture options 46
picture resolution 50
picture settings 50
picture-in-picture 43
play disc 42
play music 47
play radio 46
play USB storage device 45
power settings 51
predenedsoundmode 48
preference 50
program radio stations 46
R
radio 46
region codes 55
remote control 34
repeat 45
S
shufe 45
sleep timer 51
slide animation 46
software update 53
software version 53
sound 48
speaker position 36
speaker setup 39
speakerspecications 55
subtitle language 50
subtitle position 51
surround sound 49
synchronize picture and sound 43
system audio control 40
T
troubleshooting (network) 59
troubleshooting (picture) 58
troubleshooting (play) 58
troubleshooting (sound) 58
tune radio stations 46
U
update software (through Internet) 54
update software (through USB) 53
USB storage device 45
user manual 32
V
VCD 51
video connection (composite video) 38
video connection (HDMI ARC) 37
video connection (standard HDMI) 37
video formats 56
video options 45
video settings 50
VOD code (DivX) 45
VUDU 48
67
P&F USA Inc. PO Box 2248 Alpharetta, GA 30023-2248
ONE (1) YEAR LIMITED WARRANTY
WARRANTY COVERAGE:
This warranty obligation is limited to the terms set forth
below.
WHO IS COVERED:
This product is warranted to the original purchaser or the per-
son receiving the product as a gift against defects in materials and
workmanship as based on the date of original purchase
(“Warranty Period”) from an Authorized Dealer. The original
sales receipt showing the product name and the purchase date
from an authorized retailer is considered such proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material
or workmanship occurs and a valid claim is received within
the Warranty Period. At its option, the company will either (1)
repair the product at no charge, using new or refurbished
replacement parts, or (2) exchange the product with a product
that is new or which has been manufactured from new, or ser-
viceable used parts and is at least functionally equivalent or most
comparable to the original product in current inventory,
or (3) refund the original purchase price of the product.
The company warrants replacement products or parts provided
under this warranty against defects in materials and workmanship
from the date of the replacement or repair for ninety (90) days
or for the remaining portion of the original product’s warranty,
whichever provides longer coverage for you. When a product or
part is exchanged, any replacement item becomes your property
and the replaced item becomes the company property. When a
refund is given, your product becomes the company property.
Note: Any product sold and identified as refurbished or
renewed carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty
requirements are met. Failure to follow all requirements
can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMI-
TATIONS:
This Limited Warranty applies only to the new products that
can be identified by the trademark, trade name, or logo affixed
to it. This Limited Warranty does not apply to any non-Philips
hardware product or any software, even if packaged or sold
with the product. Non-Philips manufacturers, suppliers, or
publishers may provide a separate warranty for their own
products packaged with the bundled product.
The company is not liable for any damage to or loss of any ,
programs data, or other information stored on any media
contained within the product, or any non-Philips product or part
not covered by this warranty. Recovery or reinstallation of
programs, data or other information is not covered under this
Limited Warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-Philips product, (b)
to damage caused by service performed by anyone other than
an Authorized Service Location, (c) to a product or
a part that has been modified without written permission,
or (d) if any serial number has been removed or defaced,
or (e) product, accessories or consumables sold “AS IS”
without warranty of any kind by including refurbished Philips
product sold “AS IS” by some retailers.
This Limited Warranty does not cover:
• Shipping charges to return defective product.
• Labor charges for installation or setup of the product, adjust-
ment of customer controls on the product, and installation or
repair of antenna/signal source systems outside of the product.
• Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images or
screen markings resulting from viewing fixed stationary con-
tent for extended periods, product cosmetic appearance items
due to normal wear and tear, unauthorized repair or other
cause not within the control of the company.
• Damage or claims for products not being available for use, or
for lost data or lost software.
• Damage from mishandled shipments or transit accidents when
returning product.
• A product that requires modification or adaptation to enable
it to operate in any country other than the country for which
it was designed, manufactured, approved and/or authorized, or
repair of products damaged by these modifications.
• A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operate per Owner’s Manual.
TO OBTAIN ASSISTANCE IN THE U.S.A., CANADA,
PUERTO RICO, OR U.S. VIRGIN ISLANDS…
Contact Customer Care Center at:
1-866-310-0744
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CON-
SUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDEN-
TAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PROD-
UCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY.
Some states do not allow the exclusions or limitation of inciden-
tal or consequential damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or exclusions may
not apply to you.
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
Specifications are subject to change without notice
© 2014 Koninklijke Philips N.V. All rights reserved.
Trademarks are the property of Koninklijke Philips N.V. or their respective owners.
HTS3541_F7_M2_UM_V1.0
P&F USA, Inc.
PO Box 2248 Alpharetta, GA 30023-2248
